Ideal VSW1301 User Manual

Product Manual

Qty

Description

1

Occ/Vac Sensor VSW1301

1

Sensor Cradle

2

Mounting Screw

1

Locking Screw

1

Instruction card

VSW1301 Wall Mount Occupancy/Vacancy Sensor

PRODUCT DESCRIPTION

The Audacy VSW1301 Occupancy/Vacancy
Sensor is a battery powered device specially
designed to detect the presence or absence
of occupants and wirelessly transmit this
information to the Audacy Gateway. The
information provided by the sensor is used
to determine whether lights should remain
on or turned off to reduce energy
consumption. The product has a 25-year
battery life design and will not require AC or
DC line power, providing building owners
and occupants placement flexibility.

KEY FEATURES

FCC and IC approved
Flexible ceiling mounting options
25+ year battery life
Small form factor with internal antenna
RoHS compliant
Factory configurable for custom
applications

Audacy®, Smart Connector® and Smart Switch® are registered trademarks of IDEAL INDUSTRIES.

All other trademarks are the property of their respective owners.

PRODUCT CONTENTS

The following items are included inside the
package:

ND7947-1 01/2014 Users Manual – VSW1301 Occupancy/Vacancy Sensor Page 1
www.idealindustries.com

Product Manual

Item

Description

Radio

915 MHz Internal Antenna

Regulatory Approvals

FCC Part 15 and Industry Canada
FCC ID: 2AAMXVSW1301
IC: 11250A-VSW1301

Transmit Range

100 ft. indoors to an Audacy Gateway or Smart Connector in a typical
commercial office building

Power

25+ year Li battery, non-replaceable

Operating Temperature

10°C to 32°C

Storage Temperature

-20°C to 50°C

Installation
Environment

Indoor use only
Mounting

2 bracket mounting holes (See mechanical drawing for dimensions)

Color

White

Dimensions

4.56” x 2.29” x 1.67” (115.82 x 58.17 x 42.4 mm)

Weight

2.9 oz

Warranty

1 year

VSW1301 Wall Mount Occupancy/Vacancy Sensor

SET-UP AND OPERATION

1. Wall-mount the VSW1301 cradle in the desired location with the optional mounting

screws(2). Cradle can be mounted directly to drywall.

2. Press the button located on the bottom side of the Occ/Vac Sensor VSW1301 to

activate device.

3. An optional screw can be used to lock the Smart Switch in the cradle.

SPECIFICATIONS

ND7947-1 01/2014 Users Manual – VSW1301 Occupancy/Vacancy Sensor Page 2
www.idealindustries.com

Product Manual

VSW1301 Wall Mount Occupancy/Vacancy Sensor

MECHANICAL (REAR VIEW)

MECHANICAL (TOP VIEW)

*Dimensions in inches

*Dimensions in inches

ND7947-1 01/2014 Users Manual – VSW1301 Occupancy/Vacancy Sensor Page 3
