AVS-ID1
Active Pixels
2.12MP [1944(H)x1092(V)]
IDENTIFIER SERIES LICENSE PLATE RECOGNITION AVS 1080P CAMERA
Main Features
1/3” 1080p Panasonic CMOS Sensor
2.12M Pixels (1,000 TV Lines)
Vari-focal Lens (ICR f=5~50mm)
5pcs of SR-LED & 25pcs of 5phi IR LED
Max. 15M Recognition Distance (Max. 50Km/h)
B/W Images for both Day & Night (LED Continuous On)
3D-DNR, OSD, UTC Supported
HD-AVS Camera (CVBS Out Mode Supported)
Weather-proof Housing(70Ø)
SpecificationsDimension
Model
Signal System
Pickup Device
Scanning System
Sync. System
Total Pixels
Min. Illumination
No. of IRED
H-Resolution
S/N Ratio
Video Out (BNC)
Lens
Lens (Mount)
Angle of View
OSD
Camera Title
Language
Exposure
White Balance
BLC
Day & Night Mode
Gain Control
Electronic Shutter
DSS(Sens-up)
Noise Reduction
Mirror
Other Features
Power Source
Power Consumption
Operating Temp.
Size (mm)
Weight
AVS-ID1
HD-AVS
1/3”(D-6mm) 2.12M Panasonic CMOS Sensor
Progressive Scan (16:9)
Internal
2.47MP [1956(H)x1266(V)]
0Lux(Continuous IR on)
5ea SR-LED and 25ea 5Ø (850nM)
More than 1,000TV Lines(H)
More than 50dB (AGC off)
HD-AVS: 1080p@25/30 or CVBS 1.0V p.p
DC Auto Vari-focal f=5~50mm, F1.4
Board type (Ø14)
56˚~7˚(D), 44˚~5.8˚ (H), 33˚~4.4˚(V)
Via 5-direction Tact-switch
Off, On(Max. 15 Characters)
English, Russian, French, Spanish, Portuguese, German
Chinese(Simplified), Chinese(Traditional), Japanese,
Korean, Italian, Polish, Dutch, Turkish, Hebrew, Arabic
DC
Auto
Off
B/W only
AGC (1~15)
1/500sec
N/A
2DNR, 3DNR
Off, On(Mirror, Flip, Rotation)
Motion Detection (4 Zone), Privacy Mask (4 Zones),
Freeze, Neg. Image, Lens Shading, Defog etc.
DC 12V
Less than 5 Watts (410mA@DC12V)
-10
℃ ∼55℃
(Humidity :0%RH ∼90%RH)
70Ø (Bullet Diameter)
1,240g (Gift-box packing)
TELE WIDE
FAR NEAR
1
2
GND
DC12V
3
4
Function I/O Note Remarks
OSD Joystick N/A 5-directional OSD joystick
1
VIDEO OUT OUT 2ndVideo signal output 75 Ω
2
POWER IN Camera power input DC12V
3
VIDEO OUT OUT Video signal output (BNC) 75 Ω
4
To switch to each video standard,
move the joystick to the
directions below and hold for
over three seconds.
(A) TVI : Up
(B) AVS : Down
(C) CVBS : Left
(D) AHD : Right
SETUP MENU SUB MENU1 SUB MENU2 SUB MENU3 SUB MENU4 VALUE
MIN. SHU. 1/30(25)
MAX. SHU. 1/60(50), FLK, 1/240, 1/480, 1/1000, 1/2000, 1/5000, 1/10000, 1/50000
AUTO, 1/30, 1/60, FLK, 1/240, 1/480, 1/1000, 1/2000, 1/5000, 1/10000,
1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30
AREA
LENS
EXPOSURE
BACKLIGHT
WHITE
BALANCE
DAY
&
NIGHT
NR
DC
MANUAL
SHUTTER
AGC 0 ~ 15
SENS-UP
BRIGHTNESS 1~100
D-WDR
DEFOG
OFF
BLC
HSBLC
ATW
AWB
AWC -> SET
INDOOR
OUTDOOR
MANUAL
COLOR
B/W
EXT
AUTO
2DNR OFF, LOW, MIDDLE, HIGH
3DNR OFF, LOW, MIDDLE, HIGH
MODE
IRIS SPEED 0~15
AUTO SENS-UP X2, X4, X6, X8, X10, X15, X20, X25, X30
OFF
AUTO LEVEL 0~8
ON
OFF
AUTO
OFF
LEVEL LOW, MIDDLE, HIGH
AREA
DEFAULT
SELECT AREA1, AREA2, AREA3, AREA4,
DISPLAY ON, OFF
BLACK MASK ON, OFF
LEVEL 0~100
MODE
DEFAULT
BLUE 0~100
RED 0~100
BURST ON, OFF
IR SMART
D->N (DELAY) 0~60
N->D (DELAY) 0~60
D->N (AGC) 1~255
D->N (DELAY) 1~60
N->D (AGC) 1~255
N->D (DELAY) 1~60
OUTDOOR
INDOOR
POS/SIZE
GRADATION 0~2
DEFAULT
ALL DAY
NIGHT AGC LEVEL 0~255
ON LEVEL 0~15
OFF
SETUP MENU SUB MENU1 SUB MENU2 SUB MENU3 SUB MENU4 VALUE
CAM TITLE ON, OFF
FREEZE
SPECIAL
ADJUST
EXIT
D-EFFECT
MOTION
PRIVACY
LANGUAGE
DEFFECT
RS485
SHARPNESS
MONITOR
LSC ON, OFF
VIDEO OUT NTSC, PAL
SAVE & END Exit SETUP menu without saving
RESET Reset to factory setting
NOT SAVE Exit SETUP menu after saving
MIRROR OFF, MIRROR, V-FLIP, ROTATE
NEG. IMAGE ON, OFF
OFF
SELECT AREA1, AREA2, AREA3, AREA4
DISPLAY ON, OFF
SENSITIVITY 0~100
COLOR GREEN, BLUE, WHITE, RED
ON
OFF
ON
LIVE DPC
WHITE DPC
BLACK DPC
CAM ID 0~255
ID DISPLAY ON, OFF
BAUD RATE 2400, 4800, 9600, 19200, 38400
AUTO
OFF OFF/ ON
LCD
CRT
TRANS 0.00, 0.25, 0.75, 1.00
VIEW TYPE ALL, OFF, BLOCK, OUT LINE
ALARM
DEFAULT
SELECT
DISPLAY
TRANS 0.25, 0.50, 0.75, 1.00
DEFAULT
ON
OFF
ON
OFF
ON
OFF
LEVEL 0~10
START AGC 0~255
END AGC 0~255
GAMMA 0.45, 0.50, 0.55, 0.60, 0.65, 0.70, 0.75, 0.80, 0.85, 0.90, 0.95, 1.00, USER
BLUE GAIN 0~100
RED GAIN 0~100
BLUE GAIN 0~100
RED GAIN 0~100
OSD VIEW ON, OFF
ALARM OUT ON, OFF
TIME 0~15
OFF
MOSAIC
INV.
COLOR WHITE, BLACK, RED, BLUE, YELLOW, GREEN, CYAN, USER
ARB, ENG, CHN1, CHN2, GER, FRA, ITA, SPA, POL, RUS, POR,
NED, TUR, KOR, JPN, HEB
AGC LEVEL 0~255
LEVEL 0~100
POS/SIZE
START
DPC VIEW ON, OFF
LEVEL 0~100
AGC 0~14
SENS-UP X2, X4, X6, X8, X10, X15, X20, X25, X30
POS/SIZE
START
DPC VIEW ON, OFF
LEVEL 0~100
