HD Vandal Proof IP Dome Camera User’s Manual
Version 3.0.0
Welcome
Thank you for purchasing our IP camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!
i
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC or 24V AC in the IEC60950-1.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage
and installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series IP camera should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam
device. Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding holes of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily
maintenance work.
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.
ii
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
Accessory Name
Amount
IPC Unit
1
MD9M data converter cable
1
Accessories bag
1
Quick Start Guide
1
CD
1
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean
the device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are
included. Contact your local retailer ASAP if something is broken in your package.
iii
Table of Contents
1 General Introduction
..................................................................................................................
1
1.1
Overview........................................................................................................................
1
1.2
Features.........................................................................................................................
1
1.3
Specifications................................................................................................................
2
1.3.1
Performance
...........................................................................................................
2
1.3.2
Factory Default Setup
...........................................................................................
3
2
Structure
............ ........... ........... ........... ........... ............. ........... ........... ........... ........... ........... ........
11
2.1
Multiple-function Combination Cable ......................................................................
11
2.2
Framework and Dimension.......................................................................................
12
2.3
Bidirectional talk .........................................................................................................
13
2.3.1
Device Connection
..............................................................................................
13
2.3.2
Operation
..............................................................................................................
13
2.4
Alarm Setup.................................................................................................................
13
3
Installa tion
............ ........... ........... ........... ........... ............. ........... ........... .......... ......... ........... ........
15
3.1
Device Installation ......................................................................................................
15
3.2
SD Card Installation...................................................................................................
18
3.3
Lens Adjustment.........................................................................................................
18
4
Quick Configuration Tool.........................................................................................................
20
4.1
Overview......................................................................................................................
20
4.2
Operation.....................................................................................................................
20
5
Web Operation..........................................................................................................................
23
5.1
Network Connection...................................................................................................
23
5.2
Login and Main Interface...........................................................................................
23
iv
6 FAQ ...............................................................................................................................................26
Appendix Toxic or Hazardous Materials or Elements ...............................................................27
v
1 General Introduction
User
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Management
Support central server backup function in accordance with your configuration
and setup in alarm or schedule setting
Storage
Support record via Web and the recorded file are storage in the client-end
PC.
Function
Support built-in SD card.
Support local SD card hot swap, support short-time storage when encounter
disconnection.
Real-time respond to external local alarm input and video detect as user pre-
Alarm
defined activation setup and exert corresponding message in screen and
audio prompt(allow user to pre-record audio file)
Function
Real-time video detect: motion detect, camera masking.
Can generate an alarm when network abnormal, SD card abnormal event
occurred.
IPC supports one-channel audio/video data transmit to network terminal and
Network
then decode. Delay is within 270ms (network bandwidth support needed)
Max supports 20 connections.
Monitor
Adopt the following audio and video transmission protocol: HTTP, TCP, UDP,
MULTICAST, RTP/RTCP, RTSP and etc.
Support web access, widely used in WAN.
Network
Realize IPC configuration and management via Ethernet.
Support device management via web or client-end.
Management
Support various network protocols.
Peripheral
Support the on-off alarm device to alarm via the sound or the light.
Equipment
Power
External power adapter DC12V/AC 24V
Support PoE.
Assistant
Log function
Function
Support PAL/NTSC
1.1 Overview
This series IP camera integrates the traditional camera and network video technology. It adopts
audio and video data collection, transmission together. It can connect to the network directly without
any auxiliary device.
This series IPC uses standard H.264 video compression technology and G.711a audio
compression technology, which maximally guarantee the audio and video quality.
This series IPC enclosure has the strong resistance capacity, which can guarantee the proper work
performance under heavy strike. It supports real-time monitor and listening at the same time. It
supports analog video output and dual-way bidirectional talk.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the
network and then use a network client-end. Due to its multiple functions and various uses, this series
IPC is widely used in many environments such office, bank, road monitor and etc.
1.2 Features
1
Model
ICIP3000DV-IR Series
Not Available
Parameter
Syste
m
Main
TI Davinci high performance DSP
Processor
OS
Embedded LINUX
System
Support real-time network, local record, and remote operation at the same
Resources
time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
SD card status, bit stream statistics, log, and software version.
Vid
eo
Image Sensor
1/2.8-inch CMOS
1/3-inch CCD
Pixel
2048（H）*1536（V）
1280(H)*960(V)
Day/Night
Paramet
er
Support day/night mode switch and IR-CUT at the same time.
Mode
Auto Iris
DC drive
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Manual/Auto
Manual/Auto
Electronic
Manual/Auto
PAL: It ranges from 1/3 to
PAL: It ranges from 1/3 to 1/10000.
1/100000.
Shutter
NTSC: It ranges from 1/4 to 1/10000.
NTSC: It ranges from 1/4 to
1/100000.
Video
Compression
H264/JPEG/MJPEG
Standard
PAL:
PAL:
Main stream
Main stream（2048*1536@15fps）
（1280*960@12.5fps）
extra stream,（704*576@15fps）
extra stream,
Main stream（1920*1080@25fps）
（704*576@12.5fps）
Video Frame
extra stream（704*576@25fps）
Main stream（1280*720@25fps）
Rate
NTSC:
extra stream（704*576@25fps）
Main stream（2048*1536@15fps）
NTSC:
extra stream（704×480@15fps）
Main stream（2048*1536@22fps）
Main stream（1920*1080@30fps）
extra stream（704×480@22fps）
extra stream（704×480@30fps）
Main stream（1920*1080@30fps）
extra stream（704×480@30fps）
H.264: 56Kbps-8192Kbps.
Video Bit Rate
ＭJPEG is adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
2
Support system resource information and running status real-time display.
Day/Night mode auto switch (ICR switch).
Built-in IR light. Support IR night vision (For ICIP3000DV-IR Series only).
Backlight compensation: screen auto split to realize backlight compensation
to adjust the bright.
Support electronic shutter and gain setup.
Support video watermark function to avoid vicious video modification.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for IPC performance specification.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Channel title, time title, motion detect, privacy mask.
Information
Lens
3.3~12mm@F1.4
2.8~12mm@F1.4
Lens Interface
CS. Lens is the default accessories
Audio Input
1-channel，RCA audio input.
Audio
Audio Output
1-channel, RCA, audio output.
Bidirectional
Reuse the first audio input channel
Talk Input
Audio Bit Rate
16kbps 16bit
Audio
Compression
G.711a/G.711u/PCM
Standard
396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The 6
th
Vide
o
Motion Detect
level has the highest sensitivity)
Activation event, alarm device, audio/video storage, image snapshot, log,
email function and etc.
Video Loss
Activation event, alarm device, audio/video storage, image snapshot, log,
email function and etc.
Alarm Input
2-channel input，1-channel output
BackupandRecord
Record
Manual>External alarm >Video detect>Schedule
Priority
Local Storage
Support Micro SD card storage
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network
Standard HTTP, TCP/IP, IPv4/IPv6, ARP, IGMP, ICMP, RTSP, RTP, UDP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP,
Protocol
NFS.
Remote
Monitor, system setup, file download, log information, maintenance ,
Operation
upgrade and etc
Interface
AUX
Video Output
1-channel analog video output，BNC port, 9-pin port connection
Reset
6-pin port connection
IR light
35 LED, IR distance 10 to 20 meters (For 3000DVIR series product only)
General
Power
Support AC24V/DC12V power. PoE
Power
7W MAX
Consumption
Working
-10℃~+60℃
Parame
ter
Temperature
Working
10%~90%
Humidify
Dimensions(m
¢160x118.5
m)
Weight
1.25g
Installation
Support various installation modes（Enclosure and bracket is optional）
1.3.2 Factory Default Setup
Please refer to the following sheet for factory default setup information.
3
Function
Default setup
Item
ICIP3000DV-IR
Setup Type
Series
Series
Conditions
Brightness
50
Contrast
50
Hue
50
Saturation
50
Gain mode
Auto
Gain limit
80
Exposure mode
Auto
Auto iris
Enable
Scene mode
Auto
Day/night mode
Auto
BLC
Off
Flip
Disable
Video
Video
bit Bit stream
General
stream
type
Encode
H.264B
mode
Resolution
1080P
720P(1280*72
（1920*1080）
0)
Frame rate
PAL: 25
（FPS）
NTSC:30
Main
Bit stream
CBR
stream
type
Reference bit
3584-8192 Kb/S
rate
Bit rate
8192
I frame
50
interval
Watermark
Enable
settings
Watermark
DigitalCCTV
character
Extra
Enable
Enable
stream
Bit stream
General
type
Encode
H.264B
mode
Resolution
CIF(352×288/35
CIF(352×288/3
2×240)
52×240)
Frame rate
PAL: 25
（FPS）
NTSC:30
Bit rate type
CBR
Reference bit
192-1024Kb/S
rate
4
Function
Default setup
Item
ICIP3000DV-IR
Setup Type
Series
Series
Bit rate
640
I frame
50
interval
Snap type
General snap
Image size
1080P
720P(1280*7
Snapshot
（1920*1080）
20)
Quality
Better
Interval
7s
Privacy mask
Enable
Overlay
Channel title
Enable
Time title
Enable
Path
Snapshot
C:\PictureDownload
path
Record path
C:\RecordDownload
Aud
io
Enable
Enable
Main stream
Encode
G.711A
mode
Enable
Disable
Sub(Extra) stream
Encode
G.711A
mode
Network setup
Host name
IPC
Ethernet card
Wire(Default)
Mode
Static
MAC
Depends on the device
address
IP version
IPV4
IP address
192.168.1.168
Subnet mask
255.255.255.0
TCP/IP
Default
192.168.1.1
gateway
Preferred
8.8.8.8
DNS
Alternate
8.8.8.8
DNS
Enable
ARP/Pingto
Enable
to set IP
address
service
Connection
Max
10
connection
TCP port
37777
5
Function
Default setup
Item
ICIP3000DV-IR
Setup Type
Series
Series
UDP port
37778
HTTP port
80
RTSP port
554
Enable
Disable
PPPoE
User name
N/A
Password
N/A
Server type
Disable ，CN99 DDNS
Server IP
none
Port
80
DDNS
Domain
none
name
User name
none
Password
N/A
Update
5m
period
IP filter
Trusted sites
Disable
SMTP server
none
Port
25
Anonymity
Disable
User name
anonymity
Password
N/A
Sender
none
SMTP（email）
Authenticatio
n (Encrypt
N/A
mode)
Title
IPC Message
(Subject)
Main
N/A
Receiver
Interval
0s
Health email
Disable ，interval=60m
UPnP
Enable UPnP
Disable
SNMP v1
Disable
SNMP v2
Disable
SNMP port
161
SNMP
Read
public
community
Write
private
community
Trap address
N/A
Trap port
162
6
Function
Default setup
Item
ICIP3000DV-IR
Setup Type
Series
Series
Enable
Enable
Bonjour
Server name
“Device name+SN”.
Depends on the device.
Multicast
239.255.42.42
Multicast
address
Port
36666
Enable
Disable
SN
1
Auto register
Server IP
0.0.0.0
Port
7000
Sub-device
none
ID
WIFI
On(Enable)
Enable
Real-time
0
QoS
monitor
Command
0
Event
Video detect
Motio
n
Enable
Disable
management
Anti-dither
5 seconds
Sensitivity
3
dete
ct
Record
Enable
Channel
Record
10 seconds
Delay
Relay
(Alarm)
Enable
output
Alarm delay
10s
Send email
Disable
PTZ
Disable
Activation
N/A
Address
0
Snapshot
Disable
Vide
o
Enable
Disable
Record
Enable
(Camer
a)
Channel
Record
10 seconds
Delay
Relay out
Enable
maskin
g
Record
10 seconds
Delay
Send email
Disable
PTZ
Disable
7
Function
Default setup
Item
ICIP3000DV-IR
Setup Type
Series
Series
Activation
Disable
Address
0
Snapshot
Disable
Relay
Enable
Disable
Relay input
Alarm1
(Alarm)
Anti-dither
5s
Sensor type
NO
Record
activation
Enable
channel
Record delay
10s
Relay
(Alarm)
Enable
Alarm setup
output
Relay
10s
(Alarm) delay
Send email
Disable
PTZ
Disable
Activation
N/A
Address
0
Snapshot
Disable
Relay
(Alarm)
1
output
Abnormity
No
Enable
Disable
Relay
SD
Enable
(Alarm)
card
output
Relay output
10s
delay
Send email
Disable
Capacity
Enable
Disable
Capacity limit
(Space
10%
threshold)
warning
Relay
(Alarm)
Enable
output
Relay output
10s
delay
Send email
Disable
errorS
D
Enable
Disable
Relay
c
a
r
d
(Alarm)
Enable
output
8
Function
Default setup
Item
ICIP3000DV-IR
Setup Type
Series
Series
Relay output
10s
delay
Send email
Disable
Disconnectio
n
Enable
Disable
Record
Enable
Record delay
10s
Relay
(Alarm)
Enable
output
Relay output
10s
delay
I
P
Enable
Disable
confli
ct
Record
Enable
Record delay
10s
Relay
Enable
(Alarm)
output
Relay output
10s
delay
Storage
FTP enable
Disable
management
Server IP
N/A
Port
21
User name
anonymity
FT
Password
N/A
Remote
P
share
storage path
Destination(Storag
Emergency
e )
storage
to
Disable
local path
Networ
k
NAS enable
Disable
Mode
NFS
Server IP
N/A
storag
e
Port
21
User name
N/A
Password
N/A
Remote
N/A
storage path
Conditions
(Record
Pack
8m
control)
duration
Pre-record
5s
Disk full
Overwrite
9
Default setup
Item
ICIP3000DV-IR
Series
Series
Record mode
Auto
setupLo
cal
Device name
Device factory SN
Language
English
Video
NTSC
NTSC
standard
Date
Date format
Y-M-D
Time format
24H
and
Time zone
GMT+08:00
time
Current time
Sync PC
DST
Disable
General setup
DTS type
Week
Start time
00:00:00 of the first Sunday of the
month
End time
00:00:00 of the second Monday of
the month
Synchronize
Disable
with NTP
NTP server
clock.isc.org
Port
37
Update
10m
period
Protocol
PELCOD
Address
1
PTZ setup
Baud rate
9600
Data bit
8
Stop bit
1
Parity
N/A
Auto reboot
Enable
Auto maintenance
Auto delete
Disable
old files
Function
Setup Type
System
management
10
2 Structure
Port Name
Function
Connection
Note
VIDEO OUT
Video
output
BNC
Output analog video signal. It can connect to the
port
TV monitor to view the video.
AUDIO IN
Audio
input
RCA
Input audio signal. It can receive the analog audio
port
signal from the pickup.
AUDIO OUT
Audio
output
RCA
Output audio signal to the devices such as the
port
sound box.
12V DC/AC24V
Power
input
/
Power port. Input DC 12V/AC 24V
port
I/O
I/O cable port
/
Connect to I/O port cable.
LAN
Network port
Ethernet
Connect to standard Ethernet cable.
port
Support PoE.
Port Name
Cable
Name
Note
Color
I/OPort
Red
ALARM_COM
Alarm output public port.
Pin
Brown
ALARM_IN1
Alarm input port 1. It is to receive the on-off signal
from the external alarm source.
2.1 Multiple-function Combination Cable
You can refer to the following figure for multiple-function combination cable information. See
Figure 2-1.
Figure 2-1
Please refer to the following sheet for detailed information.
Please refer to the follow sheet for detailed information of MD9M data converter cable.
11
Port Name
Cable
Name
Note
Color
Grey
ALARM_IN2
Alarm input port 2. It is to receive the on-off signal
from the external alarm source.
Alarm output port. It is to output the alarm signal
White
ALARM_NO
to the alarm device.
NO: normal open alarm output port.
It works with the ALARM_COM port.
It is to restore factory default setup.
Blue
RESET
When the device is working properly, please
connect the blue cable (restore default setup port)
to the orange cable (GND signal) for 5 seconds,
the device can resume factory default setup.
Orange
GND
Ground port
2.2 Framework and Dimension
Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and
Figure 2-3.
Figure 2-2
12
Figure 2-3
2.3 Bidirectional talk
2.3.1 Device Connection
Before the operation, connect the active pickup to the audio input port of the device. Connect the
active speaker to the audio output port of the device. Please make sure the client-end device has the
audio input and output function. For example, you need to connect the microphone and then
earphone to the PC if you want to implement the bidirectional talk function.
2.3.2 Operation
Login the Web and click the bidirectional talk button to enable this function. Click this button again; you
can close current bidirectional talk.
2.4 Alarm Setup
The alarm interface is shown as in Figure 2-4. Please follow the steps listed below for local alarm input
and output connection.
1) Connect the alarm input device to the alarm input port (grey or brown pin of I/O port cable).
2) Connect the alarm output device to the alarm output port (White-pin) and alarm output public
port (Red-pin). The alarm output port supports NO (normal open) alarm device only.
3) Open the Web, go to the Figure 2-4. Please set the alarm input 01 port for the brown-pin (the
1st channel) of I/O port cable. The alarm input 02 is for the grey-pin (the 2nd channel) of I/O port
cable. Then you can select the corresponding type (NO/NC.)
4) Set the WEB alarm output. The alarm output port of the alarm output 01 device (The white-pin of the
I/O port cable).
13
Figure 2-4
14
3 Installation
This series IPC can be put on the table to realize surveillance. Or you can use the bracket or the
in-ceiling installation to realize the hang function. Please refer to the steps listed below.
3.1 Device Installation
Step 1
Use the inner hexagonal wrench (provided) to loose the three inner hexagon screws in the dome
cover and then open the cover. The device is shown as in Figure 3-1
Figure 3-1
Step 2
Use the inner hexagonal wrench (provided) to loose the three inner hexagon screws in the dome
and then remove the device pedestal. See Figure 3-2 .
With IR light Without IR light
Figure 3-2
15
Step 3
Draw out the cable exit and four screw holes in the installation position according to the device
pedestal. Dig the four plastic expansion bolt holes and cable exit. Insert the four plastic expansion
bolts into the screw holes
Step 4
Adjust the camera pedestal to the proper position and then draw the cable through the cable exit you
just dug in the ceiling (wall). Line up the four screw holes in the device pedestal to the four plastic
expansion bolt holes in the installation position. Put the four self-tapping screws in the device
pedestal and then use the screwdriver to secure the screws in the four plastic expansion bolts firmly.
Step 5
Adjust the device position and line up the three inner hexagon screws of the device to the three holes
of the installation position. Put the three inner hexagon screws into the screw holes at the bottom of
the pedestal. Use the inner hexagon screwdriver to fix firmly. Connect the GND to the ground wires to
improve stability. See Figure 3-3 .
With IR light Without IR light
Figure 3-3
Step 6
Adjust the X-Y-Z axis module to turn the device to the proper monitor angle. Please follow the steps
listed below to adjust. See Figure 3-4.
Please note, for the dome of the IR light, you can skip step a) and step e).
a): Slightly push the two sides to squeeze the plastic hook so that you can take off the
dome enclosure.
b):Slightly loose the screws at the two sides of the X-Y-Z module manually, you can adjust the
module tilt rotation angle (15°～90°).
c):Slightly loose the screw of the pressing slice, you can adjust the video rotation angle of the
module (0°～355°)
d):Adjust the turning ring of the pedestal, you can adjust the module pan rotation angle (0°～
355°).
16
e): Put the enclose back after you completed the setup.
With IR light Without IR light
Figure 3-4
Please note, the screws in the following figure are the optical adjustment component. Please
make sure it is outward and do not allow it to touch the X-Y-Z axis module. See Figure 3-5
Figure 3-5
Step 7
Put the dome cover back and then put the three inner hexagon screws into the holes of the device.
Use the inner hexagonal wrench to fasten these three screws. See Figure 3-6
Figure 3-6
17
3.2 SD Card Installation
Important
Before you install the SD card, please unplug he power cable to shut down the device!
First, please refer to the step1 in the chapter 3.1 to open the device.
Second, please adjust the proper position to install the SD card.
Last, please refer to the step 7 in the chapter 3.1 to complete the installation. See Figure 3-7.
With IR light Without IR light
Figure 3-7
3.3 Lens Adjustment
Step 1
Slightly loose the screw B manually and then turn the screw B slowly. Adjust the lens focus distance
to the proper position according to the monitor video. See Figure 3-8.
Step 2
Use the flat screwdriver to loose the screw A slightly and then turn the Screw A slowly. Adjust the lens
focus to get the clear video and then use the flat screwdriver to secure the screw firmly.
Step 3
When you are adjusting the screw A, the video may becomes blur. Please slightly adjust the screw B
manually to get the vivid video. Finally fix the screw.
18
With IR light Without IR light
Figure 3-8
19
4 Quick Configuration Tool
4.1 Overview
Quick configuration tool can search current IP address, modify IP address. At the same time, you can
use it to upgrade the device.
Please note the tool only applies to the IP addresses in the same segment.
4.2 Operation
Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 4-1. In
the device list interface, you can view device IP address, port number, subnet mask, default
gateway, MAC address and etc.
Figure 4-1
Select one IP address and then right click mouse, you can see an interface is shown as in Figure 4-2.
Figure 4-2
20
Select the “Open Device Web” item; you can go to the corresponding web login interface. See
Figure 4-3.
Figure 4-3
If you want to modify the device IP address without logging in the device web interface, you can go
to the configuration tool main interface to set.
In the configuration tool search interface (Figure 4-1), please select a device IP address and then
double click it to open the login interface. Or you can select an IP address and then click the
Login button to go to the login interface. See Figure 4-4.
In Figure 4-4, you can view device IP address, user name, password and port. Please modify
the corresponding information to login.
Please note the port information here shall be identical with the port value you set in TCP port in Web
Network interface. Otherwise, you can not login the device.
If you are use device background upgrade port 3800 to login, other setups are all invalid.
Figure 4-4
After you logged in, the configuration tool main interface is shown as below. See Figure 4-5.
21
Figure 4-5
22
5 Web Operation
This series IPC product support the Web access and management via PC.
Web includes several modules includes monitor channel preview, PTZ control, system configuration,
alarm and etc.
IP camera factory default setup:
IP address: 192.168.1.108.
User name: admin
Password: admin
5.1 Network Connection
Please follow the steps listed below for network connection.
Make sure the IPC has connected to the network properly.
Please set the IP address, subnet mask and gateway of the PC and the IPC respectively. IPC
default IP address is 192.168.1.108. Subnet mask is 255.255.255.0. Gateway is 192.168.1.1
Use order ping ***.***.***.***(* IP camera address) to check connection is OK or not.
5.2 Login and Main Interface
Open IE and input IP camera address in the address bar.
For example, if your camera IP is 192.168.1.108, then please input http:// 192.168.1.108 in IE
address bar. See Figure 5-1.
Figure 5-1
The login interface is shown as below. See Figure 5-2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Input your IP
address here
23
Figure 5-2
If it is your first time to login in, system pops up warning information to ask you whether install
control webrec.cab or not after you logged in for one minute. Please click OK button, system can
automatically install the control. When system is upgrading, it can overwrite the previous Web too.
If you can’t download the ActiveX file, please check whether you have installed the plug-in to
disable the control download. Or you can lower the IE security level. See Figure 5-3.
Figure 5-3
After you logged in, you can see the main window. See Figure 5-4.
24
Figure 5-4
Please refer to the Web Operation Manual included in the resource CD for detailed operation
instruction.
25
6 FAQ
Bug
I can not boot up
Please click RESET button for at least five seconds to restore
the device.
factory default setup.
SD
card
write
Do not set the SD card as the storage media to storage the
times
schedule record file. It may damage the SD card duration.
I can not use the
When disk information is shown as hibernation or capacity is 0,
disk as the storage
please format it first (Via Web).
media.
I can
not upgrade
When network upgrade operation failed, you can use port 3800 to
the
device
via
network.
continue upgrade.
Recommended SD
Kingston 4GB， Kingston 1GB， Kingston 16GB， Transcend
card brand
16GB， SanDisk 1G， SanDisk 4G.
Usually we recommend the 4GB (or higher) or industry-level high
speed card in case the slow speed results in data loss.
Audio function
Please use active device for the audio monitor input, otherwise there
is no audio in the client-end.
The lightproof
ring
The lightproof ring of the IR device lens is the necessary component
of the IR device
when it works. You can not view the clear video when the IR light is
on if you remove the lightproof ring.
26
Appendix Toxic or Hazardous Materials or Elements
Component
Toxic or Hazardous Materials or Elements
Name
Pb Hg
Cd Cr VI
PBB
PBDE
Circuit Board
○
○
○ ○ ○ ○
Component
Device
Construction
○
○
○ ○ ○ ○
Material
Wire and Cable
○
○
○ ○ ○ ○
Packing
○
○
○ ○ ○ ○
Components
Accessories
○
○
○ ○ ○ ○
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the
parts is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard. During the
environmental-friendly use period (EFUP) period, the toxic or hazardous substance or elements
contained in products will not leak or mutate so that the use of these (substances or elements) will not
result in any severe environmental pollution, any bodily injury or damage to any assets. The consumer
is not authorized to process such kind of substances or elements, please return to the corresponding
local authorities to process according to your local government statutes。
Note
This user’s manual is for reference only. Slight difference may be found in user interface.
All the designs and software here are subject to change without prior written notice.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
27
Loading...
