Icom IC-F3062S, IC-F3062T, IC-F3063T, IC-F3063S, IC-F3061S User Manual

...

0 (0)

SERVICE MANUAL

VHF TRANSCEIVER

S-14223HZ-C1 Mar. 2006

INTRODUCTION

This service manual describes the latest service information for the TRANSCEIVER

To upgrade quality, all electrical or mechanical parts and internal circuits are subject to change without notice or obligation.

IC-F3061T/S, IC-F3062T/S and IC-F3063T/S VHF

at the time of publication.

MODEL VERSION SYMBOL CHANNEL SPACING KEY PAD

IC-F3061T IC-F3061S 4-key IC-F3062T IC-F3062S 4-key IC-F3063T IC-F3063S 4-key

U.S.A [USA-01] 15.0 kHz/30.0 kHz

EURO [EUR-01] 12.5 kHz/25.0 kHz

GENERAL [GEN-01]

12.5 kHz/20.0 kHz /25.0 kHz

10-key

DANGER

NEVER connect the transceiver to an AC outlet or to a DC

power supply that uses more than 7.2 V. Such a connection could cause a fire or electric hazard.

DO NOT expose the transceiver to rain, snow or any liquids.

DO NOT reverse the polarities of the power supply when

connecting the transceiver.

DO NOT apply an RF signal of more than 20 dBm (100 mW) to the antenna connector. This could damage the transceiver's front end.

ORDERING PARTS

Be sure to include the following four points when ordering replacement parts:

1. 10-digit Icom parts number

2. Component name and informations

3. Equipment model name and unit name

4. Quantity required

5030002830 LCD M4-0078TAY-2 IC-F3061T Front unit 5 pieces 8810009220 Screw

PH B0 M2×8 ZK (BT)

IC-F3061T Chassis 10 pieces

Addresses are provided on the inside back cover for your convenience.

REPAIR NOTES

1. Make sure the problem is internal before disassembling the transceiver.

2. DO NOT open the transceiver until the transceiver is disconnected from its power source.

3. DO NOT force any of the variable components. Turn them slowly and smoothly.

4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.

5. DO NOT keep power ON for a long time when the transceiver is defective.

6. DO NOT transmit power into a signal generator or a sweep generator.

7. ALWAYS connect a 30 dB to 40 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when using such test equipment.

8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.

Icom, Icom Inc. and logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.

SECTION 1 SPECIFICATIONS

SECTION 2 INSIDE VIEWS

SECTION 3 DISASSEMBLY INSTRUCTIONS

SECTION 4 OPTIONAL UNIT INSTALLATION

SECTION 5 CIRCUIT DESCRIPITON

5-1 RECEIVER CIRCUITS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

5-2 TRANSMITTER CIRCUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

5-3 PLL CIRCUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

5-4 POWER SUPPLY CIRCUITS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

5-5 PORT ALLOCATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

SECTION 6 ADJUSTMENT PROCEDURES

6-1 PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

6-2 FREQUENCY ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

6-3 TRANSMIT ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

6-4 RECEIVE ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6

SECTION 7 PARTS LIST

SECTION 8 MECHANICAL PARTS AND DISASSEMBLY

SECTION 9 SEMICONDUCTOR INFORMATION

SECTION 10 BOARD LAYOUTS

10-1 FRONT UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

10-2 MAIN UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

10-3 RF UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

10-4 JACK UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

10-5 VR UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

10-6 BC-160. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

SECTION 11 BLOCK DIAGRAM

SECTION 12 VOLTAGE DIAGRAM

SECTION 13 BC-160

SECTION 1 SPECIFICATIONS

[USA-01], [GEN-01] [EUR-01]

• Frequency coverage 136–174 MHz

• Type of emission Wide 16K0F3E (25.0 kHz/30.0 kHz) 16K0F3E (25.0 kHz)

Middle – 14K0F3E (20.0 kHz)

11K0F3E, 11K0F7E/D* (15.0 kHz)

Narrow

• Number of programable channels 512 channels (128 zones)

• Antenna impedance 50 Ω (nominal)

• Operating temperature range −22˚F to +140˚F –25˚C to +55˚C

• Power supply requirement Specified Icom's battery packs only (Operatable voltage; 7.2 V DC negative ground)

GENERAL

• Current drain (approx.)

• Dimensions (projections not included)

• Weight (with BP-232, approx.) 12 oz 340 g

• Transmit output power 5 W (High), 2 W (Low2), 1 W (Low1)

• Modulation Variable reactance frequency modulation

• Max. frequency deviation Wide ±5.0 kHz

• Frequency error ±1.0 ppm ±1.5 kHz

• Spurious emission 75 dB typ. 0.25 µW (≤1 GHz), 1.00 µW (>1 GHz)

• Adjacent channel power Wide More than 70 dB (80 dB typ.)

TRANSMITTER

• Audio harmonic distortion 3% typ. (with 1 kHz AF 40% deviation)

• FM hum and noise (without CCITT filter)

• Limiting charact of modulation 60–100% of max. deviation

• Microphone impedance 2.2 k

• Receive system Double conversion superheterodyne

• Intermediate frequencies 1st IF; 46.35 MHz, 2nd IF; 450 kHz

• Sensitivity 0.25 µV typ. at 12 dB SINAD − 4 dBµV (EMF) typ. at 20 dB SINAD

• Squelch sensitivity (at threshold) 0.25 µV typ.

• Adjacent channel selectivity

• Spurious response More than 70 dB

• Intermodulation More than 70 dB (74 dB typ.) More than 65 dB (67 dB typ.)

• Hum and Noise

RECEIVER

(without CCITT filter)

• Residual modulation (with CCITT filter)

• Audio output power 0.5 W typ. at 5% distortion with an 8 Ω load

• Audio output impedance 8

Measurements made in accordance with EIA-152-C/204D, TIA-603 ([USA-01], [GEN-01]) or

All stated specifications are subject to change without notice or obligation.

*; Optional UT-119S/H is required for the digital mode operation.

Stand-by 95 mA

Max.audio 600 mA

at 5 W 1.5 A

at 1 W 0.7 A

Middle – ±4.0 kHz

Narrow ±2.5 kHz

Middle – More than 70 dB (80 dB typ.)

Narrow More than 60 dB (70 dB typ.)

Wide More than 40 dB (46 dB typ.) –

Narrow More than 34 dB (40 dB typ.) –

Wide More than 70 dB (75 dB typ.)

Middle − More than 70 dB (75 dB typ.)

Narrow More than 65 dB (68 dB typ.)

Wide More than 40 dB (46 dB typ.) −

Narrow More than 34 dB (40 dB typ.) −

Wide − More than 45 dB (55 dB typ.)

Middle − More than 43 dB (53 dB typ.)

Narrow − More than 40 dB (50 dB typ.)

8K50F3E, 8K10F1E/D* (12.5 kHz)

4K00F1E/D* (6.25 kHz)

2 3/32 (W) × 5 11/32 (H) × 1 17/32 (D) in 53.0 (W) × 136.0 (H) × 38.5 (D) mm

Ω

EN 300 086 ([EUR-01]).

8K50F3E (12.5 kHz)

4K00F1E/D* (6.25 kHz)

1 - 1

SECTION 2 INSIDE VIEWS

• FRONT UNIT

Mic selector Q506: UNR9113J Q516: UNR9213J

AF power amplifier controller Q501: 2SB1132 Q502: XP6501

AF power amplifier (IC508: TDA8547TS)

Speaker selector (Q512, Q513: UNR9213J)

Expander IC (IC506: M62320FP)

Expander IC (IC505: M62320FP)

• RF UNIT (TOP VIEW)

APC amplifier (IC601: TA75S01F)

TX power detector (D604: RB706F-40)

• RF UNIT (BOTTOM VIEW)

TX power detector (D605: RB706F-40)

TX/RX antenna switch circuit

TX power amplifier (Q601: RD07MVS1)

• MAIN UNIT (TOP VIEW)

RF amplifier (Q10: 3SK293)

D/A converter (IC20: M62334FP)

Mixer (Q37: 3SK324)

ALC amplifier (IC15: AN6123MS)

• MAIN UNIT (BOTTOM VIEW)

CPU 5V regulator (IC6: NJM2870)

1st IF amplifier (Q25: 2SC4215)

FM IF IC (IC3: TA31136FNG)

PLL IC (IC1: LMX2352TM)

D/A converter (IC4: M62364FP)

CPU (IC18: HD64F2268TF20V)

2 - 1

DTMF decoder (IC10: BU8872FS)

SECTION 3 DISASSEMBLY INSTRUCTIONS

• REMOVING THE CHASSIS UNIT

Unscrew 1 nut A, and remove 2 knobs B and C.

1 2 Unscrew 2 screws D. 3 Take off the chassis unit in the direction of the arrow. 4 Disconnect the flat cable E form J501. 5 Remove the seal F. 6 Unscrew 2 nuts G and remove the plate H.

Chassis unit

J501

• REMOVING THE RF UNIT

Unsolder 3 points A.

1 2 Unscrew 4 screws B and remove the RF unit from the

chassis.

RF unit

• REMOVING THE MAIN UNIT

1 Unsolder 1 point A. 2 Unscrew 1 screw B and remove the VR unit. 3 Unsolder 5 points C and remove the shield plate D. 4 Unsolder 10 points E. 5 Unscrew 7 screws F and remove the MAIN unit from the

chassis.

VR unit

C 5

MAIN unit

• REMOVING THE FRONT UNIT

1 Disconnect the flat cable A from J503. 2 Unsolder 2 points B. 3 Unscrew 6 screws C and remove the plate D and FRONT

unit.

J503

FRONT unit

3 - 1

SECTION 4 OPTIONAL UNIT INSTALLATION

CAUTION! Optional unit installation should be done at authorized Icom servise center only. The waterproof capability of the transceiver cannot be guaranteed if you install an unit yourself, or have it done at a non-authorised dealer/service center.

Install the optional unit as follows.

Rotate [VOL] to turn the power OFF, and remove the battery pack.

Remove the anntena and antenna nut A.

Remove the rotary selector B and volume control C.

Unscrew two screws D, then take off the chassis from the front panel in the direction of the arrow.

BE CAREFUL! Flat cable is connected between the MAIN unit on the chassis and front panel.

Install the optional unit as below.

• UT-96R, UT-109R and UT-110R installation*

DO NOT attach the unit

to the connector “J2.“ Otherwise no TX modulation or AF output is available.

• UT-119S/H installation

DO NOT attach the unit

to the connector “J1.“ Otherwise no TX modulation or AF output is available.

*; The following PC bord modiﬁ cation is required when installing optional UT-109R and UT-110R.

Cut the pattern on the PC board at “MIC“ and “AFOUT“ as shown below.

AFOUT

MIC

4 - 1

NOTE: When uninstalling the unit

Be sure to re-solder the disconnected points as below when you remove the unit. Otherwise, no TX modulation or AF output is available.

Re-solder

SECTION 5 CIRCUIT DESCRIPTION

5-1 RECEIVER CIRCUITS

5-1-1 ANTENNA SWITCH (MAIN and RF UNITS)

The received signals from the antenna connector are passed through the antenna switch which toggles the receive (RX) line and transmit (TX) line.

The received signals from the antenna connector are passed through the low-pass ﬁ lter (LPF; L601−L603, C601, C602, C604

−C606, C608, C609, C663), and the antenna switch (D601 and D603 are OFF).

While transmitting, the voltage on the T5V line is applied to D601 and D603, and these are ON. Thus the TX line is connected to the antenna. Simultaneously, the RX line is connected to the GND to prevent transmit signal entering.

While receiving, no voltage is applied to the D601 and D603, and these are OFF. Thus the TX line and the antenna is disconnected to prevent received signals entering. Simultaneously, the RX line is disconnected from the GND and the received signals are passed through the LPF (RF UNIT; L604, C611, C612, MAIN UNIT; L29, C117).

The ﬁ ltered signals from the LPF (RF UNIT; L604, C611, C612, MAIN UNIT; L29, C117) are then applied to the RF circuit via the two staged tunable bandpass filter (BPF; D23, D24, L31, L32, C120−C122, C125−C127).

5-1-2 RF CIRCUIT (MAIN UNIT)

The received signals are filtered and amplified at the RF circuit.

The ﬁ ltered signals are applied to the RF ampliﬁ er (Q10). The amplified signals are applied to the 1st mixer (Q37) via another two-staged BPF (D28, D29, L33, L34, C140−C144, C147).

The converted 1st IF signal is passed through the 1st IF ﬁ lter (in wide mode; FI1, in narrow mode; FI4) via the bandwidth switch (D34), to remove adjacent signals. The filtered signal is applied to the 1st IF ampliﬁ er (Q25) via another bandwidth switch (D35). The ampliﬁ ed 1st IF signal is then applied to the FM IF IC (IC3, pin 16).

5-1-4 2nd IF AND DEMODULATOR CIRCUITS (MAIN UNIT)

The 1st IF signal is converted into the 2nd IF signal, and demodulated.

The 1st IF signal from the 1st IF ampliﬁ er (Q25) is applied to the 2nd IF mixer in the FM IF IC (IC3, pin 6). And the 1st IF signal is converted into the 450 kHz 2nd IF signal by being mixed with the 2nd LO signal from the reference frequency oscillator (X1) via the tripler (Q18).

The converted 2nd IF signal is output from pin 3, and passed through the 2nd IF ﬁ lter (FI2) to suppress sideband noise. In narrow mode, the 2nd IF signal is also passed through another 2nd IF ﬁ lter (FI3) via bandwidth switches (D32, D33).

The ﬁ ltered 2nd IF signal is applied to the limiter ampliﬁ er in the FM IF IC (IC3, pin 5). The ampliﬁ ed 2nd IF signal is FMdemodulated at the quadrature detector (X5, IC3, pins 10, 11) and output from pin 9. The demodulated AF signals are then applied to the AF circuits.

5-1-5 AF CIRCUITS (FRONT and MAIN UNITS)

The demodulated AF signals from the FM IF IC are ampliﬁ ed and filtered at AF circuits. This transceiver employs the base band IC for audio signal processing for both transmit and receive. The base band IC is an audio processor and composed of pre-ampliﬁ er, compressor, expander, scrambler, etc. in its package.

5-1-3 1st IF CIRCUITS

The received signals are converted into the 1st IF signal, and amplified at the 1st IF circuits.

The filtered signals from the RF circuit are converted into the

46.35 MHz 1st IF signal by being mixed with the 1st Local Oscillator (LO) signals from the VCO (155 MHz and below; Q1, D1

−D4, 155 MHz and higher; Q2, D5−D8) at the 1st mixer (Q37).

• 2nd IF AND DEMODULATOR CIRCUITS

D/A converter

(IC4)

Demodulated signals to the AF circuits

Quadrature

detector

Filter amp.

1110

735

Limiter amp.

D33

N/W SW

RSSI

+5V

The demodulated AF signals from the FM IF IC (IC3, pin 9) are applied to the base band IC (IC5, 23) via the Digital/Analog switch (IC14, pins 2, 15).

The applied AF signals are ampliﬁ ed at the ampliﬁ er (RXA1) and level adjusted at the volume controller (VR3), then suppressed unwanted 3 kHz and higher audio signals at LPF. The filtered AF signals are applied or bypassed the TX/RX HPF, scrambler, de-emphasis sections in sequence.

D32

N/W SW

FI3

FI2

Noise

detector

Mixer

45.9 MHz

BPF

Q18

15.3 MHz

FM IF IC (IC3)

1st IF signal from the IF amplifier (Q25)

“NOIS” signal to the CPU (IC18: pin 37)

“RSSI” signal to the CPU (IC18: pin 50)

5 - 1

The TX/RX HPF filters out 250 Hz and lower audio signals, and the de-emphasis circuit obtains –6 dB/oct of audio characteristics. The expander expands the compressed audio signals and also noise reduction function is provided.

The AF signals are then level adjusted at the volume controller (VR4) and ampliﬁ ed at the ampliﬁ er (RXA2). The ampliﬁ ed AF signals are output from pin 20 and passed through another deemphasis circuit (IC13, pins 2, 15), and then applied to the D/ A converter (IC4, pin 16) for level adjustment via the AF mute switch (IC14, pins 3, 4).

The level-adjusted AF signals are applied to the AF ampliﬁ er (FRONT UNIT; IC509, pin 2). The amplified AF signals are output from pin 1, and applied to the AF power amplifier (IC508, pin 17) to obtain 0.5 W of AF output power. The powerampliﬁ ed AF signals are output from pin 18, and then applied to the internal speaker.

If an external speaker-microphone or headset is attached to the multi-connector (JACK UNIT; MP801), the AF signals from the AF amplifier (IC509, pin 1) are applied to the AF power ampliﬁ er (IC508, pin 14). The power-ampliﬁ ed AF signals are then output from pin 13, and applied to the multi-connector (JACK UNIT; MP801).

• CTCSS/DTCS

A portion of the demodulated AF signals are passed through the active LPF (Q28) to filters CTCSS/DTCS signal. The filtered signal is applied to the CPU (IC18, pin 46). The CPU compares the applied signal and the set CTCSS/DTCS, then output the serial data to the expand IC (FRON UNIT; IC505, pin 3), and the expand IC outputs “AFON” signal from pin 4 to the AF power ampliﬁ er controller (Q501, Q502, D508).

• 2/5 TONE

2/5 tone signals in the demodulated AF signals are passed through the LPF in the base band IC (IC5) and output from pin 21, then applied to the CPU (IC18, pin 45) and decoded.

• DTMF

DTMF signals in the demodulated AF signals are passed through the LPF in the base band IC (IC5) and output from pin 21, then applied to the DTMF decoder (IC10, pin 1) and decoded.

5-2 TRANSMITTER CIRCUITS

5-2-1 MICROPHONE AMPLIFIER CIRCUITS (MAIN UNIT)

The AF signals from the microphone (MIC signals) are ﬁ ltered and level-adjusted at microphone ampliﬁ er circuits.

5-1-5 SQUELCH CIRCUIT

• NOISE SQUELCH

The squelch mutes the AF output signals when no RF signals are received. By detecting noise components (30 kHz and higher signals) in the demodulated AF signals, the squelch circuit toggles the AF power ampliﬁ er ON and OFF.

A portion of the demodulated AF signals from the FM IF IC (IC3, pin 9) are applied to the D/A converter (IC4, pin 1) for level adjustment (squelch threshold adjustment). The leveladjusted AF signals are output from pin 2 and passed through the noise filter (IC3, pins 7, 8, R121−R124, C216−C218). The ﬁ ltered noise signals are ampliﬁ ed the noise components only.

The amplified noise components are converted into the pulsetype signal at the noise detector section, and output from pin 13 as the “NOIS” signal. The signal is applied to the CPU (IC18, pin

37). Then the CPU outputs serial data to the expand IC (FRON UNIT; IC505, pin 3), and the expand IC outputs “AFON” signal from pin 4 according to the “NOIS” signal level, to the AF power ampliﬁ er controller (FRONT UNIT; Q501, Q502, D508). The AF power amplifier controller toggles AF power amplifier (FRONT UNIT; IC508) ON and OFF according to the "AFON" signal.

• TONE SQUELCH

The tone squelch circuit detects tone signals and opens the squelch only when receiving a signal containing a matched sub audible tone. When the tone squelch is in use, and a signal with a mismatched or no sub audible tone is received, the tone squelch circuit mutes the AF signals even when the noise squelch is open.

MIC signals from the microphone are passed through the microphone switch (FRON UNIT; Q515). The microphone switch selects the AF signals from the internal microphone (FRON UNIT; MC1) or from an external microphone.

MIC signals from the microphone switch (FRON UNIT; Q515) are applied to the microphone ampliﬁ er (FRON UNIT; IC509, pin 6), and amplified AF signals are output from pin 7, and passed through the pre-emphasis circuit (IC13, pins 4, 5) to obtain +6 dB/oct of frequency characteristic. The preemphasized MIC signals are then applied to the microphone ampliﬁ er (IC9, pin 9). And the ampliﬁ ed MIC signals are output from pin 8, and applied to the D/A converter (IC4, pin 9) for level adjustment (=microphone sensitivity adjustment). The level-adjusted MIC signals are output from pin 10, and applied to the ALC (Automatic Level Control) circuit (IC15, pin 3) which limits the amplitude of the MIC signals to prevent over deviation. The amplitude-limited MIC signals are output from pin 5, then applied to the base band IC (IC5, pin 3).

The applied MIC signals are ampliﬁ ed at the ampliﬁ er (TXA1), and level adjusted at the volume controller (VR1). The level adjusted MIC signals are applied or bypassed the compressor section, pre-emphasis section, TX/RX HPF, de-scrambler, limiter, splatter, in sequence, then applied to another volume controller.

The compressor compresses the MIC signals to provide high S/N ratio for receive side, and the pre-emphasis obtains +6 dB/oct audio characteristics. The TX/RX HPF filters out 250 Hz and lower audio signals, the limiter limits its level and the splatter ﬁ lters out 3 kHz and higher audio signals.

The ﬁ ltered MIC signals are level adjusted at another volume controller (VR2), and then output from pin 7 via smoothing ﬁ lter (SMF).

• BASE BAND IC BLOCK DIAGRAM

Com-

pressor

LPF

TXA1

RXA1

VR1

(HPF)

VR3

(HPF)

3TXIN

23RXIN

21SDEC

Pre-

emphasis

TX/RX

HPF

Scrambler/

De-scrambler

5 - 2

BASE BAND IC (IC5)

Limiter Splatter VR2

De-

emphasis

Expander

VR4

SMF

RXA2

7 MOD

20 SIGNAL

The output AF signals are then passed through the Digital/ Analog switch (IC14, pins 12, 14) and applied to the AF mixer (IC9, pin 6) where the MIC signals and Tone signals are mixed with (while CTCSS/DTCS are in use) via the PM/FM switch (IC13, pins 12, 14).

The CTCSS and DTCS signals are generated by the CPU (IC18) and output from pins 89−91. The output signals are passed through the 3 registers (R263–R265) to change its wave form. The wave form changed CTCSS/DTCS signals are passed through the LPF (IC17, pins 1, 3) and the D/A converter (IC4, pins 21, 22) for level adjustment. The level adjusted CTCSS/ DTCS signals are then applied to the AF mixer (IC9, pin 6)

2/5 tone and DTMF signals are

generated by the CPU (IC18)

and output from pin 43. The output signals are passed through two LPF's (IC17, pins 8, 10 and pins 5, 7), then applied to the AF mixer (IC9, pin 6)

The mixed AF signals are output from pin 7 of the AF mixer (IC9) and passed through the D/A converter (IC4, pins 3, 4) for level adjustment (=deviation adjustment), then applied to the modulation circuit (D9) as the modulation signals. The modulation signals are also applied to the reference frequency oscillator (X1) via D/A converter (IC4, pins 11, 12) and AF ampliﬁ er (IC21, pins 1, 4).

5-2-2 MODULATION CIRCUIT (MAIN UNIT)

The modulation signals from the microphone ampliﬁ er circuits are applied to the D9, and modulate the VCO oscillating signal by changing the reactance of D9. The modulated VCO output signal is buffer-ampliﬁ ed by Q4 and Q6, then applied to transmit ampliﬁ ers as a transmit signal via the TX/RX switch (D14 is ON, D15 is OFF).

5-2-3 TRANSMIT AMPLIFIERS (RF UNIT)

The transmit signal from the TX/RX switch (MAIN UNIT; D14 is ON, D15 is OFF) is ampliﬁ ed to the transmit output level by pre-driver (Q603), driver (Q602) and power (Q601) ampliﬁ ers.

The power-amplified transmit signal is passed through the two LPF’s (L607, L608, C620, C622−C624, C664 and L606, C615−617) to filter off the harmonic components in the transmit signal. The ﬁ ltered transmit signal is passed through the antenna switching circuit (D601 and D603 are ON), then applied to the antenna connector (CHASSIS; J1) via another LPF (L601−L603, C601, C602, C604−C606, C608, C609, C663).

5-2-4 APC CIRCUIT (RF UNIT)

The APC (Automatic Power Control) circuit stabilizes transmit output power to prevent the transition of the transmit output power level which is caused by load mismatching or heat effect, etc. The APC circuit also selects transmit output power from high, middle and low power.

A portion of the transmit signal is detected by the transmit power detector (D604, D605) to produce a DC voltage corresponding to the transmit output power level. The detected voltage is applied to the APC amplifier (IC601, pin 3). The transmit power setting voltage “T2” from the D/A converter (MAIN UNIT; IC20, pin 2) is applied to another input terminal (pin 1) as the reference voltage.

The APC ampliﬁ er compares the detected voltage and reference voltage, and the difference of the voltage is output from pin 4. The output voltage controls the bias of the drive (Q602) and power (Q601) amplifiers to reduce/increase the gain of these ampliﬁ ers for stable transmit output power.

The change of transmit output power is carried out by the change of reference voltage "T2," and the transmit power muting is carried out by the TX mute switch (Q606), using the “TMUT” signal from the CPU (IC18, pin 13).

5-2-4 OVER CURRENT DETECTION CIRCUIT (RF UNIT)

The driving current of the drive (Q602) and power (Q601) amplifiers is detected at the current detector (Q604, Q605) by detecting the difference of voltage between both terminals of R623. The detected voltage "ISENS" is applied to the CPU (IC18, pin 47).

In case of the over current, the CPU outputs "TMUT" signal from pin 13 to TX mute switch (Q606) to stop the transmitting for protection of transmit ampliﬁ ers (Q601, Q602).

5-3 PLL CIRCUITS

5-3-1 VCO (Voltage Controlled Oscillator) CIRCUITS (MAIN UNIT)

A VCO is a oscillator which its oscillating frequency is controlled by adding voltage (lock voltage).

This transceiver has 3 VCO’s; RX VCO1 (Q1, D1−D4), RX VCO2 (Q2, D5−D8) and TX VCO (Q3, D10−D12). The RX VCO1 oscillates the 1st LO signals for 155 MHz and higher, and the RX VCO2 oscillates the 1st LO signals for 155 MHz and lower frequencies. And the TX VCO oscillates the transmit output signal.

• RX VCO1 and RX VCO2

The RX VCO1/RX VCO2 (Q1, D1−D4/Q2, D5−D8) oscillates the 1st LO signals. The output signals are amplified by the buffer ampliﬁ ers (Q4, Q6), and applied to the 1st mixer (Q37) via TX/RX switch (D14 is OFF, D15 is ON) and LPF (L38, L39, C161−C164, C383, C384), to be mixed with the received signals to produce the 46.35 MHz 1st IF signal.

• TX VCO

The TX VCO (Q3, D10−D12) oscillates the transmit signal. The output signal is applied to the transmit ampliﬁ ers via the buffer ampliﬁ ers (Q4, Q6) and TX/RX switch (D14 is ON, D15 is OFF).

• APC CIRCUIT

Q604, Q605

“ISENS”

from TX/RX switch (MAIN UNIT; D14, D15)

“T2”

Q606

“TMUT”

Current

detector

T5V

Drive amp.

Q602

Powe r amp.

Q603 Predrive amp.

IC601 ALC amp.

–

to the receive circuits

Q601

LPF

ANT

D604

Power detecter

D605

LPF

to the anntena

5 - 3

A portion of the each VCO output is applied to the PLL IC (IC1, pin 6) via the buffer ampliﬁ ers (Q4, Q5) and the tunable BPF (D30, D31, L40, C170−C174).

5-3-2 PLL CIRCUIT (MAIN UNIT)

The PLL circuit provides stable oscillation of the transmit frequency and receive 1st LO frequency. The PLL output frequency is controlled by the divided ratio (N-data) from the CPU.

The buffer-ampliﬁ ed VCO output signals from the tunable BPF (D30, D31, L40, C170−C174) are applied to the PLL IC (IC1, pin 6). The applied signals are divided at the prescaler and programmable counter according to the “SSO” signal from the CPU (IC18, pin 10). The divided signal is phase-compared with

• PLL CIRCUIT

the reference frequency signal from the reference frequency oscillator (X1), at the phase detector.

The phase difference is output from pin 4 as a pulse type signal after being passed through the internal charge pump. The output signal is converted into the DC voltage (lock voltage) by passing through the loop ﬁ lter (R7, R9, R12, C17, C18, C20). The lock voltage is applied to the variable capacitors (D1 and D2 of RX VCO1, D7 and D8 of RX VCO2, D11 and D12 of TX VCO) and locked to keep the VCO frequency constant.

If the oscillated signal drifts, its phase changes from that of the reference frequency, causing a lock voltage change to compensate for the drift in the VCO oscillating frequency.

RX VCO1 (155–174 MHz)

Q1, D1–D4

RX VCO2 (136–155 MHz)

Q2, D5–D8

Loop

filter

PLL unlock signal to the CPU (IC18, pin 73)

Charge

pump

Phase

detector

TX VCO

Q3, D10–D12

Programmable

divider

Divide

ratio

adjustment

Reference

divider

Buffer Q4

PLL IC (IC1)

Prescaler

Shift register

Buffer Q6

Buffer Q5

14 15

BPF

SCK

SSO

PLL control signals from the CPU (IC18)

PLST

15.3 MHz reference frequency signal

D14

to transmitter circuit

D15

to 1st mixer circuit

5-4 POWER SUPPLY CIRCUITS (MAIN UNIT)

Voltage from the attached battery pack is routed to whole of the circuit in the transceiver via switches and regulators.

!TTACHEDOPTIONALUNITS

!&AMPLIFIERCONTROLLER

&2/.45.)411$

!TTACHEDOPTIONALUNITS

ETC

#05)#

%%02/-)#

ETC

$!CONVERTERS

ETC

0,,)#)#

"ASEBAND)#)#

ETC

62%&

)#

62%&

REGURATOR

#056

6

)#

#056

REGURATOR

6

REGURATOR

111

11

0OWERSWITCH

6##

48POWERAMPLIFIERS

2&5.)411

#URRENT

SENSOR

"ATTERYPACK

15.3 MHz

2&5.)4 112

0,,)#)#

4RANSMITTERCIRCUITS

2ECEIVERCIRCUITS

46

26

1

46

REGURATOR

26

REGURATOR

1

36

REGURATOR

1

h4#v

h2#v

5 - 4

h3#v







#05



)#

6OLTAGELINE

#ONTROLSIGNAL

5-5 PORT ALLOCATIONS

5-5-1 CPU (MAIN UNIT; IC18)

Port

No.

Name

1 DSDA Outputs serial data to the D/A converter (IC20, pin 6).

2 DAST Outputs strobe signal to the D/A converter (IC4, pin 6).

3 SIDE3

4−7 CBI0−3 Input ports for [ROTARY SELECTOR] (VR UNIT; S701).

10 SSO

11 SCK

13 PLST

15 DASW

17 TMUT

18 NWC2

19 NWC1

20 DDSD

21 DDAC

26 T5C

27 R5C

28 S5C

29 PTTSW

30 SIDE2

32 RMUT Outputs mute signal to the AF mute switch (D42).

37 NOIS

38 POSW

39 DDST

40 MTCK

41 PWON

43 SENC

44 BEEP Outputs beep sound to the AF circuits (IC4, pin 13).

45 SDEC Input port for decoded 2/5 tone and DTMF signals.

46 CDEC Input port for decoded CTCSS/DTCS signal.

47 ISENS

48 BATV Input port for remaining battery power. 49 LVIN Input port for VCO lock voltage.

50 RSSI

55 EMER Input port for [Emer] switch (VR UNIT; S702).

Input port for [Side3] key (S4). "Low"=When the key is pushed.

Outputs serial data to the PLL IC (IC1, pin 15), D/A converter (IC4, pin 8).

Outputs serial crock signal to the PLL IC (IC1, pin

14), D/A converter (IC4, pin 8). Outputs PLL strobe signal to the PLL IC (RF UNIT;

IC1, pin 16). Outputs mode (Digital/Analog) switching signal to

the D/A converter (IC14, pins 10, 11). Outputs transmit mute signal to the transmit mute

switch (RF UNIT; Q606). Outputs Narrow/Wide mode switching signal to the

bandwidth switches (Q26, D32, D33). Outputs Narrow/Wide mode switching signal to the

bandwidth switches (Q27, Q41, Q42, D34, D35). Outputs serial data to the DTMF decode IC (IC10,

pin 9). Outputs serial clock signal to the DTMF decode IC

(IC10, pin 11). Outputs T5V line control signal to the T5V regulator

(Q15). "Low"= While transmitting.

Output R5V line control signal to the R5V regulator (Q16). "Low"= While receiving.

Output S5V line control signal to the S5V regulator (Q14). "Low"=While power save mode.

Input port for [PTT] switch (S3). "Low"=When the switch is pushed.

Input port for [Side2] key (S5). "Low"=When the key is pushed.

Input port for the noise level from the FM IF IC (IC3, pin 13).

Input port for power switch (VR UNIT; R702) from power controller (D36).

Outputs strobe signal to the DTMF decode IC (MAIN UNIT; IC10, pin 14).

Outputs serial clock signal to the base band IC (MAIN UNIT; IC5, pin 9).

Outputs VCC line control signal to the power switch (Q30, Q31). "Low"=While the power is ON.

Outputs single tone encode signal to the LPF (IC17, pin 10).

Input port for power amplifier current detect signal from the current detector (RF UNIT; Q604, Q605).

Input port for RSSI signal from the FM IF IC (IC3, pin 12).

Description

Port

No.

Name

70 CSFT

71 DUSE

73 UNLK

74 RLED

75 TLED

78 FSDA

79 FSCL

81 CIRQ

88 SIDE1

CENC0−

89−

92 EMPH

93 MTDT Outputs serial data to the base band IC (IC5, pin 10).

96 MSCK

97 PMFM

98 ESDA Outputs serial data to the EEPROM (IC19, pin 5).

99 ESCL

100 RESL Input port for reset signal from the reset IC (IC8, pin 1).

Outputs CPU clock frequency shift signal to the CPU clock oscillator (X2, D38).

Outputs CTCSS/DTCS select signal to the CTCSS/ DTCS switch (Q34).

Input port for PLL unlock detect signal from the PLL IC (IC1, pin 11).

Outputs RX indicator (VR UNIT; DS701) control signal to the LED driver (VR UNIT; Q701).

Outputs TX indicator (VR UNIT; DS701) control signal to the LED driver (VR UNIT; Q701).

Outputs serial data to the expand IC (FRONT UNIT; IC505, pin 3).

Outputs serial clock signal to the expand IC (FRONT UNIT; IC505, pin 3).

Input port for external connection detect signal from J1 and J2.

Input port for [Side1] key (S6). "Low"=When the key is pushed.

Output CTCSS/DTCS signals to the LPF (IC17, pin 3).

Outputs emphasis characteristic change signal to the D/A converter (IC13, pins 9, 10).

Outputs serial clock signal to the base band IC (MAIN UNIT; IC5, pin 13).

Outputs modulation mode switching signal to the PM/FM switch (IC13, pin 11) .

Outputs serial clock signal to the EEPROM (IC19, pin 6).

Description

5-5-2 D/A CONVERTER (MAIN UNIT; IC20)

Port

No.

Name

1T1

2T2

3 TXLVA

4 RXLVA

Outputs BPF tuning voltage to the tunable BPF (

D24, L31, L32, C120−C122, C125−C127

• While receiving

Outputs BPF tuning voltage to the tunable BPF

D28, D29, L33, L34, C140−C144, C147).

(

• While transmitting

Outputs TX power setting voltage to the APC ampliﬁ er (RF UNIT; IC601).

Outputs oscillation frequency adjust voltage to the TX VCO (Q3, D10−D12).

Outputs oscillation frequency adjust voltage to the RX VCO1/2 (

Description

D23,

Q1, D1−D4/Q2, D5−D8).

5-5-3 EXPAND IC (FRONT UNIT; IC505)

Port

No.

Name

4 AFON

5 LIGH

6 SPCON

7 MCON

Outputs AF power ampliﬁ er (Q508, Q509) control signal to the AF power ampliﬁ er controller (Q501, Q502, D508).

Outputs backlight control signal to the backlight driver (Q507−Q509).

Outputs internal/external speaker select signal to the SP/ESP switch (Q512, Q513).

Outputs internal/external microphone select signal to the microphone controller (Q505, D504).

Description

5 - 5

SECTION 6 ADJUSTMENT PROCEDURES

6-1 PREPARATION

When adjusting IC-F3060 series, the optional CS-F3060 ADJ (modiﬁ ed OPC-966

▄

REQUIRED TEST EQUIPMENT

CLONING CABLE

; see illustration page 5-2) and below test equipments are required.

EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE

FM deviation meter

Frequency counter

RF power meter

Frequency range Measuring range

Frequency range Frequency accuracy Sensitivity

Measuring range Frequency range Impedance SWR

: DC–300 MHz : 0 to ±10 kHz

: 0.1–300 MHz : ±1 ppm or better : 100 mV or better

: 1–10 W : 100–300 MHz : 50

Ω

: Better than 1.2 : 1

ADJUSTMENT SOFTWARE

Attenuator

Standard signal generator (SSG)

Oscilloscope

External speaker

(Rev. 1.1 or later), OPC-966

Power attenuation Capacity

Frequency range Output level

Frequency rang Measuring range

Input impedance Capacity

JIG CABLE

: 20 or 30 dB : 10 W

: 0.1–300 MHz : 0.1 µV to 32 mV

(–127 to –17 dBm)

: DC–20 MHz : 0.01–20 V

: 8

Ω

: 1 W or more

▄

SYSTEM REQUIREMENTS

• Microsoft® Windows® 98/98SE/Me/2000/XP

• RS-232C serial port (D-sub 9 pin)

▄

ADJUSTMENYT SOFTWARE INSTALLATION

Quit all applications when Windows is running.

Insert the CD into the appropriate CD drive.

Double-click the “Setup.exe” contained in the ‘CS-F3060

ADJ’ folder in the CD drive.

The “Welcome to the InstallShield Wizard for CS-F3060

ADJ” will appear. Click [Next>].

The “Choose Destination Location” will appear. Then click

[Next>] to install the software to the destination folder. (e.g. C:\Program Files\Icom\CS-F3060 ADJ) After the installation is completed, the “InstallShield Wiz-

ard Complete” will appear. Then click [Finish].

Eject the CD.

Program group ‘CS-F3060 ADJ’ appears in the ‘Programs’

folder of the start menu, and ‘CS-F3060 ADJ’ icon appears on the desk top screen.

▄

BEFORE STARTING SOFTWARE ADJUSTMENT

Clone the adjustment frequencies into the transceiver, and set the conﬁ guration using with the CS-F3060

WARE

before starting the software adjustment. Otherwise, the

CLONING SOFT-

software adjustment can not be started.

CAUTION!: BACK UP the originally programmed mem-

ory data in the transceiver before programming the adjustment frequencies. When program the adjustment frequencies into the transceiver, the transceiver’s memory data will be overwritten and lose original memory data at the same time.

Microsoft and Windows are registered trademarks of Microsoft Corporation in the U.S.A. and other countries.

▄

STARTING SOFTWARE ADJUSTMENT

Connect the transceiver and PC with OPC-966

Turn the transceiver power ON.

Boot up Windows, and click the program group ‘CS-F3060

JIG CABLE

ADJ’ in the ‘Programs’ folder of the [Start] menu, then CS-F3060 series ADJ’s window appears.

Click ‘Connect’ on the CS-F3060 ADJ’s window, then

appears transceiver’s up-to-date condition.

Set or modify adjustment data as speciﬁ ed.

• ADJUSTMENT FREQUENCY LIST

CH FREQUENCY ADJUSTMENT ITEM

1 174.000 MHz

2 154.900 MHz

3 155.000 MHz

4 155.000 MHz

5 155.000 MHz

6 136.000 MHz

7 174.000 MHz

8 136.000 MHz

9* 155.000 MHz

10* 136.000 MHz

11* 174.000 MHz

12 155.000 MHz

13 155.000 MHz

†

*; Necessary only when the optional UT-119 is installed.

†

; [EUR-01] only

†

155.000 MHz

136.000 MHz

174.000 MHz

TX power Mode

TX power Mode CTCSS

TX power Mode

: Low1 : Narrow

: High : Wide

: Low2 : Wide

: Low1 : Wide

: Low1 : Narrow

: Low1 : Digital

: Low1 : Wide : 151.4 Hz

: Low1 : Narrow

: Low1 : Middle

6 - 1

• CONNECTION

Standard signal generator

0.1 µV to 32 mV

(–127 dBm to –17 dBm)

CAUTION!

DO NOT transmit while

the SSG is connected to the antenna connector

to the antenna connector

Attenuator

20 dB or 30 dB

RF power meter

0.1–10 W/50 Ω

Frequency

counter

RS-232C cable

deviation meter

Osciiloscope

• JIG cable

IC-F3060 series

/0# #LONINGCABLE

OPC-966

(JIG CABLE)

%LECTROLYTICCAPACITOR

§&

044% 044

-)#

-)#%

30n 30

!DDAJUMPERWIREHERE



!UDIOGENERATOR (ZTOK(Z

044

!#

MILLIVOLTMETER

n 

3PEAKER 7

5 - 2

• PC SCREEN EXAMPLE

!DJUSTMENTSETTING

4RANSMITOUTPUTPOWER

-ODULATIONBALANCE

-ODULATIONPRESET

#4#33$4#3DEVIATION

3QUELCH

2EFERENCEFREQUENCY

2ECEIVESENSITIVITY

28,OCKVOLTAGE,OW

28,OCKVOLTAGE(IGH

28,OCKVOLTAGEPRESET,OW

28,OCKVOLTAGEPRESET(IGH

48,OCKVOLTAGE

48,OCKVOLTAGEPRESET

3METER

&-DEVIATION.ARROW

$EVIATION-IDDLE

$EVIATION7IDE

$EVIATION$IGITAL

-ODEPRESET

;%52=ONLY

./4%

4HEABOVEVALUESFORSETTINGSAREEXAMPLEONLY %ACHTRANSCEIVERHASITSOWNSPECIFICVALUESFOREACHSETTING

6 - 3

6-2 FREQUENCY ADJUSTMENT

Select an adjustment item using [↑] / [↓] keys, then set to the speciﬁ ed value using [←] / [→] keys on the connected PC's keyboard.

ADJUSTMENT ADJUSTMENT CONDITION

PLL LOCK VOLTAGE [RX LVA1]

[RX LVA2] 2 • Channel

[TX LVA] 3 • Channel

PLL LOCK VOLTAGE

REFERENCE FREQUENCY [REF]

1 • Channel

• Lock voltage preset [LV (RX1)]

• Receiving

• Lock voltage preset [LV (RX2)]

• Receiving

• Lock voltage preset

[LV (TX)]

• Transmitting

1 • Channel

• Receiving

2 • Channel

• Receiving

3 • Channel

• Transmitting

• Channel : CH 1 Top

• Connect an RF power meter to the

antenna connector.

• Transmitting

: CH 2

: 153 [3.0 V]

: CH 7

: 153 [3.0 V]

: CH 7

: 153 [3.0 V]

: CH 6 PC

: CH 5

: CH 6

UNIT OPERATION

screen

panel

MEASUREMENT

Click [I/O Check] in the Clone menu to open the "I/O Check window." Click [Update (F5)] button, then check the "LVIN" item on the CS-F3060 ADJ's screen as below.

Click [Update (F5)] button, then check the "LVIN" item on the CS-F3060 ADJ's screen.

Loosely couple a frequency counter to the antenna connector.

VALUE

3.0 V

0.6–1.6 V (Verify)

174.000000 MHz

• I/O Check window

,OCKVOLTAGE

6 - 4

6-3 TRANSMIT ADJUSTMENT

Select an adjustment item using [↑] / [↓] keys, then set to the speciﬁ ed value using [←] / [→] keys on the connected PC's keyboard.

ADJUSTMENT ADJUSTMENT CONDITION

OUTPUT POWER

1 • Channel

• Transmitting

: CH 3 Top

[Power (Hi)]

[Power (L2)] 2 • Channel

: CH 4 2.0 W

• Transmitting

[Power (L1)] 3 • Channel

: CH 5 1.0 W

• Transmitting

MODULATION BALANCE [BAL (Narrow)]

1 • Channel

• Preset [MOD Narrow]

: CH 13 : 60

• No audio applied to the JIG cable.

• Set an FM deviation meter same as; HPF

LPF De-emphasis Detector

: OFF : 20 kHz : OFF : (P–P)/2

• Push [P0] key while transmitting.

FM DEVIATION (NARROW) [MOD N C]

• Channel : CH 13

• Connect an audio generator to the JIG cable and set as;

Frequency : 1.0 kHz Level : 150 mV rms

• Set the FM deviation meter to same condi-

tion as "MODULATION BALANCE."

• Transmitting

(NARROW) [MOD N L]

(NARROW) [MOD N H]

(WIDE) [MOD W C]

(WIDE) [MOD W L]

(WIDE) [MOD W H]

(MIDDLE)

†

[MOD M C]

(MIDDLE)

†

[MOD M L]

(MIDDLE)

†

[MOD M H]

DIGITAL DEVIATION* [MOD D C]

• Channel

• Transmitting

• Channel

• Transmitting

• Channel

• Transmitting

• Channel

• Transmitting

• Channel

• Transmitting

• Channel

• Transmitting

• Channel

• Transmitting

• Channel

• Transmitting

• Preset [Digital Mode] : 7

• Channel : CH 9

• Set the FM deviation meter to same condi-

: CH 8

: CH 1

: CH 5

: CH 6

: CH 7

: CH 14

: CH 15

: CH 16

tion as "MODULATION BALANCE."

• Transmitting

[MOD D L] 3

• Channel

: CH 10

• Transmitting

[MOD D H] 4

• Channel

: CH 11

• Transmitting

CTCSS/DTCS DEVIATION [CTCSS/DTCS]

• Channel : CH 12

• No audio applied to the JIG cable.

• Set the FM deviation meter to same condi-

tion as "MODULATION BALANCE."

• Transmitting

†

; [EUR-01] only.

*; Necessary only when the optional UT-119 is installed.

UNIT OPERATION

panel

Top

panel

Top

panel

Top

panel

Top

panel

MEASUREMENT

Connect an RF power meter to the antenna connector.

Connect the FM deviation meter to the antenna connector through an attenuator.

Connect an FM deviation meter to the antenna connector through an attenuator.

VALUE

5.0 W

Set to square wave form

±2.05 to ±2.15 kHz

±4.05 to ±4.15 kHz

±3.15 to ±3.25 kHz

±1.41 to ±1.45 kHz

±0.68 to ±0.72 kHz

6 - 5

6-4 RECEIVE ADJUSTMENT

Select an adjustment item using [↑] / [↓] keys, then set to the speciﬁ ed value using [←] / [→] keys on the connected PC's keyboard.

ADJUSTMENT ADJUSTMENT CONDITION

RECEIVE SENSITIVITY [BPF T1 C] [BPF T2 C]

NOTE:

adjusted properly.

"RECEIVE SENSITIVITY" must be adjusted before "S-METER." Otherwise, "S-METER" will not be

• Channel : CH 5

• Connect the SSG to the antenna connector and set as;

[BPF T1 H] [BPF T2 H]

Frequency Level Modulation Deviation

• Receiving

• Channel

Frequency

: 155.000 MHz : +20 dBµ

†

(–87 dBm) : 1 kHz : ±3.5 kHz

: CH 6 : 136.000 MHz

UNIT LOCATION

Multi

connec-

tor

• Receiving

[BPF T1 L] [BPF T2 L]

• Channel Frequency

: CH 7 : 174.000 MHz

• Receiving

CONVENIENT:

The "RECEIVE SENSITIVITY" can be adjustment automatically. 1: Put the cursor on "BPF T1 C/L/H ALL" or "BPF T2 C/L/H ALL" and then push [ENTER] key. 2: The connected PC tunes BPF's to peak levels automaticaly. or 1: Put the cursor on the one of "BPF T1 C/L/H" and "BPF T2 C/L/H" as desired. 2: Push [ENTER] key to start tuning. 3: Repeat 1 and 2 to perform additional BPF tuning.

S-METER [RSSI]

SQUELCH [SQL]

†;

The output level of the standard signal generator (SSG) is indicated as the SSG's open circuit.

• Channel : CH 6 Push the [ENTER] key on the connected PC's keyboard to set

• Connect the SSG to the antenna connec-

"S3" level.

tor and set as;

Frequency Level Modulation Deviation

• Receiving

• Set the SSG as; Level

: 136.000 MHz : +23 dBµ

†

(–84 dBm) : 1 kHz : ±3.5 kHz

: –7dBµ† (–114 dBm)

Push the [ENTER] key on the connected PC's keyboard to set "S1" level.

• Receiving

1 • Channel : CH 5 External

• Close the squelch by adjusting the value of

speaker

[SQL] item on the CS-F3060 ADJ's screen.

• Connect the SSG to the antenna connector and set as;

Frequency Level Modulation Deviation

• Receiving

: 155.000 MHz : –14 dBµ

†

(–121 dBm) : 1 kHz : ±3.5 kHz

MEASUREMENT

Connect the SINAD meter with an 8 Ω load to the JIG cable.

Connect an 8 Ω speaker to the JIG cable.

VALUE

Minimum distortion

level

Set the [SQL] to the value that the audio signals just appears.

6 - 6

SECTION 7 PARTS LIST

• IC-F3061/F3062/F3063/T/S

[FRONT UNIT]

REF ORDER NO. NO.

IC501 1180002401 S.REG S-812C30AMC-C2K-G B 66.7/35.7 IC505 1110006440 S.IC M62320FP DF5J B 74/36.8 IC506 1110006440 S.IC M62320FP DF5J B 56.8/24.5 IC508 1110006770 S.IC TDA8547TS/N B 79.6/11.9 IC509 1110005330 S.IC NJM12904V-TE1 B 79.8/24.9

Q501 1520000460 S.TR 2SB1132 T100 R B 75.2/25 Q502 1590001190 S.TR XP6501-(TX) .AB B 75.8/20.8 Q505 1590002230 S.TR UMG2N TL B 71.5/22 Q506 1590003230 S.TR UNR9113J-(TX) B 83.3/41 Q507 1590003290 S.TR UNR9213J-(TX) B 72.3/6.1 Q508 1590001330 S.TR DTA114EUA T106 B 72.2/9 Q509 1590000980 S.TR DTB123EK T146 B 72.4/12.3 Q512 1590003290 S.TR UNR9213J-(TX) B 72/18 Q513 1590003290 S.TR UNR9213J-(TX) B 74.9/15.6 Q514 1590003230 S.TR UNR9113J-(TX) B 67.6/26.8 Q515 1560001360 S.FET 2SK3019 TL B 81/32.2 Q516 1590003290 S.TR UNR9213J-(TX) B 80.9/36

D502 1790001250 S.DIO MA2S111-(TX) B 71/23.9 D503 1790001250 S.DIO MA2S111-(TX) B 66.8/21.1 D504 1790001250 S.DIO MA2S111-(TX) B 71/25.1 D505 1160000140 S.DIO DAP222 TL B 63.6/21.9 D506 1160000140 S.DIO DAP222 TL B 63.6/26 D508 1160000060 S.DIO DAN202U T106 B 75.1/5.7

R503 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 74/20 R504 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 74.8/18.4 R505 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 76.6/18.4 R506 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 75.2/13.7 R508 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 81.8/18.2 R509 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 79.1/18.2 R510 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 81.7/16.6 R511 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 78.3/16.6 R513 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 85.2/41.1 R514 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 87.5/38.8 R515 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 81.8/34 R516 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 79.4/32.4 R517 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 67.4/24.8 R518 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 66.2/22.5 R519 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 69.4/22.3 R520 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 69.4/20.7 R521 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 68.3/24.8 R522 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 53.6/18.8 R523 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 54.6/18.8 R524 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 55.6/18.8 R525 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 56.6/18.8 R526 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 65.2/22.1 R527 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 63.6/23.5 R528 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 63.6/24.4 R529 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 65/24.7 R530 7030009280 S.RES ERJ2GEJ 391 X (390) B 71.6/14.4 R531 7030005000 S.RES ERJ2GEJ 471 X (470) B 82.7/33 R532 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 65.2/28 R533 7030007250 S.RES ERJ2GEJ 220 X (22) B 63.6/27.6 R534 7030007250 S.RES ERJ2GEJ 220 X (22) B 63.6/28.6 R535 7030004970 S.RES ERJ2GEJ 470 X (47) B 69.7/3.4 R536 7030004970 S.RES ERJ2GEJ 470 X (47) B 69.7/5.4 R537 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 69.7/4.4 R538 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 72/3.1 R539 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 69.7/2.4 R540 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 80.3/20.2 R541 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 79.4/20.2 R542 7030005220 S.RES ERJ2GEJ 223 X (22 k R543 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 82.6/27.1 R544 7030004980 S.RES ERJ2GEJ 101 X (100) B 82.6/29.9 R546 7030009280 S.RES ERJ2GEJ 391 X [10-key type] only B 71.6/15.3 R547 7030009280 S.RES ERJ2GEJ 391 X [10-key type] only B 71.6/16.2 R548 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 74.4/8.5 R552 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 79.8/30.4 R553 7030005090 S.RES ERJ2GEJ 104 X (100 k) [4-key type] only B 71/42 R554 7030005090 S.RES ERJ2GEJ 104 X (100 k) [10-key type] only B 72.6/42 R555 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 74.4/9.4 R557 7030004970 S.RES ERJ2GEJ 470 X (47) B 87/34.7 R558 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 73.9/18.4 R559 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 77.4/16.6 R560 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 77.5/18.4 R561 7030005000 S.RES ERJ2GEJ 471 X (470) B 82.7/22.7

DESCRIPTION

B 81.7/28.3

)

H/V

LOCATION

[FRONT UNIT]

REF ORDER NO. NO.

R562 7030005000 S.RES ERJ2GEJ 471 X (470) B 83.4/20.3 R563 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 80.4/16.6 R564 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 79.5/16.6 R566 7030010040 S.RES ERJ2GEJ-JPW B 77.6/20.2 R567 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 81/30.4

C501 4550006760 S.TAN TEESVB21A336M8R B 93.4/37.3 C502 4550006760 S.TAN TEESVB21A336M8R B 96.7/37.3 C506 4550006250 S.TAN TEESVA 1A 106M8R B 75.8/31.1 C507 4550006250 S.TAN TEESVA 1A 106M8R B 70.5/29 C508 4550006250 S.TAN TEESVA 1A 106M8R B 70.5/31.1 C509 4030017460 S.CER ECJ0EB1E102K B 75.6/12.5 C510 4030016930 S.CER ECJ0EB1A104K B 73.1/20 C511 4030017460 S.CER ECJ0EB1E102K B 75.7/18.4 C514 4550006250 S.TAN TEESVA 1A 106M8R B 78.5/5.4 C515 4030016930 S.CER ECJ0EB1A104K B 80.9/18.2 C517 4030016930 S.CER ECJ0EB1A104K B 80/18.2 C518 4030017460 S.CER ECJ0EB1E102K B 71.9/26.7 C520 4030017460 S.CER ECJ0EB1E102K B 87/41.1 C522 4030016930 S.CER ECJ0EB1A104K B 84.7/39.9 C523 4030016930 S.CER ECJ0EB1A104K B 80/34 C524 4030017460 S.CER ECJ0EB1E102K B 68.5/20.7 C525 4030016930 S.CER ECJ0EB1A104K B 80.9/34 C526 4030017460 S.CER ECJ0EB1E102K B 70.9/26.7 C527 4030017460 S.CER ECJ0EB1E102K B 86.1/41.1 C528 4030016930 S.CER ECJ0EB1A104K B 80/40.6 C529 4030016930 S.CER ECJ0EB1A104K B 58/29.5 C530 4030017460 S.CER ECJ0EB1E102K B 80/41.6 C531 4030017460 S.CER ECJ0EB1E102K B 56.4/29.5 C532 4550007090 S.TAN TEESVA 1A 226M8R B 67.4/39.9 C534 4030016930 S.CER ECJ0EB1A104K B 65.8/38.2 C535 4030016790 S.CER ECJ0EB1C103K B 64.9/38.2 C536 4550005980 S.TAN TEESVA 1A 475M8R B 67/31.5 C537 4030016930 S.CER ECJ0EB1A104K B 55/37.7 C538 4550000460 S.TAN TEESVA 1C 105M8R B 54.6/31.9 C539 4030016930 S.CER ECJ0EB1A104K B 82.6/28.3 C540 4030018140 S.CER ECJ0EB1H391K B 81.2/20.2 C541 4030016930 S.CER ECJ0EB1A104K B 74.4/7.6 C542 4030017440 S.CER ECJ0EC1H221J B 79.8/29.4 C543 4550006250 S.TAN TEESVA 1A 106M8R B 75.8/29 C544 4030017460 S.CER ECJ0EB1E102K B 82.6/26.2 C559 4030016790 S.CER ECJ0EB1C103K T 87.9/28 C560 4030017770 S.CER ECJ0EB1E332K B 78.5/20.2 C561 4030016930 S.CER ECJ0EB1A104K B 82.4/31.1

J501 6510025240 S.CNR IMSA-9631S-20Y912 B 63.5/11.4 J502 6510025250 S.CNR IMSA-9631S-08Y912 B 58.8/35.5 J503 6510025260 S.CNR IMSA-9631S-10Y912 B 89.8/24.4

DS501 5040002960 S.LED SML-A12MT T86 T 82.9/33.6 DS502 5040002960 S.LED SML-A12MT T86 T 82.9/23.1 DS503 5040002960 S.LED SML-A12MT T86 T 82.9/12.6 DS504 5040002420 S.LED SML-310MT T86 T 38.1/12.9 DS505 5040002420 S.LED SML-310MT T86 T 38.1/30.9 DS506 5040002420 S.LED SML-310MT T86 [10-key type] only T 29.2/14.9 DS507 5040002420 S.LED SML-310MT T86 [10-key type] only T 29.2/28.9 DS508 5040002420 S.LED SML-310MT T86 [10-key type] only T 11.7/14.9 DS509 5040002420 S.LED SML-310MT T86 [10-key type] only T 11.7/28.9 DS510 5030002830 LCD M4-0078TAY-2

MC501 7700002480 MIC SKB-2746 LPC

W501 9028930010 WIR 23/04/020/W02/W02 W502 9014506004 WIR 23/00/025/W02/W02

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

H/V

LOCATION

7 - 1

[MAIN UNIT]

REF ORDER NO. NO.

IC1 1130010100 S.IC LMX2352TMX/NOPB B 58.2/18.3 IC3 1110003491 S.IC TA31136FNG (D EL) B 76.6/32.9 IC4 1190001350 S.IC M62364FP 600D B 42.1/18.1 IC5 1110006221 S.IC AK2346P-E2/P B 51.3/36.4 IC6 1110005350 S.IC NJM2870F05-TE1 B 96.8/10.2 IC8 1110005771 S.IC S-80942CNMC-G9CT2G B 13.2/28.8 IC9 1110005340 S.IC NJM12902V-TE1 B 42.4/29 IC10 1130012960 S.IC BU8872FS-E2 B 5.8/15.4 IC13 1140013200 S.IC CD4053BPWR B 41.7/8.2 IC14 1140013200 S.IC CD4053BPWR B 49.1/8.2 IC15 1110005310 S.IC AN6123MS T 50.8/23.2 IC17 1110005340 S.IC NJM12902V-TE1 B 25.6/38.1 IC18 1140010191 S.IC HD64F2268TF20V B 23/23.1 IC19 1140012950 S.IC 24LC512T-I/SM B 25/6.7 IC20 1190001340 S.IC M62334FP 600C T 99.1/34.7 IC21 1120002830 S.IC NJM2125F-TE1 B 53.9/25.1 IC22 1140013200 S.IC CD4053BPWR B 4.7/29.2 IC24 1130011760 S.IC CD4094BPWR B 15.1/7.4

Q1 1530002920 S.TR 2SC4226-T1 R25 T 80.6/11.6 Q2 1530002920 S.TR 2SC4226-T1 R25 T 76.4/16.4 Q3 1530002920 S.TR 2SC4226-T1 R25 T 78.4/22.7 Q4 1530003311 S.TR 2SC5107-O (TE85R F) T 80/17.1 Q5 1530003311 S.TR 2SC5107-O (TE85R F) B 78.5/25.5 Q6 1530002920 S.TR 2SC4226-T1 R25 B 84.4/19.8 Q6 1530003311 S.TR 2SC5107-O (TE85R F) B 84.4/19.8 Q10 1580000731 S.FET 3SK293 (TE85L F) T 100.4/20 Q11 1560000840 S.FET 2SK1829 (TE85R) [USA-01], [GEN-01] B 99.6/19.2 1560000841 S.FET 2SK1829 (TE85R F) [others] B 99.6/19.2 Q12 1520000460 S.TR 2SB1132 T100 R T 98.9/9.7 Q13 1590001190 S.TR XP6501-(TX) .AB T 104.7/8.7 Q14 1510000920 S.TR 2SA1577 T106 Q B 93.4/7.2 Q15 1510000920 S.TR 2SA1577 T106 Q B 90.7/9.5 Q16 1510000920 S.TR 2SA1577 T106 Q T 90.2/9.8 Q17 1530002851 S.TR 2SC4116-BL (TE85R F) B 75.3/18.3 Q18 1530002851 S.TR 2SC4116-BL (TE85R F) B 67.1/29.6 Q21 1590001400 S.TR XP1214 (TX) B 78.9/15.3 Q22 1590001400 S.TR XP1214 (TX) B 78.9/20.4 Q23 1590003290 S.TR UNR9213J-(TX) B 82.2/16 Q24 1590003290 S.TR UNR9213J-(TX) B 59.7/31 Q25 1530002601 S.TR 2SC4215-O (TE85R F) B 86.9/35.1 Q26 1590003230 S.TR UNR9113J-(TX) B 67.7/33.8 Q27 1590003230 S.TR UNR9113J-(TX) B 95/32.4 Q28 1590001650 S.TR XP4601 (TX) B 64.1/35.9 Q30 1590003321 S.FET TPC6103 (TE85L F) B 101.2/9.1 Q31 1590003290 S.TR UNR9213J-(TX) T 93.2/7.5 Q32 1560001360 S.FET 2SK3019 TL B 62.8/13 Q33 1560000541 S.FET 2SK880-Y (T5RICOM F) B 61.6/25.2 Q34 1590003290 S.TR UNR9213J-(TX) B 34.8/35.2 Q35 1590003290 S.TR UNR9213J-(TX) T 16.7/26.7 Q37 1580000800 S.FET 3SK324UG-TL-E T 89.2/16 Q38 1530002851 S.TR 2SC4116-BL (TE85R F) T 74.3/41.9 Q41 1530002851 S.TR 2SC4116-BL (TE85R F) T 86.9/22 Q42 1530002851 S.TR 2SC4116-BL (TE85R F) B 89.8/21.9 Q44 1590003230 S.TR UNR9113J-(TX) B 8.6/10.7 Q45 1560001360 S.FET 2SK3019 TL T 49.3/27 Q46 1590003290 S.TR UNR9213J-(TX) T 95.3/7.5

D1 1750000771 S.VCP HVC376BTRF-E T 71.2/11.6 D2 1750000771 S.VCP HVC376BTRF-E T 70.3/10 D3 1720000640 S.VCP 1SV284 (TPH3) [USA-01], [GEN-01] T 67.6/10 1720000641 S.VCP 1SV284 (TPH3 F) [others] T 67.6/10 D4 1720000640 S.VCP 1SV284 (TPH3) [USA-01], [GEN-01] T 66.4/10 1720000641 S.VCP 1SV284 (TPH3 F) [others] T 66.4/10 D5 1720000640 S.VCP 1SV284 (TPH3) [USA-01], [GEN-01] T 65.5/15.3 1720000641 S.VCP 1SV284 (TPH3 F) [others] T 65.5/15.3 D6 1720000640 S.VCP 1SV284 (TPH3) [USA-01], [GEN-01] T 66.7/15.3 1720000641 S.VCP 1SV284 (TPH3 F) [others] T 66.7/15.3 D7 1750000771 S.VCP HVC376BTRF-E T 69.3/14.4 D8 1750000771 S.VCP HVC376BTRF-E T 69.3/16.9 D9 1720000471 S.VCP 1SV239 (TPH3 F) T 69.2/21.5 D10 1750000721 S.VCP HVC375BTRF-E T 72.6/22.3 D11 1750000771 S.VCP HVC376BTRF-E T 68.1/25.1 D12 1750000771 S.VCP HVC376BTRF-E T 65.5/25 D13 1790001250 S.DIO MA2S111-(TX) B 75.3/20.2 D14 1790001621 S.DIO 1SV308 (TPL3 F) B 87.7/14.2 D15 1790001260 S.DIO MA2S077-(TX) T 86.1/17 D21 1790001240 S.DIO MA2S728-(TX) B 99.7/34.8 D22 1790001260 S.DIO MA2S077-(TX) B 99.7/33.6 D23 1750000721 S.VCP HVC375BTRF-E T 104.7/23.7 D24 1750000721 S.VCP HVC375BTRF-E T 104.7/20.7 D25 1790001250 S.DIO MA2S111-(TX) B 103.3/18.7 D26 1750000370 S.DIO DA221 TL B 99.4/24.1 D27 1750000370 S.DIO DA221 TL B 100.2/21.8 D28 1750000711 S.VCP HVC350BTRF-E T 95.6/19.1

DESCRIPTION

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

D29 1750000711 S.VCP HVC350BTRF-E T 94.1/19.9 D30 1790001260 S.DIO MA2S077-(TX) B 68.5/24.3 D31 1790001260 S.DIO MA2S077-(TX) B 71.1/24.3 D32 1750001070 S.DIO DAN235ETL T 70.8/39.2 D33 1750001070 S.DIO DAN235ETL T 70.6/34.3 D34 1750001070 S.DIO DAN235ETL B 90.3/19.6 D35 1750001070 S.DIO DAN235ETL B 91.1/34.5 D36 1160000060 S.DIO DAN202U T106 T 93.9/10.6 D37 1730002320 S.ZEN MA8051-M (TX) T 14.2/25.1 D38 1790001260 S.DIO MA2S077-(TX) B 12.8/32.6 D40 1160000050 S.DIO DAP202U T106 B 19.1/37 D41 1790001250 S.DIO MA2S111-(TX) B 46/25 D42 1160000140 S.DIO DAP222 TL T 17.9/12.3

FI1 2030000500 S.MLH FL-401 (46.35 MHz) T 91.4/27.4 FI2 2020002120 S.CER CFWCA450KGFA-R0 T 65/34.6 FI3 2020002180 S.CER CFWKA450KHFA-R0 T 76.7/34.6 FI4 2030000150 S.MLH FL-335 (46.350 MHz) B 91.4/27.4

X1 6050012380 S.XTL CR-826 (15.3 MHz) B 57.9/26.5 X2 6050011720 S.XTL CR-764 (19.6608 MHz) T 2.9/32.3 X3 6050011730 S.XTL CR-765 (3.6864 MHz) T 51.2/35.3 X4 6050012320 S.XTL CR-818 (4.194304 MHz) T 2.9/15.2 X5 6070000190 S.DCR CDBCB450KCAY24-R0 T 84.5/38.2

L1 6200004660 S.COL MLF1608A 1R8K-T B 52.9/21 L2 6200007170 S.COL MLF1608A 3R3K-T T 69.1/11 L3 6200007170 S.COL MLF1608A 3R3K-T T 68.1/15.3 L4 6200007170 S.COL MLF1608A 3R3K-T T 66.8/23.3 L5 6200003640 S.COL MLF1608E 100K-T T 68.6/8 L6 6200007170 S.COL MLF1608A 3R3K-T T 65.2/10 L7 6200002390 S.COL LQW31HN64NJ03L T 74.3/9.6 L8 6200011120 S.COL 0.40-2.00-10TL 90.5N T 71.6/16.2 L9 6200003640 S.COL MLF1608E 100K-T T 67/18.4 L10 6200007170 S.COL MLF1608A 3R3K-T T 64.2/15.3 L11 6200008190 S.COL 0.25-1.9-8TL 80N T 73.3/25.3 L12 6200003640 S.COL MLF1608E 100K-T T 70.1/26.3 L13 6200008090 S.COL LQW2BHN68NJ03L T 64.7/22.9 L14 6200007170 S.COL MLF1608A 3R3K-T T 70.5/23.1 L15 6200006981 S.COL ELJRE R10GFA T 80.9/19 L16 6200007911 S.COL ELJRF 18NJFB B 76.6/26.4 L17 6200009101 S.COL ELJRE R18GFA B 85.2/17.9 L29 6200005741 S.COL ELJRE 47NGFA B 101.3/31.9 L30 6200007750 S.COL LQW2BHN56NJ03L B 100.3/36.4 L31 6200008090 S.COL LQW2BHN68NJ03L T 103.5/25.3 L32 6200008090 S.COL LQW2BHN68NJ03L T 104.2/19 L33 6200007750 S.COL LQW2BHN56NJ03L T 98/21.1 L34 6200007750 S.COL LQW2BHN56NJ03L T 92.5/17.8 L38 6200006671 S.COL ELJRE 68NGFA T 89.6/13.1 L39 6200005731 S.COL ELJRE 39NGFA T 87.3/16.9 L40 6200007911 S.COL ELJRF 18NJFB B 66.5/26.4 L45 6200004480 S.COL MLF1608D R82K-T B 73.7/29 L46 6200003540 S.COL MLF1608D R22K-T B 69.1/30.4 L49 6200007850 S.COL ELJNC R82K-F B 92.2/17.3 L50 6200011031 S.COL ELJRF R10JFB B 53.5/41.3

R1 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 54.1/27.3 R2 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 51.4/23.8 R3 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 52.9/28.3 R4 7030005000 S.RES ERJ2GEJ 471 X (470) T 57.9/22.4 R5 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 54.1/29.1 R6 7410001130 S.ARY EXB28V102JX B 53/15.7 R7 7030010040 S.RES ERJ2GEJ-JPW B 63/20.5 R9 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 63.5/21.7 R11 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 62.1/23.3 R12 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 65.8/20.5 R13 7030010040 S.RES ERJ2GEJ-JPW T 79.8/9.3 R14 7030011000 S.RES RR0510P-392-D (3.9 k) T 78.5/9.5 R15 7030008340 S.RES RR0510P-182-D (1.8 k) T 78.5/10.5 R16 7030011000 S.RES RR0510P-392-D (3.9 k) T 74.6/13.2 R17 7030008340 S.RES RR0510P-182-D (1.8 k) T 74.6/15.7 R18 7030010040 S.RES ERJ2GEJ-JPW T 75.8/14.5 R19 7030011000 S.RES RR0510P-392-D (3.9 k) T 76.5/25.6 R20 7030008340 S.RES RR0510P-182-D (1.8 k) T 78.5/24.8 R21 7030010040 S.RES ERJ2GEJ-JPW T 77.5/24.8 R22 7030005000 S.RES ERJ2GEJ 471 X (470) T 81.4/13.9 R23 7030005000 S.RES ERJ2GEJ 471 X (470) T 78.1/14.1 R24 7030008370 S.RES ERJ2GEJ 561 X (560) T 78/21 R25 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 77.2/19 R26 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 80.8/20.5 R27 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 83.2/13.6 R28 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 75.3/21.3 R29 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 79/19.1 R30 7030004980 S.RES ERJ2GEJ 101 X (100) T 81.7/20.6 R31 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 80.3/25.2 R32 7030004980 S.RES ERJ2GEJ 101 X (100) B 80.8/26.5 R33 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 82.1/19.2 R34 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 83.5/17.7

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

H/V

LOCATION

7 - 2

[MAIN UNIT]

REF ORDER NO. NO.

R35 7030004980 S.RES ERJ2GEJ 101 X (100) B 84.8/16.8 R36 7030010040 S.RES ERJ2GEJ-JPW B 83.5/21.8 R37 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 86.1/14.3 R38 7030004980 S.RES ERJ2GEJ 101 X (100) B 89.6/12.9 R38 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 89.6/12.9 R60 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 103.9/22.6 R61 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 103.9/21.7 R62 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 102.7/22.5 R63 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 102.7/17.4 R64 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 103.9/15.7 R65 7030008280 S.RES ERJ2GEJ 271 X (270) T 99.8/23.6 R66 7030005530 S.RES ERJ2GEJ 100 X (10) T 101.1/22.1 R67 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 102.2/19.8 R68 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 97.4/18.5 R69 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 101.5/17.9 R70 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 103.2/17 R71 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 98.7/21.4 R72 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 96.6/23.5 R73 7030004970 S.RES ERJ2GEJ 470 X (47) B 96.6/22.6 R74 7030005000 S.RES ERJ2GEJ 471 X (470) T 98.6/18.6 R75 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 95.4/21.1 R76 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 94.2/21.9 R77 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 95.7/23.1 R86 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 85/17.4 R87 7030004980 S.RES ERJ2GEJ 101 X (100) T 85/13.5 R88 7030005580 S.RES ERJ2GEJ 560 X (56) T 59.8/17.5 R89 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 67.5/24.7 R90 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 70.1/24.3 R91 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 59.9/32.5 R95 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 88.7/36.2 R98 7030005010 S.RES ERJ2GEJ 681 X (680) B 87.2/36.9 R99 7030004980 S.RES ERJ2GEJ 101 X (100) B 89.2/37.4 R100 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 77.8/36.6 R101 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 82.9/33.1 R102 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 71.4/31.9 R103 7030004970 S.RES ERJ2GEJ 470 X (47) B 76.2/39.9 R104 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 70.9/35.7 R105 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 69.1/34.4 R106 7030010040 S.RES ERJ2GEJ-JPW T 70.3/36.8 R107 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 71.5/37.6 R108 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 72.3/35.2 R109 7030007060 S.RES ERJ2GEJ 684X (680 k) B 65/29.4 R110 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 67.2/32.3 R111 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 70.8/41.2 R112 7030005000 S.RES ERJ2GEJ 471 X (470) B 80/36.2 R113 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 48.1/17.7 R115 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 92.1/19 R116 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 91/20.3 R117 7030007300 S.RES ERJ2GEJ 332 X (3.3 k R118 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 93.6/33.5 R119 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 91.9/33 R120 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 91.5/36.1 R121 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 72.2/35 R122 7030005000 S.RES ERJ2GEJ 471 X (470) B 75/36.6 R123 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 73.2/38.2 R124 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 74.1/38.2 R126 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 37.1/29.1 R127 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 38/30.7 R128 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 48/35.2 R130 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 62.2/36.3 R131 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 64.6/37.6 R132 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 63/37.6 R133 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 64.8/34.1 R134 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 64.8/33.1 R135 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 63.2/33.1 R136 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 62.3/34 R137 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 66.9/37.1 R138 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 67.8/38 R139 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 68.8/38 R140 7030011660 S.RES ERJ2RKF 1002 (10 k) B 57.3/39.6 R141 7030011670 S.RES ERJ2RKF 3902 (39 k) B 57.3/41.2 R142 7030011660 S.RES ERJ2RKF 1002 (10 k) B 56.4/38 R143 7030011670 S.RES ERJ2RKF 3902 (39 k) T 54.3/38.2 R144 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 45.9/38 R145 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 48/30.4 R146 7030010040 S.RES ERJ2GEJ-JPW T 44/29.2 R147 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 56.5/38.9 R148 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 56.5/39.9 R149 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 55.2/37.6 R150 7030005000 S.RES ERJ2GEJ 471 X (470) B 33.3/7.4 R151 7030005000 S.RES ERJ2GEJ 471 X (470) T 45.9/19.2 R152 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 48/38.4 R153 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 46.8/34.8 R154 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 46.8/35.7 R155 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.9/5 R156 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 52.4/6.2 R157 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 54.2/6.9 R158 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 45.2/39.8 R159 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.2/38.9 R161 7030010040 S.RES ERJ2GEJ-JPW B 38/29.1 R162 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 53.6/9.6 R163 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 39.3/21.4

DESCRIPTION

B 87.6/22.1

)

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R164 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 38.4/21.4 R165 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) B 42.5/24.2 R166 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 38.4/6.1 R167 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 37.2/7.5 R168 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 48.7/29.8 R169 7030011650 S.RES ERJ2GEJ 243X (24 k) B 46.7/30.7 R170 7030004980 S.RES ERJ2GEJ 101 X (100) T 53.9/22.6 R171 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 48.3/22.7 R174 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 51.8/25.8 R175 7030009270 S.RES ERJ2GEJ 821 X (820) T 50.9/25.8 R176 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 35.7/8.8 R177 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 53.6/10.5 R178 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 38.7/30.5 R179 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 40.7/25.7 R180 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 39.5/34.2 R181 7030011680 S.RES ERJ2RKF 2703 (270 k) T 21.9/35.4 R182 7030010040 S.RES ERJ2GEJ-JPW B 40.7/24.2 R183 7030007060 S.RES ERJ2GEJ 684X (680 k) B 46.7/27 R184 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 44.5/25.7 R185 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 47.6/28.9 R186 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 48/25.4 R189 7030010040 S.RES ERJ2GEJ-JPW B 91.5/7.3 R190 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 99.8/11.2 R191 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 99/9.1 R192 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 102/9.2 R193 7030004980 S.RES ERJ2GEJ 101 X (100) T 99.5/6.2 R194 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 96.8/7.3 R195 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 95.3/6.9 R196 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 93.8/9.3 R197 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 90.7/11.4 R198 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 89.1/11.4 R199 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 92.2/9.4 R200 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 90.1/8.1 R201 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 62.5/11.4 R202 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 70.2/21.5 R203 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 61/29.9 R204 7030008370 S.RES ERJ2GEJ 561 X (560) T 60.1/29.4 R205 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 59.7/31.5 R206 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 28.2/33.4 R208 7030005240 S.RES ERJ2GEJ 473 X (47 k R209 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 24.6/33.4 R210 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 22.8/33.4 R211 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 25.5/34.9 R212 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 22.1/37.1 R213 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 22.1/38.9 R214 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 22.1/39.9 R215 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 20.5/41.7 R216 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 20.5/40.7 R217 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 41.3/25.7 R219 7030004980 S.RES ERJ2GEJ 101 X (100) T 17.1/30.8 R220 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 39.5/25.7 R221 7410001130 S.ARY EXB28V102JX B 31.3/18.9 R222 7410001130 S.ARY EXB28V102JX T 30.2/20.4 R223 7410001130 S.ARY EXB28V102JX B 29.8/16.3 R225 7410001130 S.ARY EXB28V102JX B 28/14.5 R226 7410001130 S.ARY EXB28V102JX B 26.3/12.7 R227 7410001130 S.ARY EXB28V102JX T 21.3/15.6 R228 7030005000 S.RES ERJ2GEJ 471 X (470) T 103.3/33.9 R229 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 28.7/9.6 R230 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 31.2/5.2 R231 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 102.4/35.6 R233 7410001140 S.ARY EXB28V104JX T 22.2/21.2 R235 7410001130 S.ARY EXB28V102JX B 16.7/15.5 R236 7410001140 S.ARY EXB28V104JX T 23.8/19.2 R237 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 14.8/16.6 R238 7030004980 S.RES ERJ2GEJ 101 X (100) B 12.9/22.3 R239 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.6/26.8 R240 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 33.8/27.1 R242 7410000770 S.ARY EXB-V4V 102JV (1 k) B 33.3/20.6 R243 7030005530 S.RES ERJ2GEJ 100 X (10) T 7.7/28.7 R244 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 6.5/29.1 R245 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 18.6/30.9 R246 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 11.1/33.7 R247 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 10.2/32.1 R248 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 22.1/26.3 R249 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 21.3/24.3 R251 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 27.6/31.9 R252 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 27.9/30.9 R253 7410001140 S.ARY EXB28V104JX T 27.9/28.9 R254 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 27.4/31.7 R255 7410000770 S.ARY EXB-V4V 102JV (1 k) T 25.3/30.9 R256 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 33.1/25.2 R257 7410001130 S.ARY EXB28V102JX B 32.3/28.9 R258 7410001140 S.ARY EXB28V104JX T 33.2/29.6 R259 7410001130 S.ARY EXB28V102JX B 34.1/27.1 R260 7030010040 S.RES ERJ2GEJ-JPW B 29.2/34.9 R261 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 22.8/33.8 R262 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 21.9/33.4 R263 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 25.5/24.2 R264 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 25.5/25.1 R265 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 25.5/26 R266 7030005120 S.RES ERJ2GEJ 102 X (1 k

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

B 26.4/33.4

)

T 21.9/33.8

)

S.=Surface mount

H/V

LOCATION

7 - 3

[MAIN UNIT]

REF ORDER NO. NO.

R267 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 12.9/18.6 R268 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 10.6/24 R272 7030004970 S.RES ERJ2GEJ 470 X (47) T 90/18.9 R273 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 88.7/14.2 R274 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 89.4/17.2 R275 7030004980 S.RES ERJ2GEJ 101 X (100) B 90.3/15.6 R276 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 4/22.8 R277 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.1/21.4 R279 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 22.7/11.3 R280 7510001730 S.TMR ERTJOEP 473J B 58.8/6.9 R281 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 59.2/5.4 R282 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 71.4/21.6 R283 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 35.3/16.7 R284 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 36.3/16.6 R286 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 37.5/14.9 R287 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 28.6/40.9 R288 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 29.2/37.6 R289 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 29.2/39.4 R290 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 28.9/40.7 R291 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 46.8/24.5 R292 7030007270 S.RES ERJ2GEJ 151 X (150) B 88.7/33.3 R293 7030004970 S.RES ERJ2GEJ 470 X (47) B 93.3/21.3 R294 7030007280 S.RES ERJ2GEJ 331 X (330) B 91.4/33 R295 7030005710 S.RES ERJ2GEJ 121 X (120) T 89.9/22.5 R296 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 92.8/15.7 R297 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 91.5/13.9 R298 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 91.3/15.1 R300 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 90.3/14.2 R301 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 104.3/31.5 R302 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 19.5/12.4 R303 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 76.6/41.1 R304 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 75.5/43.6 R305 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 27.6/32.9 R306 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 33/23.1 R307 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 16.8/10.7 R308 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 36.1/28.1 R309 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 25.9/11.3 R310 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 29.7/17.3 R311 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 13.6/27.8 R312 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 15.3/31.2 R313 7030007340 S.RES ERJ2GEJ 153 X (15 k R314 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 10/32 R315 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 10.9/32 R316 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 13.7/12.2 R317 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 12.8/12.2 R318 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 11.9/12.2 R319 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 10.7/17.6 R320 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.6/9.2 R321 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 88.6/20.8 R322 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 87.6/21.1 R323 7030007280 S.RES ERJ2GEJ 331 X (330) T 87.9/23.7 R325 7030007270 S.RES ERJ2GEJ 151 X (150) B 92.1/21.7 R328 7510001730 S.TMR ERTJOEP 473J T 56.1/37.6 R329 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 56.1/35.9 R330 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 55.2/35.9 R331 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 47.2/17.1 R332 7030005010 S.RES ERJ2GEJ 681 X (680) T 51.6/27 R333 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 18.4/14.3 R334 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 23.1/35.8 R335 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 89.8/20.5 R336 7510001730 S.TMR ERTJOEP 473J B 41.6/24.2 R337 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 57.3/7.4 R338 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 34.5/4.9

C1 4030017400 S.CER ECJ0EC1H220J B 54.1/28.2 C2 4030017620 S.CER ECJ0EC1H100C T 57.9/24 C3 4030017430 S.CER ECJ0EC1H101J T 57.9/20.8 C4 4030016930 S.CER ECJ0EB1A104K B 56.6/30.8 C5 4030016790 S.CER ECJ0EB1C103K B 63.5/19.3 C6 4550007080 S.TAN TEESVA 1C 106M8R T 57.9/13.2 C7 4030017460 S.CER ECJ0EB1E102K B 64.4/19.3 C8 4030016790 S.CER ECJ0EB1C103K B 58.4/23.1 C9 4030016790 S.CER ECJ0EB1C103K B 62.6/17.5 C10 4030016930 S.CER ECJ0EB1A104K B 52.8/13.7 C11 4030017420 S.CER ECJ0EC1H470J B 51.1/13.9 C12 4030017420 S.CER ECJ0EC1H470J B 49.9/16.6 C13 4030017420 S.CER ECJ0EC1H470J B 51.3/17 C15 4030017460 S.CER ECJ0EB1E102K B 60.8/13.6 C17 4550000550 S.TAN TEESVA 1V 224M8R B 63.9/25.3 C18 4030016790 S.CER ECJ0EB1C103K B 65.5/19.3 C20 4340000281 S.MLR ECPU1E473KB5 B 65.2/21.9 C21 4030017420 S.CER ECJ0EC1H470J T 67.8/11.8 C22 4030017420 S.CER ECJ0EC1H470J T 67/13.6 C23 4030017420 S.CER ECJ0EC1H470J B 66.4/19.3 C24 4030017390 S.CER ECJ0EC1H180J T 68.9/9.2 C25 4030017510 S.CER ECJ0EC1H680J T 70.8/8.3 C26 4030017570 S.CER ECJ0EC1H040B T 77.3/9 C27 4030017660 S.CER ECJ0EC1H330J T 78.5/8.5 C28 4030017660 S.CER ECJ0EC1H330J T 80.8/9.3 C29 4030017660 S.CER ECJ0EC1H330J T 80.2/13.5 C30 4030016790 S.CER ECJ0EB1C103K T 78.5/11.4

DESCRIPTION

T 6.7/32.9

)

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C31 4030017460 S.CER ECJ0EB1E102K T 78.5/12.3 C32 4030017460 S.CER ECJ0EB1E102K T 74.2/16.9 C33 4030016790 S.CER ECJ0EB1C103K T 74.2/17.8 C34 4030017660 S.CER ECJ0EC1H330J T 74.2/14.5 C35 4030017660 S.CER ECJ0EC1H330J T 75.8/13.6 C36 4030017660 S.CER ECJ0EC1H330J T 77.2/14.1 C37 4030017590 S.CER ECJ0EC1H070C T 73.7/13.2 C38 4030017510 S.CER ECJ0EC1H680J T 69.1/18.5 C39 4030017400 S.CER ECJ0EC1H220J T 67.7/17.2 C40 4030016790 S.CER ECJ0EB1C103K T 80.3/24.8 C41 4030017460 S.CER ECJ0EB1E102K T 79.4/24.8 C42 4030017510 S.CER ECJ0EC1H680J T 76/24.4 C43 4030017390 S.CER ECJ0EC1H180J T 76.4/22.5 C44 4030017660 S.CER ECJ0EC1H330J T 76.3/21 C45 4030017560 S.CER ECJ0EC1H2R5B T 75.4/22.5 C46 4030017340 S.CER ECJ0EC1H010B T 74.2/22.1 C47 4030017400 S.CER ECJ0EC1H220J T 74.2/23.1 C48 4030017440 S.CER ECJ0EC1H221J T 70.4/25.1 C49 4030017360 S.CER ECJ0EC1H030B T 67.7/26.1 C50 4030017360 S.CER ECJ0EC1H030B T 65.5/26.1 C51 4030017570 S.CER ECJ0EC1H040B T 68.4/24 C52 4030017380 S.CER ECJ0EC1H050B T 68.4/23.1 C53 4030017540 S.CER ECJ0EC1HR75B T 80.2/14.5 C54 4030017540 S.CER ECJ0EC1HR75B T 78.4/15.5 C55 4030017530 S.CER ECJ0EC1H0R5B T 78/17.9 C56 4030017420 S.CER ECJ0EC1H470J B 81.7/20.5 C57 4030017460 S.CER ECJ0EB1E102K B 83.7/15.6 C58 4550006250 S.TAN TEESVA 1A 106M8R B 74.1/22.8 C59 4030016790 S.CER ECJ0EB1C103K B 74.4/16.3 C60 4030017460 S.CER ECJ0EB1E102K T 81.8/16.7 C61 4030017730 S.CER ECJ0EB1E471K T 81.7/22.2 C62 4030017620 S.CER ECJ0EC1H100C B 80.3/23.6 C63 4030017460 S.CER ECJ0EB1E102K B 76.6/24.8 C64 4030017560 S.CER ECJ0EC1H2R5B B 75.6/26.4 C65 4030017460 S.CER ECJ0EB1E102K B 81.3/25.2 C66 4030017590 S.CER ECJ0EC1H070C B 80.7/18.7 C67 4030017460 S.CER ECJ0EB1E102K B 85.3/21.8 C68 4030017460 S.CER ECJ0EB1E102K B 85.2/15.4 C69 4030017620 S.CER ECJ0EC1H100C B 86.1/16.6 C117 4030017630 S.CER ECJ0EC1H120J B 99.7/32.2 C118 4030017460 S.CER ECJ0EB1E102K B 101.3/34.6 C119 4030017580 S.CER ECJ0EC1H060C B 98/35.3 C120 4030017580 S.CER ECJ0EC1H060C T 105.5/25 C121 4030017460 S.CER ECJ0EB1E102K T 101.4/24.9 C122 4030017460 S.CER ECJ0EB1E102K T 102.7/20.7 C123 4030017460 S.CER ECJ0EB1E102K T 102.3/23.7 C124 4030017460 S.CER ECJ0EB1E102K B 103.5/21 C125 4030017340 S.CER ECJ0EC1H010B T 105.5/22.2 C126 4030017570 S.CER ECJ0EC1H040B T 103.9/17.5 C127 4030017570 S.CER ECJ0EC1H040B T 103.9/16.6 C129 4030017460 S.CER ECJ0EB1E102K T 99.8/22.7 C130 4030017420 S.CER ECJ0EC1H470J T 99.8/21.7 C131 4030016930 S.CER ECJ0EB1A104K B 97.8/19.8 C132 4030017460 S.CER ECJ0EB1E102K B 101.3/19.8 C133 4030017460 S.CER ECJ0EB1E102K B 104.4/17.4 C134 4030016930 S.CER ECJ0EB1A104K B 97.8/21.4 C135 4030016930 S.CER ECJ0EB1A104K B 97.9/25 C136 4030017460 S.CER ECJ0EB1E102K B 96.6/24.4 C137 4030017490 S.CER C1608 JB 1A 105K-T B 96.6/20.2 C138 4030017460 S.CER ECJ0EB1E102K T 98.6/24 C139 4030017460 S.CER ECJ0EB1E102K B 96.6/25.3 C140 4030017460 S.CER ECJ0EB1E102K T 97.7/18.6 C141 4030017570 S.CER ECJ0EC1H040B T 96.8/18.6 C142 4030017460 S.CER ECJ0EB1E102K T 96.5/20.7 C143 4030017460 S.CER ECJ0EB1E102K T 92.8/20.7 C144 4030017550 S.CER ECJ0EC1H1R5B T 94.3/18.2 C145 4030017460 S.CER ECJ0EB1E102K T 93.3/21.9 C146 4030017460 S.CER ECJ0EB1E102K B 95/24.6 C147 4030017580 S.CER ECJ0EC1H060C T 90.9/18 C148 4030017640 S.CER ECJ0EC1H150J T 90.9/16.4 C161 4030017620 S.CER ECJ0EC1H100C T 87.2/14.9 C162 4030017630 S.CER ECJ0EC1H120J T 86.8/13.4 C163 4030017630 S.CER ECJ0EC1H120J T 87/20 C164 4030017620 S.CER ECJ0EC1H100C T 86.5/18.7 C166 4030017460 S.CER ECJ0EB1E102K T 85.5/14.7 C167 4030017460 S.CER ECJ0EB1E102K B 73.4/26.8 C168 4030017460 S.CER ECJ0EB1E102K T 59.8/15.9 C169 4030017380 S.CER ECJ0EC1H050B B 66/25.1 C170 4030017350 S.CER ECJ0EC1H020B B 67.5/26.4 C171 4030017580 S.CER ECJ0EC1H060C B 69.5/25.8 C172 4030017380 S.CER ECJ0EC1H050B B 68.5/26.4 C173 4030017580 S.CER ECJ0EC1H060C B 70.5/26.4 C174 4030017350 S.CER ECJ0EC1H020B B 71.6/26.4 C177 4030017390 S.CER ECJ0EC1H180J T 87.7/25.7 C177 4030017640 S.CER ECJ0EC1H150J T 87.7/25.7 C180 4030017460 S.CER ECJ0EB1E102K B 87.2/37.8 C181 4030016790 S.CER ECJ0EB1C103K B 86.3/38.7 C182 4030016790 S.CER ECJ0EB1C103K B 90.8/37.4 C183 4030016790 S.CER ECJ0EB1C103K B 81.4/30.6 C184 4030017460 S.CER ECJ0EB1E102K B 81.8/31.9 C185 4550006250 S.TAN TEESVA 1A 106M8R B 77.4/38.4 C186 4030017420 S.CER ECJ0EC1H470J B 78.7/36.6

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

LOCATION

H/V

7 - 4

+ 50 hidden pages

Icom IC-F3062S, IC-F3062T, IC-F3063T, IC-F3063S, IC-F3061S User Manual

INTRODUCTION

TABLE OF CONTENTS

SECTION 1 SPECIFICATIONS

SECTION 2 INSIDE VIEWS

SECTION 3 DISASSEMBLY INSTRUCTIONS

SECTION 4 OPTIONAL UNIT INSTALLATION

SECTION 5 CIRCUIT DESCRIPTION

SECTION 6 ADJUSTMENT PROCEDURES

SECTION 7 PARTS LIST
