ICP Sata/Pata Adapter Installation And User Manual

Hardware Installation and User Guide 1

ICP SATA/PATA Adapter

SATA/PATA Adapter for ICP RAID Controllers
with SATA Ports

Hardware Installation and User Guide

Version 1.0

June 2003

Copyright 2003 ICP vortex Computersysteme GmbH. ICP "Intelligent Computer
Peripherals" is a registered trademark.*Other names and brands may be claimend as
the property of others.

2 Hardware Installation and User Guide

IMPORTANT NOTICE - READ BEFORE MAKING USE OF THE INFORMATION CONTAINED HEREIN

This information is provided “as is.” Information in this document is provided solely to enable use of ICP products. Except as provided in ICP vortex’s
Terms and Conditions of sale ICP vortex and/or its suppliers assume no liability whatsoever, and ICP vortex and/or its suppliers disclaim any express
or implied warranty, relating to this information including liability or warranties relating to fitness for a particular purpose, merchantability, satisfactory
quality or infringement of any patent, copyright or other intellectual property right. ICP vortex and/or its suppliers assume no responsibility for any
omissions or any errors which may appear in this document nor does it make a commitment to update the information contained herein.

ICP vortex retains the right to make changes to this document and its products at any time, without notice.

No License, express or implied, by Estoppel or otherwise, to any intellectual property rights is granted by this document. ICP products are not intended
for use in medical, life saving, or life sustaining applications.

Any recommended operating or test methods are correct to ICP’s reasonable knowledge at the time of writing. ICP vortex and/or its suppliers accept
no liability for the implementation of these methods within the user’s environment. The user is responsible for and must satisfy itself that any use
made of this information or ICP products is suitable to its needs.

Any named third party suppliers are provided for information only. The hardware vendor remains solely responsible for the design, sale and
functionality of its product, including any liability arising from product infringement or product warranty. ICP vortex accepts no liability for the quality of
third party suppliers, and cannot guarantee that third party products are suitable or are compatible with Intel products or that third party suppliers will
not change parts so that they are no longer compatible or no longer suitable.

IN NO EVENT WILL ICP VORTEX AND/OR ITS SUPPLIERS BE LIABLE TO THE RECIPIENT OR USER OF THIS INFORMATION FOR ANY LOSS
OF PROFITS, LOSS OF USE, BUSINESS INTERRUPTIONS, INFRINGEMENT OF ANY THIRD PARTY INTELLECTUAL PROPERTY RIGHTS,
LOSS OR CORRUPTION OF DATA, INCIDENTAL, INDIRECT, SPECULATIVE, CONSEQUENTIAL, OR SPECIAL DAMAGES, HOWSOEVER
ARISING AND IRRESPECTIVE OF WHETHER INTEL HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

THE LIMITATIONS AND DISCLAIMERS SET FORTH HEREIN WERE AN ESSENTIAL ELEMENT IN ICP VORTEX AGREEING TO SUPPLY THIS
INFORMATION FREE OF CHARGE. THEY SHALL APPLY NOTWITHSTANDING SECTION 1.1 OF THE TERMS AND CONDITIONS OF SALE OF
ICP VORTEX

Hardware Installation and User Guide 3

The ICP SATA/PATA Adapter

The ICP SATA/PATA Adapter

1

1.1 Product Description

The ICP SATA/PATA Adapter is a plug-in adapter for PATA hard disk drives (parallel
ATA, sometimes called UDMA or IDE hard disk drives). It contains a so-called I/O
translator which translates the PATA signals of a hard disk drive into SATA (Serial ATA).

Note:

The ICP SATA/PATA Adapter is designed for the connection to an ICP SATA RAID
Controller alone. It supports only PATA hard disk drives and no other PATA devices like
CD-ROM drives or CD-RW drives.

1.2 Scope of Delivery

Together with the ICP SATA/PATA Adapter you receive a so called Y-power cable which
allows to supply both the ICP SATA/PATA Adapter and an appropriate PATA hard disk
with power from your computers power supply using a standard 4-pin power connection.
