INSTRUCTION MANUAL Ver 1. 0

ICR-100X Speed Dome Camera

CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN THE COVERS.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONAL

This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

This Device compiles with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interface, and (2) This device must accept any interference received, including

interference that may cause undesired operations.

Speed Dome Camera Instruction Manual 2/57

Important Safety Guide

1. Read, heed and follow all the Instructions

Read all the safety and operating instructions before using the product.

2. Keep this manual

Keep this manual for reference in future.

3. Attachments / Accessories

Use only the attachments or accessories specified by the manufacturer.

4. Installation z Do not install near any heat resources such as radiators, heat registers, stoves, or other

appratus including amplifiers that product heat. Improperly installed product may fall, cause serious injury to a child or adult and damage the product.

z Do not block any ventilation holes or openings. Install in accordance with the

manufacturer’s instructions.

z Use only with the cart, stand, tripod, bracket, mounting devices, or table specified by

the manufacturer.

z Installation should be done only by qualified personnel and conform to all the

instructions by the manufacturer.

z Refer all servicing to qualified service personnel. z Unless the product is specifically marked as IP66, more than IP66 or confirmed by the

manufacturer, it is designed for indoor use only and it must not be installed where exposed to rain and moisture.

z Do not load on the product. z Use stainless steel hardware to fasten the mount. z To prevent damage from water leakage when installing a mount outdoors on a roof or

wall, apply sealant properly around holes.

z These servicing instructions are for use by qualified service personnel only. To reduce

the risk of electric shock, do not perform any servicing other that contained in the operationg instructions unless you are qualified to do so.

z Use only replacement parts specified by the manufacturer.

5. Power source

This product should be operated only from the type of the power source indicated on the marking label.

NOTICE

Speed Dome Camera Instruction Manual 3/57

Caution

 Operating

z Before using, make sure that the power supply and others are properly installed. z While operating, if any abnormal condition or malfunction is observed, stop using the

product immediately and then contact your local dealer.

 Handling

z Do not disassemble or tamper with the parts inside the product. z Do not drop or subject the product to shock and vibration as this can damage the

product.

z Care must be taken when you clean the clear dome cover. Especially, scratch and dust

will ruin the quality of the product.

 Installation and Storage

z Do not install the product in areas of extreme temperature, which exceed the allowable

range.

z Avoid installing in humid or dusty places. z Avoid installing in places where radiation is present. z Avoid installing in places where there are strong magnetic fields and electric signals. z Avoid installing in places where the product would be subject to strong vibrations.

NOTICE

Speed Dome Camera Instruction Manual 4/57

TABLE OF CONTENTS

① Introduction

Features 8 Package Components 10 Main Part Description 12

② Installation

DIP Switch Setup 14

In-Ceiling Mount Installation 17

Installation with Surface Mount Bracket

Installation with Ceiling Mount Bracket

Installation with Wall Mount Bracket

Installation with Ceiling Mount Bracket

Installation with Wall Mount Bracket

Wiring and Cabling 24

③ Operation

Check Point before Operation 27

Check Points for Preset and Pattern Function before Operation 27

OSD Menu 28

Reserved Preset (Hot Keys) 28

Preset 29

Swing 29

Pattern 30

Group 31

Other Functions 31

OSD Display 33

④ OSD Menu

Quick Programming Guide 34

Main Menu 34

Display Setup 35

Privacy Zone Mask Setup 36

Camera Setup 38

Motion Setup 42

Preset Setup 45

Swing Setup 47

Pattern Setup 48

Group Setup 49

System Initialize 52

⑤ Specifications

Dimension 56

Speed Dome Camera Instruction Manual 5/57

Fea tu re s

 Powerful Zoom Camera & Setup Options

z Image Sensor : Sony 1/4" Interline Transfer CCD z Zoom : ×10 Optical Zoom, ×10 Digital Zoom (MAX. ×100 Zoom Magnification)

z Day & Night, Privacy Mask and WDR (WDR Possible Models Only) z Various Focus Mode : Auto-Focus, Manual Focus, Semi-Auto Focus z Various Setup Options in OSD Menu.

 Powerful Pan/Tilt Functions

z MAX. 360°/sec High Speed Pan/Tilt Motion z With the Vector Drive Technology, Pan/Tilt motions are accomplished along the

shortest path. As a result, the time to target view is remarkably short and the video on the monitor is very natural in monitoring.

INTRODUCTION

z With the Micro-Stepping Control Technology, the video looks very natural at high

zoom magnification during a jog operation on a controller since the camera can be controlled by 0.05°/sec. Hence it is very easy to make the camera focus on desired target views at high zoom magnification. Additionally it is easy to make the camera focus on desired positions with zoom-proportional pan/tilt movement.

 Preset, Pattern, Swing, Group, Privacy Mask and More…

z MAX. 127 Presets are programmable and each preset can have its own parameter

values independently from the other presets. For an example, refer to the below table.

Preset No. White Balance Auto Exposure ••• Label Remarks

Preset 1 Case A Case 3 “ENTRANCE”

Preset 2 Case C Case 5 “WAREHOUSE”

Preset 3 Case V Case 2 “OFFICE”

•••

Preset 95 − − − − Reserved for OSD Menu

•••

Preset 128 Case K Case 9 “TERRACE”

z MAX. 8 sets of Swing are programmable. This function is that the camera moves

repetitively between two preset positions at programmed speeds.

z MAX. 4 Patterns are programmable. This function is that the camera memorizes the

path (mostly curve path) by the joystick of the controller and revives the trajectory operated by the joystick as closely as possible.

Speed Dome Camera Instruction Manual 8/57

z MAX. 8 sets of Group are programmable. This function is that the camera memorizes

the combination of Presets, Pattern and/or Swings sequently and runs Presets, Pattern and/or Swings repetitively. A Group can be combined upto 20 functions with any of Preset/Pattern/Swing.

z MAX. 4 Privacy Masks are programmable, not to intrude on any other’s privacy.

 PTZ(Pan/Tilt/Zoom) Control

z With the RS-485 communication connection, MAX. 255 units of cameras can be

connected to a single controller.

z Pelco-D or Pelco-P protocols can be selected as a control protocol in the current

firmware version.

 OSD(On Screen Display) Menu

z OSD menu is provided to display the status of camera and to configure the functions

interactively.

z The information such as Camera ID, Pan/Tilt Angle, Direction, Alarm Input and Preset

is displayed on screen.

INTRODUCTION

Alarm In/Out Function(Only for the models which have I/O function)



z 3 alarm sensor inputs and 1 alarm sensor outputs are available. z Alarm sensor input is decoupled with photo-couplers to avoid external electric noise

and shock perfectly.

z Both of N.O.(Normal Open) sensors and N.C.(Normal Close) sensors can be used and

the signal range of the sensor input is from DC 5.0V to 12.0V for various applications.

z The camera can be set to move to a Preset position or to run functions such as Pattern,

Swing and Group when there are external sensor activations. Also “Post Alarm” function is possible, which is supposed to activate after user-defined time period and sequentially in succession to the action by external sensor activations.

 Reserved Presets(Hot Keys)

z Most camera setup options can be set up easily and directly with the reserved presets

(Hot Keys), without entering into OSD menu. For more information, refer to “Reserved Presets(Hot Keys)” in this manual.

 Network Function(Only for the IP addressable models)

z Network functions including remote monitoring, bidirectional audio and others are

available through IP based network such as LAN, ADSL/VDSL, and Wireless LAN. For more information, refer to the separated manual for IP Addressable models.

Perfect Outdoor Environment Compatibility and Easy Installation



z The fans and heaters are built-in in the camera for cold and hot temperature

environment. Also idealistic mechanical design protects the camera from water and dust. (IP66 when installed properly with wall mount bracket only / Only for outdoor models)

z It is easy to install and repair the camera.

Speed Dome Camera Instruction Manual 9/57

Package Component

 Product & Accessories

INTRODUCTION

z Main Body & Surface Mount Bracket z Default Accessories

z Accessories for The Models with Alarm In/Out

Function [I/O Cable]

 Brackets (Optional)

[Main Cable, Calblock, Screws : Tapping M4×16,

Tapping M4×25, Machine M3×6, Machine M3×8]

z Accessories for The IP Addressable Models

[Crossover LAN Cable, Audio Cable, CD]

z Wall Mount Bracket

[Screws : Machine M3×8, Hex Lag #14×50]

Speed Dome Camera Instruction Manual 10/57

[Screws : Machine M3×8, Tapping M4×25]

z Ceiling Mount Bracket

Package Component

 Product & Accessories

z Main Body & Surface Mount Bracket z Default Accessories

INTRODUCTION

[Main Cable, Wrench]

z Accessories for The Models with Alarm In/Out

Function [I/O Cable]

 Brackets (Optional)

z Accessories for The IP Addressable Models

[Crossover LAN Cable, Audio Cable, CD]

z Wall Mount Bracket

[Screws : Machine M5×15, Hex Lag #14×50]

[Screws : Machine M5×15, Anchor Bolt

z Ceiling Mount Bracket

3/8"×70]

Speed Dome Camera Instruction Manual 11/57

Main Part Description

INTRODUCTION

Mounting Hook

DIP Switch

Mounting Screw Hole

Reset Switch (IP Model)

N Port (IP Model)

LA Audio Port (IP Model) Main Connector

Sensor I/O Port (I/O Model)

Dome Cover

z Dome Cover Do not detach the protection vinyl from the dome cover before

finishing all the installation process to protect the dome cover from scratches or dust.

z DIP Switch Used to set up camera IDs and protocols.

z Mounting Hook Used to assemble the main body with wall mount bracket or

ceiling mount bracket. Insert the mounting hooks into the holes on the surface of the main body and turn the main body.

z Mounting Screw Hole Used to assemble the main body with a bracket with screws.

z Main Connector Used fo r th e power wire, the video c abl e and the RS-485

communication cable connection.

z Sensor I/O Port Used for the sensor in/out connection. (The sensor I/O function

possible models only)

z LAN Port Used for the Ethernet connection. (IP addressable models only)

z Audio Port Used for the audio in/out connection. (IP addressable models only)

z Reset Switch Used to initialize all the network configurations to the factory

default. (IP addressable models only) Press the button for more than 5 seconds to initialize the network system.

Speed Dome Camera Instruction Manual 13/57

INSTALLATION

DIP Switch Setup

Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol.

 Camera ID Setup

12345678

z ID numbers of cameras are set up with binary numbers.

See the examples shown below.

Pin 1 2 3 4 5 6 7 8

Binary Value 1 2 4 8 16 32 64 128

ex) ID=5 on off on off off off off off ex) ID=10 off on off on off off off off

z The camera ID range is “1~255”. Camera ID must not be

“0”!

z The factory default of the camera ID is “1”. z Match the camera ID with the Cam ID setting of your DVR

or Controller to control the camera.

z If you are connecting a single camera to a controller,

terminate the camera. When connecting more than one camera to a single controller, terminate the last camera on the communication line. The last camera means the camera farthest in cable length from the controller.

z Note that the total length of the communication cable

between a controller and the camera(s) on the same communication line must be less than 1.2Km.

Speed Dome Camera Instruction Manual 14/57

 Communication Protocol Setup

z Select an appropriate Protocol with the DIP switch combination.

Switch Mode

INSTALLATION

Protocol

1234

(Pin 1)

(Pin 2)

(Pin 3)

OFF OFF OFF PELCO-D, 2400 bps

ON OFF OFF PELCO-D, 9600 bps

z Match the camera protocol with the camera protocol in the setting of

z Adjust the DIP switch after turning off the camera. If you changed the

z The factory default protocol is “Pelco-D, 2400 bps”.

OFF ON OFF PELCO-P, 4800 bps

ON ON OFF PELCO-P, 9600 bps

Others Reserved

your DVR or controller to control the camera.

camera protocol by changing the DIP S/W, the change will be effective after you reboot the camera.

Speed Dome Camera Instruction Manual 15/57

 Terminal Resistor Setup

he terminal resistor is used for the following cases.

z Case 1 : In case that the control cable length between a camera and

1234

z Case 2 : In case that multiple cameras are connected to a

INSTALLATION

a controller is relatively very long (1:1 Connection)

If the communication cable length is very long, the electrical signal will bound in the terminal point. This reflected signal causes distortion of original signal. Accordingly, the camera can be out of control. In this case, the terminal resistor of both sides i.e. the camera and the controller must be set to ‘ON’ state.

controller.

Due to similar reasons with the case 1, the terminal resister of the controller and the last camera must be set to ‘ON’ state. The last camera means the camera farthest in cable length from the controller. Do not turn on the terminal resistor of all the cameras on the same communication cable.

Controller

Terminal Resistor ON

RS-485

#1 #2 #n

Terminal Resistor

OFF

Terminal Resistor

OFF

Terminal Resisto

Speed Dome Camera Instruction Manual 16/57

INSTALLATION

Installation with Ceiling Mount Bracket (MPS/MPL Model)

① Remove the ceiling tile from the ceiling

and cut a hole whose diameter is 30~40mm on the ceiling tile to pass the wires and cables through to the upside of the ceiling mount bracket and attach the ceiling mount bracket on it. (Tapping M4×25)

② Pull the wires and cables for the system

as below. Turn the bracket adapter on its axis in CW(Clockwise) direction unitl it stops and screw the surface mount bracket. (Machine M3×8)

Bracket Adapter

Surface mount Bracket

Speed Dome Camera Instruction Manual 19/57

INSTALLATION

③ Connect the wires and cables to the ports

and install the main body. (Machine M3×8)

④ Align the dome cover stud with the dome

cover assembly stud and slightly push the dome cover to the ceiling. Turn the dome cover clockwise and screw on the dome cover lock-up screw. Then remove the protection vinyl from the dome cover. (Machine M3×6)

Important Notice

z Before starting the installation, make sure that the Camera ID and Protocol are set up properly. z When the pipe hole for wiring and cabling on side of the Surface Mount Bracket is not used, make sure

that the hole is properly sealed with the supplied Hole Plug.

z To adjust the installation height from the mounting surface, the pipe and coupler should be needed

between the surface mount part of the ceiling mount bracket and the camera mount part of the ceiling mount bracket. Note that they are not supplied by the manufacturer.

Speed Dome Camera Instruction Manual 20/57

Installation with Ceiling Mount Bracket

INSTALLATION

① Remove the ceiling tile from the ceiling

and cut a hole whose diameter is 30~40mm on the ceiling tile to pass the wire(s) and cable(s) through to the upside of the ceiling. (In case of the wiring and cabling through the mounting surface only) Then prepare the ceiling mount bracket. Pull the wire(s) for the system as below. (Anchor Bolt 3/8"×70)

② Pull the wire(s) and cable(s) for the

system as below. Wire the cable(s) to the ports. Insert the mounting hooks into the holes on the surface of the main body and turn the main body. Assemble the main both with the camera mount adaptor with the 3 screws. (Machine M5×15)

③ Screw the dome cover to the main body

and remove the protection vinyl from the dome cover.

Important Notice

z Before starting the installation, make sure that the Camera ID and Protocol are set up properly. z To adjust the installation height from the mounting surface, the pipe and coupler should be needed

between the surface mount part of the ceiling mount bracket and the camera mount part of the ceiling mount bracket. Note that they are not supplied by the manufacturer.

Speed Dome Camera Instruction Manual 22/57

Installation with Wall Mount Bracket

INSTALLATION

① Make a hole whose diameter is 30~40mm

on the mounting surface to pass the wire(s) and cable(s) through the mounting surface. (In case of the wiring and cabling through the mounting surface only) Then prepare the wall mount bracket. Pull the wire(s) and cable(s) for the system as below. Attach the wall mount bracket to the mounting surface. (Hex Lag #14×50)

② Pull the wire(s) and cable(s) for the

③ Screw the dome cover to the main body

and remove the protection vinyl from the dome cover.

Important Notice

z Before starting the installation, make sure that the Camera ID and Protocol are set up properly.

Speed Dome Camera Instruction Manual 23/57

 Video

z Use BNC coaxial cable only.

 Alarm Input

Internal

IN COM+

IN 1-

Sensor 1

+5V~12V

INSTALLATION

IN 3-

Sensor 3

Before connecting sensors, check driving voltages and output signal types of the sensors. Since output signal types of the sensors are divided into Open Collector type and Voltage Output type in general, the wiring must be done properly after considering those types.

Signal Description

IN COM+ The electric power source to drive input circuit. Connect the (+) wire of electric

power source to drive the Sensors to this port as shown in the above circuit.

IN1 -, IN2 -, IN3 - Connect the outputs of sensors to each port as shown in the above

circuit.

If you want to use Alarm Input, the types of sensors must be selected in OSD menu. The sensor types are divided into Normal Open and Normal Close. If wrong sensor types are selected, alarms should be activated reversely to sensor inputs.

~ Normal Open Output Voltage is high state when sensor is activated

~ Normal Close Output Voltage is high state when sensor is not activated

 Relay Output

Internal

OUT 1

AC or DC

LOAD

The maximum loads are as follows.

Power Type DC Power AC Power

Maximum Load MAX. DC 24V, 1A MAX. AC 125V, 0.5A

Speed Dome Camera Instruction Manual 26/57

OPERATION

Check Points before Operation

z Before turning on the system, check if the wire(s) and cable(s) are connected properly. z Check if the camera ID on the controller is properly selected. The camera ID must be

identical to that of the target camera. The camera ID can be checked by reading the DIP switch of the camera or on OSD.

z If your controller supports multi-protocols, the protocol must be changed to match to that of

the camera.

z Adjust the DIP switch after turning off the camera. If you changed the camera protocol by

changing the DIP S/W, the change will be effective after you reboot the camera.

z Since the operation method can be different by controllers, refer to your controller manual

if the camera can not be controlled properly. The operation of this manual is based on the standard Pelco® Controller.

Check Points for Preset and Pattern Function before Operation

z Check fully how to operate preset function and pattern function with your controller or DVR

in advance to operate the camera functions when using a controller or a DVR.

z Refer to the following table when using standard Pelco® protocol controllers.

< Go Preset > Input [Preset Number] and press [Preset] button shortly.

< Set Preset > Input [Preset Number] and keep pressing [Preset] button for more than 2 seconds.

< Run Pattern > Input [Pattern Number] and press [Pattern] button shortly.

< Set Patter n > Input [Pattern Number] and keep pressing [Pattern] button for more than 2 seconds.

z If your controller or DVR has no pattern button or function, use the Hot Keys with preset

numbers. For more information, refer to “Reserved Presets(Hot Keys)” in this manual.

Speed Dome Camera Instruction Manual 27/57

OPERATION

OSD Menu

z Function With OSD menu, the system can be properly configured for each

application.

z Entering into OSD Go Preset [95]

Reserved Presets (Hot Keys)

z Description Some Preset numbers are reserved to change some parameters without entering into

OSD menu.

z Hot Keys Go Preset [95] : Entering into OSD menu

Go Preset [131~134] : Running Pattern Function 1 ~ 4

Go Preset [141~148] : Running Swing Function 1 ~ 8

Go Preset [151~158] : Running Group Function 1 ~ 8

Go Preset [161] : Turning off Relay Output

Set Preset [161] : Turning on Relay Output

Go Preset [167] : Setting Zoom Proportional Function to ON

Set Preset [167] : Setting Zoom Proportional Function to OFF

Go Preset [170] : Setting Camera BLC Mode to OFF

Go Preset [171] : Setting Camera BLC Mode to ON

Go Preset [174] : Setting Camera Focus Mode to AUTO

Go Preset [175] : Setting Camera Focus Mode to Manual

Go Preset [176] : Setting Camera Focus Mode to SEMI-AUTO

Go Preset [177] : Setting Day & Night Mode to AUTO

Go Preset [178] : Setting Day & Night Mode to NIGHT

Go Preset [179] : Setting Day & Night Mode to DAY

Go Preset [190] : Setting OSD Display Mode to AUTO (Except Privacy Mask)

Go Preset [191] : Setting OSD Display Mode to OFF (Except Privacy Mask)

Go Preset [192] : Setting OSD Display Mode to ON (Except Privacy Mask)

Go Preset [193] : Setting all Privacy Mask Display to OFF

Go Preset [194] : Setting all Privacy Mask Display to ON

Speed Dome Camera Instruction Manual 28/57

OPERATION

Preset

z Function MAX. 127 positions are programmable. The Preset number can be

assigned from 1 to 128 except 95. Preset 95 is reserved for entering into OSD menu. Camera parameters such as White Balance, Auto Exposure and others can be set up independently and each preset can have its own parameter values independently from the other persets. When setting up presets with a controller, Label should be blank and "Camera Adjust" should be set to "GLOBAL" as the default. To change the parameters, enter into OSD menu.

z Setting Presets Set Preset [1~128]

z Running Presets Go Preset [1~128]

z Deleting Presets To delete Presets, enter into OSD menu.

Swing

z Function This function is that the camera moves repetitively between two

preset positions at programmed speeds. When a swing function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in CW(Clockwise) direction. Then the camera moves from the preset assigned as the 2nd point to the preset assigned as the 1st point in CCW(Counterclockwise) direction.

1st Preset

CCW

2nd Preset

In case that the preset assigned as the 1st point and the preset assigned as the 2nd point are same, the camera turns on its axis by 360° in CW(Clockwise) direction and then it turns back on its axis by 360° in CCW(Counterclockwise) direction. The Swing speed is defined from 1°/sec to 180°/sec.

z Setting Swings To set Swing, enter into OSD menu.

z Running Swings

Method 1) <Run Pattern> [Swing NO. + 10] Method 2) <Go Preset> [Swing NO. + 140]

ex) Run Swing 3 : <Run Pattern> [13] ex) Run Swing 3 : <Go Preset> [143]

z Deleting Swings To delete Swings, enter into OSD menu.

Speed Dome Camera Instruction Manual 29/57

OPERATION

Pattern

z Function This function is that the camera memorizes the path (mostly curve

path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible.

MAX. 4 Patterns are programmable and Maximum 1200 communication commands can be programmed in a pattern.

z Setting Patterns A Pattern can be created by the following methods.

Method 1) <Set Pattern> [Pattern NO.]

{ The Pattern programming window appears on the monitor as

below.

EDIT PATTERN 1

[NEAR:SAVE /FAR:DELETE] 0/0/x1/N

{ The movement by Joystick and the preset movement can be

memorized in a pattern.

{ After a pattern is programmed, the remaining storage is

displayed in progress bar on the screen.

{ To save the recording, press NEAR key and to cancel, press

FAR key.

Method 2) Programming in OSD Menu : See the section “How to use OSD Menu”.

z Running Patterns

Method 1) <Run Pattern> [Pattern NO.] Method 2) <Go Preset> [Pattern NO. + 130]

ex) Run Pattern 2 : <Run Pattern> [2] ex) Run Pattern 2 : <Go Preset> [132]

z Deleting Patterns To delete Patterns, enter into OSD menu.

Note) When the system memorizes Patterns, the commands are stored in the momories, not the positions of Pan/Tilt/Zoom. Hence there might be small differences between the original path and the revived path by path type of Patterns. Note that it is not a problem in position precision.

Speed Dome Camera Instruction Manual 30/57

OPERATION

Group

z Function This function is that the camera memorizes the combination of

Presets, Pattern and/or Swings sequently and runs Presets, Pattern and/or Swings repetitively. MAX. 8 sets of Group are programmable. Each group can have MAX. 20 actions which are the combination of Preset, Pattern and Swing. Preset speed can be set up and the repeat number of Pattern & Swing can be set up in Group setup. Dwell time between actions can be set up also.

Dwell Time

Preset 1 Pattern 1 Swing 1

Max 20 Entities

z Setting Groups To set Groups, enter into OSD menu.

z Running Groups

Method 1) <Run Pattern> [Group NO. + 20] Method 2) <Go Preset> [Group NO. + 150]

ex) Run Group 7 : <Run Pattern> [27] ex) Run Group 7 : <Go Preset> [157]

z Deleting Groups To delete Groups, enter into OSD menu.

Other Functions

z Power Up Action This setting defines a specific activity (Preset, Pattern, Swing and

Group) to be performed in the event that the power to the camera is cycled. This function enables the user to resume, after turning on power, the last action being executed before turning off the power. Most of actions such as Preset, Pattern, Swing and Group are available for this function but Jog actions are not available to resume.

z Auto Flip In case that tilt angle arrives at the top of tilt orbit(90°), zoom module

camera turns on its axis by 180° at the top of tilt orbit and moves to opposite tilt direction (180°) to keep tracing targets.

z Parking Action This feature allows the camera to begin a specified operation after a

programmed time of inactivity. This function makes the camera automatically run a pre-defined action if there is no command from controller for a pre-defined time period. “Wait Time” means how long a camera should wait for from the previous-last (most recent) command before running the pre-defined action. It can be set to 1 second ~ 3 hours.

Speed Dome Camera Instruction Manual 31/57

OPERATION

z Alarm Input 3 Alarm Inputs are available. When external sensors activate, the

camera runs pre-defined actions such as Preset, Pattern, Swing and Group. After the pre-defined time period passed, “Post Alarm” activates, which is pre-defined. Note that only the latest alarm input is effective when multiple sensors are activated at the same time.

z Privacy Zone Mask Privacy Zone Mask allows the user to program 4 rectangulars that

can not be viewed by the operator of the system. To protect others’ privacy, MAX. 4 Privacy Masks can be created on the arbitrary position to hide objects such as windows, shops or private house. With the Spherical Coordinates system, powerful Privacy Zone Mask function is possible. A mask area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.

z GLOBAL/LOCAL Image Setup

WB(White Balance) and AE(Auto Exposure) can be set up independently for each preset. There are 2 modes, "Global" mode & "Local" mode. The Global mode is that WB and/or AE are/is set up totally and simultaneously for all presets. The Global parameter setup such as WB and AE can be done in "ZOOM CAMERA SETUP" menu. The Local mode is that WB and/or AE are/is set up independently or separately for each preset. The Local parameter setup for WB and AE can be done in each preset setup menu. Each Local parameter such as WB and AE activates correspondingly when the camera arrives at each preset position. During jog operation, Global WB/AE value should be applied. All Local WB/AE values do not change although Global WB/AE value changes. The Local mode has the prior to the Global mode.

z Semi-Auto Focus This mode automatically exchanges focus modes between Manual

Focus mode and Auto Focus mode by operation. Manual Focus mode activates in preset operation and Auto Focus mode activates during jog operation. With Manual mode at presets, Focus data is memorized in each preset in advance and the camera calls focus data in correspondence with presets as soon as the camera arrives at presets. It should shorten time to get focuses. The focus mode automatically changes to Auto Focus mode when jog operation starts.

Speed Dome Camera Instruction Manual 32/57

OPERATION

OSD Display

Preset Label

Camera ID

LABEL12345 PRESET1

I:-2- O:1 CAM 1 15/4/x1/N

P/T/Z Information

Action Title

Alarm Information

z P/T/Z Information Displays the amount of pan from zero degree vertical, the amount of

tilt from zero degree horizontal and current compass direction. Also identifies the amount of the zoom magnification.

z Camera ID Displays the selected Camera ID (Address).

z Action Title

Identfies Actions

"SET PRESET xxx" When Preset xxx is memorized.

"PRESET xxx" When the camera reaches Preset xxx.

"PATTERN x" When Pattern x is in action.

"SWG×/PRESET xxx" When Swing x is in action. Displays both of Swing

number and Preset number.

"UNDEFINED" When a undefined function is called to run

z Preset Label Displays preset labels when the camera arrives at presets.

z Alarm Information Displays activated alarms. This information shows current state of

Alarm Inputs and Relay Outputs. If an Input point is ON state, it will show a number corresponding to each point. If an Input point is OFF state, '-' will be displayed.

Example) The point 2 & 3 of inputs are ON and Output is ON, OSD will show as below.

I:-23 O:1

Speed Dome Camera Instruction Manual 33/57

OSD MENU

Quick Programming Guide

z The menu items with < > always have sub-menus. z To go to submenus or make the cursor move to the right, press NEAR key. z To go to the previous-upper level menus, press FAR key. z To make a selection, press NEAR key z To cancel a selection, press FAR key z To move the cursor in the menu, use the joystick to the Up/Down direction or Left/Right

direction.

z To change a value of an item, use Up/Down of the joystick in the controller. z To save changes, press NEAR key.

z To cancel changes, press FAR key.

Main Menu

SPEED DOME CAMERA

----------------------- <SYSTEM INFORMATION> <DISPLAY SETUP> <DOME CAMERA SETUP>

EXIT

z System

Information

z Display Setup Enables the user to program how labels

z Dome Camera

Setup

z System Initialize Initializes all system configurations and

Displays the system information and configuration. The system setting can not be changed using the OSD menu and the information is for reference only.

are displayed on the monitor.

Enables the user to configure various functions of the camera.

all data to the factory default parameters.

Speed Dome Camera Instruction Manual 34/57

Display Setup

OSD MENU

DISPLAY SETUP

----------------------- CAMERA ID ON PTZ INFORMATION AUTO ACTION TITLE AUTO PRESET LABEL AUTO ALARM I/O AUTO <SET NORTH DIRECTION> <PRIVACY ZONE>

BACK EXIT

Display setup allows you to program how labels are displayed on the monitor. In case of AUTO, the labels are displayed on the monitor when there are any changes in parameters.

z Camera ID [ON/OFF]

Displays the selected Camera ID (Address).

z PTZ Information [ON/OFF/AUTO]

Displays the amount of pan from zero degree vertical, the amount of tilt from zero degree horizontal and current compass direction. Also identifies the amount of the zoom magnification.

z Action Title [ON/OFF/ AUTO]

Identfies Actions. "SET PRESET xxx" "PRESET xxx" "PATTERN x" "SWG/PRESET xxx" "UNDEFINED"

z Preset Label [O N/OFF/AUTO]

Displays the preset labels when the camera arrives at presets.

z Alarm I/O [ON/OFF/AUTO]

Displays the activated alarms. This information shows the current state of Alarm Inputs and Relay Outputs. If an Input point is ON state, it will show a number corresponding to each point. If an Input point is OFF state, '-' will be displayed.

Example) The point 2 & 3 of inputs are ON and Output is ON, OSD will show as below.

Speed Dome Camera Instruction Manual 35/57

I:-23 O:1

 Compass Direction Setup

OSD MENU

SET NORTH DIRECTION

------------------------

Move the camera to a target position and press NEAR button to save the direction as North. The direction is the reference direction to assign other compass directions.

MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL

Privacy Zone Mask Setup

PRIVACY ZONE

----------------------- MASK NO 1 UNDEFINED DISPLAY OFF CLEAR MASK CANCEL <EDIT MASK>

BACK EXIT

Privacy Zone Mask allows the user to program 4 rectangulars that can not be viewed by the operator of the system. To protect privacy, MAX. 4 Privacy Masks can be created on the arbitrary position to hide objects such as windows, shops or private house. With the Spherical Coordinates system, powerful Privacy Zone Mask function is possible. A mask area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.

z Mask NO [1~4]

Selects a Mask number to program. If the selected mask has already data, the camera moves as it was programmed. Otherwise, “UNDEFINED” will be displayed under the Mask number.

z Display [ON/OFF]

Sets if the mask of the selected mask number shows or not on the screen.

z Clear Mask [CANCEL/OK]

Deletes the mask data of the selected mask number.

Speed Dome Camera Instruction Manual 36/57

 Privacy Zone Mask Area Setup

OSD MENU

EDIT MASK 1

------------------------

MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL]

 Privacy Zone Mask Size Setup

EDIT MASK 1

------------------------

Move your camera to an area to mask. Then a mask and the menu to adjust the mask size will be displayed.

Adjusts the mask size. Use the joystick or the arrow buttons of your controller to adjust mask size.

z  (Left/Right) Adjusts the mask width.

z  (Up/Down) Adjusts the mask height.

[ :ADJUST MASK WIDTH] [ :ADJUST MASK HEIGHT]

[NEAR:SAVE /FAR:CANCEL]

Speed Dome Camera Instruction Manual 37/57

OSD MENU

Camera Setup

ZOOM CAMERA SETUP

----------------------- FOCUS MODE SEMIAUTO DIGITAL ZOOM ON IMAGE FLIP OFF SHARPNESS 16 <WHITE BALANCE SETUP> <AUTO EXPOSURE SETUP>

Sets the general functions of zoom camera module.

z Focus Mode [AUTO/MANUAL/SEMIAUTO]

Sets camera Focus mode. { SEMIAUTO Mode This mode automatically exchanges focus

modes between Manual Focus mode and Auto Focus mode by operation. Manual

BACK EXIT

Focus mode activates in preset operation and Auto Focus mode activates during jog operation. With Manual mode at presets, Focus data is memorized in each preset in advance and the camera calls focus data in correspondence with presets as soon as camera arrives at presets. It should shorten time to get

z Digital Zoom [ON/OFF]

focuses. Focus mode automatically changes to Auto Focus mode when jog operation starts.

Sets the digital zoom functions to ON/OFF. If this is set to OFF, the optical zoom function runs but the zoom function stops at the end of optical zoom magnification.

z Image Flip [ON/OFF]

Sets System Image Flip Function to ON/OFF. When this function is set to ON, flipped images always come out. When the camera is installed as Desktop type, set to ON to get proper images.

z Sharpness [0~31]

Sets image sharpness to enhance pictures.

Speed Dome Camera Instruction Manual 38/57

 White Balance Setup

OSD MENU

WB SETUP - GLOBAL

----------------------- WB MODE AUTO RED ADJUST -- BLUE ADJUST ---

BACK EXIT

z WB Mode [AUTO/MANUAL]

Retains color balance over a color temperature range. In auto mode, this feature automatically processes the viewed image. In Manual mode, Red and Blue level can be set up manually.

z Red Adjust [10~60]

Adjusts the picture output in the red range.

z Blue Adjust [10~60]

Adjusts the picture output in the blue range.

Speed Dome Camera Instruction Manual 39/57

 Auto Exposure Setup

OSD MENU

AE SETUP - GLOBAL

----------------------- BACKLIGHT OFF DAY/NIGHT <AUTO2> BRIGHTNESS 25 IRIS AUTO SHUTTER ESC AGC HIGH SSNR MIDDLE SENS-UP <AUTO> BACK EXIT

z Backlight [ON/OFF]

Sets Backlight Compensation to ON/OFF. If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. Backlight compensation enhances objects in the center of the picture. The camera uses the center of the picture to adjust the iris. If there is a bright light source outside of this area, it will wash out to white. The camera will adjust the iris so that the object in the sensitive area is properly exposed.

z Day/Night [AUTO1/AUTO2/DAY/NIGHT]

Sets Day&Night mode. You can increase sensitivity in low light conditions by switching to black-white mode (removing the IR cut filter or turning on DSS). Color mode is preferred in normal lighting conditions. The time to change a mode is 10 sec.

# AUTO1 Mode : The sensitivity to change a mode is fixed.

# AUTO2 Mode : The sensitivity to change Night mode to Day mode is adjustable. The sensitivity range is 1~255. The higher numeric value is selected, the lower illumination Night mode changes to Day mode at. If this is set to AUTO2 mode, ACG is fixed to HIGH.

z Brightness [0~100]

Adjusts the brightness of the images. Iris, The Shutter Speed and Gain are adjusted automatically in correspondence with each numeric value.

Speed Dome Camera Instruction Manual 40/57

OSD MENU

z IRIS [AUTO/MANUAL(0~100)]

Sets Iris to operate automatically or at a user-defined level. If Iris is set to Auto, Iris has higher priority in adjusting AE and Shutter Speed is fixed. Auto iris is the lens function that automatically opens closes the iris in response to changing light conditions.

If Iris is set to Manual, Iris is fixed and Iris

has lower priority in adjusting AE, in comparison with others. The Iris level range is 0 ~ 100.

z Shutter Speed [ESC/A.Flicker/Manual(×128~1/120000

sec)] Sets Shutter Speed. Shutter Speed is the

duration of the electronic shutter. If Iris is set to Manual and Shutter Speed is set to ESC, Shutter Speed has higher priority. If Shutter Speed is set to A.Flicker, to remove Flicker, Shutter Speed should be set to 1/100 sec. for NTSC and 1/120 for PAL.

z AGC [OFF/NORMAL/HIGH]

Sets AGC. This setting enhances image brightness automatically in case that luminance level of image signal is too low.

z SSNR [OFF/LOW/MIDDLE/HIGH]

Sets SSNR. This setting enhances the images by deducting noises when the gain level of the mages is too high.

z SENS-UP [AUTO(2~128)/OFF]

Sets SENS-UP. This setting activates Slow Shutter function when luminance of image (signal) is too dark.

Speed Dome Camera Instruction Manual 41/57

It is possible to set up the maximum number of frames piled up one on another by Slow Shutter function.

OSD MENU

Motion Setup

MOTION SETUP

----------------------- MOTION LOCK OFF PWR UP ACTION ON AUTO FLIP ON JOG MAX SPEED 120/SEC JOG DIRECTION INVERSE FRZ IN PRESET OFF <PARKING ACTION SETUP> <ALARM INPUT SETUP> BACK EXIT

Sets the general functions of Pan/Tilt motions.

z Motion

Lock

[ON/OFF] If Motion Lock is set to ON, it is impossible to

set up and delete Preset, Swing, Pattern and Group. It is possible only to run those functions. To set up and delete those functions, enter into OSD menu.

z Power Up

Action

z Auto Flip [ON/OFF]

[ON/OFF] Refer to “Other Functions" section.

Refer to “Other Functions" section.

z Jog Max

Speed

[1°/sec ~360°/sec] Sets the maximum jog speed. Jog speed is

inversely proportional to the zoom magnifications. As the zoom magnification goes up, the pan/tilt speed goes down.

z Jog

Direction

[INVERSE/NORMAL] Sets the Jog Direction. If this is set to

‘Inverse’, the view direction in the screen is same as the direction of joystick. If this is set to ‘Normal’, the view direction in the screen is the reverse dirction of joystick.

z Freeze

in Preset

[ON/OFF] Sets Frame Freeze Function. This feature

freezes the scene on the monitor when going to a preset. At the start point of a preset movement, a camera starts freezing the image of the start point. Camera keeps displaying the image of the start point during preset movement and does not display the images which camera gets during preset movement. As soon as camera stops at preset end point, camera starts displaying live images which it gets at the end preset point. This feature also reduces bandwidth when working with digital systems or digital network systems.

This function availability should be different by models.

Speed Dome Camera Instruction Manual 42/57

 Parking Action Setup

OSD MENU

PARKING ACTION SETUP

----------------------- PARK ENABLE OFF WAIT TIME 00:10:00 PARK ACTION HOME

BACK EXIT

This feature allows the camera to begin a specified action after a programmed time of inactivity.

z Park Enable [ON/OFF]

If Park Enable is set to ON, the camera runs an assigned function automatically if there is no PTZ command during the programmed "Wait Time".

z Wait Time [1~59 sec. / 1~180 min.]

Wait Time can be programmed from 1 second to 180 minutes.

z Park Action [HOME/PRESET/PATTERN/SWING/GROU

P/PREV ACTION] This feature defines the activity when the

camera parks. If Park Action is set to “HOME”, the camera moves to the home position which is memorized when the system boots. If Park Action is set to “PREV. ACTION”, the camera runs the previous action which it ran most recently.

Speed Dome Camera Instruction Manual 43/57

 Alarm Input Setup

OSD MENU

ALARM INPUT SETUP

----------------------- ALARM NO. 1

TYPE N.OPEN ACTION NOT USED HOLD TIME ENDLESS POST ACTION HOME

BACK EXIT

Defines Alarm Function. When an alarm is receive, an input signal to the camera triggers the user-defined action programmed for the alarm.

z Alarm No [1~3]

Selects a sensor number to set up.

z Type [Normal OPEN/Normal CLOSE]

Selects sensor operation type.

z Action [NOT

USED/PRESET/PATTERN/SWING/GROUP] Selects an action to run when a sensor

signal is input.

z Hold Time [ENDLESS / 1~59 SEC. / 1~180 MIN.]

Sets the time period for the action which is run by external sensor activation. After the time period passes, the action pre-defined in “Post Action” runs sequentially in succession to the action by external sensor activation. If this option is set to “ENDLESS”, “Post Action” does not activate.

z Post Action [HOME/PRESET/PATTERN/SWING/GROUP

/PREV ACTION] Selects the action that a camera will run

after the time period in“HOLD TIME” passes. If Post Action is set to “PREV. ACTION”, the camera runs the previous action which it ran most recently.

Speed Dome Camera Instruction Manual 44/57

OSD MENU

Preset Setup

PRESET SETUP

----------------------- PRESET NO. 1

CLR PRESET CANCEL <EDIT SCENE> <EDIT LABEL> LABEL123 RELAY OUT OFF CAM ADJUST GLOBAL

BACK EXIT

z Preset

Number

[1~128] Selects a preset number to set up. If a

selected preset is already defined, the camera moves to the pre-defined position and preset parameters such as Label and CAM Adjust show on the monitor. If a selected preset is not defined, “UNDEFINED” shows on the monitor.

z Clear

Preset

[CANCEL/OK] Deletes the data of the selected Preset.

z Edit

Preset Scene

z Edit

Preset Label

Re-defines the scene position of the selected Preset.

Edits the label of the selected Preset to show on the monitor when the preset runs. MAX. 10 alphanuberic characteristics are allowed.

z Relay Out Defines the relay output.

z CAM Adjust [GLOBAL/LOCAL]

Speed Dome Camera Instruction Manual 45/57

 Preset Scene Setup

OSD MENU

EDIT SCENE - PRESET 1

------------------------

MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL]

 Preset Label Setup

EDIT LABEL - PRESET 1

----------------------- [ ]

--------- 1234567890 OK ABCDEFGHIJ CANCEL KLMNOPQRST UVWXYZabcd efghijklmn opqrstuvwx yz<>-/:.

----------

○1 Use the Joystick to move the camera to a desired

position.

○2 Save the preset position by pressing NEAR key.

○3 Press FAR key to cancel targeting the preset position.

Edit the label of the selected preset to show on the monitor when camera arrives at the preset. In the Edit Label menu, the dark rectangular is the cursor. As soon as finishing selecting an alphabet or a number, the cursor moves to the next digit.

[ ]

Current Cursor Positio

① With Left/Right/Up/Down of the joystick, move to a

desired Alphabet or a desired number in the Alphanumeric set. To select a desired Alphabet or a desired number, press the NEAR key.

---------1234567890 ABCDEFGHIJ KLMNOPQRST UVWXYZabcd efghijklmn opqrstuvwx yz<>-/:.

----------

Back Space Char.Space Char.

If you want to use a blank, select the double quotation mark (" "). If you want to delete an Alphabet or a number, use the back space character (" ←").

② If you complete the Label editing, move the cursor to

"OK" and press the NEAR key to save the completed label. To abort the current change, move the cursor to "Cancel" and press the NEAR key.

Speed Dome Camera Instruction Manual 46/57

OSD MENU

Swing Setup

SWING SETUP

----------------------- SWING NO. 1 1ST POS. NOT USED 2ND POS. NOT USED

SWING SPEED 30/SEC CLEAR SWING CANCEL RUN SWING

BACK EXIT

z Swing

Number

z 1st Position 2nd Position

[1~8] Selects a Swing number to edit. If the

selected Swing is not defined, "NOT USED" is displayed in the 1st Position and the 2nd Position.

[PRESET 1~128] Sets the 2 positions for a Swing function. If

the selected preset is not defined, "UNDEFINED" is displayed as shown below.

SWING SETUP

----------------------- SWING NO. 1 1ST POS. PRESET5 2ND POS. NOT USED UNDEFINED

When a swing function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in CW(Clockwise) direction. Then the camera moves from the preset assigned as the 2nd point to the preset assigned as the 1st point in CCW (Counterclockwise) direction. In case that the preset assigned as the 1st point and the preset assigned as the 2nd point are same or only 1 Preset position is assigned, the camera turns on its axis by 360° in CW direction and then it turns on its axis by 360° in CCW direction.

z Swing

Speed

[1°/sec. ~180°/sec.] Defines Swing speed between the 2 Preset

positions from 1°/sec to 180°/sec

z Clear Swing [CANCE L/OK]

Deletes the data of the selected Swing.

z Run Swing Runs Swing for the test purposes to check

if it works properly.

Speed Dome Camera Instruction Manual 47/57

①

OSD MENU

Pattern Setup

PATTERN SETUP

----------------------- PATTERN NO. 1 UNDEFINED CLR PATTERN CANCEL RUN PATTERN <EDIT PATTERN>

BACK EXIT

 Pattern Edit

EDIT PATTERN 1

------------------------

z Pattern Number [1~4 ]

Selects a Pattern number to edit. If the selected pattern number is not defined, "UNDEFINED" will be displayed under the selected pattern number.

z Clear Pattern [CANCE L/OK]

Deletes the data of the selected pattern.

z Run Pattern Runs the Pattern for the test purposes to

check if it works properly.

z Edit Pattern Edits the selected pattern.

ith the Joystick of your controller, move the camera to the start position with an appropriate zoom magnafication. To start the pattern recording, press NEAR key. To exit, press FAR key.

MOVE TO START POSITION [NEAR:START /FAR:CANCEL]

EDIT PATTERN 1

[NEAR:SAVE /FAR:DELETE] 0/0/x1/N

② Move camera with joystick of controller or run preset

function to memorize the path (mostly curve path) in the selected pattern. The movement by Joystick and preset movement will be memorized in a pattern. After a pattern is programmed, the remaining storage is displayed in progress bar on the screen.

③ To save the data and exit, press NEAR key. To cancel

saving the data and delete the data, press FAR key.

Speed Dome Camera Instruction Manual 48/57

①

OSD MENU

Group Setup

GROUP SETUP

----------------------- GROUP NO. 1 UNDEFINED CLEAR GROUP CANCEL RUN GROUP <EDIT GROUP>

BACK EXIT

 Group Edit

EDIT GROUP 1

----------------------- NO ACTION ### DWELL OPT

----------------------- 1 NONE 2 NONE 3 NONE 4 NONE 5 NONE

----------------------- SAVE CANCEL [NEAR:EDIT]

z Group Number [1~8]

Selects a Group number to edit. If the selected Group number is not

defined, "UNDEFINED" will be displayed under the selected Group number.

z Clear Group [CANCEL/OK]

Deletes the data of the selected Group.

z Run Group Runs the Group for the test purposes to

check if it works properly.

z Edit Group Edit the selected Group.

Press Near key when the cursor is at “NO” to start editing the selected Group.

EDIT GROUP 1

----------------------- NO ACTION ### DWELL OPT

----------------------- 1 NONE 2 NONE 3 NONE 4 NONE 5 NONE

----------------------- SAVE [NEAR:EDIT ACT] CANCEL [FAR :EDIT END]

the cursor up/down to select an Action. Press Near key to edit.

Speed Dome Camera Instruction Manual 49/57

② Note that MAX. 20 actions are allowed in a Group. Move

④

③

OSD MENU

EDIT GROUP 1

----------------------- NO ACTION ### DWELL OPT

----------------------- 1 NONE 2 NONE 3 NONE 4 NONE 5 NONE

----------------------- SAVE [ :MOVE CURSOR] CANCEL [ :CHANGE VAL.]

EDIT GROUP 1

----------------------- NO ACTION ### DWELL OPT

----------------------- 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE 5 NONE

----------------------- SAVE [ :MOVE CURSOR] CANCEL [ :CHANGE VAL.]

Define Action, Dwell time and Option. Note that the dark rectangular is the cursor. Move the cursor Left/Right to select an item and move cursor Up/Down to change each parameter.

z Action ### [NONE/PRESET/SWING/PATTERN]

z DWELL [0 SEC. ~ 4 MIN.]

Sets the Dwell Time between functions.

z OPT Option. It is a preset speed when a

preset is selected in the Action. It is the number of repeat when a Pattern or a Swing is selected in the Action.

Edit the items such as Action, ###, Dwell and OPT by moving the cursor.

EDIT GROUP 1

----------------------- NO ACTION ### DWELL OPT

----------------------- 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE 5 NONE

----------------------- SAVE [NEAR:EDIT ACT] CANCEL [FAR :EDIT END]

⑤ After finishing editing a Action, press Near key to go to

the previous-upper level menu (Step ②). Move the cursor Up/Down to select an Action number and repeat Step ② ~ Step ④ to keep editing the selected Group.

Speed Dome Camera Instruction Manual 50/57

⑥

OSD MENU

EDIT GROUP 1

----------------------- NO ACTION ### DWELL OPT

----------------------- 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE 5 NONE

----------------------- SAVE CANCEL

After finishing setting up, press FAR key to exit. Then the cursor will move to “SAVE”. Press Near key to save the data.

Speed Dome Camera Instruction Manual 51/57

OSD MENU

System Initialization

SYSTEM INITIALIZE

----------------------- CLEAR ALL DATA NO CLR DISPLAY SET NO CLR CAMERA SET NO CLR MOTION SET NO CLR EDIT DATA NO REBOOT CAMERA NO REBOOT SYSTEM NO

BACK EXIT

 Factory Default

z Display Parameters z Camera Parameters

Camera ID ON Focus Mode SemiAuto PTZ Information AUTO Digital Zoom ON Action Title AUTO Image Flip OFF

z Clear All Data Deletes all configuration data and the system

is set to the factory default.

z Clear Display Set Initializes all the configuration data for Display. z Clear Camera Set Initializes all the configuration data for

Camera.

z Clear Motion Set Initializes all the configuration data for Motion. z Clear Edit Data Deletes all the configuration data for Preset,

Swing, Pattern and Group.

z Reboot Camera Reboots the zoom camera module. z Reboot System Reboots the system.

Preset Label AUTO Sharpness 16 Alarm I/O AUTO White Balance AUTO North Direction Pan 0° Backlight OFF Privacy Zone Undefined Day&Night AUTO2 Night→Day Level 176 Brightness 25 Iris AUTO Shutter ESC z Motion Parameters AGC HIGH Motion Lock OFF SSNR MIDDLE Power Up Action ON SENS-UP AUTO (4 Frame) Auto Flip ON Jog Max Speed 120°/sec z User-Defined Data Jog Direction INVERSE Preset 1~128 Undefined Freeze In Preset OFF Swing 1~8 Undefined Park Action OFF Pattern 1~4 Undefined Alarm Action OFF Group 1~8 Undefined

Speed Dome Camera Instruction Manual 52/57

SPECIFICATIONS

Specifications

CAMERA PART

Video Signal Format NTSC PAL

Image Sensor 1/4'' Interline Transfer CCD

Total Pixels 811 (H)×508(V) 410K 795(H)×596(V) 470K

Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K

Horizontal Resolution 500 TV Lines(Color), 570 TV Lines(B/W)

Video Signal-to-Noise 50 dB (AGC Off)

Zoom ×10 Optical Zoom, ×10 Digital Zoom

Forcal Length F1.8, f=3.8~38mm

Angle of View H : 51.2°(Wide)~5.58°(Tele) / V : 39.3°(Wide)~4.27°(Tele)

Zoom Speed 1.67 sec (Wide to Tele) 1.75 sec (Wide to Tele)

Minimum Illuminance 0.7 Lux (Color) / 0. 02 Lux (B/W), 50 IRE

Day & Night Auto / Day / Night(ICR)

Focus Auto / Manual / SemiAuto

Iris Auto / M anual

Shutter Speed ×128 ~ 1/120000 sec

AGC Normal / High / Off

White Balance Auto / Manual(Red, Blue Gain Adjustable. 1800°K~10500°K)

BLC Low / Middle / High / Off

Flickerless Selectable

SSNR Low / Middle / High / Off

Privacy Zone 4 Masks, Spherical Coordinate

Speed Dome Camera Instruction Manual 53/57

SPECIFICATIONS

MECHANISM PART

Movement Range

Speed

Preset 127 Presets (Label, Independent Camera Parameter Setting)

Pattern 4 Patterns [1200 Commands(Approx. 5 Minute) / Pattern]

Swing 8 Swings

Group

Other Pan/Tilt Functions Auto Flip, Auto Parking, Power Up Action and etc.

Communication RS-485

Protocol Pelco-D, Pelco-P Selectable

OSD English, Menu / PTZ information etc

Sensor Input 3 Inputs, Photo-Coupler Type, DC 5V~12V

Pan 360°(Endless)

Tilt 90°

Preset 360°/sec.

Jog 0.05 ~ 360°/sec. (Proportional to Zoom)

Swing 1~ 180°/sec.

8 Groups (MAX. 20 Actions with The Combination of Preset,

Pattern and Swing)

Alarm Outputs 1 Output, Relay Output, MAX. Load DC24V 1A / AC125V 0.5A

Fan Always ON

Heater Operation Start from Internal Temperature 10°C

Operation Temperature

AC24V Model Analog Model ICR-100X AC 24V / 1.5 A

0°C ~ 40°C (MPS / MPL / MAI Model)

-30°C ~ 50°C (MAO Model)

RATED POWER

Speed Dome Camera Instruction Manual 54/57

IC Realtime ICR200X User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
