ICRealtime ICIP-D2022-28-C Specsheet

ICIP-D2022-28-C

2MP HD Recessed Mount Dome Network Camera

● 1/2.8” 2 Megapixel progressive Starvis TM

CMOS

● H.265&H.264 triple-stream encoding

● 50/60fps@1080P(1920×1080)

● Smart Detection supported

● WDR(120dB), Day/Night(ICR), 3DNR,

AWB,AGC,BLC

● 2.8mm fixed lens

● Built-in Mic

● Micro SD memory, IK08, PoE

System Overview

The camera to choose when aesthetics matter, the
ICIP-D2022-28-C. A camera with a minimalistic footprint yet
premier features and resolution.

The ICIP-D2022-28-C is a recessed mount Dome camera,
designed to be installed in ceiling mount applications. The
recessed can allows for all of the camera components to be
concealed inside the ceiling while leaving a small, sleek dome
footprint exposed for the lowest profile dome camera possible.
Inside the chassis is a 1/3’’ 4MP CMOS based image sensor
that supports True WDR (120 dB). The HD 2MP image itself is
compressed on board is triple encoded into three separate
streams, and supports both H.265 and H.264 compression for
the highest fidelity of video while maintaining the lowest
bitrate possible. A 2.8mm lens offers a 110 degree horizontal
field of vision

The real magic of this camera lies in it’s AI (Advanced
Intelligence) suite of features, which includes: Tripwire,
Intrusion, Scene Change, and Face Detection.

Functions

Wide Dynamic Range

Embedded with industry leading wide dynamic range (WDR)
technology, vivid pictures are achieved even in the most intense
contrast lighting conditions. For applications with both bright and
low lighting conditions that change quickly, True WDR (120dB)
optimizes both the bright and dark areas of a scene at the same
time to provide usable video.

the edge allowing detection of multiple object behaviors such as
abandoned or missing objects. IVS also supports Tripwire
analytics, allowing the camera to detect when a predetermined line
has been crossed, ideal for business intelligence, workforce
optimization, and actionable intelligence.

Environmental

With a temperature range of -10 °C to +45 °C (14 °F to +113 °F),
the camera is designed for soft indoor temperature environments.

Protection

Supporting ±30% input voltage tolerance, this camera suits even
the most unstable conditions for outdoor applications. Its 6KV
lightning rating provides protection against the camera and its
structure from the effects of lightning. IK08 compliance enables
the camera to sustain the equivalent of 1.7kg (3.75lbs) force.

Smart H.265+

Deliver high quality video without straining the network, Smart
H.265+ is the optimized implementation of H.265. The Smart
H.265+ encoding technology includes a scene adaptive encoding
strategy, dynamic GOP, dynamic ROI, flexible multi-frame
reference structure and intelligent noise reduction, providing
saving of up to 70% of bandwidth and storage when compared
with standard H.265.

HEVC (H.265)

The H.265 (ITU-T VCEG) video compression standard offers
double the data compression ratio at the same level of video
quality, or substantially improved video quality at the same bit rate,
as compared to older video compression technologies. H.265
offers such impressive compression by expanding the pattern
comparison and difference coding, improving motion vector
prediction and motion region merging, and incorporating an
additional filtering step called sample-adaptive offset filtering.

Intelligent Video System (IVS)

With built-in intelligent video analytics, the camera has the ability
to detect and analyze moving objects for improved video
surveillance. The camera provides optional standard intelligence at

1 | www.icrealtime.com SH-20190315-HV1-D1.01

ICIP-D2022-28-C

Technical Specification

Camera

Image Sensor

Effective Pixels

RAM/ROM

Scanning System

Electronic Shutter Speed

Minimum Illumination

S/N Ratio

IR Distance

IR On/Off Control

IR LEDs

Lens

Lens Type

Mount Type

Focal Length

Max. Aperture

Angle of View

Optical Zoom

Focus Control

Close Focus Distance

DORI Distance

Lens Detect Observe Recognize Identify

2.8mm 44m(144ft) 17m(56ft) 9m(30ft) 4m13ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Intelligence

IVS

Advanced Intelligent Functions

Video

Compression

Streaming Capability

Resolution

Frame Rate

Bit Rate Control

Bit Rate

Day/Night

BLC Mode

White Balance

Gain Control Auto / Manual

Noise Reduction 3D DNR

1/2.8” 2 Megapixel Progressive CMOS

1920(H) x 1080(V)

256MB / 32MB

Progressive

Auto / Manual, 1/3(4)~1/100000s

0.009Lux/F2.0(Color,1/3s,30IRE)

0.07Lux/2.0(Color,1/3s,30IRE)

0.005Lux/F2.0(B/W,1/3s,30IRE)

0.03Lux/2.0(B/W,1/30s,30IRE)

More than 50dB

N/A

N/A

N/A

Fixed

Board-in

2.8mm

F2.0

H: 110°, V: 60°

N/A

Fixed

N/A

Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚

Tripwire, Intrusion, Object Abandoned/Missing

Face Detection

H.265+ / H.265 / H.264+ / H.264

3 Streams

1080P(1920x1080)/SXGA(1280x1024)/1.3M(1280x

960)/720P(1280x720)/D1(704x576|704x480)/VGA(64
0x480)/CIF(352x288|352x240)

Main stream: 1080P(1~50/60fps)

Sub Stream: D1(1~50/60fps)

Third Stream: 720P(1~50/60fps)

CBR/VBR

H.265:12K~6912Kbps
H.264:32K~10240Kbps

Electronic

BLC / HLC / WDR (120dB)

Auto / Natural / Street Lamp / Outdoor / Manual

Motion Detection Off / On (4 Zone, Rectangle)

Region of Interest Off / On (4 Zone)

Electronic Image Stabilization
(EIS)

Smart IR N/A

Defog N/A

Digital Zoom 16x

Flip 0° / 90° / 180° / 270°

Mirror Off / On

Privacy Masking Off / On (4 Area, Rectangle)

N/A

Audio

Compression

G.711a / G.711Mu / AAC / G.726

Network

Ethernet RJ-45 (10/100Base-T)

Protocol

Interoperability ONVIF, PSIA, CGI

Streaming Method Unicast / Multicast

Max. User Access 20 Users

Edge Storage

Web Viewer IE, Chrome, Firefox, Safari

Management Software SmartICRSS, DSS

Smart Phone IOS, Android

HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP;
DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP; NTP;
Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP

NAS
Local PC for instant recording
Micro SD card 128GB

Certifications

Certifications

CE (EN 60950:2000)
FCC: FCC Part 15 Subpart B

Interface

Video Interface

Audio Interface

RS485

Alarm

N/A

Built-in Mic

N/A

N/A

Electrical

Power Supply

Power Consumption

DC12V, PoE (802.3af)(Class 0)

<3.5W

Environmental

Operating Conditions -10° C ~ -45° C (14° F ~ +113° F) / Less then 95% RH

Storage Conditions -10° C ~ -45° C (14° F ~ +113° F) / Less then 95% RH

Ingress Protection N/A

Vandal Resistance IK08

Construction

Casing Plastic

Dimensions 93mm x 116.5mm (3.65” x 4.58”)

Net Weight 0.225Kg (0.50lb)

Gross Weight 0.37Kg (0.82lb)
