Manual IB-AC620-CRManual IB-AC620-CR
(EN) Product information (English) IB-AC620-CR
Protection box for memory cards
(DE) Produktinformation (Deutsch) IB-AC620-CR
Schutzbox für Speicherkarten
Handbuch IB-AC620-CR
Zur Vermeidung körperlicher Schäden, sowie von Sach-, Geräte­schäden und Datenverlust beachten Sie bitte folgende Hinweise:
Signalwort und Sicherheitszeichen kennzeichnen die Warnstufe und geben einen sofortigen Hinweis auf Wahrscheinlichkeit, Art und Schwere der Folgen, wenn die Maßnahmen zur Vermeidung der Gefahr nicht befolgt werden.
GEFAHR
wird.
WARNUNG
VORSICHT
ACHTUNG
1. Gefahren durch elektrische Spannung
WARNUNG
• vor Benutzung Betriebsanleitung lesen
• vor Arbeiten am Gerät, Spannungsfreiheit sicherstellen
• Kontaktschutzblenden nicht entfernen
• Kontakt mit Spannungsführenden Komponenten vermeiden.
• Steckkontakte nicht mit spitzen und metallischen Gegenständen berühren
• Verwendung nur in dafür vorgesehenen Umgebungen
• Gerät ausschließlich mit Typenschildkonformen Netzteil betreiben!
• Gerät/Netzteil fern von Feuchtigkeit, Flüssigkeit, Dampf und Staub halten
• Eigenständige Modifikationen sind unzulässig
• Gerät nicht während eines Gewitters anschließen
• Geben Sie Ihr Gerät im Reparaturfall in den Fachhandel
2. Gefahren während Montage (wenn vorgesehen)
VORSICHT
(wenn vorgesehen) möglich
• vor Montage, Betriebsanleitung lesen
• Kontakt mit scharfen Kanten oder spitzen Bauteilen vermeiden
• Bauteile nicht mit Gewalt zusammensetzen
• geeignetes Werkzeug verwenden
• nur gegebenenfalls mitgeliefertes Zubehör und Werkzeug verwenden
3. Gefahren durch Wärmeentwicklung
ACHTUNG
teils
• externe Erwärmung vermeiden und Luftaustausch zulassen
• Lüfter-Auslass und passive Kühlkörper freihalten
• direkte Sonneneinstrahlung auf Gerät/Netzteil vermeiden
• ausreichend Umgebungsluft für Gerät/Netzteil sicherstellen
• keine Gegenstände auf dem Gerät/Netzteil abstellen
warnt vor einer unmittelbar gefährlichen Situation, die zum Tod oder zu schweren Verletzungen führen
warnt vor einer möglicherweise gefährlichen Si­tuation, die zum Tod oder zu schweren Verletzungen führen kann.
warnt vor einer möglicherweise gefährlichen Situ­ation, die zu leichten Verletzungen führen kann.
warnt vor einer möglichen Situation, die zu Sach­und Umweltschäden führen und den Betriebsablauf stören kann.
Kontakt mit elektrisch leitenden Teilen
Lebensgefahr durch Stromschlag
Scharfkantige Bauteile
Finger- oder Handverletzungen bei Zusammenbau
Mangelhafte Belüftung des Geräts/Netzteils
Überhitzung und Ausfall des Geräts/Netz-
Handbuch IB-AC620-CRHandbuch IB-AC620-CR
4. Gefahren durch Kleinstteile und Verpackung
WARNUNG
• Kleinteile, Zubehör für Kinder unzugänglich verwahren
• Plastiktüten und Verpackung für Kinder unzugänglich verwahren/ent­sorgen
• Kleinteile und Verpackungen nicht in Kinderhände geben
5. Möglicher Datenverlust
ACHTUNG
• Unbedingt Hinweise in der Bedienungsanleitung/Schnellinstallationsanleitung beachten
• Produkt nur verwenden, wenn Spezifikationen erfüllt sind
• Datensicherung vor Inbetriebnahme durchführen
• Datensicherung vor Anschluss neuer Hardware durchführen
• dem Produkt beiliegendes Zubehör verwenden
6. Reinigung des Gerätes
ACHTUNG
Kurzschluss am Gerät
• vor Reinigung, das Gerät außer Betrieb nehmen
• aggressive bzw. scharfe Reinigungs- und Lösungsmittel sind ungeeignet
• nach der Reinigung sicherstellen, dass keine Restfeuchtigkeit vorhanden ist
• Reinigung der Geräte am besten mit trockenem Antistatiktuch durchführen
7. Entsorgung des Gerätes
ACHTUNG
Recyclingkreislauf unterbrochen
Gemeinde.
Bei Fragen kontaktieren Sie gerne unseren Support unter
support@raidsonic.de oder besuchen Sie unsere Internetseite www. raidsonic.de.
Dieses auf dem Produkt und der Verpackung angebrachte Sym­bol zeigt an, dass dieses Produkt nicht mit dem Hausmüll entsorgt werden darf. In Übereinstimmung mit der Richtlinie über Elektro­und Elektronik-Altgeräte (WEEE) darf dieses Elektrogerät und ggf. enthaltene Batterien nicht im normalen Hausmüll oder dem Gelben Sack entsorgt werden. Wenn Sie dieses Produkt und ggf. enthaltene Batterien entsorgen möchten, bringen Sie diese bitte zur Verkaufsstelle zurück oder zum Recycling-Sammelpunkt Ihrer
Erstickungsgefahr
Lebensgefahr durch Ersticken oder Verschlucken
Datenverlust bei Inbetriebnahme
Unwiederbringlicher Datenverlust möglich
Schädigende Reinigungsmittel
Kratzer, Farbveränderungen, Feuchteschäden oder
Umweltverschmutzung, Wiederverwertung nicht möglich
Mögliche Umweltbelastung durch Bestandteile,
Manual IB-AC620-CR
Please read carefully the following information to prevent injuries, damage to material and device as well as data loss:
Warning levels
Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.
DANGER
WARNING
CAUTION
IMPORTANT
1. Risk of electrical shock
WARNING
• Read the operating instructions prior to use
• Make sure the device has been de-energised prior to working on it
• Do not remove contact protection panels
• Avoid contact with conducting parts
• Do not bring plug contacts in contact with pointed and metal objects
• Use in intended environments only
• Operate the device using a power unit meeting the specifications of the type plate only!
• Keep the device/power unit away from humidity, liquid, vapour and dust
• Do not modify the device
• Do not connect the device during thunderstorms
• Approach specialist retailers if you require repairs
2. Hazards during assembly (if intended)
CAUTION
(if intended)
• Read the operating instructions prior to assembly
• Avoid coming into contact with sharp edges or pointed components
• Do not force components together
• Use suitable tools
• Use potentially enclosed accessories and tools only
3. Hazards caused by a development of heat
IMPORTANT
• Prevent externally heating up components and ensure an exchange of air
• Do not cover the fan outlet and passive cooling elements
• Avoid direct sunlight on the device/power unit
• Guarantee sufficient ambient air for the device/power unit
• Do not place objects on the device/power unit
Warns of a directly hazardous situation causing death or serious injury.
Warns of a potentially hazardous situation that may cause death or serious injury.
Warns of a potentially hazardous situation that may cause minor injury.
Warns of a potential situation that may cause material or environmental damage and disrupt operative processes.
Contact with parts conducting electricity
Risk of death by electrical shock
Sharp components
Potential injuries to fingers or hands during assembly
Insufficient device/power unit ventilation
Overheating and failure of the device/power unit
Manual IB-AC620-CRManual IB-AC620-CR
4. Hazards caused by very small parts and packaging
WARNING
• Keep small parts and accessories away from children
• Store/dispose of plastic bags and packaging in an area that is inaccessi­ble to children
• Do not hand over small parts and packaging to children
5. Potential data loss
IMPORTANT
• Always comply with the information in the operating instructions/quick installation guide
• Exclusively use the product once the specifications have been met
• Back up data prior to commissioning
• Back up data prior to connecting new hardware
• Use accessories enclosed with the product
6. Cleaning the device
IMPORTANT
• Disconnect the device prior to cleaning
• Aggressive or intense cleaning agents and solvents are unsuitable
• Make sure there is no residual moisture after cleaning
• We recommend cleaning devices using a dry, anti-static cloth
7. Disposing of the device
IMPORTANT
components, recycling circle interrupted
local waste disposal and recycling point.
If you have any questions, please do not hesitate to contact our support at support@raidsonic.de or visit our website at www.raidsonic.de.
This icon on product and packaging indicates that this product must not be disposed of as part of domestic waste. In compli­ance with the Waste Electrical and Electronic Equipment Directive (WEEE) this electrical device and potentially included batteries must not be disposed of in conventional, domestic waste or re- cycling waste. If you would like to dispose of this product and potentially included batteries, please return it to the retailer or your
Risk of suffocation
Risk of death by suffocation or swallowing
Data lost during commissioning
Potentially irreversible data loss
Harmful cleaning agents
Scratches, discolouration, damage caused by mois­ture or short circuit in the device
Environmental pollution, unsuitable for recycling
Potential environmental pollution caused by
Manual IB-AC620-CR
Package content
1x IB-AC620-CR, 1x SIM tool, 1x carabiner, 1x quick installation guide
Overview
1. Locking clip
2 3 4 5 6
2. Carabiner hook
3. Molded EVA foam cushion for microSD, SD and CF cards
4. SIM tool - for easily taking cards
5. Silicone seal ring
6. Polycarbonate shell
1
Manual IB-AC620-CRManual IB-AC620-CR
Protection box for memory cards
The protection box by ICY BOX is made from high quality and eco-friendly materials. It has a sturdy and durable shell with the custom fit molded foam cushion, which can accommodate selected memory cards and keep them safe from shock, dust and water splashing. With a silicone seal ring, the case can effectively keep dust and water away. Moreover, the ergonomic locking clip can realize easily opening and closing. A good partner for storing and carrying your sensitive memory cards.
Key Features
- Protects cards against humidity, dust and shock
- Sturdy and durable shell - made of polycarbonate
- Ergonomic tailored card slots, easy for card putting and taking
- For 4x CF cards, 8x SD cards, 16x microSD cards (not included)
- Dust, shock, and weather resistant silicone seal
- Ergonomic locking system and with a carabiner for easily carrying
Usage
1. Open the protective box by unlocking the locking clip.
2. Now you can see four identical sections. Each can be filled with up to 4x
microSD, 2x SD and 1x CF cards at the same time. They are held securely in position by the matching cut-out in the foam.
3. Close the box and close the locking clip firmly!
Attention! Although the silicone seal keeps out dust and moisture, the protec­tion box does not have an IP protection classification, so we recommend not to expose the protection box to extreme environmental conditions.
Handbuch IB-AC620-CR
Verpackungsinhalt
IB-AC620-CR, 1x SIM Werkzeug, 1x Carabinerhaken, 1x Schnellinstalla­tionshinweis
Übersicht
1
1. Verschlußriegel
2 3 4 5 6
2. Carabinerkaken
3. Schaumstoffeinsatz mit Aussparungen für microSD,
SD und CF Karten
4. SIM Werkzeug – zur Kartenentnahme
5. Silikondichtung
6. Polykarbonathülle
Handbuch IB-AC620-CRHandbuch IB-AC620-CR
Schutzbox für Speicherkarten
Die Schutzbox von ICY BOX ist aus hochwertigen und umweltfreundlichen Materialien hergestellt. Sie hat eine stabile und belastbare Hülle mit dem maßgeschneiderten und geformten Schaumstoffeinsätzen, welche aus­gewählte Speicherkarten aufnehmen können und sie vor Stößen, Staub und Spritzwasser schützen. Mittels des Silikon-Dichtringes kann die Schutzbox Staub und Feuchtigkeit wirksam fernhalten. Darüber hinaus ermöglicht der ergonomische Verriegelungsclip ein einfaches Öffnen und Schließen. Ein guter Partner für die Aufbewahrung und den Transport Ihrer empfindlichen Speicherkarten.
Hauptmerkmale
- Schützt Speicherkarten vor Feuchtigkeit, Staub und Stößen
- Stabile und langlebige Hülle aus Polykarbonat
- Ergonomisch angepasste Kartenaussparungen für das einfache Einlegen
und Entnehmen von Karten
- Für 4x CF-Karten, 8x SD-Karten, 16x microSD-Karten
(nicht im Lieferumfang enthalten)
- Staub-, stoß- und wetterfeste Silikondichtung
- Ergonomische Verriegelungslösung
Verwendung
1. Öffnen Sie die Schutzbox durch aufklappen des Verschlußriegels.
2. Jetzt sehen Sie vier identische Bereiche. Jeder kann gleichzeitig mit bis zu
4x microSD-, 2x SD- und 1x CF-Karten gefüllt werden. Sie werden durch den passenden Ausschnitt im Schaumstoff sicher in Position gehalten.
3. Schließen Sie die Box und klappen den Verschlußriegel wieder fest zu!
Achtung! Die Silikondichtung hält zwar Staub und Feuchtigkeit ab, dennoch verfügt das Gerät über keine IP Schutzklassifizierung, so dass wir empfehlen, die Schutzbox keinen extremen Umgebungsbedingungen auszu­setzen.
