ICP T4H324GKD200, H4H318GKD200, T4H318GKD200, C4H330GKE100, H4H330GKE100 Technical Support Manual
...
TECHNICAL SUPPORT MANUAL
Split System Heat Pump
(C,H,T)4H3
Safety Labeling and Signal Words
DANGER, WARNING, CAUTION, and
NOTE
The signal words DANGER, WARNING, CAUTION, and NOTE are used to identify levels of haz-
ard seriousness. The signal word DANGER is only
used on product labels to signify an immediate hazard. The signal words WARNING, CAUTION, and
NOTE will be used on product labels and throughout this manual and other manuals that may apply
to the product.
DANGER − Immediate hazards which will result in
severe personal injury or death.
WARNING − Hazards or unsafe practices which
could result in severe personal injury or death.
CAUTION − Hazards or unsafe practices which
may result in minor personal injury or product or
property damage.
NOTE − Used to highlight suggestions which will
result in enhanced installation, reliability, or operation.
Signal Words in Manuals
The signal word WARNING is used throughout this
manual in the following manner:
!
The signal word CAUTION is used throughout this
manual in the following manner:
!
Signal Words on Product Labeling
Signal words are used in combination with colors
and/or pictures on product labels.
WARNING
WARNING
CAUTION
TABLE OF CONTENTS
Model Number Identification 2.....................
Wiring Diagrams 3...............................
Charging Chart 4.................................
Tech Labels (Expanded Data) 5 − 12................
Cooling Multipying Factors 13 − 17..................
Heating Multipying Factors 18 − 22.................
MODELS
C4H318GKD200 H4H318GKD200 T4H318GKD200
C4H324GKD200 H4H324GKD200 T4H324GKD200
C4H330GKE100 H4H330GKE100 T4H330GKE100
C4H336GKE100 H4H336GKE100 T4H336GKE100
C4H342GKE100 H4H342GKE100 T4H342GKE100
C4H348GKE100 H4H348GKE100 T4H348GKE100
C4H360GKD300 H4H360GKD300 T4H360GKD300
!
DEATH, PERSONAL INJURY, AND/OR PROPERTY
DAMAGE HAZARD
Failure to carefully read and follow this warning
could result in equipment malfunction, property
damage, personal injury and/or death.
Installation or repairs made by unqualified persons could result in equipment malfunction, property damage, personal injury and/or death.
The information contained in this manual is intended for use by a qualified service technician familiar with safety procedures and equipped with
the proper tools and test instruments.
Installation must conform with local building
codes and with the National Electrical Code
NFPA70 current edition or Canadian Electrical
Code Part 1 CSA C.22.1.
WARNING
428 04 5402 00 May 2010
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
OUTDOOR UNIT MODEL NUMBER IDENTIFICATION GUIDE (single phase)
Digit Position: 1 2 3 4 5, 6 7 8 9 10 11 12
Example Part Number:
Product Family
4 = R−410A REFRIGERANT
A = Air Conditioner
H = Heat Pump TYPE
3 = 13 SEER
4 = 14 SEER
5 = 15 SEER
6 = 16 SEER
7 = 17 SEER
8 = 18 SEER NOMINAL EFFICIENCY
18 = 18,000 BTUH = 1½ tons
24 = 24,000 BTUH = 2 tons
30 = 30,000 BTUH = 2½ tons
36 = 36,000 BTUH = 3 tons
42 = 42,000 BTUH = 3½ tons
48 = 48,000 BTUH = 4 tons
60 = 60,000 BTUH = 5 tons NOMINAL CAPACITY
A = Standard Grille
G = Coil Guard Grille
C = Coastal FEATURES
H 4 H 3 18 G K D 2 0 0
K = 208/230−1−60 VOLTAGE
Sales Code
Engineering Revision
Extra Digit
Extra Digit
ACCESSORIES PART NUMBER IDENTIFICATION GUIDE
Digit Position: 1 2 3 4 5 6, 7 8, 9 10, 11
Example Part Number:
N = Non−Branded BRANDING
A = Accessory PRODUCT GROUP
S = Split System (AC & HP) KIT USAGE
A = Original
B = 2nd Generation MAJOR SERIES
0 = Generic or Not Applicable
2 = R−22
4 = R−410A REFRIGERANT
Product Identifier Number
Package Quantity
Type of Kit (Example: CH = Crankcase Heater)
N A S A 0 0 1 01 C H
2 428 04 5402 00
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 3
Model Sizes: 18, 24, 30, 36, 42, 48, 60
330751−101_D
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
R−410A CHARGING CHART
Rating Plate (required) Subcooling Temperature ° F (° C)
Measured Liquid
Pressure (psig)
° F (° C) ° F (° C) ° F (° C) ° F (° C) F (° C) F (° C)
6 3 8 4 10 6 12 7 14 8 16 9
R−410A Required Liquid Line Temperature ° F (° C)
251 78 26 76 24 74 23 72 22 70 21 68 20
259 80 27 78 26 76 24 74 23 72 22 70 21
266 82 28 80 27 78 26 76 24 74 23 72 22
274 84 29 82 28 80 27 78 26 76 24 74 23
283 86 30 84 29 82 28 80 27 78 26 76 24
291 88 31 86 30 84 29 82 28 80 27 78 26
299 90 32 88 31 86 30 84 29 82 28 80 27
308 92 33 90 32 88 31 86 30 84 29 82 28
317 94 34 92 33 90 32 88 31 86 30 84 29
326 96 36 94 34 92 33 90 32 88 31 86 30
335 98 37 96 36 94 34 92 33 90 32 88 31
345 100 38 98 37 96 36 94 34 92 33 90 32
364 104 40 102 39 100 38 98 37 96 36 94 34
374 106 41 104 40 102 39 100 38 98 37 96 36
384 108 42 106 41 104 40 102 39 100 38 98 37
395 110 43 108 42 106 41 104 40 102 39 100 38
406 112 44 110 43 108 42 106 41 104 40 102 39
416 114 46 112 44 110 43 108 42 106 41 104 40
427 116 47 114 46 112 44 110 43 108 42 106 41
439 118 48 116 47 114 46 112 44 11 0 43 108 42
450 120 49 118 48 116 47 114 46 11 2 44 110 43
462 122 50 120 49 118 48 116 47 114 46 112 44
474 124 51 122 50 120 49 118 48 116 47 114 46
4 428 04 5402 00
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 5
MULTIPLYING FACTORS
(Refer to pages 5−11)
† Total capacities are net (I.D. blower heat subtracted) system capacities based on 25 foot (7.6m) line set.
If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
†† At TVA rating indoor condition (75 °F db, 63 °F wb), all other indoor air temperatures are at 80 ° F db
If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
* System amps are total of indoor and outdoor amps.
‡ Chart data is for 80° F indoor dry bulb. For indoor db temperatures other than 80° F, measure Indoor db and Indoor CFM, and plug these into the
formula below. Measure outdoor db and indoor wet bulb, apply these to the chart above, find MBh and S/T, and plug these into the formula below.
(Note: if indoor db is the only thing changing, total capacity, MBh, stays the same.)
Sensible Capacity at Indoor db LOWER than 80 ° F = ( MBh x S/T ) −
( 80 − Indoor db ) x 835 x Indoor CFM
1000
(
)
Sensible Capacity at Indoor db HIGHER than 80 ° F = ( MBh x S/T ) +
( Indoor db − 80 ) x 835 x Indoor CFM
1000
(
)
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
6 428 04 5402 00
CFM 72 67 63†† 62 57 7 2 67 63†† 62 57 7 2 67 63†† 62 57 7 2 67 63†† 62 57 72 67 63†† 62 57
MBh†
20.50 18.60 17.2 4 16.89 16.29 19.51 17.6 9 16.37 16.04 15.62 18.48 16.7 2 15.45 15.1 6 14.91 17.37 15.70 14.49 14.24 14.1 5 16.20 14.60 13.45 13.3 3 13.33
S/T‡
0.51 0.70 0.7 3 0.92 1.00 0.52 0.7 1 0.74 0.94 1.00 0.53 0.7 3 0.76 0.97 1.00 0.5 4 0.75 0.7 8 0.99 1.0 0 0.55 0.78 0.81 1.0 0 1.00
AMPS*
5.81 5.85 5.8 9 5.89 5.90 6.48 6.5 3 6.56 6.56 6.57 7.23 7.2 7 7.30 7.30 7.31 8.0 4 8.08 8.1 2 8.12 8.1 2 8.94 8.99 9.01 9.0 1 9.01
HI PR
268 266 264 263 263 30 9 307 305 304 304 35 5 352 350 35 0 349 405 402 400 400 40 0 460 457 455 455 455
LO PR
155 142 132 130 126 15 7 144 135 133 129 16 0 147 137 13 5 133 162 149 139 138 13 7 165 152 142 141 141
MBh†
20.89 18.96 17.5 7 17.25 16.95 19.86 18.0 0 16.67 16.39 16.24 18.78 17.0 0 15.72 15.4 9 15.48 17.64 15.94 14.72 14.68 14.6 8 16.42 14.80 13.65 13.8 1 13.81
S/T‡
0.53 0.73 0.7 6 0.96 1.00 0.54 0.7 5 0.78 0.98 1.00 0.54 0.7 7 0.79 1.00 1.00 0.5 6 0.79 0.8 2 1.00 1.0 0 0.57 0.82 0.85 1.0 0 1.00
AMPS*
5.93 5.98 6.0 1 6.02 6.02 6.61 6.6 5 6.68 6.68 6.69 7.35 7.3 9 7.42 7.43 7.43 8.1 7 8.21 8.2 4 8.24 8.2 4 9.07 9.11 9.14 9.1 4 9.14
HI PR
268 266 264 264 264 31 0 307 305 305 305 35 5 353 351 35 0 350 405 403 401 401 40 1 460 458 456 456 456
LO PR
158 145 136 134 132 16 1 147 138 136 135 16 3 150 140 13 8 138 165 152 142 142 14 2 168 154 144 146 146
MBh†
21.17 19.23 17.8 3 17.57 17.50 20.12 18.2 4 16.89 16.75 16.75 19.00 17.2 0 15.91 15.9 6 15.96 17.83 16.11 14.88 15.12 15.1 2 16.57 14.95 13.79 14.2 1 14.21
S/T‡
0.54 0.76 0.7 9 1.00 1.00 0.55 0.7 8 0.81 1.00 1.00 0.56 0.8 0 0.83 1.00 1.00 0.5 7 0.83 0.8 6 1.00 1.0 0 0.59 0.86 0.89 1.0 0 1.00
AMPS*
6.06 6.10 6.1 4 6.14 6.14 6.73 6.7 8 6.81 6.81 6.81 7.48 7.5 2 7.55 7.55 7.55 8.2 9 8.34 8.3 7 8.36 8.3 6 9.19 9.24 9.27 9.2 6 9.26
HI PR
269 267 265 265 265 31 1 308 306 306 306 35 6 353 351 35 1 351 406 403 401 402 40 2 461 458 456 457 457
LO PR
161 148 138 137 136 16 3 150 140 139 139 16 5 152 142 14 3 143 168 154 144 146 14 6 170 157 146 150 150
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
6.61 6.29 5.9 6 8.47 8.18 7.87 10.4 9 10.20 9.91 12.71 12.3 9 12.1 0 15.25 14.8 7 14.53 18.01 17.64 17.27 21.07 20.6 4 20.23 23.90 23.62 23.30
T/R
13.40 12.80 12.3 0 17.30 16.80 16.30 21.5 0 21.10 20.70 26.30 25.90 25.5 0 31.90 31.4 0 30.90 38.10 37.60 37.10 45.20 44.6 0 44.00 51.80 51.60 51.30
AMPS*
5.30 5.50 5.7 0 5.53 5.75 5.98 5.7 6 6.00 6.26 6.02 6.28 6.5 5 6.35 6.62 6.91 6.7 5 7.04 7.3 4 7.23 7.5 4 7.86 7.60 7.96 8.32
HI PR
231 246 263 246 262 28 0 263 281 299 284 30 2 321 311 32 9 348 342 362 382 380 40 0 421 411 435 459
LO PR
40 41 41 52 52 53 65 66 66 80 81 81 97 98 98 116 117 117 137 137 138 155 157 159
MBh†
6.77 6.46 6.1 2 8.66 8.37 8.08 10.6 9 10.41 10.1 2 12.97 12.62 12.3 3 15.54 15.2 1 14.82 18.36 18.00 17.62 21.41 21.0 6 20.67 24.06 23.79 23.50
T/R
12.00 11.50 11.0 0 15.40 15.00 14.60 19.1 0 18.80 18.40 23.40 23.00 22.6 0 28.30 27.9 0 27.40 33.70 33.40 32.90 39.80 39.4 0 39.00 45.10 45.00 44.80
AMPS*
5.38 5.58 5.7 8 5.57 5.80 6.03 5.7 7 6.02 6.28 6.01 6.27 6.5 4 6.30 6.58 6.86 6.6 6 6.95 7.25 7.03 7.3 6 7.71 7.3 8 7.72 8.07
HI PR
227 242 259 240 257 27 4 256 273 291 275 29 2 311 299 31 8 336 328 347 367 358 38 0 403 388 410 433
LO PR
40 41 41 52 52 52 65 66 66 80 81 81 97 97 98 116 116 117 136 137 137 152 154 156
MBh†
6.92 6.61 6.2 7 8.84 8.53 8.22 10.8 7 10.59 10.3 0 13.19 12.86 12.5 4 15.80 15.4 6 15.08 18.65 18.28 17.90 21.54 21.2 9 20.94 24.09 23.87 23.61
T/R
10.80 10.40 10.0 0 13.90 13.60 13.20 17.2 0 16.90 16.60 21.10 20.70 20.4 0 25.40 25.1 0 24.70 30.30 29.90 29.50 35.30 35.2 0 34.90 39.80 39.80 39.70
AMPS*
5.46 5.66 5.8 6 5.64 5.87 6.10 5.8 2 6.06 6.32 6.03 6.29 6.5 5 6.30 6.57 6.84 6.6 3 6.91 7.21 6.93 7.2 5 7.58 7.2 5 7.58 7.92
HI PR
224 239 256 236 252 27 0 250 267 285 268 28 5 304 290 309 32 7 317 336 356 343 36 5 386 370 392 415
LO PR
40 40 41 52 52 52 65 65 66 80 81 81 97 97 98 115 116 116 134 135 137 150 152 154
105 115
Entering Indoor Temperature − Degrees F, Wet Bulb
525
600
675
COOLING
18 Size Outdoor With FS(M,U)4X18 Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85 95
Entering Indoor Temperature − Degrees F, Dry Bulb
525
600
675
HEATING
18 Size Outdoor With FS(M,U)4X18 Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
− 173 2737475767
7
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 7
CFM 72 67 63†† 62 57 7 2 67 63†† 62 57 7 2 67 63†† 62 57 7 2 67 63†† 62 57 72 67 63† † 62 57
MBh†
26.97 24.65 22.9 4 22.50 21.73 25.72 23.4 9 21.84 21.42 20.87 24.41 22.2 6 20.68 20.3 0 19.96 23.03 20.97 19.46 19.14 19.0 0 21.54 19.59 18.16 17.9 6 17.96
S/T‡
0.51 0.70 0.7 2 0.91 1.00 0.52 0.7 1 0.74 0.93 1.00 0.52 0.7 2 0.75 0.95 1.00 0.5 3 0.74 0.7 7 0.98 1.0 0 0.54 0.77 0.79 1.0 0 1.00
AMPS*
7.21 7.21 7.2 2 7.21 7.22 8.09 8.1 0 8.10 8.10 8.11 9.07 9.0 8 9.09 9.09 9.09 10.16 10.17 10.18 10.18 10.1 8 11.36 11.3 7 11.39 11.39 11.39
HI PR
281 278 275 275 274 32 4 320 318 317 316 37 1 367 365 36 4 363 422 418 416 415 41 5 479 475 473 472 473
LO PR
154 141 131 129 125 15 6 143 133 131 128 15 8 145 135 13 3 131 161 148 138 136 13 5 164 150 140 139 139
MBh†
27.42 25.09 23.3 7 22.96 22.57 26.13 23.8 8 22.22 21.86 21.66 24.76 22.6 0 21.02 20.7 2 20.70 24.27 21.27 19.76 19.67 19.6 7 21.80 19.84 18.41 18.5 7 18.57
S/T‡
0.53 0.73 0.7 5 0.95 1.00 0.53 0.7 4 0.77 0.97 1.00 0.54 0.7 6 0.79 1.00 1.00 0.5 5 0.78 0.8 1 1.00 1.0 0 0.57 0.81 0.83 1.0 0 1.00
AMPS*
7.36 7.36 7.3 7 7.37 7.37 8.25 8.2 5 8.26 8.26 8.26 9.22 9.2 3 9.24 9.24 9.24 8.9 5 10.32 10.34 10.33 10.3 3 11.50 11.5 2 11.53 11.54 11.54
HI PR
282 279 276 276 275 32 5 321 319 318 318 37 1 368 365 36 5 365 357 419 417 417 41 7 479 476 473 474 474
LO PR
157 144 134 132 130 15 9 146 136 134 133 16 2 148 138 13 7 137 162 150 140 140 14 0 166 153 143 144 144
MBh†
27.75 25.40 23.6 8 23.36 23.27 26.42 24.1 6 22.50 22.32 22.31 26.10 22.8 5 21.26 21.3 0 21.30 24.55 21.48 19.97 20.23 20.2 3 22.87 20.02 18.59 19.0 7 19.07
S/T‡
0.54 0.76 0.7 8 0.99 1.00 0.55 0.7 7 0.80 1.00 1.00 0.55 0.7 9 0.82 1.00 1.00 0.5 6 0.82 0.8 4 1.00 1.0 0 0.58 0.85 0.87 1.0 0 1.00
AMPS*
7.52 7.52 7.5 2 7.52 7.52 8.40 8.4 0 8.41 8.41 8.41 8.08 9.3 9 9.39 9.39 9.39 9.1 1 10.47 10.49 10.48 10.4 8 10.26 11.6 8 11.69 11.68 11.68
HI PR
282 279 277 276 276 32 5 322 319 319 319 30 8 369 366 36 6 366 358 420 417 418 41 8 413 476 474 475 475
LO PR
160 147 137 135 135 16 2 149 139 138 138 16 3 151 140 14 1 141 165 153 142 145 14 5 167 155 145 149 149
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
9.58 9.29 8.9 6 11.98 11.70 11.40 14.5 8 14.30 14.0 2 17.51 17.18 16.8 5 20.82 20.4 7 20.14 24.20 23.95 23.63 27.14 26.9 5 26.71 30.15 30.01 29.80
T/R
14.30 14.00 13.6 0 18.00 17.70 17.40 22.1 0 21.90 21.60 26.80 26.50 26.2 0 32.10 31.8 0 31.60 37.70 37.60 37.40 42.70 42.7 0 42.70 47.80 48.00 48.10
AMPS*
6.62 6.93 7.2 4 6.91 7.24 7.59 7.2 1 7.58 7.96 7.60 7.98 8.3 7 8.08 8.48 8.90 8.5 1 8.97 9.4 4 8.95 9.4 2 9.91 9.44 9.95 10.46
HI PR
233 250 267 248 265 28 3 265 283 301 286 30 5 324 312 33 1 352 336 358 381 361 38 4 408 389 414 438
LO PR
39 39 39 50 50 50 62 63 63 77 77 77 92 93 93 108 110 111 122 124 125 136 138 140
MBh†
9.77 9.48 9.1 5 12.19 11.91 11.61 14.8 1 14.53 14.2 5 17.80 17.46 17.1 3 21.14 20.7 9 20.44 24.17 24.00 23.84 26.94 26.8 3 26.68 29.60 29.61 29.54
T/R
12.70 12.50 12.1 0 16.00 15.70 15.50 19.5 0 19.30 19.10 23.70 23.40 23.2 0 28.30 28.1 0 27.90 32.70 32.70 32.80 36.70 36.8 0 37.00 40.60 41.00 41.20
AMPS*
6.68 7.00 7.3 1 6.94 7.28 7.63 7.2 1 7.57 7.95 7.56 7.93 8.3 2 8.00 8.39 8.80 8.3 2 8.76 9.23 8.70 9.1 6 9.64 9.0 8 9.58 10.09
HI PR
229 245 262 242 259 27 7 257 275 293 277 29 5 314 300 31 9 339 319 341 363 341 36 4 387 363 388 413
LO PR
38 39 39 50 50 50 62 62 63 76 77 77 92 92 93 106 108 109 119 121 123 131 133 136
MBh†
9.94 9.65 9.3 3 12.37 12.09 11.80 15.0 3 14.73 14.4 5 18.06 17.71 17.3 7 21.40 21.0 6 20.71 24.07 23.97 23.82 26.59 26.6 0 26.53 28.87 29.03 29.10
T/R
11.50 11.20 11.0 0 14.40 14.20 13.90 17.6 0 17.40 17.20 21.20 21.00 20.8 0 25.40 25.2 0 25.00 28.70 28.90 28.90 31.90 32.2 0 32.40 34.80 35.40 35.80
AMPS*
6.77 7.08 7.4 0 7.00 7.34 7.69 7.2 5 7.60 7.98 7.57 7.94 8.3 2 7.95 8.37 8.77 8.2 2 8.66 9.10 8.55 9.0 0 9.48 8.8 4 9.34 9.85
HI PR
226 242 259 237 254 27 2 251 269 287 270 28 8 306 290 310 33 0 307 328 350 326 34 8 371 343 368 393
LO PR
38 39 39 49 50 50 62 62 63 76 77 77 92 92 93 104 106 107 115 118 120 125 129 132
6727 37 47 57
Entering Indoor Temperature − Degrees F, Dry Bulb
700
800
900
HEATING
24 Size Outdoor With FS(M,U)4X24**** Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
−37 17
800
900
COOLING
24 Size Outdoor With FS(M,U)4X24 Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85 95 105 115
Entering Indoor Temperature − Degrees F, Wet Bulb
700
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
8 428 04 5402 00
CFM 57 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 57 62 63† † 67 72
MBh†
27.76 29.00 29.5 7 31.74 34.69 26.66 27.6 2 28.15 30.23 33.05 25.50 26.1 7 26.66 28.6 4 31.30 24.27 24.66 25.10 26.97 29.5 0 22.94 23.06 23.41 25.1 7 27.53
S/T‡
1.00 0.88 0.7 0 0.68 0.50 1.00 0.9 0 0.72 0.69 0.51 1.00 0.9 2 0.73 0.70 0.51 1.0 0 0.95 0.7 5 0.72 0.5 2 1.00 0.97 0.77 0.7 4 0.53
AMPS*
10.55 10.56 10.5 6 10.58 10.61 11.89 11.9 0 11.91 11.92 11.95 13.39 13.3 9 13.40 13.4 1 13.43 15.04 15.03 15.05 15.06 15.0 7 16.83 16.83 16.83 16.8 4 16.85
HI PR
278 280 280 283 287 32 1 322 323 326 330 36 8 369 370 37 3 377 419 420 421 424 42 9 475 475 476 480 484
LO PR
121 126 128 138 150 12 4 128 130 140 153 12 7 130 132 14 2 155 131 133 135 145 15 8 135 136 137 147 161
MBh†
29.75 30.51 31.0 6 33.24 36.21 28.58 29.0 9 29.58 31.67 34.50 27.34 27.6 0 28.01 30.0 0 32.68 26.03 26.06 26.39 28.26 30.8 0 24.61 24.61 24.64 26.3 9 28.76
S/T‡
1.00 0.92 0.7 4 0.71 0.53 1.00 0.9 4 0.75 0.72 0.53 1.00 0.9 6 0.77 0.74 0.54 1.0 0 1.00 0.7 9 0.76 0.5 5 1.00 1.00 0.81 0.7 9 0.57
AMPS*
9.22 9.23 9.2 3 9.25 9.28 10.57 10.5 7 10.58 10.5 9 10.62 12.05 12.0 6 12.06 12.0 8 12.10 13.70 13.70 13.71 13.71 13.7 3 15.49 15.49 15.50 15.5 0 15.50
HI PR
280 281 281 284 288 32 3 323 324 327 332 36 9 370 370 37 4 378 421 421 422 425 43 0 477 477 477 480 485
LO PR
126 129 131 141 154 12 9 131 133 143 156 13 3 134 135 14 5 159 136 136 138 148 16 1 140 140 140 150 164
MBh†
29.72 30.09 30.5 8 32.77 35.75 28.49 28.6 5 29.04 31.14 33.98 27.18 27.1 9 27.43 29.4 1 32.11 25.80 25.80 25.75 27.61 30.1 8 24.31 24.31 23.96 25.6 9 28.08
S/T‡
1.00 0.96 0.7 6 0.73 0.53 1.00 0.9 8 0.77 0.75 0.53 1.00 1.0 0 0.79 0.77 0.54 1.0 0 1.00 0.8 1 0.79 0.5 6 1.00 1.00 0.84 0.8 2 0.57
AMPS*
11.00 11.00 11.0 0 11.02 11.05 12.34 12.3 5 12.35 12.37 12.39 13.83 13.8 3 13.83 13.8 5 13.87 15.47 15.47 15.47 15.48 15.5 0 17.27 17.27 17.26 17.2 6 17.28
HI PR
281 282 282 285 289 32 4 324 325 328 332 37 1 371 371 37 5 379 422 422 422 426 43 1 479 479 478 481 486
LO PR
130 132 134 144 157 13 4 134 136 146 159 13 7 137 138 14 8 161 141 141 140 150 16 4 145 145 142 153 166
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
12.02 11.62 11.1 9 15.08 14.71 14.32 18.3 3 17.98 17.61 21.82 21.49 21.1 3 25.66 25.2 5 24.86 29.99 29.55 29.13 34.77 34.3 1 33.84 39.34 38.81 38.33
T/R
14.50 14.20 13.8 0 18.40 18.10 17.70 22.5 0 22.30 22.00 27.00 26.80 26.6 0 32.00 31.8 0 31.60 37.80 37.60 37.40 44.40 44.2 0 43.90 50.80 50.50 50.30
AMPS*
8.17 8.58 8.9 9 8.56 9.01 9.46 8.9 7 9.45 9.95 9.44 9.96 10.49 10.01 10.54 11.10 10.7 1 11.28 11.87 11.46 12.1 1 12.77 12.1 1 12.74 13.40
HI PR
235 251 268 251 268 28 6 269 287 306 291 31 0 329 316 33 6 356 347 368 390 381 40 4 428 412 435 459
LO PR
36 37 37 47 47 48 59 59 60 72 73 73 87 88 88 104 104 105 123 123 124 142 143 144
MBh†
12.26 11.85 11.4 2 15.33 14.97 14.58 18.6 1 18.26 17.90 22.12 21.79 21.4 4 26.04 25.6 4 25.23 30.47 30.00 29.56 35.11 34.7 0 34.25 39.58 39.17 38.72
T/R
12.90 12.60 12.3 0 16.30 16.00 15.70 19.9 0 19.70 19.50 23.80 23.70 23.5 0 28.30 28.1 0 27.80 33.40 33.10 32.90 38.80 38.7 0 38.50 44.20 44.10 44.00
AMPS*
8.24 8.65 9.0 7 8.59 9.03 9.49 8.9 5 9.43 9.92 9.36 9.87 10.40 9.86 10.3 9 10.93 10.49 11.05 11.62 11.05 11.6 7 12.32 11.6 7 12.29 12.93
HI PR
231 247 264 245 262 28 0 262 280 298 281 30 0 319 304 32 3 344 332 353 374 359 38 2 406 388 411 435
LO PR
36 37 37 47 47 47 59 59 59 72 73 73 87 88 88 103 104 104 122 123 124 140 141 142
MBh†
12.47 12.07 11.6 4 15.56 15.20 14.82 18.8 6 18.51 18.15 22.38 22.05 21.7 2 26.41 25.9 7 25.55 30.87 30.39 29.93 35.28 34.9 4 34.55 39.69 39.35 38.96
T/R
11.70 11.40 11.1 0 14.60 14.40 14.20 17.8 0 17.70 17.50 21.30 21.20 21.1 0 25.30 25.1 0 24.90 29.90 29.70 29.50 34.40 34.4 0 34.30 39.00 39.00 39.00
AMPS*
8.34 8.75 9.1 7 8.64 9.09 9.55 8.9 6 9.44 9.94 9.33 9.84 10.36 9.81 10.3 1 10.85 10.38 10.91 11.48 10.80 11.4 1 12.04 11.3 8 11.99 12.62
HI PR
228 244 260 241 258 27 5 256 273 292 273 29 2 311 295 31 4 334 321 341 362 343 36 6 389 370 393 417
LO PR
36 37 37 47 47 47 59 59 59 72 72 73 87 87 88 103 104 104 121 122 123 138 139 141
Entering Indoor Temperature − Degrees F, Dry Bulb
875
1000
1125
HEATING
30 Size Outdoor With FS(M,U)4X30**** Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
− 173 27374757677
Entering Indoor Temperature − Degrees F, Wet Bulb
875
1000
1125
COOLING
30 Size Outdoor With FS(M,U)4X30**** Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85 95 105
115
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 9
CFM 57 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 57 62 63† † 67 72
MBh†
33.16 33.94 34.5 4 37.01 40.35 31.86 32.3 5 32.90 35.27 38.48 30.46 30.6 9 31.16 33.4 2 36.50 28.98 28.99 29.32 31.48 34.4 3 27.35 27.35 27.34 29.3 8 32.16
S/T‡
1.00 0.91 0.7 2 0.69 0.50 1.00 0.9 3 0.73 0.70 0.51 1.00 0.9 5 0.75 0.72 0.52 1.0 0 1.00 0.7 7 0.74 0.5 3 1.00 1.00 0.79 0.7 7 0.54
AMPS*
10.88 10.88 10.8 9 10.91 10.93 12.11 12.1 1 12.12 12.14 12.16 13.47 13.4 7 13.48 13.4 9 13.52 14.96 14.96 14.97 14.99 15.0 1 16.58 16.58 16.58 16.6 0 16.63
HI PR
276 277 278 280 284 31 9 320 320 323 327 36 6 366 367 37 0 374 418 418 418 421 42 5 474 474 474 477 481
LO PR
121 124 125 135 147 12 4 126 127 137 150 12 7 128 130 13 9 152 131 131 132 142 15 4 135 135 134 144 157
MBh†
34.28 34.55 35.0 4 37.51 40.87 32.89 32.9 3 33.34 35.71 38.95 31.42 31.4 2 31.54 33.8 0 36.90 29.86 29.85 29.65 31.81 34.7 6 28.15 28.14 27.61 29.6 4 32.43
S/T‡
1.00 0.95 0.7 5 0.72 0.52 1.00 1.0 0 0.76 0.74 0.53 1.00 1.0 0 0.78 0.76 0.54 1.0 0 1.00 0.8 0 0.78 0.5 5 1.00 1.00 0.83 0.8 1 0.56
AMPS*
11.15 11.15 11.1 5 11.17 11.20 12.38 12.3 8 12.39 12.40 12.43 13.74 13.7 4 13.74 13.7 6 13.78 15.23 15.23 15.23 15.25 15.2 8 16.85 16.85 16.85 16.8 7 16.90
HI PR
278 278 279 281 285 32 1 321 321 324 328 36 7 367 368 37 0 374 419 419 419 422 42 6 475 475 475 478 481
LO PR
126 127 128 138 150 12 9 129 130 140 152 13 2 132 132 14 2 155 136 136 134 144 15 7 140 140 137 147 159
MBh†
35.18 35.17 35.4 2 37.88 41.26 33.73 33.7 3 33.67 36.03 39.28 32.19 32.1 8 31.82 34.08 37.18 30.5 5 30.55 29.89 32.04 34.9 9 28.77 28.77 27.81 29.8 3 32.60
S/T‡
1.00 1.00 0.7 8 0.75 0.53 1.00 1.0 0 0.80 0.77 0.54 1.00 1.0 0 0.82 0.79 0.55 1.0 0 1.00 0.8 4 0.82 0.5 7 1.00 1.00 0.87 0.8 5 0.58
AMPS*
11.41 11.41 11.4 2 11.44 11.46 12.65 12.6 5 12.65 12.67 12.69 14.01 14.0 1 14.01 14.02 14.05 15.5 0 15.50 15.50 15.52 15.5 4 17.12 17.12 17.11 17.1 3 17.16
HI PR
279 279 279 282 285 32 2 322 322 325 328 36 9 369 368 37 1 375 420 420 419 422 42 6 477 477 475 478 482
LO PR
130 130 130 140 153 13 3 133 132 142 155 13 6 136 134 14 4 157 140 140 136 146 15 9 144 144 139 149 161
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
14.67 14.11 13.5 0 18.39 17.89 17.35 22.3 4 21.87 21.37 26.52 26.08 25.6 1 31.22 30.68 30.14 35.5 9 35.26 34.88 39.80 39.4 6 39.08 44.00 43.69 43.32
T/R
13.80 13.40 12.9 0 17.40 17.10 16.70 21.3 0 21.10 20.70 25.50 25.30 25.1 0 30.30 30.00 29.70 34.8 0 34.80 34.70 39.20 39.2 0 39.20 43.70 43.80 43.80
AMPS*
9.60 9.97 10.3 5 10.07 10.50 10.93 10.5 4 11.02 11.5 0 11.09 11.60 12.1 3 11.73 12.2 7 12.82 12.22 12.82 13.44 12.81 13.4 3 14.08 13.43 14.09 14.77
HI PR
233 249 265 248 265 28 2 266 283 302 287 30 6 325 312 33 1 351 332 354 376 356 37 8 401 381 405 429
LO PR
38 38 38 49 49 49 61 61 62 75 75 76 90 91 91 104 105 106 117 118 120 130 132 134
MBh†
14.99 14.43 13.8 1 18.74 18.24 17.71 22.7 1 22.26 21.76 26.92 26.48 26.0 2 31.69 31.1 8 30.65 35.68 35.40 35.10 39.71 39.4 7 39.17 43.61 43.45 43.19
T/R
12.30 12.00 11.5 0 15.50 15.20 14.90 18.9 0 18.70 18.40 22.50 22.40 22.2 0 26.70 26.50 26.30 30.3 0 30.30 30.30 33.90 34.0 0 34.10 37.50 37.70 37.80
AMPS*
9.75 10.14 10.5 2 10.18 10.61 11.05 10.6 1 11.08 11.5 7 11.10 11.61 12.1 3 11.63 12.2 0 12.77 12.06 12.65 13.26 12.57 13.1 9 13.82 13.07 13.73 14.40
HI PR
229 245 261 243 260 27 7 259 276 295 278 29 6 316 299 31 9 340 317 338 360 338 36 0 383 359 382 407
LO PR
38 38 38 48 49 49 61 61 61 74 75 75 90 90 91 102 103 104 114 116 118 126 129 130
MBh†
15.28 14.73 14.1 1 19.04 18.56 18.03 23.0 3 22.59 22.10 27.30 26.85 26.3 8 31.99 31.5 8 31.06 35.69 35.47 35.21 39.57 39.4 5 39.15 43.09 43.06 42.93
T/R
11.10 10.80 10.5 0 13.90 13.70 13.40 17.0 0 16.80 16.60 20.20 20.10 19.9 0 23.90 23.8 0 23.60 26.80 26.80 26.90 29.80 30.0 0 30.10 32.70 32.90 33.10
AMPS*
9.93 10.32 10.7 0 10.32 10.76 11.20 10.7 1 11.18 11.6 7 11.17 11.67 12.1 9 11.62 12.1 8 12.76 12.01 12.59 13.19 12.45 13.0 6 13.69 12.86 13.51 14.18
HI PR
226 242 258 239 255 27 3 253 271 289 271 29 0 309 290 31 0 330 306 327 349 325 34 7 369 342 365 389
LO PR
38 38 38 48 49 49 61 61 61 74 75 75 89 90 91 100 102 103 112 114 116 123 125 127
1200
1350
HEATING
36 Size Outdoor With FSU4X36 Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
−3 7 17 27 37
105 115
Entering Indoor Temperature − Degrees F, Dry Bulb
1050
47 57 67
Entering Indoor Temperature − Degrees F, Wet Bulb
1050
1200
1350
COOLING
36 Size Outdoor With FSU4X36 Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85
95
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
10 428 04 5402 00
CFM 57 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 57 62 63† † 67 72
MBh†
39.05 40.45 41.2 3 44.21 48.26 37.54 38.5 6 39.29 42.14 46.00 35.93 36.5 8 37.24 39.9 6 43.63 34.22 34.53 35.09 37.67 41.1 5 32.37 32.38 32.79 35.2 0 38.47
S/T‡
1.00 0.91 0.7 2 0.69 0.51 1.00 0.9 3 0.73 0.71 0.52 1.00 0.9 5 0.75 0.72 0.52 1.0 0 0.97 0.7 7 0.74 0.5 3 1.00 1.00 0.79 0.7 6 0.54
AMPS*
13.22 13.25 13.2 6 13.31 13.40 14.67 14.6 8 14.69 14.74 14.81 16.27 16.2 8 16.29 16.3 3 16.39 18.03 18.04 18.05 18.08 18.1 4 19.98 19.98 19.99 20.0 1 20.05
HI PR
277 278 279 281 284 32 0 321 321 324 327 36 7 367 368 37 1 374 418 419 419 422 42 6 475 475 475 478 482
LO PR
125 129 131 141 154 12 8 131 133 143 156 13 1 133 135 14 5 159 135 136 137 148 16 1 139 139 140 150 164
MBh†
40.48 41.22 41.9 3 44.93 48.98 38.87 39.2 8 39.91 42.77 46.64 37.16 37.2 8 37.78 40.5 0 44.18 35.34 35.34 35.55 38.12 41.6 4 33.38 33.37 33.17 35.5 7 38.84
S/T‡
1.00 0.95 0.7 5 0.72 0.52 1.00 0.9 7 0.77 0.74 0.53 1.00 0.9 9 0.78 0.76 0.54 1.0 0 1.00 0.8 0 0.78 0.5 5 1.00 1.00 0.83 0.8 0 0.56
AMPS*
13.57 13.58 13.5 9 13.64 13.72 15.01 15.0 1 15.02 15.07 15.14 16.60 16.6 0 16.61 16.6 5 16.72 18.37 18.37 18.37 18.41 18.4 7 20.31 20.31 20.31 20.3 3 20.36
HI PR
278 279 279 282 285 32 1 321 322 325 328 36 8 368 369 37 2 375 420 420 420 423 42 7 476 476 476 478 482
LO PR
130 132 134 144 158 13 3 134 136 146 160 13 6 137 138 14 8 162 140 140 140 150 16 4 144 144 142 153 167
MBh†
41.65 41.88 42.4 4 45.43 49.51 39.96 39.9 6 40.35 43.21 47.10 38.15 38.1 5 38.16 40.87 44.56 36.2 4 36.24 35.87 38.43 41.9 6 34.18 34.17 33.43 35.8 2 39.08
S/T‡
1.00 0.99 0.7 8 0.75 0.54 1.00 1.0 0 0.80 0.77 0.55 1.00 1.0 0 0.82 0.79 0.56 1.0 0 1.00 0.8 4 0.82 0.5 7 1.00 1.00 0.87 0.8 4 0.58
AMPS*
13.90 13.91 13.9 1 13.97 14.05 15.34 15.3 4 15.34 15.40 15.47 16.93 16.9 3 16.93 16.97 17.04 18.6 9 18.69 18.69 18.73 18.7 9 20.63 20.63 20.62 20.6 5 20.68
HI PR
279 280 280 282 286 32 2 322 323 325 329 36 9 369 369 37 2 376 421 421 421 423 42 8 477 477 476 479 483
LO PR
135 135 137 147 160 13 8 138 138 149 162 14 1 141 140 15 1 164 144 144 142 153 16 6 148 148 145 155 169
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
17.53 17.06 16.5 4 21.61 21.17 20.69 26.0 0 25.58 25.13 30.74 30.29 29.8 5 36.21 35.68 35.03 42.0 9 41.58 41.04 47.60 47.1 1 46.60 53.07 52.62 52.13
T/R
14.50 14.30 13.9 0 18.00 17.80 17.60 21.8 0 21.70 21.50 26.00 25.90 25.7 0 30.90 30.70 30.40 36.3 0 36.10 36.00 41.40 41.3 0 41.20 46.60 46.60 46.50
AMPS*
11.81 12.34 12.8 8 12.28 12.86 13.45 12.8 1 13.42 14.05 13.41 14.06 14.7 3 14.17 14.85 15.52 14.9 2 15.67 16.45 15.64 16.4 0 17.19 16.49 17.29 18.12
HI PR
234 251 268 249 266 28 4 265 283 302 285 30 4 324 310 33 0 349 334 356 378 359 38 1 404 387 410 434
LO PR
36 36 36 46 47 47 58 59 59 72 72 73 87 87 88 103 104 105 118 119 120 132 134 135
MBh†
17.88 17.40 16.8 9 21.99 21.52 21.08 26.3 9 25.97 25.53 31.20 30.69 30.2 9 36.75 36.21 35.58 42.4 4 42.00 41.57 47.57 47.2 4 46.84 52.73 52.50 52.10
T/R
12.90 12.70 12.4 0 16.00 15.80 15.60 19.3 0 19.20 19.00 23.00 22.80 22.7 0 27.30 27.10 26.90 31.8 0 31.70 31.60 35.90 35.9 0 35.90 40.00 40.20 40.30
AMPS*
11.97 12.51 13.0 5 12.40 12.98 13.57 12.8 7 13.47 14.10 13.41 14.04 14.7 1 14.11 14.77 15.43 14.6 9 15.42 16.18 15.33 16.0 8 16.86 16.04 16.84 17.65
HI PR
230 246 263 243 260 27 8 258 276 295 276 29 4 314 298 31 8 338 318 339 362 340 36 2 385 364 387 411
LO PR
36 36 36 46 47 47 58 59 59 72 72 73 87 87 88 102 103 104 115 117 118 129 131 132
MBh†
18.21 17.74 17.2 1 22.32 21.88 21.41 26.7 5 26.32 25.90 31.61 31.11 30.6 7 37.22 36.68 36.15 42.5 0 42.19 41.81 47.37 47.1 5 46.84 52.15 52.04 51.83
T/R
11.70 11.50 11.2 0 14.40 14.20 14.00 17.3 0 17.20 17.10 20.60 20.50 20.3 0 24.40 24.30 24.10 28.1 0 28.10 28.10 31.50 31.6 0 31.70 34.90 35.10 35.30
AMPS*
12.17 12.71 13.2 5 12.55 13.13 13.72 12.9 8 13.59 14.21 13.48 14.10 14.7 6 14.14 14.79 15.48 14.6 0 15.31 16.05 15.17 15.9 1 16.68 15.78 16.56 17.36
HI PR
227 243 260 238 256 27 3 252 270 289 269 28 7 307 290 30 9 329 307 327 349 326 34 8 370 347 370 393
LO PR
36 36 36 46 47 47 58 59 59 72 72 72 87 87 87 100 102 103 113 115 116 125 127 129
Entering Indoor Temperature − Degrees F, Dry Bulb
1225
1400
1575
HEATING
42 Size Outdoor With FS(M,U)4X42**** Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
− 173 27374757677
Entering Indoor Temperature − Degrees F, Wet Bulb
1225
1400
1575
COOLING
42 Size Outdoor With FS(M,U)4X42**** Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85 95 105
115
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 11
CFM 57 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 57 62 63† † 67 72
MBh†
45.85 47.48 48.4 3 52.07 56.99 43.97 45.1 3 46.02 49.50 54.20 42.02 42.7 2 43.52 46.8 3 51.28 39.96 40.24 40.92 44.04 48.2 5 37.77 37.77 38.19 41.1 1 45.04
S/T‡
1.00 0.89 0.7 1 0.68 0.50 1.00 0.9 1 0.72 0.69 0.51 1.00 0.9 4 0.74 0.71 0.51 1.0 0 0.96 0.7 6 0.73 0.5 2 1.00 1.00 0.78 0.7 5 0.53
AMPS*
14.69 14.66 14.6 5 14.59 14.48 16.48 16.4 7 16.46 16.43 16.35 18.42 18.4 2 18.42 18.4 0 18.35 20.52 20.52 20.52 20.53 20.5 1 22.77 22.77 22.78 22.8 1 22.83
HI PR
271 272 273 276 281 31 3 314 315 318 323 35 9 360 360 36 4 369 409 409 410 414 42 0 464 464 465 469 474
LO PR
126 130 132 142 155 12 9 132 134 144 158 13 3 135 136 14 7 160 136 137 139 149 16 2 140 140 141 151 165
MBh†
47.61 48.44 49.3 1 52.98 57.90 45.61 46.0 3 46.79 50.29 55.00 43.52 43.5 5 44.18 47.5 0 51.96 41.33 41.33 41.48 44.61 48.8 2 39.01 39.00 38.66 41.5 7 45.51
S/T‡
1.00 0.93 0.7 4 0.71 0.51 1.00 0.9 6 0.75 0.73 0.52 1.00 1.0 0 0.77 0.74 0.53 1.0 0 1.00 0.7 9 0.77 0.5 4 1.00 1.00 0.82 0.7 9 0.55
AMPS*
15.04 15.02 15.0 1 14.94 14.83 16.84 16.8 4 16.83 16.79 16.70 18.80 18.8 0 18.80 18.7 7 18.72 20.91 20.91 20.91 20.91 20.8 8 23.17 23.17 23.17 23.1 9 23.21
HI PR
273 273 274 277 282 31 5 315 316 320 324 36 1 361 362 36 5 370 411 411 411 416 42 1 466 466 466 470 476
LO PR
131 133 135 145 159 13 5 136 137 147 161 13 8 138 139 15 0 163 142 142 141 152 16 6 145 145 144 154 168
MBh†
49.07 49.26 49.9 5 53.62 58.55 46.96 46.9 5 47.35 50.84 55.56 44.75 44.7 5 44.66 47.96 52.43 42.4 4 42.44 41.88 44.99 49.2 1 39.99 39.99 38.98 41.8 8 45.80
S/T‡
1.00 0.97 0.7 7 0.74 0.53 1.00 1.0 0 0.78 0.76 0.54 1.00 1.0 0 0.80 0.78 0.55 1.0 0 1.00 0.8 3 0.80 0.5 6 1.00 1.00 0.86 0.8 3 0.58
AMPS*
15.39 15.38 15.3 8 15.30 15.18 17.20 17.2 0 17.20 17.15 17.06 19.17 19.1 7 19.17 19.15 19.08 21.2 9 21.29 21.29 21.29 21.2 5 23.56 23.56 23.56 23.5 8 23.58
HI PR
274 274 275 278 282 31 7 317 317 320 325 36 3 363 362 36 6 371 413 413 412 416 42 1 468 468 467 471 476
LO PR
136 137 138 148 162 13 9 139 140 150 164 14 2 142 142 15 2 166 146 146 144 154 16 8 150 150 146 156 170
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
20.81 20.34 19.8 4 25.42 24.97 24.49 30.3 8 29.94 29.50 35.87 35.33 34.8 4 42.17 41.59 41.03 48.3 1 47.84 47.37 54.67 54.2 5 53.77 57.59 58.09 58.58
T/R
15.10 14.80 14.6 0 18.50 18.30 18.10 22.3 0 22.10 22.00 26.50 26.30 26.2 0 31.40 31.30 31.10 36.3 0 36.30 36.20 41.50 41.5 0 41.50 43.90 44.70 45.50
AMPS*
13.31 13.89 14.4 8 13.85 14.48 15.12 14.4 3 15.10 15.80 15.07 15.78 16.5 3 15.76 16.58 17.42 16.4 6 17.28 18.13 17.33 18.1 9 19.09 17.65 18.70 19.80
HI PR
234 250 268 247 264 28 3 263 282 300 283 30 2 322 305 32 6 348 329 350 371 356 37 8 401 367 394 423
LO PR
37 37 37 47 48 48 60 60 60 73 74 74 88 89 89 103 104 105 118 119 120 124 128 132
MBh†
21.19 20.73 20.2 3 25.83 25.38 24.91 30.8 1 30.38 29.94 36.40 0.00 35.31 42.6 2 42.17 41.6 1 48.38 48.00 47.60 52.0 0 52.90 53.57 53.71 54.7 6 55.57
T/R
13.40 13.20 13.0 0 16.40 16.20 16.10 19.7 0 19.60 19.50 23.40 -70.0 0 23.10 27.60 27.60 27.4 0 31.60 31.6 0 31.60 34.10 35.00 35.8 0 35.30 36.30 37.30
AMPS*
13.51 14.09 14.6 9 14.00 14.63 15.27 14.5 1 15.19 15.87 15.09 0.00 16.52 15.6 4 16.42 17.2 3 16.28 17.08 17.91 16.6 6 17.67 18.71 16.77 17.8 1 18.88
HI PR
229 246 263 241 258 27 7 256 274 293 274 -15 31 2 293 313 334 314 335 35 6 327 354 382 332 359 388
LO PR
37 37 37 47 48 48 60 60 60 73 -15 74 88 88 89 101 102 103 109 114 118 113 117 122
MBh†
21.55 21.08 20.5 9 26.21 25.76 25.29 31.2 0 30.78 30.34 36.89 36.32 35.7 7 42.78 42.48 42.06 48.0 8 47.99 47.67 49.39 50.4 5 51.31 50.69 51.89 52.92
T/R
12.10 11.90 11.7 0 14.70 14.60 14.50 17.6 0 17.60 17.50 21.00 20.80 20.7 0 24.50 24.50 24.50 27.7 0 27.90 28.00 28.50 29.4 0 30.20 29.30 30.30 31.20
AMPS*
13.75 14.33 14.9 2 14.19 14.82 15.46 14.6 6 15.33 16.01 15.21 15.89 16.6 1 15.66 16.42 17.21 16.2 1 17.02 17.84 16.27 17.2 4 18.24 16.33 17.32 18.35
HI PR
226 242 260 236 254 27 2 250 268 287 268 28 6 305 284 30 4 324 303 324 345 306 33 2 358 308 335 362
LO PR
37 37 37 47 48 48 59 60 60 73 73 74 87 88 89 99 101 102 101 106 110 104 109 114
Entering Indoor Temperature − Degrees F, Dry Bulb
1400
1600
1800
HEATING
48 Size Outdoor With FS(M,U)4X48**** Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
− 173 27374757677
Entering Indoor Temperature − Degrees F, Wet Bulb
1400
1600
1800
COOLING
48 Size Outdoor With FS(M,U)4X48**** Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85 95 105
115
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
12 428 04 5402 00
CFM 57 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 5 7 62 63†† 67 72 57 62 63† † 67 72
MBh†
57.36 59.39 60.5 3 64.73 70.28 55.12 56.6 0 57.68 61.72 67.10 52.73 53.6 7 54.66 58.5 0 63.63 50.21 50.63 51.50 55.15 60.0 1 47.45 47.46 48.09 51.5 0 56.06
S/T‡
1.00 0.89 0.7 1 0.68 0.50 1.00 0.9 1 0.72 0.70 0.51 1.00 0.9 4 0.74 0.71 0.52 1.0 0 0.96 0.7 6 0.73 0.5 2 1.00 1.00 0.78 0.7 5 0.54
AMPS*
19.05 19.15 19.1 9 19.39 19.65 21.05 21.1 2 21.17 21.37 21.63 23.25 23.3 0 23.35 23.5 5 23.81 25.67 25.69 25.73 25.94 26.2 1 28.32 28.32 28.35 28.5 6 28.82
HI PR
285 287 288 292 297 32 9 330 331 336 341 37 6 377 378 38 3 389 428 429 430 435 44 1 485 485 486 491 497
LO PR
125 129 131 141 155 12 8 131 133 144 157 13 1 134 136 14 6 159 135 136 138 148 16 2 139 139 140 150 164
MBh†
59.46 60.48 61.5 4 65.72 71.26 57.07 57.6 3 58.58 62.60 67.97 54.53 54.6 6 55.44 59.2 6 64.37 51.85 51.85 52.17 55.79 60.6 4 48.92 48.91 48.63 52.0 1 56.56
S/T‡
1.00 0.94 0.7 4 0.71 0.52 1.00 0.9 6 0.75 0.73 0.52 1.00 0.9 9 0.77 0.75 0.53 1.0 0 1.00 0.7 9 0.77 0.5 4 1.00 1.00 0.82 0.7 9 0.56
AMPS*
19.62 19.67 19.7 1 19.91 20.17 21.62 21.6 5 21.69 21.89 22.15 23.82 23.8 3 23.86 24.0 6 24.33 26.24 26.24 26.25 26.45 26.7 2 28.89 28.89 28.86 29.0 7 29.32
HI PR
287 288 289 293 298 33 1 332 333 337 342 37 9 379 380 38 4 390 431 431 431 436 44 2 488 488 487 492 498
LO PR
130 133 135 145 159 13 3 135 137 147 160 13 7 137 138 14 9 163 140 140 141 151 16 5 144 144 143 153 167
MBh†
61.15 61.41 62.2 6 66.42 71.95 58.65 58.6 5 59.21 63.21 68.56 55.97 55.9 7 55.98 59.77 64.87 53.1 6 53.15 52.62 56.21 61.0 4 50.07 50.06 49.00 52.3 4 56.86
S/T‡
1.00 0.97 0.7 7 0.74 0.53 1.00 1.0 0 0.78 0.76 0.54 1.00 1.0 0 0.80 0.78 0.55 1.0 0 1.00 0.8 3 0.81 0.5 6 1.00 1.00 0.86 0.8 3 0.58
AMPS*
20.17 20.18 20.2 2 20.42 20.67 22.17 22.1 7 22.19 22.39 22.65 24.37 24.3 7 24.36 24.57 24.83 26.7 9 26.79 26.75 26.95 27.2 1 29.43 29.43 29.36 29.5 6 29.82
HI PR
289 290 290 294 299 33 3 333 334 338 343 38 1 381 381 38 5 391 433 433 432 437 44 3 490 490 488 493 499
LO PR
135 136 137 148 161 13 8 138 139 149 163 14 1 141 141 15 1 165 145 145 143 153 16 7 149 149 145 156 170
CFM 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75 65 70 75
MBh†
24.57 23.76 22.9 0 30.47 29.75 28.96 36.6 9 36.02 35.29 43.32 42.67 42.0 0 50.72 49.99 49.25 58.7 6 58.00 57.22 66.48 65.6 6 64.84 74.57 73.71 72.82
T/R
14.10 13.70 13.3 0 17.60 17.30 17.00 21.3 0 21.10 20.80 25.30 25.20 25.0 0 29.90 29.70 29.50 35.0 0 34.80 34.60 39.90 39.7 0 39.60 45.20 45.00 44.90
AMPS*
16.03 16.71 17.4 0 16.75 17.50 18.27 17.4 9 18.29 19.12 18.30 19.16 20.0 5 19.25 20.16 21.10 20.0 5 20.99 21.98 21.05 22.0 4 23.07 22.17 23.21 24.28
HI PR
230 246 263 243 260 27 7 258 276 294 276 29 4 314 295 31 5 335 314 334 355 337 35 8 380 363 385 408
LO PR
34 35 35 44 45 45 56 56 57 68 69 69 83 83 84 97 98 99 112 113 114 127 128 129
MBh†
25.10 24.29 23.4 3 31.01 30.31 29.54 37.2 9 36.63 35.89 43.97 43.31 42.6 6 51.55 50.73 50.01 59.1 8 58.52 57.81 66.76 66.0 6 65.31 73.14 73.11 72.79
T/R
12.50 12.20 11.9 0 15.60 15.40 15.10 18.9 0 18.70 18.50 22.40 22.20 22.1 0 26.40 26.20 26.10 30.6 0 30.50 30.40 34.70 34.7 0 34.60 38.30 38.70 38.80
AMPS*
16.31 16.99 17.6 9 16.96 17.71 18.49 17.6 2 18.42 19.25 18.34 19.19 20.0 8 19.14 20.07 21.03 19.8 6 20.79 21.76 20.72 21.7 0 22.72 21.46 22.57 23.69
HI PR
226 242 259 237 254 27 2 251 269 287 267 28 5 304 284 30 3 324 300 320 341 320 34 1 363 337 361 385
LO PR
34 35 35 44 45 45 56 56 56 68 69 69 83 83 83 96 97 98 110 111 112 122 124 126
MBh†
25.59 24.78 23.9 2 31.52 30.81 30.05 37.8 1 37.15 36.44 44.55 43.89 43.2 2 52.26 51.46 50.75 59.4 2 58.83 58.23 66.69 66.1 4 65.53 70.31 70.72 70.80
T/R
11.30 11.10 10.8 0 14.00 13.90 13.60 16.9 0 16.80 16.60 20.10 19.90 19.8 0 23.70 23.50 23.40 27.1 0 27.10 27.00 30.60 30.6 0 30.60 32.40 32.90 33.20
AMPS*
16.63 17.30 18.0 1 17.22 17.97 18.75 17.8 2 18.62 19.44 18.49 19.33 20.2 0 19.15 20.07 21.01 19.8 2 20.75 21.70 20.57 21.5 4 22.54 20.88 21.99 23.12
HI PR
222 239 256 233 250 26 7 246 263 281 260 27 8 297 274 29 4 314 290 310 330 307 32 8 350 315 339 363
LO PR
34 35 35 44 45 45 56 56 56 68 69 69 82 83 83 95 96 97 108 109 111 114 117 120
Entering Indoor Temperature − Degrees F, Dry Bulb
1750
2000
2250
HEATING
60 Size Outdoor With FS(M,U)4X60**** Indoor Heating
Outdoor Ambient Temperature − Degrees F, Dry Bulb
− 173 27374757677
Entering Indoor Temperature − Degrees F, Wet Bulb
1750
2000
2250
COOLING
60 Size Outdoor With FS(M,U)4X60**** Indoor Cooling
Outdoor Ambient Temperature − Degrees F, Dry Bulb
75 85 95 105
115
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 13
COOLING Multiplying Factors for other Indoor Combinations
Indoor
Model
Furnace
Model
Capac. (MBh) Power (AMPS)
Indoor
Model
Furnace
Model
Capac. (MBh) Power (AMPS)
Indoor
Model
Furnace
Model
Capac. (MBh) Power (AMPS)
(C,H,T)4H318
*FS(M,U)4X18**** 1.00 1.00 EHD4X24A** *9MPV075 1.05 0.96 FEM4P24**A* 1.02 0.93
ED*4X18B** *8MPV050 1.02 0.97 EHD4X24A** *9MVX040 1.05 0.96 FEM4X18**** 1.02 0.93
ED*4X18B** MV08B15**B* 1.01 0.92 EHD4X24A** *9MVX060 1.05 0.96 FEM4X24**** 1.03 0.94
ED*4X24B** *8MPV050 1.05 0.96 EHD4X24A** MV08B15**B* 1.03 0.90 FS(M,U)4P18**A* 1.02 0.97
ED*4X24B** MV08B15**B* 1.02 0.91 EHD4X24A** 1.02 1.02 FS(M,U)4P24**A* 1.02 0.98
ED*4X24B** 1.01 1.01 EMA4X24D** 1.02 1.02 FSA4X18**A* 1.00 1.05
ED*4X24F** 1.01 1.01 FEA4X18**A* 1.01 0.92 FSA4X24**A* 1.01 1.01
EHD4X24A** *8MPV050 1.05 0.96 FEA4X24**A* 1.03 0.90 FVM4X24**** 1.03 0.90
EHD4X24A** *9MPV050 1.05 0.96 FEM4P18**A* 1.02 0.93 FXM4X18**A* 1.04 0.91
FXM4X24**A* 1.04 0.91
(C,H,T)4H324
*FS(M,U)4X24**** 1.00 1.00 EHD4X24A** *8MPV075 1.02 0.96 EHD4X30A** *9MVX040 1.04 0.97
ED*4X24B** *8MPV050 1.02 0.98 EHD4X24A** *8MPV100 1.04 0.97 EHD4X30A** *9MVX060 1.04 0.98
ED*4X24B** MV08B15**B* 1.02 0.92 EHD4X24A** *8MPV125 1.03 0.96 EHD4X30A** *9MVX080 1.05 0.95
ED*4X24B** 1.01 1.01 EHD4X24A** *9MPV050 1.02 0.98 EHD4X30A** *9MVX100 1.05 0.95
ED*4X24F** *8MPV075 1.03 0.96 EHD4X24A** *9MPV075 1.02 0.98 EHD4X30A** MV08B15**B* 1.04 0.93
ED*4X24F** *9MPV050 1.02 0.96 EHD4X24A** *9MPV100 1.03 0.96 EHD4X30A** MV12F19**B* 1.04 0.93
ED*4X24F** *9MPV075 1.03 0.96 EHD4X24A** *9MPV125 1.04 0.97 EHD4X30A** 1.02 1.02
ED*4X24F** *9MVX040 1.02 0.96 EHD4X24A** *9MVX040 1.02 0.96 EMA4X24D** 1.01 1.01
ED*4X24F** *9MVX060 1.03 0.96 EHD4X24A** *9MVX060 1.03 0.96 FEA4X24**A* 1.00 0.94
ED*4X24F** MV12F19**B* 1.02 0.92 EHD4X24A** *9MVX080 1.04 0.98 FEA4X30**A* 1.01 0.95
ED*4X24F** 1.01 1.01 EHD4X24A** *9MVX100 1.04 0.97 FEM4P24**A* 1.00 0.96
ED*4X30B** *8MPV050 1.04 0.97 EHD4X24A** MV08B15**B* 1.03 0.92 FEM4P30**A* 1.04 0.97
ED*4X30B** MV08B15**B* 1.03 0.92 EHD4X24A** MV12F19**B* 1.03 0.92 FEM4X24**** 1.02 0.96
ED*4X30B** 1.02 1.02 EHD4X24A** 1.01 1.01 FEM4X30**** 1.04 0.96
ED*4X30F** *8MPV075 1.04 0.98 EHD4X30A** *8MPV050 1.04 0.97 FS(M,U)4P24**A* 1.03 0.99
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
14 428 04 5402 00
COOLING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
ED*4X30F** *9MPV050 1.04 0.97 EHD4X30A** *8MPV075 1.04 0.98 FS(M,U)4P30**A* 1.04 1.00
ED*4X30F** *9MPV075 1.04 0.97 EHD4X30A** *8MPV100 1.05 0.95 FS(M,U)4X30**** 1.02 1.02
ED*4X30F** *9MVX040 1.04 0.97 EHD4X30A** *8MPV125 1.06 0.96 FVM4X24**** 1.03 0.92
ED*4X30F** *9MVX060 1.04 0.98 EHD4X30A** *9MPV050 1.04 0.97 FVM4X36**** 1.03 0.92
ED*4X30F** MV12F19**B* 1.03 0.92 EHD4X30A** *9MPV075 1.04 0.97 FXM4X24**A* 1.04 0.97
ED*4X30F** 1.02 1.02 EHD4X30A** *9MPV100 1.04 0.97 FXM4X30**A* 1.04 0.98
EHD4X24A** *8MPV050 1.02 0.98 EHD4X30A** *9MPV125 1.05 0.99
(C,H,T)4H330
*FS(M,U)4P30**A* 1.00 1.00 EHD4X30A** *8MPV075 1.00 1.00 EHD4X36A** *9MPV125 1.00 0.96
ED*4X30B** MV08B15**B* 1.00 0.96 EHD4X30A** *8MPV100 1.00 1.00 EHD4X36A** *9MVX040 1.00 1.00
ED*4X30F** *8MPV075 1.00 1.00 EHD4X30A** *8MPV125 1.00 0.96 EHD4X36A** *9MVX060 1.00 1.00
ED*4X30F** *9MPV050 1.00 1.00 EHD4X30A** *9MPV050 1.00 1.00 EHD4X36A** *9MVX080 1.00 0.96
ED*4X30F** *9MPV075 1.00 1.00 EHD4X30A** *9MPV075 1.00 1.00 EHD4X36A** *9MVX100 1.00 0.96
ED*4X30F** *9MVX040 1.00 1.00 EHD4X30A** *9MPV100 1.00 1.00 EHD4X36A** MV08B15**B* 1.00 0.96
ED*4X30F** *9MVX060 1.00 1.00 EHD4X30A** *9MPV125 1.00 1.00 EHD4X36A** MV12F19**B* 1.00 0.96
ED*4X30F** MV12F19**B* 1.00 0.96 EHD4X30A** *9MVX040 1.00 1.00 FEA4X30**A* 1.00 1.00
ED*4X36B** MV08B15**B* 1.00 0.96 EHD4X30A** *9MVX060 1.00 1.00 FEA4X36**A* 1.00 1.00
ED*4X36F** *8MPV075 1.00 1.00 EHD4X30A** *9MVX080 1.00 1.00 FEM4P30**A* 1.00 1.00
ED*4X36F** *9MPV050 1.00 1.00 EHD4X30A** *9MVX100 1.00 1.00 FEM4P30**A* 1.00 1.00
ED*4X36F** *9MPV075 1.00 1.00 EHD4X30A** MV08B15**B* 1.00 0.96 FEM4P36**A* 1.00 1.00
ED*4X36F** *9MVX040 1.00 1.00 EHD4X30A** MV12F19**B* 1.00 0.96 FEM4P36**A* 1.00 1.00
ED*4X36F** *9MVX060 1.00 1.00 EHD4X36A** *8MPV050 1.00 1.00 FEM4X30**** 1.00 1.00
ED*4X36F** MV12F19**B* 1.00 0.96 EHD4X36A** *8MPV075 1.00 0.96 FEM4X36**** 1.00 1.00
ED*4X36J** *8MPV100 1.00 0.96 EHD4X36A** *8MPV100 1.00 0.96 FS(M,U)4P30**A* 1.00 1.00
ED*4X36J** *8MPV125 1.00 0.96 EHD4X36A** *8MPV125 1.00 0.96 FVM4X24**** 1.00 0.96
ED*4X36J** *9MPV100 1.00 0.96 EHD4X36A** *9MPV050 1.00 1.00 FVM4X36**** 1.00 0.96
ED*4X36J** *9MVX080 1.00 0.96 EHD4X36A** *9MPV075 1.00 1.00 FVM4X48**** 1.00 0.96
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 15
COOLING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
EHD4X30A** *8MPV050 1.00 1.00 EHD4X36A** *9MPV100 1.00 0.96 FXM4X30**A* 1.00 0.96
FXM4X36**A* 1.00 0.96
(C,H,T)4H336
*FS(M,U)4P36**A* 1.00 1.00 ED*4X42J** MV16J22**B* 1.00 0.96 EHD4X42A** *9MPV075 1.00 0.96
ED*4X36B** *8MPV050 0.99 0.99 ED*4X42J** 1.00 1.00 EHD4X42A** *9MPV100 1.00 0.96
ED*4X36B** MV08B15**B* 0.99 0.95 ED*4X42L** *9MPV125 1.00 0.96 EHD4X42A** *9MPV125 1.00 0.96
ED*4X36B** 0.99 0.99 ED*4X42L** *9MVX100 1.00 0.96 EHD4X42A** *9MVX040 1.00 1.00
ED*4X36F** *8MPV075 0.99 0.95 ED*4X42L** MV20L24**B* 1.00 0.96 EHD4X42A** *9MVX060 1.00 0.96
ED*4X36F** *9MPV050 0.99 0.99 ED*4X42L** 1.00 1.00 EHD4X42A** *9MVX080 1.00 0.96
ED*4X36F** *9MPV075 0.99 0.99 EHD4X36A** *8MPV050 0.99 0.99 EHD4X42A** *9MVX100 1.00 0.96
ED*4X36F** *9MVX040 0.99 0.99 EHD4X36A** *8MPV075 0.99 0.95 EHD4X42A** MV08B15**B* 1.00 0.96
ED*4X36F** *9MVX060 0.99 0.99 EHD4X36A** *8MPV100 0.99 0.95 EHD4X42A** MV12F19**B* 1.00 0.92
ED*4X36F** MV12F19**B* 0.99 0.95 EHD4X36A** *8MPV125 0.99 0.95 EHD4X42A** MV16J22**B* 1.00 0.92
ED*4X36F** 0.99 0.99 EHD4X36A** *9MPV050 0.99 0.99 EHD4X42A** MV20L24**B* 1.00 0.92
ED*4X36J** *8MPV100 0.99 0.95 EHD4X36A** *9MPV075 0.99 0.95 EHD4X42A** 1.00 1.00
ED*4X36J** *8MPV125 0.99 0.95 EHD4X36A** *9MPV100 0.99 0.95 EMA4X36D** 0.99 0.99
ED*4X36J** *9MPV100 0.99 0.95 EHD4X36A** *9MPV125 0.99 0.95 FEA4X36**A* 1.00 1.00
ED*4X36J** *9MVX080 0.99 0.95 EHD4X36A** *9MVX040 0.99 0.99 FEM4P36**A* 1.00 1.00
ED*4X36J** MV16J22**B* 0.99 0.95 EHD4X36A** *9MVX060 0.99 0.95 FEM4P36**A* 1.00 1.00
ED*4X36J** 0.99 0.99 EHD4X36A** *9MVX080 0.99 0.95 FEM4P42**A* 1.00 1.00
ED*4X42F** *8MPV075 1.00 0.96 EHD4X36A** *9MVX100 0.99 0.95 FEM4P42**A* 1.00 0.96
ED*4X42F** *9MPV050 1.00 1.00 EHD4X36A** MV08B15**B* 0.99 0.95 FEM4X36**** 1.00 0.96
ED*4X42F** *9MPV075 1.00 1.00 EHD4X36A** MV12F19**B* 0.99 0.91 FEM4X42**** 1.00 0.96
ED*4X42F** *9MVX040 1.00 1.00 EHD4X36A** MV16J22**B* 0.99 0.91 FS(M,U)4P36**A* 1.00 1.00
ED*4X42F** *9MVX060 1.00 1.00 EHD4X36A** MV20L24**B* 0.99 0.91 FS(M,U)4P42**A* 1.00 1.00
ED*4X42F** MV12F19**B* 1.00 0.96 EHD4X36A** 0.99 0.99 FS(M,U)4P42**A* 1.00 1.00
ED*4X42F** 1.00 1.00 EHD4X42A** *8MPV050 1.00 1.00 FS(M,U)4X42**** 1.00 1.00
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
16 428 04 5402 00
COOLING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
ED*4X42J** *8MPV100 1.00 0.96 EHD4X42A** *8MPV075 1.00 0.96 FSM4X36**** 1.00 1.00
ED*4X42J** *8MPV125 1.00 0.96 EHD4X42A** *8MPV100 1.00 0.96 FVM4X24**** 1.00 0.96
ED*4X42J** *9MPV100 1.00 0.96 EHD4X42A** *8MPV125 1.00 0.96 FVM4X36**** 1.00 0.96
ED*4X42J** *9MVX080 1.00 0.96 EHD4X42A** *9MPV050 1.00 1.00 FVM4X48**** 1.01 0.92
FXM4X36**A* 1.00 0.96
FXM4X42**A* 1.00 0.96
(C,H,T)4H342
*FS(M,U)4P42**A* 1.00 1.00 ED*4X48J** 1.00 1.00 EHD4X48A** *9MVX060 1.00 0.96
ED*4X42F** *8MPV075 0.98 0.98 ED*4X48L** *9MPV125 1.00 0.96 EHD4X48A** *9MVX080 1.00 0.96
ED*4X42F** MV12F19**B* 0.98 0.93 ED*4X48L** *9MVX100 1.00 0.96 EHD4X48A** *9MVX100 1.00 0.96
ED*4X42F** 0.98 0.98 ED*4X48L** MV20L24**B* 1.00 0.96 EHD4X48A** MV12F19**B* 1.00 0.92
ED*4X42J** *8MPV100 0.98 0.93 ED*4X48L** 1.00 1.00 EHD4X48A** MV16J22**B* 1.00 0.92
ED*4X42J** *8MPV125 0.98 0.93 EHD4X42A** *8MPV075 0.98 0.93 EHD4X48A** MV20L24**B* 1.00 0.92
ED*4X42J** *9MPV100 0.98 0.93 EHD4X42A** *8MPV100 0.98 0.93 EHD4X48A** 1.00 1.00
ED*4X42J** *9MVX080 0.98 0.93 EHD4X42A** *8MPV125 0.98 0.93 EMA4X48D** 1.00 1.00
ED*4X42J** MV16J22**B* 0.98 0.93 EHD4X42A** *9MPV075 0.98 0.98 FEM4P42**A* 1.00 1.00
ED*4X42J** 0.98 0.98 EHD4X42A** *9MPV100 0.98 0.93 FEM4P42**A* 1.00 0.96
ED*4X42L** *9MPV125 0.98 0.93 EHD4X42A** *9MPV125 0.98 0.93 FEM4P48**A* 1.00 1.00
ED*4X42L** *9MVX100 0.98 0.93 EHD4X42A** *9MVX060 0.98 0.98 FEM4P48**A* 1.00 0.96
ED*4X42L** MV20L24**B* 0.98 0.93 EHD4X42A** *9MVX080 0.98 0.93 FEM4X42**** 1.00 0.96
ED*4X42L** 0.98 0.98 EHD4X42A** *9MVX100 0.98 0.93 FEM4X48**** 1.00 0.92
ED*4X48F** *8MPV075 1.00 0.96 EHD4X42A** MV12F19**B* 0.98 0.93 FS(M,U)4P42**A* 1.00 1.00
ED*4X48F** *9MPV075 0.98 0.98 EHD4X42A** MV16J22**B* 0.98 0.93 FS(M,U)4P48**A* 1.00 1.00
ED*4X48F** *9MVX060 1.00 1.00 EHD4X42A** MV20L24**B* 0.98 0.93 FS(M,U)4P48**A* 1.00 1.00
ED*4X48F** MV12F19**B* 1.00 0.92 EHD4X42A** 0.98 0.98 FS(M,U)4X42**** 0.98 0.98
ED*4X48F** 1.00 1.00 EHD4X48A** *8MPV075 1.00 0.96 FS(M,U)4X48**** 1.00 1.00
ED*4X48J** *8MPV100 1.00 0.96 EHD4X48A** *8MPV100 1.00 0.96 FVM4X36**** 0.98 0.93
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 17
COOLING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
ED*4X48J** *8MPV125 1.00 0.96 EHD4X48A** *8MPV125 1.00 0.96 FVM4X48**** 1.00 0.92
ED*4X48J** *9MPV100 1.00 0.96 EHD4X48A** *9MPV075 1.00 1.00 FXM4X42**A* 1.00 0.96
ED*4X48J** *9MVX080 1.00 0.96 EHD4X48A** *9MPV100 1.00 0.96 FXM4X48**A* 1.00 0.92
ED*4X48J** MV16J22**B* 1.00 0.96 EHD4X48A** *9MPV125 1.00 0.96
(C,H,T)4H348
*FS(M,U)4P48**A* 1.00 1.00 ED*4X60J** 1.00 1.00 EHD4X60A** *9MPV125 1.00 0.96
ED*4X48F** 0.98 0.98 ED*4X60L** *9MPV125 1.00 0.96 EHD4X60A** *9MVX080 1.00 0.96
ED*4X48J** *8MPV100 0.98 0.94 ED*4X60L** *9MVX100 1.00 0.96 EHD4X60A** *9MVX100 1.00 0.96
ED*4X48J** *8MPV125 0.98 0.94 ED*4X60L** MV20L24**B* 1.00 0.96 EHD4X60A** MV16J22**B* 1.00 0.96
ED*4X48J** *9MPV100 0.98 0.98 ED*4X60L** 1.00 1.00 EHD4X60A** MV20L24**B* 1.00 0.96
ED*4X48J** *9MVX080 0.98 0.98 EHD4X48A** *8MPV100 0.98 0.94 EHD4X60A** 1.00 1.00
ED*4X48J** MV16J22**B* 0.98 0.94 EHD4X48A** *8MPV125 0.98 0.94 FEM4P48**A* 0.98 0.98
ED*4X48J** 0.98 0.98 EHD4X48A** *9MPV100 0.98 0.94 FEM4P48**A* 0.98 0.98
ED*4X48L** *9MPV125 0.98 0.94 EHD4X48A** *9MPV125 0.98 0.94 FEM4P60**A* 1.00 1.00
ED*4X48L** *9MVX100 0.98 0.94 EHD4X48A** *9MVX080 0.98 0.94 FEM4P60**A* 1.00 0.96
ED*4X48L** MV20L24**B* 0.98 0.94 EHD4X48A** *9MVX100 0.98 0.94 FEM4X48**** 1.00 0.96
ED*4X48L** 0.98 0.98 EHD4X48A** MV16J22**B* 0.98 0.94 FEM4X60**** 1.00 0.96
ED*4X60J** *8MPV100 1.00 0.96 EHD4X48A** MV20L24**B* 0.98 0.94 FS(M,U)4P48**A* 1.00 1.00
ED*4X60J** *8MPV125 1.00 0.96 EHD4X48A** 0.98 0.98 FS(M,U)4X48**** 0.98 0.98
ED*4X60J** *9MPV100 1.00 0.96 EHD4X60A** *8MPV100 1.00 0.96 FS(M,U)4X60**A* 1.00 1.00
ED*4X60J** *9MVX080 1.00 0.96 EHD4X60A** *8MPV125 1.00 0.96 FVM4X48**** 0.98 0.94
ED*4X60J** MV16J22**B* 1.00 0.96 EHD4X60A** *9MPV100 1.00 0.96 FVM4X60**** 1.00 0.92
FXM4X48**A* 1.00 0.96
FXM4X60**A* 1.00 0.92
(C,H,T)4H360
*FS(M,U)4X60**** 1.00 1.00 ED*4X60L** 0.99 0.99 FEM4X60**** 1.01 0.97
ED*4X60J** *8MPV125 1.00 0.98 EHD4X60A** *8MPV125 1.00 0.98 FS(M,U)4X60**A* 1.00 1.00
ED*4X60J** MV16J22**B* 1.01 0.99 EHD4X60A** MV16J22**B* 1.01 0.95 FVM4X60**** 1.02 0.96
ED*4X60J** 0.99 0.99 EHD4X60A** MV20L24**B* 1.01 0.95 FXM4X60**A* 1.01 0.95
ED*4X60L** MV20L24**B* 1.01 0.99 EHD4X60A** 1.00 1.00
> Indicates Tested Indoor Model
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
18 428 04 5402 00
HEATING Multiplying Factors for other Indoor Combinations
Indoor
Model
Furnace
Model
Capac. (MBh) Power (AMPS)
Indoor
Model
Furnace
Model
Capac. (MBh) Power (AMPS)
Indoor
Model
Furnace
Model
Capac. (MBh) Power (AMPS)
(C,H,T)4H318
*FS(M,U)4X18**** 1.00 1.00 EHD4X24A** *9MVX040 1.00 0.90 FEM4X24**** 0.98 0.91
ED*4X18B** *8MPV050 0.99 0.94 EHD4X24A** *9MVX060 1.00 0.90 FS(M,U)4P18**A* 1.00 0.97
ED*4X18B** MV08B15**B* 0.96 0.94 EHD4X24A** MV08B15**B* 0.97 0.90 FS(M,U)4P24**A* 1.00 0.96
ED*4X24B** *8MPV050 1.00 0.90 EHD4X24A** 1.00 0.96 FSA4X18**A* 1.00 1.00
ED*4X24B** MV08B15**B* 0.97 0.91 EMA4X24D** 1.00 0.96 FSA4X24**A* 1.00 0.99
ED*4X24B** 1.00 0.98 FEA4X18**A* 0.99 0.93 FVM4X24**** 0.97 0.90
ED*4X24F** 1.00 0.98 FEA4X24**A* 0.99 0.91 FXM4X18**A* 0.99 0.90
EHD4X24A** *8MPV050 1.00 0.90 FEM4P18**A* 0.98 0.93 FXM4X24**A* 0.99 0.90
EHD4X24A** *9MPV050 1.00 0.90 FEM4P24**A* 0.98 0.93
EHD4X24A** *9MPV075 1.00 0.90 FEM4X18**** 0.98 0.93
(C,H,T)4H324
*FS(M,U)4X24**** 1.00 1.00 EHD4X24A** *8MPV075 0.99 0.90 EHD4X30A** *9MVX040 0.96 0.91
ED*4X24B** *8MPV050 1.00 0.95 EHD4X24A** *8MPV100 0.98 0.88 EHD4X30A** *9MVX060 0.96 0.90
ED*4X24B** MV08B15**B* 0.98 0.93 EHD4X24A** *8MPV125 0.98 0.88 EHD4X30A** *9MVX080 0.93 0.86
ED*4X24B** 1.00 0.98 EHD4X24A** *9MPV050 0.99 0.92 EHD4X30A** *9MVX100 0.95 0.88
ED*4X24F** *8MPV075 1.00 0.93 EHD4X24A** *9MPV075 0.99 0.93 EHD4X30A** MV08B15**B* 0.95 0.89
ED*4X24F** *9MPV050 1.00 0.95 EHD4X24A** *9MPV100 0.98 0.90 EHD4X30A** MV12F19**B* 0.95 0.89
ED*4X24F** *9MPV075 1.00 0.93 EHD4X24A** *9MPV125 0.99 0.91 EHD4X30A** 0.97 0.95
ED*4X24F** *9MVX040 0.99 0.95 EHD4X24A** *9MVX040 0.99 0.94 EMA4X24D** 1.00 0.96
ED*4X24F** *9MVX060 1.00 0.94 EHD4X24A** *9MVX060 0.99 0.93 FEA4X24**A* 0.98 0.96
ED*4X24F** MV12F19**B* 0.98 0.93 EHD4X24A** *9MVX080 0.99 0.90 FEA4X30**A* 0.98 0.94
ED*4X24F** 1.00 0.98 EHD4X24A** *9MVX100 0.99 0.91 FEM4P24**A* 0.99 0.97
ED*4X30B** *8MPV050 0.97 0.91 EHD4X24A** MV08B15**B* 0.98 0.91 FEM4P30**A* 0.99 0.92
ED*4X30B** MV08B15**B* 0.96 0.90 EHD4X24A** MV12F19**B* 0.98 0.91 FEM4X24**** 0.99 0.95
ED*4X30B** 0.98 0.96 EHD4X24A** 1.00 0.96 FEM4X30**** 0.98 0.91
ED*4X30F** *8MPV075 0.96 0.88 EHD4X30A** *8MPV050 0.95 0.90 FS(M,U)4P24**A* 0.99 0.95
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 19
HEATING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
ED*4X30F** *9MPV050 0.96 0.90 EHD4X30A** *8MPV075 0.95 0.88 FS(M,U)4P30**A* 0.98 0.94
ED*4X30F** *9MPV075 0.96 0.90 EHD4X30A** *8MPV100 0.94 0.86 FS(M,U)4X30**** 1.00 0.97
ED*4X30F** *9MVX040 0.97 0.91 EHD4X30A** *8MPV125 0.94 0.86 FVM4X24**** 0.97 0.90
ED*4X30F** *9MVX060 0.96 0.89 EHD4X30A** *9MPV050 0.96 0.91 FVM4X36**** 0.96 0.89
ED*4X30F** MV12F19**B* 0.96 0.90 EHD4X30A** *9MPV075 0.96 0.91 FXM4X24**A* 0.99 0.92
ED*4X30F** 0.98 0.96 EHD4X30A** *9MPV100 0.94 0.87 FXM4X30**A* 0.98 0.91
EHD4X24A** *8MPV050 0.99 0.92 EHD4X30A** *9MPV125 0.95 0.88
(C,H,T)4H330
*FS(M,U)4P30**A* 1.00 1.00 EHD4X30A** *8MPV100 0.98 0.98 EHD4X36A** *9MVX060 0.99 0.96
ED*4X30B** MV08B15**B* 0.97 0.97 EHD4X30A** *8MPV125 0.98 0.98 EHD4X36A** *9MVX080 0.99 0.94
ED*4X30F** *8MPV075 0.99 0.99 EHD4X30A** *9MPV050 0.98 1.01 EHD4X36A** *9MVX100 0.99 0.95
ED*4X30F** *9MPV050 0.99 1.01 EHD4X30A** *9MPV075 0.98 1.01 EHD4X36A** MV08B15**B* 0.98 0.95
ED*4X30F** *9MPV075 0.99 1.01 EHD4X30A** *9MPV100 0.98 0.99 EHD4X36A** MV12F19**B* 0.98 0.94
ED*4X30F** *9MVX040 0.99 1.01 EHD4X30A** *9MPV125 0.98 0.98 FEA4X30**A* 1.00 1.00
ED*4X30F** *9MVX060 0.99 1.00 EHD4X30A** *9MVX040 0.98 1.01 FEA4X36**A* 1.00 1.00
ED*4X30F** MV12F19**B* 0.98 0.97 EHD4X30A** *9MVX060 0.98 1.00 FEM4P30**A* 1.00 1.00
ED*4X36B** MV08B15**B* 0.98 0.98 EHD4X30A** *9MVX080 0.98 0.97 FEM4P30**A* 1.00 1.00
ED*4X36F** *8MPV075 0.98 0.97 EHD4X30A** *9MVX100 0.98 0.99 FEM4P36**A* 1.00 1.00
ED*4X36F** *9MPV050 0.98 1.00 EHD4X30A** MV08B15**B* 0.98 0.97 FEM4P36**A* 1.00 1.00
ED*4X36F** *9MPV075 0.98 0.99 EHD4X30A** MV12F19**B* 0.98 0.97 FEM4X30**** 0.99 0.98
ED*4X36F** *9MVX040 0.98 1.00 EHD4X36A** *8MPV050 1.00 0.98 FEM4X36**** 0.97 0.94
ED*4X36F** *9MVX060 0.98 0.98 EHD4X36A** *8MPV075 0.99 0.95 FS(M,U)4P30**A* 1.00 1.00
ED*4X36F** MV12F19**B* 0.98 0.97 EHD4X36A** *8MPV100 0.99 0.94 FVM4X24**** 0.98 0.97
ED*4X36J** *8MPV100 0.98 0.95 EHD4X36A** *8MPV125 0.99 0.94 FVM4X36**** 0.97 0.96
ED*4X36J** *8MPV125 0.98 0.95 EHD4X36A** *9MPV050 0.99 0.98 FVM4X48**** 0.98 0.93
ED*4X36J** *9MPV100 0.98 0.96 EHD4X36A** *9MPV075 0.99 0.97 FXM4X30**A* 0.97 0.95
ED*4X36J** *9MVX080 0.98 0.95 EHD4X36A** *9MPV100 0.99 0.95 FXM4X36**A* 1.00 0.95
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
20 428 04 5402 00
HEATING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
EHD4X30A** *8MPV050 0.98 1.00 EHD4X36A** *9MPV125 0.99 0.95
EHD4X30A** *8MPV075 0.98 0.99 EHD4X36A** *9MVX040 0.99 0.98
(C,H,T)4H336
*FS(M,U)4P36**A* 1.00 1.00 ED*4X42J** 0.99 1.00 EHD4X42A** *9MPV125 0.97 0.90
ED*4X36B** *8MPV050 0.97 1.01 ED*4X42L** *9MPV125 0.97 0.93 EHD4X42A** *9MVX040 0.97 0.95
ED*4X36B** MV08B15**B* 0.97 0.96 ED*4X42L** *9MVX100 0.97 0.94 EHD4X42A** *9MVX060 0.97 0.93
ED*4X36B** 0.99 1.02 ED*4X42L** MV20L24**B* 0.97 0.93 EHD4X42A** *9MVX080 0.97 0.90
ED*4X36F** *8MPV075 0.97 0.97 ED*4X42L** 0.97 0.98 EHD4X42A** *9MVX100 0.97 0.91
ED*4X36F** *9MPV050 0.97 1.00 EHD4X36A** *8MPV050 0.99 1.00 EHD4X42A** MV08B15**B* 0.97 0.91
ED*4X36F** *9MPV075 0.97 0.99 EHD4X36A** *8MPV075 0.97 0.94 EHD4X42A** MV12F19**B* 0.97 0.91
ED*4X36F** *9MVX040 0.97 1.00 EHD4X36A** *8MPV100 0.97 0.91 EHD4X42A** MV16J22**B* 0.97 0.90
ED*4X36F** *9MVX060 0.97 0.98 EHD4X36A** *8MPV125 0.97 0.91 EHD4X42A** MV20L24**B* 0.97 0.91
ED*4X36F** MV12F19**B* 0.97 0.95 EHD4X36A** *9MPV050 0.97 0.97 EHD4X42A** 0.97 0.94
ED*4X36F** 0.99 1.01 EHD4X36A** *9MPV075 0.97 0.96 EMA4X36D** 0.99 1.01
ED*4X36J** *8MPV100 0.97 0.94 EHD4X36A** *9MPV100 0.97 0.93 FEA4X36**A* 1.00 1.02
ED*4X36J** *8MPV125 0.97 0.94 EHD4X36A** *9MPV125 0.97 0.92 FEM4P36**A* 1.00 1.00
ED*4X36J** *9MPV100 0.97 0.95 EHD4X36A** *9MVX040 0.97 0.97 FEM4P36**A* 1.00 1.00
ED*4X36J** *9MVX080 0.97 0.95 EHD4X36A** *9MVX060 0.97 0.95 FEM4P42**A* 1.00 0.94
ED*4X36J** MV16J22**B* 0.97 0.94 EHD4X36A** *9MVX080 0.97 0.92 FEM4P42**A* 1.00 0.94
ED*4X36J** 1.00 1.02 EHD4X36A** *9MVX100 0.97 0.93 FEM4X36**** 0.99 0.94
ED*4X42F** *8MPV075 0.97 0.95 EHD4X36A** MV08B15**B* 0.97 0.93 FEM4X42**** 1.00 0.95
ED*4X42F** *9MPV050 0.97 0.98 EHD4X36A** MV12F19**B* 0.97 0.92 FS(M,U)4P36**A* 1.00 1.00
ED*4X42F** *9MPV075 0.97 0.97 EHD4X36A** MV16J22**B* 0.97 0.92 FS(M,U)4P42**A* 1.00 0.97
ED*4X42F** *9MVX040 0.97 0.99 EHD4X36A** MV20L24**B* 0.97 0.92 FS(M,U)4P42**A* 0.99 0.96
ED*4X42F** *9MVX060 0.97 0.97 EHD4X36A** 0.99 0.98 FS(M,U)4X42**** 1.00 1.00
ED*4X42F** MV12F19**B* 0.97 0.94 EHD4X42A** *8MPV050 0.97 0.96 FSM4X36**** 1.00 0.99
ED*4X42F** 0.99 1.00 EHD4X42A** *8MPV075 0.97 0.92 FVM4X24**** 0.97 0.96
> Indicates Tested Indoor Model
- continued on next page -
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 21
HEATING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
ED*4X42J** *8MPV100 0.97 0.93 EHD4X42A** *8MPV100 0.97 0.90 FVM4X36**** 0.97 0.95
ED*4X42J** *8MPV125 0.97 0.92 EHD4X42A** *8MPV125 0.97 0.89 FVM4X48**** 0.97 0.90
ED*4X42J** *9MPV100 0.97 0.94 EHD4X42A** *9MPV050 0.97 0.95 FXM4X36**A* 1.00 0.93
ED*4X42J** *9MVX080 0.97 0.94 EHD4X42A** *9MPV075 0.97 0.94 FXM4X42**A* 1.00 0.93
ED*4X42J** MV16J22**B* 0.97 0.93 EHD4X42A** *9MPV100 0.97 0.91
(C,H,T)4H342
*FS(M,U)4P42**A* 1.00 1.00 ED*4X48J** 0.99 0.99 EHD4X48A** *9MVX060 0.99 0.99
ED*4X42F** *8MPV075 0.96 0.99 ED*4X48L** *9MPV125 0.99 0.97 EHD4X48A** *9MVX080 0.99 0.96
ED*4X42F** MV12F19**B* 0.96 0.97 ED*4X48L** *9MVX100 0.99 0.97 EHD4X48A** *9MVX100 0.99 0.97
ED*4X42F** 1.00 1.03 ED*4X48L** MV20L24**B* 0.96 0.93 EHD4X48A** MV12F19**B* 0.96 0.93
ED*4X42J** *8MPV100 0.96 0.96 ED*4X48L** 0.99 0.99 EHD4X48A** MV16J22**B* 0.96 0.92
ED*4X42J** *8MPV125 0.96 0.96 EHD4X42A** *8MPV075 0.99 0.98 EHD4X48A** MV20L24**B* 0.96 0.92
ED*4X42J** *9MPV100 0.96 0.98 EHD4X42A** *8MPV100 0.99 0.96 EHD4X48A** 0.99 0.98
ED*4X42J** *9MVX080 0.99 1.00 EHD4X42A** *8MPV125 0.99 0.96 EMA4X48D** 0.99 1.00
ED*4X42J** MV16J22**B* 0.96 0.96 EHD4X42A** *9MPV075 0.99 1.01 FEM4P42**A* 0.99 0.98
ED*4X42J** 0.99 1.02 EHD4X42A** *9MPV100 0.99 0.97 FEM4P42**A* 0.99 0.98
ED*4X42L** *9MPV125 0.96 0.97 EHD4X42A** *9MPV125 0.99 0.97 FEM4P48**A* 0.99 0.97
ED*4X42L** *9MVX100 0.96 0.97 EHD4X42A** *9MVX060 0.99 1.00 FEM4P48**A* 0.98 0.96
ED*4X42L** MV20L24**B* 0.96 0.96 EHD4X42A** *9MVX080 0.99 0.97 FEM4X42**** 0.98 0.97
ED*4X42L** 0.99 1.02 EHD4X42A** *9MVX100 0.99 0.97 FEM4X48**** 0.99 0.95
ED*4X48F** *8MPV075 0.99 0.98 EHD4X42A** MV12F19**B* 0.96 0.93 FS(M,U)4P42**A* 1.00 1.00
ED*4X48F** *9MPV075 0.99 1.00 EHD4X42A** MV16J22**B* 0.96 0.93 FS(M,U)4P48**A* 0.99 0.97
ED*4X48F** *9MVX060 0.99 0.99 EHD4X42A** MV20L24**B* 0.96 0.93 FS(M,U)4P48**A* 0.99 0.97
ED*4X48F** MV12F19**B* 0.96 0.92 EHD4X42A** 0.99 0.99 FS(M,U)4X42**** 0.99 1.02
ED*4X48F** 0.99 0.98 EHD4X48A** *8MPV075 0.99 0.98 FS(M,U)4X48**** 0.99 0.99
ED*4X48J** *8MPV100 0.99 0.96 EHD4X48A** *8MPV100 0.99 0.95 FVM4X36**** 0.96 0.98
ED*4X48J** *8MPV125 0.99 0.96 EHD4X48A** *8MPV125 0.99 0.95 FVM4X48**** 0.96 0.93
> Indicates Tested Indoor Model
- continued on next page -
International Comfort Products, LLC
Lewisburg, Tennessee 37091 USA
TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
22 428 04 5402 00
HEATING Multiplying Factors for other Indoor Combinations (continued)
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
Indoor
Model
Power (AMPS)Capac. (MBh)
Furnace
Model
ED*4X48J** *9MPV100 0.99 0.98 EHD4X48A** *9MPV075 0.99 1.00 FXM4X42**A* 0.99 0.97
ED*4X48J** *9MVX080 0.99 0.97 EHD4X48A** *9MPV100 0.99 0.97
ED*4X48J** MV16J22**B* 0.96 0.93 EHD4X48A** *9MPV125 0.99 0.96
(C,H,T)4H348
*FS(M,U)4P48**A* 1.00 1.00 ED*4X60L** *9MPV125 0.97 0.97 EHD4X60A** *9MVX100 0.97 0.96
ED*4X48F** 1.00 1.03 ED*4X60L** *9MVX100 0.97 0.97 EHD4X60A** MV16J22**B* 0.97 0.94
ED*4X48J** *8MPV100 0.97 0.98 ED*4X60L** MV20L24**B* 0.97 0.95 EHD4X60A** MV20L24**B* 0.97 0.94
ED*4X48J** *8MPV125 0.97 0.98 ED*4X60L** 1.00 1.01 EHD4X60A** 1.00 1.00
ED*4X48J** *9MPV100 0.97 0.99 EHD4X48A** *8MPV100 0.97 0.97 FEM4P48**A* 0.97 0.99
ED*4X48J** *9MVX080 0.97 0.99 EHD4X48A** *8MPV125 0.97 0.97 FEM4P48**A* 0.97 0.99
ED*4X48J** MV16J22**B* 0.97 0.96 EHD4X48A** *9MPV100 0.97 0.98 FEM4P60**A* 0.99 0.98
ED*4X48J** 1.00 1.02 EHD4X48A** *9MPV125 0.97 0.98 FEM4P60**A* 0.99 0.98
ED*4X48L** *9MPV125 0.97 0.98 EHD4X48A** *9MVX080 0.97 0.98 FEM4X48**** 1.00 0.99
ED*4X48L** *9MVX100 0.97 0.99 EHD4X48A** *9MVX100 0.97 0.98 FEM4X60**** 0.99 0.95
ED*4X48L** MV20L24**B* 0.97 0.96 EHD4X48A** MV16J22**B* 0.97 0.95 FS(M,U)4P48**A* 0.97 0.97
ED*4X48L** 1.00 1.02 EHD4X48A** MV20L24**B* 0.97 0.95 FS(M,U)4X48**** 0.97 1.00
ED*4X60J** *8MPV100 0.97 0.96 EHD4X48A** 1.00 1.01 FS(M,U)4X60**A* 1.00 1.01
ED*4X60J** *8MPV125 0.97 0.96 EHD4X60A** *8MPV100 0.97 0.95 FVM4X48**** 0.97 0.96
ED*4X60J** *9MPV100 0.97 0.98 EHD4X60A** *8MPV125 0.97 0.94 FVM4X60**** 0.97 0.93
ED*4X60J** *9MVX080 0.97 0.98 EHD4X60A** *9MPV100 0.97 0.96 FXM4X48**A* 0.97 0.95
ED*4X60J** MV16J22**B* 0.97 0.95 EHD4X60A** *9MPV125 0.97 0.96 FXM4X60**A* 0.99 0.94
ED*4X60J** 1.00 1.01 EHD4X60A** *9MVX080 0.97 0.96
(C,H,T)4H360
*FS(M,U)4X60**** 1.00 1.00 ED*4X60L** 0.99 0.99 FEM4X60**** 0.98 0.95
ED*4X60J** *8MPV125 0.99 0.98 EHD4X60A** *8MPV125 1.01 0.99 FS(M,U)4X60**A* 1.00 1.00
ED*4X60J** MV16J22**B* 0.98 0.96 EHD4X60A** MV16J22**B* 0.99 0.96 FVM4X60**** 0.98 0.94
ED*4X60J** 0.99 0.99 EHD4X60A** MV20L24**B* 0.99 0.95 FXM4X60**A* 0.98 0.94
ED*4X60L** MV20L24**B* 0.98 0.96 EHD4X60A** 1.00 1.00
> Indicates Tested Indoor Model
Loading...
