Ice-O-Matic GEM0956R, GEM0650R, GEM1256R User Manual

SERVICE AND INSTALLATION MANUAL

GEM Models: Remote

GEM0650R, GEM0956R, GEM1256R

Pearl Ice™ Series

Ice-O-Matic
11100 East 45th Ave
Denver, Colorado 80239
Part Number 9081350-02 17-3144-01 Date 10/08

By Ice-O-Matic

8

GEM0650/0956/1256 Remote Introduction

How To Use This Manual
Ice-O-Matic provides this manual as an aid to the end user and service technician in installation and

maintenance of the Pearl Ice™ Series ice machines. Do not attempt to perform installation, start-up or
maintenance unless you have read and fully understand this manual.

If, at any time, you encounter conditions that are not addressed in this manual, call, E-mail or write the
Ice-O-Matic Service Department:

Ice-O-Matic
11100 E. 45
Denver, Co. 80239
Attn: Technical Service Department
E-Mail: [e-mail]

Telephone Numbers Any Service communication must include:
800-423-3367 All Departments • Model Number
888-349-4423 Technical Assistance Only • Serial number
303-371-3737 • A detailed explanation of the problem

Keep this manual for future reference.

The GEM0650R, GEM0956R and GEM1256R Service Parts Manuals are available separately.

Ice-O-Matic icemakers and dispensers are not approved for outdoor installation.
WARNING

repairs are performed on the ice machine and related equipment.
CAUTION:

machine and related equipment

th

Ave.

: Always disconnect electrical power and shut off water supply whenever maintenance or

Always wear protective eyewear whenever maintenance or repairs are performed on the ice

Page i

GEM0650/0956/1256 Remote Table Of Contents

Table of Contents

Introduction.................................................................................................................................. Page i

Table Of Contents........................................................................................................................ Page ii

Freight Claim Procedure.............................................................................................................. Page iii

Warranty...................................................................................................................................... Page iv

For The Installer (Guidelines)...................................................................................................... Page 1

Remote Condenser...................................................................................................................... Page 6

For The Installer (Remote Condenser Location) ......................................................................... Page 7

For The Plumber.......................................................................................................................... Page 11

For The Electrician....................................................................................................................... Page 12

For The Installer (Completed Installation).................................................................................... Page 13

For The Installer (Final Check List).............................................................................................. Page 14

Start Up........................................................................................................................................ Page 15

Component Description............................................................................................................... Page 16

Electrical Sequence..................................................................................................................... Page 19

Operation: Water ......................................................................................................................... Page 20

Operation: Refrigeration .............................................................................................................. Page 21

Operation: Performance .............................................................................................................. Page 24

Sanitizing and Cleaning............................................................................................................... Page 25

Remote Condenser Maintenance................................................................................................ Page 26

Bearing Maintenance................................................................................................................... Page 27

Sensor Maintenance.................................................................................................................... Page 28

Auger Maintenance...................................................................................................................... Page 29

Service Diagnosis........................................................................................................................ Page 30

Control System Diagnostics......................................................................................................... Page 32

Removal and Replacement: Water Reservoir and Bin Controls.................................................. Page 33

Removal and Replacement: Bearing and Breaker ...................................................................... Page 34

Removal and Replacement: Auger.............................................................................................. Page 35

Removal and Replacement: Water Seal...................................................................................... Page 36

Removal and Replacement: Evaporator...................................................................................... Page 37

Removal and Replacement: Gear Motor..................................................................................... Page 38

Removal and Replacement: Fan Blade and Fan Motor............................................................... Page 39

Refrigeration System Service...................................................................................................... Page 40

Wiring Diagram: GEM0650R....................................................................................................... Page 41

Wiring Diagram: GEM0956R....................................................................................................... Page 42

Wiring Diagram: GEM1256R....................................................................................................... Page 43

Service History............................................................................................................................. Page 44

Page ii

GEM0650/0956/1256Remote Freight Claim Procedure

Important!

Inspect Promptly

This merchandise has been carefully inspected and packed in accordance with the carrier’s packing
specifications. Responsibility for safe delivery has been assumed by the carrier. If loss or damage occurs, you
as the consignee must file a claim with the carrier and hold the container for carrier’s inspection.

Visible Loss or Damage

Any external evidence of loss or damage must be fully described and noted on your freight bill or express
receipt and signed by the carrier’s agent. Claim should be filed on a form available from the carrier.

Concealed Loss or Damage

If loss or damage does not appear until merchandise has been unpacked, make a written request for
inspection by the carrier within 15 days of the delivery date. Then file a claim on a form from the carrier.

File Claim Without Delay Do Not Return Damaged Merchandise to Ice-O-Matic

Page iii

GEM0650/0956/1256 Remote Warranty

Ice-O-Matic

Domestic & International Limited Warranty

Mile High Equipment LLC (the “Company”) warrants Ice-O-Matic brand ice machines, ice dispensers, remote condensers, water filters, and ice storage
bins to the end customer against defects in material and factory workmanship for the following:

• Cube ice machines,”GEM” model compressed ice machines
,” MFI” model flake ice machines and remote condensers. ­Thirty-six (36) months parts and labor

• “EF” and “EMF” model flake ice machines - Twenty-four (24)
months parts and labor

• CD model dispensers - Thirty-six (36) months parts and
labor

An additional twenty-four (24) month warranty on parts (excluding labor) will be extended to all cube ice machine evaporator plates and compressors,
“GEM” model compressed ice machine compressors, and “MFI” model flake ice machine compressors from the date of original installation. An additiona l
thirty-six (36) month warranty on parts (excluding labor) will be extended to all “EF” and “EMF” model flake ice machine compressors from the date of
original installation. The company will replace EXW (Incoterms 2000) the Company plant or, EXW (Incoterms 2000) the Company-authorized distributor,
without cost to the Customer, that part of any such machine that becomes defective. In the event that the Warranty Registration Card indicating the
installation date has not been returned to Ice-O-Matic, the warranty period will begin on the date of shipment from the Company. Irrespective of the
actual installation date, the product will be warranted for a maximum of seventy-two (72) months from date of shipment from the Company.

ICE-model cube ice machines which are registered in the Water Filter Extended Warranty Program will receive a total of eighty-four (84) months parts
and labor coverage on the evaporator plate from the date of original installation. Water filters must be installed at the time of installation and registered
with the Company at that time. Water filter cartridges must be changed every six (6) months and that change reported to the Company to maintain the
extended evaporator warranty.

No replacement will be made for any part or assembly which (I) has been subject to an alteration or accident; (II) was used in any way which, in the
Company’s opinion, adversely affects the machine’s performance; (III) is from a machine on which the serial number has been altered or removed; or,
(IV) uses any replacement part not authorized by the Company. This warranty does not apply to destruction or damage caused by unauthorized service,
using other than Ice-O-Matic authorized replacements, risks of transportation, damage resulting from adverse environmental or water conditions,
accidents, misuse, abuse, improper drainage, interruption in the electrical or water supply, charges related to the replacement of non-defective parts or
components, damage by fire, flood, or acts of God.

This warranty is valid only when installation, service, and preventive maintenance are performed by a Company-authorized distributor, a Company­authorized service agency, or a Company Regional Manager. The Company reserves the right to refuse claims made for ice machines or bins used in
more than one location. This Limited Warranty does not cover ice bills, normal maintenance, after-install adjustments, and cleaning.

Limitation of Warranty
This warranty is valid only for products produced and shipped from the Company after January, 2007. A product produced or installed before

that date shall be covered by the Limited W arranty in effect at the date of its shipment. The liability of the Compan y for breach of this
warranty shall, in any case, be limited to the cost of a new part to replace any part, which proves to be defe ctive. The Company makes no
representations or warranties of any character as to accessories or auxiliary equipment not manufactured by the Company. REPAIR OR

REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CUSTOMER. MILE HIGH EQUIPMENT SHALL
NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OR MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE LENGTH OF THIS WARRANTY.

Filing a Claim All claims for reimbursement must be received at the factory within 90 da ys from date of service time period will be void. The model, the serial number and, if necessary, proof of installation, must be included in the claim. Claims for labor to

replace defective parts must be included with the part claim to receive consideration. Payment on claims for labor will be limited to the published labor
time allowance hours in effect at the time of repair. The Company may elect to require the return of components to validate a claim. Any defective part
returned must be shipped to the Company or the Company-authorized distributor, transportation charges pre-paid, and properly sealed and tagged. Th e
Company does not assume any responsibility for any expenses incurred in the field incidental to the repair of equipment covered by this warranty. The
decision of the Company with respect to repair or replacement of a part shall be final. No pe rson is authorized to give any oth er warranties or to assume
any other liability on the Company’s behalf unless done in writing by an officer of the Company.

GOVERNING LAW

This Limited Warranty shall be governed by the laws of the state of Delaware, U.S.A., excluding their conflicts of law principles. The United Nations
Convention on Contracts for the International Sale of Goods is hereby excluded in its entirety from application to this Limited Warranty.

Mile High Equipment LLC, 11100 East 45

Parts and Labor

• Ice storage bins -Twenty-four (24) month parts and labor

• IOD model dispensers - Twenty-four (24) months parts, Twelve (12) months

labor

• Water filter systems - Twelve (12) months parts and labor (not including filter
cartridges)

to be eligible for credit. All claims outside this

th

Avenue, Denver, Colorado 80239 [phone]

January 2007

Page iv

GEM0650/0956/1256 Remote For the Installer

Installation Guidelines:

For proper operation of the Ice-O-Matic ice machine, the following installation guidelines must be followed.
Failure to do so may result in loss of production capacity, premature part failures, and may void all warranties.

Ambient Operating Temperatures: (Not including remote condenser)

Minimum Operating Temperature: 50°F (10°C)
Maximum Operating Temperature 100°F (38°C)

Note: Ice-O-Matic ice makers and dispensers are not approved for outdoor installation.
Incoming Water Supply

Minimum incoming water temperature: 40°F (4.5°C)
Maximum incoming water temperature: 100°F (38°C)
Minimum incoming water pressure: 20 psi (1.4 bar)
Maximum incoming water pressure: 80 psi (4.1 bar)

Note: If water pressure exceeds 80 psi a water pressure regulator must be installed.
Drains

All drain lines must be installed per local codes. Flexible tubing is not recommended. Route bin drain, vented
float overflow drain and water condenser drain individually to a floor drain. The use of condensate pumps for
draining water is not recommended by Ice-O-Matic. Ice-O-Matic assumes no responsibility for improperly
installed equipment.

Water Filtration

A water filter system should be installed with the ice machine.

Clearance Requirements

Self-contained air cooled ice machines must have a minimum of 6 inches (15cm) of clearance at the sides of
the ice machine for proper air circulation.

Stacking

Ice-O-Matic Pearl Ice™ machines are not designed to be stacked.

Dispenser Application

The Pearl Ice™ machine is approved for specific dispenser applications, reference page 4.

Electrical Specifications

Refer to the serial plate at the rear of the ice machine to make sure proper voltage and circuit breaker size
have been supplied. Make sure the machine is on a dedicated circuit. The Pearl Ice™ Series are not supplied
with an electrical power cord and will need to be installed and wired per local electrical codes.

Adjustments

Level the machine within 1/8 inch in all directions. Adjust the cabinet or bin legs as required.
Check the bin control for proper operation.
Check the water level in the reservoir for proper adjustment.
Check the water regulating valve adjustment if water cooled.

Page 1

GEM0650/0956/1256 Remote For The Installer

GEM0650/0956R

Page 2

GEM0650/0956/1256 Remote For The Installer

GEM1256R

Page 3

GEM0650/0956/1256 Remote For the Installer

Bin Application

The Pearl Ice™ Series are designed to fit the following Ice-O-Matic Bins

●B42, using Bin Top KBT 24 (Note: GEM0650 and GEM0956 ONLY)

●B25, B40 B55 using Bin Top KBT 19.

●B100 using Bin Top KBT 23 (one unit) or KBT 22 (two units).

●B120, B150, B170 Not designed for Pearl Ice™ Series.

Dispenser Application

The Pearl Ice™ Series can be placed on and used with certain ice and beverage dispensers. Kits are required
for proper operation.

IOM

Pearl Ice™ Accessory List

Dispenser GEM0650 GEM0956 GEM1256
Ice-O-Matic IOD150

KBT15022, KGEMDIV KBT15022, KGEMDIV Does not fit

Ice-O-Matic IOD200 or
IOD250

Cornelius ED or DF150

Cornelius ED or DF200

Cornelius ED or DF250

Lancer Nugget Ready
Flavor Select

SerVend S-200, SV200, S­250, SV-250

KBT25022, KGEMBIOD KBT25022, KGEMBIOD KBT25030, KGEMBIOD,

KGEMDIV

KBT15022,
R629088514(Cornelius
Model)

KBT25022, KGEM200 KBT25022, KGEM200 KBT25030, KGEM200

KBT25022, KGEM250 KBT25022, KGEM250 KBT25030, KGEM250

N/A N/A N/A

N/A N/A N/A

KBT15022,
R629088514(Cornelius
Model)

Does not fit

Ice Machine Specifications

Model
Number

WxDxH
(Inches)

Basic
Electrical

Condenser

Minimum Circuit
Ampacity

Maximum
Fuse Size

Refrigerant
Charge oz. R404

GEM0650R 21x24x27 115/60/1 Remote 22.5 30 208

GEM0956R 21x24x27 208-230/60/1 Remote 14.1 20 208

GEM1256R 30x24x27 208-230/60/1 Remote 17.3 25 208

Page 4

GEM0650/0956/1256 Remote For the Installer

Location:

Ice-O-Matic ice machines are designed to be installed indoors in a controlled environment. Install the ice
machine in a location where it has enough space around it to be accessible for service. A minimum of 6 inches
must be allowed at the back for air circulation on air cooled models. Try to avoid hot, dirty and crowded
locations. Be sure that the location of the machine is within the environmental limitations.

Storage Bin:

Remove the bin packaging. Tip the storage bin on its back, using parts of the packaging to protect the exterior
finish. Remove the skid and install the legs into the threaded holes in the bottom of the bin. Turn the leg
levelers all the way in preparation for leveling later. Return the bin to the upright position.
Note: Do not push the bin into position, but lift it there. Pushing a bin, especially one with ice in it, can cause
damage to the bin legs and mounts.
Install the appropriate bin top according to the instructions provided with the bin top.

Ice machine:

The ice machine is heavy, so the use of a mechanical lift is recommended for lifting the machine high enough
to install on top of the bin. After the unit is placed on the bin, line it up so it is even with the back side. Secure
the ice machine to the bin with the hardware provided with the ice machine. Remove the front panel and
remove any shipping blocks or packaging material.

Proper functioning of the bin door requires the bin door, when it is opened, to be in a stable position. If the ice
machine is too far forward on the bin, the opened door may not be stable, resulting in an unexpected closing of
the bin door.

If the ice machine is to be mounted on a bin or dispenser other than an Ice-O-Matic, refer to the manufacturer’s
instructions for machine mounting. Ice-O-Matic will not be responsible for damage or injury that results from
unexpected closing of the bin door as a result of the ice machine being too far forward on the bin.

Water Limitations:

An ice machine is a food manufacturing plant: it takes a raw material, water and transforms it into a food
product, ice. The purity of the water is very important in obtaining pure ice and maximizing product life. This
section is not intended as a complete resource for water related questions, but it does offer these general
recommendations:

●Check with a water treatment specialist for a water test and recommendations regarding water filters and
treatment.

●In most cases, the water used to make ice should be filtered or treated, depending upon the water.

There is no one type of water filter that is effective in all situations. That is why a water test is important.

RO Water Limitations:

Water conductivity must be no less that 35 microSiemens/cm.

Notice:

Ice-O-Matic ice machines are designed and manufactured with the highest regard for safety and performance
and meet or exceed the standards of UL, NSF and CUL.

Ice-O-Matic assumes no liability or responsibility of any kind for products manufactured by Ice-O-Matic that
have been altered in any way, including the use of any part and/or other components not specifically approved
by Ice-O-Matic.

Ice-O-Matic reserves the right to make design changes and/or improvements at anytime. Specifications and
design are subject to change without notice.

Page 5

GEM0650/0956/1256 Remote Remote Condenser

ERC Dimensions (Inches) GRC1001 GRC1061 GCR2061
A 33.36 33.36 33.36

B 10.75 10.75 10.75
C 23.81 23.81 23.81
D 2.04 2.04 2.04
E 6.12 6.12 6.12
F 16.73 16.73 16.73
G 11.65 11.65 11.65
H 19.57 19.57 19.57
Pearl Ice™ Number GEM0650R GEM0956R GEM1256R

Line Sets

RT325404 25 Foot Precharged Line Set
RT340404 40 Foot Precharged Line Set
RT345404 45 Foot Precharged Line Set
RT360404 60 Foot Precharged Line Set

Page 6

GEM0650/0956/1256 Remote Remote Condenser Location

Use the following for planning the placement of the remote condenser relative to the ice machine.
Location Limits: Remote condenser location must not exceed ANY of the following:

● Maximum rise from the ice machine to the remote condenser is 35 physical feet.

● Maximum drop from the ice machine to the remote condenser is 15 physical feet.

● Physical line set maximum length is 100 feet.

● Calculated

Calculation Formula

● Drop = dd x 6.6 (dd= distance in feet)

● Rise = rd x 1.7 (rd = distance in feet)

● Horizonal Run = hd x 1 (hd = distance in feet)

● Calculation: Drop(s) + Rise(s) + Horizontal Run = dd+rd+hd=Calculated Line Length

Configurations that do NOT meet these requirements must receive written authorization from
Ice-O-Matic. This includes multipass or rack system remote condensers.

Do NOT:

● Route a line set that rises, then falls, then rises.

● Route a line set that falls, then rises, then falls.

Calculation Example 1:

The remote condenser is to be located 5 feet below the ice machine and then 20 feet away horizontally.
(5 feet x 6.6=33 feet) + (20 feet) = 53 feet. This location would be acceptable.

Calculation Example 2:
The remote condenser is to be located 35 feet above the ice machine and then 100 feet away horizontally.
(35 feet x 1.7=59.5 feet) + (100 feet) = 159.5 feet. 159.5 feet is greater than the 150 maximum is NOT
acceptable.

line set length maximum is 150 feet.

Page 7

GEM0650/0956/1256 Remote For the Installer

Remote Condenser Location:

Limited to a 25 foot or a 40 foot length of precharged refrigerant tubing connecting the ice machine to the
remote condenser. The remote condenser must be above or level with the ice machine. Select the best
available location, protecting the remote condenser from extremes of dirt, dust and sun. Meet all applicable
building codes. Usually the services of a licensed electrician are required.

Roof Attachment:

1. Install and attach the remote condenser to the roof of the building, using the methods and practices of

construction that conform to the local building codes, including having a roofing contractor secure the
remote condenser to the roof.

2. Have an electrician connect the remote condenser fan motor wires to the ice machine, using the junction

box at the back of the ice machine.

Precharged Line Set Routing
CAUTION: Do not connect the precharged

tubing until all routing and forming of the
tubing is complete. See the coupling
instructions for connecting information.

1. Each set of precharged tubing refrigerant lines

consists of a 3/8 diameter liquid line and a 1/2
inch diameter discharge line. Both ends of
each line have quick connect couplings, one
end has a Schrader valve connection, that end
goes to the condenser.

Note: The openings in the building ceiling or

wall, listed in the next step, are the minimum
sizes recommended for passing the refrigerant
lines through.

2. Have the roofing contractor cut a minimum

hole for the refrigerant lines of 1.750 inch.
Check local codes, a separate hole may be
required for the electrical power to the
condenser.

CAUTION: DO NOT KINK OR CRIMP

REFRIGERANT TUBING WHEN
INSTALLING IT.

3. Route the refrigerant lines through the roof

opening. Follow straight line routing whenever
possible. Any excess tubing MUST remain
within the building.

4. Spiral the excess length of precharged tubing

inside the building. Use a horizontal spiral
(does not need to be as tight as illustrated) to
avoid any traps in the lines.

5. Have the roofing contractor seal the holes in

the roof per local codes.

CAUTION: The couplings on the sets of

precharged lines are self sealing when
installed properly. Carefully follow the
instructions:

Page 8

GEM0650/0956/1256 Remote For the Installer

Typical Installation

REMOTE CONDENSER

ICE MACHINE

Page 9
