ICRealtime ICIP-D2001-IR-D Specsheet

ICIP-D2001-IR-D

Features

 3.6mm fixed lens
 Max. IR LEDs length 90’/30m
 IP66, IK10, & PoE
 30fps@1080P (1920×1080)

Revision 1.1; 01/2016

ICIP-D2001-IR-D

Model

ICIP-D2001-IR-D

Camera

Image Sensor

1/2.7” 2MP progressive scan CMOS

Effective Pixels

1920 (H)×1080 (V)

Scanning system

Progressive

Electronic Shutter Speed

Auto/Manual 1/3(4) ~ 1/10000

Min. Illumination

0.01lux@F2.0 (color); 0Lux@F2.0 (IR on)

S/N Ratio

> 50dB

Camera Features

Max IR LEDs Length

90’/30m

Day/Night

Auto (ICR) / Color / B/W

Backlight Compensation

BLC / HLC / WDR (120Db)

White Balance

Auto / Sunny / Night / Outdoor / Customized

Gain Control

Auto / Manual

Noise Reduction

3D

Privacy Masking

Up to 4 areas

Lens

Focal Length

3.6mm

Max Aperture

F2.0

Focus Control

Manual

Angle of View

H: 93°

Lens Type

Fixed lens

Mount Type

Board-in Type

Video

Compression

H.264 / H.264B / H.264H / MJPEG

Resolution

1080P (1920×1080) / 720P (1280×720) / D1 (704×576/704×480) / CIF
(352×288/352×240)

Frame Rate

Main Stream: 1080P / 720P (1 ~ 30fps)
Sub Stream: D1 / CIF (1 ~ 30fps)
Third Stream: 720P (1 ~ 13/4fps)

Bit Rate

H.264: 32K ~ 10Mbps

Corridor Mode

Supported

Smart Function

Smart Detection

Tripwire, Intrusion, Abandoned/Missing, Scene Change, Audio detect,
Face detect

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP,
SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP,
IP Filter, QoS, Bonjour, 802.1x

Compatibility

ONVIF, PSIA, CGI

Max. User Access

20

Smart Phone

iPhone, iPad, Android, Windows Phone

General

Power Supply

DC12V, PoE (802.3af)

Power Consumption

Max 4W

Specifications
