IDS IDS1600, IDS1200 User Manual
I
N
H
E
P
D
I
G
I
T
A
L
S
E
C
U
R
I
T
Y
IDS
Users Guide to Keypad
Functions
MANUAL NO. 700-146-01D ISSUED NOVEMBER 2002 VERSION 2.17
2 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
Summary of Operation
mrasid/mrA
]#[ + ]EDOCRESU[
mrAyawAkciuQ
nwoddloH
]1[
dnoces1rof
mrAyatSkciuQ
nwoddloH
]5[
dnoces1rof
oG&mrAyatSkciuQ
nwoddloH
]6[
dnoces1rof
lenaPybrewsnAdecroF
]8[
demrasidebtsummetsyS-
cinaP
nwoddloH
]P[
dnoces1rof
eriF
nwoddloH
]F[
dnoces1rof
ycnegremElacideM
nwoddloH
]M[
dnoces1rof
yromeMmralA
nwoddloH
]0[
dnoces1rof
snoititraPegnahC
nwoddloH
]EDOM[
+dnoces1rof
NOITITRAP[
]REBMUN + [ ]
enozassapyB
nwoddloH
]9[
+dnoces1rof [
]
REBMUNENOZ
+ [ ] + ]#[
enozemihcmargorP
nwoddloH
]2[
+dnoces1rof [
]
REBMUNENOZ
+ [ ] + ]#[
enozyatsmargorP
nwoddloH
]3[
+dnoces1rof [
]
REBMUNENOZ
+ [ ] + ]#[
enozzzubmargorP
nwoddloH
]4[
+dnoces1rof [
]
REBMUNENOZ
+ [ ] + ]#[
sutatSelbuorTweiV
nwoddloH
]7[ +dnoces1rof ]#[
sseruD
]#[ + ]EDOCSSERUD[
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 3
IDS1600 USER MANUAL
Contents
Glossary ..........................................................................5
1. Introduction to the IDS1600......................................................6
1.1 Notes...........................................................................................6
2. Understanding the LED Keypad Indicators ............................7
2.1 Notes on the LCD Keypad...........................................................8
3. Operation of the LED Keypad..................................................8
4. System Information ..................................................................9
4.1 Programmed Functions ...............................................................9
4.2 User Codes ...............................................................................10
4.3 Zone Information ........................................................................12
5. Arming the System .................................................................13
5.1 Away Arming Procedure ............................................................13
5.2 Quick A way Arming ...................................................................14
5.3 Stay Arming...............................................................................14
5.4 Quick Stay Arming ....................................................................15
5.5 S tay Arm and Go .......................................................................15
5.6 Arming a Partition from a Master Keypad..................................16
5.7 Arming from a Key-Switch or Remote Control...........................17
5.8 Auto-Arming ..............................................................................17
5.9 Arming with Entry/ Exit or Follower Zones Violated...................17
5.10 Forced Arming ...........................................................................17
6. Zone Bypassing .......................................................................18
6.1 To Bypass a Zone......................................................................1 8
6.2 To Un-Bypass a Zone ................................................................2 0
7. Disarming the System ............................................................21
7.1 Disarming with a User Code......................................................2 1
7.2 Disarming a Partition from a Master Keypad.............................22
7.3 To Disarm with a Key-Switch or Remote Control.......................23
8. Emergency Situations ............................................................23
8.1 Fire Alarm..................................................................................23
8.2 Panic Alarm...............................................................................24
8.3 Medical Alarm............................................................................24
8.4 Duress Code .............................................................................24
4 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
9.0 Emergency Evacuation Plan .................................................25
10. System Memory ......................................................................25
10.1 Alarm Memory:..........................................................................25
1 1. User Codes...............................................................................26
1 1. 1 Entering New /Changing Existing User Codes. .........................26
1 1. 2 Deleting User Codes - LED Keypad ..........................................28
12. Stay Zones ...............................................................................28
12.1 T o Program S tay Zones .............................................................28
12.2 T o Cancel the S tay Zones..........................................................30
13. Buzz Zones ..............................................................................32
13.1 T o Program Buzz Zones............................................................3 2
13.2 T o Cancel Buzz Zones ..............................................................34
14. Chime Zones............................................................................36
14.1 T o Program the Chime Zones ....................................................36
14.2 T o Cancel the Chime Zones.......................................................38
15. LCD Keypad Menu Navigation ..............................................39
15.1 Main Menu ................................................................................39
15.2 View Menu ................................................................................41
15.3 Quick Arm .................................................................................4 1
15.4 Program Zones/ Zone Menu ......................................................41
15.5 Assign User Codes ...................................................................43
15.6 Set Date and Time ....................................................................43
15.7 Stay Arm ...................................................................................43
15.8 Stay Arm and Go.......................................................................4 3
15.9 Reset Fire Sensor .....................................................................43
15.10 Answer Phone ..........................................................................43
16. Trouble-Shooting ....................................................................44
16.1 Trouble Conditions.....................................................................44
16.2 Problems When Arming the System .........................................44
16.3 Problems when disarming the system ......................................45
16.4 For Service ................................................................................45
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 5
IDS1600 USER MANUAL
Glossary
Alarm This is the history of the most recent violations that
Memory occurred the last time the system was armed.
Arm To set the system into the ARMED mode. In this mode,
violating a zone will activate an alarm condition. If the
system is programmed accordingly, will cause a reporting
code to be sent to the monitoring company.
Bypass To deactivate a zone. When the panel is ARMED,
violation of a bypassed zone will be ignored.
Disarm To deactivate the system. Fire, medical and panic
functions remain active while the system is disarmed.
Entry/ Exit A zone with a programmable time delay, which allows the
Zone user to exit the premises after arming the system and
time to reach the keypad after entering the armed
premises. This zone is generally the last exit point of the
building and the first entry point i.e. the front door of a
home.
Follower A zone that may be temporarily violated either during the
Zone exit delay period or after violation of an entry/ exit zone.
This allows the user access to disarm the system. A
Follower zone will behave as per an Instant zone if
violated prior to the violation of an entry/ exit zone.
Instant When the system is armed, violation of an instant zone
Zone will immediately cause an alarm condition to be
registered.
Stay Arm Arming that allows for certain preprogrammed, STAY
zonesto be violated while the system is armed.
Stay Arm Arming that allows the user to STAY ARM and leave the
and Go premises.
Stay Zone Zones which are bypassed automatically when the
system is STAY ARMED.
Zone A specific area of your premises guarded by sensors
which detect violations of that area.
6 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
1. Introduction to the IDS1600
The IDS1600 Control Panel is manufactured to the highest specification and will provide many years of service if correctly installed and
maintained. The unit is designed for simple operation yet provides the
maximum protection for you, your family or business. For trouble free
operation please follow the instructions contained in this User Manual.
Your security system consists of a control panel, one or more keypads and various sensors and detectors. An enclosure will contain the
control panel which includes the system electronics, fuses and standby battery . There is normally no reason for anyone other than the
installer or service professional to have access to the control panel.
1.1 Notes
Read the entire manual carefully and keep it in an accessible
place.
Your security system should be installed and serviced by a
qualified security professional who should instruct you regarding
the level of protection provided and the operation of the system.
Should you have any questions regarding the operation of the
system, contact your security company representative.
Your system should be tested on a regular basis. Before testing
the system please notify your security company of your intention
to do so.
NEVER disconnect the mains power as the back-up battery will
eventually discharge thereby causing the control panel to
shutdown.
A security system cannot prevent emergencies. It is only
intended to alert you and - if included - your central station of an
emergency situation.
Smoke and heat detectors may not detect all fire situations.
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 7
IDS1600 USER MANUAL
2. Understanding the LED Keypad Indicators
Refer to illustration on inside front cover of manual.
1. ARMED Indicator (Red)
detanimullIdemrAnoititraP
dehsiugnitxEdemrasiDnoititraP
gnihsalF
yromeMronoitidnoCmralA
t
ixE/yrtnE,
yaleD
2. AWAY Indicator (Red)
detanimullIedoMyawAnidemrAmetsyS
dehsiugnitxEedoMyatS/demrasiDmetsyS
3. TROUBLE Indicator (Red)
detanimullInoitidnoCelbuorT
dehsiugnitxEmetsysronoititraphtiwsmelborpoN
4. READY Indicator (Green)
detanimullIdemraebotydaersinoititraP
5. ZONE Indicators (Y ellow)
detanimullIdessapybenoZ
dehsiugnitxEraelcenoZ
gnihsalFdetaloivenoZ
8 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
2.1 Notes on the LCD Keypad
Refer to illustration on inside back cover of the manual.
0 1 / 0 1 / 9 9 0 : 0 4
RE A D Y MO N
MRA ELBUORT
The illustration above shows what text is shown on the LCD
display as well as the status of the ARM and TROUBLE
indicators. Below is a key showing the three possible states of
the indicators and the symbols used to represent them.
detanimull
I
dehsiugnitx
E
gnihsal
F
Where procedures followed for programming functions are the
same for the two keypads, illustrations showing the LCD display
and indicator status will accompany the text directions for the
LED keypad.
Where procedures vary between the keypads, the directions and
illustrations for the LCD keypad procedure will follow those of the
LED keypad. For easy distinction of instructions, the instructions
for the LCD keypad are shaded in grey .
NOTE:
There is a section at the end of the manual dedicated to explaining the
navigation of the LCD keypad menu.
3. Operation of the LED Keypad
To ensure correct operation of your security system it is essential to
familiarize yourself with the use of the keypad.
The keypad has a buzzer , command entry keys and zone and
system status L.E.D.’s.
The keypad is used to send commands to the system and to
display the current system status.
The keypad(s) will be mounted in a convenient location within
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 9
IDS1600 USER MANUAL
the protected premises generally close to the entry/exit zones.
A sensor which has registered an alarm condition will be
indicated on the keypad by the corresponding zone light flashing.
The keypad buzzer will sound under the following conditions.
When any key is pressed during the entry of codes.
Three times if one or more of the zones are violated when
attempting to arm the system.
To indicate a trouble condition.
During the entry/exit delay.
Will sound for 2 seconds when a chime zone is violated.
4. System Information
4.1 Programmed Functions
Check with your installer which of the following functions have been
enabled.
Partitionate - up to 8 partitions per system
Quick Away Arm
Quick Stay Arm
Arm with Entry/Exit or Follower Zones Violated
Stay Arm
Stay Arm and Go
Siren Sound on Arm/Disarm (double toot - arm/ short toot - disarm)
Panic Alarm
Fire Alarm
Medical Alarm
Chime Zones
Buzz Zones
Zone T amper Monitoring
Remote Arm and Disarm
10 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
4.2 User Codes
res
U
.o
N
edoCresU emaNresU
snoititraP
1 2 3 4 5 6 7 8
10
4321edoCretsaMtluafeD XXXXXXXX
10
edoCretsaMweN
20
30
40
50
60
70
80
90
01
11
21
31
41
51
61
71
81
91
02
12
22
32
42
52
62
72
82
92
03
13
23
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 11
IDS1600 USER MANUAL
res
U
.o
N
edoCresU emaNresU
snoititraP
1 2 3 4 5 6 7 8
33
43
53
63
73
83
93
04
14
24
34
44
54
64
74
84
94
05
15
25
35
45
55
65
75
85
95
06
16
26
36
46
12 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
4.3 Zone Information
enoZ epyTenoZ tixE/yrtnE.g.e emaNenoZ roodnehctiK.g.e
rebmuNnoititraP
1 2 3 4 5 6 7 8
1
2
3
4
5
6
7
8
9
01
11
21
31
41
51
61
siyaledyrtnEyramirP1noititraPehT.sdnoces
siyaledyrtnEyradnoceS1noititraPehTsdnoces
siyaleDtixE1noititraPehT.sdnoces
siyaledyrtnEyramirP2noititraPehT.sdnoces
siyaledyrtnEyradnoceS2noititraPehTsdnoces
siyaleDtixE2noititraPehT.sdnoces
siyaledyrtnEyramirP3noititraPehT.sdnoces
siyaledyrtnEyradnoceS3noititraPehTsdnoces
siyaleDtixE3noititraPehT.sdnoces
siyaledyrtnEyramirP4noititraPehT.sdnoces
siyaledyrtnEyradnoceS4noititraPehTsdnoces
siyaleDtixE4noititraPehT.sdnoces
siyaledyrtnEyramirP5noititraPehT.sdnoces
siyaledyrtnEyradnoceS5noititraPehTsdnoces
siyaleDtixE5noititraPehT.sdnoces
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 13
IDS1600 USER MANUAL
siyaledyrtnEyramirP6noititraPehT.sdnoces
siyaledyrtnEyradnoceS6noititraPehTsdnoces
siyaleDtixE6noititraPehT.sdnoces
siyaledyrtnEyramirP7noititraPehT.sdnoces
siyaledyrtnEyradnoceS7noititraPehTsdnoces
siyaleDtixE7noititraPehT.sdnoces
siyaledyrtnEyramirP8noititraPehT.sdnoces
siyaledyrtnEyradnoceS8noititraPehTsdnoces
siyaleDtixE8noititraPehT.sdnoces
5. Arming the System
There are various options for arming the system
5.1 Away Arming Procedure
[#] + [USER CODE]
(Leave via Entry Exit Zone)
1. Ensure that the READY indicator is illuminated; if not, check
that all protected doors and windows are closed and that motion
has ceased in areas covered by motion detectors.
0 1 / 0 1 / 9 9 0 : 0 4
RE A D Y MO N
MRA ELBUORT
2. If necessary, close the front door .
3. Press the [#] key to cancel any unintended key entries.
4. Enter a valid 4 digit [USER CODE]. If you make a mistake, press
the [#] key and re-enter the code.
5. The ARMED indicator will flash for the duration of the exit delay.
Any bypassed zones will be shown by a steady illuminated zone
indicator.
14 IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17
IDS1600 USER MANUAL
0 1 / 0 1 / 9 9 0 : 0 4
D E L A Y T I M E
MRA ELBUORT
6. The arming process has begun. Leave only via the follower and
entry/exit zones.
0 1 / 0 1 / 9 9 0 : 0 4
AW A Y A RME D MON
MRA ELBUORT
5.2 Quick Away Arming
[1]
(Hold down the key until the keypad buzzer sounds)
If this function is enabled, it is possible to AWA Y arm by simply
holding down the [1] key until the keypad buzzer sounds and the
arming process begins.
5.3 Stay Arming
[#] + [USER CODE]
(Do not leave premises)
This allows the user to arm the perimeter zones while disabling the
interior zones so that it is possible to remain on the premises.
1. Ensure that the READY indicator is illuminated; if not, check
that all protected doors and windows are closed and that motion
has ceased in the areas covered by motion detectors.
0 1 / 0 1 / 9 9 0 : 0 4
RE A D Y MO N
MRA ELBUORT
IDS1600 USER MANUAL NO. 700-146-01D ISSUED NOV 2002 VER 2.17 15
IDS1600 USER MANUAL
2. If necessary, close the front door .
3. Press the [#] key to cancel any unintended entries.
4. Enter a valid [USER CODE].
5. DO NOT open the front door. If the front door is opened the
system will arm in AWAY mode.
6. The ARMED indicator will flash for the duration of the exit delay.
0 1 / 0 1 / 9 9 0 : 0 4
D E L A Y T I M E
MRA ELBUORT
7. The AWAY indicator will remain extinguished.
0 1 / 0 1 / 9 9 0 : 0 4
S T A Y A RME D MON
MRA ELBUORT
8. Any ST AY zones (shown by a steadily illuminated indicator) will
be automatically bypassed.
9. Ensure that you enter only those zones that are bypassed.
5.4 Quick Stay Arming
[5]
(Hold down the key until the keypad buzzer sounds)
It is possible to STAY arm by holding down the [5] key until the
keypad beeps. There is no exit delay.
5.5 Stay Arm and Go
[6]
(Hold down the key until the keypad buzzer sounds)
This is a quick function which allows the user to STAY arm and leave
the premises.
1. Hold down the [6] key until the keypad buzzer sounds. The
