Integrated Circuit Systems

Video Clock Synthesizer

ICS1526

General Description

The ICS1526 is a low-cost, high-performance
frequency generator. It is suited to general purpose
phase controlled clock synthesis as well as
line-locked and genlocked high-resolution video
applications. Using ICS’s advanced low-voltage
CMOS mixed-mode technology, the ICS1526 is an
effective clock synthesizer that supports video
projectors and displays at resolutions from VGA to
beyond XGA.

The ICS1526 offers single-ended clock outputs to 110
MHz. The HSYNC_out, and VSYNC_out pins provide
the regenerated versions of the HSYNC and VSYNC
inputs synchronous to the CLK output.

The advanced PLL uses its internal programmable
feedback divider. The device is programmed by a
standard I
a TSSOP16 package.

2

C-bus™ serial interface and is available in

ICS1526 Functional Diagram

OSC

HSYNC

VSYNC

2

I

ICS1526

C

HSYNC_out

VSYNC_out

CLK

LOCK

Features

• Lead-free packaging (Pb-free)

• Low jitter (typical 27 ps short term jitter)

• Wide input frequency range

• 8 kHz to 100 MHz

• LVCMOS single-ended clock outputs

• Up to 110 MHz

• Uses 3.3 V power supply

• 5 Volt tolerant Inputs (HSYNC, VSYNC)

• Coast (ignore HSYNC) capability via VSYNC pin

• Industry standard I

• PLL Lock detection via I

• 16-pin TSSOP package

2

C-bus programming interface

2

C or LOCK output pin

Applications

• Frequency synthesis

• LCD monitors, video projectors and plasma displays

• Genlocking multiple video subsystems

Pin Configuration (16-pin TSSOP)

VSSD

SDA

SCL
VSYNC
HSYNC

VDDA
VSSA

OSC

1
2
3
4
5
6
7

16
15
14
13
12
11
10

8 9

VDDD
VSSQ
VSYNC_out
VDDQ
CLK
HSYNC_out
LOCK
I2CADR

MDS 1526 K Revision 110905

ICS reserves the right to make changes in the preliminary device data
identified in this publication without notice. ICS advises its customers
to obtain the latest version of all device data to verify that information

being relied upon is current and accurate.

Section 1 OverviewICS1526 Data Sheet

Section 1 Overview

The ICS1526 is a user-programmable,
high-performance general purpose clock generator. It
is intended for graphics system line-locked and
genlocked applications and provides the clock signals
required by high-performance analog-to-digital
converters.

Figure 1-1 Simplified Block Diagram

OSC

HSYNC

VSYNC

Divider

3..129

PFD

The ICS1526 has the ability to operate in line-locked
mode with the HSYNC input.

1.1 Phase-Locked Loop

The phase-locked loop has a very wide input frequency
range (8 kHz to 100 MHz). Not only is the ICS1526 an
excellent, general purpose clock synthesizer, but it is
also capable of line-locked operation. Refer to the
block diagram below.

CP VCO

FD

12..4103

VCOD

2,4,8,16

Flip-flop

Flip-flop

CLK

HSYNC_out

VSYNC_out

Note: Polarity controls and other circuit elements are not shown in above diagram for simplicity

The heart of the ICS1526 is a voltage controlled
oscillator (VCO). The VCOs speed is controlled by the
voltage on the loop filter. This voltage will be described

The input HSYNC and VSYNC can be conditioned by a
high-performance Schmitt-trigger by sharpening the
rising/falling edge.

later in this section.

The HSYNC_out and VSYNC_out signals are aligned

The VCOs clock output is first passed through the VCO

with the output clock (CLK) via a set of flip flops.
Divider (VCOD). The VCOD allows the VCO to operate
at higher speeds than the required output clock.

NOTE: Under normal, locked operation the VCOD has
no effect on the speed of the output clocks, just the
VCO frequency.

The output of the VCOD is the full speed output
frequency seen on the CLK. This clock is then sent

1.2 Output Drivers and Logic Inputs

The ICS1526 uses low-voltage TTL (LVTTL) inputs and

LVCMOS outputs, operating at the 3.3 V supply

voltage. The LVTTL inputs are 5 V tolerant.

The LVCMOS drive resistive terminations or

transmission lines.
through the 12-bit internal Feedback Divider (FD). The
feedback divider controls how many clocks are seen
during every cycle of the input reference.

1.3 Automatic Power-On Reset Detection

The ICS1526 has automatic power-on reset detection
The Phase Frequency Detector (PFD) then compares

the feedback to the input and controls the filter voltage
by enabling and disabling the charge pump. The

(POR) circuitry and it resets itself if the supply voltage

drops below threshold values. No external connection

to a reset signal is required.
charge pump has programmable current drive and will

source and sink current as appropriate to keep the
input and the clock output aligned.

MDS 1526 K 2 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

1.4 I2C Bus Serial Interface

The ICS1526 uses a 5 volt tolerant, industry-standard

2

C-bus serial interface that runs at either low speed

I
(100 kHz) or high speed (400 kHz). The interface uses
12 word addresses for control and status: one
write-only, eight read/write, and three read-only
addresses.

Section 1 OverviewICS1526 Data Sheet

Two ICS1526 devices can sit on the same I

2

C bus,
each selected by the Master according to the state of
the I2CADR pin. The 7-bit device address is 0100110
(binary) when I2CADR is low. The device address is
0100111 (binary) when I2CADR is high. See Section 4,

“Programming”

MDS1526 K 3 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 2 Pin DescriptionsICS1526 Data Sheet

Section 2 Pin Descriptions

Table 2-1 ICS1526 Pin Descriptions

PIN NO. PIN NAME TYPE DESCRIPTION COMMENTS Notes

1 VSSD

2SDA

3SCL

4 VSYNC

5HSYNC

6VDDA

7 VSSA

8OSC

9I2CADR

10 LOCK

11 HSYNC_out

12 CLK

13 VDDQ

14 VSYNC_out

15 VSSQ

16 VDDD

POWER Digital ground

IN/OUT Serial data I2C-bus 1

IN Serial clock I2C-bus 1

IN Vertical sync 1 & 2

IN Horizontal sync Clock input to PLL 1 & 2

POWER Analog supply Power for analog circuitry

POWER Analog ground Ground for analog circuitry

IN Oscillator Input from crystal oscillator package 1 & 2

IN I2C device address Chip I2C address select

LVCMOS

Lock PLL Lock detect

OUT

LVCMOS

OUT

LVCMOS

HSYNC output Schmitt-trigger filtered HSYNC

realigned with the output pixel clock

Pixel clock output LVCMOS driver for full speed clock

OUT

POWER Output driver supply Power for output drivers

LVCMOS

OUT

VSYNC output Schmitt-trigger filtered VSYNC

realigned with the output pixel clock

POWER Output driver ground Ground for output drivers

POWER Digital supply Power for digital sections

Notes: 1. These LVTTL inputs are 5 V tolerant.

2. Connect to ground if unused.

MDS 1526 K 4 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 3 Register map summary

Section 3 Register map summaryICS1526 Data Sheet

Word
Address Name Access Bit Name Bit #

00h Input

Control

01h Loop

Control

R / W CPen 0 1 Charge Pump Enable

VSYNC_Pol 1 0 VSYNC Polarity (Charge Pump Enable)

HSYNC_Pol 2 0 HSYNC Polarity

Reserved 3 0 Reserved

Reserved 4 0 Part requires a 0 for correct operation

Reserved 5 0 Reserved

EnPLS 6 1 Enable PLL Lock Output

Reserved 7 0 Reserved

R / W ICP0-2 0-2 ICP (Charge Pump Current)

*

Reserved 3 Reserved

VCOD0-1 4-5 VCO Divider

Reserved 6-7 Reserved

Reset
Value Description

0=External Enable via VSYNC, 1=Always Enabled

Requires 00h:0=0
0=Coast (charge pump disabled) while VSYNC low,
1=Coast (charge pump disabled) while VSYNC high

0=Rising Edge, 1=Falling Edge

0=Disable, 1=Enable

Bit 2,1,0 = {000 =1 µA, 001 = 2 µA, 010 = 4 µA... 110 = 64 µA, 111 =
128 µA}. Increasing the PF Detector Gain makes the loop respond
faster, raising the loop bandwidth. The typical value when using the
internal loop filter is 011.

Bit 5,4 = {00 = ÷2, 01=÷4, 10=÷8, 11=÷16}

02h FdBk Div

03h FdBk Div

04h Reserved Reserved 0-7 0 Reserved

05h Schmitt-

06h Output

*

0

*

1

trigger

Enables

R / W FBD0-7 0-7 Feedback Divider LSBs (bits 0-7)

R / W FBD8-11 0-3 Feedback Divider MSBs (bits 8-11)

Divider setting = 12-bit word + 8
Minimum 12 = 000000000100
Maximum 4103 =111111111111

Reserved 4-7 Reserved

R / W Schmitt

*

R / W Reserved 0 0 Reserved

control

Metal_Rev 1-7 0 Metal Mask Revision Number

OE 1 0 Output Enable for CLK, HSYNC_out, VSYNC_out

Reserved 2-7 0 Reserved

0 1 Schmitt-trigger control

0=Schmitt-trigger, 1=No Schmitt-trigger

0=High Impedance (disabled), 1=Enabled

MDS1526 K 5 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 3 Register map summaryICS1526 Data Sheet

Word
Address Name Access Bit Name Bit #

07h Osc_Div R / W Osc_Div 0-6 0-6 0 Osc Divider modulus

In-Sel 7 0 Input Select

08h Reset Write PLL 0-7 x Writing 5Ah resets PLL and commits values written to word

09-0Fh Reserved Read Reserved 0-7 Reserved

10h Chip Ver Read Reserved 0-7 Reserved

11h Chip Rev Read Chip Rev 0-7 01 Reserved

12h Rd_Reg Read Reserved 0 N/A Reserved

PLL_Lock 1 N/A PLL Lock Status

Reserved 2-7 0 Reserved

Reset
Value Description

Minimum 3 =0000001 binary, Maximum 129 = 1111111 binary
Divider setting = 7-bit word + 2

0=HSYNC Input, 1=OSC Input
OSC input clock must be present to select OSC input

addresses 01h-03h and 05h

0=Unlocked, 1=Locked

*. Written values to these registers do not take effect immediately, but require a commit via register 08h

MDS 1526 K 6 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 4 Programming

4.1 Industry-Standard I2C Serial Bus: Data Format

Figure 4-1 ICS1526 Data Format for I2C 2-Wire Serial Bus

Single/multiple register write (page write)

Single/multiple register read

Sequential single/multiple register read

Device address

0 1 0 0 1 1 B

S
T
A
R
T

Device address

0 1 0 0 1 1 B 0 1 0 0 1 1 B

S
T
A
R
T

Device address

0 1 0 0 1 1 B

S
T
A
R
T

Word address Data (0)

0

A
C
K

Word address Data (0)

0

A
C
K

1

Data (0)
A
C
K

A
C
K

Device address

A

S

C

T

K

A
R
T

...

A
C
K

Data (n)

Section 4 ProgrammingICS1526 Data Sheet

...

A
C
K

1

A
C
K

Da ta (n )

S

N

T

O

O

A

P

C
K

A

S

C

T

K

O
P

...

A
C
K

Da ta (n )

S

N

T

O

O

A

P

C
K

Master d riv es line Sla ve drives line

Notes:
The ICS1526 uses 16-byte pages (00h-0Fh is the first page, 10h-1Fh is the second page). Writing or reading

beyond the end of page yields undefined results.

The ICS1526 has a device address of 010011B, where B is the state of the I2CADR pin.

MDS1526 K 7 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 5 AC/DC Operating ConditionsICS1526 Data Sheet

Section 5 AC/DC Operating Conditions

5.1 Absolute Maximum Ratings

Table 5-1 lists absolute maximum ratings for the ICS1526. Stresses above these ratings can cause permanent

damage to the device. These ratings, which are standard values for ICS commercially rated parts, are stress rat­ings only. Functional operation of the ICS1526 at these or any other conditions above those indicated in the opera­tional sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended
periods can affect product reliability. Electrical parameters are guaranteed only over the recommended operating

temperature range.

Table 5-1 ICS1526 Absolute Maximum Ratings

Item Rating

VDD, VDDA, VDDQ (measured to VSS)

*

Digital Inputs VSS –0.3 V to 5.5 V

Analog Inputs VSS -0.3 V to 6.0 V

Analog Outputs VSSA –0.3 V to VDDA +0.3 V

Digital Outputs VSSQ –0.3 V to VDDQ +0.3 V

Storage Temperature –65°C to +150°C

4.3 V

Junction Temperature 125°C

Soldering Temperature 260°C

ESD Susceptibility* > 2 KV

**

*. Measured with respect to VSS. During normal operations, the VDD supply voltage for the ICS1526 must

remain within the recommended operating conditions.

**. Electrostatic-sensitive devices. Do not open or handle except in a static-free workstation.

Table 5-2 Environmental Conditions

Parameter Min. Typ. Max. Units

Ambient Operating Temperature 0 – +70 ° C

Power Supply Voltage +3.0 +3.3 +3.6 V

Table 5-3 DC Characteristics

Parameter Symbol Conditions Min. Max. Units

Digital Supply Current IDDD VDDD = 3.6 V - 25 mA

Output Driver Supply Current IDDQ VDDD = 3.6 V

No drivers enabled

Analog Supply Current IDDA VDDA = 3.6 V - 5 mA

Power consumption 300 mW

Power-On-Reset (POR)

VSS 1.8 V

Threshold

-6mA

MDS 1526 K 8 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 5 AC/DC Operating ConditionsICS1526 Data Sheet

Table 5-4 AC Characteristics

Parameter Symbol Min. Typical Max. Units Notes

General

VCO Frequency f

VCO

VCO Gain K 165 MHz/V

40 400 MHz

AC Inputs

OSC Input Frequency f

OSC

0.02 100 MHz

Analog Input (HSYNC/VSYNC)

HSYNC Input Frequency f

VSYNC Input Frequency f

Input High Voltage V

Input Low Voltage V

HSYNC

VSYNC

IH

IL

Input Hysteresis 0.2 0.8 V Schmitt trigger active

8 10,000 kHz

30 120 Hz

1.7 5.5 V

VSS - 0.3 1.1 V

SDA, SCL, OSC Digital Inputs

Input High Voltage V

Input Low Voltage V

IH

IL

25.5V

VSS - 0.3 0.8 V

I2CADDR Digital Input

Input High Voltage V

Input Low Voltage V

IH

IL

2 VDD+0.3 V

VSS - 0.3 0.8 V

SDA Digital Output

SDA Output Low Voltage V

SDA Output High Voltage V

OL

OH

0.4 V IOUT = 3 mA

6.0 V Determined by
external Rset resistor

LVCMOS Outputs (CLK, HSYNC_out, VSYNC_out, LOCK)

Output Frequency F

Duty Cycle S

s

DC

Jitter, STJ, RMS STJ 0.027 ns 30 kHz input to 50

Jitter, STJ, pk-pk STJ 0.200 ns

Jitter, Input-Output IOJ 2.500 ns HSYNC in to CLK out

HSYNC to HSYNC_out
propagation delay (without
Schmitt trigger)

HSYNC to HSYNC_out
propagation delay (with
Schmitt-trigger)

CLK to HSYNC_out/
VSYNC_out skew

Clock/ HSYNC_out/

T

CR

VSYNC_out
Transition Time - Rise

MDS1526 K 9 Revision 110905

2.5 110 MHz VDDD = 3.3 V

45 50 55 % 2

MHz output

29ns 1

610ns 1

1.0 ns

1.0 1.5 ns 2

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 5 AC/DC Operating ConditionsICS1526 Data Sheet

Parameter Symbol Min. Typical Max. Units Notes

Clock/ HSYNC_out/
VSYNC_out
Transition Time - Fall

LOCK Transition Time - Rise T

LOCK Transition Time - Fall T

Note 1—Measured between chosen edge of HSYNC (00h:2) and rising edge of output

Note 2—Measured at 110 MHz, 3.3 VDC, 25

T

CF

LR

LF

o

C, 15 pF, unterminated

1.0 1.5 ns 2

3.0 ns 2

2.0 ns 2

MDS 1526 K 10 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com

Section 6 Package Outline and Package DimensionsICS1526 Data Sheet

Section 6 Package Outline and Package Dimensions

16-pin TSSOP 4.40 mm body, 0.65 mm pitch

Package dimensions are kept current with JEDEC Publication No. 95

INDEX
AREA

A2

16

Symbol Min Max Min Max

Millimeters Inches

A--1.20--0.047

A1 0.05 0.15 0.002 0.006

E1

E

A2 0.80 1.05 0.032 0.041

b 0.19 0.30 0.007 0.012
C 0.09 0.20 0.0035 0.008
D 4.90 5.1 0.193 0.201

1 2

E 6.40 BASIC 0.252 BASIC

E1 4.30 4.50 0.169 0.177

D

e 0.65 Basic 0.0256 Basic
L 0.45 0.75 0.018 0.030
α 0° 8° 0° 8°

aaa -- 0.10 -- 0.004

A

A1

- C -

e

b

SEATING

PLANE

L

c

aaa C

Section 7 Ordering Information

Part / Order Number Marking Shipping Packaging Package Temperature

ICS1526GLF 1526GLF Tubes 16-pin TSSOP 0 to +70° C

ICS1526GLFTR 1526GLF Tape & Reel 16-pin TSSOP 0 to +70° C

“LF” denotes Pb (lead) free package.
While the information presented herein has been checked for both accuracy and reliability, Integrated Circuit Systems (ICS)

assumes no responsibility for either its use or for the infringement of any patents or other rights of third parties, which would
result from its use. No other circuits, patents, or licenses are implied. This product is intended for use in normal commercial
applications. Any other applications such as those requiring extended temperature range, high reliability, or other extraordinary
environmental requirements are not recommended without additional processing by ICS. ICS reserves the right to change any
circuitry or specifications without notice. ICS does not authorize or warrant any ICS product for use in life support devices or
critical medical instruments.

MDS1526 K 11 Revision 110905

Integrated Circuit Systems, 525 Race Street, San Jose, CA 95126, tel [phone] www.icst.com
