IDTECK SR10 User Manual

User’s Manual

13.56MHz Contactless Smart Card Reader

2

Table of Contents

1. Important Safety Instructions................................................................3

2. General ....................................................................................................3

3. Features...................................................................................................4

4. Identifying Supplied Parts .....................................................................4

5. Specification ...........................................................................................5

6. Installation...............................................................................................6

7. Wire Color Table .....................................................................................8

8. Output Format.........................................................................................9

9. Wire Connection to Access Controller...............................................10

10. Operation.............................................................................................10

11. FCC Registration Information............................................................12

12. Warranty and Service.........................................................................13

3

1. Important Safety Instructions

When using the 13.56MHz [MIFARE] Contactless Smart Card Reader, basic safety precautions
should always be followed to reduce the risk of fire, electrical shock, and injury to persons.
In addition, the following should also be followed:

1. Fully read and understand all instructions and follow them completely.

2. Follow all warnings and instructions marked on the product.

3. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. If necessary, use mild soap.

4. Do not use this product near water.

5. Only operate this product using the type of power source indicated. If you are not sure of the type
of power supplied to your installation site, consult your dealer of local power company.

6. Never insert objects of any kind into the product or through the cabinet slots as they may touch
voltage points and/or short circuit parts possibly resulting in fire or electric shock.

Never spill liquid of any kind on the product.

7. Never disassemble this product by yourself; take the unit to a qualified service center whenever
service or repair is required. Opening or removing the covers may expose you to dangerous
voltages or other risks. Also, incorrect reassembly can cause electric shock when the unit is
subsequently used.

8. Unplug this product from the Direct Current (DC) power source and refer to qualified service
personnel under these conditions:

a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled on the product.
c. If the product does not operate normally after following the operating instructions in this

manual.
Adjust only those controls that are covered by the operating instructions in this manual.
Improper adjustment of other controls that are not covered by this manual may damage
the unit and will often require extensive work by a qualified technician to restore normal
operation.

d. If the product exhibits a distinct change in performance.

2. General

The IDTECK SR10 Smart Card Reader can be compatible with Philips Mifare™ Card.
The unit provides integrated operation of reader and is designed by which can install easily to door
frame or wall. The IDTECK SR10 is elegant looking and built in an attractive 10cm (4") read range
smart card reader.
It reads serial numbers from Philips Mifare™ compatible cards and transmits the data to the control
panel in various output formats.
Three LED indicators (red and green) and inside Piezo buzzer sound will guarantee you an accurate
and reliable system operations.

4

3. Features

- 13.56MHz [MIFARE] Contactless smart Card Reader / Writer

- ISO 14443 type A compatible

- Serial Number Read only

- Read Range: Up to 4 inch (10cm)

- 34bit Wiegand (default) / RS232, ABA Track II (optional) Output Format

- 3 Array LED Indicators (Red and Green) and Beeper

- External LED Control

- External Buzzer Control

- Easy to install on Mullion Mounting suitable

- Solid Epoxy Potted

- Waterproof / IP65 / IP66

- Warranty: Life Time

- Reverse Polarity Protection

- Compatible Software: Smart Card Read / Write Software

- Compatible Controller: iCON100SR, iTDC-SR, Third Party Controller

4. Identifying Supplied Parts

Please unpack and check the contents of the box:

Reader Module SR10 Bezel User’s Manual

(1ea) (1ea) (1copy)

3.5*40 Screw 3.5*12 Screw Anchor Bolt

(2ea) (2ea) (2ea)

5

5. Specification

Model SR10

Passive Type

ISK50 / IMC135: Up to 2 inch (5cm)

ISC80: Up to 4 inch (10cm)

Read Range

Active Type

IDA150 / IDA200 Compatible

Reading Time (Card)

30ms

Power / Current

DC 12V / Max.50mA

Input Port

2ea (External LED Control, External Buzzer Control)

Output Format

34bit Wiegand (Default) / RS232, ABA Track II (Optional)

LED Indicator / Beeper

3 Array LED Indicators (Red, Green) / Piezo Buzzer

Operating Temperature -35° to +65℃ (-31° to +149℉)

Operating Humidity

10% to 90% relative humidity non-condensing

Color / Material

Dark Peal Gray / Polycarbonate

Dimension (W x H x T)

47mm X 115mm X 22 mm (1.8’’ X 4.5’’ X 0.88’’)

Weight

150g (0.33lbs)

Index of Protection

IP65 / IP66

Certification

FCC, CE, MIC

[Card reading range by Contactless Smart[Mifare] Reader Series]

Model ISC80 ISK50 IMC135 IHC80

SR10 /
SR30 /
SRK101

4 inch (10cm)

2 inch (5cm)

SR10B /
SR30B /
SRK101B

4 inch (10cm)

2 inch (5cm)

SR10RW /
SR30RW /
SRK101RW

4 inch (10cm)

2 inch (5cm)

FINGER007SR(B)
FINGER006SR(B)
FGR006SR(B)

4 inch (10cm)

2 inch (5cm)

SR505 4 inch (10cm)

2 inch (5cm)

Read
Range

FACE007SR
FACE006SR

4 inch (10cm)

2 inch (5cm)

6

6. Installation

6-1. Mullion/Wall Mount:

Drill two 6-32 or M3 screws 3.3" (8.38cm) apart in vertical and drill one 1/2" hole for the reader

cable 1.7" (4.31cm) apart from the top hole.

(Skip this step, if you have installed an electric gang box.)

6-2. Put reader cable into the center hole and install the reader module by using two 6-32 or M3 screws.
6-3. Put bezel into the reader module, then push bezel until you hear the locking sound.

6-4. Installation consideration

6-4-1. Installation of SR10 on metal

Read range will be reduced if located on metal surfaces or in the vicinity of metal objects.
The amount of reduction will be a factor of the amount of metal and the distance the
Reader is from the metal. Metal near the Reader absorbs energy from the Reader excite
field and affects the signal being received from the card by re-directing excite field
transmissions into the receiver circuitry. Moving the Reader away from the metal objects
reduces energy loss.
Try to limit the amount of metallic materials installed near the SR10.
Use a plastic electrical box if possible.
When installing the Reader on metal door frame, add Isolation Spacers between the
Reader and metal door frame. If you do so, read range reduction can be improved.
The typical read distance specification (2-4 inches at 12VDC) refers to operation without
metal in the vicinity of the Reader.
The read distance will be reduced if metal is installed nearby. The SR10RW generate a
magnetic field on all sides of the Reader. Any metal that conducts electricity, especially
metal that contains iron, steel or copper will interfere with the field and reduce the effective
spacer between the Reader and the metal object.

7

① Installation of two readers side by side and back to back

Read range is not affected if the side by side distance between two readers is equal to
or greater than eight inches (20cm). If the distance between the two readers is less
than eight inches (20cm), field interference between the two readers may result in a
double-badge read.

When installing two readers back-to-back on a wall that will separate the two readers

by eight inches (20cm) or less, a metal plate (for example: Reader isolation plate,

metal wall) must be placed between the readers. To obtain the maximum read range,

mount each proximity reader onto one or more Isolation Spacers.

Two readers can simultaneously read the same badge or tag if the distance
between the two readers is less than 8 inches (20cm), side by side.

Note

Two readers can simultaneously read the same badge or tag if the distance
between the two readers is less than 8 inches (20cm), back-to-back.

Note

8

7. Wire Color Table

SIGNAL COLOR

Main Power (+12V) Red

Power Ground (GND) Black

ABA Track II CP Out Orange

Wiegand Data 0 Out /

ABA Track II Data Out

Green

Wiegand Data 1 Out /

ABA Track II Clock Out

White

Buzzer Control In Blue

LED Control In Yellow

34/26bit Wiegand Select In Gray

RS232 (TX) Purple

Not Connect Brown

* Please cut out tail connector before installation.

9

8. Output Format

8-1. 34/26bit Wiegand Output Format

1. Data format

26bit Wiegand output format 34bit Wiegand output format

Bit 1 Even parity of bit 2 ~ bit 13 Bit 1 Even parity of bit 2 ~ bit 17
Bit 2∼9

Facility code (000 ~ 255)

Bit 10∼25

ID number (00000 ~ 65,535)

Bit 2∼25

4byte ID number

(0000000001 ~ 4,294,967,295)

Bit 26 Odd parity of bit 14 ~ bit 25 Bit 34 Odd parity of bit 18 ~ bit 33

2. Timing diagram

8.2 RS232 Output format (Optional)

START (0x02H) DATA (10 or 8 characters) END (0x03H) LRC

3.5V

0.5V

100uS

1mS

Data 0

100uS

100uS

Data 1

3.5V

0.5V

5V

5V

0V

0V

+15V

-15V

+3V

-3V

pace (=0)

Mark (=1)

8 Data Bits

2 Stop Bits

Indeterminate

Region

Data packet corresponding to ASCII character 'A'

Start Bit

010000010

LSB MSB

0V

10

9. Wire Connection to Access Controller

10. Operation

10-1. Apply power and you can see the 3-Array red LED is on, indicating the reader is on ‘Standby ’.

10-2. Present a proximity card to the reader until you hear a beep sound and the LED changes the

color to green simultaneously and the reader sends the RF card data to the controller. Then the
LED changes the color to red again for next reading.
All 3 LEDs are off when you have access to card and then are on orderly from left.

10-3. LED Control:

To be off the LEDs, you may connect the LED Control Input (Yellow wire) to the power ground.
Then the green LED is on.
Present a proximity card. The LED changes the color to red simultaneously, then to green again
for next reading.
All 3 LEDs are off when you have access to card and then are on orderly from left.

10-4. Buzzer Control:

When the reader reads a proximity card, only one beep sound generates in normal operating
mode but you can generate more beep sounds to distinguish whether the access is granted or
denied. To generate more beeps, you may control the Beeper Control Input (Blue wire) to the
power ground, then you can turn the beeper on while you hold the Beeper Control Input to the
power ground.

Red

Black

Orange

Green

White

Blue

Yellow

Gray
Purple
Brown

Access Controller

Main Power (+12V)

Power Ground (GND)

ABA Track II CP Out

Wiegand Data 0 Out /

ABA Track II Data Out

Wiegand Data 1 Out /

ABA Track II Clock Out

Buzzer Control In

LED Control In

34/26bit Wiegand Select In

RS232 (TX)

Not Connect

11

10-5. 4-byte (34bit) / 3-byte (26bit) selection:

The reader outputs the serial number of a card which is a 4-byte number. It is possible to
make the reader send only 3 bytes with the most significant byte trimmed off. It is useful when
there are controllers which deal with 3-byte data only as most of existing controllers do.
For 3-byte outputs, connect the 34-bit / 26-bit selection input (Gray wire) to ground.

※Caution: It is unavoidable that some card numbers are duplicated in 3-byte output.

e.g.)

34bit – 0x21 0x97 0x32 0xBC : Hexa

0563557052 : Decimal

26bit – 0x32 (FAC) 0x97 0x21 (ID number) :Hexa

050(FAC) 38689 (ID number) : Decimal

12

11. FCC Registration Information

FCC REQUIREMENTS PART 15

Caution: Any changes or modifications in construction of this device which are not expressly

approved by the manufacturer for compliance could void the user's authority to operate

the equipment.

NOTE: This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions;

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class B Digital Device,

pursuant to Part 15 of the FCC Rules. These limits are designed to this equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be

determined by turning the radio or television off and on, the user is encouraged to try to correct

interference by one or more of the following measures.

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on another circuit.

4. Consult the dealer or an experienced radio/TV technician for help.

13

12. Warranty and Service

The following warranty and service information applies only to the United States of America and
Republic of Korea. For the information in other countries, please contact your local distributor.
To obtain in or out of warranty service, please prepay shipment and return the unit to the service
facility listed below.

Headquarters: IDTECK Co., Ltd.
5F Ace Techno Tower B/D,
684-1 Deungchon-Dong, Gangseo-Gu,
SEOUL, KOREA 157-030
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Website: www.idteck.com

U.S Branch: RF Logics Inc.
370 Amapola Ave, #106
Torrance, CA 90501
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Website: www.rflogics.com

Hong Kong Branch: IDTECK Hong Kong
12/F, B2B Centre, No.36 Connaught Road West, Hong Kong
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Website: www.ristarhk.com

Please use the original container, or pack the unit(s) in a sturdy carton with sufficient packing to
prevent damage, include the following information:

1. A proof-of-purchase indicating model number and date of purchase.

2. Bill-to address.

3. Ship-to address.

4. Number and description of units shipped.

5. Name and telephone number of person to contact.

6. Reason for return and description of the problem.

NOTE: Damage occurring during shipment is deemed the responsibility of the carrier, and claims

should be made directly to the carrier.

14

MEMO

15

MEMO

July. 2006 Copyright ©2006 IDTECK Co., Ltd.

MARSR10HE2X

The specification contained in this manual are subject to change without notice at any time.

5F, Ace Techno Tower B/D, 684-1, Deungchon-Dong,
Gangseo-Gu, Seoul, 157-030, Korea

Tel : [phone]
Fax : [phone]

E-mail : [e-mail]
