Technology GmbH
www.raidsonic.de
ICY BOX
IB-MS303-T
Monitor stand with table support for
one monitor up to 27" (68 cm)
Key features
• Creates space on the desktop and provides a more flexible
and productive workspace
• Well-engineered design slim and ergonomic
• Smart Torque Adjust™ built-in spring gauge can be adjusted
to suit various monitor weights
• Gas spring counterbalance moves the monitor with a light touch
• Cable management routes cables under the arm
to reduce clutter for a clean look
• Grommet and desk mount base suit most desks with adjustable clamp height
• Pear-shaped VESA® slot simplifies the mounting of the monitor
• Supports 75x75 und 100x100 VESA® standards
Technical data
Model
Article no.
EAN
Brand
Colour
Material
Maximum size of monitor
Number of monitors
Max. weight of monitor
Max. arm extend (center of VESA
Max. arm height (center of VESA
®
VESA
- swivel (hinge)
®
VESA
- tilt (hinge)
Arm - tilt
®
VESA
- rotate (pivot)
Base - rotate (pivot)
®
VESA
compatible
Mounting
Table thickness
®
support)
®
support)
IB-MS303-T
60469
4250078168515
ICY BOX
Black
Steel / plastic / aluminum alloy
27"
1
Up to 6.5 kg/monitor
Up to 500 mm
Up to 410 mm
+/- 90° horizontal
+ 90°/-45° vertical
+/- 45° vertical
+/- 90° horizontal
360° vertical
75x75 / 100x100 mm
Full metall clamp or grommet base
10-85 mm
Packing content
IB-MS303-T, allen wrench, set of screws, quick installation
160mm 225mm-290mm 50mm
180°
75mm
100mm
115mm
75mm
100mm
117mm
360°
360°
360°
+90°
-45°
min160mm-max410mm
100mm
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
10mm-85mm
Technology GmbH
www.raidsonic.de
ICY BOX IB-MS303-T
Monitor stand with table support
for one monitor up to 27"
Requirements
The bracket is suitable for monitors with a screen diagonal up to 27" and the VESA® standards 100x100
and 75x75. It is important that the monitor should not exceed a maximum weight of 6.5 kg.
With firm hold
The desk mount allows the IB-MS303-T to be attached to desks. The ingenious design ensures a
uniformly distributed weight and firm hold on the desk.
Movable
No matter how you like to work - the different joints can be moved in many angles. This allows the monitor
to be aligned exactly as required. A full rotation of 360° is possible, just like adjusting the height, inclination
or distance to the wall.
Logistical data
Packing unit:
Total weight:
Gross weight (with packing):
Net weight:
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
6 pcs./carton
17.34 kg/carton
2.7 kg
2.3 kg
Dimension/carton:
Dimension (with packing):
Dimension of article:
Country of origin:
430x605x410 mm
125x405x295 mm
150x500x410 mm
China
