ICRealtime ICIP-MC2028 Specsheet
ICIP-MC2028
2MP IR Mobile Network Camera
● 1/2.8” 2 Megapixel progressive scan
STRAVIS™ CMOS
● H.265&H.264 triple-stream encoding
● 50/60fps@1080(1920×1080)
● WDR(120dB), Day/Night(ICR),
3DNR,AWB,AGC,BLC
● 2.8mm fixed lens
● Max. IR LEDs Length 30m
● Micro SD memory, IP67, IK10, IP6K9K, PoE
● EN50155, E-MARK(ECE-Regulation No.10)
System Overview
This mobile camera is specially designed for trains, buses
and other vehicles. Due to its high-specification design, the
mobile camera meets the requirements of vehicle
standards such as EN50155, E-MARK(ECE-Regulation
No.10), making the camera able to withstand the tough
conditions like vibrations, shocks and wide range
temperature fluctuations. The external camera meets the
IP6K9K standard, which makes it dustproof and
waterproof, sustaining high pressure / steam jet cleaning
directly.
Functions
IP6K9K
IP6K9K is the degrees of protection (IP code, ISO 20653)
for road vehicles, protection of electrical equipment against
foreign objects, water and access. Products meet the
IP6K9K standard, can be directly used high pressure /
steam jet cleaning.
EN50155
EN50155 is a European standard for railway applicationselectronic equipment used on rolling stock. The mobile
camera meets the requirements of EN50155, making the
camera able to withstand the tough conditions like
vibrations, shocks and other harsh vehicle environment, to
meet the needs of vehicle monitoring.
with both bright and low lighting conditions that change
quickly, True WDR (120dB) optimizes both the bright and
dark areas of a scene at the same time to provide usable
video.
Environmental
With a temperature range of -40 °C to +70 °C (-40 °F to
+158 °F), the camera is designed for extreme temperature
environments. The camera complies to an IK10 impact
rating making it capable of withstanding the equivalent of
5 kg (11.02 lbs) of force. Subjected and certified to
rigorous dust and water immersion tests, the IP67 rating
makes it suitable for demanding outdoor applications.
Smart H.265+
Delivering high quality video without straining the network,
Smart H.265+ is the optimized implementation of H.265.
The Smart H.265+ encoding technology includes a scene
adaptive encoding strategy, dynamic GOP, dynamic ROI,
flexible multi-frame reference structure and intelligent
noise reduction, providing saving of up to 70% of
bandwidth and storage when compared with standard
H.265.
Wide Dynamic Range
Embedded with industry leading wide dynamic range
(WDR) technology, vivid pictures are achieved even in the
most intense contrast lighting conditions. For applications
1 | www.icrealtime.com SH-20190327-HV1-D1.01
ICIP-MC2028
Technical Specification
Camera
Image Sensor
Effective Pixels
RAM/ROM
Scanning System
Electronic Shutter Speed
Minimum Illumination
S/N Ratio
IR Distance
IR On/Off Control
IR LEDs
Lens
Lens Type
Mount Type
Focal Length
Max. Aperture
Angle of View
Optical Zoom
Focus Control
Close Focus Distance
DORI Distance
Lens Detect Observe Recognize Identify
2.8 mm 144ft 52ft 30ft 13ft
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range
Intelligence
IVS
Advanced Intelligent Functions
Video
Compression
Streaming Capability
Resolution
Frame Rate
Bit Rate Control
Bit Rate
Day/Night
BLC Mode
White Balance
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
1/2.8” 2 Megapixel progressive scan CMOS
1920(H) x 1080(V)
512MB/32MB
Progressive
Auto/Manual, 1/3~1/100000s
0.009Lux/F2.0( Color,1/3s,30IRE)
0.07Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
More than 50dB
Distance up to 30m(98ft)
Auto/ Manual
2
Fixed
Board-in
2.8mm
F2.0
H: 110°, V: 58°
N/A
Fixed
N/A
Pan:0˚~20˚; Tilt:±15˚; Rotation:0˚~360˚
Tripwire, Intrusion, Object Abandoned/Missing
Face Detection
H.265+/H.265/H.264+/H.264
3 Streams
1080P(1920×1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
Main Stream: 1080P(1~50/60fps)
Sub Stream: D1(1~50/60fps)
Third Stream: 1080P(1~25/30fps)
CBR/VBR
H.264: 24~10240Kbps
H.265: 14~9984Kbps
Auto(ICR) / Color / B/W
BLC / HLC / WDR(120dB)
Auto/Natural/Street Lamp/Outdoor/Manual
Electronic Image Stabilization
(EIS)
Smart IR Support
Defog N/A
Digital Zoom 16x
Flip 0° / 90° / 180° / 270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)
N/A
Audio
Compression
N/A
Network
Ethernet
Protocol
Interoperability ONVIF, PSIA, CGI
Streaming Method Unicast / Multicast
Max. User Access 10 Users/20 Users
Edge Storage
Web Viewer IE, Chrome, Firefox, Safari
Management Software SmartICRSS, DSS
Smart Phone IOS, Android
-AS: RJ45(10/100Base-T)
-M12:M12 D-Coding(10/100Base-T)
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
NAS
Local PC for instant recording
Micro SD card 128GB
Certifications
Certifications
UL: UL60950-1
Interface
Video Interface
Audio Interface
RS485
Alarm
N/A
1/1 channel In/Out (-AS Model)
N/A
1 channel In: 5mA 5VDC
1 channel Out: 300mA 12VDC (-AS Model)
Electrical
Power Supply
Power Consumption
-AS: DC12V, PoE (802.3af)(Class 0)
-M12: PoE (802.3af)(Class 0)
<6.5W
Environmental
Operating Conditions -40° C ~ +70° C (-40° F ~ +158° F) / Less than 95% RH
Storage Conditions -40° C ~ +70° C (-40° F ~ +158° F) / Less than 95% RH
Ingress Protection IP67, IP6K9K
Vandal Resistance IK10
Construction
Casing Metal
Dimensions 140.6mm×112.9mm×69.4mm (5.53”×4.44”×2.73”)
Net Weight 0.59Kg (1.3lb)
Gross Weight 0.8Kg (1.76lb)
2 | www.icrealtime.com SH-20190327-HV1-D1.01
