Icy Box IB-2531StS Specifications
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Technical data
Model IB-2531StS
Article No. 25351
EAN code 4250078184546
Brand ICY BOX
Article text 1x 2.5" SATA Mobile Rack
Colour Black
Material Metal/Plastic
HDD size 2.5"
HDD height Up to 9.5 mm
HDD interface 1x SATA I/II
HDD capacity No limit
Required space 1x extension card slot
Key features
• Mobile Rack for installation in a free extension card slot
• 1x 2.5" SATA HDD or SSD
• EasySwap® - HDD or SSD installation without screws
• HDD capacity not limited
• Supports HDD height up to 9.5 mm
• Transfer rate up to 3.0 Gbit/s
• LED for power and HDD access
• Plug & Play and Hot Swap
• Supports all operating systems
Hot Swap Yes
Plug & Play Yes
Host connection 1x SATA Power Connector 15Pin/
1x SATA Data Connector 7Pin
Transfer rate Up to 3 Gbit/s
Operating system OS independent
LED Power/HDD access
Alarm No
Lock No
Power switch No
Fan No
Power connector 1 x 15Pin SATA
IB-2531StS
1x 2.5" SATA Mobile Rack
Extension HDD instead of extension card
With this mobile rack you can update your computer with an extra 2.5" SATA HDD.
Easy Swap® makes the changing of the HDD easy, fast and safe.
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Packing content: 1x IB-2531StS, 1x SATA cable, 1x LED cable, 1x screws, 1x manual
Front view
Unlocking
LED Power/HDD access
LED Connector 4Pin
SATA Power
Connector 15Pin
SATA Data
Connector 7Pin
Rear view
Logistical data
Packing unit: 40 pcs./carton Dimension / carton: 340x340x295 mm Import tax: 84733080
Total weight: 11.1 kg/carton Dimension (incl. packing): 135x160x30 mm
Gross weight (incl. packing): 0.26 kg Dimension from article: 145x120x25 mm
Net weight: 0.154 kg Country of origin: China
