FC9Y-B812-0A
FC4A SERIES
Micro Programmable
Logic Controller
User’s Manual
MICROSMART USER’S MANUAL UPDATE
Introduction
This manual includes additional descriptions of new modules and upgraded functionality in detail.
New Modules
CPU Modules (All-in-One Type)
Power Voltage Input Type Output Type I/O Points Type No.
24V DC 24V DC Sink/Source
Relay Output
240V AC/30V DC, 2A
AC Input Module
Input Type Input Points Terminal Type No.
120V AC 8 points Removable Terminal Block FC4A-N08A11
Upgraded Functionality
Nine new functions have been implemented in the MicroSmart CPU modules. Availability of the nine new functions
depends on the model and system program version of the MicroSmart CPU modules as listed below:
10-I/O Type (6 in / 4 out) FC4A-C10R2C
16-I/O Type (9 in / 7 out) FC4A-C16R2C
24-I/O Type (14 in / 10 out) FC4A-C24R2C
CPU Module
AS-Interface Master Module
Compatibility
64KB Memory Cartridge
Compatibility
PID Instruction Upgrade
HMI Module Initial Screen
Selection
RS485 User Communication
Compatibility
User Communication BCC
Upgrade
(ADD-2comp, Modbus ASCII, and
Modbus RTU)
Pulse Instructions Upgrade
Coordinate Conversion
Instructions Upgrade
Intelligent Module Access
Instructions
All-in-One Type Slim Type
FC4A-C10R2
FC4A-C10R2C
——
203 or higher 202 or higher
————
FC4A-C16R2
FC4A-C16R2C
FC4A-C24R2
FC4A-C24R2C
——
202 or higher 202 or higher
FC4A-D20K3
FC4A-D20S3
FC4A-D20RK1
FC4A-D20RS1
FC4A-D40K3
FC4A-D40S3
201 or higher
202 or higher
203 or higher
To confirm the system program version of the MicroSmart CPU module, use WindLDR on a computer connected with the
CPU module. Bring WindLDR into the online mode. The system program version is indicated on the PLC status dialog
box. For details about the procedure, see page 28-1.
UPDATEINFO « MICROSMART USER’S MANUAL »
SAFETY PRECAUTIONS
• Read this user’s manual to make sure of correct operation before starting installation, wiring, operation, maintenance, and
inspection of the MicroSmart.
• All MicroSmart modules are manufactured under IDEC’s rigorous quality control system, but users must add a backup or
failsafe provision to the control system using the MicroSmart in applications where heavy damage or personal injury may
be caused in case the MicroSmart should fail.
• In this user’s manual, safety precautions are categorized in order of importance to Warning and Caution:
Warning
•Turn off the power to the MicroSmart before starting installation, removal, wiring, maintenance, and inspection of the
MicroSmart. Failure to turn power off may cause electrical shocks or fire hazard.
• Special expertise is required to install, wire, program, and operate the MicroSmart. People without such expertise must not
use the MicroSmart.
• Emergency stop and interlocking circuits must be configured outside the MicroSmart. If such a circuit is configured inside
MicroSmart, failure of the MicroSmar t may cause disorder of the control system, damage, or accidents.
the
• Install the MicroSmart according to the instructions described in this user’s manual. Improper installation will result in f alling, failure, or malfunction of the
Caution
• The MicroSmart is designed for installation in a cabinet. Do not install the MicroSmar t outside a cabinet.
• Install the MicroSmart in environments described in this user’s manual. If the MicroSmart is used in places where the
MicroSmart is subjected to high-temperature, high-humidity, condensation, corrosive gases, excessive vibrations, and
excessive shocks, then electrical shocks, fire hazard, or malfunction will result.
• The environment for using the MicroSmart is “Pollution degree 2.” Use the MicroSmart in environments of pollution
degree 2 (according to IEC 60664-1).
• Prevent the MicroSmart from falling while moving or transporting the MicroSmar t, otherwise damage or malfunction of
the MicroSmart will result.
• Prevent metal fragments and pieces of wire from dropping inside the MicroSmart housing. Put a cover on the MicroSmar t
modules during installation and wiring. Ingress of such fragments and chips may cause fire hazard, damage, or malfunction.
• Use a power supply of the rated value. Use of a wrong power supply may cause fire hazard.
• Use an IEC 60127-approved fuse on the power line outside the
the
MicroSmart is destined for Europe.
• Use an IEC 60127-approved fuse on the output circuit. This is required when equipment containing the MicroSmart is destined for Europe.
• Use an EU-approved circuit breaker. This is required when equipment containing the MicroSmart is destined for Europe.
•Make sure of safety before starting and stopping the MicroSmar t or when operating the MicroSmar t to force outputs on or
off. Incorrect operation on the
• If relays or transistors in the MicroSmart output modules should fail, outputs may remain on or off. For output signals
which may cause heavy accidents, provide a monitor circuit outside the
• Do not connect the ground wire directly to the MicroSmart. Connect a protective ground to the cabinet containing the
MicroSmart using an M4 or larger screw. This is required when equipment containing the MicroSmart is destined for
Europe.
• Do not disassemble, repair, or modify the MicroSmart modules.
• Dispose of the battery in the MicroSmart modules when the battery is dead in accordance with pertaining regulations.
When storing or disposing of the battery, use a proper container prepared for this purpose. This is required when equipment
containing the MicroSmart is destined for Europe.
•When disposing of the MicroSmar t, do so as an industrial waste.
Warning notices are used to emphasize that improper operation may cause
severe personal injury or death.
MicroSmart.
Caution notices are used where inattention might cause personal injury or
damage to equipment.
MicroSmart. This is required when equipment containing
MicroSmart may cause machine damage or accidents.
MicroSmart.
« MICROSMART USER’S MANUAL »PREFACE-1
About This Manual
This user’s manual primarily describes entire functions, installation, and programming of the MicroSmart CPU, I/O, and
all other modules. Also included are powerful communications of the MicroSmart and troubleshooting procedures.
CHAPTER 1: GENERAL INFORMATION
General information about the MicroSmart, features, brief description on special functions, and various system setup configurations for communication.
CHAPTER 2: MODULE SPECIFICATIONS
Specifications of CPU, input, output, mixed I/O, analog I/O, and other optional modules.
CHAPTER 3: INSTALLATION AND WIRING
Methods and precautions for installing and wiring the MicroSmart modules.
CHAPTER 4: OPERATION BASICS
General information about setting up the basic MicroSmart system for programming, starting and stopping MicroSmar t
operation, and simple operating procedures from creating a user program using WindLDR on a PC to monitoring the Micro-
operation.
Smart
CHAPTER 5: SPECIAL FUNCTIONS
Stop/reset inputs, run/stop selection at memory backup error, keep designation for internal relays, shift registers, counters,
and data registers. Also included are high-speed counter, catch input, interrupt input, timer interrupt, input filter, user program read/write protection, constant scan time, partial program download, and many more special functions.
CHAPTER 6: ALLOCATION NUMBERS
Allocation numbers available for the MicroSmart CPU modules to program basic and advanced instructions. Special internal relays and special data registers are also described.
CHAPTER 7: BASIC INSTRUCTIONS
Programming of the basic instructions, available operands, and sample programs.
CHAPTER 8: ADVANCED INSTRUCTIONS
General rules of using advanced instructions, terms, data types, and formats used for advanced instructions.
CHAPTER 9 THROUGH CHAPTER 23:
Detailed descriptions on advanced instructions grouped into 15 chapters.
CHAPTER 24 THROUGH CHAPTER 27:
Analog I/O control and various communication functions such as data link, computer link, and modem mode.
CHAPTER 28: TROUBLESHOOTING
Procedures to determine the cause of trouble and actions to be taken when any trouble occurs while operating the Micro-
.
Smart
APPENDIX
Additional information about execution times for instructions, I/O delay time, and MicroSmart type list.
INDEX
Alphabetical listing of key words.
IMPORTANT INFORMATION
Under no circumstances shall IDEC Corporation be held liable or responsible for indirect or consequential damages resulting
from the use of or the application of IDEC PLC components, individually or in combination with other equipment.
All persons using these components must be willing to accept responsibility for choosing the correct component to suit their
application and for choosing an application appropriate for the component, individually or in combination with other equipment.
All diagrams and examples in this manual are for illustrative purposes only. In no way does including these diagrams and examples in this manual constitute a guarantee as to their suitability for any specific application. To test and approve all programs,
prior to installation, is the responsibility of the end user.
PREFACE-2 « MICROSMART USER’S MANUAL »
TABLE OF CONTENTS
HAPTER 1: GENERAL INFORMATION
C
About the MicroSmart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Special Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
HAPTER 2: MODULE SPECIFICATIONS
C
CPU Modules (All-in-One Type) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
CPU Modules (Slim Type) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Input Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Output Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Mixed I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Analog I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-43
HMI Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-49
HMI Base Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-50
Communication Adapters and Communication Modules . . . . . . . . . . . . . . . . . . . . 2-51
Memory Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-54
Clock Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-56
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
HAPTER 3: INSTALLATION AND WIRING
C
Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Assembling Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Disassembling Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Installing the HMI Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Removing the HMI Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Removing the Terminal Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Removing the Communication Connector Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Mounting on DIN Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Removing from DIN Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Direct Mounting on Panel Surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Installation in Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Mounting Direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Input Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Output Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Terminal Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
HAPTER 4: OPERATION BASICS
C
Connecting MicroSmart to PC (1:1 Computer Link System) . . . . . . . . . . . . . . . . . . . 4-1
Start/Stop Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Simple Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
« MICROSMART USER’S MANUAL »i
TABLE OF CONTENTS
HAPTER 5: SPECIAL FUNCTIONS
C
Function Area Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Stop Input and Reset Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Run/Stop Selection at Memory Backup Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Keep Designation for Internal Relays, Shift Registers, Counters, and Data Registers 5-4
High-speed Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Catch Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Interrupt Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
Timer Interrupt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
Input Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
User Program Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
Constant Scan Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
Partial Program Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
Analog Potentiometers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30
Analog Voltage Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
HMI Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-32
Expansion Data Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-42
HAPTER 6: ALLOCATION NUMBERS
C
Operand Allocation Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
I/O, Internal Relay, and Special Internal Relay Operand Allocation Numbers . . . . . . . 6-3
Operand Allocation Numbers for Data Link Master Station . . . . . . . . . . . . . . . . . . . 6-5
Operand Allocation Numbers for Data Link Slave Station . . . . . . . . . . . . . . . . . . . . . 6-5
Special Internal Relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Special Data Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
Expansion I/O Module Operands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
HAPTER 7: BASIC INSTRUCTIONS
C
Basic Instruction List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
LOD (Load) and LODN (Load Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
OUT (Output) and OUTN (Output Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
SET and RST (Reset) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
AND and ANDN (And Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
OR and ORN (Or Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
AND LOD (Load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
OR LOD (Load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
BPS (Bit Push), BRD (Bit Read), and BPP (Bit Pop) . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
TML, TIM, TMH, and TMS (Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
CNT, CDP, and CUD (Counter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
CC= and CC≥ (Counter Comparison) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
DC= and DC≥ (Data Register Comparison) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
SFR and SFRN (Forward and Reverse Shift Register) . . . . . . . . . . . . . . . . . . . . . . . 7-18
SOTU and SOTD (Single Output Up and Down) . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-22
MCS and MCR (Master Control Set and Reset) . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23
JMP (Jump) and JEND (Jump End) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-25
END . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-26
ii « MICROSMART USER’S MANUAL »
HAPTER 8: ADVANCED INSTRUCTIONS
C
Advanced Instruction List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Advanced Instruction Applicable CPU Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Structure of an Advanced Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Input Condition for Advanced Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Source and Destination Operands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Using Timer or Counter as Source Operand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Using Timer or Counter as Destination Operand . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Data Types for Advanced Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Discontinuity of Operand Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
NOP (No Operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
HAPTER 9: MOVE INSTRUCTIONS
C
MOV (Move) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
MOVN (Move Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
IMOV (Indirect Move) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
IMOVN (Indirect Move Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
BMOV (Block Move) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
IBMV (Indirect Bit Move) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
IBMVN (Indirect Bit Move Not) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
TABLE OF CONTENTS
HAPTER 10: DATA COMPARISON INSTRUCTIONS
C
CMP= (Compare Equal To) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
CMP<> (Compare Unequal To) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
CMP< (Compare Less Than) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
CMP> (Compare Greater Than) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
CMP<= (Compare Less Than or Equal To) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
CMP>= (Compare Greater Than or Equal To) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
ICMP>= (Interval Compare Greater Than or Equal To) . . . . . . . . . . . . . . . . . . . . . . 10-4
HAPTER 11: BINARY ARITHMETIC INSTRUCTIONS
C
ADD (Addition) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
SUB (Subtraction) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
MUL (Multiplication) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
DIV (Division) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
ROOT (Root) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-7
HAPTER 12: BOOLEAN COMPUTATION INSTRUCTIONS
C
ANDW (AND Word) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
ORW (OR Word) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
XORW (Exclusive OR Word) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
HAPTER 13: SHIFT / ROTATE INSTRUCTIONS
C
SFTL (Shift Left) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1
SFTR (Shift Right) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-3
BCDLS (BCD Left Shift) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-4
WSFT (Word Shift) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-5
ROTL (Rotate Left) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-6
ROTR (Rotate Right) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-7
« MICROSMART USER’S MANUAL » iii
TABLE OF CONTENTS
HAPTER 14: DATA CONVERSION INSTRUCTIONS
C
HTOB (Hex to BCD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-1
BTOH (BCD to Hex) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-2
HTOA (Hex to ASCII) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-3
ATOH (ASCII to Hex) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-5
BTOA (BCD to ASCII) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-7
ATOB (ASCII to BCD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-9
ENCO (Encode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-11
DECO (Decode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-12
BCNT (Bit Count) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-13
ALT (Alternate Output) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-14
HAPTER 15: WEEK PROGRAMMER INSTRUCTIONS
C
WKTIM (Week Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-1
WKTBL (Week Table) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2
Setting Calendar/Clock Using WindLDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-5
Setting Calendar/Clock Using a User Program . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-5
Adjusting Clock Using a User Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-6
Adjusting Clock Cartridge Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-7
HAPTER 16: INTERFACE INSTRUCTIONS
C
DISP (Display) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-1
DGRD (Digital Read) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-3
HAPTER 17: USER COMMUNICATION INSTRUCTIONS
C
User Communication Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-1
User Communication Mode Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-2
Connecting RS232C Equipment through RS232C Port 1 or 2 . . . . . . . . . . . . . . . . 17-2
RS232C User Communication System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-3
Connecting RS485 Equipment through RS485 Port 2 . . . . . . . . . . . . . . . . . . . . . . 17-4
RS485 User Communication System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-4
Programming WindLDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-5
TXD1 (Transmit 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-6
TXD2 (Transmit 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-6
RXD1 (Receive 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-15
RXD2 (Receive 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-15
User Communication Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-27
ASCII Character Code Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-28
RS232C Line Control Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-29
Sample Program – User Communication TXD . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-32
Sample Program – User Communication RXD . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-34
HAPTER 18: PROGRAM BRANCHING INSTRUCTIONS
C
LABEL (Label) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-1
LJMP (Label Jump) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-1
LCAL (Label Call) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-3
LRET (Label Return) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-3
IOREF (I/O Refresh) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-5
DI (Disable Interrupt) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-7
EI (Enable Interrupt) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-7
iv « MICROSMART USER’S MANUAL »
HAPTER 19: COORDINATE CONVERSION INSTRUCTIONS
C
XYFS (XY Format Set) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-1
CVXTY (Convert X to Y) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-2
CVYTX (Convert Y to X) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-3
HAPTER 20: PULSE INSTRUCTIONS
C
PULS1 (Pulse Output 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-1
PULS2 (Pulse Output 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-1
PWM1 (Pulse Width Modulation 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-7
PWM2 (Pulse Width Modulation 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-7
RAMP (Ramp Control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-13
ZRN1 (Zero Return 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-24
ZRN2 (Zero Return 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-24
HAPTER 21: PID INSTRUCTION
C
PID (PID Control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-2
Application Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-14
HAPTER 22: DUAL / TEACHING TIMER INSTRUCTIONS
C
DTML (1-sec Dual Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
DTIM (100-msec Dual Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
DTMH (10-msec Dual Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
DTMS (1-msec Dual Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
TTIM (Teaching Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-3
TABLE OF CONTENTS
HAPTER 23: INTELLIGENT MODULE ACCESS INSTRUCTIONS
C
RUNA READ (Run Access Read) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-2
RUNA WRITE (Run Access Write) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-3
STPA READ (Stop Access Read) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-4
STPA WRITE (Stop Access Write) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-5
HAPTER 24: ANALOG I/O CONTROL
C
System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-1
Data Register Allocation Numbers for Analog I/O Modules . . . . . . . . . . . . . . . . . . 24-2
HAPTER 25: DATA LINK COMMUNICATION
C
Data Link Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-1
Data Link System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-2
Data Register Allocation for Transmit/Receive Data . . . . . . . . . . . . . . . . . . . . . . . 25-3
Special Data Registers for Data Link Communication Error . . . . . . . . . . . . . . . . . . 25-4
Data Link Communication between Master and Slave Stations . . . . . . . . . . . . . . . 25-5
Special Internal Relays for Data Link Communication . . . . . . . . . . . . . . . . . . . . . . 25-6
Programming WindLDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-7
Refresh Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-9
Operating Procedure for Data Link System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-11
Data Link with Other PLCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-12
« MICROSMART USER’S MANUAL »v
TABLE OF CONTENTS
HAPTER 26: COMPUTER LINK COMMUNICATION
C
Computer Link System Setup (1:N Computer Link System) . . . . . . . . . . . . . . . . . . 26-1
Programming WindLDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-2
Monitoring PLC Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-3
RS232C/RS485 Converter FC2A-MD1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-4
HAPTER 27: MODEM MODE
C
System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-1
Applicable Modems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-2
Special Internal Relays for Modem Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-2
Special Data Registers for Modem Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-3
Originate Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-3
Disconnect Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-5
AT General Command Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-5
Answer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-6
Modem Mode Status Data Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-7
Initialization String Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-8
Preparation for Using Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-9
Programming Data Registers and Internal Relays . . . . . . . . . . . . . . . . . . . . . . . . . 27-9
Setting Up the CPU Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-9
Programming WindLDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-10
Operating Procedure for Modem Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-11
Sample Program for Modem Originate Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-12
Sample Program for Modem Answer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-13
Troubleshooting in Modem Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-14
HAPTER 28: TROUBLESHOOTING
C
ERR LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-1
Reading Error Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-1
Special Data Registers for Error Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-3
General Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-3
CPU Module Operating Status, Output, and ERR LED during Errors . . . . . . . . . . . . 28-4
Error Causes and Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-4
User Program Execution Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-6
Troubleshooting Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-7
Restriction on Ladder Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-8
PPENDIX
A
Execution Times for Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Breakdown of END Processing Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
I/O Delay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Instruction Steps and Applicability in Interrupt Programs . . . . . . . . . . . . . . . . . . . . . A-3
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Type List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
NDEX
I
vi « MICROSMART USER’S MANUAL »
1: GENERAL INFORMATION
Introduction
This chapter describes general information for understanding the MicroSmart’s powerful capabilities and system setups to
use the MicroSmart in various ways of communication.
About the MicroSmart
IDEC’s MicroSmart is a new family of micro programmable logic controllers available in two styles of CPU modules; allin-one and slim types. The all-in-one type CPU module has 10, 16, or 24 I/O terminals and is equipped with a built-in universal power supply to operate on 100 to 240V AC or 24V DC. Using four 16-point I/O modules, the 24-I/O type CPU
module can expand the I/O points up to a total of 88 points. The slim type CPU module has 20 or 40 I/O terminals and
operates on 24V DC. The total I/O points can be expanded to a maximum of 264.
User programs for the MicroSmart can be edited using WindLDR on a Windows PC. Since WindLDR can load e xisting user
programs made for IDEC’s previous PLCs such as all FA series, MICRO-1, MICRO3, MICRO
your software assets can be used in the new control system.
Program capacity of the all-in-one type CPU modules is 4,800 bytes (800 steps) on the 10-I/O type CPU module, 15,000
bytes (2,500 steps) on the 16-I/O type, and 27,000 bytes (4,500 steps) on the 24-I/O type. Slim type CPU modules have a
program capacity of 27,000 bytes (4,500 steps) or 31,200 bytes (5,200 steps). When using an optional 64KB memory cartridge on slim type CPU modules, the program capacity can be expanded up to 64,500 bytes (10,750 steps).
3
C, and OpenNet Controller,
Features
Powerful Communication Functions
The MicroSmart features four powerful communication functions.
When a MicroSmart CPU module is connected to a computer, operating status and I/O status
Maintenance
Communication
(Computer Link)
User Communication
Modem Communication
Data Link
Communication Adapter (All-in-one 16- and 24-I/O type CPU modules)
Communication Module (Slim type CPU modules)
In addition to the standard RS232C port 1, the all-in-one 16- and 24-I/O type CPU modules feature a port 2 connector to
install an optional RS232C or RS485 communication adapter. All slim type CPU modules can be used with an optional
RS232C or RS485 communication module to add communication port 2. With an optional HMI base module mounted
with a slim type CPU module, an optional RS232C or RS485 communication adapter can also be installed on the HMI
base module.
can be monitored on the computer, data in the CPU can be monitored or updated, and user
programs can be downloaded and uploaded. All CPU modules (except the all-in-one 10-I/O
type) can set up a 1:N computer link system to connect a maximum of 32 CPU modules to a
computer.
All MicroSmart CPU modules can be linked to external RS232C devices such as computers,
printers, and barcode readers, using the user communication function. RS485 user communication is also available on upgraded CPU modules of slim 20-I/O relay output and 40-I/O
types.
All MicroSmart CPU modules (except the all-in-one 10-I/O type) can communicate through
modems using the built-in modem protocol.
All MicroSmart CPU modules (except the all-in-one 10-I/O type) can set up a data link system.
One CPU module at the master station can communicate with 31 slave stations through an
RS485 line to exchange data and perform distributed control ef fectively.
RS232C Communication Adapter
RS232C Communication Module
RS485 Communication Adapter
RS485 Communication Module
Used for computer link 1:1 communication, user communication, and modem
communication.
Available in mini DIN connector and terminal block styles. Used for computer link
1:1 or 1:N communication, user communication, and data link communication.
« MICROSMART USER’S MANUAL »1-1
1: GENERAL INFORMATION
HMI Module (all CPU modules)
An optional HMI module can be installed on any all-in-one type CPU module, and also on the HMI base module mounted
next to any slim type CPU module. The HMI module makes it possible to manipulate the RAM data in the CPU module
without using the Online menu options in WindLDR.
HMI module functions include:
• Displaying timer/counter current values and changing timer/counter preset values
• Displaying and changing data register values
• Setting and resetting bit operand statuses, such as inputs, outputs, internal relays, and shift register bits
• Displaying and clearing error data
• Starting and stopping the PLC
• Displaying and changing calendar/clock data (only when using the clock cartridge)
• Confirming changed timer/counter preset values
Clock Cartridge (all CPU modules)
An optional clock cartridge can be installed on the CPU module to store real time calendar/clock data for use with
advanced instructions to perform time-scheduled control.
Memory Cartridge (all CPU modules)
A user program can be stored on an optional memory cartridge using WindLDR from a computer , and the memory cartridge
can be installed on another CPU module to replace user programs without the need for connecting to a computer.
Analog I/O Modules (all CPU modules except the all-in-one 10- and 16-I/O types)
Analog I/O modules are available in 3-I/O types, 2-input type, and 1-output type. The input channel can accept either voltage (0 to 10V DC) and current (4 to 20 mA) signals or thermocouple (types K, J, and T) and resistance thermometer (Pt
100) signals. The output channel generates voltage (0 to 10V DC) and current (4 to 20 mA) signals.
AS-Interface Master Module (slim type 20-I/O relay output and 40-I/O types)
Four upgraded slim type CPU modules (FC4A-D20RK1, FC4A-D20RS1, FC4A-D40K3, and FC4A-D40S3) with system
program ver . 201 and higher can use the AS-Interface master module, and hav e additional internal relays and data registers
to communicate with slaves, such as actuators and sensors, through the AS-Interface bus. For details about AS-Interface
communication, see a separate user’s manual for the MicroSmart AS-Interface master module (manual No. FC9Y-B644).
Special Functions
The MicroSmart features various special functions packed in the small housing as described belo w. For details about these
functions, see the following chapters.
Stop and Reset Inputs
Any input terminal on the CPU module can be designated as a stop or reset input to control the MicroSmart operation.
RUN/STOP Selection at Startup when “Keep” Data is Broken
When data to be kept such as “keep” designated counter values are broken while the CPU is powered down, the user can
select whether the CPU starts to run or not to prevent undesirable operation at the next startup.
“Keep” or “Clear” Designation of CPU Data
Internal relays, shift register bits, counter current values, and data register values can be designated to be kept or cleared
when the CPU is powered down. All or a specified range of these operands can be designated as keep or clear types.
High-speed Counter
The MicroSmart has four built-in high-speed counters to make it possible to count up to 65,535 (FFFFh) high-speed pulses
which cannot be counted by the normal user program processing. One high-speed counter (all-in-one type CPU modules)
or two high-speed counters (slim type CPU modules) can be used as either two-phase or single-phase high-speed counters
at a maximum count input frequency of 20 kHz. Three or two others are single-phase high-speed counters with a maximum counting frequency of 5 kHz. The high-speed counters can be used for simple positioning control and simple motor
control.
1-2 « MICROSMART USER’S MANUAL »
1: GENERAL INFORMATION
Catch Input
Four inputs can be used as catch inputs. The catch input makes sure to recei ve short input pulses (rising pulse of 40 µsec or
falling pulse of 150 µsec minimum) from sensors without regard to the scan time.
Interrupt Input
Four inputs can be used as interrupt inputs. When a quick response to an external input is required, such as positioning
control, the interrupt input can call a subroutine to execute an interrupt program.
Timer Interrupt
In addition to the interrupt input, slim type CPU modules FC4A-D20RK1, FC4A-D20RS1, FC4A-D40K1, and FC4AD40S1 have a timer interrupt function. When a repetitive operation is required, the timer interrupt can be used to call a
subroutine repeatedly at predetermined intervals of 10 through 140 msec.
Input Filter
The input filter can be adjusted for eight inputs to reject input noises. Selectable input filter values to pass input signals are
0 msec, and 3 through 15 msec in 1-msec increments. The input filter rejects inputs shorter than the selected input filter
value minus 2 msec. This function is useful for eliminating input noises and chatter in limit switches.
User Program Read/Write Protection
The user program in the CPU module can be protected against reading and/or writing by including a password in the user
program. This function is effective for security of user programs.
Constant Scan Time
The scan time may vary whether basic and advanced instructions are executed or not depending on input conditions to
these instructions. When performing repetitive control, the scan time can be made constant by entering a required scan
time value into a special data register reserved for constant scan time.
Partial Program Download
Normally, the CPU module has to be stopped before downloading a user program. All CPU modules (except the all-in-one
10-I/O type) have run-time program download capabilities to do wnload a user program containing small changes while the
CPU is running in either 1:1 or 1:N computer link system. This function is particularly useful to make small modifications
to the user program and confirm the changes while the CPU is running.
Analog Potentiometer
All CPU modules have an analog potentiometer , e xcept the all-in-one 24-I/O type CPU module has tw o analog potentiometers. The values (0 through 255) set with analog potentiometers 1 and 2 are stored to special data registers. The analog
potentiometer can be used to change the preset value for a timer or counter.
Analog Voltage Input
Every slim type CPU module has an analog voltage input connector. When an analog voltage of 0 through 10V DC is
applied to the analog voltage input connector, the signal is converted to a digital v alue of 0 through 255 and stored to a special data register. The data is updated in every scan.
Pulse Output
Slim type CPU modules have pulse output instructions to generate high-speed pulse outputs from transistor output terminals used for simple position control applications, illumination control, trapezoidal control, and zero-return control.
PID Control
All CPU modules (except the all-in-one 10- and 16-I/O types) have the PID instruction, which implements a PID (proportional, integral, and derivative) algorithm with built-in auto tuning to determine PID parameters. This instruction is primarily designed for use with an analog I/O module to read analog input data, and turns on and off a designated output to
perform PID control in applications such as temperature control. In addition, the PID instruction can also generate an analog output using an analog I/O module.
Expansion Data Register
Slim type CPU modules FC4A-D20RK1, FC4A-D20RS1, FC4A-D40K3, and FC4A-D40S3 have expansion data registers
D2000 through D7999. Numerical data can be set to expansion data registers using WindLDR. When downloading the user
program, the preset values of the expansion data registers are also downloaded to the EEPROM in the CPU module. Since
the data in the EEPROM is non-volatile, the preset v alues of the e xpansion data registers are maintained semi-permanently
and loaded to the RAM each time the CPU is powered up.
« MICROSMART USER’S MANUAL »1-3
1: GENERAL INFORMATION
System Setup
This section illustrates system setup configurations for using powerful communication functions of the MicroSmart.
User Communication and Modem Communication System
The all-in-one 16- and 24-I/O type MicroSmart CPU modules have port 1 for RS232C communication and port 2 connector. An optional RS232C or RS485 communication adapter can be installed on the port 2 connector. With an RS232C communication adapter installed on port 2, the 16- or 24-I/O type MicroSmart CPU module can communicate with two
RS232C devices at the same time.
The figure below illustrates a system setup of user communication and modem communication. In this example, the operating status of a remote machine is monitored on a computer through modems connected to port 2 and the data is transferred through port 1 to a pager transmitter using the user communication.
The same system can be set up using any slim type CPU module and an optional RS232C communication module.
For details about the user communication, see page 17-1.
For details about the modem mode, see page 27-1.
All-in-One 16- or 24-I/O Type CPU Module
Port 1
Port 2 Connector
Pager Transmitter
Data
Transmission
Pager
RS232C
Communication
Adapter on
Modem
Data
Communication
1-4 « MICROSMART USER’S MANUAL »
Modem
Computer
1: GENERAL INFORMATION
Computer Link System
When the MicroSmart is connected to a computer, operating status and I/O status can be monitored on the computer, data
in the CPU module can be monitored or updated, and user programs can be downloaded and uploaded. When an optional
RS485 communication adapter is installed on the port 2 connector of the all-in-one 16- or 24-I/O type CPU modules or
when an optional RS485 communication module is mounted with any slim type CPU modules, a maximum of 32 CPU
modules can be connected to one computer in the 1:N computer link system.
For details about the computer link communication, see pages 4-1 and 26-1.
Computer Link 1:1 Communication
Computer Link Cable 4C
3m (9.84 ft.) long
Computer Link Cable 4C
3m (9.84 ft.) long
Computer Link 1:N Communication
FC2A-KC4C
FC2A-KC4C
Port 1
RS232C Communication
Adapter on Port 2 Connector
RS232C Communication Module
Port 2
All-in-One 16- or 24-I/O Type CPU Module
All-in-One Type CPU Module
Slim Type CPU Module
Port 1
Adapter on Port 2 Connector
RS232C/RS485 Converter
FC2A-MD1
RS232C Cable
HD9Z-C52
1.5m (4.92 ft.) long
Twisted-pair Shielded Cable
RS485 Communication Module
« MICROSMART USER’S MANUAL »1-5
RS485 Communication
1st Unit
2nd Unit
Slim Type CPU Module
32nd Unit
Port 2
1: GENERAL INFORMATION
Data Link System
With an optional RS485 communication adapter installed on the port 2 connector, one 16- or 24-I/O type CPU module at
the master station can communicate with 31 slave stations through the RS485 line to exchange data and perform distributed control effectively. The RS485 terminals are connected with each other using a 2-core twisted pair cable.
The same data link system can also be set up using any slim type CPU modules mounted with RS485 communication
modules.
For details about the data link communication, see page 25-1.
Master Station Slave Station 1 Slave Station 31
Basic System
The all-in-one 10-I/O type CPU module has 6 input terminals and 4 output terminals. The 16-I/O type CPU module has 9
input terminals and 7 output terminals. The 24-I/O type CPU module has 14 input terminals and 10 output terminals. Only
the 24-I/O type CPU module has an expansion connector to connect I/O modules. When four 16-point input or output
modules are connected to the 24-I/O type CPU module, the I/O points can be expanded to a maximum of 88 points.
Any slim type CPU module can add a maximum of seven expansion I/O modules.
4 I/O modules maximumAll-in-One 24-I/O Type CPU Module
1-6 « MICROSMART USER’S MANUAL »
1: GENERAL INFORMATION
Operator Interface Communication System
The MicroSmart can communicate with IDEC’s HG series operator interfaces through RS232C port 1 and port 2.
Optional cables are available for connection between the
an optional RS232C communication adapter on the all-in-one type CPU module or an optional RS232C communication
module on the slim type CPU module, two operator interfaces can be connected to one MicroSmart CPU module.
For details about communication settings, see the user’s manual for the operator interface.
To RS232C Por t 1 or 2
MicroSmart and HG series operator interfaces. When installing
O/I Communication Cable
Applicable Cables to Operator Interfaces
Operator Interface O/I Communication Cable For Use on MicroSmart
HG1B, HG2A Series
HG2F, HG3F, HG4F Series
HG series Operator Interface
FC4A-KC1C RS232C port 1 and port 2
HG9Z-XC183 Por t 2 only
FC4A-KC2C RS232C port 1 and port 2
HG9Z-3C125 Port 2 only
« MICROSMART USER’S MANUAL »1-7
1: GENERAL INFORMATION
AS-Interface Network
Actuator-Sensor-Interface, abbreviated AS-Interface
The MicroSmart can be connected to the AS-Interface network using the AS-Interface master module (FC4A-AS62M).
AS-Interface is a type of field bus that is primarily intended to be used to control sensors and actuators. AS-Interface is a
network system that is compatible with the IEC62026 standard and is not proprietary to any one manufacturer. A master
device can communicate with slave devices such as sensors, actuators, and remote I/Os, using digital and analog signals
transmitted over the AS-Interface bus.
The AS-Interface system is comprised of the following three major components:
• One master, such as the MicroSmart AS-Interface master module
• One or more slave devices, such as sensors, actuators, switches, and indicators
• Dedicated 30V DC AS-Interface power supply (26.5 to 31.6V DC)
These components are connected using a two-core cable for both data transmission and AS-Interface power supply. ASInterface employs a simple yet efficient wiring system and features automatic slave address assignment function, while
installation and maintenance are also very easy.
For details about AS-Interf ace communication, see a separate user’s manual for the MicroSmart AS-Interface master module (manual No. FC9Y-B644).
Maximum Communication Distance
Without repeater: 100 m
With 2 repeaters: 300 m
MicroSmart AS-Interface Master Module
PS2R AS-Interface Power Supply
SX5A AS-Interface
Communication Terminal
IP67 Outside-panel Type
Sensor
AS-Interface
Gateway
SX5A AS-Interface
Communication Terminal
IP20 Inside-panel Type
Sensor
(AS-Interface Direct
Connection Type)
Manifold Solenoid Valve
Open Network (DeviceNet, CC-Link)
Light Tower
(AS-Interface
Direct
Connection Type)
AS-Interface Safety at Work
AS-Interface
Safety Monitor
Light Curtain
Emergency
Stop Switch
SwitchNet Control Units
(AS-Interface Direct Connection Type)
TM
SwitchNet is an IDEC trademark for pushbuttons, pilot lights, and other control units
capable of direct connection to the AS-Interface. SwitchNet devices are completely
compatible with AS-Interface Ver. 2.1.
1-8 « MICROSMART USER’S MANUAL »
The AS-Interface Safety Monitor is required
to connect safety devices, such as the light
curtain and emer gency stop switch, to the
AS-Interface line.
2: MODULE SPECIFICATIONS
Introduction
This chapter describes MicroSmart modules, parts names, and specifications of each module.
Available modules include all-in-one type and slim type CPU modules, digital input modules, digital output modules,
mixed I/O modules, analog I/O modules, HMI module, HMI base module, communication adapters, communication modules, memory cartridge, and clock cartridge.
CPU Modules (All-in-One Type)
All-in-one type CPU modules are available in 10-, 16-, and 24-I/O types. The 10-I/O type has 6 input and 4 output terminals, the 16-I/O type 9 input and 7 output terminals, and the 24-I/O type 14 input and 10 output terminals. Every all-in-one
type CPU module has communication port 1 for RS232C communication. In addition, the 16- and 24-I/O type CPU modules have port 2 connector to install an optional RS232C or RS485 communication adapter for 1:N computer link, modem
communication, or data link communication. Every all-in-one type CPU module has a cartridge connector to install an
optional memory cartridge or clock cartridge.
CPU Module Type Numbers (All-in-One Type)
Power Voltage 10-I/O Type 16-I/O Type 24-I/O Type
100 -240V AC (50/60 Hz) FC4A-C10R2 FC4A-C16R2 FC4A-C24R2
24V DC FC4A-C10R2C FC4A-C16R2C FC4A-C24R2C
Parts Description (All-in-One Type)
(2) Sensor Power Terminals
(12) Port 1
(13) Analog Potentiometer
(14) Port 2 Connector
Bottom View
(1) Power Supply Terminals
(15) Cartridge Connector
(16) Terminal Cover
(17) Hinged Lid
(4) Output Terminals
(3) Input Terminals
(5) Expansion Connector
(6) Input LED (IN)
From Left:
(7) Power LED (PWR)
(8) Run LED (RUN)
(9) Error LED (ERR)
(10) Status LED (STAT)
(11) Output LED (OUT)
(20) Expansion
Connector
Seal
These figures illustrate the 24-I/O
type CPU module.
Functions of each part are described
on the following page.
(18) HMI Connector Cover
(16) Terminal Cover
(19) Dummy Cartridge
« MICROSMART USER’S MANUAL »2-1
2: MODULE SPECIFICATIONS
(1) Power Supply Terminals
Connect power supply to these terminals. Power voltage 100-240V AC or 24V DC. See page 3-16.
(2) Sensor Power Terminals (AC power type only)
For supplying power to sensors (24V DC, 250mA). These terminals can be used for supplying power to input circuits.
Use the sensor power supply only for supplying power to input devices connected to the MicroSmart.
(3) Input Terminals
For connecting input signals from input devices such as sensors, pushbuttons, and limit switches. The input terminals
accept both sink and source DC input signals.
(4) Output Terminals
For connecting output signals to output devices such as electromechanical relays and solenoid valv es. The internal output relay is rated at 240V AC/2A or 30V DC/2A.
(5) Expansion Connector (24-I/O type CPU module only)
For connecting digital and analog I/O modules to the 24-I/O type CPU module.
(6) Input LED (IN)
Turns on when a corresponding input is on.
10-I/O Type
(7) Power LED (PWR)
LED Indicators
IN
012345
Turns on when power is supplied to the CPU module.
(8) Run LED (RUN)
Turns on when the CPU module is executing the user program.
(9) Error LED (ERR)
Turns on when an error has occurred in the CPU module.
16-I/O Type
PRES012 3
WRUNR
T
A
T
R
0123456710
OUT
IN
(10) Status LED (STAT)
The status LED can be turned on or off using the user program
to indicate a specified status.
(11) Output LED (OUT)
Turns on when a corresponding output is on.
24-I/O Type
PRES0123456
WRUNR
01234567101112131415
T
A
T
R
OUT
(12) Port 1 (RS232C)
For connecting a computer to download a user program and
monitor the PLC operation on a computer using WindLDR.
PRES012345671011
WRUNR
T
A
T
R
(13) Analog Potentiometer
Sets a value of 0 through 255 to a special data register. The 10- and 16-I/O types have one potentiometer. The 24-I/O
type has two potentiometers. The analog potentiometer can be used to set a preset value for an analog timer.
(14) Port 2 Connector (16- and 24-I/O type CPU modules only)
For connecting an optional RS232C or RS485 communication adapter.
IN
OUT
(15) Cartridge Connector
For connecting an optional memory cartridge or clock cartridge.
(16) Terminal Cover
For protecting the input and output terminals. When wiring the terminals, open the covers.
(17) Hinged Lid
Open the lid to gain access to the port 1, port 2 connector, and analog potentiometer.
(18) HMI Connector Cover
Remove the HMI connector cover when using an optional HMI module.
(19) Dummy Cartridge
Remove the dummy cartridge when using an optional memory cartridge or clock cartridge.
(20) Expansion Connector Seal (24-I/O type CPU module only)
Remove the expansion connector seal when connecting a digital or analog I/O module.
2-2 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
General Specifications (All-in-One Type CPU Module)
Normal Operating Conditions
CPU Module
Operating Temperature 0 to 55°C (operating ambient temperature)
Storage Temperature –25 to +70°C
Relative Humidity 10 to 95% (non-condensing)
Pollution Degree 2 (IEC 60664-1)
Degree of Protection IP20 (IEC 60529)
Corrosion Immunity Atmosphere free from corrosive gases
Altitude
Vibration Resistance
Shock Resistance
ESD Immunity Contact discharge: ±6 kV, Air discharge: ±8 kV (IEC 61000-4-2)
Weight
AC Power Type FC4A-C10R2 FC4A-C16R2 FC4A-C24R2
DC Power Type FC4A-C10R2C FC4A-C16R2C FC4A-C24R2C
Operation: 0 to 2,000m (0 to 6,565 feet)
Transport: 0 to 3,000m (0 to 9,840 feet)
When mounted on a DIN rail or panel surface:
5 to 9 Hz amplitude 3.5 mm, 9 to 150 Hz acceleration 9.8 m/sec
2 hours per axis on each of three mutually perpendicular axes (IEC 61131-2)
2
147 m/sec
ular axes (IEC 61131-2)
AC Power Type 230g 250g 305g
DC Power Type 240g 260g 310g
(15G), 11 msec duration, 3 shocks per axis on three mutually perpendic-
2
(1G)
Power Supply
Rated Power Voltage AC power type: 100 to 240V AC, DC power type: 24V DC
Allowable Voltage Range AC power type: 85 to 264V AC, DC power type: 20.4 to 28.8V DC (including ripple)
Rated Power Frequency AC power type: 50/60 Hz (47 to 63 Hz)
Maximum Input Current
Maximum
Power
Consumption
Allowable Momentary Power
Interruption
Dielectric Strength
Insulation Resistance
Noise Resistance
Inrush Current 35A maximum 35A maximum 40A maximum
Grounding Wire UL1007 AWG16
Power Supply Wire UL1015 AWG22, UL1007 AWG18
Effect of Improper Power
Supply Connection
AC Power Type
DC Power Type
250 mA (85V AC)
160 mA (24V DC)
FC4A-C10R2: 30VA (264V AC), 20VA (100V AC) (CPU module*)
FC4A-C16R2: 31VA (264V AC), 22VA (100V AC) (CPU module*)
FC4A-C24R2: 40VA (264V AC), 33VA (100V AC) (CPU module* + 4 I/O modules)
*The CPU module power consumption includes 250mA sensor power.
FC4A-C10R2C: 3.9W (24V DC) (CPU module)
FC4A-C16R2C: 4.6W (24V DC) (CPU module)
FC4A-C24R2C: 8.7W (24V DC) (CPU module + 4 I/O modules)
10 msec (at the rated power voltage)
Between power and or terminals: 1,500V AC, 1 minute
Between I/O and or terminals: 1,500V AC, 1 minute
Between power and or terminals: 10 MΩ minimum (500V DC megger)
Between I/O and or terminals: 10 MΩ minimum (500V DC megger)
AC or DC power terminals: 1.5 kV, 50 nsec to 1 µsec
I/O terminals (coupling clamp): 1.5 kV, 50 nsec to 1 µsec
Reverse polarity: Normal operation (AC), No operation, no damage (DC)
Improper voltage or frequency: Permanent damage may be caused
Improper lead connection: Permanent damage may be caused
300 mA (85V AC)
190 mA (24V DC)
450 mA (85V AC)
360 mA (24V DC)
Note: The maximum number of relay outputs that can be turned on simultaneously is 33 points (AC power type CPU module)
or 44 points (DC power type CPU module) including relay outputs on the CPU module.
« MICROSMART USER’S MANUAL »2-3
2: MODULE SPECIFICATIONS
Function Specifications (All-in-One Type CPU Module)
CPU Module Specifications
CPU Module
Program Capacity
Expandable I/O Modules ——4 modules
I/O Points
User Program Storage EEPROM
RAM Backup
Control System Stored program system
Instruction Words
Processing
Time
Internal Relay 256 1024 1024
Shift Register 64 128 128
Data Register 400 1300 1300
Counter
(adding, dual pulse reversible,
up/down selection reversible)
Timer
(1-sec, 100-msec, 10-msec, 1-msec)
Input Filter 3 to 15 msec (selectable in increments of 1 msec)
Catch Input
Interrupt Input
Self-diagnostic Function
Start/Stop Method
Input 6914
Output 4710
Backup Duration Approx. 30 days (typical) at 25°C after backup battery fully charged
Backup Data Internal relay, shift register, counter, data register
Battery Lithium secondary battery
Charging Time Approx. 24 hours for charging from 0% to 90% of full charge at 25°C
Battery Life Approx. 1000 cycles of discharging down to 10% and full charging
Replaceability Impossible to replace battery
Basic instruction 1.65 msec (1000 steps) See page A-1.
END processing
FC4A-C10R2
FC4A-C10R2C
4,800 bytes
(800 steps)
35 basic
38 advanced
0.64 msec (not including expansion I/O service, clock function processing, data
link processing, and interrupt processing) See page A-2.
32 100 100
32 100 100
Four inputs (I2 through I5) can be designated as catch inputs or interrupt inputs
Minimum turn on pulse width: 40 µsec maximum
Minimum turn off pulse width: 150 µsec maximum
Power failure, watchdog timer, data link connection, user program EEPROM sum
check, timer/counter preset value sum check, user program RAM sum check,
keep data, user program syntax, user program writing, CPU module, clock IC, I/O
bus initialize, user program execution
Turning power on and off
Start/stop command in WindLDR
Turning start control special internal relay M8000 on and of f
Turning designated stop or reset input off and on
FC4A-C16R2
FC4A-C16R2C
15,000 bytes
(2,500 steps)
35 basic
40 advanced
27,000 bytes
(4,500 steps)
35 basic
46 advanced
FC4A-C24R2
FC4A-C24R2C
Expansion:
64
System Statuses at Stop, Reset, and Restart
Internal Relay, Shift Register,
Mode Output
Run Operating Operating Operating Operating
Stop (Stop input ON) OFF Unchanged Unchanged Unchanged
Reset (Reset input ON) OFF OFF/Reset to zero OFF/Reset to zero Reset to zero
Restart Unchanged Unchanged OFF/Reset to zero Reset to preset
2-4 « MICROSMART USER’S MANUAL »
Counter, Data Register
Keep Type Clear Type
Timer Current Value
2: MODULE SPECIFICATIONS
Communication Function
Communication Port Port 1 (RS232C)
Standards EIA RS232C EIA RS232C EIA RS485
Maximum Baud Rate 19,200 bps 19,200 bps
Maintenance Communication
(Computer Link)
User Communication Possible Possible Impossible
Modem Communication Impossible Possible Impossible
Data Link Communication Impossible Impossible Possible
Quantity of Slave Stations —— 31
Maximum Cable Length Special cable Special cable 200m *
Isolation between Internal Circuit
and Communication Port
* Recommended cable for RS485: Twisted-pair shielded cable with a minimum core wire of 0.3 mm2.
Conductor resistance 85 Ω/km maximum, shield resistance 20 Ω/km maximum.
Possible Possible Possible
Not isolated Not isolated Not isolated
Port 2 (RS232C)
Communication Adapter
Built-in Functions
Total 4 points
Single/two-phase selectable: 20 kHz (1 point)
Single-phase: 5 kHz (3 points)
1 point (10- and 16-I/O type CPU)
2 points (24-I/O type CPU)
High-speed Counter
Sensor Power Supply
(AC power type only)
Analog Potentiometer
Maximum Counting Frequency
and High-speed Counter Points
Counting Range 0 to 65535 (16 bits)
Operation Mode Rotar y encoder mode and adding counter mode
Output Voltage/Current 24V DC (+10% to –15%), 250 mA
Overload Detection Not available
Isolation Isolated from the internal circuit
Quantity
Data Range 0 to 255
Port 2 (RS485)
Communication Adapter
Computer link: 19,200 bps
Data link: 38,400 bps
Memory Cartridge (Option)
Memory Type EEPROM
Accessible Memory Capacity 32 KB
Hardware for Storing Data CPU module
Software for Storing Data WindLDR
Quantity of Stored Programs One user program can be stored on one memor y car tridge.
Program Execution Priority
When a memory cartridge is installed, the user program on the memory car tridge is
executed.
Clock Cartridge (Option)
Accuracy ±30 sec/month (typical) at 25°C
Backup Duration Approx. 30 days (typical) at 25°C after backup battery fully charged
Battery Lithium secondary battery
Charging Time Approx. 10 hours for charging from 0% to 90% of full charge
Battery Life Approx. 100 recharge cycles after discharging down to 10% of full charge
Replaceability Impossible to replace battery
« MICROSMART USER’S MANUAL »2-5
2: MODULE SPECIFICATIONS
DC Input Specifications (All-in-One Type CPU Module)
CPU Module
Input Points and Common Line
FC4A-C10R2
FC4A-C10R2C
6 points
in 1 common line
FC4A-C16R2
FC4A-C16R2C
9 points
in 1 common line
FC4A-C24R2
FC4A-C24R2C
14 points
in 1 common line
Ter minal Arrangement See CPU Module Terminal Arrangement on pages 2-8 and 2-9.
Rated Input Voltage 24V DC sink/source input signal
Input Voltage Range 20.4 to 28.8V DC
Rated Input Current
Input Impedance
Turn ON Time
Turn OFF Time
Isolation
I0 and I1: 11 mA
I2 to I7, I10 to I15: 7 mA/point (24V DC)
I0 and I1: 2.1 kΩ
I2 to I7, I10 to I15: 3.4 kΩ
I0 to I5: 35 µsec + filter value
I6, I7, I10 to I15: 40 µsec + filter value
I0 and I1: 45 µsec + filter value
I2 to I7, I10 to I15: 150 µsec + filter value
Between input terminals: Not isolated
Internal circuit: Photocoupler isolated
Input Type Type 1 (IEC 61131)
External Load for I/O Interconnection Not needed
Signal Determination Method Static
Effect of Improper Input Connection
Both sinking and sourcing input signals can be connected. If any input
exceeding the rated value is applied, permanent damage may be caused.
Cable Length 3m (9.84 ft.) in compliance with electromagnetic immunity
Input Operating Range Input Internal Circuit
The input operating range of the Type 1
(IEC 61131-2) input module is shown
below:
Inputs I0 and I1
28.8
24
15
5
Input Voltage (V DC)
0
1.2 13.8
Input Current (mA)
Inputs I2 to I15
28.8
24
15
5
Input Voltage (V DC)
0
1.2 8.4
Input Current (mA)
11.36.5
ON Area
Transition
Area
OFF Area
ON Area
Transition
Area
OFF Area
74.2
Inputs I0 and I1 Inputs I2 to I15
Input
COM
1.8 kΩ
I/O Usage Limits
When using the FC4A-C16R2/C or FC4A-C24R2/C at an ambient temperature
of 55°C in the normal mounting direction, limit the inputs and outputs,
respectively, which turn on simultaneously along line (1).
28.8
26.4
Input Voltage (V DC)
0
I/O Simultaneous ON Ratio (%)
(2) 45°C
(1) 55°C
Input
COM
Internal Circuit
3.3 kΩ
Internal Circuit
When using at 45°C, all I/Os can be
turned on simultaneously at input voltage 28.8V DC as indicated with line
(2).
When using the FC4A-C10R2/C, all
I/Os can be turned on simultaneously
at 55°C, input voltage 28.8V DC.
For other possible mounting directions, see page 3-12.
700
100
2-6 « MICROSMART USER’S MANUAL »
Relay Output Specifications (All-in-One Type CPU Module)
2: MODULE SPECIFICATIONS
CPU Module
FC4A-C10R2
FC4A-C10R2C
FC4A-C16R2
FC4A-C16R2C
FC4A-C24R2
FC4A-C24R2C
No. of Outputs 4 points 7 points 10 points
COM0 3 NO contacts 4 NO contacts 4 NO contacts
Output Points per Common Line
COM1 1 NO contact 2 NO contacts 4 NO contacts
COM2 —1 NO contact 1 NO contact
COM3 ——1 NO contact
Ter minal Arrangement See CPU Module Terminal Arrangement on pages 2-8 and 2-9.
Maximum Load Current
2A per point
8A per common line
Minimum Switching Load 0.1 mA/0.1V DC (reference value)
Initial Contact Resistance 30 mΩ maximum
Electrical Life 100,000 operations minimum (rated load 1,800 operations/hour)
Mechanical Life 20,000,000 operations minimum (no load 18,000 operations/hour)
Rated Load (resistive/inductive) 240V AC/2A, 30V DC/2A
Between output and or terminals: 1,500V AC, 1 minute
Dielectric Strength
Between output terminal and internal circuit: 1,500V AC, 1 minute
Between output terminals (COMs): 1,500V AC, 1 minute
Contact Protection Circuit for Relay Output See page 3-15.
Output Delay
Command
Output Relay Status
ON
OFF
ON
OFF
OFF delay: 10 msec maximum
Chatter: 6 msec maximum
ON delay: 6 msec maximum
« MICROSMART USER’S MANUAL »2-7
2: MODULE SPECIFICATIONS
CPU Module Terminal Arrangement (All-in-One Type)
The input and output terminal arrangements of the all-in-one type CPU modules are shown below.
AC Power Type CPU Module
FC4A-C10R2
Sensor Power Terminals
Input Terminals
AC Power Terminals
Output Terminals
+24V 0V
DC IN 0 1 2 3 4 5
DC OUT COM
100-240VAC Ry.OUT Ry.OUT
LN
COM0 COM1 30 1 2
FC4A-C16R2
FC4A-C24R2
Sensor Power Terminals
Input Terminals
AC Power Terminals
Output Terminals
Sensor Power Terminals
Input Terminals
+24V 0V 10
DC IN 0 1 2 3 4 5 6 7
DC OUT COM
100-240VAC Ry.OUT
LN
+24V 0V 10 11 12 13 14 15
DC OUT COM
COM0
DC IN 0 1 2 3 4 5 6 7
Ry.OUT
COM1 4 5
Ry.OUT
COM2 60 1 2 3
AC Power Terminals
LN
COM0
100-240VAC Ry.OUT
Output Terminals
2-8 « MICROSMART USER’S MANUAL »
Ry.OUT
COM1
Ry.OUT
COM2 100 1 2 3 4 5 6 7
Ry.OUT
COM3 11
FC4A-C10R2C
Ry.OUT Ry.OUT
COM0 COM1 30 1 2
COM
DC IN 0 1 2 3 4 5
+–
24VDC
Input Terminals
DC Power Terminals
Output Terminals
10
COM
DC IN 0 1 2 3 4 5 6 7
Ry.OUT
COM0
Ry.OUT
COM1 4 5
Ry.OUT
COM2 60 1 2 3
+–
24VDC
Input Terminals
DC Power Terminals
Output Terminals
10 11 12 13 14 15
COM
DC IN 0 1 2 3 4 5 6 7
Ry.OUT
COM0
Ry.OUT
COM1
Ry.OUT
COM3 11
Ry.OUT
COM2 100 1 2 3 4 5 6 7
+–
24VDC
Input Terminals
DC Power Terminals
Output Terminals
2: MODULE SPECIFICATIONS
DC Power Type CPU Module
FC4A-C16R2C
FC4A-C24R2C
« MICROSMART USER’S MANUAL »2-9
2: MODULE SPECIFICATIONS
I/O Wiring Diagrams (All-in-One Type CPU Module)
The input and output wiring examples of the CPU modules are shown below. For wiring precautions, see pages 3-13
through 3-16.
AC Power Type CPU Module DC Power Type CPU Module
DC Source Input Wiring DC Source Input Wiring
External
Sensor
Power
Power
–
+
–
+
2-wire
Sensor
External
Power
–
+
–
+
2-wire
Sensor
+24V 0V
DC IN 0 1 2 3 4 5
DC OUT COM
DC IN 0 1 2 3 4 5
COM
DC Sink Input Wiring DC Sink Input Wiring
Sensor
Power
External
+
Power
–
+24V 0V
DC IN 0 1 2 3 4 5
DC OUT COM
+
–
2-wire
Sensor
External
+
Power
–
DC IN 0 1 2 3 4 5
COM
AC Power and Relay Output Wiring DC Power and Relay Output Wiring
+
–
2-wire
Sensor
100-240VAC Ry.OUT Ry.OUT
LN
Fuse
COM0 COM1 30 1 2
L
+
–
N
L
LLL L
+
–
N
Fuse
Fuse
Load
2-10 « MICROSMART USER’S MANUAL »
24VDC
+–
+–
Ry.OUT Ry.OUT
COM0 COM1 30 1 2
L
+
–
N
LLL L
Fuse
L
+
Load
–
N
2: MODULE SPECIFICATIONS
CPU Modules (Slim Type)
Slim type CPU modules are available in 20- and 40-I/O types. The 20-I/O type has 12 input and 8 output terminals, and the
40-I/O type has 24 input and 16 output terminals. The FC4A-D20RK1 and FC4A-D20RS1 have 2 transistor outputs used
for high-speed counter and pulse outputs in addition to 10 relay outputs. Every slim type CPU module has communication
port 1 for RS232C communication, and can mount an optional RS232C or RS485 communication module for 1:N computer link, modem communication, and data link communication. The HMI base module can also be mounted to install an
optional HMI module and a communication adapter. Every slim type CPU module has two cartridge connectors to install
an optional memory cartridge and a clock cartridge.
CPU Module Type Numbers (Slim Type)
I/O Points Output Type High-speed Transistor Output (Q0 & Q1) Type No.
20 (12 in / 8 out)
20 (12 in / 8 out)
40 (24 in / 16 out)
Parts Description (Slim Type)
Transistor Sink Output 0.3A FC4A-D20K3
Transistor Source Output 0.3A FC4A-D20S3
Relay Output
240V AC/30V DC, 2A
Sink Output 0.3A FC4A-D20RK1
Source Output 0.3A FC4A-D20RS1
Transistor Sink Output 0.3A FC4A-D40K3
Transistor Source Output 0.3A FC4A-D40S3
(10) Analog Potentiometer
(11) Analog Voltage Input Connector
(15) Communication Connector
Side View
(12) Port 1
(13) Cartridge Connector 1
(14) Cartridge Connector 2
(1) Power Supply Terminals (2) I/O Terminals
(16) Hinged Lid
(3) Expansion Connector
(4) Power LED (PWR)
(5) Run LED (RUN)
(6) Error LED (ERR)
(7) Status LED (STAT)
(8) Input LED (DC.IN)
(9) Output LED (Tr.OUT or Ry.OUT)
(18) Expansion
Connector
Seal
These figures illustrate the 40-I/O
type CPU module.
Functions of each part are described
on the following page.
(17) Dummy Cartridges
« MICROSMART USER’S MANUAL » 2-11
2: MODULE SPECIFICATIONS
(1) Power Supply Terminals
Connect power supply to these terminals. Power voltage 24V DC. See page 3-17.
(2) I/O Terminals
For connecting input and output signals. The input terminals accept both sink and source 24V DC input signals. Transistor and relay output types are available. Transistor output type has MIL connectors and relay output type has removable screw connectors.
(3) Expansion Connector
For connecting digital and analog I/O modules.
(4) Power LED (PWR)
Turns on when power is supplied to the CPU module.
(5) Run LED (RUN)
Turns on when the CPU module is executing the user program.
(6) Error LED (ERR)
Turns on when an error occurs in the CPU module.
(7) Status LED (STAT)
The status LED can be turned on or off using the user program to
indicate a specified status.
(8) Input LED (IN)
Turns on when a corresponding input is on.
(9) Output LED (Tr.OUT or Ry.OUT)
Turns on when a corresponding output is on.
(10) Analog Potentiometer
Sets a value of 0 through 255 to a special data register. All slim
type CPU modules have one potentiometer, which can be used to
set a preset value for an analog timer.
(11) Analog Voltage Input Connector
For connecting an analog voltage source of 0 through 10V DC. The
analog voltage is converted to a value of 0 through 255 and stored
to a special data register.
(12) Port 1 (RS232C)
For connecting a computer to download a user program and monitor the PLC operation on a computer using WindLDR.
(13) Cartridge Connector 1
For connecting an optional memory cartridge or clock cartridge.
(14) Cartridge Connector 2
For connecting an optional memory cartridge or clock cartridge.
(15) Communication Connector
For connecting an optional communication module or HMI base
module. Remove the connector cover before connecting a module.
(16) Hinged Lid
Open the lid to gain access to the port 1, cartridge connectors 1 and
2, analog potentiometer, and analog voltage input connector.
(17) Dummy Cartridges
Remove the dummy cartridge when using an optional memory cartridge or clock cartridge.
20-I/O Type (Transistor Output)
20-I/O Type (Relay Output)
40-I/O Type (Transistor Output)
LED Indicators
PWR
RUN
ERR
STAT
0
1
2
3
4
5
6
7
10
11
PWR
RUN
ERR
STAT
0
1
2
3
DC.IN
PWR
RUN
ERR
STAT
0
1
2
3
4
5
6
7
10
11
Tr.OUT Tr.OUT
DC.IN
4
5
6
7
10
11
12
13
12
13
0
1
2
3
4
5
6
7
12
13
DC.
IN
0
1
2
3
4
5
6
7
Tr.OUT
Ry.OUT
DC.IN
14
15
16
17
20
21
22
23
24
25
26
27
0
1
2
3
4
5
6
7
Tr.
OUT
10
11
12
13
14
15
16
17
(18) Expansion Connector Seal
Remove the expansion connector seal when connecting a digital I/O or analog I/O module.
2-12 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
General Specifications (Slim Type CPU Module)
Normal Operating Conditions
CPU Module
Operating Temperature 0 to 55°C (operating ambient temperature)
Storage Temperature –25 to +70°C
Relative Humidity 10 to 95% (non-condensing)
Pollution Degree 2 (IEC 60664-1)
Degree of Protection IP20 (IEC 60529)
Corrosion Immunity Atmosphere free from corrosive gases
Altitude
Vibration Resistance
Shock Resistance
ESD Immunity Contact discharge: ±6 kV, Air discharge: ±8 kV (IEC 61000-4-2)
Weight 140g 185g 180g
FC4A-D20K3
FC4A-D20S3
Operation: 0 to 2,000m (0 to 6,565 feet)
Transport: 0 to 3,000m (0 to 9,840 feet)
When mounted on a DIN rail or panel surface:
5 to 9 Hz amplitude 3.5 mm, 9 to 150 Hz acceleration 9.8 m/sec
2 hours per axis on each of three mutually perpendicular axes (IEC 61131-2)
2
147 m/sec
ular axes (IEC 61131-2)
(15G), 11 msec duration, 3 shocks per axis on three mutually perpendic-
FC4A-D20RK1
FC4A-D20RS1
FC4A-D40K3
FC4A-D40S3
2
(1G)
Power Supply
Rated Power Voltage 24V DC
Allowable Voltage Range 20.4 to 26.4V DC (including ripple)
Maximum Input Current 560 mA (26.4V DC) 700 mA (26.4V DC) 700 mA (26.4V DC)
Maximum Power Consumption
Allowable Momentary Power
Interruption
Dielectric Strength
Insulation Resistance
Noise Resistance
Inrush Current 50A maximum (24V DC)
Grounding Wire UL1015 AWG22, UL1007 AWG18
Power Supply Wire UL1015 AWG22, UL1007 AWG18
Effect of Improper Power
Supply Connection
Note: The maximum number of relay outputs that can be turned on simultaneously is 96 points including relay outputs on
the CPU module.
CPU module + 7 I/O modules
14W (26.4V DC) 17W (26.4V DC) 17W (26.4V DC)
10 msec (at 24V DC)
Between power and terminals: 500V AC, 1 minute
Between I/O and terminals: 1,500V AC, 1 minute
Between power and terminals: 10 MΩ minimum (500V DC megger)
Between I/O and terminals: 10 MΩ minimum (500V DC megger)
DC power terminals: 1.0 kV, 50 nsec to 1 µsec
I/O terminals (coupling clamp): 1.5 kV, 50 nsec to 1 µsec
Reverse polarity: No operation, no damage
Improper voltage or frequency: Permanent damage may be caused
Improper lead connection: Permanent damage may be caused
« MICROSMART USER’S MANUAL » 2-13
2: MODULE SPECIFICATIONS
Function Specifications (Slim Type CPU Module)
CPU Module Specifications
CPU Module
Program Capacity
Expandable I/O Modules 7 modules
I/O Points
User Program Storage EEPROM
RAM Backup
Control System Stored program system
Instruction Words
Processing
Time
Internal Relay 1024 1024 + 560 for AS-Interface operands (Note 2)
Shift Register 128
Data Register 1300 1300 + 300 for AS-Inter face operands (Note 2)
Expansion Data Register —6,000
Counter 100 (adding, dual pulse reversible, up/down selection reversible)
Timer 100 (1-sec, 100-msec, 10-msec, 1-msec)
Input Filter 3 to 15 msec (selectable in increments of 1 msec)
Catch Input
Interrupt Input
Self-diagnostic Function
Start/Stop Method
Note 1: When using a 64KB memory cartridge and WindLDR ver. 4.2 or higher.
Note 2: When using a CPU module with system program ver. 201 or higher and WindLDR ver. 4.2 or higher.
Input 12
Output 8816
Backup Duration Approx. 30 days (typical) at 25°C after backup batter y fully charged
Backup Data Internal relay, shift register, counter, data register, expansion data register
Battery Lithium secondar y batter y
Charging Time Approx. 24 hours for charging from 0% to 90% of full charge at 25°C
Battery Life Approx. 1000 cycles of discharging down to 10% and full charging
Replaceability Impossible to replace battery
Basic instruction 1.65 msec (1000 steps) See page A-1.
END processing
FC4A-D20K3
FC4A-D20S3
27,000 bytes
(4,500 steps)
Expansion: 128
35 basic
53 advanced
0.64 msec (not including expansion I/O service, clock function processing, data
link processing, and interrupt processing) See page A-2.
Four inputs (I2 through I5) can be designated as catch inputs or interrupt inputs
Minimum turn on pulse width: 40 µsec maximum
Minimum turn off pulse width: 150 µsec maximum
Power failure, watchdog timer, data link connection, user program EEPROM sum
check, timer/counter preset value sum check, user program RAM sum check,
keep data, user program syntax, user program writing, CPU module, clock IC, I/O
bus initialize, user program execution
Turning power on and off
Start/stop command in WindLDR
Turning start control special internal relay M8000 on and of f
Turning designated stop or reset input off and on
FC4A-D20RK1
FC4A-D20RS1
31,200 bytes (5,200 steps)
64,500 bytes (10,750 steps) (Note 1, Note 2)
12
35 basic
72 advanced
Expansion: 224
24
FC4A-D40K3
FC4A-D40S3
Expansion: 224
System Statuses at Stop, Reset, and Restart
Internal Relay, Shift Register, Counter,
Mode Output
Run Operating Operating Operating Operating
Stop (Stop input ON) OFF Unchanged Unchanged Unchanged
Reset (Reset input ON) OFF OFF/Reset to zero OFF/Reset to zero Reset to zero
Restart Unchanged Unchanged OFF/Reset to zero Reset to preset
Note: All expansion data registers are keep types. AS-Inter face operands (M1300-M1977 and D1700-D1999) remain
unchanged when the reset input is turned on.
2-14 « MICROSMART USER’S MANUAL »
Data Register, Expansion Data Register
Keep Type Clear Type
Timer Current Value
2: MODULE SPECIFICATIONS
Communication Function
Port 2 (RS232C)
Communication Port Port 1 (RS232C)
Standards EIA RS232C EIA RS232C EIA RS485
Maximum Baud Rate 19,200 bps 19,200 bps
Maintenance Communication
(Computer Link)
User Communication Possible Possible Possible (Note 1)
Modem Communication Impossible Possible Impossible
Data Link Communication Impossible Impossible Possible
Quantity of Slave Stations —— 31
Maximum Cable Length Special cable Special cable 200m (Note 2)
Isolation between Internal Circuit
and Communication Port
Note 1: RS485 user communication is available on upgraded CPU modules only, see page 17-1.
Note 2: Recommended cable for RS485: Twisted-pair shielded cable with a minimum core wire of 0.3 mm
Conductor resistance 85 Ω/km maximum, shield resistance 20 Ω/km maximum.
Possible Possible Possible
Not isolated Not isolated Not isolated
Communication Module
Communication Adapter
Port 2 (RS485)
Communication Module
Communication Adapter
Computer link: 19,200 bps
User comm.: 19,200 bps
Data link: 38,400 bps
2
.
Built-in Functions
Total 4 points
Single/two-phase selectable: 20 kHz (2 points)
Single-phase: 5 kHz (2 points)
High-speed Counter
Analog Potentiometer
Analog Voltage Input
Pulse Output
Maximum Counting Frequency
and High-speed Counter Points
Counting Range 0 to 65535 (16 bits)
Operation Mode Rotar y encoder mode and adding counter mode
Quantity 1 point
Data Range 0 to 255
Quantity 1 point
Input Voltage Range 0 to 10V DC
Input Impedance Approx. 100 kΩ
Data Range 0 to 255
Quantity 2 points
Maximum Frequency 20 kHz
Memory Cartridge (Option)
Memory Type EEPROM
Accessible Memory Capacity 32 KB or 64 KB (64KB cartridge is for upgraded CPU modules only, see page 2-54)
Hardware for Storing Data CPU module
Software for Storing Data WindLDR
Quantity of Stored Programs One user program can be stored on one memor y car tridge.
Program Execution Priority
When a memory cartridge is installed, the user program on the memory car tridge is
executed.
Clock Cartridge (Option)
Accuracy ±30 sec/month (typical) at 25°C
Backup Duration Approx. 30 days (typical) at 25°C after backup battery fully charged
Battery Lithium secondary battery
Charging Time Approx. 10 hours for charging from 0% to 90% of full charge
Battery Life Approx. 100 recharge cycles after discharging down to 10% of full charge
Replaceability Impossible to replace battery
« MICROSMART USER’S MANUAL » 2-15
2: MODULE SPECIFICATIONS
DC Input Specifications (Slim Type CPU Module)
CPU Module
Input Points and Common Lines
FC4A-D20K3
FC4A-D20S3
12 points
in 1 common line
FC4A-D20RK1
FC4A-D20RS1
12 points
in 1 common line
FC4A-D40K3
FC4A-D40S3
24 points
in 2 common lines
Ter minal Arrangement See CPU Module Terminal Arrangement on pages 2-19 through 2-22.
Rated Input Voltage 24V DC sink/source input signal
Input Voltage Range 20.4 to 26.4V DC
Rated Input Current
Input Impedance
Turn ON Time
Turn OFF Time
Isolation
I0, I1, I6, I7: 5 mA/point (24V DC)
I2 to I5, I10 to I27: 7 mA/point (24V DC)
I0, I1, I6, I7: 5.7 kΩ
I2 to I5, I10 to I27: 3.4 kΩ
I0 to I7: 35 µsec + filter value
I10 to I27: 40 µsec + filter value
I0, I1, I6, I7: 45 µsec + filter value
I2 to I5, I10 to I27: 150 µsec + filter value
Between input terminals: Not isolated
Internal circuit: Photocoupler isolated
Input Type Type 1 (IEC 61131)
External Load for I/O Interconnection Not needed
Signal Determination Method Static
Effect of Improper Input Connection
Both sinking and sourcing input signals can be connected. If any input
exceeding the rated value is applied, permanent damage may be caused.
Cable Length 3m (9.84 ft.) in compliance with electromagnetic immunity
Connector on Mother Board
FL26A2MA
(Oki Electric Cable)
MC1.5/13-G-3.81BK
(Phoenix Contact)
FL26A2MA
(Oki Electric Cable)
Connector Insertion/Removal Durability 100 times minimum
Input Operating Range
The input operating range of the Type 1
(IEC 61131-2) input module is shown
below:
Inputs I0, I1, I6, and I7
26.4
24
15
5
Input Voltage (V DC)
0
1.2 12.4
Input Current (mA)
Inputs I2 to I5 and I10 to I27
26.4
24
15
5
Input Voltage (V DC)
0
1.2 7.7
Input Current (mA)
11.36.5
ON Area
Transition
Area
OFF Area
ON Area
Transition
Area
OFF Area
74.2
Input Internal Circuit
Inputs I0, I1, I6, and I7 Inputs I2 to I5 and I10 to I27
Input
COM
4.7 kΩ
Input
COM
Internal Circuit
3.3 kΩ
I/O Usage Limits
When using the FC4A-D20K3/S3 at an ambient temperature of 55°C in the
normal mounting direction, limit the inputs and outputs, respectively, which
turn on simultaneously along line (1).
When using the FC4A-D40K3/S3, limit the inputs and outputs, respectively,
which turn on simultaneously on each connector along line (2).
26.4
24.0
(2) 55°C
(1) 55°C
Input Voltage (V DC)
0
I/O Simultaneous ON Ratio (%)
(3) 40°C
50
60 70 800
100
When using at 40°C, all I/Os can
be turned on simultaneously at
26.4V DC as indicated with line (3).
When using the FC4A-D20RK1/
RS1, all I/Os can be turned on
simultaneously at 55°C, input voltage 26.4V DC.
Internal Circuit
2-16 « MICROSMART USER’S MANUAL »
Transistor Sink and Source Output Specifications (Slim Type CPU Module)
2: MODULE SPECIFICATIONS
FC4A-D20S3
FC4A-D20RS1
FC4A-D40S3
CPU Module
FC4A-D20K3
FC4A-D20RK1
FC4A-D40K3
Output Type Sink output Source output
FC4A-D20K3/S3: 8 points in 1 common line
Output Points and Common Lines
FC4A-D20RK1/RS1: 2 points in 1 common line
FC4A-D40K3/S3: 16 points in 2 common lines
Ter minal Arrangement See CPU Module Terminal Arrangement on pages 2-19 through 2-22.
Rated Load Voltage 24V DC
Operating Load Voltage Range 20.4 to 28.8V DC
Rated Load Current 0.3A per output point
Maximum Load Current 1A per common line
Voltage Drop (ON Voltage) 1V maximum (voltage between COM and output terminals when output is on)
Inrush Current 1A maximum
Leakage Current 0.1 mA maximum
Clamping Voltage 39V±1V
Maximum Lamp Load 8W
Inductive Load L/R = 10 msec (28.8V DC, 1 Hz)
External Current Draw
Isolation
100 mA maximum, 24V DC
(power voltage at the +V terminal)
Between output terminal and internal circuit: Photocoupler isolated
Between output terminals: Not isolated
100 mA maximum, 24V DC
(power voltage at the –V terminal)
FC4A-D20K3/S3: FL26A2MA (Oki Electric Cable)
Connector on Mother Board
FC4A-D20RK1/RS1: MC1.5/16-G-3.81BK (Phoenix Contact)
FC4A-D40K3/S3: FL26A2MA (Oki Electric Cable)
Connector Insertion/Removal Durability 100 times minimum
Turn ON Time
Output Delay
Turn OFF Time
Q0, Q1: 5 µsec maximum
Q2 to Q17 300 µsec maximum
Q0, Q1: 5 µsec maximum
Q2 to Q17 300 µsec maximum
Output Internal Circuit
FC4A-D20K3, -D20RK1, and -D40K3 (Sink Output)
Internal Circuit
FC4A-D20S3, -D20RS1, and -D40S3 (Source Output)
+V
Output
Internal Circuit
COM(–)
COM(+)
Output
–V
« MICROSMART USER’S MANUAL » 2-17
2: MODULE SPECIFICATIONS
Relay Output Specifications (Slim Type CPU Module)
CPU Module FC4A-D20RK1 FC4A-D20RS1
No. of Outputs 8 points including 2 transistor output points
COM0 (2 points transistor sink output) (2 points transistor source output)
Output Points per Common Line
Ter minal Arrangement See CPU Module Terminal Arrangement on page 2-20.
Maximum Load Current
Minimum Switching Load 0.1 mA/0.1V DC (reference value)
Initial Contact Resistance 30 mΩ maximum
Electrical Life 100,000 operations minimum (rated load 1,800 operations/hour)
Mechanical Life 20,000,000 operations minimum (no load 18,000 operations/hour)
Rated Load (resistive/inductive) 240V AC/2A, 30V DC/2A
Dielectric Strength
Connector on Mother Board MC1.5/16-G-3.81BK (Phoenix Contact)
Connector Insertion/Removal Durability 100 times minimum
Contact Protection Circuit for Relay Output See page 3-15.
COM1 3 NO contacts
COM2 2 NO contacts
COM3 1 NO contact
2A per point
8A per common line
Between output and terminals: 1,500V AC, 1 minute
Between output terminal and internal circuit: 1,500V AC, 1 minute
Between output terminals (COMs): 1,500V AC, 1 minute
Output Delay
Command
Output Relay Status
ON
OFF
ON
OFF
OFF delay: 10 msec maximum
Chatter: 6 msec maximum
ON delay: 6 msec maximum
2-18 « MICROSMART USER’S MANUAL »
CPU Module Terminal Arrangement and I/O Wiring Diagrams (Slim Type)
FC4A-D20K3 (20-I/O Transistor Sink Output Type CPU Module)
Applicable Connector: FC4A-PMC26P (not supplied with the CPU module)
2: MODULE SPECIFICATIONS
Source Input Wiring
2-wire Sensor
–
NPN
–
24V DC
+
Ter minal No. Input Terminal No. Output
+
26 I0 25 Q0
24 I1 23 Q1
22 I2 21 Q2
20 I3 19 Q3
18 I4 17 Q4
16 I5 15 Q5
14 I6 13 Q6
12 I7 11 Q7
10 I10 9 COM(–)
8 I11 7 COM(–)
6 I12 5 COM(–)
4 I13 3 +V
2 COM 1 +V
Sink Output Wiring
LoadLFuse
• COM(–) terminals are connected together internally.
• COM and COM(–) terminals are not connected together internally.
• +V terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 through 3-17.
L
L
L
L
L
L
L
Fuse
+–
FC4A-D20S3 (20-I/O Transistor Source Output Type CPU Module)
Applicable Connector: FC4A-PMC26P (not supplied with the CPU module)
Sink Input Wiring
2-wire Sensor
+
PNP
+
24V DC
–
Ter minal No. Input Terminal No. Output
–
26 I0 25 Q0
24 I1 23 Q1
22 I2 21 Q2
20 I3 19 Q3
18 I4 17 Q4
16 I5 15 Q5
14 I6 13 Q6
12 I7 11 Q7
10 I10 9 COM(+)
8 I11 7 COM(+)
6 I12 5 COM(+)
4 I13 3 –V
2 COM 1 –V
• COM(+) terminals are connected together internally.
• COM and COM(+) terminals are not connected together internally.
• –V terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 through 3-17.
Source Output Wiring
LoadLFuse
L
L
L
L
L
L
L
Fuse
+–
« MICROSMART USER’S MANUAL » 2-19
2: MODULE SPECIFICATIONS
FC4A-D20RK1 (20-I/O Relay and Transistor Sink High-speed Output Type CPU Module)
Applicable Terminal Blocks: TB1 (Left Side) FC4A-PMT13P (supplied with the CPU module)
TB2 (Right Side) FC4A-PMTK16P (supplied with the CPU module)
Source Input Wiring
TB1 TB2
2-wire Sensor
–
NPN
–
24V DC
+
Ter minal No. Input Terminal No. Output
+
1I0 1 Q0
2I1 2 Q1
3I23COM(–)
4I3 4 +V
5I4 5 NC
6I5 6 Q2
7I6 7 Q3
8I7 8 Q4
9 I10 9 COM1
10 I11 10 NC
11 I12 11 Q5
12 I13 12 Q6
13 COM 13 COM2
14 NC
15 Q7
16 COM3
Sink Output Wiring
LoadLFuse
L
+–
L
L
L
+–
L
L
AC
L
AC
• Outputs Q0 and Q1 are transistor sink outputs; others are relay outputs.
• COM, COM(–), COM1, COM2, and COM3 terminals are not connected
together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 through 3-17.
FC4A-D20RS1 (20-I/O Relay and Transistor Source High-speed Output Type CPU Module)
Applicable Terminal Blocks: TB1 (Left Side) FC4A-PMT13P (supplied with the CPU module)
TB2 (Right Side) FC4A-PMTS16P (supplied with the CPU module)
Sink Input Wiring
TB1 TB2
2-wire Sensor
+
PNP
+
24V DC
–
Ter minal No. Input Terminal No. Output
–
1I0 1 Q0
2I1 2 Q1
3I23COM(+)
4I3 4 –V
5I4 5 NC
6I5 6 Q2
7I6 7 Q3
8I7 8 Q4
9 I10 9 COM1
10 I11 10 NC
11 I12 11 Q5
12 I13 12 Q6
13 COM 13 COM2
14 NC
15 Q7
16 COM3
Source Output Wiring
LoadLFuse
L
L
L
L
L
L
L
• Outputs Q0 and Q1 are transistor source outputs; others are relay outputs.
• COM, COM(+), COM1, COM2, and COM3 terminals are not connected
together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 through 3-17.
+–
+–
AC
AC
2-20 « MICROSMART USER’S MANUAL »
FC4A-D40K3 (40-I/O Transistor Sink Output Type CPU Module)
Applicable Connector: FC4A-PMC26P (not supplied with the CPU module)
2: MODULE SPECIFICATIONS
Source Input Wiring
CN1
2-wire Sensor
–
NPN
–
24V DC
+
2-wire Sensor
–
NPN
–
24V DC
+
Ter minal No. Input Terminal No. Output
+
CN2
Ter minal No. Input Terminal No. Output
+
26 I0 25 Q0
24 I1 23 Q1
22 I2 21 Q2
20 I3 19 Q3
18 I4 17 Q4
16 I5 15 Q5
14 I6 13 Q6
12 I7 11 Q7
10 I10 9 COM(–)
8 I11 7 COM(–)
6 I12 5 COM(–)
4 I13 3 +V
2 COM 1 +V
26 I14 25 Q10
24 I15 23 Q11
22 I16 21 Q12
20 I17 19 Q13
18 I20 17 Q14
16 I21 15 Q15
14 I22 13 Q16
12 I23 11 Q17
10 I24 9 COM(–)
8 I25 7 COM(–)
6 I26 5 COM(–)
4 I27 3 +V
2 COM 1 +V
Sink Output Wiring
LoadLFuse
L
L
L
L
L
L
L
Fuse
+–
LoadLFuse
L
L
L
L
L
L
L
Fuse
+–
• Terminals on CN1 and CN2 are not connected together internally.
• COM(–) terminals are connected together internally.
• COM and COM(–) terminals are not connected together internally.
• +V terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 through 3-17.
« MICROSMART USER’S MANUAL » 2-21
2: MODULE SPECIFICATIONS
FC4A-D40S3 (40-I/O Transistor Source Output Type CPU Module)
Applicable Connector: FC4A-PMC26P (not supplied with the CPU module)
Sink Input Wiring
CN1
2-wire Sensor
–
+
PNP
+
24V DC
–
CN2
2-wire Sensor
–
+
PNP
+
24V DC
–
Ter minal No. Input Terminal No. Output
26 I0 25 Q0
24 I1 23 Q1
22 I2 21 Q2
20 I3 19 Q3
18 I4 17 Q4
16 I5 15 Q5
14 I6 13 Q6
12 I7 11 Q7
10 I10 9 COM(+)
8 I11 7 COM(+)
6 I12 5 COM(+)
4 I13 3 –V
2 COM 1 –V
Ter minal No. Input Terminal No. Output
26 I14 25 Q10
24 I15 23 Q11
22 I16 21 Q12
20 I17 19 Q13
18 I20 17 Q14
16 I21 15 Q15
14 I22 13 Q16
12 I23 11 Q17
10 I24 9 COM(+)
8 I25 7 COM(+)
6 I26 5 COM(+)
4 I27 3 –V
2 COM 1 –V
Source Output Wiring
LoadLFuse
L
L
L
L
L
L
L
Fuse
+–
LoadLFuse
L
L
L
L
L
L
L
Fuse
+–
• Terminals on CN1 and CN2 are not connected together internally.
• COM(+) terminals are connected together internally.
• COM and COM(+) terminals are not connected together internally.
• –V terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 through 3-17.
2-22 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Input Modules
Digital input modules are available in 8-, 16-, and 32-point DC input modules and an 8-point AC input module with a
screw terminal block or plug-in connector for input wiring. All DC input modules accept both sink and source DC input
signals.
The input modules can be connected to the all-in-one 24-I/O type CPU module and all slim type CPU modules to expand
input terminals. The all-in-one 10- and 16-I/O type CPU modules cannot connect input modules.
Input Module Type Numbers
Module Name 8-point DC Input 16-point DC Input 32-point DC Input 8-point AC Input
Screw Terminal FC4A-N08B1 FC4A-N16B1 — FC4A-N08A11
Connector — FC4A-N16B3 FC4A-N32B3 —
Parts Description
(1) Expansion Connector
(2) Module Label
(3) LED Indicator
(4) Terminal No.
(5) Cable Terminal/Connector
The above figures illustrate the 8-point DC input module.
(1) Expansion Connector Connects to the CPU and other I/O modules.
(The all-in-one 10- and 16-I/O type CPU modules cannot be connected.)
(2) Module Label Indicates the input module Type No. and specifications.
(3) LED Indicator Turns on when a corresponding input is on.
(4) Terminal No. Indicates terminal numbers.
(5) Cable Terminal/Connector Five different terminal/connector styles are available for wiring.
« MICROSMART USER’S MANUAL » 2-23
2: MODULE SPECIFICATIONS
I
it
I
DC Input Module Specifications
Type No. FC4A-N08B1 FC4A-N16B1 FC4A-N16B3 FC4A-N32B3
Input Points and Common Lines
8 points in 1
common line
Ter minal Arrangement See Input Module Terminal Arrangement on pages 2-26 through 2-28.
Rated Input Voltage 24V DC sink/source input signal
Input Voltage Range 20.4 to 28.8V DC
Rated Input Current 7 mA/point (24V DC) 5 mA/point (24V DC)
Input Impedance 3.4 kΩ 4.4 kΩ
Turn ON Time (24V DC) 4 msec
Turn OFF Time (24V DC) 4 msec
Isolation
Between input terminals: Not isolated
Internal circuit: Photocoupler isolated
External Load for I/O Interconnection Not needed
Signal Determination Method Static
Effect of Improper Input Connection
Both sinking and sourcing input signals can be connected. If any input
exceeding the rated value is applied, permanent damage may be caused.
Cable Length 3m (9.84 ft.) in compliance with electromagnetic immunity
Connector on Mother Board MC1.5/10-G-3.81BK (Phoenix Contact) FL20A2MA (Oki Electric Cable)
Connector Insertion/Removal Durability 100 times minimum
All Inputs ON
Internal Current Draw
All Inputs OFF
25 mA (5V DC)
0 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
Weight 85g 100g 65g 100g
16 points in 1
common line
40 mA (5V DC)
0 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
16 points in 1
common line
35 mA (5V DC)
0 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
32 points in 2
common lines
65 mA (5V DC)
0 mA (24V DC)
10 mA (5V DC)
0 mA (24V DC)
nput Operating Range
The input operating range of the Type 1
(IEC 61131-2) input module is shown
below:
FC4A-N08B1 and FC4A-N16B1
28.8
24
ON Area
nput Internal Circu
FC4A-N08B1 and FC4A-N16B1 FC4A-N16B3 and FC4A-N32B3
Input
3.3 kΩ
Input
4.3 kΩ
COM
Internal Circuit
COM
Internal Circuit
Input Usage Limits
15
5
Input Voltage (V DC)
0
1.2 8.4
Input Current (mA)
FC4A-N16B3 and FC4A-N32B3
28.8
24
15
5
Input Voltage (V DC)
0
0.9 6.4
Input Current (mA)
7.04.2
5.33.2
Transition
Area
OFF Area
ON Area
Transition
Area
OFF Area
When using the FC4A-N16B1 at 55°C in the normal mounting direction, limit
the inputs which turn on simultaneously along line (1). At 45°C, all inputs
can be turned on simultaneously at 28.8V DC as indicated with line (2).
When using the FC4A-N16B3 or -N32B3 at 55°C, limit the inputs which turn
on simultaneously on each connector along line (3). At 30°C, all inputs can
be turned on simultaneously at 28.8V DC as indicated with line (4).
When using the FC4A-N08B1, all inputs can be turned on simultaneously at
55°C, input voltage 28.8V DC.
28.8
26.4
Input Voltage (V DC)
0
Input Simultaneous ON Ratio (%)
(2) 45°C
(1) 55°C
28.8
26.4
24.0
Input Voltage (V DC)
100
700
0
Input Simultaneous ON Ratio (%)
(4) 30°C
(3) 55°C
50
100
90
700
2-24 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
AC Input Module Specifications
Type No. FC4A-N08A11
Input Points and Common Lines 8 points in 2 common lines
Ter minal Arrangement See Input Module Terminal Arrangement on page 2-29.
Rated Input Voltage 100 to 120V AC (50/60 Hz)
Input Voltage Range 85 to 132V AC
Rated Input Current 15 mA/point (120V AC, 60 Hz)
Input Type AC input, Type 1, 2, 3 (IEC 61131-2)
Input Impedance 0.8 kΩ (60 Hz)
Turn ON Time 25 msec
Turn OFF Time 30 msec
Between input terminals in the same common: Not isolated
Isolation
External Load for I/O Interconnection Not needed
Signal Determination Method Static
Effect of Improper Input Connection
Connector on Mother Board MC1.5/11-G-3.81BK (Phoenix Contact)
Connector Insertion/Removal Durability 100 times minimum
All Inputs ON
Internal Current Draw
All Inputs OFF
Weight 80g
Between input terminals in different commons: Isolated
Between input terminals and internal circuits: Photocoupler isolated
If any input exceeding the rated value is applied, permanent damage may be
caused.
60 mA (5V DC)
0 mA (24V DC)
30 mA (5V DC)
0 mA (24V DC)
Input Operating Range
The input operating range of the Type 1, 2, 3 (IEC 61131-2)
input module is shown below:
FC4A-N08A11
132
120
100
79
74
Input Voltage (V AC)
20
0
115
5
24 16.9
Input Current (mA)
12.7
ON Area
Transition
Area
OFF Area
Input Internal Circuit
FC4A-N08A11
Input
COM
Internal Circuit
Input Usage Limits
When using the FC4A-N08A11, all inputs can be
turned on simultaneously at 55°C, input voltage
132V AC.
132
120
102
Input Voltage (V AC)
0
Input Simultaneous ON Ratio (%)
55°C
500
100
« MICROSMART USER’S MANUAL » 2-25
2: MODULE SPECIFICATIONS
DC Input Module Terminal Arrangement and Wiring Diagrams
FC4A-N08B1 (8-point DC Input Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT10P (supplied with the input module)
DC.IN
0
1
2
3
4
5
6
7
Source Input Wiring
2-wire Sensor
–
+
Ter minal No. Input
0I0
1I1
2I2
Sink Input Wiring
2-wire Sensor
3I3
4I4
5I5
6I6
7I7
COM COM
+
–
01234567
–
24V DC
+
NPN
COM COM
• Two COM terminals are connected together internally.
• For input wiring precautions, see page 3-13.
COM COM
FC4A-N16B1 (16-point DC Input Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT10P (supplied with the input module)
+
PNP
24V DC
Ter minal No. Input
–
0I0
1I1
2I2
3I3
4I4
5I5
6I6
7I7
COM COM
COM COM
DC.IN
0 1 2 3 4 5 6 7
COM COM
10 11 12 13 14 15 16 17
COM COM
0
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
Source Input Wiring
2-wire Sensor
–
+
Ter minal No. Input
0I0
1I1
2I2
3I3
NPN
4I4
5I5
6I6
7I7
COM COM
COM COM
–
+
10 I10
11 I11
12 I12
13 I13
14 I14
15 I15
16 I16
17 I17
–
24V DC
+
NPN
COM COM
COM COM
• Four COM terminals are connected together internally.
• For input wiring precautions, see page 3-13.
Sink Input Wiring
2-wire Sensor
–
+
PNP
–
+
PNP
+
24V DC
–
Ter minal No. Input
0I0
1I1
2I2
3I3
4I4
5I5
6I6
7I7
COM COM
COM COM
10 I10
11 I11
12 I12
13 I13
14 I14
15 I15
16 I16
17 I17
COM COM
COM COM
2-26 « MICROSMART USER’S MANUAL »
FC4A-N16B3 (16-point DC Input Module) — Connector Type
Applicable Connector: FC4A-PMC20P (not supplied with the input module)
Source Input Wiring
2-wire Sensor
–
24V DC
+
Sink Input Wiring
2-wire Sensor
+
24V DC
–
–
NPN
+
PNP
Ter minal No. Input Terminal No. Input
+
–
20 I0 19 I10
18 I1 17 I11
16 I2 15 I12
14 I3 13 I13
12 I4 11 I14
10 I5 9 I15
8I67I16
6I75I17
4 COM 3 COM
2NC1NC
Ter minal No. Input Terminal No. Input
20 I0 19 I10
18 I1 17 I11
16 I2 15 I12
14 I3 13 I13
12 I4 11 I14
10 I5 9 I15
8I67I16
6I75I17
4 COM 3 COM
2NC1NC
2: MODULE SPECIFICATIONS
2-wire Sensor
–
+
NPN
–
24V DC
+
2-wire Sensor
–
+
PNP
+
24V DC
–
• Two COM terminals are connected together internally.
• For input wiring precautions, see page 3-13.
« MICROSMART USER’S MANUAL » 2-27
2: MODULE SPECIFICATIONS
FC4A-N32B3 (32-point DC Input Module) — Connector Type
Applicable Connector: FC4A-PMC20P (not supplied with the input module)
• COM0 terminals are connected together internally.
• COM1 terminals are connected together internally.
• COM0 and COM1 terminals are not connected together internally.
• For input wiring precautions, see page 3-13.
Source Input Wiring
CN1
2-wire Sensor
–
+
NPN
–
24V DC
+
No. Input No. Input
Sink Input Wiring
CN1
2-wire Sensor
–
+
PNP
+
24V DC
–
No. Input No. Input
20 I0 19 I10
18 I1 17 I11
16 I2 15 I12
14 I3 13 I13
12 I4 11 I14
10 I5 9 I15
8I67I16
6I75I17
4 COM0 3 COM0
2NC1NC
20 I0 19 I10
18 I1 17 I11
16 I2 15 I12
14 I3 13 I13
12 I4 11 I14
10 I5 9 I15
8I67I16
6I75I17
4 COM0 3 COM0
2NC1NC
2-wire Sensor
–
+
NPN
24V DC
2-wire Sensor
–
+
PNP
24V DC
CN2
2-wire Sensor
–
+
No. Input No. Input
20 I20 19 I30
2-wire Sensor
–
+
18 I21 17 I31
16 I22 15 I32
14 I23 13 I33
NPN
–
+
–
24V DC
+
12 I24 11 I34
10 I25 9 I35
8 I26 7 I36
6 I27 5 I37
NPN
24V DC
–
+
4 COM1 3 COM1
2NC1NC
CN2
2-wire Sensor
+
No. Input No. Input
–
20 I20 19 I30
2-wire Sensor
–
+
18 I21 17 I31
16 I22 15 I32
14 I23 13 I33
PNP
+
–
+
24V DC
–
12 I24 11 I34
10 I25 9 I35
8 I26 7 I36
6 I27 5 I37
PNP
24V DC
+
–
4 COM1 3 COM1
2NC1NC
2-28 « MICROSMART USER’S MANUAL »
AC Input Module Terminal Arrangement and Wiring Diagrams
FC4A-N08A11 (8-point AC Input Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the input module)
2: MODULE SPECIFICATIONS
AC.IN
1023
COM0
NC 4 5 6
7 COM1
0
1
2
3
4
5
6
7
Ter minal No. Output
0I0
1I1
2I2
3I3
COM0 COM0
AC
NC NC
4I4
5I5
6I6
7I7
COM1 COM1
AC
• Two COM terminals are not connected together internally.
• For input wiring precautions, see page 3-13.
• Do not connect an external load to the input terminals.
« MICROSMART USER’S MANUAL » 2-29
2: MODULE SPECIFICATIONS
Output Modules
Digital output modules are available in 8- and 16-point relay output modules, 8-, 16- and 32-point transistor sink output
modules, and 8-, 16- and 32-point transistor source output modules with a screw terminal block or plug-in connector for
output wiring.
The output modules can be connected to the all-in-one 24-I/O type CPU module and all slim type CPU modules to expand
output terminals. The all-in-one 10- and 16-I/O type CPU modules cannot connect output modules.
Output Module Type Numbers
Module Name Terminal Type No.
8-point Relay Output
16-point Relay Output FC4A-R161
8-point Transistor Sink Output FC4A-T08K1
8-point Transistor Source Output FC4A-T08S1
16-point Transistor Sink Output
16-point Transistor Source Output FC4A-T16S3
32-point Transistor Sink Output FC4A-T32K3
32-point Transistor Source Output FC4A-T32S3
Removable Terminal Block
MIL Connector
Parts Description
FC4A-R081
FC4A-T16K3
(1) Expansion Connector
(2) Module Label
(3) LED Indicator
(4) Terminal No.
(5) Cable Terminal/Connector
The above figures illustrate the 8-point relay output module.
(1) Expansion Connector Connects to the CPU and other I/O modules.
(The all-in-one 10- and 16-I/O type CPU modules cannot be connected.)
(2) Module Label Indicates the output module Type No. and specifications.
(3) LED Indicator Turns on when a corresponding output is on.
(4) Terminal No. Indicates terminal numbers.
(5) Cable Terminal/Connector Five different terminal/connector styles are available for wiring.
2-30 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Relay Output Module Specifications
Type No. FC4A-R081 FC4A-R161
Output Points and Common Lines 8 NO contacts in 2 common lines 16 NO contacts in 2 common lines
Ter minal Arrangement See Relay Output Module Terminal Arrangement on page 2-32.
Maximum Load Current
Minimum Switching Load 0.1 mA/0.1V DC (reference value)
Initial Contact Resistance 30 mΩ maximum
Electrical Life 100,000 operations minimum (rated load 1,800 operations/hour)
Mechanical Life 20,000,000 operations minimum (no load 18,000 operations/hour)
Rated Load (resistive/inductive) 240V AC/2A, 30V DC/2A
Dielectric Strength
Connector on Mother Board
Connector Insertion/Removal Durability 100 times minimum 100 times minimum
All Outputs ON
Internal Current Draw
All Outputs OFF
Weight 110g 145g
Contact Protection Circuit for Relay Output See page 3-15.
2A per point
7A per common line 8A per common line
Between output and or terminals: 1,500V AC, 1 minute
Between output terminal and internal circuit: 1,500V AC, 1 minute
Between output terminals (COMs): 1,500V AC, 1 minute
MC1.5/11-G-3.81BK
(Phoenix Contact)
30 mA (5V DC)
40 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
MC1.5/10-G-3.81BK
(Phoenix Contact)
45 mA (5V DC)
75 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
Note: When relay output modules are connected to the all-in-one 24-I/O type CPU module or any slim type CPU module, the
maximum number of relay outputs that can be turned on simultaneously, including the outputs on the CPU module, are
shown below.
CPU Module Type All-in-One 24-I/O CPU Module Slim Type CPU Module
Maximum Relay Outputs Turning On Simultaneously 33 54
Output Delay
Command
Output Relay Status
ON
OFF
ON
OFF
OFF delay: 10 msec maximum
Chatter: 6 msec maximum
ON delay: 6 msec maximum
« MICROSMART USER’S MANUAL » 2-31
2: MODULE SPECIFICATIONS
Relay Output Module Terminal Arrangement and Wiring Diagrams
FC4A-R081 (8-point Relay Output Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the output module)
Ry.OUT
1023
COM0
NC 456
0
1
2
3
4
5
6
7
Fuse
+
–
DC
Fuse
+
DC
–
–
+
Fuse
–
+
Fuse
DC
DC
Fuse
AC
Fuse
AC
Fuse
• COM0 and COM1 terminals are not connected together internally.
Load
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
7 COM1
FC4A-R161 (16-point Relay Output Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT10P (supplied with the output module)
Ter minal No. Output
L
L
L
L
0Q0
1Q1
2Q2
3Q3
COM0 COM0
NC NC
L
L
L
L
4Q4
5Q5
6Q6
7Q7
COM1 COM1
Ry.OUT
0 1 2 3 4 5 6 7
COM0 COM0
10 11 12 13 14 15 16 17
COM1 COM1
0
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
Ter minal No. Output
0Q0
1Q1
2Q2
3Q3
4Q4
5Q5
6Q6
7Q7
Fuse
+
–
DC
–
+
Fuse
DC
Fuse
AC
Fuse
Load
L
L
L
L
L
L
L
L
COM0 COM0
COM0 COM0
10 Q10
11 Q11
12 Q12
13 Q13
14 Q14
15 Q15
16 Q16
17 Q17
Fuse
+
–
DC
–
+
Fuse
DC
Fuse
AC
L
L
L
L
L
L
L
L
COM1 COM1
COM1 COM1
• COM0 terminals are connected together internally.
• COM1 terminals are connected together internally.
• COM0 and COM1 terminals are not connected together internally.
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
2-32 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Transistor Sink Output Module Specifications
Type No. FC4A-T08K1 FC4A-T16K3 FC4A-T32K3
Output Type Transistor sink output
Output Points and Common Lines
Ter minal Arrangement
8 points
in 1 common line
See Transistor Sink Output Module Terminal Arrangement on pages 2-34
and 2-35.
Rated Load Voltage 24V DC
Operating Load Voltage Range 20.4 to 28.8V DC
Rated Load Current 0.3A per output point 0.1A per output point
Maximum Load Current (at 28.8V DC)
0.36A per output point
3A per common line
Voltage Drop (ON Voltage) 1V maximum (voltage between COM and output terminals when output is on)
Inrush Current 1A maximum
Leakage Current 0.1 mA maximum
Clamping Voltage 39V±1V
Maximum Lamp Load 8W
Inductive Load L/R = 10 msec (28.8V DC, 1 Hz)
External Current Draw 100 mA maximum, 24V DC (power voltage at the +V terminal)
Isolation
Connector on Mother Board
Between output terminal and internal circuit: Photocoupler isolated
Between output terminals: Not isolated
MC1.5/10-G-3.81BK
(Phoenix Contact)
Connector Insertion/Removal Durability 100 times minimum
10 mA (5V DC)
20 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
Turn ON time: 300 µsec maximum
Turn OFF time: 300 µsec maximum
Internal Current
Draw
Output Delay
All Outputs ON
All Outputs OFF
Weight (approx.) 85g 70g 105g
16 points
in 1 common line
32 points
in 2 common lines
0.12A per output point
1A per common line
FL20A2MA (Oki Electric Cable)
10 mA (5V DC)
40 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
20 mA (5V DC)
70 mA (24V DC)
10 mA (5V DC)
0 mA (24V DC)
Output Internal Circuit
Sink Output
Internal Circuit
+V
Output
COM(–)
« MICROSMART USER’S MANUAL » 2-33
2: MODULE SPECIFICATIONS
Transistor Sink Output Module Terminal Arrangement and Wiring Diagrams
FC4A-T08K1 (8-point Transistor Sink Output Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT10P (supplied with the output module)
Tr.OUT
0
1
2
3
4
5
6
7
Fuse
Load
Ter minal No. Output
L
L
L
L
L
L
L
L
01234567
Fuse
+–
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
COM(–)
+V
FC4A-T16K3 (16-point Transistor Sink Output Module) — Connector Type
Applicable Connector: FC4A-PMC20P (not supplied with the output module)
0Q0
1Q1
2Q2
3Q3
4Q4
5Q5
6Q6
7Q7
COM(–) COM(–)
+V +V
Fuse
Load
+–
Ter minal No. Output Terminal No. Output
L
L
L
L
L
L
L
L
20 Q0 19 Q10
18 Q1 17 Q11
16 Q2 15 Q12
14 Q3 13 Q13
12 Q4 11 Q14
10 Q5 9 Q15
8Q67Q16
6Q75Q17
4 COM(–) 3 COM(–)
2+V1+V
• COM(–) terminals are connected together internally.
• +V terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
LoadLFuse
L
L
L
L
L
L
L
+–
2-34 « MICROSMART USER’S MANUAL »
FC4A-T32K3 (32-point Transistor Sink Output Module) — Connector Type
Applicable Connector: FC4A-PMC20P (not supplied with the output module)
CN1
Fuse
Fuse
Load
+–
Load
+–
Ter minal No. Output Terminal No. Output
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
20 Q0 19 Q10
18 Q1 17 Q11
16 Q2 15 Q12
14 Q3 13 Q13
12 Q4 11 Q14
10 Q5 9 Q15
8Q67Q16
6Q75Q17
4 COM0(–) 3 COM0(–)
2 +V0 1 +V0
CN2
Ter minal No. Output Terminal No. Output
20 Q20 19 Q30
18 Q21 17 Q31
16 Q22 15 Q32
14 Q23 13 Q33
12 Q24 11 Q34
10 Q25 9 Q35
8 Q26 7 Q36
6 Q27 5 Q37
4 COM1(–) 3 COM1(–)
2 +V1 1 +V1
2: MODULE SPECIFICATIONS
LoadLFuse
L
L
L
L
L
L
L
+–
LoadLFuse
L
L
L
L
L
L
L
+–
• Terminals on CN1 and CN2 are not connected together internally.
• COM0(–) terminals are connected together internally.
• COM1(–) terminals are connected together internally.
• +V0 terminals are connected together internally.
• +V1 terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
« MICROSMART USER’S MANUAL » 2-35
2: MODULE SPECIFICATIONS
Transistor Source Output Module Specifications
Type No. FC4A-T08S1 FC4A-T16S3 FC4A-T32S3
Output Type Transistor source output
Output Points and Common Lines
Ter minal Arrangement
8 points
in 1 common line
See Transistor Source Output Module Terminal Arrangement on pages 2-37
and 2-38.
Rated Load Voltage 24V DC
Operating Load Voltage Range 20.4 to 28.8V DC
Rated Load Current 0.3A per output point 0.1A per output point
Maximum Load Current (at 28.8V DC)
0.36A per output point
3A per common line
Voltage Drop (ON Voltage) 1V maximum (voltage between COM and output terminals when output is on)
Inrush Current 1A maximum
Leakage Current 0.1 mA maximum
Clamping Voltage 39V±1V
Maximum Lamp Load 8W
Inductive Load L/R = 10 msec (28.8V DC, 1 Hz)
External Current Draw 100 mA maximum, 24V DC (power voltage at the –V terminal)
Isolation
Connector on Mother Board
Between output terminal and internal circuit: Photocoupler isolated
Between output terminals: Not isolated
MC1.5/10-G-3.81BK
(Phoenix Contact)
Connector Insertion/Removal Durability 100 times minimum
10 mA (5V DC)
20 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
Turn ON time: 300 µsec maximum
Turn OFF time: 300 µsec maximum
Internal Current
Draw
Output Delay
All Outputs ON
All Outputs OFF
Weight (approx.) 85g 70g 105g
16 points
in 1 common line
32 points
in 2 common lines
0.12A per output point
1A per common line
FL20A2MA (Oki Electric Cable)
10 mA (5V DC)
40 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
20 mA (5V DC)
70 mA (24V DC)
10 mA (5V DC)
0 mA (24V DC)
Output Internal Circuit
Source Output
COM(+)
Output
Internal Circuit
–V
2-36 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Transistor Source Output Module Terminal Arrangement and Wiring Diagrams
FC4A-T08S1 (8-point Transistor Source Output Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT10P (supplied with the output module)
Tr.OUT
0
1
2
3
4
5
6
7
Load
Ter minal No. Output
L
L
L
L
L
L
L
01234567
Fuse
+–
L
COM(+) COM(+)
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
COM(+)
–V
FC4A-T16S3 (16-point Transistor Source Output Module) — Connector Type
Applicable Connector: FC4A-PMC20P (not supplied with the output module)
0Q0
1Q1
2Q2
3Q3
4Q4
5Q5
6Q6
7Q7
–V –V
Fuse
Load
+–
Ter minal No. Output Terminal No. Output
L
L
L
L
L
L
L
L
20 Q0 19 Q10
18 Q1 17 Q11
16 Q2 15 Q12
14 Q3 13 Q13
12 Q4 11 Q14
10 Q5 9 Q15
8Q67Q16
6Q75Q17
4 COM(+) 3 COM(+)
2–V1–V
• COM(+) terminals are connected together internally.
• –V terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
LoadLFuse
L
L
L
L
L
L
L
+–
« MICROSMART USER’S MANUAL » 2-37
2: MODULE SPECIFICATIONS
FC4A-T32S3 (32-point Transistor Source Output Module) — Connector Type
Applicable Connector: FC4A-PMC20P (not supplied with the output module)
CN1
Fuse
Fuse
Load
+–
Load
+–
Ter minal No. Output Terminal No. Output
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
20 Q0 19 Q10
18 Q1 17 Q11
16 Q2 15 Q12
14 Q3 13 Q13
12 Q4 11 Q14
10 Q5 9 Q15
8Q67Q16
6Q75Q17
4 COM0(+) 3 COM0(+)
2 –V0 1 –V0
CN2
Ter minal No. Output Terminal No. Output
20 Q20 19 Q30
18 Q21 17 Q31
16 Q22 15 Q32
14 Q23 13 Q33
12 Q24 11 Q34
10 Q25 9 Q35
8 Q26 7 Q36
6 Q27 5 Q37
4 COM1(+) 3 COM1(+)
2 –V1 1 –V1
LoadLFuse
L
L
L
L
L
L
L
+–
LoadLFuse
L
L
L
L
L
L
L
+–
• Terminals on CN1 and CN2 are not connected together internally.
• COM0(+) terminals are connected together internally.
• COM1(+) terminals are connected together internally.
• –V0 terminals are connected together internally.
• –V1 terminals are connected together internally.
• Connect a fuse appropriate for the load.
• For output wiring precautions, see page 3-14.
2-38 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Mixed I/O Modules
The 4-in/4-out mixed I/O module has 4-point DC sink/source inputs and 4-point relay outputs, with a screw terminal block
for I/O wiring. The 16-in/8-out mixed I/O module has 16-point DC sink/source inputs and 8-point relay outputs, with a
wire-clamp terminal block for I/O wiring.
The mixed I/O modules can be connected to the all-in-one 24-I/O type CPU module and all slim type CPU modules to
expand input and output terminals. The all-in-one 10- and 16-I/O type CPU modules cannot connect mixed I/O modules.
Mixed I/O Module Type Numbers
Module Name Terminal Type No.
4-in/4-out Mixed I/O Module Removable Terminal Block FC4A-M08BR1
16-in/8-out Mixed I/O Module Non-removable Wire-clamp Terminal Block FC4A-M24BR2
Parts Description
(1) Expansion Connector
(2) Module Label
(3) LED Indicator
(4) Terminal No.
(5) Cable Terminal
The above figures illustrate the 4-in/4-out mixed I/O module.
(1) Expansion Connector Connects to the CPU and other I/O modules.
(The all-in-one 10- and 16-I/O type CPU modules cannot be connected.)
(2) Module Label Indicates the mixed I/O module Type No. and specifications.
(3) LED Indicator Turns on when a corresponding input or output is on.
(4) Terminal No. Indicates terminal numbers.
(5) Cable Terminal Two different terminal styles are available for wiring.
« MICROSMART USER’S MANUAL » 2-39
2: MODULE SPECIFICATIONS
Mixed I/O Module Specifications
Type No. FC4A-M08BR1 FC4A-M24BR2
I/O Points
4 inputs in 1 common line
4 outputs in 1 common line
Ter minal Arrangement See Mixed I/O Module Terminal Arrangement on pages 2-41 and 2-42.
Connector on Mother Board
MC1.5/11-G-3.81BK
(Phoenix Contact)
Connector Insertion/Removal Durability 100 times minimum Not removable
All I/Os ON
Internal Current Draw
All I/Os OFF
25 mA (5V DC)
20 mA (24V DC)
5 mA (5V DC)
0 mA (24V DC)
Weight 95g 140g
DC Input Specifications (Mixed I/O Module)
Input Points and Common Line 4 points in 1 common line 16 points in 1 common line
Rated Input Voltage 24V DC sink/source input signal
Input Voltage Range 20.4 to 28.8V DC
Rated Input Current 7 mA/point (24V DC)
Input Impedance 3.4 kΩ
Turn ON Time 4 msec (24V DC)
Turn OFF Time 4 msec (24V DC)
Isolation
External Load for I/O Interconnection Not needed
Signal Determination Method Static
Effect of Improper Input Connection
Cable Length 3m (9.84 ft.) in compliance with electromagnetic immunity
Between input terminals: Not isolated
Internal circuit: Photocoupler isolated
Both sinking and sourcing input signals can be connected. If any input
exceeding the rated value is applied, permanent damage may be caused.
16 inputs in 1 common line
8 outputs in 2 common lines
Input: F6018-17P (Fujicon)
Output: F6018-11P (Fujicon)
65 mA (5V DC)
45 mA (24V DC)
10 mA (5V DC)
0 mA (24V DC)
Input Operating Range
The input operating range of the Type 1 (IEC 61131-2)
input module is shown below:
I/O Usage Limits
When using the FC4A-M24BR2 at an ambient temperature of 55°C in the normal mounting direction, limit the
inputs and outputs, respectively, which turn on simulta-
28.8
24
15
5
Input Voltage (V DC)
0
1.2 8.4
Input Current (mA)
ON Area
Transition
Area
OFF Area
74.2
neously along line (1).
Input Internal Circuit
Input
COM
3.3 kΩ
Internal Circuit
2-40 « MICROSMART USER’S MANUAL »
When using at 45°C, all I/Os can be turned on simultaneously at input voltage 28.8V DC as indicated with line
(2).
When using the FC4A-M08BR1, all I/Os can be turned on
simultaneously at 55°C, input voltage 28.8V DC.
28.8
26.4
Input Voltage (V DC)
0
0
I/O Simultaneous ON Ratio (%)
(2) 45°C
(1) 55°C
80
100
2: MODULE SPECIFICATIONS
Relay Output Specifications (Mixed I/O Module)
Type No. FC4A-M08BR1 FC4A-M24BR2
Output Points and Common Lines 4 NO contacts in 1 common line 8 NO contacts in 2 common lines
Maximum Load Current
Minimum Switching Load 0.1 mA/0.1V DC (reference value)
Initial Contact Resistance 30 mΩ maximum
Electrical Life 100,000 operations minimum (rated load 1,800 operations/hour)
Mechanical Life 20,000,000 operations minimum (no load 18,000 operations/hour)
Rated Load (resistive/inductive) 240V AC/2A, 30V DC/2A
Dielectric Strength
Contact Protection Circuit for Relay Output See page 3-15.
Output Delay
2A per point
7A per common line
Between output and or terminals: 1,500V AC, 1 minute
Between output terminal and internal circuit: 1,500V AC, 1 minute
Between output terminals (COMs): 1,500V AC, 1 minute
Command
Output Relay Status
ON
OFF
ON
OFF
OFF delay: 10 msec maximum
Chatter: 6 msec maximum
ON delay: 6 msec maximum
Mixed I/O Module Terminal Arrangement and Wiring Diagrams
FC4A-M08BR1 (Mixed I/O Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the mixed I/O module)
DC.IN
Ry.OUT
1023
COM0
NC 012
0
1
2
3
0
1
2
3
Source Input Wiring
2-wire Sensor
–
24V DC
+
–
NPN
+
Relay Output Wiring
Fuse
+
–
DC
–
+
Fuse
DC
Sink Input Wiring
+
24V DC
–
Fuse
Fuse
AC
2-wire Sensor
+
PNP
Load
Ter minal No. I/O
–
0I0
1I1
2I2
3I3
COM0 COM0
NC NC
L
L
L
L
0Q0
1Q1
2Q2
3Q3
COM1 COM1
3 COM1
Ry.OUTDC.IN
• COM0 and COM1 terminals are not connected together internally.
• For wiring precautions, see pages 3-13 and 3-14.
« MICROSMART USER’S MANUAL » 2-41
2: MODULE SPECIFICATIONS
FC4A-M24BR2 (Mixed I/O Module) — Wire-clamp Terminal Type
Source Input Wiring
2-wire Sensor
–
+
NPN
–
24V DC
+
Relay Output Wiring
Fuse
+
–
Fuse
+
–
DC
DC
–
+
–
+
Ter minal No. Input
1I0
2I1
3I2
4I3
5I4
6I5
7I6
8I7
9 I10
10 I11
11 I12
12 I13
13 I14
14 I15
15 I16
16 I17
17 COM0
DC
Fuse
DC
Fuse
Fuse
AC
Fuse
AC
Sink Input Wiring
2-wire Sensor
+
PNP
+
24V DC
–
Fuse
Load
L
L
L
L
L
L
L
L
Ter minal No. Input
–
1I0
2I1
3I2
4I3
5I4
6I5
7I6
8I7
9 I10
10 I11
11 I12
12 I13
13 I14
14 I15
15 I16
16 I17
17 COM0
Ter minal No. Output
1Q0
2Q1
3Q2
4Q3
5 COM1
6NC
7Q4
8Q5
9Q6
10 Q7
11 COM2
• COM0, COM1, and COM2 terminals are not connected together internally.
• Connect a fuse appropriate for the load.
• For wiring precautions, see pages 3-13 and 3-14.
2-42 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Analog I/O Modules
Analog I/O modules are available in 3-I/O types, 2-input type, and 1-output type. The input channel can accept either voltage and current signals or thermocouple and resistance thermometer signals. The output channel generates voltage and
current signals. Each analog I/O module has a screw terminal block for I/O wiring.
The analog I/O modules can be connected to the all-in-one 24-I/O type CPU module and all slim type CPU modules. The
all-in-one 10- and 16-I/O type CPU modules cannot connect analog I/O modules.
Analog I/O Module Type Numbers
Name Input Type Output Type I/O Points Terminal Type No.
Analog I/O Module
Analog Input Module
Analog Output Module —
Parts Description
Voltage (0-10V DC)
Current (4-20mA)
Thermocouple
Resistance thermometer
Voltage (0-10V DC)
Current (4-20mA)
Voltage (0-10V DC)
Current (4-20mA)
—2 inputs FC4A-J2A1
Voltage (0-10V DC)
Current (4-20mA)
2 inputs
1 output
Removable
Terminal
Block
1 output FC4A-K1A1
FC4A-L03A1
FC4A-L03AP1
(1) Expansion Connector
(2) Module Label
(3) Power LED (PWR)
(4) Terminal No.
(5) Cable Terminal
All analog I/O modules have the same terminal style.
(1) Expansion Connector Connects to the CPU and other I/O modules.
(The all-in-one 10- and 16-I/O type CPU modules cannot be connected.)
(2) Module Label Indicates the analog I/O module Type No. and specifications.
(3) Power LED Turns on when power is supplied to the analog I/O module.
(4) Terminal No. Indicates terminal numbers.
(5) Cable Terminal All analog I/O modules have a removable terminal block.
« MICROSMART USER’S MANUAL » 2-43
2: MODULE SPECIFICATIONS
Analog I/O Module Specifications
General Specifications
Type No. FC4A-L03A1 FC4A-L03AP1 FC4A-J2A1 FC4A-K1A1
Rated Power Voltage 24V DC
Allowable Voltage Range 20.4 to 28.8V DC
Ter minal Arrangement See Analog I/O Module Terminal Arrangement on pages 2-47 and 2-48.
Connector on Mother Board MC1.5/11-G-3.81BK (Phoenix Contact)
Connector Insertion/Removal Durability 100 times minimum
Internal Current Draw
External Current Draw (Note) 45 mA (24V DC) 40 mA (24V DC) 35 mA (24V DC) 40 mA (24V DC)
Weight 85g
Note: The external current draw is the value when all analog inputs are used and the analog output value is at 100%.
50 mA (5V DC)
0 mA (24V DC)
Analog Input Specifications
Analog Input Signal Type Voltage Input Current Input Thermocouple
Input Range 0 to 10V DC 4 to 20 mA DC
Input Impedance 1 MΩ minimum 10Ω 1 MΩ minimum 1 MΩ minimum
Allowable Conductor Resistance
(per wire)
Input Detection Current ———1.0 mA maximum
Sample Duration Time 20 msec maximum 20 msec maximum
Sample Repetition Time 20 msec maximum 20 msec maximum
Total Input System Transfer Time 105 msec + 1 scan time (Note 1) 200 msec + 1 scan time (Note 1)
Type of Input
Operating Mode Self-scan
Conversion Method ∑∆ type ADC
Maximum Error at 25°C ±0.2% of full scale
Input Error
Digital Resolution 4096 increments (12 bits)
Input Value of LSB 2.5 mV 4 µA
Temperature Coefficient ±0.006% of full scale/°C
Repeatability after
Stabilization Time
Non-lineality ±0.2% of full scale
Maximum Error ±1% of full scale
———200Ω maximum
Single-ended
input
±0.5% of full scale
50 mA (5V DC)
0 mA (24V DC)
Differential input
50 mA (5V DC)
0 mA (24V DC)
Type K
(0 to 1300°C)
Type J
(0 to 1200°C)
Type T
(0 to 400°C)
±0.2% of full scale
plus reference
junction compensation accuracy
(±4°C maximum)
K: 0.325°C
J: 0.300°C
T: 0.100°C
50 mA (5V DC)
0 mA (24V DC)
Resistance
Thermometer
Pt 100
3-wire type
(–100 to 500°C)
±0.2% of full
scale
0.15°C
2-44 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Analog Input Signal Type Voltage Input Current Input Thermocouple
Data Type in Application Program
Monotonicity Yes
Input Data Out of Range Detectable (Note 3)
Maximum Temporary
Deviation during
Electrical Noise Tests
Common Mode
Noise
Resistance
Isolation
Effect of Improper Input Connection No damage
Maximum Permanent Allowed Overload
(No Damage)
Selection of Analog Input Signal Type Using software programming
Calibration or Verification to Maintain
Rated Accuracy
Characteristics
Common Mode Voltage 16V DC
Input Filter No
Cable
Crosstalk 2 LSB maximum
0 to 4095 (12-bit data)
–32768 to 32767 (optional range designation) (Note 2)
±3% maximum
Common mode reject ratio (CMRR): –50 dB
Twisted pair shielded cable is recommended for improved noise immunity
Isolated between input and power circuit
Photocoupler-isolated between input and internal circuit
13V DC 40 mA DC —
Impossible
—
Resistance
Thermometer
Accuracy is not
assured when
noise is applied
Analog Output Specifications
Analog Output Signal Type Voltage Output Current Output
Output Range 0 to 10V DC 4 to 20 mA DC
Load Impedance 2 kΩ minimum 300Ω maximum
Applicable Load Type Resistive load
FC4A-L03A1: 50 msec
Settling Time
Total Output System Transfer Time
Maximum Error at 25°C ±0.2% of full scale
Temperature Coefficient ±0.015% of full scale/°C
Repeatability after
Stabilization Time
Output
Error
Digital Resolution 4096 increments (12 bits)
Output Value of LSB 2.5 mV 4 µA
Data Type in Application Program
Output Voltage Drop ±1% of full scale —
Non-lineality ±0.2% of full scale
Output Ripple 1 LSB maximum
Overshoot 0%
Total Error ±1% of full scale
FC4A-L03AP1: 130 msec
FC4A-K1A1: 50 msec
FC4A-L03A1: 50 msec + 1 scan time
FC4A-L03AP1: 130 msec + 1 scan time
FC4A-K1A1: 50 msec + 1 scan time
±0.5% of full scale
0 to 4095 (12-bit data)
–32768 to 32767 (optional range designation) (Note 2)
« MICROSMART USER’S MANUAL » 2-45
2: MODULE SPECIFICATIONS
Analog Output Signal Type Voltage Output Current Output
Monotonicity Yes
Current Loop Open — Not detectable
Maximum Temporary
Noise
Resistance
Electrical Noise Tests
Cable Twisted pair shielded cable is recommended for improved noise immunity
Crosstalk No crosstalk because of 1 channel output
Isolation
Effect of Improper Output Connection No damage
Selection of Analog Output Signal Type Using software programming
Calibration or Verification to Maintain
Rated Accuracy
Note 1: Total input system transfer time = Sample repetition time × 2 + Internal processing time + 1 scan time
Note 2: The 12-bit data (0 to 4095) processed in the analog I/O module can be linear-converted to a value between –32768
and 32767. The optional range designation, and analog I/O data minimum and maximum values can be selected using data
registers allocated to analog I/O modules. See page 24-2.
Note 3: When an error is detected, a corresponding error code is stored to a data register allocated to analog I/O operating
status. See page 24-2.
Deviation during
±3% maximum
Isolated between output and power circuit
Photocoupler-isolated between output and internal circuit
Impossible
Type of Protection
Input Circuit
+V2 +V1
15 MΩ
NC (A)
+ (B’)
10Ω
– (B)
–V1
1 kΩ
1 kΩ
1 kΩ
Input Data
Multiplexer
Input
Selection
Signal
Output Circuit
Output Circuit
+
–
2-46 « MICROSMART USER’S MANUAL »
Analog I/O Module Terminal Arrangement and Wiring Diagrams
FC4A-L03A1 (Analog I/O Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the analog I/O module)
2: MODULE SPECIFICATIONS
24V DC
+–
Analog voltage/current
input device
Analog voltage/current
output device
Analog voltage/current
output device
Fuse
+
–
+
–
+
–
Ter minal No. Channel
+
24V DC–
+
–
NC
–
NC
–
OUT
IN0+
IN1+
• Connect a fuse appropriate for the applied voltage and current draw, at the
position shown in the diagram. This is required when equipment containing
the MicroSmart is destined for Europe.
• Do not connect any wiring to unused channels.
FC4A-L03AP1 (Analog I/O Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the analog I/O module)
Ter minal No. Channel
NC A
–B
NC A
–B
Analog voltage/current
input device
Resistance
thermometer
Thermocouple
24V DC
+–
+
–
Fuse
+
–
A
B’
B
• Connect a fuse appropriate for the applied voltage and current draw, at the
position shown in the diagram. This is required when equipment containing
MicroSmart is destined for Europe.
the
• When connecting a resistance thermometer, connect the three wires to R TD
(resistance temperature detector) terminals A, B’, and B of input channel 0
or 1.
• When connecting a thermocouple, connect the two wires to terminals + and
– of input channel 0 or 1.
• Do not connect any wiring to unused channels.
• Do not connect the thermocouple to a hazardous voltage (60V DC or 42.4V
peak or higher).
+
–
+
–
24V DC
OUT
IN0+B’
IN1+B’
« MICROSMART USER’S MANUAL » 2-47
2: MODULE SPECIFICATIONS
FC4A-J2A1 (Analog Input Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the analog input module)
24V DC
+–
Analog voltage/current
output device
Analog voltage/current
output device
Fuse
+
–
+
–
Ter minal No. Channel
+
NC
NC
NC
–
NC
–
• Connect a fuse appropriate for the applied voltage and current draw, at the
position shown in the diagram. This is required when equipment containing
the MicroSmart is destined for Europe.
• Do not connect any wiring to unused channels.
FC4A-K1A1 (Analog Output Module) — Screw Terminal Type
Applicable Terminal Block: FC4A-PMT11P (supplied with the analog output module)
24V DC–
—
IN0+
IN1+
24V DC
+–
Analog voltage/current
input device
Fuse
+
–
Ter minal No. Channel
+
24V DC–
+
–
NC
NC
NC
NC
OUT
—NC
—NC
• Connect a fuse appropriate for the applied voltage and current draw, at the
position shown in the diagram. This is required when equipment containing
MicroSmart is destined for Europe.
the
• Do not connect any wiring to unused channels.
2-48 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
HMI Module
The optional HMI module can mount on any all-in-one type CPU module, and also on the HMI base module mounted next
to any slim type CPU module. The HMI module makes it possible to manipulate the RAM data in the CPU module without using the Online menu options in WindLDR. For details about operating the HMI module, see page 5-32. For installing
and removing the HMI module, see pages 3-3 and 3-4.
HMI Module Type Number
Module Name Type No.
HMI Module FC4A-PH1
Parts Description
(1) Display Screen
(2) ESC Button
(1) Display Screen The liquid crystal display shows menus, operands, and data.
(2) ESC Button Cancels the current operation, and returns to the immediately preceding operation.
(3) ▲ Button Scrolls up the menu, or increments the selected operand number or value.
(4) ▼ Button Scrolls down the menu, or decrements the selected operand number or value.
(5) OK Button Goes into each control screen, or enters the current operation.
(6) HMI Connector Connects to the all-in-one CPU module or HMI base module.
(6) HMI Connector(3) ▲ Button (4) ▼ Button (5) OK Button
HMI Module Specifications
Type No. FC4A-PH1
Power Voltage 5V DC (supplied from the CPU module)
Internal Current Draw 200 mA DC
Weight 20g
Caution
• Turn off the power to the MicroSmart before installing or removing the HMI module to prevent
electrical shocks and damage to the HMI module.
• Do not touch the connector pins with hand, otherwise contact characteristics of the connector
may be impaired.
« MICROSMART USER’S MANUAL » 2-49
2: MODULE SPECIFICATIONS
HMI Base Module
The HMI base module is used to install the HMI module when using the slim type CPU module. The HMI base module
also has a port 2 connector to attach an optional RS232C or RS485 communication adapter.
When using the all-in-one type CPU module, the HMI module is not needed to install the HMI module.
HMI Base Module Type Number
Module Name Type No.
HMI Base Module FC4A-HPH1
Parts Description
(1) HMI Connector
(4) Communication Connector
(2) Hinged Lid
(3) Port 2 Connector
(1) HMI Connector For installing the HMI module.
(2) Hinged Lid Open the lid to gain access to the port 2 connector.
(3) Port 2 Connector For installing an optional RS232C or RS485 communication adapter.
(4) Communication Connector Connects to the slim type CPU module.
2-50 « MICROSMART USER’S MANUAL »
2: MODULE SPECIFICATIONS
Communication Adapters and Communication Modules
All MicroSmart CPU modules have communication port 1 for RS232C communication. In addition, all-in-one 16- and 24I/O type CPU modules have a port 2 connector. An optional communication adapter can be installed on the port 2 connector for RS232C or RS485 communication. The 10-I/O type CPU module does not have a port 2 connector.
A communication module can be attached to any slim type CPU module to use port 2 for additional RS232C or RS485
communication. When the HMI base module is attached to a slim type CPU module, a communication adapter can be
installed to the port 2 connector on the HMI base module.
When using the RS232C communication adapter or communication module for port 2, maintenance communication, user
communication, and modem communication are made possible. With the RS485 communication adapter or communication module installed, maintenance communication, data link communication, and user communication (upgraded CPU
modules of slim 20-I/O relay output types and 40-I/O types only) can be used on port 2.
Communication Adapter and Communication Module Type Numbers
Name Termination Type No.
RS232C Communication Adapter Mini DIN connector FC4A-PC1
RS485 Communication Adapter
RS232C Communication Module Mini DIN connector FC4A-HPC1
RS485 Communication Module
Mini DIN connector FC4A-PC2
Screw Terminal Block FC4A-PC3
Mini DIN connector FC4A-HPC2
Screw Terminal Block FC4A-HPC3
Parts Description
RS232C Communication Adapter (Mini DIN)
RS485 Communication Adapter (Mini DIN)
(1) Port 2
(2) Connector
(1) Port 2 RS232C or RS485 communication port 2.
(2) Connector Connects to the port 2 connector on the all-in-one type CPU module or HMI base module.
RS232C Communication Module (Mini DIN)
RS485 Communication Module (Mini DIN)
(1) Communication
Connector
(3) Hinged Lid
(3) Hinged Lid
RS485 Communication Adapter (Screw Terminal)
(1) Port 2
(2) Connector
RS485 Communication Module (Screw Terminal)
(1) Communication
Connector
(2) Port 2
(1) Communication Connector Connects to the slim type CPU module.
(2) Port 2 RS232C or RS485 communication port 2.
(3) Hinged Lid Open the lid to gain access to port 2.
« MICROSMART USER’S MANUAL » 2-51
(2) Port 2
2: MODULE SPECIFICATIONS
Communication Adapter and Communication Module Specifications
Type No.
Standards EIA RS232C EIA RS485 EIA RS485
Maximum Baud Rate 19,200 bps 19,200 bps
Maintenance Communication
(Computer Link)
User Communication Possible Impossible Possible (Note 1)
Modem Communication Possible Impossible Impossible
Data Link Communication Impossible Impossible Possible
Quantity of Slave Stations ——31
Maximum Cable Length Special cable Special cable 200m (Note 2)
Isolation between Internal Circuit
and Communication Port
Note 1: RS485 user communication is available on upgraded CPU modules only, see page 17-1.
Note 2: Recommended cable for RS485: Twisted-pair shielded cable with a minimum core wire of 0.3 mm
Conductor resistance 85 Ω/km maximum, shield resistance 20 Ω/km maximum.
The proper tightening torque of the terminal screws on the RS485 communication adapter and RS485 communication module is 0.22 to 0.25 N·m. For tightening the screws, use screwdriver SZS 0,4 x 2,5 (Phoenix Contact).
FC4A-PC1
FC4A-HPC1
Possible Possible Possible
Not isolated Not isolated Not isolated
FC4A-PC2
FC4A-HPC2
FC4A-PC3
FC4A-HPC3
Computer link: 19,200 bps
User com.: 19,200 bps
Data link: 38,400 bps
2
.
Installing the Communication Adapter and Communication Module
Caution
Communication Adapter
To install the communication adapter on the all-in-one type CPU module, open the hinged lid and remove the dummy cartridge. Push the communication adapter into the port 2 connector from the front until it bottoms and is secured by the
latches. Similarly, when installing the communication adapter on the HMI base module, open the hinged lid, and push the
communication adapter into the port 2 connector from the front until it bottoms and is secured by the latches.
Communication Adapter
• Before installing the communication adapter or communication module, turn off the power to the
MicroSmart CPU module. Otherwise, the communication adapter or CPU module may be dam-
aged, or the MicroSmart may not operate correctly.
Communication Adapter
Hinged Lid
Port 2 Connector
Dummy Cartridge
After installing the communication adapter,
attach the dummy cartridge again.
2-52 « MICROSMART USER’S MANUAL »
Hinged Lid
Port 2 Connector
After installing the communication adapter on an all-in-one
type CPU module, view the communication adapter through
the dummy cartridge opening, and check to see that the PC
board of the communication adapter is in a lower level than the
top of the terminal block.
2: MODULE SPECIFICATIONS
Communication Module
Communication Module Slim Type CPU Module
When installing a communication module on the slim type
CPU module, remove the communication connector cover
from the slim type CPU module. See page 3-6.
Place the communication module and CPU module side by
side. Put the communication connectors together for easy
alignment.
With the communication connectors aligned correctly and the
blue unlatch button in the down position, press the communication module and CPU module together until the latches click to
attach the modules together firmly. If the unlatch button is in
the up position, push down the button to engage the latches.
Unlatch Button Communication Connector Cover
Removing the Communication Adapter and Communication Module
Caution
• Before removing the communication adapter or communication module, turn off the power to the
MicroSmart CPU module. Otherwise, the communication adapter or CPU module may be dam-
aged, or the MicroSmart may not operate correctly.
Communication
Adapter PC Board
Ter minal Block
Communication Adapter
To remove the communication adapter from the all-in-one type
CPU module, first remove the dummy cartridge. While pushing
up the communication adapter PC board with a finger through
the dummy cartridge opening, disengage the latches from the
communication adapter using a flat screwdriver. Pull out the
communication adapter from the port 2 connector. When
removing the communication adapter from the HMI module,
take similar steps.
Communication Module
If the modules are mounted on a DIN rail, first remove the
modules from the DIN rail as described on page 3-7.
Push up the blue unlatch button to disengage the latches, and
pull the modules apart as shown on the right.
« MICROSMART USER’S MANUAL » 2-53
Unlatch Button
2: MODULE SPECIFICATIONS
Memory Cartridge
A user program can be stored on an optional memory cartridge installed on a MicroSmart CPU module from a computer
running WindLDR, and the memory cartridge can be installed on another MicroSmart CPU module of the same type. Using
a memory cartridge, the CPU module can exchange user programs where a computer cannot be used.
This feature is available on all models of CPU modules.
Memory Cartridge Type Number
Module Name Type No. Remarks
32KB Memory Cartridge FC4A-PM32
The 64KB memory cartridge can be used on slim type CPU modules
FC4A-D20RK1, FC4A-D20RS1, FC4A-D40K3, and FC4A-D40S3 with sys-
64KB Memory Cartridge FC4A-PM64
User Program Execution Priority
Depending whether a memory cartridge is installed on the MicroSmart CPU module or not, a user program stored on the
memory cartridge or in the CPU module EEPROM is executed, respectively.
Memory Cartridge User Program Execution Priority
Installed on the CPU Module The user program stored on the memory cartridge is executed.
Not installed on the CPU Module The user program stored on the EEPROM in the CPU module is executed.
tem program ver. 201 or higher only. The program capacity expands up
to 64,500 bytes (10,750 steps).
To edit user programs over 32 KB (5200 steps), use WindLDR ver. 4.2
or higher.
Memory Cartridge Specifications
Type No. FC4A-PM32 FC4A-PM64
Memory Type EEPROM
Accessible Memory Capacity 32 KB 64 KB
Hardware for Storing Data CPU module
Software for Storing Data WindLDR WindLDR ver. 4.2 or higher
Quantity of Stored Programs One user program can be stored on one memor y car tridge.
The optional clock cartridge (FC4A-PT1) and the memory cartridge cannot be used together on the all-in-one type CPU
module. The clock cartridge and the memory cartridge can be used together on the slim type CPU module.
User Program Compatibility
The CPU module can execute only user programs created for the same CPU module type. When installing a memory cartridge, make sure that the user program stored on the memory cartridge matches the CPU module type. If the user program
is not for the same CPU module type, a user program syntax error occurs and the CPU module cannot run the user program.
Caution
• User Program for Upgraded CPU Modules
The upgraded functionality summarized on the inside of the front cover of this manual can be
used only on upgraded CPU modules. When a memory cartridge contains a user program for the
new functionality, do not install the memory cartridge into CPU modules with an older system
program version, otherwise the user program is not executed correctly. Make sure that the
upgraded functionality is used on the right CPU module.
2-54 « MICROSMART USER’S MANUAL »
Installing and Removing the Memory Cartridge
2: MODULE SPECIFICATIONS
Caution
• Before installing or removing the memory cartridge, turn off the power to the MicroSmart CPU
module. Otherwise, the memory cartridge or CPU module may be damaged, or the MicroSmart
may not operate correctly.
• Do not touch the connector pins with hand, otherwise electrostatic discharge may damage the
internal elements.
All-in-One Type CPU Module
The cartridge connector is normally closed with a
dummy cartridge. To install the memory cartridge,
open the terminal cover and remove the dummy cartridge from the CPU module. Make sure of correct
orientation of the memory cartridge. Insert the memory cartridge into the cartridge connector until it bottoms. Do not insert the memory cartridge diagonally,
otherwise the terminal pins will be deformed.
After installing the memory cartridge, close the terminal cover.
To remove the memory cartridge, hold both edges of
the memory cartridge and pull it out.
Slim Type CPU Module
Cartridge connectors 1 and 2 are normally closed
with a dummy cartridge. To install the memory cartridge, open the hinged lid and remove the dummy
cartridge from the CPU module. Make sure of correct
orientation of the memory cartridge, and insert the
memory cartridge into cartridge connector 1 or 2
until it bottoms. After installing the memory cartridge, close the hinged lid.
Only one memory cartridge can be installed to either
cartridge connector 1 or 2 on the slim type CPU
module. A memory cartridge and a clock cartridge
can be installed at the same time.
To remove the memory cartridge, hold both edges of
the memory cartridge and pull it out.
Ter minal Cover
Memory Cartridge
FC4A-PM32
Cartridge
Connector
Hinged Lid
Cartridge Connector 1
Memory Cartridge
FC4A-PM32
Cartridge Connector 2
Downloading and Uploading User Program to and from Memory Car tridge
When a memory cartridge is installed on the CPU module, a user program is downloaded to and uploaded from the memory cartridge using WindLDR on a computer . When a memory cartridge is not installed on the CPU module, a user program
is downloaded to and uploaded from the CPU module. For the procedures to download a user program from WindLDR on a
computer, see page 4-8.
With a memory cartridge installed on a CPU module, if the user program stored on the memory cartridge does not match
the CPU module type, downloading is possible, but uploading is not possible. To upload a user program, make sure that
the existing user program stored on the memory cartridge matches the CPU module type. Downloading is always possible
to new blank memory cartridges installed on any type of CPU modules.
« MICROSMART USER’S MANUAL » 2-55
2: MODULE SPECIFICATIONS
Clock Cartridge
With the optional clock cartridge installed on any type of MicroSmart CPU modules, the MicroSmar t can be used for
time-scheduled control such as illumination and air conditioners. For setting the calendar/clock, see page 15-5.
Clock Cartridge Type Number
Module Name Type No.
Clock Cartridge FC4A-PT1
Clock Cartridge Specifications
Accuracy ±30 sec/month (typical) at 25°C
Backup Duration Approx. 30 days (typical) at 25°C after backup battery fully charged
Battery Lithium secondar y batter y
Charging Time Approx. 10 hours for charging from 0% to 90% of full charge
Battery Life Approx. 100 recharge cycles after discharging down to 10% of full charge
Replaceability Impossible to replace battery
The optional memory cartridge (FC4A-PM32) and the clock cartridge cannot be used together on the all-in-one type CPU
module. The memory cartridge and the clock cartridge can be used together on the slim type CPU module.
Installing and Removing the Clock Cartridge
Caution
• Before installing or removing the clock cartridge, turn off the power to the MicroSmart CPU
module. Otherwise, the clock cartridge or CPU module may be damaged, or the MicroSmart may
not operate correctly.
• Do not touch the connector pins with hand, otherwise electrostatic discharge may damage the
internal elements.
All-in-One Type CPU Module
The cartridge connector is normally closed with a
dummy cartridge. To install the clock cartridge, open
the terminal cover and remove the dummy cartridge
from the CPU module. Make sure of correct orientation of the clock cartridge. Insert the clock cartridge
into the cartridge connector until it bottoms. Do not
insert the clock cartridge diagonally, otherwise the
terminal pins will be deformed. After installing the
clock cartridge, close the terminal cover.
To remove the clock cartridge, hold both edges of the
clock cartridge and pull it out.
Slim Type CPU Module
To install the clock cartridge, open the hinged lid and
remove the dummy cartridge from the CPU module.
Make sure of correct orientation of the clock cartridge, and insert the clock cartridge into cartridge
connector 1 or 2 until it bottoms. After installing the
clock cartridge, close the hinged lid.
Only one clock cartridge can be installed to either
cartridge connector 1 or 2 on the slim type CPU
module. A clock cartridge and a memory cartridge
can be installed at the same time.
To remove the clock cartridge, hold both edges of the
clock cartridge and pull it out.
Ter minal Cover
Clock Cartridge
FC4A-PT1
Cartridge
Connector
Hinged Lid
Cartridge Connector 1
Clock Cartridge
FC4A-PT1
Cartridge Connector 2
2-56 « MICROSMART USER’S MANUAL »
Dimensions
All MicroSmart modules have the same profile for consistent mounting on a DIN rail.
CPU Modules
FC4A-C10R2, FC4A-C10R2C, FC4A-C16R2, FC4A-C16R2C
2: MODULE SPECIFICATIONS
FC4A-C24R2, FC4A-C24R2C
80.0
90.04.5*
*8.5 mm when the clamp is pulled out.
95.0 70.0
70.0
90.04.5*
*6.3 mm when the clamp is pulled out.
All dimensions in mm.
« MICROSMART USER’S MANUAL » 2-57
2: MODULE SPECIFICATIONS
FC4A-D20K3, FC4A-D20S3
FC4A-D20RK1, FC4A-D20RS1
35.4 11.3 70.0
90.04.5*
*8.5 mm when the clamp is pulled out.
47.5 14.6 70.0
FC4A-D40K3, FC4A-D40S3
90.04.5*
*8.5 mm when the clamp is pulled out.
47.5 11.3 70.0
90.04.5*
*8.5 mm when the clamp is pulled out.
2-58 « MICROSMART USER’S MANUAL »
All dimensions in mm.
2: MODULE SPECIFICATIONS
I/O Modules
FC4A-N08B1, FC4A-N08A11, FC4A-R081, FC4A-T08K1, FC4A-T08S1, FC4A-M08BR1,
FC4A-L03A1, FC4A-L03AP1, FC4A-J2A1, FC4A-K1A1
3.8
FC4A-N16B1, FC4A-R161
3.8
23.5 14.6 70.0
90.04.5*
*8.5 mm when the clamp is pulled out.
23.5 14.6 70.0
FC4A-M24BR2
3.8
39.1
90.04.5*
*8.5 mm when the clamp is pulled out.
1.0
90.04.5*
70.0
*8.5 mm when the clamp is pulled out.
All dimensions in mm.
« MICROSMART USER’S MANUAL » 2-59
2: MODULE SPECIFICATIONS
FC4A-N16B3, FC4A-T16K3, FC4A-T16S3
3.8
17.6 11.3 70.0
FC4A-N32B3, FC4A-T32K3, FC4A-T32S3
3.8
29.7 11.3 70.0
90.04.5*
*8.5 mm when the clamp is pulled out.
90.04.5*
*8.5 mm when the clamp is pulled out.
Example: The following figure illustrates a system setup consisting of the all-in-one 24-I/O type CPU module, an 8-point
relay output module, and a 16-point DC input module mounted on a 35-mm-wide DIN rail using BNL6P mounting clips.
23.5 23.5 9.0
45.0
95.09.0
35.0
DIN Rail
BNL6P Mounting Clip
*8.5 mm when the clamp is pulled out.
2-60 « MICROSMART USER’S MANUAL »
4.5* 90.0
All dimensions in mm.
HMI, HMI Base, and Communication Modules
FC4A-PH1
35.0
42.0
FC4A-HPH1
2: MODULE SPECIFICATIONS
38.0 13.9
FC4A-HPC1, FC4A-HPC2, FC4A-HPC3
22.5 13.9 70.0
71.0
90.04.5*
*8.5 mm when the clamp is pulled out.
90.04.5*
*8.5 mm when the clamp is pulled out.
All dimensions in mm.
« MICROSMART USER’S MANUAL » 2-61
2: MODULE SPECIFICATIONS
2-62 « MICROSMART USER’S MANUAL »
3: INSTALLATION AND WIRING
Introduction
This chapter describes the methods and precautions for installing and wiring MicroSmart modules.
Before starting installation and wiring, be sure to read “Safety Precautions” in the beginning of this manual and under-
stand precautions described under Warning and Caution.
Warning
Caution
• Turn off the power to the MicroSmart before starting installation, removal, wiring, maintenance,
and inspection of the MicroSmart. Failure to turn power off may cause electrical shocks or fire
hazard.
• Emergency stop and interlocking circuits must be configured outside the MicroSmart. If such a
circuit is configured inside the MicroSmart, failure of the MicroSmart may cause disorder of the
control system, damage, or accidents.
• Special expertise is required to install, wire, program, and operate the MicroSmar t. People with-
out such expertise must not use the MicroSmart.
• Prevent metal fragments and pieces of wire from dropping inside the MicroSmart housing. Put a
cover on the MicroSmart modules during installation and wiring. Ingress of such fragments and
chips may cause fire hazard, damage, or malfunction.
• Do not touch the connector pins with hand, otherwise electrostatic discharge may damage the
internal elements.
Installation Location
The MicroSmart must be installed correctly for optimum performance.
All-in-One Type
The MicroSmart is designed for installation in a cabinet. Do not
install the MicroSmart outside a cabinet.
The environment for using the MicroSmart is “Pollution degree 2.”
Use the MicroSmart in environments of pollution degree 2 (according to IEC 60664-1).
Make sure that the operating temperature does not drop below 0°C
or exceed 55°C. If the temperature does exceed 55°C, use a fan or
cooler.
Mount the MicroSmart on a vertical plane as shown at right.
To eliminate excessive temperature build-up, provide ample venti-
lation. Do not install the MicroSmart near, and especially above,
any device which generates considerable heat, such as a heater,
transformer, or large-capacity resistor. The relati ve humidity should
be above 30% and below 95%.
The MicroSmart should not be exposed to excessiv e dust, dirt, salt,
direct sunlight, vibrations, or shocks. Do not use the MicroSmart in
an area where corrosive chemicals or flammable gases are present.
The modules should not be exposed to chemical, oil, or water
splashes.
« MICROSMART USER’S MANUAL »3-1
Mounting Clip
BNL6P
Slim Type
Mounting Clip
BNL6P
3: INSTALLATION AND WIRING
Assembling Modules
Caution
The following example demonstrates the procedure for assembling the all-in-one 24-I/O type CPU module and an I/O
module together. When assembling slim type CPU modules, take the same procedure.
1. When assembling an input or output module,
remove the expansion connector seal from the
24-I/O type CPU module.
2. Place the CPU module and I/O module side by side. Put the
expansion connectors together for easy alignment.
3. With the expansion connectors aligned correctly and the
blue unlatch button in the down position, press the CPU
module and I/O module together until the latches click to
attach the modules together firmly. If the unlatch button is
in the up position, push down the button to engage the
latches.
• Assemble MicroSmar t modules together before mounting the modules onto a DIN rail. Attempt
to assemble modules on a DIN rail may cause damage to the modules.
• Turn off the power to the MicroSmart before assembling the modules. Failure to turn power off
may cause electrical shocks.
Disassembling Modules
Caution
1. If the modules are mounted on a DIN rail, first remove the
modules from the DIN rail as described on page 3-7.
2. Push up the blue unlatch button to disengage the latches,
and pull the modules apart as shown. When disassembling
slim type CPU modules, take the same procedure.
• Remove the MicroSmart modules from the DIN rail before disassembling the modules. Attempt
to disassemble modules on a DIN rail may cause damage to the modules.
• Turn off the power to the MicroSmart before disassembling the modules. Failure to turn power
off may cause electrical shocks.
Unlatch Button
Unlatch Button
3-2 « MICROSMART USER’S MANUAL »
Installing the HMI Module
Unlatch Button Communication Connector Cover
Slim Type CPU Module
HMI Base Module
HMI Module
3: INSTALLATION AND WIRING
Caution
• Turn off the power to the MicroSmart before installing or removing the HMI module to prevent
electrical shocks.
• Do not touch the connector pins with hand, otherwise electrostatic discharge may damage the
internal elements.
The optional HMI module (FC4A-PH1) can mount on any all-in-one type CPU module, and also on the HMI base module
mounted next to any slim type CPU module. For specifications of the HMI module, see page 2-49. For details about operating the HMI module, see page 5-32.
All-in-One Type
1. Remove the HMI connector cover from the CPU module. Locate the HMI connector inside the CPU module.
2. Push the HMI module into the HMI module connector in the CPU module until the latch clicks.
HMI Connector
HMI Module
Slim Type
1. When using the HMI module with the slim type CPU mod-
ule, prepare the optional HMI base module (FC4A-HPH1).
See page 2-50.
2. Locate the HMI connector inside the HMI base module.
Push the HMI module into the HMI connector in the HMI
base module until the latch clicks.
3. Remove the communication connector cover from the slim
type CPU module. See page 3-6.
4. Place the HMI base module and CPU module side by side.
With the communication connectors aligned correctly and
the blue unlatch button in the down position, press the HMI
base module and CPU module together until the latches
click to attach the modules together firmly. If the unlatch
button is in the up position, push down the button to engage
the latches.
« MICROSMART USER’S MANUAL »3-3
3: INSTALLATION AND WIRING
Removing the HMI Module
Caution
This section describes the procedures for removing the HMI module from the optional HMI base module mounted next to
any slim type CPU module.
1. Insert a thin flat screwdri ver (ø3.0 mm maximum) between the gap
on top of the HMI module until the tip of the screwdriver bottoms.
• Turn off the power to the MicroSmart before installing or removing the HMI module to prevent
electrical shocks.
• Do not touch the connector pins with hand, otherwise electrostatic discharge may damage the
internal elements.
2. While turning the screwdri ver in the direction as sho wn, disengage
the latch on the HMI module and pull out the HMI module.
3. Remove the HMI module from the HMI base module.
Latch
3-4 « MICROSMART USER’S MANUAL »
Removing the Terminal Blocks
3: INSTALLATION AND WIRING
Caution
• Turn off the power to the MicroSmart before installing or removing the terminal blocks to pre-
vent electrical shocks.
• Use the correct procedures to remove the terminal blocks, otherwise the terminal blocks may be
damaged.
This section describes the procedures for removing the terminal blocks from slim type CPU modules FC4A-D20RK1 and
FC4A-D20RS1.
1. Before removing the terminal blocks, disconnect all
wires from the terminal blocks.
Remove the shorter terminal block on the left first,
then remove the longer one on the right.
First, remove the
shorter terminal
block.
FC4A-D20RK1 and FC4A-D20RS1
Next, remove the
longer terminal
block.
2. When removing the longer terminal block, hold the
center of the terminal block, and pull it out straight.
3. Do not pull one end of the longer terminal block,
otherwise the terminal block may be damaged.
« MICROSMART USER’S MANUAL »3-5
3: INSTALLATION AND WIRING
C
Removing the Communication Connector Cover
Caution
• When using a thin screwdriver to pull out the communication connector cover, insert the screw-
driver carefully and do not damage the electronic parts inside the CPU module.
• When first pushing in the communication connector cover to break, take care not to injure your
finger.
Before mounting a communication module or HMI base module next
ommunication
Connector Cover
to the slim type CPU module, the communication connector cover
must be removed from the CPU module. Break the communication
connector cover on the slim type CPU module as described below.
Bridges B
Bridges A
1. Carefully push in the communication connector cover at position (1) to break bridges A as shown in either figure
below.
(1)
2. The other end (2) of the communication connector cover will come out as shown at left below. Push in this end.
3. Then, the opposite end (3) will come out. If the end does not come out, insert a thin screwdri ver into the gap and pull
out the end (3).
Hold the communication connector cover at (3), and pull off the communication connector cover to break bridges B.
(3)
(2)
3-6 « MICROSMART USER’S MANUAL »
Mounting on DIN Rail
35-mm-wide DIN Rail
Clamp
(A)
(B)
Direct Mounting Strip
FC4A-PSP1P
3: INSTALLATION AND WIRING
Caution
• Install the MicroSmar t modules according to instructions described in this user’s manual.
Improper installation will result in falling, failure, or malfunction of the MicroSmart.
• Mount the MicroSmar t modules on a 35-mm-wide DIN rail or a panel surface.
Applicable DIN rail: IDEC’s BAA1000NP or BAP1000NP (1000mm/39.4” long)
1. Fasten the DIN rail to a panel using screws firmly.
2. Pull out the clamp from each MicroSmart module,
and put the groove of the module on the DIN rail.
Press the modules towards the DIN rail and push in
the clamps as shown on the right.
3. Use BNL6P mounting clips on both sides of the
MicroSmart modules to prevent moving sideways.
Removing from DIN Rail
1. Insert a flat screwdriver into the slot in the clamp.
Groove
35-mm-wide DIN Rail
Clamp
2. Pull out the clamps from the modules.
3. Turn the MicroSmart modules bottom out.
Direct Mounting on Panel Surface
MicroSmart modules can also be mounted on a panel
surface inside a console. When mounting a slim type
CPU module, digital I/O module, analog I/O module,
HMI base module, or communication module, use
optional direct mounting strip FC4A-PSP1P as
described below.
Installing the Direct Mounting Strip
1. Remove the clamp from the module by pushing the
clamp inward.
2. Insert the direct mounting strip into the slot where the
clamp has been removed (A). Further insert the direct
mounting strip until the hook enters into the recess in
the module (B).
« MICROSMART USER’S MANUAL »3-7
3: INSTALLATION AND WIRING
Removing the Direct Mounting Strip
1. Insert a flat screwdriver under the latch of the direct
(B)
(A)
mounting strip to release the latch (A).
2. Pull out the direct mounting strip (B).
Mounting Hole Layout for Direct Mounting on Panel Surface
Make mounting holes of ø4.3 mm as shown below and use M4 scre ws (6 or 8 mm long) to mount the MicroSmart modules
on the panel surface.
• CPU Modules
FC4A-C10R2, FC4A-C10R2C, FC4A-C24R2, FC4A-C24R2C
FC4A-C16R2, FC4A-C16R2C
2-ø4.3
2-ø4.3
83.0
90.0
68.0
80.0
90.0
83.0
83.0
95.0
FC4A-D20K3, FC4A-D20S3 FC4A-D20RK1, FC4A-D20RS1,
FC4A-D40K3, FC4A-D40S3
35.4
24.1
2-ø4.3
90.0
103.0
47.5
24.1
2-ø4.3
90.0
103.0
3.0
3-8 « MICROSMART USER’S MANUAL »
3.0
All dimensions in mm.
3: INSTALLATION AND WIRING
• I/O Modules
FC4A-N08B1, FC4A-N16B1, FC4A-N08A11, FC4A-R081, FC4A-N16B3, FC4A-T16K3, FC4A-T16S3
FC4A-R161, FC4A-T08K1, FC4A-T08S1, FC4A-M08BR1,
FC4A-L03A1, FC4A-L03AP1, FC4A-J2A1, FC4A-K1A1
23.5
3.0
2-ø4.3
90.0
6.3
103.0
6.3
FC4A-N32B3, FC4A-T32K3, FC4A-T32S3 FC4A-M24BR2
29.7
6.3
2-ø4.3
6.3
17.6
3.0
39.1
2-ø4.3
90.0
103.0
2-ø4.3
3.0
90.0
103.0
3.0
90.0
103.0
• HMI Base Module •Communication Modules
FC4A-HPH1 FC4A-HPC1, FC4A-HPC2, FC4A-HPC3
20.3
38.0
2-ø4.3
90.0
103.0
4.8
22.5
2-ø4.3
90.0
103.0
3.0
3.0
All dimensions in mm.
« MICROSMART USER’S MANUAL »3-9
3: INSTALLATION AND WIRING
Example 1: Mounting hole layout for FC4A-C24R2 and 23.5-mm-wide I/O modules
12.3 23.5 23.5 23.5
10-ø4.3
83.0
3.0 3.0 3.0 3.0
23.583.0
15.3 23.5 23.5
103.0
Direct Mounting Strip
FC4A-PSP1P
113.0±0.2
Example 2: Mounting hole layout for, from left, FC4A-HPH1, FC4A-D20K3, FC4A-N16B3, FC4A-N32B3, and
FC4A-M24R2 modules
41.8 17.6 17.6 29.7
103.0
3.0
3.0
3.0 3.0 3.0
41.8 17.6 17.6 29.7
3-10 « MICROSMART USER’S MANUAL »
All dimensions in mm.
3: INSTALLATION AND WIRING
Installation in Control Panel
The MicroSmart modules are designed for installation in a cabinet. Do not install the MicroSmar t modules outside a cabinet.
The environment for using the
degree 2 (according to IEC 60664-1).
When installing the MicroSmart modules in a control panel, take the convenience of operation and maintenance, and resistance against environments into consideration.
All-in-One Type CPU Module
MicroSmart is “Pollution degree 2.” Use the MicroSmart in environments of pollution
Front Panel
40 mm
minimum
Slim Type CPU Module
20 mm minimum
20 mm minimum
20 mm minimum
40 mm
minimum
20 mm minimum
80 mm
minimum
20 mm minimum
Wiring Duct
Front Panel
20 mm minimum
40 mm
minimum
40 mm
minimum
20 mm minimum
80 mm
minimum
20 mm minimum
Wiring Duct
« MICROSMART USER’S MANUAL » 3-11
3: INSTALLATION AND WIRING
Mounting Direction
Mount the MicroSmart modules horizontally on a vertical plane as shown on the preceding page. K eep a suf ficient spacing
around the MicroSmart modules to ensure proper ventilation and keep the ambient temperature between 0°C and 55°C.
All-in-One Type CPU Module
When the ambient temperature is 35°C or below, the all-in-one type CPU modules can also be mounted upright on a horizontal plane as shown at left below. When the ambient temperature is 40°C or belo w, the all-in-one type CPU modules can
also be mounted sideways on a vertical plane as shown in the middle below.
Allowable Mounting Direction
at 35°C or below
at 40°C or below
Incorrect Mounting DirectionAllowable Mounting Direction
Slim Type CPU Module
Always mount the slim type CPU modules horizontally on a vertical plane as shown on the preceding page. Any other
mounting directions are not allowed.
Incorrect Mounting DirectionIncorrect Mounting DirectionIncorrect Mounting Direction
3-12 « MICROSMART USER’S MANUAL »
Input Wiring
3: INSTALLATION AND WIRING
Caution
• Separate the input wiring from the output line, power line, and motor line.
• Use proper wires for input wiring.
All-in-one type CPU modules: UL1015 AWG22 or UL1007 AWG18
Slim type CPU and I/O modules: UL1015 AWG22
DC Source Input DC Sink Input
24V DC
2-wire Sensor
–
+
–
NPN
DC.IN
+
01234567
COM COM
0
1
2
3
4
5
6
7
24V DC
2-wire Sensor
+
–
+
PNP
DC.IN
–
01234567
COM COM
0
1
2
3
4
5
6
7
« MICROSMART USER’S MANUAL » 3-13
3: INSTALLATION AND WIRING
Output Wiring
Caution
Relay Output
Connect a fuse appropriate
• If output relays or transistors in the MicroSmar t CPU or output modules should fail, outputs may
remain on or off. For output signals which may cause heavy accidents, provide a monitor circuit
outside the MicroSmart.
• Connect a fuse to the output module, selecting a fuse appropriate for the load.
• Use proper wires for output wiring.
All-in-one type CPU modules: UL1015 AWG22 or UL1007 AWG18
Slim type CPU and I/O modules: UL1015 AWG22
• When equipment containing the MicroSmar t is intended for use in European countries, insert an
IEC 60127-approved fuse to each output of every module for protection against overload or
short-circuit. This is required when equipment containing the MicroSmart is destined for Europe.
for the load.
Fuse
+
–
Fuse
+
–
DC
DC
–
DC
+
Fuse
–
DC
+
Fuse
Fuse
AC
Fuse
AC
Fuse
Load
L
L
L
L
L
L
L
L
Ry.OUT
1023
COM0
NC 456
7 COM1
0
1
2
3
4
5
6
7
Transistor Sink Output Transistor Source Output
Tr.OUT
Load
Fuse
Fuse
+–
01234567
L
L
L
L
L
L
L
L
COM(–)
+V
Connect a fuse
appropriate for the load.
3-14 « MICROSMART USER’S MANUAL »
0
1
2
3
4
5
6
7
Fuse
+–
Connect a fuse
appropriate for the load.
Fuse
Load
L
L
L
L
L
L
L
L
Tr.OUT
01234567
COM(+)
–V
0
1
2
3
4
5
6
7
3: INSTALLATION AND WIRING
Contact Protection Circuit for Relay and Transistor Outputs
Depending on the load, a protection circuit may be needed for the relay output of the MicroSmart modules. Choose a protection circuit from A through D shown below according to the power supply and connect the protection circuit to the outside of the CPU or relay output module.
For protection of the transistor output of the
tor output circuit.
Protection Circuit A
MicroSmart modules, connect protection circuit C shown below to the transis-
Output Q
COM
Protection Circuit B
Output Q
COM
Protection Circuit C
Output Q
COM
Inductive Load
C
R
Inductive Load
R
Inductive Load
This protection circuit can be used when the load impedance is
smaller than the RC impedance in an AC load power circuit.
R: Resistor of approximately the same resistance value as the load
C: 0.1 to 1 µF
This protection circuit can be used for both A C and DC load po wer
circuits.
C
R: Resistor of approximately the same resistance value as the load
C: 0.1 to 1 µF
+or–
This protection circuit can be used for DC load power circuits.
Use a diode with the following ratings.
Reverse withstand voltage: Power voltage of the load circuit × 10
+–
Forward current: More than the load current
Protection Circuit D
Output Q
COM
Inductive Load
Varistor
+or–
This protection circuit can be used for both A C and DC load po wer
circuits.
« MICROSMART USER’S MANUAL » 3-15
3: INSTALLATION AND WIRING
Power Supply
All-in-One Type CPU Module (AC and DC Power)
Caution
• Use a power supply of the rated value. Use of a wrong power supply may cause fire hazard.
• The allowable power voltage range is 85 to 264V AC for the AC power type CPU module and
16.0 to 31.2V DC for the DC power type CPU module. Do not use the MicroSmart CPU module
on any other voltage.
• On the AC power type CPU module, if the power voltage turns on or off very slowly between 15
and 50V AC, the CPU module may run and stop repeatedly between these voltages. If failure or
disorder of the control system, damage, or accidents may be caused, provide a measure for prevention using a voltage monitoring circuit outside the MicroSmart.
• Use an IEC 60127-approved fuse on the power line outside the MicroSmart. This is required
when equipment containing the MicroSmart is destined for Europe.
Power Supply Voltage
The allowable power voltage range for the all-in-one type MicroSmart CPU module is 85 to 264V AC for the AC power
type and 16.0 to 31.2V DC for the DC power type.
Power failure detection voltage depends on the quantity of used input and output points. Basically, power failure is
detected when the power voltage drops below 85V AC or 16.0V DC, stopping operation to prevent malfunction.
A momentary power interruption for 20 msec or less is not recognized as a power failure at the rated voltage of 100 to
240V AC or 24V DC.
Inrush Current at Powerup
When the all-in-one AC or DC power type CPU module is powered up, an inrush current of a maximum of 35A (10- and
16-I/O type CPU modules) or 40A (24-I/O type CPU module) flows.
Power Supply Wiring
Use a stranded wire of UL1015 AWG22 or UL1007
AWG18 for power supply wiring. Make the power supply
wiring as short as possible.
Run the power supply wiring as far away as possible from
motor lines.
Grounding
To prevent electrical shocks, connect the or terminal
to a proper ground using a wire of UL1007 AWG16. The
grounding also prevents malfunctioning due to noise.
Do not connect the grounding wire in common with the
grounding wire of motor equipment.
AC Power DC Power
L N
100-240
V AC
24V DC
+ –
+
–
3-16 « MICROSMART USER’S MANUAL »
Slim Type CPU Module (DC Power)
3: INSTALLATION AND WIRING
Caution
• Use a power supply of the rated value. Use of a wrong power supply may cause fire hazard.
• The allowable power voltage range for the slim type MicroSmart CPU module is 20.4 to 26.4V
DC. Do not use the MicroSmart on any other voltage.
• If the power voltage turns on or off very slo wly between 10 to 15V DC, the MicroSmart may run
and stop repeatedly between these voltages. If failure or disorder of the control system, damage,
or accidents may be caused, provide a measure for prevention using a voltage monitoring circuit
outside the MicroSmart.
• Use an IEC 60127-approved fuse on the power line outside the MicroSmart. This is required
when equipment containing the MicroSmart is destined for Europe.
Power Supply Voltage
The allowable power voltage range for the slim type
MicroSmart CPU module is 20.4 to 26.4V DC.
Power failure detection voltage depends on the quantity of used input and output points. Basically, power failure is
detected when the power voltage drops below 20.4V DC, stopping operation to prevent malfunction.
A momentary power interruption for 10 msec or less is not recognized as a power failure at the rated voltage of 24V DC.
Inrush Current at Powerup
When the slim type CPU module is powered up, an inrush current of a
maximum of 50A flows.
Power Supply Wiring
Use a stranded wire of UL1015 AWG22 or UL1007 AWG18 for power
supply wiring. Make the power supply wiring as short as possible.
+ –
Run the power supply wiring as far away as possible from motor lines.
Grounding
To prevent electrical shocks, connect the terminal to a proper ground
+
–
24V DC
using a wire of UL1015 AWG22 or UL1007 AWG18. The grounding also
prevents malfunctioning due to noise.
Do not connect the grounding wire in common with the grounding wire of
motor equipment.
« MICROSMART USER’S MANUAL » 3-17
3: INSTALLATION AND WIRING
Terminal Connection
Caution
• Make sure that the operating conditions and environments are within the specification values.
• Be sure to connect the grounding wire to a proper ground, otherwise electrical shocks may be
caused.
• Do not touch live terminals, otherwise electrical shocks may be caused.
• Do not touch terminals immediately after power is turned off, otherwise electrical shocks may be
caused.
• When using ferrules, insert a wire to the bottom of the ferrule and crimp the ferrule.
• When connecting a stranded wire or multiple solid wires to a screw terminal block, use a ferrule.
Otherwise the wire may slip off the screw terminal block.
Ferrules, Crimping Tool, and Screwdriver for Phoenix Terminal Blocks
The screw terminal block can be wired with or without using ferrules on the end of cable. Applicable ferrules for the Phoenix terminal blocks and crimping tool for the ferrules are listed below. The screwdriver is used for tightening the screw ter minals on the MicroSmart modules. These ferrules, crimping tool, and screwdriver are made by Phoenix Contact and are
available from Phoenix Contact.
Type numbers of the ferrules, crimping tool, and screwdriv er listed below are the type numbers of Phoenix Contact. When
ordering these products from Phoenix Contact, specify the Order No. and quantity listed below.
Ferrule Order No.
Quantity of Cables Cable Size Phoenix Type Order No. Pcs./Pkt.
UL1007 AWG16 AI 1,5-8 BK 32 00 04 3 100
For 1-cable connection
For 2-cable connection
UL1007 AWG18 AI 1-8 RD 32 00 03 0 100
UL1015 AWG22 AI 0,5-8 WH 32 00 01 4 100
UL1007 AWG18 AI-TWIN 2 x 0,75-8 GY 32 00 80 7 100
UL1015 AWG22 AI-TWIN 2 x 0,5-8 WH 32 00 93 3 100
Crimping Tool and Screwdriver Order No.
Tool Name Phoenix Type Order No. Pcs./Pkt.
Crimping Tool CRIMPFOX ZA 3 12 01 88 2 1
For CPU modules SZS 0,6 x 3,5 12 05 05 3 10
Screwdriver
Screw Terminal Tightening Torque
For I/O modules and
communication adapter
SZS 0,4 x 2,5 12 05 03 7 10
CPU modules 0.5 N·m
I/O modules
Communication adapter
0.22 to 0.25 N·m
3-18 « MICROSMART USER’S MANUAL »
4: OPERATION BASICS
Introduction
This chapter describes general information about setting up the basic MicroSmart system for programming, starting and
stopping MicroSmart operation, and introduces simple operating procedures from creating a user program using WindLDR
on a computer to monitoring the MicroSmart operation.
Connecting MicroSmart to PC (1:1 Computer Link System)
The MicroSmart can be connected to a Windows PC in two ways.
Computer Link through Port 1 or Port 2 (RS232C)
When connecting a Windows computer to the RS232C port 1 or port 2 on the MicroSmart CPU module, enable the maintenance protocol for the RS232C port using the Function Area Settings in WindLDR. See page 26-2.
To set up a 1:1 computer link system, connect a computer to the CPU module using the computer link cable 4C (FC2AKC4C). The computer link cable 4C can be connected to port 1 directly. When connecting the cable to port 2 on the all-inone 16- or 24-I/O type CPU module, install an optional RS232C communication adapter (FC4A-PC1) to the port 2 connector. When connecting to port 2 on the slim type CPU module, an optional RS232C communication module (FC4AHPC1) is needed. The RS232C communication adapter can also be installed on the HMI base module (FC4A-HPH1).
Computer Link Cable 4C
FC2A-KC4C
3m (9.84 ft.) long
Port 1 (RS232C)
RS232C
D-sub 9-pin
Female Connector
Note: The port 2 connector is
available on the all-in-one 16and 24-I/O type CPU modules
only; not on the 10-I/O type.
RS232C Communication Adapter
Port 2 (Note)
FC4A-PC1
Port 1 (RS232C)
RS232C Communication Module
FC4A-HPC1
Port 2
Port 1 (RS232C)
HMI Base Module
FC4A-HPH1
All-in-One Type
CPU Module
Slim Type
CPU Module
Slim Type
CPU Module
RS232C Communication Adapter
« MICROSMART USER’S MANUAL »4-1
Port 2
FC4A-PC1
4: OPERATION BASICS
Computer Link through Port 2 (RS485)
When connecting a Windows computer to port 2 on the all-in-one 16- or 24-I/O type CPU module or slim type CPU module, enable the maintenance protocol for port 2 using the Function Area Settings in WindLDR. See page 26-2.
To set up a 1:1 computer link system using the all-in-one 16- or 24-I/O type CPU module, install an optional RS485 communication adapter (FC4A-PC2) to the port 2 connector. Connect a computer to the RS232C/RS485 converter (FC2AMD1) using the RS232C cable (HD9Z-C52). Connect the RS232C/RS485 converter to the CPU module using the user
communication cable 1C (FC2A-KP1C). The RS232C/RS485 converter is powered by an 24V DC source or an AC
adapter with 9V DC output. For details about the RS232C/RS485 converter, see page 26-4.
To set up a 1:1 computer link system using the slim type CPU module, an optional RS485 communication module (FC4AHPC2) is needed. The RS485 communication adapter can also be installed on the HMI base module (FC4A-HPH1).
RS232C Cable
HD9Z-C52
1.5m (4.92 ft.) long
RS232C
D-sub 9-pin
Female Connector
RS232C/RS485 Converter
FC2A-MD1
RS485 Communication Adapter
Port 2
FC4A-PC2
User Communication Cable 1C
FC2A-KP1C
2.4m (7.87 ft.) long
A: Pin 1
B: Pin 2
SG: Pin 7
Port 2
All-in-One Type
CPU Module
RS485 Communication Module
FC4A-HPC2
Slim Type
CPU Module
HMI Base Module
FC4A-HPH1
Port 2
RS485 Communication Adapter
FC4A-PC2
4-2 « MICROSMART USER’S MANUAL »
Slim Type
CPU Module
Loading...
