ICS N4865A Instruction Manual

Download

ICS ELECTRONICS

ICS

a division of Systems West Inc.

LAN Adapter

Web Site http://www.icselect.com August 2009 Edition Rev x3

ICS ELECTRONICS

ICS

division of Systems West Inc.

LIMITED WARRANTY

Within 12 months of delivery, ICS Electronics will repair or replace this product,

bor is included). Return this product to ICS Electronics, or other designated repair

EMI/RFI WARNING

not installed and used in accordance with the instruction manual, may cause inter-

50082-1, which are designed to provide reasonable protection against such interfer-

Certiﬁ cate of Compliance reproduced in Figure 1-3.

VEE is a trademark of Agilent, Palo Alto, CA

LabView is a Trademark of National Instruments, Austin, TX

ICS and GPIB AnyWhere are trademarks of ICS Electronics, Pleasanton, CA

Product Description, Speciﬁ cations, IEEE-488 Interface, Ethernet

Shipment Veriﬁ cation, Installation Guide, Conﬁ guration Settings,

Mounting Instructions.

Introduction, Operation, GPIB Operation, Web Server Operation,

Block Diagram Description

Maintenance, Troubleshooting and Repair

Maintenance, Troubleshooting Guide, Selftest Error Codes,

Reseting Default Network Settings, Updating Firmware, and Repair

A1 IEEE-488.1, IEEE-488.2 and SCPI Descriptions

A3 ICS RPC Conﬁ guration Commands

This section provides a description and speciﬁ cations for ICS's Model N4865A

LAN Adapter.

The Model N4865A GPIB

LAN Adapter is a hardware module that provides

The Model N4865A is designed to interface with and control Agilent DSO/

MSO7000 Series and DSO/MSO9000 Series oscilloscopes. The N4865A

has two ways to connect to an oscilloscope after power turn-on and selftest.

The user can specify an IP address for the oscilloscope and the N4865A will

N4865A will do an UDP broadcast and attempt to connect to the ﬁ rst VXI-11.3

then ready to accept GPIB bus commands and device speciﬁ c messages for its

The N4865A follows the IEEE-488.2 Message Exchange Protocol when

handling GPIB commands and device messages and should only be used with

IEEE-488.2 compatible GPIB Controllers. GPIB commands are converted to

VXI-11.3 equivalents and transmitted to the companion oscilloscope. Device

The N4865A can accept reverse channel Service Requests and will assert SRQ

The N4865A's operation and network settings are completely programmable

by commands from its Ethernet interface, eliminating the need to open the unit

to change or verify a function setting. The setup parameters can be changed

the N4865A to its default network settings at any time.

The N4865A and its companion oscilloscope can be placed anywhere on the

ICS's N4865A Interface is packaged in ICS's small metal Minibox™ case which

provides proven EMI/RFI protection and rack mounting capability. Rear panel

RJ-45 and GPIB connectors provide access to the network and GPIB bus. Front

panel LEDs provide visual network and GPIB bus status and diagnostic help

The following speciﬁ cations apply to all N4865A models. Options for your

unit may be found by comparing the list below to those listed on the Ethernet

N4865A - X General Model Number

The N4865A's 488 Bus interface meets the IEEE STD 488.1-1987 standard

SH1, AH1, T6, L4, SR1, PP0, DC0, RL0, DT0, C1 - C4 and C9

The N4865A's GPIB Bus drivers incorporate powerup/down protection to

prevent sending invalid data to the bus. GPIB fanout is up to 14 devices.

The N4865A's GPIB primary address is entered and saved in ﬂ ash memory

Interface.

Primary address range is 0 - 30. The default GPIB address is 4.

The N4865A follows the IEEE-488.2 Message Exchange Protocol when han-

All device data messages sent to the N4865A must be terminated with EOI

device_write

RPC. When the

N4865A is addressed to talk, it sends a

device_read

RPC to the companion

device_read

response packet.

Large Listen messages are handled by holding off the GPIB bus while a buffer

reading multiple talk buffers worth of data from the oscilloscope and outputting

them to the GPIB bus until a response packet is received from the oscilloscope

GPIB Listen buffer 1024 bytes (see Note 1)

GPIB Talk buffer 1024 bytes (see Note 1)

Note 1. Working buffer size may be smaller if the companion oscilloscope reports smaller maximum

packet sizes in its

response.

When the N4865A is transistioned to the Listen Active State from the Talk

Active State, it discards any data in the GPIB talk buffer. Similarly, when the

N4865A is transistioned to the Talk Active State from the Listen Active State,

The following are short term data rates:

> 17 kbytes/second to the GPIB bus from 4865 memory.

> 20 kbytes/second from the GPIB bus to 4865 memory.

The following times are averages and vary depending upon what the 4865

Short device commands 18 milliseconds typical

*IDN? Queries 46 milliseconds typical

The N4865A uses the

device_remote

and

device_local

RPCs to transmit the

When the N4865A receives a Selected Device Clear or a Device Clear on the

device_clear

RPC to the companion oscilloscope and

When the 4896 receives a Group Execute Trigger (GET) on the GPIB Bus, any

the N4865A sends a

device_trigger

RPC to the companion oscilloscope.

When the N4865A receives a Reverse Channel Service Request, it sends a

device_readstb

RPC to the companion oscilloscope to obtain the Status Register

response and assert the GPIB SRQ signal. The SRQ signal is deasserted when

the N4865A is Serial Polled or when the N4865A learns that the companion

The N4865A periodically reads the companion oscilloscope's Status Byte

polling rate is 3 Hz.

The N4865A supports the Internet Protocol Suite, including the Transmission

IEEE-802.3 Compliant. 10 Mbs with 10BaseT, 100 Mbs with 100BaseT

The IP Address, Subnet Mask, and Gateway values can be set to static values

The N4865A has the capability to accept an address from a DHCP Server. If

the N4865A is set to DHCP and does not receive a IP address, it defaults to a

The N4865A's MAC Address is saved internally and can be read with ICS's

VXI-11 Conﬁ guration Utility or with a Web Browser. See Section 2.

The N4865A uses the ports listed in Table 1-1

Port Usage Protocols Notes

Error Logger

The N4865A's standard HTML pages conform to HTML version 4.01 or XHTML

User can redeﬁ ne the other page names, page layouts or add additional pages.

The WebServer serves the stored pages after substituting values for the variable

placeholders. The standard N4865A pages are:

404.html 404 Error Page (required page)

reboot.html Reboot Page

Image ﬁ les with .jpg or .gif extensions are served as graphics

The user can replace the standard HTML pages and image ﬁ les with modiﬁ ed

pages or add additional pages and images to the card. User is responsible for

XHTML version 1.0. Guidelines for modifying the pages, HTML ﬁ les and the

Update Utility are described in Application Bulletin AB80-5.

File types supported .html, .gif and .jpg

Number of ﬁ les 32 maximum

File size 63 kbytes maximum for all ﬁ les

32 kbytes maximum for a single ﬁ le

File name size 27 characters

The N4865A operates as a VXI-11 client and is fully compliant to the VXI-11

The N4865A's RPC protocol conforms to ONC RPC Version 2 per the VXI-11

The N4865A addresses its companion LAN oscilloscope as

If AutoFind is On, the N4865A does a UDP broadcast to the entire IP universe

to ﬁ nd an VXI-11.3 compatible oscilloscope. The extent of the broadcast is

the ﬁ rst VXI-11.3 compatible oscilloscope that replies. Connection capability

If AutoFind is Off, no UDP broadcast is issued and the N4865A will try to link

to an oscilloscope at the user designated ip address.

Command

Function Choices Default Source (1)

IP Address Mode Static or Dynamic Dynamic E

Address 0.0.0.0 to 169.254.48.65 E

255.255.255.255

Net Mask 0.0.0.0 to 255.255.0.0 E

255.255.255.255

KeepAlive On or Off On E

Address 0-30 0 E

Auto Disconnect On or Off Off E

Addresses 255.255.255.255

AutoFind On of Off On E

Notes: 1. E = Ethernet Interface as the conﬁ guration port for Browsers or

for ICS's VXI-11 Conﬁ guration Utility.

Address is factory set and is not user changeable.

The MAC Address can be read with the VXI-11 Conﬁ guration Utility

4. Setting AutoFind ON causes the N4865A to ignore the Oscilloscope

IP Address setting.

The N4865A has eight front

panel LEDs that normally display the following

LAN - Indicates the unit is connected to an active Ethernet

oscilloscope or to the network.

ACT - Indicates activity over the Ethernet connection.

RDY - Blinks at a 1 Hz rate while doing an AutoFind of the

TALK - Indicates the unit is an active GPIB Talker.

LSTN - Indicates the unit is an active GPIB Listener.

ERR - Solid on when the N4865A runs into a problem that

prevents it from continuing.

When the N4865A is turned on, it performs an internal selftest which takes

LED bit weights are:

RDY TALK LSTN SRQ ERR

16 8 4 2 1

If DHCP is selected, the N4865A will wait 15-20 seconds for a DHCP server

response before defaulting to its Auto IP address. It then starts looking for a

If the N4865A ﬁ nds a selftest error, it blinks the error code on its front panel

LEDs. Refer to paragraph 5.4 for a description of the selftest errors and their

possible causes.

Figure 1-1 N4865A Outline Dimensions

18.92 cm

Side View

14.15 cm

End View

3.86

.254

0.95 cm

max

connector

(18.92 cm L x 14.15 cm W x 3.86 cm H)

(See Figure 1-1)

Weight - 1.37 lbs. (.6 kg.)

Temperature - Operating -10 °C to +55 °C

Storage -40 °C to +70 °C

Humidity - 0-90% RH without condensation

GPIB Connector with metric studs

Ethernet Interface

RJ-45 Connector

Power Jack

2.45 mm plug, center positive

LAN Reset button on rear panel

Power Network GPIB Bus

LED LEDs LEDs

Figure 1-2 N4865A Front Panel Indicators

EMI/RFI Meets limits for part 15, Class A of US FCC Docket 20780

CE Certiﬁ cate of Compliance reproduced in Figure 1-3. The

N4865A uses the 8065 PCB assembly and 8065 Certiﬁ cate.

UL/CSA/VDE AC Wall adapter has applicable UL/CSA/VDE

Figure 1-3 Certiﬁ cate of Conformity

120204 Quick Start Guide

895011 Ethernet Crossover Cable

895014 USB Power Cable

123170 Support CD-ROM with Model N4865A Instruction

Manual

120170 N4865A Instruction Manual

114210 Single Rack Mounting Kit

114211 Dual Rack Mounting Kit

104705 GPIB Cable, 0.5 meters long

104710 GPIB Cable, 1 meters long

104720 GPIB Cable, 2 meters long

104740 GPIB Cable, 4 meters long

895011 Ethernet Crossover Cable

895014 USB Power Cable

This page left intentionally blank

When unpacking, check the unit for signs of shipping damage (damaged box,

ICS Electronics or your local sales representative immediately. Also, call the

replaced without waiting for the claim against the carrier to be settled.

Take a moment to verify that the following items were included with your

unit:

(1) Model N4865A GPIB to LAN Adapter

(1) Quick Start Guide

(1) USB Power Cord

(1) Ethernet Crossover Cable

(1) Support CD-ROM with Instruction Manual PDF

When shipped, the N4865A is conﬁ gured to operate with a dynamic IP address

that will fall back to an IP address of 169.254.48.65 if no DHCP server is found.

Refer to Table 1-2 for all N4865A factory settings.

The following steps should be used as a guide to setting up and using your

N4865A.

with a Web Browser.

has an IP address in the range of 169.254.xxx.xxx it should successfully

If the oscilloscope has an IP address outside of the N4865A’s range, either

the N4865A or the oscilloscope needs to have its IP address changed. See

paragraphs 3.1.1 and 2.5.

to conﬁ gure the N4865A’s network and/or GPIB settings as directed in

paragraph 2.5. If you are resetting the oscilloscope’s IP address, do not

to install the N4865A in the rack mounting kit. Mount the rack mount

4. After conﬁ guration, the N4865A can be connected to its companion LAN

rear panel and to the oscilloscope’s RJ-45 connector. Use a GPIB Cable

to connect the N4865A to the GPIB Controller.

Figure 2-1 N4865A Direct Oscilloscope Connection

Address Mode

Static or Static lets the user set the N4865A’s IP Address, Net

DHCP Mask and Gateway IP values. DHCP enables the

N4865A to accept the IP values supplied by a DHCP

to IP address 169.254.48.65 and Net Mask of

IP Address Any Sets the N4865A’s own IP address. Any valid IP

between 0.0.0.0 and 255.255.255.255. The default for

Net Mask Any 254.254.0.0. for B range operation.

last octet. i.e. 192.168.0.1.

KeepAlive

On or Off Enables the N4865A’s socket layer to send the client a

no activity on the socket. If the client fails to reply,

the N4865A will close the socket, release any locks

not support Keep Alive messages. Factory setting is

N4865A’s

0 to 30 Sets the GPIB address the N4865A uses for itself on

Address the GPIB bus. Values are 0 to 30. Recommended

values are 0 and 21. Factory setting is 4.

Instrument IP Any Sets the oscilloscope’s IP address. Not required if

AutoFind is On. If AutoFind is Off, the N4865A will

look for an oscilloscope at just this IP address. The

AutoFind

On or Off Enables the N4865A to ignore the Oscilloscope IP

N4865A will attempt to open channels and link to

the ﬁ rst oscilloscope it ﬁ nds. Enable AutoFind for

back-to-back connections only. Disable AutoFind

Factory setting is On.

Note: Default values are listed in Table 1-2

This paragraph provides two methods to conﬁ gure the N4865A for operation with

the companion oscilloscope. When shipped, N4865As are conﬁ gured as listed

back-to-back connections or when connected through a hub or switch. If the

range.

tion Page.

The Web Browser method uses a standard browser such as Firefox, Internet

Explorer or Netscape to view and change the N4865A’s current settings.

the supplied Ethernet Crossover Cable to connect the computer to the

unit as shown in Figure 2-2. This will eliminate any potential network

to power the N4865A.

Figure 2-2 N4865A Connected to PC with a Crossover Cable

An alternate connection is to use a standard Ethernet Cable to connect the

4865 GPIB to LAN

Instrument



Figure 2-3 N4865A Connected to the local hub

blinking which indicates that the N4865A is ready to communicate with

the PC.

N4865A’s B range of 169.254.xxx.xxx range so it can communicate with

the unit. (To check, run ipconﬁ g in the Command Prompt box). If the

range, record the current settings and temporarily set the following network

Check ‘Use the following IP Address’

IP Address 169.254.0.2

Subnet mask 255.255.0.0

Click Okay twice to apply the new settings and close the open windows.

Minimize the Network Places window.

4. Open the browser and enter the N4865A’s default IP address of 169.254.48.65

your browser. Here you can read all of the information about the N4865A

6. If you want to change any of the settings, press the ‘Update Conﬁ gura-

tion’ button. A Conﬁ guration Page similar to the one shown in Figure 2-5

Figure 2-4 N4865A Welcome Page

Figure 2-5 N4865A Conﬁ guration Page

and GPIB

Address settings as desired. If you

to the one shown in Figure 2-6 will appear in your browser.

Figure 2-6 N4865A Conﬁ rmation Page

the unit’s ﬂ ash memory. Press the ‘Reboot’ button to reboot the unit and

page will appear in your browser.

may have to change the PC’s Local Area Network settings if you selected

The RPC Conﬁ guration method involves using selected RPC commands from

those listed in Appendix 3 to change the N4865A settings. Refer to Appendix

mands.

The N4865A has an internal header for driving external LEDs. The N4865A

provides 5 Vdc to power the external LEDs. User should provide current

pinouts are listed in Table 2-3

Pin Signal Pin Signal

4 ACT 9 no connection

Figure 2-7 External LED Circuit

The N4865A has the following jumper positions. See Figure 2-8 on the next

page:

Jumper Function Factory

Setting

W1 Default Restore. See paragraph 5.6 Open

W2 Option Jumper. Selects N4865A ﬁ rmware Installed

W5 SRQ LED signal selection LAT

SRQ selects GPIB bus SRQ signal.

LAT selects N4865A processor output latch

W7 JTAG Loading Jumpers. For factory test use Open

W8 only. ARM

Notes: Open jumpers may be parked on a single post.

Figure 2-8 N4865A Jumper Locations

S1 RESET

DEF

OPM

LAN

LED Header

JTAG Header

SRQ LAT

PLD ARM

PWR

The Model N4865A is held in its rack mounting kit with a winged-’U’ shaped

bracket. Perform the following steps to install a N4865A in a rack mounting

kit:

bezel through the rack mount kit from the rear of the kit. Push it forward

through the opening until the rubber feet line up with the holes in the rack

mounting kit. Push the unit down until it rests ﬂ at on the kit and the feet

mounting kit.

mount kit and protrude equally through the front panel of the rack

mounting kit.

4. Set the bracket so its two holes line up with the holes in the rack mount-

rack.

This page left intentionally blank

3.1 INTRODUCTION

This section describes the operation of the N4865A GPIB

LAN Adapter.

3.2 OPERATION

3.2.1 Oscilloscope Discovery and Linkage

to locate a server for 15-20 seconds before defaulting to its Auto IP address

that IP address.

If AutoFind

is enabled, the N4865A does a UDP broadcast and waits for a

reply. It then queries any replying oscilloscope to see if it has a VXI-11.3

RPC Service. If one is found, the N4865A attempts to open communication

While the N4865A can communicate with an oscilloscope at any legal IP ad-

by the network topology, its Net Mask and Gateway settings. The factory set

N4865A can communicate to an oscilloscope in the AutoIP B address range

N4865A to its companion oscilloscope in a back-to-back conﬁ guration or through

If AutoFind is disabled and the N4865A has been conﬁ gured to use a speciﬁ c

When the N4865A ﬁ nds a VXI-11.3 compatible oscilloscope it opens a core

Interrupt channel if the oscilloscope supports it.

The N4865A's RDY LED blinks during the oscilloscope discovery process,

N4865A links with a LAN oscilloscope and becomes ready to transmit GPIB

the oscilloscope, it will attempt to reconnect to the oscilloscope.

3.2.2 GPIB Operation

The N4865A only operates correctly with an IEEE-488.2 compatible GPIB

EOI asserted on the last character as the N4865A does not check for message

terminators. The N4865A will assert EOI when it outputs the last character in

the response received from the LAN oscilloscope if the END bit was asserted

When the N4865A receives a terminated device message from the GPIB bus

the N4865A sends the data to the companion oscilloscope with the

device_write

RPC. The N4865A holds the GPIB bus while transmitting the data to the com-

panion oscilloscope. In the case of large messages, the N4865A sends the data

to the companion oscilloscope when its GPIB listen buffer becomes full. When

the ﬁ rst buffer load of data has been sent to the companion oscilloscope, the

N4865A accepts the next buffer worth of data. The process repeats with the

N4865A handling a buffer worth of data at a time until the N4865A receives

the last portion of the data with EOI asserted on the last byte. Unterminated

When the N4865A is made an active talker, it sends a

device_read

RPC to the

response data from the companion oscilloscope that is terminated with END

buffer, the N4865A outputs the ﬁ rst buffer of data to the GPIB bus and sends

device_read

RPC to the oscilloscope to read the next buffer's

END asserted. If the companion oscilloscope returns a zero length response,

the N4865A will not have any data for the GPIB bus and the GPIB read opera-

tion will timeout.

When the N4865A is addressed to talk and has received a response packet with

END asserted, it will not fetch additional data from the companion oscilloscope

until it has been addressed to listen and sent a device message, a GPIB Device

Trigger, a GPIB Device Clear command or an Interface Clear.

When the N4865A is transistioned to the Listen Active State from the Talk

Active State, it discards any data in the GPIB talk buffer. Similarly, when the

N4865A is transistioned to the Talk Active State from the Listen Active State,

If the N4865A receives a Service Request from the oscilloscope over the

Reverse Interrupt channel, the N4865A will query the oscilloscope's Status

RPC when it is safe to do so. If bit 6 in

the Status Byte is set, the N4865A will assert the SRQ line on the GPIB bus

The SRQ line will be deasserted and the SRQ LED will be turned off. Future

the program in the GPIB Controller.

The N4865A periodically queries the companion oscilloscope's Status Byte to

update its own Status Byte at a low 3 Hz rate. If the N4865A discovers that the

the SRQ signal on the GPIB bus and turn off its SRQ LED. The N4865A's

N4865A's low query rate and the user's program.

N4865A has ﬁ nished outputting response data, after a GPIB Device Clear or

3.2.3 Web Server

The N4865A includes an HTML server that provides a Welcome html page

that lets a user view the N4865A's properties, its network and GPIB Bus set-

tings and the AutoFind status. The Welcome page also displays the companion

The Conﬁ guration page is self explanatory. Select DHCP for dynamic IP op-

before defaulting to an IP address of 169.254.48.65. Select Static to operate the

N4865A at a ﬁ xed IP address and then enter the desired IP address, Net Mask

A Conﬁ rmation page lets the user save the new settings and restart the N4865A

3.3 PROGRAMMING GUIDELINES

The N4865A can be used successfully to operate a LAN oscilloscope with

to compensate for delays in converting the commands and transmitting them

The following multiple sequences should be avoided:

3.3.1 Multiple Triggers

the 488.2 '*TRG' Common Command. The N4865A may miss multiple GET

488.1 GET.

3.3.2 Multiple Device Clears

the oscilloscope(s) to clear their buffers and output lines. Many oscilloscopes

The N4865A may miss multiple DC or SDC commands when sent to it at high

3.3.3 Multiple Serial Polls

Multiple high speed Serial Polls will return the same value. The N4865A's

Request and before asserting the SRQ signal and periodically thereafter at a 3

rial Poll updates are inhibited while the N4865A is in the listen addressed state

Trigger, after a Device Clear command or after an Interface Clear.

3.3.4 Message Terminators

requires that all Device data messages sent to it be terminated with EOI as-

terminated with both a linefeed character and EOI asserted. (The IEEE-488.2

NL terminator)

The N4865A's GPIB responses are terminated with EOI asserted on the last

byte. Any terminating character is supplied by the companion oscilloscope as

part of its response message.

3.3.5 Transferring Large Files

The N4865A transfers large data ﬁ les in blocks of one Talk buffer or one Listen

buffer worth of data at a time. These buffers are a maximum of 1,024 bytes.

Users should set their program to read data in blocks that are multiples of 1,024

bytes for best performance. The user's program should not untalk or unlisten

the N4865A in the middle of transferring large data ﬁ les. Setting readdress

time. Timeouts should be set for 1 second per kbyte of data transfer.

3.3.6 Linkage Lost

When the N4865A links to a oscilloscope, it turns the RDY LED solid on after

RPC. The N4865A only knows the

RPCs. There is nothing to alert the N4865A to the oscilloscope being turned

RPCs depends upon the Test Application. If the Test Application is quiescent

rate.

When the N4865A does not receive a valid RPC response, it turns off the RDY

LED and attempts to relink to the oscilloscope. If it is successful, the N4865A

RPC should be considered lost. The user will have to consider this in his

program.

3.4

3.4.1 WebServer Pages

The OEM can customize the N4865A's WebServer conﬁ guration pages to iden-

tify the product and incorporate the company logo by following the guidelines

3.4.2 End-User Documentation

relate to the end product. In most cases the end-user needs directions for:

product and show the end-user how to use them.

4. Using special commands like the trigger functions if applicable.

how to enable Service Requests (SRQs) and how to read the oscilloscope's

The N4865A is transparent and does not have any SCPI commands.

3.4.3 Utility Programs and Drivers

None associated with the N4865A.

3.4.4

LAN Adapter are hereby given permis-

this manual for other purposes without the expressed written consent of ICS

Electronics is forbidden.

This page left intentionally blank

This section describes the theory of operation of the N4865A.

A block diagram of the N4865A is shown in Figure 4-1. The N4865A is a

microprocessor based device that performs the VXI-11 client functions to

The N4865A is made up of seven major elements, most of which are intercon-

bus.

Incoming GPIB commands or device messages are received by the GPIB Inter-

packets from the LAN instrument are received by the LAN Interface chip and

placed in the GPIB talk buffer. The response data in the GPIB talk buffer is

their VXI-11 equivalents and sent through the Ethernet interface to the LAN

Figure 4-1 shows a block diagram of the N4865A’s internal logic. Most of the

major logic elements center around the 16-bit data bus from the ARM7 Proces-

The FLASH chip stores the program code and the conﬁ guration parameters.

At power turn-on time, the ARM7 processor loads the program code from the

FLASH into the RAM chip. The program is then run out of the RAM chip.

At power turn-on, the processor clears the LEDs, does a brief check of the

processor had found a hardware error, the loading process would stop and the

LEDs would blink the appropriate error code. New units default to using the

program stored in the program0 space. Units that have been updated in the

program0 space.

Figure 4-1 N4865A Block Diagram

Power

Supply

9-32 VDC

Input

+5V

3.3V Reg

+3.3V

GPIB

CTLR

RAM

ARM7 Processor

Address

DCDR

µP BUS

FLASH

Latch

Front Panel LEDs

LAN

INTFC

GPIB

Fltr

TCP/IP

LAN

Rear Panel Reset Button

4-3

After the correct program code is transferred to RAM, the LAN and GPIB

Interfaces are initialized. If the N4865A has a good LAN connection, it starts

the instrument discovery process. When the N4865A has linked to an instru-

ment, it is ready to receive messages from a GPIB Controller. The operating

The power supply

is a switching regulator that converts the unregulated DC input

to +5 volts DC to run the N4865A’s peripheral logic chips. A 3.3 regulator

regulates the 5 Vdc down to 3.3 volts to power the processor and major logic

This page purposely left blank.

This section describes the maintenance testing, troubleshooting, and repair

procedures for ICS's Model N4865A GPIB

LAN Adapter.

MAINTENANCE

The N4865A does not require periodic calibration and has no internal adjust-

ments. However, if the N4865A is used in an application where the IEEE 488

bus cables are frequently changed, the N4865A's IEEE 488 Bus Connector

may occasionally require cleaning to remove wax and dirt buildup. New bus

The brightener is an organic compound and may be cleaned off by washing the

Table 5-1 lists several common fault indications and suggests actions that

If the fault isolation procedure requires internal measurements,

unit. Use extreme caution during troubleshooting, adjustments,

TROUBLESHOOTING GUIDE

Possible

Unit will not turn on Power cord not Push power cord into DC

PWR LED off plugged in receptacle

Power at AC outlet Check outlet and power

adapter

Wrong DC adapter Use ICS supplied adapter

DC plug polarity N4865A requires + polarity on

wrong center pin.

All LEDs on Internal fault Check TP4 (3.3V) and TP5

(5 V) for proper voltage.

Return unit for repair

Unit shows blinking Self test fault Refer to Self Test errors in

LEDs Table 5-2.

ERR LED blinks. Instrument communication

error. The N4865A is unable to

communicate with the LAN

instrument. Usually means no

response from the instrument.

ACT LED blinks Normal operation

RDY LED blinks The N4865A is looking for a

VXI-11.3 compatible LAN

instrument. If blinking con-

tinues more than 20 seconds,

check instrument connections

and its network settings. Be

sure it is VXI-11.3 compatible.

TROUBLESHOOTING GUIDE (CONT.)

Possible

Unit does not LAN LED off Network not detected.

respond to client PC after 30 seconds No network cable or local

hub/switch. Check hub/switch

power. Replace Ethernet cable.

Wrong cable type. Use a cross-

to a PC. Use a standard cable

to connect to a hub or network

No network. Check hub,

tion

LAN LED on No network messages

ACT LED never on received by the N4865A.

Check PC IP settings. Settings

must match N4865A's settings

for proper communication.

N4865A not set to factory

defaults. Hold Rest button in

while power cycling the unit.

See para 5.5.

LAN LED on Possible link error. Link to

ACT LED blinks correct N4865A or IP address.

Not linked to a LAN RDY LED blinking Instrument LAN connections.

Instrument Be sure LAN instrument is

connected directly to the

N4865A or to it via a local hub

Hub or switch error. Power

Instrument IP settings wrong.

Check settings. See para 2.4-1

LAN Instrument N4865A in Local Send the N4865A a Selected

not in Remote Device Clear command with

REN on or send the N4865A an

Enable Remote command.

TROUBLESHOOTING GUIDE (CONT.)

Possible

Message not sent Missing terminator All device messages must be

to LAN instrument terminated with a LF and

EOI asserted on the last byte.

Verify the GPIB Controller

settings.

No response from Instrument not Verify that the instrument's

N4865A Responding error indicator is not on.

Response Terminator Device message to the GPIB

EOI asserted on the last char-

read terminator settings.

Missing instrument Instrument did not get a query.

response data or has not response data. See

program error above

Instrument did not respond.

programming and commands.

Does not get all data Instrument was not asked for

in a large message additional data. Verify that the

N4865A was not addressed

message, a Device Trigger or a

Device Clear after talking out

the ﬁ rst data.

Missing data bytes Controller using ATN holdoff.

when reading large when doing partial reads.

ﬁ les. Change read size to a multiple

Device command Serial poll the device or read

error its Event Status Register to

determine reason for no

response.

N4865A reverts to Conﬁ guration Press Save and Reboot

power turn-on conﬁ guration

At power turn on, the N4865A conducts a selftest of its major components.

The test takes about 5 seconds. During the selftest the PWR LED is on and the

RDY LED is off. A successful test ends when the RDY LED on. Test failures

Front Panel LEDs

⊕

x x x x x x x fatal error (CPU,

⊕

− − − − − − Β LAN IC, Network

⊕

− − − − − Β - GPIB IC or GPIB

⊕

− − − − − Β Β Conﬁ guration Error

⊕

− − − − Β − − OS Issued Exit

⊕

− − − − Β − Β RAM IC or Memory

⊕

− − − − Β B − OS Error

⊕

− − − − Β B B Flash Error

Symbols:

⊕

= solid on, B = blinking, x = solid on or off

RDY PWR LAN ACT TALK LSTN SQR ERR Fault

FLASH, RAM..etc.)

− − − − − − − − fatal error (power

supply)

Socket Failure or DHCP

Transceivers

or Flash Failure

overﬂ ow error

The N4865A can be reset to the default network settings listed in Table 1-2 by

holding the rear panel LAN Reset Button in for 10 seconds while turning the

N4865A’s Power Switch on.

handle works well.) You should be able to feel the Reset button move as

you gently depress it.

button depressed until the three front panel yellow LEDs blink.

4. Release the Reset button and turn Power off before connecting any cables

to the unit.

The N4865A's ﬁ rmware can be updated in the ﬁ eld without returning the unit

to the factory.

the keyboard as they only have enough power for a mouse.

http://www.icselect.com. Highlight the Download tab and select 'VXI-11

Network setting to the N4865A's AutoIP range as described in paragraph

4. Run the N4865A Update Utility. If it will not run, download the Visual

LEDs (TALK, LSTN and SRQ) will blink while the new program is be-

N4865A as required to complete the update process.

Do not exit the Update Program until told to do so. It will

For service or repair information, please contact your local Agilent Sales Ofﬁ ce

Appendix

488.2, SCPI)

The IEEE Std 488 Bus is a convenient means of connecting instruments

two computers. The IEEE Std 488.1 covers the electrical and mechanical

bus speciﬁ cations and the state diagrams for each bus function. The IEEE

The SCPI standard developed a tree like series of standard commands for

programmable instruments so that similar instruments by different manu-

The IEEE Std 488 Bus, or GPIB as it is commonly referred to, provides a

portion of the bus is governed by IEEE -Std 488.1 - 1978. The interface

passive cabling is needed to interconnect the devices. The cables connect

to the signal line as shown in Figure A-1. Eight of the lines (DIO1-DIO8)

parallel manner. Data and message transfer is asynchronous, coordinated

by the three handshake lines (DAV, NRFD, NDAC). The other ﬁ ve lines

Two types of messages are transferred over the bus:

Interface messages - for bus management

Device-dependent messages - for device control and data

transfer

The system controller is a controller that becomes active at power turn-on.

A-3

talker

the system controller and is passed back to other controller(s) as required.

their unaddressed state.

Each bus device is identiﬁ ed by a ﬁ ve-bit binary address. There are 31

possible primary addresses 0 through 30. Address 31 is reserved as the

by setting rocker switches on each devices' rear panel. Devices that are

DEVICE B

Able to Talk

and to Listen



e.g. DVM

DEVICE C

Able to Listen



e.g. Signal 

generator

IFC ATN SRQ REN EOI

DAV NRFD NDAC

DIO1-8

Bus Control Lines

Byte Transfer Control Lines

Data Bus (8 Lines)

DEVICE A Able to Talk, Listen and Control  e.g. Computer

the three handshake lines. No step in the sequence can be initiated until

the previous step is completed. Information transfer proceeds as fast as

the devices respond (up to 1 Mbs), but no faster than that allowed by the

to listen simultaneously, only one device at a time can be addresses as a

talker. When a talk address is put on the data lines, all other talkers are

The messages are transmitted on the seven least signiﬁ cant data lines and

programmed to correctly respond to each device's message termination

REN (remote enable) is sent by the system controller and is used with

EOI (end or identify) is used by a device to indicate the end of a multiple-

byte transfer sequence. When a controller-in-charge sets both the ATN and

EOI lines true, each device conﬁ gured to respond to a parallel poll indicates

A-5

transmitted with ATN off. The following chart lists the standard command

My listen address (controller to self)

MTA

My talk address (controller to self)

Device listen address

Device talk address

Secondary Device address (device optional address)

Unlisten

Listen

Universal Commands (to all devices)

Local Lockout

DCL

Device Clear

Parallel Poll Unconﬁ gure

Serial Poll Enable

Serial Poll Disable

Selected Device Clear

Go to Local

Device Trigger

Parallel Poll Conﬁ gure

Take Control

0 being the logic true level. Cable connectors are modiﬁ ed Amphenol 24

pin Blue ribbon style connectors (57-30240) with metric jack screws.

A-6

-- Go to Local

COMMAND

(PCG)

MEANING DEFINED BY

PCG CODE

MEANING DEFINED BY PCG CODEMEANING DEFINED BY

MEANING DEFINED BY

PCG CODE

MEANING DEFINED BY PCG CODEMEANING DEFINED BY

A-7

ATN RET

A-8

Power On

User Request

Command Error

Execution Error

Device Dependent Error

Query Error

Request Control

Operation Complete

Standard

Event Status

*ESR?

7 6 5 4 3 2 1 0

Logical OR

Standard

Event Status

Enable

*ESE <NRf>

*ESE?

Queue

Not-Empty

7 5 4 3 2 1 0

Logical OR

7 6 3 2 1 0

RQS

MSS

ESB

MAV

{

Service

Request

Generation

Output Queue

Status Byte Register

read by Serial Poll

read by *STB?

Service Request

Enable Register

*SRE <NRf>

Capabilities

A-9

Message Formats

The IEEE 488.2 Standard was established in 1987 to standardize message

protocols, status reporting and deﬁ ne a set of common commands for use

Semicolons are used to separate messages.

Colons are used to separate command words.

Commas are used to separate data ﬁ elds.

<nl>

Line feed and/or EOI on last character terminates a

'program message'. Line feed (ASCII 10) and EOI

terminates a RESPONSE MESSAGE.

Asterisk deﬁ nes a 488.2 common command.

With IEEE 488.2, status reporting was enhanced from the simple serial

poll response byte in IEEE 488.1 to the multiple register concept shown in

Figure A-3. The IEEE 488.2 Standard standardized the bit assignments in

the Status Byte Register, added eight more bits of information in the Event

the Status Byte Register. The Status and Event registers have enabling

registers that can control the generation of their summary reporting bits and

ultimately SRQ generation. Each 488.2 device must implement a Status

registers providing they follow the model shown in Figure A-3.

The IEEE 488.2 Standard also mandated a list of required and optional Com-

A-10

Differences From IEEE 488.1

The user who is familiar with the older 488.1 devices should take the fol-

bit in response to a *STB? query. The MSS bit is cleared when the condi-

tion is cleared.

488.2 restricts the Device Clear to only clearing the device's buffers and

pending operations. It does not clear the Status Reporting Structure or the

to reset the outputs.

488.2 commands are really special data messages and are executed by the

Enable Register values are only saved and restored if the *PSC command is

0. A *PSC command of 1 causes zeros to be loaded into the enable registers

Required common commands are:

Clear Status Command

Standard Event Status Enable Command

Standard Event Status Enable Query

Standard Event Status Register Query

Identiﬁ cation Query

Operation Complete Command

Operation Complete Query

Reset Command

Service Request Enable Command

Service Request Enable Query

Status Byte Query

Self-Test Query

Wait-to-Continue Command

Devices that support parallel polls must support the following three com-

mands:

Individual Status Query?

Parallel Poll Register Enable Command

Parallel Poll Register Enable Query

Devices that support Device Trigger must support the following commands:

Trigger Command

Pass Control Back Command

Devices that save and restore settings support the following commands:

Recall conﬁ guration

Save conﬁ guration

Devices that save and restore enable register settings support the following

Saves enable register values and enables/disables recall

programming syntax of 488.2 to give the programmer the capability handling

be implemented exactly as speciﬁ ed. Guidelines are included for adding

program generators. The obvious beneﬁ ts of SCPI for the ATE programmer

replace one manufacturer's instrument with one from another manufacturer,

This consistent programming environment is achieved by the use of deﬁ ned

program messages, instrument responses and data formats for all SCPI

hopping from the tree trunk out on the branches to the leaves. Subsequent

keywords are considered to be at the same branch level until a new com-

plete command is sent to the device. SCPI commands may be abbreviated

A-13

be used when entering a command. Figure A-4 shows some single SCPI

baud setting

'Sets character format

to 8 data bits

Multiple SCPI commands may be concatenated together as a compound

to the same tree level as the previous command. Starting the subsequent

program message without affecting the above rules. Figure A-5 shows some

Compound Command Examples

The response includes ﬁ ve items because the command contains 5 queries.

The ﬁ rst item is

which is the baud rate, the second item is

(bit/word) which is

the current setting. The BIT 6 command was not accepted because only 7

XON

means that XON

(ESR register bit 5) which means execution

represents the sum of the binary bit weights for the bits with a logic '1'

by the unit. A range of values can be indicated by the starting and stopping

For more information about SCPI refer to the SCPI Standard or to the SCPI

A-15

The following document describes ICS's Conﬁ guration RPC Protocol.

This information is supplied to enable a RPC programmer to conﬁ gure ICS

This document deﬁ nes the conﬁ guration interface to the ICS Ethernet de-

Edevice, for the purposes of modifying the operational characteristics of the

Edevice. Edevices are ICS products whose Model number is in the 8xxx

range. Not all commands are supported by all Edevices.

This speciﬁ cation addresses the Edevice communication for the purposes

This speciﬁ cation is to be considered an addendum to the VXI-11 speciﬁ ca-

tion for communication to the VXI-11 compliant ICS Edevice Interfaces.

The Edevice follows the VXI-11.2 and/or VXI-11.3 speciﬁ cations.

This speciﬁ cation has the following objectives:

Edevice conﬁ guration.

A-16

tional, June, 1987.

The Edevice Conﬁ guration protocol uses the ONC remote procedure call

to conceptually call a function on another computer.

The client identiﬁ es the remote procedure by means of a program ID,

program version, and procedure number. This information is encoded into

the target procedure is then executed. The server is required to respond to

return values.

Table B.1 lists the RPC messages used by the Edevice conﬁ guration protocol.

Messages that apply to the 8065 are marked by an 'x' in the 8065 column.

The client shall issue an RPC command to the Edevice directing the action

to be taken. The Edevice shall attempt to execute the action and will then

reply with an RPC reply.

A-17

reply and then (if the status is No Error) execute the action.

to Error Codes as deﬁ ned by the VXI-11 (section B.5.2).

terminated and will contain a leading length numerical value deﬁ ning the

total length (inclusive of the NULL).

Message ID Description 8065 Reboot

Req'd

rpc_port_number 2 RPC TCP port

hostname 7 Edevice TCP hostname

netmask 10 network netmask X Yes

keepalive 12 keepalive time X No

ren_mode 15 REN active at boot X Yes

reload_conﬁ g 20 force reload of default conﬁ g X No

reload_factory 21 reload factory conﬁ g settings X No

reboot 23 cause a reboot of the Eth488 X No

A-18

the last data ﬁ eld and may consist of any byte value.

When the Action boolean signals a read of a mode/value setting, the RPC

RPC command is not used, it must exist. If the mode/value is not contained

The successful modiﬁ cation of a conﬁ guration setting will result in the

The Edevice conﬁ guration procedures shall use an RPC program ID of

A-19

The interface_name procedure is used to read/modify the current VXI-11

unsigned int action;

unsigned int length;

opaque name<>;

};

unsigned int error;

unsigned int length;

opaque name<>;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The name string must be a NULL terminated string with a 32-byte maximum

Name is unchanged if the name ﬁ eld exceeds 32-bytes.

The returned Int_Name_Resp structure will always contain the current

0 No error

A-20

The rpc_port_number procedure is used to read/modify the TCP port used

by the RPC server.

unsigned int action;

unsigned int port;

};

unsigned int error;

unsigned int port;

};

Rpc_Port_Resp rpc_port_number (Rpc_Port_Parms) = 2;

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The port value must be within the range of 0x0001 and 0xFFFF. An error

The returned Rpc_Port_Resp structure will always contain the current RPC

0 No error

The core_port_number procedure is used to read/modify the TCP port used

by the VXI-11 core channel.

unsigned int action;

unsigned int port;

};

unsigned int error;

unsigned int port;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The port value must be within the range of 0x0001 and 0xFFFF. An error

The returned Core_Port_Resp structure will always contain the current

VXI-11 Core Port value, irrespective of the error value.

0 No error

The abort_port_number procedure is used to read/modify the TCP port used

by the VXI-11 abort channel.

unsigned int action;

unsigned int port;

};

unsigned int error;

unsigned int port;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The port value must be within the range of 0x0001 and 0xFFFF. An error

The returned Abort_Port_Resp structure will always contain the current

VXI-11 Abort Port value, irrespective of the error value.

0 No error

A-23

The conﬁ g_port_number procedure is used to read/modify the TCP port

used by the Edevice conﬁ guration channel.

unsigned int action;

unsigned int port;

};

unsigned int error;

unsigned int port;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The port value must be within the range of 0x0001 and 0xFFFF. An error

The returned Conﬁ gt_Port_Resp structure will always contain the current

VXI-11 Abort Port value, irrespective of the error value.

0 No error

The comm_timeout procedure is used to read/modify the TCP timeout value.

unsigned int action;

unsigned int timeout;

};

unsigned int error;

unsigned int timeout;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The timeout value is not range checked, thus it is possible to deﬁ ne an

The comm_timeout procedure applies only to the VXI-11 core and Edevice

0 No error

A-25

The hostname procedure is used to read/modify the hostname used by the

Edevice. The hostname is only applicable if a dynamic DNS service is

unsigned int action;

unsigned int length;

opaque name<>;

};

unsigned int error;

unsigned int length;

opaque name<>;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The name string must be a NULL terminated string with a 32-byte maximum

Name is unchanged if the name ﬁ eld exceeds 32-bytes.

The returned Hostname_Resp structure will always contain the current

hostname value, irrespective of the error value.

0 No error

A-26

The static_ip_mode procedure is used to read/modify the static IP mode. If

unsigned int action;

unsigned int mode;

};

unsigned int error;

unsigned int mode;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The mode must be either 0 (dynamic) or 1 (static). An error of 5 is returned

The returned Static_IP_Resp structure will always contain the current static

0 No error

A-27

The ip_number procedure is used to read/modify the static IP number. If

unsigned int action;

unsigned char ip[4];

};

unsigned int error;

unsigned char ip[4];

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The ip must be exactly 4-bytes in length. An error of 5 is returned and the

The returned IP_Number_Resp structure will always contain the current

0 No error

A-28

The netmask procedure is used to read/modify the netmask. If static_ip_mode

unsigned int action;

unsigned char netmask[4];

};

unsigned int error;

unsigned char netmask[4];

};

Netmask_Resp netmask (Netmask_Parms) = 10;

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The netmask must be exactly 4-bytes in length. An error of 5 is returned

The returned Netmask_Resp structure will always contain the current net-

0 No error

A-29

The gateway procedure is used to read/modify the gateway IP. If static_ip_

unsigned int action;

unsigned char gateway[4];

};

unsigned int error;

unsigned char gateway[4];

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The gateway must be exactly 4-bytes in length. An error of 5 is returned

0 No error

A-30

The keepalive procedure is used to read/modify the keepalive value. If set

to zero, then keepalives will not be used. If used, then this is the time (in

unsigned int action;

unsigned int time;

};

unsigned int error;

unsigned int time;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The time value is not range checked, thus it is possible to deﬁ ne an impos-

used. If a channel remains inactive for the speciﬁ ed time period, then a

keepalive is sent (assuming time is non-zero). The returned Keepalive_Resp

the error value.

time is speciﬁ ed, Keepalive will be active regardless of time.

0 No error

A-31

The gpib_address procedure is used to read/modify the Edevice GPIB bus

unsigned int action;

unsigned int address;

};

unsigned int error;

unsigned int address;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The address must be within the range of 0 and 30. An error of 5 is returned

The returned Gpib_Addr_Resp structure will always contain the current

Edevice GPIB bus address, irrespective of the error value.

0 No error

A-32

The system_controller procedure is used to read/modify the system control-

unsigned int action;

unsigned int controller;

};

unsigned int error;

unsigned int controller;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The controller mode must be either 0 or 1. An error of 5 is returned and the

be invalid.

The returned Sys_Control_Resp structure will always contain the current

0 No error

A-33

The ren_mode procedure is used to read/modify the REN mode. If the REN

unsigned int action;

unsigned int ren;

};

unsigned int error;

unsigned int ren;

};

Ren_Resp ren_mode (Ren_Parms) = 15;

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The ren mode must be either 0 or 1. An error of 5 is returned and the current

REN mode is unchanged if ren is determined to be invalid.

The returned Ren_Resp structure will always contain the current REN mode,

0 No error

A-34

The eos_8bit_mode procedure is used to read/modify the 8-bit EOS compare

unsigned int action;

unsigned int eos8bit;

};

unsigned int error;

unsigned int eos8bit;

};

Eos_8bit_Resp eos_8bit_mode (Eos_8bit_Parms) = 16;

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The eos8bit mode must be either 0 or 1. An error of 5 is returned and the

be invalid.

The returned Eos_8bit_Resp structure will always contain the current 8-bit

EOS compare mode, irrespective of the error value.

0 No error

A-35

The auto_eos_mode procedure is used to read/modify the automatic EOS

be sent with EOI.

unsigned int action;

unsigned int autoEos;

};

unsigned int error;

unsigned int autoEos;

};

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The autoEos mode must be either 0 or 1. An error of 5 is returned and the

The returned Auto_Eos_Resp structure will always contain the current

0 No error

A-36

The eos_active_mode procedure is used to read/modify the EOS active mode.

unsigned int action;

unsigned int eosActive;

};

unsigned int error;

unsigned int eosActive;

};

EosActive_Resp eos_active_mode (Eos_Active_Parms) = 18;

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The eosActive mode must be either 0 or 1. An error of 5 is returned and

the current automatic EOS mode is unchanged if eosActive is determined

to be invalid.

The returned Eos_Active_Resp structure will always contain the current

EOS mode, irrespective of the error value.

0 No error

A-37

The eos_char procedure is used to read/modify the EOS character.

unsigned int action;

unsigned int eos;

};

unsigned int error;

unsigned int eos;

};

Eos_Char_Resp eos_char (Eos_Char_Parms) = 19;

The action value determines whether the client wishes to execute a read of

the current setting, or a modiﬁ cation of the current value.

turned.

The eos character must be in the range of 0x00 through 0xFF. An error of

to be invalid.

The returned Eos_Char_Resp structure will always contain the current

0 No error

A-38

The reload_conﬁ g procedure is used to cause a reload of the conﬁ guration

unsigned int error;

};

Reload_Conﬁ g_Resp reload_conﬁ g (void) = 20;

The returned Reload_Conﬁ g_Resp.error value determines whether the

0 No error

A-39

The reload_factory procedure is used to cause the Edevice to reset the

tions to the default conﬁ guration are lost as a result. Note that dynamic

reboot is executed.

unsigned int error;

};

Reload_Factory_Resp reload_factory (void) = 21;

The returned Reload_Factory_Resp.error value determines whether the Ede-

0 No error

A-40

The commit_conﬁ g procedure is used to cause the current conﬁ guration

reload_conﬁ g or a reboot.

unsigned int error;

};

The returned Commit_Conﬁ g_Resp.error value determines whether the

0 No error

The reboot procedure is used to cause the Edevice to reboot. This causes

unsigned int error;

};

Reboot_Resp reboot (void) = 23;

The returned Reboot_Resp.error value determines whether the Edevice has

block the RPC reply.

0 No error

The idnReply procedure is used to obtain a response similar to the GPIB

};

unsigned int error;

unsigned int length;

unsigned char reply[128];

};

The length determines the length of the data buffer. The maximum length

Error Meaning

0 No error

A-43

The errorLogger procedure is used to obtain the current contents of the

};

unsigned int error;

unsigned int count;

unsigned int errors[100];

};

The error log will contain 100 entries. The count will signify how many are

Note this function returns all entries and ﬂ ushes the error log. Do not run

this function more than 5 times per second to avoid impacting the 8065's

performance and overloading the network.

Refer to the ErrorLogger utility for the error value deﬁ nitions.

Error Meaning

0 No error

This page purposely left blank.

Index-1

Accessories

Accessories, included

AutoFind

Block Diagram

Block Diagram description

IEEE 488

A-

Methods

to benchtop

Default settings

Description

Device Clears

Device Triggers

DHCP

EMI/RFI Warning

Error Codes

Ethernet Interface

Factory

Default settings, recovering

Factory conﬁ guration

Firmware updating

Front Panel Indicators

Functional Description

A-

Index-2

HTML Pages

IEEE-488

A-

Messages

A-

IEEE 488.2 STANDARD

A-

Differences from 488.1

A-1

Message Formats

A-

IEEE 488 Interface

IEEE 488

A-

Message formats (IEEE 488.2)

A-1

IEEE 488 Bus Description

A-

IEEE 488.1

IEEE 488 Interface

488.2 required status reporting

capabilities

A-

A-1

Indicators

Indicators, front panel

Installation

Installation guide

IP Address

IP KeepAlive

Jumper

Locations

KeepAlive

Large Files

LEDs, front panel

LED Header

Pinouts

Lost Linkage

MAC Address

Maintenance

Message Terminators

Model number

N4865A

Block Diagram

Default settings

Description

Firmware update

Front Panel Indicators

HTML Pages

HTML User Conﬁ gurability

IP Address

IP KeepAlive

Jumpers

MAC Address

Model Number

Port Usage

Programmable functions

Theory of Operation

WebServer

Network Settings

Index-3

Documentation

Theory of

PC IP Address

Physical

Physical speciﬁ cations

Port Usage Table

Power Supply

Programmable functions

Programming Guidelines

Linkage lost

Message Terminators

Multiple Device Clears

Multiple Serial Polls

Multiple Triggers

Transferring large ﬁ les

Rack mounting

Rack Mounting Instructions

Recovering factory default set-

tings

Repair

Resetting to factory defaults

Reverting to factory ﬁ rmware

RPC Conﬁ guration Method

Examples

A-1

Example

A-1

example

examples

A-1

Error reporting

A-1

Theory of Operation

Trademarks

Troubleshooting

Troubleshooting Guide

Updating 8065 ﬁ rmware

VXI-11

Warranty

WebServer

Pages

Web Browser Conﬁ guration

Index-4

This page left intentionally blank

ICS N4865A Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
