IDX CW-7 Cam-Wave HD, Cam-Wave HD CW-7, Cam-Wave HD CW-7 TX, Cam-Wave HD CW-7 RX Operation Manual

CW-7

Operation Manual

EU Version 2

nd

Edition

IDX Company, Ltd.

1

IDX thanks you for choosing the CW-7 and is sure that you will benefit
from its unique features.
Please read this instruction manual to safely operate and to maximize
performance.

The material contained in this manual consists of information that is
the property of IDX Company, Ltd. and is intended solely for the use
by the purchasers of the equipment described in this manual.
IDX Company, Ltd. prohibits the duplication of any portion of this
manual or the use herein for any application other that the operation
or maintenance of the equipment described in this manual without the
expressed written permission of IDX Company, Ltd.

2

Table of contents

I. SAFETY INSTRUCTIONS ................................................................... 3

II. CONTENTS ........................................................................................... 7

1. Product overview ............................................................................... 7

2. Switches and connectors ................................................................... 9

2.1. CW-7 TX .................................................................................... 9

2.2. CW-7 RX ................................................................................... 11

3. LED indicators ................................................................................ 13

3.1. LED indicator functions ......................................................... 13

3.2. CW-7 Link initialization ......................................................... 14

4. Selecting frequencies and power output ........................................ 15

4.1. Available frequencies and transmission power ..................... 15

4.2. DFS function ........................................................................... 16

5. Link mode -UNICAST/MULTICAST .............................................. 17

5.1. UNICAST mode (1 to 1 communication) ................................ 17

5.2. MULTICAST mode (1 to n communication) .......................... 18

6. Operation guide ............................................................................... 19

6.1. Set up ....................................................................................... 19

6.2. Operating procedures ............................................................. 19

6.3. When signal reception is unstable ......................................... 20

6.4. Power back-up function .......................................................... 20

6.5. Power through feature ............................................................ 20

7. Important notice .............................................................................. 21

III. Specifications ................................................................................... 22

8. CW-7 TX ........................................................................................... 22

9. CW-7 RX .......................................................................................... 24

IV. Warranty & Service ......................................................................... 26

3

I. SAFETY INSTRUCTIONS

To use this product safely and correctly please follow the safety
precautions set out below. Product misuse may cause fire, shock,
injury, product failure or other hazards. Please read this manual prior
to using your CW-7 and retain for future reference.

CAUTION
Fire or electric shock may cause
injury or other accidents.

●Before using an external power

supply, always check that the voltage
is within the specified range and that
the polarity of the connector is
correct, as this will avoid smoke or
fire.

●Do not attempt to disassemble,
modify or repair this product yourself.
It may cause fire or electric shock.
Please consult your dealer or local
IDX office for inspection and repair
services.

●Do not use this product near water or
in high humidity environments. It may
cause fire or electric shock.

●In case of damage, smoke, unusual
smell or other unexpected situations,
stop use immediately and consult
your dealer or local IDX office.

●Turn the power switch off if any liquid
or substance gets inside the product.
Continuous use under such condition
may cause shortage, fire or electric
shock.

●When a battery is mounted on
CW-7, or CW-7 is mounted on a video
camera or on a monitor, please
ensure that they are correctly and
firmly locked.

4

CAUTION - continued

Fire or excessive heat may cause

injury or damage to surroundings.

●If ventilation openings are blocked,
this may cause excessive heat or
damage.

●After long periods of continuous
use, the case of the unit may become
very heated – be cautious when
touching.

●Using the CW-7 in an environment
with a lot of moisture, soot or dust
may cause excessive heat or electric
shock.

●Do not stare at LED lights on the
side panel of CW-7, as this may cause
damage to the eyes.

●Do not place this product on an
uneven or vibrating surface. It may
cause malfunction or damage.

5

CW-7 Important Notification of Use

CAUTION

IDX requires that CW-7 TX (transmitter) be installed on the
V-Mount interface of a video camera. Depending on
connectivity, installing CW-7 TX with equipment other than
a video camera may cause problems to CW-7 TX or other
equipment.

For further information, and to install the CW-7 system with
equipment other than a video camera, please contact your

local IDX representative.

Caution on the use of this product and radio waves

 This product has been approved for technical standard compliance

certification as a wireless device of radio stations with low antenna
power specified under the ETSI Radio wave regulations. Therefore a
license for radio station use is not required to operate this product.

 This product is allowed to be used only in Europe.
 This product is pursuant to the ETSI standard and can be used in

both indoor and outdoor environments.

Please note that it is a user’s responsibility to confirm an appropriate

authority and use of wireless equipment in the each country.

 When the frequency selection SW is "DFS AUTO" mode, it will take

about one minute to link the system in order to detect the presence or
absence of radar wave in the area..

 CW-7 uses 5GHz band radio frequencies and it has been shown not to

interfere with medical devices. However, when in use, it is
recommended to keep the CW-7 at least 30cm (12in.) away from
medical devices to ensure safety.

This equipment is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC. In order to obtain the declaration of
conformity statement for the European Union
countries, please contact the appropriate IDX office.

6

CW-7 Important Notification of Use

CAUTION

Please do not connect between DC-IN of CW-7 and DC-OUT
of the camera while powering with battery as shown below.
This may cause serious damages to the CW-7.

Attention: When used EXT-DC and battery simultaneously

 Mount a battery after EXT-DC power is turned ON.
 When EXT-DC power OFF and turns ON again, please remove battery.

7

II. CONTENTS

1. Product overview

The CW-7 is a wireless transmission device which transmits HD-SDI/SDI
video and audio with 5GHz band radio frequencies. TX is the transmitter,
and connects to a video source such as a video camera. RX is the receiver,
and connects to a monitor, for example. Video and audio from the video
source can be observed without cable connections. CW-7, also, provides
DFS1 function which enable to use indoor and outdoor without any concern
of local wireless regulations. With the transmission output power in HIGH
mode, the signals can be transmitted up to 50m (150ft) if a direct
line-of-sight is offered between TX and RX.

Features

 Supported HD-SDI / SD-SDI input and output.
 Transmitting HD video (1080i, 1080p, 720p) and SD video (525i/625i)
 Supporting SDI embedded audio. (Audio CH1 and CH2 only)
 Transmission delay is less than 1msec.
 Signal protection by 128bit AES encryption (in UNICAST mode)
 WHDI technology supplied by AMIMON enables un-compressed high

quality video transmission.

 Both automatic and manual selection of transmitted frequencies.
 Newly adopted DFS functionality allows for use in outdoors as well.
 Two-level select (HIGH/LOW) of transmission output power.
 Power can be supplied either by V-Mount type Lithium Ion battery or by

EXT DC via XLR 4P connector.

 Backup power failure function enables switching to a battery if the

external DC failed.

 Either of EXT DC or battery power supply to the camera thorough CW-7.

1

DFS (Dynamic Frequency Selection):
This function automatically changes the frequency used by the wireless
equipment. The provided 5GHz band wireless equipment will not affect the
weather radar.
