Engineering Specification
www.panelook.com
Engineering Specification
Type 18.1 SXGA Color TFT/LCD Module
Model Name: ITSX98E
Document Control Number: OEM I-98E-04
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
3/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
i Contents
i Contents ii Record of Revision
1.0 Handling Precautions
2.0 General Description
2.1 Characteristics
2.2 Functional Block Diagram
3.0 Absolute Maximum Ratings
3.1 Component Temperature
4.0 Optical Characteristics
4.1 Luminance Uniformity
4.2 Image Retention
5.0 Signal Interface
5.1 Connectors
5.2 Interface Signal Connector
5.3 Interface Signal Description
5.4 Interface Signal Electrical Characteristics
5.5 Backlight Connector Signal Description
5.6 Backlight Input Signal Electrical Characteristics
6.0 Pixel format image
7.0 Interface Timings
7.1 Timing Characteristics
7.2 Timing Definition
8.0 Power Consumption
9.0 Power ON/OFF Sequence
10.0 Mechanical Characteristics
11.0 National Test Lab Requirement
12.0 Backlight Life
13.0 Packaging Specification
14.0 Label
www.panelook.com
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
4/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
ii Record of Revision
Date Document Revision Page Summary
June 4,2001 OEM I-98E-01 All First Edition for customer.
September 28,2001 OEM I-98E-02 5,8 To update White Luminance
www.panelook.com
Based on Internal Spec. as of May 11,2001.
October 19,2001
Feb. 2,2007 OEM I-98E-04
OEM I-98E-03
5
7
8
19
21
24,25
27,28
10
12
13
14
Updated by establishment of the New Company
as "International Display Technology".
Based on Internal Spec. EC H30912 as of
October 19,2001.
To update Weight, Optical Rise Time + Fall Time
and Power Consumption.
To update value of Shock Test Criteria.
To update Viewing Angle and Response Time.
To update Dimming Curve.
To add Note for Timing Characteristics.
To update Power Consumption.
To update Reference Drawings.
4.0 Optical Characteristics
Min Contrast spec add.
Optical equipment change.
4.2 Image Retention spec add.
5.1 Connectors
34
35,36
37,38
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
Change IF connector type to RoHs.
Change Inverter connector type to RoHs.
12.0 Backlight Life spec add.
13.0 Packaging Specification add.
14.0 Label spec add.
5/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
1.0 Handling Precautions
Damage to the panel or the panel electronics may result from any deviation from the recommended
power on/off sequencing. The panel should not be hot plugged. Refer to the Power On/Off Sequence section in this Specification.
Handle the panel with care. The LCD panel and CCFL (Cold Cathode Fluorescent Lamp)s are made of
glass and may crack or break if dropped or subjected to excessive force.
The CCFLs contain a small amount of Mercury so should not be disposed of to landfill. Dispose of as
required by local ordinances or regulations.
The LCD module contains small amounts of material having no flammability grade. The exemption
conditions of the flammability requirements (4.7.3.4, IEC60950 3rd.Ed. or UL60950 3rd.Ed.) should be applied.
The panel may be damaged by the application of twisting or bending forces to the module
assembly.Care should be taken in the design of the monitor housing and the assembly procedure to prevent stress damage to the panel especially the lamp cable and the lamp connector..
Use standard earthing/grounding procedures to prevent damage to the CMOS LSI while handling the
module.
Use earthing/grounding procedures, an ionic shower, or similar to prevent static damage while
removing the protective front sheet.
The front polarizer can be easily damaged. Take care not to scratch the front surface with any hard or
abrasive material. Dust, finger marks, grease etc. can be removed with a soft damp cloth (a small amount of mild detergent can be used on the damp cloth). Do not apply water or datergent directly to the front surface as this may cause staining or damage the electronic components.
Never use any solvent on the front polarizer or module as this may cause permanent damage.
Do not open or modify the module assembly.
Continuous operation of the panel with the same screen content may result in some image sticking.
Over 10 hours operation with the same content is not recommended.
Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
Please do not use middle 3(three) screw holes on the upper(long) side and middle 3(three) screw holes
on the lower(long) side for panel fixing. These screw holes are for manufacturing purpose only.
 The information contained herein is presented only as a guide for the applications of our
products. No responsibility is assumed by International Display Technology for any infringements of patents or other right of the third partied which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of International Display Technology or others.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
www.panelook.com
6/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
2.0 General Description
This specification applies to the Type 18.1 Color TFT/LCD Module 'ITSX98E'. This module is designed for a LCD monitor style display unit.This module includes inverter card. The screen format and electrical interface are intended to support the VESA SXGA (1280(H) x 1024(V)at 60Hz) screen. Support color is native 16M colors(RGB 8-bit data driver). All input signals are LVDS(Low Voltage Differential Signaling) interface compatible. This model is meet RoHs requirements.
2.1 Characteristics
The following items are characteristics summary on the table under 25 degree C condition:
www.panelook.com
CHARACTERISTICS ITEMS
Screen Diagonal [mm] 460
Pixels H x V 1280(x3) x 1024
Active Area [mm] 359.0(H) x 287.2(V)
Pixel Pitch [mm] 0.2805(per one triad) x 0.2805
Pixel Arrangement R,G,B Vertical Stripe
Weight [grams] 2,900 typ.
Physical Size [mm] 389.0(W) typ. x 317.2(H) typ. x 35.0 (D) max.
Display Mode Normally Black
Display Surface Treatment Anti-Glare
Support Color 16M (RGB 8-bit data)
White Luminance [cd/m2] 270 Typ
Contrast Ratio 400 : 1 Typ.
Optical Rise Time/Fall Time [msec] Rise Time + Fall Time : 40 Typ. (total)
Input Voltage [V] +12 +/- 5%
Power Consumption [W] 38.8 typ., 46.6 max.
SPECIFICATIONS
Electrical Interface
Temperature Range [degree C] Operating Storage (Shipping)
LVDS Dual (Even/Odd R/G/B Data(8bit), 3sync signals, Clock)
0 to +50
-20 to +60
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
7/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
2.2 Functional Block Diagram
www.panelook.com
The following diagram shows the functional block of this Type 18.1 Color TFT/LCD Module.
LCD module
Interface card
+12V
LVDS Signals
SELLVDS
Connector
HIROSE DF14-30P-1.25H(59)
Mating DF14-30S-1.25C
Connector JST S8B-PH-SM3
Mating JST PHR-8
Y-card
Gatearray
X-card
TFT/LCD
Array/Cell
1280x1024
Backlight unit
+12V VDIM
BLON
Inverter card
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
8/38
www.panelook.com
Global LCD Panel Exchange Center
y
Engineering Specification
3.0 Absolute Maximum Ratings
Absolute maximum ratings of the module is as follows:
Item
Logic/LCD Drive Voltage Vin -0.3 +13.2 V
Backlight Voltage VBL -0.3 +13.2 V
Select LVDS data order SELLVDS -0.3 3.3 V
Brightness control VDIM -0.3 5.3 V
Backlight on signal BLON -0.3 +5.3 V
Operating Temperature TOP 0 +50 deg.C
Operating Humidity HOP 8 80 %RH
Storage Temperature TST -20 +60 deg.C
Storage Humidity HST 5 95 %RH
Vibration 1.5 G Hz
Shock 50 11 G ms
Note 1: Maximum Wet-Bulb should be 39 degree C and No condensation. Note 2:
- Sign Vibration:10-200-10Hz, 1.5G, 30 min, X, Y, Z Axis, Each One Time. Shock Specification
- Half sine wave:50G 11msec. -X+/-, -Y+/-, -Z+/- (Total 6 directions), Each one time Shock.
3.1 Component Temperature
The table below shows the maximum component temperature to guarantee this specification.
Vibration Specification
S
mbol
www.panelook.com
Min Max Unit Conditions
(Note 1)
(Note 1)
(Note 1)
(Note 1)
(Note 2) (Note 2)
Half sine wave
Component Max. Temp. Spec (degree C)
Gate Array 95
X-Driver IC 85
Transformer(Inverter) 105
Inductor Coil (DC/DC) 100
Polarizer(Cell) 60
Note: If any cases of the operating condition, these components shall not exceed these temperature.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
9/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
4.0 Optical Characteristics
The optical characteristics are measured under stable conditions as follows under 25 degree C condition:
Item Conditions Specification
Typ. Note
www.panelook.com
Viewing Angle (Degrees)
K:Contrast Ratio Horizontal (Right)
Vertical (Upper)
Contrast ratio 400 200
Response Time (ms) Rising (10%->90%)
Color Red x 0.640 +0.030
Chromaticity Red y 0.330 +0.030
(CIE) Green x 0.290 +0.030
Green y 0.600 +0.030
Blue x 0.150 +0.030
Blue y 0.060 +0.030
White x 0.313 +0.030
Horizontal (Right) K>
15 (Left)
Vertical (Upper) K>
15 (Lower)
K>
10 (Left)
K>
10 (Lower)
+
Falling (90%->10%)
85 85
85 85
-
-
-
-
40
-
-
-
-
85 Min. 85 Min.
85 Min. 85 Min.
-
White y 0.329 +0.030
Maximum White Luminance (cd/m2) VDIM=0V
Note:Measure center of the screen.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
270 230 Min.
10/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
(
)
Engineering Specification
The following is the note for the Optical Characteristics:
Viewing or Measuring Direction
www.panelook.com
Z
Viewing o r Measuring Direction
+h-v
LEFT
LOW ER
X
CENTER OF LCD
X=0,Y=0,Z=0
UPPER
RIGHT
Y
There is the Uniformity Measurement below: 'Lbright' represents the Luminance of the point that is brighter than the other point to be compared. 'Ldark' represents the Luminance of the point that is darker than the other point to be compared. Measuring points are shown in the following Fig. 9 circles are defined for 9 points.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
11/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
Chromaticity and White Balance are defined as the C.I.E. 1931 x,y coordinates at the center of LCD. The Standard Equipment are as shown below table.
Item Standard Equipment
Viewing Angle BM5A by Topcon Optical
Contrast USB 2000 Ocean Optics
Response Time 6030 Lecory
White Luminance USB 2000 Ocean Optics
Luminance Uniformity USB 2000 Ocean Optics
Chromaticity CS1000T by Konica Minolta
White Balance USB 2000 Ocean Optics
The measurement is to be done after 120 minutes of Power-on of BackLight. Unless otherwise specified, the ambient conditions are as following.
Ambient Temperature : 25 + 2 ( degreeC ) Ambient Humidity : 25 - 85 ( % ) Atmospheric Pressure : 86.0 - 104.0 ( kPa )
4.1 Luminance Uniformity
When the backlight is on with all pels in the selected state (white), the luminance uniformity is defined as follows;
Where:
L
: The luminance of the brightness part of the area
bright
: The luminance of the darkest part of the area
L
dark
1. Adjacent Area L
Luminance Uniformity = >
L
over a circular area of 10mm diameter placed anywhere on the screen.
2. Screen Total L
dark
bright
dark
www.panelook.com
0.80
Luminance Uniformity = >
L
bright
0.60
over the entire screen.
3. Screen Total (9 points measurement)
L
Luminance Uniformity = >
L
dark
bright
0.80
over the entire screen.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
12/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
4.2 Image Retention
The panel spec of image retention is as follows.
Test method: The L0 IDT Log pattern on L255 background below is displayed for the display time
Then, change the pattern to L128 All gray pattern and count the time
until all IDT Log can’t read.
www.panelook.com
Display Time 5sec 60sec
Time until disappearing
Definition of disappearing time: The time when the brightness will reach to 0.89% difference from background
level (L128).
| L logo − L128 |
x 100 <
 
L128
 
0.89%
5sec
15sec
1
2
1
2
1
1
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
13/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
5.0 Signal Interface
5.1 Connectors
Physical interface is described as for the connector on module. These connectors are capable of accommodating the following signals and will be following components.
Connector Name / Designation Signal Connector
Manufacturer HIROSE
Type / Part Number DF14-30P-1.25H(56)
Mating Type / Part Number DF14-30S-1.25C
Contact / Part Number DF14-2628SCFA
www.panelook.com
Connector Name / Designation For Backlight Connector on Inverter card
Manufacturer JST
Type / Part Number S8B-PH-SM3-TB(D)(LF) or
S8B-PH-SM4-TB(LF)(SN)
Mating Type / Part Number PHR-8
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
14/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
5.2 Interface Signal Connector
Pin # Signal Name Pin # Signal Name
30 Vin(+12V) 29 Vin(+12V)
28 Vin(+12V) 27 VinRTN(GND)
26 VinRTN(GND) 25 VinRTN(GND)
24 SELLVDS 23 (RESERVED)
22 DGND 21 RxOIN3+
20 RxOIN3- 19 RxOCLKIN+
www.panelook.com
18 RxOCLKIN- 17 RxOIN2+
16 RxOIN2- 15 RxOIN1+
14 RxOIN1- 13 RxOIN0+
12 RxOIN0- 11 RxEIN3+
10 RxEIN3- 9 RxECLKIN+
8 RxECLKIN- 7 RxEIN2+
6 RxEIN2- 5 RxEIN1+
4 RxEIN1- 3 RxEIN0+
2 RxEIN0- 1 LVDSGND
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
15/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
5.3 Interface Signal Description
The module uses a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be SN75LVDS83(negative edge sampling) or compatible. The first LVDS port (RxExxx) transmits even pixels while the second LVDS port (RxOxxx) transmits odd pixels.
Please refer to the chart below for pin #1 of Signal Connector.
LCD Drive Connector No.1 Pin location
www.panelook.com
Pin No.1
Module Back side view
Signal Connector
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
16/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
PIN # SIGNAL NAME Description
30 Vin +12.0V Power Supply
29 Vin +12.0V Power Supply
28 Vin +12.0V Power Supply
27 VinRTN Ground for Vin line
26 VinRTN Ground for Vin line
25 VinRTN Ground for Vin line
24 SELLVDS Select LVDS data order. See the following figure.
23 (RESERVED) This pin should be left open.
www.panelook.com
22 DGND Signal Ground
21 RxOIN3+ Positive LVDS differential data input (Odd data)
20 RxOIN3- Negative LVDS differential data input (Odd data)
19 RxOCLKIN+ Positive LVDS differential clock input (Odd Clock)
18 RxOCLKIN- Negative LVDS differential clock input (Odd Clock)
17 RxOIN2+ Positive LVDS differential data input (Odd data)
16 RxOIN2- Negative LVDS differential data input (Odd data)
15 RxOIN1+ Positive LVDS differential data input (Odd data)
14 RxOIN1- Negative LVDS differential data input (Odd data)
13 RxOIN0+ Positive LVDS differential data input (Odd data)
12 RxOIN0- Negative LVDS differential data input (Odd data)
11 RxEIN3+ Positive LVDS differential data input (Even data)
10 RxEIN3- Negative LVDS differential data input (Even data)
9 RxECLKIN+ Positive LVDS differential clock input (Even Clock)
8 RxECLKIN- Negative LVDS differential clock input (Even Clock)
7 RxEIN2+ Positive LVDS differential data input (Even data,H-Sync,V-Sync,DSPTMG)
6 RxEIN2- Negative LVDS differential data input (Even data,H-Sync,V-Sync,DSPTMG)
5 RxEIN1+ Positive LVDS differential data input (Even data)
4 RxEIN1- Negative LVDS differential data input (Even data)
3 RxEIN0+ Positive LVDS differential data input (Even data)
2 RxEIN0- Negative LVDS differential data input (Even data)
1 DGND Signal Ground
Note: Input signals of odd and even clock shall be the same timing.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
17/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
The interface card has a 100ohm resistor between positive and negative lines of each LVDS signal input on the internal circuit.
(SELLVDS=Low)
RxECLKIN+
RxECLKIN-
www.panelook.com
1 cycle
RxEIN0+ RxEIN0-
RxEIN1+ RxEIN1-
RxEIN2+ RxEIN2-
RxEIN3+ RxEIN3-
RxOCLKIN+
RxOCLKIN-
RxOIN0+ RxOIN0-
RxOIN1+ RxOIN1-
ER1
EG2
EB3
ER7
OR1
OG2
ER0
EG1
EB2
ER6
OR0
OG1
EG0
EB1
DSP
NA
OG0
OB1
ER5
EB0
V-S
EB7
OR5
OB0
ER4
EG5
H-S
EB6
OR4
OG5
ER3
EG4
EB5
EG7
1 cycle
OR3
OG4
ER2
EG3
EB4
EG6
OR2
OG3
ER1
EG2
EB3
ER7
OR1
OG2
ER0
EG1
EB2
ER6
OR0
OG1
EG0
EB1
DSP
NA
OG0
OB1
RxOIN2+ RxOIN2-
RxOIN3+ RxOIN3-
OB3
OR7
OB2
OR6
NA
NA
NA
OB7
NA
OB6
OB5
OG7
OB4
OG6
OB3
OR7
OB2
OR6
Note: R/G/B data 7:MSB, R/G/B data 0:LSB
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
NA
NA
18/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
(SELLVDS=High)
RxECLKIN+
RxECLKIN-
www.panelook.com
1 cycle
RxEIN0+ RxEIN0-
RxEIN1+ RxEIN1-
RxEIN2+ RxEIN2-
RxEIN3+ RxEIN3-
RxOCLKIN+
RxOCLKIN-
RxOIN0+ RxOIN0-
RxOIN1+ RxOIN1-
ER3
EG4
EB5
ER1
OR3
OG4
ER2
EG3
EB4
ER0
OR2
OG3
EG2
EB3
DSP
NA
OG2
OB3
ER7
EB2
V-S
EB1
OR7
OB2
ER6
EG7
H-S
EB0
OR6
OG7
ER5
EG6
EB7
EG1
1 cycle
OR5
OG6
ER4
EG5
EB6
EG0
OR4
OG5
ER3
EG4
EB5
ER1
OR3
OG4
ER2
EG3
EB4
ER0
OR2
OG3
EG2
EB3
DSP
NA
OG2
OB3
RxOIN2+ RxOIN2-
RxOIN3+ RxOIN3-
OB5
OR1
OB4
OR0
NA
NA
NA
OB1
NA
OB0
OB7
OG1
OB6
OG0
OB5
OR1
OB4
OR0
Note: R/G/B data 7:MSB, R/G/B data 0:LSB
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
NA
NA
19/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
The following is LVDS Signal description.
www.panelook.com
LVDS DATA NAME Description
DSP
V-S
H-S
TI LVDS X'mitter (SN75LVDS83) Signal name
D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15 D16 D17 D18 D19 D20 D21 D22 D23 D24 D25 D26 D27
Note: SELLVDS: Pin#7 of Signal connector
Display Timing
Vertical Sync
Horizontal Sync
ITSX98E LVDS Signal (SELLVDS=Low)
Red0 Red1 Red2 Red3 Red4 Red7 Red5 Green0 Green1 Green2 Green6 Green7 Green3 Green4 Green5 Blue0 Blue6 Blue7 Blue1 Blue2 Blue3 Blue4 Blue5 NA H Sync V Sync Disp Timing Red6
When the signal is high, the pixel data shall be valid to be
displayed.
Both Positive and negative polarity are acceptable.
Both Positive and negative polarity are acceptable.
ITSX98E LVDS Signal (SELLVDS=High)
Red2 Red3 Red4 Red5 Red6 Red1 Red7 Green2 Green3 Green4 Green0 Green1 Green5 Green6 Green7 Blue2 Blue0 Blue1 Blue3 Blue4 Blue5 Blue6 Blue7 NA H Sync V Sync Disp Timing Red0
Red0: LSB, Red7: MSB
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
20/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
5.4 Interface Signal Electrical Characteristics
Input signals shall be low or Hi-Z state when Vin is off. It is recommended to refer the specifications of SN75LVDS82DGG(Texas Instruments) in detail.
Signal electrical characteristics are as follows;
Parameter Condition Min Max unit
www.panelook.com
Vth
Vtl
LVDS Timing
Differential Input High Voltage (Vcm=+1.2V)
Differential Input High Voltage (Vcm=+1.2V)
100 mV
-100 mV
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
21/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
LVDS Macro AC characteristics.
Parameter Symbol Min Typ Max Unit
LVDS Clock Cycle Trxc 17.6 18.5 20 [ns]
LVDS Data Cycle Trxd Trxc/7 [ns]
Sample Data Setup Time
(Trxc=Typ.)
Sample Data Hold Time
(Trxc=Typ.)
Data Sample Time Trxs Trxc/14 [ns]
Data Sample Cycle Trxsc Trxc/7 [ns]
Name Description Min Typ Max Unit Note
www.panelook.com
Trxss 600 [ps]
Trxsh 600 [ps]
SELLVDS High voltage 2 3 3.3 V
Low voltage -0.1 0 0.7 V
Current -1 - 1 mA
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
22/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
5.5 Backlight Connector Signal Description
PIN # SIGNAL NAME Description
1 VBL +12.0V Power Supply for backlight
2 VBL +12.0V Power Supply for backlight
3 VBL +12.0V Power Supply for backlihgt
4 RTN Ground for VBL line, VDIM and BLON
5 RTN Ground for VBL line, VDIM and BLON
6 RTN Ground for VBL line, VDIM and BLON
7 VDIM Brightness control voltage input(0-4V), (0V:brightness MAX, 4V:brightness MIN)
8 BLON backlihgt on/off signal(Hi:backlight ON, Low:backlight OFF) TTL level
5.6 Backlight Input Signal Electrical Characteristics
Name Description Min Typ Max Unit Note
www.panelook.com
BLON High voltage 2.0 5.0 5.25 V
Low voltage -0.1 0 0.8 V
Current -1.0 - 1.0 mA
VDIM Input Voltage Range 0 - 4.0 V
Current -1.0 - 1.0 mA
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
0V:Brightness Max. 4V:Brightness Min.
23/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
The following chart is the Dimming Signal (VDIM) versus Luminance curve for your reference.
ITSX98E Dimming Curve (VDIM vs Lumi.)
120.0%
100.0%
80.0%
www.panelook.com
60.0%
Luminance(%)
40.0%
20.0%
0.0% 0 0.5 1 1.5 2 2.5 3 3.5 4
Lumi(%)
VDIM(V)
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
24/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
www.panelook.com
6.0 Pixel format image
Following figure shows the relationship of the input signals and LCD pixel format image. Odd and even pair of RGB data are sampled at a time.
Even Odd Even Odd
1st Line
0 1 1279
RGB RGB
1278
R
B R
G
B
G
1024th Line
RGB RGB
R
B R
G
B
G
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
25/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
p
p
f
(*1)
p
(*1)
p
f
Engineering Specification
7.0 Interface Timings
Basically, interface timings described here is not actual input timing of LCD module but output timing of SN75LVDS82DGG(Texas Instruments) or equivalent.
7.1 Timing Characteristics
Item Symbol MIN. TYP. MAX. Unit
Signal
www.panelook.com
DTCLK Freq. Fdck
DTCLK Cycle Tck 17.6 18.5
+V-Sync Frame Rate
+V-Sync Cycle Tv 16.39 16.66 17.78 ms
+V-Sync Cycle Tv 1035 1066
+V-Sync active level Tva 3 3
+V-Sync V-back
+V-Sync V-front
+DSPTMG V-Line m - 1024
+H-Sync Scan Rate 1/Th
+H-Sync Cycle Th 844 844
+H-Sync active level
+H-Sync Back
+H-Sync Front
+DSPTMG Display Pixels n - 640
Note 1: Typical value is refer to VESA STANDARD.
Note 2: When there are invalid timing, Display appears black pattern.
Synchronous Signal Defects and enter Auto Refresh for LCD Module Protection Mode.
(*1): Tha+Thb should be less than 1024 Tck.
orch Tvb 7 38 63 lines
orch Tv
orch
orch Th
11/Tv
Tha
Thb
50
56.25 60.02 61 Hz
11
-
456
4 124
424
54 56.8 MHz
63.98
20
2047
-
-
1023
-
ns
lines
lines
lines
lines
KHz
Tck
Tck
Tck
Tck
Tck
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
26/38
www.panelook.com
Global LCD Panel Exchange Center
(
Engineering Specification
7.2 Timing Definition
Vertical Timing
www.panelook.com
DSPTMG
-VSYNC
+VSYNC
Support mode T1 Vertical
1280 x 1024 at 60Hz (VESA STANDARD) (H line rate: 15.6 us)
Horizontal Timing
DSPTMG
-HSYNC
T3 T5 T6
T1 T2
T2
Blanking
0.656 ms (42 lines)
T9 T11 T12
Active Field
16.005 ms (1024 lines)
T7 T8
T4
T3 VSYNC Front Porch
0.016 ms (1 line)
T10
T4 Frame Time
16.661 ms (1066 lines)
T5 VSYNC Width
0.047 ms (3 lines)
T6 VSYNC Back Porch
0.594 ms (38 lines)
+HSYNC
Support mode T7
1280 x 1024 (VESA STANDARD)
Horizontal
3.778 us (408 dots)
T8 Active Field
11.852 us (1280 dots)
T9 HSYNC
0.444 us (48 dots)
T10 H line Time
15.630 us (1688 dots)
T11 HSYNC
1.037 us (112 dots)
T12 HSYNC
2.296 us (248 dots)
Dotclock: 108.000
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
27/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
Interface Timing Definition
Tva
V-Sync
H-Sync
www.panelook.com
Tv
DSPTMG
H-Sync
Dot clock
DSPTMG
Video(Even)
Video(Odd)
Tck
Tha
Tvb Tvf
01 m-1
Vsync, Hsync and Display Timing
Th
Thd
Thb Thf
0
1
2
3
Video signal, Hsync and Dot clock
n-2
n-1
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
28/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
8.0 Power Consumption
Input power specifications are as follows;
SYMBOL PARAMETER Min Typ Max UNITS CONDITION
Vin Logic/LCD Drive
Voltage
Iin Vin Current
Pin(1) Vin Power
Pin(2)
Logic/LCD
DC current Waveform
Vin rp Allowable
Logic/LCD Drive Ripple Voltage
www.panelook.com
11.4 12 12.6 V
550 mA
4.5 W
5.2 6.3 W
Refer to the Typical Logic/LCDCurrent Waveform shown in the following Figure. Waveform may vary in paticular application. Actual current waveform on user application must be evaluated and make sure the ripple current and/or peak current should be allowable to user power supply.
500 mVp-p
Maximum Load Condition
Vin=11.4V (All White Pattern) (This value indicates long term average.) Typical Load Condition (Vertical Gray Bar, 256 Scale) Maximum Load Condition (All White)
(All White)
VBL Backlight power
voltage
PBL Backlight Power
consumption
Note: A used DC power supply for this LCD module should be have a over current protection function to safety.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
11.4 12 12.6 V
33.6 40.3 W
Brightness=max
29/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
Figure. Typical Logic/LCD Current Waveform
Condition: Maximum Load Condition(All White) Voltage: 12.0V measured at Interface Connector J1 Interface Cable: AWG28, 30 Conductors, L=500mm from Voltage Source to EUT
www.panelook.com
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
30/38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
9.0 Power ON/OFF Sequence
Vin and VBL power and lamp on/off sequence is as follows. Interface signals are also shown in the chart. Signals from any system shall be Hi-Z state or low level when Vin and VBL are off. It is recommended that the BLON should be supplied after other signals are stable in order to avoid visible screen noise when power-on.
www.panelook.com
Vin
0 V
Signals
0 V
VBL
0 V
BLON
0 V
10%
10%
90%
30ms max. and 1ms min.
0 min. 0 min.
10%
90%
30ms max. and 1ms min.
5ms min. 0 min.
1.9V
0.9V
1uS max.
90%
10% 10%
10ms min.
10%
100ms min.
90%
10% 10%
1.9V
0.9V
1uS max.
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
31/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
10.0 Mechanical Characteristics
Note: Please do not use middle 3(three) screw holes on the upper(long) side and middle 3(three) screw holes
on the lower(long) side for panel fixing. These screw holes are for manufacturing purpose only.
www.panelook.com
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
32/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
www.panelook.com
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
33/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
11.0 National Test Lab Requirement
The display module is authorized to Apply the UL Recognized Mark.
Conditions of Acceptability
Conditions of Acceptability - When installed on the end-product, consideration shall be given to the following;
1. This component has been judged on the basis of the required spacings in the Standard for Safety of Information Technology Equipment, CAN/CSA C22.2 No. 60950-00 *UL60950, Third Edition, which are based on the IEC 60950, Third Edition, which would cover the component itself if submitted for Listing.
2. The inverter output circuits are Limited Current Circuits.
3. The units are intended to be supplied by SELV.
4. The terminals and connectors are suitable for factory wiring only.
5. A suitable Electrical enclosure shall be provided.
www.panelook.com
12.0 Backlight Life
Backlight Life Time 50,000 Hours (Typ) condition 25 degree C
30,000 Hours (Min)
The assumed Backlight Life will be until the luminance becomes 105 cd/m luminance.
2
or more at maximum white
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
34/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
13.0 Packaging Requirement
The packaging of the LCD meets 75 cm drop test. The following is the drawing of the package.
www.panelook.com
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
35/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
www.panelook.com
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
36/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
14.0 Label
There are labels on the rear side of the Module.
www.panelook.com
Serial Number Label
BARCODE CHARACTER AREA
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
37/38
www.panelook.com
Global LCD Panel Exchange Center
Engineering Specification
Date Label
YY and WW of the Week Code stand for the Year and the Week of the Year of manufacturing of the Module respectively.
UL Label
www.panelook.com
****** End Of Page ******
(C) Copyright International Display Technology 2006 All Rights reserved
Feb. 2, 2007 OEM I-98E-04
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
38/38
www.panelook.com
Loading...
