iDect K1 User Manual

Page 1

Digital cordless telephone

User Guide

with Caller Display and SMS Messaging

Before you use this phone system, please read this User Guide carefully

This equipment is not designed for making emergency calls when there’s an electrical power failure. You should make alternative arrangements for dialling emergency services when necessary.

Color profile: Generic CMYK printer profile Composite Default screen

Ver 1, Aug 06 (BTP)

and hands-free Speakerphone

Page 2

Important note — emergency calls

The iDECT K1 is not designed for making emergency calls if the mains power fails. So you should make alternative arrangements for access to Emergency Services.

(This means that you should also have a basic phone, that does not need mains power, connected to your line so that you can make calls during a power failure.)

If you need help …

The Help Line is available from 9.00 am to 5.00 pm, Monday to Friday, on

0845 345 9677

Calls are charged at Local Call rate.

Unpacking your iDECT K1 system

In the box are:

■ the cordless handset (up to five, depending on

which iDECT K1 system you’ve bought)

■

the base unit

■

two batteries and a battery compartment cover for each handset

■

a telephone line cable for the base unit

■

a mains power lead and adapter for the base unit

■

up to four charger pods, each with a separate mains power lead and adapter, for multi-handset systems

Keep the packaging materials in a safe place in case you later need to transport the unit. Keep

your sales (till) receipt, which is your guarantee. Before you can use the handset to make calls

you’ll need to fit and fully charge the batteries, as described on page 8. Please read the notes on page 9 before you install the base unit.

Color profile: Generic CMYK printer profile Composite Default screen

Page 3

PHONE /SPEAKERPHONE button

Press to begin, answer or end a phone call. Press during a call to switch the speakerphone on and off.

(Note: the speakerphone wont work if the batteries are low.)

HANDSET LOCATOR (PAGE) button

Press to make all registered handsets ring (this is useful if you've forgotten where you

Where to find it

Charger LED

This comes on when you the handset's batteries are being charged.

Left and right Soft buttons

Press to select the functions shown above them on the display (for example,

Redial or Menu.)

#/R (Recall) button

You may need the Recall function during a call if your iDECT K1 is connected to a PBX, or if you use BT’s Select Services.

HANG UP /ON–OFF / X (Cancel) button

Press to end a call. Press while using menus to cancel and return to idle mode. Press and hold for 4 seconds to turn the handset on and off.

Arrow buttons

Press or during a call to adjust the volume in the earpiece. Press to navigate through the menu on the display.

Press in idle mode for short-cut functions

/INT (Intercom) button

Press and hold for 1 second to make an intercom call (if you have more than one handset).

To subscribe to network features like Caller Display and Call Waiting, simply call your network service provider (the company that supplies your line). You dont need to do anything special on your iDECT K1 phone to set these features up.

If the display is blank

Press the button to switch

the handset on

Color profile: Generic CMYK printer profile Composite Default screen

IN USE light

This comes on when you have a connection to the telephone line, and flashes when the unit is ringing for an incoming call.

put a handset).

—

to go straight to the

menu.

SMS text

messages

to go straight to a list of

(CID) records.

Caller

Display

to go straight to a list of

entries.

Phone

Book

Short cuts

1 NEW SMS

2 NEW CALLS

05/02 16:12

Page 4

Help Line: 0845 345 9677 (Local Call rate) 1

JANE 1

When this shows ‘nearly empty’ ( ), put the handset on the base unit orchargerpod as soon as possible, to charge the batteries. While the batteries are being charged, the symbol blinks.

Appears when you have a connection to the outside line. Flashes when there’s an incoming call to be answered (even if the ringer is turned off).

Appears when the speakerphone is turned on.

Symbols on the display

The handset’s number (if you have more than one handset on your iDECT K1 system)

The handset’s name

The time and date

Intercom call

Handset ringer off

Flashes while your handset is ringing for an intercom call, and comes on steadily when the call’s connected.

While an incoming ring, handset rings in silence, see page 36 to change ringer volume.

Signal level

This is on steadily when there’s a radio link between the handset and base unit. lasheswhile the handset is trying to establish a link .

It f

to the base unit

If this symbol flashes while you’re on a call, move closer to the base unit

Battery charge level

Phone

Speakerphone

New call

Appears when you have missed incoming calls or new SMS (if you subscribe to Caller Display or SMS).

What the symbols mean

The duration of each call is shown on the display from 5 seconds after you press the PHONE button for a line, until 10 seconds after you end the call.

Color profile: Generic CMYK printer profile Composite Default screen

05/02 16:30

Page 5

Contents

Read these notes first 6

Choosing a site for the base unit and charger pod 6

Radio signals between handset and base unit 6

Mains power connection 6

Installation and set-up 7 Before you start 9

Electrical safety 9 Interference 9 ‘Out of range’ warning 9

Switching on and off 10 Making and answering calls 11

Using the speakerphone 11 To make a call 11 To answer a call 11 To end a call 11 Earpiece volume 12 To mute the mouthpiece 12 Last Number Redial (LNR) 12

To delete a number in Redial list To store a Redial number in

Phone Book 13

The Phone Book (memory dialling) 14

To store a number 14 To call a stored number 15 To edit a Phone Book entry 15 To delete a Phone Book entry 16 To delete all Phone Book entries 16

Caller Display 17

To check Caller Display records 18 To return a call 18 To store a Caller Display number in

the Phone Book 18 To delete a Caller Display record 19

Contents

Help Line: 0845 345 9677 (Local Call rate) 3

Handset settings 41

Auto answer

Base unit settings 44 Base unit PIN 44

Troubleshooting 47 Cleaning and care 53 Guarantee and service 54 Technical details 55

Connection and conditions for use

You can connect your iDECT K1 to a direct exchange line (DEL) — a line connected to a local exchange, with its own phone number; to an extension socket connected to a DEL; or to an extension on an approved compatible PBX. Do not connect the iDECT K1 as an extension to a payphone.

The ringer equivalence numbers (RENs) of all instruments (phones, fax machines, etc.) connected to an exchange line must not add up to more than 4 — otherwise, one or more of them may not ring and/or answer calls correctly. The iDECT K1 has a REN of 1, and most other telephones have a REN of 1 unless marked otherwise.

Color profile: Generic CMYK printer profile Composite Default screen

To copy the Phone Book between handset(s) 16

To delete all Caller Display record 19

Using a multi-handset system 29

To make an intercom call 29 To answer an intercom call 30 To end an intercom call 30 To transfer a call 30 To shuttle between two calls 31 To set up a three-way conference 31 New Call tone 32 To page all handsets from the

base unit 32

Handset registration 34

To register a new handset to your base unit 34

To de-register a handset 35 To register to a different brand of

base unit 35

SMS text messaging — read this first 20

Caller Display 20 Registering for the SMS service 20 The SMS Send and Receive numbers

SMS message boxes 22 SMS text messaging 23

To write and send a text message 23 To read your messages 25 To reply to a message 27 To delete a message from the Outbox or Drafts Box 27 To check or change the Send and Receive numbers 28

To select a base unit 33

To change dial mode 45 Date and time 45 To change the flash time 46

Sound settings 36

Handset ringer 36 Base ringer 37 Internal ring 37 Tone setting 39 iSleep 39

To change the handset name 41 Display language 42 To adjust display contrast 42 Returning to the default settings 43

Page 6

Menu Structure

iDECT K1 Menu Structure

Key Tone

Volume

Melody

Timer finish

Level 1~5

Level off, 1~3

Once

Daily

Batter

Low

Out of Range

Volume

iSleep Of

BS Ring

Tone

Timer Start

Timer finish

Timer Start

Charge Tone

Melody 1~10Melody

Sound Setting Handset Volume

HS Ring

Internal Ring Melody Melody 1~20

Volume

Delete Entry

PB Transfer

Delete All

Earpiece

Speaker

Level off, 1~5

Melody 1~20

List End Tone

Phonebook New Entry

View Entry

Edit Entry

Scroll with navigation

button

Default HS Confirm

Contrast Level 1~3

Enter PIN

Base Auto 1--

Handset Set Auto Answer

Select Base

Language

Handset Name IDECT

Base 1 2 3 4

Long

Pause Time 0S~4S

Pulse

Flash Time Short

Medium

Date & Time

hh:mm DD-MM-Y

Default BS Confirm

Dial Mode DTMF

Base Set Change PIN

Enter PIN

Remove HS

Unregistered 1--

SMS Center2

Terminal Nr

Draft SMS Screen

SMS Screen

Delete All

Info/Status

Service Center SMS Center 1

Send SMS

Call

Save SMS

Delete

Delete All

Outbox SMS screen Edit SMS

Edit SMS

Send SMS

Save to P.Book

Call

Delete

Delete All

Forward

Use Text

Edit Screen Number

Send SMS

Save SMS

Delete

Delete All

SMS Write

Inbox

Call Log Save to P.Book

Help Line: 0845 345 9677

(Local Call rate)

Enter new PIN

Enter PIN

Page 7

Read these notes first

Choosing a site for the base unit and charger pod

The base unit and charger pod(s) should be placed on a level surface, in a position where:

■

the mains adapter plug will reach an easily accessible 230-V

AC switched mains supply socket — never try

to lengthen the mains power cable

■

the base unit’s telephone line cable will reach your telephone line socket or extension socket (the charger pod does not have a telephone line connection)

■

it is not close to another telephone — this can cause radio interference

■

it is not close to a sink, bath or shower, or anywhere else where it might get wet

■

it is not close to other electrical equipment — fridges, washing machines, microwave ovens, fluorescent lights, TVs etc.

Radio signals between handset and base unit

To use your handset and base unit together, you must be able to establish a radio link between them. Be aware that:

■ Any large metal object — like a refrigerator, a mirror

or a filing cabinet — between the handset and the base unit may block the radio signal.

■

Other solid structures, like walls, may reduce the signal strength.

Mains power connection

IMPORTANT — The iDECT K1 base unit and charger pod must be used with the mains adapter supplied with the unit. Using any other adapter will result in noncompliance with EN60950, and will invalidate any approval given to this apparatus.

Make sure mains power to the base unit stays switched on. The iDECT K1 needs electrical power for normal operation; not just for charging the batteries.

Installation and set-up

Help Line: 0845 345 9677 (Local Call rate) 7

Choose a suitable site for the base unit

Plug the mains adapter into a 230 V AC, 50 Hz mains socket, with the switch on the socket set to OFF

Switch on at the mains socket(s)

If you have one or more charger pods …

Use the telephone line iDECT K1 —

do not use any other telephone line cord

cord supplied with your

Connect the mains power lead and the telephone line cord into the underside of the base unit

Installation and set-up

Page 8

Fit two rechargeable batteries in each handset

Help Line: 0845 345 9677 (Local Call rate) 9

Charge the batteries for 15 hours

Before you use the handset for the first time, it’s important to charge the batteries fully.

The handset ‘beeps’ when it’s correctly in position on the charging cradle.

Leave the handset on the charging cradle for 15 hours.

Make sure the mains socket is switched on if you want to use the phone — it will not work without electrical power

Connect the base unit to the telephone line

Switch off power at the mains socket Insert the telephone line plug into

the socket as shown Switch mains power back on

Use the plug to raise the shutter before pushing it into the socket

NOTE: the charger pod does not have a connection to the telephone line.

The navigation buttons

In the instructions, these buttons are represented by arrows, as shown here.

SMS text messages

(CID)

Caller

Display

Phone

Book

Before you start

Electrical safety

■

DON’T let the base unit or charger pod get wet. Electrical equipment can cause serious injury if used while you are wet or standing in water.

■

If the base unit or charger pod ever falls into water, DON’T retrieve it until you have unplugged the power lead from the mains and the telephone line plug from the telephone socket (base unit only); then pull it out by the unplugged cables.

■

NEVER use your iDECT K1 outdoors during a thunder

storm — unplug the base unit from the telephone line and the mains socket when there are storms in your area. Damage caused by lightning is not covered by the guarantee.

Interference If the sound quality gets worse as you move around

while on a call, this is probably caused by interference between the handset and the base unit, perhaps because you are too near to another phone or other electrical equipment.

Move to a different position to clear the interference. If you do not move, your call may be cut off.

Radio interference in the environment may occasion

ally cause a short break in the link between the handset and the base unit while you are on a call. The ‘signal level’ on symbol handset’s display may flash until the link is restored.

‘Out of range’

warning

If you hear a warning tone during a call, and/or the sound in the earpiece becomes faint or distorted, you may be going out of range of the base unit. Move nearer to the base unit within 20 seconds, until the tone stops. Otherwise, your call may be cut off.

Page 9

Switching on and off

To switch the handset on and off

To switch the handset off (in case you need to save battery power when the handset is away from the base unit):

◗

Press the HANG UP button and hold it for 4 seconds

To switch the handset back on:

◗

Briefly press the HANG UP button, or replace the handset on the base unit or

Notes

■

When the handset is switched off, it can’t be used for making calls, including emergency calls.

■

When the handset is switched off, it won’t ring for incoming calls, but the base unit will ring. To answer a call when the handset is switched off, you need to switch it back on. It may take a few moments for the handset to re-establish a radio link with the base unit.

Help Line: 0845 345 9677 (Local Call rate) 11

charger pod

Making and answering calls

Using the speakerphone

You can switch between speakerphone and

earpiece mode during calls at any time by

button. The display will show if speaker on.

To make a call

Key in the telephone number

If you make a mistake, press the soft key

<=I

to clear digits one by one from the display.

Press the button

(You can dial the number after you press the

button to get Dial tone if you prefer,

but you can’t correct any mistakes if you do it this way. If you press the button before

you dial, the display shows [calling]

To answer a call

When there's an incoming call,

◗

Press to answer the call

To end a call

◗

Press the button

The

IN USE

light on the base unit will goes out

◗

Or just replace the handset on the base unit

Press the á or â button to adjust volum when speaker is on, there are three volume levels.

The speakerphone won't work if the battery is low.

Or you can press right soft key

Silence

make handset silence, if you don't want to

◗

answer the call.

Page 10

Earpiece volume

During a call, to adjust the volume in the earpiece or speakerphone:

◗

Press the á or â button

There are three volume levels. After you end the call, the volume will stay at the level you’ve set.

To mute the mouthpiece

During a call, to mute the mouthpiece so the person on the other end can’t hear you:

◗

Press the soft key

To un-mute the mouthpiece, press the soft key

again.

Last Number Redial (LNR)

To make a repeat call to one of the last 10 numbers you dialled (up to 24 digits) :

1 Press the right soft key

2 Press the á or â button if necessary until

the number is displayed

3 Press the button to dial the number

To delete Redial list

1 Press the right soft key , then the á or â

button until the number is displayed

2 Press the soft key Option

The display shows [Delete] and [Delete All] [Delete] only delete selected redial number , [

Delete All] will delete all redial list.

3 Press soft key OK to confirm what you selected

Making and answering calls

Help Line: 0845 345 9677 (Local Call rate) 13

To store a Redial number in the Phone Book

Press the Redial button, then the á or â button until the number is displayed

Press

Option

button

The display shows [

Save to P.Book

]

Key in a name then press

4 The display show [

enter Number

], you

can edit the number then press

Select the [

VIP Tone

] press OK to confirm

Making and answering calls

There are 20 melodies [

Melody 1

]

to [

Melody 20

]

Buttons to press for text characters — press the button repeatedly until you get the character you want

PQRS7ß

ABC2ДавВЖЗ

TUV8ÜÙúû

DEF3ëéèê

WXYZ9

GHI4Ìíîï

JKL5

MNO6ЦтуфШС

upper case/lower case

-/ \

=<>()

,.:

;

[space] 1

@&$¥£§#

Page 11

The Phone Book (memory dialling)

You can store up to 200 numbers in the Phone Book. Each number can have up to 24 digits, and can be stored with a name of up to 12 characters (including spaces).

To store a number

1 Press the Menu button then press OK 2 Press the Option button 3 Select [New Entry ] then press OK

4 Key in a name and press OK

5 Key in a number and press OK

The display shows [

Enter Number]

6 Select ring tone [Melody1-Melody20]

and press

OK to confirm.

* This is a short-cut method. You can also press the

Phone Book button followed by the MENU button. Or you can simply press of .

** Refer to the diagram on page 13 if you’re not sure how to

key in text using the numbered keypad.

*** If you use Caller Display, it’s best to store the number with

the full national dialling code, even if it’s a local number. You’ll still be charged at Local rate when you call the number

The display shows [

Enter Name

]

Press button to go back standby mode

To call a stored number

The display shows the name and number

in the Phone Book.

Press the á or â button to go to the number you want OR you can search by pressing a button on the

numeric keypad for the first letter of the name, then using the á and â buttons if necessary.

Press the button to dial the number

To edit a Phone Book entry

â button to go to the number you want

Press

Option

then use â button to

select [

Edit Entry

]

PressOKbutton

The display shows [

Enter Name

[

Enter Number

] & [

Tone

] section.

4 Edit the name , number or Tone and

Press to go back standby mode

Press the

then OK buttton

Press the

then OK buttton

pressOK to confirm

The Phone Book (memory dialling)

Help Line: 0845 345 9677

(Local Call rate)

Page 12

The Phone Book (memory dialling)

To delete a Phone Book entry

1 Press the Menu then OK buttton 2 Press or to go to the number you want

3 Press Option button 4 Use or to select [Delete Entry

]

5 Press OK to confirm

To delete all Phone Book entries

3 Use

to select [Delete All]

4 Press OK button

The display shows [

Delete All?]

Press OK to confirm

Help Line: 0845 345 9677 (Local Call rate) 17

Press the

then OK buttton

Press

Option

button

Caller Display

To subscribe to this feature, you need to contact your service provider, who will tell how much it will cost.

Caller Display lets you see the phone numbers of your callers on the handset’s display, before you answer. The iDECT K1 will store the numbers of the last 30 callers (whether or not you answered the call) so you can call them back later. When the Caller Display list is full, the next incoming number will overwrite the oldest one.

If you’ve got new Caller Display records, the symbol is shown on the display.

The record number is onwards.#01

Here are some examples of Caller Display records:

A call from someone whose name and number are stored in your Phone Book.

indicates that you’ve received two calls from this number (the one shown is the most recent).

A call from someone whose name and number are not stored in your Phone Book.

There has been just one call from this number ( )

A call from someone who withheld their number by dialling 141 (or whose service provider withheld their number).

A call from someone whose number is unavailable (for example, an international call).

#01 NEW <02>

Option

Esc

Jane 02084329876 05/02 16:12

#01 NEW <02>

Option

Esc

02084329876 05/02 16:12

#01 NEW <02>

Option

Esc

WITHHELD 05/02 16:12

#01 NEW <02>

Option

Esc

UNAVAILABLE 05/02 16:12

To copy the Phone Book between

Press the

then OK buttton

handsets

If you have more handsets system, when you have stored names and numbers in one handset's Phone Book, you can copy them to other handsets.

Use

to select [

PB Transfer

] then press OK

The display shows other handsets which you

have registered.

Press

Option

button

Use or to select handset you want, then press OK

The handset you selected rings, press the

left soft key [

] to accept copying, or the

right soft key [

Reject

] to cancel copying.

After copying the phonebook, the display shows

[

Finish

] and goes back to idle mode.

èèè

Page 13

To check Caller Display records

Press to go to [Call Log ] menu

3 Press OK button to view the record(s)

4 Press button to go back to

standby mode

To return a call

To ring back someone who’s called you:

4 Press or go to the number you want

5 Press button to dial the number

To store a Caller Display number in the Phone Book

4 Press or go to the number you want

Press

Option button

7 Key in the name, number & select ring tone 8 Press

OK to confirm

9 Press to go back to standby mode

Caller Display

Help Line: 0845 345 9677 (Local Call rate) 19

Press the button

Press to go to [

Call Log

] menu

PressOKbutton to view the record(s)

Press the button

Press to go to [

Call Log

] menu

PressOKbutton to view the record(s)

Press the button

Press or go to Select [

Save to P.Book

]

then press

To Delete a Caller Display record

To Delete all Caller Display record

Caller Display

Use or button to select the number

Press the button

Press to go to the [

Call Log

]

then press

you want

Press Option button

Select [

Delete

] by or button

Press OK to confirm

Press the button

Press to go to the [

Call Log

]

then press

Press Option button

Select [

Delete All ] by or button

PressOK to confirm

or press the short-cut button

Page 14

SMS text messaging — read this first

SMS stands for short message service — also called text messaging, or just texting. Users whose phones

support SMS can send each other messages with up to 160 characters (140 characters on mobile phones).

Your iDECT K1 can send and receive SMS messages to and from mobile phones and compatible land-line phones. You can also send messages to non-SMS phones; the messages will be converted into speech.

The SMS service is provided by BT. If your network provider (the company that supplies your telephone line) is not BT, and you find you can’t send or receive text messages, check that the network provider supports the BT SMS service in your area.

Caller Display IMPORTANT — to use the SMS service, you must

subscribe to the Caller Display service (see also page

17) from your network provider; you can’t use the SMS service without Caller Display.

Registering for the SMS service

By sending your first SMS text message, you automatically register for the service, and you’ll receive a text message welcoming you. You may also receive other text messages with information about the service.

It is occasionally possible to become de-registered from the BT SMS service — for example, when a message cannot be delivered because your SMS phone is switched off. If this happens, you’ll start to receive text messages as spoken calls from the Messaging Centre.

Usually, you can automatically re-register by simply sending another text message. If you have problems, turn to page 50 for advice.

The SMS Send and Receive numbers

Your iDECT K1 is preprogrammed with two telephone numbers for the SMS service — the Send number and the Receive number. These are:

BT service numbers

Send telephone number

1470P1709400

The 1470 ensures that your number is not withheld on this call, even if you normally withhold it*.

The P inserts a pause before dialling the number.

Receive telephone number

080058752

Terminal number

9 (all messages)

* The SMS service will not work if your number is not sent to the network when you send messages.

It’s important to leave these numbers as they are. If they’ve been accidentally changed, you’ll need to reprogram them as described on page 28.

SMS text messaging — read this first

Help Line: 0845 345 9677 (Local Call rate) 21

(SMS Center 1)

(SMS Center 2)

Page 15

SMS message boxes

Your iDECT K1 has three message boxes:

■

The Inbox, which holds messages you’ve received from other people (incoming messages).

■

The Outbox, where a copy of each message you’ve sent is stored.

■

Draft Box, where you can store complete or partwritten messages to send later.

The total number of messages that can be stored in the message boxes is 20. If you reach the limit of 20 stored messages, the handset’s display shows

SMS Full

and your iDECT K1 won’t receive any new SMS messages until you delete some messages to make room (see pages 27 for details of how to delete messages).

When SMS memory is full, you can still send or forward a message from any of the message boxes. But no copy will be stored in the Outbox after you’ve sent it.

SMS text messaging — read this first

SMS text messaging

To check that the SMS text messaging service is working OK on your line, it’s a good idea to send your first text message to yourself. Simply follow the instructions below, keying in your own phone number — including the full dialling code — at step 5. The message should arrive in your Inbox shortly afterwards.

To write and send a text message

1 Press the short-cut button

(0r press the left Soft button [

Menu], then

use the or button to scroll to

SMS and

select it by pressing the left Soft button [

OK])

The display gives you the options:

Write — to write a message Inbox — to go to your Inbox. The number of

new messages and the total number of messages in your Inbox are shown (for example,

(02/07)

means you have two new messages and seven messages altogether).

Outbox — to go to your Outbox. The number

of messages in your Outbox is shown.

Draft — to go to your Draft Box.

Service Center — to check or change the

SMS Send and Receive numbers.

2 Press the left Soft button [OK] to select

Write

The display shows

3 Write your message

Each time you press a numbered button, the line at the bottom of the display shows the characters you can type by pressing this button repeatedly.

Help Line: 0845 345 9677 (Local Call rate) 23

Buttons to press for text characters — press the button repeatedly

until you get the character you want

PQRS7ß

ABC2ДавВЖЗ

TUV8ÜÙúû

DEF3ëéèê

WXYZ9

GHI4Ìíîï

JKL5

MNO6ЦтуфШС

upper case/lower case

-/ \

=<>()

,.:

;

[space] 1

@&$¥£§#

Write

Page 16

While writing, you can:

—

use the #(hash) key to switch between upper-case (capital letters) and lower-case (the first letter of the message is always upper-case);

—

use the and buttons to move to the beginning or end of the message;

—

use the right Soft button [Esc] to delete unwanted characters.

When your message is ready —

4 Press the left Soft button [OK]

The display shows

Number:

Key in the recipient’s phone number, including the full dialling code (even if it’s a local number)

Or press the right soft button [

PBook] to

search for a number in the Phone Book

(The number must be stored in the Phone Book with the full dialling code, even if it’s a local number.)

Press the left Soft button [OK]

The display shows

Send SMS

Press the left Soft button [OK] to send the message

The display shows

Message Sending . . .

for a few moments.

continued overleaf …

SMS text messaging

If you hear an

error tone…

If you hear a double high-pitched ‘beep’ it means the message was not sent and shows [

Failed ]

you can go to your Drafts Box and delete the message (see page 27). See pages 50 to 51 for possible reasons solutions.

To read your messages

Incoming text messages are stored in your Inbox. If there are new messages in your Inbox,

SMS is

displayed above the left Soft button.

1 Press the short-cut button

OR press the left Soft button [

Menu], then

use the

or button to scroll to

SMS and

select it by pressing the left Soft button [

OK]

2 If necessary, scroll to Inbox and press the

left Soft button [

OK] to select it

The display shows the numbers or name

of messages.

3 Press the left Soft button [R ead] to display

the full text

4 Press the left Soft button [Option ] for menu

options

The display gives you the options:

Forward

— forward the message

SMS text messaging

Help Line: 0845 345 9677 (Local Call rate) 25

Save SMS

" ! " means is new message.

— reply the message

Use Text

— edit the message

Save to PBook

— Store the Sender's number

in phone book

Page 17

SMS text messaging

Call — make the call to this sender.

DeleteAll

— clear the Inbox.

5 Use the or button to go to the option

you want, then press the left Soft button [

OK]

to select it

… and to store a caller’s number in the Phone Book

If you select

Save to PBook, the display shows

Enter Name

… or to delete messages from the Inbox

If you select

Delete

◗

Press the left Soft button [OK] to delete this message, or the right Soft button [

Esc]

to cancel without deleting the message.

If you select

Delete All

, you’ll be asked:

Delete All?

◗

Press the left Soft button [OK] to delete all messages from the list, or the right Soft button [

Esc] to cancel

To reply to a message

1 Go to the message you want to reply to, as

described under ‘To read your messages’

2 Scroll to Reply and press the left

Soft button [

OK] to select it

3 keying in your reply

4 Press the left Soft button [OK ]

The display shows the number of the person

who sent the message.

5 Press the left Soft button [OK]

The display shows

Send SMS

6 Press the left Soft button [OK ] to send the

message

To delete a message from the Outbox or Drafts Box

1 Press the left Soft button [Menu ], then use

the or button to scroll to

SMS and

select it by pressing the left Soft button [

OK]

2 Scroll to Outbox or Draft and press the

left Soft button [

OK] to select it

3 4

Press the left Soft button [Read ]

options

Use the or button to go to

Delete , then press the left Soft

button [

OK] to deletet it

SMS text messaging

Help Line: 0845 345 9677 (Local Call rate) 27

Delete — delete this message from the Inbox.

Key in a number and press OK

The display shows [

Enter Number

]

Select ring tone [

Melody1-Melody20

]

and press

to confirm.

Press button to go back standby mode

Save SMS

Press the left Soft button [

Option]

for menu

Page 18

To check or change the Send and Receive numbers

You should not normally need to change these numbers — they should stay as listed on page 33.

1 Press the short-cut button

(or press the left Soft button [

Menu], then

use the or button to scroll to

SMS and

select it by pressing the left Soft button [

OK])

2 Scroll to and press the left Soft button

[

OK] to select it

The display gives you the options:

SMS Center 1 <Send numbers> SMS Center 2 <Receive numbers> Terminal Nr.

3 Scroll to the option you want and press the

left Soft button [

OK] to select it

4 If necessary, edit the number

To insert a pause in the number, press and hold the

(star) button for 2 seconds.

5 Press the left Soft button [OK] to confirm

SMS text messaging

Using a multi-handset system

If you have an iDECT K1 multi-handset system, you already have more than one handset registered to your base unit. You can register additional handsets — up to five per base unit. With two or more handsets, you can:

■

make intercom calls from one handset to another

■

transfer an outside call from one handset to another

■

shuttle between an outside call and an intercom call

■

set up a three-way conference call

Each handset’s number (1 to 5) is shown on its display.

Only one handset can be connected to the outside line at once. If you try to make a call while another handset is already on the line, you’ll hear Busy tone.

To make an intercom call

There are two ways to make an intercom call. First method:

Press and hold button for 2 sconds until the INT symbol flashes on the display

Key the available handset number or press

All

to call all handsets

The other handset rings, and its display

[

Calling handset #

]

Help Line: 0845 345 9677

(Local Call rate)

Page 19

To answer an intercom call

The ringing tune for intercom calls is different from that for outside calls.

When someone makes an intercom call to you, your handset’s display shows [Call from #] with the number of the handset calling you.

◗

Press to answer

To end an intercom call

◗

Press button

◗

Or simply replace the handset on the base unit or charger pod

To transfer a call

When you’re talking on an outside call (a call you’ve either made or answered), you can transfer it to another handset:

1 Press and hold button until the Intercom

symbol flashes on the display. Then key in the number of the other handset (or

All to call all other handsets)

The outside call is put on hold and the other handset rings. When the other handset user answers, you can speak to her/him.

If the other user does not answer, you can get back to the outside call at any time by pressing

2 Press button to hang up and transfer

If you prefer, you canpress to transfer the outside call before the other handset answers your intercom call. If the user hasn’t answered after 30 seconds, the outside call will come back to you and your handset will ring.

Using a multi-handset system

To shuttle between two calls

When you have made or answered an outside call and then made an intercom call, you can shuttle from one to the other, like this:

◗

putting the other on hold

You can transfer the outside call to the other handset by pressing while you’re

connected to the intercom call If you press while you’re connected

to the outside call, you’ll disconnect it.

To set up a three-way conference

1 Make or answer an outside call 2 Press and hold the button then key in

the number of the other handset (or

All to

call all other handsets)

è The outside call is put on hold and the other

handset rings. When the other user answers:

3 Press Option button and select [

Conference]

To end the conference

◗

Press the button

Using a multi-handset system

Help Line: 0845 345 9677 (Local Call rate) 31

by or button, then press OKbutton

the call

the right soft key [

Back

]

Press Option button and select [

Switch Calls

]

by or button to speak to each in turn,

The displays shows

Conference

Page 20

New Call tone When you are on an intercom call and an

outside call comes in, you’ll hear New Call tone to tell you that someone is calling you.

To answer the outside call and end the intercom call:

◗

Press the right Soft button [

Back]

◗

Press the button to answer.

To page all handsets from the base unit

To make all registered handsets ring (this is useful if you’ve forgotten where you put a handset):

◗

Press the HANDSET LOCATOR button

Handsets ring for up to 30 seconds and their displays show [

Paging]

To stop the ringing before 30 seconds:

◗

EITHER press the HANDSET LOCATOR

◗

OR press on any handset

Using a multi-handset system

32 Help Line: 0845 345 9677 (Local Call rate) 33

on the base unit

button again

To select a base unit

If your handset is registered to more than one base unit, it will automatically select the one with which can best set up a radio link (usually the nearest one). Or you can select a base unit manually.

You don't need this function if you have only one base unit.

1 2

Press the button

Press to go to the [

Handset Set

]

The display shows [

Base

]

then press

Press or to select [

Select Base

]

then press

[

Auto 1 2 ...

]

Key number 0 for Auto, 1 or 2 to select

the base you want

Using a multi-handset system

OR press to end the intercom call.

Handset rings

Press the left soft button

Page 21

34 Help Line: 0845 345 9677 (Local Call rate) 35

Registration failed?

If this happens, try again, making sure you don’t leave too long between steps. If you still can’t register the handset, contact the Help Line for advice.

To de-register a handset

You may need to do this in order to replace a faulty handset.

Press

button

Press to go to [

Base Set

] menu

Select [

Remove HS

] by or and press

The display shows [

Enter PIN

]

Key in the PIN, the default PIN is 0000

PressOK button to confirm

The display shows register handset list

Key the handset number to de-register you want

You will hear a confirm tone, the display

Handset registration

then press OK

shows [

unregister

To register to a different brand of base unit

Your iDECT K1 can be registered to any GAPcompatible base unit; or your can register other GAPcompatible handsets to your iDECT K1 base unit.

But we do not guarantee that all features or display messages will be available using other manufacturers’ equipment.

Press the button

Handset registration

The handset(s) supplied with your iDECT K1 base unit are already registered to it, so you don’t need to register them. But if you’ve bought extra handsets separately, you’ll need to register them. Each iDECT K1 handset can be registered to up to four base units.

To register a new handset to your base unit

Make sure the handset you’re registering is in standby mode.

Use or button to select [

]

The display shows base list [

Base 1 2 3 4

]

Key the available base number

The display shows [

Enter PIN

]

Key in the PIN, the default PIN is 0000

The display shows

REGISTERING...

Immediately press the HANDSET LOCATOR button on the base unit and hold it until you hear a tone

The handset’s display flashes for a while, then shows numbers of available free handset, you can key anyone if you prefer or waiting for a

Press to go to the [

Handset Set

]

then press

moment, the handset is auto-matically given the lowest free handset number.

Page 22

Sound settings

Handset

1 Press the button 2

è The display shows

The handset rings at the current level. There are four volume levels —1,2,3,4,5 and off, with the volume at off, the handset won’t ring.

5 Use the â or á button to go to the level you

prefer then press

OK to confirm

è or press ESC to go back without change

The display shows ringer melody and the current melody. There are 20 melodies, [

Melody 1] to [Melody 20 ]

7 Press the á or â button to move between

the melodies. When you reach the one you prefer, press

OK to confirm

8 Press button to go back to standby mode

ringer

Base ringer

Sound settings

Help Line: 0845 345 9677

(Local Call rate)

Press to select the [

Sound Setting

]

then press

Press or to select the [

HS Ring

]

then press

Press or to select the [

Volume

] then press

Press to select the [

Melody

] by

after Step 3

Press the button

The display shows The base unit rings at the current level. There are four volume levels —1,2,3, and off, with the volume set to off, the base unit won't ring

Use the â or á button to go to the level you prefer then press

to confirm

or press

ESC

to go back without change

The display shows ringer melody and the current melody. There are 10 melodies, [

Melody 1

] to [

Melody 10

]

Press the á or â button to move between the melodies. When you reach the one you prefer, press

to confirm

Press button to go back to standby

Press to select the [

Sound Settin

g ]

then press

Press or to select the [

BS Ring

]

then press

Press or to select the [

Volume

] then press

Press to select the [

Melody

] by

after Step 3

for incoming calls.

mode

Page 23

Internal ring

Sound settings

Help Line: 0845 345 9677 (Local Call rate) 39

Tone setting

Press the button

Press to go to the [

Sound Setting

]

The display shows [

K ey Tone

]

then press

Press or to go to the [ T

one

]

then press

[

C harge Tone

]

Press

Off

soft key to turn these off if you

[

Ba ttery Low

]

[

O ut of Range

]

[

List End Tone

]

or turn these on by

soft key,

[

] symbol will change into [

]

iSleep

Press the button

Press to go to the [

Sound Setting

]

The display shows [

Off

]

then press

Press or to go to the [i

Sleep

]

then press

[

Once

]

You can set a special period to make your iDECT K1 not ring once or daily as below

[

Daily

]

Press the button

The display shows The handset rings at the current level. There are four volume levels —1,2,3,4,5

Use the â or á button to go to the level you prefer then press

to confirm

or press

ESC

to go back without change

The display shows ringer melody and the current melody. There are 20 melodies, [

Melody 1

] to [

Melody 20

]

Press the á or â button to move between the melodies. When you reach the one you prefer, press

to confirm

Press button to go back to standby mode

Press to select the [

Sound Setting

]

then press

Press or to select the [

Internal Ring

]

then press

Press or to select the [

Volume

] then press

Press to select the [

Melody

] by

after Step 3

prefer, [V] symbol will change into [-]

Page 24

Sound settings

Either,

Select [

Once

] and press

The display shows [

Timer Start

]

[

HH:MM

]

Key in the iSleep finish time in 24-hour clock

The display shows [

Timer Finish

]

[

HH:MM

]

then press

Key in the iSleep start time in 24-hour clock then press

, it won't ring once in the

setting time. OR,

Select [

Daily

] and press

The display shows [

Timer Start

]

[

HH:MM

]

Key in the iSleep start time in 24-hour clock

The display shows [

Timer Finish

]

[

HH:MM

]

then press

Key in the iSleep finish time in 24-hour clock then press

, it won't ring daily in the

setting time. If you want to turn iSleep off, simply

select [

Off

] at step 2 and press OK, your iDECT K1

always ring.

To change

the handset

Press the button

Press to go to the [

Handset Set

]

then press

Press or to go to [

Handset Name

]

then press

name

Enter your Handset name and confirm by OK

Press to clear if you have wrong typing.

Press the button to go back to

standby mode

Handset Settings

Normally, when there's an incoming call, you need to press on handset to answer it.

Auto answer

With auto-answer turned on, if a call comes in when the handset is in place on the base unit or charger pod, you can answer the call by simply lifting the handset.

Press the button

Press to go to the [

Handset Set

]

then press

Press or to go to [

Auto Answer

]

Press the left soft key ON to switch it ON

or press the left soft key

OFF

to switch it OFF

[- ] symbol will change into [V]

[V] symbol will change into [-]

Help Line: 0845 345 9677

(Local Call rate)

Page 25

To adjust display contrast

1 2

Returning to default settings

The default settings for handset are:

Handset settings

■

Handset settings

Help Line: 0845 345 9677 (Local Call rate) 43

Press the button

Press to go to the [

Handset Set]

è There are 3 contrast levels , [Level 1]

then press

Press or to go to the [

Contrast

]

then press

to [

Level 3

]

Use the â or á to select the contrast level

PressOKto confirm

Ringer volume level -

5 Ringer melody - 17 Earpiece volume level - 2 Speakerphone volume level - 2

■

Key tone - ON Charge tone - ON Battery Low tone - ON Auto answer - OFF

■

Display contrast - 2

To return all handset settings to their defaults:

1 2

Press the button

Press to go to the [

Handset Set

]

The display shows [

Confirm ?

]

then press

Press or to select [

Default HS

]

PressOKto confirm

Display

language

Press the button

Press to go to the [

Handset Set

]

Select the language you want then press

then press

Press or to select [

Language

] and press

To change the language on the display:

Page 26

Base unit settings

Base unit PIN

To change dial mode

Base unit settings

Help Line: 0845 345 9677 (Local Call rate) 45

The default PIN for base unit is 0000, if you want to protect your base unit's settings, you can change the PIN to any four-digit number you'll easily remember.

To change the PIN :

1 2

Press the button

Press to go to the [

Base Set]

è The display shows [Enter PIN]

then press

Press or to select [

Change PIN

]

then press

Key in the current PIN code, the default PIN is 0000

Key in your chosen new PIN then press

Re-enter your new PIN then press

You will hear a tone, the PIN has been

changed.

1 2

Press the button

Press to go to the [

Base Set

]

then press

You should always leave the dialing mode at its default setting - DTMF.

To change the dial mode if necessary

The display shows [

DTMF

]

Press or to select [

Dial Mode

]

then press

[

Pulse

]

Select the dial mode and press OK to confirm

The [V] display on your chosen dial mode

Date and

1 2

Press the button

Press to go to the [

Base Set

]

then press

The display shows [

Set Time & Day

]

Press or to select [

Date & Time

]

then press OK

Time

[

Set Time & Day

]

[

hh:mm DD-MM-YY

]

[

00:00 01/01/05

]

Key in the time and day

PressOK to confirm

Page 27

Base unit settings

Troubleshooting

The iDECT K1 must be serviced by trained engineers. NEVER attempt any repairs or adjustments yourself — you could make the problem worse and invalidate the Guarantee.

ALWAYS check first that:

■

you have followed all the steps listed on pages 6 to 7 to install and set up your iDECT K1

■

all connectors are firmly inserted in their sockets

■

mains power is switched on at the socket

■

the handset’s batteries are correctly and securely installed, and are not run down

Everyday use

“I cannot make

or answer calls.”

If the handset’s display is blank, it may be switched off. Press the HANG UP button to switch it back on.

Check that the base unit’s mains power adapter is plugged in and power is switched on. The base unit needs mains power for normal operation of the phone — not just for charging the batteries.

Make sure you’re using the telephone line cable that was supplied with your iDECT K1. Other telephone line cables might not work.

Move the handset closer to the base unit. Check the Battery Level symbol on the display. If it’s

low, replace the handset on the base unit or charger pod to recharge the batteries.

If auto-answer is turned off (page 41), you need to press any button (except HANG UP) on the handset to answer an incoming call. Turn auto-answer on if you want to answer calls by simply lifting the handset from the base unit or charger pod.

Switch off power at the mains socket, wait for a few seconds and then switch back on. This may help.

Help Line: 0845 345 9677 (Local Call rate) 47

To change the

This is for setting the flash (recall) signal length, you should not need to change the setting. Unless you're having problems using your iDECT K1 on a PBX.

1 2

Press the button

Press to go to the [Base Set]

è The display shows [Short]

then press

Press or to select [Flash Time]

then press

flash time

[

Medium

]

[

Long

]

Select the flash time by or , and

pressOKto confirm

Page 28

“When I press

keys, nothing happens.”

Make sure the batteries are correctly fitted in your handset. If the ‘battery charge level’ symbol on the display shows ‘low’, recharge the batteries.

“When I key in a

number, it appears on the display, but I can’t make an outside call.”

Try moving the handset closer to the base unit. Try a different position for the base unit — somewhere

higher if possible, or further from other electrical equipment.

If you have more than one registered handset, make sure another handset isn’t already using the line.

“The phone

does not ring”

Check that the base unit’s mains power adapter is plugged in and power is switched on. The base unit needs mains power for normal operation of the phone — not just for charging the batteries.

Make sure you’re using the telephone line cable that was supplied with your iDECT K1. Other telephone line cables might not work.

Check that the total REN value of all equipment connected to your telephone line is no more than 4 (see page 3). Disconnect one or more telephones and see whether that helps.

“There is inter

ference and noise on the line.”

Move the handset closer to the base unit, or to a different position.

Try moving the base unit so that it’s not near other electrical equipment, such as a television or a computer.

Troubleshooting

You’ll get the best results if you site the base unit as high as possible. For example, in a two-storey house,

the first-floor landing is an ideal place for the base unit.

“My call was cut

off when I went out of range. Now I can’t use my handset.”

Move the handset closer to the base unit before you try again to make a call.

“I hear ‘beeps’

from my handset while I’m on a call.”

You may be going out of range of the base unit. Move closer, or your call may be cut off.

Check the ‘battery charge level’ symbol on the display. If it is low, recharge the batteries.

“The Caller

Display feature isn’t working.”

You need to subscribe to the Caller Display feature. Contact your service provider (BT or cable company).

The caller may have withheld their number by dialling

141. Or they may be calling from a network that does not transmit the Caller ID (for example, it may be an international call).

“When I try to

make a call, I hear Busy tone.”

If you have more than one handset registered to your base unit, make sure that another handset isn’t already using the line.

“The volume in

the earpiece is low when I’m on a call.”

Make sure you’re holding the earpiece correctly over your ear.

Adjust the volume using the á or â button.

Troubleshooting

Help Line: 0845 345 9677 (Local Call rate) 49

Page 29

Using a multi-handset system

“I can’t transfer

a call.”

Make sure the other handset is in range of the base unit. Make sure you’re dialling the correct number for the

other handset 1 to 5, or (

All for all registered handsets).

Troubleshooting

Help Line: 0845 345 9677 (Local Call rate) 51

SMS text messaging

“I can’t send

text messages.”

You need to subscribe to Caller Display from your network provider in order to use SMS text messaging.

Your message boxes may be full — delete messages to make room (pages 27).

When keying in the recipient’s number, always include the full dialling code, even if it’s a local number.

Check that the Send and Receive phone numbers in your iDECT K1 have not been accidentally changed. Use the steps listed on page 28 to check the numbers, and correct them if necessary —

Send: 1470P1709400; Receive:080058752 Terminal: 9

Is your telephone line supplied by Telewest or NTL? In some areas, lines supplied by these companies do not support the BT SMS service.

If you route your calls through a different service provider from the one which supplies your line, it’s possible that this could cause problems. Contact the Binatone Help Line for advice.

“I can’t receive

text messages.”

If there’s a problem with receiving text messages on your phone, they will arrive as spoken messages — the BT Message Centre will call you and you’ll be told how to listen to your messages. Here’s what to do:

1 Check that the Receive phone number in your

iDECT K1 has not been accidentally changed. Use the steps listed on page 28 to check the number, and correct it if necessary. It should be 080058752 and the Terminal number should be 9.

2 If you’re sure the Receive number and Terminal number

are correct, try this: write a text message with just one word —

00000 (five zeroes).

3 A short time later, you should receive a text message

from the Message Centre. You’ll then be able to receive text messages as normal.

Batteries

“The handset‘s

batteries are running low within an hour or two.”

Before you first used the handset, you should have left it on the base unit or charger pod for up to 15 hours to charge the batteries fully.

You may need to replace the batteries (see below). Clean the battery charging contacts on the base unit

with a dry cloth. Check the connections between the base unit and the

mains power socket.

“I try to

recharge the batteries, but I still get a warning that they are low.”

You need to replace the batteries. To find out how to obtain replacements, call 0845 345 9677, between

9.00 am and 5.00 pm, Monday to Friday. Dispose of used batteries safely — never burn them,

or put them where they could get punctured.

ALWAYS use the batteries supplied with your iDECT K1 — other batteries may burst, causing damage.

Page 30

“Last Number

Redial and/or memory dialling don’t work on a PBX.”

When you first make a call, after keying in the outside line access code (e.g. 9), press option to select "

Insert Pause ".

access code and the telephone number. You should later be able to redial the number.

When storing numbers in memory, you can include the

outside line access code (e.g. 9) with each number.

Help Line: 0845 345 9677 (Local Call rate) 53

This inserts a pause between the

PBX use

“The Recall

function doesn’t seem to work.”

You may need to change the recall signal length from its default of 100 ms. Consult your PBX documentation for help if necessary. To change the flash time, use the [Base Set]menu (page 46).

Troubleshooting

If the fault persists …

Disconnect all other instruments connected to the same line as the iDECT K1 and see whether you can make a call.

Disconnect the base unit from the telephone line and plug a different phone into the master telephone socket. Try making a call. If this works, the line is OK.

Cleaning and care

■

Do not clean any part of your iDECT K1 with benzene, thinner or other solvent chemicals — this may cause permanent damage which is not covered by the Guar

antee. When necessary, clean it with a damp cloth.

■

Keep your iDECT K1 away from hot, humid conditions or strong sunlight, and don’t let it get wet.

■

Every effort has been made to ensure high standards of reliability for your iDECT K1. However, if something does go wrong, please do not try to repair it yourself — consult your supplier or the Help Line.

If the call does not work, and you are using a two-way socket adapter, remove it and plug a telephone directly into the socket. If the call now works, the adapter may be faulty.

If you cannot make a call, the fault may be on the exchange line. Contact the service provider (the BT engineers on 151, or your cable company).

If you still cannot identify the cause of the problem, contact the Help Line on 0845 345 9677.

Page 31

54 Help Line: 0845 345 9677 (Local Call rate) 55

Guarantee and service

The iDECT K1 is guaranteed for 12 months from the date of purchase shown on your sales receipt. The Guar

antee does not cover damage by misuse or negligence, or by excessive voltages — for example, faults on the telephone line, or lightning.

Please keep your sales (till) receipt — this is your guarantee. You should also keep the original packaging

material. In the unlikely event that you need to return your

iDECT K1 to our Repair Centre while it is under guarantee, there will be a £5 handling charge.

While the unit is under Guarantee

1 Disconnect the base unit from the telephone line and

the mains electricity supply

2 Pack up all parts of your iDECT K1, using the original

packaging. Remember to include the mains adapter

3 Return the unit to the shop where you bought it,

making sure you take your sales receipt

After the Guarantee has expired

If the unit is no longer under Guarantee, first follow steps 1 and 2 as for repair under Guarantee. Then …

3 Call our Service Department on 0845 345 9677 and ask

for a quotation of the repair charge and details of where to send your iDECT K1 for repair

4 Make sure you include with your iDECT K1:

■

your name and address

■

a cheque or postal order for the value of the repair charge

5 Return your iDECT K1 to the address given by the

Service Department

Binatone Telecom plc operates a policy of continuous product improvement, and so reserves the right to make changes to the product and functions without notice.

Technical details

Standard Digital Enhanced Cordless

Telecommunications (DECT)

Frequency range 1.88 to 1.9 GHz (bandwidth = 20 MHz) Channel bandwidth 1.728 MHz Operating range up to 300 m outdoors; up to 50 m

indoors

Operating time standby:150 hours approx.

talking: 15 hours approx. battery charge time: 15 hours

Temperature range Operating 0 ºC to 40 ºC

Storage -20 ºC to 60 ºC

Electrical power

Handset — two AAA-size NiMH 750mAh

rechargeable batteries

Base unit/charger pod — input 230 V AC, 50 Hz; output

AC 6 V, 300 mA Port specification The port (connected to the mains

power supply) is a SELV port with respect to EN41003. The port (connected to the telephone line) is a TNV

port with respect to EN41003. PBX compatibility Timed break recall: programmable as

100 ms (recommended for most PBX systems) or 250 ms. Pause length: 3 seconds. Signalling type: DTMF (dual-tone multifrequency), also called tone dialling.

Network connection This equipment is intended to be used in the UK only. Operation on other countries’ PSTN termination points cannot be guaranteed.

Page 32

Waste electrical products must not be disposed of with household waste. This equipment should be taken to your local recycling centre for safe treatment.
