Boilers
Condensing
icos HE 4
W 5
plus II 6
xtra 7
Concord CXC 8
GT Condenser 9
Gas Atmospheric
Concord CXA/H S/H 10
Concord Modular 11
Concord CXSi/H 12
Radiators
Stelrad Radiators
22
Traditional
Elite 24
Compact 25
Low Surface Temperature
LST Standard 26
LST Plus 27
Specifier Range
Concord ES/H 13
High Efficiency
Super Series 4 14
Super Plus 15
Pressure Jet
Buccaneer GTE 16
Falcon GTS 17
Harrier GTE 18
Viceroy GT 19
Viscount GTE 20
Vanguard L 21
Style 28
Planar 29
Concord 30
Radiator Options
31
2
Ideal Boilers
Ideal Boilers is one of the most respected names in the UK Commercial and
Domestic heating industry. We design and develop ranges to suit the ever
changing UK marketplace. With the market’s continued move towards
condensing products, Ideal launched the condensing range.
The recent addition of the xtra maintains Ideal’s position as the
market leading supplier in the Commercial and Industrial boiler sector.
The Commercial Heating Team
As industry leaders Ideal Boilers and Stelrad Radiators are committed to
ensuring that all products are engineered to the highest standards.
To support our products we have a comprehensive service department who
can supply you with in-depth product knowledge and system advice which
will ensure that your heating will run efficiently and will increase the
lifespan of our products.
Contact Numbers
Sales
01482 498690
Tel:
Fax: 01482 498621
Technical
Tel: 01482 498376
Fax: 01482 498621
Training
Tel: 01482 498432
Fax: 01482 498605
email: commercial_heating@idealboilers.com
Website
Our newly designed website contains useful information including details of
training courses, product information and literature, merchant stockists,
a background to Part L2, contact information and many more features.
You will find the website located at:
www.idealcommercialboilers.com
3
condensing
icos HE 30 + 36kW
• Wall mounted
• Robust cast aluminium heat exchanger
• Compact
• Easy to install and service
• Modulating output down to 10.4kW
• Wide range of flue options
• Optional remotely mountable user controls
General Data icos HE (30 + 36)
Model 30 36
Boiler Output (condensing) 50/30˚C 11.4 - 32.8 11.4 - 39.8
Boiler Output (non-condensing) 80/60˚C 10.4 - 30.1 10.4 - 37.0
Height 645
Width 450
Depth 410
Flow/Return Connections (mm) 28
”
Gas Inlet (BSP) RC1/
Concentric 60/100 60/100
Flue Size (mm)
Twin Pipe 80/80 80/80
Maximum Working Pressure (bar) 3
Water Content (L)
Approx Dry Weight (kg) 52.6 52.6
Boiler
Clearances
4.7 4.7
Top (mm) 165
Below (mm) 150
Left (mm) 15
2
Right (mm) 15
Front (mm) 450
Condensate Drain (mm) 21.5
Option Kits
Boiler icos HE 30 + 36
Remote user control kit ✓
Stand off kit ✓
4
Syphon kit ✓
Condensate pump kit ✓
W 45 - 80kW
• Natural gas and propane
• Single unit or modular configuration,
wall or frame mounted
• Robust cast aluminium heat exchanger
• Easy to install and service
• Simple UK voltage system controls wiring
• Modulating output down to 13kW
• Wide range of flue options
General Data W (45 - 80)
Model W45 W45P W60 W60P W80 W80P
Boiler output (condensing)
50/30˚C
Boiler output (non-condensing)
80/60˚C
Height 900
Width 540 540 540 540 650 650
Depth 500
Flow/Return Connections (BSP) R11/4
Gas Inlet (mm) 22
Flue Size (mm) 80/125 & 100/150 80/125 & 100/150 100/150
Maximum Working Pressure (bar) 4
Water Content (L)
Approx Dry Weight (kg) 87 87 88 88 101 101
Boiler
Clearances
13.9 - 46.9 13.7 - 45.9 13.9 - 62.3 13.6 - 60.6 21.3 - 82.7 20.7 - 80.0
12.6 - 43.7 12.6 - 58.9 19.5 - 78.2
88881010
Top (mm) dependant on flue
Below (mm) 300
Left (mm) 50
Right (mm) 50
Option Kits
Boiler W
Modulating sequencer kit ✓
Programmable room thermostat kit ✓
Control interface kit ✓
Outside sensor kit ✓
Tank sensor kit ✓
Remote indication kit ✓
Hours run meter(s)
BMS (0-10V) kit ✓
Pump kit ✓
Multi boiler frame and header kits ✓
*Provided as standard
*
5
condensing
plus II 90 - 310kW
Range of six models
•
Compact size - small footprint
•
High modulation - Close load matching (all models down to 11.6kW)
•
108.4% Net efficiency (fully condensing) at 30% part load
•
Boilers consist of several modules giving built-in standby capability
•
Robust cast aluminium heat exchanger
•
Integral commissioning and fault diagnostics
•
Optional flue and system connections for fast installations
•
Meets Building Regulations 2006 (Part L2)
•
General Data plus II (90 - 310)
Model F90 F140 F180 F220 F270 F310
New
Model
Boiler output (condensing)
50/30˚C
Boiler output (non-condensing)
80/60˚C
Height 1053
Width 695 695 832 968 1102 1236
Depth 695
Flow/Return Connections (BSP) R2
Gas Inlet (BSP) R11/
Flue Size (mm) 150 150 150 200 200 200
Maximum Working Pressure (bar) 6
Water Content (L) 10.1 14.2 18.3 22.4 26.5 30.6
Approx Dry Weight (kg) 153 182 223 261 301 345
Front (mm) 600
Boiler
Clearances
Back (mm) 450* 450* 450 450 450 450
12.5 - 92.6 12.5 - 136.8 12.5 - 179.3 12.5 - 228.6 12.5 - 280.7 12.5 - 321.5
11.2 - 89.5 11.2 - 132.2 11.2 - 173.4 11.2 - 221.0 11.2 - 271.3 11.2 - 311.0
2
Side (mm) 50 (1 side) & 450 (other side), increase to 600 for side flues.
*F90 & F140 300 if no rear flue.
Option Kits
Boiler plus II
Outside sensor kit
Tank sensor kit ✓
Remote indication kit
6
*
*
Hours run meter(s)
BMS (0-10V) kit
*Provided as standard
*
*
xtra 80 - 560kW
Robust cast aluminium heat exchanger
•
In-built commissioning and fault diagnostics
•
Low NOx emissions
•
Volt free contacts supplied as standard
•
Meets Building Regulations 2006 (Part L2)
•
Compact size - small footprint
•
Fully modulating operation down to 20% of output
•
Up to 107.5% nett efficiency (fully condensing)
•
Fits through standard doorways
•
General Data xtra (80 - 560)
Model 80 120 160 200 240 280 320 400 480 560
Boiler output (condensing) 25.6 - 25.6 - 32.0 - 47.1 - 51.4 - 55.6 - 75.3 - 107.5 - 116.1 - 118.3 50/30˚C 82.2 123.4 164.5 207.8 249.4 290.9 329.0 415.6 498.8 581.8
Boiler output (non-condensing) 23.3 - 23.2 - 29.0 - 43.1 - 47.0 - 51.0 - 67.8 - 97.7 - 105.5 - 107.7 80/60˚C 77.4 116.0 154.8 195.4 234.5 273.6 311.6 390.8 469.0 547.2
Height 1150
Extended
Output
Range
Width 600 600 600 600 600 600 1200 1200 1200 1200
Depth 1024 1024 1024 1327 1327 1327 1004 1326 1326 1326
Flow connection (BSP) R2” R2” R2” R2” R2” R2” 80* 80* 80* 80*
Return connection (BSP) R2” R2” R2” R2” R2” R2” 80* 80* 80* 80*
Gas inlet connection (BSP) R1” R1” R1” R1” R1” R1” R2* R2* R2* R2*
Nominal flue size / concentric (mm) 150 150 150 200 200 200 200 250 250 250
Maximum working pressure (bar) 6
Water content (L) 11.0 14.3 17.5 18.4 24.0 27.2 35.0 36.8 48.0 54.4
Weight (kg) 132 150 168 198 215 233 336 396 430 466
Front (mm) 600
Boiler
Clearances
*DN flange. Flow, return and gas connection sizes shown are for the optional header kit.
If header kit not used: Flow & Return connections are 2 x R2. Gas connection is 2 x R1.
Back (mm) 700 700 700 700 700 700 1000 1000 1000 1000
Side (mm) 450 150 450 150 450 150 450 150 450 150 450 150 450 450 450 450
(LH)(RH) (LH)(RH) (LH)(RH) (LH)(RH) (LH)(RH) (LH)(RH)
Option Kits
Boiler xtra
80 - 280 320 - 560
Boiler xtra
80 - 280 320 - 560
Modulating sequence control for ✓✓
controlling multiple boiler installations
Programmable room thermostat ✓✓
Tank sensor kit ✓ n/a
BMS control kit (0-10V) ✓ Standard
Outside sensor kit ✓✓
Room sensor kit ✓✓
Sequencer DHW sensor kit ✓✓
Control interface kit ✓ Standard
7
condensing
Concord CXC 48 - 116kW
• Natural gas fired condensing boiler
• Meets Building Regulations 2006 (Part L2)
• Fully condensing high efficiency 85%
at 80˚C, 93% at 60˚C flow
• Compact space saving design
• Full automatic ignition
• Advanced electronic controls
General Data Concord CXC (48 - 116)
Model 48 70 94 116
Boiler output (condensing)
50/30˚C
Boiler output (non-condensing)
80/60˚C
Height 1438
Width 600
Depth 723 846 969 1092
Flow/Return Connections (BSP) RC2
Gas Inlet (BSP) RC3/
Flue Size (mm) 150
Maximum Working Pressure (bar) 4.5
Water Content (L) 28 36 43 51
Approx Dry Weight (kg) 298 350 442 494
Front (mm) 750
Boiler
Clearances
Back (mm) 200
48.83 69.84 93.65 116.25
44.63 63.84 83.60 106.30
3
4
RC
4
/
RC
3
4
/
RC1
Option Kits
Boiler
Remote indication board
Outside sensor
8
Side (mm) 50 50 50 100
Concord CXC
✓
✓
GT Condenser 199 - 1096kW
• Up to 16% extra heat
• Compact space saving design
• Adjustable flue and system connections
• Low flue and system resistances
• High insulation levels
• Fanned or standard versions
• Suitable for Harrier, Viceroy and Viscount boilers
General Data GT Condenser (199 - 1096)
Model RCI 300 RCI 300V RCI 400 RCI 400V RCI 500 RCI 500V
Output (kW) 180 - 450 230 - 670 390 - 986
Height (mm) 1687 1777 1883
Width (mm) 610 698 830
Depth (mm) (over optional fan) 1156 1250 1376
Flue Size (mm) 300 350 400
The addition of a GT Condenser to the boiler can
provide up to 16% more heat by cooling the flue gases
to gain both sensible and latent heat from condensation.
The lower the system return temperature being fed into
the Condenser the more the gain. It all provides benefits
in lower emissions and lower fuel bills.
This GT Condenser range is suitable for gas fired
boilers only but can be fitted to dual fuel boilers with
Harrier, Viceroy and Viscount boilers with a boiler output
range suitability from 180kW (614,000 Btu/h) to
986kW (3,364,000Btu/h). Three output models cover
this range and to ensure easy flue installation, each is
available with or without a fan to overcome the flue
pressure loss of the GT Condenser if necessary. A 6 bar
working pressure capability ensures system application
is straight forward.
suitable flue design. Six models are available to suit
Option Kits
Boiler GT Condenser
Fan version RCI 300V
RCI 400V
RCI 500V
9
gas atmospheric
Concord CXA/H S/H 40 - 120kW
• Ultra reliable gas atmospheric boilers
• High, full and part load efficiencies -
meets Building Regulations 2006 (Part L2)
• Auto ignition
• Remote indication kit options
• CXA/H natural gas or propane CXA P/H (40-100kW)
• CXA/H is On/Off and CXS/H is High/Low operation
General Data Concord CXA/H S/H (40 - 120)
Model 40/H 50/H 60/H 70/H 80/H 90/H 100/H 110/H 120/H
Sections 3 4 4 5 5 6 6 7 7
Output (kW) 40 50 60 70 80 90 100 110 120
Height 1000
Width 600
Depth 750 882 882 1042 1042 1212 1212 1385 1385
Flow/Return Connections (BSP)
Gas Inlet (BSP) RC3/4 RC3/4 RC3/4 RC3/4 RC3/4 RC1 RC1 RC1 RC1
Flue Size (mm) 150 150 175 175 200 200 200 250 250
Maximum Working Pressure (bar)
Water Content (L) 22 30 30 37 37 45 45 53 53
Approx Dry Weight (kg) 210 265 265 330 330 395 395 490 490
Front (mm) 750
Boiler
Clearances
Back (mm) 0 0 0 150 150 300 300 300 300
Sides (mm) 50 50 50 50 50 100 100 100 100
RC2
6
Option Kits
Boiler CXA/H CXS/H
Volt free contacts, boiler run,
overheat & lockout
Down draft thermostat kit ✓✓
Header kits (available from merchants) ✓✓
Propane models ✓
10
✓✓
Concord Modular 80 - 720kW
• Suitable for Concord CXA/H and CXS/H models
• Multiple installation outputs from 80-720kW
• All servicing and maintenance from the front of boilers
• Large clean-out cover for full access to flueways
• Standard boiler width: 600mm
• Factory assembled and tested units
• Sequencer control kit available
• Remote indication kit options
General Data Concord Modular (80 - 720)
Model 40/H 50/H 60/H 70/H 80/H 90/H 100/H 110/H 120/H
No. Boilers 2x 80kW 100kW 120kW 140kW 160kW 180kW 200kW 220kW 240kW
3x 120kW 150kW 180kW 210kW 240kW 270kW 300kW 330kW 360kW
4x 160kW 200kW 240kW 280kW 320kW 360kW 400kW 440kW 480kW
5x 200kW 250kW 300kW 350kW 400kW 450kW 500kW 550kW 600kW
6x 240kW 300kW 360kW 420kW 480kW 540kW 600kW 660kW 720kW
Option Kits
Boiler Modular
Sequencer control kit ✓
Outside sensor kit Mandatory
Sequencer control kit
11
gas atmospheric
Concord CXSi/H 110 - 180kW
• Ultra reliable gas atmospheric boilers
• High, full and part load efficiencies -
meets Building Regulations 2006 (Part L2)
• Auto ignition
• Remote indication kit options
• High/Low operation
General Data Concord CXSi/H (110 - 180)
Model 110/H 120/H 140/H 160/H 180/H
Sections 778910
Output (kW) 110 120 140 160 180
Height 1000
Width 1107 1107 1230 1353 1476
Depth 1036 1036 1036 1086 1140
Flow/Return Connections (mm) Flow: DN65 Flange. Return RC2
Gas Inlet (BSP) RC11/2
Flue Size (mm) 250 250 250 250 300
Maximum Working Pressure (bar) 6
Water Content (L) 53 53 60 68 76
Approx Dry Weight (kg) 520 520 587 654 721
Front (mm) 700
Boiler
Clearances
Back (mm) 200
Side (mm) 100 (not including clearance for side fitted flow header)
Option Kits
Boiler CXSi/H
Volt free contacts, alarm & boiler run conditions ✓
12
Concord ES/H 140 - 380kW
• High/Low adjustable operation on all models
• High, full and part load efficiencies -
meets Building Regulations 2006 (Part L2)
• Assembled or unassembled
heat exchanger availability
• Robust cast iron heat exchanger
• Easy to install and service
• Low return temperature capability
General Data Concord ES/H (140 - 380)
Model 140/H 160/H 180/H 200/H 220/H 260/H 300/H 340/H 380/H
Sections 8 9 10 11 12 14 16 18 20
Output (kW) 140 160 180 200 220 260 300 340 380
Height 1406 1406 1406 1406 1406 1406 1406 1406 1406
Width 970 1058 1146 1234 1322 1498 1674 1850 2026
Depth 1362 1362 1362 1362 1362 1412 1412 1412 1462
Flow/Return Connections (BSP)
Gas Inlet (BSP) RP1 RP1 RP1 RP1 RP1 RP11/
Flue Size (mm) 250 250 300 300 300 350 350 350 400
Maximum Working Pressure (bar)
Water Content (L) 61 68 76 84 91 106 122 137 154
Approx Dry Weight (kg) 667 730 807 880 934 1096 1227 1364 1476
Front (mm) 1000
Boiler
Clearances
Back (measured from rear edge of jacket) (mm) 500
At sides Water connection side (RH or LH) (mm) 400
At sides Non connection side (RH or LH) (mm) 200
R2
4
6
4
/
1
RP1
RP1
1
RP1
4
/
Option Kits
Boiler ES/H
1
2
/
Hours run meter (1 or 2 hours) ✓
Flue gas thermometer ✓
13
high efficiency
Super Series 4 50 - 600kW
• Vertical and horizontal models
• High efficiency 85% (gross)
• Low NOx emissions (class 5)
• 50kW Modules
• Sequence controlled
• Compact size
• Complete package gas/water headers
General Data Super Series 4 (50 - 600)
Model 50/V 100/V 150/V 150/VA 200/V 250/V 250/H 300/V 300/H 350/V 400/V 450/V 450/H 500/V 500/H 550/V 550/H 600V 600H
Modules 1 2 33455667899101011111212
Output (kW) 50 100 150 150 200 250 250 300 300 350 400 450 450 500 500 550 550 600 600
Height 782 1432 1912 1487 1487 1967 1443 1972 1443 1618 1618 2144 1345 2144 1345 2144 1345 2144 1345
Width 439 701 701 1171 1171 1171 1783 1171 1783 1822 1822 1833 2393 1833 2393 1833 2392 1833 2393
Depth 698 698 698 698 698 698 698 698 698 1350 1350 1350 1350 1350 1350 1350 1350 1350 1350
Flow/Return Connections (DN flange)
Gas Inlet (BSP) RC3/4 RC1 RC11/4 RC11/4 RC11/4 RC11/2 RC11/2 RC11/2 RC11/2 RC2 RC2 RC2 RC2 RC2 RC2 RC2 RC2 RC2 RC2
Flue Size (mm) 125 175 200 200 250 250 250 300 300 350 350 400 400 400 400 450 450 450 450
Maximum Working Pressure (bar)
Water Content (L) 4.5 11.9 20.7 21.7 26.2 37.7 39.7 44.5 44.5 63.3 68.1 97.6 92.6 102.4 97.4 107.2 102.2 112 107
Approx Dry Weight (kg) 82.1 187.7 274.1 296.4 348 461 411.2 511.2 513.7 765 813 985 972 1033 1020 1080 1067 1129 1115
Front (mm)
Boiler
Clearances
Back (mm)
Left (mm)
40 50 65 65 65 80 80 80 80 100 100 125 125 125 125 125 125 125 125
6
950
25 25 25 25 25 25 25 25 25 950 950 950 950 950 950 950 950 950 950
450 900 900 900 900 900 900 900 900 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Right (mm)
Option Kits
Boiler
Water flow switch for boiler protection in
the event of pump failure
External sequencer control kit
Module blanking off pack
14
450 900 900 900 900 900 900 900 900 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Super Series 4
✓
✓
✓
Super Plus 200 - 600kW
• Horizontal assembly
• High efficiency 85% (gross)
• Low NOx emissions (class 5)
• 100kW Modules
• Ultra compact
• Sequence controlled
• Easy to install and service
General Data Super Plus (200 - 600)
Model 200/S 300/3 300/3A 400/4 400/4A 500/5 600/6
Modules 2334456
Output (kW) 200 300 300 400 400 500 600
Height 1800 1900 1900 1900 1900 1900 1900
Width 910 1510 2115 1510 2115 2115 2115
Depth 990 990 990 990 990 990 990
Flow/Return Connections (DN flange) 65 125 125 125 125 125 125
RC2 RC2 RC2 RC2 RC2 RC2
Gas Inlet (BSP) RC11/
Flue Size (mm) 250 350 350 450 450 450 450
Maximum Working Pressure (bar) 6
Water Content (L) 19.8 29.7 29.7 39.7 39.7 49.5 59.4
Approx Dry Weight (kg) 328.3 466.4 466.4 546.1 546.1 715.6 794.6
Front (mm) 900
Boiler
Clearances
Back (mm) 25
Left (mm) 500
Right (mm) 500
2
Option Kits
Boiler
Water flow switch for boiler protection in
the event of pump failure
Remote indication of boiler on,
lockout and overheat for each module
Module blanking off pack
Super Plus
✓
✓
✓
15
pressure jet
Buccaneer GTE 21 - 39kW
• Natural gas, oil fired or dual fuel
• High efficiency
• Minimal emissions
• Compact size
• Comprehensive control
• Low temperature operation
General Data Buccaneer GTE (21 - 39)
Model GTE 4 GTE 5 GTE 6
Sections 4 5 6
Output (kW) 21 - 27 27 - 33 32 - 39
Height (mm) 835
Width (mm) 570
Depth (mm) 812 939 1066
Flow/Return Connections (BSP) R11/4
Maximum Working Pressure (bar) 4
Flue Size (mm) 125 125 153
Water Content (L) 24.5 30.0 35.5
Approx Dry Weight (kg) 182 210 238
Front 1000
Back (mm) 500
Boiler
Clearances
Left (mm) 500
Right (mm) 500
Option Kits
Boiler Buccaneer GTE
DHW sensor ✓
16
Falcon GTS 40-100kW
• Natural gas or oil fired
• High efficiency
• Minimal emissions
• Compact size
New
• Comprehensive control
• Low temperature operation
General Data Falcon GTS (40 - 100)
Model GTS 4 GTS 5 GTS 6 GTS 7 GTS 8
Sections 4 5 6 7 8
Output (kW) 40-50 50-64 64-78 78-92 92-100
Height 1100
Width 520
Depth 772 899 1026 1153 1280
Flow/Return Connections (BSP) R11/4 R11/4 R11/2 R11/2 R11/2
Maximum Working Pressure (bar) 4
Flue Size (mm) 153 153 180 180 180
Model
Water Content (L) 36 43 50 57 64
Approx Dry Weight (kg) 254 296 344 381 423
Front (mm) 1000
Boiler
Clearances
Back (mm) 500
Left (mm) 500
Right (mm) 500
Option Kits
Boiler Falcon GTS
DHW sensor ✓
17
pressure jet
Harrier GTE 105 - 330kW
• Natural gas, oil fired or dual fuel
• High efficiency
• Minimal emissions
• 3 pass heat exchanger
• Compact size
• Meets Building Regulations 2006 (Part L2)
General Data Harrier GTE (105 - 330)
Model GTE5 GTE6 GTE7 GTE8 GTE9
Sections 5 6 7 8 9
Output (kW) 140 180 230 280 330
Height 1297
Width 796
Depth 1151 1311 1471 1631 1791
Flow/Return Connections (DN flange)
Flue Size (mm) 180 180 200 200 200
Maximum Working Pressure (bar)
Water Content (L) 116 136 156 176 196
Approx Dry Weight (kg) 748 906 1043 1165 1289
Front (mm) 1500
Boiler
Clearances
Back (mm) 1000
Side - non hinge (mm) 100
Side - door hinge (mm) 500 or 200 + burner length
65
6
Option Kits
Boiler Harrier GTE
Hours run meter(s) ✓
De Luxe control panel (High / Low operation) ✓
Flue gas thermometer ✓
GT Condenser ✓
18
Viceroy GT 300 - 780kW
• Natural gas, oil fired or dual fuel
• High efficiency
• Minimal emissions
• 3 pass heat exchanger
• Compact size
• Meets Building Regulations 2006 (Part L2)
General Data Viceroy GT (300 - 780)
Model GT8 GT9 GT10 GT11 GT12 GT13 GT14
Sections 8 9 10 11 12 13 14
Output (kW) 390 450 540 600 670 720 780
Height 1695
Width 1000
Depth 1505 1665 1825 1985 2145 2305 2465
Flow/Return Connections (mm) 75 75 75 100 100 100 100
Flue Size (mm) 250 250 250 300 300 300 300
Maximum Working Pressure (bar) 6
Water Content (L) 366 409 452 495 538 581 624
Approx Dry Weight (kg) 1941 2028 2524 2492 2653 2881 3117
Front (mm) 1500 2000 2000 2000 2500 2500 2500
Boiler
Clearances
Back (mm) 1000
Left (mm) 500
Right (mm) 500
Option Kits
Boiler Viceroy GT
Hours run meter(s) ✓
De Luxe control panel (High / Low operation) ✓
Flue gas thermometer ✓
GT Condenser ✓
19
pressure jet
Viscount GTE 754 - 1450kW
• Natural gas, oil fired or dual fuel
• Meets Building Regulations 2006 (Part L2)
• Minimal emissions
• 4 pass heat exchanger
• Comprehensive control
• Low temperature return
General Data Viscount GTE (754 - 1450)
Model GTE14 GTE15 GTE16 GTE17 GTE18 GTE19 GTE20 GTE21 GTE22 GTE23 GTE24 GTE25
Sections 14 15 16 17 18 19 20 21 22 23 24 25
Output (kW) 812 870 928 986 1044 1102 1160 1218 1276 1334 1392 1450
Height 1760
Width 1172
Depth 2105 2245 2355 2445 2555 2645 2845 2955 3045 3155 3245 3355
Flow/Return Connections (mm) 139.7 139.7 139.7 139.7 159 159 159 159 159 159 159 159
Flue Size (mm) 450 450 450 500 500 500 500
Maximum Working Pressure (bar) 6
Water Content (L) 655 693 731 769 807 845 905 943 981 1019 1057 1095
Approx Dry Weight (kg) 3218 3430 3629 3814 3950 4128 4369 4567 4755 4951 5140 5340
Front (mm) 1500
Boiler
Clearances
Back (mm) 300 436 436 656 656 656 936 936 936 1266 1266 1266
Side - non hinge (mm) 500
Right (mm) 1200
500x700max 500x700max 500x700max 500x700max 500x700max
Option Kits
Boiler Viscount GTE
Hours run meter(s) ✓
De Luxe control panel (High / Low operation) ✓
Flue gas thermometer ✓
GT Condenser ✓
20
Vanguard L 130 - 3500kW
• Steel shell construction
• Natural gas, oil fired or dual fuel
• One or two stage operation
• High efficiency 91% net (82% gross)
• Reverse flame combination chamber design
• Easy to install and service
• Meets Building Regulations 2006 (Part L2)
General Data Vanguard L (130 - 3500)
Model 170 240 290 340 420 510 630 760 870 970 1100 1320 1570 1850 2200 2650 3000 3500
Output (kW) 170 240 290 340 420 510 630 760 870 970 1100 1320 1570 1850 2200 2650 3000 3500
Height 1272 1272 1372 1372 1542 1542 1542 1622 1622 1622 1622 1622 1732 1732 1892 1892 2080 2340
Width 820 820 860 860 890 890 890 1122 1122 1122 1352 1352 1462 1462 1622 1622 1670 1920
Depth 1214 1474 1411 1541 1606 1801 2113 1989 2184 2379 2346 2686 2781 3151 3225 3545 3835 3879
Flow/Return Connections (DN flange) 65 65 80 80 100 100 100 125 125 125 150 150 175 175 200 200 200 200
Flue Size (mm) 200 200 250 250 250 250 250 350 350 350 400 400 450 450 520 520 570 620
Maximum Working Pressure (bar) 6
Water Content (L) 190 251 264 298 398 462 565 671 753 836 1040 1242 1418 1617 2086 2324 2553 4862
Approx Dry Weight (kg) 435 510 588 629 796 919 1047 1341 1447 1553 1821 2030 2780 3280 4145 4465 5110 6700
Front (mm) Same length as boiler
Boiler
Clearances
Back (mm) 500
Side - non hinge (mm) 100
Right (mm) 200 + burner length
21
Stelrad Radiators
Stelrad Radiators
Stelrad is the UK market leader in central heating radiators, offering the
widest range, and in more sizes, than any other manufacturer. Our highly
advanced production and distribution facility in Mexborough, UK, produces
over 2.5 million steel panel radiators a year, for both Domestic and
Commercial markets.
From the classic, traditional Elite to the sophisticated, stylish Excel - Stelrad
has a variety of styles and finishes to harmonise with any period or
contemporary setting.
The Stelrad Team
Radiators
08708 498056
Tel:
Fax: 08708 498058
Spares Sales
Tel: 01482 498665
Technical Information
01482 498663
Tel:
email: info@stelrad.com
Website
You’ll find information here on the entire product range; user guides,
installation and mounting instructions, servicing manuals and technical
product data, available options; as well as the services we offer in support of
our products.
You will find the website located at:
www.stelrad.com
22
quality, choice & style
Ladder &
Mini Ladder
• 28 Models
• Heights 698 - 1800mm
• Lengths 400, 500 & 600mm
• Output 240 - 1022 watts
• Types Straight/Curved -
White/Chrome
• Cost effective
• Adds elegance
STR
• 5 Models
• Heights 645, 745mm
• Lengths 425, 625, 825mm
• Output 419 - 922 watts
• Functional and aesthetically
superior
Bergamo
• 6 Models
• Heights 740, 1172, 1730mm
• Lengths 500, 600mm
• Output 376 - 940 watts
• New flat tube design
Vertex
• 12 Models
• Heights 1604, 1804, 2004,
2204mm
• Lengths 445, 580, 715mm
• Output 1110 - 2304 watts
• Type P2
Classic Column
• 59 Models
• Heights 300, 500, 600,
750, 1800, 2000, 2500mm
• Lengths 315 - 1800mm
• Output 297 - 3015 watts
• Types 2, 3, 4 columns
• Chic solution
23
Traditional
Data & Dimensions
Height Length Output Watts at Δ T50
(mm) (mm) K1 P+ K2 P1
300 500 259 388 506 •
300 1000 517 776 1012 •
300 1500 776 1164 1518 •
300 2000 1034 1552 2024 •
300 2500 1293 1940 2530 •
300 3000 1551 2328 3036 •
450 400 307 442 564 190
450 500 384 553 705 238
450 600 461 664 845 286
450 700 538 774 986 333
450 800 614 885 1127 381
450 900 691 995 1268 428
450 1000 768 1106 1409 476
450 1100 845 1217 1550 •
450 1200 922 1327 1691 571
450 1400 1075 1548 1973 666
450 1600 1229 1770 2254 762
450 1800 1382 1991 2536 •
450 2000 1536 2212 2818 952
450 2200 1690 2433 3100 •
450 2400 1843 2654 3382 1142
450 2600 1997 2876 3663 •
450 2800 2150 3097 3945 •
450 3000 2304 3318 4227 •
600 400 400 564 711 244
600 500 500 705 889 305
600 600 600 845 1067 366
600 700 700 986 1245 427
600 800 800 1127 1422 488
600 900 900 1268 1600 549
600 1000 1000 1409 1778 610
600 1100 1100 1550 1956 •
600 1200 1200 1691 2134 732
600 1400 1400 1973 2489 854
600 1600 1600 2254 2845 976
600 1800 1800 2536 3200 •
600 2000 2000 2818 3556 1220
600 2200 2200 3100 3912 •
600 2400 2400 3382 4267 1464
600 2600 2600 3663 4623 •
600 2800 2800 3945 4978 •
600 3000 3000 4227 5334 •
700 400 457 639 804 280
700 500 571 799 1006 350
700 600 685 958 1207 419
700 700 799 1118 1408 489
700 800 914 1278 1609 559
700 900 1028 1437 1810 629
700 1000 1142 1597 2011 699
700 1100 1256 1757 2212 •
700 1200 1370 1916 2413 839
700 1400 1599 2236 2815 979
700 1600 1827 2555 3218 1118
700 1800 2056 2875 3620 •
700 2000 2284 3194 4022 1398
700 2200 2512 3513 4424 •
700 2400 2741 3833 4826 1678
700 2600 2969 4152 5229 •
700 2800 3198 4472 5631 •
700 3000 3426 4791 6033 •
ⵜ
Elite
• 216 Models
• Heights 300, 450, 600, 700mm
• Lengths 400 - 3000mm
• Output 190 - 6033 watts
• Types P1, K1, P+ & K2
• Working pressure - 16psi (8 bar)
• 10 Year Warranty
Options
See page 31
24
Data & Dimensions
Height Length Output Watts at Δ T50
(mm) (mm) K1 P+ K2 P1
300 500 255 373 491 •
300 1000 509 745 982 •
300 1500 764 1118 1473 •
300 2000 1018 1490 1964 •
300 2500 1273 1863 2455 •
300 3000 1527 2235 2946 •
450 400 302 422 548 190
450 500 378 528 686 237
450 600 454 633 823 284
450 700 529 739 960 332
450 800 605 844 1097 379
450 900 680 950 1234 427
450 1000 756 1055 1371 474
450 1100 832 1161 1508 •
450 1200 907 1266 1645 569
450 1400 1058 1477 1919 664
450 1600 1210 1688 2194 758
450 1800 1361 1899 2468 •
450 2000 1512 2110 2742 948
450 2200 1663 2321 3016 •
450 2400 1814 2532 3290 1138
450 2600 1966 2743 3565 •
450 2800 2117 2954 3839 •
450 3000 2268 3165 4113 •
600 400 392 538 693 248
600 500 490 673 866 310
600 600 588 807 1039 371
600 700 686 942 1212 433
600 800 784 1076 1386 495
600 900 882 1211 1559 557
600 1000 980 1345 1732 619
600 1100 1078 1480 1905 •
600 1200 1176 1614 2078 743
600 1400 1372 1883 2425 867
600 1600 1568 2152 2771 990
600 1800 1764 2421 3118 •
600 2000 1960 2690 3464 1238
600 2200 2156 2959 3810 •
600 2400 2352 3228 4157 1486
600 2600 2548 3497 4503 •
600 2800 2744 3766 4850 •
600 3000 2940 4035 5196 •
700 400 447 612 784 286
700 500 559 765 981 358
700 600 670 918 1177 429
700 700 782 1071 1373 501
700 800 894 1224 1569 572
700 900 1005 1377 1765 644
700 1000 1117 1530 1961 715
700 1100 1229 1683 2157 •
700 1200 1340 1836 2353 858
700 1400 1564 2142 2745 1001
700 1600 1787 2448 3138 1144
700 1800 2011 2754 3530 •
700 2000 2234 3060 3922 1430
700 2200 2457 3366 4314 •
700 2400 2681 3672 4706 1716
700 2600 2904 3978 5099 •
700 2800 3128 4284 5491 •
700 3000 3351 4590 5883 •
ⵜ
Compact
• 216 Models
• Heights 300, 450, 600, 700mm
• Lengths 400 - 3000mm
• Output 190 - 5883 watts
• Types P1, K1, P+ & K2
• Working Pressure - 16psi (8bar)
• 10 Year Warranty
Options
See page 31
25
low surface temperature
Data & Dimensions
Height Emitter Length Output Watts at Δ T50
(mm) Height (mm) K1 P+ K2
(mm)
500 300 560 196 284 348
500 300 760 293 426 522
500 300 960 391 568 696
500 300 1160 489 710 870
500 300 1360 587 852 1044
500 300 1560 685 994 1218
500 300 1760 782 1136 1392
500 300 1960 880 1278 1566
650 450 560 290 386 478
650 450 760 435 580 717
650 450 960 580 773 956
650 450 1160 725 966 1195
650 450 1360 870 1159 1434
650 450 1560 1015 1352 1673
650 450 1760 1160 1546 1912
650 450 1960 1305 1739 2151
800 600 560 365 501 615
800 600 760 548 751 922
800 600 960 730 1002 1230
800 600 1160 913 1252 1537
800 600 1360 1096 1502 1844
800 600 1560 1278 1753 2152
800 600 1760 1461 2003 2459
800 600 1960 1643 2254 2767
ⵜ
LST Standard
• 72 Models
• Heights 500, 650, 800mm
• Lengths 560 - 1960mm
• Output 196 - 2767 watts
• Types K1, P+ & K2
• Safety grilles supplied as standard
• Casing supplied with valve/pipework
“knockouts” on side panels
• Flexibility of choice
• Competitively versatile
Options
Remote sensing thermostatic valves
26
Data & Dimensions
Model Height Height Emitter Length Emitter Output Watts at Δ T50
(mm)
inc Kick Grille Height (mm) Length K1 P+ K2
(mm) (mm) (mm)
500 500 300 650 400 203 290 362
500 500 300 850 600 304 435 542
500 500 300 1050 800 406 580 723
500 500 300 1250 1000 507 725 904
500 500 300 1450 1200 608 870 1085
500 500 300 1650 1400 710 1015 1266
Integral Kick GrilleOptional Kick GrilleOptional Kick Grille
500 500 300 1850 1600 811 1160 1446
500 500 300 2050 1800 913 1305 1627
500 650 400 650 400 264 388 456
500 650 400 850 600 397 581 685
500 650 400 1050 800 529 775 913
500 650 400 1250 1000 661 969 1141
500 650 400 1450 1200 793 1163 1369
500 650 400 1650 1400 925 1357 1597
500 650 400 1850 1600 1058 1550 1825
500 650 400 2050 1800 1190 1744 2054
600 750 400 650 400 336 461 558
600 750 400 850 600 503 692 837
600 750 400 1050 800 671 922 1116
600 750 400 1250 1000 839 1153 1395
600 750 400 1450 1200 1007 1384 1674
600 750 400 1650 1400 1175 1614 1953
600 750 400 1850 1600 1342 1845 2232
600 750 400 2050 1800 1510 2075 2511
ⵜ
LST Plus
• 72 Models
Disabled Adaptor
The disabled adapter comes as standard and is
designed to aid those who may find it difficult to
manoeuver the standard control.
• Heights 500, 650, 750mm
• Lengths 650 - 2050mm
• Output 203 - 2511 watts
• Types K1, P+ & K2
• Specialised integrated features as standard
• Complete pre-assembled package
• Unique design ensuring safety
and fast installation
Blanking Cap
Each LST 2 has a blanking cap which
can be used to make the LST 2 totally
tamper proof.
TRV - Lockable
The TRV within the LST 2 can be locked
at any temperature within the range so
that performance and comfort levels can
be maintained. Also comes with 2m
remote sensing capiliary as standard.
Kick Grilles
Optional kick grilles are provided on the
two larger models and can be used as
either full unit grilles or simply pipe
cores.
27
specifier range
Data & Dimensions - Style
Height Length Output Watts at Δ T50
(mm) (mm) K1 K2 P+ P2
300 500 225 435 • •
300 1000 450 869 • •
300 1400 630 1217 • •
300 2000 900 1738 • •
500 400 290 514 • •
500 600 436 772 • •
500 800 581 1029 • •
500 1000 726 1286 • •
500 1200 871 1543 • •
500 1400 1016 1800 • •
500 1600 1162 2058 • •
500 1800 1307 2315 • •
500 2000 1452 2572 • •
600 400 339 597 • •
600 600 508 895 • •
600 800 678 1194 • •
600 1000 847 1492 • •
600 1200 1016 1790 • •
600 1400 1186 2089 • •
600 1600 1355 2387 • •
600 1800 1525 2686 • •
600 2000 1694 2984 • •
ⵜ
Style
• 44 Models
Data & Dimensions - Style Lo-line
Height Length Output Watts at Δ T50
(mm) (mm) K1 K2 P+ P2
200 500 • 242 307 •
200 1000 • 483 614 •
200 1400 • 676 860 •
200 2000 • 966 1228 •
Data & Dimensions - Style Vertical
Height Length Output Watts at Δ T50
(mm) (mm) K1 K2 P+ P2
1600 300 • • • 707
1600 500 • • • 1062
1600 600 • • • 1228
1800 300 • • • 785
1800 500 • • • 1180
1800 600 • • • 1364
2000 300 • • • 862
2000 500 • • • 1295
2000 600 • • • 1498
2400 300 • • • 1011
2400 500 • • • 1520
2400 600 • • • 1757
• Heights 300, 500, 600mm
• Lengths 400 - 2000mm
• Output 225 - 2984 watts
• Types K1 & K2
• Stylish linear design
Options
See page 31
28
Data & Dimensions
Height Length Output Watts at Δ T50
(mm) (mm) K1 K2
300 500 235 465
300 1000 469 929
300 1400 657 1301
300 2000 938 1858
400 400 250 471
400 600 376 706
400 800 501 942
400 1000 626 1177
400 1200 751 1412
400 1400 876 1648
400 1600 1002 1883
400 1800 1127 2119
400 2000 1252 2354
500 400 310 564
500 600 464 847
500 800 619 1129
500 1000 774 1411
500 1200 929 1693
500 1400 1084 1975
500 1600 1238 2258
500 1800 1393 2540
500 2000 1548 2822
600 400 364 654
600 600 547 980
600 800 729 1307
600 1000 911 1634
600 1200 1093 1961
600 1400 1275 2288
600 1600 1458 2614
600 1800 1640 2941
600 2000 1822 3268
ⵜ
Planar
• 62 Models
• Heights 300, 400, 500, 600mm
• Lengths 400 - 2000mm
• Output 235 - 3268 watts
• Types K1 & K2
6 Tappings
The planar comes with 6 tappings enabling a multitude
of installation configurations which dramatically reduce
installation time.
• 6 Tappings - Pre-piped TBSE
• Flat fronted design
Options
See page 31
29
data & dimensions
30
Data & Dimensions - Plane
Height Length Elements Plane Plane
(mm) (mm) Single Double
440 500 6 382 673
440 600 6 458 808
440 700 6 535 942
440 800 6 611 1077
440 900 6 688 1211
440 1000 6 764 1346
440 1100 6 840 1481
440 1200 6 917 1615
440 1400 6 1070 1884
440 1600 6 1222 2154
440 1800 6 1375 2423
440 2000 6 1528 2692
440 2200 6 1681 2961
440 2400 6 1834 3230
440 2600 6 1986 3500
440 2800 6 2139 3769
440 3000 6 2292 4038
588 500 8 500 827
588 600 8 599 992
588 700 8 699 1158
588 800 8 799 1323
588 900 8 899 1489
588 1000 8 999 1654
588 1100 8 1099 1819
588 1200 8 1199 1985
588 1400 8 1399 2316
588 1600 8 1598 2646
588 1800 8 1798 2977
588 2000 8 1998 3308
588 2200 8 2198 3639
588 2400 8 2398 3970
588 2600 8 2597 4300
588 2800 8 2797 4631
588 3000 8 2997 4962
736 500 10 606 1046
736 600 10 727 1255
736 700 10 848 1464
736 800 10 970 1674
736 900 10 1091 1883
736 1000 10 1212 2092
736 1100 10 1333 2301
736 1200 10 1454 2510
736 1400 10 1697 2929
736 1600 10 1939 3347
736 1800 10 2182 3766
736 2000 10 2424 4184
736 2200 10 2666 4602
736 2400 10 2909 5021
736 2600 10 3151 5439
736 2800 10 3394 5858
736 3000 10 3636 6276
Data & Dimensions - Vertical & Slimline
Height Length Elements Vertical Slimline
(mm) (mm)
1800 320 8 872
1800 440 6 780
1800 520 13 1417
1800 588 8 1040
1800 640 16 1744
1800 736 10 1300
2000 320 8 978
2000 440 11 870
2000 520 13 1589
2000 588 8 1160
2000 640 16 1956
2000 736 10 1450
Concord
• 130 Models
• Heights 144, 292, 440, 588, 736,
1800, 2000mm
• Lengths 320 - 3000mm
• Output 382 - 6276 watts
• Low water content for fast efficient heat-up
• High pressure tested to withstand 6.0 bar
Options
See page 31
Data & Dimensions - Lo-Line
Height Length Elements Lo-Line
(mm) (mm)
144 800 2 530
144 1000 2 663
144 1200 2 796
144 1400 2 928
144 1600 2 1061
144 1800 2 1193
144 2000 2 1326
144 2200 2 1459
292 800 4 898
292 1000 4 1122
292 1200 4 1346
292 1400 4 1571
292 1600 4 1795
292 1800 4 2020
292 2000 4 2244
292 2200 4 2468
radiator options
Valves
Stelrad can offer a range of
luxury valves to complement
our design products.
Extension Pieces
20/30 and 40mm extension
pieces are available to help
bridge gaps on replacement
installations.
3
/4” Adaptor
The adaptor enables you to
3
connect to
no detriment to
performance.
/4”pipework with
Floor Standing
Brackets
When wall space is at a
premium or has insufficient
load bearing, floor standing
brackets can offer a suitable
alternative.
Continental
Brackets
If it is extra security you
need, continental brackets
clean up the top and bottom
seam offering greater
stability.
Top Grilles & Side
Panels
Can be fitted to Elite
radiators when a more
aesthetic solution is
required.
A full range of options and accessories can be seen by visiting
www.stelrad.com
31
The Ideal Commercial Range
Boiler output
Atmospheric Boilers
Concord CXA/H
Concord CXS/H
Concord CXSi/H
Concord ES/H
Concord Modular
High Efficiency Boilers
Concord Super Series 4
Concord Super Plus 200-600
Condensing Boilers
icos HE
W
Concord CXC 48-116
IIII
plus
xtra
GT Condenser 180-990
kW
Btu/h (000)
20 40 100150 200 600 800 1000 1500 3500
68 136 340511 682 2047 2729 3412 5118 11942
40-120
40-120
110-180
140-380
80-720
50-600
30-36
45-80
90-310
80-560
Pressure Jet Boilers
Buccaneer GTE
Falcon GTS
Harrier GTE
Viceroy GT
Viscount GTE
Vanguard L
Contact Numbers
Sales
Tel: 01482 498690
Fax: 01482 498621
Technical
Tel: 01482 498376
Fax: 01482 498621
Training
21-39
40-100
105-330
300-780
Approval
These appliances are certified to
G.A.D. 90/396 and B.E.D. 92/42
safety and performance Directives
for gas boilers.
Ideal Boilers pursues a policy of
continuous improvement in design
and performance of its products
and reserves the right to vary
specification without notice.
Statutory rights of the consumer
are not affected.
754-1450
130-3500
Assurance of quality
BS EN ISO 9001: 2000
Tel: 01482 498432
Fax: 01482 498605
Ideal Stelrad Group, PO Box 103, National Avenue, Kingston upon Hull HU5 4JN.
www.idealcommercialboilers.com www.stelrad.com email: commercial_heating@idealboilers.com
Range/7/07 Issued subject to standard conditions
© 2007 Ideal Boilers Limited
Loading...
