IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

IDT79R3081 RISController



IDT 79R3081, 79R3081E

IDT 79RV3081, 79RV3081E

with FPA

Integrated Device Technology, Inc.

FEATURES

• Instruction set compatible with IDT79R3000A, R3041, R3051, and R3071 RISC CPUs

• High level of integration minimizes system cost — R3000A Compatible CPU — R3010A Compatible Floating Point Accelerator — Optional R3000A compatible MMU — Large Instruction Cache — Large Data Cache — Read/Write Buffers

• 43VUPS at 50MHz — 13MFlops

• Flexible bus interface allows simple, low cost designs

• Optional 1x or 2x clock input

• 20 through 50MHz operation

• "V" version operates at 3.3V

• 50MHz at 1x clock input and 1/2 bus frequency only

R3081 BLOCK DIAGRAM

ClkIn

Int(5:0)

Clock Generator

Unit/Clock Doubler

System Control

Coprocessor

(CP0)

Exception/Control

Registers

Memory Management

Registers

Translation

Lookaside Buffer

(64 entries)

Master Pipeline Control

Virtual Address

• Large on-chip caches with user configurability — 16kB Instruction Cache, 4kB Data Cache — Dynamically configurable to 8kB Instruction Cache,

8kB Data Cache

— Parity protection over data and tag fields

• Low cost 84-pin packaging

• Superset pin- and software-compatible with R3051, R3071

• Multiplexed bus interface with support for low-cost, lowspeed memory systems with a high-speed CPU

• On-chip 4-deep write buffer eliminates memory write stalls

• On-chip 4-deep read buffer supports burst or simple block reads

• On-chip DMA arbiter

• Hardware-based Cache Coherency Support

• Programmable power reduction mode

• Bus Interface can operate at half-processor frequency

BrCond(3:2,0)

Floating Point

Integer

CPU Core

General Registers

(32 x 32)

ALU

Shifter

Mult/Div Unit

Address Adder

PC Control

FP Interrupt

Coprocessor

(CP1)

(16 x 64)

Exponent Unit

Add Unit

Divide Unit

Multiply Unit

Exception/Control

Physical Address Bus

Parity

Generator

4-deep

The IDT logo is a registered trademark, and RISController, R3041, R3051, R3052, R3071, R3081, R3720, R4400, R4600, IDT/kit, and IDT/sim are trademarks of Integrated Device Technology, Inc.

Read

Buffer

Configurable

Instruction

Cache

(16kB/8kB)

4-deep

Write

Buffer

Address/

Data

Data Bus

R3051 Superset Bus Interface Unit

DMA

Arbiter

Ctrl

Configurable

Data

Cache

(4kB/8kB)

BIU

Control

Rd/Wr

Ctrl

SysClk

Coherency

Logic

Invalidate

Control

Data Bus

2889 drw 01

MILITARY AND COMMERCIAL TEMPERATURE RANGES OCTOBER 2001

2001 Integrated Device Technology, Inc. 5.5 DSC-9064/5

5.5 1

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

INTRODUCTION

The IDT R3051 family is a series of high-performance 32bit microprocessors featuring a high-level of integration, and targeted to high-performance but cost sensitive processing applications. The R3051 family is designed to bring the highperformance inherent in the MIPS RISC architecture into low-cost, simplified, power sensitive applications.

Thus, functional units have been integrated onto the CPU core in order to reduce the total system cost, rather than to increase the inherent performance of the integer engine. Nevertheless, the R3051 family is able to offer 43VUPS performance at 50MHz without requiring external SRAM or caches.

The R3081 extends the capabilities of the R3051 family, by integrating additional resources into the same pin-out. The R3081 thus extends the range of applications addressed by the R3051 family, and allows designers to implement a single, base system and software set capable of accepting a wide variety of CPUs, according to the price/performance goals of the end system.

In addition to the embedded applications served by the R3051 family, the R3081 allows low-cost, entry level computer systems to be constructed. These systems will offer many times the performance of traditional PC systems, yet cost approximately the same. The R3081 is able to run any standard R3000A operation system, including ACE UNIX. Thus, the R3081 can be used to build a low-cost ARC compliant system, further widening the range of performance solutions of the ACE Initiative.

An overview of this device, and quantitative electrical parameters and mechanical data, is found in this data sheet; consult the complete description of this processor.

"R3081 Family Hardware User's Guide"

for a

DEVICE OVERVIEW

As part of the R3051 family, the R3081 extends the offering of a wide range of functionality in a compatible interface. The R3051 family allows the system designer to implement a single base system, and utilize interface-compatible processors of various complexity to achieve the price-performance goals of the particular end system.

Differences among the various family members pertain to the on-chip resources of the processor. Current family members include:

• The R3052E, which incorporates an 8kB instruction cache,

a 2kB data cache, and full function memory management

unit (MMU) including 64-entry fully associative Translation

Lookaside Buffer (TLB).

• The R3052, which also incorporates an 8kB instruction

cache and 2kB data cache, but does not include the TLB,

and instead uses a simpler virtual to physical address

mapping.

• The R3051E, which incorporates 4kB of instruction cache

and 2kB of data cache, along with the full function MMU/

TLB of the R3000A.

• The R3051, which incorporates 4kB of instruction cache and 2kB of data cache, but omits the TLB, and instead uses a simpler virtual to physical address mapping.

• The R3081E, which incorporates a 16kB instruction cache, a 4kB data cache, and full function memory management unit (MMU) including 64-entry fully associative Translation Lookaside Buffer (TLB). The cache on the R3081E is user configurable to an 8kB Instruction Cache and 8kB Data Cache.

• The R3081, which incorporates a 16kB instruction cache, a 4kB data cache, but uses the simpler memory mapping of the R3051/52, and thus omits the TLB. The cache on the R3081 is user configurable to an 8kB Instruction Cache and 8kB Data Cache. Figure 1 shows a block level representation of the functional

units within the R3081E. The R3081E could be viewed as the embodiment of a discrete solution built around the R3000A and R3010A. However, by integrating this functionality on a single chip, dramatic cost and power reductions are achieved.

CPU Core

The CPU core is a full 32-bit RISC integer execution

engine, capable of sustaining close to single cycle execution. The CPU core contains a five stage pipeline, and 32 orthogonal 32-bit registers. The R3081 uses the same basic integer execution core as the entire R3051 family, which is the R3000A implementation of the MIPS instruction set. Thus, the R3081 family is binary compatible with the R3051, R3052, R3000A, R3001, and R3500 CPUs. In addition, the R4000 represents an upwardly software compatible migration path to still higher levels of performance.

The execution engine in the R3081 uses a five-stage

pipeline to achieve near single-cycle instruction execution rates. A new instruction can be initiated in each clock cycle; the execution engine actually processes five instructions concurrently (in various pipeline stages). Figure 2 shows the concurrency achieved in the R3081 execution pipeline.

System Control Co-Processor

The R3081 family also integrates on-chip the System

Control Co-processor, CP0. CP0 manages both the exception handling capability of the R3081, as well as the virtual to physical address mapping.

As with the R3051 and R3052, the R3081 offers two

versions of memory management and virtual to physical address mapping: the extended architecture versions, the R3051E, R3052E, and R3081E, incorporate the same MMU as the R3000A. These versions contain a fully associative 64entry TLB which maps 4kB virtual pages into the physical address space. The virtual to physical mapping thus includes kernel segments which are hard-mapped to physical addresses, and kernel and user segments which are mapped page by page by the TLB into anywhere in the 4GB physical address space. In this TLB, 8 pages can be “locked” by the kernel to insure deterministic response in real-time applications. Figure 3 illustrates the virtual to physical mapping found in the R3081E.

5.5 2

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

The extended architecture versions of the R3051 family

I#1

ALURD MEM WB

(the R3051E, R3052E, and R3081E) allow the system designer to implement kernel software which dynamically manages

I#2

ALURD MEM WB

user task utilization of system resources, and also allows the Kernel to protect certain resources from user tasks. These capabilities are important in general computing applications

I#3

ALURD MEM WB

such as ARC computers, and are also important in a variety of embedded applications, from process control (where protection

I#4

ALURD MEM WB

may be important) to X-Window display systems (where virtual memory management can be used). The MMU can

I#5

ALURD MEM WB

also be used to simplify system debug.

R3051 family base versions (the R3051, R3052, and R3081)

remove the TLB and institute a fixed address mapping for the

Current

CPU

Cycle

Figure 2. R3081 5-Stage Pipeline

2889 drw 02

various segments of the virtual address space. These devices still support distinct kernel and user mode operation, but do not require page management software, leading to a simpler software model. The memory mapping used by these devices is shown in Figure 4. Note that the reserved spaces are for compatiblity with future family members, which may map onchip resources to these addresses. References to these addresses in the R3081 will be translated in the same fashion as the rest of their respective segments, with no traps or exceptions signalled.

When using the base versions of the architecture, the

system designer can implement a distinction between the user tasks and the kernel tasks, without having to implement page management software. This distinction can be implemented by decoding the output physical address. In systems which do not need memory protection, and wish to have the kernel and user tasks operate out of the same memory space, high-order address lines can be ignored by

0xffffffff

0xc0000000

0xa0000000

0x80000000

VIRTUAL PHYSICAL

Kernel Mapped

(kseg2)

Kernel Uncached

(kseg1)

Kernel Cached

(kseg0)

Any

Physical

Memory

3548MB

the address decoder, and thus all references will be seen in

User Mapped

Cacheable

(kuseg)

0x00000000

Figure 3. Virtual to Physical Mapping of Extended Architecture

Any

Memory

Versions

512 MB

2889 drw 03

the lower gigabyte of the physical address space.

Floating Point Co-Processor

The R3081 also integrates an R3010A compatible floating

point accelerator on-chip. The FPA is a high-performance coprocessor (co-processor 1 to the CPU) providing separate add, multiply, and divide functional units for single and double precision floating point arithmetic. The floating point accelerator

0xffffffff

VIRTUAL

1MB Kernel Rsvd

PHYSICAL

features low latency operations, and autonomous functional units which allow differing types of floating point operations to function concurrently with integer operations. The R3010A

Kernel Cached

(kseg2)

0xc0000000

Kernel Uncached

(kseg1)

0xa0000000

Kernel Cached

(kseg0)

0x80000000

1MB User Rsvd

User Cached (kuseg)

0x00000000

Figure 4. Virtual to Physical Mapping of Base Architecture Versions

Kernel Cacheable

Tasks

Kernel/User

Cacheable

Tasks

Inaccessible

Kernel Boot

and I/O

1024 MB

2048 MB

512 MB

2889 drw 04

appears to the software programmer as a simple extension of the integer execution unit, with 16 dedicated 64-bit floating point registers (software references these as 32 32-bit registers when performing loads or stores). Figure 5 illustrates the functional block diagram of the on-chip FPA.

Clock Generator Unit

The R3081 is driven from a single input clock which can be either at the processor rated speed, or at twice that speed. Onchip, the clock generator unit is responsible for managing the interaction of the CPU core, caches, and bus interface. The R3081 includes an on-chip clock doubler to provide higher frequency signals to the internal execution core; if 1x clock mode is selected, the clock doubler will internally convert it to

5.5 3

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

a double frequency clock. The 2x clock mode is provided for compatiblity with the R3051. The clock generator unit replaces the external delay line required in R3000A based applications.

Instruction Cache

The R3081 implements a 16kB Instruction Cache. The system may choose to repartition the on-chip caches, so that the instruction cache is reduced to 8kB but the data cache is increased to 8kB. The instruction cache is organized with a line size of 16bytes (four entries). This large cache achieves hit rates in excess of 98% in most applications, and substantially contributes to the performance inherent in the R3081. The cache is implemented as a direct mapped cache, and is capable of caching instructions from anywhere within the 4GB physical address space. The cache is implemented using physical addresses (rather than virtual addresses), and thus does not require flushing on context switch.

The instruction cache is parity protected over the instruction word and tag fields. Parity is generated by the read buffer during cache refill; during cache references, the parity is checked, and in the case of a parity error, a cache miss is processed.

Data Cache

The R3081 incorporates an on-chip data cache of 4kB, organized as a line size of 4 bytes (one word). The R3081 allows the system to reconfigure the on-chip cache from the default 16kB I-Cache/4kB D-Cache to 8kB of Instruction and 8kB of Data caches.

The relatively large data cache achieves hit rates in excess of 95% in most applications, and contributes substantially to

the performance inherent in the R3081. As with the instruction cache, the data cache is implemented as a direct mapped physical address cache. The cache is capable of mapping any word within the 4GB physical address space.

The data cache is implemented as a write-through cache, to insure that main memory is always consistent with the internal cache. In order to minimize processor stalls due to data write operations, the bus interface unit incorporates a 4deep write buffer which captures address and data at the processor execution rate, allowing it to be retired to main memory at a much slower rate without impacting system performance. Further, support has been provided to allow hardware based data cache coherency in a multi-master environment, such as one utilizing DMA from I/O to memory.

The data cache is parity protected over the data and tag fields. Parity is generated by the read buffer during cache refill; during cache references, the parity is checked, and in the case of a parity error, a cache miss is processed.

Bus Interface Unit

The R3081 uses its large internal caches to provide the majority of the bandwidth requirements of the execution engine, and thus can utilize a simple bus interface connected to slower memory devices. Alternately, a high-performance, low-cost secondary cache can be implemented, allowing the processor to increase performance in systems where bus bandwidth is a performance limitation.

As part of the R3051 family, the R3081 bus interface utilizes a 32-bit address and data bus multiplexed onto a single set of pins. The bus interface unit also provides an ALE (Address Latch Enable) output signal to de-multiplex the A/D bus, and

Cache Data

Data Bus

(32) (32)

Instructions Operands

Exponent Part Fraction

Condition

Codes

Control Unit

and Clocks

(11) (11) (11) (53) (53) (53)

A B Result Result

Exponent

Unit

Divide Unit

Multiply Unit

Figure 5. FPA Functional Block Diagram

(53) (53) (56)

Add Unit

Round

ResultAB

2889 drw 05

5.5 4

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

simple handshake signals to process CPU read and write requests. In addition to the read and write interface, the R3051 family incorporates a DMA arbiter, to allow an external master to control the external bus.

The R3081 also supports hardware based cache coherency during DMA writes. The R3081 can invalidate a specified line of data cache, or in fact can perform burst invalidations during burst DMA writes.

The R3081 incorporates a 4-deep write buffer to decouple the speed of the execution engine from the speed of the memory system. The write buffers capture and FIFO processor address and data information in store operations, and present it to the bus interface as write transactions at the rate the memory system can accommodate.

The R3081 read interface performs both single datum reads and quad word reads. Single reads work with a simple handshake, and quad word reads can either utilize the simple handshake (in lower performance, simple systems) or utilize a tighter timing mode when the memory system can burst data at the processor clock rate. Thus, the system designer can choose to utilize page or nibble mode DRAMs (and possibly use interleaving, if desired, in high-performance systems), or use simpler techniques to reduce complexity.

In order to accommodate slower quad word reads, the R3081 incorporates a 4-deep read buffer FIFO, so that the external interface can queue up data within the processor before releasing it to perform a burst fill of the internal caches.

The R3081 is R3051 superset compatible in its bus interface. Specifically, the R3081 has additional support to simplify the design of very high frequency systems. This support includes the ability to run the bus interface at one-half the processor execution rate, as well as the ability to slow the transitions between reads and writes to provide extra buffer disable time for the memory interface. However, it is still possible to design a system which, with no modification to the PC Board or software, can accept either an R3041, R3051, R3052, R3071, or R3081.

SYSTEM USAGE

The IDT R3051 family has been specifically designed to allow a wide variety of memory systems. Low-cost systems can use slow speed memories and simple controllers, while other designers may choose to incorporate higher frequencies, faster memories, and techniques such as DMA to achieve maximum performance. The R3081 includes specific support for high perfromance systems, including signals necessary to implement external secondary caches, and the ability to perform hardware based cache coherency in multi-master systems.

Figure 6 shows a typical system implementation. Transparent latches are used to de-multiplex the R3081 address and data busses from the A/D bus. The data paths between the memory system elements and the A/D bus is managed by simple octal devices. A small set of simple PALs is used to control the various data path elements, and to control the handshake between the memory devices and the CPU.

Depending on the cost vs. performance tradeoffs appropriate

to a given application, the system design engineer could include true burst support from the DRAM to provide for highperformance cache miss processing, or utilize a simpler, lower performance memory system to reduce cost and simplify the design. Similarly, the system designer could choose to implement techniques such as external secondary cache, or DMA, to further improve system performance.

DEVELOPMENT SUPPORT

The IDT R3051 family is supported by a rich set of development tools, ranging from system simulation tools through PROM monitor and debug support, applications software and utility libraries, logic analysis tools, sub-system modules, and shrink wrap operating systems. The R3081, which is pin and software compatible with the R3051, can directly utilize these existing tools to reduce time to market.

Figure 7 is an overview of the system development process typically used when developing R3051 family applications. The R3051 family is supported in all phases of project development. These tools allow timely, parallel development of hardware and software for R3051 family applications, and include tools such as:

• Optimizing compilers from MIPS, the acknowledged leader

in optimizing compiler technology.

• Cross development tools, available in a variety of

development environments.

• The IDT Evaluation Board, which includes RAM, EPROM,

I/O, and the IDT PROM Monitor.

• IDT/sim



, which implements a full prom monitor

(diagnostics, remote debug support, peek/poke, etc.).

• IDT/kit, which implements a run-time support package for

R3051 family systems.

PERFORMANCE OVERVIEW

The R3081 achieves a very high-level of performance. This performance is based on:

• An efficient execution engine. The CPU performs ALU

operations and store operations in a single cycle, and has

an effective load time of 1.3 cycles, and branch execution

rate of 1.5 cycles (based on the ability of the compilers to

avoid software interlocks). Thus, the execution engine

achieves over 35 VUPS performance when operating out

of cache.

• A full featured floating point accelerator/co-processor.

The R3081 incorporates an R3010A compatible floating

point accelerator on-chip, with independent ALUs for floating

point add, multiply, and divide. The floating point unit is fully

hardware interlocked, and features overlapped operation

and precise exceptions. The FPA allows floating point

adds, multiplies, and divides to occur concurrently with

each other, as well as concurrently with integer operations.

• Large on-chip caches. The R3051 family contains caches

which are substantially larger than those on the majority of

today’s microprocessors. These large caches minimize the

number of bus transactions required, and allow the R3051

family to achieve actual sustained performance very close

to its peak execution rate. The R3081 doubles the cache

available on the R3052, making it a suitable engine for

5.5 5

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

ClkIn

IDT R3081

RISController

I/O Controller

Address/Data

R3051

Local Bus

DRAM DRAMPROM I/O I/O

Figure 6. R3081 RISChipset Based System

Control

DRAM

Controller

IDT73720

Bus Exchanger

2889 drw 06

System

Architecture

Evaluation

Cache-3051

SPP

Benchmarks

Evaluation Board

Laser Printer System

X-Terminal System

System

Development

Phase

Software

DBG Debugger

PIXIE Profiler

MIPS Compiler Suite

Stand-Alone Libraries

Floating Point Library

Cross Development Tools

Adobe PostScript PDL

MicroSoft TrueImage PDL

PeerlessPage Printer OS

X-Server

Hardware

Hardware Models

General CAD Tools

Evaluation Board

Laser Printer System

Support Chips

Figure 7. R3051 Family Development Toolchain

System

Integration

and Verfification

Logic Analysis

Diagnostics

IDT/sim

IDT/kit

In-Circuit Emulation

Remote Debug

Real-Time OS

2889 drw 07

5.5 6

IDT79R3081 RISController MILITARY AND COMMERICAL TEMPERATURE RANGES

many general purpose computing applications, such as ARC compliant systems.

• Autonomous multiply and divide operations. The R3051 family features an on-chip integer multiplier/divide unit which is separate from the other ALU. This allows the CPU to perform multiply or divide operations in parallel with other integer operations, using a single multiply or divide instruction rather than “step” operations.

• Integrated write buffer. The R3081 features a four deep write buffer, which captures store target addresses and data at the processor execution rate and retires it to main memory at the slower main memory access rate. Use of on-chip write buffers eliminates the need for the processor to stall when performing store operations.

• Burst read support. The R3051 family enables the system designer to utilize page mode or nibble mode RAMs when performing read operations to minimize the main memory read penalty and increase the effective cache hit rates.

These techniques combine to allow the processor to achieve over 43 VUPS integer performance, 13MFlops of Linpack performance, and 70,000 dhrystones without the use of external caches or zero wait-state memory devices.

The performance differences between the various family members depends on the application software and the design of the memory system. The impact of the various cache sizes, and the hardware floating point, can be accurately modeled using Cache-3051. Since the R3041, R3051, R3052, R3071, and R3081 are all pin and software compatible, the system designer has maximum freedom in trading between performance and cost. A system can be designed, and later the appropriate CPU inserted into the board, depending on the desired system performance.

SELECTABLE FEATURES

The R3081 allows the system designer to configure certain aspects of operation. Some of these options are established when the device is reset, while others are enabled via the Config registers:

• BigEndian vs. LittleEndian Byte Ordering. The part can be configured to operate with either byte ordering. ACE/ARC systems typically use Little Endian byte ordering. However, various embedded applications, written originally for a Big Endian processor such as the MC680x0, are easier to port to a Big Endian system.

• Data Cache Refill of one or four words. The memory system must be capable of performing four word refills of instruction cache misses. The R3081 allows the system designer to enable D-Cache refill of one or four words dynamically. Thus, specialized algorithms can choose one refill size, while the rest of the system can operate with the other.

• Half-frequency bus mode. The processor can be configured such that the external bus interface is at one-half the frequency of the processor core. This simplifies system design; however, the large on-chip caches mitigate the performance impact of using a slower system bus clock.

• Slow bus turn-around. The R3081 allows the system designer to space processor operations, so that more time

is allowed for transitions between memory and the processor on the multiplexed address/data bus.

• Configurable cache. The R3081 allows the system designer to use software to select either a 16kB Instruction Cache/4kB Data Cache organization, or an 8kB Instruction/8kB Data Cache organization.

• Cache Coherent Interface. The R3081 has an optional hardware based cache coherency interface intended to support multi-master systems such as those utilizing DMA between memory and I/O.

• Optional 1x or 2x clock input. The R3081 can be driven with an R3051 compatible 2x clock input, or a lower frequency 1x clock input.

THERMAL CONSIDERATIONS

The R3081 utilizes special packaging techniques to improve the thermal properties of high-speed processors. Thus, the R3081 is packaged using cavity down packaging, with an embedded thermal slug to improve thermal transfer to the surrounding air.

The R3081 utilizes the 84-pin plastic package, with the die being attached to a heat slug. The DL84 package allows for an efficient thermal transfer between the die and the heat slug. The heat slug offers a greater area for convection at any given temperature. Even nominal amounts of airflow will dramatically reduce the junction temperature of the die, resulting in cooler operation. The DL84 package is available at all frequencies, and is pin and form compatible with the PLCC used for the R3051. Thus, designers can interchange R3081s and R3051s in a particular design, without changing their PC Board.

The R3081 is guaranteed in a case temperature range of 0°C to +85°C. The type of package, speed (power) of the device, and airflow conditions, affect the equivalent ambient temperature conditions which will meet this specification.

The equivalent allowable ambient temperature, TA, can be calculated using the thermal resistance from case to ambient (ØCA) of the given package. The following equation relates ambient and case temperature:

TA = T C - P * ØCA

where P is the maximum power consumption at hot temperature, calculated by using the maximum Icc specification for the device.

Typical values for ØCA at various airflows are shown in Table 1.

Note that the R3081 allows the operational frequency to be turned down during idle periods to reduce power consumption. This operation is described in the R3081 Hardware User's Guide. Reducing the operation frequency dramatically reduces power consumption.

5.5 7

IDT79R3081 RISController MILITARY AND COMMERICAL TEMPERATURE RANGES

minimize skew due to slow rise or fall times. A typical part will

Airflow (m/s) 012345

DL84

21.0 12.8 12.0 9.9 9.2 8.5

have less than 2ns rise or fall (10% to 90% signal times) when driving the test load.

Therefore, the system designer should use care when designing for direct SysClk use. Total loading (due to devices

DL84

PL84

Table 1 Thermal Resistance at Various Airflows

18.3 10.1 9.3 7.2 6.6 5.8

36.6 29.6 27.0 26.2 25.4 24.8

18.3 10.1 9.3 7.2 6.6 5.8

connected on the signal net and the routing of the net itself) should be minimized to ensure the SysClk output has a smooth and rapid transition. Long rise and/or fall times may cause a degradation in the speed capability of an individual device.

Similarly, the R3081 employs feedback on its ALE output to ensure adequate address hold time to ALE. The system designer should be careful when designing the ALE net to

NOTES ON SYSTEM DESIGN

The R3081 has been designed to simplify the task of highspeed system design. Thus, set-up and hold-time requirements have been kept to a minimum, allowing a wide variety of system interface strategies.

To minimize these AC parameters, the R3081 employs

minimize total loading and to minimize skew between ALE and the A/D bus, which will ensure adequate address access latch time.

IDT's field and factory applications groups can provide the system designer with assistance for these and other design issues.

feedback from its SysClk output to the internal bus interface unit. This allows the R3081 to reference input signals to the reference clock seen by the external system. The SysClk output is designed to provide relatively large AC drive to

5.5 8

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

PIN DESCRIPTION

PIN NAME I/O DESCRIPTION

A/D(31:0) I/O Address/Data: A 32-bit time multiplexed bus which indicates the desired address for a bus transaction

in one phase, and which is used to transmit data between the CPU and external memory resources during the rest of the transfer.

Bus transactions on this bus are logically separated into two phases: during the first phase, information about the transfer is presented to the memory system to be captured using the ALE output. This information consists of:

Address(31:4): The high-order address for the transfer is presented on A/D(31:4). BEBE(3:0): These strobes indicate which bytes of the 32-bit bus will be involved in

the transfer, and are presented on A/D(3:0).

During write cycles, the bus contains the data to be stored and is driven from the internal write buffer. On read cycles, the bus receives the data from the external resource, in either a single data transaction or in a burst of four words, and places it into the on-chip read buffer.

During cache coherency operations, the R3081 monitors the A/D bus at the start of a DMA write to capture the write target address for potential data cache invalidates.

Addr(3:2) O Low Address (3:2) A 2-bit bus which indicates which word is currently expected by the processor.

Specifically, this two bit bus presents either the address bits for the single word to be transferred (writes or single datum reads) or functions as a two bit counter starting at ‘00’ for burst read operations.

During cache coherency operations, the R3081 monitors the Addr bus at the start of a DMA write to capture the write target address for potential data cache invalidates.

Diag(1) O Diagnostic Pin 1. This output indicates whether the current bus read transaction is due to an on-chip

cache miss, and also presents part of the miss address. The value output on this pin is time multiplexed:

Cached: During the phase in which the A/D bus presents address information, this

pin is an active HIGH output which indicates whether the current read is a result of a cache miss.

Miss Address (3): During the remainder of the read operation, this output presents address

bit (3) of the address the processor was attempting to reference when the cache miss occurred. Regardless of whether a cache miss is being processed, this pin reports the transfer address during this time.

On write cycles, this output signals whether the data being written as retained in the on-chip data cache. The value of this pin is time multiplexed during writes:

Cached: During the address phase of write transactions, this signal is an active

high output which indicates that the store data was retained in the on-chip data cache.

Reserved: The value of this pin during the data phase of writes is reserved.

Diag(0) O Diagnostic Pin 0. This output distinguishes cache misses due to instruction references from those

due to data references, and presents the remaining bit of the miss address. The value output on this pin is also time multiplexed:

DD: If the “Cached” Pin indicates a cache miss, then a high on this pin at this

time indicates an instruction reference, and a low indicates a data reference. If the read is not due to a cache miss but rather an uncached reference, then this pin is undefined during this phase.

Miss Address (2): During the remainder of the read operation, this output presents

address bit (2) of the address the processor was attempting to reference when the cache miss occurred. Regardless of whether a cache miss is being processed, this pin reports the transfer address during this time.

During write cycles, the value of this pin during both the address and data phases is reserved.

2889 tbl 02

5.5 9

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

PIN DESCRIPTION (Continued):

PIN NAME I/O DESCRIPTION

ALE I/O Address Latch Enable: Used to indicate that the A/D bus contains valid address information for the bus

transaction. This signal is used by external logic to capture the address for the transfer, typically using transparent latches.

During cache coherency operations, the R3081 monitors ALE at the start of a DMA write, to capture the write target address for potential data cache invalidates.

Rd Wr

DataEn

Burst/ WrNear

Ack

RdCEn

SysClk

BusReq

BusGnt

IvdReq

CohReq

SBrCond(3:2) I Branch Condition Port: These external signals are internally connected to the CPU signals CpCond(3:0). BrCond(0) These signals can be used by the branch on co-processor condition instructions as input ports. There are two

BusError

O Read: An output which indicates that the current bus transaction is a read. I/O Write: An output which indicates that the current bus transaction is a write. During coherent DMA, this input

indicates that the current transfer is a write.

O External Data Enable: This signal indicates that the A/D bus is no longer being driven by the processor during

read cycles, and thus the external memory system may enable the drivers of the memory system onto this bus without having a bus conflict occur. During write cycles, or when no bus transaction is occurring, this signal is negated, thus disabling the external memory drivers

O Burst Transfer/Write Near: On read transactions, the

Burst

signal indicates that the current bus read is requesting a block of four contiguous words from memory. This signal is asserted only in read cycles due to cache misses; it is asserted for all I-Cache miss read cycles, and for D-Cache miss read cycles if quad word refill is currently selected.

On write transactions, the

WrNear

output tells the external memory system that the bus interface unit is performing back-to-back write transactions to an address within the same 512 word page as the prior write transaction. This signal is useful in memory systems which employ page mode or static column DRAMs, and allows near writes to be retired quickly.

I Acknowledge: An input which indicates to the device that the memory system has sufficiently processed the

bus transaction, and that the CPU may either terminate the write cycle or process the read data from this read transfer.

During Coherent DMA, this input indicates that the current write transfer is completed, and that the internal invalidation address counter should be incremented.

I Read Buffer Clock Enable: An input which indicates to the device that the memory system has placed valid

data on the A/D bus, and that the processor may move the data into the on-chip Read Buffer.

O System Reference Clock: An output from the CPU which reflects the timing of the internal processor "Sys"

clock. This clock is used to control state transitions in the read buffer, write buffer, memory controller, and bus interface unit. This clock will either be at the same frequency as the CPU execution rate clock, or at one-half that frequency, as selected during reset.

I DMA Arbiter Bus Request: An input to the device which requests that the CPU tri-state its bus interface signals

so that they may be driven by an external master.

O DMA Arbiter Bus Grant. An output from the CPU used to acknowledge that a

BusReq

has been detected, and

that the bus is relinquished to the external master.

I Invalidate Request. An input provided by an external DMA controller to request that the CPU invalidate the

Data Cache line corresponding to the current DMA write target address. This signal is the same pin as Diag(0)

I Coherent DMA Request. An input used by the external DMA controller to indicate that the requested DMA

operations could involve hardware cache coherency. This signal is the Rsvd(0) of the R3051.

types of Branch Condition inputs: the SBrCond inputs have special internal logic to synchronize the inputs, and thus may be driven by asynchronous agents. The direct Branch Condition inputs must be driven synchronously. Note that BrCond(1) is used by the internal FPA, and thus is not available on an external pin.

I Bus Error: Input to the bus interface unit to terminate a bus transaction due to an external bus error. This signal

is only sampled during read and write operations. If the bus transaction is a read operation, then the CPU will take a bus error exception.

2889 tbl 03

5.5 10

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

PIN DESCRIPTION (Continued):

PIN NAME I/O DESCRIPTION

Int

(5:3) I Processor Interrupt: During normal operation, these signals are logically the same as the

signals of the R3000. During processor reset, these signals perform mode initialization of the CPU, but in a different (simpler) fashion than the interrupt signals of the R3000.

There are two types of interrupt inputs: the

SInt

inputs are internally synchronized by the processor, and may be driven by an asynchronous external agent. The direct interrupt inputs are not internally synchronized, and thus must be externally synchronized to the CPU. The direct interrupt inputs have one cycle lower latency than the synchronized interrupts. Note that the interrupt used by the on-chip FPA will not be monitored externally.

ClkIn I Master Clock Input: This input clock can be provided at the execution frequency of the CPU (1x clock mode)

or at twice that frequency (2x clock mode), as selected at reset.

Reset

I Master Processor Reset: This signal initializes the CPU. Mode selection is performed during the last cycle

Reset

Rsvd(4:1) I/O Reserved: These four signal pins are reserved for testing and for future revisions of this device. Users must not

connect these pins. Note that Rsvd(0) of the R3051 is now used for the

CohReq

input pin.

Int

(5:0)

SInt

2889 tbl 04

(2:0)

ABSOLUTE MAXIMUM RATINGS

(1, 3)

Symbol Rating Commercial Military Unit

TERM Terminal Voltage –0.5 to +7.0 –0.5 to +7.0 V

with Respect to GND

C Operating Case 0 to +85 –55 to +125 °C

Temperature

BIAS Case Temperature –55 to +125 –65 to +135 °C

Under Bias

STG Storage –55 to +125 –65 to +155 °C

Temperature

IN Input Voltage –0.5 to +7.0 –0.5 to +7.0 V

NOTES:

1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

IN minimum = –3.0V for pulse width less than 15ns.

2. V V

IN should not exceed VCC +0.5V.

3. Not more than one output should be shorted at a time. Duration of the short should not exceed 30 seconds.

2889 tbl 05

AC TEST CONDITIONS—R3081

Symbol Parameter Min. Max. Unit

IH Input HIGH Voltage 3.0 — V

V V

IL Input LOW Voltage — 0 V IHS Input HIGH Voltage 3.5 — V

ILS Input LOW Voltage — 0 V

AC TEST CONDITIONS—RV3081

Symbol Parameter Min. Max. Unit

IH Input HIGH Voltage 3.0 — V IL Input LOW Voltage — 0 V

IHS Input HIGH Voltage 3.0 — V

V V

ILS Input LOW Voltage — 0 V

OUTPUT LOADING FOR AC TESTING

+4mA

2889 tbl 06

RECOMMENDED OPERATING TEMPERATURE AND SUPPLY VOLTAGE

Grade Temperature(Case) GND VCC

Military –55°C to +125°C 0V 5.0 ±10%

Commercial 0°C to +85°C 0V 5.0 ±5%

Commercial 0°C to +85°C 0V 3.3 ±5%

REF

+1.5V

–

–4mA

Signal CLD

2889 tbl 07

SysClk

50 pf

All Others 25 pf

2889 tbl 08

5.5 11

To Device Under Test

2889 drw 08

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

DC ELECTRICAL CHARACTERISTICS RV3081

(1, 2)

COMMERCIAL TEMPERATURE RANGE

Symbol Parameter Test Conditions Min. Max. Min. Max. Units

VOH Output HIGH Voltage VCC = Min., IOH = –4mA 2.4 — 2.4 — V

VOL Output LOW Voltage VCC = Min., IOL = 4mA — 0.4 — 0.4 V

VIH Input HIGH Voltage

VIL Input LOW Voltage

VIHS Input HIGH Voltage VILS Input LOW Voltage

CIN Input Capacitance

COUT Output Capacitance

ICC Operating Current VCC = 3.3V, TA = 25°C — 375 — 425 mA

IIH Input HIGH Leakage VIH = VCC — 100 — 100 µA IIL Input LOW Leakage VIL = GND –100 — –100 — µA

IOZ Output Tri-state Leakage VOH = 2.4V, VOL = 0.5V –100 100 –100 100 µA

(3)

(1)

(2,3)

(1,2)

(4,5)

— 2.0 — 2.0 — V — — 0.8 — 0.8 V — 2.8 — 2.8 — V — — 0.4 — 0.4 V — — 10 — 10 pF — — 10 — 10 pF

— (TC = 0°C to +85°C, VCC = +3.3V ±5%)

20MHz 25MHz

NOTES:

1. V

IL Min. = –3.0V for pulse width less than 15ns. VIL should not fall below -0.5V for larger periods. IHS and VILS apply to CIkIn and

2. V

IH should not be held above VCC + 0.5V.

3. V

4. Guaranteed by design.

5. ALE is 12pF for SysClk values C

Reset

and C

for all speeds.

OUT

AC ELECTRICAL CHARACTERISTICS RV3081 COMMERCIAL TEMPERATURE RANGE

Symbol Signals Description Min. Max. Min. Max. Unit

BusReq, Ack, BusError RdCEn

CohReq

t1a A/D Set-up to

BusReq, Ack, BusError RdCEn

CohReq

t2a A/D Hold from

t3 A/D, Addr, Diag, ALE,

Burst/WrNear, Rd, DataEn

t4 A/D, Addr, Diag, ALE,

Burst/WrNear, Rd, DataEn

BusGnt

Wr, Rd, Burst/WrNear

t8 ALE Asserted from

t9 ALE Negated from t10 A/D Hold from ALE negated t11

DataEn

t12

DataEn

t14 A/D Driven from t15

Wr, Rd, DataEn, Burst/WrNear

t16 Addr(3:2) Valid from t17 Diag Valid from

, Set-up to

, Hold from

, A/D Valid from

Tri-state from

Driven from

Asserted from Negated from

Asserted from Asserted from A/D tri-state

Negated from

(1, 2)

— (TC = 0°C to +85°C, VCC = +3.3V ±5%)

20MHz 25MHz

SysClk

rising 6 — 5 — ns

SysClk

falling 7 — 6 — ns

SysClk

rising 4 — 4 — ns

SysClk

falling 2 — 2 — ns

SysClk

rising — 10 — 10 ns

SysClk

falling — 10 — 10 ns

SysClk

rising — 8 — 7 ns

SysClk

falling — 8 — 7 ns

SysClk

rising — 5 — 5 ns

SysClk

rising — 4 — 4 ns

SysClk

falling — 4 — 4 ns

SysClk

SysClk SysClk SysClk

(3)

falling — 15 — 15 ns

(3)

rising

falling — 7 — 6 ns

2— 2— ns

0— 0— ns 0— 0— ns

—6 —6 ns — 12 — 11 ns

2889 tbl 09

5.5 12

IDT79R3081 RISController MILITARY AND COMMERCIAL TEMPERATURE RANGES

AC ELECTRICAL CHARACTERISTICS

COMMERCIAL TEMPERATURE RANGE

RV3081 (cont.)

(1, 2)

— (TC = 0°C to +85°C, VCC = +3.3V ±5%)

20MHz 25MHz

Symbol Signals Description Min. Max. Min. Max. Unit

t18 A/D Tri-state from t19 A/D t20 ClkIn (2x clock mode) Pulse Width HIGH 10 — 8 — ns t21 ClkIn (2x clock mode) Pulse Width LOW 10 — 8 — ns t22 ClkIn (2x clock mode) Clock Period 25 250 20 250 ns t23

Reset

t24

Reset

t25

Reset

t26

Int

t27

Int

t28

SInt

, SBrCond Set-up to

t29

SInt

, SBrCond Hold from

t30

Int

, BrCond Set-up to

t31

Int

, BrCond Hold from

tsys

tsys/2

tderate All outputs Timing deration for loading — 1 — 1 ns/

NOTES:

1. All timings referenced to 1.5V. All timings measured with respect to a 2.5ns rise and fall time.

2. The AC values listed here reference timing diagrams contained in the

3. Guaranteed by design.

4. This parameter is used to derate the AC timings according to the loading of the system. This parameter provides a deration for loads over the specified test condition; that is, the deration factor is applied for each 25pF over the specified test load condition.

5. In 1x clock mode, t22 is replaced by t44/2.

6. In 1x clock mode, the design guarantees that the input clock rise and fall times can be as long as 5ns.

SysClk

(full frequency mode) Pulse Width

t32

SysClk

(full frequency mode) Clock High Time

t33

SysClk

(full frequency mode) Clock LOW Time

SysClk

(half frequency mode) Pulse Width

t34

SysClk

(half frequency mode) Clock HIGH Time

t35

SysClk

(half frequency mode) Clock LOW Time t36 ALESet-up to t37 ALEHold from t38 A/DSet-up to ALE falling 10 — 9 — ns t39 A/DHold from ALE falling 2 — 2 — ns t40

Set-up to

t41

Hold from t42 ClkIn (1x clock mode) Pulse Width HIGH t43 ClkIn (1x clock mode) Pulse Width LOW t44 ClkIn (1x clock mode) Clock Period

SysClk

falling 9 — 8 — ns

SysClk

falling 2 — 2 — ns

SysClk

rising 10 — 9 — ns

SysClk

rising 3 — 3 — ns

SysClk

Pulse Width from Vcc valid 200 — 200 — µs Minimum Pulse Width 32 — 32 — tsys Set-up to Mode set-up to Mode hold from

over C

SysClk

falling — 10 — 10 ns

falling to data valid — 13 — 12 ns

SysClk

falling 6 — 5 — ns

Reset

rising 10 — 9 — ns

Reset

rising 0 — 0 — ns

SysClk

falling 6 — 5 — ns

SysClk

falling 3 — 3 — ns

SysClk

falling 6 — 5 — ns

SysClk

falling 3 — 3 — ns

(5)

4*t22 4*t22 4*t22 4*t22 4*t22 ns

(5)

(6)

(3, 4)

R3081 Family Hardware User's Manual

2*t22 2*t22 2*t22 2*t22 ns t22-2 t22+2 t22-2 t22+2 ns

t22-2 t22+2 t22-2 t22+2 ns

2*t22-2 2*t22+2 2*t22-2 2*t22+2 ns 2*t22-2 2*t22+2 2*t22-2 2*t22+2 ns

20 — 16 — ns 20 — 16 — ns 50 50 40 50 ns

25pF

2889 tbl 11

5.5 13

+ 28 hidden pages
