DVR-56CL
4-Ch H.264E Cube Real-time DVR with Built-in 5.6" LCD
Affordable and compact, the DVR-56CL is a 4 channel DVR with a built in 5.6’’ LCD screen. By
adopting the ‘All-in-One’ design and having a small form factor (a bit shorter than a standard Shoe Box),
the DVR56CL is well suited for installations where space is a premium. Standard installations for the
DVR56CL include marine vessels, and more commonly inside ATM’s.
Although small in size, the DVR56CL has a full suite of features that is expected of a professional grade
DVR, including: D1 resolution recording, 2 channels of audio recording, and two-way audio.
Like all IC Realtime series recorders, this device utilizes H.264E (Enhanced H.264) compression
technology, enabling crisp image viewing with the least bandwidth consumption possible. This unit
adopts an embedded system design, as well as a Linux Operating System, resulting in high levels of
stability, performance, and most importantly: reliability. In addition, this unit is fully operational from
remote locations (Search/Playback/Backup/Configuration) over standard Ethernet networks.
Features
Built-in high resolution 5.6" LCD
USB interface provides PC-like mouse control
Advanced H.264E video compression
2-channel audio, 4-channel video real-time live view and recording
Up-to D1/4CIF resolution recording
Pentaplex function: live view, recording, playback, backup and remote access
Multiple control methods: front panel, IR remote control, DVR keyboard, USB mouse
Revision 1.1 – 8/15
Smart video detection: motion, video loss, blank video
Smart camera setting: privacy mask, camera lock, color setting, title display
PTZ and Speed dome camera control: supports >60 PTZ protocols. 3D intelligent auto tracking
function with ICR SmartWDR series Speed domes
Two-way audio
Alarm input and output ports
Powerful network features: built-in web server, central management software for multiple DVRs
which allows for remote liveviewing, recording, retrieval, setting, and log/status querying
500G SATA HDD pre-installed
DVR-56CL
Model
DVR-56CL
System
Main Processor
High performance embedded microprocessor
Operating System
Embedded LINUX
System Resources
Pentaplex function: live, recording, playback, backup & remote access
Control Mode
Front panel, USB mouse, IR remote control, Keyboard, Network
Video
Input
4 channel, BNC(1.0Vp-p, 75 Ω)
Standard
NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Output
1 TV, BNC(1.0Vp-p, 75Ω)
Audio
Input
2 channel, BNC(200-2800mV, 30KΩ)
1 channel for bidirectional-talk input synchronously
Output
1 channel, BNC(200-3000mV, 5KΩ)
Display
Display Split
1/4
Resolution
1280x1024, 1280x720, 1024x768, 800x600
Privacy Masking
4 self-defined
OSD
ATM/POS information, Camera title, time, video loss, camera lock, motion
detection, recording
Recording
Video/Audio Compression
H.264 / G.711
Image Resolution
D1/4CIF(704x576/704x480) / CIF(352x288/352x240) /
QCIF(176x144/176x120)
Encoding Speed
Main Stream: D1/HD1/2CIF/CIF (1~25/30fps)
Extra Stream: CIF/QCIF(1~25/30fps)
Bit Rate
32~2048Kb/s
Record Mode
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300
sec
Record Priority
Manual >Alarm >MD >Regular
Playback & Backup
Sync Playback
1/2/4
Search Mode
ATM/POS Information,Time/Date, Alarm, Motion Detection & Exact search
(accurate to second)
Playback Functions
Play, Pause, Stop, Rewind, Fast play, Slow play, Next
Backup Mode
Flash drive/ USB HDD/ USB CD/DVD / Network download
Network
Ethernet
RJ-45 port (10/100M)
Network Functions
TCP/IP, UDP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Email, Alarm
Server
Storage
Internal HDD
2 SATA ports, Max 4TB per HDD supported
Auxiliary Interface
Specifications
USB
2 ports, 1 for mouse control, 1 for backup
RS232
ICRealtime keyboard, PC communication
RS485
PTZ control
eSATA
1 port
General
Power Supply
AC 100~240 V, 50/60 Hz
Power Consumption
18W-22W
Working Environment
+14 ~ 130°F/ -10"C~ 55"C / 10%~95% RH / 86~106kpa
Dimensions (W×D×H)
200mm×130mm×320mm ATM box
7.87"×5.12"×12.60”
Weight
7.71lb-9.92lb or 3.5kg-4.5kg or 123.46oz-158.73oz(without HDD)
IC Realtime LLC
3050 N Andrews Avenue Extension
Pompano Beach, FL 33064
(866) 997-9009
www.icrealtime.com
Designs and specifications subject to change without notice. Copyright © 2015 IC Realtime, LLC. All rights reserved.
