IEI Integration AFL-LX User Manual

IEI Technology Corp.
User Manual
AFOLUX LX Series Flat Panel PC
AFOLUX LX Series Flat Panel PC
MODEL:
AFL LX Series
TFT LCD, Wireless LAN, Bluetooth, Touch Screen,
RS-232/422/485 and IP 64 Protection
Rev. 2.01 – 14 February, 2012
Page 1
AFOLUX LX Series Flat Panel PC

Revision

Date Version Changes
14 February, 2012 2.01 Added Section 3.10: Power-up the System
28 October, 2010 2.00 Updated for R20 version
30 September, 2009 1.21 Added screw torque warning
13 April, 2009 1.20 Added AFL-xxA-LX-R12 and AFL-xxA-LX24V-R11 models
information
October, 2007
August, 2007
January, 2007
1.11 Added new model (AFL-10A-LX) information
1.10
1.00
- Added Bluetooth module specifications
- Added AT/ATX mode selection description
- Modified jum per settings information
- Added Watchdog Timer appendix Initial release
Page 2
AFOLUX LX Series Flat Panel PC
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are

Copyright

reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
Page 3
AFOLUX LX Series Flat Panel PC

Table of Contents

1 INTRODUCTION.........................................................................................................11
1.1 AFOLUX LX SERIES FLAT PANEL PC OVERVIEW ................................................... 12
1.1.1 Model Variations.............................................................................................. 12
1.1.2 Applications ..................................................................................................... 13
1.1.3 Standard Features............................................................................................ 14
1.2 EXTERNAL OVERVIEW.............................................................................................. 14
1.2.1 General Description......................................................................................... 14
1.2.2 Front Panel...................................................................................................... 14
1.2.3 Rear Panel ....................................................................................................... 15
1.2.4 Top Panel and Side Panels............................................................................... 15
1.2.5 Bottom Panel.................................................................................................... 16
1.3 INTERNAL OVERVIEW............................................................................................... 17
1.4 SPECIFICATIONS ....................................................................................................... 17
1.4.1 Preinstalled Hardware Components................................................................ 17
1.4.2 System Specifications....................................................................................... 18
1.4.3 Motherboard Specifications............................................................................. 19
1.4.4 Flat Panel Screen Specifications..................................................................... 20
1.4.5 Touch Screen Specifications............................................................................. 21
1.4.6 Bluetooth Module Specifications ..................................................................... 21
1.5 DIMENSIONS............................................................................................................. 23
1.5.1 AFL-07A-LX Dimensions................................................................................. 23
1.5.2 AFL-08AH-LX Dimensions.............................................................................. 24
1.5.3 AFL-10A-LX Dimensions................................................................................. 25
1.5.4 AFL-12A-LX Dimensions................................................................................. 26
2 MOTHERBOARD....................................................................................................... 27
2.1 INTRODUCTION......................................................................................................... 28
2.2 CPU SUPPORT.......................................................................................................... 28
2.2.1 AMD® Geode™ LX 800 500MHz Specifications............................................. 28
2.2.2 AMD® Geode™ LX 800 500MHz Power Management................................... 29
Page 4
AFOLUX LX Series Flat Panel PC
2.3 SYSTEM CHIPSET...................................................................................................... 29
2.4 GRAPHICS SUPPORT.................................................................................................. 30
2.5 ETHERNET CONTROLLER SPECIFICATIONS................................................................ 32
2.5.1 Overview.......................................................................................................... 32
2.5.2 Features ........................................................................................................... 32
2.6 PERIPHERAL DEVICE INTERFACES, CONNECTORS, AND SLOTS ................................. 33
2.6.1 OEM Options................................................................................................... 33
2.6.2 Internal Slots.................................................................................................... 33
2.6.3 Internal Peripheral Device Connectors........................................................... 33
2.6.4 External Peripheral Device Connectors.......................................................... 34
3 INSTALLATION ......................................................................................................... 35
3.1 INSTALLATION PRECAUTIONS ................................................................................... 36
3.2 PREINSTALLED COMPONENTS................................................................................... 36
3.3 INSTALLATION AND CONFIGURATION STEPS ............................................................. 37
3.4 UNPACKING .............................................................................................................. 37
3.4.1 Packing List ..................................................................................................... 38
3.5 CF CARD INSTALLATION .......................................................................................... 39
3.6 HDD INSTALLATION (AF-12A-LX ONLY) ............................................................... 41
3.7 AT/ AT X MODE SELECTION...................................................................................... 43
3.7.1 AT Power Mode................................................................................................ 43
3.7.2 ATX Power Mode............................................................................................. 44
3.8 MOUNTING THE SYSTEM .......................................................................................... 44
3.8.1 Wall Mounting.................................................................................................. 44
3.8.2 Panel Mounting................................................................................................ 47
3.8.3 Arm Mounting .................................................................................................. 50
3.8.4 Cabinet and Rack Installation ......................................................................... 52
3.9 BOTTOM PANEL CONNECTORS ................................................................................. 54
3.9.1 LAN Connection............................................................................................... 54
3.9.2 Serial Device Connection ................................................................................ 55
3.9.3 USB Device Connection................................................................................... 56
3.10 POWER-UP THE SYSTEM ......................................................................................... 57
4 SYSTEM MAINTENANCE ....................................................................................... 58
4.1 SYSTEM MAINTENANCE INTRODUCTION .................................................................. 59
Page 5
4.2 MOTHERBOARD REPLACEMENT ............................................................................... 59
4.3 INTERNAL ALUMINUM COVER REMOVAL ................................................................. 59
4.3.1 AFL-07A-LX Internal Aluminum Cover Removal............................................ 60
4.3.2 AFL-08AH-LX Internal Aluminum Cover Removal......................................... 61
4.3.3 AFL-10A-LX Internal Aluminum Cover Removal............................................ 62
4.3.4 AFL-12A-LX Internal Aluminum Cover Removal............................................ 63
4.4 MEMORY MODULE REPLACEMENT........................................................................... 64
4.5 JUMPER SETTINGS .................................................................................................... 66
4.5.1 JP3: COM3 Pin-9 Signal Select Jumper Settings............................................ 67
4.5.2 JP4: COM1 and COM2 Pin-9 Signal Select Jumper Settings......................... 68
4.5.3 JP5: COM2 Mode Select Jumper Settings....................................................... 68
4.5.4 JP6: COM2 Mode Select Jumper Settings....................................................... 69
4.5.4.1 COM2 RS-422 and RS-485 Pinouts ......................................................... 69
5 AWARD BIOS SETUP................................................................................................. 70
AFOLUX LX Series Flat Panel PC
5.1 INTRODUCTION......................................................................................................... 71
5.1.1 Starting Setup................................................................................................... 71
5.1.2 Using Setup...................................................................................................... 71
5.1.3 Getting Help..................................................................................................... 72
5.1.4 Main BIOS Menu ............................................................................................. 72
5.2 STANDARD CMOS FEATURES .................................................................................. 74
5.2.1 IDE Primary Master/Slave .............................................................................. 77
5.3 ADVANCED BIOS FEATURES .................................................................................... 79
5.4 ADVANCED CHIPSET FEATURES ................................................................................ 84
5.5 INTEGRATED PERIPHERALS....................................................................................... 86
5.6 POWER MANAGEMENT SETUP .................................................................................. 90
5.7 PNP/PCI CONFIGURATIONS ...................................................................................... 96
5.8 PC HEALTH STATUS ................................................................................................. 99
A SAFETY PRECAUTIONS....................................................................................... 101
A.1 SAFETY PRECAUTIONS .......................................................................................... 102
A.1.1 General Safety Precautions........................................................................... 102
A.1.2 Anti-static Precautions.................................................................................. 103
A.1.3 Product Disposal........................................................................................... 104
A.2 MAINTENANCE AND CLEANING PRECAUTIONS ...................................................... 104
Page 6
AFOLUX LX Series Flat Panel PC
A.2.1 Maintenance and Cleaning............................................................................ 104
A.2.2 Cleaning Tools............................................................................................... 105
B BIOS CONFIGURATION OPTIONS..................................................................... 106
B.1 BIOS CONFIGURATION OPTIONS ........................................................................... 107
C SOFTWARE DRIVERS ............................................................................................110
C.1 REMOTE MANAGEMENT TOOL................................................................................111
C.2 TOUCH PANEL DRIVER............................................................................................111
C.2.1 Introduction....................................................................................................111
C.2.2 Driver Installation..........................................................................................112
C.2.3 Touch Panel Driver Configuration.................................................................115
D WATCHDOG TIMER ...............................................................................................116
E HAZARDOUS MATERIALS DISCLOSURE ........................................................119
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 120
Page 7
AFOLUX LX Series Flat Panel PC
List of Figures
Figure 1-1: Front View..................................................................................................................15
Figure 1-2: AFL-07A-LX/AFL-08AH-LX Rear View.....................................................................15
Figure 1-3: AFL-08AH-LX Top View............................................................................................16
Figure 1-4: AFL-08AH-LX Side View...........................................................................................16
Figure 1-5: AFOLUX LX Series Bottom View.............................................................................17
Figure 1-6: AFL-07A-LX Dimensions (units in mm) ..................................................................23
Figure 1-7: AFL-08AH-LX Dimensions (units in mm)................................................................24
Figure 1-8: AFL-10A-LX Dimensions (units in mm) ..................................................................25
Figure 1-9: AFL-12A-LX Dimensions (units in mm) ..................................................................26
Figure 2-1: AFLMB-LX800 Connector Overview........................................................................34
Figure 3-1: Back Cover Retention Screws.................................................................................39
Figure 3-2: AFL-08AH-LX Plastic Back Cover Removal ...........................................................40
Figure 3-3: CF Card Location......................................................................................................40
Figure 3-4: AFL-08AH-LX Plastic Back Cover Replacement....................................................40
Figure 3-5: AFL-12A-LX Aluminum Back Cover Retention Screws.........................................41
Figure 3-6: Four Hexagonal Pillars on the Bottom Panel.........................................................41
Figure 3-7: AFL-12A-LX HDD Bracket Retention Screws.........................................................42
Figure 3-8: AF-12A-LX HDD Retention Screws..........................................................................42
Figure 3-9: AT/ATX Switch Location...........................................................................................43
Figure 3-10: Wall-mounting Bracket...........................................................................................45
Figure 3-11: Chassis Support Screws........................................................................................46
Figure 3-12: Secure the Panel PC...............................................................................................47
Figure 3-13: AFL-07A-LX Panel Opening ...................................................................................48
Figure 3-14: AFL-08AH-LX Panel Opening.................................................................................48
Figure 3-15: AFL-10A-LX Panel Opening ...................................................................................48
Figure 3-16: AFL-12A-LX Panel Opening ...................................................................................49
Figure 3-17: Tighten the Panel Mounting Clamp Screws (AFL-10A/12A-LX) .........................50
Figure 3-18: AFL-07A-LX/AFL-08AH-LX Arm Mounting Retention Screw Holes....................51
Figure 3-19: AFL-10A-LX/AFL-12A-LX Arm Mounting Retention Screw Holes......................51
Figure 3-20: The Rack/Cabinet Bracket......................................................................................52
Figure 3-21: Secure the Rack/Cabinet Bracket (AFL-10A-LX/AFL-12A-LX)............................53
Page 8
AFOLUX LX Series Flat Panel PC
Figure 3-22: Install into a Rack/Cabinet .....................................................................................54
Figure 3-23: LAN Connection......................................................................................................54
Figure 3-24: Serial Device Connector.........................................................................................55
Figure 3-25: USB Device Connection.........................................................................................56
Figure 3-26: Power Connector and Power Button ....................................................................57
Figure 4-1: AFL-07A-LX Aluminum Back Cover Retention Screws.........................................60
Figure 4-2: Four Hexagonal Pillars on the Bottom Panel (AFL-07A-LX).................................60
Figure 4-3: AFL-08AH-LX Aluminum Back Cover Retention Screws......................................61
Figure 4-4: Four Hexagonal Pillars on the Bottom Panel (AFL-08AH-LX)..............................61
Figure 4-5: Wireless Module Cables...........................................................................................62
Figure 4-6: The Internal Aluminum Cover Removal..................................................................62
Figure 4-7: Power Switch Cable..................................................................................................62
Figure 4-8: AFL-10A-LX Aluminum Back Cover Retention Screws.........................................63
Figure 4-9: Four Hexagonal Pillars on the Bottom Panel (AFL-10A-LX).................................63
Figure 4-10: AFL-12A-LX Aluminum Back Cover Retention Screws.......................................64
Figure 4-11: Four Hexagonal Pillars on the Bottom Panel (AFL-12A-LX)...............................64
Figure 4-12: SO-DIMM Socket Location .....................................................................................65
Figure 4-13: DDR SO-DIMM Module Installation........................................................................65
Figure 4-14: Jumper Locations...................................................................................................67
Page 9
AFOLUX LX Series Flat Panel PC
List of Tables
Table 1-1: Model Variations.........................................................................................................13
Table 1-2: AFOLUX LX Series System Specifications..............................................................19
Table 1-3: Motherboard Specifications ......................................................................................20
Table 1-4: TFT LCD Monitor Specifications...............................................................................20
Table 1-5: Touch Panel Specifications.......................................................................................21
Table 1-6: Bluetooth Module Specifications..............................................................................22
Table 2-1: Geode LX Graphics Features ....................................................................................31
Table 4-1: COM3 Pin-9 Signal Select Jumper Settings.............................................................67
Table 4-2: COM1 and COM2 Pin-9 Signal Select Jumper Settings..........................................68
Table 4-3: COM2 Mode Select Jumper Settings........................................................................68
Table 4-4: COM2 Mode Select Jumper Settings........................................................................69
Table 4-5: RS-422 Pinouts ...........................................................................................................69
Table 4-6: RS-485 Pinouts ...........................................................................................................69
Table 5-1: BIOS Navigation Keys................................................................................................72
Page 10
AFOLUX LX Series Flat Panel PC
Chapter
1

1 Introduction

Page 11
AFOLUX LX Series Flat Panel PC

1.1 AFOLUX LX Series Flat Panel PC Overview

The AFOLUX LX series flat panel PC is a flexible, multi-functional and fanless flat panel
PC that can be applied in diverse operational environments and implemented in
multi-faceted applications. The AFOLUX LX series comes fully kitted with a
high-performance motherboard and a host of other peripheral interface connectors. The
integrated wireless LAN module and Bluetooth module ensure an uninterrupted wireless
connection. The flexible AT/ATX power mode selection allows the AFOLUX series to meet
multiple application requirements. The AFOLUX LX series is designed for ease of use and
easy installation.

1.1.1 Model Variations

The model variations of AFOLUX LX series are listed in 4Table 1-1. The AFOLUX LX
series all comes with a touch screen and an 802.11b/g wireless module.
AFL-07A Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 400cd/m
-LX/R/512-R20 400cd/m
-LX24V/R/256-R20 400cd/m
-LX24V/R/512-R20 400cd/m
2
7” 256MB DDR 12 V DC No
2
7” 512MB DDR 12 V DC No
2
7” 256MB DDR 18~30 V DC No
2
7” 512MB DDR 18~30 V DC No
AFL-08AH Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 450cd/m
-LX/R/512-R20 450cd/m
-LX24V/R/256-R20 450cd/m
-LX24V/R/512-R20 450cd/m
2
8.4” 256MB DDR 12 V DC No
2
8.4” 512MB DDR 12 V DC No
2
8.4” 256MB DDR 18~30 V DC No
2
8.4” 512MB DDR 18~30 V DC No
AFL-10A Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 400cd/m
-LX/RH/256-R20 400cd/m
-LX/R/512-R20 400cd/m
-LX/RH/512-R20 400cd/m
-LX24V/R/256-R20 400cd/m
-LX24V/RH/256-R20 400cd/m
-LX24V/R/512-R20 400cd/m
-LX24V/RH/512-R20 400cd/m
2
10.4” 256MB DDR 12 V DC No
2
10.4” 256MB DDR 12 V DC Yes
2
10.4” 512MB DDR 12 V DC No
2
10.4” 512MB DDR 12 V DC Yes
2
10.4” 256MB DDR 18~30 V DC No
2
10.4” 256MB DDR 18~30 V DC Yes
2
10.4” 512MB DDR 18~30 V DC No
2
10.4” 512MB DDR 18~30 V DC Yes
Page 12
AFOLUX LX Series Flat Panel PC
AFL-12A Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 500cd/m
-LX/RH/256-R20 500cd/m
-LX/R/512-R20 500cd/m
-LX/RH/512-R20 500cd/m
-LX24V/R/256-R20 500cd/m
-LX24V/RH/256-R20 500cd/m
-LX24V/R/512-R20 500cd/m
-LX24V/RH/512-R20 500cd/m
2
12.1” 256MB DDR 12 V DC No
2
12.1” 256MB DDR 12 V DC Yes
2
12.1” 512MB DDR 12 V DC No
2
12.1” 512MB DDR 12 V DC Yes
2
12.1” 256MB DDR 18~30 V DC No
2
12.1” 256MB DDR 18~30 V DC Yes
2
12.1” 512MB DDR 18~30 V DC No
2
12.1” 512MB DDR 18~30 V DC Yes
Table 1-1: Model Variations

1.1.2 Applications

The AFOLUX LX series all-in-one panel PC is designed for multiple applications. Its
durability and strength makes it an ideal choice for public access computers. Some
possible applications include:
Vehicle Interior device
o Truck PC o Logistic car PC
General computing
o PC based testing center o Distance learning
Industrial applications
o Plant environment monitoring system o Factory automation platform o Manufacturing shop flow o Equipment and device control
Home and building automation
o Digital surveillance system o E-home platform o Home IA control terminal
Self-Service Kiosk
o Receptionist kiosk in hotel and business premises o Self registration terminal in hospital and airport
Page 13
o Ticket vending machine for transportation use

1.1.3 Standard Features

Some of the standard features of the AFOLUX LX series flat panel PC include:
Fanless Design
AMD® Geode LX-800 processor
Rugged mechanism design with ABS/PC case
IP 64 dustproof and waterproof front panel
One 256MB/512MB DDR memory module pre-installed
AT/ATX power mode supported
Wireless LAN integrated with PIFA antenna
Dual 10/100Mbps Ethernet support
One CompactFlash
AFOLUX LX Series Flat Panel PC
®
Type II socket support
Simplified installation process
RoHS compliance

1.2 External Overview

1.2.1 General Description

The AFOLUX LX series is a stylish flat panel PC that comprises of a screen, rear panel,
top panel, bottom panel and two side panels (left and right). An ABS/PC plastic front frame
surrounds the front screen. The rear panel provides screw holes for a wall-mounting
bracket compliant with VESA FDMI standard. The bottom panel provides access to
external interface connectors that include LAN, USB 2.0, serial port, reset button, power
connector and power switch.

1.2.2 Front Panel

The front side of the AFOLUX LX series is a flat panel TFT LCD screen with LED backlight
surrounded by an ABS/PC plastic frame.
Page 14
AFOLUX LX Series Flat Panel PC
Figure 1-1: Front View

1.2.3 Rear Panel

The rear panel provides access to retention screw holes that support the wall mounting.
Refer to
4Figure 1-2.
Figure 1-2: AFL-07A-LX/AFL-08AH-LX Rear View

1.2.4 Top Panel and Side Panels

The top panel and side panels of AFOLUX LX series provides access to slots that support
panel mount and rack mount (
4Figure 1-3 and 4Figure 1-4).
Page 15
AFOLUX LX Series Flat Panel PC
Figure 1-3: AFL-08AH-LX Top View
Figure 1-4: AFL-08AH-LX Side View

1.2.5 Bottom Panel

The bottom panel of the AFOLUX LX series has the following I/O interfaces (4Figure 1-5):
1 x Audio jack
1 x RS-232 serial port connector
1 x RS-232 or RS-422/485 serial port connector (selected by a jumper)
1 x Power connector
2 x RJ-45 10/100Mbps Ethernet connectors
2 x USB 2.0 connectors
1 x Power switch
1 x Reset button
Page 16
AFOLUX LX Series Flat Panel PC
Figure 1-5: AFOLUX LX Series Bottom View

1.3 Internal Overview

The AFOLUX LX series internal components are protected in a plastic back cover. An
AT/ATX switch is in the left side of the aluminum chassis inside the plastic cover. Other
internal components, the motherboard, wireless LAN module and DDR memory module,
are installed in the aluminum chassis on a metal sheet that protects the rear of the TFT
LCD screen. Below the metal sheet is a circuit board that is connected to the screen and
the motherboard.

1.4 Specifications

1.4.1 Preinstalled Hardware Components

The AFOLUX LX series flat panel PC has the following preinstalled components:
1 x Motherboard
1 x TFT LCD screen
1 x Touch screen
1 x Inverter
1 x Wireless LAN module
1 x DDR memory module
1 x Bluetooth module
1 x AT/ATX switch
1 x HSUPA module (optional)
Page 17
AFOLUX LX Series Flat Panel PC
The technical specifications for some of these components and the system are shown in
the sections below.

1.4.2 System Specifications

The technical specifications for the AFOLUX LX series systems are listed in 4Table 1-2.
SPECIFICATION AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX Front Panel ABS/PC plastic front panel Chassis Aluminum chassis LCD Panel 7” 8.4” 10.4” 12.1” Resolution 800 x 480 800 x 600 800 x 600 1024 x 768 Brightness 400cd/m Contrast Ratio 400:1 600:1 700:1 700:1 Viewing Angle (H-V) 140/110 160/140 160/140 160/160
2
450cd/m2 400cd/m2 500cd/m2
RGB Bit 6-bit 6-bit 6-bit 6-bit Backlight LED backlight LED backlight LED backlight LED backlight Touch Screen 4-wire resistive type Extension 1 x Mini PCI (for wireless LAN module)
1 x Bluetooth module (USB interface, Bluetooth v2.0)
Drive Bay N/A N/A N/A HSUPA Module N/A N/A Optional SSD CompactFlash Audio AMP 1.5W + AMP 1.5W (internal speaker) I/O 1 x Audio jack
1 x RS-232 serial port
1 x RS-232 or RS-422/485 serial port
2 x 10/100 Mbps Ethernet port
2 x USB 2.0 port
1 x Power switch
1 x Reset button
®
4-wire resistive type 5-wire resistive type 5-wire resistive type
1 x 2.5” HDD bay or
optional HSUPA module
Type II
1 x AT/ATX power switch (internal)
Power AFL-xxA-LX Series: 12 V DC input (36W DC power adapter)
AFL-xxA-LX24V Series: 18~30 V DC input
Power Consumption 20W 20W 25W 29W
Page 18
AFOLUX LX Series Flat Panel PC
SPECIFICATION AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX Mounting Feature Panel, Rack, Wall, Arm, Stand Operating Temperature
Relative Humidity 5% ~ 80% RH, non-condensing Vibration 5 - 17Hz, 0.1” double amplitude displacement.
Shock 10G Acceleration, peak to peak (11ms) Dimension (W x H x D) 226 x 140 x 41 234 x 184 x 42 276 x 227 x 50.7 304 x 246 x 50 Net/Gross Weight 0.6 Kg 0.8 Kg 1.4kg 1.8 Kg Front Panel Protection IP 64 compliant Safety Meets UL / CE / CCC EMC Meets CE / FCC class B
0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC-50ºC
0ºC-40ºC (using HDD)
17 - 640Hz, 1.5G acceleration, peak to peak.
Table 1-2: AFOLUX LX Series System Specifications

1.4.3 Motherboard Specifications

The AFOLUX LX series come with an AFLMB-LX800 motherboard. The technical
specifications of the motherboard are listed in
4Table 1-3.
Specification AFLMB-LX800 CPU AMD Southbridge Chipset AMD Display CRT integrated in AMD
Memory Supports one 1GB DDR 333/400 200-pin SO-DIMM SDRAM module Extension One mini PCI slot BIOS Award BIOS SSD CF Type II Super I/O N/A for legacy free Audio AC'97 Codec Realtek ALC203, AMP 2W LAN 10/100 Base-T dual RTL8100C COM 1 x RS-232 serial port
®
Geode™ LX 800 500Mhz
®
Geode™ CS5536
®
Geode™ LX800
®
24-bit TTL integrated in AMD
18-bit LVDS supported by buffer
Geode™ LX800
Page 19
1 x RS-232 or RS-422/485 serial port
IDE One 44-pin IDE connects to two IDE devices Touch Screen Controller DMC9000 Power Supply DC 12V In Dimensions 102mm x 186mm
AFOLUX LX Series Flat Panel PC
Table 1-3: Motherboard Specifications

1.4.4 Flat Panel Screen Specifications

The AFOLUX LX series come with a TFT LCD monitor with LED backlight. The
specifications for the LCD monitor are shown in
Specification AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX Size 7” 8.4” 10.4” 12.1” Resolution 800 x 480 (WVGA) 800 x 600 (SVGA) 800 x 600 (SVGA) 1024 x 768 (XGA) Pixel Pitch (mm) 0.0635 x 0.1905 0.213 x 0.213 0.264 x 0.264 0.3075 x 0.3075 LCD Color 262K colors 262K colors 262K colors 262K colors View Angel (H/V) 140/110 160/140 160/140 160/160 Brightness (cd/m2) 400 450 400 500 Contrast Ratio 400:1 600:1 700:1 700:1 RGB Bit 6-bit 6-bit 6-bit 6-bit Backlight LED LED LED LED
4Table 1-4 below.
Table 1-4: TFT LCD Monitor Specifications
Page 20
AFOLUX LX Series Flat Panel PC

1.4.5 Touch Screen Specifications

The AFOLUX LX series come with an analog resistive type touch panel. 4Table 1-5 lists the
touch panel specifications.
Specification AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX
Model PANJIT 1070404C PANJIT 1084403B PANJIT 1104502A PANJIT 1121505B
Type Analog Resistive Type Touch Panel
Wire Type 4-wire 4-wire 5-wire 5-wire
Viewing Area (mm) 154.90 x 93.94 130.75 x 173.38 219.8 x 166.8 188.0 x 250.0
Active Area (mm) 152.40 x 91.44 127.78 x 170.38 212.1 x 159.3 185.0 x 246.0
Total Transmission 78%
Maximum Voltage DC7V
Connector Type FPC.
Operating Temperature -10°C ~ 60°C -10°C ~ 40°C
Operating Humidity 20% ~ 90% RH
Storage Temperature -20°C ~ 70°C
Storage Humidity 20% ~ 90% RH
Dimensions 165 x 104 x 1.4 145.5 x 188 x 2.1 238.8x 188.7 x 2.6 204 x 268 x 2.1
Table 1-5: Touch Panel Specifications

1.4.6 Bluetooth Module Specifications

The AFOLUX LX series are all integrated with a Bluetooth module. The Bluetooth module
enables the transmission between various peripheral devices through a Bluetooth network.
The peripheral devices may include:
Headsets
Barcode readers
PDA
Printers
Cell phones
Keyboard and mouse
Page 21
AFOLUX LX Series Flat Panel PC
The technical specifications of the Bluetooth module are listed in 4Table 1-6.
Specification Bluetooth Module Standard Bluetooth v2.0 Frequency Band 2.402GHz~2.480GHz unlicensed ISM band Modulation Method GFSK for 1Mbps
π/4-DQPSK for 2Mbps
8-DPSK for 3Mbps
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum) RF Output Power Class 2 (under 4dBm) Antenna Terminal 50 Ohms DC Power DC 3.3V or DC 5V I/O Interface USB 2.0 interface Two GPIO Interface LED link indicator interface Dimensions 35mm x 11mm Operating System Windows XP, Windows 2000, Windows 98SE, Windows Me
Table 1-6: Bluetooth Module Specifications
Page 22
AFOLUX LX Series Flat Panel PC

1.5 Dimensions

1.5.1 AFL-07A-LX Dimensions

The dimensions of the AFL-07A-LX flat panel PC are shown in 4Figure 1-6 below.
Figure 1-6: AFL-07A-LX Dimensions (units in mm)
Page 23

1.5.2 AFL-08AH-LX Dimensions

The dimensions of the AFL-08AH-LX flat panel PC are shown in 4Figure 1-7 below.
AFOLUX LX Series Flat Panel PC
Figure 1-7: AFL-08AH-LX Dimensions (units in mm)
Page 24
AFOLUX LX Series Flat Panel PC

1.5.3 AFL-10A-LX Dimensions

The dimensions of the AFL-10A-LX flat panel PC are shown in 4Figure 1-7 below.
Figure 1-8: AFL-10A-LX Dimensions (units in mm)
Page 25

1.5.4 AFL-12A-LX Dimensions

The dimensions of the AFL-12A-LX flat panel PC are shown in 4Figure 1-7 below.
AFOLUX LX Series Flat Panel PC
Figure 1-9: AFL-12A-LX Dimensions (units in mm)
Page 26
AFOLUX LX Series Flat Panel PC
Chapter
2

2 Motherboard

Page 27
AFOLUX LX Series Flat Panel PC

2.1 Introduction

The AFOLUX LX series flat screen PC contains the AFLMB-LX800 motherboard. The
motherboard is the heart of any computer and is responsible for transmitting, receiving
and processing data as well as driving the different onboard devices. This chapter gives a
brief introduction to the AFLMB-LX800 motherboard.

2.2 CPU Support

The AFLMB-LX800 motherboard comes with a preinstalled AMD® Geode™ LX 800
500MHz CPU.
2.2.1 AMD® Geode™ LX 800 500MHz Specifications
The specifications for the 500MHz AMD® Geode™ LX 800 are listed below
x86/x87-compatible core
Processor frequency up to 500 MHZ
64K I/64K D L1 cache and 128K L2 cache
Split I/D cache/TLB (Translation Look-Aside Buffer)
64-bit DDR Memory interface up to 400MHz (LX 800), up to 333MHz (LX 700)
Integrated FPU that supports the Intel MMX
instruction sets
9 GB/s internal GeodeLink™ Interface Unit (GLIU)
Security Block
®
and AMD 3DNow!™ Technology
o 128-bit AES (CBC/ECB) o True Random Number Generator
High-resolution CRT and TFT outputs (simultaneous operation)
o Support for High Definition (HD) and Standard Definition (SD) standards o Support 1920x1440 in CRT mode and 1600x1200 in TFT mode
VESA 1.1 and 2.0 VIP/VDA support
0.13 micron process
481-terminal PBGA (Plastic Ball Grid Array) with internal heatspreader
Page 28
AFOLUX LX Series Flat Panel PC
2.2.2 AMD® Geode™ LX 800 500MHz Power Management
The power management for the 500MHz AMD® Geode™ LX 800 is listed below:
1.8W Typical (3.9W TDP) @ 500MHz
GeodeLink active hardware power management
Hardware support for standard ACPI software power management
I/O companion SUSP#/SUSPA# power controls
Lower power I/O
Wakeup on SMI/INTR

2.3 System Chipset

The AFLMB-LX800 motherboardl has a preinstalled AMD® Geode™ CS5536 system
chipset. The system chipset features are listed below.
GeodeLink ™ Interface Unit
o 64-bit, 66MHz operation o PCI VSM (Virtual System Module) that makes the interface transparent to
applications software and BIOS
o Programmable routing descriptors, use and activity monitors, and SSMI
(Synchronous System Management Interrupt)
ATA-6 Controller
o 100 MB/second IDE Controller in UDMA mode per the ATA-6
specification
o 5V interface
Flash Interfa ce
o Multiplexed with IDE interface Connects to an array of industry standard
NAND Flash and/or NOR Flash
USB Cont roller
o 4 USB ports (two internal and two external) o Supports both USB 1.1 and USB 2.0 o 3 host ports o 1 host/device
Page 29
Audio Codec 97 (AC97) Controller
AFOLUX LX Series Flat Panel PC
o AC97 specification v2.3 compliant interface to multiple audio codecs:
Serial In, Serial Out, Sync Out, Bit Clock In
o Legacy “PC Beep” support
Diverse Device
o 82xx Legacy Devices o IR Communication Port o System Management Bus (SMB) Controller o LPC (Low Pin Count) Port o General Purpose I/Os (GPIOs) o 8 Multi-Function General Purpose Timers (MFGPTs) o Real-Time Clock (RTC) with CMOS RAM o Power Management Controller o ACPI v2.0 compliant

2.4 Graphics Support

The Geode LX processor’s Graphics Processor is a BitBLT/vector engine that supports
pattern generation, source expansion, pattern/source transparency, 256 ternary raster
operations, alpha blenders to support alpha- BLTs, incorporated BLT FIFOs, a GeodeLink
interface and the ability to throttle BLTs according to video timing. New features added to
the Graphics Processor include:
Command buffer interface
Hardware accelerated rotation BLTs
Color depth conversion
Paletized color
Full 8x8 color pattern buffer
Separate base addresses for all channels
Monochrome inversion
4Table 2-1: Geode LX Graphics Features lists a complete list of Geode LX graphics
features. For more details, please refer to the AMD website or the Geode LX series data
Page 30
book available from AMD.
AFOLUX LX Series Flat Panel PC
Feature AMD Geode™ LX Processor
Color Depth 8, 16, 32 bpp (A) RGB 4 and 8-bit indexed
ROPs 256 (2-src, dest and pattern)
BLT Buffers FIFOs in Graphics Processor
BLT Splitting Managed by hardware
Video Synchronized BLT/Vector Throttle by VBLANK
Bresenham Lines Yes
Patterned (stippled) Lines Yes
Screen to Screen BLT Yes
Screen to Screen BLT with mono expansion Yes
Memory to Screen BLT Yes (throttled rep movs writes)
Accelerated Text No
Pattern Size (Mono) 8x8 pixels
Pattern Size (Color) 8x8 pixels
Monochrome Pattern Yes (with inversion)
Dithered Pattern (4 color) No
Color Pattern 8, 16, 32 bpp
Transparent Pattern Monochrome
Solid Fill Yes
Pattern Fill Yes
Transparent Source Monochrome
Color Key Source Transparency Y with mask
Variable Source Stride Yes
Variable Destination Stride Yes
Destination Write Bursting Yes
Selectable BLT Direction Vertical and Horizontal
Alpha BLT
VGA Support Decodes VGA Register
Pipeline Depth Unlimited
Accelerated Rotation BLT 8, 16, 32 bpp
Yes (constant α, α/pix, or sep. α channel)
Color Depth Conversion 5:6:5, 1:5:5:5, 4:4:4:4, 8:8:8:8
Table 2-1: Geode LX Graphics Features
Page 31
AFOLUX LX Series Flat Panel PC

2.5 Ethernet Controller Specifications

2.5.1 Overview

The Realtek RTL8100C(L) is a highly integrated and cost-effective single-chip Fast
Ethernet controller. It is enhanced with an ACPI (Advanced Configuration Power Interface)
management function for PCI in order to provide efficient power management for
advanced operating systems with OSPM (Operating System Directed Power
Management).
The RTL8100C(L) also supports remote wake-up (including AMD Magic Packet™ and
Microsoft® Wake-up frame) to increase cost-efficiency in network maintenance and
management. It is an ideal solution for notebook/motherboard-embedded network
designs.

2.5.2 Features

Integrates Fast Ethernet MAC, physical chip, and transceiver onto a single
chip
10Mbps and 100Mbps operation
Supports 10Mbps and 100Mbps N-way auto-negotiation
Supports 25MHz Crystal or 25MHz OSC as the internal clock source
Complies with PC99/PC2001 standards
Supports ACPI power management
Provides PCI bus master data transfer
Provides PCI memory space or I/O space mapped data transfer
Supports PCI clock speed of 16.75MHz-40MHz
Advanced power saving mode
Supports Wake-on-LAN and remote wake-up (AMD Magic Packet™, Link
Change, and Microsoft® Wake-up frame)
Half/Full duplex capability
Supports Full Duplex Flow Control (IEEE 802.3x)
Provides interface to 93C46 EEPROM to store resource configuration and ID
parameters
Page 32
Provides PCI clock run pin
Provides LED pins for network operation status indication
AFOLUX LX Series Flat Panel PC
2.5/3.3V power supply with 5V tolerant I/Os

2.6 Peripheral Device Interfaces, Connectors, and Slots

The peripheral device connectors, interfaces and slots on the WAFER-LX motherboard
are listed in the sections below.

2.6.1 OEM Options

Many of the peripheral device connectors listed below are not connected to any devices.
These connectors are reserved for OEM customizations. For a customized option, please
contact the vendor, reseller or IEI sales representative.

2.6.2 Internal Slots

The slots listed below can all be found on the WAFER-LX motherboard.
1 x 200-pin DDR SO-DIMM socket
1 x CFII slot

2.6.3 Internal Peripheral Device Connectors

The peripheral device connectors listed below are located on the AFLMB-LX800
motherboard and used for the AFOLUX series.
connectors that are used for the AFOLUX series.
1 x Audio connector
1 x CompactFlash
1 x Inverter connector
1 x LCD interface connector
1 x LED connector
1 x Mini PCI socket (for wireless LAN module)
1 x Power switch connector
1 x Touch screen connector
®
(CF) slot
4Figure 2-1 shows the overview of the
Page 33
AFOLUX LX Series Flat Panel PC
Figure 2-1: AFLMB-LX800 Connector Overview

2.6.4 External Peripheral Device Connectors

The peripheral device connectors listed below are located on the rear panel of the
AFLMB-LX800 motherboard.
2 x Ethernet connectors
2 x USB connectors
2 x Serial port connectors
1 x Reset button
1 x Power connector
Page 34
AFOLUX LX Series Flat Panel PC
Chapter
3

3 Installation

Page 35

3.1 Installation Precautions

When installing the flat panel PC, please follow the precautions listed below:
Power turned off: When installing the flat panel PC, make sure the power is
off. Failing to turn off the power may cause severe injury to the body and/or
damage to the system.
Certified En gineers: Only certified engineers should install and modify
onboard functionalities.
Mounting: The flat panel PC is a heavy device. When mounting the system
onto a rack, panel, wall or arm please make sure that at least two people are
assisting with the procedure.
Anti -static Discharge: If a user open the rear panel of the flat panel PC, to
configure the jumpers or plug in added peripheral devices, ground themselves
first and wear and anti-static wristband.
AFOLUX LX Series Flat Panel PC

3.2 Preinstalled Components

The following components are all preinstalled.
Motherboard
TFT LCD screen
256MB/512MB DDR memory module
Resistive type touch screen
Wireless LAN module
Bluetooth module
AT/ATX power switch
Preinstalled OEM customizations may include the following.
Different DDR memory module
HSUPA module (AFL-10A-LX and AFL-12A-LX models only)
Hard disk drive (AFL-12A-LX model only)
Page 36
Installation of some of the components are described in the following sections.
AFOLUX LX Series Flat Panel PC

3.3 Installation and Configuration Steps

The following installation steps must be followed.
Step 1: Unpack the flat panel PC
Step 2: Install CF card
Step 3: Install HDD (AFL-12A-LX model only)
Step 4: Mount the flat panel PC
Step 5: Connect peripheral devices to the bottom panel of the flat panel PC
Step 6: Configure the systemStep 0:

3.4 Unpacking

To unpack the flat panel PC, follow the steps below:
WARNING!
The front side LCD screen has a protective plastic cover stuck to the
screen. Only remove the plastic cover after the flat panel PC has been
properly installed. This ensures the screen is protected during the
installation process.
Step 1: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
external (second) box.
Step 2: Open the external (second) box.
Step 3: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
internal (first) box.
Step 4: Lift the monitor out of the boxes.
Step 5: Remove both polystyrene ends, one from each side.
Page 37
Step 6: Pull the plastic cover off the flat panel PC.
Step 7: Make sure all the components listed in the packing list are present. Step 0:

3.4.1 Packing List

Step 1: The AFOLUX LX flat panel PC is shipped with the following components:
Quantity Item Image
Standard
1 AFOLUX LX series panel PC
1 Power adapter
AFOLUX LX Series Flat Panel PC
1 Power cord
1 User manual CD and driver CD
1 Touch pen
Optional
4
Panel mounting clamp
(6)
(AFL-12A-LX)
1 Wall mounting kit
Page 38
AFOLUX LX Series Flat Panel PC
1 128MB CompactFlash® card with Windows
CE 5.0 pre-installed and SDK
1 1GB CompactFlash® card with Windows
XPE pre-installed
Step 2: If any of these items are missing or damaged, contact the distributor or sales
representative immediately.

3.5 CF Card Installation

WARNING:
Over-tightening back cover screws will crack the plastic frame.
Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).
The AFOLUX LX series has one CF Type II slot inside the rear panel. To install the CF
card, follow the instructions below.
Step 1: Remove the nine retention screws (
panel PC.
4Figure 3-1) and lift the cover off the flat
Figure 3-1: Back Cover Retention Screws
Step 2: For AFL-08AH-LX, lift the cover off and pull down the cover a bit to make it
possible to lift the cover further more after removing the nine retention screws
Page 39
AFOLUX LX Series Flat Panel PC
(4Figure 3-2). Push the power switch while lifting the back cover. More strength is
required to separate the cover from the chassis.
Figure 3-2: AFL-08AH-LX Plastic Back Cover Removal
Step 3: Locate the CF slot. Insert a CF card into the slot (
4Figure 3-3).
Figure 3-3: CF Card Location
Step 4: Replace the plastic back cover. For AFL-08AH-LX, more strength is required
when pushing the bottom part of the cover down to the chassis (
4Figure 3-4).
Page 40
Figure 3-4: AFL-08AH-LX Plastic Back Cover Replacement
Step 5: Once replaced reinsert the nine previously removed retention screws. Step 0:
AFOLUX LX Series Flat Panel PC

3.6 HDD Installation (AF-12A-LX Only)

WARNING:
Over-tightening back cover screws will crack the plastic frame.
Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).
To install the HDD into the AF-12A-LX, please follow the steps below:
Step 1: Remove the plastic back cover. See Section
43.5 above.
Step 2: Remove the eight retention screws securing the internal aluminum cover
4Figure 3-5).
(
Figure 3-5: AFL-12A-LX Aluminum Back Cover Retention Screws
Step 3: Remove the four hexagonal pillars on the bottom panel.
Figure 3-6: Four Hexagonal Pillars on the Bottom Panel
Step 4: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-12A-LX.
Page 41
AFOLUX LX Series Flat Panel PC
Step 5: Disconnect the power switch cable from the motherboard and remove the
aluminum cover.
Step 6: Remove the four HDD bracket retention screws (
4Figure 3-7) and lift the HDD
bracket off the panel PC.
Figure 3-7: AFL-12A-LX HDD Bracket Retention Screws
Step 7: Attach the HDD brackets to the HDD. To do this, align the four retention screw
holes in the both sides of the HDD bracket with the retention screw holes on the
sides of the HDD. Insert four retention screws into the HDD bracket (
4Figure
Page 42
3-8).
Figure 3-8: AF-12A-LX HDD Retention Screws
Step 8: Connect the IDE cable to the rear of HDD.
Step 9: Install the HDD into the AF-12A-LX by aligning the retention screw holes in the
HDD brackets with the retention screw holes on the chassis. Insert the four
retention screws.
AFOLUX LX Series Flat Panel PC
Step 10: Re-connect the power switch cable to the motherboard.
Step 11: Replace the aluminum back cover to the chassis.
Step 12: Replace the plastic back cover. Step 0:

3.7 AT/ATX Mode Selection

AT and ATX power modes can both be used on the AFOLUX LX series. The selection is
made through an AT/ATX switch on the aluminum chassis inside the plastic back cover
(
4Figure 3-9). To select AT mode or ATX mode, follow the steps below.
Step 1: Remove the plastic back cover. See Section
Step 2: Locate the AT/ATX switch on the aluminum chassis (
Figure 3-9: AT/ATX Switch Location
Step 3: Adjust the AT/ATX switch. Step 0:

3.7.1 AT Power Mode

43.5 above.
4Figure 3-9).
With the AT mode selected, the power is controlled by a central power unit rather than a
power switch. The AFOLUX LX panel PC turns on automatically when the power is
connected. The AT mode benefits a production line to control multiple panel PCs from a
central management center and other applications including:
ATM
Self-service kiosk
Plant environment monitoring system
Factory automation platform
Page 43
Manufacturing shop flow

3.7.2 ATX Power Mode

With the ATX mode selected, the AFOLUX LX panel PC goes in a standby mode when it
is turned off. The panel PC can be easily turned on via network or a power switch in
standby mode. Remote power control is perfect for advertising applications since the
broadcasting time for each panel PC can be set individually and controlled remotely. Other
possible application includes
Security surveillance
Point-of-Sale (POS)
Advertising terminal
AFOLUX LX Series Flat Panel PC

3.8 Mounting the System

WARNING!
When mounting the flat panel PC onto an arm, onto the wall or onto a
panel, it is better to have more than one person to help with the installation
to make sure the panel PC does not fall down and get damaged.
The four methods of mounting the AFOLUX LX are listed below.
Wall mounting
Panel mounting
Arm mounting
Rack mounting
The four mounting methods are described below.

3.8.1 Wall Mounting

To mount the flat panel PC onto the wall, please follow the steps below.
Page 44
AFOLUX LX Series Flat Panel PC
Step 1: Select the location on the wall for the wall-mounting bracket.
Step 2: Carefully mark the locations of the four brackets screw holes on the wall.
Step 3: Drill four pilot holes at the marked locations on the wall for the bracket retention
screws.
Step 4: Align the wall-mounting bracket screw holes with the pilot holes.
Step 5: Secure the mounting-bracket to the wall by inserting the retention screws into
the four pilot holes and tightening them (
4Figure 3-10).
Figure 3-10: Wall-mounting Bracket
Step 6: Insert the four monitor mounting screws provided in the wall mounting kit into the
four screw holes on the real panel of the flat panel PC and tighten until the screw
shank is secured against the rear panel (
4Figure 3-11).
Step 7: Align the mounting screws on the monitor rear panel with the mounting holes on
the bracket.
Step 8: Carefully insert the screws through the holes and gently pull the monitor
downwards until the monitor rests securely in the slotted holes (
4Figure 3-11).
Ensure that all four of the mounting screws fit snuggly into their respective
slotted holes.
Page 45
AFOLUX LX Series Flat Panel PC
Figure 3-11: Chassis Support Screws
NOTE:
In the diagram below the bracket is already installed on the wall.
Step 9: Secure the panel PC by fastening the retention screw of the wall-mounting
bracket. (
4Figure 3-12).
Page 46
AFOLUX LX Series Flat Panel PC
Figure 3-12: Secure the Panel PC

3.8.2 Panel Mounting

To mount the AFOLUX LX series flat panel PC into a panel, please follow the steps below.
Step 1: Select the position on the panel to mount the flat panel PC.
Step 2: Cut out a section from the panel that corresponds to the rear panel dimensions
of the flat panel PC. Take care that the panel section that is cut out is smaller
than the overall size of the metal frame that surrounds the flat panel PC but just
large enough for the rear panel of the flat panel PC to fit through (
4Figure 3-14 and 4Figure 3-15).
4Figure 3-13,
Page 47
AFOLUX LX Series Flat Panel PC
Figure 3-13: AFL-07A-LX Panel Opening
Figure 3-14: AFL-08AH-LX Panel Opening
Figure 3-15: AFL-10A-LX Panel Opening
Page 48
AFOLUX LX Series Flat Panel PC
Figure 3-16: AFL-12A-LX Panel Opening
Step 3: Slide the flat panel PC through the hole until the aluminum frame is flush against
the panel.
Step 4: Insert the panel mounting clamps into the pre-formed holes along the edges of
the chassis, behind the aluminum frame. There are a total of 4 panel mounting
clamps for AFL-07A-LX/ AFL-08AH-LX and 6 panel mounting clamps for
AFL-10A-LX/AFL-12A-LX.
Step 5: Tighten the screws that pass through the panel mounting clamps until the plastic
caps at the front of all the screws are firmly secured to the panel (
4Figure 3-17).
Page 49
AFOLUX LX Series Flat Panel PC
Figure 3-17: Tighten the Panel Mounting Clamp Screws (AFL-10A/12A-LX)

3.8.3 Arm Mounting

The AFOLUX LX series is VESA (Video Electronics Standards Association) compliant and
can be mounted on an arm with a 75mm or 100mm interface pad. To mount the AFOLUX
LX series on an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that
the arm has a 75mm interface pad. If the mounting arm is not VESA
Page 50
compliant it cannot be used to support the AFOLUX LX series flat panel
PC. The AFL-10A-LX and AFL-12A-LX also support VESA MIS-D 100.
AFOLUX LX Series Flat Panel PC
Step 2: Once the mounting arm has been firmly attached to the surface, lift the flat panel
PC onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
flat panel PC. The AFL-07A-LX/ AFL-07A-LX arm mount retention screw holes
are shown in
4Figure 3-19.
4Figure 3-18 and the AFL-10A-LX/AFL-12A-LX are shown in
Figure 3-18: AFL-07A-LX/AFL-08AH-LX Arm Mounting Retention Screw Holes
Figure 3-19: AFL-10A-LX/AFL-12A-LX Arm Mounting Retention Screw Holes
Page 51
Step 4: Secure the flat panel PC to the interface pad by inserting four retention screws
through the bottom of the mounting arm interface pad and into the flat panel PC.
Step 0:

3.8.4 Cabinet and Rack Installation

The AFL LX series flat panel PC can be installed into a cabinet or rack. The installation
procedures are similar to the panel mounting installation. To do this, please follow the
steps below:
NOTE:
When purchasing the cabinet/rack installation bracket, make sure it is
compatible with both the AFL LX series flat panel PC and the rack/cabinet
AFOLUX LX Series Flat Panel PC
into which the AFL LX series is installed.
Step 1: Slide the rear chassis of the AFL LX series flat panel PC through the
rack/cabinet bracket until the aluminum frame is flush against the front of the
bracket (
4Figure 3-20).
Figure 3-20: The Rack/Cabinet Bracket
Page 52
Step 2: Insert the rack mounting clamps into the pre-formed holes along the edges of
the flat panel PC, behind the ABS/PC plastic frame. There are a total of 4 rack
AFOLUX LX Series Flat Panel PC
mounting clamps for AFL-07A-LX/ AFL-08AH-LX and 6 rack mounting clamps
for AFL-10A-LX/AFL-12A-LX.
Step 3: Tighten the screws that pass through the rack mounting clamps until the plastic
caps at the front of all the screws are firmly secured to the bracket (
4Figure 3-21).
Figure 3-21: Secure the Rack/Cabinet Bracket (AFL-10A-LX/AFL-12A-LX)
Step 4: Slide the flat panel PC with the attached rack/cabinet bracket into a rack or
cabinet (
4Figure 3-22).
Page 53
AFOLUX LX Series Flat Panel PC
Figure 3-22: Install into a Rack/Cabinet
Step 5: Once the flat panel PC with the attached rack/cabinet bracket has been properly
inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to
the front of the rack or cabinet (

3.9 Bottom Panel Connectors

3.9.1 LAN Connection

There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection
to an external network. To connect a LAN cable with an RJ-45 connector, please follow
the instructions below.
Step 1: Locate the RJ-45 connectors on the bottom panel of the AFOLUX LX Series.
Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of
the RJ-45 connectors on the bottom panel of the AFOLUX LX Series. See
4Figure 3-23.
4Figure 3-22).
Page 54
Figure 3-23: LAN Connection
AFOLUX LX Series Flat Panel PC
Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN
cable RJ-45 connector into the onboard RJ-45 connector. Step 0:

3.9.2 Serial Device Connection

The AFOLUX LX Series has two single female DB-9 connectors on the bottom panel for a
serial device. Follow the steps below to connect a serial device to the AFOLUX LX Series
panel PC.
Step 1: Locate the DB-9 connector. The location of the DB-9 connector is shown in
Chapter 2.
Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into
the DB-9 connector on the bottom panel. See
4Figure 3-24.
Figure 3-24: Serial Device Connector
Step 3: Secure the connector. Secure the serial device connector to the external
interface by tightening the two retention screws on either side of the connector.
Page 55
Step 0:

3.9.3 USB Device Connection

There are two external USB 2.0 connectors. To connect a USB 2.0 or USB 1.1 device,
please follow the instructions below.
Step 1: Located the USB connectors. The locations of the USB connectors are shown
in Chapter 2.
Step 2: Align the connectors. Align the USB device connector with one of the
AFOLUX LX Series Flat Panel PC
connectors on the bottom panel. See
4Figure 3-25.
Page 56
Figure 3-25: USB Device Connection
Step 3: Insert the device connector. Once aligned, gently insert the USB device
connector into the onboard connector. Step 0:
AFOLUX LX Series Flat Panel PC

3.10 Power-up the System

WARNING:
Make sure a power supply with the correct input voltage is being fed
into the system. Incorrect voltages applied to the system may cause
damage to the internal electronic components and may also cause
injury to the user.
To power-on the AFL LX Series please follow the steps below:
Step 1: Connect the power adapter to the power connector. Then, connect the power
adapter to the power source.
Step 2: Push the power button. See
Step 3: Once turned on, the power LED on the front panel should light on. Step 0:
74Figure 3-26
Figure 3-26: Power Connector and Power Button
Page 57
AFOLUX LX Series Flat Panel PC
Chapter
4

4 System Maintenance

Page 58
AFOLUX LX Series Flat Panel PC

4.1 System Maintenance Introduction

If the components of the AFOLUX LX series fail they must be replaced, such as the
wireless LAN module or the motherboard. Please contact the system reseller or vendor to
purchase the replacement parts. Back cover removal instructions and jumper settings for
the AFOLUX LX series are described below.

4.2 Motherboard Replacement

A user cannot replace a motherboard. If the motherboard fails it must be shipped back to
IEI to be replaced. If the system motherboard has failed, please contact the system vendor,
reseller or an IEI sales person directly.

4.3 Internal Aluminum Cover Removal

WARNING!
BEFORE REMOVING THE BACK COVER, MAKE SURE THE POWER IS OFF. Failing to do so may lead to severe damage of AFOLUX LX series
and injury to the body.
WARNING!
PLEASE TAKE ANTISTATIC PRECAUTIONS WHEN WORKING WITH THE INTERNAL COMPONENTS. The interior of the AFOLUX LX series
contains very sensitive electronic components. These components are
easily damaged by electrostatic discharge (ESD). Before working with the
internal components make sure all the anti-static precautions described
earlier have been observed.
To replace any of the following components,
Page 59
Motherboard
DDR memory module
Wireless LAN module
Inverter
The internal aluminum back cover of the AFOLUX LX series must be removed. To remove
the aluminum back cover, please follow the steps below.
AFOLUX LX Series Flat Panel PC

4.3.1 AFL-07A-LX Internal Aluminum Cover Removal

Step 1: Remove the two retention screws securing the internal aluminum cover (4Figure
4-1).
Figure 4-1: AFL-07A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
4Figure 4-2).
Figure 4-2: Four Hexagonal Pillars on the Bottom Panel (AFL-07A-LX)
Step 3: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-07A-LX.
Step 4: Disconnect the power switch cable from the motherboard and remove the
aluminum cover. Step 0:
Page 60
AFOLUX LX Series Flat Panel PC

4.3.2 AFL-08AH-LX Internal Aluminum Cover Removal

Step 1: Remove the four retention screws (4Figure 4-3).
Figure 4-3: AFL-08AH-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
4Figure 4-4).
Figure 4-4: Four Hexagonal Pillars on the Bottom Panel (AFL-08AH-LX)
Step 3: Detach the tapes securing the wireless module cables on the chassis (
4-5).
Step 4: Carefully cross the wireless module cables over the screw holes of the
aluminum cover (
4Figure 4-5).
4Figure
Page 61
AFOLUX LX Series Flat Panel PC
Figure 4-5: Wireless Module Cables
Step 5: Push the external interface connector apart from the aluminum cover and lift the
cover (
4Figure 4-6).
Figure 4-6: The Internal Aluminum Cover Removal
Step 6: Disconnect the power switch cable (
remove the aluminum cover.
4Figure 4-7) from the motherboard and
Figure 4-7: Power Switch Cable

4.3.3 AFL-10A-LX Internal Aluminum Cover Removal

Step 1: Remove the eight retention screws securing the internal aluminum cover
4Figure 4-10).
(
Page 62
AFOLUX LX Series Flat Panel PC
Figure 4-8: AFL-10A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
Figure 4-9: Four Hexagonal Pillars on the Bottom Panel (AFL-10A-LX)
Step 3: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-10A-LX.
Step 4: Disconnect the power switch cable from the motherboard and remove the
aluminum cover. Step 0:

4.3.4 AFL-12A-LX Internal Aluminum Cover Removal

Step 1: Remove the eight retention screws securing the internal aluminum cover
4Figure 4-10).
(
4Figure 4-11).
Page 63
AFOLUX LX Series Flat Panel PC
Figure 4-10: AFL-12A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
Figure 4-11: Four Hexagonal Pillars on the Bottom Panel (AFL-12A-LX)
Step 3: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-12A-LX.
Step 4: Disconnect the power switch cable from the motherboard and remove the
aluminum cover. Step 0:

4.4 Memory Module Replacement

The flat panel PC is preinstalled with a 256MB/512MB DDR memory module. If the
memory module is fail, follow the instructions below to replace the memory module.
4Figure 4-11).
Page 64
Step 1: Remove the back cover. See Section
Step 2: Remove the internal aluminum back cover. See Section
43.5 above.
44.3 above.
Step 3: Locate the DDR memory module on the motherboard of the flat panel PC
4Figure 4-12).
(
AFOLUX LX Series Flat Panel PC
Figure 4-12: SO-DIMM Socket Location
Step 4: Remove the DDR memory module by pulling both the spring retainer clips
outward from the socket.
Step 5: Grasp the DDR memory module by the edges and carefully pull it out of the
socket.
Step 6: Install the new DDR memory module by pushing it into the socket at an angle
4Figure 4-13).
(
Step 7: Gently pull the spring retainer clips of the SO-DIMM socket out and push the
rear of the DDR memory module down (
4Figure 4-13).
Step 8: Release the spring retainer clips on the SO-DIMM socket. They clip into place
and secure the DDR memory module in the socket.Step 0:
Figure 4-13: DDR SO-DIMM Module Installation
Page 65

4.5 Jumper Settings

NOTE:
A jumper is a metal bridge that is used to
close an electrical circuit. It consists of
two metal pins and a small metal clip
(often protected by a plastic cover) that
slides over the pins to connect them.
To CLOSE/SHORT a jumper means
AFOLUX LX Series Flat Panel PC
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper
means removing the plastic clip from a
jumper.
The motherboard comes with two jumpers. They are listed below.
COM3 pin-9 signal select (JP3)
COM1 and COM2 pin-9 signal select (JP4)
COM2 Mode Select Jumper Settings (JP5)
COM2 Mode Select Jumper Settings (JP6)
Jumper
Page 66
AFOLUX LX Series Flat Panel PC
Figure 4-14: Jumper Locations

4.5.1 JP3: COM3 Pin-9 Signal Select Jumper Settings

The COM3 pin-9 signal can be selected as 12V, 5V or Ring.
JP3 Description
Short 1-2 COM3 pin-9 is 12V output
Short 3-4 COM3 pin-9 is RI input Default Short 5-6 COM3 pin-9 is 5V output
Table 4-1: COM3 Pin-9 Signal Select Jumper Settings
Page 67
AFOLUX LX Series Flat Panel PC

4.5.2 JP4: COM1 and COM2 Pin-9 Signal Select Jumper Settings

The COM1 and COM2 pin-9 signal can be selected as 12V, 5V or Ring.
JP4 Description
Short 1, 3 COM1 pin-9 is 12V output Short 3, 5 COM1 pin-9 is 5V output
Short 5, 7 COM1 pin-9 is 5V output Short 7, 9 COM1 pin-9 is RI input Default
Short 2, 4 COM2 pin-9 is 12V output Short 4, 6 COM2 pin-9 is 5V output
Short 6, 8 COM2 pin-9 is 5V output Short 8, 10 COM2 pin-9 is RI input Default
Table 4-2: COM1 and COM2 Pin-9 Signal Select Jumper Settings

4.5.3 JP5: COM2 Mode Select Jumper Settings

The COM2 can be selected as RS-232 or RS-485.
JP5 Description
Short 1-2 RS-232 Default
Short 2-3 RS-485
Table 4-3: COM2 Mode Select Jumper Settings
Page 68
AFOLUX LX Series Flat Panel PC

4.5.4 JP6: COM2 Mode Select Jumper Settings

The COM2 can be selected as RS-232 or RS-485.
JP6 Description
Short 1-2 RS-232 Default Short 2-3 RS-485
Short 4-5 RS-232 Default Short 5-6 RS-485
Short 7-8 RS-232 Default Short 8-9 RS-485
Short 10-11 RS-232 Default Short 11-12 RS-485
Table 4-4: COM2 Mode Select Jumper Settings
4.5.4.1 COM2 RS-422 and RS-485 Pinouts
The pinouts for RS-422 and RS-485 operation of external serial port COM 2 are detailed
below.
COM 2 RS-422 Description
Pin 1 TX-
Pin 2 TX+ Pin 6 RX-
Pin 7 RX+
Table 4-5: RS-422 Pinouts
COM 2 RS-485 Description
Pin 1 Data­Pin 2 Data+
Table 4-6: RS-485 Pinouts
Page 69
AFOLUX LX Series Flat Panel PC
Chapter
5

5 Award BIOS Setup

Page 70
AFOLUX LX Series Flat Panel PC

5.1 Introduction

A licensed copy of Phoenix Award BIOS is preprogrammed into the ROM BIOS. The BIOS
setup program allows users to modify the basic system configuration. This chapter
describes how to access the BIOS setup program and the configuration options that may
be changed.

5.1.1 Starting Setup

The Phoenix Award BIOS is activated when the computer is turned on. The setup program
can be activated in one of two ways.
1. Press the D
2. Press the D
appears on the screen.
If the message disappears, restart the computer and try again.
ELETE key as soon as the system is turned on or ELETE key when the “Press Del to enter SETUP” message

5.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PAGEUP and P
AGEDOWN keys to change entries, press F1 for help and press ESC to quit. Navigation
keys are shown below.
Key Function
Up arrow Move to the item above
Down arrow Move to the item below
Left arrow Move to the item on the left hand side
Right arrow Move to the item on the right hand side
+/Page up Increase the numeric value or make changes
-/Page down Decrease the numeric value or make changes
Esc Main Menu – Quit and do not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu --
Exit current page and return to Main Menu
F1 General help, only for Status Page Setup Menu and Option
Page Setup Menu
F2 Item help
Page 71
F5 Previous values for the page menu items
F6 Fail-safe defaults for the current page menu items
F7 Optimized defaults for the current page menu items
F9 Menu in BIOS
F10 Save changes and Exit BIOS
Table 5-1: BIOS Navigation Keys

5.1.3 Getting Help

When F1 is pressed a small help window describing the appropriate keys to use and the
AFOLUX LX Series Flat Panel PC
possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again.

5.1.4 Main BIOS Menu

Once the BIOS opens, the main menu (4BIOS Menu 1) appears.
SC or
BIOS Menu 1: Award BIOS CMOS Setup Utility
NOTE:
Page 72
AFOLUX LX Series Flat Panel PC
The following sections will completely describe the menus listed below and
the configuration options available to users.
The following menu options are seen in 4BIOS Menu 1.
Standard CMOS Features: Changes the basic system configuration. Advanced BIOS Features: Changes the advanced system settings. Advanced Chipset Features: Changes the chipset configuration features. Integrated P eripherals: Changes the settings for integrated peripherals.  Power Management Setup: Configures power saving options. PnP/PCI Configurations: Changes the advanced PCI/PnP settings.  PC Heal th Status: Monitors essential system parameters.
The following user configurable options are also available in
4BIOS Menu 1:
Load Fail-Safe Defaults
Use the Load Fail-Safe Defaults option to load failsafe default values for each BIOS parameter in the setup menus. Press F6 for this operation on any page.
Load Optimized Defaults
Use the Load Optimized Defaults option to load optimal default values for each BIOS parameter in the setup menus. Press F7 for this operation on any page.
Set Supervisor Password
Use the Set Supervisor Password option to set the supervisor password. By default, no
supervisor password is set. To install a supervisor password, select this field and enter the
password. After this option is selected, a red dialogue box appears with “Enter Password: ”. Type the password and press EConfirm Password: ” dialogue box and press E
NTER. Retype the original password into the
NTER. To disable the password, simply
press E
NTER in the “Enter Password: ” dialogue box, then press any key in the
Password Disabled !!!” dialogue box.
Page 73
Set User Password
Use the Set User Password option to set the user password. By default no user
password is set. To install a user password, select this field and enter the password. After
this option is selected, a red dialogue box appears with “Enter Password: ”. Type the
AFOLUX LX Series Flat Panel PC
password and press E dialogue box and press E Password: ” dialogue box, then press any key in the “Password Disabled !!!” dialogue
box.
Save & Exit Setup
Use the Save & Exit Setup option to save any configuration changes made and exit the
BIOS menus.
Exit Without Saving
Use the Exit Without Saving option to exit the BIOS menus without saving any
configuration changes.
NTER. Retype the original password into the “Confirm Password: ”
NTER. To disable the password, simply press ENTER in the “Enter

5.2 Standard CMOS Features

Use the Standard CMOS Features BIOS menu (4BIOS Menu 2) to set basic BIOS
configuration options.
Page 74
AFOLUX LX Series Flat Panel PC
BIOS Menu 2: Standard CMOS Features
Date [Day mm:dd:yyyy]
Use the Date option to set the system date.
Time [hh/mm/ss]
Use the Time option to set the system time.
IDE Master and IDE Slave
When entering setup, BIOS auto detects the presence of IDE devices. The Standard CMOS Features menu shows the status of the auto detected IDE devices. The following IDE devices are detected and shown in the Standard CMOS Features menu:
IDE Primary Master
IDE Primary Slave
Page 75
IDE device configurations are changed or set in the IDE Configuration menu. If an IDE
device is detected, and one of the above listed two BIOS configuration options is selected,
AFOLUX LX Series Flat Panel PC
the IDE configuration options shown in Section
Halt On [All, But Keyboard]
Use the Halt On option to specify what errors detected during the power up process stop
the system.
All Errors
No Errors
All, But Keyboard
Base Memory:
The Base Memory is NOT user configurable. The POST determines the amount of base
Whenever BIOS detects a non-fatal error the
The system boot is not stopped for any errors
(Default) The system boot does not stop for a keyboard
45.2.1 appear.
system is stopped and the user prompted.
that may be detected.
error; it stops for all other errors.
(or conventional) memory installed in the system. The value of the base memory is
typically 512K for systems with 512K memory installed, or 640K for systems with 640K or
more memory installed.
Extended Memory
The Extended Memory is NOT user configurable. The BIOS determines how much
extended memory is present during the POST. This is the amount of memory above 1MB
located in the memory address map of the CPU.
Total Memory
The Total Memory is NOT user configurable.
Page 76
AFOLUX LX Series Flat Panel PC

5.2.1 IDE Primary Master/Slave

Use the IDE Primary Master/Slave menu to set or change the master/slave IDE
configurations.
IDE HDD Auto-Detection [Press Enter]
Use the IDE HDD Auto-Detection option to enable BIOS to automatically detect the IDE settings. Select IDE HDD Auto-Detection and press E
the HDD type. Do not set this option manually.
IDE Primary Master [Auto]
Use the IDE Primary Master option to activate or deactivate the following drive channels:
Channel 0 Master
Channel 0 Slave
Channel 1 Master
Channel 1 Slave
None
Auto
NTER. BIOS automatically detects
If no drives are connected to the IDE channel select this
option. Once set, this IDE channel becomes
inaccessible and any drives attached to it are
undetected.
(Default) Setting this option allows the device to be automatically
Manual
Access Mode [Auto]
The Access Mode option can only be configured if the BIOS configuration option is set to either Manual or Auto. Use the Access Mode option to determine the hard disk BIOS
translation modes. Most systems now use hard drives with large capacities and therefore
either the LBA translation mode or auto mode should be selected.
detected by the BIOS.
Selecting this option allows manual configuration of the
device on the IDE channel in BIOS.
Page 77
AFOLUX LX Series Flat Panel PC
CHS
LBA
Large
Auto
Capacity
The Capacity specification indicates the storage capacity of the HDD installed in the
system.
Cylinder
Select this mode if the HDD capacity is less than
504MB.
Select this mode if the HDD capacity is more than
8.4GB.
This mode is an extended ECHS mode and while it
supports HDDs larger than 504MB, it is not
recommended.
(Default) If you are unsure of what access mode to set, select this
option.
The Cylinder specification indicates how many cylinders (tracks) are on the HDD installed
in the system.
Head
The Head specification indicates how many logical heads are on the HDD installed in the
system.
Precomp
The Precomp specification indicates on what track the write precompensation begins.
Landing Zone
The Landing Zone specification indicates where the disk head will park itself after the
system powers off.
Page 78
AFOLUX LX Series Flat Panel PC
Sector
The Sector specification indicates how many logical sectors the HDD has been divided
into.

5.3 Advanced BIOS Features

Use the Advanced BIOS Features menu (4BIOS Menu 3) to configure the CPU and
peripheral device configuration options.
BIOS Menu 3: Advanced BIOS Features
Virus Warning [Disabled]
NOTE:
Many disk diagnostic programs can cause the above warning message to
Page 79
appear when the program attempts to access the boot sector table. If you
are running such a program, it is recommended that the virus protection
function be disabled beforehand.
Use the Virus Warning option to enable BIOS to monitor the boot sector and partition
table of the HDD for any attempted modification. If a modification attempt is made, the
BIOS halts the system and an error message appears. If necessary, an anti-virus program
can then be run to locate and remove the virus before any damage is done.
AFOLUX LX Series Flat Panel PC
Enabled
Disabled
CPU Internal Cache [Enabled]
Use the CPU Internal Cache option to enable or disable the internal CPU cache.
Disabled
Enabled
Boot From LAN Control [Disabled]
Use the BOOT From LAN Control option to enable the system to be booted from a
remote system.
Activates automatically when the system boots up
causing a warning message to appear when anything
attempts to access the boot sector or HDD partition table.
(Default) No warning message appears when there is an attempt
to access the boot sector or HDD partition table.
The internal CPU cache is disabled.
(Default) The internal CPU cache is enabled.
Page 80
Disabled
Enabled
(Default) The system cannot be booted from a remote system
through the LAN.
The system can be booted from a remote system
through the LAN.
AFOLUX LX Series Flat Panel PC
Boot Device
Use the Boot Device options to select the order of the devices the system boots from.
There are three boot device configuration options:
First Boot Device [Default: HDD-0] Second Boot Device [Default: HDD-1] Third Boot Dev ice [Default: CDROM]
Using the default values, the system first looks for the first HDD to boot from. If it cannot
find the first HDD, it boots from a second HDD. If both the HDD are unavailable, the
system boots from a CD-ROM.
Boot Device configuration options are:
LS120
HDD-0
SCSI
CDROM
HDD-1
USB-FDD
USB-ZIP
USB-CDROM
USB-HDD
LAN
Disabled
Boot Other Device [Enabled]
Use the Boot Other Device option to determine whether the system uses a second or
third boot device if the first boot device is not found.
Disabled
The system does not look for second and third boot
devices if the first one is not found.
Page 81
AFOLUX LX Series Flat Panel PC
Enabled
Boot Up Numlock Status [On ]
Use the Boot Up Numlock Status option to specify the default state of the numeric
keypad.
Off
On
Gate A20 Option [Fast]
Use the Gate A20 Option to set if the keyboard controller or the chipset controls the Gate
A20 switching.
Normal
(Default) The system looks for second and third boot devices if the
first one is not found.
The keys on the keypad are not activated.
(Default) Activates the keys on the keypad.
The keyboard controller does the switching.
Fast
Typematic Rate Setting [Disabled]
Use the Typematic Rate Setting configuration option to specify if only one character is
allowed to appear on the screen if a key is continuously held down. When this option is
enabled, the BIOS reports as before, but it then waits a moment, and, if the key is still held
down, it begins to report that the key has been pressed repeatedly. This feature
accelerates cursor movement with the arrow keys.
Disabled
Enabled
Typematic Rate (Chars/sec) [6]
The Typematic Rate option can only be configured if the Typematic Rate Setting is enabled. Use the Typematic Rate option to specify the rate keys are accelerated.
(Default) The chipset does the switching.
(Default) Disables the typematic rate.
Enables the typematic rate.
Page 82
6
(Default) 6 characters per second
AFOLUX LX Series Flat Panel PC
8
10
12
15
20
24
30
Typematic Delay (Msec) [250]
The Typematic Rate option can only be configured if the Typematic Rate Setting is enabled. Use the Typematic Delay option to specify the delay time between when a key
is first pressed and when the acceleration begins.
250
8 characters per second
10 characters per second
12 characters per second
15 characters per second
20 characters per second
24 characters per second
30 characters per second
(Default) 250 milliseconds
500
750
1000
Security Option [Setup]
Use the Security Option to limit access to both the system and Setup, or just Setup.
Setup
System
NOTE:
500 milliseconds
750 milliseconds
1000 milliseconds
(Default) The system does not boot and access to Setup is denied
if the correct password is not entered at the prompt.
The system boots, but access to Setup is denied if the
correct password is not entered at the prompt.
To disable security, select the password setting in the Main Menu. When
Page 83
asked to enter a password, don’t type anything, press ENTER and the
security is disabled. Once the security is disabled, the system boots and
Setup can be accessed.
OS Select For DRAM > 64MB [Non-OS2]
Use the OS Select For DRAM > 64MB option to specify the operating system.
AFOLUX LX Series Flat Panel PC
Non-OS2
OS2
Small Logo (EPA) Show [Disabled]
Use the Small Logo (EPA) Show option to specify if the Environmental Protection
Agency (EPA) logo appears during the system boot-up process. If enabled, the boot up
process may be delayed.
Disabled
Enabled
(Default) Select this option when not using the OS/2 operating
system.
Specifies the operating system used as OS/2.
(Default) EPA logo does not appear during boot up.
EPA logo appears during boot up.

5.4 Advanced Chipset Features

Use the Advanced Chipset Features menu (4BIOS Menu 4) to change chipset
configuration options.
Page 84
AFOLUX LX Series Flat Panel PC
BIOS Menu 4: Advanced Chipset Features
CPU Frequency [500MHz]
Use the CPU Frequency option to set the CPU frequency. The CPU Frequency options
are:
Auto
200MHz
333MHz
400MHz
433MHz
500MHz (Default)
Memory Frequency [Auto]
Use the Memory Frequency option to set the frequency of the installed DRAM modules. The Memory Frequency options are:
Page 85
Auto (Default)
100MHz
133MHz
166MHz
200MHz
Video Memory Size [32M]
Use the Video Memory Size option to determine how much memory is allocated to the video graphics device. The Video Memory Size options are:
None
8M
16M
32M (Default)
AFOLUX LX Series Flat Panel PC
64M
128M
254M
OnBoard Audio [Enabled]
Use the OnBoard Audio option to enable or disable the onboard codec.
Disabled
Enabled
The onboard codec is disabled.
(Default) The onboard codec is detected and enabled.

5.5 Integrated Peripherals

Use the Integrated Peripherals menu (4BIOS Menu 5) to change the configuration options
for the attached peripheral devices.
Page 86
AFOLUX LX Series Flat Panel PC
BIOS Menu 5: Integrated Peripherals
On-Chip IDE Channel 1 [Enabled]
Use the On-Chip IDE Channel 1 option to specify if the system uses the integrated
primary IDE channel or not.
Disabled
Enabled
Drive PIO Mode [Auto]
Use the Drive PIO Mode options below to select the Programmed Input/Output (PIO)
mode for the following HDDs:
The primary IDE channel is not used.
(Default) The primary IDE channel is used.
Page 87
Master Drive PIO Mode
Slave Drive PIO Mode
AFOLUX LX Series Flat Panel PC
Auto
Mode 0
Mode 1
Mode 2
Mode 3
Mode 4
IDE UDMA [Auto]
Use the IDE UDMA option below to select the Ultra DMA (UDMA) mode for the following
HDDs:
IDE Primary Master UDMA
IDE Primary Slave UDMA
Disabled
(Default) The computer selects the correct mode.
PIO mode 0 selected with a maximum transfer rate of 3.3MBps.
PIO mode 1 selected with a maximum transfer rate of 5.2MBps.
PIO mode 2 selected with a maximum transfer rate of 8.3MBps.
PIO mode 3 selected with a maximum transfer rate of 11.1MBps.
PIO mode 4 selected with a maximum transfer rate of 16.6MBps.
The UDMA for the HDD device is disabled.
Auto
IDE DMA transfer access [Enabled]
Use the IDE DMA transfer access option to enable or disable DMA support for IDE
devices connected to the system.
Disabled
Enabled
IDE HDD Block Mode [Enabled]
If the drive connected to the system supports block mode, use the IDE HDD Block Mode
option to enable the system to detect the optimal number of block read/writes per sector
Page 88
(Default) The computer selects the correct UDMA.
All IDE drive DMA transfers are disabled. The IDE drives
(Default) All IDE drive DMA transfers are enabled.
use PIO mode transfers.
AFOLUX LX Series Flat Panel PC
the system IDE drive can support. Block mode is also called block transfer, multiple
commands, or multiple sector read/write.
Disabled
Enabled
Onboard Serial Port 1 [3F8/IRQ4]
Use the Onboard Serial Port 1 option to select the I/O address and IRQ for the onboard
serial port 1. The serial port can be disabled or the I/O address and the IRQ can be
automatically selected by the BIOS. The Onboard Serial Port 1 options are:
Disabled
3F8/IRQ4 (Default)
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Auto
Onboard Serial Port 2 [2F8/IRQ3]
Block mode is not supported.
(Default) Block mode is supported.
Use the Onboard Serial Port 2 option to select the I/O address and IRQ for the onboard
serial port 2. The serial port can be disabled or the I/O address and the IRQ can be
automatically selected by the BIOS. The Onboard Serial Port 2 options are:
Disabled
3F8/IRQ4
2F8/IRQ3 (Default)
3E8/IRQ4
2E8/IRQ3
Auto
Touch controller Port [2E8]
Use the Touch controller Port option to select the I/O address for the onboard touch
panel controller port. The touch panel controller port can be disabled or the I/O address
can be automatically selected by the BIOS. The Touch controller Port options are:
Page 89
Disabled
3F8
2F8
3E8
2E8 (Default)
Touch controller Use IRQ [IRQ7]
Use the Touch controller Use IRQ option to select the IRQ for the onboard touch panel
controller port. The touch panel controller port can be disabled or the IRQ can be
automatically selected by the BIOS. The Touch controller Use IRQ options are:
IRQ5
IRQ7 (Default)

5.6 Power Management Setup

AFOLUX LX Series Flat Panel PC
Use the Power Management Setup menu (4BIOS Menu 6) to set the BIOS power
management and saving features.
Page 90
AFOLUX LX Series Flat Panel PC
BIOS Menu 6: Power Management Setup
ACPI Function [Enabled]
Use the ACPI Function to enable the ACPI (Advanced Configuration and Power Interface)
function.
Disabled
Enabled
ACPI function disabled.
(Default) ACPI function enabled.
Page 91
ACPI Suspend Type [S1(POS)]
Use the ACPI Suspend Type BIOS option to specify the sleep state the system enters
when not being used.
AFOLUX LX Series Flat Panel PC
S1 (POS)
S3 (STR)
S1 & S3
Power Management [ACPI]
Use the Power Management option to set the power management type used by the
system.
Disabled
Legacy
(Default) System appears off. The CPU is stopped; RAM is
refreshed; the system is running in a low power mode.
System appears off. The CPU has no power; RAM is in
slow refresh; the power supply is in a reduced power
mode.
Both suspend modes are implemented
All power management options are turned off. The only
user configurable options are the power button and
alarm settings.
Standby and suspend modes can be set.
APM
ACPI
x Standby Mode [Disabled]
The Standby Mode option can only be selected if the Power Management option is set to Legacy. The Standby Mode specifies the amount of time the system can be inactive before the system enters standby mode. The Standby Mode options are:
Disabled (Default)
1 Sec
5 Sec
Page 92
Advanced power management (APM) is activated
(Default) Advanced Configuration and Power Interface (ACPI) is
activated.
AFOLUX LX Series Flat Panel PC
10 Sec
15 Sec
30 Sec
45 Sec
1 Min
5 Min
10 Min
15 Min
30 Min
45 Min
60 Min
90 Min
120 Min
x Suspend Mode [Disabled]
The Suspend Mode option can only be selected if the Power Management option is set to Legacy. The Suspend Mode specifies the amount of time the system can be inactive before the system enters suspend mode. The Suspend Mode options are:
Disabled (Default)
1 Sec
5 Sec
10 Sec
15 Sec
30 Sec
45 Sec
1 Min
5 Min
10 Min
15 Min
30 Min
45 Min
60 Min
90 Min
120 Min
Page 93
Modem Use of IRQ
Use the Modem Use of IRQ to select the IRQ address for the system modem. The
following IRQ addresses are available.
N/A
3 (Default)
4
5
7
9
10
11
Wake-on Lan Control [Disabled]
AFOLUX LX Series Flat Panel PC
Use the Wake-on Lan Control option to enable activity on the LAN to rouse the system
from a suspend or doze state.
Disabled
Enabled
Soft-Off by PWR-BTTN [Instant-Off]
Use the Soft-Off by PWR-BTTN option to enabled the system to enter a very
low-power-usage state when the power button is pressed.
Instant-Off
Delay 4-sec
(Default) Wake event not generated by LAN activity.
Wake event generated by LAN activity.
(Default) When the power button is pressed, the system is
immediately shutdown.
To shutdown the system the power button must be held
down longer than four seconds otherwise the system
enters a low power usage state.
Power-On by Alarm [Disabled]
Use the Power-On by Alarm option to specify when the computer is roused from a
suspended state.
Page 94
AFOLUX LX Series Flat Panel PC
Disabled
Enabled
IRQ Wakeup Events [Press Enter]
To view the IRQ Wakeup Events options press E
(Default) The real time clock (RTC) cannot generate a wake
event
If selected, the following appears with values that
can be selected:
Time (hh:mm:ss) Alarm
After setting the alarm, the computer will turn itself
on from a suspend state when the alarm goes off.
NTER.
BIOS Menu 7: IRQ Wakeup Events
The following IRQs can be used to generate wake events:
IRQ1 (KeyBoard) ON
IRQ3 (COM 2) OFF
Page 95
IRQ4 (COM 1) OFF
IRQ5 (LPT 2) OFF
IRQ6 (Floppy Disk) OFF
IRQ7 (LPT 1) OFF
IRQ8 (RTC Alarm) OFF
IRQ9 (IRQ2 Redir) OFF
IRQ10 (Reserved) OFF
IRQ11 (Reserved) OFF
IRQ12 (PS/2 Mouse) OFF
IRQ13 (Coprocessor) OFF
IRQ14 (Hard Disk) OFF
IRQ15 (Reserved) OFF

5.7 PnP/PCI Configurations

AFOLUX LX Series Flat Panel PC
Use the PnP/PCI Configurations menu (4BIOS Menu 8) to set the plug and play, and PCI
options.
BIOS Menu 8: PnP/PCI Configurations
Page 96
AFOLUX LX Series Flat Panel PC
PNP OS Installed [No]
The PNP OS Installed option determines whether the Plug and Play devices connected to
the system are configured by the operating system or the BIOS.
No
Yes
Init Display First [Onboard]
Use the Init Display First option to select the primary display device.
PCI Slot
Onboard
Reset Configuration Data [Disabled]
(Default) If the operating system does not meet the Plug and Play
specifications, BIOS configures all the devices in the system.
Set this option if the system is running Plug and Play aware
operating systems. The operating system changes the
interrupt, I/O, and DMA settings.
The display connected to the PCI slot is the primary
display.
(Default) The display connected to the onboard connector is the
primary display.
Use the Reset Configuration Data option to reset the Extended System Configuration
Data (ESCD) when exiting setup if booting problems occur after a new add-on is installed.
Disabled
Enabled
Resources Controlled By [Auto (ESCD)]
Use the Resources Controlled By option to either manually configure all the boot and
plug and play devices, or allow BIOS to configure these devices automatically. If BIOS is
allowed to configure the devices automatically IRQs, DMA and memory base address
fields cannot be set manually.
Auto(ESCD)
(Default) ESCD will not be reconfigured
ESCD will be reconfigured after you exit setup
(Default) BIOS automatically configures plug and play devices as
Page 97
AFOLUX LX Series Flat Panel PC
well as boot devices.
Manual
x IRQ Resources [Press Enter]
The IRQ Resources option can only be selected if the Resources Controlled By option is
set to Manual.
The IRQ Resources menu has the following options:
IRQ-3 assigned to
IRQ-4 assigned to
IRQ-10 assigned to
IRQ-11 assigned to
The above options all have the following default options.
PCI Device
Manually configure the plug and play devices and any
other boot devices.
(Default) The IRQ is assigned to legacy ISA for devices compliant
with the original PC AT bus specification, PCI/ISA PNP for
devices compliant with the Plug and Play standard
whether designed for PCI or ISA bus architecture.
Reserved
x Memory Resources [Press Enter]
The Memory Resources menu can only be accessed if the Resources Controlled By option is set to Manual. Use Memory Resources to select a base address and the length
for the memory area used by a peripheral that requires high memory.
The menu has two configurable options:
Reserved Memory Base
Reserved Memory Length
The IRQ is reserved by BIOS.
Page 98
AFOLUX LX Series Flat Panel PC
PCI/VGA Palette Snoop [Disabled]
Use the PCI/VGA Palette Snoop option to enable the system to determine whether or not
some special VGA cards, high-end hardware MPEG decoders and other similar devices
are allowed to look at the VGA palette on the video card so these devices can determine
what colors are in use. This option is needed very rarely and should be left "Disabled"
unless a video device specifically requires the setting to be enabled upon installation.
Disabled
Enabled
(Default) Does not allow the graphics devices to examine the VGA
Allows the graphics devices to examine the VGA palette on

5.8 PC Health Status

The PC Health Status menu (4BIOS Menu 9) has no user configurable options, but shows
system operating parameters that are essential to the stable operation of the system.
palette on the graphics card.
the graphics card.
BIOS Menu 9: PC Health Status
The following system parameters are monitored by the PC Health Status menu.
Page 99
Voltages
AFOLUX LX Series Flat Panel PC
The following voltages are monitored:
Vcore
VccMem
+3.3 V
+12 V
VBAT(V)
5VSB(V)
Page 100
