ICRealtime AVR-1416 Specsheet

AVR-1416

16 C h a n n e l 1 0 8 0 P 1 U T r i b r i d D V R

Features

 Up to 16 cameras with 1080p @15fp/s / 720p@30fp/s
 Support HDAVS, Analog & up to 2 IP Video inputs
 HDMI/VGA simultaneous video output
 Support 2 SATA HDDs up to 8TB, 2 USB2.0
 3D intelligent positioning with ICR PTZ dome camera
 ONVIF Version 2.3

Revision 1.3; 06/2016

AVR-1416

Model

AVR-1416

System

Main Processor

Embedded processor

Operating System

Embedded LINUX

Video

Input

16 channel, BNC

Standard

HDAVS: 1080P / 720P HDAVS Camera
Analog: NTSC (525 Line, 60f/s), PAL (625 Line, 50f/s)
IP: 1080P / 720P / D1 / CIF IP Camera (up to 2)

Audio

Input

4 channel, RCA

Output

1 channel, RCA

Two-way Talk

Audio input/output channel 1

Display

Interface

1 HDMI, 1 VGA

Resolution

1920×1080, 1280×1024, 1280×720, 1024×768, 800×600

Display Split

1/4/8/9/16

Privacy Masking

4 rectangular zones (each camera)

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording

Video/Audio Compression

H.264/G.711

Resolution

1080P (1920×1080) / 720P (1280×720) / 960H (960×576/960×480) / D1/4CIF
(704×576/704×480) / CIF (352×288/352×240) / QCIF (176×144/176×120)

Record Rate

Main Stream: 1080P(1~15fps) / 720P / 960H / D1 /HD1 / 2CIF / CIF (1~30fps)
Extra Stream: CIF / QCIF (1~30fps), D1 (1~15fps)

Bit Rate

48~4096Kb/s

Record Mode

Manual, Schedule (Regular (Continuous), MD), Stop

Record Interval

1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection & Alarm

Trigger Events

Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Spot, Snapshot,
Buzzer & Screen tips

Video Detection

Motion Detection, MD Zones: 396 (22×18), Video Loss, & Camera Blank

Alarm Input

16 channel

Relay Output

3 channel

Playback & Backup

Sync Playback

1/4/9/16

Search Mode

Time/Date, MD & Exact search (accurate to second)

Playback Functions

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next
camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, &
Digital zoom
Backup Mode

USB Device/Network

Network

Ethernet

RJ-45 port (10/100M/1000M)

Network Functions

HTTP, IPv4/IPv6, TCP/IP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS,
PPPoE, DDNS, FTP, IP Filter, SNMP, & P2P

Max. User Access

128 users

Specifications
