IDEAL INDUSTRIES 61-633, 61-635 User Manual

IDEAL INDUSTRIES INC. TECHNICAL MANUAL MODELS: 61-633

61-635

The Service Information provides the following information:

• Precautions and safety information

• Specifications

• Basic maintenance (cleaning, replacing the battery and fuses)

• Performance test procedures

• Calibration and calibration adjustment procedures

Form Number: TM61633-5

Revision: 5. Date: December 2006

Form Number TM61633-5 Rev 5 Dec 2006

TABLE OF CONTENTS

Title Introduction Precautions and Safety Information

Symbols

Safety Information

Specifications

General Specification

Voltage Specifications

dBm / dB Specifications

Current Specifications

Peak Hold, Resistance Specifications

Continuity and Diode Specifications

Capacitance Specifications

Frequency Counter and Duty Factor Specifications

Temperature Specifications

Physical and environment characteristics

Certification and compliance

Required Equipment

Basic Maintenance

Opening the Meter Case

Replacing the Battery

Testing Fuses (FS1 and FS2)

Replacing Fuses

Cleaning

Input Terminals

Performance Tests

A Basic Operability Test

Testing the Display

Testing the Voltage Function

Testing the Millivoltage (mV) Function

Testing the Peak Hold Function

Testing the Resistance Function

Testing the Capacitance Function

Testing the Diode Function

Testing the Milliamp Function

Testing the Amp Function

Testing the Frequency Function

Testing the Duty Factor Function

Testing the Temperature Function

Calibration

Calibrating the ACV Frequency Response

Page

1 1

1

2

3

4

5

6

7

8

9

11

12

13

14

15

15/16

16

16/17

17

17/18

18

19/20

21

Form Number TM61633-5 Rev 5 Dec 2006

Introduction

Warning

To avoid shock or injury, do not perform the verification tests or calibration

procedures described in this manual unless you are qualified to do so.

The information provided in this document is for the use of qualified personnel only.

Caution

The 61-630 serials contain parts that can be damaged by static discharge.

Follow the standard practices for handling static sensitive devices.

For additional information about IDEAL INDUSTRIES and its products,

and services, visit IDEAL INDUSTRIES web site at:

www.idealindustries.com

Precautions and Safety Information

Use the Meter only as described in the Users Manual. If you do not do so, the

protection provided by the Meter may be impaired. Read the “Safety Information”

page before servicing this product. In this manual, a Warning identifies conditions and actions that pose hazard (s) to the user; a Caution identifies conditions and

actions that may damage the Meter or the test instruments.

The Symbols

The symbols used on the Meter and in this manual are explained in Table A.

Table A. The Symbols

Symbol Meaning Symbol Meaning

Page 1

Alternating signal

Direct signal

Refer to the manual. Important information.

Battery

Earth ground

Fuse

Take appropriate precautions. Hazardous voltage may be present

Double insulated

CAT III IEC over voltage Category III

Form Number TM61633-5 Rev 5 Dec 2006

Page 2

SAFETY

Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. To avoid potential hazards, use the product only as specified.

CAUTION.

These statements identify conditions or practices that could result in damage to the equipment or other property.

WARNING.

These statements identify conditions or practices that could result in personal injury or loss of life.

Specific precautions Use proper Fuse. To avoid fire hazard, use only the fuse type and rating specified for this product.

Do not operate without covers. To avoid personal injury, do not apply any voltage or current to the product

without the covers in place.

Electric overload. Never apply a voltage to a connector on the product that is outside the range specified for that

connector.

Avoid electric shock. To avoid injury or loss of life, do not connect or disconnect probes or test leads while they

are connected to a voltage source.

Do not operate in wet/damp conditions. To avoid electric shock, do not operate this product in wet or damp

conditions.

Form Number TM61633-5 Rev 5 Dec 2006

Page 3

SPECIFICATIONS

All specifications are warranted unless noted typical and apply to models 61-633 and 61-635.

Stated accuracies are at 23

General specifications

Characteristics

LCD display digits 4¾ or 3¾

Bargraph segments 80 Segment Graph

Display count 40,000 or 4,000

Numeric update rate 2 times / sec (40.000 count)

Bargraph 20 times/sec

Polarity display Automatic

Overrange display OL is displayed

Low voltage indicator

Automatic power-off time Automatic backlit off = 15 minutes

Power source One 9V dry cell battery

Maximum input voltage 1000V (750V AC) CAT II, Between V and COM

Maximum floating voltage 1000V (750V AC) CAT II, Between any terminal and earth

Maximum input current 400mA between mA and COM

Maximum open circuit Voltage (current inputs) 600V between A and COM and between mA and COM

Overload protection mA connector 1 A (600V) fast blow fuse

A connector 15A (600V) fast blow fuse

V connector 1100 Vp, V , V AC+DC

Temperature Coefficient 0.1 x (Spec. Accuracy) 1°C, < 18 C or > 28°C.

Battery Life 100 hours typical (alkaline)

°

±5°C at less than 80% relative humidity and without the battery indicator displayed.

Description

4 times / sec (4,000 count)

is indicated

ground

10A continuous between A and COM (20A for 30 seconds, between A and COM)

850 Vp, mV LVΩ, Ω, Hz,

, mV , AC+DC

, , , %DF, °C, °F

Form Number TM61633-5 Rev 5 Dec 2006

Page 4

Measurement Characteristics

All at 23°C ±5°C, < 80% Rh. Specifications are expressed as ±([% of reading] + [number of digits]). Multiply accuracy Digits by l0 in 40,000 count Mode.

DC VOLTAGE:

DCV 61-633 61-635

40mV ± (0.20%+8d) ± (0.06% + 8d)

400mV ± (0.20% + 2d) ± (0.06% + 2d)

4V, 40V, 400V, 1000V ± (0.20% + 2d) ± (0.06% + 1d)

AC VOLTAGE:

ACV 61-633 61-635

400mV

40Hz~ 100Hz ± (1.20% + 5d) ± (0.70% + 5d)

100Hz ~ 1KHz ± (2.00% + 5d) ± (1.00% + 5d)

4V

40Hz ~ 100Hz ± (1.00% + 5d) ± (0.70% + 5d)

100Hz ~ 1KHz ± (2.00% + 5d) ± (1.00% + 5d)

1KHz ~ 10KHz ± (3.00% + 6d) ± (2.00% + 6d) 10KHz ~ 20KHz N.A ± (3.00% + 7d) 20KHz ~ 50KHz N.A ± (5.00% + 8d)

50KHz ~ 100KHz N.A ± (10.00% + 10d)

40V

40Hz ~ 100Hz ± (1.20% + 5d) ± (0.70% + 5d)

100Hz ~ 1KHz ± (2.00% + 5d) ± (1.00% + 5d)

1KHz ~ 10KHz ± (3.00% + 6d) ± (2.00% + 6d) 10KHz ~ 20KHz N.A ± (3.00% + 7d) 20KHz ~ 50KHz N.A ± (5.00% + 8d)

50KHz ~ 100KHz N.A ± (10.00% + l0d)

400V

40Hz ~ 100Hz ± (1.20% + 5d) ± (0.70% + 5d)

100Hz ~ 1KHz ± (2.00% + 5d) ± (1.00% + 5d)

1KHz ~ 10KHz ±(3.00% + 6d) ± (2.00% + 6d) 10KHz ~ 20KHz N.A ± (3.00% + 7d) 20KHz ~ 50KHz N.A ± (5.00% + 8d)

750V

40Hz ~ 100Hz ±(1.20% + 5d) ± (0.70% + 5d)

100Hz ~ 1KHz ± (2.00% + 5d) ± (1,00% + 6d)

Bandwidth 40Hz ~ 10KHz 40Hz ~ 100 KHz

dBm (typical): -l5dBm to +55 dBm (0 dBm = lmW into 600Ω). dBv (typical): -80 dBv to + 50 dBv (0 dBv = 1 Vrms).

Note: (ACV only) Add additional 40Digits for reading under 30% of range. Specifications exclude under 20% of range for 20KHz ~ 100KHz.

Resolution: 1µV in the 400mV range Input Impedance: 10MΩ, <l00pF Overload Protection: 1000V dc, 750V rms AC Conversion Type: AC Coupled True RMS responding AC + DC Volts: Same as AC(RMS) +1.00% + 8d Crest Factor: +1.5% addition error for C.F. 1.4 to 3

+3.0% addition error for C.F. from 3 to 4

Form Number TM61633-5 Rev 5 Dec 2006

DC CURRENT:

DCA 61-633 61-635

40mA, 400mA, 4A, 10A ± (0.50% + 4d) ±(0.20% + 4d)

AC CURRENT:

ACA 61-633 61-635

40mA, 400mA, 4A, 10A ±(1.20% + 8d) ± (0.80% + 8d)

Bandwidth 40Hz ~ 400Hz 40Hz ~ 400Hz

Range: 40mA, 400mA, 4A, 10A Resolution: 1µA in the 40mA range Burden Voltage: 800mV max. for mA input, 1V max. for A input AC Conversion Type: AC Coupled True RMS responding Input Protection: Equipped with High Energy Fuse

1A, 600V, IR 10KV fuse (Bussmann BBS-1 or equivalent) for mA input 15A, 600V, IR 100KV fuse (Bussmann KTK 15 or equivalent) for A input

AC + DC Current: Same as AC(RMS) + 1.00% + 8d C.F.: Same as ACV

PEAK HOLD: +[± (0.7% + 20)] additional error for >10% of full scale

RESISTANCE:

OHM 61-633 61-635

4000, 4K 0 ± (0.50% + 2d) ± (0.30% + 2d)

40KQ, 400K0 ± (0.50% + 2d) ± (0.30% + 2d)

4M0 ± (0.50% + 4d) ± (0.30% + 4d)

40M0 ± (5.00% + 5d) ± (5.00% + 5d)

LV OHM 61-633 61-635

4K0 ,40K0 400K 0 ± (1.00% + 2d) ± (0.60% ÷ 2d)

4M0 ± (1.00% + 4d) ± (0.60% + 4d)

40M0 ± (7.00% + 5d) ± (7.00% + 5d)

Resolution: 0.01 Ω in the 4000 range Open Circuit Voltage: 3.3V Open Circuit Low Voltage: 0.6V Input Protection: 600V rms

CONTINUITY CHECK Continuity Threshold: Approximately 50Ω Continuity Indicator: 2KHz Tone Buzzer Input Protection: 600V rms

DIODE TEST Test Current: 1.1 mA (Typical) Open Circuit Voltage: 3.3V DC (max) Input Protection: 600V rms

Page 5
