HD IR Waterproof Network Dome Camera User’s Manual
Version 3.5.1
i
Welcome
Thank you for purchasing our Network camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!
ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC in the IEC60950-1.This series product supports PoE too. Please note:
Do not connect these two power supplying sources to the device at the same time; it may result
in device damage!
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding studs of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.
iii
Accessory Name
Amount
Network Camera Unit
1
Quick Start Guide
1
Installation Accessories Bag
1
CD
1
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the
device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
iv
Table of Contents
1 General Introduction .............................................................................................................. 1
1.1 Overview ................................................................................................................... 1
1.2 Features ................................................................ .................................................... 1
1.3 Specifications ........................................................................................................... 2
1.4 Factory Default Setup .............................................................................................. 3
2 Structure ................................................................................................................................. 8
2.1 Components ............................................................................................................. 8
2.2 Framework and Dimension ..................................................................................... 8
3 Device Installation ............................................................................................................... 10
3.1 Installation Steps .................................................................................................... 10
3.2 Restore Factory Default Setup Introduction ........................................................ 12
4 Quick Configuration Tool .................................................................................................... 13
4.1 Overview ................................................................................................................. 13
4.2 Operation ................................................................................................................ 13
5 Web Operation ..................................................................................................................... 15
5.1 Network Connection............................................................................................... 15
5.2 Login and Logout ................................................................................................... 15
6 FAQ ....................................................................................................................................... 17
Appendix Toxic or Hazardous Materials or Elements ............................................................. 18
1
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Storage
Function
Support central server backup function in accordance with your configuration
and setup in alarm or schedule setting
Support record via Web and the recorded file are storage in the client-end
PC.
Support network storage function such as FTP.
Network
Monitor
Network camera supports one-channel video data transmit to network
terminal and then decode. Delaying time is within 270ms (network bandwidth
support needed)
Max supports 20 connections.
Adopt the following video transmission protocol: HTTP, TCP, UDP,
MULTICAST, RTP/RTCP, RTSP and etc.
Support web access.
Network
Management
Realize network camera configuration and management via Ethernet.
Support device management via web or client-end.
Power
External power adapter DC 12V.
Support PoE.
Warning！
Do not connect these two power supplying sources to the device at the
same time; it may result in device damage!
Assistant
Function
Log function
Support system resource information and running status real-time display.
Day/Night mode auto switch.
Support picture parameter setup such as electronic shutter and gain setup.
Support motion detect.
Backlight compensation: screen auto split to realize backlight compensation
to adjust the bright.
Support video watermark function to avoid vicious video modification.
Built-in IR light. Support IR night vision.
The enclosure conforms to the IP 66 protection. Has the waterproof function.
1 General Introduction
1.1 Overview
This series network camera integrates the traditional camera and network video technology. It adopts
video data collection, transmission together. It can connect to the network directly without any auxiliary
device.
This series network camera uses standard H.264 video compression technology, which maximally
guarantees the video quality.
It supports the IR night vision function. In the night environments, the device can use the IR light to
highlight the object which is suitable for the surveillance function in the low illumination environments.
The waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for
use in the outdoor environments.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the
network and then use a network client-end. Due to its multiple functions and various uses, this series
network camera is widely used in many environments such office, bank, road monitor and etc.
1.2 Features
2
Model
Parameter
ICIP D2000IR
System
Main Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/2.8-inch CMOS
Pixel
1920(H)*1080(V)
Day/night
Support IR-CUT switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
Exposure Mode
Manual/Auto
PAL: It ranges from 1/3 to 1/10000
NTSC: It ranges from 1/4 to 1/10000
Video
Compression
Standard
H.264/JPEG/MJPEG
Video Frame
Rate
PAL:
Main stream(1920*1080@25fps)，extra stream(704*576@25fps)
NTSC:
Main stream(1920*1080@30fps),
extra stream,(704*480@30fps)
Video Bit Rate
48k~8192kbps
Bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The
6th level has the highest sensitivity)
Activation event: video storage, image snapshot, log, email function
and etc.
Record
and
Backup
Record Priority
Manual>External alarm >Video detect>Schedule
Storage
Management
Support FTP storage.
N
e
t
w
o
Wire Network
1-ch 10/100 M Ethernet , RJ45 port
1.3 Specifications
Please refer to the following sheet for network camera performance specification.
3
Network Protocol
HTTP, TCP/IP, ARP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP,
DNS, DDNS, PPPOE, IPv4/6, SNMP, UPNP, NTP
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Restore Default
Setup
Built-in Reset button
IR light
IR light 25M.
General Parameter
Power
DC12V power and PoE.
Warning！
Do not connect these two power supplying sources to the device
at the same time; it may result in device damage!
Power
Consumption
4.5W MAX
Working
Temperature
-10℃~+60℃
Working
Humidify
10%~90%
Dimensions(mm)
Φ 113×86
Weight
280g(Excluding box)
Installation
Fixed on the wall, ceiling and etc.
Setup
Item
Default Setup
ICIP D2000IR
Camera
Conditions
Brightness
50
Contrast
50
Sharpness
50
Saturation
50
Anti-flicker
Outdoor
Gain Mode
Auto
Gain Limit
0~50
Scene Mode
Auto
Day/night Mode
Auto
BLC
Off
Mirror
Off
Flip
Off
Video
Video bit stream
Main
Stream
Bit stream
type
General
Encode mode
H.264
Resolution
1080P(1920*1080)
Frame
Rate(FPS)
PAL: 25
NTSC:30
Bit Rate Type
CBR
Recommende
d Bit
3584-8192 Kb/S
1.4 Factory Default Setup
Please refer to the following sheet for factory default setup information.
4
Setup
Item
Default Setup
ICIP D2000IR
Bit Rate
8192
I Frame
interval
50
Watermark
Enable
Watermark
character
DigitalCCTV
Sub
Stream
Enable
Enable
Bit stream
type
General
Encode
mode
H.264B
Resolution
CIF(352*288)
Frame
Rate(FPS)
PAL: 25
NTSC:30
Bit Rate Type
CBR
Recommend
ed Bit
192-1024Kb/S
Bit Rate
1024
I Frame
interval
50
Snapshot
Snapshot
Type
General
Image Size
1080P（1920*1080）
Quality
Better
Interval
1s
Video Overlay
Privacy Mask
Disable
Channel Title
Enable
Time Title
Enable
Path
Snapshot
Path
C:\PictureDownload
Record Path
C:\RecordDownload
Network
TCP/IP
Host Name
IPC
Ethernet Card
Wire(Default)
Mode
Static
Mac Address
Device MAC address when it is shipped out of the
factory
IP Version
IPV4
IP Address
192.168.1.108
Subnet Mask
255.255.255.0
Default
Gateway
192.168.1.1
5
Setup
Item
Default Setup
ICIP D2000IR
Preferred
DNS
8.8.8.8
Alternate
DNS
8.8.8.8
Enable
ARP/Ping set
device IP
address
service
Enable
Connection
Max
Connection
10
TCP Port
37777
UDP Port
37778
HTTP Port
80
RTSP Port
554
Enable HTTP
Disable
HTTPs Port
443
PPPoE
Enable
Disable
Username
none
Password
N/A
DDNS
Server Type
Disable，CN99 DDNS
Server IP
none
Server Port
80
Domain
Name
none
User
none
Password
****
Update
Period
10 minutes
IP Filter
Trusted sites
Disable
SMTP(Email)
SMTP Server
none
Port
25
Anonymity
Disable
User Name
anonymity
Password
****
Sender
none
Authenticatio
n (Encryption
mode)
N/A
Title (Subject)
IPC Message
6
Setup
Item
Default Setup
ICIP D2000IR
Attachment
N/A
Mail Receiver
0 seconds
Email Test
Disable，interval=60 seconds
UPnP
Enable UPnP
Disable
SNMP
SNMP Port
161
Read
Community
public
Write
Community
private
Trap Address
N/A
Trap Port
162
SNMP
Version
SNMP v1:Disable
SNMP v2:Disable
SNMP v3:Disable
Bonjour
Enable
Enable
Server Name
Device factory SN
Multicast
Multicast
Address
239.255.42.42
Port
36666
QoS
Real-time
Monitor
0
Command
0
Event
Video detect
Motion Detect
Enable
Disable
Anti-dither
5 seconds
Sensitivity
3
Record
Channel
Enable
Record Delay
10 seconds
Send Email
Disable
Snapshot
Disable
Video
Masking
Enable
Disable
Record
Channel
Enable
Record Delay
10 seconds
Send Email
Disable
Snapshot
Disable
Storage
Storage
FTP
Enable FTP
Disable
Server IP
N/A
Port
21
Username
anonymity
Password
N/A
7
Setup
Item
Default Setup
ICIP D2000IR
Remote path
share
Emergency
(Local)
Disable
Record Control
Pack Duration
8 minutes
Pre-record
5 seconds
Disk Full
Overwrite
Record Mode
Auto
Bit Stream
Main Stream
System
General
Local Host
Device No
Device MAC address
Language
English
Video
Standard
PAL/NTSC
Date and time
Date Format
Y-M-D
Time Format
24H
Time Zone
GMT+08:00
System Time
Sync
DST
Disable
DST Type
Week
Start Time
00:00:00 of the first Sunday of the month
End Time
00:00:00 of the second Monday of the month
NTP
Disable
NTP Server
clock.isc.org
Port
37
Update
Period
10 minutes
Auto Maintenance
Auto Reboot
Enable
Auto Delete
Old Files
Disable
8
No.
Port
Name
Connector
Note
4
LAN
Network
port
Ethernet
To connect to standard
Ethernet.
5
DC12V
DC 12V
power
To connect to DC12V power
supply.
Component
Component Name
Component 1
Device lens
Component 2
Dome body
Component 3
Dome enclosure
2 Structure
2.1 Components
You can refer to the following figure for multiple-function combination cable information. See Figure
2-1.
Figure 2-1
Please refer to the following sheet for detailed information.
2.2 Framework and Dimension
9
Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and
Figure 2-3.
Figure 2-2
Figure 2-3
10
3 Device Installation
3.1 Installation Steps
Important
Before the installation, please make sure the installation environments can at least support 3x weight
of the camera.
Please follow the steps listed below to install the device. Please refer to Figure 3-1 for reference.
Step 1
Turn clockwise to remove the decoration ring from the snap joints.
Step 2
Please take the installation position map in the accessories bag, and then paste it on the ceiling or the
wall according to your monitor area requirements. Draw and then dig three plastic expansion bolts
holes in the installation surface and then insert three expansion bolts in the holes. Secure these three
bolts firmly. Please draw the cable out from the cable exit when you install the device.
Step 3
Adjust the device installation pedestal to the proper position and then line up the three screw holes in
the device pedestal to the three plastic expansion bolt holes in the installation position. Put the three
self-tapping screws in the three plastic expansion bolts firmly. Loosen the M3X8 cross recessed pan
head slot screw of the pedestal to unfasten the preforming. (Do not remove, loosen a little bit will be
OK.). Adjust the lens to the proper monitor angle and then use the original preforming to turn the M3X8
cross recessed pan head slot screw back.
Step4
Line up the three spigots of the decoration ring to the jags from the bottom to the top and then turn
clockwise until you hear a clear sound ”KA”. Now the installation is complete.
Figure 3-1
Important
Please pay attention to the dome camera direction when you are installing. Please refer to the
following figure for detailed information. See Figure 3-2.
11
Figure 3-2
Note
This series product supports two cable exits. One is from the bottom and the other is from the side.
Please refer to the following figure for cable exit from the side information.
Figure 3-3
Please earth the GND port of the device to enhance the device reliability. The GND port is near the
cable exit port on the rear of the dome. The GND screw uses the M2X5 pan screw.
12
Figure 3-4
3.2 Restore Factory Default Setup Introduction
Important
Please use RESET button when device is running.
Step1
Please refer to step1 and step2 in chapter 3.1to loose the dome body. Push a little bit; you can take
the dome body from the gland cover.
Step2
Take the dome body out and then turn the top cover hard to remove.
Step3
Slightly press the RESET button to complete the reset function. See Figure 3-5.
Step4
Turn the top cover back to the original position. Please make sure it reaches the original position,
otherwise it may result in water leakage!
Step5
Put the dome back to the gland cover. Please refer to step4 in chapter 3.1 to install the decoration ring
back.
Figure 3-5
13
4 Quick Configuration Tool
4.1 Overview
Quick configuration tool can search current IP address, modify IP address. At the same time, you can
use it to upgrade the device.
Please note the tool only applies to the IP addresses in the same segment.
4.2 Operation
Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 4-1.
In the device list interface, you can view device IP address, port number, subnet mask, default
gateway, MAC address and etc.
Figure 4-1
Select one IP address and then right click mouse, you can see an interface is shown as in Figure 4-2.
Select the “Open Device Web” item; you can go to the corresponding web login interface.
Figure 4-2
If you want to modify the device IP address without logging in the device web interface, you can go to
the configuration tool main interface to set.
14
In the configuration tool search interface (Figure 4-1), please select a device IP address and then
double click it to open the login interface. Or you can select an IP address and then click the Login
button to go to the login interface. See Figure 4-3.
In Figure 4-3, you can view device IP address, user name, password and port. Please modify the
corresponding information to login.
Please note the port information here shall be identical with the port value you set in TCP port in Web
Network interface. Otherwise, you cannot login the device.
If you are using device background upgrade port 3800 to login, other setups are all invalid.
Figure 4-3
After you logged in, the configuration tool main interface is shown as below. See Figure 4-4.
Figure 4-4
For detailed information and operation instruction of the quick configuration tool, please refer
to the Quick Configuration Tool User’s Manual included in the resources CD.
15
Input your IP
address here
5 Web Operation
This series network camera product supports the Web access and management via PC.
Web includes several modules: monitor channel preview, system configuration, alarm and etc.
5.1 Network Connection
Please follow the steps listed below for network connection.
Make sure the network camera has connected to the network properly.
Please set the IP address, subnet mask and gateway of the PC and the network camera
respectively. Network camera default IP address is 192.168.1.108. Subnet mask is 255.255.255.0.
Gateway is 192.168.1.1
Use order ping ***.***.***.***(* network camera address) to check connection is OK or not.
5.2 Login and Logout
Open IE and input network camera address in the address bar. See Figure 5-1.
Figure 5-1
The login interface is shown as below. See Figure 5-2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
16
Figure 5-2
If it is your first time to login in, system pops up warning information to ask you whether install control
webrec.cab or not after you logged in for one minute. Please click OK button, system can
automatically install the control. When system is upgrading, it can overwrite the previous Web too.
If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable
the control download. Or you can lower the IE security level.
After you logged in, you can see the main window. See Figure 5-3.
Figure 5-3
Please refer to the Web Operation Manual included in the resource CD for detailed operation
instruction.
17
Bug
I can not boot up
the device or
operate properly.
Please click RESET button for at least five seconds to restore
factory default setup.
The water leakage
occurred.
The unauthorized front or rear cap remove many result in water
leakage.
The glass front cap has sustained heavy push or strike.
The waterproof plug of the rear cap becomes loosen.
IR video is poor.
Do not use the proper supplying power. The IR light can not turn on
completely.
The object is out of the IR distance range of current device.
IR-CUT does not turn to the night mode. The photosensitive chip of
the front-end can not sense the IR light.
I can not upgrade
the device via
network.
When network upgrade operation failed, you can use port 3800 to
continue upgrade.
I can not login the
client-end or the
WEB.
For Windows OS 98 or Windows ME user, if you can not install the
client-end or can not view after the installation. We recommend the
win2000sp4 OS or install the client-end of the low version.
The Active X control is blocked.
The display card version shall be dx8.1 or higher.
Network connection error occurred.
Invalid network setup.
Invalid user name or password.
I can not play the
download file.
There is no player.
There is no DX8.1 or higher.
For the MEDIA PLAYER, there shall be Div X503Bundle.exe plugin
if you play the .AVI file.
For Windows XP user, you need to install the plugin
DivX503Bundle.exe and ffdsho-2004 1012.exe.
To guarantee
setup update
After you modified the important setup, please reboot the device via
the software to make sure the setup has been updated to the
storage medium.
Power adapter
The general power adapter can work ranging from 0℃ to 40 ℃. The
device may result in unstable power supply when the temperature
exceeds the working temperature.
Please replace an industry-level power adapter if you are using in
the harsh environments.
6 FAQ
18
Component
Name
Toxic or Hazardous Materials or Elements
Pb
Hg
Cd
Cr VI
PBB
PBDE
Circuit Board
Component
○ ○ ○ ○ ○
○
Device Case
○ ○ ○ ○ ○ ○
Wire and Cable
○ ○ ○ ○ ○ ○
Packing
Components
○ ○ ○ ○ ○
○
Accessories
○ ○ ○ ○ ○
○
Appendix Toxic or Hazardous Materials or Elements
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the
parts is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard. During the
environmental-friendly use period (EFUP) period, the toxic or hazardous substance or elements
contained in products will not leak or mutate so that the use of these (substances or elements) will not
result in any severe environmental pollution, any bodily injury or damage to any assets. The consumer
is not authorized to process such kind of substances or elements, please return to the corresponding
local authorities to process according to your local government statutes.
Note
This user’s manual is for reference only. Slight difference may be found in user interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks mentioned are the properties of their respective
owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
Loading...
