SDI011

Dual interface (contactless and contact) stationary reader

SCM Microsystems

Reference Manual – version 1.01

Reference manual

SDI011 Dual Interface (Contactless and Contact)

Stationary Reader

Oskar-Messter-Strasse, 13

85737 Ismaning

Germany

Phone +49 89 9595 5000 • Fax +49 89 9595 5555

Date

Version

Description of change

08/09/2010

1.0

Initial Version

11/10/2010

1.01

Add FCC warning Typo corrections

Document history

Contact information

http://www.scmmicro.com/products-services/smart-card-readers-terminals/contactless-dualinterface-readers.html

For sales information, please email sales@scmmicro.com

Table of Contents

1. Legal information ................................................................................................................... 9

1.1. Disclaimers ..................................................................................................................... 9

1.2. FCC ................................................................................................................................ 9

1.2.1. Section 15.21 Information to user ........................................................................... 9

1.2.2. Section 15.105 (b) ................................................................................................... 9

1.3. Licenses ......................................................................................................................... 9

1.4. Trademarks .................................................................................................................. 10

2. Introduction to the manual ................................................................................................... 11

2.1. Objective of the manual ............................................................................................... 11

2.2. Target audience ........................................................................................................... 11

2.3. Product version corresponding to the manual ............................................................. 11

2.4. Definition of various terms and acronyms .................................................................... 12

2.5. References ................................................................................................................... 13

2.6. Conventions ................................................................................................................. 14

3. General information about SDI011 ...................................................................................... 15

3.1. SDI011 key benefits ..................................................................................................... 15

3.2. SDI011 key features ..................................................................................................... 15

3.3. SDI011 ordering information ........................................................................................ 16

3.4. SDI011 customization options ...................................................................................... 16

3.5. Contactless communication principles and SDI011 usage recommendations ............ 17

3.5.1. Power supply......................................................................................................... 17

3.5.2. Data exchange ...................................................................................................... 17

3.5.3. Recommendations ................................................................................................ 18

3.6. Applications .................................................................................................................. 19

3.6.1. General ................................................................................................................. 19

3.6.2. Applications provided by SCM Microsystems ....................................................... 19

4. SDI011 characteristics ........................................................................................................ 20

4.1. SDI011 high level architecture ..................................................................................... 20

4.1.1. Block diagram ....................................................................................................... 20

4.1.2. Software architecture ............................................................................................ 21

4.2. Quick reference data .................................................................................................... 22

4.2.1. SDI011 dimensions ............................................................................................... 22

4.2.2. LED behavior ........................................................................................................ 23

4.2.3. Other data ............................................................................................................. 24

5. Software modules ................................................................................................................ 26

5.1. Installation .................................................................................................................... 26

5.2. Utilities .......................................................................................................................... 26

5.3. Driver ............................................................................................................................ 26

5.3.1. SDI011 listing ........................................................................................................ 26

5.3.2. Supported operating systems ............................................................................... 27

5.3.3. PC/SC 2.0 compliant ATR for contactless interface ............................................. 27

5.4. Firmware ...................................................................................................................... 30

5.4.1. CCID transport protocol ........................................................................................ 30

5.4.2. Automatic PPS for the contactless interface ......................................................... 31

6. Commands description ........................................................................................................ 32

6.1. Generic APDU .............................................................................................................. 32

6.1.1. Get UID Command ............................................................................................... 32

6.1.2. Escape command APDU ...................................................................................... 34

6.2. Set of APDU for contactless storage user tokens ........................................................ 35

6.2.1. STORAGE_CARD_CMDS_READ_BINARY ........................................................ 35

6.2.2. STORAGE_CARD_CMDS_WRITE_BINARY ...................................................... 37

6.2.3. STORAGE_CARD_CMDS_LOAD_KEYS ............................................................ 39

6.2.4. STORAGE_CARD_CMDS_AUTHENTICATE ...................................................... 40

6.2.5. STORAGE_CARD_CMDS_VALUE_BLOCK ....................................................... 42

6.3. Set of APDU for ISO/IEC14443-4 user tokens ............................................................ 43

6.3.1. T=CL Command .................................................................................................... 43

6.3.2. T=CL user command ............................................................................................ 44

6.4. Set of APDU defined by SCM Microsystems ............................................................... 45

6.4.1. MIFARE DESFire Commands .............................................................................. 45

6.5. Escape commands for the contactless interface ......................................................... 46

6.5.1. Sending escape commands to SDI011 ................................................................ 46

6.5.2. Escape command codes ....................................................................................... 46

6.5.3. READER_GETCARDINFO ................................................................................... 47

6.5.4. READER_LED_CONTROL_BY_FW .................................................................... 48

6.5.5. READER_LEDCONTROL .................................................................................... 48

6.5.6. READER_CNTLESS_GET_MFRC_REV ............................................................. 48

6.5.7. READER_CNTLESS_GET_ATS_ATQB .............................................................. 49

6.5.8. READER_CNTLESS_GET_TYPE ....................................................................... 49

6.5.9. READER_CNTLESS_SET_TYPE ........................................................................ 49

6.5.10. READER_CNTLESS_RF_SWITCH ..................................................................... 50

6.5.11. READER_CNTLESS_RAW_CFG ........................................................................ 50

6.5.12. READER_CNTLESS_RAW_XMIT_EX ................................................................ 51

6.5.13. READER_ CNTLESS_DISABLE_PPS ................................................................. 52

6.5.14. READER_SWITCH_RF_ON_OFF ....................................................................... 52

6.5.15. READER_CNTLESS_848KBPS ........................................................................... 53

6.5.16. READER_CNTLESS_BAUDRATE ....................................................................... 54

6.5.17. READER_CNTLESS_FORCE_BAUDRATE_PCSC_REV2 ................................ 55

6.6. Escape commands for the contact interface ................................................................ 56

6.6.1. Sending escape commands to SDI011 ................................................................ 56

6.6.2. Escape command codes ....................................................................................... 56

6.6.3. READER_SETMODE ........................................................................................... 56

6.6.4. READER_GETMODE ........................................................................................... 57

6.6.5. READER_APDU_TRANSFER.............................................................................. 57

6.6.6. READER_SWITCH_SPEED ................................................................................. 58

6.6.7. READER_SWITCH_PROTOCOL......................................................................... 58

6.6.8. READER_DISABLE_PPS ..................................................................................... 59

6.6.9. READER_GETIFDTYPE ...................................................................................... 59

6.6.10. READER_GETINFO_EXTENDED ....................................................................... 60

7. Annexes ............................................................................................................................... 61

7.1. Annex A – Status words table ...................................................................................... 61

7.2. Annex B – Sample code using escape commands through Escape IOCTL ............... 62

7.3. Annex C - SCM Proprietary CLA bytes ........................................................................ 67

7.4. Annex D – Mechanical drawings .................................................................................. 68

7.4.1. Top Casing ............................................................................................................ 68

7.4.2. Bottom Casing ...................................................................................................... 69

7.4.3. Stand ..................................................................................................................... 70

SDI011 REFERENCE MANUAL 9

1. Legal information

1.1. Disclaimers

The content published in this document is believed to be accurate. SCM Microsystems does not, however, provide any representation or warranty regarding the accuracy or completeness of its content and regarding the consequences of the use of information contained herein. If this

document has the status ―Draft‖, its content is still under internal review and yet to be formally

validated. SCM Microsystems reserves the right to change the content of this document without prior

notice. The content of this document supersedes the content of previous versions of the same document. The document may contain application descriptions and/or source code examples, which are for illustrative purposes only. SCM Microsystems gives no representation or warranty that such descriptions or examples are suitable for the application that the reader may want to use them for.

Should you notice problems with the provided documentation, please provide your feedback to

support@scmmicro.com.

1.2. FCC

1.2.1. Section 15.21 Information to user

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment

1.2.2. Section 15.105 (b)

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

1.3. Licenses

If the document contains source code examples, they are provided for illustrative purposes only and subject to the following restrictions:

 You MAY at your own risk use or modify the source code provided in the document

in applications you may develop. You MAY distribute those applications ONLY in form of compiled applications.

SDI011 REFERENCE MANUAL 10

 You MAY NOT copy or distribute parts of or the entire source code without prior

written consent from SCM Microsystems.

 You MAY NOT combine or distribute the source code provided with Open Source

Software or with software developed using Open Source Software in a manner that subjects the source code or any portion thereof to any license obligations of such Open Source Software.

If the document contains technical drawings related to SCM Microsystems products, they are provided for documentation purposes only. SCM Microsystems does not grant you any license to its designs.

1.4. Trademarks

MIFARE is a registered trademark of NXP Semiconductors BV. Windows is a trademark of Microsoft Corporation.

SDI011 REFERENCE MANUAL 11

Item

Version

Hardware

1.0

Firmware

7.36

Windows Contact Driver

5.19

Windows Contactless Driver

5.20 MAC driver

5.0.18

LINUX Driver

5.0.18

2. Introduction to the manual

2.1. Objective of the manual

This manual provides an overview of the hardware and software features of the SDI011 dual interface (contactless and contact) reader, hereafter referred to as ―SDI011‖.

This manual describes in details interfaces and supported commands available for developers using SDI011 in their applications.

2.2. Target audience

This document describes the technical implementation of SDI011. The manual targets software developers. It assumes knowledge about 13.56 MHz contactless

technologies like ISO/IEC 14443 and commonly used engineering terms. Should you have questions, you may send them to support@scmmicro.com .

2.3. Product version corresponding to the manual

SDI011 REFERENCE MANUAL 12

Term

Expansion

APDU

Application Protocol Data Unit

ATR

Answer to Reset, defined in ISO7816

ATS

Answer to select, defined in ISO/IEC 14443

Byte

Group of 8 bits

CCID

Chip Card Interface Device

CID

Card Identifier

Contactless

DFU

Device Firmware Upgrade

Divider receive: used to determine the baud rate between the reader to the card

Divider send: used to determine the baud rate between the card to the reader

LED

Light emitting diode

MIFARE

The ISO14443 Type A with extensions for security (NXP)

Not applicable

NAD

Node Address

Nibble

Group of 4 bits. 1 digit of the hexadecimal representation of a byte. Example: 0xA3 is represented in binary as (10100011)b. The least significant nibble is 0x3 or (0011)b and the most significant nibble is 0xA or (1010)b

PCD

Proximity Coupling Device

PC/SC

Personal Computer/Smart Card: software interface to communicate between a PC and a smart card

PICC

Proximity Integrated Chip Card

PID

Product ID

Proximity

Distance coverage till ~10 cm.

PUPI

Pseudo unique PICC identifier

RFU

Reserved for future use

Radio Frequency

STCII

Smart card reader controller ASIC from SCM Microsystems

USB

Universal Serial Bus

VID

Vendor ID

(xyz)b

Binary notation of a number x, y, z 0,1

0xYY

The byte value YY is represented in hexadecimal

2.4. Definition of various terms and acronyms

SDI011 REFERENCE MANUAL 13

Doc ref in the manual

Description

Issuer

ISO/IEC 78163

Identification cards — Integrated circuit

cards — Part 3: Cards with contacts — Electrical interface and transmission protocols

ISO / IEC

ISO/IEC 78164

Identification cards - Integrated circuit(s) cards with contacts Part 4: Interindustry commands for interchange ISO/IEC 7816-4: 1995 (E)

ISO / IEC ISO/IEC

14443-3

Identification cards — Contactless integrated circuit(s) cards — Proximity

cards — Part 3: Initialization and anti-collision

ISO / IEC

ISO/IEC 14443-4

Identification cards — Contactless integrated circuit(s) cards — Proximity cards Part 4: Transmission protocol ISO/IEC 144434:2001(E)

ISO / IEC PC/SC

Interoperability Specification for ICCs and Personal Computer Systems v2.01

PC/SC Workgroup

CCID

Specification for Integrated Circuit(s) Cards Interface Devices 1.1

USB-IF USB

Universal Serial Bus Specification 2.0

USB-IF

2.5. References

SDI011 REFERENCE MANUAL 14

b7 b6 b5 b4 b3 b2 b1 b0

B4 B5 B6 B7 B8 B9 B10 B11B0 B1 B2 B3

Least significant nibbleMost significant nibble

1 Byte = 8 bits = 2 nibbles

Bit number 0Bit number 5

String of 12 bytes

Byte number 11Byte number 2

2.6. Conventions

Bits are represented by lower case ‗b‘ where followed by a numbering digit. Bytes are represented by upper case ‗B‘ where followed by a numbering digit.

Example:

163 decimal number is represented

 in hexadecimal as 0xA3  in binary as (10100011)b

The least significant nibble of 0xA3 is

 0x3 in hexadecimal  (0011)b in binary

The most significant nibble of =xA3 is

 0xA in hexadecimal  (1010)b in binary

SDI011 REFERENCE MANUAL 15

3. General information about SDI011

3.1. SDI011 key benefits

With its combination of a modern slim design and its state of the art feature set, SDI011 is the perfect desktop reader choice for environments where both contact and contactless smart card support is required. Such environments may be corporate where physical and logical access control is implemented.

As for all SCM Microsystems products, SDI011 is designed to offer best in class interoperability with various formats of tokens: cards, dongles, watches or NFC mobile phones.

Its infield upgradeable firmware makes SDI011 a secure and future-proof investment providing both flexibility and fast time to market for new applications as well as minimum risk linked to contactless technology standards evolution.

3.2. SDI011 key features

 13.56MHz contactless reader:

o ISO14443 type A & B, o MIFARE

 ISO7816 compliant contact smart card reader  PC/SC v2.0 compliant  In field upgradeable firmware  Unique serial number which enables that SDI011 can be plugged into any USB slot

on a PC without having to re-install the driver.

SDI011 REFERENCE MANUAL 16

Item

Part number

SDI011

905214

Contactless SDK

905124

Contact SDK

905129

3.3. SDI011 ordering information

3.4. SDI011 customization options

Upon request, SCM can customize:

 The color of the casing  The logo  The product label  The USB strings

Terms and conditions apply, please contact your local SCM representative or send an email to

sales@scmmicro.com.

SDI011 REFERENCE MANUAL 17

3.5. Contactless communication principles and SDI011 usage recommendations

SDI011 is a dual interface reader capable of reading both contact smart cards and contactless user tokens. The following paragraph focuses on a few specifics of the contactless communication to outline usage recommendations in order to ensure best user experience.

SDI011 is a contactless reader1 designed to communicate with user tokens.

User tokens2 are made of a contactless integrated circuit card connected to an antenna

User tokens can take several form factors:

 Credit card sized smart card  Key fob  NFC mobile phone etc…

Communication between SDI011 and user tokens uses magnetic field inductive coupling.

The magnetic field generated by SDI011 has a carrier frequency of 13.56MHz.

3.5.1. Power supply

When the user token is put in the magnetic field of the reader, its antenna couples with the reader and an induction current appears in the antenna thus providing power to the integrated circuit. The generated current is proportional to the magnetic flux going through the antenna of the user token.

3.5.2. Data exchange

The carrier frequency of the magnetic field is used as a fundamental clock signal for the communication between the reader and the card. It is also used as a fundamental clock input for the integrated circuit microprocessor to function.

To send data to the user token the reader modulates the amplitude of the field. There are several amplitude modulation and data encoding rules defined in ISO/IEC 14443. The reader should refer to the standard for further details.

To answer to the reader, the integrated circuit card of the user token modulates its way of loading (impedance) the field generated by the reader. Here also further details can be found in ISO/IEC 14443.

In the ISO/IEC 14443 standard, the reader is called the proximity coupling device (PCD)

In the ISO/IEC 14443 standard, the user token is called proximity integrated chip card (PICC)

SDI011 REFERENCE MANUAL 18



It is recommended for proper communication to avoid putting SDI011 in close proximity of conductive materials.



It is recommended to present only one user credential at a time in front of SDI011.



It may happen that SDI011 is not capable of communicating with extremely large or extremely small antennas.



In order to optimize the coupling between the reader and the user token, it is recommended to put both antennas as parallel as possible



In order to optimize transaction speed between the reader and the card it is recommended to place the user token as close as possible to the reader. This will increase the amount of energy supplied to the user credential which will then be able to use its microprocessor at higher speeds

3.5.3. Recommendations

The communication between the reader and the user token is sensitive to the presence of material or objects interfering with the magnetic field generated by the reader.

The presence of conductive materials like metal in the vicinity of the reader and the user token can severely degrade the communication and even make it impossible. The magnetic field of

the reader generates Eddy or Foucault‘s currents in the conductive materials; the field is

literally absorbed by that kind of material.

The presence of multiple user tokens in the field also interferes with the communication. When several user tokens are in the field of the reader, load of the field increases which implies that less energy is available for each of them and that the system is detuned. For this reason, SCM Microsystems has implemented in its driver only 1 slot by default. This means that in the event several user tokens are in the field of the SDI011, only one will be active. It is possible using INF configuration to enable up to 4 slots – i.e. to activate up to 4 user tokens nevertheless depending on the power consumption of the user tokens communication cannot be guaranteed.

Please note that multiple contactless slots feature is supported but is kept disabled by default.

The SDI011 driver on configuration allows the presence and use of several PICCs (maximum 4) at the same time. The driver can support multiple logical connections and present each of them as a slot logical device to the Resource Manager and higher components. Also the simultaneous working of multiple Contactless cards is not guaranteed and depends on the antenna size and the power requirements of the card.

The communication between the reader and the user token is sensitive to the geometry of the system {reader, user token}. Parameters like the geometry and specially the relative size of the reader and user token antennas directly influence the inductive coupling and therefore the communication.

SDI011 was primarily designed and optimized to function with user credentials of various technologies having the size of a credit card.

SDI011 REFERENCE MANUAL 19

SDI

010

Tokens

Application logic + User

personal data for given

set of applications

USB link

PC/SC interface

RF link (13.56MHz) ISO14443 interface

Host

Application logic

SDI010

Interface device

Network

3.6. Applications

3.6.1. General

SDI011 is a transparent reader designed to interface a personal computer host supporting PC/SC interface with 13.56MHz user tokens like public transport cards, contactless banking cards, electronic identification documents – e.g. e-passports, e-ID cards, driving licenses etc.

Those user tokens can have several form factors like credit cards, key fobs, NFC mobile phones or USB dongles like SCT3511 that SCM Microsystems markets.

SDI011 itself handles the communication protocol but not the application related to the token. The application-specific logic has to be implemented by software developers on the host.

3.6.2. Applications provided by SCM Microsystems

SCM Microsystems does not provide payment or transport applications. SCM Microsystems provides a few applications for development and evaluation purposes that

can function with SDI011. There are many tools provided; here are two of them:

 The NFC forum tag reader/writer is a standalone application that enables the user to

read and write NFC forum compliant records into NFC forum compatible tags. It is an easy to use tool to configure rapidly NFC forum tag demonstrations. Note: SDI011 supports NFC forum tag type 2 and 4, only.

 Smart card commander version 1.1 provides NFC forum record parsing functionality

of NDEF records in XML format as well as scripting functionality which can be very useful for developers to develop and debug their applications. This tool can be used for both the contact and the contactless interfaces of SDI011.

SDI011 REFERENCE MANUAL 20

Device controller

STC2 ASIC (SCM) with

embedded flash

RF front-end

MFRC531 (NXP)

EMC filter +

Matching circuitry

LED

text text text

Antenna

To host

ISO7816 contact

smart card interface

4. SDI011 characteristics

4.1. SDI011 high level architecture

4.1.1. Block diagram

The link between SDI011 and the host to which it is connected is the USB interface providing both the power and the communication channel.

SDI011 has a device controller which is SCM‘s STCII ASIC. This ASIC has several interfaces available. In SDI011 implementation 3 peripherals are connected to the device controller:

 LED for reader status indication  A contact smart card interface  An RF front-end that handles the RF communication

The ASIC embeds flash memory. The flash is programmed during the manufacturing of SDI011 devices. This flash contains the firmware developed by SCM Microsystems to handle all the ISO7816 contact protocol, the RF communication protocols and the PC/SC communication protocol with the host. The flash can be upgraded once the device is deployed in the field, hence enabling firmware upgrades to add and potentially patch features.

The RF front-end ensures the coding/decoding/framing modulation/demodulation required for the RF communication. It is controlled by the device controller through registers.

The matching circuitry provides the transmission and receiver paths adaptation for the antenna to function properly.

SDI011 REFERENCE MANUAL 21

4.1.2. Software architecture

Applications can interface with the driver directly through the PC/SC interface.

The SDI011 driver implements PC/SC v2.0 API towards upper layers and uses SCM firmware commands encapsulated in CCID-like protocol for the contactless slot and full CCID for the contact slot.

The SDI011 contactless driver handles all the contactless-related intelligence – i.e. ISO/IEC 14443 and the SDI011 firmware handles the raw transport of data to and from the contactless cards.

SDI011 REFERENCE MANUAL 22

Item

Characteristic

Value

SDI011

Weight

128 Grams

External dimensions

L 118 mm  W 78mm  H 22mm

Cable length

1.5 meter long with USB type A connector

Default color

Black with metallic silver

Default label

4.2. Quick reference data

4.2.1. SDI011 dimensions

Drawing with dimensions of the SDI011 and accessories can be found in annex.

SDI011 REFERENCE MANUAL 23

SDI011 states

LED1 Indication (GREEN)

LED2 Indication (RED)

Just after plug-in (with drivers

already installed)

OFF

Just after DFU operation

OFF

Suspend / standby

OFF

Reader powered, Contact card IN, but not powered (98/ME – issue power down using the Testresman utility)

500ms ON 500ms OFF

OFF

Reader powered, Contact card IN, but not powered (2K/XP – power down takes place )

OFF

Reader powered, Contactless card IN, but not powered (98/ME - issue power down using the

Testresman utility)

500ms ON 500ms OFF

Reader powered, Contactless card IN, but not powered (2K/XP - power down takes place )

Contact card powered / communication

500ms ON 500ms OFF

OFF

Contactless card powered / communication

500ms ON 500ms OFF

Reader / card errors

OFF

100ms ON 100ms OFF

Firmware upgrade running

OFF

Combi3 card powered in contact Slot

500ms ON 500ms OFF

OFF

Combi card powered using RF field

500ms ON 500ms OFF

4.2.2. LED behavior

SDI011 is equipped with a bicolor LED. Its behavior is described in the table below.

A combi card is a smart card which has both a contact and a contactless interface. Some of those cards have one controller with two interfaces. Data can be accessed through the contact or the contactless interface. For those when the contact interface is powered up the contactless interface is disabled. There are nevertheless in the market combi cards with 1 contact chip and 1 contactless chip. Those cards can be seen at the same time as a contact and a contactless card when inserted in the contact interface of SDI011.

SDI011 REFERENCE MANUAL 24

Parameter

Value/Description

Clock of the device controller

24 MHz

API

PC/SC 2.0

Operating temperature range

0º to 50ºC

Operating humidity range

Up to 95%RH non condensing

Certifications

USB CE FCC VCCI WEEE RoHS WHQL

Parameter

Value/Description

DC characteristics

High bus powered (SDI011 draws power from USB bus) Voltage: 5V Max. Current : 200mA Suspend current : 380uA

USB specification

USB 2.0 FS Device

USB Speed

Full Speed Device (12Mbit/s)

Device Class

Vendor

PID

0x5121

VID

0x04E6

4.2.3. Other data

4.2.3.1. General

4.2.3.2. USB

SDI011 REFERENCE MANUAL 25

Parameter

Value/Description

RF carrier frequency

13.56 MHz +/- 50ppm

Modulation

12 to 14 %

ID1 format tokens supported

ISO/IEC 14443-4 PICC type A and type B MIFARE Type B memory card PICC through SCM-proprietary APDU

Maximum baud rate

424Kbps (848 Kbps is available as configurable option)

Multiple PICC in field

Supported and is kept disabled by default.

Allows the presence and use of several PICC‘s (Maximum 4) at the same

time. The driver can support multiple logical connections and present each of them as a slot logical device to the Resource Manager and higher components. Also the simultaneous working of multiple Contactless cards is not guaranteed and depends on the antenna size and the power requirements of the card.

Parameter

Value/Description

Smart card operating frequency

4MHz

Maximum supported card baud-rate

500Kbps

Cards supported

Class A and Class AB smart cards (Class B only cards not supported) Synchronous smart cards

ISO-7816 compliant

Yes

EMV‘2000 compliant

Not validated

CT-API compliant

Yes

Number of slots

Single smart card slot

Ejection mechanism

Manual

4.2.3.3. Contactless interface

4.2.3.4. Contact interface

SDI011 REFERENCE MANUAL 26



Operating systems supported by DFU tool:

 Windows 98  Windows ME  Windows 2000  Windows 2003 Server (32 & 64 bit)  Windows XP (32 & 64 bit)  Windows Vista (32 & 64 bit)  Windows Server 2008 (32 & 64 bit)

5. Software modules

5.1. Installation

SCM provides an installer for Windows and for Mac The installers can be used to install the driver as well as some utilities.

5.2. Utilities

The following utilities are available:

 A tool for device firmware upgrade (DFU)  A tool for testing the installation of the PC/SC driver  A tool for testing the resource manager  A tool called PC/SC Diag capable of providing basic information about the reader

and a card through PC/SC stack

The DFU utility comes with a specific driver for dynamic Device Firmware Upgrade (DFU) through the USB interface.

5.3. Driver

5.3.1. SDI011 listing

SDI011 is listed by PC/SC applications as

 SCM Microsystems Inc. SDI011 Smart Card Reader for the contact reader  SCM Microsystems Inc. SDI011 Contactless Reader for the contactless reader

SDI011 REFERENCE MANUAL 27



Operating systems supported by the driver:

 Windows 98  Windows ME  Windows 2000  Windows 2003 Server (32 & 64 bit)  Windows XP (32 & 64 bit)  Windows Vista (32 & 64 bit)  Windows Server 2008 (32 & 64 bit)

5.3.2. Supported operating systems

5.3.3. PC/SC 2.0 compliant ATR for contactless interface

When a user token is placed on the reader, initialization, anti-collision is done. The user token is automatically activated and an ATR is built as defined in the PC/SC specification.

SDI011 REFERENCE MANUAL 28

Byte#

Value

Designation

Description

0x3B

Initial header

0x8n

n indicates the number of historical bytes in following ATR

0x80

TD1

Nibble8 indicates no TA2, TB2, TC2 Nibble 0 means T=0

0x01

TD2

Nibble8 indicates no TA3, TB3, TC3 Nibble 1 means T=1

4...3+n

0x80

A status indicator may be present in an optional TLV data object

0x4F

Optional TLV data object

Tag: Application identifier

Length

1 byte

RID

Registered identifier on 5 bytes

PIX

Proprietary identifier extension on 3 bytes

0x00 0x00 0x00 0x00

4 RFU bytes

4+n TCK

XOR of all previous bytes

MIFARE Classic 4K

MIFARE Ultralight

5.3.3.1. ATR for contactless storage user tokens

The ATR of the user token is composed as described in the table below. In order to allow the

application to identify the storage card properly, it‘s Standard and Card name describing bytes

must be interpreted according to the Part 3 Supplemental Document, maintained by PC/SC. Tokens using technology like MIFARE are examples of such user tokens.

Example of the ATR built for contactless storage tokens:

SDI011 REFERENCE MANUAL 29

Byte#

Value

Designation

Description

0x3B

Initial header

1 0x8n

n indicates the number of historical bytes in following ATR

0x80

TD1

Nibble8 indicates no TA2, TB2, TC2 Nibble 0 means T=0

0x01

TD2

Nibble8 indicates no TA3, TB3, TC3 Nibble 1 means T=1

4...3+n

Historical bytes or application information

Type A: the historical bytes from the ATS (up to 15 bytes) Type B (8 bytes):

 Byte 0 through 3: application data from ATQB,  Byte 4 through 6: protocol info byte from ATQB,  Byte 7: highest nibble is the MBLI (maximum

buffer length index) from ATTRIB, lowest nibble is 0x0

4+n TCK

XOR of all previous bytes

Type A

Type B

5.3.3.2. ATR for ISO/IEC 14443-4 user tokens

The user token exposes its ATS or application information which is mapped to an ATR. The table describes how this mapping is done.

Example of the ATR built for an ISO14443-4 user tokens:

SDI011 REFERENCE MANUAL 30

5.4. Firmware

5.4.1. CCID transport protocol

SDI011 implements a transport protocol that is compliant with USB Device Class: Smart Card CCID Specification for Integrated Circuit(s) Cards Interface Devices Revision 1.10 for the

contact smart card interface and CCID-like transport protocol for the contactless interface. This paragraph describes the CCID specification features that are implemented and those that

are not implemented.

5.4.1.1. CCID class requests supported

 Abort

5.4.1.2. CCID messages supported

The following CCID messages are supported both for the contact and the contactless interfaces when received through bulk-out endpoint.

 PC_to_RDR_IccPowerOn  PC_to_RDR_IccPowerOff  PC_to_RDR_GetSlotStatus  PC_to_RDR_XfrBlock  PC_to_RDR_GetParameters  PC_to_RDR_SetParameters  PC_to_RDR_Escape  PC_to_RDR_Abort  PC_to_RDR_NotifySlotChange

The following CCID messages are NOT implemented and hence fail with command not supported error:

 PC_to_RDR_ResetParameters  PC_to_RDR_IccClock  PC_to_RDR_T0APDU  PC_to_RDR_Secure  PC_to_RDR_Mechanical  PC_to_RDR_SetDataRateAndClockFrequency

5.4.1.3. CCID Error Codes

Extensive error codes are reported on many conditions during all CCID responses. Most of the error messages are reported by the CCID appropriately. Some of the main error codes for the contact interface are:

 HW_ERROR  XFR_PARITY_ERROR

SDI011 REFERENCE MANUAL 31

 BAD_ATR_TS  BAD_ATR_TCK  ICC_MUTE

The following sub-sections discuss when and why these error codes are returned:

5.4.1.3.1. HW_ERROR

This error code is returned when a hardware short circuit condition is detected, during application of power to the card or if any other internal hardware error is detected. This error code has been defined in the error code table 6.2-2 of the CCID specification.

5.4.1.3.2. XFR_PARITY_ERROR

This error code is returned when a parity error condition is detected. This error will be reported in the response to a PC_to_RDR_XfrBlock message. This error code has been defined in the error code table 6.2-2 of the CCID specification.

5.4.1.3.3. ICC_MUTE

This error code is returned when the card does not respond until the reader time out occurs. This error will be reported in the response to PC_to_RDR_XfrBlock message and PC_to_RDR_IccPowerOn messages. This error code has been defined in the error code table

6.2-2 of the CCID specification.

5.4.2. Automatic PPS for the contactless interface

Automatic PPS is implemented in SDI011‘s driver. This means that by default SDI011 switches to the maximum communication speed indicated by the card during its selection. Automatic PPS can be disabled using escape messages as explained later in this manual.

When Auto PPS is disabled (discussed in escape messages section) the reader works at the default baud rate of 106kbps. An escape command has been introduced in the driver to force the required baud rate.

The maximum speed supported by SDI011 is 424Kbps by default. Using escape messages as explained later in this manual it is possible to change this.

SDI011 REFERENCE MANUAL 32

CLA

INS

Data in

0xFF

0xCA

0x00

Data Out

UID + SW1 + SW2

SW1

SW2

Description

0x90

0x00

NO ERROR

0x62

0x82

End of UID reached before Le bytes (Le is greater than UID length)

0x6C

0xXX

Wrong Length. 0xXX is the exact value for Le

6. Commands description

6.1. Generic APDU

6.1.1. Get UID Command

6.1.1.1. Description

GET UID will retrieve the UID or SNR or PUPI of the user token. This command can be used for all supported technologies.

6.1.1.2. Format

Setting Le = 0x00 can be used to request the full UID or PUPI is sent back.(e.g. for ISO14443A single 4 bytes, double 7 bytes, triple 10 bytes, for ISO14443B 4 bytes PUPI).

6.1.1.3. Response

6.1.1.4. Status Words

Further error codes can be found in annex

SDI011 REFERENCE MANUAL 33

ISO14443-4A

ISO14443-4B

MIFARE 4K

MIFARE Ultralight

6.1.1.5. Examples

SDI011 REFERENCE MANUAL 34

CLA

INS

Data in

0xFF

0xCC

0x00

Input buffer of escape command

Type A passport

Type B passport

6.1.2. Escape command APDU

6.1.2.1. Description

This command can be used to send escape commands to SDI011. For description of escape commands please refer to the dedicated chapter in this manual.

6.1.2.2. Format

Lc is the length of the escape command‘s input buffer. See escape commands description later

in this manual

6.1.2.3. Response

Output buffer of the escape command

6.1.2.4. Example

To get the ATS or ATQB of the ISO14443-4 based user token, you can use this APDU to send the READER_CNTLESS_GET_ATS_ATQB (0x93) escape command

To get the reader status about support of 848Kbps, you can use this APDU to send the READER_CNTLESS_848KBPS (0x9D) escape command.

By default the SDI011 doesn‘t have 848Kbps enabled on its contactless interface, the following sequence

 Checks the status (0x00 as response, means 848Kbps is disabled)  Enables 848Kbps  Checks the status again and the answer 0x01 indicates 848Kbps is enabled

SDI011 REFERENCE MANUAL 35

CLA

INS

0xFF

0xB0

Address

MSB

Address

LSB

0xXX

Data Out

Data + SW1 + SW2

SW1

SW2

Description

0x90

0x00

NO ERROR

0x62

0x81

WARNING: part of the returned data may be corrupted

0x82

WARNING: end of file reached before Le bytes where read

0x67

0x00

Length incorrect

0x68

0x00

CLA byte incorrect

0x69

0x81

Command not supported

0x82

Security status not satisfied

0x86

Command not allowed

0x6A

0x81

Function not supported

0x82

File not found, addressed blocks or bytes do not exist

0x6B

0x00

Wrong P1, P2 parameters

0x6C

0xXX

Wrong Le, 0xXX is the correct value

6.2. Set of APDU for contactless storage user tokens

6.2.1. STORAGE_CARD_CMDS_READ_BINARY

6.2.1.1. Description

Using this APDU, application can read a memory block on user tokens based on technologies like MIFARE Classic 1K or 4K (block size 0x10 bytes) or MIFARE Ultra light (block size 0x04 bytes).

6.2.1.2. Format

Where:

 P2 indicates the block number from where to read  Le can be a short (maximum value 255) or extended (maximum value 65535). If

Le=0x00, then all the bytes until the end of the block are read (0x10 bytes for MIFARE Classic 1K or 4K cards and 0x04 bytes for MIFARE Ultra Light cards).

6.2.1.3. Response

6.2.1.4. Status words

SDI011 REFERENCE MANUAL 36

6.2.1.5. Example

For a MIFARE Classic 1K card which has the following memory content:

To read the seventh block, you have to issue the following command and get the following response:

SDI011 REFERENCE MANUAL 37

CLA

INS

Data in

0xFF

0xD6

Address

MSB

Address

LSB

0xXX

Data

Data Out

SW1 + SW2

SW1

SW2

Description

0x90

0x00

NO ERROR 0x69

0x81

Command not supported

0x64

0x00

State of the non-volatile memory unchanged

6.2.2. STORAGE_CARD_CMDS_WRITE_BINARY

6.2.2.1. Description

This APDU writes data to a memory address

6.2.2.2. Format

Where:

 P2 indicate the memory block number where data should be written  Lc=0x10 for MIFARE Classic 1K/4K. Lc=0x04 for MIFARE Ultralight

6.2.2.3. Response

6.2.2.4. Status Words

6.2.2.5. Example

For a MIFARE Classic Ultralight card which has the following memory content: Issuing the command

SDI011 REFERENCE MANUAL 38

Results into the following memory mapping

SDI011 REFERENCE MANUAL 39

CLA

INS

Data in

0xFF

0x82

0x00

Key Type

Key Length

Key value

Data Out

SW1 + SW2

SW1

SW2

Description

0x90

0x00

NO ERROR

0x69

0x83

Reader key not supported

0x85

Secured transmission not supported

0x87

Non volatile memory not available

0x88

Key number not valid

0x89

Key length not correct

6.2.3. STORAGE_CARD_CMDS_LOAD_KEYS

6.2.3.1. Description

Some type of user tokens like MIFARE Classic may require that an authentication happens before any data can be read or written. To perform this authentication, keys need to be loaded in the reader‘s memory using this command.

6.2.3.2. Format

Where P2 can have the following values (please refer to MIFARE documentation from NXP for further details on what is key A and Key B):

 0x60 to use the Key A  0x61 to use the Key B

6.2.3.3. Response

6.2.3.4. Status Words

SDI011 REFERENCE MANUAL 40

CLA

INS

Data in

0xFF

0x86

0x00

0x05

Data

Byte #

Value

Description

0x01

Version

Address MSB

Address LSB

0x60

Key A

0x61

Key B

Number of the key to be used for authentication

Data Out

SW1 + SW2

SW1

SW2

Description

0x90

0x00

NO ERROR 0x63

0x00

WARNING no further info

0x69

0x82

Security status not satisfied

0x84

Referenced key not usable

0x86

Key type not known

6.2.4. STORAGE_CARD_CMDS_AUTHENTICATE

6.2.4.1. Description

This command enables to perform authentication for user tokens based on MIFARE Classic 1K or 4K. Before this command can be successfully executed, the STORAGE_CARD_CMDS_LOAD_KEY command must have been executed.

6.2.4.2. Format

Where the data field is structured as follow

Information about memory structure of MIFARE Classic must be requested from NXP Semiconductors.

6.2.4.3. Response

6.2.4.4. Status Words

SDI011 REFERENCE MANUAL 41

6.2.4.5. Example

For a MIFARE Classic 1K card which has the following memory mapping:

Reading sector 0 or sector 1 of this card requires authentication with key A or key B. The following example:

 authenticates with key A of sector 1  reads block #6  authenticates against sector 3  reads block #E

SDI011 REFERENCE MANUAL 42

CLA

INS

Data in

0xFF

0xF0

0x00

Block#

Data

Byte #

Value

Description

0xC0

Increment

0xC1

Decrement

Block number

B2-B5

Value (LSB first)

Data Out

SW1 + SW2

SW1

SW2

Description

0x90

0x00

NO ERROR

0x67

0x00

Length incorrect

0x68

0x00

CLA byte incorrect

0x6A

0x81

Function not supported

0x6B

0x00

Wrong P1, P2 parameters

CLA

INS

Data in

0xFF

0xF0

0x00

0x1E

0x06

0xC0 0x1E 0x01 0x00 0x00 0x00

6.2.5. STORAGE_CARD_CMDS_VALUE_BLOCK

6.2.5.1. Description

This APDU is used to interact with MIFARE Classic e-purse applications. Please refer to MIFARE Classic documentation available from NXP Semiconductors for further details on MIFARE classic memory mapping and commands.

6.2.5.2. Format

Where P2 code the address of the block number addressed Where the data field is structured as follow

6.2.5.3. Response

6.2.5.4. Status Words

6.2.5.5. Example

The above APDU will increment the value in block number 0x1E of a MIFARE Classic-based user token by a value of 0x01.

SDI011 REFERENCE MANUAL 43

CLA

INS

Data

Data Out

PICC answer as defined in ISO/IEC 7816-4+ SW1 + SW2

SW1

SW2

Description

See ISO/IEC 7816-4

6.3. Set of APDU for ISO/IEC14443-4 user tokens

6.3.1. T=CL Command

Description

SDI011 can transfer directly ISO/IEC7816-4 APDU to the PICC. SDI011 supports user tokens that have both the MIFARE and T=CL partitions. Depending on

the APDU sent by the host, the reader switches to the corresponding mode (MIFARE or T=CL) automatically and the command is processed accordingly.

6.3.1.1. Format

Description of the APDU commands can be found in ISO/IEC 7816-4 specification.

6.3.1.2. Response

As defined in ISO/IEC 7816-4.

6.3.1.3. Status Words

As defined in ISO/IEC 7816-4.

6.3.1.4. Example

The following APDU sequence reads the first 256 bytes of the data group 1 as specified in ICAO LDS (logical data structure) for machine readable travel documents with open access. It first selects the issuer application using its AID (0xA0 0x00 0x00 0x02 0x47 0x10 0x01), then selects the DG1 file (0x01 0x01) and then does a read binary.

SDI011 REFERENCE MANUAL 44

CLA

INS

Data

0xFF

0xFE

0x00

Lraw_data

Raw_data

Data Out

PICC response data+ SW1 + SW2

SW1

SW2

Description

6.3.2. T=CL user command

Description

This command can be used to send raw data to the user token.

6.3.2.1. Format

6.3.2.2. Response

6.3.2.3. Status Words

User should refer to the status words defined by the PICC manufacturer for a description of the status words

6.3.2.4. Example

Let‘s consider the Select command defined in ISO7816-4. This command being ISO can be sent to the user token in 2 different ways:

 Using the T=CL command  Using the T=CL user command

Here are the 2 answers for the select command:

The T=CL command is nevertheless more useful for sending commands which are not defined in ISO7816.

SDI011 REFERENCE MANUAL 45

CLA

INS

Data

0xFF

0xDE

0x00

Lcommand

Command

Data Out

DESFire response data+ 9000 if the DESFire response data is of single byte DESFire response data if the DESFire response data is more than 1 byte

6.4. Set of APDU defined by SCM Microsystems

6.4.1. MIFARE DESFire Commands

Description

This command can be used to send commands to DESFire-based user tokens. For a description of DESFire commands please contact NXP Semiconductors.

6.4.1.1. Format

Response

SDI011 REFERENCE MANUAL 46

Escape command

Code

READER_GETCARDINFO

0x11

READER_LEDCONTROL

0x19

READER_CNTLESS_GET_MFRC_REV

0x92

READER_CNTLESS_GET_ATS_ATQB

0x93

READER_CNTLESS_GET_TYPE

0x94

READER_CNTLESS_SET_TYPE

0x95

READER_CNTLESS_RF_SWITCH

0x96

READER_CNTLESS_RAW_CFG

0x97

READER_CNTLESS_RAW_XMIT_EX

0xAE

READER_ CNTLESS_DISABLE_PPS

0x99

READER_SWITCH_RF_ON_OFF

0x9C

READER_CNTLESS_848KBPS

0x9D

READER_CNTLESS_BAUDRATE

0x9E

READER_CNTLESS_FORCE_BAUDRATE_PCSC_REV2

0xAD

READER_LEDCTRL_BY_FW

0xB2

6.5. Escape commands for the contactless interface

6.5.1. Sending escape commands to SDI011

A developer can use 2 methods to send escape commands to SDI011 to the contactless interface

 SCardControl method defined in PC/SC API  SCardTransmit method defined in PC/SC API in conjunction with the escape

command APDU defined earlier in this manual

6.5.2. Escape command codes

Escape commands can be used by an application to configure SDI011 to function in a mode that is not its default configured mode or to get specific information. To put the SDI011 back into its default mode, either the SDI011 has to be unplugged and plugged again or the application can send again the same escape command.

The following escape commands are supported by SDI011 for the contactless interface.

Sample code to send escape commands can be found in annex.

SDI011 REFERENCE MANUAL 47

Input buffer

0x11

Output buffer

Value

Description

0x01

Contactless card present

0xNN

Baud rate of card-reader communication

0xXY

X – Upper nibble indicates 0 - memory card 1 - T=CL card 2 - Dual mode card

Y – Lower nibble indicates 0 - Type A card 1 - Type B card

6.5.3. READER_GETCARDINFO

This escape command is used to get information about the card placed on the reader. The SDI011 returns an error if no card is placed on it.

The input buffer shall contain the escape command code

The output buffer contents are described below.

The Baud rate of card-reader communication 0xNN shall indicate a BYTE as follows

b1 – 212kbps supported (direction reader to card) b2 – 424kbps supported (direction reader to card) b3 – 848kbps supported (direction reader to card) b5 – 212kbps supported (direction card to reader) b6 – 424kbps supported (direction card to reader) b7 – 848kbps supported (direction card to reader) b8 – 1 – indicates same baud rate in both directions

0 – indicates different baud rates in opposite directions

For Example: If 0xNN = 0x77, the card supports all baud rates namely 106, 212, 424 and 848 kbps in both

directions. This card can be forced to work at different baud rates in the send and receive directions using the escape command READER_CNTLESS_FORCE_BAUDRATE_PCSC_REV2.

If 0xNN = 0xB3, the card supports 106, 212 and 424 kbps in both directions. This card can be made to work only at the same baud rate in the send and receive directions using the escape command READER_CNTLESS_FORCE_BAUDRATE_PCSC_REV2.

SDI011 REFERENCE MANUAL 48

Byte #

Value

Description

0xB2

Escape command code

B1 0x00

Disable LED control by FW

0x01

Enable LED control by FW

Output buffer

NULL

Byte #

Value

Description

0x19

Escape command code

0x00

LED number

B2 0x00

LED ON

0x01

LED OFF

Output buffer

NULL

Input buffer

0x92

6.5.4. READER_LED_CONTROL_BY_FW

This escape command may be used to enable or disable LED control by the firmware. The input buffer is

The output buffer is

6.5.5. READER_LEDCONTROL

This escape command is used to turn ON/OFF the LED. This escape command shall work only if LED control by firmware is disabled. The input buffer shall contain 3 bytes

The output buffer is

6.5.6. READER_CNTLESS_GET_MFRC_REV

This escape message retrieves the revision number of the RF ASIC MFRC531. The input buffer contains the escape command code

The output buffer contains the version of the MFRC531 ASIC.

SDI011 REFERENCE MANUAL 49

Input buffer

0x93

Input buffer

0x94

Value

Description

0x00

Type A

0x01

Type B

0x02

Type A + type B

Byte #

Value

Description

0x95

Escape command code

0x00

Type A

0x01

Type B

0x02

Type A + type B

Output buffer

NULL

6.5.7. READER_CNTLESS_GET_ATS_ATQB

This escape command enables the host to retrieve the ATS for Type A T= CL or the ATQB for Type B cards.

The input buffer contains the escape command code

The output buffer contains the ATS bytes or the ATQB bytes depending on the type of PICC placed on the reader.

6.5.8. READER_CNTLESS_GET_TYPE

This escape command retrieves the type of the card which SDI011 is configured to poll for. The input buffer shall contain the escape command code

The output buffer shall point to a BYTE buffer which will contain the type value coded as

6.5.9. READER_CNTLESS_SET_TYPE

This escape command configures the type of cards SDI011 will poll for. Using this command can improve the polling efficiency of SDI011 for applications where only

type A or only type B cards are expected. The default is Type A + type B (0x02). The input buffer shall contain 2 bytes

The output buffer is

SDI011 REFERENCE MANUAL 50

Byte #

Value

Description

0x96

Escape command code

0x00

Switch RF Field OFF

0x01

Switch RF Field ON

0xFF

Get current field state

Output buffer

NULL

Output buffer

Description

0x01

RF field is OFF

0x00

RF field is ON

Byte #

Value

Description

0x97

Escape Function code

0x00

Type A will be use for further transmissions in raw mode

0x01

Type B will be use for further transmissions in raw mode

Output buffer

NULL

6.5.10. READER_CNTLESS_RF_SWITCH

This escape command can be used to retrieve/set the RF state of SDI011. The default RF field state is ON. The input buffer shall contain 2 bytes

After the RF is turned off, to turn the RF ON again, card connect shall be done in direct mode. If B1 of the input buffer is 0x00 or 0x01 the output buffer is

If B1 of the input buffer is 0xFF, the output buffer is a BYTE buffer with 2 possible values

6.5.11. READER_CNTLESS_RAW_CFG

This escape command switches SDI011 to raw mode. When SDI011 is in raw mode it only polls for one type of contactless card. SDI011 is by default not in this mode and therefore READER_CNTLESS_RAW_XMIT_EX

would fail. The input buffer contains 2 bytes

The output buffer is

Once SDI011 is in raw mode commands can be sent using READER_CNTLESS_RAW_XMIT_EX escape command.

SDI011 REFERENCE MANUAL 51

Byte #

Value

Description

0xAE

Escape Function code

B1 Wait Time

B2 Is CRC required?

B3 No of bits per command

B4 Card Type 0 – Type A 1 – type B

B5 Command length

B6 - Bn

Command

Byte #

Value

Description

0x97

READER_CNTLESS_RAW_CONFIG code

0x01

Type B will be used

Byte #

Value

Description

0xAE

READER_CNTLESS_RAW_XMIT_EX code

0x03

FWI is set to 3

0x01

Enable CRC (CRC will be calculated by the RF front end of SDI011)

0x00

Number of bits to be sent in the command 0 – Entire byte will be sent

0x01

Type B

0x03

Command length in bytes

0x05

REQB command‘s anti-collision prefix byte

0x00

REQB command‘s application family

identifier

0x01

REQB command parameter with slot number set as 1

6.5.12. READER_CNTLESS_RAW_XMIT_EX

This escape command can only be executed by the firmware once SDI011 is put in raw mode using the READER_CNTLESS_RAW_CFG escape command.

This escape command can be used to send commands to smart card when SDI011 is in raw mode

The input buffer is

The output buffer contains the response to the command from the offset B6 onwards. The following example uses the raw mode to send a REQB command First, we have to switch the SDI011 into raw mode for type B communication

Then, we can send the following bytes to obtain the ATQB response of any type B user token in the field

SDI011 REFERENCE MANUAL 52

Byte #

Value

Description

0x99

Escape command code

B1 0x01

Disable Auto-PPS

0x00

Enable Auto-PPS

Output buffer

NULL

Byte #

Value

Description

0x9C

Escape command code

0x00

Switch RF Field OFF when contact card is present in the reader

0x01

Switch RF Field ON when contact card is present in the reader

0xFF

Get current field state when Contact smart card is present in the reader

6.5.13. READER_ CNTLESS_DISABLE_PPS

By default SDI011 does automatic PPS – i.e. it switches the RF communication speed to the highest possible supported by the card.

This escape command can be used to switch ON/OFF automatic PPS. When automatic PPS is OFF, then 106Kbps only is available.

The input buffer is

The output buffer is

6.5.14. READER_SWITCH_RF_ON_OFF

This escape command can be used to switch the RF field ON or OFF when a Contact smart card is inserted into the reader.

By default, the RF field is always in the ON state and when any contact smart card is inserted in the reader, the RF field is turned OFF.

The input buffer shall contain 2 bytes

After the RF is turned off, to turn the RF ON again, card connect shall be done in direct mode.

SDI011 REFERENCE MANUAL 53

Output buffer

NULL

Output buffer

Description

0x00

RF field is OFF

0x01

RF field is ON

Byte #

Value

Description

0x9D

Escape command code

0x00

Disable 848Kbps support

0x01

Enable 848Kbps support

0xFF

Get current status on 848Kbps support

Output buffer

NULL

Output buffer

Description

0x00

848Kbps is disabled

0x01

848Kbps is enabled

If B1 of the input buffer is 0x00 or 0x01 the output buffer is

If B1 of the input buffer is 0xFF, the output buffer is a BYTE buffer with 2 possible values

6.5.15. READER_CNTLESS_848KBPS

This escape command can be used to enable/disable 848kbps support by SDI011 as well as query whether 848kbps is currently enabled or disabled by SDI011.

The RF communication with a user token will only switch to 848Kbps provided the user token supports this baud rate and provided automatic PPS is ON.

The input buffer shall contain 2 bytes

If B1 of the input buffer is 0x00 or 0x01 then the output buffer is

If B1 of the input buffer is 0xFF, the output buffer is a BYTE buffer with following possible values

SDI011 REFERENCE MANUAL 54

Input buffer

0x9E

Output buffer

Description

0x00

106Kbps in both directions

0x01

106Kbps from PICC to PCD, 212Kbps from PCD to PICC

0x02

106Kbps from PICC to PCD, 424Kbps from PCD to PICC

0x03

106Kbps from PICC to PCD, 848Kbps from PCD to PICC

0x10

212Kbps from PICC to PCD, 106Kbps from PCD to PICC

0x11

212Kbps in both directions

0x12

212Kbps from PICC to PCD, 424Kbps from PCD to PICC

0x13

212Kbps from PICC to PCD, 848Kbps from PCD to PICC

0x20

424Kbps from PICC to PCD, 106Kbps from PCD to PICC

0x21

424Kbps from PICC to PCD, 212Kbps from PCD to PICC

0x22

424Kbps in both directions

0x23

424Kbps from PICC to PCD, 848Kbps from PCD to PICC

0x30

848Kbps from PICC to PCD, 106Kbps from PCD to PICC

0x31

848Kbps from PICC to PCD, 212Kbps from PCD to PICC

0x32

848Kbps from PICC to PCD, 424Kbps from PCD to PICC

0x33

848Kbps in both directions

6.5.16. READER_CNTLESS_BAUDRATE

This escape command can be used to get the actual operating baud rate of card-reader communication.

The input buffer shall contain the escape message value.

The output buffer shall point to a BYTE buffer with following possible values

SDI011 REFERENCE MANUAL 55

Byte #

Value

Description

0xAD

Escape command code

0x00

Apply the baud rate specified by the card

0x01

Force baud rate specified in B2

B2 b0- DR=2 supported, if bit is set to 1 b1- DR=4 supported, if bit is set to 1 b2- DR=8 supported, if bit is set to 1 b3- shall be set to 0, 1 is RFU b4- DS=2 supported, if bit is set to 1 b5- DS=4 supported, if bit is set to 1 b6- DS=8 supported, if bit is set to 1 b7- 1 if the same D is required for

both communication directions b8- 0 if different D is supported for

each communication direction

Encoding of the baud rate to be forced if B1 value is 0x01. No need to send this byte in case B1 has the value =x00

NULL

If B1=0x00

Output buffer

NULL

6.5.17. READER_CNTLESS_FORCE_BAUDRATE_PCSC_REV2

This escape command can be used to force baud rate for Contactless cards. The input buffer is

The output buffer is

SDI011 REFERENCE MANUAL 56

Escape command

Code

READER_SETMODE

0x01

READER_GETMODE

0x02

READER_APDU_TRANSFER

0x08

READER_SWITCH_SPEED

0x0A

READER_SWITCH_PROTOCOL

0x0C

READER_DISABLE_PPS

0x0F

READER_GETIFDTYPE

0x12

READER_GETINFO_EXTENDED

0X1E

Byte #

Value

Description

0x01

Escape command code

0x00

ISO 7816 mode

0x01

EMV mode

0x02

Memory card mode

Output buffer

NULL

6.6. Escape commands for the contact interface

6.6.1. Sending escape commands to SDI011

A developer can use the following method to send escape commands to SDI011 for the contact interface

 SCardControl method defined in PC/SC API

6.6.2. Escape command codes

The following escape commands are supported by SDI011 for the contact interface

6.6.3. READER_SETMODE

This escape command may be used to set the mode of the reader. Applications may call this function, to set the desired mode. Typically, this call is used to switch between the EMV, ISO7816 and the memory card modes of operation.

The input buffer is

The output buffer is

SDI011 REFERENCE MANUAL 57

Byte #

Value

Description

0x02

Escape command code

Output buffer

Description

0x00

ISO 7816 mode

0x01

EMV mode

0x02

Memory card mode

Byte #

Value

Description

0x08

Escape command code

B1- Bn

Command APDU

6.6.4. READER_GETMODE

This escape command may be used to retrieve the current mode of the reader.

The input buffer is

The output buffer is

6.6.5. READER_APDU_TRANSFER

This escape command may be used to exchange an APDU with the smart card.

The input buffer is

The output buffer contains the response APDU.

The maximum number of bytes that can be transmitted and received is given below. Transmit: Case 1,2,3 APDU: Max of 256 bytes per APDU Case 4 APDU: Max of 255 bytes per APDU

Receive: Max of 259 bytes per APDU

SDI011 REFERENCE MANUAL 58

Byte #

Value

Description

0x0A

Escape command code

B1 Fi value

B2 Di value

Output buffer

NULL

Byte #

Value

Description

0x0C

Escape command code

B1 0x00

T0_PROTOCOL

0X01

T1_PROTOCOL

Output buffer

NULL

6.6.6. READER_SWITCH_SPEED

In case, when the application is capable of switching the card‘s speed through APDU (if the card supports such a feature), this escape command is used to inform the reader about the speed change occurred between application and card. The first byte will contain the escape function value; the next two bytes contain Fi and Di respectively. The output buffer field shall be NULL.

The input buffer is

The output buffer is

6.6.7. READER_SWITCH_PROTOCOL

In case, when the application is capable of switching the card‘s protocol through APDU (if the card support such a feature), this escape command is used to inform the reader about the protocol change occurred between application and card.

The input buffer is

The output buffer is

SDI011 REFERENCE MANUAL 59

Byte #

Value

Description

0x0F

Escape command code

B1 0x00

Enable PPS

0X01

Disable PPS

Output buffer

NULL

Byte #

Value

Description

0x12

Escape command code

6.6.8. READER_DISABLE_PPS

This escape command disables the automatic PPS done by the firmware.

The input buffer is

The output buffer is

6.6.9. READER_GETIFDTYPE

This escape command is used to get the current IFD type from the reader. The first byte of the input buffer contains the escape id value. The reader gets the value from the reader capability structure, which is implemented in the reader as a configurable item. The output buffer shall point to a WORD buffer. The IFD type of SDI011-Generic is 0x010E,

The input buffer is

SDI011 REFERENCE MANUAL 60

Byte #

Value

Description

0x1E

Escape command code

6.6.10. READER_GETINFO_EXTENDED

This escape command is used to get the information of the reader like the major and minor version of the firmware, capabilities of the reader and the Unicode serial number. The output buffer shall point to an application allocated SCARD_READER_GETINFO_PARAMS_EX structure mentioned below.

The input buffer is

typedef struct __SCARD_READER_GETINFO_PARAMS_EX { OUT BYTE byMajorVersion; OUT BYTE byMinorVersion; OUT BYTE bySupportedModes; // 0 – ISO7816, 1 – EMV, 2 – Memory card OUT WORD wSupportedProtocols; // 1 – T=0; 2 - T=1; 3 – T=0 & T=1 OUT WORD winputDevice; OUT BYTE byPersonality; OUT BYTE byMaxSlots; OUT BYTE bySerialNoLength; OUT BYTE[28] bySerialNumber; }SCARD_READER_GETINFO_PARAMS_EX, *PSCARD_READER_GETINFO_PARAMS_EX;

SDI011 REFERENCE MANUAL 61

SW1

SW2

Description

0x90

0x00

NO ERROR

0x67

0x00

LENGTH INCORRECT

0x6D

0x00

INVALID INSTRUCTION BYTE

0x6E

0x00

CLASS NOT SUPPORTED

0x6F

0x00

UNKNOWN COMMAND

0x63

0x00

NO INFORMATION GIVEN

0x65

0x81

MEMORY FAILURE

0x68

0x00

CLASS BYTE INCORRECT

0x69

0x82

Command not allowed, security status not satisfied

0x6A

0x81

FUNCTION NOT SUPPORTED

0x6B

0x00

WRONG PARAMETER P1-P2

7. Annexes

7.1. Annex A – Status words table

SDI011 REFERENCE MANUAL 62

7.2. Annex B – Sample code using escape commands through Escape IOCTL

File Name : T_hbr.H

#ifdef __cplusplus

extern "C" {

#endif

#define IOCTL_CCID_ESCAPE SCARD_CTL_CODE (0xDAC)

#define CCID_GET_848KBPS_STATUS 0xFF9D

#define CCID_SET_848KBPS_ON 0x019D

#define CCID_SET_848KBPS_OFF 0x009D

#define MINTIMEOUT 300

#ifdef __cplusplus

}

#endif

File Name : T_hbr.CPP

#include <windows.h>

#include <winbase.h>

#include <stdio.h>

#include <conio.h>

#include "winscard.h"

#include "winerror.h"

#include "T_hbr.H"

VOID main(VOID)

{

SCARDCONTEXT ContextHandle;

SCARDHANDLE CardHandle;

BYTE OutByte;

WORD InWord,i;

DWORD ActiveProtocol; /* ICC protocol */

ULONG InBufLen,ResLen;

ULONG ret;

SDI011 REFERENCE MANUAL 63

SCARD_READERSTATE Reader[1];

// please add the name of the used reader here or use SCardListReaders

// to find the right reader name

char *ReaderName[] = {"SCM Microsystems Inc. SDI011 Contactless Reader 0",

NULL};

/*************************************************************************************** *****************/

ContextHandle = -1;

ret = SCardEstablishContext(SCARD_SCOPE_USER, NULL, NULL, &ContextHandle);

if (ret == SCARD_S_SUCCESS)

{

ret = SCardConnect( ContextHandle,

ReaderName[0],

SCARD_SHARE_SHARED,

SCARD_PROTOCOL_T0 | SCARD_PROTOCOL_T1,

&CardHandle,

&ActiveProtocol);

if (ret == SCARD_S_SUCCESS)

{

/* get actual 848kbps status: ON/OFF */

InBufLen = 2;

InWord = CCID_GET_848KBPS_STATUS;

ret = SCardControl (CardHandle,

IOCTL_CCID_ESCAPE,

&InWord,

InBufLen,

&OutByte,

&ResLen);

printf ("\n Get 848kbps status: %lx: %.2x", ret,OutByte);

Reader[0].dwCurrentState = SCARD_STATE_UNAWARE;

Reader[0].dwEventState = SCARD_STATE_UNAWARE;

Reader[0].szReader = ReaderName[0];

ret = SCardGetStatusChange( ContextHandle,

SDI011 REFERENCE MANUAL 64

MINTIMEOUT,

Reader,

1);

printf ("\nATR: ");

for (i=0; i<Reader->cbAtr; i++)

{

printf ("%.2x ",Reader->rgbAtr[i]);

}

printf ("\n----------------------------------------------\n");

/* enable 848KBPS: ON */

printf ("\nEnable 848kbps ");

InBufLen = 2;

InWord = CCID_SET_848KBPS_ON;

ret = SCardControl (CardHandle,

IOCTL_CCID_ESCAPE,

&InWord,

InBufLen,

&OutByte,

&ResLen);

ret = SCardDisconnect(CardHandle, SCARD_RESET_CARD);

ret = SCardConnect (ContextHandle,

ReaderName[0],

SCARD_SHARE_SHARED,

SCARD_PROTOCOL_T0 | SCARD_PROTOCOL_T1,

&CardHandle,

&ActiveProtocol);

/* get actual 848KBPS status: ON/OFF */

InBufLen = 2;

InWord = CCID_GET_848KBPS_STATUS;

ret = SCardControl (CardHandle,

IOCTL_CCID_ESCAPE,

&InWord,

InBufLen,

&OutByte,

&ResLen);

SDI011 REFERENCE MANUAL 65

printf ("\n Get 848kbps status: %lx: %.2x", ret,OutByte);

Reader[0].dwCurrentState = SCARD_STATE_UNAWARE;

Reader[0].dwEventState = SCARD_STATE_UNAWARE;

Reader[0].szReader = ReaderName[0];

ret = SCardGetStatusChange (ContextHandle,

MINTIMEOUT,

Reader,

1);

printf ("\nATR: ");

for (i=0; i<Reader->cbAtr; i++)

{

printf ("%.2x ",Reader->rgbAtr[i]);

}

printf ("\n----------------------------------------------\n");

/* Disable 848Kbps: OFF */

printf ("\nDisable 848KBPS ");

InBufLen = 2;

InWord = CCID_SET_848KBPS_OFF;

ret = SCardControl(CardHandle, IOCTL_CCID_ESCAPE,

&InWord, InBufLen,

&OutByte, 1, &ResLen);

ret = SCardDisconnect(CardHandle, SCARD_RESET_CARD);

ret = SCardConnect(ContextHandle,

ReaderName[0],

SCARD_SHARE_SHARED,

SCARD_PROTOCOL_T0 | SCARD_PROTOCOL_T1,

&CardHandle,

&ActiveProtocol);

/* get actual 848KBPS status: ON/OFF */

InBufLen = 2;

InWord = CCID_GET_848KBPS_STATUS;

ret = SCardControl(CardHandle, IOCTL_CCID_ESCAPE,

&InWord, InBufLen,

&OutByte, 1, &ResLen);

printf ("\n Get 848KBPS status: %lx: %.2x", ret,OutByte);

Reader[0].dwCurrentState = SCARD_STATE_UNAWARE;

Reader[0].dwEventState = SCARD_STATE_UNAWARE;

SDI011 REFERENCE MANUAL 66

Reader[0].szReader = ReaderName[0];

ret = SCardGetStatusChange(ContextHandle, MINTIMEOUT, Reader, 1);

printf ("\nATR: ");

for (i=0; i<Reader->cbAtr; i++)

{

printf ("%.2x ",Reader->rgbAtr[i]);

}

printf ("\n----------------------------------------------\n");

ret = SCardDisconnect(CardHandle, SCARD_RESET_CARD);

}

else

{

printf("\n SCardConnect failed with 0x%.8lX",ret);

}

ret = SCardReleaseContext(ContextHandle);

}

else

{

printf("\n SCardEstablishContext failed with %.8lX",ret);

}

printf("\npress any key to close the test tool\n");

getch();

}

SDI011 REFERENCE MANUAL 67

CLA Byte

Function

0xF0

Contact Memory cards

0xFF

MIFARE-TCL Switching

T=CL User command

Escape command APDU

Function

CLA byte – PC/SC1.0

CLA byte – PC/SC2.0

T=CL User Command APDU

0xFC

0xFF

MIFARE DESFire APDU

0xFC

0xFF

Escape Command APDU

0xFD

0xFF

7.3. Annex C - SCM Proprietary CLA bytes

The second SCM Proprietary APDU is blocked for the application layer. This is used for internal communication i.e. between the driver and the firmware.

In order to maintain compatibility with some customer applications which use the CLA bytes of PC/SC 1.0 architecture, the following switching mechanism can be used.

Option1: Use the CLA byte of PC/SC1.0 architecture Option2: Use the CLA byte of PC/SC2.0 architecture

The above two options can be controlled by

 Configuring the firmware  INF/registry entry  Vendor IOCTL.

By default, option #2 is set in the firmware binary.

The entry System\CurrentControlSet\Services\SCM\ProprietaryAPDUOption is kept disabled in the INF by default. Enabling this key and setting this entry to 0 will override the firmware setting with option #1. Enabling this key and setting this entry to 1 will override the firmware setting with option #2.

Vendor IOCTL_SWITCH_PROPRIETARY_APDU_OPTION (0x856) can also be used to switch between the two options. Input buffer with value 0x00 will switch to option#1 and input buffer with value 0x01 will switch to option#2.

SDI011 REFERENCE MANUAL 68

7.4. Annex D – Mechanical drawings

7.4.1. Top Casing

SDI011 REFERENCE MANUAL 69

7.4.2. Bottom Casing

SDI011 REFERENCE MANUAL 70

7.4.3. Stand
