ICs AUDIO POWER AMPLIFIERS PIN INFO & CROSS Schematic

AudioAudio

Aplikacje

SPIS

OBUDOWA

AUDIO POWER AMPLIFIER

SCHEMAT

Vcc.min Vcc.nom Vcc.max P-out RL. kucist orginal zamena str.

T I P

V V V W ohm

5G31A 6 12 0,4 8 TABS1-14 3
5G31B 6 15 0,7 8 TABS1-14 3
5G31C 6 18 1 8 TABS1-14 3
5G37 6 18 2 8 TABS2-8 3
888-2 9 24 2X 7,5 4 9-SIP TDA1521 106
A1034P 1,6 3 6 2X 30mW 32 16-DIP AN7108 6
A2000V 3,5 9 28 2X 2,8 4 11-SQL TDA2005 109
A2005V 3,5 9 28 2X 2,8 4 11-SQL TDA2005 109
A2030 ± 6 ± 14 ± 18 16 4 TO-220/5 TDA2030 109
A205K 4 15 20 4,5 4 12-DIP+a ~TBA810AS 99
A208E 4 15 20 5 4 TABS3-12 TBA810AS 99
A208K 4 15 20 5 4 TABS3-12 ~TBA810AS 99
A210E 4 15 20 1,3 4 12-DIP+a TBA810AS 99
A210K 4 15 20 5 4 TABS3-12 ~TBA810AS 99
A211D 4,5 9 15 1 8 TABS4-14 ~TAA611 98
AN214(P,Q) 7 13 18 4,4 4 9-SILP 3
AN272 12 20 34 5 8 10-DILP 3
AN313 9 16 20 2X 3 8 16-DILP 3
AN315 6 13 18 5,5 4 11-SILP 3
AN374 6 9 16 1 8 TO-100 3
AN5260 9 24 26 6,6 8 11-SILP 3
AN5265 12 12-16 26 2.3 8 HSIP009 4
AN5270 11 12-18 24 4,3 8 HSIP009 4
AN5272 12,2 18 27,5 2X 4 8 HSIP012 4
AN5273 12,2 18 27,5 2X 4 8 HSIP012 AN5274 4
AN5274 14,2 18 27,5 2X 4 8 HSIP012 AN5273 5
AN5275 10 32 40 2X 15 8 HSIP012 5
AN5276 10 19 24 2X 5 8 HSIP012 AN5277 5
AN5277 10 26 32 2X 10 8 HSIP012 5
AN5278 12 18 26 4,8 8 HSIP012 5
AN7102S 1,5 3 4,2 2X 75mW 32 18-DIP 5
AN7105 4,2 6 9 2X 0,38 8 18-DIP 6
AN7106K 1,8 3 4,5 2X 0,14 8 24-SDIP 6
AN7108 2,4 4,5 6 2X 30mW 32 16-DIP CXA1034 6
AN7110 6 9 18 1,2 8 9-SIP AN7130 7
AN7111 6 9 18 1,2 8 9-SIP AN7140 7
AN7112 6 9 14 0,7 16 9-SIP LA4140 7
AN7114 4 6 11 1 4 14-DIP+g AN1115 7
AN7115 6 9 13 2,1 4 14-DIP+g 7
AN7116 4,5 6 9 0,77 4 9-SIP 7
AN7117 4,5 6 9 0,65 4 9-SIP 7
AN7118 2,4 3 4,5 2X 13mW 4 DIP-16 7
AN7118S 2,4 3 4,5 2X13mW 4 18-MDIP 7
AN7120 6 9 18 2,1 4 14-DIP+g 8
AN7124 5 12 18 2X 5 3 HSIP012 8
AN7125 5 12 18 2X 12 4 HSIP012 8
AN7130 9 13 18 4,2 4 9-SIL 7
AN7131 9 13 24 5 4 9-SIL AN7140 7
AN7133N 9 12 24 2X 5,8 3 23-SQL 8
AN7134NR 9 15 24 2X 7,5 3 23-SQL 9
AN7135 5 15 18 2X 7,5 3 HSIP012 9
AN7139 6 9 18 2X 2,1 4 12-SIL HSIP012 AN7148 9
AN7140 9 13 24 5 4 9-SIL 7
AN7142 3,8 6 18 2X 1 4 16-DIP+g 10
AN7143 4,8 9 24 2X 2 4 12-SIL 10
AN7145H 8 16 24 2X 4,5 8 18-DILP 10
AN7145L 5 6 20 2X 1 4 18-DILP ~AN7145H 10
AN7145M 6 9 20 2X 2,4 4 18-DILP ~AN7145H 10
AN7146H 8 16 24 2X 4,5 8 18-DILP AN7145H 10
AN7146M 6 9 20 2X 2,3 8 18-DILP AN7145M,H 10
AN7147N 5 12 22 2X 5,3 3 12-SIL HSIP012 AN7149N 9
AN7148 6 9 18 2X 2,1 4 12-SIL HSIP012 AN7139 9
AN7149N 5 12 22 2X 5,3 3 12-SIL HSIP012 AN7147N 9
AN7150 9 13 18 5,7 4 11-SIP AN7154 10
AN7151 9 13 18 5,7 4 11-SIP AN7155 10
AN7154 9 13 24 5,5 4 11-SILP 10
AN7155 9 13 24 5,5 4 11-SILP 10
AN7156N 8 13 24 2X 5,5 4 12-SILP 11
AN7158N 9 16 24 2X 7,5 4 12-SILP 11
AN7161 10 15 26 2X 10 4 12-SIL 11
AN7161N 6 15 26 23 4 12-SILP 11
AN7162K 7 13,2 18 14 4 9-SILP 11
AN7163 8 13,2 24 17 4 12-SIL 11
AN7164 8,3 21 24 30 8 12-SIL HSIP012 11
AN7164N 8,3 26,4 30 47 8 HSIP012 11
AN7166 9 13 24 2X 5,5 4 12-SILP 11
AN7168 8 13 24 2X 5,7 4 12-SILP AN7169 12
AN7169 9 13 24 2X 5,7 4 12-SILP 12
AN7170 8 26,4 35 9,5 8 11-SILP HSIP011 12
AN7171NK 9 13 24 2X 9 4 16-SQL 12

e

AUDIO POWER AMPLIFIER

143

Vcc.min Vcc.nom Vcc.max P-out RL. kucist orginal zamena str.

T I P

V V V W ohm

AN7173NK 9 13,2 24 2X 12,5 4 16-SQL HZIP16 12
AN7174K 9 13,2 24 2X 14 4 16-SQL 12
AN7176 9 13 24 2X 7,5 4 12-SIL 12
AN7176BTL 9 13 24 14 4 12-SIL 12
AN7176K 8 13,2 24 14 4 12-SIL 12
AN7177 9 13 24 2X 18 4 23-SQL 13
AN7178 8 12 18 2X 5,7 3 12-SIL AN7168 12
AN7188K 9 13 24 2x 18 4 16-SQL 13
AN7190NK 8 13,2 18 2X 18 4 HZIP16 13
AN7190NZ 8 13,2 18 2X 18 4 HZIP15 13
AN7194K 6 12 24 2X 10 4 HZIP016 13
AN7194Z 6 12 24 2X 10 4 HZIP015 13
AN7195K 8 13,2 18 2X 14 4 HZIP016 13
AN7195Z 8 13,2 18 2X 14 4 HZIP015 13
AN7198Z 8 13,2 18 2X 18,5 4 HZIP015 13
AN7199Z 8 13,2 18 2X 18,5 4 HZIP015 14
AN7510 3 5 13,5 2X 1 8 HDIP016 14
AN7510S 3 5 13,5 2X 0,5 16 SOP016 14
AN7510SH 3 5 12 2X 1,1 8 HSOP056 14
AN7511 3 5 13,5 1 8 DIP008 14
AN7511S 3 5 13,5 0,5 16 SOP008 14
AN7512 3,5 5 13,5 2X 1 8 HDIP016 14
AN7512S 3,5 5 13,5 2X 0,5 16 SOP016 14
AN7512SH 3 5 12 2X 1 8 HSOP056 14
AN7513 3,5 5 13,5 1 8 DIP008 14
AN7513S 3,5 5 13,5 0,5 16 SOP008 14
AN7522 3,5 8 13,5 2X 3 8 HSIP012 15
AN7523 3,5 8 13,5 1X 3 8 HSIP009 15
AN7535NSA 1,8 2,6 3,4 2X 30mW 16 SSOP024 15
AN7550NZ 8 13,2 18 4X 19,5 4 HZIP025 15
AN7551Z 8 13,2 18 4X 19,5 4 HZIP025 15
AN7555Z 8 13,2 18 4X 19,5 4 HZIP025 15
AN7560Z 8 13,2 18 4X 19,5 4 HZIP025 15
AN7561Z 8 13,2 18 4X 19,5 4 HZIP025 12
BA3506A 1,8 3 1,5 2X 0,6 16 16-DIP 16
BA3516 2,4 3 5 2X 0,2 32 16-DIP 16
BA501 8 13 18 4 4 8-SIL 16
BA511 9 13 15 4,5 4 10-SIL BA532 16
BA514 6 9 12 2 4 8-SIL 16
BA515 3 9 15 0,23 4 12-SQP 16
BA5152F 1 1,5 1,8 2X 12mW 16 16-MDIP 17
BA518 2,5 12 1,5 8 8-SIL BA547 17
BA5204 1,5 3 4,5 2X 35mW 16 16-SQP 17
BA5204F 1,5 3 4,5 2X 35mW 16 16-MDIP 17
BA5206BF 1,8 3 4,5 2X 64mW 16 16-MDIP 17
BA5208AF 2 3 4,5 2X 24mW 4 16-DIP 17
BA521 9 13 16 5,8 4 10-SIL BA532 16
BA524 9 12 15 3,8 4 10-SIL 17
BA526 3 6 9 0,43 8 9-SIP BA527 18
BA527 3 6 10 0,8 4 9-SIP KIA6278S 18
BA5302A 6 9 13 2X 2,4 4 12-DIP+b BA5304 18
BA5304 6 9 13 2X 3 3 12-DIP+b 18
BA532 6 13 16 5,8 4 10-SIL 16
BA534 6 9 12 2,3 4 10-SIL HSIP10 BA524 17
BA535 8 12 20 2X 4,8 4 12-SILP ~BA536 18
BA536 8 12 18 2X 4,5 4 12-SILP BA5402,A 18
BA5386 4 9 12 0,32 8 8-DIP 18
BA5402,A 8 12 18 2X 4,2 4 12-SILP BA5406 18
BA54021 9 12 19 2X 4,2 4 12-SILP 18
BA5404 6 12 20 0,36 32 9-SIP 18
BA5406 5 12 15 2X 5 3 12-SILP SIP12 BA536 18
BA5408 12 15 28 2X 7,5 4 12-SILP 18
BA5410 6 12 20 2X 5,2 3 10-SIL HSIP010 18
BA5412 9 12 24 2X 5,4 3 12-SILP 18
BA5413 9 12 24 2X 5,4 3 12-SIL 18
BA5415A 5 12 18 2X 5,4 3 12-SILP SIP-M12 18
BA5415A BTL 5 12 18 12-SILP SIP-M12 18
BA5416 5 12 15 12-SIL 18
BA5416 BTL 5 12 15 2X 5,4 3 12-SIL HSIP-B12 18
BA5417 6 12 15 2X 5 3 HSIP15 19
BA5417BTL 19
BA546 3 6 12 0,33 8 9-SIP BA527 18
BA547 2,5 12 1,5 8 8-SIL BA518 17
BW4100 3 6 12 1 4 14-DIP+g LA4100 37
BW4101 3 6 12 1,5 4 14-DIP+g LA4101 37
BW4102 3 9 12 2,1 4 14-DIP+g LA4102 37
BW4112 6 9 12 2,3 4 14-DIP+g LA4112 37
CA2002 11 14,4 28 8 2 TO220/5V TDA2002V 109
CA2002M 11 14,4 18 8 2 TO220/5H TDA2002H 109
CA2004 8 24 28 12 4 TO220/5 ~TDA2004 109

144

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. kucist orginal zamena str.

T I P

V V V W ohm

CA2004M 8 24 28 12 4 TO220/5 ~TDA2004 109
CA3020 6 9 12 0,5 TO-101 19
CA3020A 6 9 12 1 TO-101 19
CA3131 9 24 5 8 TABS6-16 19
CA3132 9 24 5 8 TABS6-16 19
CD1034 1,5 9,5 2X 0,38 32 16-DIP AN7108 6
CX20089A 0,9 1,25 4,5 2X 4mW 32 19
CX20172 0,9 2,2 4,5 2X 21mW 8 19
CXA1005P 1,5 3 6 2X 0,38 32 16-DIP AN7108 6
CXA1034P 1,5 3 9 2X 0,35 32 16-DIP AN7108 6
CXA1189M 2,2 3 6 2X 30mW 32 20
CXA1289M 1,5 3 6 2X 30mW 32 20
CXA1622M 1,8 3 4,5 2X 011 8 16-MDIP 20
CXA1622M-MOS. 1,8 3 4,5 2X 0,32 8 16-MDIP 20
CXA1622P 1,8 6 7 2X 0,45 8 16-DIP 20
CXA8008P 2,2 3 4,5 2X 30mW 32 18-DIP 21
D1005P 1,5 3 9,5 2X 0,35 32 16-DIP AN7108 6
D2283 3 9 15 1,2 8 DIP-8 ULN2283B 132
D7232P 3,5 9 12 2X 2,2 4 12-SIL TA7232P 88
D7240P 9 13 18 2X 5,8 4 12-SIL TA7240P 89
DG4100 3 6 12 1 4 14-DIP+g LA4100 37
DG4101 3 6 12 1,5 4 14-DIP+g LA4101 37
DG4102 3 9 12 2,1 4 14-DIP+g LA4102 37
DG810DS 4 14,4 20 6 4 12-QIP+a TBA810 99
ESM1231C 12 28 32 20 4 11-SIL 21
ESM1432 ± 15 20 4 11-SIL 21
ESM1532C ± 16 20 4 11-SIL 21
ESM1632C ± 13 14 4 11-SIL 21
ESM1732C ± 9 8 2 11-SIL 21
ESM231 9 18 24 15 4 14-QIP+d TDA1042 21
ESM432C 9 28 30 20 4 11-SIL ESM532C 21
ESM432N 9 28 30 20 4 14-QIP+d 21
ESM532C 9 28 32 20 4 11-SIL 21
ESM532N 9 28 32 20 4 14-QIP+d 21
ESM632C 9 24 26 14 4 11-SIL ESM532C 21
ESM632N 9 24 26 14 4 14-QIP+d 21
ESM732C 9 14 18 8 4 11-SIL 21
FD4100 3 6 12 1 4 14-DIP+g LA4100 37
FD4112 6 9 12 2,3 4 14-DIP+g LA4112 37
FY4112 6 9 12 2,3 4 14-DIP+g LA4112 37
GML005 18 22 24 2 8 22
GML006 30 34 5 15 22
GML007 -24 -34 1,5 15 22
GML008 30 34 2 15 22
GML024 9 12 32 8 8 10-SIP 22
GML025 18 20 43 32 4 10-SIP 22
GML026 9 12 32 10 8 10-SIP 22
GML040 ± 26 ± 33 40 4 22
HA13001 8 13,2 26 2X 5,5 4 12-SIL 23
HA13008 8 13.2 18 2X 5,5 4 12-SIL 23
HA1306W 9 13 18 3,5 4 10-QIP+f 23
HA1308 9 13 28 5 8 10-SIL 23
HA1309 9 13 33 6 8 10-SIL 23
HA1310 6 9 12 0,5 8 11-SILP 23
HA13102 9 13,2 18 2X 5,5 4 12-SIL 23
HA13104 9 13 16 5,5 4 12-SILP 23
HA13108 8 13,2 18 2X 4,3 4 12-SIL 23
HA13115 18 24 40 2X 6 8 12-SILP 23
HA13116 8 13,2 18 20 4 15-SQL 24
HA13117 8 13,2 18 14 4 15-SQL 24
HA13118 8 13,2 26 18 4 15-SQL SP15-TA 24
HA13119 8 13,2 18 2X 5,5 4 15-SQL 24
HA1312 6 9 12 1 12-QIP+a 24
HA13127 8 14,4 18 2X 17 4 16-SQL HA13128 24
HA13128 8 14,4 18 2X 22 4 16-SQL 24
HA1313 9 13 20 2 8 11-SILP 23
HA13130 8 14,4 18 2X 22 4 16-SQL HA13135 24
HA13135 8 14,4 18 2X 22 4 16-SQL 24
HA1314 6 9 12 1 8 11-SIP 23
HA13150A 8 13,2 18 4X 18 4 23-SQL SP-23TE 25
HA13151 8 13,2 18 4X 14 4 23-SQL SP-23TE 25
HA13152 8 13,2 18 4X 14 4 23-SQL SP-23TE HA13151 25
HA13153A 8 13,2 18 4X 15 4 23-SQL SP-23TE 26
HA13154A 8 13,2 18 4X 14 4 23-SQL SP23-TE HA13153A 26
HA13155 8 13,2 18 4X 19 4 23-SQL SP-23TE 25
HA13156 8 13,2 18 4X23 4 28-SQL SP-28TA 26
HA13158A 8 13,2 18 4X 20 4 23-SQL SP-23TE HA13159 25
HA13159 8 13,2 18 4X 22 4 23-SQL SP-23TE 25
HA1316 4,5 6 10 0,7 8 11-SIP 23
HA1317,V,W,VU,WU 20 26 36 8 8 10-DIP+g 24

AUDIO POWER AMPLIFIER

145

Vcc.min Vcc.nom Vcc.max P-out RL. kucist orginal zamena str.

T I P

V V V W ohm

HA1322W 9 13 18 5,5 4 10-DIP+f 24
HA1324 9 13 18 4,5 4 10-DIP+g 24
HA1325 9 13 20 2 8 12-DIP+a 26
HA1329 3 6 9 2,5 8 12-DIP+a 26
HA1338 20 24 33 6 8 10-QIP+f 27
HA1339A 8 13 18 5,5 4 10-SILP+a 27
HA1339AR 8 13 18 5,5 4 10-SILP+a 27
HA1342A 8 13 18 5,5 4 10-SILP+a 27
HA1342AR 8 13 18 5,5 4 10SILP+a 27
HA1345V 20 26 36 8 8 10-SILP 27
HA1350 ± 20 ± 25 ± 30 18 8 10-SILP HA1370 27
HA1361 4,5 6 9 1 4 12-DIP+d 27
HA1366W 8 13,2 18 5,5 4 10-SILP+a 27
HA1366WR 8 13,2 18 5,5 4 10-SILP+a 27
HA1367A 4,5 6 9 2,2 4 20-DIP+b 28
HA1368 9 13 18 5,3 4 10-SILP+a 27
HA1368R 9 13 18 5,3 4 10-SILP+a 27
HA1370 ± 22 ± 25 ± 30 18 4 10-SILP 27
HA1371 6 9 15 7,3 4 12-QIP+d 27
HA1372 9 13 18 5,5 4 10-DIP+f 28
HA1374 8 15 22 2X 3 8 10-SILP+a 28
HA1374A 8 17 25 2X 4 8 10-SILP+a 28
HA1377,A 8 13 18 2X 5,8 4 12-SIL 28
HA1384 10 13,2 18 20 4 12-SIL 28
HA1388 10 13,2 18 18 4 12-SIL 28
HA1389 15 22 30 7 8 10-SILP+a 29
HA1389R 15 22 30 7 8 10-SILP+a 29
HA1392 8 12 20 2X 4,3 4 12-SIL 29
HA1393 10 13,2 18 19 4 12-SIL 29
HA1394 18 25 35 2X 8,2 8 12-SIL 29
HA1395 9 18 25 2X 10 8 12-SIL 29
HA1396 9 13 18 20 4 12-SIL 29
HA1397 ± 22 ± 30 20 4 12-SIL 29
HA1398 8 14,4 20 2X 4,2 4 12-SIL 28
HA2214 3 2X 1,6 4 MDIP-14 29
HLX1402R 32 38 13 8 30
HLX1403R 20 34 43 25 4 30
IR3R22 1,5 3 8 70mW 4 8-DIP 30
IX0250CE 6 9 14 4,5 4 12-SQL 30
IX0365CE 6 12 20 6 4 12-SQL 30
IX1020 3 9 16 3,6 4 12-QIP+a 30
K1021YH1 6 35 5 8 9-SQL 140
K148YH1 ± 12 1 30 138
K148YH2 6 9 12 1 4 138
K174YH11 ± 5 ± 15 ± 18 10 4 14-DIP TDA2020 138
K174YH11 BTL ± 5 ± 15 ± 18 15 4 139
K174YH14 8 15 18 5,5 4 TO-220/5 TDA2003 138
K174YH15 13 15 16,5 2X 9 2 11-SQL TDA2004 139
K174YH17 1,8 3 6,6 2X 10mW 16 16-MDIP TA7688F 139
K174YH18 5 9 12 2X 1 4 17-SQL 140
K174YH19 I ± 6 ± 15 ± 18 15 4 TO-220/5 140
K174YH19 II ± 6 ± 15 ± 18 15 4 TO-220/5 140
K174YH4A 5,4 9 9,9 1 4 8-DIP+a TAA300 138
K174YH4B 5,4 9 9,9 1 4 8-DIP+a TAA300 138
K174YH5 9 12 14 2 4 12-DIP+a 138
K174YH7 9 12 18 4,5 4 12-DIP+a 138
K174YH8 9 12 18 2 4 12-DIP+a 138
K174YH9 12 18 24 5 4 12-DIP+a TBA810AT 99
K224YH16 -25 -33 4 8 16-SIP 139
K224YH17 ± 20 ± 20 4 17-SIP 139
KA2201,A,B,N 3 9 14 1,2 8 8-DIP TBA820M 30
KA2202 4 9 16 1 4 14-QIP+g 30
KA2203 4 9 14 1,2 8 14-DIP+g 31
KA2204 6 12 18 6 4 10-SILP 31
KA2205 6 12 18 5,8 4 10-SILP 31
KA22061 6 9 14 2X 2,3 4 12-DIP+b 31
KA22061BTL 6 9 14 4,7 8 12-DIP+b 31
KA22062 6 12 16 2X 4,5 4 12-SIL TA7283AP 31
KA22065 6 12 15 2X 4,6 4 12-SIL TA8207K 32
KA2206B 6 9 15 2X 2,3 4 12-DIP+b KA22061 31
KA2206BTL 6 9 15 4,7 8 12-DIP+b KA22061 31
KA2207 5 12 20 2,3 4 14-QIP+g 30
KA2209B 1,8 6 9 2X 0,65 4 8-DIP TDA2822M 31
KA2209BTL 1,8 6 9 8-DIP TDA2822M 31
KA2210 9 13,2 18 2X 5,5 4 12-SIL ~LA4445 32
KA22101 9 13,2 18 23 4 12-SQL TA7250BP 32
KA22103 9 13,2 18 2X 19 4 17-QILP TA8210H 32
KA2210BTL 9 13,2 18 12-SIL ~LA4445 32
KA2211 9 1213,2 18 2X 5,8 4 12-SIL 32
KA2212 3,5 6 12 0,5 8 9-SIP LA4140 32

146

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. kucist orginal zamena str.

T I P

V V V W ohm

KA22132 1,6 4,6 6 2X 30mW 32 16-DIP AN708 6
KA2214 3 9 13 2X 1,2 8 14-DIP+g uPC1263C 32
KB4433A 1,6 3 6 2X 0,15 4 16-DIP 33
KD-28 3 9 15 2X 1,8 4 8-DIP 33
KIA4227 9 13,2 18 2X 5,5 4 14-DIP+g 33
KIA6205AH 9 13,2 25 2X 15 4 17-QILP+s TA8205AH 33
KIA6210AH 9 14,4 18 2X 22 4 17-QILP+s 33
KIA6216H 9 14,4 18 2X 15 4 17-QILP+s 33
KIA6220H 9 14,4 18 2X 26 2 17-QILP+s 33
KIA6221AH 9 14,4 18 2X 26 2 17-QILP+s 33
KIA6227 8 14,4 24 2X 12 4 34
KIA6248K 6 14,4 18 2X 7,3 2 spec. 34
KIA6248K-BTL 6 14,4 18 18 spec. 34
KIA6269P 4,5 6 9 2X 1 4 16-DIP 34
KIA6278S 2 6 10 0,72 4 9-SIP AN7118 34
KIA6280H 6 14,4 15 2X 5,8 4 12-SQL 34
KIA6281H 6 14,4 15 2X 5,8 4 12-SQL 34
KIA6283K 6 14,4 15 2X 3 4 12-SIL 34
KIA6419P 2 3….12 16 0,4 32 8-DIP 35
KIA7208 8 14 0,95 4 10-silp 35
KIA7217A,P 9 13 18 5,8 4 10-SIL 35
KIA7227 5,5 12-SQL 34
KIA7299 9 13,2 18 2X 5,8 4 12-SQL 35
L133T 5 18 30 5 8 TO-3/8 36
L142 8 14,4 18 10..20 TO-220/5 TDA2003 36
L149 ± 16 ± 20 20 4 TO-220/5 36
L165 ± 9± 10 ± 15 ± 18 18 4 TO-220/5 35
L165 +36 18 4 TO-220/5 35
L272M 4 12 28 2X 0,56 10 8-DIP 36
L272M BTL 4 12 28 2,5 10 8-DIP 36
L2750 4 14,4 28 2X 10 4 11-SQL 36
L2750 BTL 4 14,4 28 22 4 11-SQL 36
LA4030 6 11 16 1 8 8-DIP+a LA4032 37
LA4031 9 13 18 2 8 8-DIP+a LA4032 37
LA4032 12 18 25 3 8 8-DIP+a 37
LA4050P 9 11 16 1 8 8-DIP+a LA4051 37
LA4051P 12 17 23 2,5 8 8DIP+a 37
LA4100 4,5 6 9 1 4 14-DIP+g LA4102 37
LA4101 4,5 7,5 11 1,5 4 14-DIP+g LA4102 37
LA4102 6 9 13 2,1 4 14-DIP+g 37
LA4108 9 12 18 2X 5,3 4 20-DIP 37
LA4110 4,5 6 9 1 4 14-DIP+g LA4112 37
LA4112 6 9 12 2,3 4 14-DIP+g 37
LA4120 4,5 6 12 2X 1 2/8 20-DILP LA4126T 37
LA4125 6 9 12 2X 2,4 2/8 20-DIP+c LA4126T 37
LA4125T 9 12 14 2X 4,2 4/8 20-DIP+c LA4126T 37
LA4126 6 9 12 2X 2,4 4 20-DIP+c LA4125T 37
LA4126T 6 12 14 2X 4,2 4 20-DIP+c LA4125T 37
LA4137 6 7,5 11 1,8 3,2 14-DIP+g LA4138 37
LA4138 6 9 13 2,7 3,2 14-DIP+g 37
LA4140 4,5 6 9 0,5 8 9-SIP AN7112 38
LA4145 3,5 6 9 0,9 4 9-SIP LA4146 38
LA4146 3,5 6 9 0,9 4 9-SIP ~LA4145 38
LA4147 3,6 6 9 0,9 4 9-SIP 38
LA4162 3,6 6 11 0,5 8 16-DIP 38
LA4170 6 8 14 2X 0,1 8/200 14-DIP+g ~LA4175 38
LA4175 9 12 14 2X 0,1 39 14-DIP+g ~LA4170 39
LA4177 4,5 6 9 2X 0,1 32 14-DIP+h ~LA4175 39
LA4178 3 6 12 2X 0,1 32 14-DIP+h 39
LA4180 4,5 6 9 2X 1 4 14-DIP+b LA4182 39
LA4180 BTL 4,5 6 9 2 8 12-DIP+b LA4182 39
LA4182 4,5 9 12 2X 2,3 4 12-DIP+b LA4183 39
LA4182 BTL 4,5 9 12 4,6 8 12-DIP+b LA4183 39
LA4183 4,5 9 12 2X 2,3 4 12-DIP+b LA4182 39
LA4183 BTL 4,5 9 12 4,7 8 12-DIP+b LA4182 39
LA4185 6 9 13 2X 2,4 4 14-SILP LA4185T 39
LA4185T 9 12 18 2X 4,2 4 14-SILP 39
LA4185T BTL 6 9 15 7,7 4 14-SILP 39
LA4190 4,5 6 9 2X 1 4 12-DIP+b LA4192 39
LA4192 4,5 9 11 2X 2,3 4 12-DIP+b 39
LA4195 6 9 13 2X 2,4 4 20-DILP LA4195T 39
LA4195T 9 12 18 2X 4,2 4 20-DILP 39
LA4200 8 11 16 1,5 8 14-DIP+g LA4201 39
LA4201 8 14 20 2,5 8 14-DIP+g 39
LA4220 9 16 22 3,5 8 10-SIL 40
LA4230 12 22 31 6 8 12-SIL LA4250 40
LA4250 12 25 35 8 8 12-SIL ~LA4250 40
LA4260 11 14 22 2X 2,5 8 10-SIL LA4261 40
LA4261 11 16 25 2X 3,5 8 10-SIL LA4270 40
LA4265 11 16 25 2X 3,5 8 10-SIL 40

AUDIO POWER AMPLIFIER

147

Vcc.min Vcc.nom Vcc.max P-out RL. kuciste orginal zamena str.

T I P

V V V W ohm

LA4270 11 25 35 2X 6 8 10-SIL 40
LA4275 11 23 25 6 8 7-SIL 40
LA4280 10 30 32 2X 10 8 14-SILP 40
LA4282 10 30 32 2X 10 8 12-SILP 40
LA4400 8 13 18 4,5 4 12-SIL 40
LA4420 9 13 18 5,5 4 10-SIL 41
LA4422 I 9 13 18 5,8 4 10-SIL 41
LA4422 II MOSNA 41
LA4425 5 13,2 18 5 4 TO-220/5 41
LA4430 9 13,2 18 4,5 4 10-SIL LA4420 41
LA4440 8 13 18 2X 6 4 14-SILP 41
LA4440 BTL 8 13 18 19 4 14-SILP 41
LA4443 41
LA4445 9 13 18 2X 5,5 4 12-SILP KA2210 42
LA4445BTL 9 13 18 12 4 12-SILP KA2210 42
LA4446 10 13 18 2X 5,5 4 13-SIL 42
LA4446BTL 10 13 18 12 4 13-SIL 42
LA4450 15 26,4 37 2X 20 4 14-SILP 42
LA4460N 9 13 18 12 4 10-SILP 42
LA4461N 9 13 18 12 4 10-SILP 42
LA4465 9 13 18 12 4 10-SILP 42
LA4466 9 13 18 12 4 10-SILP 42
LA4467 10 13 18 12 4 12-SILP 43
LA4468 10 13 18 12 4 12-SILP 43
LA4470 9 13 18 20 4 14-SILP 43
LA4471 9 13 18 20 4 14-SILP 43
LA4475 14,4 18 20 4 14-QILP 43
LA4476 14,4 18 20 4 14-QILP 43
LA4480 8 13 18 2X 4 4 12-SILP 43
LA4485 43
LA4490 9 13 18 20 4 14-SILP 43
LA4491 9 13 18 20 4 14-SILP 43
LA4495 14,4 18 20 4 14-QILP 43
LA4496 14,4 18 20 4 14-QILP 43
LA4497 14,4 18 20 4 14-QILP 43
LA4498 14,4 18 20 4 14-QILP 43
LA4500 9 12 24 2X 5,3 3 20-DILP LA4505 43
LA4500 BTL 9 15 24 12 3 20-DILP 44
LA4505 9 15 24 2X 8,5 3 20-DILP 43
LA4505 BTL 9 15 24 18 3 20-DILP 44
LA4507 BTL 9 16 24 9 8 14-SILP 43
LA4508 9 15 24 2X 8,5 3 14-SILP 43
LA4509 9 15 24 2X 8,5 3 14-SILP 43
LA4510 3 6 0,24 4 9-SIP 43
LA4520 4,5 6 10 2X 0,24 32 20-DIP 43
LA4530M 1,8 3 5 2X 36mW 32 20-MDIP 45
LA4530S 1,8 3 5 2X 36mW 32 16-SQP 46
LA4533M 1,6 3 4 2X 0,3 16 10-SMDIP 45
LA4534M 1,6 3 4 2X 0,3 16 10-SMDIP 45
LA4535M 0,9 1,5 4 2X 0,3 16 10-MDIP 45
LA4537M 0,9 1,5 4 2X 0,3 16 10-SMDIP 45
LA4538M 0,9 1,5 4,5 2X 8mW 16 14-SMDIP 45
LA4540 7 15 15 18 4 18-SQL 45
LA4550 4,5 9 13 2X 1 4 12-DIP+b LA4555 45
LA4550 BTL 4,5 9 13 2,5 8 12-DIP+b LA4555 45
LA4555 6 9 12 2X 2,3 4 12-DIP+b 45
LA4555 BTL 6 9 12 4,5 8 12-DIP+b 45
LA4557 6 9 12 2X 2,4 4 12-DIP+b 46
LA4557 BTL 6 9 12 4,6 8 12-DIP+b 46
LA4558 7,5 9 12 2X 2,4 4 12-DIP+b 46
LA4558 BTL 7,5 9 12 4,5 8 12-DIP+b 46
LA4560M 4,5 6 2X 0,12 32 24-MDIP 46
LA4570 I 1,8 3 4,5 2X 40mW 16 16-DIP 46
LA4570 II 1,8 3 4,5 2X 40mW 16 16-DIP 47
LA4570M I 1,8 3 4,5 2X 40mW 16 16-MDIP 46
LA4570M II 1,8 3 4,5 2X 40mW 16 16-MDIP 47
LA4571MB 1,8 3 4,5 2X 40mW 16 20-MDIP 47
LA4575 1,8 3 4,5 2X 20mW 16/32 16-DIP 47
LA4575M 1,8 3 4,5 2X 20mW 16/32 16-MDIP 47
LA4580M 1,8 3 4,5 2X 0,2 16/32 20-MDIP 48
LA4597 6 9 18 2X 2,9 3,2 13-SIL 47
LA4598 6 9 18 2X2,9 3,2 14-QILP 47
LA4620 8 15 24 2X 17 4 23-QILP 48
LA4630N 8 12 24 2X 5+10 3 18-SILP 48
LA4700N 9 13 18 2X 12 4 18-SILP 49
LA4705 8 14,4 24 2X 15 4 18-SILP 49
LA4708 8 14,4 24 2X 20 4 18-SILP 49
LA4725 9 14,4 16 2x 30 4 14-SILP 49
LA4728 9 14,4 16 2x 35 4 14-SILP 49
LA4800V 1,8 3 3,6 3 16SSMDIP 50

148

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

LA4805V 1,8 3 3,6 30SSMDIP 50
LH0021 ± 5 ± 12 ± 18 10 TO-3/8 50
LH0041 ± 5 ± 14 ± 18 100 TO-8/12 50
LH0101 ± 7 ± 19 30 4 50
LM12 ± 30 150 4 51
LM13080 3 9 1 4 8-DIP 51
LM1875 ± 10 ± 15 ± 22 25 4 TO-220/5 51
LM1877N…N-8 6 20 24 2X 2 8 14-DIP 51
LM1893 6 12 1 8 51
LM1895 3 6 18 1,1 4 8-DIL 51
LM1896 3 6 9 2X 1,1 4 14-DIP 52
LM2002A 2 16 25 10 2 TO-220/5 TDA2003 53
LM2005 8 14 18 2X 10 4 11-SQL TDA2005 109
LM2877 6 20 24 2X 4,5 8 11-SIL 51
LM2878 6 22 32 2X5,5 8 11-SIL 51
LM2879 6 28 32 2X 8 8 11-SQL 51
LM2895 3 12 15 4,3 4 11-SIL 51
LM2896 3 12 15 2X 2,5 8 11-SIL 52
LM377N 10 20 26 2X 2 8 14D-DIP LM1877 51
LM378N 10 24 35 2X 4 8/16 14-DIP 51
LM379S 10 28 35 2X 6 8 14-DIP+d 51
LM380N 10 18 22 2,5 8 14DIP 52
LM380N-8 10 18 22 2,5 8 8-DIP 52
LM383A 5 14,7 25 7 3 TO-220/5 TDA2003 53
LM383AT 5 14,7 40 7 2 T0-220/5 TDA2003 53
LM384N 12 22 26 5 8 14-DIP 52
LM386N-1 4 6 12 0,325 8 8-DIP 53
LM386N-3 4 9 12 0,7 8 8-DIP 53
LM386N-4 5 16 18 1 32 8-DIP 53
LM387AN 9 24 40 0,5 8-DIP NJM387 53
LM387N 9 24 30 0,5 8-DIP NJM387 53
LM387V 9 18 28 0,6 14-DIP 53
LM388N-1 4 12 16 2,2 8 14-DIP 53
LM388N-2 4 6 12 0,9 4 14-DIP 53
LM388N-3 5 16 18 3,8 8 14-DIP 53
LM389 4 9 12 0,5 16 18-DIP 53
LM390N 4 6 9 1 4 14-DIP 53
LM4701T ± 10 ± 10/32 ±32 30 4 11-SQL 53
LM4752T 24 2X 11 4 7-SQL 54
LM4755T 24 2X 11 4 9-SQL 54
LM4861 2,7 5 5,5 1,9 4 8-MDIP 54
LM4862M,N 2,7 5 5,5 0,69 4 8-(M)DIP 54
LM4871M,N 5 1,1 8 8-MDIP 54
LM675 ± 6 ± 25 ± 30 25 8 TO-220/5 54
LM820M 3 9 16 2 4 8-DIL TBA820M 99
LM831 II-MONO 1,6 5 6 8 16-(M)DIP 54
LM831 I-MONO 1,6 5 6 8 16-(M)DIP 54
LM831 I-STEREO 1,6 5 6 2X 044 8 16-(M)DIP 54
LS045 20 40mW 600 T0-99 55
M5106P 9 12 15 1 8 14-DIL 55
M51101L 9 14,4 18 2X 5 4 12-SIL 55
M51102L 9 14,4 18 2X 5,5 4 12-SIL 55
M51103L 10 13 18 5,5 4 9-SIL 55
M5112Y 9 13 18 5 4 10-SQL 55
M51182L 3 9 15 0,38 16 8-SIP 55
M5118L 3 9 15 0,38 8 8-SIP 55
M51501L 3,5 6 10 0,4 8 8-SIP 55
M51503L 2 3 7,5 0,22 8 8-SIP 56
M51512L 10 13 18 4 4 10-SIL 56
M51513L 9 13 16 5,8 4 10-SIL 56
M51513R 9 13 16 5,8 4 10-SIL 56
M51514L 9 13 18 5,5 4 10-SIL 56
M51515BL 9 13 18 2X 5,5 4 14-SILP M51517L 56
M51515L 9 13 18 2X 5,5 4 14-SILP M51517L 56
M51516L 9 13 18 12 4 9-SIL 56
M51517L 9 13 18 2X 5,5 4 14-SILP 56
M51518L 9 13 18 5,5 4 9-SIL 56
M5155L 3,5 6 12 1 8 9-SIL 56
M5160 7,5 30 2X 7,5 4 12-SIL 57
M51601L 9 12 20 2X 4,5 4 12-SIL 57
M51602P 1,8 3 4,5 2X 32mW 32 16-MDIP 57
MA7307 3 9 16 1,6 8 8-DIP 57
MA759 9 12 15 2 32 TO-200 57
MB3705 9 13 18 4,4 4 8-SIL 57
MB3712 9 13 18 5,7 4 8-SIL 57
MB3713 9 13 18 5,7 4 8-SIL 57
MB3714A 8 13 18 6 4 8-SIL 57
MB3715A 8 13 18 6 4 8-SIL 57
MB3722 9 13,2 18 2X 5,8 4 12-SILP 58
MB3730 8 13,2 18 12 4 7-SILP MB3730A 57

AUDIO POWER AMPLIFIER

149

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

MB3730A 8 13,2 18 14 4 7-SILP 57
MB3731 8 13,2 18 18 4 12-SILP 58
MB3732 8 13,2 18 14 4 7-SILP 58
MB3733 8 13,2 18 20 4 12-SILP 58
MB3734 8 13,2 18 14 4 9-SIL 58
MB3735 8 13,2 18 20 4 9-SIL 58
MB3736 8 13,2 18 23 2 12-SQL 58
MB3737A 8 13,2 18 26 2 12-SQL 58
MB3742 9 13,2 16 2X 15 4 17-SQL 58
MC13060 6 16 32 1-2 16/32 SOP-8 59
MC1306P 6 12 15 0,5 8 8-DIP 59
MC1316 6 12 15 1 8 14-DIP 59
MC13500T2 12 13 40 8 12-SILP 59
MC1438 4 9 12 1 4 8-DIP 59
MC1454G ± 6 ± 18 1 16 10-SIL 59
MC1538 4 12 2 4 8-DIP 59
MC1554G 6 18 1 16 8-SIL 59
MC3360P 6 12 0,25 16 9-SIL 59
MC34119D 2 13,2 16 0,25 32 8-MDIP 59
MC34119P 2 13,2 16 0,25 32 8-DIL KIA6416P 59
MDA2010 5 14 18 12 4 14-DIP TDA2020 111
MDA2020 5 17 22 18,5 4 14-DIP TDA2020 111
MFC9020 12 20 2 16 8-QIP+g 60
NE540L ± 5 ± 20 ± 22 35 8 TO-100 60
NJM2073D 1,8 4 15 2X 0,25 4 8-DIP 60
NJM2073D-BTL 1,8 4 15 4 8-DIP 60
NJM2073S 1,8 4 15 2X 0,25 4 9-SIP 60
NJM2073S-BTL 1,8 4 15 4 9-SIP 60
NJM2113D 2 6 16 0,25 32 8-DIP 60
NJM2113L 2 9 16 0,8 100 8-SIP 60
NJM2135D 2 6 32 0,25 32 8-DIP 60
NJM2135L 2 9 16 0,8 100 8-SIP 60
OPA2544T ± 10 ± 35 ~30 4 11-SQL 61
OPA501 ± 10 ± 28 ± 40 25 8 TO-3/8 61
OPA502 ± 10 ± 40 ± 45 50 8 TO-3/8 61
OPA511 ± 10 ± 45 60 4 TO-3/8 61
OPA544 I ± 10 ± 35 30 4 TO-220/5 61
OPA544 II ± 10 ± 35 30 4 TO-220/5 61
OPA547T ± 4 ± 30 7-SQL 61
PA04 ± 15 ± 95 800 4 TO-3/8 61
PA246 4 9 18 2 8 14-DIP+b 62
PA26 5 28 40 2X 30 4 12-SILP 62
S1531 I / II 1 1,2 1,7 0,12 8-DIP 62
S1531G I / II 1 1,2 1,7 0,12 8-MDIP 62
SF214 9 13 18 4,4 4 9-SILP AN214(P,Q) 3
SFC2790C 6 9 12 1 8 TO-100 62
SI1010G ± 17 10 8 8-HYB 62x41x11 SI1020G 62
SI1020G ± 23 20 8 8-HYB 62x41x11 62
SI1020GL ± 23 20 8 8-HYB 62x41x11 63
SI1020H ± 23 20 8 12-HYB 54x31x7 63
SI1030GL ± 27 32 8 10-HYB 88x54x13 63
SI1050G ± 33 50 8 10-HYB 88x54x13 63
SI1050GL ± 33 50 8 10-HYB 88x54x13 63
SI1125H ± 25 25 8 12-HYB 54x31x7 63
SI1125HD ± 25 2X 25 8 16-HYB 68x42x8 SI1130H 63
SI1130H ± 27 30 8 12-HYB 54x31x7 63
SL34 1,2 9 0,4 8 14-DIP+c 63
SL345 4 15 4 4 14-DIP+c 64
SL402D 10 14 18 2,5 7,5 64
SL403D 10 18 20 3,5 7,5 64
SL414 9 16 20 3 7,5 64
SL415 15 20 25 5 7,5 64
SL630C 6 12 18 0,25 40 64
SL6310 4,5 9 15 0,5 8 8-DIP 65
SN16881ND 12-QIP+b TBA800 65
SN16922ND 12-QIP+b TBA810S 65
SN16975 65
SN76001 65
SN76001ANQ 12-QIP+c TAA611-B12 65
SN76002 64
SN76003 64
SN76003N 65
SN76008 65
SN76013 65
SN76013N 65
SN76018 65
SN76827 65
SN76829 65
STK011 25 38 6,5 8 HYB STK015 66
STK013 32 50 2X 9,5 8 HYB STK014 66

150

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

STK015 32 48 9,5 8 HYB STK016 66
STK016 38 54 15 8 HYB 66
STK020 ± 16 ± 24 10 8 HYB STK027 66
STK024 44 60 20 8 HYB STK031 66
STK025 ± 22 ± 30 20 8 HYB STK032 66
STK027 ± 19 ± 27 15 8 HYB 66
STK030 ± 24 ± 35 25 8 HYB 66
STK031 48 66 25 8 HYB STK035 66
STK035 54 70 30 8 HYB 66
STK040 ± 16,5 ± 25 2X 10 8 HYB STK041 67
STK041 ± 20 ± 29 2X 15 8 HYB STK043 67
STK043 ± 22 ± 32,5 2X 20 8 HYB 67
STK050,N ± 35 ± 45 50 8 HYB STK070 66
STK054 ± 19 ± 27,5 15 8 HYB 67
STK055 ± 20 ± 28 15 8 HYB 67
STK057 ± 22 ± 32 20 8 HYB 67
STK060 ± 27 30 8 HYB 67
STK067 26,4 35 30 330 HYB STK071 67
STK070,N ± 42 ± 55 70 8 HYB 66
STK071 26,4 35 60 165 HYB 67
STK075 ± 20 ± 28 15 8 HYB STK077 67
STK075G ± 20 ± 28 15 8 HYB STK077G 67
STK077 ± 22 ± 32 20 8 HYB STK078 67
STK077G ± 22 ± 32 20 8 HYB STK078G 67
STK078 ± 25 ± 35 24 8 HYB STK080 67
STK078-105 ± 25 ± 35 24 8 HYB 67
STK078G ± 25 ± 35 24 8 HYB STK080G 67
STK080 ± 27 ± 39 30 8 HYB STK082 67
STK080G ± 27 ± 39 30 8 HYB STK082G 67
STK082 ± 30 ± 43 35 8 HYB 67
STK082-105 ± 30 ± 43 35 8 HYB 67
STK082G ± 30 ± 43 35 8 HYB 67
STK084 ± 35 ± 50 50 8 HYB STK086 67
STK084G ± 35 ± 50 50 8 HYB STK086G 67
STK085 ± 38 ± 55 60 8 HYB STK086 67
STK085-105 ± 38 ± 55 60 8 HYB 67
STK085G ± 38 ± 55 60 8 HYB STK086G 67
STK086 ± 42 ± 55 70 8 HYB 67
STK086G ± 42 ± 55 70 8 HYB 67
STK1030 ± 28,5 ± 40 30 8 HYB STK1040 68
STK1035 ± 28,5 ± 40 30 8 HYB STK1039 68
STK1039 ± 30 ± 46 35 8 HYB STK1045 68
STK1040 ± 33 ± 48 40 8 HYB STK1050 68
STK1045 ± 33 ± 48 40 8 HYB STK1049 68
STK1050 ± 36 ± 53 50 8 HYB STK1060 68
STK1060 ± 40 ± 56 60 8 HYB ~STK1070 68
STK1070 ± 40 ± 56 60 8 HYB 68
STK350-000 ± 55 60-70 4147 53x22 68
STK350-010 ± 59 70-80 4147 53x22 68
STK350-020 ± 65 80-90 4147 53x22 68
STK350-030 ± 75 90-100 4147 53x22 68
STK350-040 ± 80 100-120 4147 53x22 68
STK350-050 ± 90 120-150 4147 53x22 68
STK400-010 ± 17,5 ± 26 3X 10 6 4086A 78x44 69
STK400-020 ± 20 ± 29 3X 15 6 4086A 78x44 69
STK400-030 ± 23 ± 34 3X 20 6 4086A 78x44 69
STK400-040 ± 25 ± 36 3X 25 6 4086A 78x44 69
STK400-050 ± 26 ± 39 3X 30 6 4086A 78x44 69
STK400-060 ± 28 ± 41 3X 35 6 4086A 78x44 69
STK400-070 ± 30 ± 44 3X 40 6 4086A 78x44 69
STK400-080 ± 31 ± 45 3X 45 6 4086A 78x44 69
STK400-090 ± 32 ± 47 3X 50 6 4086A 78x44 69
STK400-100 ± 35 ± 51 3X 60 6 4086A 78x44 69
STK400-110 ± 38 ± 56 3X 70 6 4086A 78x44 69
STK400-210 ± 15,5 ± 26 3X 10 6 4086A 78x44 69
STK400-220 ± 20 ± 29 3X 15 6 4086A 78x44 69
STK400-230 ± 23 ± 34 3X 20 6 4086A 78x44 69
STK400-240 ± 25 ± 36 3X 25 6 4086A 78x44 69
STK400-250 ± 26 ± 39 3X 30 6 4086A 78x44 69
STK400-260 ± 28 ± 41 3X 35 6 4086A 78x44 69
STK400-270 ± 30 ± 44 3X 40 6 4086A 78x44 69
STK400-280 ± 31 ± 45 3X 45 6 4086A 78x44 69
STK400-290 ± 32 ± 47 3X 50 6 4086A 78x44 69
STK400-300 ± 35 ± 51 3X 60 6 4086A 78x44 69
STK400-310 ± 38 ± 56 3X 70 6 4086A 78x44 69
STK400-450 2X 15+30 6 4086A 78x44 70
STK400-460 2X 15+35 6 4086A 78x44 70
STK400-470 2X 20+40 6 4086A 78x44 70
STK400-480 2X 20+45 6 4086A 78x44 70
STK400-490 2X 25+50 6 4086A 78x44 70

AUDIO POWER AMPLIFIER

151

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

STK400-500 2X 30+60 6 4086A 78x44 70
STK400-510 2X 35+70 6 4086A 78x44 70
STK400-520 2X 40+80 6 4086A 78x44 70
STK400-530 2X50+100 6 4086A 78x44 70
STK400-650 2X 15+30 6 4086A 78x44 70
STK400-660 2X 15+35 6 4086A 78x44 70
STK400-670 2X 20+40 6 4086A 78x44 70
STK400-680 2X 20+45 6 4086A 78x44 70
STK400-690 2X 25+50 6 4086A 78x44 70
STK400-700 2X 30+60 6 4086A 78x44 70
STK400-710 2X 35+70 6 4086A 78x44 70
STK400-720 2X 40+80 6 4086A 78x44 70
STK400-730 2X50+100 6 4086A 78x44 70
STK401-010 ± 18 ± 27 2X 10 6 4134 64x36 71
STK401-020 ± 20 ± 29 2X 15 6 4134 64x36 71
STK401-030 ± 23 ± 34 2X 20 6 4134 64x36 71
STK401-040 ± 25 ± 36 2X 25 6 4134 64x36 71
STK401-050 ± 26 ± 39 2X 30 6 4134 64x36 71
STK401-060 ± 28 ± 41 2X 35 6 4134 64x36 71
STK401-070 ± 30 ± 44 2X 40 6 4134 64x36 71
STK401-080 ± 31 ± 45 2X 45 6 4134 64x36 71
STK401-090 ± 32 ± 47 2X 50 6 4134 64x36 71
STK401-100 ± 35 ± 51 2X 60 6 4029 78x44 71
STK401-110 ± 38 ± 56 2X 70 6 4029 78x44 71
STK401-120 ± 42 ± 61 2X 80 6 4068A 78x44 71
STK401-130 ± 45 ± 65 2X 100 6 4068A 78x44 71
STK401-140 ± 51 ± 74 2X 120 6 4068A 78x44 71
STK401-210 ± 18 ± 27 2X 10 6 4068A 78x44 71
STK401-220 ± 20 ± 29 2X 15 6 4068A 78x44 71
STK401-230 ± 23 ± 34 2X 20 6 4068A 78x44 71
STK401-240 ± 25 ± 36 2X 25 6 4068A 78x44 71
STK401-250 ± 26 ± 39 2X 30 6 4068A 78x44 71
STK401-260 ± 28 ± 41 2X 35 6 4068A 78x44 71
STK401-270 ± 30 ± 44 2X 40 6 4068A 78x44 71
STK401-280 ± 31 ± 45 2X 45 6 4068A 78x44 71
STK401-290 ± 32 ± 47 2X 50 6 4068A 78x44 71
STK401-300 ± 35 ± 51 2X 60 6 4068A 78x44 71
STK401-310 ± 38 ± 56 2X 70 6 4068A 78x44 71
STK401-320 ± 42 ± 61 2X 80 6 4068A 78x44 71
STK401-330 ± 45 ± 65 2X 100 6 4068A 78x44 71
STK401-340 ± 51 ± 74 2X 120 6 4068A 78x44 71
STK4017 26,4 45 6,5 8 4021A 46x25 STK4019 74
STK4019 32 54 10 8 4021A 46x25 STK4021 74
STK4021 38 64 15 8 4021A 46x25 STK4023 74
STK4023 44 73 20 8 4070 59x31 STK4025 74
STK4024II ± 23 ± 34,5 20 8 4033 59x31 STK4026II 71
STK4024V ± 24 ± 37 20 8 4062 64x31 STK4026V 72
STK4025 48 80 25 8 4070 59x31 74
STK4026II ± 26 ± 38 25 8 4033 59x31 STK4028II 71
STK4026V ± 26 ± 39 25 8 4062 64x31 STK4028V 72
STK4028II ± 27,5 ± 42 30 8 4033 59x31 STK4030II 71
STK4028V ± 27 ± 42 30 8 4062 64x31 STK4030V 72
STK4028X ± 29 ± 42 30 8 4062 64x31 STK4030X 73
STK4030II ± 30 ± 45 35 8 4033 59x31 STK4032II 71
STK4030V ± 30 ± 45 35 8 4062 64x31 STK4032V 72
STK4030X ± 32 ± 46 35 8 4062 64x31 STK4032X 73
STK4032II ± 32 ± 48 40 8 4033 59x31 STK4034II 71
STK4032V ± 32 ± 49 40 8 4062 64x31 STK4034V 72
STK4032X ± 33 ± 49 40 8 4062 64x31 STK4034X 73
STK4034II ± 33,5 ± 50 45 8 4033 59x31 STK4036II 71
STK4034V ± 33,5 ± 50 45 8 4062 64x31 STK4036V 72
STK4034X ± 35 ± 50 45 8 4062 64x31 STK4036X 73
STK4036II ± 35 ± 52 50 8 4033 59x31 STK4038II 71
STK4036V ± 35 ± 52 50 8 4062 64x31 STK4038V 72
STK4036X ± 36 ± 52 50 8 4062 64x31 STK4038X 73
STK4036XI ± 37 ± 53,5 50 8 4075 64x36 STK4038XI 73
STK4038II ± 38 ± 57 60 8 4033 59x31 STK4040II 71
STK4038V ± 38 ± 57 60 8 4062 64x31 STK4040V 72
STK4038X ± 39 ± 57 60 8 4062 64x31 STK4040X 73
STK4038XI ± 40 ± 58 60 8 4075 64x36 STK4040XI 73
STK4040II ± 42 ± 60 70 8 4033 59x31 71
STK4040V ± 42 ± 62 70 8 4062 64x31 72
STK4040X ± 42,5 ± 62 70 8 4062 64x31 73
STK4040XI ± 43,5 ± 63 70 8 4075 64x36 STK4042XI 73
STK4042II ± 45 ± 65 80 8 4075 64x36 STK4044II 71
STK4042V ± 45 ± 65 80 8 4075 64x36 STK4044V 72
STK4042X ± 46 ± 67 80 8 4075 64x36 STK4044X 73
STK4042XI ± 46,5 ± 67 80 8 4075 64x36 STK4044XI 73
STK4044 II ± 51 ± 73 100 8 4075 64x36 71
STK4044V ± 51 ± 73 100 8 4075 64x36 72

152

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

STK4044X ± 51 ± 74 100 8 4075 64x36 73
STK4044XI ± 51 ± 74 100 8 4075 64x36 73
STK4046II ± 54 ± 80 120 8 4051A 78x44 STK4048II 72
STK4046V ± 55 ± 80 120 8 4051A 78x44 STK4048V 72
STK4046XI ± 55 ± 80 120 8 4051A 78x44 STK4048XI 73
STK4048II ± 59 ± 87 150 8 4051A 78x44 STK4050II 72
STK4048V ± 60 ± 87 150 8 4051A 78x44 STK4050V 72
STK4048XI ± 60 ± 87 150 8 4051A 78x44 73
STK405-010 2X 10 6 HYB 74
STK405-030 2X 20 6 HYB 74
STK405-050 2X 30 6 HYB 74
STK405-070 2X 40 6 HYB 74
STK405-090 2X 50 6 HYB 74
STK4050II ± 66 ± 95 200 8 4051A 78x44 72
STK4050V ± 66 ± 95 200 8 4051A 78x44 72
STK405-100 2X 60 6 4068A 78x44 74
STK405-110 2X 70 6 4068A 78x44 74
STK405-120 2X 80 6 4068A 78x44 74
STK4065 13,2 30 25 2 4081 46x25 74
STK4067 13,2 30 50 1 4131 64x31 74
STK4100MK2 ± 13,5 ± 20.5 2x 6 4 HYB 78x32 STK4110MK2 75
STK4100MK5 ± 14 ± 21 2X 6 8 HYB 78 x32 STK4110MK5 75
STK4101II ± 13 ± 20,5 2X 6 8 HYB 64x36 STK4111II 74
STK4102II ± 13,2 ± 20,5 2X 6 8 4083 64x31 74
STK4110MK2 ± 17 ± 27 2X 10 4 HYB 78x32 STK4120MK2 75
STK4110MK5 ± 18 ± 27 2X 10 8 HYB 78 x32 STK4120MK5 75
STK4111II ± 17 ± 26 2X 10 8 HYB 64x36 STK4121II 74
STK4111V ± 18 2X 10 8 4040 64x36 STK4141V 75
STK4112II ± 17 ± 26 2X 10 8 4083 64x31 75
STK4120MK2 ± 21 ± 30,5 2X 15 4 HYB 78x32 STK4130MK2 75
STK4120MK5 ± 21,5 ± 32 2X 15 8 HYB 78 x32 STK4130MK5 75
STK4121II ± 20 ± 30,5 2X 15 8 4040 64x36 STK4131II 74
STK4121V ± 21,5 ± 32 2X 15 8 4040 64x36 STK4141V 75
STK4122II ± 20 ± 30,5 2X 15 8 4083 64x31 75
STK413 18 29 2X 3 8 HYB STK415 76
STK4130MK2 ± 23 ± 35,5 2X 20 4 HYB 78x32 STK4140MK2 75
STK4130MK5 ± 24,5 ± 36 2X 20 8 HYB 78 x32 STK4140MK5 75
STK4131II ± 23 ± 34,5 2X 20 8 4040 64x36 STK4141II 74
STK4131V ± 24,5 ± 36 2X 20 8 4040 64x36 STK4141V 75
STK4132II ± 23 ± 34,5 2X 20 8 4083 64x31 75
STK4140MK2 ± 27 ± 40 2X 25 4 HYB 78x32 STK4150MK2 75
STK4140MK5 ± 27 ± 40,5 2X 25 8 HYB 78 x32 STK4150MK5 75
STK4141II ± 26 ± 39 2X 25 8 4040 64x36 STK4151II 74
STK4141V ± 27 ± 40,5 2X 25 8 4040 64x36 STK4151V 75
STK4141X ± 27,5 ± 41 2X 25 8 4146 105x32 STK4151X 76
STK4142II ± 26 ± 39 2X 25 8 4040 64x36 75
STK4144MK2 ± 27 ± 40 2X 25 8 4086A 78x44 STK4154MK2 77
STK4144MK5 ± 27 ± 40,5 2X 25 8 4086A 78x44 STK4154MK5 77
STK4145MK2 ± 27 ± 40 2X 25 8 4086A 78x44 STK4155MK2 77
STK4145MK5 ± 27 ± 40,5 2X 25 8 4086A 78x44 STK4155MK5 78
STK415 24 35 2X 6,5 8 HYB 76
STK4150MK2 ± 28 ± 42 2X 30 4 HYB 78x32 STK4160MK2 75
STK4150MK5 ± 28,5 ± 42 2X 30 8 HYB 78 x32 STK4160MK5 75
STK4151II ± 27 ± 42 2X 30 8 4042 78x44 STK4161II 74
STK4151V ± 28 ± 42 2X 30 8 4040 64x36 STK4161V 75
STK4151X ± 29 ± 42,5 2X 30 8 4146 105x32 STK4161X 76
STK4152II ± 27,5 ± 42 2X 30 8 4040 64x36 75
STK4154MK2 ± 28 ± 42 2X 30 8 4086A 78x44 STK4164MK2 77
STK4154MK5 ± 28,5 ± 42 2X 30 8 4086A 78x44 STK4164MK5 77
STK4155MK2 ± 28 ± 42 2X 30 8 4086A 78x44 STK4165MK2 77
STK4155MK5 ± 28,5 ± 42 2X 30 8 4086A 78x44 STK4165MK5 78
STK4159MK2 ±21/27,5 ±30,5/42 15+30+15 8 HYB 90x53 STK4169MK2 78
STK4160MK2 ± 30,5 ± 45 2X 40 4 HYB 78x32 STK4170MK2 75
STK4160MK5 ± 30,5 ± 46 2X 35 8 HYB 78 x32 STK4170MK5 75
STK4161II ± 30 ± 45 2X 35 8 4042 78x44 STK4171II 74
STK4161V ± 30,5 ± 46 2X 35 8 4040 64x36 STK4171V 75
STK4161X ± 31 ± 46,5 2X 35 8 4146 105x32 STK4171X 76
STK4162II ± 30 ± 45 2X 35 8 4040 64x36 75
STK4164MK2 ± 30,5 ± 45 2X 35 8 4086A 78x44 STK4174MK2 77
STK4164MK5 ± 30,5 ± 46 2X 35 8 4086A 78x44 STK4174MK5 77
STK4165MK2 ± 30,5 ± 45 2X 35 8 4086A 78x44 STK4175MK2 77
STK4165MK5 ± 30,5 ± 46 2X 35 8 4086A 78x44 STK4175MK5 78
STK4169MK2 ±21/30 ±30,5/45 15+35+15 8 HYB 90x53 STK4179MK2 78
STK4170MK2 ± 32 ± 48 2X 40 4 HYB 78x32 STK4180MK2 75
STK4170MK5 ± 32,5 ± 49 2X 40 8 HYB 78 x32 STK4180MK5 75
STK4171II ± 32 ± 48 2X 40 8 4042 78x44 STK4181II 74
STK4171V ± 32,5 ± 49 2X 40 8 4040 64x36 STK4181V 75
STK4171X ± 33 ± 49,5 2X 40 8 4146 105x32 STK4181X 76
STK4172II ± 32 ± 48 2X 40 8 4040 64x36 75
STK4174MK2 ± 32 ± 48 2X 40 8 4086A 78x44 STK4184MK2 77

AUDIO POWER AMPLIFIER

153

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

STK4174MK5 ± 32,5 ± 49 2X 40 8 4086A 78x44 STK4184MK5 77
STK4175MK2 ± 32 ± 48 2X 40 8 4086A 78x44 STK4185MK2 77
STK4175MK5 ± 32,5 ± 49 2X 40 8 4086A 78x44 STK4185MK5 78
STK4176X ± 26 ± 49,5 2X 40 4 4146 105x32 STK4186X 78
STK4179MK2 ±34,5/48 ±34,5/48 20+40+20 8 HYB 90x53 STK4189MK2 78
STK4180MK2 ±33,5 ± 50 2X 50 4 HYB 78x32 STK4190MK2 75
STK4180MK5 ± 34 ± 51 2X 45 8 HYB 78 x32 STK4190MK5 75
STK4181II ± 33 ± 50 2X 45 8 4042 78x44 STK4191II 74
STK4181V ± 34 ± 51 2X 45 8 4040 64x36 STK4191V 75
STK4181X ± 34 ± 51,5 2X 45 8 4146 105x32 STK4191X 76
STK4182II ± 33,5 ± 50 2X 45 8 4040 64x36 75
STK4184MK2 ± 33,5 ± 50 2X 45 8 4086A 78x44 STK4194MK2 77
STK4184MK5 ± 34 ± 51 2X 45 8 4086A 78x44 STK4194MK5 77
STK4185MK2 ± 33,5 ± 50 2X 45 8 4086A 78x44 STK4195MK2 77
STK4185MK5 ± 34 ± 51 2X 45 8 4086A 78x44 STK4195MK5 78
STK4186X ± 27,5 ± 51,5 2X 45 4 4146 105x32 STK4196X 78
STK4189MK2 ±23/33,5 ±34,5/50 20+45+20 8 HYB 90x53 STK4199MK2 78
STK4190MK2 ± 35 ± 52,5 2X 50 4 HYB 78x32 75
STK4190MK5 ± 35,5 ± 53 2X 50 8 HYB 78 x32 75
STK4191II ± 35 ± 52,5 2X 50 8 4042 78x44 74
STK4191V ± 35,5 ± 53 2X 50 8 4040 64x36 75
STK4191X ± 36 ± 53,5 2X 50 8 4146 105x32 STK4201X 76
STK4192II ± 35 ± 52,5 2X 50 8 4040 64x36 75
STK4194MK2 ± 35 ± 52,5 2X 50 8 4086A 78x44 77
STK4194MK5 ± 35,5 ± 53 2X 50 8 4086A 78x44 77
STK4195MK2 ± 35 ± 52,5 2X 50 8 4086A 78x44 77
STK4195MK5 ± 35,5 ± 53 2X 50 8 4086A 78x44 78
STK4196X ± 29 ± 53,5 2X 50 4 4146 105x32 STK4206X 78
STK4199MK2 ± 27/35 ±40/52,5 25+50+25 8 HYB 90x53 78
STK4200MK5 ± 39 ± 57 2X 60 4 HYB 78x44 STK4210MK5 79
STK4201II ± 38 ± 55 2X 60 8 4086A 78x44 STK4211 II 79
STK4201V ± 39 ± 57 2X 60 8 4086A 78x44 STK4211V 75
STK4201X ± 39 ± 57,5 2X 60 8 4146 105x32 STK4211X 76
STK4204MK2 ± 38,5 ± 55 2X 60 8 4110A 90x53 STK4214MK2 79
STK4204MK5 ± 39 ± 57 2X 60 8 4110A 90x53 STK4214MK5 80
STK4205MK2 ± 38,5 ± 55 2X 60 8 4110A 90x53 STK4215MK2 80
STK4205MK5 ± 39 ± 57 2X 60 8 4110A 90x53 STK4215MK5 80
STK4206X ± 32 ± 57,5 2X 60 4 4146 105x32 STK4216X 78
STK4209MK2 ± 28/38 ±42/55 30+60+30 8 HYB 90x53 STK4219MK2 81
STK4210MK5 ± 43 ± 62 2X 70 4 HYB 78x44 STK4220MK5 79
STK4211II ± 42 ± 60 2X 70 8 4086A 78x44 STK4221 II 79
STK4211V ± 43 ± 63 2X 70 8 4086A 78x44 STK4221V 75
STK4211X ± 43,5 ± 62,5 2X 70 8 4146 105x32 76
STK4214MK2 ± 42 ± 60 2X 70 8 4110A 90x53 STK4224MK2 79
STK4214MK5 ± 43 ± 62 2X 70 8 4110A 90x53 STK4224MK5 80
STK4215MK2 ± 42 ± 60 2X 70 8 4110A 90x53 STK4225MK2 80
STK4215MK5 ± 43 ± 62 2X 70 8 4110A 90x53 STK4225MK5 80
STK4216X ± 34 ± 62 2X 70 4 4146 105x32 78
STK4219MK2 ±30,5/42 ± 45/60 35+70+35 8 HYB 90x53 STK4229MK2 81
STK4220MK5 ± 45 ± 65 2X 80 4 HYB 78x44 STK4230MK5 79
STK4221II ± 45 ± 65 2X 80 8 4086A 78x44 STK4231 II 79
STK4221V ± 45 ± 65 2X 80 8 4086A 78x44 STK4231V 76
STK4224MK2 ± 45 ± 65 2X 80 8 4110A 90x53 STK4234MK2 79
STK4224MK5 ± 45 ± 65 2X 80 8 4110A 90x53 STK4234MK5 80
STK4225MK2 ± 45 ± 65 2X80 8 4110A 90x53 STK4235MK2 80
STK4225MK5 ± 45 ± 65 2X 80 8 4110A 90x53 STK4235MK5 80
STK4229MK2 ± 32/45 ± 48/65 40+80+40 8 HYB 90x53 STK4239MK2 81
STK4230MK5 ± 51 ± 75 2X 100 4 HYB 78x44 79
STK4231II ± 51 ± 75 2X 100 8 4086A 78x44 79
STK4231V ± 51 ± 75 2X 100 8 4086A 78x44 STK4241V 76
STK4234MK2 ± 51 ± 75 2X 100 8 4110A 90x53 79
STK4234MK5 ± 51 ± 75 2X 100 8 4110A 90x53 80
STK4235MK2 ± 51 ± 75 2X 100 8 4110A 90x53 80
STK4235MK5 ± 51 ± 75 2X 100 8 4110A 90x53 80
STK4239MK2 ± 35/51 ± 52,5/70 50+100+50 8 HYB 90x53 81
STK4241II ± 55 ± 87 2X 120 8 4086A 78x44 79
STK4241V ± 54 ± 78 2X 120 8 4086A 78x44 76
STK430 BTL 14 22 7 8 HYB 82
STK430 II 26,4 43 2X 15 4 HYB ~STK439 81
STK430 III 31 50 2X 20 4 HYB ~STK439 81
STK433 23 32 120 2X 5 8 HYB STK435 82
STK433-105 23 32 2X 5 8 HYB STK435 82
STK4332 23 32 2X 5 8 4032A 59x25 STK4352 83
STK435 27 39 2X 7 8 HYB STK436 82
STK4352 27 39 2X 7 8 4032A 59x25 STK4362 83
STK436 32 50 2X 10 8 HYB 82
STK4362 33 50 2X 10 8 4033 59x31 STK4372 83
STK437 33 50 2X 10 8 HYB STK439 82
STK4372 35 54 2X 12 8 4033 59x31 STK4392 83
STK439 39 56 2X 15 8 HYB STK441 82

154

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

STK4392 39 56 2X 15 8 4033 59x31 STK4412 83
STK441 44 63 2X 25 8 HYB STK443 82
STK441-105 44 63 2X 20 8 HYB STK443 82
STK4412 44 63 2X 20 8 4033 59x31 STK4432 83
STK443 49 70 2X 25 8 HYB 82
STK4432 49 70 2X 25 8 4033 59x31 83
STK457 ± 18 ± 26 2X 10 8 HYB STK459 82
STK459 ± 21 ± 31 2X 15 8 HYB STK460 82
STK460 ± 23 ± 32 2X 20 8 HYB 82
STK461 ± 23 ± 33 2X 20 8 HYB STK463 82
STK463 ± 26 ± 38 2X 25 8 HYB STK465 82
STK465 ± 28 ± 41 2X 30 8 HYB 82
STK4773 ± 19 ± 26 2X 10 8 HYB STK4793 83
STK4793 ± 22 ± 31 2X 15 8 HYB STK4803 83
STK4803 ± 24 ± 35 2X 20 8 HYB STK4813 83
STK4813 ± 24 ± 35 2X 20 8 HYB STK4833 83
STK4833 ± 25,5 ± 39 2X 25 8 HYB STK4843 83
STK4843 ± 27,5 ± 43 2X 30 8 HYB STK4853 83
STK4853 ± 27,5 ± 43 2X 30 8 HYB STK4863 83
STK4863 ± 30 ± 47 2X 35 8 HYB STK4893 83
STK4873 ± 30 ± 47 2X 35 8 HYB STK4893 83
STK4893 ± 32 ± 46 2X 40 8 HYB STK4913 83
STK4905 8 13,5 18 spec. 83
STK4913 ± 35 ± 50 2X 50 8 HYB 83
SVI3101C ± 33 6 84
SVI3102C 84
TA6206F 0,9 1,5 5 32 16-MDIP 85
TA6210AH 8 14,4 18 2X 22 4 17-QIP+s 85
TA7066P 8 16 25 0,15 150 7-SIP 85
TA7092P 9 13,2 3,5 4 8-QIP+b 85
TA7140P 3,5 16 25 0,15 150 7-SIP 85
TA7200P 9 16 22 3,3 16 10-SIL 85
TA7203P 8 14 20 2X 2 8 14-DIP+a 86
TA7204P 9 13 18 4,2 4 10-SIL 85
TA7205AP 9 13,2 18 5,8 4 10-SIL 86
TA7207P 4,5 6 10 0,95 4 10-SIL TA7208P 86
TA7208P 5 9 14 2 4 10-SIL 86
TA7210P 20 34 40 11 8 12-SIL 86
TA7211P 3,5 6 10 1,8 8 14-DIP+g TA7212P 86
TA7212P 3,8 9 15 3,8 8 14-DIP+g 86
TA7214P 9 13 18 2X 4,8 4 20-DIP+c 86
TA7215P 4,5 9 16 2X 2,2 4 20-DILP 87
TA7216P 23 6,5 8 12-SIL 87
TA7217AP 9 13,2 18 5,8 4 10-SIL 86
TA7220P 12 45 0,15 150 10-SIL 87
TA7222AP 8 13,2 18 5,8 4 10-SIL 87
TA7223P 3,5 6 12 1 4 14-DIP+b 87
TA7227CP 8 14,4 25 2X 5,5 4 12-SIL 87
TA7227P 8 14,4 25 2X 5,5 4 12-SQL 87
TA7227P-BTL 8 13,2 25 17 4 12-SQL 87
TA7229P 7 12 16 2X 3,9 4 20-DILP 88
TA7230P 5,5 14 20 2X 4 4 10-SIL 88
TA7232P 3,5 9 12 2X 2,2 4 12-SIL 88
TA7232P BTL 3,5 9 12 5,5 4 12-SIL 88
TA7233P 6 12 16 2X 4,5 4 12-SIL 88
TA7235P 1,8 9/12 24 1,6 4 8-DIL 88
TA7236P,AP 6 15 18 2X 7 4 89
TA7237P,AP 8 13,2 18 17 4 12-SILP 89
TA7238P 12 18 27 8,5 4 10-SIL 87
TA7240P 9 13,2 18 2X 5,8 4 12-SILP 89
TA7240P-BTL 9 13,2 18 19 4 12-SILP 89
TA7241P 9 13,2 18 2X 5,8 4 12-SILP 89
TA7241P-BTL 9 13,2 18 19 4 12-SILP 89
TA7246P 6 15 18 2X 7 4 20-DIP+c 89
TA7250AP 9 13 18 23 4 12-SQL 90
TA7251AP 9 13 18 23 4 12-SQL 90
TA7252P,AP 9 13,2 18 9,6 2 7-SIL 90
TA7263P 9 13 25 2X 5,8 4 (12-SILP) ~TA7240 89
TA7264P 9 13 25 2X 5,8 4 (12-SILP) ~TA7241 89
TA7268P 20 34 40 11 8 12-SQL 90
TA7269P 6 15 20 2X 8 3 12-SQL 90
TA7270P 8 14,4 25 2X 5,8 4 12-SQL ~TA7240 89
TA7271P 8 14,4 25 2X 5,8 4 12-SQL ~TA7241 89
TA7273P 18 28 37 2X 13 8 12-SQL 90
TA7274P 9 13 18 12 4 ~7-SIL 90
TA7275P 9 13 18 12 4 ~7-SIL 90
TA7280P 9 13 18 2X 5,8 4 12-SQL 90
TA7281P 9 13 18 2X 5,8 4 12-SQL 91
TA7282P 6 12 15 2X 4,6 4 12-SIL KA22063 91
TA7283AP 6 12 15 2X 3 4 12-SIL KA22062 88

AUDIO POWER AMPLIFIER

155

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

TA7283P 6 12 15 2X 4,6 4 12-SIL KA22062 91
TA7286P 6 12 15 2X 4,6 4 12-SQL 90
TA7299P 9 13,2 18 2X 5,8 4 12-SQL 91
TA7313AP 4 6 14 0,5 8 9-SIP AN7112 91
TA7331F 2 4,5 6 0,3 8 16-MDIP 91
TA7331P 2 4,5 6 0,3 8 9-SIP 91
TA7336P 3 6 9 0,34 8 9-SIP 91
TA7368F 2 9 10 1,1 8 16-MDIP 92
TA7368P 2 9 10 1,1 8 9-SIP 92
TA7376P 1,8 4,5 6 0,3 4 9-SIP 92
TA7625F 2 4,5 6 0,4 4 16-DIP 93
TA7628P 3,5 6 9 0,6 8 16-DIP 92
TA7688F 2 3 6 2X 38mW 32 16-MDIP 93
TA7688P 1,8 3 6 2X 38mW 16 16-DIP K174YH17 93
TA7767F 0,9 1,5 3 2X 0,02 32 16-DIP 92
TA7769P 4,5 6 9 2X 1 4 16-DIP 93
TA8111AP 1,8 3 6 2X 0,16 32 16-DIP 93
TA8157FN 0,9 1,5 2,2 2X 0,5 16-SSMDIP KIA8157FN 93
TA8200AH 10 28 37 2X 13 8 12-SQL 94
TA8201AK 8 14,4 25 17 4 7-QILP HZIP7 94
TA8205AH 8 13,2 25 2X 15 4 17QILP KA22102 94
TA8205L 8 13,2 25 2X15 4 17SILP ~TA8205AH 94
TA8207K 6 12 15 2X 4,6 4 12-SIL KA22065 94
TA8208H 8 13,2 25 2X 5,8 4 12-SQL 94
TA8210AH 8 13,2 25 2X 19 4 17-QILP KA22103 94
TA8210AL 8 13,2 25 2X 19 4 17-SILP ~TA8210AH 94
TA8211AH 10 20 30 2X 6 8 12-SQL 94
TA8213K 10 20 30 6 8 17QILP HZIP7 95
TA8215H 8 14,4 18 2X 18 4 17-QLIP 95
TA8216H 10 28 37 2X 13 8 12-SQL 95
TA8217P 9 20 2X 2,5 4 12-DIP+b 95
TA8220H 9 14,4 18 2X 30 2 17-QILP HZIP17 95
TA8221AH 9 14,4 18 2X 30 2 17-QILP 96
TA8221AL 9 14,4 18 2X 30 2 17-SILP ~TA8221AH 96
TA8225H 10 14,4 18 45 2 17-QILP 95
TA8225L 10 14,4 18 45 2 17-SILP ~TA8225H 95
TA8229K 9 12 18 2X 4,6 4 15-SIL 96
TA8231L 9 14,4 18 2X 42 2 17-SILP 96
TA8238K 6 13,2 18 2X 5,3 4 15-SIL 96
TA8246H 10 20 30 2X 6 8 12-SQL 97
TA8251AH 9 14,4 18 4X 30 4 25-QILP KIA8251AH 97
TA8255AH 9 14,4 18 2X 22 4 25-QILP KIA8255AH 96
TA8256H 10 20 30 2X 6 8 12-SQL 97
TA8269P 6 15 20 2X 8 4 12-SQL 97
TA8270P 9 13,2 18 2X 5,8 4 12-SQL 97
TA8270P BTL 9 13,2 18 19 4 12-SQL 97
TA8271P 9 13,2 18 2X 5,8 4 12-SQL 97
TA8271P BTL 9 13,2 18 19 4 12-SQL 97
TAA611-A12 6 9 12 1,8 4 14-QIP+c 98
TAA611-B12 6 12 15 2,1 8 14-QIP+c SN76001ANQ 98
TAA621 9 24 27 4 16 12-QIP+dj 98
TAA900 4,5 9 13 1,8 4 TO-100 98
TBA 810 verzija II 4 16 25 6 4 12-QIP+a 99
TBA1908A 18,5 25 98
TBA641A 9 12 2,2 4 14-QIP+c,d 98
TBA641B 9 14 16 4,5 4 14-QIP+c,J 98
TBA690 6 12 22 1 8 16-DIP 98
TBA700+ 6 12 24 1 8 16-DIP 98
TBA790X 9 12 0,65 15 14-DIP 98
TBA800 5 24 30 5 16 12-QIP+b 99
TBA800A 5 24 30 5 16 12-QIP+a 99
TBA800C 5 24 30 5 16 12-QIP+b 99
TBA810 I 3,5 14 20 6 4 12-QIP+a TBA810AT 99
TBA810ACB I 4 14 28 6 4 12-QIP+a TBA810AT 99
TBA810AS I 4 14 20 6 4 12-QIP+a A210E 99
TBA810AT I 4 16 25 6 4 12-QIP+a 99
TBA820 I 3 12 16 2 8 14-QIP 99
TBA820 II 3 12 16 2 8 14-QIP 99
TBA820M I 3 9 16 1,6 4 8-DIP 99
TBA820M II 3 9 16 1,6 4 8-DIP 99
TBA915G 12 17 0,5 20 9-SIL 100
TBA915K 12 17 0,5 20 TO-100 99
TCA1003 1,3 5mW 200 8-MDIP 100
TCA1004 1,3 5mW 200 8-MDIP 100
TCA120 7 12,5 18 4 4 12-QIP+a 100
TCA1365B ± 4 ± 15 ± 21 20 8,2 TO-220/7 100
TCA150KA 6 12 15 4 4 16-DIP 100
TCA150KB 14 18 5,5 4 16-DIP 100
TCA160B 7,5 9 16 1,2 8 16-DILP 101
TCA210 8 12 17 0,5 15 16-DIP 100

156

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

TCA2365(1/2-2/2) ± 4 ± 10 ± 16 2X 10 8,2 9-SIL 101
TCA2465(1/2-2/2) I ± 3 ± 10 ± 21 2X 10 4 9-SIL 101
TCA2465A(1/2-2/2) ± 3 ± 10 ± 20 2X 10 4 16-DIP 101
TCA365 ± 5 ± 15 ± 21 20 8 TO-220/5 101
TCA760 5 9 14 1,1 8 16-DIP 101
TCA760B 3,5 20 5 16-DIP 101
TCA830 3,5 14,4 20 5 12-QIP+b 102
TCA830A 3,5 14,4 20 5 12-QIP+a 102
TCA830S 3,5 14 20 4,2 4 16-DIP 102
TCA830SM 3,5 14 20 2,3 4 16-DIP 102
TCA940 4 20 24 10 4 12-QIP+a TBA810AT 102
TCA940E 6 20 24 6,5 8 12-QIP+b TBA810T 102
TDA1004 9 14 24 5,7 4 16-DIP 102
TDA1004A 9 14 24 6,2 4 16-DIP+c 102
TDA1009 5 16 24 2X 6 4 16-DIP+c 102
TDA1010 6 14,4 24 6,2 4 9-SIL SOT110B 102
TDA1010A 6 14,4 24 6 4 9-SIL SOT110B 102
TDA1011 3,6 12 24 4,2 4 9-SIL SOT110B 102
TDA1011A 5 12 24 6,5 4 9-SIL SOT110B 102
TDA1012 3,6 9 18 2 4 16-DIP 102
TDA1013,A 15 18 35 4,5 8 9-SIL SOT110B 103
TDA1013B 10 18 40 4,2 8 9-SIL SOT110B 103
TDA1015 3,6 12 18 4,2 4 9-SIL SOT110B 103
TDA1015T 3,6 9 12 0,5 16 8-MDIP SO-8 103
TDA1016 3,6 9 15 2 4 16-DIP SOT-38 103
TDA1020 6 14,4 18 12 2 9-SIL SOT110B 103
TDA1037 4 24 28 5 16 9-SIL 103
TDA1042 9 14 18 10 2 14-QIP 104
TDA1042B 9 14 18 10 2 14-QIP +d 104
TDA1045 6 9 12 1,3 8 14-QIP 104
TDA1051 6 12 18 1,3 15 14-QIP 104
TDA1099SP 9 14 20 2X 10 2 11-SIL 104
TDA1100SP 9 14 40 10 2 11-SIL 104
TDA1102 ± 6 ± 12 ± 16 20 4 11-SIL 104
TDA1103P 9 28 32 20 4 11-SIL 104
TDA1111SP 12 28 30 20 4 11-SIL 104
TDA1308T 2,2 5 8 2X 60mW 32 8-MDIP SO-8 105
TDA1410H 10 34 36 16 4 TO-220/5 ~TDA2003 109
TDA1420H 10 40 44 30 4 TO-220/5 ~TDA2003 109
TDA1510,A,AQ BTL 6 14,4 18 24 4 13-QILP SOT-141C 105
TDA1510.A,AQ 6 14,4 18 2X 12 2 13-QILP SOT-141C 105
TDA1512 10 25 35 13 4 9-SILP 105
TDA1512A 10 25 35 13 4 105
TDA1512AQ 10 25 35 13 4 9-QILP 105
TDA1514,A ± 10 ± 27,5 ± 30 48 8 9-SILP SOT-131 105
TDA1515AQ 6 14,4 18 2X 12 2 13-QILP SOT-141C 105
TDA1515AQ BTL 6 14,4 18 24 4 13-QILP SOT-141C 105
TDA1516BQ 6 14,4 18 2X 11 2 13-QILP SOT-141C ~TDA1518BQ 105
TDA1516BQ BTL 6 14,4 18 22 4 13-QILP SOT-141C ~TDA1518BQ 106
TDA1517 6 14,4 2X 6 6 4 9-SIL-SQL SOT110B 106
TDA1518BQ 6 14,4 18 2X 11 2 13-QILP SOT-141C 105
TDA1518BQ BTL 6 14,4 18 22 2 13-QILP SOT-141C 106
TDA1519 6 14,4 2X 6 6 4 9-SIL-SQL SOT110B 106
TDA1519A 6 14,4 17,5 2X 11 2 9-S(Q)ILP SOT131/157 106
TDA1519A BTL 6 14,4 17,5 22 4 9-S(Q)ILP SOT131/157 106
TDA1519B 6 14,4 17,5 2X 6 4 9-SIL SOT-110B 106
TDA1519B BTL 6 14,4 17,5 12 4 9-SIL SOT-110B 106
TDA1521 I ± 7,5 ± 16 ± 21 2X 12 8 9-SILP SOT131 106
TDA1521,A,B II 106
TDA1521A I ± 7,5 ± 16 ± 21 2X 6 8 9-SIL SOT110B 106
TDA1521Q I ± 7,5 ± 16 ± 21 2X 12 8 9-QILP SOT157 106
TDA1551Q 6 14,4 18 4X 11 2 17-QILP SOT243R 106
TDA1551Q BTL 6 14,4 18 2X 22 4 17-QILP SOT243R 106
TDA1552Q 6 14,4 18 2X 22 4 13-QILP SOT141R 107
TDA1553CQ 6 14,4 18 2X 22 4 13-QILP SOT141R 107
TDA1553Q 6 14,4 18 2X 22 4 13-QILP SOT141R 107
TDA1554Q 6 14,4 18 4X 11 2 17-QILP SOT243R 107
TDA1554Q BTL 6 14,4 18 2X 22 4 17-QILP SOT243R 107
TDA1555Q 6 14,4 18 4X 11 2 17-QILP SOT243R 107
TDA1555Q BTL 6 14,4 18 2X 22 4 17-QILP SOT243R 107
TDA1556Q 6 14,4 18 2X 22 4 17-QILP SOT243R 107
TDA1557Q 6 14,4 18 2X 22 4 17-QILP SOT243R 107
TDA1558Q 6 14,4 18 4X 11 2 17-QILP SOT243R 108
TDA1558Q BTL 6 14,4 18 2X 22 4 17-QILP SOT243R 108
TDA1560Q 8 14,4 30 40 8 17-QILP SOT243R 108
TDA1562Q 14,4 70 8 17-SILP 108
TDA1904 9 14 20 4,5 4 16DIP 108
TDA1905 4 24 30 5,5 4 16-DIP 108
TDA1908 4 24 30 8 8 12-QIP+b TDA1908A 108
TDA1908A 4 22 30 8 8 12-QIP+a TDA1908 108

AUDIO POWER AMPLIFIER

157

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

TDA2002 4 14,4 18 8 2 TO-220/5 TDA2003 109
TDA2002H,V 4 14,4 28 8 2 TO-220/5 109
TDA2003 8 14,4 18 12 2 TO-220/5 109
TDA2003(MOSNA) 8 14,4 18 18 4 109
TDA2004 8 14,4 18 2X 6,5 4 11-SQL K174YH15 109
TDA2004 8 14,4 18 2X11 1,6 11-SQL K174YH15 109
TDA2004-BTL 8 14,4 18 18 4 11-SQL 109
TDA2005 8 14,4 18 2X12 2 11-SQL 109
TDA2005-BTL 8 14,4 18 22 1,6 11-SQL 109
TDA2006 I ± 6 ± 12 ± 15 12 4 TO-220/5 TDA2006 109
TDA2006 II (MOSNA) ± 6 ± 12 ± 15 24 8 TO-220/5 TDA2006 109
TDA2006 III ± 6 ± 12 ± 15 8 8 TO-220/5 TDA2006 110
TDA2007 7,5 15 22 2X 6 8 9-SIL 110
TDA2007A 8 18 28 2X 6 4 9-SIL 110
TDA2007A-BTL 8 18 26 14 8 9-SIL 110
TDA2008 I 10 22 28 12 4 TO-220/5 ULN3702Z 110
TDA2008 II (MOSNA) 10 22 28 20 8 TO-220/5 110
TDA2009,S 8 23 28 2X 11 4 11-SQL 110
TDA2009A 8 24 28 2X 12,5 4 11-SQL 110
TDA2009A-BTL 8 23 28 20 4 11-SQL 110
TDA2010 ± 5 ± 14 ± 18 12 4 14-DIP+c TDA2020 111
TDA2020 ± 5 ± 18 ± 22 20 4 14-DIP+c MDA2020 111
TDA2020D ± 5 ± 20 ± 25 45 4 14-DIP+c MDA2020 111
TDA2025 12 32 48 40 8 TO-220/7 111
TDA2030 I ± 6 ± 14 ± 18 14 4 TO-220/5 109
TDA2030 II (MOSNA) ± 6 ± 14 ± 18 28 8 TO-220/5 109
TDA2030 III ± 6 ± 14 ± 18 9 8 TO-220/5 110
TDA2040 I ± 2,5 ± 16 ± 20 22 4 TO-220/5 109
TDA2040 II (MOSNA) ±2,5 ± 16 ± 20 30 8 TO-220/5 109
TDA2040 III ±2,5 ± 16 ± 20 12 8 TO-220/5 110
TDA2050V I ± 4,5 ± 22 ± 25 32 8 TO-220/5 111
TDA2050V II 111
TDA2051V I ± 2,5 ± 18 ± 25 40 4 TO-220/5 111
TDA2051V II 111
TDA2052 ± 5 ± 18 ± 25 30 4 T0-220/7 111
TDA2610,A 15 25 38 4...7 10 16-DIP+c 111
TDA2611A 6 23 35 5 15 9-SIL SOT110B 111
TDA2612 10 26 35 10 4 16-DIP+c 111
TDA2613 15 24 42 8 8 9-SIL SOT110B 112
TDA2613 ± 7,5 ± 12 ± 20 6 8 9-SIL SOT110B 112
TDA2614 15 24 42 8,5 8 9-SIL SOT110 112
TDA2614 ± 7,5 ± 12 ± 20 6 8 9-SIL SOT110 112
TDA2615 ± 7,5 ± 12 ± 21 2X 6 8 9-SIL SOT110 112
TDA2616 ± 7,5 ± 16 ± 21 2X 12 8 9-SIL SOT131 112
TDA2616Q ± 7,5 ± 16 ± 21 2X 12 8 9-SQL SOT151 112
TDA2822 6 9 15 2X 1,7 4 16-DIP 112
TDA2822 -MOSNA 6 9 15 3,2 8 16-DIP 112
TDA2822D 1,8 6 15 2X 0,38 8 8-MDIP 112
TDA2822D -MOSNA 1,8 6 15 0,8 16 8-MDIP 112
TDA2822M 1,8 9 15 2X 0,3 32 8-DIP 112
TDA2822M -MOSNA 1,8 9 15 1 32 8-DIP 112
TDA2824 3 6 15 2X 0,65 4 16-DIP 113
TDA2824 BTL 3 6 15 1 8 16-DIP 113
TDA2824S 3 9 15 2X 1,7 4 9-SIP 113
TDA2824S BTL 3 9 15 3,2 8 9-SIP 113
TDA2870 5 14,4 20 9 2 TO-220/7 113
TDA3000 9 24 26 15 4 TO-220/7 113
TDA4920 4 9 18 2X 3 2 9-SIL TDA4925 113
TDA4920 BTL 4 9 18 6 4 9-SIL TDA4925 113
TDA4925 6 14,4 25 2X 5,2 4 9-SIL 113
TDA4925 BTL 6 14,4 25 5,4 4 9-SIL 113
TDA4930 8 19 22 2X 10 4 9-SIL TDA4935 113
TDA4930 BTL 8 19 22 20 4 9-SIL TDA4935 113
TDA4935 8 24 32 2X 15 4 9-SIL 113
TDA4935 BTL 8 24 32 30 4 9-SIL 113
TDA7050 1,6 3 16 2X 70mW 32 DIL-8 SOT97 113
TDA7050 1,6 3 16 140 32 8-DIP SOT97 114
TDA7050 BTL 1,6 3 16 140mW 32 8-MDIP SO8 113
TDA7050T BTL 1,6 3 16 140mW 32 8-MDIP SO8 114
TDA7052A 4,5 6 18 1 8 8-DIP SOT97 114
TDA7052AT 4,5 6 18 0,55 8 8-MDIP SO8 114
TDA7053 3 6 18 2X 1,2 8 16-DIP SOT38 114
TDA7053A 4,5 6 18 2X 1 8 16-DIP SOT38 114
TDA7053AT 4,5 6 18 2X 0,55 8 16-MDIP SO8 114
TDA7055Q 3 12 18 2X 6 4 114
TDA7056 3 11 18 3 16 9-SIL SOT110 114
TDA7056A 4,5 12 18 3,5 16 9-SIL SOT110 114
TDA7056B 4,5 12 18 3,5 16 9-SIL SOT110BE 114
TDA7057AQ 4,5 12 18 3,5 16 13-QILP SOT141 114
TDA7057Q 3 11 18 3 16 13-QILP SOT141 114

158

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

TDA7230A 1,8 3 6 2X 48mW 16 16-DIP 115
TDA7231 1,8 3 / 9 16 0,11/1,6 4 8-DIP 115
TDA7233 1,8 9 15 1,6 4 8-DIP 115
TDA7233D 1,8 6 / 9 15 0,7 / 1,6 4 8-MDIP 115
TDA7233S 1,8 12 15 1,9 8 9-SIL 115
TDA7235 9 / 12 16 1,6 / 1,8 ### 8-DIP 115
TDA7236 0,9 1,25 1,8 2X 17mW 32 8-DIP 115
TDA7236D 0,9 1,25 1,8 2X 17mW 32 8-MDIP 115
TDA7240A 9 14,4 28 20 4 TO-220/5 115
TDA7241,B 9 14,4 28 20 4 TO-220/5 116
TDA7245 12 14 30 5 4 18-DIP 116
TDA7245A 12 16,5 30 6 4 18-DIP 116
TDA7246 12 22 30 14 4 TO-220/7 116
TDA7250 ± 10 ± 35 ± 45 2X 50 4 20-DIP 116
TDA7253 10 26 32 8 8 11-QILP 116
TDA7255 8 14,4 28 2X 1 2 15-SQL 116
TDA7255-BTL 8 14,4 28 22 4 15-SQL 116
TDA7256 8 14,4 28 30 2 11-SQL 117
TDA7261 ± 5 ± 20 ± 22,5 25 8 8-SIL 117
TDA7262 8 28 35 2X 20 4 11-SQL 117
TDA7263 10 28 32 2X 12 8 11-SILP 117
TDA7263M 10 28 32 2X 12 8 11-QILP 117
TDA7264 ± 5 ± 20 ± 22.5 2X 25 8 8-SIL 117
TDA7265 ± 5 ± 20 ± 22.5 2X 25 8 11-SQL 117
TDA7266,S 3 11 18 2X 5 8 15-SQL 117
TDA7266M 3 11 18 7 8 15-SQL 117
TDA7267 4,5 12 18 2 8 DIL-8 118
TDA7267A 5 14,5 18 3 8 16-DIL 118
TDA7268 4,5 12 18 2X 2 8 16-DIL 118
TDA7269 ± 10 ± 14 ± 32 2X 10 8 11-SQL 118
TDA7269A I - II ± 10 ± 14 ± 32 2X 14 8 11-SQL 118
TDA7285 1,8 3 6 2X 50mW 16 20-DIP 119
TDA7285D 1,8 3 6 2X 50mW 16 20-MDIP 119
TDA7293V ± 12 ± 40 ± 50 100 8 15-SQL 118
TDA7294 ± 10 ± 33 ± 40 100 6 15-SQL 118
TDA7295 ± 10 ± 22 ± 40 80 4 15-SQL 118
TDA7296A ± 10 ± 18 ± 35 60 4 15-SQL 118
TDA7297 6 16,5 18 2x 15 8 15-SQL 118
TDA7298 ± 6 ± 20 ± 22 28 8 TO-220/7 119
TDA7299 I - II ± 10 ± 14 ± 32 2x 6 8 11-SQL 118
TDA7350 8 14,4 18/28 2X 11 2 11-SQL 119
TDA7350-BTL 8 14,4 18/28 22 4 11-SQL 119
TDA7353 8 14,4 18/28 2X 13 1,6 11-SQL 119
TDA7353-BTL 8 14,4 18/28 28 4 11-SQL 119
TDA7360 8 14,4 18/28 2X 12 1,6 11-SQL 119
TDA7360-BTL 8 14,4 18/28 22 3,2 11-SQL 120
TDA7363 10 14,4 32 28 3,2 11-SQL 120
TDA7365 8 14,4 28 2X 6 4 15-SQL 120
TDA7370 I 8 14,4 18/28 4X 6,5 4 15-SQL 120
TDA7370 II BTL 8 14,4 18/28 2X 20 4 15-SQL 120
TDA7374B 8 14,4 18/28 2X 21 4 15-SQL 120
TDA7375H,V 8 14.4 18 2X 25 4 15-SQL 120
TDA7376B 8 14,4 18 2X25 4 15-SQL 120
TDA7382 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7383 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7384A 8 14,4 18 4X 25 4 25-QILP spec. 121
TDA7385 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7386 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7390 8 14,4 18 35 / 25 2 / 4 11-SQL 121
TDA7391 8 14,4 18 32 3,2 11-SQL 121
TDA7396 8 14,4 18 45 / 27 2 / 4 11-SQL 121
TDA7454 8 14,4 18 60 / 35 2 / 4 25-QILP spec. 121
TDA7480 ± 10 ± 10,5 ± 16 4….8 10 DIL-20 121
TDA7481 ± 10 ± 15 ± 25 4….8 18 15-SQL 122
TDA7482 ± 10 ± 15 ± 25 4….8 25 15-SQL 122
TDA7490 ± 10 ± 16 ± 25 2X 25 4 25-QILP spec. 126
TDA7494 11 21 35 10 8 15-SQL 122
TDA7495 11 28 35 2X 11 8 15-SQL 122
TDA7496 10 22 32 2X 5,5 8 15-SQL 122
TDA7496L 10 14 18 2X 2 8 20-DIL 122
TDA7497 11 28 35 2X 10+16 2x8+6 17-SQL 126
TDA7499 ± 5 ± 14 ± 18 2X 6 8 11-SQL 122
TDA8510J 6 15 18 2X 13+25 2+2+2 17-QILP SOT243-1 123
TDA8541 4,5 5 18 1 8 8-DIL 123
TDA8541T 4,5 5 18 0,55 8 8-MDIL 123
TDA8542 2,2 5 18 2X 1 8 16-DIL SOT97-1 123
TDA8542T 2,2 5 18 2X 1 8 16-MDIL 123
TDA8542TS 2,2 5 18 2X 0,7 16 20-MDIL SOT163-1 123
TDA8543 4,5 5 18 2,2 8 16-DIP 123
TDA8543T 4,5 5 18 1,2 8 16-MDIL 123

AUDIO POWER AMPLIFIER

159

Vcc.min Vcc.nom Vcc.max P-out RL. ku}I{te orginal zamena str.

T I P

V V V W ohm

TDA8547 2,2 5 18 2X 1 8 16-DIL 123
TDA8547T 2,2 5 18 2X 1 8 16-MDIL 123
TDA8547TS 2,2 5 18 2X 1 8 20-MDIL 124
TDA8551,T 2,7 5 5,5 1 8 8-DIL 124
TDA8551,T 1,9 2-6/6-18 30 0,14 25 16-DIL 124
TDA8559,T 1,9 2-6/6-18 30 2X 35mW 32 16-DIL 124
TDA8560Q 8,5 14,4 18 2X 40 2 13-QILP SOT141-6 124
TDA8561TH I - II 6 14,4 18 4X 12 2 20-MDIP SOT418-2 124
TDA8561TH I - II 6 14,4 18 2X 24 4 20-MDIP SOT418-2 124
TDA8564Q I 6 14,4 18 2X 24 4 17-QILP SOT243-1 124
TDA8564Q II 6 14,4 18 4X 12 2 17-QILP SOT243-1 125
TDA8565Q 6 14,4 18 4X 12 2 17-QILP SOT243-1 125
TDA8566Q 6 14,4 18 2X 25 4 17-QILP SOT243-1 125
TDA8566Q 6 14,4 18 2X 40 2 17-QILP SOT243-1 125
TDA8581 I - II 6 14,4 18 4 / 8 17-QILP SOT243-1 125
TDA8581 III 6 14,4 18 4 / 8 17-QILP SOT243-1 125
TDA8920J ± 15 ± 30 2X 50 8 17-QILP SOT243-1 127
TDA8944J 6 12 18 2X 7 8 17-QILP SOT243-1 128
TDA8945S 6 18 25 15 8 17-QILP SOT243-1 128
TEA2024 8 12 20 3X 3,5 4 10-SIL 129
TEA2025B 3 9 15 2X2,3 4 14-DIP 129
TEA2025B BTL 3 9 15 4,7 8 14-DIL 129
U2431B 3 6 8 2X 0,22 16 9-SIP U2432 129
U2432B 1,8 4,5 10 2X 0,7 8 9-SIP U2433 129
U2433B 1,8 4,5 10 2X 0,7 8 9-SIP U2432 129
U2433B BTL 1,8 4,5 10 1,4 8 9-SIP 129
U2822B 1,8 4,5 10 2X 0,7 8 8-DIP U2823B 130
U2823B 1,8 4,5 10 2X 0,7 8 8-DIP U2822B 130
U2823B BTL 1,8 4,5 10 1,4 8 8-DIP 130
U410B 3 9 15 1,1 8 8-DIP 130
U411B 3 9 15 1 8 8-DIP 130
U412B 3 9 16 1 8 8-DIP 130
U413B 3 9 16 1 8 8-DIP 130
U413FB 3 9 16 1 8 8-MDIP 130
U420B 3 9 16 1 8 8-DIP 130
U820B 3 9 16 1,1 8 8-DIP 130
U821B 3 9 16 1 8 8-DIP 130
uA706 6 12 16 5,5 4 12-QIP+a 130
UL 1481T 4 14,4 25 7 4 12-QIP+A TBA810AS 99
UL1401L 11 16 1 8 TO3/9 131
UL1401P 11 16 1 8 12-DIP 130
UL1403L 18 25 3 8 TO3/9 131
UL1403P 18 25 3 8 12-QIP+b 131
UL1405L 22 27 5 8 TO3/9 131
UL1461 13,2 18 3 4 12-DIP 131
UL1480P 24 30 5 16 12-QIP+a 131
UL1481P 14,4 20 6 4 12-QIP+a 131
UL1482K 3,5 9 16 2 4 12-QIP TBA820 99
UL1490N 9 12 0,65 15 14-DIP 131
UL1491R 6 9 12 1,2 8 14-DIP 131
UL1492R 6 12 15 2,1 8 14-DIP 131
UL1493R 6 9 12 2,1 4 14-DIP 131
UL1495N 9 12 0,65 15 14-DIP 131
UL1496R 6 9 12 1,2 8 14-DIP 131
UL1497R 6 12 15 2,1 8 14-DIP 131
UL1498R 6 9 12 2,1 4 14-DIP 131
ULN2274B 9 18 2X 1 14 QIP+b 132
ULN2277 9 30 2X 2 15 QIP+b 132
ULN2278B 9 22 2X 2 16 QIP+b 132
ULN2280B 9 26 2,5 17 QIP+b 131
ULN2281B 9 32 4 18 QIP+b 131
ULN2283B 3 9 15 1,2 19 8DIP 132
ULN3701Z 8 18 10 20 TO-220/5 ~TDA2003 132
ULN3702Z 8 26 12 21 TO-220/5 ~TDA2008 132
ULN3703Z I - II 8 18 10 22 TO-220/5 133
ULN3705M 1,8 6 9 0,6 23 8-DIP 132
ULN3718BM 1,8 3…6 9 0,43 8-DIP 133
ULN3750B 3 14 2X 2,3 8 QIP+b 132
ULN3782M 1,8 6 9 2X 0,6 16 8-DIP 132
ULN3784B 9 28 5 8 QIP+b 131
ULN3793W 8 12 18 20 8 12-SILP 132
ULX3777 1,8 9 15 2X 1,2 4 12-SIL 133
ULX3788W 8 14,4 18 20 4 12-SIL 133
UPC1020H 9 13,2 17 5,2 4 10-SIL 134
UPC1025H 9 13,2 17 4,8 4 10-SIL 134
UPC1030H 9 13,2 17 5,8 4 10-SIL 134
UPC1154H 9 13,2 17 4,8 4 10-SIL 1341
UPC1155H 9 13,2 17 5,8 4 10-SIL 134
UPC1156H 9 13,2 17 5,8 4 10-SIL 134
UPC1177H 4,5 6 10 2X 3,5 4 12-SIL 134

160

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. kucist orginal zamena str.

T I P

V V V W ohm

UPC1181H 9 13,2 16 5,8 4 7-SILP 134
UPC1182H 9 13,2 16 5,8 4 7-SILP 134
UPC1185H(H2) 9 13,2 18 2X 5,8 4 12-SILP 135
UPC1188H ± 17 ± 22 ± 28 18 8 10-SILP 135
UPC1212C 3,5 6 9 1 4 8-DIP+g 135
UPC1213C 4,5 9 11 2,4 4 8-DIP+g 135
UPC1218H 2,2 3 10 0,25 8 8-SIP 135
UPC1225H ± 36 ± 50 12-SIL uPC1270H 135
UPC1230H(H2) 9 13 25 20 4 12-SILP 135
UPC1238H ± 6,5 ± 13 ± 18 12,5 4 TO-220/5 TDA2030 135
UPC1241H 9,5 13,2 16 9,2 2 8-SIL 136
UPC1242H 9 13,2 16 9,2 2 8-SIL 136
UPC1260G 1,8 3 4,5 2X 40mW 32 20-MDIP 136
UPC1263C 6 9 12 2X 2 4 14-DIP+g KA2214 136
UPC1270H ± 36 ± 50 12-SIL uPC1225H 135
UPC1274V 9 13,2 25 20 4 15-SQL 136
UPC1277H 9 14,4 18 2X 4,2 4 12-SIL 136
UPC1278H 6 9 20 2X 2,5 4 12-SIL 136
UPC1280V 9 13 18 20 4 15-SQL 136
UPC1288V 6 12 20 2X 7 40 14-SQL 137
UPC1308V 9 13,2 16 15 4 14-SQL 137
UPC1310V 9 13,2 16 2X 5,8 4 14-SQL 137
UPC1316C 3 12 16 2X 2 8 14-DIP+g 137
UPC1318AV 9 13,2 16 20 4 14-SQL 137
UPC1321V 9 13,2 16 20 8 15-SIL 137
UPC1331V 5 9 12 2X 2,2 8 14-SILP 137
UPC1332V 7 12 16 2X 4 8 14-SILP 137
UPC1335V 6 15 20 2X 7 4 14-SQL 137
UPC2002 8 13,2 18 5,4 4 TO220/5 TDA2002 109
UPC2005 8 13,2 18 2X 5,5 3,2 11-SQL TDA2005 109
UPC563 9 13,2 17 5,2 4 10-SIL 133
TDA7285 1,8 3 6 2X 50mW 16 20-DIP 119
TDA7285D 1,8 3 6 2X 50mW 16 20-MDIP 119
TDA7293V ± 12 ± 40 ± 50 100 8 15-SQL 118
TDA7294 ± 10 ± 33 ± 40 100 6 15-SQL 118
TDA7295 ± 10 ± 22 ± 40 80 4 15-SQL 118
TDA7296A ± 10 ± 18 ± 35 60 4 15-SQL 118
TDA7297 6 16,5 18 2x 15 8 15-SQL 118
TDA7298 ± 6 ± 20 ± 22 28 8 TO-220/7 119
TDA7299 I - II ± 10 ± 14 ± 32 2x 6 8 11-SQL 118
TDA7350 8 14,4 18/28 2X 11 2 11-SQL 119
TDA7350-BTL 8 14,4 18/28 22 4 11-SQL 119
TDA7353 8 14,4 18/28 2X 13 1,6 11-SQL 119
TDA7353-BTL 8 14,4 18/28 28 4 11-SQL 119
TDA7360 8 14,4 18/28 2X 12 1,6 11-SQL 119
TDA7360-BTL 8 14,4 18/28 22 3,2 11-SQL 120
TDA7363 10 14,4 32 28 3,2 11-SQL 120
TDA7365 8 14,4 28 2X 6 4 15-SQL 120
TDA7370 I 8 14,4 18/28 4X 6,5 4 15-SQL 120
TDA7370 II BTL 8 14,4 18/28 2X 20 4 15-SQL 120
TDA7374B 8 14,4 18/28 2X 21 4 15-SQL 120
TDA7375H,V 8 14.4 18 2X 25 4 15-SQL 120
TDA7376B 8 14,4 18 2X25 4 15-SQL 120
TDA7382 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7383 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7384A 8 14,4 18 4X 25 4 25-QILP spec. 121
TDA7385 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7386 8 14,4 18 4X 22 4 25-QILP spec. 121
TDA7390 8 14,4 18 35 / 25 2 / 4 11-SQL 121
TDA7391 8 14,4 18 32 3,2 11-SQL 121
TDA7396 8 14,4 18 45 / 27 2 / 4 11-SQL 121
TDA7454 8 14,4 18 60 / 35 2 / 4 25-QILP spec. 121
TDA7480 ± 10 ± 10,5 ± 16 4….8 10 DIL-20 121
TDA7481 ± 10 ± 15 ± 25 4….8 18 15-SQL 122
TDA7482 ± 10 ± 15 ± 25 4….8 25 15-SQL 122
TDA7490 ± 10 ± 16 ± 25 2X 25 4 25-QILP spec. 126
TDA7494 11 21 35 10 8 15-SQL 122
TDA7495 11 28 35 2X 11 8 15-SQL 122
TDA7496 10 22 32 2X 5,5 8 15-SQL 122
TDA7496L 10 14 18 2X 2 8 20-DIL 122
TDA7497 11 28 35 2X 10+16 2x8+6 17-SQL 126
TDA7499 ± 5 ± 14 ± 18 2X 6 8 11-SQL 122
TDA8510J 6 15 18 2X 13+25 2+2+2 17-QILP SOT243-1 123
TDA8541 4,5 5 18 1 8 8-DIL 123
TDA8541T 4,5 5 18 0,55 8 8-MDIL 123
TDA8542 2,2 5 18 2X 1 8 16-DIL SOT97-1 123
TDA8542T 2,2 5 18 2X 1 8 16-MDIL 123
TDA8542TS 2,2 5 18 2X 0,7 16 20-MDIL SOT163-1 123
TDA8543 4,5 5 18 2,2 8 16-DIP 123
TDA8543T 4,5 5 18 1,2 8 16-MDIL 123

AUDIO POWER AMPLIFIER

161

Vcc.min Vcc.nom Vcc.max P-out RL. kuciste orginal zamena str.

T I P

V V V W ohm

TDA8547 2,2 5 18 2X 1 8 16-DIL 123
TDA8547T 2,2 5 18 2X 1 8 16-MDIL 123
TDA8547TS 2,2 5 18 2X 1 8 20-MDIL 124
TDA8551,T 2,7 5 5,5 1 8 8-DIL 124
TDA8551,T 1,9 2-6/6-18 30 0,14 25 16-DIL 124
TDA8559,T 1,9 2-6/6-18 30 2X 35mW 32 16-DIL 124
TDA8560Q 8,5 14,4 18 2X 40 2 13-QILP SOT141-6 124
TDA8561TH I - II 6 14,4 18 4X 12 2 20-MDIP SOT418-2 124
TDA8561TH I - II 6 14,4 18 2X 24 4 20-MDIP SOT418-2 124
TDA8564Q I 6 14,4 18 2X 24 4 17-QILP SOT243-1 124
TDA8564Q II 6 14,4 18 4X 12 2 17-QILP SOT243-1 125
TDA8565Q 6 14,4 18 4X 12 2 17-QILP SOT243-1 125
TDA8566Q 6 14,4 18 2X 25 4 17-QILP SOT243-1 125
TDA8566Q 6 14,4 18 2X 40 2 17-QILP SOT243-1 125
TDA8581 I - II 6 14,4 18 4 / 8 17-QILP SOT243-1 125
TDA8581 III 6 14,4 18 4 / 8 17-QILP SOT243-1 125
TDA8920J ± 15 ± 30 2X 50 8 17-QILP SOT243-1 127
TDA8944J 6 12 18 2X 7 8 17-QILP SOT243-1 128
TDA8945S 6 18 25 15 8 17-QILP SOT243-1 128
TEA2024 8 12 20 3X 3,5 4 10-SIL 129
TEA2025B 3 9 15 2X2,3 4 14-DIP 129
TEA2025B BTL 3 9 15 4,7 8 14-DIL 129
U2431B 3 6 8 2X 0,22 16 9-SIP U2432 129
U2432B 1,8 4,5 10 2X 0,7 8 9-SIP U2433 129
U2433B 1,8 4,5 10 2X 0,7 8 9-SIP U2432 129
U2433B BTL 1,8 4,5 10 1,4 8 9-SIP 129
U2822B 1,8 4,5 10 2X 0,7 8 8-DIP U2823B 130
U2823B 1,8 4,5 10 2X 0,7 8 8-DIP U2822B 130
U2823B BTL 1,8 4,5 10 1,4 8 8-DIP 130
U410B 3 9 15 1,1 8 8-DIP 130
U411B 3 9 15 1 8 8-DIP 130
U412B 3 9 16 1 8 8-DIP 130
U413B 3 9 16 1 8 8-DIP 130
U413FB 3 9 16 1 8 8-MDIP 130
U420B 3 9 16 1 8 8-DIP 130
U820B 3 9 16 1,1 8 8-DIP 130
U821B 3 9 16 1 8 8-DIP 130
uA706 6 12 16 5,5 4 12-QIP+a 130
UL 1481T 4 14,4 25 7 4 12-QIP+A TBA810AS 99
UL1401L 11 16 1 8 TO3/9 131
UL1401P 11 16 1 8 12-DIP 130
UL1403L 18 25 3 8 TO3/9 131
UL1403P 18 25 3 8 12-QIP+b 131
UL1405L 22 27 5 8 TO3/9 131
UL1461 13,2 18 3 4 12-DIP 131
UL1480P 24 30 5 16 12-QIP+a 131
UL1481P 14,4 20 6 4 12-QIP+a 131
UL1482K 3,5 9 16 2 4 12-QIP TBA820 99
UL1490N 9 12 0,65 15 14-DIP 131
UL1491R 6 9 12 1,2 8 14-DIP 131
UL1492R 6 12 15 2,1 8 14-DIP 131
UL1493R 6 9 12 2,1 4 14-DIP 131
UL1495N 9 12 0,65 15 14-DIP 131
UL1496R 6 9 12 1,2 8 14-DIP 131
UL1497R 6 12 15 2,1 8 14-DIP 131
UL1498R 6 9 12 2,1 4 14-DIP 131
ULN2274B 9 18 2X 1 14 QIP+b 132
ULN2277 9 30 2X 2 15 QIP+b 132
ULN2278B 9 22 2X 2 16 QIP+b 132
ULN2280B 9 26 2,5 17 QIP+b 131
ULN2281B 9 32 4 18 QIP+b 131
ULN2283B 3 9 15 1,2 19 8DIP 132
ULN3701Z 8 18 10 20 TO-220/5 ~TDA2003 132
ULN3702Z 8 26 12 21 TO-220/5 ~TDA2008 132
ULN3703Z I - II 8 18 10 22 TO-220/5 133
ULN3705M 1,8 6 9 0,6 23 8-DIP 132
ULN3718BM 1,8 3…6 9 0,43 8-DIP 133
ULN3750B 3 14 2X 2,3 8 QIP+b 132
ULN3782M 1,8 6 9 2X 0,6 16 8-DIP 132
ULN3784B 9 28 5 8 QIP+b 131
ULN3793W 8 12 18 20 8 12-SILP 132
ULX3777 1,8 9 15 2X 1,2 4 12-SIL 133
ULX3788W 8 14,4 18 20 4 12-SIL 133
UPC1020H 9 13,2 17 5,2 4 10-SIL 134
UPC1025H 9 13,2 17 4,8 4 10-SIL 134
UPC1030H 9 13,2 17 5,8 4 10-SIL 134
UPC1154H 9 13,2 17 4,8 4 10-SIL 1341
UPC1155H 9 13,2 17 5,8 4 10-SIL 134
UPC1156H 9 13,2 17 5,8 4 10-SIL 134
UPC1177H 4,5 6 10 2X 3,5 4 12-SIL 134

162

AUDIO POWER AMPLIFIER

Vcc.min Vcc.nom Vcc.max P-out RL. kuciste orginal zamena str.

T I P

V V V W ohm

UPC1181H 9 13,2 16 5,8 4 7-SILP 134
UPC1182H 9 13,2 16 5,8 4 7-SILP 134
UPC1185H(H2) 9 13,2 18 2X 5,8 4 12-SILP 135
UPC1188H ± 17 ± 22 ± 28 18 8 10-SILP 135
UPC1212C 3,5 6 9 1 4 8-DIP+g 135
UPC1213C 4,5 9 11 2,4 4 8-DIP+g 135
UPC1218H 2,2 3 10 0,25 8 8-SIP 135
UPC1225H ± 36 ± 50 12-SIL uPC1270H 135
UPC1230H(H2) 9 13 25 20 4 12-SILP 135
UPC1238H ± 6,5 ± 13 ± 18 12,5 4 TO-220/5 TDA2030 135
UPC1241H 9,5 13,2 16 9,2 2 8-SIL 136
UPC1242H 9 13,2 16 9,2 2 8-SIL 136
UPC1260G 1,8 3 4,5 2X 40mW 32 20-MDIP 136
UPC1263C 6 9 12 2X 2 4 14-DIP+g KA2214 136
UPC1270H ± 36 ± 50 12-SIL uPC1225H 135
UPC1274V 9 13,2 25 20 4 15-SQL 136
UPC1277H 9 14,4 18 2X 4,2 4 12-SIL 136
UPC1278H 6 9 20 2X 2,5 4 12-SIL 136
UPC1280V 9 13 18 20 4 15-SQL 136
UPC1288V 6 12 20 2X 7 40 14-SQL 137
UPC1308V 9 13,2 16 15 4 14-SQL 137
UPC1310V 9 13,2 16 2X 5,8 4 14-SQL 137
UPC1316C 3 12 16 2X 2 8 14-DIP+g 137
UPC1318AV 9 13,2 16 20 4 14-SQL 137
UPC1321V 9 13,2 16 20 8 15-SIL 137
UPC1331V 5 9 12 2X 2,2 8 14-SILP 137
UPC1332V 7 12 16 2X 4 8 14-SILP 137
UPC1335V 6 15 20 2X 7 4 14-SQL 137
UPC2002 8 13,2 18 5,4 4 TO220/5 TDA2002 109
UPC2005 8 13,2 18 2X 5,5 3,2 11-SQL TDA2005 109
UPC563 9 13,2 17 5,2 4 10-SIL 133
UPC571C ± 12 6,5 8 14-DIP 133
UPC575C2 9 13,2 20 2 8 8-DIP+h 134
UPC576H 12 18 27 3,5 8 10-SIL 134
UPC578C ± 12 ± 15 7 8 14-DILP 134
XR-T65119 2 5 16 0,25 32 8-DIP 133

163

AUDIO POWER AMPLIFIER

DIC = keramik-ceramic

SDIP = raspon pin. 1,78mm

DIP(DIL) = ras.pin. 2,54mm

DILP

DIP / QIP+c

DIP / QIP+f

SILP / QILP

DIP/ QIP+c

DIP(DIL)

DIP / QIP+h

DIP / QIP+d DIP / QIP+j

QIP

SILP QILP

MDIP(MDIL) FLATP SIP

SIL

DIP / QIP+b DIP / QIP+a

SQL

MSIP

AUDIO POWER AMPLIFIER

1

165

SQP

QILP+spec

QIP+s

HZIP-

QILP

Flexiwatt 25

HZIP-7

KIA-kuciste ...specTO-220/

TO-100

4021A 4029

TO-3/4 TO-3/9

QILP-spec.

4032

166

AUDIO POWER AMPLIFIER

4033 4034 4035

4040

4042

4047

4048

4051A

4053A

4061

4082

4083A

4062

4083

4075

4070

4092 4093

4121 QILP-25

AUDIO POWER AMPLIFIER

STK4905

4147

167

5G31A,B,C

5G37

AN214,P,Q/SF214

AN313

AN 272

AN315

AN374

AUDIO POWER AMPLIFIER

AN5260

3

AN5265

AN5270

AUDIO POWER AMPLIFIER

AN5272

AN5273

4

AN5274

AN5275

AN5276/AN5277

AN5278

AN7102S

AUDIO POWER AMPLIFIER

5

AN7105

AN7106K

6

AN7108

AUDIO POWER AMPLIFIER

AN7110/AN7130

AN7111/AN7131/AN7140

AN7112

AN7116

AN7114/AN7115

AN7117

AUDIO POWER AMPLIFIER

AN7118

6

AN7118S

7

AN7120

AN7124

AUDIO POWER AMPLIFIER

AN7125

AN7133N

8

AN 7134NR

AN 7135

AN 7139/AN7148

AN7147N/AN7149N

AUDIO POWER AMPLIFIER

9

AN7142

AN7143

AUDIO POWER AMPLIFIER

AN7145H,L,M/AN7146H,M

AN7150/AN7154

AN7151/AN7155

10

AN7156N

AN7158N/AN7166

AN7161

AN7162K

AN 7161N

AN7163

AN7164

AUDIO POWER AMPLIFIER

AN7164N

11

AN7168/AN7169/AN7176

AN7176-BTL

AN7170

AN7171NK/AN7173NK/AN7176K

AN7561Z

12

AUDIO POWER AMPLIFIER

AN7174K

AN7178

AN7177

AN7188K

AN7190NK/7190NZ

AN7194K/AN7194Z

AN7198Z

AN7195K/AN7195Z

AUDIO POWER AMPLIFIER

13

AN7199Z AN7510/AN7510S

AN7510SH

AUDIO POWER AMPLIFIER

AN7511/AN7511S

AN7512SH

AN7512/AN7512S

AN7513/AN7513S

14

AN7522

AN7523

AN7550NZ/AN7551Z

Inverted pin layout of

AN7550NZ on right and left pins

AN7535NSA

AUDIO POWER AMPLIFIER

AN7555Z/AN7560Z

15

BA3506A/BA3516

AUDIO POWER AMPLIFIER

BA501

BA514

BA511/BA521/BA532

BA515

16

BA5152F

BA518/BA547

BA5206BF

BA5204/BA5204F

BA524/BA534

BA5208AF

AUDIO POWER AMPLIFIER

17

BA526/BA527/BA546 BA5302A/BA5304

BA5386

BA5404

BA535/536/5402,A/5406/5408/54021

BA5410

18

AUDIO POWER AMPLIFIER

BA5412/BA5413/BA5415A/BA5416

BA5415ABTL/BA5416-BTL

BA5417

BA5417-BTL

CA3020/CA3020A

CX20089A

CA3131/CA3132

AUDIO POWER AMPLIFIER

CX20172

19

CXA1189M CXA1289M

CXA1622P/CXA1622M

AUDIO POWER AMPLIFIER

CXA1622P/CXA1622M-MOSNA

20

CXA8008P

ESM1231C

ESM231

ESM1432/ESM1532C/ESM1632C/ESM1732C

ESM432N/ESM532N/ESM632N

ESM432C/ESM532C/ESM632C

AUDIO POWER AMPLIFIER

ESM732C

p

21

GML005 GML006

GML007

GML024

GML008

GML025

22

AUDIO POWER AMPLIFIER

GML026

GML040

HA13001

HA13008/HA13108

HA1306W

HA1310/HA1313/HA1314/HA1316

HA1308/HA1309

HA13102

HA13104

AUDIO POWER AMPLIFIER

HA13115

23

HA13116/HA13117/HA13118 HA13119

HA13127/HA13128/HA13130/HA13135

HA1312

AUDIO POWER AMPLIFIER

HA1322W

HA1317,V,W,VU,WU

HA1324

24

HA13150A/HA13151/HA13152/HA13155

AN374

HA13158A/HA13159

AUDIO POWER AMPLIFIER

25

AN 272

HA13156

AUDIO POWER AMPLIFIER

HA13153A/HA13154A

HA1325

HA1329

26

HA1338

HA1339A,AR/HA1342A,AR

HA1339AR/HA1342AR REVERSE PINNING

HA1345V

HA1368,R

HA1350/HA1370

HA1361

HA1368R REVERSE PINNING

HA1371

AUDIO POWER AMPLIFIER

HA1366W,WR

HA1366WR REVERSE PINNING

27

HA1367A

AUDIO POWER AMPLIFIER

HA1372

HA1377,A/HA1398

HA1374/HA1374A

HA1384/HA1388

28

HA1389R REVERSE PINNING

HA1389,R

HA1392

HA1393

HA1395

HA1394

HA1396

HA1397

AUDIO POWER AMPLIFIER

HA2214

29

HLX1402R HLX1403R

IR3R22

IX0365CE

IX0250CE

IX01020

30

AUDIO POWER AMPLIFIER

KA2201,A,B,N

KA2202/KA2207

KA2203

KA2204

KA2205

KA22062

KA2206B/KA22061

KA2206B-BTL/KA22061-BTL

KA2209B

AUDIO POWER AMPLIFIER

KA2209-BTL

31

KA22065 KA2210

KA2211

KA2212

KA2210-BTL

KA2214

32

AUDIO POWER AMPLIFIER

KA22103

KA22101

KB4433A

KD-28

KIA62051H

KIA6210AH/KIA6216H

KIA6220H

KIA6221AH

AUDIO POWER AMPLIFIER

33

KIA6227/KIA7227 KIA6248K

KIA6269P

KIA6278S

KIA6248K-BTL

KIA6280H

34

AUDIO POWER AMPLIFIER

KIA6281H

KIA6283K

KIA6419P

KIA7208

KIA7217,A,P

L165

KIA7299

L142

2 X L142-MOSNA VEZA

AUDIO POWER AMPLIFIER

35

L149

L133T

L272,M

L272,M-BTL

36

AUDIO POWER AMPLIFIER

L2750/L2750-BTL

LA4030/LA4031/LA4032

LA4050P/LA4051P

LA4100/LA4101/LA4102

LA4110/LA4112

LA4108

LA4120/LA4125/LA4125T

LA4126,T

AUDIO POWER AMPLIFIER

LA4137/LA4138

37

LA4140 LA4145/LA4146

LA4147

LA4170

LA4162

38

AUDIO POWER AMPLIFIER

GENERATOR

LA4175/LA4177/LA4178

LA4180/LA4182/LA4183

LA4185,T

LA4185T-BTL

LA4180/LA4182/LA4183-BTL

LA4190/LA4192

LA4195,T

AUDIO POWER AMPLIFIER

LA4200/LA4201

39

LA4220 LA4230/LA4250

LA4260/4261/LA4270

LA4275

LA4265

LA4280

40

AUDIO POWER AMPLIFIER

LA4282

LA4400

LA4420/LA4430

LA4422 I

LA4422 II

LA4425

LA4443

LA4440

AUDIO POWER AMPLIFIER

LA4440-BTL

41

LA4445 LA4445-BTL

LA4446

LA4450

LA4446 BTL

LA4460N

42

AUDIO POWER AMPLIFIER

LA4465/LA4466

LA4465 REVERSE PINNING

LA4461N

LA4467/LA4468

LA4468 REVERSE PINNING

LA4471/LA4476

LA4470/LA4475

LA4480

LA4485

LA4491/LA4496/LA4498

LA4490/LA4495/LA4497

AUDIO POWER AMPLIFIER

LA4500/LA4505

43

LA4500-BTL/LA4505-BTL

LA4507-BTL

LA4510

LA4508/LA4509

LA4520

44

AUDIO POWER AMPLIFIER

LA4530M

LA4530S

LA4533M/LA4534M

LA4535M/LA4537M

LA4540

LA4538M

5

AUDIO POWER AMPLIFIER

LA4550/LA4555

LA4550-BTL/LA4555-BTL

45

LA4557 LA4558

LA4557-BTL

LA4558-BTL

LA4560M

46

AUDIO POWER AMPLIFIER

LA4570,M I

LA4570,M II

LA4571MB

LA4597

LA4575/LA4575M

AUDIO POWER AMPLIFIER

LA4598

47

LA4580M

AUDIO POWER AMPLIFIER

LA4620

LA4630N

48

LA4700N

LA4705/LA4708

LA4725/LA4728

AUDIO POWER AMPLIFIER

49

LA4800V LA4805V

AUDIO POWER AMPLIFIER

LH0021

LH0041

LH0101

50

LH0021 LA0041

LM12

LM13080

LM1875

LM1895/LM2895

LM1893

LM2877/LM2878/LM2879

LM377N/LM378N/LM1877N..N8

AUDIO POWER AMPLIFIER

LM379S

51

LM1896 LM2896

52

AUDIO POWER AMPLIFIER

LM380N/LM384N

LM380N-8

4

8

LM383AT,T/LM2002A

LM386N-1/LM386N-3/LM386N-4

LM387N,AN

LM388N-1/LM388-2/LM388-3

AN387V

LM389

LM390N

AUDIO POWER AMPLIFIER

LM4701T

53

LM4752T LM4755T

LM4861/LM4862M,N

LM675

LM4871M,N

LM831 I

54

AUDIO POWER AMPLIFIER

LM831 II

LM831 III

LS045

M5106P

M51101L/M51102L

M5112Y

M51103L

M51182L

M5118L

AUDIO POWER AMPLIFIER

M51501L

55

M51503L M51512L

M51513L/M51513R

M51513R REVERSE PINNING

M51515L,BL/M51517L

M51514L

M51516L

56

AUDIO POWER AMPLIFIER

M51518L

M5155L

M5160/M51601L

M51602P

MA7307

MB3705

MB3713 REVERSE PINNING

MB3712/MB3713

MB3714A/MB3715A

MB3715A REVERSE PINNING

AUDIO POWER AMPLIFIER

MB3715A REVERSE PINNING

MB3730/3730A

57

MB3722

MB3731/MB3733

MB3735

MB3734

MB3736/MB3737A

58

AUDIO POWER AMPLIFIER

MB3742

MB3732

MC1306P

MC1316

MC13500T2

MC1454G/1554G

MC1438/MC1538

MC3360P

MC34119P,D

AUDIO POWER AMPLIFIER

MC13060

59

MFC9020 NE540L

NJM2073D

NJM2073S

NJM2073D-BTL

NJM2073S-BTL

60

AUDIO POWER AMPLIFIER

NJM2113D,L

NJM2135D,L

OPA2544T

2

OPA501

OPA502

OPA544 I

OPA511

OPA544 II

OPA547T

AUDIO POWER AMPLIFIER

PA04,A

61

PA26

PA246

SFC2790C

S1531,G I

S1531,G II

62

AUDIO POWER AMPLIFIER

SI1010G/SI1020G

SI

SI1020GL/SI1030GLSI1020GL/SI1030GL

SI1020H

SI1050G

SI1050GL

SI1125HD

SI1125H/SI1130H

AUDIO POWER AMPLIFIER

SL34

63

SL345 SL403D

SL402D

AUDIO POWER AMPLIFIER

SL415

SL414

SL630C

2

64

SL6310

SN16881ND

SN16922ND

SN76001ANQ

SN76001

SN76002

SN76003/SN76013

AUDIO POWER AMPLIFIER

SN76008/SN76018/SN76827/SN76829

65

STK011/STK015/STK016 STK020/STK027

STK013

AUDIO POWER AMPLIFIER

STK024/STK031/STK035

0

STK030

STK025

STK050,N/STK070,N

66

STK040/STK041/STK043

STK054/STK055/STK057

STK067/STK071

STK060/075/077/078/080/082/084/085/086

STK075G/077G/078G/080G/082G

STK078-105/STK082-105/STK085-105

AUDIO POWER AMPLIFIER

STK084G/STK085G/STK086G

67

STK1030/1035/1039/1040/1045/1050/1060/1070

AUDIO POWER AMPLIFIER

STK350-000/-010/-020/-030/-040/-050

68

STK400-010/-020/-030/-040/-050/-060/-070/-080/-090/-100/-110

STK400-210/-220/-230/-240/-250/-260/-270/-280/-290/-300/-310

AUDIO POWER AMPLIFIER

69

STK400-450/-460/-470/-480/-490/-500/-510/-520/-530

AUDIO POWER AMPLIFIER

STK400-650/-660/-670/-680/-690/-700/-710/-720/-730

70

STK401-010/-020/-030/-040/-050/-060/-070/-080/-090/-100/-110/-120/-130-140

STK401-210/-220/-230/-240/-250/-260/-270/-280/-290/-300/-310/-320/-330/-340

STK4024II/4026II/4028II/4030II/4032II/4034II/4036II/4038II/4040II/4042II/4044II

AUDIO POWER AMPLIFIER

71

AN 272

STK4024V/4026V/4028V/4030V/4032V/4034V/4036V/4038V/4040V/4042V/4044V

STK4046II/4048II/4050II

72

STK4046V/4048V/4050V

AUDIO POWER AMPLIFIER

STK4028X/4030X/4032X/4034X/4036X/4038X/4040X/4042X/4044X

STK4036XI/4038XI/4040XI/4042XI/4044XI

STK4046XI/4048XI

AUDIO POWER AMPLIFIER

73

STK4017/4019/4021/4023/4025 STK4065/STK4067

STK405-010/-030/-050/-70/-080/-100/-110/-120

74

AUDIO POWER AMPLIFIER

STK4101II/4111II/4121II/4131II

STK4100MK2/4110/4120/4130/4140/4150/4160/4170/4180/4190MK2

STK4100MK5/4110/4120/4130/4140/4150/4160/4170/4180/4190MK5

STK4102II/4112II/4122II/4132II/4142II/4152II/4162II/4172II/4182II/4192II

666N

STK4111V/21V/31V/41V/51V/61/71/81/91/STK4201V/4211V/4221V/4231V/4241V

AUDIO POWER AMPLIFIER

75

STK413/STK415

STK4141X/4151X/4161X/4171X/4181X/4191X4201X/42011X

AUDIO POWER AMPLIFIER

STK4144MK2/4154MK2/4164MK2/4174MK2/4184MK2/4194MK2

76
