TouchSecure
Desktop Reader
®
Quick Start Guide
Connection
Specifications
Technical Support
support@identive-infrastructure.com
Introduction
The TouchSecure Desktop Reader is a complete paradigm shift fro m the historical design
of card readers, offering innovative customer solutions to meet the demands of a
changing world. The reader lever ages employee’s traditional buil ding access cards for
other applications, including office shared services, equipment sign-out and cafeteria, to
name a few. The TouchSecure Desktop Reader delivers the employee card ID in a
keyboard emulation format that most applications recognize.
The TouchSecure Desktop Reader will read a wide selection of proximity card formats,
MIFARE, ISO144443A/B and ISO15693 CSN cards.
Parts List
1 - Installation Guide
1 - Reader with USB cable
Installation
1. Remove the reader from the box.
2. Determine the mounting location of the reader.
3. Using Velcro or equivalent material affix reader to desired surfa ce.
4. Connect USB cable to target PC or network device.
5. Power up the reader, letting the reader setup and prepare for
operation.
6. Verify that the LED is illumi nated.
7. Present a card that is programmed to operate in the system and if
operating correctly, the LED change colors depending on programming.
Federal Communications Statement
The FCC requires the following st atements for your information:
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide r easonable protection
against harmful interference when the equipment is ope rated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause ha rmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interferenc e at his own expense.
This device complies with Part 15 of FCC Rules . Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that m ay cause undesired operation.
Changes or modifications not expressly approved by I dentive could void the user's authority to
operate the equipment.
Power + 5 VDC
Read Distance
125 kHz
13.56 mHz
Up to 10.16 cm (4”)
Up to 5.1 cm (2”)
(Depending on local environme ntal
conditions and type of RFID c ards)
Data Output
US Keyboard Emulation
Interface
USB
Temperature Range -35 to 65C (-31 to 150F)
Operating Humidity
5% to 95% (non-
condensing)
Dimensions
118 x 78 x 22 mm
Approvals FCC, VCCI, EMC, C Tick
Audio / Visual
Buzzer, Tri color LED
Cable
1.5 m USB cable
Transmit Frequency 13.56 mHz & 125 kHz
Standards
ISO15693, ISO14443A/B
Environment RoHS
125 kHz Card
Compatibilities
HID, Indala, Cardax, NXP
Hitag II UID, GE, Farpointe
13.56 mHz Card
Compatibilities
ISO14443A/B CSN,
ISO15693 CSN
