iDevices iGrill 2 User Manual

User Manual

2

Table of Contents

In the Box 3

Quick Start Instructions 3

Getting Started 4

iDevices Connected App 4
Battery Replacement 5
Powering On & Off 5
Connecting 6
Mounting 6
Probe Use 7
Probe Wrap Use 8

Using the iGrill

2

9

Display 9
Probe Toggle Buttons 9
Proximity Sensor 10
Custom & Preset Alarms 10
Renaming Probes 12
Timer Tool 12
Globe Tool 13
Graph Tool 13

Problem Solving 13

Disclaimer 17

Regulations 17

3

In the Box

Inside your iGrill2 box, you will nd:

• 1 iGrill2

• 2 AA Batteries

• 2 Pro Meat Probes

• 2 Probe Wraps

• 2 Colored Probe Indicators

• 1 Optional Magnetic Disc

• Quick Start Guide

Quick Start Instructions

1. Download the iDevices® Connected app from the App StoreSM or
Google PlayTM Store on one of the following compatible devices:

• iPhone® (4S and later)

• iPad® (3rd generation and later)

• iPad miniTM (all generations)

• iPod touch® (5th generation and later)

• Many AndroidTM devices equipped with Bluetooth® 4.0 and
running Android software version 4.3 or later

2. Enable Bluetooth on your smart device under ‘Settings’.

3. Separate the iGrill2 from its base by rmly holding the base with one
hand and gently pulling the iGrill2 top upwards with the other hand.

4. On the underside of the iGrill2, depress and remove the battery
door. Insert the two supplied AA batteries with their negative
terminals compressing the springs and replace the battery door.

5. Clip the iGrill2 top back into its base.

4

6. Plug one or more probes into the probe ports of the iGrill2.

7. Press the power button located at the bottom of the faceplate
between the < and > buttons for two seconds. The display will
animate and a single beep will sound, indicating that the iGrill2 has
powered on.

8. Open the iDevices Connected app to connect to your iGrill2. Tap on
the iDevices logo in the gray toolbar at the top of the app. Select
your iGrill2 from the device manager.

9. You are ready to use your iGrill2!

Getting Started

iDevices Connected App

The iDevices Connected app provides all of the functionality and
customization you’ll need to get the most out of your iGrill2. The iDevices

Connected app is compatible with the following devices:

• iPhone (4S and later)

• iPad (3rd generation and later)

• iPad mini (all generations)

• iPod touch (5th generation and later)

• Many Android devices equipped with Bluetooth 4.0 and running
Android software version 4.3 or later

You must be running iOS 7+ or Android version 4.3+ on your device to use
the iDevices Connected app. Please visit the App Store or Google Play
Store and search “iDevices Connected” to download the free iDevices
Connected app.

Once you’ve downloaded the app, you’ll have access to links
for instructional videos, step-by-step instructions and FAQ’s for
troubleshooting.

5

Battery Replacement

To replace your iGrill2 batteries, follow these steps:

• Separate the iGrill2 from its base by rmly holding the base with one
hand and gently pull the iGrill2 top upwards with the other hand.

• On the underside of the iGrill2, depress and remove the battery
door.

• Replace the two AA batteries with their negative terminals
compressing the springs and replace the battery door.

Battery Precautions:

• Do not mix new and old batteries

• Do not mix alkaline, standard (carbon zinc) or rechargeable (ni-cad,
ni-mh, etc.) batteries.

• Dispose of spent or damaged batteries according to manufacturer
instructions and local laws.

Powering On & Off

To turn on the iGrill2, follow these steps:

• Press the power button located at the bottom of the faceplate
between the < and > buttons.

• The display will animate, and a single beep will be heard, indicating
it has powered on.

To turn off the iGrill2, follow these steps:

• Press and hold down the power button located at the bottom of
the faceplate between the < and > buttons for three seconds. The
display will show “OFF”.

• Upon releasing the power button, the iGrill2 will turn off.

Auto Shut-Off:

• The iGrill2 will stay powered on for ve minutes before automatically
turning off if there are no probes installed and it is not paired to a
smart device.

6

• The iGrill2 will stay powered on for eight hours before automatically
turning off if not paired to a smart device and probes are installed.

• The iGrill2 will stay powered on indenitely if at least one probe is
installed and it is paired with a smart device.

Connecting

To connect your iGrill2 to your iPhone, iPad, iPod touch or Android device

follow these steps:

• Open Settings

• Tap Bluetooth

• Set Bluetooth to On

• While turned on, place your iGrill2 next to your smart device
and open the iDevices Connected app. Your smart device will
automatically recognize any available iDevices products and display
them in the device manager. You can view your device manager by
tapping the iDevices logo at the top of the app.

• Select your iGrill2 from the device manager. You will then be sent a
pairing request. Once you accept, your smart device will pair with
the iGrill2 and you are ready to congure your settings and start
cooking!

To connect an additional iGrill2 (or other iDevices product) to your iPhone,

iPad, iPod touch or Android device follow these steps:

• While turned on, place your iGrill2 (or other iDevices product) next
to your smart device and open the iDevices Connected app.

• Tap on the gray bar located at the top of the screen to expose the
device manager. Select the product you would like to pair with
from the device manager. Your smart device will display a pairing
request. Once accepted, your smart device will pair with the

additional product and you are ready to congure your settings and

start cooking!

Mounting

• The iGrill2‘s base is magnetic for convenient positioning on a cool
portion of your grill, smoker or other magnetic surfaces.

7

• The iGrill2 can be taken out of its base, rotated 180° and set back
into its base for two different viewing angles.

• The iGrill2 comes with an optional magnetic disc with an adhesive
on one side. This allows the iGrill2 to magnetically mount to a non­magnetic surface. The magnetic disc has a protective cover on its
face to protect it from being scratched.

To mount your magnetic disc, please follow the below steps:

• Clean the surface thoroughly where the magnetic disc will be
adhered to ensure proper bonding.

• Remove the lm covering the adhesive on the magnetic disc.

• Adhere the magnetic disc to your desired surface.

• Let the magnetic disc bond to the surface for 6-12 hours before
mounting your iGrill2 to the disc.

• Place your iGrill2 on the magnetic disc.

The magnetic base is not designed to withstand high heat
and it must be placed on a cool surface. If the surface is too
hot to touch, it’s too hot for the iGrill2 base!

Probe Use

• Pro Meat Probe and Pro Ambient Probe Acceptable Temperature

Range: -22°F to 620°F (-30ºC to 326ºC)

• Meat Probe Acceptable Temperature Range: -22ºF to 572ºF (-30ºC
to 300ºC).

• The Meat Probes should always be inserted into the center of the
item being cooked for an accurate temperature reading.

• When using a standard Meat Probe, be sure to route the probe wire

where it will not be exposed to ames or temperatures exceeding

8

572° (300ºC). Pro Meat Probes may be exposed to temperatures as
high as 620ºF (326ºC).

• The Pro Ambient Probe should be clipped between two grates
inside your grill, smoker or oven. Ensure the tip of the probe does
not touch the grates.

• The probe wraps allow for convenient storage of your probes and
are magnetic so that they can be stored under your iGrill2 when not
in use.

The colored probe indicators are for visual identication of

the probe(s) within the app and cosmetic purposes only.
They are not designed for heat safety.

The probes should be cleaned by hand with a dishcloth,
standard dishwashing soap and warm water. The probes are
not dishwasher safe. Take precaution not to get the probe’s
wiring wet.

Be sure to avoid water exposure to the probes’ wiring as
well as the area where the probes’ wiring meets the probes.
The probes are not waterproof and damage may result from
water exposure. The probes should never be submersed in
water.

Temperatures below -22°F or above 572°F (-30ºC or above
300ºC) will not display in the iDevices Connected app and
will cause the probe to disappear from connection.

Probe Wrap Use

To wrap your probe(s):

• Hold the probe wrap so that the clip segment is on the bottom left
and the iDevices logo is legible in the center of the probe wrap.

• Snap the probe into the probe wrap’s clip, ensuring that the probe’s
body follows the contour of the probe wrap and leaves a ½ inch gap
between the probe and the wire channel of the probe wrap. The tip
of the probe should be pointed downward.

9

• Wrap your probe’s wire clockwise around the probe wrap.

• When you reach the adapter end of the probe wire, it can be
inserted into the probe wrap’s wire channel to secure the wrapping.

Using the iGrill

2

Display

The iGrill2’s display contains the following:

Display

• Displays temperature of currently active probe.

• Displays “DC” for temperatures below -22°F (-30ºC).

• Displays “DH” for temperatures above 572°F (300ºC).

• Displays “OFF” during power off sequence.

• Animates during power on sequence and during reset.

Bluetooth LED

• Blinks blue when discoverable and awaiting pairing.

• Illuminates solid blue when paired.

Probe Indicator LEDs

• Far left side LED illuminates to indicate Probe 1 temperature being
displayed.

• Middle left side LED illuminates to indicate Probe 2 temperature
being displayed.

• Middle right side LED illuminates to indicate Probe 3 temperature
being displayed.

• Far right side LED illuminates to indicate Probe 4 temperature being
displayed.

Probe Toggle Buttons

10

The iGrill2 has two buttons adjacent to the power button to toggle
between probes when there is more than one probe connected.

• Pressing the < or > button will switch from the currently displayed
probe temperature (as indicated by the illuminated probe indicator
LED) to the next probe.

• Holding either the < or > button down for one second will activate
a cycle that will continuously cycle through displaying each probe’s
temperature.

• Pressing the <, >, or power button while the alternating display
cycle is activated will disable the display cycle.

Proximity Sensor

The use of Bluetooth Smart allows the iGrill2 to sense when a paired smart
device moves in or out of range. The iGrill2 will automatically wake and

sleep at the below distances to conserve power:

• Sleep ~ 30 feet away

• Wake ~ 5 feet away

*Proximity function based on Bluetooth signal strength. Signal strength
is inuenced by a number of factors including the smart device
and environment.

Custom & Preset Alarms

Manage iPhone, iPad or iPod touch alarms:

If you are having issues hearing the alarms from the iDevices Connected

app, try these steps:

• Open Settings on your smart device

• Tap “Notication Center”

• Choose the iDevices Connected app and make sure to enable

notications, including “Sounds” and “Alerts”

11

Manage Android device alarms:

• Open Settings on your device

• Find “Apps” and search for the iDevices Connected app (This could
be located in your “Application Manager”)

• Make sure notications are enabled

Make sure the volume setting for your smart device is
properly set. If your sounds are off or set at a low setting,
you may not hear the alarm properly.

Manage iDevices Connected app alarms:

Within the app, tap “Set Preset” to the right of a connected probe’s
running temperature. This will bring you to your “Choose Preset” options.

Preset Alarms:

The iDevices Connected app offers preset alarms for many types of meats
and cooking temperatures. Tapping a preset alarm will set it. You can also
create your own custom preset alarm for any desired temperature. There

are two different types of presets:

• Peak: Alarm will sound when probe temperature reaches set peak
temperature.

• Range: Alarm will sound when probe temperature is above the high
temperature or below the low temperature.

Creating a custom preset alarm:

• Tap “Set Preset”

12

• Tap “Create New”

• Name your preset

• Set temperature(s)

• Tap “Save”

Your custom preset will be saved in the “My Peak Presets”
and “My Range Presets” sections of the alarm screen.

The iDevices Connected app will not display temperatures
below -22°F (-30ºC) or above 572°F (300ºC).

When your target temperature has been reached, the iGrill2
will produce an audible tone and the iDevices Connected

app alarm will alert you with a notication.

When a temperature reading goes outside your target
range, the iGrill2 will produce an audible tone and it’s display
will blink the current temperature as the iDevices Connected
app alarm alerts you.

Renaming Probes

A probe can be renamed by tapping on the “Probe #” to the left of the

running temperature, then:

• Naming your probe under “Probe Name”

• Choose a probe color from the “Probe Color Indicator” if needed

• Tap “Save” when done

Timer Tool

The timer tool allows users to set up timers. An alert will appear when the
timer runs out.

13

Create a new timer:

• Under “More” located at the bottom of the screen, tap “Timers”

• Tap “Create New” to create a new timer

• Add a timer title

• Set desired time length using scroll wheels

• Tap “Save” in the top right corner of the app. Start the timer by
sliding it on in the Timers menu.

Globe Tool

The globe tool will show other users of the iDevices Connected app.
Tapping on a pin will display a user-posted message and picture. Take a
look at what other cooks around the world have made to ignite ideas for
your next cooking adventure!

*You will only show up on the Globe if you share via Facebook.

Graph Tool

The iDevices Connected app’s Graph Tool illustrates the temperature
progression over time for your probe as you cook.

Tap on the graph to get a more detailed look of your cook. Below the

graph, tap “More”. You will see options to export the graph as a CSV le

or clear the history of the graph.

Clearing the history of the graph removes all data related to your cook.

Problem Solving

The following information covers some of the most common
troubleshooting issues with the iGrill2. If you need further assistance, please
review the iGrill2 FAQ page at http://idevicesinc.com/support or contact a
member of our Customer Support Team at [email protected].

My iGrill2 won’t turn on.

14

If your iGrill2 is brand new, please be sure that the batteries have been
inserted correctly with their negative terminals each compressing a spring.
If this does not resolve the issue or if your iGrill2 is not brand new, please
try replacing the batteries with a pair of brand new AA batteries.
If you are still unable to turn on your iGrill2, please contact our Customer
Support Team for assistance by emailing [email protected].

I’m having difculty pairing my iGrill2 with my smart device.

iPhone, iPad or iPod touch:

If the iGrill2 appears in your Bluetooth settings with the status “Not

Connected”, follow these steps from your Bluetooth settings menu:

• Tap the blue (i) the right of the iGrill2 device name.

• Select the option “Forget this Device”.

• Turn Bluetooth OFF on your smart device.

• Completely shut down your smart device.

• Separate the iGrill2 from its base by rmly holding the base with one
hand and gently pull the iGrill2 top upwards with the other hand.

• While still powered on, remove the iGrill2 battery door and press

the reset button down with a pin for ve seconds and reinstall the

battery door.

• Power up your smart device and turn Bluetooth back on.

• Tap on the iDevices logo in the gray toolbar at the top of the app.
Select your iGrill2 from the device manager. Your smart device will
pair with the iGrill2 and you are ready to congure your settings and
start cooking!

Android device:

If the iGrill2 device appears in your Bluetooth settings but is not showing
in the iDevices Connected app, follow these steps from your Bluetooth

settings menu:

• Tap on the icon to the right of the device and tap “unpair”

15

• Turn Bluetooth OFF on your smart device

• Completely shut down your smart device

• Separate the iGrill2 from its base by rmly holding the base with one
hand and gently pulling the iGrill2 upwards with the other hand.

• While still powered on, depress and remove the iGrill2 battery door,
press the reset button down with a pin for 5 seconds and reinstall
the battery door.

• Replace the battery cover.

• Power up your device and turn Bluetooth back on.

• Click on the iDevices logo in the gray toolbar at the top of the app.
Select your iGrill2 from the dropdown menu. Your device will pair
with the iGrill2 and you are ready to congure your settings and start
cooking!

If you are having intermittent Bluetooth issues with your Android device

and want to restart Bluetooth from the app:

• Tap “More” located at the bottom of the app

• Tap “Support”

• Tap “Restart Android Bluetooth” and “Restart” when prompted

Bluetooth will restart on your Android device and you will have the ability
to pair.

If you do not see the iGrill2 in your Bluetooth settings, please ensure
that you are using the iDevices Connected app. If you experience
further problems, please contact our Customer Support Team for further
assistance.

I’m experiencing issues with the iDevices Connected app for my
iPhone, iPad or iPod touch.

The iDevices Connected app requires iOS 7.0 or higher to operate.

If you are experiencing a problem with the iDevices Connected app for
iOS, please try following the steps below to resolve any potential problems

16

on the device-side:

• Make sure the iGrill2 is paired with your smart device via Bluetooth
and a temperature probe is plugged into the unit.

• Tap the Home button on the smart device.

• From the Home screen, double tap the Home button again. This will

zoom out of the home screen and display any/all previously running

apps on your smart device.

• Swipe to locate the “iDevices Connected” app.

• Swipe the “iDevices Connected” app image upward to close the
existing session.

• Tap the Home button on your smart device to close the Multitasking
Bar.

• Re-open the iDevices Connected app by tapping the app icon on
the Home screen.

If you are still experiencing a problem after completing these steps, please
contact our Customer Support Team for further assistance.

I’m experiencing issues with the iDevices Connected app for my
Android device.

The iDevices Connected app requires Android version 4.3 or higher to
operate.

If you are experiencing a problem with the iDevices Connected app for
Android, please try following the steps below to resolve any potential
problems on the device-side.

• Make sure the iGrill2 is paired with your Android device via
Bluetooth and a temperature probe is plugged into the unit.

• Go to your app manager and quit out of the iDevices Connected
app

• Re-open the iDevices Connected app by tapping the app icon.

If you are still experiencing a problem after completing these steps, please

17

contact our customer support team for further assistance.

I don’t have a device with which to pair my iGrill2, can I still use it?

Yes, the iGrill2 has a display to show its temperature readings and it can be
used to view the current temperature from the inserted probes. The alarm
settings, timer tool, globe tool, graph tool and probe renaming features for
the iGrill2 require the use of the iDevices Connected app and a compatible
Bluetooth Smart Ready device.

Disclaimer

The appliance is not to be used by children or persons with reduced
physical, sensory or mental capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction.

Children should be supervised and instructed not to play with the
appliance.

For detailed instructions regarding the iDevices Connected app, please
download the iDevices Connected app User Manual from the iDevices
website www.idevicesinc.com.

Regulations

FCC COMPLIANCE STATEMENT:

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.

INFORMATION TO USER:

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of FCC Rules. These limits are

18

designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance with the
instructions, it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try and correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the distance between the equipment and the receiver

• Connect the equipment to outlet on a circuit different from that to
which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help.

Canada – Industry Canada (IC)

This device complies with Industry Canada license-exempt RSS Standard(s).

Operation is subject to the following two conditions:

(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired
operation of the device.

Cet appareil est conforme avec Industrie Canada exempts de licence
standard RSS (s). Son fonctionnement est soumis aux deux conditions

suivantes:

(1) cet appareil ne doit pas provoquer d’interférences et (2) cet appareil
doit accepter toute interference, y compris celles pouvant causer un
mauvais fonctionnement de l’appereil.

19
