IEI Integration AFL-07A 08AH User Manual

AFOLUX LX Series Flat Panel PC
AFOLUX LX Series Flat Panel PC
Page i
A
FOLUX LX Series Flat Panel PC
Date Version Changes
2007-10 1.11 Added new model (AFL-10A-LX) information
2007-08 1.10
2007-01 1.00
- Added Bluetooth module specifications
- Added optional GPRS module specifications
- Added AT/ATX mode selection description
- Modified jumper settings information
- Added Watchdog Timer appendix Initial release
Page ii
AFOLUX LX Series Flat Panel PC
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
Page iii
A
FOLUX LX Series Flat Panel PC
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the AFOLUX LX series
or personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the AFOLUX LX series. Cautions are easy to recognize. The word “caution” is
written as “CAUTION,” both capitalized and bold and is followed. The italicized text is the
cautionary message. A caution message is shown below:
Page iv
AFOLUX LX Series Flat Panel PC
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the AFOLUX LX series.
Please take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the AFOLUX LX series. Please
take note messages seriously.
Page v
A
FOLUX LX Series Flat Panel PC
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the AFOLUX LX series from or contact an IEI
sales representative directly. To contact an IEI sales representative,
please send an email to
The items listed below should all be included in the AFOLUX LX series package.
1 x Power cord
1 x Power adapter
1 x Touch pen
1 x User Manual and driver CD
1 x Panel mounting kit (optional)
1 x Wall mounting kit (optional)
1 x 128MB CompactFlash® card with Windows CE 5.0 pre-installed (optional)
1 x 1GB CompactFlash® card with Windows XPE pre-installed (optional)
Images of the above items are shown in Chapter 3 on page
sales@iei.com.tw.
28.
Page vi
AFOLUX LX Series Flat Panel PC
Table of Contents
1 INTRODUCTION..................................................................................................... 1
1.1 AFOLUX LX SERIES FLAT PANEL PC OVERVIEW..................................................... 2
1.1.1 Model Variations................................................................................................ 2
1.1.2 Applications ....................................................................................................... 3
1.1.3 Standard Features.............................................................................................. 3
1.2 EXTERNAL OVERVIEW ............................................................................................... 4
1.2.1 General Description........................................................................................... 4
1.2.2 Front Panel........................................................................................................ 4
1.2.3 Rear Panel ......................................................................................................... 5
1.2.4 Top Panel and Side Panels................................................................................. 5
1.2.5 Bottom Panel...................................................................................................... 6
1.3 INTERNAL OVERVIEW................................................................................................. 7
1.4 SPECIFICATIONS ......................................................................................................... 7
1.4.1 Preinstalled Hardware Components.................................................................. 7
1.4.2 System Specifications......................................................................................... 7
1.4.3 Motherboard Specifications............................................................................... 9
1.4.4 Flat Panel Screen Specifications..................................................................... 10
1.4.5 Touch Screen Specifications............................................................................. 10
1.4.6 Bluetooth Module Specifications ......................................................................11
1.4.7 Optional GPRS Module Specifications............................................................ 12
1.5 DIMENSIONS ............................................................................................................ 13
1.5.1 AFL-07A-LX Dimensions................................................................................. 13
1.5.2 AFL-08A-LX Dimensions................................................................................. 14
1.5.3 AFL-10A-LX Dimensions................................................................................. 15
1.5.4 AFL-12A-LX Dimensions................................................................................. 16
2 MOTHERBOARD.................................................................................................. 17
2.1 INTRODUCTION ........................................................................................................ 18
2.2 CPU SUPPORT.......................................................................................................... 18
2.2.1 AMD® Geode™ LX 800 500MHz Specifications............................................. 18
2.2.2 AMD® Geode™ LX 800 500MHz Power Management................................... 19
Page vii
A
2.3 SYSTEM CHIPSET ..................................................................................................... 19
2.4 GRAPHICS SUPPORT ................................................................................................. 20
2.5 ETHERNET CONTROLLER SPECIFICATIONS ............................................................... 22
2.5.1 Overview.......................................................................................................... 22
2.5.2 Features ........................................................................................................... 22
2.6 PERIPHERAL DEVICE INTERFACES, CONNECTORS, AND SLOTS................................. 23
2.6.1 OEM Options................................................................................................... 23
2.6.2 Internal Slots.................................................................................................... 23
2.6.3 Internal Peripheral Device Connectors........................................................... 23
2.6.4 External Peripheral Device Connectors.......................................................... 24
3 INSTALLATION .................................................................................................... 25
3.1 INSTALLATION PRECAUTIONS ................................................................................... 26
3.2 PREINSTALLED COMPONENTS .................................................................................. 26
3.3 INSTALLATION AND CONFIGURATION STEPS ............................................................. 27
FOLUX LX Series Flat Panel PC
3.4 UNPACKING.............................................................................................................. 27
3.4.1 Packing List ..................................................................................................... 28
3.5 CF CARD INSTALLATION.......................................................................................... 29
3.6 HDD INSTALLATION (AF-12A-LX ONLY)............................................................... 31
3.7 AT/ATX MODE SELECTION ..................................................................................... 33
3.7.1 AT Power Mode................................................................................................ 33
3.7.2 ATX Power Mode............................................................................................. 34
3.8 MOUNTING THE SYSTEM .......................................................................................... 34
3.8.1 Wall Mounting.................................................................................................. 34
3.8.2 Panel Mounting................................................................................................ 37
3.8.3 Arm Mounting .................................................................................................. 40
3.8.4 Cabinet and Rack Installation ......................................................................... 42
3.9 BOTTOM PANEL CONNECTORS ................................................................................. 44
3.9.1 LAN Connection............................................................................................... 44
3.9.2 Serial Device Connection ................................................................................ 45
3.9.3 USB Device Connection................................................................................... 47
4 SYSTEM MAINTENANCE .................................................................................. 49
4.1 SYSTEM MAINTENANCE INTRODUCTION .................................................................. 50
4.2 MOTHERBOARD REPLACEMENT ............................................................................... 50
Page viii
AFOLUX LX Series Flat Panel PC
4.3 INTERNAL ALUMINUM COVER REMOVAL ................................................................. 50
4.3.1 AFL-07A-LX Internal Aluminum Cover Removal............................................ 51
4.3.2 AFL-08A-LX Internal Aluminum Cover Removal............................................ 52
4.3.3 AFL-10A-LX Internal Aluminum Cover Removal............................................ 54
4.3.4 AFL-12A-LX Internal Aluminum Cover Removal............................................ 55
4.4 MEMORY MODULE REPLACEMENT .......................................................................... 56
4.5 JUMPER SETTINGS .................................................................................................... 57
4.5.1 JP3: COM3 Pin-9 Signal Select Jumper Settings............................................ 58
4.5.2 JP4: COM1 and COM2 Pin-9 Signal Select Jumper Settings......................... 59
4.5.3 JP5: COM2 Mode Select Jumper Settings....................................................... 59
4.5.4 JP6: COM2 Mode Select Jumper Settings....................................................... 60
5 AWARD BIOS SETUP ........................................................................................... 61
5.1 INTRODUCTION ........................................................................................................ 62
5.1.1 Starting Setup................................................................................................... 62
5.1.2 Using Setup...................................................................................................... 62
5.1.3 Getting Help..................................................................................................... 63
5.1.4 Main BIOS Menu ............................................................................................. 63
5.2 STANDARD CMOS FEATURES.................................................................................. 65
5.2.1 IDE Primary Master/Slave .............................................................................. 68
5.3 ADVANCED BIOS FEATURES.................................................................................... 70
5.4 ADVANCED CHIPSET FEATURES ................................................................................ 76
5.5 INTEGRATED PERIPHERALS ...................................................................................... 78
5.6 POWER MANAGEMENT SETUP.................................................................................. 81
5.7 PNP/PCI CONFIGURATIONS ..................................................................................... 88
5.8 PC HEALTH STAT US ................................................................................................. 91
A SAFETY PRECAUTIONS..................................................................................... 93
A.1 SAFETY PRECAUTIONS ............................................................................................ 94
A.1.1 General Safety Precautions............................................................................. 94
A.1.2 Anti-static Precautions.................................................................................... 95
A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 95
A.2.1 Maintenance and Cleaning.............................................................................. 95
A.2.2 Cleaning Tools................................................................................................. 96
B BIOS CONFIGURATION OPTIONS .................................................................. 97
Page ix
A
B.1 BIOS CONFIGURATION OPTIONS ............................................................................. 98
C SOFTWARE DRIVERS....................................................................................... 101
C.1 REMOTE MANAGEMENT TOOL .............................................................................. 102
C.2 TOUCH PANEL DRIVER .......................................................................................... 102
C.2.1 Introduction................................................................................................... 102
C.2.2 Driver Installation......................................................................................... 103
C.2.3 Touch Panel Driver Configuration................................................................ 106
D WA TCHDOG TIME R.......................................................................................... 107
E HAZARDOUS MATERIALS DISCLOSURE....................................................111
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ......................................112
F INDEX.....................................................................................................................115
FOLUX LX Series Flat Panel PC
Page x
AFOLUX LX Series Flat Panel PC
Figure 1-1: Front View...................................................................................................4
Figure 1-2: AFL-07A-LX/AFL-08A-LX Rear View........................................................5
Figure 1-3: AFL-08A-LX Top View ...............................................................................5
Figure 1-4: AFL-08A-LX Side View ..............................................................................6
Figure 1-5: AFOLUX LX Series Bottom View..............................................................6
Figure 1-6: AFL-07A-LX Dimensions (units in mm).................................................13
Figure 1-7: AFL-08A-LX Dimensions (units in mm).................................................14
Figure 1-8: AFL-10A-LX Dimensions (units in mm).................................................15
Figure 1-9: AFL-12A-LX Dimensions (units in mm).................................................16
List of Figures
Figure 2-1: AFLMB-LX800 Connector Overview......................................................24
Figure 3-1: Back Cover Retention Screws................................................................29
Figure 3-2: AFL-08A-LX Plastic Back Cover Removal.............................................30
Figure 3-3: CF Card Location.....................................................................................30
Figure 3-4: AFL-08A-LX Plastic Back Cover Replacement.....................................30
Figure 3-5: AFL-12A-LX Aluminum Back Cover Retention Screws.......................31
Figure 3-6: Four Hexagonal Pillars on the Bottom Panel........................................31
Figure 3-7: AFL-12A-LX HDD Bracket Retention Screws........................................32
Figure 3-8: AF-12A-LX HDD Retention Screws ........................................................32
Figure 3-9: AT/ATX Switch Location.........................................................................33
Figure 3-10: Wall-mounting Bracket..........................................................................35
Figure 3-11: Chassis Support Screws.......................................................................36
Figure 3-12: Secure the Panel PC..............................................................................37
Figure 3-13: AFL-07A-LX Panel Opening..................................................................38
Figure 3-14: AFL-08A-LX Panel Opening..................................................................38
Figure 3-15: AFL-10A-LX Panel Opening..................................................................38
Figure 3-16: AFL-12A-LX Panel Opening..................................................................39
Figure 3-17: Tighten the Panel Mounting Clamp Screws (AFL-10A/12A-LX)........40
Figure 3-18: AFL-07A-LX/AFL-08A-LX Arm Mounting Retention Screw Holes.....41
Page xi
A
Figure 3-19: AFL-10A-LX/AFL-12A-LX Arm Mounting Retention Screw Holes.....41
Figure 3-20: The Rack/Cabinet Bracket ....................................................................42
Figure 3-21: Secure the Rack/Cabinet Bracket (AFL-10A-LX/AFL-12A-LX) ..........43
Figure 3-22: Install into a Rack/Cabinet....................................................................44
Figure 3-23: LAN Connection.....................................................................................45
Figure 3-24: Serial Device Connector .......................................................................46
Figure 3-25: USB Device Connection........................................................................47
Figure 4-1: AFL-07A-LX Aluminum Back Cover Retention Screws.......................51
Figure 4-2: Four Hexagonal Pillars on the Bottom Panel (AFL-07A-LX) ...............51
Figure 4-3: AFL-08A-LX Aluminum Back Cover Retention Screws.......................52
Figure 4-4: Four Hexagonal Pillars on the Bottom Panel (AFL-08A-LX) ...............52
Figure 4-5: Wireless Module Cables..........................................................................53
Figure 4-6: The Internal Aluminum Cover Removal ................................................53
FOLUX LX Series Flat Panel PC
Figure 4-7: Power Switch Cable.................................................................................54
Figure 4-8: AFL-10A-LX Aluminum Back Cover Retention Screws.......................54
Figure 4-9: Four Hexagonal Pillars on the Bottom Panel (AFL-10A-LX) ...............54
Figure 4-8: AFL-12A-LX Aluminum Back Cover Retention Screws.......................55
Figure 4-9: Four Hexagonal Pillars on the Bottom Panel (AFL-12A-LX) ...............55
Figure 4-10: SO-DIMM Socket Location....................................................................56
Figure 4-11: DDR SO-DIMM Module Installation......................................................57
Figure 4-12: Jumper Locations..................................................................................58
Page xii
AFOLUX LX Series Flat Panel PC
Table 1-1: Model Variations..........................................................................................2
Table 1-2: AFOLUX LX Series System Specifications...............................................9
Table 1-3: Motherboard Specifications.......................................................................9
Table 1-4: TFT LCD Monitor Specifications..............................................................10
Table 1-5: Touch Panel Specifications......................................................................11
Table 1-6: Bluetooth Module Specifications ............................................................12
Table 1-7: GPRS Module Specifications...................................................................12
Table 2-1: Geode LX Graphics Features...................................................................21
Table 4-1: COM3 Pin-9 Signal Select Jumper Settings ...........................................58
List of Tables
Table 4-2: COM1 and COM2 Pin-9 Signal Select Jumper Settings ........................59
Table 4-3: COM2 Mode Select Jumper Settings.......................................................59
Table 4-4: COM2 Mode Select Jumper Settings.......................................................60
Table 5-1: BIOS Navigation Keys...............................................................................63
Page xiii
A
FOLUX LX Series Flat Panel PC
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page xiv
AFOLUX LX Series Flat Panel PC
Chapter
1

1 Introduction

Page 1
A
FOLUX LX Series Flat Panel PC

1.1 AFOLUX LX Series Flat Panel PC Overview

The AFOLUX LX series flat panel PC is a flexible, multi-functional and fanless flat panel
PC that can be applied in diverse operational environments and implemented in
multi-faceted applications. The AFOLUX LX series comes fully kitted with a
high-performance motherboard and a host of other peripheral interface connectors. The
integrated wireless LAN module and Bluetooth module ensure an uninterrupted wireless
connection. The flexible AT/ATX power mode selection allows the AFOLUX series to meet
multiple application requirements. The AFOLUX LX series is designed for ease of use and
easy installation.

1.1.1 Model Variations

The models of AFOLUX LX series are listed in Table 1-1.
AFL-07A-LX Brightness LCD Memory Wireless LAN Touch screen
/WT-R/256MB-R11 /WT-R/512MB-R11 AFL-08A-LX Brightness LCD Memory Wireless Touch screen /WT-R/256MB-R11 /WT-R/512MB-R11 AFL-08AH-LX Brightness LCD Memory Wireless Touch screen /WT-R/256MB-R11 /WT-R/512MB-R11 AFL-10A-LX Brightness LCD Memory Wireless Touch screen /WT-R/256MB-R11 /WT-R/512MB-R11 AFL-12A-LX Brightness LCD Memory Wireless Touch screen /WT-R/256MB-R11 /WT-R/512MB-R11
350cd/m2 7” 256MB DDR Yes Yes
350cd/m2 7” 512MB DDR Yes Yes
220cd/m2 8.4” 256MB DDR Yes Yes
220cd/m2 8.4” 512MB DDR Yes Yes
450cd/m2 8.4” 256MB DDR Yes Yes
450cd/m2 8.4” 512MB DDR Yes Yes
400cd/m2 10.4” 256MB DDR Yes Yes
400cd/m2 10.4” 512MB DDR Yes Yes
450cd/m2 12.1” 256MB DDR Yes Yes
450cd/m2 12.1” 512MB DDR Yes Yes
Table 1-1: Model Variations
Page 2
AFOLUX LX Series Flat Panel PC

1.1.2 Applications

The AFOLUX LX series all-in-one panel PC is designed for multiple applications. Its
durability and strength makes it an ideal choice for public access computers. Some
possible applications include:
Vehicle Interior device
o Truck PC o Logistic car PC
General computing
o PC based testing center o Distance learning
Industrial applications
o Plant environment monitoring system o Factory automation platform o Manufacturing shop flow o Equipment and device control
Home and building automation
o Digital surveillance system o E-home platform o Home IA control terminal
Self-Service Kiosk
o Receptionist kiosk in hotel and business premises o Self registration terminal in hospital and airport o Ticket vending machine for transportation use

1.1.3 Standard Features

Some of the standard features of the AFOLUX LX series flat panel PC include:
Fanless Design
AMD® Geode LX-800 processor
Rugged mechanism design with ABS/PC case
IP 64 dustproof and waterproof front panel
One 256MB/512MB DDR memory module pre-installed
AT/ATX power mode supported
Page 3
A
Wireless LAN integrated with PIFA antenna
Dual 10/100Mbps Ethernet support
One CompactFlash
Simplified installation process
RoHS compliance

1.2 External Overview

1.2.1 General Description

The AFOLUX LX series is a stylish flat panel PC that comprises of a screen, rear panel,
top panel, bottom panel and two side panels (left and right). An ABS/PC plastic front frame
surrounds the front screen. The rear panel provides screw holes for a wall-mounting
bracket compliant with VESA FDMI standard. The bottom panel provides access to
external interface connectors that include LAN, USB 2.0, serial port, reset button, power
FOLUX LX Series Flat Panel PC
®
Type II socket support
connector and power switch.

1.2.2 Front Panel

The front side of the AFOLUX LX series is a flat panel TFT LCD screen surrounded by an
ABS/PC plastic frame.
Page 4
Figure 1-1: Front View
AFOLUX LX Series Flat Panel PC

1.2.3 Rear Panel

The rear panel provides access to retention screw holes that support the wall mounting.
Refer to
Figure 1-2.
Figure 1-2: AFL-07A-LX/AFL-08A-LX Rear View

1.2.4 Top Panel and Side Panels

The top panel and side panels of AFOLUX LX series provides access to slots that support
panel mount and rack mount (
Figure 1-3: AFL-08A-LX Top View
Figure 1-3 and Figure 1-4).
Page 5
A
Figure 1-4: AFL-08A-LX Side View

1.2.5 Bottom Panel

The bottom panel of the AFOLUX LX series has the following I/O interfaces (Figure 1-5):
1 x RS-232 serial port connector
1 x RS-232 or RS-422/485 serial port connector (selected by a jumper)
FOLUX LX Series Flat Panel PC
1 x AC power adapter connector
2 x RJ-45 10/100Mbps Ethernet connectors
2 x USB 2.0 connectors
1 x Power switch
1 x Reset button
Figure 1-5: AFOLUX LX Series Bottom View
Page 6
AFOLUX LX Series Flat Panel PC

1.3 Internal Overview

The AFOLUX LX series internal components are protected in a plastic back cover. An
AT/ATX switch is in the left side of the aluminum chassis inside the plastic cover. Other
internal components, the motherboard, wireless LAN module and DDR memory module,
are installed in the aluminum chassis on a metal sheet that protects the rear of the TFT
LCD screen. Below the metal sheet is a circuit board that is connected to the screen and
the motherboard.

1.4 Specifications

1.4.1 Preinstalled Hardware Components

The AFOLUX LX series flat panel PC has the following preinstalled components:
1 x Motherboard
1 x TFT LCD screen
1 x Touch screen
1 x Inverter
1 x Wireless LAN module
1 x DDR memory module
1 x Bluetooth module
1 x AT/ATX switch
1 x GPRS module (optional)
The technical specifications for some of these components and the system are shown in
the sections below.

1.4.2 System Specifications

The technical specifications for the AFOLUX LX series systems are listed in Table 1-2.
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX Front Panel ABS/PC plastic front panel Chassis Aluminum chassis LCD Panel 7” 8.4” 10.4” 12.1”
Page 7
A
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX Resolution 800 x 480 800 x 600 800 x 600 1024 x 768 Brightness 350cd/m
Contrast Ratio 400:1 500:1 500:1 700:1 Viewing Angle (H-V) 140/100 130/110 120/100 160/160 Backlight MTBF 30000 20000 50000 50000
2
220cd/m2 or
450cd/m2
FOLUX LX Series Flat Panel PC
400cd/m
2
450cd/m2
Touch Screen 4-wire resistive type Extension 1 x Mini PCI (for wireless LAN module)
1 x Bluetooth module (USB interface, Bluetooth v2.0)
Drive Bay N/A N/A N/A GPRS Module N/A N/A Optional SSD CompactFlash Audio AMP 1.5W + AMP 1.5W (internal speaker) I/O 1 x RS-232 serial port
1 x RS-232 or RS-422/485 serial port
2 x 10/100 Mbps Ethernet port
2 x USB 2.0 port
1 x Power switch
1 x Reset button
1 x AT/ATX power switch (internal)
Power 12V, 36W DC power adapter Power Consumption 20W 20W 25W 29W
®
4-wire resistive type 5-wire resistive type 5-wire resistive type
1 x 2.5” HDD bay or
optional GPRS module
Type II
Mounting Feature Panel, Rack, Wall, Arm, Stand Operating Temperature Relative Humidity 5% ~ 80% RH, non-condensing Vibration 5 - 17Hz, 0.1” double amplitude displacement.
Shock 10G Acceleration, peak to peak (11ms) Dimension (W x H x D) Net/Gross Weight 0.6 Kg 0.8 Kg 1.4kg 1.8 Kg
Page 8
0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC-50ºC
0ºC-40ºC (using HDD)
17 - 640Hz, 1.5G acceleration, peak to peak.
226 x 140 x 41 234 x 184 x 42 276 x 227 x 50.7 304 x 246 x 50
AFOLUX LX Series Flat Panel PC
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX Front Panel Protection Safety Meets UL / CE / CCC EMC Meets CE / FCC class B
IP 64 compliant
Table 1-2: AFOLUX LX Series System Specifications

1.4.3 Motherboard Specifications

The AFOLUX LX series come with an AFLMB-LX800 motherboard. The technical
specifications of the motherboard are listed in
Specification AFLMB-LX800 CPU AMD Southbridge Chipset AMD Display CRT integrated in AMD
®
Geode™ LX 800 500Mhz
®
Geode™ CS5536
24-bit TTL integrated in AMD
Table 1-3.
®
Geode™ LX800
®
Geode™ LX800
18-bit LVDS supported by buffer
Memory Supports one 1GB DDR 333/400 200-pin SO-DIMM SDRAM module Extension One mini PCI slot BIOS Award BIOS SSD CF Type II Super I/O N/A for legacy free Audio AC'97 Codec Realtek ALC203, AMP 2W LAN 10/100 Base-T dual RTL8100C COM 1 x RS-232 serial port
1 x RS-232 or RS-422/485 serial port
IDE One 44-pin IDE connects to two IDE devices Touch Screen Controller DMC9000 Power Supply DC 12V In Dimensions 102mm x 186mm
Table 1-3: Motherboard Specifications
Page 9
A
FOLUX LX Series Flat Panel PC

1.4.4 Flat Panel Screen Specifications

The AFOLUX LX series come with a TFT LCD monitor at the front of the flat panel PC (see
Figure 1-1). The specifications for the LCD monitor are shown in Table 1-4 below.
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX Model DATA IMAGE
FG070050DNCWAG01
Size 7” 8.4” 10.4” 12.1” Resolution 800 x 480 (VGA) 800 x 600 (SVGA) 800 x 600 (SVGA) 1024 x 768 (XGA) Active Area (mm) 152.4 x 91.44 170.4 x 127.8 211.2 x 158.4 245.76 x 184.32 Pixel Pitch (mm) 0.1905 x 0.1905 0.213 x 0.213 0.264 x 0.264 0.240 x 0.240 LCD Color Native 262K colors Native 262K colors Native 262K colors Native 262K colors View Angel (H/V) 140/100 130/110 120/100 160/160 Brightness (cd/m2) 350 220 400 450 Contrast Ratio 400:1 500:1 500:1 700:1 Response Time (ms) 12(Tr) / 18(Tf) 10(Tr) / 25(Tf) 8(Tr) / 17(Tf) 6(Tr) / 17(Tf) Power Consumption 2.2W 3.3W 6.2W 4W Supply Voltage (V) 3.3 3.3 3.3 3.3 Backlight 1 CCFL 1 CCFL 2 CCFL 2 CCFL Backlight MTBF (hrs.) 30000 20000 50000 50000 Dimensions (mm) 165.0 x 104.0 x 5.5
AUO-G084SN03 Toshiba
LTA104D182F
203.0 x 142.5 x 5.7 242.0x178.45x3.2 260 x 204 x 12.2
CMO-G121X1-L01
Table 1-4: TFT LCD Monitor Specifications

1.4.5 Touch Screen Specifications

The AFOLUX LX series come with an analog resistive type touch panel. Table 1-5 lists the
touch panel specifications.
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX
Model PANJIT 1070404C
Type Analog Resistive Type Touch Panel
Wire Type 4-wire 4-wire 5-wire 5-wire
Page 10
PANJIT 1084403B PANJIT 1104502A PANJIT 1121505B
AFOLUX LX Series Flat Panel PC
Viewing Area (mm) 154.90 x 93.94 130.75 x 173.38 219.8 x 166.8 188.0 x 250.0
Active Area (mm) 152.40 x 91.44 127.78 x 170.38 212.1 x 159.3 185.0 x 246.0
Total Transmission 78%
Maximum Voltage DC7V
Connector Type FPC.
Operating Temperature -10°C ~ 60°C -10°C ~ 40°C
Operating Humidity 20% ~ 90% RH
Storage Temperature -20°C ~ 70°C
Storage Humidity 20% ~ 90% RH
Dimensions 165 x 104 x 1.4 145.5 x 188 x 2.1
Table 1-5: Touch Panel Specifications

1.4.6 Bluetooth Module Specifications

The AFOLUX LX series are all integrated with a Bluetooth module. The Bluetooth module
enables the transmission between various peripheral devices through a Bluetooth network.
The peripheral devices may include:
Headsets
Barcode readers
PDA
Printers
Cell phones
Keyboard and mouse
The technical specifications of the Bluetooth module are listed in
238.8x 188.7 x 2.6 204 x 268 x 2.1
Table 1-6.
Specification Bluetooth Module Standard Bluetooth v2.0 Frequency Band 2.402GHz~2.480GHz unlicensed ISM band Modulation Method GFSK for 1Mbps
π/4-DQPSK for 2Mbps
8-DPSK for 3Mbps
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)
Page 11
A
RF Output Power Class 2 (under 4dBm) Antenna Terminal 50 Ohms DC Power DC 3.3V or DC 5V I/O Interface USB 2.0 interface Two GPIO Interface LED link indicator interface Dimensions 35mm x 11mm Operating System Windows XP, Windows 2000, Windows 98SE, Windows Me
FOLUX LX Series Flat Panel PC
Table 1-6: Bluetooth Module Specifications

1.4.7 Optional GPRS Module Specifications

The GPRS module is one of the OEM options for the AFOLUX LX series. The technical
specifications of the GPRS module are listed in
Specification GPRS Module EDG/GPRS/GSM Air Interface
EGPRS/GPRS (PS) Feature Set
USB Interface USB 2.0 +5VDC SIM Card Interface 3.0V interface Temperature -30°C ~ +65°C
Quad-band operation GSM850, EGSM 900, DCS 1800, PCS 1900
GSM Power Class 4 (2W) for 850/900 bands
GSM Power Class 1 (1W) for 1800/1900 bands
EDFE class E2 (+27dBm in 850/900 bands,
+26dBm in 1800/1900 bands)
GSM/GPRS Rel ’97; PCS 1900 Rel ’98; EGPRS Rel ’99 compliant
GPRS Class 10, coding schemes 1-4
EDGE Class 10, Multi-slot classes 1-9
GPRS/EGPRS Class B type 1 MT
Link Adaptation
Incremental redundancy (IR)
Table 1-7.
Humidity Up to 95%, non-condensing Dimensions 109.3mm x 42.7mm x 17.7mm Operating System Windows 2000/XP Home/XP Professional
Table 1-7: GPRS Module Specifications
Page 12
AFOLUX LX Series Flat Panel PC

1.5 Dimensions

1.5.1 AFL-07A-LX Dimensions

The dimensions of the AFL-07A-LX flat panel PC are shown in Figure 1-6 below.
Figure 1-6: AFL-07A-LX Dimensions (units in mm)
Page 13
A

1.5.2 AFL-08A-LX Dimensions

The dimensions of the AFL-08A-LX flat panel PC are shown in Figure 1-7 below.
FOLUX LX Series Flat Panel PC
Figure 1-7: AFL-08A-LX Dimensions (units in mm)
Page 14
AFOLUX LX Series Flat Panel PC

1.5.3 AFL-10A-LX Dimensions

The dimensions of the AFL-10A-LX flat panel PC are shown in Figure 1-7 below.
Figure 1-8: AFL-10A-LX Dimensions (units in mm)
Page 15
A

1.5.4 AFL-12A-LX Dimensions

The dimensions of the AFL-12A-LX flat panel PC are shown in Figure 1-7 below.
FOLUX LX Series Flat Panel PC
Figure 1-9: AFL-12A-LX Dimensions (units in mm)
Page 16
AFOLUX LX Series Flat Panel PC
Chapter
2

2 Motherboard

Page 17
A

2.1 Introduction

The AFOLUX LX series flat screen PC contains the AFLMB-LX800 motherboard. The
motherboard is the heart of any computer and is responsible for transmitting, receiving
and processing data as well as driving the different onboard devices. This chapter gives a
brief introduction to the AFLMB-LX800 motherboard.

2.2 CPU Support

The AFLMB-LX800 motherboard comes with a preinstalled AMD® Geode™ LX 800
500MHz CPU.
2.2.1 AMD® Geode™ LX 800 500MHz Specifications
The specifications for the 500MHz AMD® Geode™ LX 800 are listed below
FOLUX LX Series Flat Panel PC
x86/x87-compatible core
Processor frequency up to 500 MHZ
64K I/64K D L1 cache and 128K L2 cache
Split I/D cache/TLB (Translation Look-Aside Buffer)
64-bit DDR Memory interface up to 400MHz (LX 800), up to 333MHz (LX 700)
Integrated FPU that supports the Intel MMX
instruction sets
9 GB/s internal GeodeLink™ Interface Unit (GLIU)
Security Block
®
and AMD 3DNow!™ Technology
o 128-bit AES (CBC/ECB) o True Random Number Generator
High-resolution CRT and TFT outputs (simultaneous operation)
o Support for High Definition (HD) and Standard Definition (SD) standards o Support 1920x1440 in CRT mode and 1600x1200 in TFT mode
VESA 1.1 and 2.0 VIP/VDA support
0.13 micron process
481-terminal PBGA (Plastic Ball Grid Array) with internal heatspreader
Page 18
AFOLUX LX Series Flat Panel PC
2.2.2 AMD® Geode™ LX 800 500MHz Power Management
The power management for the 500MHz AMD® Geode™ LX 800 is listed below:
1.8W Typical (3.9W TDP) @ 500MHz
GeodeLink active hardware power management
Hardware support for standard ACPI software power management
I/O companion SUSP#/SUSPA# power controls
Lower power I/O
Wakeup on SMI/INTR

2.3 System Chipset

The AFLMB-LX800 motherboardl has a preinstalled AMD® Geode™ CS5536 system
chipset. The system chipset features are listed below.
GeodeLink™ Interface Unit
o 64-bit, 66MHz operation o PCI VSM (Virtual System Module) that makes the interface transparent to
applications software and BIOS
o Programmable routing descriptors, use and activity monitors, and SSMI
(Synchronous System Management Interrupt)
ATA-6 Controller
o 100 MB/second IDE Controller in UDMA mode per the ATA-6
specification
o 5V interface
Flash Interface
o Multiplexed with IDE interface Connects to an array of industry standard
NAND Flash and/or NOR Flash
USB Controller
o 4 USB ports (two internal and two external) o Supports both USB 1.1 and USB 2.0 o 3 host ports o 1 host/device
Page 19
A
Audio Codec 97 (AC97) Controller
FOLUX LX Series Flat Panel PC
o AC97 specification v2.3 compliant interface to multiple audio codecs:
Serial In, Serial Out, Sync Out, Bit Clock In
o Legacy “PC Beep” support
Diverse Device
o 82xx Legacy Devices o IR Communication Port o System Management Bus (SMB) Controller o LPC (Low Pin Count) Port o General Purpose I/Os (GPIOs) o 8 Multi-Function General Purpose Timers (MFGPTs) o Real-Time Clock (RTC) with CMOS RAM o Power Management Controller o ACPI v2.0 compliant

2.4 Graphics Support

The Geode LX processor’s Graphics Processor is a BitBLT/vector engine that supports
pattern generation, source expansion, pattern/source transparency, 256 ternary raster
operations, alpha blenders to support alpha- BLTs, incorporated BLT FIFOs, a GeodeLink
interface and the ability to throttle BLTs according to video timing. New features added to
the Graphics Processor include:
Command buffer interface
Hardware accelerated rotation BLTs
Color depth conversion
Paletized color
Full 8x8 color pattern buffer
Separate base addresses for all channels
Monochrome inversion
Table 2-1: Geode LX Graphics Features lists a complete list of Geode LX graphics
Page 20
features. For more details, please refer to the AMD website or the Geode LX series data
book available from AMD.
AFOLUX LX Series Flat Panel PC
Feature AMD Geode™ LX Processor
Color Depth 8, 16, 32 bpp (A) RGB 4 and 8-bit indexed
ROPs 256 (2-src, dest and pattern)
BLT Buffers FIFOs in Graphics Processor
BLT Splitting Managed by hardware
Video Synchronized BLT/Vector Throttle by VBLANK
Bresenham Lines Yes
Patterned (stippled) Lines Yes
Screen to Screen BLT Yes
Screen to Screen BLT with mono expansion Yes
Memory to Screen BLT Yes (throttled rep movs writes)
Accelerated Text No
Pattern Size (Mono) 8x8 pixels
Pattern Size (Color) 8x8 pixels
Monochrome Pattern Yes (with inversion)
Dithered Pattern (4 color) No
Color Pattern 8, 16, 32 bpp
Transparent Pattern Monochrome
Solid Fill Yes
Pattern Fill Yes
Transparent Source Monochrome
Color Key Source Transparency Y with mask
Variable Source Stride Yes
Variable Destination Stride Yes
Destination Write Bursting Yes
Selectable BLT Direction Vertical and Horizontal
Alpha BLT
VGA Support Decodes VGA Register
Pipeline Depth Unlimited
Accelerated Rotation BLT 8, 16, 32 bpp
Yes (constant α, α/pix, or sep. α channel)
Color Depth Conversion 5:6:5, 1:5:5:5, 4:4:4:4, 8:8:8:8
Table 2-1: Geode LX Graphics Features
Page 21
A

2.5 Ethernet Controller Specifications

2.5.1 Overview

The Realtek RTL8100C(L) is a highly integrated and cost-effective single-chip Fast
Ethernet controller. It is enhanced with an ACPI (Advanced Configuration Power Interface)
management function for PCI in order to provide efficient power management for
advanced operating systems with OSPM (Operating System Directed Power
Management).
The RTL8100C(L) also supports remote wake-up (including AMD Magic Packet™ and
Microsoft® Wake-up frame) to increase cost-efficiency in network maintenance and
management. It is an ideal solution for notebook/motherboard-embedded network
designs.
FOLUX LX Series Flat Panel PC

2.5.2 Features

Integrates Fast Ethernet MAC, physical chip, and transceiver onto a single
chip
10Mbps and 100Mbps operation
Supports 10Mbps and 100Mbps N-way auto-negotiation
Supports 25MHz Crystal or 25MHz OSC as the internal clock source
Complies with PC99/PC2001 standards
Supports ACPI power management
Provides PCI bus master data transfer
Provides PCI memory space or I/O space mapped data transfer
Supports PCI clock speed of 16.75MHz-40MHz
Advanced power saving mode
Supports Wake-on-LAN and remote wake-up (AMD Magic Packet™, Link
Change, and Microsoft® Wake-up frame)
Half/Full duplex capability
Supports Full Duplex Flow Control (IEEE 802.3x)
Page 22
Provides interface to 93C46 EEPROM to store resource configuration and ID
parameters
Provides PCI clock run pin
AFOLUX LX Series Flat Panel PC
Provides LED pins for network operation status indication
2.5/3.3V power supply with 5V tolerant I/Os

2.6 Peripheral Device Interfaces, Connectors, and Slots

The peripheral device connectors, interfaces and slots on the WAFER-LX motherboard
are listed in the sections below.

2.6.1 OEM Options

Many of the peripheral device connectors listed below are not connected to any devices.
These connectors are reserved for OEM customizations. For a customized option, please
contact the vendor, reseller or IEI sales representative.

2.6.2 Internal Slots

The slots listed below can all be found on the WAFER-LX motherboard.
1 x 200-pin DDR SO-DIMM socket
1 x CFII slot

2.6.3 Internal Peripheral Device Connectors

The peripheral device connectors listed below are located on the AFLMB-LX800
motherboard and used for the AFOLUX series.
connectors that are used for the AFOLUX series.
1 x Audio connector
1 x CompactFlash
1 x Inverter connector
1 x LCD interface connector
1 x LED connector
1 x Mini PCI socket (for wireless LAN module)
1 x Power switch connector
®
(CF) slot
Figure 2-1 shows the overview of the
1 x Touch screen connector
Page 23
A
FOLUX LX Series Flat Panel PC
Figure 2-1: AFLMB-LX800 Connector Overview

2.6.4 External Peripheral Device Connectors

The peripheral device connectors listed below are located on the rear panel of the
AFLMB-LX800 motherboard.
2 x Ethernet connectors
2 x USB connectors
2 x Serial port connectors
1 x Reset button
1 x Power connector
Page 24
AFOLUX LX Series Flat Panel PC
Chapter
3

3 Installation

Page 25
A

3.1 Installation Precautions

When installing the flat panel PC, please follow the precautions listed below:
Power turned off: When installing the flat panel PC, make sure the power is
off. Failing to turn off the power may cause severe injury to the body and/or
damage to the system.
Certified Engineers: Only certified engineers should install and modify
onboard functionalities.
Mounting: The flat panel PC is a heavy device. When mounting the system
onto a rack, panel, wall or arm please make sure that at least two people are
assisting with the procedure.
Anti-static Discharge: If a user open the rear panel of the flat panel PC, to
configure the jumpers or plug in added peripheral devices, ground themselves
first and wear and anti-static wristband.
FOLUX LX Series Flat Panel PC

3.2 Preinstalled Components

The following components are all preinstalled.
Motherboard
TFT LCD screen
256MB/512MB DDR memory module
Resistive type touch screen
Wireless LAN module
Bluetooth module
AT/ATX power switch
Preinstalled OEM customizations may include the following.
Different DDR memory module
Hard disk drive/GPRS module (AFL-12A-LX model only)
Installation of some of the components are described in the following sections.
Page 26
AFOLUX LX Series Flat Panel PC

3.3 Installation and Configuration Steps

The following installation steps must be followed.
Step 1: Unpack the flat panel PC
Step 2: Install CF card
Step 3: Install HDD (AFL-12A-LX model only)
Step 4: Mount the flat panel PC
Step 5: Connect peripheral devices to the bottom panel of the flat panel PC
Step 6: Configure the systemStep 0:

3.4 Unpacking

To unpack the flat panel PC, follow the steps below:
WARNING!
The front side LCD screen has a protective plastic cover stuck to the
screen. Only remove the plastic cover after the flat panel PC has been
properly installed. This ensures the screen is protected during the
installation process.
Step 1: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
external (second) box.
Step 2: Open the external (second) box.
Step 3: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
internal (first) box.
Step 4: Lift the monitor out of the boxes.
Step 5: Remove both polystyrene ends, one from each side.
Page 27
A
Step 6: Pull the plastic cover off the flat panel PC.
Step 7: Make sure all the components listed in the packing list are present. Step 0:

3.4.1 Packing List

The AFOLUX LX flat panel PC is shipped with the following components:
Quantity Item Image
Standard
1 AFOLUX LX series panel PC
1 Power adapter
1 Power cord
FOLUX LX Series Flat Panel PC
1 User manual CD and driver CD
1 Touch pen
Optional
4
Panel mounting clamp
(6)
(AFL-12A-LX)
1 Wall mounting kit
1 128MB CompactFlash® card with Windows
CE 5.0 pre-installed and SDK
Page 28
AFOLUX LX Series Flat Panel PC
1 1GB CompactFlash® card with Windows
XPE pre-installed
If any of these items are missing or damaged, contact the distributor or sales
representative immediately.

3.5 CF Card Installation

The AFOLUX LX series has one CF Type II slot inside the rear panel. To install the CF
card, follow the instructions below.
Step 1: Remove the nine retention screws (
panel PC.
Figure 3-1) and lift the cover off the flat
Figure 3-1: Back Cover Retention Screws
Step 2: For AFL-08A-LX, lift the cover off and pull down the cover a bit to make it
possible to lift the cover further more after removing the nine retention screws
Figure 3-2). Push the power switch while lifting the back cover. More strength is
(
required to separate the cover from the chassis.
Page 29
A
FOLUX LX Series Flat Panel PC
Figure 3-2: AFL-08A-LX Plastic Back Cover Removal
Step 3: Locate the CF slot. Insert a CF card into the slot (
Figure 3-3).
Figure 3-3: CF Card Location
Step 4: Replace the plastic back cover. For AFL-08A-LX, more strength is required
when pushing the bottom part of the cover down to the chassis (
Figure 3-4).
Page 30
Figure 3-4: AFL-08A-LX Plastic Back Cover Replacement
Step 5: Once replaced reinsert the nine previously removed retention screws. Step 0:
AFOLUX LX Series Flat Panel PC

3.6 HDD Installation (AF-12A-LX Only)

To install the HDD into the AF-12A-LX, please follow the steps below:
Step 1: Remove the plastic back cover. See Section
Step 2: Remove the eight retention screws securing the internal aluminum cover
(
Figure 3-5).
3.5 above.
Figure 3-5: AFL-12A-LX Aluminum Back Cover Retention Screws
Step 3: Remove the four hexagonal pillars on the bottom panel.
Figure 3-6: Four Hexagonal Pillars on the Bottom Panel
Step 4: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-12A-LX.
Step 5: Disconnect the power switch cable from the motherboard and remove the
aluminum cover.
Step 6: Remove the four HDD bracket retention screws (
bracket off the panel PC.
Figure 3-7) and lift the HDD
Page 31
A
FOLUX LX Series Flat Panel PC
Figure 3-7: AFL-12A-LX HDD Bracket Retention Screws
Step 7: Attach the HDD brackets to the HDD. To do this, align the four retention screw
holes in the both sides of the HDD bracket with the retention screw holes on the
sides of the HDD. Insert four retention screws into the HDD bracket (
3-8).
Figure
Figure 3-8: AF-12A-LX HDD Retention Screws
Step 8: Connect the IDE cable to the rear of HDD.
Step 9: Install the HDD into the AF-12A-LX by aligning the retention screw holes in the
HDD brackets with the retention screw holes on the chassis. Insert the four
retention screws.
Page 32
Step 10: Re-connect the power switch cable to the motherboard.
Step 11: Replace the aluminum back cover to the chassis.
Step 12: Replace the plastic back cover. Step 0:
AFOLUX LX Series Flat Panel PC

3.7 AT/ATX Mode Selection

AT and ATX power modes can both be used on the AFOLUX LX series. The selection is
made through an AT/ATX switch on the aluminum chassis inside the plastic back cover
(
Figure 3-9). To select AT mode or ATX mode, follow the steps below.
Step 1: Remove the plastic back cover. See Section
Step 2: Locate the AT/ATX switch on the aluminum chassis (
Figure 3-9: AT/ATX Switch Location
Step 3: Adjust the AT/ATX switch. Step 0:
3.5 above.

3.7.1 AT Power Mode

Figure 3-9).
With the AT mode selected, the power is controlled by a central power unit rather than a
power switch. The AFOLUX LX panel PC turns on automatically when the power is
connected. The AT mode benefits a production line to control multiple panel PCs from a
central management center and other applications including:
ATM
Self-service kiosk
Plant environment monitoring system
Factory automation platform
Manufacturing shop flow
Page 33
A

3.7.2 ATX Power Mode

With the ATX mode selected, the AFOLUX LX panel PC goes in a standby mode when it
is turned off. The panel PC can be easily turned on via network or a power switch in
standby mode. Remote power control is perfect for advertising applications since the
broadcasting time for each panel PC can be set individually and controlled remotely. Other
possible application includes
Security surveillance
Point-of-Sale (POS)
Advertising terminal

3.8 Mounting the System

FOLUX LX Series Flat Panel PC
WARNING!
When mounting the flat panel PC onto an arm, onto the wall or onto a
panel, it is better to have more than one person to help with the installation
to make sure the panel PC does not fall down and get damaged.
The four methods of mounting the AFOLUX LX are listed below.
Wall mounting
Panel mounting
Arm mounting
Rack mounting
The four mounting methods are described below.

3.8.1 Wall Mounting

Page 34
To mount the flat panel PC onto the wall, please follow the steps below.
Step 1: Select the location on the wall for the wall-mounting bracket.
Step 2: Carefully mark the locations of the four brackets screw holes on the wall.
AFOLUX LX Series Flat Panel PC
Step 3: Drill four pilot holes at the marked locations on the wall for the bracket retention
screws.
Step 4: Align the wall-mounting bracket screw holes with the pilot holes.
Step 5: Secure the mounting-bracket to the wall by inserting the retention screws into
the four pilot holes and tightening them (
Figure 3-10).
Figure 3-10: Wall-mounting Bracket
Step 6: Insert the four monitor mounting screws provided in the wall mounting kit into the
four screw holes on the real panel of the flat panel PC and tighten until the screw
shank is secured against the rear panel (
Step 7: Align the mounting screws on the monitor rear panel with the mounting holes on
the bracket.
Step 8: Carefully insert the screws through the holes and gently pull the monitor
downwards until the monitor rests securely in the slotted holes (
Ensure that all four of the mounting screws fit snuggly into their respective
slotted holes.
Figure 3-11).
Figure 3-11).
Page 35
A
FOLUX LX Series Flat Panel PC
Figure 3-11: Chassis Support Screws
NOTE:
In the diagram below the bracket is already installed on the wall.
Step 9: Secure the panel PC by fastening the retention screw of the wall-mounting
bracket. (
Figure 3-12).Step 0:
Page 36
AFOLUX LX Series Flat Panel PC
Figure 3-12: Secure the Panel PC

3.8.2 Panel Mounting

To mount the AFOLUX LX series flat panel PC into a panel, please follow the steps below.
Step 1: Select the position on the panel to mount the flat panel PC.
Step 2: Cut out a section from the panel that corresponds to the rear panel dimensions
of the flat panel PC. Take care that the panel section that is cut out is smaller
than the overall size of the metal frame that surrounds the flat panel PC but just
large enough for the rear panel of the flat panel PC to fit through (
Figure 3-14 and Figure 3-15).
Figure 3-13,
Page 37
A
FOLUX LX Series Flat Panel PC
Figure 3-13: AFL-07A-LX Panel Opening
Figure 3-14: AFL-08A-LX Panel Opening
Figure 3-15: AFL-10A-LX Panel Opening
Page 38
AFOLUX LX Series Flat Panel PC
Figure 3-16: AFL-12A-LX Panel Opening
Step 3: Slide the flat panel PC through the hole until the aluminum frame is flush against
the panel.
Step 4: Insert the panel mounting clamps into the pre-formed holes along the edges of
the chassis, behind the aluminum frame. There are a total of 4 panel mounting
clamps for AFL-07A-LX/ AFL-08A-LX and 6 panel mounting clamps for
AFL-10A-LX/AFL-12A-LX.
Step 5: Tighten the screws that pass through the panel mounting clamps until the plastic
caps at the front of all the screws are firmly secured to the panel (
Step 0:
Figure 3-17).
Page 39
A
FOLUX LX Series Flat Panel PC
Figure 3-17: Tighten the Panel Mounting Clamp Screws (AFL-10A/12A-LX)

3.8.3 Arm Mounting

The AFOLUX LX series is VESA (Video Electronics Standards Association) compliant and
can be mounted on an arm with a 75mm or 100mm interface pad. To mount the AFOLUX
LX series on an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that
Page 40
the arm has a 75mm interface pad. If the mounting arm is not VESA
compliant it cannot be used to support the AFOLUX LX series flat panel
PC. The AFL-10A-LX and AFL-12A-LX also support VESA MIS-D 100.
AFOLUX LX Series Flat Panel PC
Step 2: Once the mounting arm has been firmly attached to the surface, lift the flat panel
PC onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
flat panel PC. The AFL-07A-LX/ AFL-07A-LX arm mount retention screw holes
are shown in
Figure 3-18 and the AFL-10A-LX/AFL-12A-LX are shown in
Figure 3-19.
Figure 3-18: AFL-07A-LX/AFL-08A-LX Arm Mounting Retention Screw Holes
Figure 3-19: AFL-10A-LX/AFL-12A-LX Arm Mounting Retention Screw Holes
Page 41
A
Step 4: Secure the flat panel PC to the interface pad by inserting four retention screws
through the bottom of the mounting arm interface pad and into the flat panel PC.
Step 0:

3.8.4 Cabinet and Rack Installation

The AFL LX series flat panel PC can be installed into a cabinet or rack. The installation
procedures are similar to the panel mounting installation. To do this, please follow the
steps below:
NOTE:
When purchasing the cabinet/rack installation bracket, make sure it is
compatible with both the AFL LX series flat panel PC and the rack/cabinet
FOLUX LX Series Flat Panel PC
into which the AFL LX series is installed.
Step 1: Slide the rear chassis of the AFL LX series flat panel PC through the
rack/cabinet bracket until the aluminum frame is flush against the front of the
bracket (
Figure 3-20).
Figure 3-20: The Rack/Cabinet Bracket
Page 42
Step 2: Insert the rack mounting clamps into the pre-formed holes along the edges of
the flat panel PC, behind the ABS/PC plastic frame. There are a total of 4 rack
AFOLUX LX Series Flat Panel PC
mounting clamps for AFL-07A-LX/ AFL-08A-LX and 6 rack mounting clamps for
AFL-10A-LX/AFL-12A-LX.
Step 3: Tighten the screws that pass through the rack mounting clamps until the plastic
caps at the front of all the screws are firmly secured to the bracket (
Figure 3-21: Secure the Rack/Cabinet Bracket (AFL-10A-LX/AFL-12A-LX)
Figure 3-21).
Step 4: Slide the flat panel PC with the attached rack/cabinet bracket into a rack or
cabinet (
Figure 3-22).
Page 43
A
FOLUX LX Series Flat Panel PC
Figure 3-22: Install into a Rack/Cabinet
Step 5: Once the flat panel PC with the attached rack/cabinet bracket has been properly
inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to
the front of the rack or cabinet (

3.9 Bottom Panel Connectors

3.9.1 LAN Connection

There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection
to an external network. To connect a LAN cable with an RJ-45 connector, please follow
the instructions below.
Step 1: Locate the RJ-45 connectors on the bottom panel of the AFOLUX LX Series.
Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of
the RJ-45 connectors on the bottom panel of the AFOLUX LX Series. See
Figure 3-23.
Figure 3-22).Step 0:
Page 44
AFOLUX LX Series Flat Panel PC
Figure 3-23: LAN Connection
Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN
cable RJ-45 connector into the onboard RJ-45 connector. Step 0:

3.9.2 Serial Device Connection

The AFOLUX LX Series has two single female DB-9 connectors on the bottom panel for a
serial device. Follow the steps below to connect a serial device to the AFOLUX LX Series
panel PC.
Step 1: Locate the DB-9 connector. The location of the DB-9 connector is shown in
Chapter 2.
Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into
the DB-9 connector on the bottom panel. See
Figure 3-24.
Page 45
A
FOLUX LX Series Flat Panel PC
Figure 3-24: Serial Device Connector
Step 3: Secure the connector. Secure the serial device connector to the external
interface by tightening the two retention screws on either side of the connector.
Step 0:
Page 46
AFOLUX LX Series Flat Panel PC

3.9.3 USB Device Connection

There are four external USB 2.0 connectors. All connectors are perpendicular to the
AFOLUX LX Series. To connect a USB 2.0 or USB 1.1 device, please follow the
instructions below.
Step 1: Located the USB connectors. The locations of the USB connectors are shown
in Chapter 2.
Step 2: Align the connectors. Align the USB device connector with one of the
connectors on the bottom panel. See
Figure 3-25.
Figure 3-25: USB Device Connection
Step 3: Insert the device connector. Once aligned, gently insert the USB device
connector into the onboard connector. Step 0:
Page 47
A
THIS PAGE IS INTENTIONALLY LEFT BLANK
FOLUX LX Series Flat Panel PC
Page 48
AFOLUX LX Series Flat Panel PC
Chapter
4

4 System Maintenance

Page 49
A
FOLUX LX Series Flat Panel PC

4.1 System Maintenance Introduction

If the components of the AFOLUX LX series fail they must be replaced, such as the
wireless LAN module or the motherboard. Please contact the system reseller or vendor to
purchase the replacement parts. Back cover removal instructions and jumper settings for
the AFOLUX LX series are described below.

4.2 Motherboard Replacement

A user cannot replace a motherboard. If the motherboard fails it must be shipped back to
IEI to be replaced. If the system motherboard has failed, please contact the system vendor,
reseller or an IEI sales person directly.

4.3 Internal Aluminum Cover Removal

WARNING!
BEFORE REMOVING THE BACK COVER, MAKE SURE THE POWER IS OFF. Failing to do so may lead to severe damage of AFOLUX LX series
and injury to the body.
WARNING!
PLEASE TAKE ANTISTATIC PRECAUTIONS WHEN WORKING WITH THE INTERNAL COMPONENTS. The interior of the AFOLUX LX series
contains very sensitive electronic components. These components are
easily damaged by electrostatic discharge (ESD). Before working with the
internal components make sure all the anti-static precautions described
earlier have been observed.
Page 50
To replace any of the following components,
AFOLUX LX Series Flat Panel PC
Motherboard
DDR memory module
Wireless LAN module
Inverter
The internal aluminum back cover of the AFOLUX LX series must be removed. To remove
the aluminum back cover, please follow the steps below.

4.3.1 AFL-07A-LX Internal Aluminum Cover Removal

Step 1: Remove the two retention screws securing the internal aluminum cover (Figure
4-1).
Figure 4-1: AFL-07A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
Figure 4-2).
Figure 4-2: Four Hexagonal Pillars on the Bottom Panel (AFL-07A-LX)
Step 3: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-07A-LX.
Step 4: Disconnect the power switch cable from the motherboard and remove the
aluminum cover. Step 0:
Page 51
A
FOLUX LX Series Flat Panel PC

4.3.2 AFL-08A-LX Internal Aluminum Cover Removal

Step 1: Remove the four retention screws (Figure 4-3).
Figure 4-3: AFL-08A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
Figure 4-4).
Figure 4-4: Four Hexagonal Pillars on the Bottom Panel (AFL-08A-LX)
Step 3: Detach the tapes securing the wireless module cables on the chassis (
4-5).
Step 4: Carefully cross the wireless module cables over the screw holes of the
aluminum cover (
Figure 4-5).
Figure
Page 52
AFOLUX LX Series Flat Panel PC
Figure 4-5: Wireless Module Cables
Step 5: Push the external interface connector apart from the aluminum cover and lift the
cover (
Figure 4-6).
Figure 4-6: The Internal Aluminum Cover Removal
Step 6: Disconnect the power switch cable (
remove the aluminum cover. Step 0:
Figure 4-7) from the motherboard and
Page 53
A
FOLUX LX Series Flat Panel PC
Figure 4-7: Power Switch Cable

4.3.3 AFL-10A-LX Internal Aluminum Cover Removal

Step 1: Remove the eight retention screws securing the internal aluminum cover
Figure 4-10).
(
Figure 4-8: AFL-10A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
Figure 4-11).
Page 54
Figure 4-9: Four Hexagonal Pillars on the Bottom Panel (AFL-10A-LX)
AFOLUX LX Series Flat Panel PC
Step 3: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-10A-LX.
Step 4: Disconnect the power switch cable from the motherboard and remove the
aluminum cover. Step 0:

4.3.4 AFL-12A-LX Internal Aluminum Cover Removal

Step 1: Remove the eight retention screws securing the internal aluminum cover
Figure 4-10).
(
Figure 4-10: AFL-12A-LX Aluminum Back Cover Retention Screws
Step 2: Remove the four hexagonal pillars on the bottom panel (
Figure 4-11).
Figure 4-11: Four Hexagonal Pillars on the Bottom Panel (AFL-12A-LX)
Step 3: Push the external interface connector apart from the aluminum cover and lift the
aluminum cover off the AFL-12A-LX.
Step 4: Disconnect the power switch cable from the motherboard and remove the
aluminum cover. Step 0:
Page 55
A

4.4 Memory Module Replacement

The flat panel PC is preinstalled with a 256MB/512MB DDR memory module. If the
memory module is fail, follow the instructions below to replace the memory module.
FOLUX LX Series Flat Panel PC
Step 1: Remove the back cover. See Section
Step 2: Remove the internal aluminum back cover. See Section
Step 3: Locate the DDR memory module on the motherboard of the flat panel PC
(
Figure 4-12).
3.5 above.
4.3 above.
Figure 4-12: SO-DIMM Socket Location
Step 4: Remove the DDR memory module by pulling both the spring retainer clips
Page 56
outward from the socket.
Step 5: Grasp the DDR memory module by the edges and carefully pull it out of the
socket.
Step 6: Install the new DDR memory module by pushing it into the socket at an angle
Figure 4-13).
(
Step 7: Gently pull the spring retainer clips of the SO-DIMM socket out and push the
rear of the DDR memory module down (
Step 8: Release the spring retainer clips on the SO-DIMM socket. They clip into place
and secure the DDR memory module in the socket.Step 0:
Figure 4-13).
AFOLUX LX Series Flat Panel PC
Figure 4-13: DDR SO-DIMM Module Installation

4.5 Jumper Settings

NOTE:
A jumper is a metal bridge that is used to
close an electrical circuit. It consists of
two metal pins and a small metal clip
(often protected by a plastic cover) that
slides over the pins to connect them. To
CLOSE/SHORT a jumper means
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper
means removing the plastic clip from a
jumper.
The motherboard comes with two jumpers. They are listed below.
COM3 pin-9 signal select (JP3)
COM1 and COM2 pin-9 signal select (JP4)
Jumper
COM2 Mode Select Jumper Settings (JP5)
COM2 Mode Select Jumper Settings (JP6)
Page 57
A
FOLUX LX Series Flat Panel PC
Figure 4-14: Jumper Locations

4.5.1 JP3: COM3 Pin-9 Signal Select Jumper Settings

The COM3 pin-9 signal can be selected as 12V, 5V or Ring.
JP3 Description
Short 1-2 COM3 pin-9 is 12V output
Short 3-4 COM3 pin-9 is RI input Default Short 5-6 COM3 pin-9 is 5V output
Table 4-1: COM3 Pin-9 Signal Select Jumper Settings
Page 58
AFOLUX LX Series Flat Panel PC

4.5.2 JP4: COM1 and COM2 Pin-9 Signal Select Jumper Settings

The COM1 and COM2 pin-9 signal can be selected as 12V, 5V or Ring.
JP4 Description
Short 1, 3 COM1 pin-9 is 12V output
Short 3, 5 COM1 pin-9 is 5V output Short 5, 7 COM1 pin-9 is 5V output
Short 7, 9 COM1 pin-9 is RI input Default Short 2, 4 COM2 pin-9 is 12V output
Short 4, 6 COM2 pin-9 is 5V output Short 6, 8 COM2 pin-9 is 5V output
Short 8, 10 COM2 pin-9 is RI input Default
Table 4-2: COM1 and COM2 Pin-9 Signal Select Jumper Settings

4.5.3 JP5: COM2 Mode Select Jumper Settings

The COM2 can be selected as RS-232 or RS-485.
JP5 Description
Short 1-2 RS-232 Default
Short 2-3 RS-485
Table 4-3: COM2 Mode Select Jumper Settings
Page 59
A

4.5.4 JP6: COM2 Mode Select Jumper Settings

The COM2 can be selected as RS-232 or RS-485.
JP6 Description
Short 1-2 RS-232 Default
Short 2-3 RS-485 Short 4-5 RS-232 Default
Short 5-6 RS-485 Short 7-8 RS-232 Default
Short 8-9 RS-485 Short 10-11 RS-232 Default
Short 11-12 RS-485
FOLUX LX Series Flat Panel PC
Table 4-4: COM2 Mode Select Jumper Settings
Page 60
AFOLUX LX Series Flat Panel PC
Chapter
5

5 Award BIOS Setup

Page 61
A

5.1 Introduction

A licensed copy of Phoenix Award BIOS is preprogrammed into the ROM BIOS. The BIOS
setup program allows users to modify the basic system configuration. This chapter
describes how to access the BIOS setup program and the configuration options that may
be changed.

5.1.1 Starting Setup

The Phoenix Award BIOS is activated when the computer is turned on. The setup program
can be activated in one of two ways.
FOLUX LX Series Flat Panel PC
1. Press the D
2. Press the D
appears on the screen.
If the message disappears, restart the computer and try again.
ELETE key as soon as the system is turned on or ELETE key when the “Press Del to enter SETUP” message

5.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PAGEUP and P
AGEDOWN keys to change entries, press F1 for help and press ESC to quit. Navigation
keys are shown below.
Key Function
Up arrow Move to the item above
Down arrow Move to the item below
Left arrow Move to the item on the left hand side
Right arrow Move to the item on the right hand side
Page 62
+/Page up Increase the numeric value or make changes
-/Page down Decrease the numeric value or make changes
Esc Main Menu – Quit and do not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu --
Exit current page and return to Main Menu
F1 General help, only for Status Page Setup Menu and Option
Page Setup Menu
AFOLUX LX Series Flat Panel PC
F2 Item help
F5 Previous values for the page menu items
F6 Fail-safe defaults for the current page menu items
F7 Optimized defaults for the current page menu items
F9 Menu in BIOS
F10 Save changes and Exit BIOS
Table 5-1: BIOS Navigation Keys

5.1.3 Getting Help

When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again.

5.1.4 Main BIOS Menu

Once the BIOS opens, the main menu (BIOS Menu 1) appears.
SC or
BIOS Menu 1: Award BIOS CMOS Setup Utility
Page 63
A
FOLUX LX Series Flat Panel PC
NOTE:
The following sections will completely describe the menus listed below and
the configuration options available to users.
The following menu options are seen in BIOS Menu 1.
 Standard CMOS Features: Changes the basic system configuration.  Advanced BIOS Features: Changes the advanced system settings.  Advanced Chipset Features: Changes the chipset configuration features.  Integrated Peripherals: Changes the settings for integrated peripherals.  Power Management Setup: Configures power saving options.  PnP/PCI Configurations: Changes the advanced PCI/PnP settings.  PC Health Status: Monitors essential system parameters.
The following user configurable options are also available in
BIOS Menu 1:
Load Fail-Safe Defaults
Use the Load Fail-Safe Defaults option to load failsafe default values for each BIOS parameter in the setup menus. Press F6 for this operation on any page.
Load Optimized Defaults
Use the Load Optimized Defaults option to load optimal default values for each BIOS parameter in the setup menus. Press F7 for this operation on any page.
Set Supervisor Password
Use the Set Supervisor Password option to set the supervisor password. By default, no
supervisor password is set. To install a supervisor password, select this field and enter the
Page 64
password. After this option is selected, a red dialogue box appears with “Enter Password: ”. Type the password and press E Confirm Password: ” dialogue box and press E
NTER. Retype the original password into the
NTER. To disable the password, simply
AFOLUX LX Series Flat Panel PC
press ENTER in the “Enter Password: ” dialogue box, then press any key in the “Password Disabled !!!” dialogue box.
Set User Password
Use the Set User Password option to set the user password. By default no user
password is set. To install a user password, select this field and enter the password. After
this option is selected, a red dialogue box appears with “Enter Password: ”. Type the password and press E dialogue box and press E Password: ” dialogue box, then press any key in the “Password Disabled !!!” dialogue
box.
Save & Exit Setup
Use the Save & Exit Setup option to save any configuration changes made and exit the
BIOS menus.
Exit Without Saving
Use the Exit Without Saving option to exit the BIOS menus without saving any
configuration changes.
NTER. Retype the original password into the “Confirm Password: ”
NTER. To disable the password, simply press ENTER in the “Enter

5.2 Standard CMOS Features

Use the Standard CMOS Features BIOS menu (BIOS Menu 2) to set basic BIOS
configuration options.
Page 65
A
FOLUX LX Series Flat Panel PC
BIOS Menu 2: Standard CMOS Features
Date [Day mm:dd:yyyy]
Use the Date option to set the system date.
Time [hh/mm/ss]
Use the Time option to set the system time.
IDE Master and IDE Slave
When entering setup, BIOS auto detects the presence of IDE devices. The Standard CMOS Features menu shows the status of the auto detected IDE devices. The following IDE devices are detected and shown in the Standard CMOS Features menu:
IDE Primary Master
IDE Primary Slave
Page 66
AFOLUX LX Series Flat Panel PC
IDE device configurations are changed or set in the IDE Configuration menu. If an IDE
device is detected, and one of the above listed two BIOS configuration options is selected,
the IDE configuration options shown in Section
Halt On [All, But Keyboard]
Use the Halt On option to specify what errors detected during the power up process stop
the system.
All Errors
No Errors
All, But Keyboard
Base Memory:
Whenever BIOS detects a non-fatal error the
The system boot is not stopped for any errors
(Default) The system boot does not stop for a keyboard
5.2.1 appear.
system is stopped and the user prompted.
that may be detected.
error; it stops for all other errors.
The Base Memory is NOT user configurable. The POST determines the amount of base
(or conventional) memory installed in the system. The value of the base memory is
typically 512K for systems with 512K memory installed, or 640K for systems with 640K or
more memory installed.
Extended Memory
The Extended Memory is NOT user configurable. The BIOS determines how much
extended memory is present during the POST. This is the amount of memory above 1MB
located in the memory address map of the CPU.
Total Memory
The Total Memory is NOT user configurable.
Page 67
A

5.2.1 IDE Primary Master/Slave

Use the IDE Primary Master/Slave menu to set or change the master/slave IDE
configurations.
IDE HDD Auto-Detection [Press Enter]
Use the IDE HDD Auto-Detection option to enable BIOS to automatically detect the IDE
FOLUX LX Series Flat Panel PC
settings. Select IDE HDD Auto-Detection and press E
the HDD type. Do not set this option manually.
IDE Primary Master [Auto]
Use the IDE Primary Master option to activate or deactivate the following drive channels:
Channel 0 Master
Channel 0 Slave
Channel 1 Master
Channel 1 Slave
None
NTER. BIOS automatically detects
If no drives are connected to the IDE channel select this
option. Once set, this IDE channel becomes
inaccessible and any drives attached to it are
undetected.
Auto
Manual
Access Mode [Auto]
The Access Mode option can only be configured if the BIOS configuration option is set to either Manual or Auto. Use the Access Mode option to determine the hard disk BIOS
Page 68
(Default) Setting this option allows the device to be automatically
detected by the BIOS.
Selecting this option allows manual configuration of the
device on the IDE channel in BIOS.
AFOLUX LX Series Flat Panel PC
translation modes. Most systems now use hard drives with large capacities and therefore
either the LBA translation mode or auto mode should be selected.
CHS
LBA
Large
Auto
Capacity
The Capacity specification indicates the storage capacity of the HDD installed in the
system.
Select this mode if the HDD capacity is less than
504MB.
Select this mode if the HDD capacity is more than
8.4GB.
This mode is an extended ECHS mode and while it
supports HDDs larger than 504MB, it is not
recommended.
(Default) If you are unsure of what access mode to set, select this
option.
Cylinder
The Cylinder specification indicates how many cylinders (tracks) are on the HDD installed
in the system.
Head
The Head specification indicates how many logical heads are on the HDD installed in the
system.
Precomp
The Precomp specification indicates on what track the write precompensation begins.
Page 69
A
Landing Zone
The Landing Zone specification indicates where the disk head will park itself after the
system powers off.
Sector
The Sector specification indicates how many logical sectors the HDD has been divided
into.

5.3 Advanced BIOS Features

Use the Advanced BIOS Features menu (BIOS Menu 3) to configure the CPU and
peripheral device configuration options.
FOLUX LX Series Flat Panel PC
BIOS Menu 3: Advanced BIOS Features
Page 70
AFOLUX LX Series Flat Panel PC
Virus Warning [Disabled]
NOTE:
Many disk diagnostic programs can cause the above warning message to
appear when the program attempts to access the boot sector table. If you
are running such a program, it is recommended that the virus protection
function be disabled beforehand.
Use the Virus Warning option to enable BIOS to monitor the boot sector and partition
table of the HDD for any attempted modification. If a modification attempt is made, the
BIOS halts the system and an error message appears. If necessary, an anti-virus program
can then be run to locate and remove the virus before any damage is done.
Enabled
Disabled
CPU Internal Cache [Enabled]
Use the CPU Internal Cache option to enable or disable the internal CPU cache.
Disabled
Enabled
Boot From LAN Control [Disabled]
Activates automatically when the system boots up
causing a warning message to appear when anything
attempts to access the boot sector or HDD partition table.
(Default) No warning message appears when there is an attempt
to access the boot sector or HDD partition table.
The internal CPU cache is disabled.
(Default) The internal CPU cache is enabled.
Use the BOOT From LAN Control option to enable the system to be booted from a
remote system.
Page 71
A
FOLUX LX Series Flat Panel PC
Disabled
(Default) The system cannot be booted from a remote system
through the LAN.
Enabled
The system can be booted from a remote system
through the LAN.
Boot Device
Use the Boot Device options to select the order of the devices the system boots from.
There are three boot device configuration options:
First Boot Device [Default: HDD-0] Second Boot Device [Default: HDD-1] Third Boot Device [Default: CDROM]
Using the default values, the system first looks for the first HDD to boot from. If it cannot
find the first HDD, it boots from a second HDD. If both the HDD are unavailable, the
system boots from a CD-ROM.
Boot Device configuration options are:
LS120
HDD-0
SCSI
CDROM
HDD-1
USB-FDD
USB-ZIP
USB-CDROM
USB-HDD
LAN
Disabled
Page 72
AFOLUX LX Series Flat Panel PC
Boot Other Device [Enabled]
Use the Boot Other Device option to determine whether the system uses a second or
third boot device if the first boot device is not found.
Disabled
Enabled
Boot Up Numlock Status [On]
Use the Boot Up Numlock Status option to specify the default state of the numeric
keypad.
Off
On
Gate A20 Option [Fast]
Use the Gate A20 Option to set if the keyboard controller or the chipset controls the Gate
The system does not look for second and third boot
devices if the first one is not found.
(Default) The system looks for second and third boot devices if the
first one is not found.
The keys on the keypad are not activated.
(Default) Activates the keys on the keypad.
A20 switching.
Normal
Fast
Typematic Rate Setting [Disabled]
Use the Typematic Rate Setting configuration option to specify if only one character is
allowed to appear on the screen if a key is continuously held down. When this option is
enabled, the BIOS reports as before, but it then waits a moment, and, if the key is still held
down, it begins to report that the key has been pressed repeatedly. This feature
accelerates cursor movement with the arrow keys.
The keyboard controller does the switching.
(Default) The chipset does the switching.
Page 73
A
FOLUX LX Series Flat Panel PC
Disabled
Enabled
Typematic Rate (Chars/sec) [6]
The Typematic Rate option can only be configured if the Typematic Rate Setting is enabled. Use the Typematic Rate option to specify the rate keys are accelerated.
6
8
10
12
15
20
(Default) Disables the typematic rate.
Enables the typematic rate.
(Default) 6 characters per second
8 characters per second
10 characters per second
12 characters per second
15 characters per second
20 characters per second
24
30
Typematic Delay (Msec) [250]
The Typematic Rate option can only be configured if the Typematic Rate Setting is enabled. Use the Typematic Delay option to specify the delay time between when a key
is first pressed and when the acceleration begins.
250
500
750
1000
24 characters per second
30 characters per second
(Default) 250 milliseconds
500 milliseconds
750 milliseconds
1000 milliseconds
Page 74
AFOLUX LX Series Flat Panel PC
Security Option [Setup]
Use the Security Option to limit access to both the system and Setup, or just Setup.
Setup
System
(Default) The system does not boot and access to Setup is denied
if the correct password is not entered at the prompt.
The system boots, but access to Setup is denied if the
correct password is not entered at the prompt.
NOTE:
To disable security, select the password setting in the Main Menu. When
asked to enter a password, don’t type anything, press E
security is disabled. Once the security is disabled, the system boots and
Setup can be accessed.
OS Select For DRAM > 64MB [Non-OS2]
NTER and the
Use the OS Select For DRAM > 64MB option to specify the operating system.
Non-OS2
OS2
Small Logo (EPA) Show [Disabled]
Use the Small Logo (EPA) Show option to specify if the Environmental Protection
Agency (EPA) logo appears during the system boot-up process. If enabled, the boot up
process may be delayed.
Disabled
(Default) Select this option when not using the OS/2 operating
Specifies the operating system used as OS/2.
(Default) EPA logo does not appear during boot up.
system.
Page 75
A
FOLUX LX Series Flat Panel PC
Enabled
EPA logo appears during boot up.

5.4 Advanced Chipset Features

Use the Advanced Chipset Features menu (BIOS Menu 4) to change chipset
configuration options.
BIOS Menu 4: Advanced Chipset Features
CPU Frequency [500MHz]
Use the CPU Frequency option to set the CPU frequency. The CPU Frequency options
are:
Auto
200MHz
333MHz
400MHz
Page 76
AFOLUX LX Series Flat Panel PC
433MHz
500MHz (Default)
Memory Frequency [Auto]
Use the Memory Frequency option to set the frequency of the installed DRAM modules. The Memory Frequency options are:
Auto (Default)
100MHz
133MHz
166MHz
200MHz
Video Memory Size [32M]
Use the Video Memory Size option to determine how much memory is allocated to the video graphics device. The Video Memory Size options are:
None
8M
16M
32M (Default)
64M
128M
254M
OnBoard Audio [Enabled]
Use the OnBoard Audio option to enable or disable the onboard codec.
Disabled
Enabled
The onboard codec is disabled.
(Default) The onboard codec is detected and enabled.
Page 77
A

5.5 Integrated Peripherals

Use the Integrated Peripherals menu (BIOS Menu 5) to change the configuration options
for the attached peripheral devices.
FOLUX LX Series Flat Panel PC
BIOS Menu 5: Integrated Peripherals
On-Chip IDE Channel 1 [Enabled]
Use the On-Chip IDE Channel 1 option to specify if the system uses the integrated
primary IDE channel or not.
Page 78
Disabled
Enabled
The primary IDE channel is not used.
(Default) The primary IDE channel is used.
AFOLUX LX Series Flat Panel PC
Drive PIO Mode [Auto]
Use the Drive PIO Mode options below to select the Programmed Input/Output (PIO)
mode for the following HDDs:
Master Drive PIO Mode
Slave Drive PIO Mode
Auto
Mode 0
Mode 1
Mode 2
Mode 3
Mode 4
IDE UDMA [Auto]
Use the IDE UDMA option below to select the Ultra DMA (UDMA) mode for the following
HDDs:
IDE Primary Master UDMA
IDE Primary Slave UDMA
(Default) The computer selects the correct mode.
PIO mode 0 selected with a maximum transfer rate of 3.3MBps.
PIO mode 1 selected with a maximum transfer rate of 5.2MBps.
PIO mode 2 selected with a maximum transfer rate of 8.3MBps.
PIO mode 3 selected with a maximum transfer rate of 11.1MBps.
PIO mode 4 selected with a maximum transfer rate of 16.6MBps.
Disabled
Auto
IDE DMA transfer access [Enabled]
Use the IDE DMA transfer access option to enable or disable DMA support for IDE
devices connected to the system.
Disabled
The UDMA for the HDD device is disabled.
(Default) The computer selects the correct UDMA.
All IDE drive DMA transfers are disabled. The IDE drives
Page 79
A
use PIO mode transfers.
FOLUX LX Series Flat Panel PC
Enabled
IDE HDD Block Mode [Enabled]
If the drive connected to the system supports block mode, use the IDE HDD Block Mode
option to enable the system to detect the optimal number of block read/writes per sector
the system IDE drive can support. Block mode is also called block transfer, multiple
commands, or multiple sector read/write.
Disabled
Enabled
Onboard Serial Port 1 [3F8/IRQ4]
Use the Onboard Serial Port 1 option to select the I/O address and IRQ for the onboard
serial port 1. The serial port can be disabled or the I/O address and the IRQ can be
(Default) All IDE drive DMA transfers are enabled.
Block mode is not supported.
(Default) Block mode is supported.
automatically selected by the BIOS. The Onboard Serial Port 1 options are:
Disabled
3F8/IRQ4 (Default)
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Auto
Onboard Serial Port 2 [2F8/IRQ3]
Use the Onboard Serial Port 2 option to select the I/O address and IRQ for the onboard
serial port 2. The serial port can be disabled or the I/O address and the IRQ can be
automatically selected by the BIOS. The Onboard Serial Port 2 options are:
Disabled
3F8/IRQ4
2F8/IRQ3 (Default)
Page 80
AFOLUX LX Series Flat Panel PC
3E8/IRQ4
2E8/IRQ3
Auto
Touch controller Port [2E8]
Use the Touch controller Port option to select the I/O address for the onboard touch
panel controller port. The touch panel controller port can be disabled or the I/O address
can be automatically selected by the BIOS. The Touch controller Port options are:
Disabled
3F8
2F8
3E8
2E8 (Default)
Touch controller Use IRQ [IRQ7]
Use the Touch controller Use IRQ option to select the IRQ for the onboard touch panel
controller port. The touch panel controller port can be disabled or the IRQ can be
automatically selected by the BIOS. The Touch controller Use IRQ options are:
IRQ5
IRQ7 (Default)

5.6 Power Management Setup

Use the Power Management Setup menu (BIOS Menu 6) to set the BIOS power
management and saving features.
Page 81
A
FOLUX LX Series Flat Panel PC
BIOS Menu 6: Power Management Setup
ACPI Function [Enabled]
Use the ACPI Function to enable the ACPI (Advanced Configuration and Power Interface)
function.
Disabled
Enabled
ACPI function disabled.
(Default) ACPI function enabled.
Page 82
AFOLUX LX Series Flat Panel PC
ACPI Suspend Type [S1(POS)]
Use the ACPI Suspend Type BIOS option to specify the sleep state the system enters
when not being used.
S1 (POS)
S3 (STR)
S1 & S3
Power Management [ACPI]
Use the Power Management option to set the power management type used by the
system.
Disabled
(Default) System appears off. The CPU is stopped; RAM is
refreshed; the system is running in a low power mode.
System appears off. The CPU has no power; RAM is in
slow refresh; the power supply is in a reduced power
mode.
Both suspend modes are implemented
All power management options are turned off. The only
user configurable options are the power button and
alarm settings.
Legacy
APM
ACPI
x Standby Mode [Disabled]
The Standby Mode option can only be selected if the Power Management option is set to Legacy. The Standby Mode specifies the amount of time the system can be inactive before the system enters standby mode. The Standby Mode options are:
Standby and suspend modes can be set.
Advanced power management (APM) is activated
(Default) Advanced Configuration and Power Interface (ACPI) is
activated.
Page 83
A
Disabled (Default)
1 Sec
5 Sec
10 Sec
15 Sec
30 Sec
45 Sec
1 Min
5 Min
10 Min
15 Min
30 Min
45 Min
60 Min
FOLUX LX Series Flat Panel PC
90 Min
120 Min
x Suspend Mode [Disabled]
The Suspend Mode option can only be selected if the Power Management option is set to Legacy. The Suspend Mode specifies the amount of time the system can be inactive before the system enters suspend mode. The Suspend Mode options are:
Disabled (Default)
1 Sec
5 Sec
10 Sec
15 Sec
30 Sec
45 Sec
1 Min
Page 84
5 Min
10 Min
15 Min
30 Min
AFOLUX LX Series Flat Panel PC
45 Min
60 Min
90 Min
120 Min
Modem Use of IRQ
Use the Modem Use of IRQ to select the IRQ address for the system modem. The
following IRQ addresses are available.
N/A
3 (Default)
4
5
7
9
10
11
Wake-on Lan Control [Disabled]
Use the Wake-on Lan Control option to enable activity on the LAN to rouse the system
from a suspend or doze state.
Disabled
Enabled
(Default) Wake event not generated by LAN activity.
Wake event generated by LAN activity.
Soft-Off by PWR-BTTN [Instant-Of f]
Use the Soft-Off by PWR-BTTN option to enabled the system to enter a very
low-power-usage state when the power button is pressed.
Instant-Off
(Default) When the power button is pressed, the system is
immediately shutdown.
Delay 4-sec
To shutdown the system the power button must be held
Page 85
A
Power-On by Alarm [Disabled]
Use the Power-On by Alarm option to specify when the computer is roused from a
suspended state.
FOLUX LX Series Flat Panel PC
down longer than four seconds otherwise the system
enters a low power usage state.
Disabled
Enabled
IRQ Wakeup Events [Press Enter]
To view the IRQ Wakeup Events options press E
(Default) The real time clock (RTC) cannot generate a wake
event
If selected, the following appears with values that
can be selected:
Time (hh:mm:ss) Alarm
After setting the alarm, the computer will turn itself
on from a suspend state when the alarm goes off.
NTER.
Page 86
