Technology GmbH
www.raidsonic.de
ICY BOX
IB-1922MF-C32
External Type-C® enclosure for M.2
NVMe SSD
Key features
• High-grade aluminium enclosure with innovative heat sink design
• PCIe 3.0 x4 data transfer rates of up to 20 Gbit/s
• M-Key socket for NVMe SSDs, 22x 30/42/60/80 mm
• Features a 30 mm fan for active cooling
• Activation of write protection via switch
• Interface to host computer: USB 3.2 (Gen 2x2) Type-C®
• Downward compatible with USB 3.1/3.0/2.0
• Supports Windows®, macOS
®
Packing content
1x IB-1922MF-C32, 1x Type-C® to Type-C® cable, 1x screw
driver, 1x screw set for M.2 fixation, 1x silicone thermal pad,
1x user manual
External USB Type-C® enclosure for M.2 NVMe SSD
Thanks to the external USB 3.2 Type-C® enclosure IB-1922MF-C32 you can take one NVMe SSD with you easily enough. It allows access to M.2 SSDs of up to
2 TB no matter to which host you connect it. The IB-1922MF-C32 is compatible with M.2 cards of 30/42/60/80 mm length, it is operating system-independent and
suitable for a variety of applications such as high-speed storage, cloning a drive or running a mobile operating system. A PCIe controller from Asmedia provides the
NVMe inside the IB-1922MF-C32 with incredible transfer rates of up to 20 Gbit/s for reading and writing and gives your M.2 SSD longevity and efficiency.
Technical data
Model
Article no.
EAN code
Brand
Colour
Material
Interface to host computer
Transfer rate
UASP support
Length of cable
Socket
M.2 card size
M.2 interface
Supported M.2 card keys
SSD capacity
Plug & Play
Cooling
IB-1922MF-C32
60792
4250078171287
ICY BOX
Anthracite/black
Aluminium, plastic
USB 3.2 (Gen 2x2) Type-C
Up to 20 Gbit/s
Yes
35 cm
M.2 M-Key PCIe x4 (NVMe)
22x 30/42/60/80 mm
PCIe x4 (NVMe)
M.2 PCIe 3.0 M-Key
Up to 2 TB
Yes
30x30 mm fan
®
Fan noise
LED
Power supply
Operating system
System requirements
and an available Asmedia chipset ASM3264 in your host PC.
Currently a macOS
A USB Type-A host interface can be connected with USB 3.1, 3.0 or 2.0 standard in
some notebooks and computers and can be used with the related data transfer rate via a
USB Type-C
The enclosure also works on devices with a Thunderbolt
the transfer rate of up to 10 Gbit/s specified by USB 3.1 (Gen 2).
The following operating systems are supported: Windows
®
to type-A cable (not included).
~ 22 dB (A)
Power, access, write protection
Bus powered
®
®
, macOS
Windows
The enclosure only supplies the full data transfer rate of up to
20 Gbit/s via a USB 3.2 (Gen 2x2) Type-C
®
based computer does not support the USB 3.2 (Gen 2x2) standard.
™
3 Type-C® interface only with
®
, macOS
®
host interface
®
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
Technology GmbH
www.raidsonic.de
ICY BOX IB-1922MF-C32
External Type-C® enclosure for M.2 NVMe SSD
Well cooled to work
The design is simple and focused entirely on functionality. Yet it is by no means unattractive! The air intake
and materials have been selected with optimal heat dissipation in mind, and an active 30 mm fan is also
integrated. Because anyone who works professionally with high-performance M.2 NVMes knows how
important sufficient cooling is to avoid performance losses.
Simply safe!
With the IB-1922MF-C32, sensitive data can now be protected against alteration and can be released
again via switch. With a small hand movement, the switch on the IB-1922MF-C32 can be moved to the
desired position. Click - Safe.
Perfect symbiosis
USB 3.2 (Gen 2x2)-capable connections on computers are far from being standard, even though some of
the latest generation of desktop motherboards already have them. This makes it all the more important to
pay attention to the new USB specification. If you want to be a technology pioneer, you will be surprised
by the incredible data transfer rates of the ICY BOX IB-1922MF-C32 enclosure solution and use the perfect
combination with our IB-PCI1901-C32 expansion card!
Logistical data
Packing unit:
Total weight:
Gross weight (with packing):
Net weight:
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
40 pcs./carton
10.4 kg/carton
0.247 kg
0.148 kg
Dimension/carton:
Dimension (with packing):
Dimension of article:
Country of origin:
440x325x230 mm
30x100x200 mm
102x42x24 mm
China
