Icom IC-2820 service manual



GUIDE FOR CD

1) COMPOSION

IC-E2820 E2820.pdf

FYC E2820_A3format.pdf

E2820_A4format.pdf

E2820_MANUAL.pdf

ar505eng.exe

Installer

README.txt

2) DESCRIPTION

E2820.pdf

The service manual for IC-E2820 including all service information. This document is mainly used for viewing on your computer display

and checking page order to make printed service manual. And, when you have a component you're looking up, you can find it quickly from parts list, schematic and board layouts, using “FIND” function of Acrobat® Reader.

E2820_A3format.pdf

Consists of pages in A3 format (Board layouts, Mechanical parts and disassembly, etc.). This file is used for printing out on A3 paper.

E2820_A4format.pdf

Consists of pages in A4 format (Disassembly instruction, Parts list, Adjustment procedure, etc.). This file is used for printing out A4 format pages.

E2820_MANUAL.pdf

The instruction manuals for IC-E2820. The contents of this document is exactly same as supplied instruction manual with the product. You can print it out to make brand new instruction manual any time you want. This document will be very helpful when you want to change or set product setting or condition for adjustment or else.

1

ar505eng.exe

ar505eng.exe is the installer of Adobe Acrobat® Reader 5.0 (English version) for Microsoft® Windows® 95/98/Me/NT/2000/

XP users.

README.txt

README.txt describes about this service manual for Windows® user that have not had the Acrobat® Reader in his computer

yet.

========================================================================================= Icom, Icom Inc. and Icom logo are registered trademarks of Icom Incorporated (Japan) in the United states, the United Kingdom, Germany, France, Spain, Russia and/or other countries.

Microsoft and Windows are registered trademarks of Microsoft Corporation in the U.S.A. and other countries.

2

DUAL BAND FM TRANSCEVER

iC-e2820

S-14326XZ-C1 Apr. 2007

INTRODUCTION CAUTION

This service manual describes the latest service information for the IC-E2820 DUAL BAND FM TRANSCEVER at the time of publication.

MODEL VERSION

IC-E2820

To upgrade quality, any electrical or mechanical parts and internal circuits are subject to change without notice or obligation.

EUR-01 EUR-02

NEVER connect the transceiver to an AC outlet or to a DC power supply that uses more than 15 V. This will ruin the transceiver.

DO NOT expose the transceiver to rain, snow or any liquids.

DO NOT reverse the polarities of the power supply when

connecting the transceiver.

DO NOT apply an RF signal of more than 20 dBm (100 mW) to the antenna connectors. This could damage the transceiver’ s front end.

ORDERING PARTS

Be sure to include the following four points when ordering replacement parts:

1. 10-digit order numbers

2. Component part number and name

3. Equipment model name and unit name

4. Quantity required

1110003491 S.IC TA31136FNG IC-E2820 MAIN UNIT 5 pieces

8820001210 Screw 2438 screw IC-E2820 Top cover 10 pieces

Addresses are provided on the inside back cover for your convenience.

Icom, Icom Inc. and Kingdom, Germany, France, Spain, Russia and/or other countries.

logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United

REPAIR NOTES

1. Make sure a problem is internal before disassembling the transceiver.

2. DO NOT open the transceiver until the transceiver is disconnected from its power source.

3. DO NOT force any of the variable components. Turn them slowly and smoothly.

4. DO NOT short any circuits or electronic parts. An insulated tuning tool MUST be used for all adjustments.

5. DO NOT keep power ON for a long time when the transceiver is defective.

6. DO NOT transmit power into a signal generator or a sweep generator.

7. ALWAYS connect a 50 dB to 60 dB attenuator between the transceiver and a Modulation Analyzer or spectrum analyzer when using such test equipment.

8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.

CONTENTS

SECTION 1 SPECIFICATIONS

SECTION 2 INSIDE VIEWS

SECTION 3 DISASSEMBLY INSTRUCTIONS

SECTION 4 CIRCUIT DESCRIPITON

4-1 RECEIVER CIRCUITS ............................................................................................................... 4-1

4-2 TRANSMITTER CIRCUITS ....................................................................................................... 4-4

4-3 FREQUENCY SYNTHESIZER .................................................................................................. 4-6

4-4 POWER SUPPLY CIRCUITS ..................................................................................................... 4-8

4-5 PORT ALLOCATIONS ............................................................................................................... 4-9

SECTION 5 ADJUSTMENT PROCEDURES

5-1 PREPARATION .......................................................................................................................... 5-1

5-2 FREQUENCY ADJUSTMENT ................................................................................................... 5-2

5-3 TRANSMIT ADJUSTMENT ....................................................................................................... 5-3

5-4 RECEIVE ADJUSTMENT .......................................................................................................... 5-4

SECTION 6 PARTS LIST

SECTION 7 MECHANICAL PARTS

SECTION 8 BOARD LAYOUTS

SECTION 9 BLOCK DIAGRAM

SECTION 10 VOLTAGE DIAGRAM

SECTION 11 HM-133

SECTION 12 UT-123 (Optional product)

SECTION 1 SPECIFICATIONS

M

•

eVd

E

1

rauG

*

T•

N

•)sllac

•

F

•

O

ep

•

F P

•%51±

•

C

T

eR

•

nA

D

• M × )H(04 × mm )D(7

W•thgie

M

LARENEG

ycneuqerF

1eporu

eporuE 044

2

R

deetna

1 :

641–44

nar zHM

noissime fo epy )

r ycneuqer

iard tnerru

vie

c

sno

isnemi

noitulose

met gnitar

r erutarep

y

tilibats ycneuqer

n

)eviecer suoenatlumis( A 8.1oidua .xam

nia

l

meR × )H(85 ×

lortnoc eto

re

).xorppa( :

tinu nia

l

lortnoc eto

meR

re

:egarevoc

,1*2

*599.945–811 :x

044–034 ,641–441 :xT

–034

,641–441 :xR/xT

2

arauG

* ;.ylno eg

:

D

V

:deetn

MA ,MF

02 .lcni( 225:slennahc yromem fo rebmu

2.6

,5:

:egna

21 ,01 ,5

+ ot C°01–

C°06

mpp5.2±:

CD

.31

V 8

:tnemeriuqer ylppus rewo

:

).xorppa :CD V 8.31 ta(

05

W

tatimsnar

ybdnat

se

)

932-OS:rotcennoc annet

05(Ω

×2 )yti

:

)dedulcni ton .jorp(

)W

(051tinU

)W(051

k 5

g

.1

012

(

g

inu

(

na

B thgiRdnaB tfeLnoisr

1

573 ,

3

59

1–811 :xR

9.

*

7

45–

3

99

*

.999–018

,641–441 :xT

3

* ;zHM044–034

lno evieceR( ,

y

)deriuqer si 321-TU lanoitpo(

nacs

gde

02 ,51 ,5.

31

A

2.1

2 dna se

2 ,

)C°06+ ot C°01–(

sreviD dna xR/xT(

)zHM :t

2

9

*59

.9

,

044–034

d

e

etnaraug toN

zHk

05 ,03 ,5

.781

mm

.13

)D(5

)

elbac noitarapes .lcni

M

ludo

•

M O

•

tu

f .xa

•

M

•

rupS

iM

•

M

ce

•

R I

mretn

•

eS

n

• F

M

VD

•

•yt

S

VD

•noitcejer egami dna suoirupS

•

R

T

IMSNART

E

T

ludo

cnat

y

noi

s

ta

wop

tup

re

r

euqe

me

si

suoi

no

taived ycn

i

snois

:

±

:

enohporc

I

REV

ECER

s

t

s evie

me

y

ide

ta

seicneuqerf e

:

dnab tfeL

r

elbairaV:mets

cae

W 5

/05

/51

zHk0

.5

Hk5.

2±

z

seL:

s

nip-8:rotcennoc

)

.xorppa(

)ediw(

a

n(

)worr

06

– naht

Bd

ludom

(

06

0

Ω

ra

s noisrevnoc-elbuoD:

:

58

t

s1

HM

.83

,zHM53.64 :ts1dnab thgiR

yt

ivitis

DANIS Bd21(

)

)%1 REB( Vµ53.0 na

†

isnes hcleuqS

( :

ytivit

†

ivitcele

(

)ylno sdnab ruetama( :

naht sseL

ht

sseL

deriuqer si 321-TU lanoitpo(

)

h

)dlohser

t

t s

seL

Vµ

1.0

8

nah

Vµ31.0

:)lacipyt

naht eroMediW

k01

seL

worraN

M

aht sseL

e

roM

)deriuqer si 321-TU lanoitpo( Bd05 naht

†

h

†

rewop tuptuo FA

)CD V 8.31 ta(

†

t eroM*

:

M

d

Ω

ol

8

a

Bd06 naht eroM :

a

55 n

4.2 naht ero

ta

W

( 5

.3 rot

cudnoc-3:srotcennoc rekaeps .txE

m )d

a

zHM 641–441 deetnarauG

y

m

cneuqerf e

)

re

repu

teh

054

:dn2 ,z :dn2

zHk zHk054

noi

ta

en

ydo

Bd6/zH

Bd06/zHk03 naht s

Bd6/zHk6 naht ero

Bd06/zHk02 n

o

FHU rof Bd

%01

.dnab tfel n

d

8/m

Ω

na htiw noitrotsi

e

s

nar zHM 044–034 dn

.ylno

g

ceps detats llA

i

ro eciton tuohtiw egnahc ot tcejbus era snoitac

agi

.noit

lbo

1 - 1

SECTION 2 INSIDE VIEWS

• TOP VIEW

D/A converter (IC1: M62364FP)

1st IF Mixer for UHF bands (IC20: SPM5001)

LO filter (763.650−953.640 MHz)

Frequency synthesizer (Right band)

AF switch (IC30: CD4066BPWR)

• BOTTOM VIEW

D/A converter (IC8: M62364FP)

Electric volume (IC33: SM6451B)

D/A converter (IC54: M62364FP)

1st IF Mixer for VHF bands (IC19: SPM5001)

LO divider (79.150−121.150 MHz)

Frequency synthesizer (Left band)

AF filter

(IC48: LM2902PWR) Level converter (IC46: MAX3221IPWR)

AF switch (IC31: CD4066BPWR)

VHF PA module (IC3: S-AV32)

AF power amplifier (IC38: LA4445)

EEPROM (IC22: 24LC512)

CPU (IC25: HD64F2506FC26)

IF IC (Left band RX) (IC15: TA31136FNG)

DTMF decoder (IC56: BU8872FS)

Reference frequency oscillator (Left band)

2 - 1

UHF PA module (IC2: S-AU82L)

IF IC (Right band) (IC18: TA31136FNG)

Reference frequency oscillator (Right band)

SECTION 3 DISASSEMBLY INSTRUCTION

1. Removing the top cover

q Unscrew 10 screws, then remove the top cover.

10 screws

Top cover

w Disconnect the speaker cable.

Speaker cable

3. Removing the MAIN UNIT

q Unscrew 11 screws from the MAIN UNIT.

w Disconnect the cooling fan cable, and unsolder 6 points at

the antenna connectors (grey colored).

6 unsoldering points

Cooling fan cable

2. Removing the bottom cover

q Unscrew 7 screws, then remove the bottom cover.

7 screws

Bottom cover

e Remove the MAIN UNIT in the direction of the arrow.

MAIN UNIT

3 - 1

SECTION 4 CIRCUIT DESCRIPTION

4-1 RECEIVER CIRCUITS

RF CIRCUITS

• 118−174 MHz

The received signals from the antenna connector ANT-1 (J1) are passed through two LPFs (L101, 104, 108, C342, 346; L88, 92, 96, C318, 326, 330), then applied to the RF ampliﬁ er (Q37) via TX/RX switch (D75). The ampliﬁ ed signals are passed through the RX switch (RL2), attenuator (D68) and tuned BPF (D55, 66), before being applied to another RF ampliﬁ er (Q33). The ampliﬁ ed signals are applied to the 1st mixer (IC19) via the another tuned BPF (D41, 44) and RX switch (D38).

While the diversity operation is activated, the received signals are also input from ANT-2 (J2). The received signals are passed through two LPFs (L103, 106, 109, C344, 348; L90, 93, 98, C319, 327, 348), antenna switch (D65, 72) and limitter (D64, 67), then applied to the RF ampliﬁ er (Q39).

The amplified signals are applied to the RX switch (RL2), and gone through the same process as the received signals from ANT-1 (J1).

• 174−260 MHz

The received signals from the antenna connector (J1) are passed through two RX switches (RL3 and D56) and the tuned BPF (D51), then applied to the RF amplifier (Q34). The amplified signals are passed through the BPF (D45), attenuator (R139, 144, 147) and RX switch (D36) before being applied to the 1st mixer (IC19).

• 260−375 MHz

The received signals from the antenna connector (J1) are passed through two RX switches (RL3 and D57) and the tuned BPF (D50), then applied to the RF ampliﬁ er (Q35).

The ampliﬁ ed signals are passed through the BPF (D465), attenuator (R142, 143, 150) and RX switch (D37) before being applied to the 1st mixer (IC19).

• 375−550 MHz

The received signals from the antenna connector (J1) are passed through the LPF (L101, 104, 108, C342, 346) and HPF (L77, 80, C296, 297, 303, 308), then applied to the RF amplifier (Q28) via TX/RX switch (D53, 61, 62). The ampliﬁ ed signals are passed through the RX switch (RL1), attenuator (D28) and tuned BPF (D19, 21, 24, 27), before being applied to another RF ampliﬁ er (Q20). The ampliﬁ ed signals are applied to the 1st mixer (IC19) via the another tuned BPF (D11, 13, 15, 17) and RX switch (D8).

While the diversity operation is activated, the received signals are also input from antenna connector ANT-2 (J2). The received signals are passed through the LPF (L103, 106, 109, C344, 348), HPF (L95, 99, C329, 333, 338), antenna switch (D69, 73, 74) and limitter (D63, 66), then applied to the RF ampliﬁ er (Q29).

The amplified signals are applied to the RX switch (RL1), and gone through the same process as the received signals from ANT-1 (J1).

• RF CIRCUITS

Left band

ight band

D38

RX SW

D35

RX SW

D7

RX SW

D8

RX SW

D44

D41,

BPF

D40,

D43

BPF

D10,

D12,

D14,

D16

BPF

,D13,

D11

D17

D15,

BPF

D36

RX SW

D37

RX SW

118−174 MHz

Q33

RF

AMP

Q32

RF

AMP

118−174 MHz

375−550 MHz

Q19

RF

AMP

375−550 MHz

Q20

RF

AMP

ATT

D55,

D60

BPF

D54,

D58

BPF

D20,

D18,

D23,

D26

BPF

D21,

D19, D24,

D27

BPF ATT

D45

BPF

D46

BPF

D68

ATT

D70

ATT

Q39

Q29

D30

ATT

RL1 Q30 D32

D28

174−260 MHz

Q34

260−375 MHz

Q35

RF AMP

RX SW

RL2 Q38 D76

RX SW

D64,D67

LIMIT

D63,D66

D51

BPF

D50

BPF

Q37

D65,D71,D72

D69,D73,D74

Q28

RF AMP

ANT

SW

D48,D49

LIMIT

D56

D57

RX SW

D78,

LIMIT

D79

LPF

HPF

TX/RX

D53 D61 D62

TX/RX

SW

RL3 Q40 D80

D59 D75 D77

RX SW

ANTENNA

LPF

ANTENNA

HPF

LPF

SW

HPF

810−1000 MHz

ATT

Q23

RF AMP

D9

RX SW

ATT

Q18

RF

AMP

D22

RX SW

HPF

4 - 1

1ST IF CIRCUITS

DEMODULATOR CIRCUITS (Left band)

RX signals from the RF circuits are converted into the 38.85 MHz 1st IF signal by being mixed with LO signals from the left band VCO (Q111, D145−147).

The converted IF signal from the 1st mixer is passed through the IF ﬁ lter (FI5) to be ﬁ ltered. The ﬁ ltered IF signal is applied to the 1st IF ampliﬁ er (Q66) via the limiter (D88). The ampliﬁ ed 1st IF signal is applied to the IF IC (IC15, pin 16)

SQUELCH CIRCUITS

• NOISE SQUELCH

A portion of FM-demodulated AF signals from the IF IC (IC15, pin 9) are level-adjusted by D/A converter (IC8), and passed throuhgh the noise ﬂ tier (IC15 and some R and C) to be ﬁ ltered noise components (30 kHz and above signals) in the AF signals. The ﬁ ltered noise components aree detected in the IC15 and output from pin 13, then applied to the CPU (IC25, pin 100) as “L_SQL” signal.

2ND IF AND DEMODULATOR CIRCUITS (Fig. 2)

IC15 is an IF IC which contains 2nd mixer, limiter ampliﬁ er, noise ampliﬁ er, quadrature detector and RSSI circuit, etc. in its package.

The 1st IF signal from the 1st IF ampliﬁ er (Q66) is converted into the 450 kHz 2nd IF signal by being mixed with tripled reference frequency signal (38.4 MHz) from the PLL IC (IC41) via the tripler (Q105). The converted 2nd IF signal is output from pin 3, and passed through the ceramic filter (FI1 for narrow mode, FI2 for wide mode) to remove sideband noise, then applied to the IF IC from pin 5 again.

• FM DEMODULATOR

The ﬁ ltered 2nd IF signal from pin 5 is ampliﬁ ed at the limiter amplifier, and FM-demodulated at the quadrature detector circuit. The demodulated AF signals are output from pin 9 and routed to the AF circuits via two AF switches (IC11 and IC13).

• AM DEMODULATOR CIRCUITS

In the AM mode, the 2nd IF signal from the FI2 is applied to the AM-demodulator circuit (Q55, Q57). The demodulated AF signals are routed to the AF circuits via two AF switches (IC11 and IC13).

Then the CPU outputs “L_AF_MUTE” signal from pin 82 to the speaker mute switch (Q102), according to the

“L_SQL” signal level. Thus the AF line is connected to the GND to turn the AF output OFF.

• CTCSS/DTCS

CTCSS/DTCS signals in the demodulated AF signals from the AF switch (IC13) are passed through the tone ﬁ lter (Q41) . The ﬁ ltered CTCSS/DTCS signals are applied to the CPU IC25, pin 70) as “L_DTCSIN” signal.

The CPU (IC25) compares the applied signal and the set CTCSS/DTCS, then outputs control signal as same as “NOISE SQUELCH.”

• DTMF

DTMF signals

in the demodulated AF signals from the AF switch (IC13) are passed through two AF switches (IC57 and IC58), then applied to the

DTMF decoder (IC56) to be

decoded.

AF CIRCUITS

The AM/FM-demodulated AF signals from the AF switch (IC11) are passed through the AF filter (Q47). The filtered AF signals are applied to the electric volume (IC33) to be adjusted its level. The level-adjusted AF signals are applied to the dual AF power amplifiier (IC38) to power level, then applied to the internal (CHASSIS; SP1) or an external speaker via external speaker jack (J7).

obtain AF output

• 2ND IF AND DEMODULATOR CIRCUITS (LEFT BAND)

AM DEMODULATOR CIRCUITS

L_R5

R306

to the AF circuits

AM-demodulated AF signals

FM-demodulatedAF signals from the D/A converter (IC8)

C407

AGC voltage to the 1st IF amplifier (Q66)

6

1

R310

R311

4

5

Q55

2

3

R319

R307

NOISE FILTER

R884

C417

R314

R317

R328

C418

C419

R321

R327

C423

6

1

R324

C425

5

2

C422

If an external speaker is connected to the J8, the leveladjusted AF signals from the electric volume (IC33) are applied to the connected speaker.

2nd IF FILTERS

C427

4

3

C426

R335

Q57

C429

R332

8

7

FILIN

FILOUT

R316

C428

DEC

D82

D83

C932

C933

FI1

I O

FI2

I O

38.4 MHz 2nd LO signal from the PLL IC (IC41)

QUADRATURE DETECTOR

X2

R341

1

2

3

4

5

6

VCC

IFIN

OSCIN

OSCOUT

MIXOUT

IF IC (IC15)

R346

C930

C931

D84

D85

C437

R334

FM-demodulated AF signals to the AF circuits

L_SQL L_RSSI

C404

R308

R315

4 - 2

C416

AFOUT

QUAD

9

10

C435

IFO UT

11

RSSI

12

N-REC

N-DET

14

13

GND

MIXIN

16

15

1st IF signal from the 1st IF amplifier(Q66)

RF CIRCUITS

• 118−174 MHz

The received signals from the antenna connector ANT-1 (J1) are passed through two LPFs (L101, 104, 108, C342, 346; L88, 92, 96, C318, 326, 330), then applied to the RF amplifier (Q37) via TX/RX switch (D59). The amplified signals are passed through the attenuator (D70) and tuned BPF (D54, 58), before being applied to another RF ampliﬁ er (Q32). The amplified signals are applied to the 1st mixer (IC20) via the another tuned BPF (D40, 43) and RX switch (D35).

• 375−550 MHz

The received signals from the antenna connector (J1) are passed through the LPF (L101, 104, 108, C342, 346) and HPF (L77, 80, C296, 297, 303, 308), then applied to the RF amplifier (Q28) via TX/RX switch (D53, 61, 62). The amplified signals are passed through the attenuator (D30) and tuned BPF (D18, 20, 23, 26), before being applied to another RF amplifier (Q19). The amplified signals are applied to the 1st mixer (IC20) via the another tuned BPF (D10, 12, 14, 16) and RX switch (D7).

• 810−1000 MHz

The received signals from the ANT-1 (J1) are passed through the HPF (L102, 105, 107, 110, C337, 339, 340, 343, 347, 349) and RX switch (D22), then applied to the RF amplifier (Q23). The amplified signals are passed through the attenuator (R39, 40, 51), and applied to the another RF ampliﬁ er (Q18) to be ampliﬁ ed again. The ampliﬁ ed signals are then passed through another attenuator (R14) and RX switch (D9) before being applied to the 1st mixer (IC20).

1ST IF CIRCUITS

RX signals from the RF circuits are converted into the 46.35 MHz 1st IF signal by being mixed with LO signals from the right band VCO (Q72, D89, 90; Q73, D87, 91, 92).

The converted IF signal from the 1st mixer (IC20) is passed through the IF ﬁ lter (IF6) to be ﬁ ltered. The ﬁ ltered IF signal is applied to the 1st IF ampliﬁ er (Q75) via the limiter (D100). The ampliﬁ ed 1st IF signal is applied to the IF IC (IC18, pin 16)

2ND IF AND DEMODULATOR CIRCUITS

IC15 is an IF IC which contains 2nd mixer, limiter ampliﬁ er, noise ampliﬁ er, quadrature detector and RSSI circuit, etc. in its package.

The 1st IF signal from the 1st IF ampliﬁ er (Q75) is converted into the 450 kHz 2nd IF signal by being mixed with tripled reference frequency signal (45.9 MHz) from the PLL IC (IC14) via the tripler (Q52). The converted 2nd IF signal is output from pin 3, and passed through the ceramic filter (FI3 for narrow mode, FI4 for wide mode) to remove sideband noise, then applied to the IF IC from pin 5 again.

• FM DEMODULATOR

The ﬁ ltered 2nd IF signal from pin 5 is ampliﬁ ed at the limiter amplifier, and FM-demodulated at the quadrature detector circuit (X3). The demodulated AF signals are output from pin 9 and routed to the AF circuits via two AF switches (IC12 and IC16).

• AM DEMODULATOR CIRCUITS

In the AM mode, the 2nd IF signal from the FI3 is applied to the AM-demodulator circuit (Q63, Q67). The demodulated AF signals are routed to the AF circuits via two AF switches (IC12 and IC16).

• DEMODULATOR CIRCUITS (Right band)

R_R5

R351

4

5

6

Q63

1

2

R352

to the AF circuits

AM-demodulated AF signals

FM-demodulatedAF signals from the D/A converter (IC8)

C450

AGC voltage to the 1st IF amplifier (Q75)

3

R358

R359

FM-demodulated AF signals to the AF circuits

C458

R366

C454

AM DEMODULATOR CIRCUITS

R374

R376

180K

Q67

R372

R885

NOISE FILTER

C471

0.01

6

1

R388

R383

R_SQL R_RSSI

C470

5

2

C460

R374

4

3

R385

C475

C476

R397

R375

C477

R402

R389

R400

C480

2nd IF FILTERS

C486

D93

D94

C487

C478

7

8

FILIN

FILOUT

AFOUT

QUAD

9

10

C927

C929

DEC

IFOUT

11

5

6

IFIN

RSSI

12

C491

R_R5

VCC

N-DET

D95

C926

FI3

C928

FI4

C495

R414

45.9 MHz 2nd LO signal from the PLL IC (IC14)

1

2

3

4

OSCIN

OSCOUT

MIXOUT

IF IC (IC18)

N-REC

GND

MIXIN

16

15

14

13

X3

R415

D96

1st IF signal from the 1st IF amplifier(Q75)

R_R5

QUADRATURE DETECTOR

4 - 3

SQUELCH CIRCUITS

• NOISE SQUELCH

A portion of FM-demodulated AF signals from the IF IC (IC18, pin 9) are level-adjusted by D/A converter (IC8), and passed throuhgh the noise ﬂ tier (IC18 and some R and C) to be ﬁ ltered noise components (30 kHz and above signals) in the AF signals. The ﬁ ltered noise components are detected in the IC18 and output from pin 13, then applied to the CPU as “R_SQL” signal.

Then the CPU outputs “R_AF_MUTE” signal from pin 51 to the speaker mute switch (Q102), according to the

“R_SQL” signal level. Thus the AF line is connected to the GND to turn the AF output OFF.

• CTCSS/DTCS

CTCSS/DTCS signals in the demodulated AF signals from the AF switch (IC16) are passed through the tone ﬁ lter (Q42) . The ﬁ ltered CTCSS/DTCS signals are applied to the CPU IC12) as “R_DTCS” signal.

The CPU (IC25) compares the applied signal and the set CTCSS/DTCS, then outputs control signal as same as “NOISE SQUELCH.”

• DTMF

DTMF signals

in the demodulated AF signals from the AF switch (IC16) are passed through two AF switches (IC57 and IC58), then applied to the

DTMF decoder (IC56) to be

decoded.

AF CIRCUITS

The AM/FM-demodulated AF signals from the AF switch (IC12) are passed through the AF filter (Q48). The filtered AF signals are applied to the electric volume (IC33) to be adjusted its level. The level-adjusted AF signals are applied to the dual AF power amplifiier (IC38) to power level, then applied to the an external speaker via external speaker jack (J8).

obtain AF output

4-2 TRANSMITTER CIRCUITS

MICROPHONE AMPLIFIER CIRCUITS

The audio signals from the microphone (MIC signals) are applied to the microphone ampliﬁ er (IC28) via J2 and HPF (Q87). The amplified MIC signals are passed through the microphone gain switch (Q88) and MIC mute switch (IC30), then passed through or by-passed ALC ampliﬁ er (IC32) via AF switches (IC29 and IC52).

The MIC signals from the AF switch (IC52) are passed though the HPF (IC48), LPF (IC48) and AF switch (IC51), and then applied to the AF amplifier (IC48). The amplified MIC signals are applied to the D/A converter (IC8) for level (deviation) adjustment. The level adjusted MIC signals are applied to the VCO as the modulation signals via modulation signal selector.

The modulation signals are applied to the variable capacitor D147 of the left band VCO (Q111, D145–147) via the modulation selector (IC9) and modulation mute switch (Q109), and modulated. The modulated VCO output are ampliﬁ ed by the buffer (Q113) and LO ampliﬁ er (IC44), and applied to the transmit ampliﬁ ers as the TX signal, via the LO switches (D155, 157), LPF(L157, C818, 820) and attenuator (R33, 37, 46).

TRANSMIT POWER AMPLIFIERS

TX signal from the attenuator (R33, 37, 46) is ampliﬁ ed by pre-drive (Q25) and drive (Q27) ampliﬁ ers to obtain RF level for power module (IC3). The ampliﬁ ed TX signal is applied to the power amplifier which is a VHF band PA module composed by two power MOS-FETs. The power-amplified TX signal is passed through the LPF, power detector, antenna switch (D59) and LPF, before being applied to the antenna connector (CHASSIS; J1).

• MICROPHONE AMPLIFIER CIRCUITS

5VS

MIC signals from the microphone

C619

C620

R527

R532

R533

HPF

R537

33K

Q87

C623

R541

R538

C624

C625

R547

R545

R560

R549

Microphone

R562

5

3

1

2

IC28

amplifier

4

C635

C636

MIC_SENC

IC29

1

AF

switch

R566

APC CIRCUITS

A portion of the TX signal from IC3 is rectiﬁ ed at the power detector (D39, D47), and converted into the DC voltage which is in proportion to the RF power, and applied to the operational amplifier (IC4, pin 6). IC4 is an APC amplifier for both of V/UHF bands. The TX power setting voltage “PCON_V” from the D/A converter (IC1, pin 7) is applied to the pin 5 as a reference. IC4 is rolled as a differential amplifier which outputs voltage in inverse proportion to rectified one. When the TX power increased, the rectified voltage also increased, that causes the decrease of output voltage of differential amplifier. The decrease of output voltage of differential ampliﬁ er causes the drop of the gate voltage of IC3, Thus the TX power maintained to keep stable level.

TX muting is carried out by TX mute SW (Q36) controlled by “TX_mute” signal. Applying “TX_mute” signal to the base terminal of Q36 to turn it ON, 8 V DC appears on the pin 6 of IC4 and its output voltage downs to 0 V DC to inactivate IC3.

HPF

IC30

C637

1

MIC

2

R577

C649

R802

AN6123MS

INPUT

3

GND

4

OUTPUT

5

mute switch

C648

R578

DET

VCC

IC32

7

6

switch

R550

Q88

7

6

C644

R801

C645

R574

R575

R804

IC52

C862

1

AF

2

R589

1

C656

R628

R784

C861

R774

C857

R775

C687

R766

C858

HPF

R640

R771

R765

IC48

1 2 3

5 6

7 8

Amplifier

ALC

LPF

R660

R664

C856

R763

C855

R764

R785

C866

IC51

7

1

6

R767

14 13 12

10 9

AF switch

R762

Modulation signals to the modulation circuits

4 - 4

The modulation signals are applied to the variable capacitor D87 of the left band VCO (Q73, D87, 91, 92) via the modulation selector (IC63) and modulation mute switch (Q64), and modulated. The modulated VCO output are ampliﬁ ed by the buffer (Q76) and LO ampliﬁ er (IC45), and applied to the transmit ampliﬁ ers as the TX signal, via the VCO switch (D102). The ampliﬁ ed LO signals are applied to the transmit ampliﬁ ers via the LO switch (D103), two HPFs (L124, C527, 532; L159, C533, 535) and attenuator (R43, 47, 57).

TRANSMIT POWER AMPLIFIERS

TX signal from the attenuator (R43, 47, 57) is ampliﬁ ed by pre-drive (Q22) and drive (Q26) ampliﬁ ers to obtain RF level for power module (IC2). The ampliﬁ ed TX signal is applied to the power amplifier which is a UHF band PA module composed by two power MOS-FETs. The power-amplified TX signal is passed through the LPF, power detector, antenna switch (D62) and LPF, before being applied to the antenna connector (CHASSIS; J1).

• APC CIRCUITS

Q25

PRE PWR DRIVE

TX signal from LO switch (D155, D157)

D29

LIMIT

VT8VT8

Q27

DRIVE AMP

IC3

AMP

HV

RF POWER DETECTOR (VHF)

L46

D39

C161

C164

C157

C155

C162

L56

APC CIRCUITS

A portion of the TX signal from IC2 is rectiﬁ ed at the power detector (D42, 52), and converted into the DC voltage which is in proportion to the RF power, and applied to the operational amplifier (IC4, pin 2). IC4 is an APC amplifier for both of V/UHF bands. The TX power setting voltage “PCON_U” from the D/A converter (IC1, pin 6) is applied to the pin 3 as a reference. IC4 is rolled as a differential amplifier which outputs voltage in inverse proportion to rectified one. When the TX power increased, the rectified voltage also increased, that causes the decrease of output voltage of differential amplifier. The decrease of output voltage of differential ampliﬁ er causes the drop of the gate voltage of IC2, Thus the TX power maintained to keep stable level.

TX muting is carried out by TX mute SW (Q36) controlled by “TX_mute” signal. Applying “TX_mute” signal to the base terminal of Q36 to turn it ON, 8 V DC appears on the pin 6 of IC4 and its output voltage downs to 0 V DC to inactivate IC3.

C314

C318

L88

LPFLPF

C326

L92

L96

C330

C186

R154

C198

C202

C203

C212

D47

C227

C226

R201

D59,D75,D77

TX/RX

SW

TX signal from LO switch (D103)

Q22

PRE PWR DRIVE

D25

LIMIT

UT8UT8

Q26

DRIVE AMP

IC2

AMP

HV

TX_MUTE

L50

C166

PCON_U

C173

C174

IC4,Q31,Q36

C176

APC

CTRL

PCON_V

D42

TX_MUTE

R166

C199

C221

C214

R176

L61

R178

C231

C224

D52

C265

C275

C272

C273

D53,D61,D62

TX/RX

SW

RF POWER DETECTOR (UHF)LPF HPF

C296

L77

C297

C303

L80

C308

L101

LPF

C342

L104

L108

C346

4 - 5

4-3 FREQUENCY SYNTHESIZER

VCOs

This transceiver has 3 VCOs; Left band VCO, Right band RX VCO and Right band TX/RX VCO.

LEFT BAND VCO (Q111, D145–147)

This VCO oscillates 1st LO signals for Left band RX and TX signal for VHF band.

The VCO output signal is ampliﬁ ed by buffer (Q113) and LO amplifier (IC44), and applied to the LO filters according to the RX frequency.

• While Receiving 118–174 MHz signals

LO signals 135.575−255.575 MHz are applied to the divider (IC43) via LO switch (D150) and attenuator (R706, 710,

711), and divided into 271.15−511.15 MHz signals. The divided LO signals are buffer-amplified by Q116, and applied to the left band 1st mixer (IC19) via the LPF (L115, 156, C809, 812, 816) and another LO switch (D156).

RIGHT BAND RX VCO (Q72, D89, 90)

This VCO oscillates 1st LO signals for right band RX (118– 174 MHz and 810–1000 MHz).

The VCO output signal is amplified by buffer (Q74) and applied to the LO amplifier (IC45) via VCO switch (D160), and applied to the LO ﬁ lters according to the RX frequency.

• While Receiving 118–174 MHz signals

LO signals 164.35−220.35 MHz are passed through the LPF (L123, 125, C529, 534, 539) via LO switches (D107, 159), and applied to the right band 1st mixer (IC20).

• While Receiving 810–1000 MHz signals

LO signals 381.825−476.82 MHz are applied to the LO amplifier (IC62) via LO switch (D101). The amplified LO signals are doubled to 763.65−953.64 MHz signals by being passed through the HPF (L130, 133, C554, 558, 560), LPF (L151, C794, 796, 799) and HPF (L135, C563, 568).

The doubled LO signals are applied to the right band 1st mixer (IC20).

• While Receiving 174–260 MHz signals

LO signals 141.15−221.145 MHz are passed through the LPF (L148, 152, C785, 789, 795, 804) via LO switches (D151,

153), and applied to the left band 1st mixer (IC19).

• While Receiving 375–550 MHz signals

LO signals 135.575−255.575 MHz are doubled to 271.15−

511.15 MHz signals, by being passed through the HPF (L149, C787, 790, 791), LPF (L151, C794, 796, 799) and HPF (L153, C800, 807) via LO switches (D152, 154). The doubled LO signals are applied to the left band 1st mixer (IC19).

The VCO output signal is ampliﬁ ed by buffer (Q113) and LO amplifier (IC44), and applied to the transmit amplifiers via the LO switches (D155, 157), LPF(L157, C818, 820) and attenuator (R33, 37, 46).

• VCO CONFIGULATION BY FREQUENCY

LEFT BAND VCO RIGHT BAND RX VCO RIGHT BAND TX/RX VCO

(Q111, D145–147) (Q72, D89, 90) (Q73, D87, 91, 92)

136–174 MHz – 400–470 MHz

Oscillating Frequency

VCO

Components

(118–174 MHz) 135.575−255.575 MHz 164.35−220.35 MHz –

(174–260 MHz) 141.15−221.145 MHz 381.825−476.82 MHz –

RX

(375–550 MHz) 135.575−255.575 MHz – 353.65−523.17 MHz

TX

RIGHT BAND TX/RX VCO (Q73, D87, 91, 92)

This VCO oscillates 1st LO signals for right band RX (375– 550 MHz).

LO signals 353.65−523.17 MHz are passed through the RF mute switch (Q79) and LPF (L131, 134, C562) via LO switches (D104, 108), and applied to the right band 1st mixer (IC20).

The VCO output signal is amplified by buffer (Q76), and applied to the LO amplifier (IC45) via the VCO switch (D102). The ampliﬁ ed LO signals are applied to the transmit ampliﬁ ers via the LO switch (D103), two HPFs (L124, C527, 532; L159, C533, 535) and attenuator (R43, 47, 57).

4 - 6

PLL CIRCUITS

The PLL circuit provides stable oscillation of the transmit frequency and receive 1st LO frequency. The PLL output frequency is controlled by the divided ratio (N-data) from the CPU.

LEFT BAND VCO LOOP

A portion of VCO output signals from the buffer (Q113) are applied to the PLL IC (IC41) via another buffer (Q112). The applied signals are programmable counter according to the control signals (“L_PLLSTB,” “PLLDATA” and "PLLCK”) from the CPU. The divided signal is phase-compared with the 12. 8 MHz reference frequency signal from the reference frequency oscillator (X5), at the phase detector.

LEFT BAND VCO LOOP

•

PLLCK PLLDATA L_PLLSTB

X5

12.8MHz

TCXO

divided at the prescaler and

IC41

PLL

IC

135.575 −255.575 MHz

LOOP

FIL

BUFF

Q112

Q111 D145 D146 D147

BUFF

The phase difference is output from pin 5 as a pulse type signal after being passed through the internal charge pump. The output signal is converted into the DC voltage (lock voltage) by passing through the loop filter (R694, 696– 698, C760–762). The lock voltage is applied to the variable capacitors (D145 and D146), and locked to keep the VCO frequency constant.

If the oscillated signal drifts, its phase changes from that of the reference frequency, causing a lock voltage change to compensate for the drift in the VCO oscillating frequency.

To the TX amplifiers

Q113

AMP

IC44

or LO filters

RIGHT BAND RX VCO LOOP

A portion of VCO output signals from the buffer (Q74) are applied to the PLL IC (IC14) via the VCO switch (D160) and another buffer (Q112). The applied signals are

divided at the prescaler and programmable counter according to the control signals (“R_PLLSTB,” “PLLDATA” and "PLLCK”) from the CPU. The divided signal is phase-compared with the 15.3 MHz reference frequency signal from the reference frequency oscillator (X1), at the phase detector.

The phase difference is output from pin 5 as a pulse type signal after being passed through the internal charge pump. The output signal is converted into the DC voltage (lock voltage) by passing through the loop filter (Q61, 62, D86). The lock voltage is applied to the variable capacitors (D91,

92), and locked to keep the VCO frequency constant.

RIGHT BAND RX AND TX/RX VCO LOOP

•

PLLCK PLLDATA R_PLLSTB

TCXO

IC14

15.3MHz

X1

PLL

IC

Q61 Q62 D86

LOOP

FIL

164.350−220.350 MHz

BUFF

−

523.170 MHz

BUFF

Q76

353.65

Q72 D89 D90

Q73 D91 D92 D87

RIGHT BAND TX/RX VCO

A portion of VCO output signals from the buffer (Q76) are applied to the PLL IC (IC14) via the VCO switch (D102) and another buffer (Q60). The applied signals are at the prescaler and programmable counter according to the control signals (“R_PLLSTB,” “PLLDATA” and "PLLCK”) from the CPU. The divided signal is phase-compared with the 15.3 MHz reference frequency signal from the reference frequency oscillator (X1), at the phase detector.

The phase difference is output from pin 5 as a pulse type signal after being passed through the internal charge pump. The output signal is converted into the DC voltage (lock voltage) by passing through the loop filter (Q61, 62, D86). The lock voltage is applied to the variable capacitors (D91,

92), and locked to keep the VCO frequency constant.

D160

To the TX amplifiers or LO filters

Q74

Q60

VCO

SW

D102

VCO

SW

BUFF

AMP

IC45

divided

4 - 7

4-4 POWER SUPPLY CIRCUITS

Voltage from the power supply is routed to whole of the circuit in the transceiver via switches and regulators.

MAIN UNIT

NOISE FILTER

IC21

5V REG

IC55,

D164

CURRENT DETECT

NOISE

FIL

Q83,

D119

5VS REG

D120

Q84,

5VS REG

HVHVTX power

amplifiers (IC2, IC3)

IDET

CPU5V

CPU (IC25) (for current monitoring)

PLL ICs (IC14, IC41),

5VS

D/A converter (IC8), ALC IC (IC32), etc.

DTMF decoder (IC56),

L5V

Electric volume (IC33), AF mixer (IC59), etc.

CPU (IC25), EEPROM (IC22), Reset IC (IC23), etc.

IC3

+5

REG

+3

REG

+3.2V

5V

CONTROL UNIT

CPU (IC13), Regulator (Q14, Q15), Protector/Buffer (IC12), etc.

Reset IC (IC9), LCD module, etc.

PWR

Q82

PWR

CTRL

Q81

VCC REG

IC24

+8

REG

5V

Limitter (D165−D168), etc.

AF filter (Q47, Q50),

8V

MIC amplifier (IC28), APC controller (IC4), etc.

VCC

AF power amplifier (IC38)

4 - 8

4-5 CPU PORT ALLOCATION

PORT NAME

No.

3

4

5

MM_MUTE

6

7

R_WN_SEL

11

MIC_SENC

17

MOD_DA

MODSEL

18

21

R_PLLSTB

22

L_PLLSTB

23

24

DTCS_SEL

25

26

L_WN_SEL

UMMUTE

27

28

29

L_VCO_SHIFT

30

R_PLLSW

31

R_UNLOCK

32

33

PLLDATA

34

L_UNLOCK

35

VMMUTE

36

37

L_PLLSW

AN

DA_SEL

DCONT

L_AMC

L_R5C

UTX_C

PLLCK

VTX_C

Cut-off frequency shifting signal to the HPF (IC48).

MIC mute signal to the MIC mute switch (IC30). “H”=MIC mute.

ALC amplifier control signal tot the AF switches (IC29 and IC52). “H”=ALC ampliﬁ er ON.

2nd IF filter (Right band; Wide/Narrow) toggling signal. “H”=Narrow. "L”=Wide.

Microphone sensitivity select signal. “H”=High sensitivity.

Modulation line switching signal to the MOD selector (Left band; IC9). “H”=Modulation enable.

Modulation line switching signal to the MOD selector (Right band; IC63). “H”=Modulation enable.

Strobe signal to the PLL IC (Right band; IC14).

Strobe signal to the PLL IC (Left band; IC41).

AM-demodulator circuit (Left band) control signal. “H”=AM mode (AM-modulator circuit is activated).

Tone filter switching signal to the LPF (Q100). “H”=DTCS mode. “L"=CTCSS mode.

RX circuits (Left band) control signal. “H”=RX circuits (Left band) is activated.

2nd IF filter (Wide/Narrow) toggling signal.(Left band) “H”=Narrow. “L”=Wide."

Modulation mute signal to the MOD mute switch (Right band; Q64). “H”=Modulation muted.

Transmitting control signal to the VT8 regulator (Q12, 15).

VCO oscillating frequency shift signal to the Left band VCO.

Lock-up time control signal to the loop ﬁ lter (Right band). “H”=Fast lock-up time.

PLL unlock signal from the PLL IC (Right band; IC14).

Clock signal to the PLL ICs (Right band; IC14, Left band; IC41). (Commonly used for both of the Left and Right bands.)

Data to the PLL ICs (Right band; IC14, Left band; IC41). (Commonly used for both of Left and Right bands.)

PLL unlock signal from the PLL IC (Left band; IC41).

Modulation mute signal to the MOD mute switch (Left band; Q109). “H”=Modulation muted.

Transmitting control signal to the UT8 regulator (Q13, 17). “H”=While transmitting.

Lock-up time control signal to the loop ﬁ lter (left band). “H”=Fast lock-up time.

DESCRIPTION I/O

PORT NAME

No.

O

I

O

I

O

R_UVCO_SEL

38

39

R_VVCO_SEL

40

L_LO_SW

42

R_DA_SEL

42

R_AFFIL_SEL

43

R_DET_MUTE

L_DA_SEL

44

45

L_DET_MUTE

48

51

R_AF_MUTE

L_AFFIL_SEL

52

53

DA2_STB

55

56

57

MIC_SEL

61

62

63

64

65

68

R_DTCS_IN

70

L_DTCS_IN

71

76

77

AF_VOL_CK

78

AF_VOL_DATA

79

AF_VOL_STB

80

AF_VOL_RES

80

82

83

L_AF_MUTE

85

MIC_PTT

D5VC

DA3STB

DTCS

DTMF

DTMSTB

MICUD

R_RSLV

L_RSLV

IDET

TEMP

SCL

PWR

SDA

VCO power control signal to the VCO select switch (Right band UHF; Q65, 68). “L”=Right band TX/RX VCO is activated.

VCO power control signal to the VCO select switch (Right band VHF; Q65, 68). “L”=Right band RX VCO is activated.

LO filter switching signal to the LO regulator (Q106).

AF line switching signal to the AF switch (IC12).

Switching signal to the AF filter (Right band; Q48).

AF line switching signal to the AF switch (IC16). “H”=AF mute.

AF line switching signal to the AF switch (IC11).

AF line switching signal to the AF switch (IC13). “H”=AF mute.

Power control signal for the optional unit. O

AF mute signal to the SP mute switch (Right band; Q101). “H”=AF mute.

Switching signal to the AF ﬁ lter (Left band; Q47).

Strobe signal to the D/A converter. O

Strobe signal to the electric volume. O

DTCS signal. O

DTMF signal. O

Connected microphone detect signal. I

Strobe signal to the DTMF decoder (IC56). -

[UP]/[DWN] key input. I

While receiving; inputs RSSI signal (IC18; Right band). While transmitting; inputs Lock Voltage from the PLL IC (IC14).

While receiving; inputs RSSI signal from IF ICl (IC15; Left band). While transmitting; inputs Lock Voltage from the PLL IC (IC41).

Current level from the current detector (IC55, Q164).

Demodulated DTCS signals from the CTCSS ﬁ lter (Q42).

Demodulated DTCS signals from the CTCSS ﬁ lter (Q41).

Transceiver's internal temparature from the thermal detector circuit (R509).

I/O port for clock signal to the EEPROM (IC22).

Serial clock signal to the electric volume IC.

Data signal to the electric volume IC. O

Latch enable signal to the electric volume IC.

Reset signal to the electric volume IC. O

Power control signal to the PWR controller (Q82). “H”=While the power is ON.

Data signal to the EEPROM (IC22). I/O

AF mute signal to the SP mute switch (Q102).

Input port for [PTT] key on the connected microphone.

DESCRIPTION I/O

O

I

I/O

O

I

4 - 9

No.

100

101

102

105

122

123

127

128

129

130

134

135

136

137

138

143

144

PORT NAME

RESET

L_SQL

CL_SFT2

R_SQL

R_DATA

TX_DATA

TX232

RX232

DA_CK

DA_DATA

DA_STB

R_R5C

R400_S

R_RX800

R_AMC

DTMSD

DTMCK

DESCRIPTION I/O

Reset enable signal input. I

Noise signal from the IF IC (Left band; IC15).

Clock frequency shifting signal. O

Noise signal from the IF IC (Right band; IC18).

Data lines for the control unit. I

Data lines for the control unit. O

Data bus for RS-232C communication. O

Data bus for RS-232C communication. I

Serial clock signal to the D/A converter. O

Serial data to the D/A converter. O

Strobe signal to the D/A converter. O

RX circuits (Right band) control signal. O

Power line control signal to the 375−550 MHz band RF circuit (Right band).

Power line control signal to the 810−1000 MHz band RF circuit (Right band).

AM-demodulator circuit (Right band) control signal.

Data to the DTMF decoder (IC56). -

Clock signal to the DTMF decoder (IC56). -

I

O

4 - 10

SECTION 5 ADJUSTMENT PROCEDURE

5-1 PREPARATION

¤ REQUIRED TEST EQUIPMENTS

When adjusting IC-E2820, following test equipments and JIG cable (modified 8-pin modular jack; see the illust below) are required.

EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE

DC power supply

RF power meter (terminated type)

Frequency counter

Modulation Analyzer

JIG CABLE

¤

Controller

Output voltage : 13.8 V DC Current capacity : More than 20 A Measuring range : 1–100 W Frequency range : 100–600 MHz Impedance : 50

Ω

SWR : Less than 1.2 : 1

Frequency range : 0.1–600 MHz Frequency accuracy : ±1 ppm or better Sensitivity : 100 mV or better

Frequency range : 30–600 MHz Measuring range : DC to ±10 kHz

8-pin modular jack

ytre

i

u

q

w

Audio generator

Standard signal generator (SSG)

AC millivoltmeter Measuring range : 10 mV to 10 V

Terminator

Attenuator

AUDIO GENERATOR

(300–3000 Hz/1–500 mV)

Frequency range : 300–3000 Hz Output level : 1–500 mV

Frequency range : 0.1–1 GHz Output level : 0.1 µV to 32 mV (–127 to –17 dBm)

Impedance : 50 Capacity : More than 100 W

Power attenuation : 40 dB Capacity : More than 100 W

AC MILLIVOLT METER

Frequency Level : 20 mV rms*

+−

80 mV rms*

: 1 kHz

1 2

Ω

(10 mV to 10 V)

+−

Main unit

JIG cable

To t h e MICROPHONE CONNECTOR

ENTERING ADJUSTMENT MODE

¤

q w e r t y u i

8V MICU/D EXTMIC PTT

MICE MIC

GND MICIN

y (MIC)

t (MICE)

w (MICU/D) u (GND)

r (PTT) u (GND)

22 kΩ

33 kΩ

[PTT]

q Connect the JIG cable to the MICROPHONE CONNECTOR (see the illust above). w Push and hold the both of [MAIN•BAND] keys, then turn power ON.

KEY ASSIGNMENTS IN THE ADJUSTMENT MODE

¤

Entering adjustment mode, the function display shows adjustment item and conditions as below.

DUAL BAND TRANSCEIVER

REF

[PWR]

[DIAL] (Right band)

Adjusts the value for the item manually.

D

N

A

B

N

I

A

M

V/MHz SCAN

M/CALL

MW

DUP

MONI

NOTE: This display is example only.

TONE DTMF

LOW

PRIO

M/CALL

MW

V/MHz SCAN

D

N

A

[MAIN•BAND] (Right band)

B

N

I

A

M

• Stores the set value

• Adjusts the value for the item automatically.

[V/MHz•SCAN]

[MAIN•BAND] (Left band)

Selects the next adjustment item.

[M/Call•MW]

Selects the previous adjustment item.

5 - 1

5-2 FREQUENCY ADJUSTMENT

• CONNECTIONS FOR FREQENCY ADJUSTMENT

FREQUENCY COUNTER

(0.1–1 GHz)

Terminator

(50 Ω/100 W)

ADJUSTMENT ADJUSTMENT CONDITIONS OPERATION VALUE

REFERENCE FREQUENCY (Left Band) [L REF]

(Right Band) [R REF]

(Loose coupling)

IC-E2820

To J 1

DC power supply

(13.8 V/20 A)

−

⊕

−

Fuses

20 A

1•

Connect a Terminator to the antenna connector (J1).

•

Loosely couple a Frequency Counter to the antenna connector (J1).

•

Transmitting

2 435.000 MHz

Black Red⊕

Rotate the right band’s [DIAL] to adjust the reference frequency, then push the right band’s [MAIN

•BAND] key.

146.000 MHz

5 - 2

5-3 TRANSMIT ADJUSTMENTS

¤ TRANSMIT OUTPUT POWER ADJUSTMENT

• CONNECTIONS FOR TX POWER ADJUSTMENT

To J 1

RF POWER METER

(100 W/50 Ω)

DC power supply

(13.8 V/20 A)

−

⊕

IC-E2820

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

144 MHz BAND TRANSMIT OUTPUT POWER (HI POWER)

(Band Low) [L PHL]

(Band High) [L PHH]

(MID POWER) (Band

Low) [L PML]

(Band High) [L PMH]

(LOW POWER) (Band

Low) [L PLL]

(Band High) [L PLH]

430 MHz BAND TRANSMIT OUTPUT POWER (HI POWER)

(Band Low) [R PHL]

(Band High) [R PHH]

(MID POWER) (Band

Low) [R PML]

(Band High) [R PMH]

(LOW POWER) (Band

Low) [R PLL]

(Band High) [R PHH]

Fuses

20 A

1••Connect an RF Power Meter to the

antenna connector (J1). Transmitting

2

−

Black Red⊕

Rotate the right band’s [DIAL] to adjust the transmit output power, then push the right band’s [MAIN

•BAND] key during transmit.

50 W

3 15 W

4

5 5 W

6

1••Connect an RF Power Meter to the

antenna connector (J1). Transmitting

2

Rotate the right band’s [DIAL] to adjust the transmit output power, then push the right band’s [MAIN

•BAND] key during transmit.

50 W

3 15 W

4

5 5 W

6

5 - 3

¤ DEVIATION ADJUSTMENT

• CONNECTION FOR MODULATION ADJUSTMENTS

MODULATION ANALYZER

(0.1–1 GHz)

HPF : OFF LPF : 20 kHz De-emphasis : OFF Detector : (P-P)/2

ATTENUATOR

(40 dB/100 W)

To J 1

DC power supply

(13.8 V/20 A)

−

⊕

IC-E2820

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

144 MHz BAND

(Band

Low) DEVIATION (Left Band)

(Band

Center)

(Band

High)

144 MHz BAND

(Band

Low) MODULATION BALANCE (Left Band)

(Band

Center)

(Band

High)

144 MHz BAND DTCS MODULATION (Left Band)

144 MHz CTCSS MODULATION (Left Band)

(FM) [L FMD]

(FM-N) [L FMD]

(FM) [L FMD]

(FM-N) [L FMD]

(FM) [L FMD]

(FM-N) [L FMD]

(FM) [L FMB]

(FM-N) [L FMB]

(FM) [L FMB]

(FM-N) [L FMB]

(FM) [L FMB]

(FM-N) [L FMB]

(FM) [L MDT]

(FM-N) [L MDT]

(FM) [L MCT]

(FM-N) [L MCT]

OSCILLOSCOPE

(DC to 10 kHz)

Connect a Modulation Analyzer to

1•

the antenna connector (J1) through an attenuator.

2 ±2.1 kHz

Connect an Audio Generator to the

• JIG cable (See the page 5-1 for the connector and setting details).

3 ±4.2 kHz

Transmitting

•

Rotate the right band’s [DIAL] to adjust the deviation, then push the right band’s [MAIN•BAND] key during transmit.

Fuses

20 A

−

Black Red⊕

±4.2 kHz

4 ±2.1 kHz

5 ±4.2 kHz

6 ±2.1 kHz

Connect a Modulation Analyzer to

1•

the antenna connector (J1) through an attenuator.

2

Connect an oscilloscope to the de-

• tector terminal of the Modulation Analyzer.

3

No audio signals are applied to the

• JIG cable (See the page 5-1).

4

Transmitting

•

Rotate the right band’s [DIAL] to adjust the wave form, then push the right band’s [MAIN•BAND] key during transmit.

(Square

Wave form)

5

6

Connect a Modulation Analyzer to

1•

the antenna connector (J1) through an attenuator.

2

No audio signals are applied to the

• JIG cable (See the page 5-1). Transmitting

•

Connect a Modulation Analyzer to

1•

the antenna connector (J1) through an attenuator.

2

No audio signals are applied to the

• JIG cable (See the page 5-1). Transmitting

•

Rotate the right band’s [DIAL] to adjust the deviation, then push the right band’s [MAIN•BAND] key.

Rotate the right band’s [DIAL] to adjust the deviation, then push the right band’s [MAIN•BAND] key .

±0.8 kHz

±0.75 kHz

5 - 4

¤ DEVIATION ADJUSTMENT (continued)

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

430 MHz DEVIATION (Right Band)

430 MHz MODULATION BALANCE (Right Band)

430 MHz DTCS MODULATION (Right Band)

430 MHz CTCSS MODULATION (Right Band)

DV MODE DEVIATION* (144 MHz Band)

DV MODE MODULATION BALANCE* (144 MHz Band)

DV MODE DEVIATION* (430 MHz Band)

DV MODE MODULATION BALANCE* (430 MHz Band)

*; Optional UT-123 is required.

(Band Low)

(Band Center)

(Band High)

(Band Low)

(Band Center)

(Band High)

(FM) [R FMD]

(FM-N) [R FMD]

(FM) [R FMD]

(FM-N) [R FMD]

(FM) [R FMD]

(FM-N) [R FMD]

(FM) [R FMB]

(FM-N) [R FMB]

(FM) [R FMB]

(FM-N) [R FMB]

(FM) [R FMB]

(FM-N) [R FMB]

(FM) [R MDT]

(FM-N) [R MDT]

(FM) [R MCT]

(FM-N) [R MCT]

(Band Low)

[L MDS]

(Band Center)

[L MDS]

(Band High)

[L MDS]

(Band Low)

[L MDB]

(Band Center)

[L MDB]

(Band High)

[L MDB]

(Band Low)

[R MDS]

(Band Center)

[R MDS]

(Band High)

[R MDS]

(Band Low)

[R MDB]

(Band Center)

[R MDB]

(Band High)

[R MDB]

1•

Connect a Modulation Analyzer to the antenna connector (J1) through an attenuator.

2 ±2.1 kHz

•

Connect an Audio Generator to the JIG cable (See the page 5-1 for the

•

connector and setting details).

3 ±4.2 kHz

Transmitting

4 ±2.1 kHz

5 ±4.2 kHz

6 ±2.1 kHz

Connect a Modulation Analyzer to

1•

the antenna connector (J1) through an attenuator.

2

No audio signals are applied to the

• JIG cable (See the page 5-1). Transmitting

•

3

4

5

6

1•

Connect a Modulation Analyzer to the antenna connector (J1) through an attenuator.

2

•

No audio signals are applied to the JIG cable (See the page 5-1).

•

Transmitting

Connect a Modulation Analyzer to

1•

the antenna connector (J1) through an attenuator.

2

No audio signals are applied to the

• JIG cable (See the page 5-1). Transmitting

•

1••Connect a Modulation Analyzer to

the antenna connector (J1) through an attenuator.

2

Transmitting

3

1••Connect a Modulation Analyzer to

the antenna connector (J1) through an attenuator.

2

Transmitting

3

1••Connect a Modulation Analyzer to

the antenna connector (J1) through an attenuator.

2

Transmitting

3

1••Connect a Modulation Analyzer to

the antenna connector (J1) through an attenuator.

2

Transmitting

3

Rotate the right band’s [DIAL] to adjust the deviation, then push the right band’s [MAIN•BAND] key during transmit.

Rotate the right band’s [DIAL] to adjust the wave form, then push the right band’s [MAIN•BAND] key during transmit.

Rotate the right band’s [DIAL] to adjust the deviation, then push the right band’s [MAIN•BAND] key.

Rotate the right band’s [DIAL] to adjust the deviation, then push the right band’s [MAIN•BAND] key during transmit.

Rotate the right band’s [DIAL] to adjust the wave form, then push the right band’s [MAIN•BAND] key during transmit.

±4.2 kHz

(Square

Wave form)

±0.8 kHz

±0.75 kHz

±0.9 kHz

Minimum deviation

±1 kHz

Minimum deviation

5 - 5

5-4 RECEIVE ADJUSTMENTS

¤ SENSITIVITY ADJUSTMENT

• CONNECTION FOR RECEIVE SENSITIVITY AND RSSI ADJUSTMENTS

To J 1

• For RX SENSITIVITY ADJ.

Modulation : 1 kHz Deviation : ±3.5 kHz Level : 0 dBµ

STANDARD SIGNAL GENERATOR

(0.1–1 GHz)

DC power supply

(13.8 V/20 A)

−

⊕

IC-E2820

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

SENSITIVITY Connect a Standard Signal Generator to the antenna connector (J1).

118.020 MHz (Left Band) [L LT1]

(Right Band)

1 • Set the SSG as;

Frequency : 118.020 MHz

2

[R LT1]

127.020 MHz (Left Band) [L MT1]

(Right Band)

3 • Set the SSG as;

Frequency : 127.020 MHz

4

[R MT1]

135.980 MHz (Left Band) [L HT1]

(Right Band)

5 • Set the SSG as;

Frequency : 135.980 MHz

6

[R HT1]

136.020 MHz (Left Band) [L LT2]

(Right Band)

7 • Set the SSG as;

Frequency : 136.020 MHz

8

[R LH2]

146.020 MHz (Left Band) [L MT2]

(Right Band)

9 • Set the SSG as;

Frequency : 146.020 MHz

10

[R MT2]

173.980 MHz (Left Band) [L HT2]

(Right Band)

11 • Set the SSG as;

Frequency : 173.980 MHz

12

[R HT2]

174.020 MHz (Left Band) [L LT3]

220.020 MHz (Left Band) [L MT3]

250.020 MHz (Left Band) [L HT3]

260.020 MHz (Left Band) [L LT4]

310.020 MHz (Left Band) [L MT4]

360.020 MHz (Left Band) [L HT4]

13 • Set the SSG as;

Frequency : 174.020 MHz

14 • Set the SSG as;

Frequency : 220.020 MHz

15 • Set the SSG as;

Frequency : 250.020 MHz

16 • Set the SSG as;

Frequency : 260.020 MHz

17 • Set the SSG as;

Frequency : 310.020 MHz

18 • Set the SSG as;

Frequency : 360.020 MHz

Fuses

20 A

−

Black Red⊕

Push the right band’s [MAIN•BAND] key.

(Automatic

adjustment)

5 - 6

¤ SENSITIVITY ADJUSTMENT (continued)

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

SENSITIVITY 375.020 MHz (Left Band)

[L LT5]

(Right Band) [R LT5]

399.980 MHz (Left Band) [L HT5]

(Right Band) [R HT5]

400.020 MHz (Left Band) [L LT6]

(Right Band) [R LT6]

440.020 MHz (Left Band) [L MT6]

(Right Band) [R MT6]

449.980 MHz (Left Band) [L HT6]

(Right Band) [R HT6]

450.020 MHz (Left Band) [L LT7]

(Right Band) [R LT7]

500.020 MHz (Left Band) [L MT7]

(Right Band) [R MT7]

549.980 MHz (Left Band) [L HT7]

(Right Band) [R HT7]

19 • Set the SSG as;

20

21 • Set the SSG as;

22

23 • Set the SSG as;

24

25 • Set the SSG as;

26

27 • Set the SSG as;

28

29 • Set the SSG as;

30

31 • Set the SSG as;

32

33 • Set the SSG as;

34

Frequency : 375.020 MHz

Frequency : 399.980 MHz

Frequency : 400.020 MHz

Frequency : 440.020 MHz

Frequency : 449.980 MHz

Frequency : 450.020 MHz

Frequency : 500.020 MHz

Frequency : 549.980 MHz

Push the right band’s [MAIN•BAND] key.

(Automatic

adjustment)

5 - 7

¤ S-METER ADJUSTMENT

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

S-METER Connect a Standard Signal Generator to the antenna connector (J1).

127.020 MHz

(S3 level)

(Full scale) (Left Band)

146.020 MHz

(S3 level)

(Full scale) (Left Band)

220.020 MHz

(S3 level)

(Full scale) (Left Band)

300.020 MHz

(S3 level)

(Full scale) (Left Band)

387.020 MHz

(S3 level)

(Full scale) (Left Band)

435.020 MHz

(S3 level)

(Full scale) (Left Band)

500.020 MHz

(S3 level)

(Full scale) (Left Band)

910.020 MHz

(S3 level)

(Full scale) (Right Band)

(Left Band) [L S31]

(Right Band) [R S31]

[L SF1]

(Right Band) [R SF1]

(Left Band) [L S32]

(Right Band) [R S32]

[L SF2]

(Right Band) [R SF2]

(Left Band) [L S33]

[L SF3]

(Left Band) [L S34]

[L SF4]

(Left Band) [L S35]

(Right Band) [R S35]

[L SF5]

(Right Band) [R SF5]

(Left Band) [L S36]

(Right Band) [R S36]

[L SF6]

(Right Band) [R SF6]

(Left Band) [L S37]

(Right Band) [R S37]

[L SF7]

(Right Band) [R SF7]

(Left Band) [R S38]

[R SF8]

1 • Set the SSG as;

Frequency : 127.020 MHz Level : −1 dBµ

2

3 • Set the SSG as;

Level : +15 dBµ

4

5 • Set the SSG as;

Frequency : 146.020 MHz Level : −1 dBµ

6

7 • Set the SSG as;

Level : +15 dBµ

8

9 • Set the SSG as;

Frequency : 220.020 MHz Level : −1 dBµ

10 • Set the SSG as;

Level : +15 dBµ

11 • Set the SSG as;

Frequency : 300.020 MHz Level : −1 dBµ

12 • Set the SSG as;

Level : +15 dBµ

13 • Set the SSG as;

Frequency : 387.020 MHz Level : −1 dBµ

14

15 • Set the SSG as;

Level : +15 dBµ

16

17 • Set the SSG as;

Frequency : 435.020 MHz Level : −1 dBµ

18

19 • Set the SSG as;

Level : +15 dBµ

20

21 • Set the SSG as;

Frequency : 500.020 MHz Level : −1 dBµ

22

23 • Set the SSG as;

Level : +15 dBµ

24

25 • Set the SSG as;

Frequency : 910.020 MHz Level : −1 dBµ

26 • Set the SSG as;

Level : +15 dBµ

Push the right band’s [MAIN•BAND] key.

(Automatic

adjustment)

5 - 8

¤ SQUELCH ADJUSTMENT

• CONNECTION FOR SQUELCH ADJUSTMENT

To J 1

TERMINATOR

(50 Ω/100 W)

ADJUSTMENT ITEM OPERATION VALUE

SQUELCH Connect a Terminator (50 Ω) to the antenna connector (J1).

127.020 MHz (FM)

[L SQ1]

(FM) [R SQ1]

(FM-N) [L SQ1]

(FM-N) [R SQ1]

146.020 MHz (FM)

[L SQ2]

(FM) [R SQ2]

(FM-N) [L SQ2]

(FM-N) [R SQ2]

220.020 MHz (FM)

[L SQ3]

(FM-N) [L SQ3]

300.020 MHz (FM)

[L SQ4]

(FM-N) [L SQ4]

387.020 MHz (FM)

[L SQ5]

(FM) [R SQ5]

(FM-N) [L SQ5]

(FM-N) [R SQ5]

440.020 MHz (FM)

[L SQ6]

(FM) [R SQ6]

(FM-N) [L SQ6]

(FM-N) [R SQ6]

1

2

3

4

5

6

7

8

9

10

Push the right band’s [MAIN•BAND] key.

11

12

13

14

15

16

17

18

19

20

DC power supply

(13.8 V/20 A)

−

⊕

Fuses

20 A

IC-E2820

−

Black Red⊕

(Automatic

adjustment)

5 - 9

¤ SQUELCH ADJUSTMENT (continued)

ADJUSTMENT ITEM OPERATION VALUE

SQUELCH 500.020 MHz (FM)

21

[L SQ7]

(FM)

22

[R SQ7]

(FM-N)

23

[L SQ7]

(FM-N)

24

[R SQ7]

910.020 MHz (FM)

25

[R SQ8]

(FM-N)

26

[R SQ8]

¤ DIVERSITY ADJUSTMENT

• CONNECTION FOR DIVERSITY ADJUSTMENT

STANDARD SIGNAL GENERATOR (1)

(0.1–1 GHz)

Push the [MAIN•BAND] key.

(Automatic

adjustment)

STANDARD SIGNAL GENERATOR (2)

(0.1–1 GHz)

To J1

To J 2

DC power supply

(13.8 V/20 A)

−

Fuses

20 A

⊕

IC-E2820

−

Black Red⊕

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

DIVERSITY Connect a Standard Signal Generator to each antenna connector (J1 and J2) independently.

127.020 MHz

(S0 level)

(Left Band) [L DL1]

(Right Band)

1 Set the SSG as;

Frequency : 127.020 MHz Level : −6 dBµ

2

[R DL1]

(S3 level) (Left Band)

[L DM1]

(Right Band) [R DM1]

(Full scale) (Left Band)

[L DH1]

3 Set the SSG as;

Level : −1 dBµ

4

5 Set the SSG as;

Level : +15 dBµ

Push the right band’s [MAIN• BAND] key.

(Automatic

adjustment)

(Right Band) [R DH1]

6

5 - 10

¤ DIVERSITY ADJUSTMENT (continued)

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE

DIVERSITY 145.020 MHz

(S0 level)

(S3 level) (Left Band)

(Full scale) (Left Band)

387.020 MHz

(S0 level)

(S3 level) (Left Band)

(Full scale) (Left Band)

435.020 MHz

(S0 level)

(S3 level) (Left Band)

(Full scale) (Left Band)

500.020 MHz

(S0 level)

(S3 level) (Left Band)

(Full scale) (Left Band)

(Left Band) [L DL2]

(Right Band) [R DL2]

[L DM2]

(Right Band) [R DM2]

[L DH2]

(Right Band) [R DH2]

(Left Band) [L DL5]

(Right Band) [R DL5]

[L DM5]

(Right Band) [R DM5]

[L DH5]

(Right Band) [R DH5]

(Left Band) [L DL6]

(Right Band) [R DL6]

[L DM6]

(Right Band) [R DM6]

[L DH6]

(Right Band) [R DH6]

(Left Band) [L DL7]

(Right Band) [R DL7]

[L DM7]

(Right Band) [R DM7]

[L DH7]

(Right Band) [R DH7]

1 • Set the SSG as;

Frequency : 145.020 MHz Level : −6 dBµ

2

3 • Set the SSG as;

Level : −1 dBµ

4

5 • Set the SSG as;

Level : +15 dBµ

6

1 • Set the SSG as;

Frequency : 387.020 MHz Level : −6 dBµ

2

3 • Set the SSG as;

Level : −1 dBµ

4

5 • Set the SSG as;

Level : +15 dBµ

6

1 • Set the SSG as;

Frequency : 435.020 MHz Level : −6 dBµ

2

3 • Set the SSG as;

Level : −1 dBµ

4

5 • Set the SSG as;

Level : +15 dBµ

6

1 • Set the SSG as;

Frequency : 500.020 MHz Level : −6 dBµ

2

3 • Set the SSG as;

Level : −1 dBµ

4

5 • Set the SSG as;

Level : +15 dBµ

6

Push the right band’s [MAIN• BAND] key.

(Automatic

adjustment)

5 - 11

SECTION 6 PARTS LIST

[CONTROL UNIT]

REF ORDER NO. NO.

IC3 1180000421 S.IC TA78L05F (TE12R,F) B 29.7/14.1 IC6 1180002371 S.REG R1111N321B-TR-F B 42.4/18.8 IC9 1110005991 S.IC S-80945CNMC-G9F-T2G B 35.8/18.5 IC10 1110006380 S.IC LM2904PWR B 111.3/23.3 IC12 1130003831 S.IC TC7S04F (TE85R,F) B 32.2/23.2 IC13 1140014060 S.IC M30620FCPGP [EUR-01] B 70.4/20.8 1140014190 S.IC M30622MAP-434GP [EUR-02] B 70.4/20.8 IC14 1130007111 S.IC TC7W04FU (TE12L,F) B 60.3/40.1

Q1 1530003990 S.TR 2SC4738-BL (TE85L,F) B 116.5/13.1 Q3 1520000201 S.TR 2SB798-T2-AZ DK B 120.6/16.8 Q14 1530003990 S.TR 2SC4738-BL (TE85L,F) B 98.2/9.9 Q15 1510000771 S.TR 2SA1586-GR (TE85R,F) B 98.2/14 Q16 1530003990 S.TR 2SC4738-BL (TE85L,F) B 43/47.5 Q17 1530003990 S.TR 2SC4738-BL (TE85L,F) B 39.1/47.5 Q18 1530003990 S.TR 2SC4738-BL (TE85L,F) B 55.4/47.5 Q19 1530003990 S.TR 2SC4738-BL (TE85L,F) B 51.5/47.5 Q20 1530003990 S.TR 2SC4738-BL (TE85L,F) B 67.8/47.5 Q21 1530003990 S.TR 2SC4738-BL (TE85L,F) B 63.9/47.5 Q22 1530003990 S.TR 2SC4738-BL (TE85L,F) B 80.2/47.5 Q23 1530003990 S.TR 2SC4738-BL (TE85L,F) B 76.3/47.5 Q24 1530003990 S.TR 2SC4738-BL (TE85L,F) B 92.6/47.5 Q25 1530003990 S.TR 2SC4738-BL (TE85L,F) B 88.7/47.5 Q26 1530003990 S.TR 2SC4738-BL (TE85L,F) B 105/47.5 Q27 1530003990 S.TR 2SC4738-BL (TE85L,F) B 101.1/47.5 Q28 1530003990 S.TR 2SC4738-BL (TE85L,F) B 117.4/47.5 Q29 1530003990 S.TR 2SC4738-BL (TE85L,F) B 113.5/47.5 Q31 1530003990 S.TR 2SC4738-BL (TE85L,F) B 35.4/21.5

D4 1790001140 S.ZEN MA8039-L (TX) B 40.2/23.6 D8 1750000940 S.DIO ISS400 TE61 B 37/27.1 D9 1750000940 S.DIO ISS400 TE61 B 35.6/25.4 D10 1750000940 S.DIO ISS400 TE61 B 27.9/24.9 D11 1750000940 S.DIO ISS400 TE61 B 27.9/21.7 D12 1790001170 S.ZEN MA8068-M (TX) B 120.5/12.5 D20 1730002670 S.ZEN MA8130-M (TX) B 98.1/23.8 D21 1790001561 S.DIO 1SS372 (TE85R,F) B 63.4/39.7 D22 1790001561 S.DIO 1SS372 (TE85R,F) B 65.9/39.7 D23 1790001561 S.DIO 1SS372 (TE85R,F) B 68.4/39.7 D24 1790001561 S.DIO 1SS372 (TE85R,F) B 67.7/35.1

X1 6050012500 S.XTL CR-839 (FTX12.288M16SM) B 54.6/12.5

L1 6200003640 S.COL MLF1608E 100K-T B 59.5/45.6

R2 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 27.5/35.1 R4 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 116.3/35.3 R6 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 25.1/35.1 R8 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 118.7/35.3 R13 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 110.5/14.3 R14 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 14.6/32.9 R21 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 113.4/14.3 R22 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 118.1/19.8 R24 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 25.5/24.7 R25 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 25.8/22.5 R41 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 58.4/8.6 R72 7410001220 S.ARY EXB28V103JX B 53.2/18.7 R76 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 96/10.6 R77 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 98.2/11.6 R78 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 16.1/32.4 R83 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 30.7/18.6 R122 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 64.2/10.4 R123 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 63.3/10.4 R125 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 73.6/9.4 R126 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 72.7/9.4 R127 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 71.8/9.4 R128 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 68.7/8.8 R129 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 67.8/8.8 R130 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 66.9/7.5 R131 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 66/7.5 R132 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 65.1/8.8 R133 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 43.5/45.4 R134 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 39.6/45.4 R135 7030003420 S.RES ERJ3GEYJ 681 V (680) B 42.3/44.9 R136 7030003420 S.RES ERJ3GEYJ 681 V (680) B 38.4/44.9 R137 7030003390 S.RES ERJ3GEYJ 391 V (390) B 114.5/8.4 R138 7030005010 S.RES ERJ2GEJ 681 X (680) B 76.1/6.7 R139 7030005010 S.RES ERJ2GEJ 681 X (680) B 48.9/8.1 R140 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 55.9/45.4 R141 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 52/45.4 R142 7030003420 S.RES ERJ3GEYJ 681 V (680) B 54.7/44.9 R143 7030003420 S.RES ERJ3GEYJ 681 V (680) B 50.8/44.9 R144 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 68.3/45.4 R145 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 64.4/45.4 R146 7030003420 S.RES ERJ3GEYJ 681 V (680) B 67.1/44.9 R147 7030003420 S.RES ERJ3GEYJ 681 V (680) B 63.2/44.9 R148 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 80.7/45.4 R149 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 76.8/45.4 R150 7030003420 S.RES ERJ3GEYJ 681 V (680) B 79.5/44.9 R151 7030003420 S.RES ERJ3GEYJ 681 V (680) B 75.6/44.9 R152 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 93.1/45.4 R153 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 89.2/45.4 R154 7030003420 S.RES ERJ3GEYJ 681 V (680) B 91.9/44.9

DESCRIPTION

M.

H/V

LOCATION

[CONTROL UNIT]

REF ORDER NO. NO.

R155 7030003420 S.RES ERJ3GEYJ 681 V (680) B 88/44.9 R156 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 105.5/45.4 R157 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 101.6/45.4 R158 7030003420 S.RES ERJ3GEYJ 681 V (680) B 104.3/44.9 R159 7030003420 S.RES ERJ3GEYJ 681 V (680) B 100.4/44.9 R160 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 117.9/45.4 R161 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 114/45.4 R162 7030003420 S.RES ERJ3GEYJ 681 V (680) B 116.7/44.9 R163 7030003420 S.RES ERJ3GEYJ 681 V (680) B 112.8/44.9 R168 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 34.7/23.7 R169 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 24/24.3 R170 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 101.5/20.6 R171 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 111.9/18.4 R172 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 111.4/16.6 R173 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 111.4/28.3 R174 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 111/30 R175 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 101.5/21.8 R176 7030004980 S.RES ERJ2GEJ 101 X (100) B 115.7/40.6 R177 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 100/11.2 R178 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 98.2/8.1 R179 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 37.8/22 R180 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 36.5/23.3 R187 7030010040 S.RES ERJ2GEJ-JPW B 63.2/13 R188 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 141.3/22.1 R189 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 9.8/30.8 R190 7410001130 S.ARY EXB28V102JX B 80.2/25.3 R191 7410001130 S.ARY EXB28V102JX B 82.2/18.5 R192 7410001130 S.ARY EXB28V102JX B 63.5/30.2 R195 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 78/27.5 R196 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 62.9/14.9 R198 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 58.1/23 R199 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 58/25 R200 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 58/25.9 R201 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 58.3/26.8 R202 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 58.3/27.7 R203 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 60.9/27.3 R204 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 60.9/25.5 R205 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 61.3/30.6 R206 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 62.8/28.4 R207 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 92.2/12.6 R208 7410001140 S.ARY EXB28V104JX B 98.6/26.8 R209 7410001140 S.ARY EXB28V104JX B 101/28.9 R210 7410001140 S.ARY EXB28V104JX B 81.7/16 R211 7410001140 S.ARY EXB28V104JX B 81.4/13.3 R212 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 59.3/29.1 R213 7030010040 S.RES ERJ2GEJ-JPW B 65.4/29.5 R216 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 54.9/26.7 R218 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 68.4/32.9 R219 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 59/43.4 R220 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 56.3/24.7

C1 4030016930 S.CER ECJ0EB1A104K B 27.9/36.9 C2 4030016930 S.CER ECJ0EB1A104K B 115.7/36.9 C3 4030016930 S.CER ECJ0EB1A104K B 25.6/36.9 C4 4030016930 S.CER ECJ0EB1A104K B 118.2/36.9 C5 4030017430 S.CER ECJ0EC1H101J B 108.3/14.3 C7 4030017420 S.CER ECJ0EC1H470J B 22.8/24.3 C8 4510008540 S.ELE EEE1CA100SR B 111/10.7 C10 4030017420 S.CER ECJ0EC1H470J B 24.2/22 C16 4030018910 S.CER C1608 JB 0J 475K-T B 75/10.7 C24 4510008500 S.ELE EEE1CA101WP B 38.5/11.7 C25 4030016790 S.CER ECJ0EB1C103K B 28.4/10.6 C26 4030017040 S.CER ECJ0EB1A333K B 38.6/18 C27 4030017460 S.CER ECJ0EB1E102K B 28.4/17.6 C28 4510008800 S.ELE EEE1EA100SR B 22.3/17 C29 4030017460 S.CER ECJ0EB1E102K B 18.2/17.8 C30 4030017420 S.CER ECJ0EC1H470J B 15.6/30.1 C31 4030017420 S.CER ECJ0EC1H470J B 15.6/27.8 C34 4030016790 S.CER ECJ0EB1C103K B 76.2/29.2 C42 4030017460 S.CER ECJ0EB1E102K B 58.3/16.1 C43 4030017460 S.CER ECJ0EB1E102K B 59.8/15.7 C44 4030017460 S.CER ECJ0EB1E102K B 55.3/16.1 C45 4030017460 S.CER ECJ0EB1E102K B 56.7/15.7 C46 4030016790 S.CER ECJ0EB1C103K B 18.4/10.5 C47 4030016790 S.CER ECJ0EB1C103K B 123.9/12.3 C48 4030016930 S.CER ECJ0EB1A104K B 100.2/14.4 C50 4030016790 S.CER ECJ0EB1C103K B 40.7/25.4 C51 4030016790 S.CER ECJ0EB1C103K B 61.1/14.5 C54 4510008660 S.ELE EEE0JA220SR B 48.5/18.9 C55 4510008660 S.ELE EEE0JA220SR B 104.3/12.2 C56 4510008540 S.ELE EEE1CA100SR B 45/12.1 C57 4550006840 S.TAN TEESVA 1E 225M8R B 90.5/25.2 C59 4550006840 S.TAN TEESVA 1E 225M8R B 95.1/25.2 C60 4550000550 S.TAN TEESVA 1V 224M8R B 83.4/25.1 C61 4550000550 S.TAN TEESVA 1V 224M8R B 72.5/32.7 C62 4550000550 S.TAN TEESVA 1V 224M8R B 72.7/34.8 C63 4550000550 S.TAN TEESVA 1V 224M8R B 72.7/36.9 C64 4550000550 S.TAN TEESVA 1V 224M8R B 72.6/39 C65 4030018860 S.CER ECJ0EB0J105K B 96.8/26.2 C66 4030018860 S.CER ECJ0EB0J105K B 49.8/30.1 C67 4030016790 S.CER ECJ0EB1C103K B 41.8/16.2 C68 4030016790 S.CER ECJ0EB1C103K B 44.8/18.5 C69 4030016790 S.CER ECJ0EB1C103K B 29.6/23.7 C70 4030017460 S.CER ECJ0EB1E102K B 17.7/31.9 C71 4510008550 S.ELE EEE1HA010SR B 104.8/18.3 C72 4510008550 S.ELE EEE1HA010SR B 104.7/23.9 C74 4030016790 S.CER ECJ0EB1C103K B 113.5/26.7

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 1

M.

S.=Surface mount

H/V

LOCATION

[CONTROL UNIT]

REF ORDER NO. NO.

C86 4030016790 S.CER ECJ0EB1C103K B 22.1/26 C87 4030016790 S.CER ECJ0EB1C103K B 116.1/25.4 C95 4550006840 S.TAN TEESVA 1E 225M8R B 52.3/24.5 C101 4550006840 S.TAN TEESVA 1E 225M8R B 93/25.2 C102 4550006840 S.TAN TEESVA 1E 225M8R B 88.3/25.2 C104 4030016790 S.CER ECJ0EB1C103K B 118.1/21 C105 4030017460 S.CER ECJ0EB1E102K B 33.4/19 C106 4030016930 S.CER ECJ0EB1A104K B 76.2/28.3 C107 4030016930 S.CER ECJ0EB1A104K B 62/14.5 C108 4030016790 S.CER ECJ0EB1C103K B 60.9/28.5 C109 4030017660 S.CER ECJ0EC1H330J B 61.4/8.3 C110 4030017660 S.CER ECJ0EC1H330J B 61.4/9.2 C111 4550006840 S.TAN TEESVA 1E 225M8R B 85.7/25.2 C113 4030017330 S.CER ECJ0EF1C104Z B 63.4/41.5 C114 4030017330 S.CER ECJ0EF1C104Z B 65.9/41.5 C115 4030017330 S.CER ECJ0EF1C104Z B 68.4/41.5 C116 4030017330 S.CER ECJ0EF1C104Z B 69.2/37.2 C117 4030017330 S.CER ECJ0EF1C104Z B 62.5/37.8 C118 4030017330 S.CER ECJ0EF1C104Z B 64.7/37.8 C119 4030017330 S.CER ECJ0EF1C104Z B 68/37.8 C120 4030017330 S.CER ECJ0EF1C104Z B 66/36.6 C121 4030017490 S.CER C1608 JB 1A 105K-T B 59.5/44.4 C122 4030017490 S.CER C1608 JB 1A 105K-T B 61.3/44.1

J3 6510025760 S.CNR B5B-ZR-SM4-TF (LF) (SN) B 119.6/29.1 J4 6510025760 S.CNR B5B-ZR-SM4-TF (LF) (SN) B 24.6/29.1 J5 6510025730 CNR HJC0187-010024 J7 6510025830 S.CNR 04-6240-034-001-800 B 92.9/34.6 J8 6510025830 S.CNR 04-6240-034-001-800 B 48.1/34.6 J9 6510016381 S.CNR 52465-1071

DS1 5030003040 LCD M6-0103TRM-5 DS21 5040002930 S.LED SML-512MW T86 T 33/6.7 DS22 5040002930 S.LED SML-512MW T86 T 137.1/30 DS23 5040002930 S.LED SML-512MW T86 T 137.1/23.4 DS24 5040002930 S.LED SML-512MW T86 T 59/6.7 DS25 5040002930 S.LED SML-512MW T86 T 72/6.7 DS26 5040002930 S.LED SML-512MW T86 T 46/6.7 DS27 5040002930 S.LED SML-512MW T86 T 85/6.7 DS28 5040002930 S.LED SML-512MW T86 T 98/6.7 DS29 5040002930 S.LED SML-512MW T86 T 111/6.7 DS31 5040003260 S.LED FAMG1211F-TR T 34.8/48 DS32 5040003260 S.LED FAMG1211F-TR T 47.2/48 DS33 5040003260 S.LED FAMG1211F-TR T 59.6/48 DS34 5040003260 S.LED FAMG1211F-TR T 72/48 DS35 5040003260 S.LED FAMG1211F-TR T 84.4/48 DS36 5040003260 S.LED FAMG1211F-TR T 96.8/48 DS37 5040003260 S.LED FAMG1211F-TR T 109.2/48 DS38 5040002930 S.LED SML-512MW T86 T 6.9/23.4 DS39 5040002930 S.LED SML-512MW T86 T 6.9/30

S5 2260001890 S.SW SKQDPA T 33/3.2 S6 2260001890 S.SW SKQDPA T 46/3.2 S7 2260001890 S.SW SKQDPA T 98/3.2 S8 2260001890 S.SW SKQDPA T 111/3.2 S10 2260001890 S.SW SKQDPA T 137.1/26.7 S11 2260001890 S.SW SKQDPA T 59/3.2 S12 2260001890 S.SW SKQDPA T 72/3.2 S13 2260001890 S.SW SKQDPA T 85/3.2 S14 2260001890 S.SW SKQDPA T 6.9/26.7 S15 2250000570 ECR SW-169 (EC09E1524405) S16 2250000570 ECR SW-169 (EC09E1524405)

EP9 6910012350 S.BEA MMZ1608Y 102BT B 16/17.3 EP10 6910012350 S.BEA MMZ1608Y 102BT B 15.3/26.6 EP11 6910012350 S.BEA MMZ1608Y 102BT B 15.3/29 EP12 6910012350 S.BEA MMZ1608Y 102BT B 15.3/31.3

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

IC1 1110004310 S.IC M62352GP 75EC T 25/108.5 IC2 1150002121 IC S-AU82L (I,Q) IC3 1150002161 IC S-AV32 (I2 Q) IC4 1110004050 S.IC NJM3404AV-TE1-#FMZB B 39.8/107.5 IC8 1190000350 S.IC M62363FP-650C T 52.5/24.3 IC9 1130007021 S.IC TC7S66FU (TE85L,F) B 73.8/31.2 IC11 1130008511 S.IC TC7W53FU (TE12L,F) T 107.5/88.7 IC12 1130008511 S.IC TC7W53FU (TE12L,F) T 101.2/88.9 IC13 1130008511 S.IC TC7W53FU (TE12L,F) B 58/39.7 IC14 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 25.3/47.3 IC15 1110003201 S.IC TA31136FNG (EL) B 57.3/64.1 IC16 1130008511 S.IC TC7W53FU (TE12L,F) B 12.4/39 IC17 1130007021 S.IC TC7S66FU (TE85L,F) T 28.5/39.5 IC18 1110003201 S.IC TA31136FNG (EL) B 11.8/63.3 IC19 1190002051 S.IC SPM5001-TL-E T 64.3/90.3 IC20 1190002051 S.IC SPM5001-TL-E T 14.9/90.5 IC21 1180001071 S.IC TA7805F (TE16L,Q) B 107.1/136 IC22 1140012950 S.IC 24LC512T-I/SM B 112.6/98.2 IC23 1110005991 S.IC S-80945CNMC-G9F-T2G T 121/74.5 IC24 1180001251 S.IC TA7808F (TE16L,Q) B 100.1/136 IC25 1140013520 S.IC HD64F2506FC26DV B 114.5/73.1 IC26 1110006490 S.IC LMV321IDCKR T 116/65.9 IC28 1130007371 S.IC TA75S558F (TE85L,F) T 22.1/27 IC29 1130008511 S.IC TC7W53FU (TE12L,F) B 28.6/27 IC30 1130011770 S.IC CD4066BPWR T 31.8/24.7 IC31 1130011770 S.IC CD4066BPWR T 70/6.3 IC32 1110005310 S.IC AN6123MS B 34.3/21.8 IC33 1130011860 S.IC SM6451BT-G-E2 T 110.3/105.3 IC34 1130008511 S.IC TC7W53FU (TE12L,F) T 101.6/34.1 IC35 1130011770 S.IC CD4066BPWR B 70/8.2 IC36 1130013010 S.IC SN74AHC1G08DCK3 B 120.3/104.3 IC37 1130008511 S.IC TC7W53FU (TE12L,F) B 114.2/30.2 IC38 1110002541 IC LA4445-E IC41 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 69.9/47.3 IC42 1130007021 S.IC TC7S66FU (TE85L,F) T 74.8/37.5 IC43 1110004460 S.IC uPB1509GV-E1 T 77.6/57.8 IC44 1110006870 S.IC uPC2709TB-E3 T 90.2/57 IC45 1110006870 S.IC uPC2709TB-E3 T 42.4/56.2 IC46 1120003020 S.IC MAX3221IPWR T 94.4/9.9 IC48 1110006350 S.IC LM2902PWR T 65.8/18 IC49 1110006740 S.IC LMV358IPWR B 104.7/32.5 IC50 1110006490 S.IC LMV321IDCKR T 100.1/28.3 IC51 1130008511 S.IC TC7W53FU (TE12L,F) T 67.9/22.8 IC52 1130008511 S.IC TC7W53FU (TE12L,F) B 35.1/27 IC53 1110006490 S.IC LMV321IDCKR B 58.1/26.9 IC54 1110004310 S.IC M62352GP 75EC T 96.5/96.9 IC55 1190002500 S.IC ZXCT1022E5TA T 111.9/122.6 IC56 1130012960 S.IC BU8872FS-E2 B 119.3/53.4 IC57 1130008511 S.IC TC7W53FU (TE12L,F) T 108.4/54.7 IC58 1130008511 S.IC TC7W53FU (TE12L,F) T 115.7/54 IC59 1130004201 S.IC TC4S66F (TE85R,F) T 111.8/100.7 IC60 1130008511 S.IC TC7W53FU (TE12L,F) B 65/34.4 IC61 1130008511 S.IC TC7W53FU (TE12L,F) B 21.4/33.8 IC62 1110006870 S.IC uPC2709TB-E3 T 32.7/59.8 IC63 1130007021 S.IC TC7S66FU (TE85L,F) B 47.1/32.4

Q1 1590001650 S.TR XP4601 (TX) B 100.8/99.4 Q2 1590001650 S.TR XP4601 (TX) T 7.1/117 Q3 1590003240 S.TR UNR9114J-(TX) B 89.2/102.2 Q4 1590003240 S.TR UNR9114J-(TX) T 23.6/103.1 Q5 1590003240 S.TR UNR9114J-(TX) B 89.1/100.1 Q6 1590003240 S.TR UNR9114J-(TX) B 89.5/104.2 Q7 1590003240 S.TR UNR9114J-(TX) B 88.6/108.2 Q8 1590003240 S.TR UNR9114J-(TX) B 99.9/94.5 Q9 1590003240 S.TR UNR9114J-(TX) T 25.7/103.1 Q10 1590003240 S.TR UNR9114J-(TX) B 89.6/106.2 Q11 1590003240 S.TR UNR9114J-(TX) T 6/121.5 Q12 1590003290 S.TR UNR9213J-(TX) T 88.4/75 Q13 1590003290 S.TR UNR9213J-(TX) T 46.5/81.3 Q14 1530003990 S.TR 2SC4738-BL (TE85L,F) T 20.9/127.8 Q15 1510000581 S.TR 2SA1362-GR (TE85R,F) T 83.9/76.2 Q16 1530003990 S.TR 2SC4738-BL (TE85L,F) T 103.2/104.4 Q17 1510000581 S.TR 2SA1362-GR (TE85R,F) T 46.1/76.2 Q18 1530003581 S.TR 2SC5231C8-TL-E T 10.8/109.8 Q19 1580000800 S.FET 3SK324UG-TL-E T 15.7/112.8 Q20 1580000800 S.FET 3SK324UG-TL-E T 86/107.4 Q21 1530003990 S.TR 2SC4738-BL (TE85L,F) T 45.7/123.3 Q22 1530003231 S.TR 2SC5085-Y (TE85R,F) B 42.6/72 Q23 1530003781 S.TR 2SC5624VH-TL-E T 11.2/124.4 Q25 1530002680 S.TR 2SC3357-T1 B 87.5/74.9 Q26 1530002680 S.TR 2SC3357-T1 B 43.1/79.7 Q27 1530003291 S.TR 2SC4703-T1 SE B 87.5/80.9 Q28 1580000800 S.FET 3SK324UG-TL-E T 28/130.5 Q29 1580000800 S.FET 3SK324UG-TL-E T 101.2/115.5 Q30 1530003990 S.TR 2SC4738-BL (TE85L,F) T 26.7/127.9 Q31 1590003230 S.TR UNR9113J-(TX) B 39.2/104.4 Q32 1580000790 S.FET 3SK318YB-TL-E T 38.5/105.7 Q33 1580000790 S.FET 3SK318YB-TL-E T 70.4/109.6 Q34 1530003781 S.TR 2SC5624VH-TL-E T 54.2/105.5 Q35 1530003781 S.TR 2SC5624VH-TL-E T 60.7/105.5 Q36 1590003230 S.TR UNR9113J-(TX) B 43.3/104.3 Q37 1580000790 S.FET 3SK318YB-TL-E T 57.4/137.1 Q38 1530003990 S.TR 2SC4738-BL (TE85L,F) T 63.5/114.6 Q39 1580000790 S.FET 3SK318YB-TL-E T 82.4/120.1 Q40 1530003990 S.TR 2SC4738-BL (TE85L,F) T 35.5/144.8 Q41 1590001650 S.TR XP4601 (TX) T 112.6/83.1 Q42 1590001650 S.TR XP4601 (TX) B 101.8/90.7 Q43 1590003260 S.TR UNR911NJ-(TX) T 60.7/43.3 Q44 1590003260 S.TR UNR911NJ-(TX) T 6/90.9 Q45 1590003240 S.TR UNR9114J-(TX) T 6/37 Q46 1590003240 S.TR UNR9114J-(TX) T 57.2/38.9 Q47 1590001190 S.TR XP6501-(TX) .AB T 115.4/94.5 Q48 1590001190 S.TR XP6501-(TX) .AB T 107.9/95.9

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 2

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

Q49 1590003290 S.TR UNR9213J-(TX) T 102.9/93.5 Q50 1590003290 S.TR UNR9213J-(TX) T 113.8/89.6 Q52 1530003990 S.TR 2SC4738-BL (TE85L,F) B 25.4/47.8 Q53 1590003230 S.TR UNR9113J-(TX) T 57/70.6 Q54 1590003270 S.TR UNR9210J-(TX) T 59/71.2 Q55 1590001190 S.TR XP6501-(TX) .AB B 52.3/40.5 Q56 1590003230 S.TR UNR9113J-(TX) T 54.9/70.5 Q57 1590001190 S.TR XP6501-(TX) .AB T 53.7/43 Q58 1530003990 S.TR 2SC4738-BL (TE85L,F) B 82.9/46.3 Q59 1590003290 S.TR UNR9213J-(TX) T 55/68.4 Q60 1530003321 S.TR 2SC5108-Y (TE85R,F) T 37.2/48.9 Q61 1510000771 S.TR 2SA1586-GR (TE85R,F) T 25.1/41.5 Q62 1530002691 S.TR 2SC4116-GR (TE85R,F) T 23.5/39.1 Q63 1590001190 S.TR XP6501-(TX) .AB B 6/39.8 Q64 1590003290 S.TR UNR9213J-(TX) B 40.6/38.1 Q65 1590001650 S.TR XP4601 (TX) B 39.3/41 Q66 1530003221 S.TR 2SC4406-4-TL-E B 63.3/66.2 Q67 1590001190 S.TR XP6501-(TX) .AB T 7.1/42.1 Q68 1590001650 S.TR XP4601 (TX) B 39.3/44.6 Q69 1590003230 S.TR UNR9113J-(TX) T 12/70 Q70 1590003270 S.TR UNR9210J-(TX) T 14.2/70 Q71 1590003230 S.TR UNR9113J-(TX) T 9.7/69.9 Q72 1530003581 S.TR 2SC5231C8-TL-E T 38.4/42.6 Q73 1530003581 S.TR 2SC5231C8-TL-E T 44.7/38.4 Q74 1530003581 S.TR 2SC5231C8-TL-E T 41.4/43.2 Q75 1530003221 S.TR 2SC4406-4-TL-E B 18.5/66.2 Q76 1530003581 S.TR 2SC5231C8-TL-E T 45.8/42.4 Q79 1590003290 S.TR UNR9213J-(TX) T 41.2/66.6 Q81 1520000460 S.TR 2SB1132 T100 R B 101.6/127 Q82 1590003450 S.TR UNR9214J-(TX) B 106.5/104.3 Q83 1510000671 S.TR 2SA1588-GR (TE85R, F) B 103.9/103 Q84 1510000671 S.TR 2SA1588-GR (TE85R, F) B 99.9/104.7 Q86 1530003990 S.TR 2SC4738-BL (TE85L,F) B 6.7/31.4 Q87 1530003990 S.TR 2SC4738-BL (TE85L,F) T 15.3/30.5 Q88 1590003290 S.TR UNR9213J-(TX) T 21.1/21.7 Q90 1590003290 S.TR UNR9213J-(TX) T 31.5/20.9 Q91 1590003290 S.TR UNR9213J-(TX) T 64.4/8.5 Q92 1590003230 S.TR UNR9113J-(TX) T 44.3/10.8 Q93 1590003290 S.TR UNR9213J-(TX) T 58.6/9.4 Q94 1510000581 S.TR 2SA1362-GR (TE85R,F) T 115.4/38.4 Q95 1590003290 S.TR UNR9213J-(TX) B 70/12 Q96 1520000201 S.TR 2SB798-T2-AZ DK T 124.5/36.5 Q97 1530003990 S.TR 2SC4738-BL (TE85L,F) T 120.9/38.6 Q98 1590003270 S.TR UNR9210J-(TX) B 117.1/99.9 Q99 1590002270 S.TR UMG9NTR T 75.5/22.3 Q100 1590003290 S.TR UNR9213J-(TX) T 113.3/71.4 Q101 1530003091 S.TR 2SC4213-B (TE85R,F) T 128/111.5 Q102 1530003091 S.TR 2SC4213-B (TE85R,F) T 123/109.1 Q103 1530003091 S.TR 2SC4213-B (TE85R,F) T 125.5/109.1 Q104 1590003260 S.TR UNR911NJ-(TX) B 74/44.4 Q105 1530003990 S.TR 2SC4738-BL (TE85L,F) B 70/47.4 Q106 1590003260 S.TR UNR911NJ-(TX) T 82.2/56.4 Q109 1590003290 S.TR UNR9213J-(TX) T 78.7/43.8 Q110 1590003300 S.TR UNR921NJ-(TX) T 89.1/35.5 Q111 1530003581 S.TR 2SC5231C8-TL-E T 88.5/42.4 Q112 1530003321 S.TR 2SC5108-Y (TE85R,F) T 82.1/49.1 Q113 1530003581 S.TR 2SC5231C8-TL-E T 90.4/46.9 Q115 1590003290 S.TR UNR9213J-(TX) T 85.8/55.7 Q116 1530003321 S.TR 2SC5108-Y (TE85R,F) T 77.4/63 Q117 1590003290 S.TR UNR9213J-(TX) T 9.7/67.7 Q118 1590003290 S.TR UNR9213J-(TX) T 116.6/42.8 Q119 1560000811 S.FET 2SK1069-4-TL-E B 71.6/36 Q120 1560000811 S.FET 2SK1069-4-TL-E B 29.3/34.4 Q121 1590003290 S.TR UNR9213J-(TX) T 76.8/39.4 Q122 1590003290 S.TR UNR9213J-(TX) B 30.6/41.7 Q123 1520000450 S.TR 2SB1132 T100 Q T 49.8/121.7

D1 1790001240 S.DIO MA2S728-(TX) T 12.7/117.1 D2 1790001240 S.DIO MA2S728-(TX) T 89.8/108.9 D3 1790001240 S.DIO MA2S728-(TX) T 70.5/113.1 D4 1790001240 S.DIO MA2S728-(TX) T 37/108.6 D5 1790001240 S.DIO MA2S728-(TX) T 57/106.8 D6 1790001240 S.DIO MA2S728-(TX) T 63.5/106.8 D7 1790001260 S.DIO MA2S077-(TX) T 14.1/97 D8 1790001260 S.DIO MA2S077-(TX) T 71.2/98.4 D9 1790001260 S.DIO MA2S077-(TX) T 10.4/97 D10 1790001621 S.DIO 1SV308 (TPL3,F) T 16.7/100.8 D11 1790001621 S.DIO 1SV308 (TPL3,F) T 75.7/98.4 D12 1750000721 S.VCP HVC375BTRF-E T 14.9/102.5 D13 1750000721 S.VCP HVC375BTRF-E T 76.4/101.5 D14 1750000721 S.VCP HVC375BTRF-E T 14.9/105.2 D15 1750000721 S.VCP HVC375BTRF-E T 78.4/103.3 D16 1790001621 S.DIO 1SV308 (TPL3,F) T 16.7/108.3 D17 1790001621 S.DIO 1SV308 (TPL3,F) T 82.2/104.8 D18 1790001621 S.DIO 1SV308 (TPL3,F) T 18.3/116.8 D19 1790001621 S.DIO 1SV308 (TPL3,F) T 90.8/104.5 D20 1750000721 S.VCP HVC375BTRF-E T 16.1/119.4 D21 1750000721 S.VCP HVC375BTRF-E T 94.2/106.2 D22 1790001621 S.DIO 1SV308 (TPL3,F) T 11.8/130.1 D23 1750000721 S.VCP HVC375BTRF-E T 16.1/120.6 D24 1750000721 S.VCP HVC375BTRF-E T 96.8/106.2 D25 1790001250 S.DIO MA2S111-(TX) B 38.1/77.6 D26 1790001621 S.DIO 1SV308 (TPL3,F) T 17.4/123.1 D27 1790001621 S.DIO 1SV308 (TPL3,F) T 99.6/103.7 D28 1720000241 S.DIO 1SV172 (TE85R,F) T 100.2/109.1 D29 1790001250 S.DIO MA2S111-(TX) B 82.8/78.4 D30 1720000241 S.DIO 1SV172 (TE85R,F) T 15.2/127 D31 1750000520 S.DIO DAN222TL B 41.8/88.2 D32 1790001250 S.DIO MA2S111-(TX) T 23.3/127.5 D35 1790001260 S.DIO MA2S077-(TX) T 21.2/98.8 D36 1790001260 S.DIO MA2S077-(TX) T 53.6/96.8 D37 1790001260 S.DIO MA2S077-(TX) T 60/96.8 D38 1790001260 S.DIO MA2S077-(TX) T 67.3/96.8

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

D39 1790000980 S.DIO MA742 (TX) B 76.8/133.6 D40 1750000711 S.VCP HVC350BTRF-E T 30/101.3 D41 1750000711 S.VCP HVC350BTRF-E T 67.8/103.5 D42 1790000980 S.DIO MA742 (TX) B 41/113.9 D43 1750000711 S.VCP HVC350BTRF-E T 32.7/101.3 D44 1750000711 S.VCP HVC350BTRF-E T 67.8/104.8 D45 1750000711 S.VCP HVC350BTRF-E T 56.8/102.5 D46 1750000721 S.VCP HVC375BTRF-E T 63.3/102.5 D47 1790000980 S.DIO MA742 (TX) B 74.9/139.4 D48 1790001250 S.DIO MA2S111-(TX) T 33.9/136.3 D49 1790001250 S.DIO MA2S111-(TX) T 35.1/136.3 D50 1750000721 S.VCP HVC375BTRF-E T 62.1/109 D51 1750000711 S.VCP HVC350BTRF-E T 55.6/109 D52 1790000980 S.DIO MA742 (TX) B 30.2/133.8 D53 1790001260 S.DIO MA2S077-(TX) T 40.3/137.9 D54 1750000711 S.VCP HVC350BTRF-E T 45.9/110.1 D55 1750000711 S.VCP HVC350BTRF-E T 74.1/116.8 D56 1790001260 S.DIO MA2S077-(TX) T 55.6/111.5 D57 1790001260 S.DIO MA2S077-(TX) T 58.6/111.5 D58 1750000711 S.VCP HVC350BTRF-E T 48.6/110.1 D59 1750001360 S.DIO L709CER (9401) B 78.7/150.1 D60 1750000711 S.VCP HVC350BTRF-E T 74.1/118.1 D61 1750001360 S.DIO L709CER (9401) B 32.5/143.2 D62 1750001360 S.DIO L709CER (9401) B 42.6/138.2 D63 1790001250 S.DIO MA2S111-(TX) T 106.5/119.7 D64 1790001250 S.DIO MA2S111-(TX) T 90.6/118.6 D65 1790001260 S.DIO MA2S077-(TX) T 94.8/122.3 D66 1790001250 S.DIO MA2S111-(TX) T 108.1/117.8 D67 1790001250 S.DIO MA2S111-(TX) T 91.9/118.6 D68 1720000241 S.DIO 1SV172 (TE85R,F) T 73.7/125.4 D69 1790001260 S.DIO MA2S077-(TX) T 108.4/123.2 D70 1720000241 S.DIO 1SV172 (TE85R,F) T 54.9/119.7 D71 1790001260 S.DIO MA2S077-(TX) T 93.7/125.7 D72 1790001621 S.DIO 1SV308 (TPL3,F) T 100.6/128.1 D73 1790001260 S.DIO MA2S077-(TX) T 108/128.9 D74 1790001621 S.DIO 1SV308 (TPL3,F) T 106.2/132.4 D75 1750001360 S.DIO L709CER (9401) B 69.5/145.4 D76 1790001250 S.DIO MA2S111-(TX) T 65.9/115 D77 1790001260 S.DIO MA2S077-(TX) T 66.8/140.6 D78 1790001250 S.DIO MA2S111-(TX) T 62.2/142.3 D79 1790001250 S.DIO MA2S111-(TX) T 63.4/142.3 D80 1790001250 S.DIO MA2S111-(TX) T 33.6/144.7 D81 1790001250 S.DIO MA2S111-(TX) B 29.7/49.9 D82 1790001250 S.DIO MA2S111-(TX) T 54.2/57.9 D83 1790001250 S.DIO MA2S111-(TX) T 54.2/50.4 D84 1790001250 S.DIO MA2S111-(TX) T 61.2/57.8 D85 1790001250 S.DIO MA2S111-(TX) T 61.2/50.3 D86 1750000370 S.DIO DA221 TL T 22.5/43.2 D87 1720000791 S.VCP HVC321B1TRF-E T 35.6/37 D88 1750000370 S.DIO DA221 TL B 65.5/68.4 D89 1750000831 S.VCP HVC362TRF-E T 31.5/41.8 D90 1750000831 S.VCP HVC362TRF-E T 33.1/40.1 D91 1750000721 S.VCP HVC375BTRF-E T 38.9/35.6 D92 1750000711 S.VCP HVC350BTRF-E T 38.9/34.4 D93 1790001250 S.DIO MA2S111-(TX) T 8.9/57.1 D94 1790001250 S.DIO MA2S111-(TX) T 8.1/49.5 D95 1790001250 S.DIO MA2S111-(TX) T 16.3/56.9 D96 1790001250 S.DIO MA2S111-(TX) T 16.3/49.4 D97 1790001250 S.DIO MA2S111-(TX) T 43.2/41.6 D100 1750000370 S.DIO DA221 TL B 20.7/68.4 D101 1790001260 S.DIO MA2S077-(TX) T 37.1/57.1 D102 1790001260 S.DIO MA2S077-(TX) T 44.3/48.5 D103 1790001621 S.DIO 1SV308 (TPL3,F) T 44/61.2 D104 1790001260 S.DIO MA2S077-(TX) T 40.2/57.9 D106 1790001260 S.DIO MA2S077-(TX) T 33.6/69.9 D107 1790001260 S.DIO MA2S077-(TX) T 37.3/69.9 D108 1790001260 S.DIO MA2S077-(TX) T 38.5/69.9 D109 1790001250 S.DIO MA2S111-(TX) T 41.9/63.4 D112 1750000520 S.DIO DAN222TL B 85.9/102.2 D113 1750000520 S.DIO DAN222TL B 85.9/104.2 D116 1790001250 S.DIO MA2S111-(TX) T 8.2/121.7 D117 1730000521 ZEN RD20E-AZ B2 D118 1790000700 DIO DSA3A1 D119 1790001250 S.DIO MA2S111-(TX) B 104.2/105 D120 1790001250 S.DIO MA2S111-(TX) B 105.7/106.3 D121 1790001250 S.DIO MA2S111-(TX) B 10.4/29.7 D122 1730002340 S.ZEN MA8047-M (TX) T 119.2/64 D124 1790001250 S.DIO MA2S111-(TX) T 104/76.2 D125 1790001250 S.DIO MA2S111-(TX) T 104/77.4 D126 1790001250 S.DIO MA2S111-(TX) T 104/78.6 D127 1790001250 S.DIO MA2S111-(TX) T 104/79.8 D128 1790001250 S.DIO MA2S111-(TX) [EUR-02] only T 106.5/76.2 D129 1790001250 S.DIO MA2S111-(TX) [EUR-02] only T 106.5/77.4 D133 1790001250 S.DIO MA2S111-(TX) T 104/72.6 D134 1790001250 S.DIO MA2S111-(TX) T 104/73.8 D135 1790001250 S.DIO MA2S111-(TX) T 104/75 D136 1790001250 S.DIO MA2S111-(TX) T 106.5/71.4 D140 1750000370 S.DIO DA221 TL T 50/12.3 D141 1790001250 S.DIO MA2S111-(TX) T 120.9/40.3 D142 1790000980 S.DIO MA742 (TX) B 117.7/102.5 D143 1790001250 S.DIO MA2S111-(TX) B 74.6/50.8 D145 1720000791 S.VCP HVC321B1TRF-E T 83/38.9 D146 1720000791 S.VCP HVC321B1TRF-E T 83.8/37.2 D147 1720000791 S.VCP HVC321B1TRF-E T 81.8/41.4 D148 1790001260 S.DIO MA2S077-(TX) T 84.7/35.4 D150 1790001260 S.DIO MA2S077-(TX) T 86.9/58.4 D151 1790001260 S.DIO MA2S077-(TX) T 86.9/60.8 D152 1790001260 S.DIO MA2S077-(TX) T 86.9/59.6 D153 1790001260 S.DIO MA2S077-(TX) T 82.5/70.7 D154 1790001260 S.DIO MA2S077-(TX) T 80.7/70 D155 1790001621 S.DIO 1SV308 (TPL3,F) T 88.4/63.5 D156 1790001260 S.DIO MA2S077-(TX) T 77.1/70 D157 1790001621 S.DIO 1SV308 (TPL3,F) T 89.3/65.5 D159 1790001260 S.DIO MA2S077-(TX) T 38.9/57.9

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 3

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

D160 1790001260 S.DIO MA2S077-(TX) T 43/48.5 D161 1750000771 S.VCP HVC376BTRF-E B 123.3/87.8 D162 1750000771 S.VCP HVC376BTRF-E B 122.3/89.6 D164 1790001250 S.DIO MA2S111-(TX) B 114.7/88.1 D165 1750000940 S.DIO ISS400 TE61 T 123.9/27.3 D166 1750000940 S.DIO ISS400 TE61 T 125.1/27.3 D167 1750000940 S.DIO ISS400 TE61 T 122.7/26.4 D168 1750000940 S.DIO ISS400 TE61 T 120.6/26.4 D169 1790001520 S.ZEN MA8075-L (TX) T 47.3/125.2

FI1 2020002390 CER LT450HW <JJE> FI2 2020002250 CER LT450EW <JJE> FI3 2020002390 CER LT450HW <JJE> FI4 2020002250 CER LT450EW <JJE> FI5 2030000590 S.MLH FL-408 (38.850 MHz) B 71/69.6 FI6 2030000600 S.MLH FL-409 (46.350 MHz) B 26.1/68.9

X1 6050011940 S.XTL CR-783 (15.3 MHz) B 23.3/43.4 X2 6070000290 DCR JTB450C24 <JJE> X3 6070000290 DCR JTB450C24 <JJE> X4 6050012530 S.XTL CR-841 (SMD49/19.6608 MHz) B 126.6/88.1 X5 6050012450 S.XTL CR-833 (12.800 MHz) B 67.9/43.4 X6 6050012480 S.XTL CR-838 (SMD-49/4.194304 MHz) B 126.6/54.7

L1 6200005721 S.COL ELJRE 33NGFA T 16/97.8 L2 6200005721 S.COL ELJRE 33NGFA T 72.4/98.4 L3 6200006981 S.COL ELJRE R10GFA T 11.1/98.8 L4 6200009220 S.COL LQW18AN15NG00D T 14.9/101.3 L5 6200009220 S.COL LQW18AN15NG00D T 75.6/100.6 L6 6200003550 S.COL MLF1608A 4R7K-T T 17.4/99 L7 6200003550 S.COL MLF1608A 4R7K-T T 75.6/97.2 L8 6200010130 S.COL LQW18AN6N8C00D T 11.5/108.1 L9 6200005741 S.COL ELJRE 47NGFA B 89.4/67 L10 6200009220 S.COL LQW18AN15NG00D T 14.9/106.4 L11 6200005741 S.COL ELJRE 47NGFA B 91.3/67.8 L12 6200009220 S.COL LQW18AN15NG00D T 79.2/104.2 L13 6200003550 S.COL MLF1608A 4R7K-T T 18.5/107.6 L15 6200003550 S.COL MLF1608A 4R7K-T T 81.2/104.1 L16 6200009070 S.COL LQW18AN18NG00D T 14.9/110.1 L17 6200005671 S.COL ELJRE 12NGFA T 10.4/113.1 L18 6200009070 S.COL LQW18AN18NG00D T 82.4/107.5 L19 6200005731 S.COL ELJRE 39NGFA B 43.6/67.5 L20 6200010130 S.COL LQW18AN6N8C00D T 11.3/122.5 L21 6200003550 S.COL MLF1608A 4R7K-T T 19/115 L22 6200005721 S.COL ELJRE 33NGFA B 43.4/74.9 L23 6200012520 S.COL 0.26-1.0-5TL 12N T 16.4/117.7 L24 6200003550 S.COL MLF1608A 4R7K-T T 89.6/104.5 L25 6200005691 S.COL ELJRE 18NGFA B 85.4/71.7 L26 6200005691 S.COL ELJRE 18NGFA B 38.3/74.9 L27 6200012520 S.COL 0.26-1.0-5TL 12N T 92.5/106.1 L28 6200005741 S.COL ELJRE 47NGFA B 83.6/75.9 L29 6200005661 S.COL ELJRE 10NGFA B 39.9/77.5 L30 6200010130 S.COL LQW18AN6N8C00D T 11.8/131.4 L31 6200012520 S.COL 0.26-1.0-5TL 12N T 15.4/122.3 L32 6200003550 S.COL MLF1608A 4R7K-T T 16.9/124.9 L33 6200012520 S.COL 0.26-1.0-5TL 12N T 98.5/106.3 L34 6200003550 S.COL MLF1608A 4R7K-T T 100.8/103.7 L35 6200005701 S.COL ELJRE 22NGFA B 38.1/79.7 L36 6200005681 S.COL ELJRE 15NGFA B 40.7/82.9 L37 6200005731 S.COL ELJRE 39NGFA B 82.8/80.5 L38 6200011580 S.COL LQW18AN33NG00D T 26.1/130.4 L39 6200011580 S.COL LQW18AN33NG00D T 101.1/117.4 L40 6200011660 S.COL LQW18ANR15G00D T 31.7/134.2 L41 6200011660 S.COL LQW18ANR15G00D T 104/113.5 L42 6200011770 S.COL LQW18ANR10G00D T 30.8/137.1 L43 6200011770 S.COL LQW18ANR10G00D T 105.7/117.9 L44 6200010910 S.COL LQW18AN56NG00D T 106.9/117.9 L45 6200011580 S.COL LQW18AN33NG00D T 32.7/136.4 L46 6200010060 S.COL AS080647-56N B 88.7/128.9 L47 6200009250 S.COL LQW18ANR22G00D T 24/99.6 L48 6200005721 S.COL ELJRE 33NGFA T 55.4/97.6 L49 6200005701 S.COL ELJRE 22NGFA T 61.9/97.6 L50 6200010040 S.COL AS100340-10N B 40.3/125 L51 6200012050 S.COL LQW18AN24NG00D T 66.1/98.4 L52 6200011650 S.COL LQW18AN68NG00D T 28.2/100.5 L53 6200011590 S.COL LQW18AN39NG00D T 27.4/102.4 L54 6200011650 S.COL LQW18AN68NG00D T 66.1/101.7 L55 6200011590 S.COL LQW18AN39NG00D T 68/100.9 L56 6200010060 S.COL AS080647-56N B 86.1/137.8 L57 6200011770 S.COL LQW18ANR10G00D T 36.3/104.1 L58 6200011580 S.COL LQW18AN33NG00D T 54.3/103.6 L59 6200011770 S.COL LQW18ANR10G00D T 70.4/107.6 L60 6200009070 S.COL LQW18AN18NG00D T 60.8/103.6 L61 6200010160 S.COL AS080440-22N B 40.8/130.4 L62 6200010420 S.COL FHW1210HC 1R0JGT B 83.4/149.7 L63 6200009070 S.COL LQW18AN18NG00D T 43.8/110.2 L64 6200011670 S.COL LQW18AN82NG00D T 43.8/107.6 L65 6200009070 S.COL LQW18AN18NG00D T 73.3/115 L66 6200011670 S.COL LQW18AN82NG00D T 75.2/114.2 L67 6200009070 S.COL LQW18AN18NG00D T 62.1/110.2 L68 6200011580 S.COL LQW18AN33NG00D T 55.6/110.2 L69 6200012960 S.COL 0.45-1.4-4TL 12.1N T 35.1/139.3 L70 6200010420 S.COL FHW1210HC 1R0JGT B 45.5/133 L71 6200002390 S.COL LQW31HN64NJ03L T 74.2/120.7 L72 6200011590 S.COL LQW18AN39NG00D T 76.3/122.5 L73 6200010160 S.COL AS080440-22N B 36.4/140.3 L74 6200002390 S.COL LQW31HN64NJ03L T 50.6/113.7 L75 6200011590 S.COL LQW18AN39NG00D T 53.6/116.3 L76 6200011660 S.COL LQW18ANR15G00D T 88.5/119.4 L77 6200010160 S.COL AS080440-22N B 38.9/145.5 L78 6200010910 S.COL LQW18AN56NG00D T 93.7/124.4

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

L79 6200003960 S.COL MLF1608A 1R0K-T T 102.4/127.3 L80 6200010160 S.COL AS080440-22N B 38.9/150.6 L81 6200011670 S.COL LQW18AN82NG00D T 84.2/116.9 L82 6200012900 S.COL 0.30-2.0-7TL 57.2N T 97.5/128.1 L83 6200003960 S.COL MLF1608A 1R0K-T T 108.1/131.6 L84 6200009220 S.COL LQW18AN15NG00D T 105.7/125.8 L85 6200009250 S.COL LQW18ANR22G00D T 56/135.1 L86 6200012980 S.COL 0.40-1.4-5TR 18.3N T 105.4/130 L87 6200009250 S.COL LQW18ANR22G00D T 80.4/121.5 L88 6200010050 S.COL AS080547-47N B 65.4/152.4 L89 6200010070 S.COL AS080747-68N B 73.6/146.9 L90 6200012760 S.COL 0.35-1.6-7TL 37.5N T 99.5/133.2 L91 6200011670 S.COL LQW18AN82NG00D T 62.7/139.8 L92 6200010060 S.COL AS080647-56N B 58.9/149.2 L93 6200012910 S.COL 0.35-1.6-8TL 45.5N T 101/136.5 L94 6200012910 S.COL 0.35-1.6-8TL 45.5N T 70.3/143.9 L95 6200012960 S.COL 0.45-1.4-4TL 12.1N T 106.6/136.1 L96 6200010050 S.COL AS080547-47N B 50/153 L97 6200011660 S.COL LQW18ANR15G00D T 61/142.4 L98 6200012760 S.COL 0.35-1.6-7TL 37.5N T 102.5/139.9 L99 6200012960 S.COL 0.45-1.4-4TL 12.1N T 107.4/140 L100 6200005731 S.COL ELJRE 39NGFA T 26.8/152.3 L101 6200010040 S.COL AS100340-10N B 30.6/153.9 L102 6200010130 S.COL LQW18AN6N8C00D T 12.7/134.3 L103 6200012400 S.COL 0.30-0.91-4TL 8.6N T 100.8/143 L104 6200010160 S.COL AS080440-22N B 25.3/148.6 L105 6200010130 S.COL LQW18AN6N8C00D T 12.7/135.6 L106 6200012980 S.COL 0.40-1.4-5TR 18.3N T 100.8/147 L107 6200010130 S.COL LQW18AN6N8C00D T 12.7/136.9 L108 6200010150 S.COL AS080340-15N B 18.1/148.2 L109 6200012920 S.COL 0.20-1.0-4TL 12.1N T 99.2/149.9 L110 6200008720 S.COL 0.30-0.8-3TL 6N [EUR-01] T 15.4/143.1 6200012620 S.COL 0.30-0.8-3TL 4.3N [EUR-02] T 15.4/143.1 L111 6200004480 S.COL MLF1608D R82K-T B 24.8/50.8 L112 6200003540 S.COL MLF1608D R22K-T B 27.9/47.9 L113 6200005701 S.COL ELJRE 22NGFA T 30.9/49.3 L114 6200005741 S.COL ELJRE 47NGFA T 35.5/48.6 L115 6200002651 S.COL NLV25T-R18J T 32.4/37 L116 6200002651 S.COL NLV25T-R18J T 35.9/35 L117 6200010100 S.COL C2012C-33NG-A T 33.2/42.3 L118 6200010030 S.COL C2012C-15NG-A T 41.3/35.5 L119 6200004951 S.COL NLV25T-1R8J B 75.8/74.9 L120 6200010381 S.COL ELJRE R15JFA T 41.1/44.9 L121 6200005731 S.COL ELJRE 39NGFA T 45.3/44.1 L122 6130003000 S.COL #617DB-1714=P3 T 64.4/83.6 L123 6200005731 S.COL ELJRE 39NGFA T 37.4/64.4 L124 6200005691 S.COL ELJRE 18NGFA T 45.7/64.4 L125 6200005731 S.COL ELJRE 39NGFA T 36.2/65.9 L126 6130003000 S.COL #617DB-1714=P3 T 70.8/84.2 L127 6130003000 S.COL #617DB-1714=P3 T 71.1/90.4 L129 6200009220 S.COL LQW18AN15NG00D T 31.6/62.2 L130 6200005671 S.COL ELJRE 12NGFA T 32.4/64.3 L131 6200005701 S.COL ELJRE 22NGFA T 39.4/63.8 L132 6130003000 S.COL #617DB-1714=P3 T 14.9/83.9 L133 6200005671 S.COL ELJRE 12NGFA T 32.4/66.2 L134 6200005701 S.COL ELJRE 22NGFA T 39.4/67.3 L135 6200005651 S.COL ELJRE 8N2ZFA T 31.8/68.2 L136 6130003000 S.COL #617DB-1714=P3 T 21.2/84.4 L137 6130003000 S.COL #617DB-1714=P3 T 21.7/90.7 L138 6190001690 S.COL ZBFS5105-PT-01 T 119/121 L139 6190001690 S.COL ZBFS5105-PT-01 T 117.4/112 L140 6190001690 S.COL ZBFS5105-PT-01 T 115.3/121 L141 6190001690 S.COL ZBFS5105-PT-01 T 117.4/115.3 L142 6200004480 S.COL MLF1608D R82K-T B 71.9/51.3 L143 6200003540 S.COL MLF1608D R22K-T B 72.3/47.8 L144 6200002611 S.COL NLV25T-R47J T 80.8/37.2 L145 6200010310 S.COL C2012C-27NG-A T 85.2/40.4 L146 6200010310 S.COL C2012C-27NG-A T 86.5/37.7 L147 6200006671 S.COL ELJRE 68NGFA T 79.4/49.4 L148 6200005731 S.COL ELJRE 39NGFA T 84.4/65.5 L149 6200005721 S.COL ELJRE 33NGFA T 80.4/61.3 L150 6200006981 S.COL ELJRE R10GFA T 87.7/47 L151 6200005661 S.COL ELJRE 10NGFA T 81.9/63.8 L152 6200005731 S.COL ELJRE 39NGFA T 84.4/68.1 L153 6200005711 S.COL ELJRE 27NGFA T 80.2/66.3 L155 6200006671 S.COL ELJRE 68NGFA T 76.2/68.2 L156 6200006671 S.COL ELJRE 68NGFA T 78.4/68.4 L157 6200006991 S.COL ELJRE 56NGFA T 88/67.1 L158 6200009351 S.COL ELJRE R22GFA T 76.2/64.9 L159 6200005691 S.COL ELJRE 18NGFA T 45.6/68.9 L160 6200003960 S.COL MLF1608A 1R0K-T T 90.2/59 L161 6200003960 S.COL MLF1608A 1R0K-T T 42.7/58.2 L162 6200009220 S.COL LQW18AN15NG00D T 32/56.2 L163 6200003640 S.COL MLF1608E 100K-T T 93/15.2 L164 6200011660 S.COL LQW18ANR15G00D T 38.4/135.2 L165 6200011650 S.COL LQW18AN68NG00D T 62.2/144.9 L166 6200011650 S.COL LQW18AN68NG00D T 89.3/121.3

R3 7030010040 S.RES ERJ2GEJ-JPW B 97.8/102.8 R4 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 102.7/98.5 R5 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 102.7/100.1 R6 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 5.2/116.2 R7 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 5.2/117.8 R8 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 86.4/75 R9 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 18.9/97.8 R10 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 73.3/96.3 R11 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 11.9/100.2 R12 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 46.5/79.4 R14 7030005300 S.RES ERJ2GEJ 150 X (15) T 11.1/102.6 R15 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 103.6/101.6 R16 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 18/128.5 R17 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 85.9/76.2 R18 7030005000 S.RES ERJ2GEJ 471 X (470) T 19.1/100.4

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 4

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R19 7030005000 S.RES ERJ2GEJ 471 X (470) T 78.5/97.2 R20 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 46.1/78.2 R22 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 87.7/67.5 R23 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 17/103.4 R24 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 78.6/100.5 R26 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.2/106.7 R27 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 17/104.3 R28 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 12.2/109.8 R29 7030005000 S.RES ERJ2GEJ 471 X (470) T 19.2/106.3 R30 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 79.2/101.2 R31 7030005000 S.RES ERJ2GEJ 471 X (470) T 82.5/102.5 R33 7030010090 S.RES ERJ2GEJ 180 X (18) B 90.3/69 R35 7030004970 S.RES ERJ2GEJ 470 X (47) T 17/110.9 R37 7030005580 S.RES ERJ2GEJ 560 X (56) B 92.1/69.9 R38 7030004970 S.RES ERJ2GEJ 470 X (47) T 84.2/105.2 R39 7030007270 S.RES ERJ2GEJ 151 X (150) T 10.6/116.5 R40 7030009200 S.RES ERJ2GEJ 390 X (39) T 11.1/117.7 R41 7030004980 S.RES ERJ2GEJ 101 X (100) T 18.4/112.4 R43 7030007280 S.RES ERJ2GEJ 331 X (330) B 43.9/66.4 R44 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 46.1/121.5 R45 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 14.4/115.5 R46 7030010090 S.RES ERJ2GEJ 180 X (18) B 91.2/69.9 R47 7030005300 S.RES ERJ2GEJ 150 X (15) B 44.3/68.8 R48 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 17.7/113.6 R49 7030004980 S.RES ERJ2GEJ 101 X (100) T 85.6/104.7 R50 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 88/105.8 R51 7030007270 S.RES ERJ2GEJ 151 X (150) T 10.6/118.9 R52 7030010040 S.RES ERJ2GEJ-JPW T 13.1/114.1 R53 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 14/113.2 R54 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 86.8/105.4 R55 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 87.8/107 R56 7030007270 S.RES ERJ2GEJ 151 X (150) B 89.4/70.7 R57 7030007280 S.RES ERJ2GEJ 331 X (330) B 42.2/69.3 R58 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 14.4/114.6 R59 7030009200 S.RES ERJ2GEJ 390 X (39) B 89.1/71.9 R60 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 87.8/108.6 R61 7030010040 S.RES ERJ2GEJ-JPW T 88.7/108.6 R63 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 44.4/72 R64 7030005010 S.RES ERJ2GEJ 681 X (680) B 42.2/70.2 R66 7030007270 S.RES ERJ2GEJ 151 X (150) B 87.9/70.7 R67 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.3/127.1 R68 7030007270 S.RES ERJ2GEJ 151 X (150) B 44.6/73.7 R70 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 12.3/126.2 R72 7030005000 S.RES ERJ2GEJ 471 X (470) T 19.7/113.7 R73 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 10.7/126.2 R74 7030005000 S.RES ERJ2GEJ 471 X (470) T 89.6/101.6 R75 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 83.6/74.9 R76 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 83.6/74 R77 7030007250 S.RES ERJ2GEJ 220 X (22) B 41/76.3 R78 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 18.4/119.4 R79 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 19.1/120.3 R80 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 11.6/129 R81 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 94.7/104.4 R82 7030000270 S.RES MCR10EZHJ 120 (121) B 81/75.2 R83 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 95.9/104.1 R85 7030005000 S.RES ERJ2GEJ 471 X (470) T 18.4/123.3 R86 7030005000 S.RES ERJ2GEJ 471 X (470) T 99.9/101 R88 7030000180 S.RES MCR10EZHJ 22 (220) B 36/77.8 R89 7030005590 S.RES ERJ2GEJ 680 X (68) B 84.5/78.9 R90 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 38.4/78.7 R91 7030005010 S.RES ERJ2GEJ 681 X (680) B 40/79.7 R92 7030000180 S.RES MCR10EZHJ 22 (220) B 34.3/77.8 R93 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 102.6/107.4 R94 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 18.3/127.6 R95 7030000180 S.RES MCR10EZHJ 22 (220) B 80.8/78.5 R96 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 83.3/79.4 R97 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 84.5/80.5 R98 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.7/124.5 R100 7030000180 S.RES MCR10EZHJ 22 (220) B 79/78.5 R101 7030010040 S.RES ERJ2GEJ-JPW T 98.1/111.6 R102 7030010040 S.RES ERJ2GEJ-JPW T 98.1/117 R103 7030010040 S.RES ERJ2GEJ-JPW T 25/127.6 R104 7030004990 S.RES ERJ2GEJ 221 X (220) B 39.1/84.3 R105 7030005300 S.RES ERJ2GEJ 150 X (15) B 85.7/83.9 R106 7030010090 S.RES ERJ2GEJ 180 X (18) B 38.6/83.1 R107 7030004970 S.RES ERJ2GEJ 470 X (47) T 27.4/134.4 R108 7030004980 S.RES ERJ2GEJ 101 X (100) T 30.7/130.1 R109 7030004970 S.RES ERJ2GEJ 470 X (47) T 103/118 R110 7030004980 S.RES ERJ2GEJ 101 X (100) T 98.5/114.4 R111 7030004990 S.RES ERJ2GEJ 221 X (220) B 38.2/84.3 R112 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 27.4/132.8 R113 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 26.1/133 R114 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 103/116.4 R115 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 100.6/118.4 R116 7030005300 S.RES ERJ2GEJ 150 X (15) B 84.1/83.9 R117 7030004980 S.RES ERJ2GEJ 101 X (100) B 84.5/85.1 R118 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 28.7/133.2 R119 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 104.3/116.1 R120 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 29.6/135.1 R121 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 105.7/114.1 R122 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 28.3/127.8 R124 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 23.3/128.5 R125 7030010040 S.RES ERJ2GEJ-JPW B 44.5/90.1 R126 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 29.5/127.4 R128 7030007270 S.RES ERJ2GEJ 151 X (150) B 43.3/90.6 R129 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 45.5/92.1 R133 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 40.8/103.6 R134 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 24.7/98.3 R135 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 58/98.1 R136 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 63.6/98.1 R137 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 68.1/99.6 R138 7030010040 S.RES ERJ2GEJ-JPW B 85.2/87.3 R139 7030007280 S.RES ERJ2GEJ 331 X (330) T 54.8/99.3 R140 7030004990 S.RES ERJ2GEJ 221 X (220) B 87.3/86.9

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R141 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 86.4/86.9 R142 7030007280 S.RES ERJ2GEJ 331 X (330) T 61.2/99.3 R143 7030005300 S.RES ERJ2GEJ 150 X (15) T 60/100.5 R144 7030007250 S.RES ERJ2GEJ 220 X (22) T 53.6/100.5 R145 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 30.9/103.5 R147 7030007280 S.RES ERJ2GEJ 331 X (330) T 54.8/100.9 R148 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 37.7/104.7 R149 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 70.6/103.7 R150 7030007280 S.RES ERJ2GEJ 331 X (330) T 61.2/100.9 R152 7030004980 S.RES ERJ2GEJ 101 X (100) B 34.6/105 R153 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 31.8/103.5 R154 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 74.5/134.2 R155 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 70.6/104.6 R156 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 56.5/101.5 R157 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 33.7/105 R158 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 35.1/107.9 R159 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 34.7/101.9 R160 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 62.9/101.5 R161 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 67.4/106.7 R162 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 34.6/106.6 R163 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 33.7/109.1 R164 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 56.9/104.8 R165 7030004970 S.RES ERJ2GEJ 470 X (47) T 36.9/101.9 R166 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 39.6/111.6 R167 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 39.1/110.3 R168 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 63.3/104.8 R169 7030004970 S.RES ERJ2GEJ 470 X (47) T 72.5/106.7 R170 7030004980 S.RES ERJ2GEJ 101 X (100) T 56.4/103.6 R171 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/103.6 R172 7030007270 S.RES ERJ2GEJ 151 X (150) T 39.4/103.3 R173 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 39.7/107.7 R174 7030007270 S.RES ERJ2GEJ 151 X (150) T 73/109.2 R175 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 40.5/104.8 R176 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 40.8/110.3 R177 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 41.2/108.2 R178 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 29.7/135.5 R179 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 73.3/111.7 R180 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 37.5/107.2 R181 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 73.3/110.8 R182 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 56/106.5 R183 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 53.7/107.3 R184 7030010040 S.RES ERJ2GEJ-JPW T 38.6/108.3 R185 7030010040 S.RES ERJ2GEJ-JPW T 69.7/111.8 R186 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 62.4/106.5 R187 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 60.1/107.3 R188 7030006070 S.RES ERJ12YJ101U (100) B 84.5/144.8 R189 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 68.5/111.2 R190 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 70.9/111.4 R191 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 65/109 R192 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 58.5/109 R193 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 43/111.7 R194 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 44.9/107.8 R195 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 61.6/111.4 R196 7030007350 S.RES ERJ2GEJ 393 X (39 k) B 44.4/111.3 R197 7030004980 S.RES ERJ2GEJ 101 X (100) B 45.7/106.2 R198 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 46.1/107.8 R199 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 52.9/110.7 R200 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 46.8/108.1 R201 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 72.1/139.6 R202 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 72.7/133.2 R203 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 77/117 R204 7030005530 S.RES ERJ2GEJ 100 X (10) T 38.2/137.9 R205 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 41.7/104.7 R206 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 47.7/108.1 R208 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 77/117.9 R209 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 74.1/133 R210 7030006070 S.RES ERJ12YJ101U (100) B 45.5/127 R211 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 44.8/104.3 R212 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 55.9/117.3 R213 7030005530 S.RES ERJ2GEJ 100 X (10) T 93.4/122.1 R215 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 103.1/106.1 R216 7030005530 S.RES ERJ2GEJ 100 X (10) T 106.4/123.2 R217 7030005710 S.RES ERJ2GEJ 121 X (120) T 72.4/122.5 R218 7030004980 S.RES ERJ2GEJ 101 X (100) T 86.4/122.5 R219 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 103.5/126.1 R220 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 85.1/119 R221 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 86/120.6 R222 7030010040 S.RES ERJ2GEJ-JPW T 56.8/131.9 R223 7030005710 S.RES ERJ2GEJ 121 X (120) T 56.3/122 R224 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 109.1/130.4 R225 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 63.3/113.2 R226 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 61.9/114.7 R227 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 85.2/122.1 R228 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 84.3/122.1 R229 7030004980 S.RES ERJ2GEJ 101 X (100) T 53.7/135.8 R230 7030004980 S.RES ERJ2GEJ 101 X (100) T 59.4/135.3 R231 7030005010 S.RES ERJ2GEJ 681 X (680) T 81.6/122.1 R232 7030005010 S.RES ERJ2GEJ 681 X (680) T 55.4/136.2 R233 7030004980 S.RES ERJ2GEJ 101 X (100) T 80.8/118.1 R234 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 56.9/138.9 R235 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 54.8/137.5 R236 7030010040 S.RES ERJ2GEJ-JPW T 78.4/123 R237 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 59/139.8 R238 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 59.5/137.9 R239 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 65.9/114 R240 7030005530 S.RES ERJ2GEJ 100 X (10) T 66.8/142.7 R241 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 13.5/148.2 R242 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 98.9/151.9 R243 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 35.5/146.7 R244 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 32.4/144.7 R245 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 34.7/148.8 R246 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 112/88.6 R247 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 117/92.2 R248 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 109.6/93.6

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 5

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R249 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 109/89.6 R251 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 115.3/82.7 R252 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 113.6/94.5 R253 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 114.4/83.6 R254 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 106.2/95.9 R255 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 112.3/81.3 R256 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 116.1/92.2 R257 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 108.7/93.6 R258 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 111.6/93.3 R259 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 106.2/92.7 R261 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 99.6/90.9 R262 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 111.9/86.8 R263 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 102.3/92.5 R264 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 99.6/90 R265 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 111.9/87.7 R266 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 116.9/97.4 R267 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 110.7/87.2 R268 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 108.7/98.1 R269 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 106.4/90.4 R270 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 107.6/90.4 R271 7030007310 S.RES ERJ2GEJ 155 X (1.5 M) T 112.7/94.5 R272 7030007280 S.RES ERJ2GEJ 331 X (330) T 115.8/96.3 R273 7030007310 S.RES ERJ2GEJ 155 X (1.5 M) T 105.3/95.9 R274 7030007280 S.RES ERJ2GEJ 331 X (330) T 107.8/98.1 R275 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 105.5/90 R276 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 111.9/85 R277 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 111.6/92.4 R278 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 110.3/85 R279 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 109.6/88.7 R280 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 105.3/94.2 R281 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 103.7/90 R282 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 108/88.7 R283 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 111.6/91.5 R284 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 105.3/91.8 R285 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 107.9/85 R286 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 103.7/88.4 R287 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 21.2/46.8 R288 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 110.4/91 R290 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 103.2/92 R292 7030010040 S.RES ERJ2GEJ-JPW B 20/44.7 R293 7030010040 S.RES ERJ2GEJ-JPW B 59.9/42.1 R294 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 102.5/87.4 R295 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 104.1/86.3 R296 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 102.5/86.5 R298 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 16.5/40.5 R299 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 21.2/45.9 R301 7030004980 S.RES ERJ2GEJ 101 X (100) B 55/40.9 R302 7030010040 S.RES ERJ2GEJ-JPW B 51.8/34 R303 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 55.8/37 R304 7030007060 S.RES ERJ2GEJ 684X (680 k) B 27.4/46.9 R305 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 57.5/74.1 R306 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 54.9/37.9 R307 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 51.5/60.7 R308 7030005000 S.RES ERJ2GEJ 471 X (470) B 54/65.9 R309 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 29.7/50.9 R310 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 52.3/38.6 R311 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 52.8/37.4 R312 7030007250 S.RES ERJ2GEJ 220 X (22) T 29.5/45.6 R313 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 26/40.9 R314 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 53.6/61.2 R315 7030010040 S.RES ERJ2GEJ-JPW B 54/67.5 R316 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 55.5/51.2 R317 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 54.8/60.7 R318 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 30.2/47.4 R319 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 51.9/37.4 R320 7030010040 S.RES ERJ2GEJ-JPW B 26.7/43.7 R321 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 56.1/61 R322 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 54.7/56.3 R323 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 54.7/48.8 R324 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 54.8/63.9 R325 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 31.6/47.4 R327 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 54.5/40.3 R328 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 54.5/41.2 R329 7030010040 S.RES ERJ2GEJ-JPW B 100.4/21.7 R330 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 62.2/59 R331 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 62.5/51.1 R332 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 51.9/42.8 R333 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 23.1/49.7 R334 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 59.3/64.3 R335 7030005000 S.RES ERJ2GEJ 471 X (470) T 52.9/40.3 R336 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 22.5/48.8 R337 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 24/43.5 R338 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 22.7/47.9 R339 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 84.3/46.1 R340 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 22.1/41.6 R341 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 57.3/61.9 R342 7030007280 S.RES ERJ2GEJ 331 X (330) T 59.8/68.7 R343 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 23.3/41.4 R344 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 21.6/39.5 R345 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 55.1/66.8 R346 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 53/65.6 R347 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.8/42.5 R348 7030005000 S.RES ERJ2GEJ 471 X (470) T 36.5/47.2 R349 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 37.7/47.5 R350 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 38.7/48.9 R351 7030004980 S.RES ERJ2GEJ 101 X (100) B 8.6/40.3 R352 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 7.6/38 R353 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 8.8/38.4 R354 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 44.5/39.1 R355 7030010040 S.RES ERJ2GEJ-JPW T 26.9/37.3 R356 7030007280 S.RES ERJ2GEJ 331 X (330) T 41.6/49.3 R358 7030005170 S.RES ERJ2GEJ 474 X (470 k) B 6/38 R359 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 7.9/36.8 R360 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 40/36.6

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R362 7030004980 S.RES ERJ2GEJ 101 X (100) T 27.8/37.3 R363 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 40.6/42.9 R364 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 38.8/42.9 R365 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 27.4/36.1 R366 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 5.2/36.8 R367 7030010040 S.RES ERJ2GEJ-JPW B 11.1/42.1 R368 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 58.7/42.8 R369 7030007280 S.RES ERJ2GEJ 331 X (330) T 27.4/34.3 R370 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 38.8/37.4 R372 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 8.5/59 R373 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 41.6/43.9 R374 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 7.3/39.4 R375 7030005000 S.RES ERJ2GEJ 471 X (470) B 8.5/65 R376 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 7.3/40.3 R377 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 41.2/45.1 R378 7030010040 S.RES ERJ2GEJ-JPW T 29/36.1 R379 7030004970 S.RES ERJ2GEJ 470 X (47) B 62.4/68.3 R380 7030005000 S.RES ERJ2GEJ 471 X (470) B 61.5/66.6 R381 7030005000 S.RES ERJ2GEJ 471 X (470) B 63.6/64.4 R382 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 36.3/38.4 R383 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 8.2/60.4 R384 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 65.6/65.9 R385 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 5.4/41.9 R386 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 37.3/43.3 R388 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 9.4/59.9 R389 7030010040 S.RES ERJ2GEJ-JPW B 8.5/66.6 R390 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 29.9/37 R394 7030008270 S.RES RR0510R-104-D (100 k) T 37.2/37.5 R395 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 63.8/67.9 R396 7030005000 S.RES ERJ2GEJ 471 X (470) T 5.6/39.4 R397 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 10.7/60.2 R398 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 16.5/69.2 R399 7030007280 S.RES ERJ2GEJ 331 X (330) B 67.2/66.8 R400 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 9.4/62.2 R402 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 6.3/50.3 R403 7030005820 S.RES RR0510P-103-D (10 k) T 36/41.1 R404 7030005820 S.RES RR0510P-103-D (10 k) T 42.9/36.3 R405 7030005820 S.RES RR0510P-103-D (10 k) T 36/42.7 R406 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 9.4/55.4 R407 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 9.4/47.9 R408 7030004970 S.RES ERJ2GEJ 470 X (47) T 37/43.8 R409 7030009270 S.RES ERJ2GEJ 821 X (820) T 40.1/39.5 R411 7030005820 S.RES RR0510P-103-D (10 k) T 43.2/38.4 R412 7030005750 S.RES RR0510R-470-D (47) T 44.3/40 R413 7030008280 S.RES ERJ2GEJ 271 X (270) T 46.3/34.9 R414 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 13.9/63.5 R415 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 7/65.5 R416 7030010040 S.RES ERJ2GEJ-JPW B 73.6/74.5 R417 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 16.7/59.5 R418 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 17/51.5 R419 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 12/61 R420 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 40/43.5 R421 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 41.5/41.6 R422 7030007280 S.RES ERJ2GEJ 331 X (330) T 16.1/68 R423 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 40.3/46.4 R426 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 44.3/42.4 R427 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 45.9/40.9 R428 7030010040 S.RES ERJ2GEJ-JPW T 37.8/60.7 R429 7030004970 S.RES ERJ2GEJ 470 X (47) B 15.8/67.5 R430 7030005000 S.RES ERJ2GEJ 471 X (470) B 16.7/66.6 R431 7030005000 S.RES ERJ2GEJ 471 X (470) B 18/63.5 R432 7030005590 S.RES ERJ2GEJ 680 X (68) T 44.6/45.6 R433 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 45.3/47.3 R434 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 20.4/65.5 R436 7030010040 S.RES ERJ2GEJ-JPW T 37.2/62.3 R438 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 19/68.9 R439 7030004990 S.RES ERJ2GEJ 221 X (220) B 21.7/65.9 R440 7030004970 S.RES ERJ2GEJ 470 X (47) T 63.1/88.3 R441 7030010040 S.RES ERJ2GEJ-JPW T 34.1/56.2 R443 7030010040 S.RES ERJ2GEJ-JPW T 68.8/81.5 R444 7030004990 S.RES ERJ2GEJ 221 X (220) T 67.5/86.3 R445 7030010040 S.RES ERJ2GEJ-JPW T 44/66.7 R446 7030010040 S.RES ERJ2GEJ-JPW T 44.9/65.8 R447 7030004990 S.RES ERJ2GEJ 221 X (220) T 68.6/87.4 R448 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 46/56.1 R449 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 36.3/55.6 R450 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 36.8/68.3 R452 7030010040 S.RES ERJ2GEJ-JPW B 28.7/73.7 R453 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 67.9/82.4 R455 7030010040 S.RES ERJ2GEJ-JPW T 40.2/60 R457 7030005530 S.RES ERJ2GEJ 100 X (10) T 30.7/59.9 R460 7030010040 S.RES ERJ2GEJ-JPW T 39.4/61.7 R461 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 52.2/96 R462 7030004970 S.RES ERJ2GEJ 470 X (47) T 13.6/88.6 R463 7030010040 S.RES ERJ2GEJ-JPW T 19.3/81.7 R464 7030004990 S.RES ERJ2GEJ 221 X (220) T 18/86.5 R465 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 31.6/70.6 R466 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 39.9/69.1 R467 7030004990 S.RES ERJ2GEJ 221 X (220) T 19.2/87.7 R469 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 22.9/87.4 R470 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 39.9/70.7 R471 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 11.5/96.6 R472 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 7.1/122.8 R473 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 122/23.9 R475 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 121.6/91.3 R476 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 121.4/76.6 R477 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 100.4/130.4 R478 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 121.6/92.2 R479 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 117/77.1 R480 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 115.9/86.2 R481 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 124.8/81.4 R482 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 116.8/86.2 R483 7030000020 S.RES MCR10EZHJ 1 (010) T 128/20.6 R484 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 118.3/77.1

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 6

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R485 7030000400 S.RES MCR10EZHJ 1.5 k B 98.7/120.5 R486 7030004980 S.RES ERJ2GEJ 101 X (100) T 110.1/63.1 R489 7030004980 S.RES ERJ2GEJ 101 X (100) T 126.3/74 R490 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 124/24.8 R493 7030004980 S.RES ERJ2GEJ 101 X (100) T 128.7/74.3 R494 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 8.4/33.2 R495 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 6.8/33.2 R497 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 123.6/23.9 R498 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 101.6/102.2 R499 7030005000 S.RES ERJ2GEJ 471 X (470) B 103.4/101.3 R500 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 101.8/104.5 R501 7030005000 S.RES ERJ2GEJ 471 X (470) B 102.2/105.7 R504 7030004980 S.RES ERJ2GEJ 101 X (100) T 125.7/24.8 R506 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 125.2/23.9 R508 7030004980 S.RES ERJ2GEJ 101 X (100) B 128.7/65.7 R509 7510001770 S.TMR NTCG10 4LH 473JT B 113.6/89.2 R510 7030007350 S.RES ERJ2GEJ 393 X (39 k) B 112.4/89.6 R511 7030004980 S.RES ERJ2GEJ 101 X (100) B 116.3/88.6 R512 7030004980 S.RES ERJ2GEJ 101 X (100) B 117.2/88.8 R514 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 7.6/29.7 R515 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 6/29.7 R516 7410001230 S.ARY EXB28V101JX B 126.9/65.8 R517 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 9.6/31.4 R518 7030004980 S.RES ERJ2GEJ 101 X (100) B 106.5/83.1 R519 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.4/31.9 R520 7410001230 S.ARY EXB28V101JX B 108.5/85.2 R521 7030005521 S.RES ERA3YKD 334V (330 k) T 116.9/68.4 R522 7030005501 S.RES ERA3YKD 124V (120 k) T 118.1/67.5 R523 7030005691 S.RES ERA3YED 123V (12 k) T 118.8/69.6 R524 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 117.8/65.4 R525 7410001230 S.ARY EXB28V101JX B 110.6/87.2 R527 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 15.7/28.6 R529 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 13.2/27.4 R530 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 114.1/65.9 R532 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 13.8/30.2 R533 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 13.8/28.6 R534 7030004980 S.RES ERJ2GEJ 101 X (100) T 107.9/65.5 R536 7030004980 S.RES ERJ2GEJ 101 X (100) T 112/63.4 R537 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.9/30.5 R538 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 16.7/28.6 R539 7030004980 S.RES ERJ2GEJ 101 X (100) B 124.2/65.3 R540 7030004980 S.RES ERJ2GEJ 101 X (100) B 125.1/66 R541 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 17.6/28.6 R545 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 19.9/28.6 R547 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 25.5/25.9 R549 7030010040 S.RES ERJ2GEJ-JPW T 24.3/27.7 R550 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 22.5/22.8 R552 7030004980 S.RES ERJ2GEJ 101 X (100) B 98.8/75.3 R553 7030004980 S.RES ERJ2GEJ 101 X (100) T 119.4/66.6 R554 7410001230 S.ARY EXB28V101JX B 120.6/61.1 R556 7410001230 S.ARY EXB28V101JX B 102.8/66.7 R557 7030004980 S.RES ERJ2GEJ 101 X (100) T 107.9/67.5 R558 7410001230 S.ARY EXB28V101JX B 99/70 R559 7410001230 S.ARY EXB28V101JX B 110.6/59 R560 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 24.3/26.1 R561 7410001230 S.ARY EXB28V101JX B 105.8/62.5 R562 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 19/27 R563 7410001230 S.ARY EXB28V101JX B 101/68.4 R564 7410001230 S.ARY EXB28V101JX B 104.6/64.9 R566 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 21.3/23.7 R567 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 110.1/79.3 R568 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 110.5/78.1 R569 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 64.8/5.6 R570 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 30.6/28 R571 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 43.7/12.6 R572 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 112.2/98.1 R573 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 110.4/98.1 R574 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 27.3/23.9 R575 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) B 28.5/23.5 R577 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 36.5/20 R578 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 37.3/24.1 R579 7030010040 S.RES ERJ2GEJ-JPW B 66.3/12.7 R581 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 58.3/7.7 R582 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 36.1/25.7 R583 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 36.1/24.1 R584 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 37/25.7 R585 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 37/24.1 R586 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 113.1/98.1 R587 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 111.3/98.1 R588 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 50.6/10.4 R589 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 33.3/24 R590 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 65.7/5.6 R591 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 74.6/4.4 R592 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 114.3/101.2 R593 7030005010 S.RES ERJ2GEJ 681 X (680) T 115.9/103.1 R594 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 59/9.6 R598 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) B 65/8 R600 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) B 40/14.3 R608 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 108.5/101.8 R609 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 105.3/104.2 R610 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 106.7/101.8 R611 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 105.8/101.8 R612 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 107.6/101.8 R613 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 105.7/103 R614 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) B 65/6.4 R615 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 99.4/32.7 R616 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 65/9.6 R617 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 120.1/41.7 R618 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 115.4/40.4 R619 7030005000 S.RES ERJ2GEJ 471 X (470) T 116.6/40.9 R620 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 121.3/41.4 R621 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 116.7/44.4 R623 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 118.5/99.4 R624 7030004980 S.RES ERJ2GEJ 101 X (100) B 70.2/14.7

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R625 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 125.9/114.3 R626 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 120.9/108.1 R627 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 112.5/77.7 R628 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 70.4/17.9 R630 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 127.9/107.5 R631 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 120.9/106.3 R632 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 114/77.5 R635 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 122.6/104.9 R637 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 70.4/16.1 R638 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 127.5/113.4 R639 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 122.5/107.2 R640 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) B 59.7/17.7 R641 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 128.3/108.7 R642 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 123.2/111.8 R643 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 70.4/17 R644 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 114.4/76.3 R645 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 114.9/77.5 R647 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 127.6/109.2 R649 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 125/107.2 R653 7030009280 S.RES ERJ2GEJ 391 X T 128.7/103.9 R658 7030009280 S.RES ERJ2GEJ 391 X T 128.7/116.1 R659 7030000100 S.RES MCR10EZHJ 4.7 (4R7) T 124.8/142.5 R660 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 61.4/17.2 R661 7030000100 S.RES MCR10EZHJ 4.7 (4R7) T 104.7/145.9 R663 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 125.2/106.3 R664 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 61.4/18.8 R665 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 122.6/144.3 R677 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 75.9/47.6 R678 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 65.8/45.9 R679 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 65.8/46.8 R680 7030010040 S.RES ERJ2GEJ-JPW B 64.6/44.8 R681 7030005530 S.RES ERJ2GEJ 100 X (10) B 73.5/46 R682 7030007060 S.RES ERJ2GEJ 684X (680 k) B 71.8/46.7 R683 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 70.6/40.9 R684 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 75/47.6 R685 7030007250 S.RES ERJ2GEJ 220 X (22) T 75.1/45.7 R686 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 68.1/49.8 R688 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 67.4/48.8 R690 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 67.4/47.9 R694 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 72/37.5 R695 7030004980 S.RES ERJ2GEJ 101 X (100) T 72.8/36.6 R696 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 71.5/36.3 R697 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 74.6/35.1 R698 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 72.4/34.7 R699 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 80.6/44.6 R700 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 79.3/41.8 R701 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 82.2/44.6 R702 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 81.8/43.4 R703 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 85.7/35 R704 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 83.6/35.8 R705 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 84/38.5 R706 7030009530 S.RES ERJ2GEJ 270 X (27) T 84.9/58.4 R707 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 75.2/49.2 R708 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 88.1/39.3 R709 7030010040 S.RES ERJ2GEJ-JPW T 85.3/61.3 R710 7030007260 S.RES ERJ2GEJ 330 X (33) T 84.9/57.5 R711 7030009530 S.RES ERJ2GEJ 270 X (27) T 83.3/58.4 R712 7030004970 S.RES ERJ2GEJ 470 X (47) T 86.9/44.2 R713 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 86.9/42.6 R714 7030009270 S.RES ERJ2GEJ 821 X (820) T 90.3/39.1 R716 7030010040 S.RES ERJ2GEJ-JPW T 84.5/62.9 R717 7030005710 S.RES ERJ2GEJ 121 X (120) T 90.3/42.3 R718 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 83.6/57.2 R719 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 83.7/47.6 R720 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 86.3/63.8 R721 7030004990 S.RES ERJ2GEJ 221 X (220) T 82.3/47.6 R722 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 82.5/60.3 R723 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 88.7/45.3 R724 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 90.3/45.3 R725 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 85.3/49.2 R726 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 84.9/48 R727 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 88.7/44.4 R728 7030005010 S.RES ERJ2GEJ 681 X (680) T 87.7/49.5 R733 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 84.6/70.7 R734 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 80.7/68.3 R737 7030010040 S.RES ERJ2GEJ-JPW T 88.6/61.3 R738 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 78.8/70.8 R739 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 89.5/61.3 R741 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 86.2/69.8 R742 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 75.7/63.8 R743 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 75.9/61.4 R744 7030005590 S.RES ERJ2GEJ 680 X (68) T 75.3/60.2 R745 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 75.7/69.5 R747 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 45.3/60.4 R748 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 41.6/47.7 R750 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 36.6/58.7 R752 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 45.3/62 R754 7030007250 S.RES ERJ2GEJ 220 X (22) T 14/111.5 R755 7030007250 S.RES ERJ2GEJ 220 X (22) T 83.8/108 R756 7030010040 S.RES ERJ2GEJ-JPW T 68.6/108.1 R757 7030010040 S.RES ERJ2GEJ-JPW T 36/105.2 R758 7030004980 S.RES ERJ2GEJ 101 X (100) T 90.9/11.1 R759 7030004980 S.RES ERJ2GEJ 101 X (100) T 90.2/6.5 R762 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 60.5/19.8 R763 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 60.2/16.1 R764 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 60.2/15.2 R765 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 60.2/14.3 R766 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 70.1/15.8 R767 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 64.4/21.3 R768 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 59.3/19.3 R769 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 60.1/18.4 R770 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 114.4/69.1 R771 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 70/20 R772 7030005000 S.RES ERJ2GEJ 471 X (470) T 73.5/19.7

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 7

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R773 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 73.5/20.6 R774 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 72.5/18.8 R775 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 72.3/20 R777 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 103.4/36.7 R778 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 105/36.7 R779 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 104.8/28.2 R780 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 104.8/27.3 R781 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 103.2/27.3 R782 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 107/33.3 R783 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 107/31.6 R784 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 70.4/17 R785 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 64.4/22.2 R786 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 74.6/11.8 R787 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 102.3/30 R788 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 101.9/32.1 R789 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 118.9/142.1 R790 7030004980 S.RES ERJ2GEJ 101 X (100) T 66.9/91.5 R791 7030004980 S.RES ERJ2GEJ 101 X (100) T 66.9/90.2 R792 7030004980 S.RES ERJ2GEJ 101 X (100) T 17.5/91.7 R793 7030004980 S.RES ERJ2GEJ 101 X (100) T 17.5/89.5 R794 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 12.9/67.6 R795 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 58/68.4 R796 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 98.2/31 R797 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 101.9/28.3 R798 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 100.6/30.1 R799 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 98.4/28.3 R800 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 99.4/30.5 R801 7030005530 S.RES ERJ2GEJ 100 X (10) B 27.3/24.8 R802 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 36.5/21.6 R804 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 72.5/17 R805 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 60.8/27.3 R806 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 60.6/24.8 R807 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 56.4/27.3 R808 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 55.9/26.1 R809 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 45.1/32.8 R810 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 60.1/26 R811 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 9.8/66 R812 7410001230 S.ARY EXB28V101JX B 101.8/78.4 R813 7410001230 S.ARY EXB28V101JX B 108.8/60.7 R814 7410001230 S.ARY EXB28V101JX B 100/76.6 R815 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 123.3/85.8 R816 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 121.9/87.9 R817 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 120.4/79.4 R818 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 120.4/78.5 R819 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 120.4/77.6 R820 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 123.4/53.5 R821 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 120.7/53.1 R822 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 120.7/54 R823 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 105.3/53.9 R825 7030004980 S.RES ERJ2GEJ 101 X (100) T 120.3/67.9 R826 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 104.4/53.9 R827 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 112.6/53.7 R828 7030010040 S.RES ERJ2GEJ-JPW T 114.7/105.4 R829 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 109.4/99.5 R830 7030004980 S.RES ERJ2GEJ 101 X (100) B 128.7/69.6 R831 7410001230 S.ARY EXB28V101JX B 119/86.6 R832 7030004980 S.RES ERJ2GEJ 101 X (100) B 120/85.1 R833 7030004980 S.RES ERJ2GEJ 101 X (100) B 120.7/84.5 R835 7030004980 S.RES ERJ2GEJ 101 X (100) T 127.8/73.5 R836 7030004980 S.RES ERJ2GEJ 101 X (100) T 127.6/75.5 R838 7410001230 S.ARY EXB28V101JX B 118.8/59.3 R839 7030004980 S.RES ERJ2GEJ 101 X (100) B 117.7/57.9 R840 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 71.2/37.7 R841 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 73.3/34.7 R842 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 67.2/34.9 R843 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 68.6/35.3 R844 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 30.2/31.5 R845 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 27.8/36.6 R846 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 27.4/35.2 R847 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 29.1/36.2 R848 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 74.8/39.3 R849 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 28.6/41.4 R850 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 112.7/119.5 R851 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 121.4/82.5 R852 7520000250 S.POS PRF18BE471QB1RB T 78.7/149.4 R853 7520000250 S.POS PRF18BE471QB1RB T 42.6/138.9 R856 7030004980 S.RES ERJ2GEJ 101 X (100) T 36.5/122.7 R857 7030010040 S.RES ERJ2GEJ-JPW T 34.2/117.5 R858 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 124.8/25.7 R859 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 121.7/26.1 R860 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 107.3/81.1 R861 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 104.1/70.1 R862 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 114.3/100.3 R863 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 108.9/79.7 R864 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 105.2/84.3 R865 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 121.1/69.9 R866 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 121.5/65.5 R867 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 121.5/63 R868 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 114.8/52.8 R869 7030010040 S.RES ERJ2GEJ-JPW T 70.6/43 R870 7030010040 S.RES ERJ2GEJ-JPW T 74.8/42.2 R871 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 111.9/118.6 R872 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 111.9/117.7 R873 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 7/119 R874 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 100.6/97.7 R875 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 46.1/126.9 R876 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 49.6/118.5 R877 7030010040 S.RES ERJ2GEJ-JPW T 37/138.3 R878 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 100.5/38.1 R879 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 99.4/37.2 R880 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 107.7/57.2 R881 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 103/55.8 R882 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 111.6/55.4 R883 7030010040 S.RES ERJ2GEJ-JPW T 128.5/58.9

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

R884 7510001770 S.TMR NTCG10 4LH 473JT T 52.7/61.2 R885 7510001770 S.TMR NTCG10 4LH 473JT T 7.3/60.4

C1 4030016930 S.CER ECJ0EB1A104K B 97.3/104 C2 4030016930 S.CER ECJ0EB1A104K T 8/119 C3 4030017460 S.CER ECJ0EB1E102K B 99/99.7 C4 4030016930 S.CER ECJ0EB1A104K T 20.7/111.9 C5 4030017460 S.CER ECJ0EB1E102K B 87.2/107.1 C6 4030017460 S.CER ECJ0EB1E102K T 5.8/89.1 C7 4030017460 S.CER ECJ0EB1E102K T 103.6/85.8 C8 4030017460 S.CER ECJ0EB1E102K T 90/74.9 C9 4030017460 S.CER ECJ0EB1E102K T 46.6/82.9 C10 4030017460 S.CER ECJ0EB1E102K T 17.7/97.7 C11 4030017460 S.CER ECJ0EB1E102K T 72.4/96.3 C12 4030017430 S.CER ECJ0EC1H101J T 12.8/99.3 C13 4030017560 S.CER ECJ0EC1H2R5B T 14.1/99 C14 4030017560 S.CER ECJ0EC1H2R5B T 72.8/100.5 C15 4030017570 S.CER ECJ0EC1H040B T 10.4/100.2 C16 4030017460 S.CER ECJ0EB1E102K T 85.9/77.8 C17 4030016930 S.CER ECJ0EB1A104K T 104.1/102.8 C18 4030016930 S.CER ECJ0EB1A104K T 19.3/128.7 C19 4030017460 S.CER ECJ0EB1E102K B 88/88.4 C21 4030017460 S.CER ECJ0EB1E102K T 18.2/100.4 C23 4030017460 S.CER ECJ0EB1E102K T 77.3/96.8 C24 4030017570 S.CER ECJ0EC1H040B T 11/105 C25 4030017560 S.CER ECJ0EC1H2R5B T 15.3/99.3 C26 4030017560 S.CER ECJ0EC1H2R5B T 73.9/99.4 C27 4030017340 S.CER ECJ0EC1H010B T 10.6/107.1 C28 4030017460 S.CER ECJ0EB1E102K T 18.2/102.9 C29 4030017530 S.CER ECJ0EC1H0R5B T 14.1/103.8 C30 4030017460 S.CER ECJ0EB1E102K T 53.9/29.8 C31 4030017660 S.CER ECJ0EC1H330J B 88.6/65.7 C32 4030017530 S.CER ECJ0EC1H0R5B T 15.8/103.8 C33 4030017590 S.CER ECJ0EC1H070C T 17/102.5 C34 4030017590 S.CER ECJ0EC1H070C T 77.3/99.9 C35 4030017460 S.CER ECJ0EB1E102K T 10.6/106.2 C36 4030017520 S.CER ECJ0EC1H0R3B T 76.8/102.9 C37 4030017640 S.CER ECJ0EC1H150J T 17/105.2 C38 4030017530 S.CER ECJ0EC1H0R5B T 78/101.8 C39 4030017460 S.CER ECJ0EB1E102K T 78/99.3 C40 4030017460 S.CER ECJ0EB1E102K T 18.2/104.7 C41 4030017640 S.CER ECJ0EC1H150J T 79.9/102.5 C43 4030017670 S.CER ECJ0EC1H390J B 90.1/65.7 C44 4030016930 S.CER ECJ0EB1A104K T 35.2/76.2 C45 4030017460 S.CER ECJ0EB1E102K T 80.4/101.7 C46 4030017600 S.CER ECJ0EC1H080C T 14.1/107.7 C47 4030017460 S.CER ECJ0EB1E102K T 18.9/108.7 C48 4030017570 S.CER ECJ0EC1H040B T 14.6/109.1 C49 4030017600 S.CER ECJ0EC1H080C T 79.6/105.7 C50 4030017570 S.CER ECJ0EC1H040B T 81.4/107 C51 4030017460 S.CER ECJ0EB1E102K T 83.3/103.4 C53 4030017340 S.CER ECJ0EC1H010B T 11.4/113.1 C54 4030017660 S.CER ECJ0EC1H330J B 89.4/69 C55 4030017610 S.CER ECJ0EC1H090C T 15.3/108.1 C56 4030017610 S.CER ECJ0EC1H090C T 80.7/106.3 C57 4030017340 S.CER ECJ0EC1H010B T 11.1/115.3 C58 4030017460 S.CER ECJ0EB1E102K T 17/110 C59 4030017460 S.CER ECJ0EB1E102K B 92.1/71.5 C60 4030017640 S.CER ECJ0EC1H150J B 45.2/68.8 C61 4030017460 S.CER ECJ0EB1E102K T 17.5/112.4 C62 4030017460 S.CER ECJ0EB1E102K T 83.3/106 C63 4030017460 S.CER ECJ0EB1E102K T 85.6/105.6 C64 4030017370 S.CER ECJ0EC1H3R5B T 11.1/120.2 C65 4030017460 S.CER ECJ0EB1E102K B 90.3/70.7 C66 4030017460 S.CER ECJ0EB1E102K T 16/114.6 C67 4030017550 S.CER ECJ0EC1H1R5B T 10.6/121.4 C68 4030017460 S.CER ECJ0EB1E102K B 42.6/73.9 C69 4030017460 S.CER ECJ0EB1E102K B 78.4/76.5 C70 4030017620 S.CER ECJ0EC1H100C B 43.4/69.7 C71 4030017600 S.CER ECJ0EC1H080C T 15.7/115.8 C72 4030017460 S.CER ECJ0EB1E102K T 12.3/128.1 C73 4030017460 S.CER ECJ0EB1E102K T 13/122.9 C74 4030017460 S.CER ECJ0EB1E102K T 12.7/115.5 C75 4030017460 S.CER ECJ0EB1E102K T 88/104.5 C76 4030017460 S.CER ECJ0EB1E102K T 86.8/109.4 C77 4030017360 S.CER ECJ0EC1H030B T 17/116.2 C78 4030017600 S.CER ECJ0EC1H080C T 89.6/107 C79 4030017460 S.CER ECJ0EB1E102K B 79.6/76.1 C80 4510008520 S.ELE EEE1CA470SP T 51.8/128.3 C81 4030017460 S.CER ECJ0EB1E102K B 87.5/71.9 C82 4030017360 S.CER ECJ0EC1H030B T 90.9/106.5 C83 4030017460 S.CER ECJ0EB1E102K B 82.4/74.4 C84 4030017350 S.CER ECJ0EC1H020B B 86.1/70.4 C85 4030017460 S.CER ECJ0EB1E102K T 19.7/116.4 C86 4030017460 S.CER ECJ0EB1E102K B 45.5/75.3 C87 4030017360 S.CER ECJ0EC1H030B B 41.3/74.9 C88 4030017460 S.CER ECJ0EB1E102K T 51.3/118.1 C89 4030017460 S.CER ECJ0EB1E102K B 81/72.8 C90 4030017460 S.CER ECJ0EB1E102K T 90.1/102.8 C91 4030017590 S.CER ECJ0EC1H070C T 18.9/118.5 C92 4030017460 S.CER ECJ0EB1E102K T 20.1/118.9 C93 4030017360 S.CER ECJ0EC1H030B B 40.1/75.4 C94 4030017460 S.CER ECJ0EB1E102K T 50.7/132.3 C95 4030017370 S.CER ECJ0EC1H3R5B T 11.1/127.4 C96 4030017530 S.CER ECJ0EC1H0R5B T 14.5/120 C97 4030017530 S.CER ECJ0EC1H0R5B T 17.8/120.6 C98 4030017590 S.CER ECJ0EC1H070C T 93.1/104.4 C99 4030017460 S.CER ECJ0EB1E102K T 94.7/103.5 C100 4030017520 S.CER ECJ0EC1H0R3B T 95.5/107 C101 4030017530 S.CER ECJ0EC1H0R5B T 95.5/105.4 C102 4030017590 S.CER ECJ0EC1H070C T 18.7/121.5 C103 4030017460 S.CER ECJ0EB1E102K T 19.6/121.5 C104 4030017350 S.CER ECJ0EC1H020B B 38.5/76.6

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 8

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C105 4030017590 S.CER ECJ0EC1H070C T 97.4/104.4 C106 4030017460 S.CER ECJ0EB1E102K T 97.3/103.2 C107 4030017460 S.CER ECJ0EB1E102K T 19.8/123.3 C108 4030017460 S.CER ECJ0EB1E102K T 100.3/102 C109 4030017650 S.CER ECJ0EC1H270J B 84.5/77.3 C110 4030017630 S.CER ECJ0EC1H120J B 85.7/77.9 C111 4030017460 S.CER ECJ0EB1E102K B 36/79.9 C112 4030017360 S.CER ECJ0EC1H030B T 15.9/123.9 C113 4030017360 S.CER ECJ0EC1H030B T 100/105.7 C114 4030017550 S.CER ECJ0EC1H1R5B T 14.7/124.3 C115 4030017550 S.CER ECJ0EC1H1R5B T 98.1/108.4 C116 4030017460 S.CER ECJ0EB1E102K T 102.2/108.6 C117 4030017460 S.CER ECJ0EB1E102K T 15.7/129 C118 4030017460 S.CER ECJ0EB1E102K T 98.1/110 C119 4030017460 S.CER ECJ0EB1E102K T 103.1/108.6 C120 4030017460 S.CER ECJ0EB1E102K T 18.3/126.7 C121 4030017460 S.CER ECJ0EB1E102K B 79.1/80.6 C122 4030017460 S.CER ECJ0EB1E102K B 35.2/75.3 C123 4030017590 S.CER ECJ0EC1H070C B 42.8/82.9 C124 4030017350 S.CER ECJ0EC1H020B B 41.5/84.3 C125 4030017350 S.CER ECJ0EC1H020B B 40/84.3 C126 4030017350 S.CER ECJ0EC1H020B T 99/116.1 C127 4030017460 S.CER ECJ0EB1E102K T 29.8/130.1 C128 4030017460 S.CER ECJ0EB1E102K T 99.4/114.4 C129 4030017460 S.CER ECJ0EB1E102K B 78.7/75.3 C130 4030017460 S.CER ECJ0EB1E102K B 80.7/80.6 C131 4030017660 S.CER ECJ0EC1H330J B 87.3/83.9 C132 4030017620 S.CER ECJ0EC1H100C B 86.8/85.1 C133 4030017350 S.CER ECJ0EC1H020B T 25/129.2 C134 4510008540 S.ELE EEE1CA100SR T 79.5/77.4 C135 4030017460 S.CER ECJ0EB1E102K T 27.4/136 C136 4030017460 S.CER ECJ0EB1E102K T 28.7/132.3 C137 4030017460 S.CER ECJ0EB1E102K T 26.1/132.1 C138 4030017460 S.CER ECJ0EB1E102K B 99.5/96.1 C139 4030017460 S.CER ECJ0EB1E102K T 103.9/114.8 C140 4030017460 S.CER ECJ0EB1E102K T 103/114.8 C141 4030017390 S.CER ECJ0EC1H180J B 85.4/85.1 C142 4030017460 S.CER ECJ0EB1E102K B 44/86.7 C143 4030017460 S.CER ECJ0EB1E102K B 40.1/86.8 C144 4030017460 S.CER ECJ0EB1E102K B 39.1/89.3 C145 4030017460 S.CER ECJ0EB1E102K B 44/87.6 C146 4030017360 S.CER ECJ0EC1H030B T 29.6/134.2 C147 4030017360 S.CER ECJ0EC1H030B T 104.8/114.8 C148 4030017460 S.CER ECJ0EB1E102K T 29.1/136.4 C149 4030017460 S.CER ECJ0EB1E102K T 105.7/115.7 C150 4030017460 S.CER ECJ0EB1E102K B 38.6/86.8 C151 4030017460 S.CER ECJ0EB1E102K B 43.6/118.5 C152 4030017460 S.CER ECJ0EB1E102K T 22.4/129.4 C153 4030017460 S.CER ECJ0EB1E102K T 49.2/116.4 C154 4030017460 S.CER ECJ0EB1E102K B 87.9/114.5 C155 4030011160 S.CER GRM31M2C2H150JV01L B 84.8/124.7 C156 4030017460 S.CER ECJ0EB1E102K B 46/103.9 C157 4030011210 S.CER GRM31M2C2H330JV01L B 87.1/133.8 C159 4030017460 S.CER ECJ0EB1E102K T 62.5/99 C160 4030017360 S.CER ECJ0EC1H030B T 22.3/99.2 C161 4030011020 S.CER GRM31M4C2H1R0CY21L B 83.6/131.4 C162 4030011140 S.CER GRM31M2C2H120JV01L B 80.2/133.9 C163 4030017600 S.CER ECJ0EC1H080C T 26.1/99.8 C164 4030017460 S.CER ECJ0EB1E102K B 78.5/132.3 C165 4030017460 S.CER ECJ0EB1E102K B 83.6/88.3 C166 4030011020 S.CER GRM31M4C2H1R0CY21L B 36.4/121.4 C167 4030017460 S.CER ECJ0EB1E102K T 53.6/98.9 C168 4030017360 S.CER ECJ0EC1H030B T 68.6/97.6 C169 4030017600 S.CER ECJ0EC1H080C T 67.2/99.6 C170 4030017460 S.CER ECJ0EB1E102K T 57.1/98.1 C171 4030017460 S.CER ECJ0EB1E102K T 60/98.9 C173 4030011020 S.CER GRM31M4C2H1R0CY21L B 40.5/118.2 C174 4030011150 S.CER GRM31M2C2H130JV01L B 37.1/116.7 C175 4030017430 S.CER ECJ0EC1H101J T 29.6/103.1 C176 4030017460 S.CER ECJ0EB1E102K B 39.2/114.9 C178 4550002980 S.TAN TEESVA 1C 225M8R B 37.6/102.3 C179 4030017460 S.CER ECJ0EB1E102K T 30.5/104.7 C181 4030017430 S.CER ECJ0EC1H101J T 69.4/102.5 C182 4030017530 S.CER ECJ0EC1H0R5B T 31.4/100.5 C183 4030017460 S.CER ECJ0EB1E102K B 35.5/105 C184 4030017460 S.CER ECJ0EB1E102K T 71.1/102.5 C185 4030017660 S.CER ECJ0EC1H330J T 31.4/102.1 C186 4030017460 S.CER ECJ0EB1E102K B 75/133 C187 4030017530 S.CER ECJ0EC1H0R5B T 66.1/104.1 C188 4030017660 S.CER ECJ0EC1H330J T 69.4/104.1 C189 4030017460 S.CER ECJ0EB1E102K T 33.2/103.9 C190 4030017460 S.CER ECJ0EB1E102K B 33.7/106.6 C191 4030017430 S.CER ECJ0EC1H101J T 33.2/103 C192 4550002980 S.TAN TEESVA 1C 225M8R B 89.7/89.9 C193 4030017460 S.CER ECJ0EB1E102K T 71.2/105.8 C194 4030017460 S.CER ECJ0EB1E102K T 56.9/100.3 C195 4030017430 S.CER ECJ0EC1H101J T 69.5/105.7 C196 4030017370 S.CER ECJ0EC1H3R5B T 53.6/102.1 C197 4030017460 S.CER ECJ0EB1E102K T 63.4/100.3 C198 4030011020 S.CER GRM31M4C2H1R0CY21L B 79.7/139.9 C199 4030017460 S.CER ECJ0EB1E102K B 40.8/112.1 C200 4030017360 S.CER ECJ0EC1H030B T 60/102.1 C202 4030011020 S.CER GRM31M4C2H1R0CY21L B 79.7/137.5 C203 4030011120 S.CER GRM31M2C2H100JV01L B 74.8/137.1 C205 4030017430 S.CER ECJ0EC1H101J T 54.8/102.5 C206 4030017460 S.CER ECJ0EB1E102K T 67.4/107.6 C207 4030017460 S.CER ECJ0EB1E102K T 35.6/102.8 C208 4030017460 S.CER ECJ0EB1E102K T 37.3/103.1 C209 4030016950 S.CER ECJ0EB1A473K B 35.5/106.6 C210 4030017460 S.CER ECJ0EB1E102K B 34.6/109.1 C211 4030017430 S.CER ECJ0EC1H101J T 61.2/102.5 C212 4030017460 S.CER ECJ0EB1E102K B 76.8/139 C213 4030017460 S.CER ECJ0EB1E102K T 56/104.8 C214 4030011060 S.CER GRM31M2C2H4R0CY21L B 40.5/121.6

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C215 4030017460 S.CER ECJ0EB1E102K T 72.5/107.6 C216 4030016930 S.CER ECJ0EB1A104K B 35.5/109.1 C217 4030017460 S.CER ECJ0EB1E102K T 62.4/104.8 C218 4030017460 S.CER ECJ0EB1E102K T 38.5/103.3 C219 4030017460 S.CER ECJ0EB1E102K T 72.1/109.2 C220 4030017460 S.CER ECJ0EB1E102K B 86.9/143.8 C221 4030017460 S.CER ECJ0EB1E102K B 40.8/111.2 C222 4030017460 S.CER ECJ0EB1E102K T 58.1/104 C223 4030017460 S.CER ECJ0EB1E102K T 64.6/104 C224 4030011060 S.CER GRM31M2C2H4R0CY21L B 37.4/131.1 C225 4510008110 S.ELE 16 CE 22 BS T 82.7/142.6 C226 4030017460 S.CER ECJ0EB1E102K B 73/139.6 C227 4030017200 S.CER GRM31BR32J102KY01L B 80.5/143.3 C228 4030016790 S.CER ECJ0EB1C103K B 43.3/102.5 C229 4030017460 S.CER ECJ0EB1E102K T 40.3/106.5 C230 4030017460 S.CER ECJ0EB1E102K B 44.2/123.3 C231 4030017460 S.CER ECJ0EB1E102K B 28.5/136 C232 4030017460 S.CER ECJ0EB1E102K B 43/110.8 C233 4030017460 S.CER ECJ0EB1E102K T 40.9/107.2 C234 4030017360 S.CER ECJ0EC1H030B T 54.9/107.7 C235 4030017460 S.CER ECJ0EB1E102K T 68.6/109.8 C236 4030017600 S.CER ECJ0EC1H080C T 42.5/108.7 C237 4030017460 S.CER ECJ0EB1E102K T 60.1/109 C238 4030016930 S.CER ECJ0EB1A104K B 43/109.9 C239 4030017360 S.CER ECJ0EC1H030B T 61.3/107.7 C240 4030017460 S.CER ECJ0EB1E102K B 86.9/146.1 C241 4030016950 S.CER ECJ0EB1A473K B 44/107.8 C242 4030017600 S.CER ECJ0EC1H080C T 73.3/112.9 C243 4030017460 S.CER ECJ0EB1E102K T 65.4/110.2 C244 4030017460 S.CER ECJ0EB1E102K T 72.1/110.8 C246 4030017460 S.CER ECJ0EB1E102K B 88.5/87.3 C247 4030017430 S.CER ECJ0EC1H101J T 63.8/109.4 C249 4030017430 S.CER ECJ0EC1H101J T 57.3/109.4 C251 4030017460 S.CER ECJ0EB1E102K T 38.2/138.8 C252 4030017430 S.CER ECJ0EC1H101J T 45.9/108.1 C253 4030017370 S.CER ECJ0EC1H3R5B T 60.4/110.9 C254 4030017460 S.CER ECJ0EB1E102K B 45.6/110.2 C255 4030017370 S.CER ECJ0EC1H3R5B T 53.9/110.7 C256 4030017430 S.CER ECJ0EC1H101J T 76.5/115.8 C257 4030017460 S.CER ECJ0EB1E102K T 46.4/106.4 C258 4030017540 S.CER ECJ0EC1HR75B T 47.3/110.9 C259 4030017460 S.CER ECJ0EB1E102K T 78.6/117 C260 4030017530 S.CER ECJ0EC1H0R5B T 72.5/117.5 C261 4030017660 S.CER ECJ0EC1H330J T 75.8/117.5 C262 4030017660 S.CER ECJ0EC1H330J T 47.3/109.3 C263 4030017460 S.CER ECJ0EB1E102K B 73.3/134.7 C264 4030017460 S.CER ECJ0EB1E102K T 48.2/106.9 C265 4030017460 S.CER ECJ0EB1E102K B 32.4/133.8 C266 4030011160 S.CER GRM31M2C2H150JV01L B 78.7/147.2 C267 4030017460 S.CER ECJ0EB1E102K T 78.2/118.4 C268 4030017430 S.CER ECJ0EC1H101J T 48.6/108.1 C270 4510008110 S.ELE 16 CE 22 BS T 43.8/130.3 C271 4030017430 S.CER ECJ0EC1H101J T 77/118.8 C272 4030011020 S.CER GRM31M4C2H1R0CY21L B 36.1/134.5 C273 4030011140 S.CER GRM31M2C2H120JV01L) B 32.6/136.7 C274 4030017460 S.CER ECJ0EB1E102K B 46.3/130.5 C275 4030017190 S.CER GRM31AR32J471KW01D B 41/134.5 C278 4030017460 S.CER ECJ0EB1E102K B 46/104.8 C279 4030017430 S.CER ECJ0EC1H101J T 93/119.9 C280 4030017460 S.CER ECJ0EB1E102K T 93.4/123.1 C281 4030006960 S.CER C1608 CH 1H 050C-T B 30.5/142.7 C282 4030017460 S.CER ECJ0EB1E102K T 56.4/116.1 C283 4030017600 S.CER ECJ0EC1H080C T 74.2/122.5 C284 4030017460 S.CER ECJ0EB1E102K T 104.3/106.6 C285 4030017600 S.CER ECJ0EC1H080C T 53.5/117.5 C286 4030011050 S.CER GRM31M3C2H3R0CY21L B 40.1/138.1 C287 4030017460 S.CER ECJ0EB1E102K T 87.6/122.1 C288 4030017570 S.CER ECJ0EC1H040B T 105.9/121.1 C289 4030017460 S.CER ECJ0EB1E102K T 74.2/127.5 C290 4030017460 S.CER ECJ0EB1E102K T 56.9/119.7 C291 4510008110 S.ELE 16 CE 22 BS T 99.7/123 C292 4030017530 S.CER ECJ0EC1H0R5B T 93.4/121.1 C293 4030017460 S.CER ECJ0EB1E102K T 106.4/122.3 C294 4030017460 S.CER ECJ0EB1E102K T 73.3/123.4 C295 4030017460 S.CER ECJ0EB1E102K T 54.4/122 C296 4030011080 S.CER GRM31M2C2H6R0DV01L B 42.6/143.2 C297 4030011730 S.CER GRM31M2C2H101JV01L B 33.6/146.8 C298 4510008110 S.ELE 16 CE 22 BS T 112.5/131.5 C299 4030017460 S.CER ECJ0EB1E102K T 82.5/122.1 C300 4030017440 S.CER ECJ0EC1H221J T 86.4/119.4 C301 4030017460 S.CER ECJ0EB1E102K T 101.1/126.6 C303 4030011060 S.CER GRM31M2C2H4R0CY21L B 42.6/148.3 C304 4030017360 S.CER ECJ0EC1H030B T 84.2/119 C305 4030017650 S.CER ECJ0EC1H270J T 94.1/126.8 C306 4030017460 S.CER ECJ0EB1E102K T 59.4/136.2 C307 4030017460 S.CER ECJ0EB1E102K T 109.1/132 C308 4030011080 S.CER GRM31M2C2H6R0DV01L B 42.6/153.2 C309 4030017580 S.CER ECJ0EC1H060C T 56.8/133.5 C310 4030011170 S.CER GRM31M2C2H180JV01L B 73.2/152.2 C311 4030017460 S.CER ECJ0EB1E102K T 83.4/122.1 C312 4030017390 S.CER ECJ0EC1H180J T 98.6/130.1 C313 4030017380 S.CER ECJ0EC1H050B T 106/127.6 C314 4030017200 S.CER GRM31BR32J102KY01L B 73.2/154.5 C315 4030017460 S.CER ECJ0EB1E102K T 52.8/135.8 C316 4030017460 S.CER ECJ0EB1E102K T 55.7/137.5 C317 4030017460 S.CER ECJ0EB1E102K T 99.8/130.4 C318 4030011170 S.CER GRM31M2C2H180JV01L B 69.4/153 C319 4030017390 S.CER ECJ0EC1H180J T 97.6/132.3 C320 4030007060 S.CER C1608 CH 1H 270J-T B 67.5/144.7 C321 4030017580 S.CER ECJ0EC1H060C T 78.8/121.8 C322 4030017460 S.CER ECJ0EB1E102K T 81.7/118.1 C323 4030017350 S.CER ECJ0EC1H020B T 106.6/133.4 C324 4030017460 S.CER ECJ0EB1E102K T 59/138.9 C325 4030017360 S.CER ECJ0EC1H030B T 60.6/139.8

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 9

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C326 4030011220 S.CER GRM31M2C2H360JV01L B 61.5/144 C327 4030018010 S.CER ECJ0EC1H360J T 98.4/137 C328 4030017580 S.CER ECJ0EC1H060C T 105.4/133.9 C329 4030017430 S.CER ECJ0EC1H101J T 109.1/136.1 C330 4030011190 S.CER GRM31M2C2H270JV01L B 54/149.3 C331 4030017440 S.CER ECJ0EC1H221J T 60.6/140.7 C332 4030017650 S.CER ECJ0EC1H270J T 100.3/138.8 C333 4030017570 S.CER ECJ0EC1H040B T 105.2/138.4 C334 4030017580 S.CER ECJ0EC1H060C T 67.7/142.7 C335 4030017660 S.CER ECJ0EC1H330J T 29.1/152.3 C336 4030017460 S.CER ECJ0EB1E102K T 67.9/115 C337 4030017550 S.CER ECJ0EC1H1R5B T 12.6/132.7 C338 4030017580 S.CER ECJ0EC1H060C T 104.7/140.9 C339 4030017430 S.CER ECJ0EC1H101J T 10.6/134.3 C340 4030017550 S.CER ECJ0EC1H1R5B T 14.5/134.8 C341 4030017460 S.CER ECJ0EB1E102K T 65.9/142.7 C342 4030011070 S.CER GRM31M2C2H5R0CY21L B 25/152.6 C343 4030017550 S.CER ECJ0EC1H1R5B T 14.5/136.4 C344 4030017380 S.CER ECJ0EC1H050B T 100.4/144.6 C345 4030017430 S.CER ECJ0EC1H101J T 64.7/143.1 C346 4030011090 S.CER GRM31M2C2H7R0DV01L B 21.7/148.4 C347 4030011040 S.CER GRM31M4C2H2R0CY21L T 16/139.6 C348 4030017590 S.CER ECJ0EC1H070C T 100.7/149.7 C349 4030011040 S.CER GRM31M4C2H2R0CY21L T 16/146.6 C350 4030017460 S.CER ECJ0EB1E102K T 33.6/146.9 C351 4030017760 S.CER ECJ0EB1H222K B 111.5/89.8 C352 4030017460 S.CER ECJ0EB1E102K T 117.4/93.8 C353 4030017460 S.CER ECJ0EB1E102K T 110/95.4 C354 4030017760 S.CER ECJ0EB1H222K B 109.7/90.8 C355 4030018920 S.CER ECJ0EB1H392K T 114.9/92.6 C356 4030018920 S.CER ECJ0EB1H392K T 107.5/94 C357 4030016970 S.CER ECJ0EB1C223K B 107.8/91.7 C358 4030018080 S.CER ECJ0EB1H182K T 113.2/93.3 C359 4030018080 S.CER ECJ0EB1H182K T 106.2/94.3 C360 4030016780 S.CER ECJ0EB1C153K T 113.2/92.4 C361 4030016970 S.CER ECJ0EB1C223K T 113.1/86.9 C362 4030016780 S.CER ECJ0EB1C153K T 107.5/93.1 C363 4030017460 S.CER ECJ0EB1E102K T 51/18.9 C364 4030016790 S.CER ECJ0EB1C103K T 110/83.6 C365 4030018080 S.CER ECJ0EB1H182K T 114/85.9 C366 4030017460 S.CER ECJ0EB1E102K B 74.8/28.6 C367 4030017040 S.CER ECJ0EB1A333K T 111.8/94.5 C368 4030017460 S.CER ECJ0EB1E102K B 110.6/90.1 C369 4030017460 S.CER ECJ0EB1E102K T 110.9/94.5 C370 4030017040 S.CER ECJ0EB1A333K T 111.9/85.9 C371 4030017040 S.CER ECJ0EB1A333K T 104.4/95.9 C372 4030016790 S.CER ECJ0EB1C103K B 104.9/88.6 C373 4030018080 S.CER ECJ0EB1H182K B 103.7/91.6 C374 4030017460 S.CER ECJ0EB1E102K T 103.5/96.3 C375 4030016780 S.CER ECJ0EB1C153K T 112.8/91 C376 4030016790 S.CER ECJ0EB1C103K B 108.8/90.8 C377 4030016780 S.CER ECJ0EB1C153K T 104.8/93 C378 4030017790 S.CER ECJ0EB1E682K T 109.1/84.5 C379 4030017040 S.CER ECJ0EB1A333K B 104.6/90 C380 4030016790 S.CER ECJ0EB1C103K T 111.6/90.6 C381 4030016790 S.CER ECJ0EB1C103K T 104.4/91.8 C382 4030017790 S.CER ECJ0EB1E682K B 104.1/87.2 C383 4030017460 S.CER ECJ0EB1E102K B 105.3/86.7 C384 4030017460 S.CER ECJ0EB1E102K T 108.1/91.7 C385 4030017460 S.CER ECJ0EB1E102K B 20/46.3 C386 4030016790 S.CER ECJ0EB1C103K B 103.4/85 C387 4030017360 S.CER ECJ0EC1H030B B 24.4/51.8 C388 4030017460 S.CER ECJ0EB1E102K T 101.2/92 C389 4030017460 S.CER ECJ0EB1E102K T 105.3/86.4 C390 4030017460 S.CER ECJ0EB1E102K T 99/87.9 C392 4030018860 S.CER ECJ0EB0J105K B 22.8/46.8 C393 4030017590 S.CER ECJ0EC1H070C B 26/51.8 C394 4550003220 S.TAN TEESVA 1E 105M8R B 16.5/37.1 C395 4030018860 S.CER ECJ0EB0J105K B 22.8/45.9 C396 4030017570 S.CER ECJ0EC1H040B B 26.5/50.1 C397 4030016790 S.CER ECJ0EB1C103K B 28.6/46.4 C398 4030017500 S.CER ECJ0EC1H560J B 25.3/49.6 C399 4030016790 S.CER ECJ0EB1C103K T 109.7/87.2 C400 4030016930 S.CER ECJ0EB1A104K B 56.6/42.5 C401 4030016930 S.CER ECJ0EB1A104K T 31.2/45.2 C402 4030017730 S.CER ECJ0EB1E471K T 50.5/30.1 C403 4030016790 S.CER ECJ0EB1C103K T 56.3/73.6 C404 4030017460 S.CER ECJ0EB1E102K B 54/63.8 C405 4030017460 S.CER ECJ0EB1E102K B 20.5/40.9 C406 4030017380 S.CER ECJ0EC1H050B B 26/45.9 C407 4030016790 S.CER ECJ0EB1C103K B 53.7/37.4 C408 4030017620 S.CER ECJ0EC1H100C B 24.4/40.9 C410 4030016930 S.CER ECJ0EB1A104K B 22.6/40.9 C411 4030017460 S.CER ECJ0EB1E102K B 26.7/42.1 C413 4030016930 S.CER ECJ0EB1A104K B 31.3/50.9 C414 4030017420 S.CER ECJ0EC1H470J B 29.7/48.8 C415 4030017730 S.CER ECJ0EB1E471K T 29.5/48 C416 4030017460 S.CER ECJ0EB1E102K B 54/69.1 C417 4030017460 S.CER ECJ0EB1E102K B 51/37.4 C418 4030017440 S.CER ECJ0EC1H221J T 56.1/62.6 C419 4030017440 S.CER ECJ0EC1H221J T 54.8/61.6 C420 4030018890 S.CER ECJ0EB0J224K T 30.4/46.5 C421 4030017730 S.CER ECJ0EB1E471K B 27.7/49.9 C422 4030017620 S.CER ECJ0EC1H100C T 54.8/63 C423 4030016930 S.CER ECJ0EB1A104K B 54.1/40.9 C424 4550007260 S.TAN F931C475MAABMA B 53.8/44.1 C425 4030018860 S.CER ECJ0EB0J105K T 52.9/39.4 C426 4030016930 S.CER ECJ0EB1A104K B 54/60.9 C427 4030016790 S.CER ECJ0EB1C103K T 52.9/41.2 C428 4030016930 S.CER ECJ0EB1A104K T 56.1/59.4 C429 4030017400 S.CER ECJ0EC1H220J T 51.9/44.4 C430 4030017360 S.CER ECJ0EC1H030B T 31.2/48.3 C431 4030017360 S.CER ECJ0EC1H030B T 31.6/46.5 C432 4030016930 S.CER ECJ0EB1A104K T 55.3/65.1

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C433 4030017040 S.CER ECJ0EB1A333K B 56.3/70.2 C434 4030017420 S.CER ECJ0EC1H470J T 32.6/49.1 C435 4030017680 S.CER ECJ0EC1H820J B 55.8/68.4 C436 4550006050 S.TAN TEESVA 0J 106M8R T 56.9/65.9 C437 4030016930 S.CER ECJ0EB1A104K T 58.8/63.1 C439 4550007080 S.TAN TEESVA 1C 106M8R B 84.7/42.7 C440 4550007080 S.TAN TEESVA 1C 106M8R B 28.5/43 C441 4030017570 S.CER ECJ0EC1H040B T 33.5/49.1 C442 4030016930 S.CER ECJ0EB1A104K T 53.5/66.8 C443 4030017420 S.CER ECJ0EC1H470J B 86.7/43.7 C444 4030017460 S.CER ECJ0EB1E102K T 35.2/46.3 C445 4030017460 S.CER ECJ0EB1E102K B 61.5/69.3 C446 4030017430 S.CER ECJ0EC1H101J T 40/49.3 C447 4030016950 S.CER ECJ0EB1A473K T 25.1/43.5 C448 4030016790 S.CER ECJ0EB1C103K T 34.4/49.1 C450 4030016790 S.CER ECJ0EB1C103K B 7/36.8 C451 4550000530 S.TAN TEESVA 1V 104M8R T 24/36.8 C452 4030017460 S.CER ECJ0EB1E102K T 28.6/42.3 C453 4550003220 S.TAN TEESVA 1E 105M8R T 59.3/38.3 C454 4030017460 S.CER ECJ0EB1E102K B 6.1/36.8 C455 4030016930 S.CER ECJ0EB1A104K B 11.1/41.2 C456 4550006250 S.TAN TEESVA 1A 106M8R T 24/34.7 C457 4030016930 S.CER ECJ0EB1A104K B 38.3/38.6 C458 4550007260 S.TAN F931C475MAABMA B 7.4/43.2 C459 4030017730 S.CER ECJ0EB1E471K T 10.5/42.8 C460 4030017460 S.CER ECJ0EB1E102K B 8.5/63.4 C461 4030017460 S.CER ECJ0EB1E102K B 62.7/63.5 C462 4030017460 S.CER ECJ0EB1E102K B 61/67.8 C463 4030016930 S.CER ECJ0EB1A104K B 7.7/40.3 C464 4030017460 S.CER ECJ0EB1E102K T 35.1/38.1 C466 4510009120 S.ELE EEE1VA2R2NR B 76.5/34.8 C467 4030017460 S.CER ECJ0EB1E102K B 60.6/66.6 C468 4030017040 S.CER ECJ0EB1A333K B 11.7/68 C469 4030017420 S.CER ECJ0EC1H470J B 80.6/42.9 C470 4030018860 S.CER ECJ0EB0J105K T 5.6/38.5 C471 4030016790 S.CER ECJ0EB1C103K T 5.6/40.3 C472 4030016790 S.CER ECJ0EB1C103K B 65.6/66.8 C473 4550000560 S.TAN TEESVA 1V 334M8R T 31.7/34.7 C474 4030017490 S.CER C1608 JB 1A 105K-T B 37.3/45.4 C475 4030017440 S.CER ECJ0EC1H221J T 10.7/61.8 C476 4030017440 S.CER ECJ0EC1H221J T 9.4/60.8 C477 4030017400 S.CER ECJ0EC1H220J T 5.4/43.5 C478 4030017460 S.CER ECJ0EB1E102K B 9.3/68 C479 4030017520 S.CER ECJ0EC1H0R3B T 39.7/36.9 C480 4030017620 S.CER ECJ0EC1H100C T 9.4/63.1 C481 4030007080 S.CER C1608 CH 1H 390J-T T 35/42.5 C482 4030017460 S.CER ECJ0EB1E102K T 42.2/40 C483 4030017360 S.CER ECJ0EC1H030B B 67.2/65.9 C484 4030009350 S.CER C1608 CH 1H 3R5B-T T 41.5/37.7 C486 4030016930 S.CER ECJ0EB1A104K B 8.3/59.8 C487 4030016930 S.CER ECJ0EB1A104K T 10.7/58.6 C488 4030007010 S.CER C1608 CH 1H 100D-T T 38.4/40.9 C489 4030007060 S.CER C1608 CH 1H 270J-T T 38.4/39.7 C490 4030017460 S.CER ECJ0EB1E102K T 37/45.5 C491 4030017680 S.CER ECJ0EC1H820J B 10.5/67.6 C492 4030006990 S.CER C1608 CH 1H 080D-T T 44.6/36.7 C493 4030007030 S.CER C1608 CH 1H 150J-T T 44.6/35.4 C495 4030016930 S.CER ECJ0EB1A104K T 13.5/62.3 C496 4030017460 S.CER ECJ0EB1E102K T 37/42.2 C497 4030017640 S.CER ECJ0EC1H150J B 73.7/66.5 C498 4030017340 S.CER ECJ0EC1H010B T 40.6/40.7 C499 4030017460 S.CER ECJ0EB1E102K T 41.6/45.9 C500 4030017360 S.CER ECJ0EC1H030B B 74.4/73 C501 4030017420 S.CER ECJ0EC1H470J T 35.7/44.6 C502 4030017460 S.CER ECJ0EB1E102K T 45.9/40 C503 4030016930 S.CER ECJ0EB1A104K T 18.2/68 C504 4030017460 S.CER ECJ0EB1E102K T 40/47.7 C506 4550006050 S.TAN TEESVA 0J 106M8R T 11.6/65.1 C507 4030017630 S.CER ECJ0EC1H120J B 72.4/74.9 C508 4030017420 S.CER ECJ0EC1H470J T 42/38.8 C509 4030017530 S.CER ECJ0EC1H0R5B T 46.1/38.4 C510 4030016930 S.CER ECJ0EB1A104K T 10/64.3 C511 4030017460 S.CER ECJ0EB1E102K T 43.6/44.6 C512 4030017400 S.CER ECJ0EC1H220J T 41.6/46.8 C513 4030017460 S.CER ECJ0EB1E102K B 17.8/68.5 C514 4030017460 S.CER ECJ0EB1E102K T 67/81.1 C515 4030017460 S.CER ECJ0EB1E102K B 18.8/64.4 C516 4030017460 S.CER ECJ0EB1E102K T 44.1/46.8 C517 4030017460 S.CER ECJ0EB1E102K B 15.5/66.2 C518 4030016790 S.CER ECJ0EB1C103K T 64/81.1 C519 4030017460 S.CER ECJ0EB1E102K B 14.9/67.5 C521 4030017360 S.CER ECJ0EC1H030B T 45.8/45.2 C522 4030017420 S.CER ECJ0EC1H470J T 45.8/46.1 C523 4030016790 S.CER ECJ0EB1C103K B 20.8/66.8 C524 4030017570 S.CER ECJ0EC1H040B T 46.2/47.3 C525 4030016790 S.CER ECJ0EB1C103K T 63.1/92 C526 4030017460 S.CER ECJ0EB1E102K T 36.3/63.2 C527 4030017590 S.CER ECJ0EC1H070C T 44/63.3 C528 4030016790 S.CER ECJ0EB1C103K T 63.1/87.4 C529 4030017640 S.CER ECJ0EC1H150J T 35.1/63.6 C530 4030016790 S.CER ECJ0EB1C103K T 70.1/80.7 C531 4030017360 S.CER ECJ0EC1H030B B 21.7/65 C532 4030017590 S.CER ECJ0EC1H070C T 44/64.9 C533 4030017590 S.CER ECJ0EC1H070C T 44.9/67.6 C534 4030017650 S.CER ECJ0EC1H270J T 34.9/65.1 C535 4030017590 S.CER ECJ0EC1H070C T 43.9/69.4 C536 4030017420 S.CER ECJ0EC1H470J T 35/57.1 C537 4030017460 S.CER ECJ0EB1E102K T 74.1/81.6 C538 4030017460 S.CER ECJ0EB1E102K T 37.3/67.1 C539 4030017640 S.CER ECJ0EC1H150J T 34.9/66.6 C540 4030017390 S.CER ECJ0EC1H180J B 28.8/65.8 C541 4030017730 S.CER ECJ0EB1E471K T 73.2/81.6 C543 4030017360 S.CER ECJ0EC1H030B B 29.5/72.2 C544 4030017350 S.CER ECJ0EC1H020B T 32.8/57.6

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 10

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C547 4030017460 S.CER ECJ0EB1E102K T 34.7/68.3 C548 4030016790 S.CER ECJ0EB1C103K B 27.5/74.2 C549 4030017460 S.CER ECJ0EB1E102K T 17.5/81.4 C550 4030016790 S.CER ECJ0EB1C103K T 73.2/90.5 C552 4030016790 S.CER ECJ0EB1C103K T 14.5/81.3 C553 4030016790 S.CER ECJ0EB1C103K T 74.1/90.5 C554 4030017350 S.CER ECJ0EC1H020B T 32.1/63.2 C555 4030016930 S.CER ECJ0EB1A104K T 71.2/96.3 C556 4030017460 S.CER ECJ0EB1E102K T 69.9/96.3 C557 4030017430 S.CER ECJ0EC1H101J T 30.7/63.6 C558 4030017340 S.CER ECJ0EC1H010B T 30.7/65.2 C559 4030016790 S.CER ECJ0EB1C103K T 13.2/92 C560 4030017350 S.CER ECJ0EC1H020B T 30.7/66.8 C561 4030016790 S.CER ECJ0EB1C103K T 13.6/87.7 C562 4030017600 S.CER ECJ0EC1H080C T 39.9/65.5 C563 4030017580 S.CER ECJ0EC1H060C T 33.1/67.5 C564 4030016790 S.CER ECJ0EB1C103K T 20.6/80.9 C565 4030017460 S.CER ECJ0EB1E102K T 30.7/68.9 C566 4030017460 S.CER ECJ0EB1E102K T 42/69.1 C567 4030017460 S.CER ECJ0EB1E102K T 41.5/65.1 C568 4030017580 S.CER ECJ0EC1H060C T 33.1/68.8 C569 4030017460 S.CER ECJ0EB1E102K T 24.7/81.8 C570 4030017730 S.CER ECJ0EB1E471K T 23.4/81.8 C572 4030016790 S.CER ECJ0EB1C103K T 23.8/90.7 C573 4030017460 S.CER ECJ0EB1E102K T 35.2/70.4 C574 4030016790 S.CER ECJ0EB1C103K T 24.7/90.7 C575 4030016930 S.CER ECJ0EB1A104K T 21.6/97.1 C576 4030017460 S.CER ECJ0EB1E102K T 21.6/96.2 C578 4030012610 S.CER C2012 JB 1C 474K-T T 120.4/134.3 C579 4510006021 ELE 16 ME 2200 HC C580 4030016930 S.CER ECJ0EB1A104K T 110.8/137.4 C581 4030017420 S.CER ECJ0EC1H470J T 18.2/19.5 C582 4030017600 S.CER ECJ0EC1H080C T 37.8/59.1 C584 4550002980 S.TAN TEESVA 1C 225M8R T 122.2/80.9 C585 4030016790 S.CER ECJ0EB1C103K B 121.2/89.2 C586 4550007080 S.TAN TEESVA 1C 106M8R B 105.2/127.1 C588 4030017390 S.CER ECJ0EC1H180J B 123.2/91.3 C589 4030017460 S.CER ECJ0EB1E102K T 14.4/26.5 C590 4030016930 S.CER ECJ0EB1A104K B 111.2/93.1 C591 4030017460 S.CER ECJ0EB1E102K T 10.9/16.1 C592 4030017460 S.CER ECJ0EB1E102K T 7.5/24.6 C593 4030017420 S.CER ECJ0EC1H470J T 126.6/18.3 C594 4030017510 S.CER ECJ0EC1H680J B 123.4/89.9 C596 4030016790 S.CER ECJ0EB1C103K B 121.9/87 C597 4030017460 S.CER ECJ0EB1E102K T 10.3/25 C598 4030017460 S.CER ECJ0EB1E102K B 99.5/130.4 C599 4030017570 S.CER ECJ0EC1H040B B 125/94.6 C600 4030017040 S.CER ECJ0EB1A333K T 121.6/72.3 C601 4030017460 S.CER ECJ0EB1E102K T 8.9/15.1 C602 4030016930 S.CER ECJ0EB1A104K B 97.3/121 C603 4030017460 S.CER ECJ0EB1E102K T 123.6/76.2 C604 4030017400 S.CER ECJ0EC1H220J B 127/81 C605 4030017420 S.CER ECJ0EC1H470J T 121.7/23 C606 4030012610 S.CER C2012 JB 1C 474K-T B 99.8/123 C607 4030017420 S.CER ECJ0EC1H470J T 122/24.8 C610 4030016930 S.CER ECJ0EB1A104K B 97.3/129.4 C611 4510008540 S.ELE EEE1CA100SR B 102.1/15.7 C612 4510008540 S.ELE EEE1CA100SR T 104.5/50.1 C613 4550007080 S.TAN TEESVA 1C 106M8R B 97.9/126.5 C614 4030016930 S.CER ECJ0EB1A104K B 113.6/90.1 C616 4030016930 S.CER ECJ0EB1A104K B 126.2/67.7 C617 4030016930 S.CER ECJ0EB1A104K T 115.5/63.5 C618 4030017460 S.CER ECJ0EB1E102K T 113.1/116.3 C619 4030016940 S.CER ECJ0EB1A393K T 14.8/27.4 C620 4030016940 S.CER ECJ0EB1A393K T 14.8/28.6 C621 4550006760 S.TAN TEESVB21A336M8R T 10.4/28.9 C622 4030017460 S.CER ECJ0EB1E102K T 116.5/128.5 C623 4030016930 S.CER ECJ0EB1A104K T 17.1/29.8 C624 4030017490 S.CER C1608 JB 1A 105K-T T 19.2/29.9 C625 4550002980 S.TAN TEESVA 1C 225M8R T 25.8/28.8 C626 4030017460 S.CER ECJ0EB1E102K T 111.4/124.7 C627 4030016790 S.CER ECJ0EB1C103K B 107.9/62.6 C628 4030017460 S.CER ECJ0EB1E102K T 113.1/118.3 C629 4030017460 S.CER ECJ0EB1E102K T 112.9/125.1 C630 4030016930 S.CER ECJ0EB1A104K T 112.7/120.4 C635 4030017460 S.CER ECJ0EB1E102K T 23.1/24.4 C636 4030008680 S.CER C2012 JF 1C 105Z-T T 19.7/24.5 C637 4030008680 S.CER C2012 JF 1C 105Z-T T 25.5/24.2 C638 4030016790 S.CER ECJ0EB1C103K T 109.6/78.1 C639 4030016970 S.CER ECJ0EB1C223K T 110.2/80.7 C640 4030016930 S.CER ECJ0EB1A104K T 111.7/79.5 C641 4030017460 S.CER ECJ0EB1E102K T 33/20.9 C642 4030017460 S.CER ECJ0EB1E102K T 32.2/28 C643 4030017770 S.CER ECJ0EB1E332K T 110.1/76.9 C644 4030018860 S.CER ECJ0EB0J105K B 28.9/24.8 C645 4030016930 S.CER ECJ0EB1A104K B 29.7/23.9 C646 4030016930 S.CER ECJ0EB1A104K B 30.5/24.8 C647 4030017770 S.CER ECJ0EB1E332K T 110.5/75.7 C648 4030016930 S.CER ECJ0EB1A104K B 36.1/24.6 C649 4030016930 S.CER ECJ0EB1A104K B 35.3/19.6 C650 4510008540 S.ELE EEE1CA100SR B 62.5/12.8 C651 4030017490 S.CER C1608 JB 1A 105K-T T 110.4/96.8 C652 4030016930 S.CER ECJ0EB1A104K B 34.9/24 C653 4030017490 S.CER C1608 JB 1A 105K-T T 114.8/97.4 C654 4030016930 S.CER ECJ0EB1A104K T 65.3/4.4 C655 4030016930 S.CER ECJ0EB1A104K T 36.5/26.9 C656 4550006250 S.TAN TEESVA 1A 106M8R B 31.6/21.8 C657 4030017460 S.CER ECJ0EB1E102K T 114.3/102.1 C658 4510008540 S.ELE EEE1CA100SR T 117.1/108 C659 4030016970 S.CER ECJ0EB1C223K T 113.5/108.8 C660 4030017400 S.CER ECJ0EC1H220J T 89.9/4.9 C661 4030018910 S.CER C1608 JB 0J 475K-T T 116.5/104.5 C662 4030017400 S.CER ECJ0EC1H220J T 89.9/11.1 C663 4510008540 S.ELE EEE1CA100SR B 61.9/7.5

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C664 4030017730 S.CER ECJ0EB1E471K B 116/32.7 C665 4510008500 S.ELE EEE1CA101WP T 125.7/43 C666 4030016970 S.CER ECJ0EB1C223K T 106/107.2 C667 4510008540 S.ELE EEE1CA100SR T 106.3/110.4 C668 4030016790 S.CER ECJ0EB1C103K B 116.4/37.6 C669 4030017730 S.CER ECJ0EB1E471K B 117.2/34 C670 4030016930 S.CER ECJ0EB1A104K B 117.3/37.6 C672 4030017460 S.CER ECJ0EB1E102K T 99.4/35.6 C673 4030017460 S.CER ECJ0EB1E102K B 119.2/98 C674 4030017460 S.CER ECJ0EB1E102K T 115.4/41.3 C675 4030017730 S.CER ECJ0EB1E471K B 117.2/33.1 C676 4030017460 S.CER ECJ0EB1E102K T 121/35 C677 4030016930 S.CER ECJ0EB1A104K B 72.5/5 C678 4510008540 S.ELE EEE1CA100SR B 41.5/10.9 C679 4030016930 S.CER ECJ0EB1A104K T 125.9/113.4 C680 4030016930 S.CER ECJ0EB1A104K T 120.9/107.2 C683 4030017040 S.CER ECJ0EB1A333K T 113/79.2 C684 4510008540 S.ELE EEE1CA100SR T 97.2/21.8 C685 4510008540 S.ELE EEE1CA100SR T 103.3/21.8 C687 4510008540 S.ELE EEE1CA100SR B 64/17.7 C688 4030018900 S.CER ECJ0EB0J474K T 128.3/109.6 C689 4030018900 S.CER ECJ0EB0J474K T 123.2/110.9 C691 4030017460 S.CER ECJ0EB1E102K B 120.6/102.5 C692 4030017920 S.CER ECJ0EB1A683K T 114/75.1 C694 4030018900 S.CER ECJ0EB0J474K T 126.1/111.3 C695 4510008540 S.ELE EEE1CA100SR T 116.8/72.9 C697 4550007080 S.TAN TEESVA 1C 106M8R B 75.6/8.4 C698 4030016790 S.CER ECJ0EB1C103K T 114.4/70 C700 4510008520 S.ELE EEE1CA470SP T 124.2/102.2 C701 4030016930 S.CER ECJ0EB1A104K B 67.5/17 C703 4510008130 S.ELE 16 CE 220 BS B 123.4/98.6 C704 4030017730 S.CER ECJ0EB1E471K T 127.5/114.3 C705 4510008540 S.ELE EEE1CA100SR B 69.4/20.3 C706 4510008520 S.ELE EEE1CA470SP T 125/119.2 C707 4510008500 S.ELE EEE1CA101WP B 121.7/109.1 C708 4030017460 S.CER ECJ0EB1E102K B 112.8/32.4 C709 4510008870 S.ELE EEE1AA471UP B 112.1/109.1 C710 4030016930 S.CER ECJ0EB1A104K T 127.2/142.8 C711 4510008870 S.ELE EEE1AA471UP B 104.2/117.2 C712 4030016930 S.CER ECJ0EB1A104K T 107.1/145.9 C714 4510008500 S.ELE EEE1CA101WP B 114.2/117.2 C716 4030016930 S.CER ECJ0EB1A104K T 124.2/144.3 C717 4030017430 S.CER ECJ0EC1H101J T 59.6/20.7 C718 4510008130 S.ELE 16 CE 220 BS B 123/117.2 C719 4030017420 S.CER ECJ0EC1H470J T 119.3/143.3 C722 4550007080 S.TAN TEESVA 1C 106M8R T 56.7/16.1 C723 4030017420 S.CER ECJ0EC1H470J B 75.7/43.7 C724 4030017420 S.CER ECJ0EC1H470J T 82.4/35.4 C725 4030017460 S.CER ECJ0EB1E102K B 65/48.6 C726 4030017460 S.CER ECJ0EB1E102K B 75.9/45.5 C727 4030017420 S.CER ECJ0EC1H470J T 79.7/45.5 C728 4030017460 S.CER ECJ0EB1E102K B 65/49.5 C729 4030017460 S.CER ECJ0EB1E102K T 75.7/41.3 C730 4030017460 S.CER ECJ0EB1E102K T 78.3/39.4 C731 4030017460 S.CER ECJ0EB1E102K B 65.8/47.7 C732 4030017420 S.CER ECJ0EC1H470J B 90.5/36 C733 4030017460 S.CER ECJ0EB1E102K B 68.1/50.7 C734 4030017460 S.CER ECJ0EB1E102K T 57.6/43.9 C735 4030017420 S.CER ECJ0EC1H470J T 80.2/41.2 C736 4030018860 S.CER ECJ0EB0J105K B 67.4/45.9 C737 4030018860 S.CER ECJ0EB0J105K B 67.4/46.8 C738 4030017360 S.CER ECJ0EC1H030B B 70.3/52 C739 4030017460 S.CER ECJ0EB1E102K T 80.7/55.5 C740 4030017460 S.CER ECJ0EB1E102K B 64.6/46.4 C741 4030017640 S.CER ECJ0EC1H150J B 70.3/49.6 C742 4030017570 S.CER ECJ0EC1H040B B 71.5/49.1 C743 4030017680 S.CER ECJ0EC1H820J B 72.7/48.8 C744 4030016790 S.CER ECJ0EB1C103K B 72.3/45.5 C746 4030017580 S.CER ECJ0EC1H060C B 70.5/45.8 C747 4030017620 S.CER ECJ0EC1H100C B 69/40.9 C748 4030016930 S.CER ECJ0EB1A104K B 65/40.9 C749 4030017460 S.CER ECJ0EB1E102K B 64.6/42.1 C750 4030016930 S.CER ECJ0EB1A104K B 75.5/48.8 C751 4030017460 S.CER ECJ0EB1E102K B 71.3/42.1 C752 4030017420 S.CER ECJ0EC1H470J B 74.6/49.7 C753 4030017730 S.CER ECJ0EB1E471K T 74.2/48 C754 4030017730 S.CER ECJ0EB1E471K T 75.1/47.3 C755 4030016930 S.CER ECJ0EB1A104K T 75.1/44.1 C759 4550000530 S.TAN TEESVA 1V 104M8R T 68.6/37.2 C760 4030016930 S.CER ECJ0EB1A104K T 71.5/34.7 C761 4030017460 S.CER ECJ0EB1E102K T 74.6/34.2 C762 4550002980 S.TAN TEESVA 1C 225M8R T 68.6/34.8 C763 4550000530 S.TAN TEESVA 1V 104M8R T 78.4/34.8 C764 4030016930 S.CER ECJ0EB1A104K T 80.2/43.4 C765 4030017460 S.CER ECJ0EB1E102K T 81.3/45.5 C766 4030017460 S.CER ECJ0EB1E102K T 90.6/36 C767 4030017460 S.CER ECJ0EB1E102K T 86.6/35 C768 4030009570 S.CER C1608 CH 1H 0R3B-T T 83/41.4 C769 4030017460 S.CER ECJ0EB1E102K T 87.5/35 C770 4030017460 S.CER ECJ0EB1E102K T 84.9/38.5 C771 4030007020 S.CER C1608 CH 1H 120J-T T 85.2/42.1 C772 4030007050 S.CER C1608 CH 1H 220J-T T 88.5/40.7 C773 4030007040 S.CER C1608 CH 1H 180J-T T 89.2/38.8 C774 4030017620 S.CER ECJ0EC1H100C T 76.4/49.6 C775 4030017620 S.CER ECJ0EC1H100C T 77.6/49.2 C776 4030017460 S.CER ECJ0EB1E102K T 86.5/57.4 C777 4030017340 S.CER ECJ0EC1H010B T 90.3/40.7 C779 4030017460 S.CER ECJ0EB1E102K T 85.2/44.6 C780 4030017460 S.CER ECJ0EB1E102K T 90.3/43.5 C781 4030017460 S.CER ECJ0EB1E102K T 84.4/49.2 C782 4030017460 S.CER ECJ0EB1E102K T 79.8/57.5 C783 4030017460 S.CER ECJ0EB1E102K T 90.3/44.4 C784 4030017460 S.CER ECJ0EB1E102K T 85.4/47.1 C785 4030017670 S.CER ECJ0EC1H390J T 85.4/63.8

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 11

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C786 4030017460 S.CER ECJ0EB1E102K T 75.3/55.5 C787 4030017630 S.CER ECJ0EC1H120J T 83.7/60.9 C788 4030017460 S.CER ECJ0EB1E102K T 79.8/55.5 C789 4030017640 S.CER ECJ0EC1H150J T 85.4/65.4 C790 4030017390 S.CER ECJ0EC1H180J T 82.5/61.3 C791 4030017600 S.CER ECJ0EC1H080C T 83/62.6 C792 4030017460 S.CER ECJ0EB1E102K T 86.3/65.9 C793 4030017340 S.CER ECJ0EC1H010B T 88.8/46.6 C794 4030017580 S.CER ECJ0EC1H060C T 79.7/63.3 C795 4030017650 S.CER ECJ0EC1H270J T 85.7/67.4 C796 4030017580 S.CER ECJ0EC1H060C T 80.9/63.8 C797 4030017400 S.CER ECJ0EC1H220J T 88.8/48.2 C798 4030017460 S.CER ECJ0EB1E102K T 80.4/60.3 C799 4030017580 S.CER ECJ0EC1H060C T 79.7/64.2 C800 4030017590 S.CER ECJ0EC1H070C T 81.9/65.9 C803 4030017460 S.CER ECJ0EB1E102K T 90.1/55.2 C804 4030017640 S.CER ECJ0EC1H150J T 85.7/68.9 C805 4030017460 S.CER ECJ0EB1E102K T 75.3/58.6 C806 4030017460 S.CER ECJ0EB1E102K T 83.3/69.3 C807 4030017590 S.CER ECJ0EC1H070C T 81.9/67.5 C808 4030017460 S.CER ECJ0EB1E102K T 90.7/60.1 C809 4030017650 S.CER ECJ0EC1H270J T 75.7/67 C811 4030017460 S.CER ECJ0EB1E102K T 89/60.1 C812 4030017500 S.CER ECJ0EC1H560J T 77.9/66.7 C814 4030017340 S.CER ECJ0EC1H010B T 89.8/62.5 C815 4030017460 S.CER ECJ0EB1E102K T 86.2/70.7 C816 4030017650 S.CER ECJ0EC1H270J T 79.5/68.7 C817 4030017460 S.CER ECJ0EB1E102K T 79.7/67.4 C818 4030017390 S.CER ECJ0EC1H180J T 90.6/66.3 C819 4030017460 S.CER ECJ0EB1E102K T 83.6/55.5 C820 4030017390 S.CER ECJ0EC1H180J T 89.9/67.8 C821 4030017420 S.CER ECJ0EC1H470J T 77.5/61.4 C822 4030017420 S.CER ECJ0EC1H470J T 75.7/66 C823 4030016790 S.CER ECJ0EB1C103K T 75.3/62.6 C827 4030017460 S.CER ECJ0EB1E102K T 44.5/58 C830 4030017460 S.CER ECJ0EB1E102K T 37.5/55.2 C831 4030017460 S.CER ECJ0EB1E102K T 36.2/59.9 C833 4030017460 S.CER ECJ0EB1E102K T 44.4/55.7 C835 4030017460 S.CER ECJ0EB1E102K T 42/59.5 C836 4030006860 S.CER C1608 JB 1H 102K-T B 114.3/127.7 C837 4030017460 S.CER ECJ0EB1E102K T 75.7/70.8 C838 4030017460 S.CER ECJ0EB1E102K T 75.1/40.4 C839 4030017460 S.CER ECJ0EB1E102K T 83.1/43.7 C840 4030017460 S.CER ECJ0EB1E102K T 46.5/63.1 C841 4030017590 S.CER ECJ0EC1H070C T 31.7/55.2 C844 4030017460 S.CER ECJ0EB1E102K T 30.9/57.8 C845 4050000280 S.FED CTH30V222S15A-TM T 87.3/113.6 C846 4050000280 S.FED CTH30V222S15A-TM T 43.5/117.5 C847 4050000280 S.FED CTH30V222S15A-TM T 119.7/129.4 C848 4030017460 S.CER ECJ0EB1E102K T 19/125.4 C849 4030011810 S.CER C1608 JB 1A 224K-T T 93.3/5.5 C850 4030011810 S.CER C1608 JB 1A 224K-T T 92.6/4.3 C851 4030011810 S.CER C1608 JB 1A 224K-T T 95.2/4.3 C852 4030011810 S.CER C1608 JB 1A 224K-T T 96.8/5.5 C855 4030018140 S.CER ECJ0EB1H391K T 61.4/15.6 C856 4030018920 S.CER ECJ0EB1H392K T 58.6/14.3 C857 4030017430 S.CER ECJ0EC1H101J T 71/15.8 C858 4030017430 S.CER ECJ0EC1H101J T 70.9/20 C859 4030017490 S.CER C1608 JB 1A 105K-T T 75.6/20.4 C860 4030017920 S.CER ECJ0EB1A683K T 75.1/19.4 C861 4030018240 S.CER ECJ0EB1E562K T 70.4/18.8 C862 4030016950 S.CER ECJ0EB1A473K T 72.5/17.9 C863 4030018910 S.CER C1608 JB 0J 475K-T B 107.1/36.7 C864 4030018910 S.CER C1608 JB 0J 475K-T B 101.1/27.5 C865 4030018910 S.CER C1608 JB 0J 475K-T B 104.2/37.8 C866 4030017040 S.CER ECJ0EB1A333K T 64.4/23.1 C867 4030018860 S.CER ECJ0EB0J105K B 101.7/31.2 C868 4030016790 S.CER ECJ0EB1C103K T 66.9/92.4 C869 4030016790 S.CER ECJ0EB1C103K T 66.9/89.3 C870 4030016790 S.CER ECJ0EB1C103K T 17.5/92.6 C871 4030016790 S.CER ECJ0EB1C103K T 17.5/90.4 C872 4550007080 S.TAN TEESVA 1C 106M8R T 56.7/18.2 C873 4030018860 S.CER ECJ0EB0J105K T 102.2/30.1 C874 4510008540 S.ELE EEE1CA100SR B 64.2/22.5 C875 4510008540 S.ELE EEE1CA100SR B 52.2/26.8 C876 4510008540 S.ELE EEE1CA100SR B 64.2/27.3 C877 4510009120 S.ELE EEE1VA2R2NR B 44.1/36 C879 4510008540 S.ELE EEE1CA100SR B 58.3/22 C882 4030017460 S.CER ECJ0EB1E102K B 105.6/101.9 C883 4030017460 S.CER ECJ0EB1E102K T 90.9/93.9 C884 4030016930 S.CER ECJ0EB1A104K T 8.2/66 C889 4030017460 S.CER ECJ0EB1E102K T 16.7/60.4 C891 4030016930 S.CER ECJ0EB1A104K T 17.3/53.2 C894 4030016790 S.CER ECJ0EB1C103K T 62.5/50.2 C895 4030017460 S.CER ECJ0EB1E102K T 29.6/111.8 C896 4030017460 S.CER ECJ0EB1E102K B 47.2/58.7 C897 4030017460 S.CER ECJ0EB1E102K B 5.6/33.6 C898 4030016930 S.CER ECJ0EB1A104K T 93.4/14.2 C899 4030017460 S.CER ECJ0EB1E102K B 128.3/77.5 C900 4030017460 S.CER ECJ0EB1E102K B 126.7/78 C901 4030017420 S.CER ECJ0EC1H470J B 123.4/55.1 C902 4030017420 S.CER ECJ0EC1H470J B 123.4/51.9 C903 4030016930 S.CER ECJ0EB1A104K T 119.1/53.1 C904 4030016930 S.CER ECJ0EB1A104K T 121.2/55.2 C905 4030016930 S.CER ECJ0EB1A104K T 103.2/53.9 C906 4030016930 S.CER ECJ0EB1A104K T 103.2/54.8 C907 4030016790 S.CER ECJ0EB1C103K B 114/56.2 C908 4030017460 S.CER ECJ0EB1E102K T 108/52.5 C909 4030017460 S.CER ECJ0EB1E102K T 114.6/51.8 C910 4030016790 S.CER ECJ0EB1C103K T 114.6/50.9 C911 4030016930 S.CER ECJ0EB1A104K T 111.7/53.7 C912 4030016930 S.CER ECJ0EB1A104K B 59.9/28.2 C913 4030017460 S.CER ECJ0EB1E102K T 114.3/98.8 C914 4030016930 S.CER ECJ0EB1A104K B 121.6/93.1

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C915 4030016930 S.CER ECJ0EB1A104K B 125.8/79.4 C916 4030016930 S.CER ECJ0EB1A104K B 121.3/83.4 C917 4030016930 S.CER ECJ0EB1A104K B 115.4/89.4 C918 4030016930 S.CER ECJ0EB1A104K T 69.3/25 C919 4030017460 S.CER ECJ0EB1E102K T 101.3/25.9 C920 4030017460 S.CER ECJ0EB1E102K B 69.7/37.1 C921 4030017460 S.CER ECJ0EB1E102K B 71.2/34.2 C922 4030017460 S.CER ECJ0EB1E102K B 29.8/32.7 C923 4030017460 S.CER ECJ0EB1E102K B 30.7/36.2 C924 4030017460 S.CER ECJ0EB1E102K B 23.2/36.6 C925 4030017460 S.CER ECJ0EB1E102K B 67.2/36.9 C926 4030016930 S.CER ECJ0EB1A104K T 15.8/58.6 C927 4030016930 S.CER ECJ0EB1A104K T 7.6/55.4 C928 4030016930 S.CER ECJ0EB1A104K T 15.8/51 C929 4030016930 S.CER ECJ0EB1A104K T 7.6/47.9 C930 4030016930 S.CER ECJ0EB1A104K T 61/59.5 C931 4030016930 S.CER ECJ0EB1A104K T 61.6/52 C932 4030016930 S.CER ECJ0EB1A104K T 52.9/56.3 C933 4030016930 S.CER ECJ0EB1A104K T 52.9/48.8 C934 4030016930 S.CER ECJ0EB1A104K T 122.5/71.2 C937 4030017460 S.CER ECJ0EB1E102K T 30.2/109 C938 4030017460 S.CER ECJ0EB1E102K T 33/107.9 C941 4030017460 S.CER ECJ0EB1E102K T 71.1/137.5 C942 4030017460 S.CER ECJ0EB1E102K T 54/124 C943 4030018900 S.CER ECJ0EB0J474K B 122.4/82.8 C944 4030016790 S.CER ECJ0EB1C103K T 121.7/27.7 C945 4030017520 S.CER ECJ0EC1H0R3B T 38.4/37 C946 4030017460 S.CER ECJ0EB1E102K T 51.9/124.2 C948 4510009010 S.ELE EEE1AA221P T 86.4/16.8 C949 4030017460 S.CER ECJ0EB1E102K B 46.8/30.5 C950 4030017400 S.CER ECJ0EC1H220J T 89.7/49.1 C951 4030018890 S.CER ECJ0EB0J224K T 76/47.7 C952 4030017570 S.CER ECJ0EC1H040B T 36.4/137.1 C953 4030017360 S.CER ECJ0EC1H030B T 37.7/136.7 C954 4510009010 S.ELE EEE1AA221P [EUR-02] only T 13.2/36.6

RL1 6330001560 S.RLY ATQ206SA T 27.3/119.6 RL2 6330001560 S.RLY ATQ206SA T 64.7/122.9 RL3 6330001560 S.RLY ATQ206SA T 24.7/144.8

J1 6510014961 S.CNR B2B-ZR-SM4-TF (LF) (SN) T 48.3/136.1 J2 6510023110 CNR 3008L-8P8C <KIN> J3 6510025950 CNR PCB-606 (6P6C) BLACK J4 6510023161 CNR DN-508B-6-L <KOU> J5 6450001430 CNR HSJ1462-01-010 J6 6510021970 S.CNR AXN330C130P B 123.5/35.9 J7 6510014961 S.CNR B2B-ZR-SM4-TF (LF) (SN) B 101/108.4 J8 6510025940 CNR PJ-3047S <XIN> J9 6450001440 CNR HSJ1403-01-010 J10 6510025970 S.CNR 41-002AA-R <MRF> T 94.8/112.6 J11 6510025970 S.CNR 41-002AA-R <MRF> T 39.7/123.2 J22 6510025970 S.CNR 41-002AA-R <MRF> T 94.8/117 J23 6510025970 S.CNR 41-002AA-R <MRF> T 36.5/119.6 J24 6510016381 S.CNR 52465-1071 T 126.3/67.5

W1 8900016070 CBL OPC-1669 W2 8900016070 CBL OPC-1669 W5 7120000470 JMP ERDS2T0 W6 7120000470 JMP ERDS2T0 W7 8900016020 CBL OPC-1671 <TJM>

EP1 6910014690 S.BEA MPZ1608S221A-T T 49.3/117.4 EP2 6910014690 S.BEA MPZ1608S221A-T T 51.1/133.4 EP3 6910012350 S.BEA MMZ1608Y 102BT B 44.3/88.7 EP4 6910012350 S.BEA MMZ1608Y 102BT B 39.4/88.2 EP5 6910012350 S.BEA MMZ1608Y 102BT T 8.9/17.2 EP6 6910018460 S.BEA MMZ1005Y102C-T T 8/22.9 EP7 6910018460 S.BEA MMZ1005Y102C-T T 10.9/17.7 EP8 6910018460 S.BEA MMZ1005Y102C-T T 12.4/25 EP9 6910018460 S.BEA MMZ1005Y102C-T T 16/25.3 EP10 6910018460 S.BEA MMZ1005Y102C-T T 13.9/25.3 EP11 6910012350 S.BEA MMZ1608Y 102BT T 15/17.2 EP12 6910018460 S.BEA MMZ1005Y102C-T T 18.2/21.6 EP13 6910012350 S.BEA MMZ1608Y 102BT T 125.9/19.6 EP14 6910012350 S.BEA MMZ1608Y 102BT T 120.2/21.7 EP16 6910018460 S.BEA MMZ1005Y102C-T T 122.9/22.5 EP18 6910018460 S.BEA MMZ1005Y102C-T B 121.6/94 EP19 6910018460 S.BEA MMZ1005Y102C-T B 123.7/81.5 EP20 6910018460 S.BEA MMZ1005Y102C-T B 125.7/80.6 EP23 6910018460 S.BEA MMZ1005Y102C-T T 12.9/28.9 EP24 6910018460 S.BEA MMZ1005Y102C-T T 57.1/9.6 EP25 6910018460 S.BEA MMZ1005Y102C-T B 127.7/32.3 EP26 6910018460 S.BEA MMZ1005Y102C-T B 119.2/41.6 EP27 6910018460 S.BEA MMZ1005Y102C-T B 119.2/40.7 EP29 6910018460 S.BEA MMZ1005Y102C-T B 119.2/39.4 EP30 6910018460 S.BEA MMZ1005Y102C-T B 127.7/39.5 EP31 6910018460 S.BEA MMZ1005Y102C-T T 89.4/9.8 EP32 6910018460 S.BEA MMZ1005Y102C-T T 89/4.9 EP33 6910018460 S.BEA MMZ1005Y102C-T B 127.7/42.2 EP34 6910018460 S.BEA MMZ1005Y102C-T B 127.7/41.3 EP35 6910018460 S.BEA MMZ1005Y102C-T B 127.7/31.4 EP36 6910018460 S.BEA MMZ1005Y102C-T B 127.7/40.4 EP37 6910018460 S.BEA MMZ1005Y102C-T T 89.5/1.7 EP38 6910018460 S.BEA MMZ1005Y102C-T B 127.7/38.6 EP39 6910018460 S.BEA MMZ1005Y102C-T B 127.7/37.7 EP40 6910018460 S.BEA MMZ1005Y102C-T B 127.7/36.8 EP41 6910018460 S.BEA MMZ1005Y102C-T B 127.7/34.1 EP42 6910018460 S.BEA MMZ1005Y102C-T B 127.7/35.9 EP43 6910018460 S.BEA MMZ1005Y102C-T B 127.7/33.2 EP47 6910018460 S.BEA MMZ1005Y102C-T T 45.7/57.9

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

6 - 12

M.

S.=Surface mount

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

EP48 6910018460 S.BEA MMZ1005Y102C-T T 91/61.3 EP49 6910014690 S.BEA MPZ1608S221A-T T 121.3/152.3 EP50 6910014690 S.BEA MPZ1608S221A-T T 109.4/155.1 EP51 6910018460 S.BEA MMZ1005Y102C-T T 119.3/144.2 EP52 6910014690 S.BEA MPZ1608S221A-T T 128.6/143.6 EP53 6910014690 S.BEA MPZ1608S221A-T T 126.3/144.3 EP54 6910014690 S.BEA MPZ1608S221A-T T 113.9/138.9 EP55 6910014690 S.BEA MPZ1608S221A-T T 108.6/147.8 EP56 6910018460 S.BEA MMZ1005Y102C-T B 119.3/38.5 EP57 6910018460 S.BEA MMZ1005Y102C-T B 119.3/37.6 EP58 6910018460 S.BEA MMZ1005Y102C-T B 119.3/36.7 EP59 6910014690 S.BEA MPZ1608S221A-T B 117.2/36.3 EP60 6910014690 S.BEA MPZ1608S221A-T B 117.2/35.1 EP61 6910018460 S.BEA MMZ1005Y102C-T B 119.3/34.3 EP62 6910018460 S.BEA MMZ1005Y102C-T B 119.3/33.4 EP63 6910018460 S.BEA MMZ1005Y102C-T B 119.3/32.5 EP64 6910018460 S.BEA MMZ1005Y102C-T B 119.3/31.6 EP66 6910018460 S.BEA MMZ1005Y102C-T B 127.7/35 EP68 6910018460 S.BEA MMZ1005Y102C-T B 41.6/14.3 EP69 6910018460 S.BEA MMZ1005Y102C-T T 52.6/10.4 EP70 6910018460 S.BEA MMZ1005Y102C-T T 45/8 EP71 6910012350 S.BEA MMZ1608Y 102BT T 47.5/130.7

DESCRIPTION

M.

H/V

LOCATION

[VR1 UNIT]

REF ORDER NO. NO.

R1 7210003250 VAR RV-320 (RK097221005H)

W1 8900016030 CBL OPC-1666 <TJM>

DESCRIPTION

M.

H/V

LOCATION

[VR2 UNIT]

REF ORDER NO. NO.

R1 7210003250 VAR RV-320 (RK097221005H)

W1 8900016030 CBL OPC-1666 <TJM>

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

H/V

M.

LOCATION

S.=Surface mount

6 - 13

SECTION 7 MECHANICAL PARTS

[CHASSIS PARTS]

REF ORDER NO. N O.

J1 6510004880 MR-DSE-01 1 J2 6510004880 MR-DSE-01 1

P1 6510009580 ZHR-2 1

SP1 2510001160 057P0802 1

MF1 2710000820 EFB0412VHD-6P38 1

W1 9016420020 23/04/140/B09/W01 1 W2 9016420010 23/00/140/B09/W01 1

MP1 8010020640 2969 CHASSIS 1 MP2 8210023550 2969 CHASSIS PANEL 1 MP3 8310068650 2969 MAGNET PLATE 1 MP5 8110009000 2969 U-COVER 1 MP6 8110009010 2969 L-COVER 1 MP7 8110009020 2969 FAN COVER 1 MP8 8930071460 2969 SP SPONGE 1 MP9 8930071380 2969 IC CLIP 1 MP10 8810009611 Screw M2.6X6 ZK3 17 MP12 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 11 MP13 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 4 MP14 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 4 MP15 8810009991 Screw BT B0 3X8 NI-ZK3 (BT) 5 MP16 8810010141 Screw PH M3X30 ZK3 4 MP18 8930014980 59 saran net 1 MP19 8930072260 2969 NET 1 MP20 8930071590 THERMALLY SHEET (BI) 1 MP36 8930016800 Thermal sheet (U) 1 MP38 8930041160 Sheet (BO) 1 MP39 8930018810 Sheet (AA) 1

DESCRIPTION

QTY.

[CONTROL UNIT]

REF ORDER NO. N O.

J5 6510025730 HJC0187-010024 1

DS1 5030003040 M6-0103TRM-5 1

S15 2250000570 SW-169 1 S16 2250000570 SW-169 1

MP1 8210023490 2969 FRONT PANEL (Inc. MP19) 1 MP2 8210023500 2969 REAR PANEL (Inc. MP25) 1 MP3 8310068770 2969 WINDOW PLATE(A) 1 MP4 8310068550 2969 WINDOW LINE 1 MP5 8310068560 2969 SUB RING 2 MP6 8310068570 2969 MAIN RING 2 MP7 8610013060 KNOB K-263 1 MP8 8610013070 KNOB K-263 (A) 1 MP9 8610013030 KNOB N-353 2 MP10 8610013040 KNOB N-354 2 MP11 8610013050 KNOB N-355 2 MP12 8310068600 2969 KNOB PLATE 2 MP13 8610011310 KNOB K-229 2 MP14 8610013100 KNOB K-229 (J) 2 MP15 8610013080 KNOB K-229 (K) 1 MP16 8610013090 KNOB K-229 (L) 1 MP17 8610013110 KNOB K-229 (M) 1 MP18 8210023540 2969 REFLECTOR 1 MP19 8930071250 2969 WINDOW SHEET 1 MP20 8930071430 2969 KEY SPONGE 1 MP21 8930071410 2969 KEY SHEET 1 MP23 8930006440 Push spring (F) 2 MP25 8830003020 Bit insert SB-264540-CD 2 MP26 8610007510 Knob spring NO.7800 2 MP27 8610007420 Knob spring NO.6601 2 MP28 8830001010 HEX NUT (A) 2 MP29 8810009221 Screw BT B0 2X8 NI-ZK3 (BT) 8 MP40 8930071860 2969 LCD PLATE 1 MP41 8930072030 2969 LCD FILTER 1 MP42 8930072020 2969 LCD SHEET 1 MP44 8930072050 2969 RBEF SHEET 1

DESCRIPTION

QTY.

[MAIN UNIT]

REF ORDER NO. N O.

J2 6510023110 3008L-8P8C 1 J3 6510025950 PCB-606 (6P6C) 1 J4 6510023161 DN-508B-6-L 1 J5 6450001430 HSJ1462-01-010 1 J8 6510025940 PJ-3047S 1 J9 6450001440 HSJ1403-01-010 1

W1 8900016070 OPC-1669 1 W2 8900016070 OPC-1669 1 W5 7120000470 ERDS2T0 1 W6 7120000470 ERDS2T0 1 W7 8900016020 OPC-1671 1

MP2* 8510018150 2969 B-VCO CASE 1 MP3* 8510014940 2601 VCO CASE 1 MP4* 8510018150 2969 B-VCO CASE 1 MP5* 8510014940 2601 VCO CASE 1 MP6* 8510016470 2775 VCO CASE 1 MP7* 8510016470 2775 VCO CASE 1 MP8* 8510018140 2969 S-VCO CASE 1 MP9* 8510018140 2969 S-VCO CASE 1 MP10 8510018160 2969 B-VCO COVER 2 MP11 8510014950 2601 VCO COVER 2 MP12 8510016460 2775 VCO COVER 2 MP13 8510016460 2775 VCO COVER 2 MP14 8930060270 2633 M-SHEET 2 MP15 8930059770 2633 M-HOLDER 2 MP16 8930073170 SPONGE(JQ) 1 MP17 8930073180 SPONGE(JR) 1

DESCRIPTION

*: Refer to SECTION 8 BOARD LAYOUTS.

QTY.

[ACCESSORIES]

REF ORDER NO. N O.

MC1 Option HM-133 1

F1 5210000080 FGB 20A 1

W1 Option OPC-1132 1 W2 8900016370 OPC-1712 1 W3 8900016050 OPC-1663 1

MP1 8010016730 150 MOBIL BRACKET (SI) 1 MP2 8930041170 452 FELT (SI) 2 MP3 8820000530 Flange bolt M4X8 NI 4 MP4 8810000951 Screw BT A0 5X16 ZC3 4 MP5 8850000180 Flat washer M5 SUS 4 MP6 8850000500 S-washer M5 SUS 4 MP7 8810000471 Screw PH (+-) M5X12 ZC3 4 MP8 8830000250 Nut M5 SUS 4 MP9 8930007300 MIC hanger 1 MP20 8310068640 2969 CHASSIS PLATE 1 MP21 8810009611 Screw M2.6X6 ZK3 1 MP22 8010020830 2969 BRACKET (Inc. MP2) 1 MP25 6910018710 NDRDY-15060304 2 MP26 8810009611 Screw M2.6X6 ZK3 2

DESCRIPTION

W1 W2

W3

MC1

QTY.

[VR1 UNIT]

REF ORDER NO. N O.

R1 7210003250 RV-320 1

W1 8900016030 OPC-1666 1

DESCRIPTION

QTY.

[VR2 UNIT]

REF ORDER NO. N O.

R1 7210003250 RV-320 1

W1 8900016030 OPC-1666 1

DESCRIPTION

QTY.

MP25

F1

MP9

MP1

MP26

MP4

MP8

MP20

MP7

MP5

MP21

MP3

MP6

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

7 - 1

MP22

MP5(C)

MP10(C)

MP9(CON)

MP3(CON)

MP23(CON)

MP7(CON)

MP10(CON)

MP9(CON)

MP5(CON)

MP11(CON)

MP9(CON)

MP28(CON)

MP4(CON)

MP6(CON)

MP5(CON)

MP10(CON)

VR1 UNIT

VR1(VR1)

MP1(CON)

MP28(CON)

MP11(CON)

MP12(CON)

MP13(CON)

MP6(CON)

MP14(CON)

MP15(CON)

MP16(CON)

MP23(CON)

MP8(CON)

MP21(CON)

MP17(CON)

MP14(CON)

MP13(CON)

MP24(CON)×2

MP29(CON)×4

MP2(C)

MP17(C)

EP1(U)

MP1(C)

MP3(C)

MP36(C)

MP9(C)

J2(C)

MP14(C)

MF1(C)

J2(C)

IC3 (M)

MP16(C)

MP7(C)

MP18(C)

MP14(C)

SP1(C)

S15(CON)

MP18(CON)

DS1(CON)

VR2 UNIT

VR2(VR2)

MP18(CON)

S16(CON)

MP29(CON)×4

CONTROL UNIT

MP15(C)

MAIN UNIT

MP12(C)

MP6(C)

MP13(M)

W7(C)

MP15(M)

MP13(C)

MP20(C)

IC2 (M)

MP14(M)

MP15(M)

MP14(M)

MP11(M)

MP12(M)

MP19(C)

MP10(M)

Unit abbreviations (C) : CHASSIS PARTS (CON) : CONTROL UNIT (M) : MAIN UNIT (U) : UT-123 (Optional product)

7 - 2

SECTION 8 BOARD LAYOUTS

• MAIN UNIT (TOP VIEW)

0V5

H0H5H10H15H20H25H30H35H40H45H50H55H60H65H70H75H80H85H90H95H100H105H110H115H120H125H130

1

J5

J2

EXTMIC

MICE

EP37

CTHV

RD ATA

GND

NC

• HM-133 (TOP VIEW)

V

8V

MICU/D

PTT MIC

MICIN

07PE

R581

Q

1

9

C654

9

65R

95R

0

13CI

R591

3PE

2

R759

066C

C850 C851

C849

C852

NC

GND

TX D ATA

5

0

2V

6P

E

21PE 1

85C

Q88

R566

0

5R

5

C

C637

09Q

1

6C

4

5R

8

5R

8

R768

717

C

67R

2

466R

R785

R767

C866

5

2V0

V53V0

3

C592

C597

126C

EP8

R529

R

735

32P

E

35R

R

2

335

E

P

01

C589

C619

Q87

C

026

25R

7

9PE

C623

8

5R

3

1

5R

4

C624

R

265

636C

R

545

IC28

536

5

06

945R

R

R547

R570

C642

03CI

C655

285R3

485R5

C456

526C

R369

R846

C473

M

4P

L116

D92

1

8

L

1

C493

14R

3

2

4C

0

IC8

C30

V5

V0

4

R396

C470

C471

7

74C

583R

4

5

Q

Q67

R374

R376

C459

459C

R340

443R

D86

C451

3

43R

2

6Q

R

733

744

C

1

6Q

R365

R378

R

R347

3R

55

IC17

3

2

R

6

R849

C452

R390

98D

L115

D90

711L

D87

4PM

C464

84C

1

5

304R

4R

0

283R

4

0

6

R

94C

493

R

C488

C489

Q72

C945

D91

974

C

4

0

C492

C484

0

24R

C498

0

4R

9

Q74

R421

C508

C482

7

9D

1

14R

R412

Q73

4R

62

L121

Q76

C502

R427

05C

9

2

33R

R335

C425

C427

Q57

R327

R328

C734

6

4Q

863

R

354C

Q43

2PM

4

5V55V06V56

R402

C929

R407

D

49

C928

8

R

14

9

6

D

C

4

I

1

514C

2

R

3

L113

02

4C

C401

C430

R325

C431

C

434

144

C

4

8

C

444

C

11L

4

105

C

843R

94C

0

8

R349

Q

0

6

3R

05

C504

C446

L120

324

R

R748

C499

C512

R356

061D

1

C

C516

15

201D

R

2

34

R

33

4

C521

C522

425C

C

924

C933

D

R323

R316

8D

C931

C894

R331

C927

R

588

R372

383

R

C476

R388

L162

R441

944

IC45

R448

R400

39D

5

8

R

C

7

74C

4

93

R419

C495

C926

C889

R417

D

5

9

7

54R

L129

C

448

IC62

C

445

C536

R750

1

38

C

D101

82

4R

285

C

D

951

0

4R

6

5

4R

5

401D

L161

C

538

301D

C

728

R747

R752

EP47

R307

C932

488R

3

1

4

R

8D38

2

R322

C419

R317

824

123R

C

R341

C930

48

D5

0

33R

R406

C891

C841

R

C830

C833

1V

01V

106C

PE

5

E

C

7

195

P

8

P

11

E

R

17

5

29Q

D140

5

8

R

96P

E

4

2PE

9

3

C363

C722

C872

C856

R769

R763

R764

R765

558C

066R

84CI

C759

IC50

97R

861D

761D

D

C762 C763

I

14C

968R

R694

C

R

067

696

R695

R

896

48R

1

C761

R697

R848

C838

IC42

Q

121

C

037

L144

C724

D

541

C

D146

R

40

7

R

507

L145

841D

077

C

307

R

6

L

C

41

767

967

C

C772

807R

011

Q

377C

777C

417R

667C

C

35

7

R870

C557C

586R

457

R

C729

PM

2

0

07R

5

7C

3

7

1D

4

7

8

6

C771

17R

Q111

717R

707

C774

1

9C

5

7

C

5

7

Q109

L147

C727

R699

467

C

C765

R701

207R

R721

211Q

C839

917R

R726

187

C

C779

C784

527

R

217R3

R728

L

051

R727

R723 R724

397C

797C

Q113

059C

C780

C783

5

447

87C

08C

R

6

R743

IC43

C821

L149

8

C

2

C

887

7

C798

C

937

Q106

R722

C790

R711

918

17R

C

8

787C

R706

R710

D152

907

R

5

Q

1

C776

D151

D150

C811

737R

L160

937R

IC44

C803

C808

84PE

3PM

R796

997R

R

R798

C873

7

561D

661

R

276

008

978

516

C

878R

IC34

Q94

C674

R618

Q118

R621

9

16R

D141

716R

Q97

C676

R620

9Q

6

566C

R881

C905

C906

R

628

216C

328R

C908

088R

75CI

288R

C

119

728R

C909

C910

85CI

C903

R821

R822

409C

388R

I

1

5C

R628

R784

667

R

758

C

C862

R804

C918

C861

R

177

C

858

R774

577R

R772

R773

C860

C859

9

Q

9

C948

EP31

266C

R

857

L163

C898

IC46

486

C

C919

586C

J3

1

6

EP14

C605

C607

R473

449C

958R

61PE

R497

R490

R858

R506

EP13

C

R504

395

384R

V

7

V0

514R

C884

C480

Q117

R811

17Q

015

C

Q69 Q70

C

60

5

414R

R422

893

R

C503

5PM

565C

C

C7

C

6

5

0

855

5

L130

1

131L

C799

697

1

587C

027R

L124

221D

R465

L133

5

31L

C568

C563

D106

C547

C534

C539

375

C

R450

1

52

L

701D

C

835

32

801D

R466

R470

C562

4

L

3

1

C567

97Q

C566

535C

544

R

235C

L159

4R

335C

64

C442

643

R

Q59

R345

65Q

3

2

4

C

Q53

634C

Q54

R342

433

C822

C809

C837

R745

L155

L158

651D

C812

R738

1

6

L

5

C817

L153

1

8C

6

R734

451D

D153

7

08C

0

608C

R733

2

51L

841L

C804

C795

987C

C815

R741

9

7C

2

751L

751D

C820

C818

D132

168R

R557

D136

435R

001Q

C698

R770

035R

62CI

125R

425

R

R523

225R

355R

528R

R865

R866

C934

42J

C554

C529

C

625

6

34R

L

MP5

9

D

1

0

C

725

048C

C422

R324

8

4C

1

C437

R

R742

328C

Q116

C794

C

1

L

5

1

97C

MP3

6

17R

551D

C814

684R

R536

C617

R867

V

57

08

V0

V

8

9

5

C6

4

4Q

R462

C561

955

C

L136

IC20

C870

C871

R792

R793

R464

R467

MP9

7

L

3

1

R469

5C

27

7

5C

4

L132

2

5C

5

945C

R463

2CI

C564

075

C

5

96

C

9PM

44C

Q17

R20

Q13

C9

1R

2

D

5466-B

)

(,6.1=t

C403

503

R

3CI

8

PM

L122

815

C

415

R453

R443

C530

L126

4

1

5

C

735C

431C

5

1Q

61C

R

71

R8

21Q

8C

D124

D125

D126

D134

538R

D127

D135

068R

D128

D129

D130

D131

D139

368R

R567

C643

836C

C639

C

746

C

R644

296C

R

IC23

R476

306C

984R

6

38R

394R

463

865R

C640

R255

R627

Q41

386C

236R

352R

5

46R

1

52R

974

484R

R817

R818

R819

R851

C584

D133

D137

D138

596C

C600

4

C525

C528

R440

IC19

R790

C868

C869

R791

MP8

R444

R447

721L

C

055

C

355

C883

093C

IC12

C388

R290

4Q

C7

C389

R285

873C

R278

R

C370

R262

R276

C

163

563C

084R

284R

9

C377

183C

482R

952R

IC11

C362

C356

C384

752R

993C

762

842R

882

R

C380

R258

R283

R277

R265

R246

C360

C358

573C

Q50

C355

652R

742R

001V

59V

R

74

D

C576

R461

D

C

655

5

C

11C

R

0

1

2

C

V

51C

D

9

L3

1

R

4

1

11R

21C

D12

31C

L4

C25

7

L1

R23

C33

L6

1

0

D

01C

1

C

2C

82

R9

1

R

8

53D

C575

C

06

1

Q4 Q9

L47

R

431

C163

35

L

L52

C175

04D

C182

C185

R

C191

D

34

1

9

R

5

02C

7

C208

5

61R

12C

71R

6

3

761

441R

C

69

1C

L58

C205

R139 R142

R147

L48 L49

R156

D45 D46

1

4

C

9

1C

07

R

531

73D

C

R

341

002

171

C

L60

R150

C211

R160

C

951

791C

R

631

5

4

5L

L

1

D41

1

6

9

C

L55

C168

31R

7

83D

1

81C

C

481

8

D

C14

2L

C26

D11

L5

L7

C36

D13

C34

D15

3

C38

C39

R19

R24

R30

C41

C45

R31

C51

47R

C90

C99

45CI

R86

C108

473C

51R

173C

372R

082R

53C

452R

9

Q48

353C

963C

763

C

172R

252R

Q47

253C

C17

R613

1

16R

016R

216R

472R

806R

862

R

R829

C651

375R

IC59

785R

275R

685R

C657

C913

R862

R592

C653

R272

395R

R266

C700

11V

501

0

Q18

C27

C35

2

C

4

R

62

D14

92C

L10

23C

C37

R27

04C

R

2

9

71L

L8

5

3

C

82R

2

5R

R

3

457R

5

4

6

C

C48

L16

C55

Q19

R35

C58

R48

16C

61D

L13

R

1

4

C47

7

2

R

C

4

1CI

C895

C937

C179

541R

351

C938

C189

R757

L57

R180

D4

Q32

8

4

R

1

R173

2

R177

R175

C229

C233

C236

36L46L

45D

C257

C

252

C262

C258

0

02R

C264

6

02R

8

62C

85D

L74

R

991

R183

D51

Q34 Q35

5

52C

C

432

R170 R171

31

2C

R

461

222

C

7

2C

1

R

861

2C

32

81C

7

D44

881

C

R155

R149

C

L12

L15

D17

3

8

R

R49

C75

42L

91D

C98

R81

C101

8R

3

C105

601C

72D

43L

61Q

R609

D56 D57

2

1R

8

5

D

42C

9

C237

R187

352

C

R195

C

932

L67L68

D50

681

R

D

R161

591C

391

R169

C49

C56

C62

C63

45R

R50

28C

72L

12

D

42D

3L

3

311C

12R

5

C284

R225

7

42C

6

R191R192

R239

2

34

C

C206

R189

532C

657

R

58

1

L59

Q33

D3

R190

C215

2

4

912C

4

C

R179

R181

471R

2

42C

L66

C50

L18

R755

02Q

C845

67C

55R

06

R

16R

C78

2D

B1

J10

C100

5

1C

101

11C

81

R

2D

8

611C

R93

911C

L41

C667

666C

121R

33CI

95

6C

828R

C661

C658

L139

R626

R631

C680

R639

Q102 Q103

C689

R642

R649

R663

036R

R 856

356

R625

C679

496C

C704

R638

Q101

R641

C688

11V

5

R

7R6

2

Q

2

C

R51

R39

C

04R

75

C74

D

1

R45

R58

D20

C66

17C

L23

C77

8

1D

L21

C91

5

C

8

9

2

C

R

758

A2

J

521

021V

V0

V5

1

Q

378R

274

R

1

6

D

1

C67

R73

Q23

L20

46

C

69C

D23

9C

7

R78

R79

C

1

L

32

59C

C72

R67

R70

7

3

C

D30

411C

L31

C112

L32

D

6

2

C120

R94

C848

58R

201C

R98

301

70

1C

4

1Q

D32

3

01R

Q

0

3

221R

R126

R

658

J11

B2

C846

R44

Q

12

8R

57

C153

EP1

R876

88C

C285

L75

C282

212R

6

22R

83Q

D76

C336

0

62C

5

L

6

D55

C

162

R203

R208

C

652

C259

C

332R

223

C

18L

J22

R102

011R

C126

821C

R115

L39

2Q

9

901R

0

411

41C

R

R119

931C

741

C

941

4L

3

44L

66D

R871

R872

6C

26C

81

L141

D169

Q123

C80

C946

C295

49C

2

0

D

7

R223

0

92C

L

R

2

R217

C294

D60

C271

762

C

2

R

A1

8

D68

C283

L71

C289

L72

C321

R

632

7

8

L

R

13

2

C

992

9

3Q

113C

4

03

822R

02

2

7

R

2

R218

C300

122

R

782C

L76

661L

46D

D71

76D

C280

C292

R213

C

972

L78

C305

56D

L82

C291

C301

9

7L

912R

C313

48L

R216

C293

882C

D63

C630

R850

D69

IC55

D73

C626

926C

041L

831L

C706

R

3

L105

L107

C

043

343

7

531C

01R

R120

41C

8

L42

L

5

4

84D

C952

94

D

8

7

R

L164

R204

3

59C

041V5

C

743

6

L

9

7

C251

31

1V

D22

C339

R80

L30

L102

733C

C117

R16

C

8

1

C152

R124

C

331

C137

R113

3

L

8

2

11R

Q28

R118

C136

C146

7

21C

01R

8

L40

D53

R853

072C

17PE

J1

C94

EP2

513

C

R

922

R

53

2

R232

L85

C

613

R234

0

22R

2

9

3C

Q37

C324

R237

C306

R230

R238

C325

C331

79L

L91

87D

97D

2R

7

7D

C

3

14

9C

1V

41V0

5

W5

L110

(MAIN UNIT)

C

943

RL3

R

442

0

5

3C

08D

54

2

R

Q40

R243

5

61L

C345

143C

0

4

43

L94

L100

C335

51V

5

11SD

J1 (CHASSIS)

DS6

DS8

MC1

DS7

DS1 DS2

V0 V5 V10 V15 V20 V25 V30 V35 V40 V45

H5H

0

• VR1 UNIT (TOP VIEW)

51H0

01

H

2H52H03H5

• CONTROL UNIT (TOP VIEW)

1W

J7

1

2

SP1

0V5V

1R

H5

H0

H10

73SD63SD53SD43SD33SD23SD13SD

3H04

22SD

01S

DS3 DS4

H

R188

32SD

01SD

54H05H5

DS5

H

0

5

6

5

7H57H08

0

H

R852

C225

W6 (MAIN UNIT)

GND

J2 (CHASSIS)

J9

J8

• VR2 UNIT (TOP VIEW)

5V

B6647A

0 V

H5

H0

981R

93SD

83SD

41S

H10

EP51

R665

C716

EP53

6W

L109

R

C344

242

843C

601L

R661

C712

55PE

EP50

94PE

913C

C312

713C

D72

68L

422R

C622

C847

723

C

9L

0

C332

L93

823C

D74

L95

C323

38L

C329

703C

892C

875C

L103

89L

C338

333C

L99

085C

45PE

C719

987R

711D

R659

C710

25PE

HV

31S21S11S

52SD42SD62SD 92SD82SD72SD

6S5S 8S7S

12SD

51S 61S

0H5H01H51H02H52H03H53H04H54H05H55H06H56H07H57H08H58H09H59H001H501H011H511H021H521H031H531H041H

V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50

8 - 1

• HM-133 (BOTTOM VIEW)

[PTT]

B6094B

1

S1

41C

C12

CI

3

2R

7

4D

D

3

R42

C24

R35

Q5

2

1R

11R

C

72

R

9

Q4

01

R

2

1D

R

34

D5

94R

1

5R

05R

4

4R

6D

R25

R24

R23

D16

4

R

2

8

7H57H0

H

MC1

H0

MIC

MICE

• CONTROL UNIT (BOTTOM VIEW)

4 1 H

3 1H0

031H5

5 2 1 H

0 21H

5

R

11H

1 73

1 1 H

1 H0

0 0 1 H50

871R

H

5 8 H09H59

08H

831R

5 7 H

7H

R130

R131

56H0

901C

14R

55 H06H

H

R 31 9

0 4 H54H05

5 3H

H

5 2H03

0 2H

51H

0 1H

5H

0 H

V0V5V10V15V20V25V30V35V40V45

• MAIN UNIT (BOTTOM VIEW)

V

7

R

Q2

Q3

9

1R

R18

I

6C

C15

31C

IC1

X1

R45

1C

D17

Q6 Q7

4

1R

C

62

51R

5

H55H06H56

84R

7D

31R

61R

4H0

22R

R

74

64R

1

D

1

3R

4

H5

R6

R8

C25

1

4R

R36

R37

C5

J1

L1

C22

C19

C21

EP1

3

C17

C18

EP2

01D

9D

2C

D1

C29

C23

R5

Q9

Q1

R

2

R39 R40

13C

C30

3H53H0

EP3

9C

01

C

D18

L2

C16

EP4

Q8

C11

83R

H

01H5

H52H0

1H02

J2

2

MICU/D

PTT MIC

8

MICIN

V0V5V10V15V20V25V30V35V40V45

0H5

8V

EXTMIC

MICE

GND

1

7

5

1

V5

1

4

1

R

2

L108

64

3C

L

4

01

C342

L101

• VR1 UNIT (BOTTOM VIEW)

B6646A

V

5

GND RVOL +3.2V RSQL

1

+3.2V

3J

R 1 37

R174

R209

01C

43C

6

12R 3

602R

C108

R212

66C

J 4

03C13C

11PE

R8

R4

7J 8J

26C36C

16C

R218

2D 4

R192

502R

R2

R6

C70

87R

21PE

R14

5J

J3 (CONTROL UNIT)

R160

R162

R C 3C4C 2

671

R161

R163

R156

Q92Q82Q 2

R158

R157

R159

R152

Q72Q6 2

R154

R153

R155

R148

R150

R149

R151

46C

C116

R144

R146

C120

R145

2D22D32D

R147

1

311C411C511C C811C911C 1 71

C122

41CI

1L

2R

121C

1 9

R140

R142

R141

R143

R133

R135

R134

71Q61Q91Q81Q12Q02Q32Q22Q52Q4

R136

C4466-B

1C

• VR2 UNIT (BOTTOM VIEW)

J5

HV 1

GND RD ATA TD ATA 4

J4 (CONTROL UNIT)

5

GND LVOL +3.2V LSQL

1

+3.2V

C47

Q3

21D

C

22R

401

Q1

12R

8C

31R

C 5

C55

C48

R177

R 7 7

41Q

51Q

R76

R207

R211

61C

R125

R126

R127

R128

R129

R132

R122

R123

81R

R196

7

C107

C51

011C

34C

C 54

1X

C56

C24

IC3

52C

C46

78C

C74

I

171R

R172

1C 0

C

C 7

17

2

571R

071R

802R

02D

C65

C59

C101

C57

C102

C111

C60

R191

R210

091R

R

591

1CI 3

2R

302R

40

R

C42

C44

C 6 7

72C

C28

9PE

02

102R

2

02

891R

991R

0

R220

612R

27R

C95

C54

C68

6CI

05C

4D

C26

1R 7 9

D8

R 1 08

IC9

D9

Q31

R168

C105

IC12

R83

C69

D10 D11

52R

2R 4

C10

R169

C7

68C

C29

01PE

5

V 0

H0 H5 H10

R

V

1

W 1

V5 0

H0 H5 H10

C314

8L

0

C

3C

3

0

8

3

0

6

9

L

3

C

3

0

L92

88

L

81

3

C

L

8

C310

D59

L62

C266

1

V0

C297

1

0

V5

4

82

C

1

D

6

L73

L77

C

7D

5

9

R

4

2

0

C

2

6

2

9

C

6

2

D

2

3C

6

02

3

02

R

1

C

622

4

D

7

212C

C198

2C

2

7

8

81

C

022

J9

C579

J8

V5

V

1

3

0

3

1

3

1

C

2

D

2

5

R178

3

72

C

C265

C272

C

2

4

2

68

C203

C202

1

6

L

C275

L

0

7

C274

02R

2

3

62

C

R

902

R154

6

81C

9

3

D

C

461

2

C

61

C161

L56

C157

64L

C610

895C

774R

IC24

IC21

C836

V

2

5

1

0

5

1V

1V0

1

0

V5

1

1V

V5

09

9V0

V

0

8

5

V

0

7

5

7

V

0

6

5

55

V

3IF

3X

5

064

7

8

C

3R

9

3

R

4

C

8

7

C491

C

64

8

R794

5

91

C

4

2

R

9

4R

3

0

3

1

C

5

7Q

R438

C523

D100

FI6

C548

254

R

3

091

7

R

C

51

6

1

2

0

C

261

1

R

51

2

R158

2

9

6

81C

2

C

1

0

C

1C

6

C174

671C

6

1

R

6

3

1C

L50

0

12R

7

C214

3

0

2

C

C199

D42

C151

R193

1

R

9

3

841R

C178

1

3Q

R167R176

I

C

4

C221

C232

6

C254

331R

0

2

5

R

822

C238

C

Q

6

3

142

C

1

12R

4

91R

9

1

7

R

C156

C278

R198

21R

9

R

0

51C

R

C144

EP4

C

1

3

C

4

D

13

R128

C142

C145

1

5

R

2

EP3

9

R

2

C

2

1

88R

C111

D25

1

11

L35

L26

R90

R106

401

5

2

421C

C104

L

2

9

19R

C

39

R

L36

C123

77

C87

Q

C68

6

2

L22

R68

68C

C

C543

R57

R64

Q22

07C

L19

R43

4

R

7

R

3

6

C

0

6

C486

IC18

C517

R431

5

C515

434R

C531

R439

045

MP6

C896

FI1

2

X

C

3

R

614C

C435

3

34C

R795

544

C

973

R

R395

D88

FI5

C507

614

R

C500

L119

C69

2

C

9

1

0

R

1

C121

97C

9

5

R

C

8

D29

98

R812

9

2

8R

8

3

C

R75

R76

L28

C

901

L25

C110

R814

C

4

8

C81

52Q

66R

R59

65R

45C

33R

56C

64R

73R

95C

R552

R558

IC25

C900

998C

038

R

C130

L37

6

5

1

551

C

C154

206C

316C

584R

C606

Q81

685C

C711C714C718

J7

D118

1D311

21

D

5C

7Q

D120

C709

C707

R647

5Q

Q

3

6Q

01Q

1C

R3

3C

C138

1Q

R874

R498

4R5R

R499

C882

R501

D119

48Q

005R

38Q

Q82

IC22

Q98

D142

326R

376C

63CI

C691

R635

307C

C

R138

141

R

041R

C19

C246

C192

R261

R264

Q8

24

Q

R263

R294

R296

373C

182R

682R

R295

C382

973C

C372

383C

572R

962R

753C

R270

R282

C

673

R249

453C

R525

R279

863C

153C

C590

015R

C614

R509

D164

719C

1

15R

215R

R831

585C

261D

C914

EP18

R475

R478

C596

R816

495C

C588

161D

C599

4X

R96

R

7

R116

9

7

R

1

141

C

R105

231

C

C131

72Q

683C

468R

R518

R520

R832

R833

C916

C943

518R

91PE

184R

02PE

C915

C604

C

8

40

24

51

03

4

6

R

IC15

C

6

4

7

C462

R

8

3

0

C461

Q

6

R381

C472

R384

R399

C483

L

9

4

7

C

MP7

22R

13C

L9

34C

11L

R563

R556

R564

R561

C627

R813

R559

C907

R

868

R839

R838

R554

935R

045R

C616

R516

805R

65CI

028R

6X

4

5

V

0

R336

R333

C387

L111

C398

C393

C

693

C421

C414

R309

D81

C413

C725

C728

R688

C733

R686

C738

C741

47C

2

1

4

2

C743

C752

R

D143

C750

R

V

5

4IF

C458

92R

2

5

83C

R287

R299

R338

C395

C392

X1

Q52

MP6

C406

023

R

R304

L112

793C

C

4

8

13R

R

8

3

6

4

7

C

Q

6

8

73R

7

R373

FI2

C424

C

047

086

C

R

C731

R678

R679

C736

C737

R690

X5

M

7P

Q105

C746

R682

447C

L143

R681

Q104

86

4

C

7

62

6

7

C723

Q58

R

933

4C

3

C443

V

0

5

4

3

663R

C

798

C

454

R358

Q63

0

54C

364C

53R

9

R352

1

53R

R

353

R494 R495

R367

C455

I

61C

892R

493

C

C405

C408 C410

R313

1

C

1

4

0

1Q

22

Q65

R363 R364

Q55

324

C

103

R

0

4

R293

947C

C747 C748

R683

57C

1

IC61

429

C

R

548

R847

0

21Q

C923

C457

3R

0

7

R360

46

Q

C877

R354

R

7

4C

1

913R

R302

R310

11

R

3

704C

R306

R303

1

3

CI

IC60

529C

24

R

8

R843

0

29C

R840

C921

9

1Q

1

C466

C469

9

237C

V

R519

15R

C922

R

908

3

6CI

5

0

2

3

Q86

R514 R515

7

D121

R801

R574

R

575

I

9

2

C

C644

448

C949

C645

C646

R589

I

C652

25C

6

8

C

4

R578

C875

R808

708

R

IC53

1

9

2

C

R810

08R

6

0

5

8

R

C876

C

I

9

C366

V

0

V

2

01V5

1

0

V5

V

H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100 H105 H110 H115 H120 H125 H130

J2

C

6

56

IC32

C649

8

5

2

7

R

0

7

R600

6C

7

8

8C

C874

EP68

7

9

R640

C687

7C

10

C

7

50

R643

5

4

R

9

C

66

C650

5

6

R

89

R

R579

3CI

5

Q

9

4

2

R

6

R637

87R

6

9

7

C

6

J4

3

4

R61

1

6

C677

J5

923R

C864

C867

R788

EP59

787R

R779

R780 R781

IC49

387R287R

C708

73CI

466C

C669

C675

EP60

EP61

EP62

EP63

EP64

6J

EP66

EP25

EP35

EP41

EP42

EP43

R777R778

C865

C863

866C

076C

EP26

EP27

EP29

EP56

EP57

EP58

209C109C

EP30

EP33

EP34

EP36

EP38

EP39

EP40

C611

3J

83CI

DMOD

ACQ

DAFOUT

AF

AMBETXD

DVC

30 1

BTONE

GND

NC

AMBERXD

NC

S-14325XH-P2

J6

Printed in Japan

16 15

GPSRXD0

GPSTXD0

GND

GPSRESET

GPSBOOT

GPSOPT

AMBERES

AMBESTB

AMBECLK

CPU5V

RXDT

DCEL

AMBEEPR

OP+5V

C5V

RXCK

TXCK

TXDT

8 - 2

SECTION 9 BLOCK DIAGRAM

• BLOCK DIAGRAM (Left side)

W50

CONTROL UNIT

S15

S16

to VR1 UNIT

to VR2 UNIT

VR1 UNIT

LVOL /LSQL

VR2 UNIT

RVOL /RSQL

A B

COM

A B

COM

Q14:2SC4738 Q15:2SA1586

NOISE FIL

IC21;TA7805F

5V REG

Q82: UNR9214J

PWR

CTRL

PWR

LSQL,LVOL

RSQL,RVOL

LDIAL_A LDIAL_B

RDIAL_A RDIAL_B

J4

1 2 3 4 5

J3

1 2 3 4 5

+3.2V

LCD_3V

REG

LCD_3V

LCD MODULE

IC55:ZXCT1022 D164:MA2S111

CURRENT DETECT

NOISE

FIL

Q83;2SA1588 D119;MA2S111

5VS REG

Q84;2SA1588 D120;MA2S111

5VS REG

Q81:2SB1132

VCC REG

to CONTROL UNIT J4

1 2 3 4 5

to CONTROL UNIT J3

1 2 3 4 5

KEY

S5-8,S10-14

L_DIAL_SW

R_DIAL_SW

LSQL,LVOL

RSQL,RVOL

(12.288MHz)

X1 CR-839

PWR

IC14:TC7W04FU

VOLTAGE

D20:MA8130

UP CON-

D21:1SS372

VERTER

D22:1SS372 D23:1SS372 D24:1SS372

A_CS1,B_CS1 A0,D0-D5,D6(SCL) D7(SI),/RES,WR(R/W),RD(E)

IC24;TA7808F

W1

L_V/MHz L_M/CALL R_M/CALL R_V/MHz

SET DUP TONE LOW PWR_SW

HV

IDET

CPU5V

5VS

L5V

5V

+8

REG

1 2 3 4 5

IC13: M30620FCPGP

L5V

MUTE

DADJMUTE

L5V

IC37: TC7W53FU

L5V

RSSI/LV SELECT

VTX_C

5VS

RSSI/LVR_RSLV SELECT

UTX_C

5VS

IC51: TC7W53FU

AF SW

DA_SEL

DTCS

AMP

L5V

BUFF

IC49: LMV358IPW

DDETMUTE

DDETSEL

L5V

OP+5V

VCC

DAFOUT

IC60: TC7W53FU

IC61: TC7W53FU

IC50: LMV321IDCK

VDET

UDET

VAFO UAFO

Q94:2SA1362BTONE Q118:UNR9213J

REG

Q96:2SB798 Q97:2SC4738 D141:MA2S111

C5V

REG

L_RSSI

L_LV

R_RSSI

R_LV

D5VC

AMP

IC48 3/4: LM2902PWR

AMOD

A

B C

D E

F

G H

I

J2

RX line

TX line

Common line

5VS

FANC

IC1:M62352GP

J5

to CONTROL UNITto MAIN UNIT

UATTC

5VS

D/A

L5V

D/A

IC54:M62352GP

J3

1 2 3 4 5

TXDATA RDATA CTHV

CTRL

Q14:2SC4738

R_RX140DA_CK R_RX400

L_RX140 L_RX220 L_RX300 L_RX400 VD5C UD5C

L5V

ATT CTRL

Q16:2SC4738

CPU5V

LEVEL

CONV

IC46: MAX3221IPWR

5V

LIMIT

D165,D166, D167,D168:

1SS400

MATRIX

D124 - D139:

MA2S111

CPU5V

D161:HVC376B D162:HVC376B

L140_R5

CPU5V

RESET

CPU5V

EEPROM

1/2

L5V

CL_SFT1/

L220_R5

L300_R5

L400_R5

5VS

REG

R_RX800

VATTVATTC

TX232 RX232

TX_DATA R_DATA

RESET

SCL/SDA

CL_SFT2

X4

CR-841

19.6608MHz

R_BPF1 R_BPF2 R_BPF3 R_BPF4 PCON_U PCON_V PL_U TX_MUTE

L_BPF1 L_BPF2 L_BPF3 L_BPF4 L400_S

IC23:S-80945CNMC

IC22:24LC512

R1,R2 R_UVCO_SEL,R_VVCO_SEL L_LO_SW,R_DA_SEL R_AFFILSEL,R_DET_MUTE L_DA_SEL,L_DET_MUTE

CLOCK SHIFT

CHASSIS UNIT

MF1

8V

VCC

+3.2V

5V

Q31:2SC4738 IC12:TC7S04F D8 - D11:1SS400

PROTECT

AND BUFF

CPU

1D_NEERG

1D_DER

VOLTAGE TRANS-

DUCER

IC10: LM2904PWR

CPU_TXD CPU_RXD

DS31-DS37:

FAMG1211F

TDATA RDATA HV

RESET

5V

+3.2V

PWR

LCD

LIGHT

CURRENT CONTROL

Q16-Q29: 2SC4738

BACK

IC9:S-80945CNMC

HV

FUN

CTRL

Q21:2SC4738 Q123:2SB1132 D169:MA8075

DA_STB

DA_DATA

DA3_STB DA_CK DA_DATA

RS-232C

J5

1 2 3 4 5 66

RESET

5V

+5

REG

IC3;TA78L05F

+3

REG

IC6:R1111N321B D4:MA8039

Q1:2SC4738 Q3:2SB798 D12:MA8068

DRIVER

KEY

BACK

LIGHT

DS21-29, DS38,39: SML-512MW

HV

To the microphone

UATTATT

D112:DAN222

REG SEL

D113:DAN222

REG SEL

Q3 - Q11 UNR9114J

L140_R5 R140_R5 L220_R5 L300_R5 VD5 UD5 R400_R5 L400_R5 R800_R5

L_VR5

L_UR5

CPU5V

1 2 3 4 5 6 7 8

J8

J9

SP1

R_RX800IDET

CPU

IC25:HD64F2506FC26

MICIN

J4

CLONE_IN CLONE_OUT

MIC

PTT

Q87: 2SC4738

56

34

12

L5V

8V

IC28: IC30: TA75S558F

HPF

5VS

D121:MA2S111

MIC_PTT

PTT DETECT

L5V

98_DATA

LEVEL

CONV

IC26:LMV321IDCK D122:MA8047

IC38:

VCC

LA4445

AF AMP

Q98:UNR9210J D142:MA742

CLONE

MIC AMP

DATAIN

AFOUT

DATAOUT

L5V

AND

SP

MUTE

MIC_PTT 98_DATA DTCS DTMF P_PTT P_SQL AF_VOL_RES AF_VOL_DATA AF_VOL_CK AF_VOL_STB

Q88:UNR9213J

IC36: SN74AHC1G08

DTMSTB

DTMSD

5VS

CD4066BPWR

MIC SENS

SELECT SW

MIC_SENS

5VS

PACKET SQL CONTROL

Q93: UNR9213J

D140:DA221

LIMIT

5VS

PACKET DATA SELECT

P_LR_SEL

L_R5C R_R5C R_AMC L_AMC

PLLCK PLLDATA L_PLLSTB R_PLLSTB DA_CK DA_DATA DA2_STB

L_WXALT L_DTCS_IN R_WXALT R_DTCS_IN

L_RSLV R_RSLV L_SQL R_SQL

MIC

MUTE

MM_MUTE

Q95:UNR9213J IC35:CD4066BPWR

Q102:2SC4213

SP

MUTE

L_AF_MUTE

R_AF_MUTE

SP

MUTE

Q101:2SC4213Q103:2SC4213

L5V L5V

IC56:

BU8872FSDTMCK

DTMF

DEC

X6

CR-838

4.194304MHz

5VS

PACKET PTT DETECT

Q92: UNR9113J

5VS

PACKET AF SELECT

Q95:UNR9213J IC35:CD4066BPWR

P_LR_SEL

DVDTMFSEL

Q43,Q44:UNR911NJ Q45,Q46:UNR9114J

L5V

ELEC.

VR

SELECT

REG

DET

P_SQL

P_MOD_MUTE

IC33: SM6451B

IC58:

5VSL5V

IC29: TC7W53FU

AF

DCONT

5VS

PACKET MODE MUTE

IC31 CD4066BPWR

AF_VOL_RES AF_VOL_DATA AF_VOL_CK AF_VOL_STB

ALC AMP

1200_9600SEL

VAFO

UAFO

L5V

AF MIXER

IC59 TC4S66F

ANALOGSW

DAFOUT

L5V

SELECT

DTMFSEL

DET

IC57: TC7W53FUTC7W53FU

L_R5 R_R5 R_AM L_AM

AN6123MS

5VS

PACKET MOD SELECT

IC32:

P_PTT

Q90:UNR9213J IC30:CD4066BPWR

VDET

UDET

GPSBOOT GPSRESET C5V GPSOPT GPSRXD0 GPSTXD0 AMBECLK AMBERES AMBESTB AMBEEPR AMBETXD AMBERXD DCEL RXDT/RXCK TXDT/TXCK ACQ/DVC

IC52: TC7W53FU

AF SW

8V

Q99: UMG9N

DA_SEL

DTCS

DTMF

CUTOFF SHIFT

IC48 1/4,2/4: LM2902PWR

HPF

AN

DMOD

CPU5V

OPTION

UT-123 UNIT

IC48 4/4: LM2902PWR

Q100:Q86:2SC4738 UNR9213J

DTCS_SEL

IC34:

TC7W53FU

DADJSEL

LPF

DIGITAL MOD SEL

DET SELECT

L_RSLV

9 - 1

• BLOCK DIAGRAM (Right side)

A

B C

D E

F

G H

I

5VS

MOD_DA MODSEL

AMP

IC53:

LMV321IDCK

DA_CK DA_DATA DA2_STB

VDET

UDET

VAFO UAFO

IC9: TC7S66FU

MOD SELECT

L_LV

PLLCK PLLDATA L_PLLSTB

R_LV

PLLCK PLLDATA R_PLLSTB

D/A

L5V

IC63: TC7S66FU

MOD SELECT

IC8: M62363FP

DAFOUT

Q119: 2SK1069

X5:CR-833

TCXO

DOM_FER_L

NOCFERL

DOM_OCV_L

8V

BUFF

D143 MA2S111 IC41: Q111:2SC5231 MB15A02PFV

12.8MHz

Q105: 2SC4738

X3

R_VCO_MOD

DOM_FER_R

NOCFERR

VAFO

UAFO

PLL

IC

Q104: UNR911NJ

X3 REG

L_R5C

8V

Q120: 2SK1069

BUFF

D81: MA2S111 IC14: MB15A02PFV

15.3MHz

X1:CR-783

TCXO

5VS

R_R5

X3

Q52:2SC4738

8V

L_AFFILSEL

AF FIL

8V

R_AFFILSEL

AF FIL

L5V

Q47:XP6501 Q50:UNR9213J

Q48:XP6501 Q49:UNR9213J

IC42:TC7S66FU Q121:UNR9213J

FILTER

SW

LOOP

FIL

135.575

–

255.575 MHz

8V

BUFF

Q112: 2SC5108

L5V

IC17:TC7S66FU Q65:XP4601 Q122:UNR9213J

R_PLLSW

5VS

PLL

IC

UMMUTE

MUTE

Q64: UNR9213J

L_PLLSW

Q109: UNR9213J

MUTE

FILTER

SW

LOOP

FIL

Q61:2SA1586 Q62:2SC4116 D86:DA221

L_WXALT

L_DTCS_IN

L_DET_MUTE

L_DA_SEL

VDET

R_WXALT

R_DTCS_IN

UDET

R_DET_MUTE

R_DA_SEL

L_VCO8

D145:HVC321B D146:HVC321B D147:HVC321B

VMMUTE

Q68:XP4601

VCO SELECT

164.350–

220.350 MHz

Q72:2SC5231 D89:HVC362 D90:HVC362

353.65

523.170 MHz

Q73:2SC5231 D91:HVC375B D92:HVC350B D87:HVC321B

WXALT

FIL

5VS

Q41: XP4601

CTCSS

FIL

5VS

IC11: TC7W53FU

DIGI/AN

SELECT

WXALT

FIL

5VS

Q42: XP4601

CTCSS

FIL

5VS

IC12: TC7W53FU

DIGI/AN

SELECT

L_VCO8

REG

BUFF

L_VCO_SHIFT

Q58: 2SC4738

Q113: 2SC5231

Q110:UNR921NJ D148:MA2S077

SHIFT

R_VVCO_SEL

R_UVCO_SEL

BUFF

–

BUFF

L5V

DET OUT

5VS

DET OUT

TC7W53FU

IC44: UPC2709TB

Q74:

2SC5231

Q76: 2SC5231 D97: MA2S111

IC13: TC7W53FU

SELECT

IC16:

SELECT

AMP

L_VR5

L5V

L_VCO8

Q115: UNR9213J

VT8

D155:1SV308 D157:1SV308

LO SW

D151:MA2S077

LO SW

D152:MA2S077

LO SW

D150:

L_UR5 L_UR5

MA2S077

LO SW

REG

D160:MA2S077

D102:MA2S077

8V

Q60: 2SC5108

L_AM

L_LO_SW

VCO

SW

VCO

SW

BUFF

L_WN_SEL

L_R5

Q55,57: XP6501

AM DET

L_2ndLO 38.4MHz

R_WN_SEL

R_R5

R_AM

Q63,67: XP6501

AM DET

REG

Q106: UNR911NJ

FI2: LT450EW

CERAMIC

L_SQL

L_RSSI

AMP

UPC2709TB

R800_R5

D109:MA2S111

450kHz

BPF

WIDE/NARROW

450kHz FI4: LT450EW

CERAMIC

BPF

WIDE/NARROW

R_2ndLO

ATT

L5V

5VS

IC45:

SW

FI1: LT450HW

CERAMIC

SELECTOR

45.9MHz

R_SQL

R_RSSI

HPF

BPF

FI3: LT450HW

CERAMIC

BPF

IF IC

136.000–174.000MHz

141.150–221.145MHz

LPF

271.150–511.150MHz

LPF

79.150–121.150MHz

IC43:UPB1509GV

Pre SCALER

R140_R5

Q59:UNR9213J Q53:UNR9113J Q54:UNR9210J Q56:UNR9113J D82:MA2S111 D83:MA2S111 D84:MA2S111 D85:MA2S111

IF IC

D93:MA2S11 D94:MA2S11 D95:MA2S11 D96:MA2S11 Q69:UNR9113J Q70:UNR9210J Q71:UNR9113J Q117:UNR9213J

UAGC

VAGC

BUFF

D103:UT8 1SV308

LO SW

D159: MA2S077

LO SW

D101: MA2S077

LO SW

D104:MA2S077

LO SW

R400_R5

X2 JTB450C24

X3 JTB450C24

Q116: 2SC5108

IC18: TA31136FN

IC62: UPC2709TB

AMP

L_R5

R_R5

LPF LPF

HPF

LPF

400.000–469.995MHz

164.350–220.350MHz

856.350–1046.340MHz

763.650–953.640MHz

HPF

353.650–503.650MHz

RF

MUTE

Q79:UNR9213J

IF AMP

Q66: 2SC4406

IC15: TA31136FN

IF AMP

Q75: 2SC4406

D153:MA2S077

LO SW

D154:MA2S077

LO SW

D156: MA2S077

D88: DA221

LIMIT

D100: DA221

LIMIT

AGC

D1–D

6:

MA2S728

HPFHPF

LPF

ATT

38.85MHz

FI5: FL-408

Q15:2SA1362 Q12:UNR9213J

8V

VTX_C

8V

UTX_C UT8

ATT

UHFYGR

R140_R5 D107:

[USA]

[others]

D108:MA2S077

R400_R5

XTAL

BPF

46.35MHz

XTAL

BPF

FI6: FL-409

VU1 UU1 VU2

VV UV V220

VT8 REG

Q17:2SA1362 Q13:UNR9213J

L_RXLO

MA2S077

LO SW

D106:MA2S077

LO SW

VT8 Q25 D75:L709CE 2SC3357

PRE

DRIVE

UT8 Q22REG 2SC5085

PRE

DRIVE

R_Lo

D29 MA2S111

LIMITER

D25 MA2S111

LIMITER

VVIF

Q27 2SC4703

Q26 2SC3357

UUIF

DRIVE

AMP

DRIVE

AMP

L140_R5

D38:MA2S077

R140_R5

D35:MA2S077

HV

LPF

IC4:NJM3404AV Q31:UNR9113J Q36:UNR9113J

APC

CTRL

PCON_V

D55:HVC350B D60:HVC350B

RF AMP

L_BPF2

D54:HVC350B D58:HVC350B

RF AMP

D47:MA742 D39:MA742

SWR DET

D42:MA742 D52:MA742

SWR DET

TX_MUTE

118–174MHz

D68:1SV172

BPF

L_BPF1L_BPF4

D70:1SV172

BPF

R_BPF1

IC3 S-AV32

PWR AMP

D41:HVC350B D44:HVC350B

RX SW

D40:HVC350B D43:HVC350B

RX SW

R_BPF4

LPF

HV

IC2 S-AU82L

PWR AMP

8V

TX_MUTE

PCON_U

VV

BPF

Q33:3SK318

L_BPF3

UV

BPF

Q32:3SK318

R_BPF3 R_BPF2 UATT

118–174MHz

Q39:3SK318

RF

LO SW

IC19: SPM5001

L_RXLO

IC20: SPM5001

VVIF

R_Lo

UUIF

D10:1SV308 D16:1SV308 D12:HVC375B D14:HVC375B

RX

UUIF

SW

D7:MA2S077 Q19:3SK324

Q2:XP4601

5V

SHIFT

CTRL

R400_S

RX

VVIF

SW

D8:MA2S077

Q1:XP4601

5V

SHIFT

CTRL

L400_S

UUIF

R_BPF3

R_BPF4

D11:1SV308 D17:1SV308 D13:HVC375B D15:HVC375B

L_BPF3

L_BPF4

VVIF

R800_R5

RX SW

BPF

D36:MA2S077

D37:MA2S077

R400_R5

RF AMP

Q18:2SC5231

D18:1SV308 D26:1SV308 D20:HVC375B D23:HVC375B

BPF

R_BPF1

R_BPF2

D19:1SV308 D27:1SV308 D21:HVC375B D24:HVC375B

BPF

L_BPF1

L_BPF2

ATT

RF AMP

D45:HVC350B

D46:HVC375B

UU1

SHIFT D48,D49:

L400_R5

VU2

Q20:3SK324

SHIFT

RX SW

ATT

AMP

VD5

Q29:3SK324

RF AMP

UD5

D30:1SV172

ATT

UATT

375–550 MHz

D28:1SV172

ATT

VATT

375–550 MHz

BPF

L_BPF4 L_BPF3

BPF

HPF

TX/RX

ATT

VATT

ATT

V220

Q34:2SC5624

VU1

Q35:2SC5624

ATT

D59:L709CE

D77:MA2S077

SW

D64,D67: MA2S111

LIMITER

D63,D66: MA2S111

LIMITER

5VS

RX SW

RL1:ATQ206SA Q30:2SC4738 D32:MA2S111

UD5

L220_R5

RF AMP

L300_R5

RF AMP

D53:MA2S077 D61:L709CE D62:L709CE

TX/RX

SW

L5V

RL2:ATQ206SA Q38:2SC4738 D76:MA2S111

RX SW

VD5

D65,D71:MA2S077 D72:1SV308

ANT

SW

UD5 D69,D73:MA2S077 D74:1SV308

ANT

SW

VD5

R_R5

Q28:3SK324

174–260 MHz

D51:HVC350B

BPF

D50:HVC375B

BPF

L_BPF3L_BPF4

RF AMP

Q23:2SC5624

HPF

RF AMP

D56:MA2S077

D22:1SV308D9:MA2S077

L_R5

Q37:3SK318

LPF

HPF

MA2S111

LIMITER

RX SW

L220_R5L220_R5

RX SW

L300_R5L300_R5

RX SW

LPF

D78:MA2S111 D79:MA2S111

RF

LIMITER

AMP

ANT-2

(CHASSIS; J2)

LPF

5VS

RX SW

RL3:ATQ206SAD57:MA2S077 Q40:2SC4738 D80:MA2S111

260–375 MHz

810–1000 MHz

HPF

ANT-1

(CHASSIS; J1)

9 - 2

SECTION 10 VOLTAGE DIAGRAM

10-1 CONTROL UNIT

2SC4738

Q20

R146

10K

680

R145

10K

1M

R41

CR-839

X1

33P

C110

P72/clk2/TA1OUT

P71/RXD2/SCL

P70/TXD2/SD A

P67/TXD1

P66/RXD 1

P65/CLK1

P64/CTS1/RTS1

P63/TXD0

P62/RXD 0

P61/CLK0

P60/CTS0/RTS0

P57/RDY/CLKOUT

P56/AL E

P55/HOL D

P54/HLDA

P53/BCLK

P52/RD

P51/WRH/BHE

P50/WRL/WR

P47/CS3 P46/CS2 P45/CS1 P44/CS0 P43/A19 P42/A18

R14

100K

DS33 FAMG1211F

GO

2SC4738 Q21

R147

680

33P

R187

2SC4738

10K

R148

R149

10K

R_DIAL_SW

10K

R122

0

P73/CTS2/RTS2

/A17

P41

Q22

R150

680

L_DIAL_SW

24

25

P74/TA2OUT/W

P40/A16

51

52

G REEN_D1

RED_D1

R170

47K

R175

47K

C46

SW-169

Left

C47

COM

SW-169

Right

123

IC10

8

C74

L_V/MHz

L_M/CALL

R_M/CALL

R_V/MHz

LDIAL_A LDIAL_B

L_DIAL_SW

RDIAL_A RDIAL_B

R176

100

R133

10K

0.01

DUP

TONE

LOW

SET

R172

R171

10K

4.7K

1

C7 1

4

567

LM2904PWR

1

C72

R173

R174

12K

10K

S5 SKQDPA

S6 SKQDPA

S11 SKQDPA

S12 SKQDPA

S13 SKQDPA

S7 SKQDPA

S8 SKQDPA

S10 SKQDPA

0.01 S15

A B

COM

0.01

S16

A B

R_DIAL_SW

2SC473 8

R134

10K

LDIAL_A LDIAL_B RDIAL_A RDIAL_B

PWR_SW

RESET

CPU_TXD

Q16

R135

R207

R220

CPU_RXD CPU_TXD

680

2SC4738 Q17

R136

680

47K

F_CE

C70

DS31 FAMG1211F

GO

10k

1k

R78

10K

0.001

R140

R72

3.2V

C108

R212

C44

0.01

47K

R205

47K

2SC4738

10K

R141

10K

0.001

R202

R203

R192

1k

R142

680

C45

47K

R206

R213

Q18

R201

47K

0

0.001

47K

R200

R204

47K

RD(E)

DS32 FAMG1211F

GO

2SC4738 Q19

R143

680

C42

R199

47K

WR(R/W)

S14

SKQDPA

0.001

C43

47K

R198

B_CS1

47K

A_CS1

0.001

C109

R144

26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50

GO

2SC473 8 Q23

R151

680

10K

R123

/RES

PWR 22

23

P76/TA3OUT

P75/TA2IN/ W

/A15

P37

P36/A14

53

54

C106

DS34 FAMG1211F

19

20

21

P77/TA3I N

P81/TA4IN/U

P80/TA4OUT/U

A13

P34/A12

P35/

P33/A11

56

55

57

0.1

0.01

10K

PWR_SW

17

18

P84/INT2

P83/INT1

P82/INT0

P32/A10

P31/A 9

VCC

59

58

C34

2SC473

Q24

R154

R152

680

R153

10K

C51

R196

47K

15

16

XIN14VCC

P85/NMI

(/-/D7)

P30/A8

P27/A7(/D7/D6)

VSS

61

60

62

DS35 FAMG1211F

GO

8

2SC4738 Q25

R155

680

RESET

0.01

0.1

C107

11

12

13

VSS

XOUT

RESET

P26/A6(/D6/D5)

P24/A4(/D4/D3)

P25/A5(/D/D4)

64

65

63

CPU_RXD

10K

L_V/MHz

L_M/CALL

10KR132

10KR131

10

7

8

9

CNVSS

P87/XCIN

P86/XCOUT

D2/D1)

/A3(/D3/D2)

P22/A2(/

P21/A1(/D1/D0)

P23

69

68

67

66

1k

R195

A0

R83

2SC4738

R158

R156

680

R157

10K

DUP

TONE

10KR130

10KR129

6

BYTE

P91/TB1IN/SIN 35P90/TB0IN/CLK3

D0/-)

/D14/INT4

P20/A0(/

P16

P17/D15/INT5

70

71

+3.2V

10K

Q26

LOW

GREEN_D1

10KR128

3

4

P92/TB2IN/SOUT 3

/INT3

P15/D13

72

73

C105

2SC4738 Q27

R159

680

RED_D1

N

D12

P14/

74

DS36 FAMG1211F

GO

10K

1

P94/DA1/TB4I N2P93/DA0/TB3I

P95/ANEX0/CLK4

P96/ANEX1/SOUT4

P97/ADTRG/SIN4

P104/AN4/KI0 P105/AN5/KI1 P106/AN6/KI2 P107/AN7/KI3

P13/D11

M 30620FCPGP

75

IC9

1

OUT

2

VDD

3

VSS

S-80945CNMC

0.001

2SC4738

R162

R160

680

R161

10K

AVCC VREF

P100/AN 0

AVSS

P

101/AN 1 P102/AN 2 P

103/AN 3

P00/D0 P01/D1 P02/D 2 P03/D 3 P04/D P05/D P06/D P07/D 7 P10/D P11/D

P12/D10

IC13

CD

NC

Q28

4 5 6

8 9

D4

MA8039

DS37 FAMG1211F

GO

2SC4738 Q29

R163

680

99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76

5

4

100

C50

C26

SET

R_V/MHz

R_M/CALL

10K R126

10K R125

10K R127

1k R190

0.01

D8

0.033

D9

R210 100k

R191

+3.2V

1SS400

R216

LVOL

LSQL RVOL RSQL

1k

C54

1SS400

C16

100kR211

D6(SCL)

D7(SI)

SML-512MW

SML-512M W

R137

/RES

47K

4.7

D0 D1 D2 D3

D4

D5

22

C68

390

0.01

DS27

DS28

7.7mA

DS29

5

4

SML-512MW

L-512MW SM

RSQL

RVOL

C4

VOUT

NC

R1111N321B

R179

47K

R138

LSQL

RSQL

1

0.

7.5mA

680

LVOL

IC6

VDD GND

DS24

DS25

CE

R180

PWR

C1

C2

SML-512M W

SML-512MW

R13

10K

C5

1

0.

C3

R4

10K

R8

10K

0.1

1 2 3

2SC4738 Q31

27K

100P

DS21

DS26

7.5mA

680

R139

2SC473 8

Q1

10

+3.2V

R76

100K

J4

B5B-ZR-SM4-TF

R6

10K

R2

10K

1

0.

0.01

C86

1 2 3 4 5

J3

C87

0.01

B5B-ZR-SM4-TF

0.01

C67

SML-512M W

SML-512MW

7.5mA

1.2K

R188

HV

R22

C8

R21

67

1 2 3 4 5

67

W1

C56

DS22

DS23

R77

R178

W1

1 2 3 4 5

10

R168

DS38

SML-512M W

SET S10

470K

D1 2

MA8068

2.2K

2SA1586

Q15

470K

100K

SML-512MW

7.5mA

1.2K

R189

Q3

+9.3V

R177

PWR S14

DS39

2SB798

10K

Q14 2SC4738

C48

C104

LCD_3V

0.1

VR1 UNIT

1

2

3

4

5

R1

VR2 UNIT

1 2 3 4 5

5V HV

100

47K

1 2 3

C24

C25

IC12

TC7S04F

R1

TA78L05FIC 3

G

0.01

5

4

HV

LCD_3V

R208 100k

C118

0.1

1SS400

D22

1SS372

R24

D20

C114

R25

MASTER

LCD_3V

2.2 MSVAC59

2.2 MSVAC101

2.2 MSVAC57

2.2 MSVAC102

MA8130

0.1

10K

SLAVE

C119

0.1

D23

1SS372

C115

R169

2.2 MSVAC111

0.22 SV AC60

0.22 SV AC61

0.22 SV AC62

0.22 SV AC63

0.22 SV AC64

2.2 MSVAC95

1

C66

R209 100k

LCD_3V

1k

R218

C116

0.1

D24

1SS372

C120

0.1

18K

C7

1SS372

MMZ1608Y102BT

EP12

EP10 EP9

MMZ1608Y102BT MMZ1608Y102BT MMZ1608Y102BT

EP11

C30

C31

C29

47P

0.001

47P

C10

A_CS1

1

C65

0.01

22

C55

L1

10U

1

C122

C121

R219

47K

IC14

8

1

7

2

6

3

5

4

TC7W04FU

IO

C_10_25V_EEE-S_C

C28

0.001

C27

10

C69

0.01

C117

0.1

B_CS1 /RES A0 W R(R/W) RD(E) D0 D1 D2 D3 D4 D5 D6(SCL) D7(SI)

C113

0.1

D21

5V

D10

D11

NC

FR

NC

CL

/DO F

04-6240-034-001-800

J7

34

36

33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17

VDD(3.18V) 16 15

A_VOUT(11.1V) 14

A_CAP5+ 13

A_CAP3+

12

A_CAP1-

11

A_CAP1+

10

A_CAP2+ 9

A_CAP28

A_CAP4+ 7

A_V4 (1.01V) 6

A_V3 (1.98) 5

A_V2 (6.84V) 4

A_V1 (7.82V) 3

A_V0 (8.78V) 2

C86

35

1

P/S

04-6240-034-001-800

J8

34

36

33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17

VDD(3.18V) 16 15

B_VOUT(8.34V) 14

B_CAP5+ 13

B_CAP3+

12

B_CAP1-

11

B_CAP1+

10

B_CAP2+ 9

B_CAP28

B_CAP4+ 7

B_V4 (1.01V) 6

B_V3 (1.98) 5

B_V2 (6.84V) 4

B_V1 (7.82V) 3

B_V0 (8.78V) 2

C86

35

1

P/S

J5

TDAT A

4

RDAT A

3

GND

2

HV

1

HJC0187-010024

*; Refer to “PARTS LIST.”

10 - 1

10-2 MAIN UNIT (1)

OPC-465

MICU/D EXTMIC

MICE

MICIN

HSJ1462-01-010

J5

CTH30V222S15A

C847

HV

W50

8V

PTT

MIC GND

3008L-8P8C

PCB-606

IC21 TA7805F

I O

0.47 C578

HVC376B

R476

J2

1 2 3 4 5 6 7 8

MMZ1005Y102CT

6 5 4 3 2 1

J3

G

IC22

1

A0

2

A1

3

A2

4

VSS5SDA

24LC512T

22K

R475

C588

18P

D162

R816

100K

0.01

C900

C585

4.7K

C603

C584

2.2 MSVA

4.7K

R494

MMZ1608Y102BT X8

EP5 EP6 EP7 EP8 EP9 EP10 EP11 EP12

C581

MMZ1005Y102CT

EP32

EP31

EP37

C660

22P

C662

6

TXDATA

5

RDATA

4

GND

3

CTHV 2 1

RD20E

D117

D118

C;4.95V

C5800.1

VCC

WP

SCL

C914

22K

R478

68P

C594

D161

HVC376B

C596

0.001

1

0.001

2 3

S-80945CNMC

C589

47P

0.001

R759

100

22P

MMZ1608Y102BT

C579

2200

DSA3A1

C58610

EP18

CPU5V

8

C590

7 6

0.1

X4

CR-841

R481

1M

4P

C599

R815

100K

C899

0.01

RESET

IC23

CD

OUT VDD VSS

NC

R484

R479

1k

R495

1k

MICU/D

0.001 C592

C591

0.001

0.22

1

C849

2 3

C850

4

0.22

5

C851

6

0.22

7

C852

8

0.22

MMZ1005Y102CTEP16

1kR473

MMZ1608Y102BTEP14

EP13

To the CONTROL UNIT

0.001

C836

MMZ1005Y102CT

47K

0.1

R482

R480

22P

C604

CL_SFT1

CL_SFT2

0.001

5

4

0.033

C600

100K

MIC_SEL

MICUD

C897

0.001

C597

0.001

IC46

FORCEOFF

EN C1+ V+ C1-

FORCEON

C2+ C2-

INVALID

VRIN9ROUT

MAX3221IPWR

100

R758

C593

R477

47K

10K

CLONE_OUT CLONE_IN

AF_VOL_CK AF_VOL_DATA AF_VOL_STB

AF_VOL_RES

L_AF_MUTE

MIC_PTT

NMI MD2

MIC_PTT RESET

L_SQL CL_SFT2 CL_SFT1

GPSRESET

R_SQL

DCEL

ACQ

98_DATA

NMI MD2 RESET

0.001

C601

VCC GND

COUT

DIN

47P

C934

220

16 15 14 13 12 11 10

2SB1132

Q81

0.001

UNR9214J

0.1

L163

C948

C898

0.1

VCC

C598

0.1

Q82

R819

R836

100

ICU and Flash

CF20OPEN

CP1

*R883

TX232

10U

R483

C602

R485

SCL SDA

PWR

R831

100

R833

100

47K

R818

RX232

1

R490 10K

47P

C605

0.47

1.5K

MA2S111

D119

4.7K

MA2S111

D120

100

47K

R817

R835

100

J24

12 34 56 78 91 0

52465-1071

C944

47P

IC24 TA7808F

I O

C606

R511 R512

100

100R832

47K

R851

EP19

EP20

100 R489

R858

470K

1SS400

D165

R859

470K

1SS400

D167

0.01

R497 4.7K

C607

C622

0.001

G

Q83

2SA1588

4.7K

R498

470

R499

2SA1588

R500

470

R501

R509

R510

C917

XIN

0.1 C916

C915

47K

MMZ1005Y102CT

XOUT

10K

R865

TX_DATA

R506

100

R866

R504

Q84

NTCG10

39K

0.1

C943

10K

R_DATA

0.1

10

C614

0.1

0.47

R867

10K

1SS400

1SS

10K

D166

D168

C610

TEMP

0.1

100 101 102 103 104 105 106 107 108

400

ZBFS5105

L138

ZBFS5105

10

C611

C612

73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99

ICUTX

ZBFS5105

L141

L140

L139

ZBFS5105

C613

0.001

C629

100

D164

MA2S111

AVcc

P50/TxD2 P51/RxD2 P52/SCK2

PF0/BREQ/IRQ2

PF1/BACK/BUZZ

PF2/WAIT

PF3/LWR/ADTRG/IRQ3 PF4/HWR PF5/RD

PF6/AS

P1Vcc

PF7/FAI Vss TEST VCL*

OSC2 OSC1 NMI

MD2 XTAL Vss EXTAL Vcc MD0 MD1 STBY RES P20/TIOCA3 P21/TIOCB3 P22/TIOCC3 P23/TIOCD3 P24/TIOCA4 P25/TIOCB4 P26/TIOCA5 P27/TIOCB5

C616

0.1

R508

TXDT

ICURX

ICUSCK

MA2S111

R830

100

TXCK

22K

10K

C618

0.001

C626

L_DTCS_IN

R525

100

D121

R514

R515

L_WXALT

72

109

R517

LOAD

5

0.001

R_WXALT

R_DTCS_IN

68

Vref

P43/AN369P42/AN270P41/AN171P40/AN0

P17/TIOCB2/TCLKD

P16/TIOCA2/IRQ1

P15/TIOCB1/TCLKC

P14/TIOCA1/IRQ0

P13/TIOCD0/TCLKB

110

111

112

113

100 R516

RXDT

RXCK

AMBERES

2.2K

100K

R519

Q86 2SC4738

ZXCT1022

L_RSLV

R520100

67

AVss

P12/TIOCC0/TCLKA

114

115

AMBECLK

VOUT4VIN

GND

NC

IC55

MICUD

R_RSLV

DTMSTB

ID ET

P11/TIOCB0

P10/TIOCA0

Vss

116

117

118

AMBEEPR

AMBESTB

3 2 1

P2Vcc

P37/TxD4

119

GPSTXD0

GPSOPT

R518

61

P91/AN962P90/AN863P47/AN764P46/AN665P45/AN566P44/AN4

P36/RxD4

120

121

GPSRXD0

R521

R522

R523

100

P35/SCK1/SCK4/SCL0/IRQ5

122

R540

100

R_DATA

P34/RxD1/SDA0

330K

120K

12K

0.001

C630

C628

DTCS

DTMF

M IC_SEL

DA3_STB

54

55

56

57

Vss

P95/AN1358P94/AN1259P93/AN1160P92/AN10

P97/AN15/DA1

P96/AN14/DA0

IC25

HD64F2506FC26

P33/TxD1/SCL1

P32/SCK0/SDA1/IRQ4

P31/RxD0

P30/TxD0

P77/TxD3

123

124

125

126

127

128

R539

100

TX_DATA

RX232

ICUTX

ICURX

ICUSCK

TX232

C;7.88V

R529

1k

33 MSVB2

C619

0.039

0.1

C617

1

3

10K

R524

D122

MA8047

R850

180K

0.1

DA_STB

GPSBOOT

L_AFFILSEL

R_AF_MUTE

P76/RxD3

P75/TMO3/SCK3

P74/TMO2/MRES

P73/TMO1/CS7

129

130

131

132

R553

100

100 R825

AMBERXD

AMBETXD

DA_CK

DA_DATA

MMZ1005Y102CT

EP23

C621

C620

0.039

R527

4.7K

IC26

5

4

2

LMV321IDCK

P72/TMO0/CS6

100

470K

R871

100K

R872

R2

R1

D5VC

L_DA_SEL

R_AFFILSEL

L_DET_MUTE

R_DET_MUTE

46

PJ747PJ648PJ549PJ450PJ351PJ252PJ153PJ0

P71/TMRI23/TMCI23/CS5

P70/TMRI01/TMCI01/CS4

PG4/CS0

PG3/CS1

PG2/CS2

PG1/CS3/IRQ7

PG0/IRQ6

PE0/D0

133

134

135

136

137

138

139

140

R493

R554

100

DVC

DA2_STB

R_R5C

R400_S

R_RX800

100

33K

R532

68K

R538

R533

R530

22K

100 R812

PE1/D1

141

142

R838

R_AMC

R537

2SC4738 Q87

C623

0.1

4.7K

R_DA_SEL

38

PH739PH640PH541PH442PH343PH244PH145PH0

PE2/D2

PE3/D3

143

RPT_MUTE

27K

L_LO_SW

R_VVCO_SEL

R_UVCO_SEL

37

PA7/A23

PE4/D4

144

P_LR_SEL

SUB_SEL

C624

R541

R814 100

100

1

L_PLLSW

R552

PA6/A22 PA5/A21 PA4/A20 PA3/A19 PA2/A18 PA1/A17 PA0/A16 PB7/A15 PB6/A14 PB5/A13 PB4/A12 PB3/A11 PB2/A10

PD7/D15 PD6/D14 PD5/D13 PD4/D12 PD3/D11 PD2/D10

100 R839

DTMSD

P_MOD_MUTE

2.2 MSVA

22K

R545

15K

100

PB1/A9 PB0/A8 PC7/A7 PC6/A6 PC5/A5 PC4/A4 PC3/A3 PC2/A2 PC1/A1

P1Vcc

PC0/A0

PD1/D9 PD0/D8 PE7/D7 PE6/D6 PE5/D5

DTMCK

C625

R547

HV

C661

0.1

14 13 12 11 10 9

C651

1

C647

0.0033

R579

10

C653

0.0033

8V

15K

R623

100K

0.0056

15K

220K

R627

R784

R772

C860

3.9K

1

3

C678

DTMSD

DTMCK

DTMSTB

100K

470

0.068

R868

0.033

Q100

UNR9213J

15K

R773

C859

UMG9N

5

2

R799

220K

10

D142

MA742

1 2 3

SN74AHC1G08DCK3

C679

0.1

C680

0.1

R632

39K

C683

R637

15K

10

C687

5.6K

C857

2.7K R775

1

5

Q99

IC50

4

100K

UNR9210J Q98

AF_VOL_CK

AF_VOL_STB

AF_VOL_DATA

C673

10K

100K

DCEL

RXDT

EP39

EP30

EP38

11

12

13

AXN330C130P

20

19

18

EP29

EP57

EP56

AMBERES

AMBESTB

AMBECLK

C669

220K

R878

C666

RXCK

TXDT

EP42

EP40

10

9

22

21

EP59

EP58

AMBEEPR

M PZ1608S221A

470P

1 2 3 4 5 6 7

10K

R608

10

R609

C667

0.022

DVC

ACQ

TXCK

AMBETXD

EP41

EP25

EP43

EP66

5

6

7

8

26

25

24

23

EP63

EP61

EP62

EP60

C5V

DMOD

DAFOUT

IC35

I/ O1

CONT1

O/I1

CONT4

O/I2 I/ O2 CONT2 CONT3 VSS8I/ O3

CD4066BPWR

27K

AMBERXD

EP35

4

27

EP64

BTONE

VDD

I/ O4 O/I4 O/I3

R610

R611

3

28

C672

R593

680

R828

0

C658

4.7

R590

MRIPT

R591

1

0

C650

2.2M

R600

IC33 1 2 3 4 5 6 7 8

10

SM6451B

C659

0.022

C913

2.2M

RPT_MUTE

2.2M

GPSRXD0

GPSTXD0

2.2M

R614

Q95

UNR9213J

RSTN ADRS1 ADRS2 DVDD LOUT LIN AVDD VRL9VRR

4

5

0.001 IC59

123

47K

R864

MMZ1005Y102CT

EP26

EP27

R616

10K

16

MDT

15

MCK

14

MLEN

13

DVSS

12

ROUT

11

RIN

10

AVSS

R829

TC4S66F

GPSOPT

GPSRESET

GPSBOOT

EP34

EP36

EP33

14

15

16

17

MMZ1005Y102CT

D5VC

1200_9600SEL

R879

220K

0.001

10K

R612

R613

27K

CLONE_IN

CLONE_OUT

1

2

2SA1362 Q94

J6

29

30

OP+5V

M PZ1608S221A

R619

UNR9213J

0.01

0.1

C668

C670 2SB798 Q96

D141

C5V

MA2S111

100

C665

470P

C664

R617

470P

C675

TC7W53FU

GND

A

5

VEE

CH1

6

INH

CH0

7

COM

VCC

8

IC34

R615

2.2M

0.001

14

0.1 C677

13 12 11 10 9

R618

470

C674

Q11

Q97 2SC4738

3.3K

4 3 2 1

L_AF_MUTE

R_AF_MUTE

DTCS

DTCS_SEL

R624

100

47K

0.001

18K

R804

R628

8

0.001

C676

R620

10K

1M

R621

C861

C862

0.047

R774

LMV321IDCK

R797

R796

2.2M

R798

1

C873

R800

220K

C;4.87V

IC36

5

4

R630

330K

R625

47K

R631

330K

R626

47K

10K

C692

0.068

R643

R640

100P

220K

R766

470K

100P

C858

1

2

34

0.001

C919

SD

9

NC

10

ACK

11

NC

12

NC

13

EST

14

NC

15

VDD

16

R635

330K

R644

R771

1 2 3 4

C684 10 C685 10

BU8872FS

0.001

C688

0.47

R639

1k

C689

0.47

L_RSLV

1 2 3 4 5 6 7 8

220K

IC37

COM INH VEE GND

TC7W53FU

OSCI

OSC0

INPUT

IC56

C691

C694

0.47

R638

10K

100K

IC60

1

COM

2

INH

3

VEE

4

GND5A

C695

10

R645

R765

220K

IC48

LM2902PWR

VCC CH0 CH1

GND

NC

NC NC

NC

2SC4213

100K

R641

R642

TC7W53FU

39K

A

8 7 6 5 4 3 2 1

Q103

R647

Q101 2SC4213

R649

8.2K

Q102 2SC4213

0.001

C925

VCC CH0 CH1

CTCSS/DTCS

0.01

C698

C856

14 13 12 11 10 9

9600bps

8 7 6 5

1M

R820

X6

CR-838

0.1

R660

0.0039

390

R653

47

C700

8 7 6

C701

R664

100K

330K

R769

10

C722

C708

VAFO UAFO

C902

47P

C901

47P

IC38

11223344556677889

390

220

R658

47

C703

C706

C704

470P

L_LV

L_RSSI

10

C705

R770

220K

100K

22K

R764

R763

390P

C855

220K

R768

R762

10

C872

R779

220K

8

IC49

0.001 123

R777

220K

C903

0.1

R821

15K

C904

R822

3.9K

0.1

100

0.1

R659

R_RSLV

220K

R778

C863

C709

330K

R785

2.2K

LA4445

C707

470

R663

68K

390K

10

9101011111212

C710

4.7

IC61 1 2 3 4

mini RIP

567

4

220K

4.7

100

C714

470

C711

0.1

C712

4.7

R661

C716

R665 12K

C924

COM INH VEE GND5A

TC7W53FU

C866

1 2 3

R786

4

C697

D-star

R780

100K

R783

LMV358IPW

R782

1 2 3 4

220

R789

0.1

C719

47P

0.001 8

VCC

7

CH0

6

CH1

0.033

IC51

COM INH VEE GND5A

TC7W53FU

R767

220K

100K

1/2 VCC

C867

100K

IC58

COM INH VEE GND

TC7W53FU

IC57

COM INH VEE GND

TC7W53FU

C718

MPZ1608S221A

EP55

1k

EP53

M PZ1608S221A

EP51

VCC CH0 CH1

R781

10K

R787

R788

1

VCC CH0 CH1

A

0.01

C907

VCC CH0 CH1

MMZ1005Y102CT

8 7 6

C864

4.7

15K

10K

C865

4.7

8 7

C909

6 5

C908

0.001

8 7 6 5

A

R880

E

5VS

R2

R1

*D1 32

R_UVCO_SELR_UVCO_SEL

R_VVCO_SELR_VVCO_SEL

L_LO_SWL_LO_SW

R_DA_SELR_DA_SEL

R_AFFILSEL

R_DET_MUTE

L_DA_SEL

L_DET_MUTE

100

R558

R563

36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14

R486

13

Vss

0

100

12

R536

0.01

5

2

C627

R562

470K

IC28

TA75S558F

100

C635

0.001

4

98_DATA

MIC_PTT

11

10 9 8 7 6 5 4 3 2 1

18K

R560

R549

3

1

R556

R813

R559

C636

1

M IC_SENC

DCONT

P_PTT

P_SQL

P_LR_SEL

R561

Q88

UNR9213J

47K

R571

100

R564

R534

R566

8.2K

1 2 3 4

Q93

100

COM INH VEE GND5A

UNR9213J

*D1 33

*D1 34

*D1 35

*D1 24

*D1 25

*D1 26

*D1 27

100

R557

100

1200_9600SEL

100

1.2K

IC29

TC7W53FU

UNR9113J

Q92

VTX_C

VMMUTE

L_UNLOC

PLLDATA

R_UNLOCK

R_PLLSW

L_VCO_SHIFT

UTX_C

UMMUTE

L_WN_SEL

L_R5C

TCS_SEL

D

L_AMC

_PLLSTB

L R_PLLSTB ANALOGSW

DDETSEL

MODSEL

MOD_DA DADJSEL

DADJMUTE

DDETMUTE

MIC_SENC

P_SQL P_PTT

R_WN_SEL

DCONT

MM_MUTE

DA_SEL

DTMFSEL

DVDTMFSEL

C637

1

R550

8

VCC

7

CH0

6

CH1

*D136

*D137

*D138

*D139

*D128

*D129

*D130

*D131

K

PLLCK

AN

1

R801

8.2K

C645

0.1

5.6K

R581

MMZ1005Y102CT

EP70

MMZ1005Y102CT

P_MOD_MUTE

SUB_SEL

DTMF

R863

MM_MUTE

1 2 3 4 5 6 7

Q90

C646

C644

10

R574

R575

100K

EP24

R860

UNR9213J

R567

4.7K

47K

0.01

C638

IC30

I/O1

CONT1

O/I1

CONT4

O/I2 I/O2 CONT2 CONT3 VSS8I/ O3

CD4066BPWR

R570

100K

UNR9213J

0.1

R802

2.2K

10K

R577

0.1

C649

3 4

OUTPUT

5

DATAOUT

EP69

MMZ1005Y102CT

47K

R861

Q91

VDD

I/ O4 O/I4 O/I3

0.001

C641

INPUT GND

J4

DN-508B-6-L

C640

14 13 12 11 10 9

1.8K

47K

R569

R572

100K R573

100K

0.1

0.001

0.1

C648

R578

AN6123MS

R594

4.7K

C642

IC32

56

12

5V

ANALOGSW

AF_VOL_RES

100K

R592

1M

R862

C657

0.001

C654

100K

DET

VCC

10

C663

34

C;4.86V

8

VCC

7

CH0

6

CH1

5

A

2

1

C652

R598

AFOUT

R582

2.2M

TC7W53FU

1M

0.1

2.2M

IC31

1

I/O1

2

O/I1

3

O/I2

4

I/O2

5

CONT2

6

CONT3

7

VSS8I/O3

CD4066BPWR

C639

CPU DTMF

2.2M

R583

R585

IC52

COM

INH VEE

GND

R589

EP68

MMZ1005Y102CT

R588

8.2K

D140

VDD CONT1 CONT4

I/O4 O/I4 O/I3

22K

R586

22K

R587

R568

100K

C643

0.022

R584

0.1

C655

2.2M

1 2 3 4

C656

10 MSVA

DATAIN

DA221

B2B-ZR-SM4-TF

J7

1 2

EP54

P50

M PZ1608S221A

EP52

EP49

MPZ1608S221A

C918

DADJSEL

DADJMUTE

DDETMUTE

DDETSEL

VDET

390K

R882

UDET

0.01

C910

0.001

DVDTMFSEL

R827

390K

R823

R826

DTMFSEL

390K

R881

HV

8V

5V

5VS

L5V

34

1 2

M PZ1608S221A

HSJ1403-01-010

M PZ1608S221A

PJ-30

MOD_DA MODSEL

R_RSSI

R_LV

UTX_CUTX_C

VTX_C

DA3_STB DA2_STB DA_STB

DA_CK DA_DATA

L_LV R_LV

L_LO_SW

R_VVCO_SEL R_UVCO_SEL

L_VCO_SHIFT PLLDATA PLLCK L_PLLSTB R_PLLSTB L_PLLSW R_PLLSW L_UNLOCK R_UNLOCK

L_R5C R_R5C R_AMC L_AMC

R400_S

0.1

AMOD

R_RX800

L_WN_SEL L_DET_MUTE L_DA_SEL

C717

100P

AN

DA_SEL

L_AFFILSEL R_AFFILSEL

L_DTCS_IN L_WXALT

0.1

C911

R_WN_SEL R_DET_MUTE R_DA_SEL

R_WXALT R_DTCS_IN

0.1

C905

L_SQ L L_RSSI

R_SQL

0.1

C906

R_RSSI

VMMUTE UMMUTE

SP1

J9

J8

47S

DAFOUT

VDET

UDET

VAFO UAFO

*; Refer to “PARTS LIST.”

10 - 2

MAIN UNIT (2)

HV

8V

5V 5VS L5V

MOD_DA

MODSEL

R_LV L_LV

VTX_C

UTX_C

AMOD DA_STB DA_CK

DA_DATA

DA2_STB

DA3_STB

L_LV R_LV

L_LO_SW

R_VVCO_SEL

R_UVCO_SEL

VMMUTE UMMUTE

To VCO

C;4.9V

C366

R805

10 EEE-S

HV 8V

L5V

R339

10 MSVA

2

SC4738

Q58

3.3K

47P

C443

C439

L_REF_MOD

0.001

C896

L_VCO_MOD

R_VCO_MOD

R_REF_MOD

R_VVCO_SEL

R_UVCO_SEL

C453

1 MSVA

2.2

C877

1 MSVA

C394

C466

2

2.

R298

18K

C469

R368

18K

L_VCO_SHIFT

47P

R_UVCO_SEL R_VVCO_SEL

VMMUTE

LREFCON

L_2ndLo L_LO_SW

REF_MOD L_PLLSW

L_UNLOCK

R_REFMOD

RREFCON

R_2ndLo

R_UNLOCK

PLLDATA

R_PLLSTB

R_PLLSW

L_VCO8

L_R5C

L_LV

R_MOD

UMMUTE

5VS

R_R5

PLLCK

R_LV

R_2ndLo

GND

MOD

8V

L_R5C

VMMUTE

L_VCO_SHIFT

LREFCON

_PLLSW

L_LO_SW

L

UMMUTE

L_LV

L_UNLOCK

PLLCK PLLDATA L_PLLSTB

PLLCK

PLLDATA

L_PLLSTB

MAIN UNIT (4)

(PLL circuit for Left band)

VHFYGR L_RXLO GND L_VR5 L_UR5

R140_R5 R800_R5 R400_R5

R_Lo

5VS

UT8

UHFYGR

L5V

DAN222

D112

DAN222

D113

L_RXLO

L220_R5

L140_R5

L300_R5

L400_R5

R140_R5 R800_R5 R400_R5

5VS

MAIN UNIT (5)

(PLL circuit for Right band)

R_UNLOCK

PLLCK

PLLDATA

R_PLLSTB

R_PLLSW

R_LV

L_RXLO

MOD_DA

4

5

0.001 IC9

TC7S66FU

123

0.1

C912

C879

10 EEE-S

R_SQL

1

3

68K

R808

C875

10 EEE-S

10 11 12

LMV321IDCK

5

IC53

4

2

R807

220K

IC8

1

VIN1

2

VOUT1

3

VOUT2

4

VIN2

5

VDD

6

LD

7

CLK

8

DI

9

VIN3 VOUT3 VOUT4 VIN413VIN5

M62363FP

C876

10 EEE-S

VDAREF

R810

18K

100K

C874

22K

R806

VOUT8 VOUT7

RESET

VOUT6 VOUT5

LREFCON

C363

0.001

24

VIN8

23 22 21

VIN7

20

GND

19 18 17

DO

16

VIN6

15 14

L_SQL

MODSEL

C949

0.001

4

5

IC63

TC7S66FU

123

220K

R809

L5V

5V

VHFYGR

VTX_C UTX_C

UT8

UHFYGR

L_VCO_SHIFT

PLLDATA PLLCK L_PLLSTB

R_PLLSTB L_PLLSW R_PLLSW

L_UNLOCK R_UNLOCK

L_R5C R_R5C R_AMC L_AMC

R400_S

R_RX800

L_WN_SEL L_DET_MUTE L_DA_SEL

L_AFFILSEL R_AFFILSEL

L_DTCS_IN

L_WXALT

DAFOUT

VDET UDET

R_WN_SEL R_DET_MUTE

R_DA_SEL

VAFO UAFO

L_SQL L_RSSI

R_SQL R_RSSI

R_WXALT

R_DTCS_I

I

L_R5C

R_R5C

R_AMC

_AMC

L

C351

R_DET_MUTE R_AFFILSEL R_DA_SEL

0.001

C352

100K

0.0022

C;7.9V

C353

L_DA_SEL

VCC CH0 CH1

IC13

TC7W53FU

IC12

TC7W53FU

0.001

0.01

L_AFFILSEL

8 7 6

0.001

C389

8

VCC

7

CH0

6

CH1

8

VCC

7

CH0

6

CH1

C390

0.001

R296

10K

C386

L_DET_MUTE

C;4.9V

Q43

UNR911NJ

Q44

UNR911NJ

Q45

UNR9114J

Q46

UNR9114J

R256

6.8K

1.5M

R247

C355

0.0039

0.0018

R252

47K

R253

R246

1.2K

68K

R251

R257

6.8K

1.5M

R248 C356

C359

0.0039

0.0018

R254

47K

100K

R249

C354

C357

0.0022

C358

3

2

1

100K

R255

0.022

R258

C361

R259

68K

Q41

XP4601

C360

22K

R262

0.022

C362

22K

R261

0.015

R;3.7V

Q47

XP6501

4

5

6

4.7K R266

R267

10K

15K

4

5

6

C365

R265

10K

Q48

XP6501

4

5

6

4.7K R268

R269

100K

Q42

R263

XP460

3

2

1

R270

10K

1.2K

R264

3

2

1

R;1.2V

0.0018

0.001

3

2

1

10K

1

4

5

6

L_R5

R_R5

R_AM

L_AM

1.5M

R271

R;0.8V

R283

R277

C367

22K

39K

0.033

C375

C380

C369

0.015

0.01

0.001

330

R272

C364

0.01

R;1.9V

C370

R276

0.033

68K

100K

R279

C368

0.01

1.5M

R273

C371

0.033

C374

330

R274

R275

15K

R281

68K

C373

0.0018

Q50

UNR9213J

R278

R285

68K

C378

0.0068

R282

10K

C376

R280

R284

22K

39K

C381

C377

0.001

0.015

Q49

0.01

C372

C379

R286

0.033

68K

C382

R288

12K

R290

12K

0.01

UNR9213J

R294

0.0068

IC11

1

COM

2

INH

3

VEE

4

GND5A

TC7W53FU

0.001

C384

0

1

COM

2

INH

R293

3

VEE

4

GND5A

1

COM

2

INH

3

VEE

4

GND5A

C388

UDET

100K

R295

C383

0.001

L_WN_SEL

R305

10K

Q53

UNR9113J

Q54

UNR9210J

C400

L_R5

R_R5

0.1

15K

470

Q57 XP6501

C429

22P

R332

FILIN

AFOUT

C433

R335

8

FILOUT

QUAD

9

C432

82P

C436

10 MSVA

0.1

C437

R334

L_2ndLo

C428

0.1

4

567

VCC

DEC

IFIN

OSCOUT

MIXOUT

N-REC

GND

N-DET

RSSI

IFOUT

10111213141516

C435

0.033

R_AM

1K

R341

X2

JTB450C24

123

N

OSCI

MIXIN

R795

22K

330

R342

Q56 UNR9113J

0.01

C403

C894

0.01

R301

100

0.1

R303

R306

18K

1.5K

0.01

R307

82K

470P

C402

R302

R308

0

0.001 C404

15K

C407

22K

R884

470

MA2S111

R316

123

R310

470K

R311

NTCG10

R315

0

L_SQL

R_SQL R_RSSI

D82

MA2S111

D83

456

180K

R314

R;3.5V

R322

12K

C932

0.1

C933

0.1

12K

R323

R;4.4V(MODE:AM)

Q55 XP6501

C417

R319

0.001

R317

10K

4.7K

2.2K

C416

0.001

R329

0

C418

220P

C419

220P

FI1 LT450HW

I O

FI2

LT450EW

R321

12K

R330

D84

C930

0.1 MA2S111

D85

C931

0.1

MA2S111

12K

R331

1

C425

1K

R327

R328

C427

0.01

180K

456

C423

123

0.1

330K

C424

4.7 F93

0.1

C426

C422

R324

68K

10P

TA31136FNG

IC15

L_RSSI

M

L_A

C399

0.01

R345

C442

3.3K

R346

UNR9213J

3.3K

0.1

1

COM

2

INH

3

VEE

4

GND5A

Q59

IC16

TC7W53FU

L_R5

C445

0.001

R;4.4V(MODE:AM)

R351

100

Q63 XP6501

123

R352

1.5K R358

18K

470K

C450

R353

0.01

22K

R359

8

VCC

7

CH0

6

CH1

0.1

C455

R_WN_SEL

DA_STB

A_CK

D DA_DATA DA3_STB

VT;0V UT;4.6V R;4.7V

470P

0.001

C541

C537

L_R5

47

R379

47

R440

0.01

C518

0.001

C525

617DB

0.01

L122

0.01

C528

R_R5

47

R429

470

R430

0.001

C519

0.01

C523

R439

220

D100

470

100K

R431

R434

R438

10K

0.001

C462

470

R380

0.001

C467

Q66

2SC4406

0.001

C461

R374

1K

R376

456

180K

R366

180K

C463

0.1

C454

0.001

R372

82K

470P C459

R367

0

C458

4.7 F93

10K R388

NTCG10

R885

4.7K

R383

R375

470

C460

0.001

R381

1

C471

0.01

123

C468

C470

470

0.033

0.01 R399

C472

330

D88

10K

Q69

UNR9210J

22P

Q117

UNR9213J

Q70

2.2K

UNR9113J

C475

220P

C476

220P

R397

R811

3.3K

DA221

C483

UNR9113J

Q71

0.1

15K

R402

R400

68K

10P

R389

0

C884

0.1

100K

R384

R395

R398

470

R396

456

Q67

XP6501

C477

330K

R385

C889

C480

3P

0.001

C891

C486

0.001

2 4

R406

D93 M A2S111

R407

D94 M A2S111

C487

0.1

8

FILIN

FILOUT

TA31136FNG

AFOUT

QUAD

9

82P

C478

OUT GND

C927

0.1

C929

0.1

7

DEC

IFOUT

10

R;3.4V

6

IFIN

RSSI

11

C491

12K

5

12

FL-408

GND

56

4

VCC

N-REC

N-DET

13

IN

C495

0.1

14

FI5

FI3

LT450HW

I O

FI4

LT450EW

I O

2

OSCIN

OSCOUT3MIXOUT

GND

MIXIN

15

R416

C507

0

3P

330

12K

D95

12K

MA2S111

C514

0.001

12P

1.8U

L119

D96

C513

0.001

C517

Q75

2SC4406

C515

C510

0.1

C506

3 1

15P

C500

C497

0.1

C503

R422

R417

C926

0.1

MA2S111

R418

C928

0.1

15K

R414

1

IC18

1K

R419

R794

16

22K

JTB450C24 X3

R415

3.3K 10 MSVA

VT;4.7V UT;0V R;4.6V

DA221

0

0.01

C530

617DB

L126

R443

R444

220

1 2 3

2 4

3P

C531

IC19

G1 D1 D24S2

SPM5001

FL-409

OUT GND

C540

R447

220

G2 S1

GND

IN

5 6

FI6

18P

100K

C868

R453

0.01 R790

6 5

R452

3 1

C543

L127

100

R791

100

617DB

C869

0.01

R463

0.01

C564

47

R462

0.01

C559

0.01

C561

617DB

C548

C549

0.01

0

0.001

C552

0.01

3P

0

R464

220

1 2 3

L132

617DB

IC20

G1 D1 D24S2

SPM5001

0.01

C553

C550

L136

R467

220

6

G2

5

S1

R_Lo

L_R5

C555

0.1

C556

0.001

4.7K

R461

0.01

470P

0.001

C570

C569

R471

4.7K

0.1

C575

C576

100K

R469

0.01

C572

C574

L137

100

R793

R792

C870

C871

0.01

120K

R472

D116

MA2S111

VAGC

UAGC

VVIF

UUIF

5VS

R_R5

R400_S

5V

UAGC VAGC

L140_R5

R140_R5

L220_R5

0.001

L300_R5

L_R5 R_R5

617DB

R400_R5

L400_R5

R_RX80

0

0.01 R800_R5

10 - 3

MAIN UNIT (3)

R_RX400 R_RX140

L400_S

L_RX140

R_RX140

L_RX220

L_RX300

VD5C

UD5C

R_RX400

L_RX400

R400_S

R400

L400_R5

R_RX800

R800_R5

R874

10K

UAGC VAGC

UNR9114

UNR9114J

UNR91

_R5

UNR9114J

L5V

VHFYGR

UHFYGR

DA3_STB

DA_DATA

10K

R873

C2

5V

C1

C3

L140_R5

R140_R5

L220_R5

L300_R5

UT8

DA_STB

DA_CK

0.1

1

2

3

0.1

J

L_R5 R_R5

Q8

UNR9114J

14J

8V

HV

VTX_C UTX_C

0.001

VTX_C

UTX_C

R_BPF3 R_BPF4

PL_U TX_MUTE PCON_ PCON_V

UATTC

UUI

F

VVI

F

5VS

1

2

3

XP4601

Q1

XP4601

R3

0

MA2S728

MA2S728 D6

Q3

UNR9114J

Q4

Q5

Q6

Q7

Q9

Q10

Q11

UNR9114

6

5

4

Q2

4.7K

C6

C7

C5

U

0.1

6

5

4

470K

R4

D1

D2

L140_R5

0.001

L220_R5

L300_R5

0.001 R400_R5

0.001

DA_DATA

C4

R5

D3

D4

D5

R140_R5

L_R5 R_R5

L400_R5

R800_R5

J

J21

3008L-8P8C

5P

C341

L104

C350

L106

18.3N

100P

M A2S111

MA2S111

5P

AS080340

0

C346

C345

D79

D80

R244

4.7K

2SC4738

R243

47K

3008L-8P8C

C348

Q40

L109

12.1N

L108

7P

J20

R242

7P

R245

2

1

2

W5

R241

RL3

ATQ206SA

10K

1

W6

82K

ERDS2T0

82K

ERDS2T0

C154

0.001

UHFLPF

UUIF

VT8

AS080647

L46

C161

1P

C164

0.001

33P

C157

15P

C155

0.001

R128

R129

5VS

R_R5

VVIF

150

1.8K

L_R5

R140_R5

L220_R5

L300_R5

UD5 VD5

12P

C162

UT8

R138

0.001

C165

AS100340

L50

1P

C166

UNR9113J

R133

330K

C156

0.001

TX_MUTE

PCON_U

L140_R5

2.2K

R137

C169

8P

L51

D38

LQW18AN24NG00D

MA2S077

3P

C168

2.2K

R134

L52

C163

8P

LQW18AN68NG00D

L47

D35

0.22U

MA2S077

V220

MA2S077

D36

D37

MA2S077

39N

L53

C160

3P

2.2K

R135

33N

L48

0.001 C167

330

2.2K

R136

0.001

C159

22N

L49

C171

L56

AS080647

MA742

C186

0.001

D39

220

0

R140

1.8K

R141

1P

C173

C176

0.001

13P

C174

2.2 MSVA

R148

Q31

0.001

C937

L54

HVC350B

LQW18AN68NG00D

C181

39N

L55

D40

100P

C175

C179

R_BPF4

(174–260 MHz)

0.001

C170

22

R144

R139

33K

100P

C182

R147

C178

C183

0.001

D41

C184

L_BPF4

HVC350B

C185

100KR145

0.001

R_BPF3

330

27K

R154

C192

2.2 MSVA

MA742

D42

R152

100

R157

0.001 1K

C190

R853

PRF18

T;0V R;4.76V

C187

0.5P

33P

HVC350B

C188

100K

C195

R149

R155

0.001

C193

L_BPF3

0.5P

D43

33P

HVC350B

100KR153

100P

C191

0.001

C189

R;4.73V

C196

3.5P

R156

100

L_BPF4

0.001

C194

R;4.72V

(260–375 MHz)

15

R143

0.001

R150

R142

330

C197

L_BPF4

C;7.85V

Q12

UNR9213J

R8

1K

C8

0.001

VHFYGR

DA_CK

IC1

1

VSS

2

AO3

3

AO4

4

AO5

5

AO6

6

AO7

7

AO8

8

AO9

9

AO10

10

VDD11VCC

M62352GP

4.7K

R6

470K

R7

V220

VD5

UD5

R400_R5

L400_R5

UU1

VU2

VV

UV

VU1

UUIF

20

GND

19

AO2

18

AO1

17

DI

16

CLK

15

LD

14

DO

13

AO12

12

AO11

R_BPF1

0.001

C895

UU1

2.2K

R9

L1

0.001

C10

33N

077

MA2S

C13

2.5P

D7

VU2

R10

L2

0.001

C11

C14

2.5P

D8

MA2S077

R800_R5

R11

L3

100P

C12

VATTC

UATTC

MA2S077

C15

4P

D9

UUIF

C16

R_BPF2

L4

2.2K

33N

2.2K

0.1U

0.001

47K

0.001

15N

R15

R16

Q15

47K

R17

2SA1362

1K

R22

L9

47N

33P

C31

C43

C19

47K

0.001

R20

R12

Q13

1K

UNR9213J

C9

IC54

L_RX300

0.001

L_RX400

L_BPF3

C25

D10

470

C24

VD5C

UD5C

L_BPF4

T;0V R;4.73V

2.5P

1SV308

L7

4.7U

C23

0.001

LQW18AN6N8C00

4P

HVC375B

C26

1SV308

C27

100KR23

R_BPF4

1

VSS

2

AO3

3

AO4

4

AO5

5

AO6

6

AO7

7

AO8

8

AO9

AO12

9

AO10

AO11

10

VDD

M62352GP

HVC375B

C29

0.5P

D12

D14

C32

0.5P

15P

7P

C33

C37

R27

R_BPF3

0.001

C40

C28

T;0V R;4.05V

C36

0.3P

D13

2.5P HVC375B

C38

0.5P

7P

C34

100K

R24

D11

L_BPF4

0.001

C39

100

R26

R28

82K

L8

1P

0.001

C35

L_RX220

L_RX140

C883

L6

4.7U

C21

0.001

R18

470

15N

L5

R19

R14

15

GND

Q17

AO2 AO1

CLK

DO

VCC

D15

39P

DI

LD

0.001

C41

L_BPF3

2SC5231

L11

47N

2SA1362

L10

100K

15P

Q18

20 19 18 17 16 15 14 13 12 11

15N

R29

470

HVC375B

100K

C45

R30

0.001

C53

1P

L400_S

C47

L12

R31

R33

18

R46

56

R37

33P

C54

C59

0.001

C44

0.1

R47

15P

C60

15

39N

L19

330

R43

FANC

Q21

2SC4738

R44

10K

L_BPF2

L_BPF1

VATTC

R35

47

0.001

C58

8P

18N

L16

C46

4P

C48

C55

L13

4.7U

0.001 1SV308

47

R38

C49

8P

C50

15N

L15

4.7U

470

C51

0.001

C57

1P

L17

180K

9P

22

R45

R754

Q19

3SK324

120K

0.001

100

R41

C61

R48

D16

0.001

18N

L18

C62

4P

9P

22

R50

R755

C56

Q20

3SK324

100

C63

R49

D17

1SV308

0.001

R;3.59V

R40

39

12N

150

R51

R39

C65

0.001

R876

R875

0

R52

R53

180K

R55

R54

C64

3.5P

150

0.001

R59

39

150

R56

0.001

C68

C70

10P

330

R57

M PZ1608S221A EP1

C88

100K

Q123

2SB1132

D169

MA8075

1k

47K

R58

8P

220K

0.001

C66

47K

R61

220K

120K

R60

C72

LQW18AN6N8C00

L20

1.5P

C67

C73

C69

0.001

C79

C83

0.001 C89

L25

0.001

C81

18N

150

R66

2P

C84

150

R68

0.001

C86

L22

33N

4.7K

R63

R64

0.001

680

Q22

2SC5085

47

C87

3P

18N

MMZ1608Y102BT

C80

C946

0.001

C93

L26

EP71

C94

EP2 M PZ1608S2

(375–550 MHz)

0.001

C74

C71

1SV308

D20

12.0N

L23

3P

C77

L21

470

4.7U

R72

D18

C85

0.001

(375–550 MHz)

0.001

C75

0

8P

C78

L27

3P

C82

L24

4.7U

D19

1SV308

C90

C76

0.001

100

0.001 R67

R70

82K

2SC5624

R73

Q23

0.001

3P

7P

C91

C92

0.001

R75

R76

B2B-ZR-SM4-TF

0.001

C96

0.5P

HVC375B

0.5P

100K

R78

R_BPF2

0.001

12.0N

470

R74

C99

0.001

C95

3.5P

2.2M

4.7K

1K

R77

22

1 2

21A

C97

100K

HVC375B

C98

0.001

R80

R_BPF1

C100

0.3P

D21

C101

7P

D22

1SV308

R82

47N

HVC375B

R79

C103

0.5P

L_BPF2

4.7K

C104

34

100KR81

120

L28

Q25 2SC3357

J1

D23

C102

7P

0.001

L_BPF1

L30

L29

10N

2P

CHASSIS unit

470

R85

D24

HVC375B

100K

R83

C105 7P

0.001

C106

LQW18AN6N8C00

R95

C121

0.001

R8

9

27P

C109

68

12P

C110

22

R88

0.001

C111

R90

M A2S111

D25

R91

1 2

1.5P

C114

12.0N

L31

3P

C112

L32

4.7U

0.001

C107

D26

1SV308

C115

1.5P

12.0N

L33

3P

C113

D28

L34

4.7U

470

0.001

C108

D27

1SV308

R86

R96

MA2S111

D29

R97

22

R92

0.001

C122

L35

22N

4.7K 7P

C123

2P

C124

680

Q26

2SC3357

MF1 FAN

0.001 100

C848

R98

D30

1SV172F

1K

R94

0.001

C117

0.001

C120

C118

0.001

1SV172F

1K

0.001

C116

R93

0.001

C119

(810–1000 MHz)

Q16

8

2SC473

0.1

C17

Q14 2SC4738

C18

0.1

0.001

C30

C882

0.001

C129

22

R100

C134

0.001

C130

L37

39N

Q27

2

SC4703

0

R103

R101

41-002AA

UD5

33P

C131

R104

2P

C125

DAN222

2P

C133

Q28

3SK324

0.001

C127

0

41-002AA-R

J11

-R

J22 41-002AA-R

0

R102

2P

C126

Q29

3SK324

0.001

C128

C132

J10

D31

R107

L38

R108

R109

L39

R110

10 EEE-S

R105

15

10P

R106

18

220

PL_U

47

33N

100

2SC4738

47

33N

100

18P

C141

R111

220

MMZ1608Y102BT

0.001

MMZ1608Y102BT

C142

0.001

C135

R112

0.001

C136

220K

0.001

C137

R113

LQW18ANR

M A2S111

Q30

0.001

C138

0.001

C139

R114

220KR115

0.001

C140

LQW18ANR15G00D

R116

15

R117

C144

EP4

C143

0.001

VT;4.20V UT;0V R;4.18V

47K

R118

C146

L40

4.7K

D32

R856

100

47K

R119

C147

L41

C145

100

0.001

EP3

3P

R121

180K

0.001 C148

180K

C149

0.00

C150

R124

R122

IC2 S-AU82L

R120

15G00D

120K

4.7K

1K

L36

15N

VGG3VDD4OUT

1IN2

CTH30V222S15A

C846

0.001

R125

L42

0.1U

180K

R126

10K

VT;0V UT;4.45V R;4.41V

L43

0.1U

1

C151

0.001

0

L45

0.001

ATQ206SA

0

R857

J23

41-002AA-R

L44

IC

3

S-AV32

VGG3VDD4OUT

1IN2

C845

CTH30V222S15A

VV

33N

UV

C152

RL1

V220

VU1

LQW18AN56NG00

C153

VT;7.81V UT;0V R;0V

MA742

1P

0.001

C202

C212

1P

C198

10P

C203

4P

C214

22K

R166

C199

0.001

10K

R162

C209

0.047

220K

82K

R158

R163

150K

C216

0.1

0.001

C210

0.001

C938

D48

MA2S111

C206

0.001

D44

L59

100K

R161

100P

T;0V R;4.75V

C207

0.001

47

R165

R757

0

100K

0.1U

L57

R159

0.001

C208

(118–174 MHz)

39K

R164

R170

100P

C205

33N

L58

K

HVC350B

D45

0.001

C213

R168

C200

3P

R160

100P

C211

L60

100K

HVC375B

D46

0.001

D47

L61

AS080440

R167

M A2S111

47

R169

C215

0.1U R756

0

R174

100

R171

39K

18N

0.001

C217

C220

C221

150

C218

C222

2SC562

100

R188

22 CV

C225

0.001 1U

0.001

C240

L62

0.001

C227

MA742

D52

68K

MA2S0

R201

100

R197

0.001

C246

8V

10K

220K

R198

R194

1K

R193

39K

R196

PRF18

R852

0.001

C941

R204

D53

C251

0.001

10

77

C226

0.001

C230

4P

C224

15K R178

C231

0.001

R176

2.2K

0.001

0.01

C228

IC4

8

1 2 3 4

NJM34

C952

4P

D49

7 6 5

04AV

L164

LQW18ANR15G00D

C241

0.047

0.001

C238

0.1

C232

R877

0

3P

C953

(118–174 MHz)

0.001

C244

0.001 180K

R179

0

R190

R185

3SK318

Q33

0.001

C219

47K

R173

Q32

3SK318

R175

150

R172

0.001

R182

0.001

4

Q34

R183

100

C223

0.001

2SC56

Q35

C242

8P

0.001

120K

220K

R181

R189

LQW18AN82NG00D

C233

180K

R177

0

R184

C236

8P

0K

120K

22

C229

0.001

R180

39K

3PC234

R192

100K

2.2M

0.001

C237

L_BPF3

39K

R186

C239

3P

24

R191

100K

2.2M

R187

L_BPF3

C243

47K

L65

C235

L66

0.001

18N

L63

L64

LQW18AN82NG00D

HVC375B

C247

0.001

18N

HVC350B

C249

R195

2.2K

D50

100P

D51

100P

L67

HVC350B

100P

C252

R_BPF2

2.2K

L68

C253

3.5P

R199

C255

3.5P

18N

HVC350B

100P

C256

L_BPF2

C258

0.75P

D54

C262

100K

R200

C257

33N

33P

D55

R203

C259

0.001

22K

R202

C254

C260

0.5P

C261

33P

R_BPF1

C263

100K

0.001 L_BPF1

100K

R206

C264

D56

M A2S077

D57

M A2S077

VATT UATT

C265

0.001

R205

0.001

C266

0.001

33K

100KR208

C267

HVC350B

C268

0.001

15P

C270

2.2K

C942

HVC350B

C271

0.001

D58

100P

D59

L709CE

22 CV

C274

C275

470P

C272

C273

R209

UNR9113J

0.001

L69

12.1N

D60

100P

1P

12P

0.001

Q36

VT;0V UT;7.73V R;0V

R210

1U

PCON_V

D61

L71

L72

C284

UATT

D63

MA2S111

100

L70

0.001

L709CE

C283

8P

100P

C280

D62

L709CE

C278

C281

64N

39N

R215

1K

0.001

C279

C291

0.001

MA2S111

R211

TX_MUTE

L73

AS080440

5P

C294

1SV172F

L74

64N

C282

MA2S111

CV 22

R213

D65

C288

D66

330K

0.001

C289

R212

0.001

LQW18ANR15

D64

D67

1k

R219

LQW18

10

0.5P

MA2S077

4P

C293

D69

C286

D68

C285

8P

39N

L75

0.001

MA2S111

C301

AN56NG00

L78

C292

R216

0.001

MA2S077

C296

6P

L77

C297

100P

3P

120

0

R217

C295

0.001

D70

1K

0.001

C290

C287

G00D

L166

LQW18AN68NG00D

L79

1U

0.001

MA2S077

D71

22 CV

C298

L84

15N

10

L76

C305

R224

C303

4P

AS080440

1.5P C337

R222

1SV172F

10K

R225

R218

100

D72

1SV308

27P

1k

D73

MA2S077

C308

L80

L102

C339

LQW18AN6N8C00

6P

C309

Q37

3SK318

0.001

C306

120

R223

R226

0.001

C300

220P

L82

57.2N

L83

1U

C307

0.001

C313

6P

AS080440

1.5P

C340

R229

L85

R230

C299

120K

C312

5P

C314

.001

0

AS080747

L89

C310

18P

1.5P C343

L105

100P

C315

100

0.22U

100

C316

M A2S111

D76

Q38 2SC4738

47K

180K

R221

0

R22

LQW18AN82NG00D

C317

0.001

18P

D74

1SV308

L86

18.3N

AS080547

L88

18P

C318

C326

C320

27P

2P

C347

L107

LQW18AN6N8C00

VT;0V UT;3.90V

0.001

R;3.85V

680

47K

R234

R232

220K

R235

0.001

LQW18AN82NG00D

4.7K

R239

R227

47K

3P

C304

220K

R228

L81

L90

37.5N

18P

C319

6P

C328

2P

C323

AS080647

L92

36P

D75

C34

L110

0.001

C324

C325

L91

R231

0.001

C311

L93

45.5N

C327

12.1N

C329

L94

45.5N

L709CE

9

2P

6N

R237

3P

R238

680

100

36P

AS080547

C330

C331

220P

0.22U

C332

C333

L95

100P

L96

27P

C334

120K

L87

Q39 3SK318

R233

L98

37.5N

4P

12.1N

0

6P

0.001

27P

C338

AS100340

L101

C342

10

R240

0.001

6P

D77

MA2S077

D78

M A2S111

0.001

L165

LQW18ANR15G00D

LQW18AN68NG00D

L97

39N

L100

33P

C335

0.001

RL2

ATQ206SA

R236

C321

C322

L103

8.6N

6P

L99

AS08044

C336

C344

10 - 4

MAIN UNIT (4)

L_VCO8

C724

47P

LREFCON

C731

L_R5C

VMMUTE

L_VCO_SHIFT

C732

C727

47P

0.001

C723

47P

R679

270K

C735

MOD

47P

10K

C736

R678

C740

1

Q104 UNR911NJ

C737

C738

3P

0.001

1

C741

R680

0

15P

R681

L142

10

C742

4P

0.82U

1

2

X5

VCON

GND3OUT

CR-833

C744

L143

0.01

82P

C743

VCC

0.22U

Q105

2SC4738

L5V

10P

D145

R701

HVC321B

C765

1K

2.2M

R702

100K

0.001

Q110 UNR921NJ

C;7.88V

L147

68N

C767

C768

D147

0.001

1K

0.001

Q11 2

2SC5108

47K

R703

0.3P

HVC321B

R719

C781

M A2S077

C769

0.001

R721

R704

D148

C784

220

0.001

C770

4.7K

R705

0.001

1K

22K

10K

C839

MA2S077

D151

R725

0.001

L145

L146

R726

R728

68 0

T;7.08V

R;7.11V

C771

12P

C2012C

R709

R708

0

10K

C772

C773

R713

R716

22P

18P

0.001

C819

D157

L157

1SV308

56N

47

820

4.7K

0

C780

C777

1P

C785

39P

C779

R712

Q 111

2SC5231

R714

R720

C789

0.001

R717

39N

15P

0.001

C783

120

L148

C792

0.001

R723

R724

0.001

27P

10K

1.8K

L152

39N

C795

R727

L150

0.1U

Q113

2SC5231

C806

0.001

C804

1K

1P

R;3.51V

15P

C793

22P

C797

4.7K

C950

22P

R733

D153

MA2S077

C815

C803

0.001

3

2

1

IC44

GND

IN

UPC2709TB

OUT

GND

VCC

D155

EP48

MMZ1005Y102CT

L160

1U

4

5

6

0.001

C808

1SV308

C818

0.001

C811

R739

18P

R737

R;3.87V

2.2K

C820

0

C814

18P

VHFYGR

L5V

VHFYG

R

L_RXLO

L_VR5

L_UR5

1P

1K

R741

Q115

UNR9213J

8V

C;4.78V

2.2M

L144

0.47U

C763

100K

R707

C766

C774

10P

C775

HVC321B

D146

R699

0.001

4

C748

R683

10P

C747

R682

680K

C746

R684

MA2S111

C750

6P

C752

D143

22K

0.001

0.1

C749

10K

0.001

100

R696

1.2K

R841

Q119

2SK1069

0.001

IC42

C760

C761

5

123

0.1

0.001

10K

UNR9213J

R848

4

Q109

R698

UNR9213J

Q121

TC7S66FU

R697

1.2K

C762

2.2 MSVA

0.1

C764

MOD

0.1 SVA

R700

C751

0.001

10K

R870

0

R694

1.5K

33K

47K

C920

R843

C759

C838

R695

0.1 SVA

0.001

C921

R685

22

0.22

470P

FOUT

DATA

0.1

C755

16

B

15

P

14

13

NC

12

FC

11

LE

10

R840

1k

10K

L_LV

R686

R688

R690

R842

C951

C754

IC41

1

OSCIN

2

OSCOUT

3

VP

4

VCC

5

DO

6

GND

7

LD

8

470P

FIN9CLOCK

R869

0

B15A02PFV1

M

8V

47P

0.1

C753

PLLCK

PLLDATA

L_PLLSTB

C725

L_2ndLo

L_LO_SW

8V

REF_MOD

L_PLLSW

L_UNLOCK

L_LV

C726

C728

0.001

C729

C730

0.001

C733

0.001

C734

0.001

PLLCK

C739

R677

Q106 UNR911NJ

0.001

10K

L_LV

10 - 5

PLLDATA

L_PLLSTB

2969

MP 2

123

MA2S077

D152

R722

C798

MP 3

4

123

2601

MP 7

123

4

2775

MP 8

4

123

4

2969

MA2S077

D150

R706

27

C787

12P

2.2K

0.001

R710

C776

C791

8P

C790

L149

R711

27

33

0.001

18P

33N

R718

C794

C782

0.001

L151

10N

C796

6P

R;4.15V

1K

0.001

C786

C788

C799

C800

7P

0.001

6P

1

2

3

4

L153

IC43

VCC1

IN

GND5SW1

UPB1509GV

C807

7P

D154

MA2S077

2.2K

27N

R734

8

VCC2

C821

7

OUT

6

47P

SW2

0.001

C805

R738

R743

Q116

2SC5108

4.7K

33K

R744

0.22U

68

L158

R742

C822

47P

C823

2.2K

C809

0.01

L155

68N

27P

C837

C812

L156

0.001

68N

56P

2.2K

R745

D156

C816

MA2S077

C817

27P

0.001

MAIN UNIT (5)

8V

R_REFMOD

RREFCON

R_2ndLo

R_UNLOCK

PLLDATA R_PLLSTB

R_PLLSW

R_LV

R_R5

PLLCK

UMMUTE

C392

R287

270K

C;7.88V

R457

0.001

C844

10

IC62

3

GND4OU T

2

8P

15N

7P

0.001

C835

R428

R455

0

GND

1

IN

UPC2709TB

R436

0

L161

1U

4.7K

R747

C544

2P

L162

C841

C831

R750

4.7K

C582

5

GND

6

VCC

0

R460

0

EP47

C827

GND

VCC

100P

C557

5 6

C526

0.001

C529

L131

22N

0.001

C840

MMZ1005Y102CT

1SV308

D103

0.001

L123

39N

15P

R752

15N

R140_R5

C562

C527

7P

L129

C554

2P

UNR9213J

8P

4.7K

L134

22N

C534

C566

L124

C830

12N

L125

39N

27P

Q79

0.001

C532

18N

C558

1P

L130

1K

C567

7P

12N

C538

C539

R466

D108

MA2S077

0.001

L133

0.001

15P

R446

0

C560

2P

R400_R5

T;7.74V R;0V

R450

C563

5VS

R470

R445

0

L135

8.2N

6P

2.2K C547

D107

MA2S077

4.7K

0.001

UT8

C565

C568

C533

7P

0.001

6P

4.7K

MA2S077

0.001

L159

R465

D106

C573

C535

7P

18N

R140_R5

R800_R5

D109

MA2S111

R400_R5

R_Lo

UHFYGR

5VS

UT8

R426

R427

4

10K

1.8K

22K

5.6K

R432

L121

MP 9

123

2969

R423

L120

Q74

2SC5231

68

C516

39N

Q76

2SC5231

1K

0.15U

0.001

C521

3P

4

C524

C522

4P

C512

R449

4.7K

R441

C536

47P

0

D101

MA2S077

D159

R748

4.7K

D160

22P

MA2S077

R433

4.7K

47P

D102

MA2S077

4.7K

C833

0.001

R448

MA2S077

IC45

3

GND4OUT

2

GND

1

IN

UPC2709TB

D104

MP 4

C501

C496

0.001

47

270

2969

2601

2775

47P

0.001

MP 5

MP 6

T;6.98V R;7.01V

C504

C499

C498

D97

MA2S111

R412

Q73 2SC5231

C509

R413

1P

C511

123

0.001

R420

R421

0.001

0.5P

C444

0.001

470

R348

47N

FOUT

DATA

CLOCK

C441

R364

1.5K

L114

4P

Q60

2SC510

27K

R337

16

B

15

P

14 13

NC

12

FC

11

LE

10 9

10K

R333

PLLCK

47P

22N

3P

C430

3P

C431

8.2K

R363

D86

DA221

IC14

OSCI N OSCOUT VP VCC DO GND LD

FIN

MB15A02PFV1

C434

L113

R_UVCO_SEL

R_VVCO_SEL

C396

C393

10K

R360

Q64

UNR9213J

X1

1

VCON

2

GND

CR-783

C397

4P

56P

7P

0.01

C398

4

VCC

3

OUT

C401

L112

0.22U

R304

8

Q52

2SC473

R_MOD

R354

47K

C395

1

10K

R299

R292

0

0.001

C385

5VS

C387

3P

0.82U

L111

R_R5

0. 1

680K

C;4.86V

C405

C408

C406

R370

0.001

5P

C457

0. 1

100K

C410

R313

10P

10K

R309

R_UNLOCK

R312

22

1

0.

C411

0.001

C464

10K

R318

C413

0.001

22K

C414

MA2S111

0. 1

C415

R320

0

47P

470P

0.22

C420

1 2 3 4 5 6 7 8

D81

470P

C421

2.2M

R325

22K

8

R340

10K

R336

R349

C446

R350

R373

6

5

4

2SC4116

18K

PLLDATA

R845

C440

0.01

100P

10K

Q65

XP4601

R343

4.7K

2SA1586

R344

10K

R338

R_PLLSTB

10 MSVA

C448

8.2K

Q62

R847

33K

47K

R377

Q61

10K

C922

R356

1

2

3

330

1.2K

R347

0.001

C923

0.001

C490

47

R408

10K

C2012C

D91

HVC350B

R403

L118

C502

C484

3.5P

C488

10K

C489

0.001

C2012C

R405

T;6.60V R;6.65V

C508

R404

Q72 2SC5231

10P

820

R409

27P

C482

47P

10K

R411

8P

C492

10K

15P

C493

Q68

6

1

2

5

4

3

XP4601

R386

3.3K

1

C474

R849 10K

0.001

IC17

R369

R844

1k

5

123

4

330

C456

UNR9213J

Q122

TC7S66FU

R378

0

10 MSVA

C452

100

0.047

C447

100R362

0

R355

R365

1.2K

SVA

C451

0.1

10K

R846

Q120

2SK1069

0.001

R_PLLSW

L115

R390

0.18U

100K

D87

HVC321B

A

1.8K

0 .33 SV

C945

0.3P

R394

C473

HVC362

D90

R382

L116

0.18U

C481

39P

D89

L117

HVC362

2.2M

0.3P

C479

HVC375B

D92

10 - 6

SECTION 11 HM-133

• EXPLODED VIEW

MP3 (C)

MP2 (C)

• ELECTRICAL PARTS [MAIN-A UNIT]

REF ORDER NO. NO.

IC1 1140011491 S.IC uPD789071MC-041-5A4-E1-A B 51.1/24.5 IC3 1110006310 S.IC BD5245G-TR B 67.3/34.8 IC6 1130012030 S.IC BR24L02FV-WE2 B 39.4/30.1

Q1 1530001941 S.TR 2SC2712-BL (TE85L,F) B 26.1/11 Q2 1590000680 S.TR DTC114EUA T106 B 21.6/34.8 Q3 1590001330 S.TR DTA114EUA T106 B 24.7/34.8 Q4 1510000771 S.TR 2SA1586-GR (TE85R,F) B 54.7/34.9 Q5 1510000771 S.TR 2SA1586-GR (TE85R,F) B 54.5/37.5 Q6 1510000771 S.TR 2SA1586-GR (TE85R,F) B 48.5/5.8 Q7 1510000771 S.TR 2SA1586-GR (TE85R,F) B 48.5/3.3 Q8 1530001941 S.TR 2SC2712-BL (TE85L,F) B 19.5/9.9 Q9 1590001010 S.TR DTB113ZK T146 B 22.8/11

D1 1790000950 S.ZEN MA8056-M (TX) B 23.1/17 D3 1750000940 S.DIO ISS400 TE61 B 64.7/23.2 D4 1750000940 S.DIO ISS400 TE61 B 64.7/29.2 D5 1750000940 S.DIO ISS400 TE61 B 59.6/25.5 D6 1750000940 S.DIO ISS400 TE61 B 58.7/20.8 D7 1750000940 S.DIO ISS400 TE61 B 42.8/16.7 D9 1750000940 S.DIO ISS400 TE61 B 34.1/16.3 D10 1750000940 S.DIO ISS400 TE61 B 34.9/17.8 D11 1750000940 S.DIO ISS400 TE61 B 38.8/14.5 D12 1750000940 S.DIO ISS400 TE61 B 57.2/29 D16 1730002280 S.ZEN MA8091-M (TX) B 55.2/14.5 D17 1730002280 S.ZEN MA8091-M (TX) B 48.8/14.5 D18 1730002280 S.ZEN MA8091-M (TX) B 12.5/13.9

X1 6060000610 S.CER EFOS4914E3 B 42.6/22.3

L1 6200001520 S.COL MLF2012D R82K-T B 12/28.9 L2 6200001520 S.COL MLF2012D R82K-T B 10.7/13.9

R2 7030000400 S.RES MCR10EZHJ 1.5 k B 24.2/8.3 R3 7030000400 S.RES MCR10EZHJ 1.5 k B 41.9/8.3 R4 7030000400 S.RES MCR10EZHJ 1.5 k B 57.3/8.2 R5 7030003400 S.RES ERJ3GEYJ 471 V (470) B 28.6/11.2 R6 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 26.8/34.7 R7 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 23.3/36.8 R8 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 19.1/33.7 R9 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 57.6/35.6 R10 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 57.6/34.3 R11 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 57.6/36.9 R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 60.4/37.2 R13 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 45.7/5.5 R14 7030003420 S.RES ERJ3GEYJ 681 V (680) B 51.5/5.9 R14 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 51.5/5.9 R15 7030003400 S.RES ERJ3GEYJ 471 V (470) B 51.5/3.3 R15 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 51.5/3.3 R16 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 45.7/4.2 R18 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 41.6/33.6 R19 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 38.4/34.5 R22 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 37.9/18.7 R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 56.1/18.1 R24 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 58/18.6 R25 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 59.8/18.9 R27 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 68.1/32.5 R35 7030000400 S.RES MCR10EZHJ 1.5 k B 69.1/11.9 R36 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 20.5/30.6 R37 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 19.1/30.6 R38 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 17.5/7.7 R39 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 24.4/5.7 R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 24.4/3 R41 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 17/32.7 R42 7030003860 S.RES ERJ3GE JPW V B 68.4/21.6 R43 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 57.4/27.5 R44 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 57.3/22.1 R45 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 53.9/18 R46 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 37.8/15.8 R47 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 37.6/17.1 R48 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 45.3/17.6 R49 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 57.3/26.2 R50 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 58.1/23.4 R51 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 57.4/24.7

C1 4030006850 S.CER C1608 JB 1H 471K-T B 52/16.9 C2 4510008500 S.ELE EEE1CA101WP B 35.5/5.8 C5 4030007050 S.CER C1608 CH 1H 220J-T B 14.9/30.4 C9 4030007050 S.CER C1608 CH 1H 220J-T B 16.3/16.9 C10 4030007050 S.CER C1608 CH 1H 220J-T B 15.6/15.5 C11 4030007050 S.CER C1608 CH 1H 220J-T B 15.6/7.2 C12 4030006860 S.CER C1608 JB 1H 102K-T B 64.9/34.4 C13 4030006860 S.CER C1608 JB 1H 102K-T B 44.3/27.6 C14 4030006900 S.CER C1608 JB 1H 103K-T B 67.5/37.2 C15 4030006860 S.CER C1608 JB 1H 102K-T B 41.9/29.7 C16 4030006860 S.CER C1608 JB 1H 102K-T B 14.1/13.6 C17 4030006860 S.CER C1608 JB 1H 102K-T B 11.7/17.4 C18 4030006860 S.CER C1608 JB 1H 102K-T B 10.4/17.4 C19 4030006860 S.CER C1608 JB 1H 102K-T B 13/25.8 C21 4030006860 S.CER C1608 JB 1H 102K-T B 11.7/25.8

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C22 4030006860 S.CER C1608 JB 1H 102K-T B 10.4/28.5 C23 4030006860 S.CER C1608 JB 1H 102K-T B 23.1/14 C24 4030006860 S.CER C1608 JB 1H 102K-T B 67.2/12.1 C25 4030006860 S.CER C1608 JB 1H 102K-T B 25.6/32.2 C26 4030006860 S.CER C1608 JB 1H 102K-T B 53/4.6 C27 4030006860 S.CER C1608 JB 1H 102K-T B 60.9/35.9 C29 4510008540 S.ELE EEE1CA100SR B 26.4/16 C30 4030011600 S.CER C1608 JB 1E 104K-T B 23/3 C31 4510008540 S.ELE EEE1CA100SR B 28.3/4.9

J1 6510023110 CNR 3008L-8P8C <KIN>

DS1 5010000120 S.LED LN1371G-(TR) T 21.9/11 DS2 5010000120 S.LED LN1371G-(TR) T 21.9/32 DS3 5010000120 S.LED LN1371G-(TR) T 39.3/11 DS4 5010000120 S.LED LN1371G-(TR) T 39.3/32 DS5 5010000120 S.LED LN1371G-(TR) T 55.9/2.5 DS6 5010000120 S.LED LN1371G-(TR) T 56.2/26.8 DS7 5010000120 S.LED LN1371G-(TR) T 71.7/14.8 DS8 5010000120 S.LED LN1371G-(TR) T 72.2/33.8 DS10 5010000150 S.LED LT1EP53A T 51.6/5 DS10 5040003160 S.LED BRPY1211C-TR T 51.6/5 DS11 5010000150 S.LED LT1EP53A T 51.6/38 DS11 5040003160 S.LED BRPY1211C-TR T 51.6/38

MC1 7700002310 MIC EM-140

S1 2260000980 SW SKHHLP014A

EP1 6910012350 S.BEA MMZ1608Y 102BT B 10.4/25.8 EP2 6910012350 S.BEA MMZ1608Y 102BT B 14.3/17.4 EP3 6910012350 S.BEA MMZ1608Y 102BT B 13/17.4 EP4 6910012350 S.BEA MMZ1608Y 102BT B 14.5/11

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

M.

H/V

LOCATION

• MECHANICAL PARTS

[CHASSIS PARTS]

REF ORDER NO. N O.

DESCRIPTION

W1 8900011271 OPC-1153A 1

MP1 8210018830 2539 FRONT PANEL 1 MP2 8210018840 2539 REAR PANEL 1 MP3 8930057380 2539 PTT BUTTON 1 MP4 8930057390 2539 LED LENS 2 MP5 8930057570 2539 SW RUBBER 1 MP6 8930057520 2539 KEYBOARD 1 MP8 8810009371 Screw BT B0 3X12NI-ZK3 (BT) 2 MP9 8810009561 Screw BT B0 2X6 NI-ZK3 (BT) 3

QTY.

[MAIN-A UNIT]

REF ORDER NO. N O.

DESCRIPTION

J1 6510023110 3008L-8P8C 1

MC1 7700002310 EM-140 1

S1 2260000980 SKHHLP014A 1

QTY.

• DIMENTIONS

(2

61.0

(2

54.3

1

/8)

104.0

(4 3/32)

13

/32)

Unit: mm (inch)

(1

31.5

1

/4)

Unit abbreviations

(C): CHASSIS PARTS (M): MAIN-A UNIT

MP5 (C)

MP1 (C)

MP4 (C)

• VOLTAGE DIAGRAM

C:7.6

J1

M8V

1

MU/D

2

M8VSW

3

PTT

4

MICE

5

MIC

6

E

7

MDATA

8

C19

L2

C21

C22

EP1

MC1

F: [FUNC] is pushed D: DTMF is activated C: Common R: Receiving T: Transmitting

8

05

R

3D

BANDUP

S7

MR

S3S4S5

VFO

S2

94R

4 R

4D

7 D

ABCD

S9

3

S6

S13 S14

2

S17

1

S21

15

R

5D

F-2

PTT

F-1

1 S

MAIN-A UNIT

MP9 (C)

S1 (M)

MP6 (C)

MP8 (C)

MC1 (M)

J1 (M)

W1 (C)

Q1

R5

32

C

L1

EP2

EP3

EP4

C16

C18

C17

D18

71

D

7 4 R

01

D

S10

6

5

S18

4

S22

1C

64R

9D

S11

9

S15 S16

8

S19

7

S23

D16

R:6.8 T:6.8

C11

C10

C30

S12

0

S20

S24

2

92C

C

D1

C9

C5

R39R40

C31

MKEY-08 MKEY-07 MKEY-06 MKEY-05 MKEY-04 MKEY-03 MKEY-02 MKEY-01 MKEY-00

34R

4

54

4

R

11

D

DTMF

FUNC

21D 6 D

DN

S8

S25

S26

C:5.0

5 2

53R

4

3R

R:7.5 T:7.5

Q9

Q8

R38

F:1.9

R22

MKEY-I0

R23

MKEY-I1

R24

MKEY-I2

R25

MKEY-I3

42C

63R

DS10

R8

1 4 R

51R

41R

Q6

3 1R

F:1.9 D:1.9

G

R

0

R27

C:5.0

R37

Q7

61

R

24

R

C:3.8 C:3.8 C:3.8

5SD6SD

7SD8SD

C12

Q2

01R

11R 6 2C

T:1.9 P:1.9

92

82

0 3

21P

11P

09O

Z B/13P

01P 1 C I

1

3

2

Q4

Q5

21R

R

G

DS11

91

12

72

22

32

4

62

02

2

20P

30P

10P5200

5

50P

41P

40P

31P

1 P

P

2

09OT/0

0

P

8

TNI

I

TESER

T

/6

/72P

P

SSV8DDV

2X

PV

1

3

2

X

P

4

7

0

11

5

9

6

21

1

C13

HR30

X1

IC3

5

1

OUT

CD

2

VDD

4

3

VSS

NC

3SD

4SD

Q3

72C

9R

LED-S2 SEND LED-M2 LED-M1

71

81

61

70

6

0

2KCSA

2DX

P

T

0PTNI/42P

0

1PTNI/52P

2

0

1IS/22

2 S S/

3 2 P

P

51

31

41

R18

R19

5 1 C

41C

C

2R

1SD2SD

C:3.8

R6R7

)1M-DEL(R-EDOM

)2MD

E L(G-ED

O M

6

7

5

8

A

P

CCV

L C

W

D S

S

6C

1A32

0

S

A

V

I

2

1

4

11 - 1

SECTION 12 UT-123 (Optional product)

• VOLTAGE DIAGRAM

63C

86

7

3C

RXDT

R390

RXCK

R391

R392

R393

AMBERXD

11G21A31Y42G52A62Y7

GND

IC354

3A

VCC

83Y9

103G114Y124A134G14

DXT_BMA

TXCK

ACQ

DVC

DCEL

CPU5V

D_TXDT

8

9

23242526272829

22

TOOBSPG

0DX

IC359

0DXRSPG

783R

D_RXCK

D_RXDT

1011121314

192021

AMB_EPR

AMB_STB

AMB_RES

AMB_CLK

V5

873C

Q222

GPSRESET

TSPG

4Y5

VCC

GND

NC

2A3

1

GPSRESET

13PIN OPT1

15

16

17

18

GPSRXD0

663C

R

583

R386

GPSBOOT

GPSTXD0

0DXRG

D_TXCK

AMB_TXD

AMB_RXD

1

23456

7

J1

30

AGND

DMOD

C5V

BTONE

AMODIN

DAFOUT

C304

D102

0DXTG

56

3R

46

3C

1 2 3 4

1

2

43

13

14

15

AD1

EPORT9

EPORT12

VDD_BACKUP

TX018RX0

EPORT11/RX1

EPORT10/TX1

17

16

R362

R363

103CI

473C

673C

773C

573

9

10

11

12

GND

XRESET

BOOT2/EXROMI

GND

GND23GND

ADREFT

19

20

21

22

J2

8 7 6

5

R307

C212

5

C303

CE

C

Q219

8

AD0

493R

3

4NC5

24RF25

R305

6

EPORT67EPORT3

GND26GND

363C

1

VDD2GND

VOUT

Q221

5

GND

EPORT8

R306

R396

IC361

EP355

Q218

1

2

3

EPORT4

EPORT54EPORT7

BOOT1/EPORT2

VDD

1PPS

EPORT1

27

28

29

30

Q201

C214

ACQ

Q223

C211

Q200

TDXT_D

753R

763R

IC353

273C

DCEL

C208

C210

173

R217

C

C213

R212

4

3

C206

DOC214DOC1

VSS

GND

4Y5

AMB_EPR

EP353

RX

C:3.3V

EP203

5

IC203

2

1

R211

R210

C207

13

15BT16

TXO17TXE18TXP19TXD20RXD21RXC22TXC23S/N24VDD

RXFB

VBIAS

PLLACQ

RX_PSAVE

RX_SIG_IN

8

9

10

11

12

C209

R209

R208

AMBEEPR

1NC2A3

VCC

383R

073C

163C

26

TXDT

SIGN201

7

IC357

3C

RXDT

CLKDIVB5RX_HOLD6RXDCACQ

RXCK

4

553

R

1

3

CE

VDD2GND

VOUT

4NC5

C102

C103

C104

TXCK

XTAL

CLKDIVA

XTAL/CLK_RX

1

2

3

R203

R204

R205

R206

IC352

RX

C:3.2V

0

IC202

01 99 8 79 69 59 49 3 29 1 09 9 8 78 6 5 48 3 28 18 08 9 87 77 67

C205

9

8 8

8

7

CP201

CP202

CP203

RX

C:4.8V

CN CN C

N

C

N CN CN CN CN

N

C CN DDV D

G

N DNG DDV

NE_D

1LES_CE 0ELS_C N

E_PEELS

NE_PI

1LES_DUAB 0LES_DUAB

NE_TFOS

CN

1L

DDV

EP202

R207

AV

L

_

ES

NNAHC

CP2

R202

DVC

C51

C52

C53

1

2

NC3NC4NC5NC

GND

D

OC

EDOC

S

0

CHANN_SEL

RATE_SEL4

75

74

R100

RXp-p

3.3V

C204

5Q6

CLR7PRE8VCC

GND

C202

R216

GND

12 - 1

AMBERES

873R

AMB_RES

C50

R50

1

2

5

34

C101

6NC7NC8

VDD9GND10GND

3

L0

L1

L2

RATE_SE

RATE_SEL

RATE_SE

X2/CLKIN

RESETN

X1

2

70

69

68

73

71

7

67

AMBERES

EP201

C201

IC201

CLK

1

2D3Q4

R215

Q202

C216

C200

2

3

OUT

X200

VCC

1

4

C203

C302

R373

FM:0V

EP200

Q51

Q50

C54

NC

6 6

1 1

12

D VD

VDD

GND

VDD

64

65

C110

R213

R214

RX

DV:1.4V

13

63

R104

C360

R303

NC

GND

14NC15NC16NC1

IC101

NC

62

61

D100

AGND

TXDTAMB_STB

AMBESTB

GND

3A

IC360

83Y9

D_TXDT

AMB_TXD

RX

FM:0V

DV:3.3V

R2

C100

7

23

24

25

18NC19

20

21

C

D

N

NC

NC22NC

EPR

GND

VD

ENCODER_EN

KLC_XR_CEDOC

KLC

BRTS_X

ATAD_XR_CEDOC

ATA K

LC

KLC_XT_NAHC

RT

B

S_X

BRTS_XT_N

T

A

AD_X

A

TA

C N

NC

0 6

59

C357

C356

11

DGND12DVDD

AVDD210AGND2

C354

NC

58

C109

RESET

9

C352

R304

VDD

GND

57

56

AMBERES

SCLKSCLK

13

14

SCLK15MCLK

REFOUT8REFCAP

7

C353

R353

55

EP352

VDD

NC

54

R105

SO

16

SDO

SDOFS18SDIFS

VINP6VINN

5

GND

53

SENSEN

17

AVDD14AGND1

R352

GND

52

51

CP1

SI

19

SDI

3

1 2 3 4

CLOCK_MODE

20

SE

VOUTP2VOUTN

1

AMBETXD

103G114Y124A134G14

AMB_CLK

R_N

_X

_

R

C _NAHC

R

D_XR_NAHC _

XT_CE

T

C

_

T_C

D_XT_

C358

R354

IC350

R351

IC300

963C

11G21A31Y42G52A62Y7

VCC

AMBE2020

VIH=Vdd+0.3V

RX

C:4.5V

C1

3

CE

4NC5

C2

C3

DNG

AHC

ED

OC

D

OC

DNG DDV

E

C

DO

AHC

D

DV

DNG

C

EDO

HC

NA

CN DV

D DDV D

D

V

DDV

V

DD DDV DNG

EP351

EP350

R350

8 7 6 5

R302

AMBECLK

1

VDD2GND

VOUT

C116

• PARTS LIST

[MAIN UNIT]

REF ORDER NO. NO.

IC1 1180002371 S.REG R1111N321B-TR-F T 13/6.8 IC101 1130010920 S.IC AMBE-2020 B 9.8/9.5 IC102 1130011930 S.IC SN74LVC1G04DCKR T 4.7/5.1 IC201 1130013440 S.IC SN74LVC2G74DCTR T 30.3/12.3 IC202 1110005430 S.IC CMX589AD5 B 37/7.5 IC203 1130007021 S.IC TC7S66FU (TE85L,F) T 39.6/5.2 IC300 1110005290 S.IC NJM2115V-TE1-#ZZZB T 28.6/6.3 IC301 1130006921 S.IC TA75W01FU (TE12L,F) T 35.7/9.1 IC350 1130011631 S.IC AD73311ARSZ B 24.3/6.4 IC352 1180002371 S.REG R1111N321B-TR-F B 12.9/26.7 IC353 1190002470 S.IC ITRAX130 <MRF> B 52.2/36.7 IC354 1130013640 S.IC TC74VHCT125AFK (E,K) T 2.5/27.2 IC357 1130013570 S.IC SN74LVC1G07DCK T 18.4/22.7 IC359 1130013570 S.IC SN74LVC1G07DCK T 18.9/18.2 IC360 1130013650 S.IC TC74VHC125FK (EL,K) T 17.8/28.8 IC361 1180002371 S.REG R1111N321B-TR-F T 23.8/20.7

Q1 1510000581 S.TR 2SA1362-GR (TE85R,F) T 12/15.7 Q2 1590003390 S.TR UNR9215J-(TX) T 8.4/13.2

Q224

Q1

R1

IC1

EP1

62 72 82 92 03 13

3

2 33 4

3 53 63 7

3 83 9

3 04 14 24 34 44 54 64 74

4

8 94

5

0

C108

4Y5

GND

2

GND3OUT

GND

1

DNGA

C351

C350

R3

Q2

RPEEBMA KLCEBMA

RX

FM:0V

DV:3.2V

BTSEBMA

OS

DXTEBMA

KLCS

NES

IS

C106

DXREBMA

C107

C113

R109

C310

DV:4.7V

FM:0.5V

RX

FM:0V

DV:0.4V

Q100

R108

C117

R106

R310

RX

C112

R107

FM:0V

RX

DV:1.3V

VCC

IC102

1NC2A3

111C

C

X100

VC

4

C114

EP100

C300

EP300

R300

R301

C301

Q50 1510000581 S.TR 2SA1362-GR (TE85R,F) B 3.3/30.7 Q51 1590001170 S.TR XP1501-(TX) .AB B 7.8/30.1 Q100 1530002280 S.TR 2SC4081 T106 S T 2.2/7.3 Q200 1590003390 S.TR UNR9215J-(TX) T 39/11.8 Q201 1590003390 S.TR UNR9215J-(TX) T 35.5/3.9 Q202 1530002280 S.TR 2SC4081 T106 S T 26.2/12.8 Q218 1520000561 S.TR 2SB1123 T-TD-E B 8.6/22.5 Q219 1590001170 S.TR XP1501-(TX) .AB B 8.1/26.4 Q221 1590003390 S.TR UNR9215J-(TX) T 6/14.4 Q222 1590003390 S.TR UNR9215J-(TX) T 5.9/17.4 Q223 1590003390 S.TR UNR9215J-(TX) T 40.9/10.8 Q224 1590003250 S.TR UNR9115J-(TX) B 5.2/24.5

D100 1790001240 S.DIO MA2S728-(TX) T 8.1/2.1 D102 1790001240 S.DIO MA2S728-(TX) T 27.9/20.1

X100 6050012290 S.XTL CR-820 (16.384 MHz) T 7.9/8.4 X200 6050012300 S.XTL CR-821 (9.8304 MHz) T 21.5/11.8

R1 7030000180 S.RES MCR10EZHJ 22 (220) T 10.3/12.5 R2 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 10/5.3 R3 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 9.9/15.7 R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 7.3/28.3 R100 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 6.3/2.2 R104 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 7/4.1 R105 7030007280 S.RES ERJ2GEJ 331 X (330 ) T 17.1/6.5 R106 7030004980 S.RES ERJ2GEJ 101 X (100 ) T 2.6/3.5 R107 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 2.6/5.1 R108 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 4/7.7 R109 7030004990 S.RES ERJ2GEJ 221 X (220 ) T 1.7/10.3 R202 7030010040 S.RES ERJ2GEJ-JPW T 32.8/13.6 R203 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 34.7/12.8 R204 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 35.6/13 R205 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 36.5/13.3 R206 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 37.4/13.8 R207 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 39.3/13.3 R208 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 41.1/13.9 R209 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 39.9/13.6 R210 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 31.5/4.1 R211 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 38.7/3.3 R212 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 40.1/7.6 R213 7030004980 S.RES ERJ2GEJ 101 X (100 ) T 28.1/12.7 R214 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 27.8/11.1 R215 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 26.3/14.6 R216 7030004990 S.RES ERJ2GEJ 221 X (220 ) T 25.6/10.8 R217 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 39.3/14.2 R300 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 22.4/5.9 R301 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 23.9/6.4 R302 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 23.9/7.6 R303 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 29.5/2.9 R304 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 30.3/3.8 R305 7310004610 S.TRI EVM-2WSX80 B15 (104) B 31.3/6.7 R306 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 35.7/5.8 R307 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 33.6/6.4 R310 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 22.9/3 R350 7030005010 S.RES ERJ2GEJ 681 X (680 ) T 25.3/8.8 R351 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 27.5/8.8 R352 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 27.9/3.8 R353 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 29.4/5.8 R354 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 20.6/11.1 R355 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 15.5/26.3 R357 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 7.5/15.4 R362 7030007280 S.RES ERJ2GEJ 331 X (330 ) T 20.2/20.4 R363 7030007280 S.RES ERJ2GEJ 331 X (330 ) T 21.5/18.1 R365 7030005000 S.RES ERJ2GEJ 471 X (470 ) B 10.4/27.3 R367 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 7.5/17 R373 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 16.1/24.1 R378 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 19/24.9 R383 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 17.5/24.8 R385 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 17.1/18.3 R386 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 16.1/20.8 R387 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 18/20.1 R390 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 4.1/30.6 R391 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 4.4/23.8 R392 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 1.6/22.4 R393 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 3/32 R394 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 22.9/23.7 R396 7030004980 S.RES ERJ2GEJ 101 X (100 ) T 24.6/22.8

C1 4550007680 S.TAN TEESVP 0J 226M8R T 11.9/9.7 C2 4550007600 S.TAN F920J106MPABMA T 12.7/11.4 C3 4030016930 S.CER ECJ0EB1A104K T 13.4/12.8 C50 4030017460 S.CER ECJ0EB1E102K B 13.1/29

DESCRIPTION

M.

H/V

LOCATION

[MAIN UNIT]

REF ORDER NO. NO.

C51 4030017460 S.CER ECJ0EB1E102K B 4.2/26.4 C52 4550006930 S.TAN TEESVP 0J 225M8R B 1.8/27.8 C53 4030017460 S.CER ECJ0EB1E102K B 3.2/28.3 C54 4030017460 S.CER ECJ0EB1E102K B 4.3/27.6 C100 4030016930 S.CER ECJ0EB1A104K B 14.8/19.2 C101 4030016930 S.CER ECJ0EB1A104K B 5.9/19 C102 4030016930 S.CER ECJ0EB1A104K T 5/8.8 C103 4030016930 S.CER ECJ0EB1A104K T 4/11.8 C104 4030016930 S.CER ECJ0EB1A104K T 3.4/2.2 C106 4030016930 S.CER ECJ0EB1A104K T 16.7/10.2 C107 4030016930 S.CER ECJ0EB1A104K T 17.6/10.2 C108 4030016930 S.CER ECJ0EB1A104K T 16.8/5 C109 4030016930 S.CER ECJ0EB1A104K T 12.1/2.8 C110 4030017420 S.CER ECJ0EC1H470J T 10.1/2 C111 4030017460 S.CER ECJ0EB1E102K T 5.6/10 C112 4030016930 S.CER ECJ0EB1A104K T 1.7/5.1 C113 4030016930 S.CER ECJ0EB1A104K T 1.7/9.4 C114 4030016930 S.CER ECJ0EB1A104K T 8.5/5.8 C116 4030016930 S.CER ECJ0EB1A104K T 5.1/2.7 C117 4030017460 S.CER ECJ0EB1E102K T 2.9/9.6 C200 4030017460 S.CER ECJ0EB1E102K T 22/14.1 C201 4030016930 S.CER ECJ0EB1A104K T 26.5/10.8 C202 4030016930 S.CER ECJ0EB1A104K T 24.7/10.8 C203 4030016930 S.CER ECJ0EB1A104K T 18.5/13.8 C204 4030017460 S.CER ECJ0EB1E102K T 32.5/12.4 C205 4030016930 S.CER ECJ0EB1A104K B 38.2/1.5 C206 4030017030 S.CER ECJ0EB1A273K B 39.1/1.5 C207 4030017030 S.CER ECJ0EB1A273K B 40/1.5 C208 4030016930 S.CER ECJ0EB1A104K B 33.1/2.1 C209 4030017400 S.CER ECJ0EC1H220J B 40.1/12.7 C210 4030018860 S.CER ECJ0EB0J105K B 38.7/12.8 C211 4030017460 S.CER ECJ0EB1E102K T 40.5/14.6 C212 4030017760 S.CER ECJ0EB1H222K B 31.1/2.9 C213 4030016930 S.CER ECJ0EB1A104K T 39.5/8.5 C214 4030017460 S.CER ECJ0EB1E102K T 33.9/3.9 C216 4030017460 S.CER ECJ0EB1E102K T 24.7/14.6 C300 4030016930 S.CER ECJ0EB1A104K T 25.2/4.4 C301 4030018860 S.CER ECJ0EB0J105K T 22.4/4.3 C302 4030016930 S.CER ECJ0EB1A104K T 27.9/2.9 C303 4030016930 S.CER ECJ0EB1A104K T 38.2/9.8 C304 4030017490 S.CER C1608 JB 1A 105K-T T 32.7/9.6 C310 4550007730 S.TAN TEESVJ 0J 106M8R T 24.9/2.1 C350 4030016930 S.CER ECJ0EB1A104K T 23.5/8.8 C351 4030016970 S.CER ECJ0EB1C223K T 24.4/8.8 C352 4030016950 S.CER ECJ0EB1A473K B 29.4/7.4 C353 4030016930 S.CER ECJ0EB1A104K B 30.2/3.1 C354 4030016930 S.CER ECJ0EB1A104K B 29.3/3.1 C355 4030017420 S.CER ECJ0EC1H470J T 18.2/8.8 C356 4550006930 S.TAN TEESVP 0J 225M8R B 23.9/11.1 C357 4030016930 S.CER ECJ0EB1A104K B 22/12.8 C358 4030016930 S.CER ECJ0EB1A104K B 20.6/12 C360 4030017460 S.CER ECJ0EB1E102K B 27.8/2.2 C361 4550007090 S.TAN TEESVA 1A 226M8R B 15.8/29.3 C362 4550007600 S.TAN F920J106MPABMA B 10.1/30.3 C363 4030016790 S.CER ECJ0EB1C103K B 59.8/46.7 C364 4030016790 S.CER ECJ0EB1C103K B 10.4/25.6 C366 4030016790 S.CER ECJ0EB1C103K T 20.5/23.7 C367 4030016790 S.CER ECJ0EB1C103K T 1.3/32.1 C368 4030016790 S.CER ECJ0EB1C103K T 17.4/21 C369 4030016790 S.CER ECJ0EB1C103K T 20.6/27.4 C370 4030016790 S.CER ECJ0EB1C103K B 13.7/30 C371 4550006930 S.TAN TEESVP 0J 225M8R B 56.9/16.2 C372 4030016790 S.CER ECJ0EB1C103K T 18.8/14.8 C374 4550007600 S.TAN F920J106MPABMA T 27.1/22.8 C375 4550007600 S.TAN F920J106MPABMA T 26.4/20.3 C376 4030016790 S.CER ECJ0EB1C103K T 24.8/24 C377 4030016790 S.CER ECJ0EB1C103K T 24.5/18.5 C378 4030017460 S.CER ECJ0EB1E102K T 29.7/17.3

J1 6510018440 S.CNR AXN430C330P T 10.5/25.7 J1 6510025790 S.CNR AXN430C030S T 10.5/25.7

EP1 6910018460 S.BEA MMZ1005Y102C-T T 14.6/9.7 EP100 6910018460 S.BEA MMZ1005Y102C-T T 8.5/4.9 EP200 6910018460 S.BEA MMZ1005Y102C-T T 20.1/13.8 EP201 6910018460 S.BEA MMZ1005Y102C-T T 27.9/14.6 EP202 6910018460 S.BEA MMZ1005Y102C-T T 37.1/4.4 EP203 6910018460 S.BEA MMZ1005Y102C-T T 38.5/7.6 EP300 6910018460 S.BEA MMZ1005Y102C-T T 24.1/3.4 EP350 6910018460 S.BEA MMZ1005Y102C-T T 28.9/1.9 EP351 6910018460 S.BEA MMZ1005Y102C-T B 21.8/11.6 EP352 6910018460 S.BEA MMZ1005Y102C-T T 17.1/7.7 EP353 6910014690 S.BEA MPZ1608S221A-T T 20.9/15.5 EP355 6910014690 S.BEA MPZ1608S221A-T B 12.5/23

DESCRIPTION

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

M.

H/V

LOCATION

• BOARD LAYOUTS

• MAIN UNIT (TOP VIEW)

• MAIN UNIT (BOTTOM VIEW)

H 06

H 5 5

H 05

H 4

702

R

20 2

R

C200

0 0 2PE

302C

2Q

Q221

3C

00 2Q

C204

10 2CI

R213

Q202

0 02X

R1

301C

322Q

2

3

1 2R

02

312C

CI

5 01R

IC1

6 03R

R307

IC300

R301

R300

411C

C108

R2

001PE

C112

1 1 2R

EP202

Q201

C214

403R

253

R

003C

C301

401R

IC102

R106 R107

302PE

C303

1 0 3CI

C304

4 12

153R

R

C201

R216

R350

C202

C351

203R

C350

553

C

C107

EP352

C106

1 PE

2C

1 C

X100

C111

2 0 1C

R108

C117

0 01Q

9

311C

01R

C211

712

R

B9466B

D102

473C

C375

C376

6 9 3

1

R

63CI

49 3

R

C369

063 CI

C366

IC357

8 6 3C

R362

783R

R386

8 73

R

R383

R373

KCM

C378

1 02PE

512

R

95 3CI

R385

R363

6 12

C

EP353

273C

7 7 3C

Q1

J1

R367

R3

R357

Q222

R390

39 3R

C367

19 3

R

45 3

CI

R392

303R

203C

EP300

0 1 3R

C109

C116

0 13C

01 1C

001 D

053PE

R100

C104

H5 4 0

DT

H 3

KC

5

H 3

DNG

0

H 2 5

H 2 0

H 1 5

H 1 0

H 5

1 P C

H 0

V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50 V55 V60

0 6H

C 3 7 1

5 H

I C 3 5 3

5 H5

5 4 H0

C207

C206

C205

DT

C K

C208

C212

G

C353

N D

C354

C360

I C 2 0 2

R 3

012R

0 5

R353

C352

IC350

I

01H51H02H52H03H53H04H

C 1 0 1

5H

C P 1

0H

V0V5V10V15V20V25V30V35V40V45V50V55V60

R208

902C

902R

C210

R206

R205

R204

R203

3C 5 6

EP351

753C

3C 5

453R

8

IC352

563R

Q219

C361

073C

05C

C362

Q 5 1

05R

C54

Q50

C53

C100

C101

3R 5 5

E P 3 5 5

C 63

4

Q 2

81

Q 2 2 4

5C 1

C52

C363

2J

12 - 2

1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan Phone : +81 (06) 6793 5302 Fax : +81 (06) 6793 0013 URL : http://www.icom.co.jp/world/index.html

<Corporate Headquarters> 2380 116th Avenue N.E., Bellevue, WA 98004, U.S.A. Phone : +1 (425) 454-8155 Fax : +1 (425) 454-1509 URL : http://www.icomamerica.com E-mail : sales@icomamerica.com <Customer Service> Phone : +1 (425) 454-7619

Glenwood Centre #150-6165 Highway 17 Delta, B.C., V4K 5B8, Canada Phone : +1 (604) 952-4266 Fax : +1 (604) 952-0090 URL : http://www.icomcanada.com E-mail : info@icomcanada.com

Unit 1 / 103 Garden Road, Clayton VIC 3168 Australia Phone : +61 (03) 9549-7500 Fax : +61 (03) 9549-7505 URL : http://www.icom.net.au E-mail : sales@icom.net.au

146A Harris Road, East Tamaki, Auckland, New Zealand Phone : +64 (09) 274 4062 Fax : +64 (09) 274 4708 URL : http://www.icom.co.nz E-mail : inquiries@icom.co.nz

10C01, Long silver Mansion, No.88, YongDing Road, Haidian District, Beijing, 100039, China Phone : +86 (010) 5889 5391/5392/5393 Fax : +86 (010) 5889 5395 E-mail : bjicom@bjicom.com URL : http://www.bjicom.com

Communication Equipment Himmelgeister Str. 100, D-40225 Dusseldorf, Germany Phone : +49 (0211) 346047 Fax : +49 (0211) 333639 URL : http://www.icomeurope.com E-mail : info@icomeurope.com

Ctra. Rubi, 88, 08190, Sant Cugat del Valles, Barcelona, SPAIN Phone : +34 (93) 590 26 70 Fax : +34 (93) 589 04 46 URL : http://www.icomspain.com E-mail : icom@icomspain.com

Unit 9, Sea St., Herne Bay, Kent, CT6 8LD, U.K. Phone : +44 (01227) 741741 Fax : +44 (01227) 741742 URL : http://www.icomuk.co.uk E-mail : info@icomuk.co.uk

Zac de la Plaine 1 Rue Brindejonc des Moulinais BP 5804 31505 Toulouse Cedex, France Phone : +33 (5) 61 36 03 03 Fax : +33 (5) 61 36 03 00 URL : http://www.icom-france.com E-mail : icom@icom-france.com

6F No.68, Sec. 1 Cheng-Teh Road, Taipei, Taiwan, R.O.C. Phone : +886 (02) 2559 1899 Fax : +886 (02) 2559 1874 URL : http://www.asia-icom.com E-mail : sales@asia-icom.com

Sopot, 3 Maja 54 Poland Phone : +48 (58) 550 7135 Fax : +48 (58) 551 0484 E-mail : icompolska@icompolska.com.pl

1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan

S-14326XZ-C1

Icom IC-2820 service manual

Specifications and Main Features

Frequently Asked Questions

User Manual

INTRODUCTION CAUTION

SECTION 1 SPECIFICATIONS

SECTION 2 INSIDE VIEWS

SECTION 4 CIRCUIT DESCRIPTION

SECTION 5 ADJUSTMENT PROCEDURE

SECTION 6 PARTS LIST

SECTION 8 BOARD LAYOUTS

SECTION 9 BLOCK DIAGRAM

SECTION 10 VOLTAGE DIAGRAM

SECTION 11 HM-133

SECTION 12 UT-123 (Optional product)
