Operator & Parts Manual

Automatic Scrubber

www.icecompanies.com

8210060

REV.06 (03-2017)

i28BT i32BT

INTELLIGENT CLEANING EQUIPMENT

Page 2

ICE i28BT / i32BT

OPERATOR MANUAL

HOW TO ORDER PARTS

Only use ICE Company supplied or equivalent parts. Parts and supplies may be ordered online,by phone, by fax or by mail.

1. Identify the machine model.

2. Identify the machine serial number from the data label.

3. Ensure the proper serial number is used from the parts list.

4. Identify the part number and quantity. Do not order by page or reference numbers.

5. Provide your name, company name, customer ID number,billing and shipping address, phone number and purchase order number.

Please ll out at time of installation for future reference.

Model No.

Serial No.

Machine Options

Sales Rep.

Sales Rep. Phone No.

Customer ID Number

Installation Date

READ OPERATOR MANUAL CAREFULLY!

ICE Company Limited

XiangShi Road LiaoBu DongGuan GuangDong China Tel: 0769 - 81869000 Fax:0769 - 81863000

Specifications and parts are subject to change without notice.

IMPORTANT: To ensure full warranty protection, please ll out & return

your warranty card.

PROTECT THE ENVIRONMENT

Please dispose of packaging materials,old machine components

such as batteries, hazardous uids, including antifreeze and oil, in an

environmentally safe way according to local waste disposal regulations.

Always remember to recycle.

Page 3

ICE i28BT / i32BT

OPERATOR MANUAL

SAFETY PRECAUTIONS......................................................................................................4

MACHINE COMPONENTS...................................................................................................5

MACHINE SETUP & INSTALLATION....................................................................................6

MACHINE OPERATION.................................................................................................7

WHILE OPERATING MACHINE..........................................................................................7

TANK DRAINING..................................................................................................................8

BATTERY CHARGING.........................................................................................................9

PREVENTATIVE MAINTENANCE.......................................................................................9

BASIC TROUBLESHOOTING............................................................................................11

TECHNICAL SPECIFICATION............................................................................................12

PARTS LIST...................................................................................................................13-36

WEAR AND TEAR PARTS..................................................................................................37

WIRING DIAGRAM.............................................................................................................38

TABLE OF CONTENTS

Page 4

ICE i28BT / i32BT

OPERATOR MANUAL

SAFETY PRECAUTIONS

This machine is intended for commercial use. It

is designed exclusively to scrub hard oors in an

indoor environment and is not constructed for any other use. Only use recommended accessories.

All operators shall read, understand and exercise the following safety precautions:

1. Do not operate machine:

- Unless trained and authorized.

- Unless you have read and understand the

operators manual.

- In ammable or explosive areas.

- If not in proper operating condition.

- In outdoors areas.

2. Before starting machine:

- Make sure all safety devices are in place

and operate properly.

3. When using machine:

- Go slow on inclines and slippery

surfaces.

- Follow all safety guidelines.

- Be very careful when using the machine in

reverse.

- Reduce speed when turning.

- Report and x any damage to machine prior

to operating it.

- Never allow children to play on or

around.

- Do not operate on inclines that exceed 5%

(3°).

4. Before leaving or servicing machine:

- Stop on level surface.

- Turn off machine.

5. When servicing machine:

- Read operators manual thoroughly prior to

operating or servicing this machine.

- Use manufacturer supplied or approved

replacement parts.

- Secure machine with wheel blocks prior to

jacking the machine up.

- Use approved jack or hoist to safely elevate

the machine.

- Disconnect batteries prior to working on

machine.

- Wear gloves when handling batteries or

battery cables.

- Avoid any contact with battery acid

- Avoid moving parts. Do not wear loose tting

clothing while servicing machine.

WARNING: Batteries emit hydrogen

gas. Explosion or re can result from

hydrogen gas. Keep sparks and open

ames away! Keep battery compartment

open when charging.

WARNING: Flammable materials can cause an explosion or re. Do not use ammable materials in tanks.

WARNING: Flammable materials or reactive metals can cause explosion or re.

Do not pick up.

Page 5

ICE i28BT / i32BT

OPERATOR MANUAL

MACHINE COMPONENTS

1. Control Handle

2. Brush pressure adjusting buttons & indicator light Brush pressure increase button Brush pressure decrease button

3. Hour meter

4. Speed Control Knob Slow Speed Fast Speed

5. Battery Meter

6. Main Power Key Switch

7. 1-STEP scrub head up/down switch & indicator light

8. Solution ow Control Buttons & Indicator Light

Solution ow Increase button Solution ow Decrease button

9. Vacuum Motor Switch & Indicator Light

10. Emergency stop button

11. Drive motor circuit breaker

12. Solution Tank Level / Drain Hose

13. On-board battery charger

14. Caster, 2Inch, Squeegee Adjustment

15. Bumper Rollers

16. Squeegee Assembly

17. Ball Valve

18. Casters, 4 Inch

19. Squeegee Vacuum Hose

20. Filter Assembly

21. Wheels, 8 Inch

22. Recovery Tank Drain Hose

23. Hose ll-port

24. Squeegee Lift Lever

25. Control Handle Start Bail Direction Decal

26. Batteries

27. Recovery Tank Support Stand

28. Vacuum Motor, 24VDC

29. Cup Holder

30. Recovery Tank Cover

31. Recovery Tank

32. ICE Logo

33. Vacuum motor circuit breaker

34. Bucket Fill Port/ Clean-Out Port

35. Solution Tank

36. LED Light

37. Front cover

38. Brush & Pad realease plunger

39. Scrub Head adjusting bolt

40. Scrub Head Skirt

41. Scrub Head Assembly

42. Parking Brake (Option)

3 2554 6

15161718192021

26 27 28

7 29

39 40

Page 6

ICE i28BT / i32BT

OPERATOR MANUAL

UNCRATING MACHINE

Be sure and check packing carton for any damage. Immediately report any damage to carrier. Check the contents of package to ensure that the following items are included:

• Machine

• 4-6V Batteries

• Squeegee assembly

• 2-Pad Drivers

INSTALLING BATTERIES

The batteries are already in the machine upon

delivery; However you will need to connect the

cables to the battery posts.

WARNING: Batteries emit hydrogen gas.

Explosion or re can result from hydrogen gas.Keep sparks and open ames away! Keep battery compartment open when charging.

Recommended Battery spec:

4-6V, 260AH@20HR deep cycle batteries.

Max. batteries dimensions :

265mm (L) X 190mm (W) X 280mm (H)

1. Turn the main power key switch off.

2. Open recovery tank to gain access to battery compartment.

3. Carefully place the batteries into the

compartment as shown in gure below. Place

the battery brace at the rear of the batteries.

DO NOT DROP BATTERIES INTO COMPARTMENT!

4. Connect battery cables to posts in numbered order as shown in drawing below.

RED to POSITIVE and BLACK to NEGATIVE.

MACHINE SET UP

PRE-OPERATION CHECKS

1. Sweep or dust mop the surface to be cleaned.

2. Check battery meter to make sure batteries are fully charged. (See BATTERY CHARGING)

3. Check that squeegee is properly installed.

4. Check that brushes / pads is properly installed.

INSTALLING BRUSHES OR PADS

1. Turn off the 1-STEP Scrub head up/down switch (see machine components, item #7) and Raise

the Scrub head off the oor, then stop machine

on the level surface, remove the key and ensure the machine is turned off.

2. If using the Pad Driver, rst attach the appropriate pad to the pad driver surface.

3. Align the pad driver or brush under the motor hub and push it upward to engage.

4. To remove the pad driver or brush, raise the scrub head and push the pad release plunger (see machine components, item #38) downward.

MOUNTING THE SQUEEGEE ASSEMBLY

1. Lift the squeegee lift lever (see machine components, item #24)to the upward position.

2. Mount the squeegee assembly to the squeegee pivot bracket. make sure the knobs are completely seated into the slots before securing knobs.

3. Connect the vacuum hose to the squeegee assembly. Loop the hose by using the hose clip provided.

4. Check the squeegee blades for proper adjustment.

MACHINE SET UP & INSTALLATION

Page 7

ICE i28BT / i32BT

OPERATOR MANUAL

FILLING THE SOLUTION TANK

The machine is equipped with a hose ll-port (see

machine components, item #23) at the rear of

the machine, and a bucket ll-port (see machine

components, item #34)located under the recovery

tank. Before accessing the bucket ll-port make

sure that the recovery tank is empty.

Fill the solution tank to the "100L" level on the solution tank sight gauge. When using the bucket

ll-port, stop lling when the level reaches the bottom edge of the ll-port.

NOTE: When lling the solution tank with a bucket, make sure that the bucket is clean. Do not use the same bucket for lling and draining the machine.

WARNING: Do not put any ammable

materials into solution tank. this can cause an

explosion or a re. Only use recommended

cleaning chemicals. Contact your janitorial

supply distributor for recommendations on

proper chemicals.

WARNING: Do not operate machine unless you have read and understand this manual.

1. Turn the main power key switch(see machine components, item #6) to the on (I) position.

2. Check the battery level meter (see machine components, item #5), if the battery meter is in the red, DO NOT continue to operate the machine and recharge the batteries immediately.

3. Turn on the 1-STEP scrub head up/dwon switch (see machine components, #7) to lower the

scrub head to the oor, the 1-STEP switch

indicator is light.

4. Lower squeegee assembly to the oor by lowering the squeegee lift lever(see machine components, item #24).

5. Check the solution ow indicator (see machine

components, item #8), adjust the solution ow control switch to a desired ow rate.

NOTE: Solution will not begin to ow until the control handle bail is pulled.

6. Turn on the vacuum motor switch(see machine components, item #9).

7. Pull the control handle bail (see machine components, item #25) backwards to start scrubbing .The machine will automatically propel forward. To reverse the machine, simply push the control handle bail forward. NOTE:

Raise squeegee when reversing machine.

8. The scrubbing speed can be adjusted, Adjust the speed control knob (see machine components, item #4) to a desired speed.

NOTE: 45-60 meters (150-200 ft)per minute is the recommended scrubbing speed.

9. simply press the pressure adjuting button to

increase (+) or decrease (-) the brush pressure as needed.

10. To stop scrubbing, release the control handle

bail, turn off the 1-STPE switch to raise the scrub head assembly, raise he squeegee assembly.

WARNING: Fire Or Explosion Hazard. Do

Not Pick Up Flammable Materials Or Reactive

Metals.

1. Go slow on inclines and slippery surfaces. Do not operate the machine on inclines that exceed 5% (3°).

2. Do not keep the machine in the same position with pad / brush spinning, keep the machine

moving to prevent damage to oor nish.

3. If the squeegee assembly leaves streaks on the

oor, raise the squeegee off the oor and wipe

the blades down with a damp cloth. Pre-sweep

the area to prevent leaving streaks on the oor.

4. Pour a recommended defoamer into the recovery tank if excessive foam appears.

WARNING: Do not allow foam to enter

the oat shut-off screen, vacuum motor

damage will result. Foam will not activate the

oat shut-off screen.

5. Occasionally check the battery level meter(see machine components, item #5). when meter is in the red, stop scrubbing and recharge the batteries.

WARNING: When battery meter is in the

red, do not continue to operate the machine. Battery damage may result.

MACHINE OPERATION

WHILE OPERATING MACHINE

Page 8

ICE i28BT / i32BT

OPERATOR MANUAL

6. When the solution tank runs empty, press the 1-STEP switch raise the brush head. Keep the squeegee down and continue to vacuum until all the dirty water is picked up.

NOTE: Brush motors will not work when the scrub head assembly raised.

NOTE: See TANK DRAINING section to learn how to drain recovery and solution tanks.

CIRCUIT BREAKER / FUSES

The machine is equipped with 2 resettable circuit breakers(see machine components, item #11, item# 33) to protect the drive motor and the vacuum motor from damage. If the circuit breakers should trip, it can't be reset immediately. You must

rst determine what caused the breaker to trip, and

allow the motor to cool down and then you can manually reset the circuit breakers.

The machine is also equipped with a 60A fuse to protect the brush motors from damage. When replacing a fuse never substitute a higher Amps

rated fuse than specied.

HOUR METER

The hour meter (see machine components, item #3) records the number of total hours the brush motor has been powered on. Use the hour meter to determine when to perform recommended maintenance procedures and to record service history.

EMERGENCY STOP BUTTON/ BRAKE

The machine is equipped with an Electromagnetic Brake Mechanism on the Transaxle. When in case of Emergency, release the Control Handle bail(see machine components, item #25) or strike the Emergency stop button (see machine components, item #10), the machine will be braked and then stop. Reset the emergency stop button, turn on the Main power key switch, and then pull the control handle bail, the machine will be restart.

NOTE: The machine can not be moved unless the Main Power Key Switch and the Control Handle bail be turned on.

WARNING: Do Not Change the Default Settings of the Electromagnetic Brake Mechanism unless Authorized, otherwise it may cause Machine Damage or Personal Injury. Contact the Authorized Service center for machine repairs.

1. Turn the machine off.

2. With the squeegee and scrub head in their "up" position, transport machine to approved area for draining tank(s).

DRAINING THE RECOVERY TANK

Any time scrubbing is completed, or when relling

solution tank, the recovery tank should be drained and cleaned.

WARNING: If the recovery tank is not

drained when the solution tank has been relled, foam or water may enter the oat shut-

off screen and cause damage to the vacuum motor.

1. While holding the drain hose (see machine components, item #22) upward, remove the cap and lower hose to drain.

2. Open the recovery tank cover and rinse out the tank. Use a rag to remove any excess dirt.

3. Clean the oat shut-off screen and debris tray located in the recovery tank .

DRAINING THE SOLUTION TANK

Any time scrubbing operation is completed, the solution tank should be drained and cleaned.

1. Pull the solution tank level hose(see machine

components, item #12) off the hose tting, this will allow the solution to ow freely into a bucket or oor drain.

2. Remove the cover of the lter assembly(see machine components, item #20) to drain the

solution tank, check the lter screen and clean

up it if necessary.

3. Rinse the solution tank with clean water after every use. This will help prevent chemical buildup and clogging of the solution lines.

4. After rinsing out the tank, securely reconnect

the tank level hose to the hose tting, replace the lter assembly cover and be sure the lter screen and the "O" ring is in the correct

position.

TANK DRAINING

Page 9

ICE i28BT / i32BT

OPERATOR MANUAL

BATTERY CHARGING

WARNING: Fire Or Explosion Hazard. Batteries Emit Hydrogen Gas. Keep Sparks and

Open Flame Away. Keep Battery Compartment Propped Open When Charging.

NOTE: Use only apprved chargers with the following specications:

• Automatic shut off circuit

• Deep cycle charging

• Output current of 20-30 Amps

• Output voltage of 24 volts

ON-BOARD BATTERY CHARGER

As standard conguration, the machine is equiped

with the On-board battery charger (see machine components, item #13). The settings of On-board battery charger had been set for the recommended batteries type.

WARNING: The On-board battery charger setting's change are to be completed by authorized service centers only. Failure to properly set will result in the batteries or

charger damage.

1. Transport the machine to a well ventilated area.

2. Turn the machine off.

3. If charging wet (lead acid) batteries check the

uid level before charging.

4. Prop up the recovery tank by the support stand (see machine components, item #27) for ventilation.

5. Connect the charger's AC power supply cord to a properly grounded receptable.

6. The charger will automatically begin to charge, once the charging cycle begins, the indicator lights will progress from red, yellow to green. when the green indicator light comes on, the charging cycle is done. Unplug the charger cord.

NOTE: The machine will can not operate when charging.

OFF-BOARD BATTERY CHARGER (OPTION)

1. Place charger and machine in a well ventilated area.

2. Turn the machine off.

3. If charging wet (lead acid) batteries check the

uid level before charging.

4. Prop up the recovery tank by the support stand (see machine components, item #27) for ventilation.

5. Connect the charger's AC power supply cord to a properly grounded receptable.

6. Connect the charger's DC cord into the machine's battery receptacle at the rear of the machine.

7. The charger will automatically begin to charge and will automatically shut off once the batteries are fully charged.

8. Upon completion of charging, disconnect the

AC power supply cord rst, and then disconnect

the charger from the machine.

WARNING: Before performing any

maintenance on the machine, be sure that the power is turned off, or the batteries are

disconnected!

WARING: Repairs are to be completed by Authorized service centers only. Any repairs completed by unauthorized persons will avoid

the warrenty.

DAILY MAINTENANCE

1. Remove pad driver/ brush and clean with approved cleaner.

2. Drain recovery and solution tanks completely and rinse out with clean water. Visually check the recovery tank for debris and clean out as necessary.

3. Raise the squeegee assembly off oor and wipe it down with a damp towel. Be sure to store the squeegee in the up position.

4. Remove the oat shut-off assembly and rinse it out with clean water.

5. Clean machine with an approved cleaner and a damp towel.

6. Recharge the batteries.

7. Check the condition of the squeegee blade wiping edge, rotate blade if worn.

PREVENTATIVE MAINTENANCE

Page 10

ICE i28BT / i32BT

OPERATOR MANUAL

MONTHLY MAINTENANCE

1. Clean the battery tops to prevent corrosion.

2. Check for loose battery cable connections.

3. Inspect and clean the recovery tank cover seal. Replce it if damaged.

4. Lubricate all grease points and pivot points with silicon spray and approved grease.

5. Check the machine for loose nuts and bolts.

6. Check the machine for leaks.

MOTOR MAINTENANCE

1. Contact your local Distributor for any motor maintenance.

2. Motor should have the brushes checked every 250 hours. Brushes should be replaced when they are worn to a length of 10 mm or less.

BATTERY MAINTENANCE

WARNING: Batteries emit hydrogen gas

and an explosion o re can result. Keep sparks and re away from batteries at all times.

WARNING: Whenever serviving batteries, be sure to wear protective gloves. Avoid contact with battery acid at all times.

NOTE: For the best machine performance, keep batteries charged at all times. Do not let them sit in a discharged condition.

1. Always follow the battery charging directions as outlined in the BATTERY CHARGING section of this manual.

2. Keep battery tops and terminals free from corrosion. A strong solution of baking soda and water is the best way to keep the batteries corrosion free. DO NOT ALLOW THE BAKING SODA / WATER SOLUTION TO ENTER THE BATTERY CELLS.

3. Use a wire brush with the baking soda solution to properly clean the battery posts and connctions.

4. Check battery connections for wear and loose terminals. replace if necessary.

MACHINE STORAGE

1. Always store the machine indoors.

2. Always store the machine in a dry area.

3. Always store the machine in its upright position.

4. Always store the machine with the pad driver/

brush raised off the oor.

5. Always store the machine with the squeegee

assembly raised off the oor.

6. If storing in an area which may reach freezing

temperatures, be sure to drain all uids from the

machine prior to storage. Any damage caused by freezing temperatures will not be covered by the warranty.

7. Drain the recovery tank.

8. Drain the solution tank of all uid.

Page 11

ICE i28BT / i32BT

OPERATOR MANUAL

PROBLEM CAUSE SOLUTION

Machine will not operate

Control handle bail not pulled Pull control handle bail Batteries need to be charged Charge batteries Bad battery(s) Replace battery(s) Loose battery cable Tighten loose cable Emergency stop button activated Reset Emergency stop botton Main PCB fuse blown Contact ICE service center Faulty key switch Contact ICE service center

Brush motor will not operate

1-STEP scrub head up/down switch is off Turn on the 1-STEP switch Battery meter lockout activated Recharge batteries Brush motor fuse blown Replace 60A fuse Brush motors over load Turn on / off the 1-STEP switch Faulty control handle bail switch Contact ICE service center Faulty brush motor or wiring Contact ICE service center Worn Motor carbon brushes Contact ICE service center Bad solenoid Contact ICE service center

Machine does not propel

The Main Power Key Switch be Turned off, the Control handle bail not pulled

Turn on the Key switch, Pull the control

handle bail Tripped drive motor circuit breaker Reset drive motor circuit breaker button Faulty transaxle motor or wiring Contact ICE service center Worn Motor carbon brushes Contact ICE service center

Vacuum motor will not operate

Tripped vacuum motor circuit breaker Reset vacuum circuit breaker button Faulty vacuum motor or wiring Contact ICE service center Worn Motor carbon brushes Contact ICE service center

Little or no

solution ow

Ball valve set too low or shut off Turn on the ball valve

Solution ow control knob set too low or

shut off

Adjust solution control ow knob

Clogged solution tank lter or solution

hose

Clean solution tank filter or flush out

solution hose Clogged solution Solenoid valve Remove valve and clean

Poor water pick up

Recovery tank is full Drain recovery tank Loose drain hose cap Tighten cap

Clogged oat shut-off screen located in

recovery tank

clean screen

Clogged squeegee assembly Clean squeegee assembly Worn squeegee blades Replace or rotate squeegee blades Incorrect squeegee blade deection Adjust squeegee blade height Loose vacuum hose connections Secure hose connections Clogged vacuum hose Remove clogged debris Damaged vacuum hose Replace vacuum hose Recovery tank cover not in place Properly position cover Damaged recovery tank cover seal Replace seal Faulty vacuum motor Contact ICE service center Low battery charge Recharge batteries

Short run time

Low battery charge Fully recharge batteries Defective batteries Replace batteries Batteries need maintenance See BATTERY MAINTENANCE Faulty battery charger Repair or replace battery charger Down pressure lever is set for extra scrub head pressure

Lower down pressure lever

BASIC TROUBLESHOOTING

Page 12

ICE i28BT / i32BT

OPERATOR MANUAL

TECHNICAL SPECIFICATIONS

MODEL i28BT i32BT

DIMENSIONS L 61.02 in / 1,550 mm 62.21 in / 1,580 mm

DIMENSIONS W 30.51 in / 775 mm 34.06 in / 865 mm

DIMENSIONS H 44.49 in / 1,130 mm 44.49 in / 1,130 mm

WEIGHT 352.74 lbs / 160 Kg 374.79 lbs / 170 Kg

WEIGHT with BATTERIES 661.39 lbs / 300 Kg 683.43 lbs / 310 Kg

SOLUTION TANK CAPACITY 26.42 Gal / 100 L

RECOVERY TANK CAPACITY 31.7 Gal / 120 L

SQUEEGEE WIDTH

Standard: 40.5 in / 1030mm

Option: 44.5 in / 1130mm

Standard: 46.5 in / 1185mm Option: 44.5 in / 1130mm

CLEANING PATH WIDTH 27.56 in / 700 mm 31.5 in / 800 mm

PRODUCTIVITY RATE 30,677 ft

/ 2,850 m2 h 34,983 ft2 / 3,250 m2 h

DRIVE SYSTEM Transaxle, 24VDC, 0.27 hp / 0.2 KW

TRAVEL SPEED, MAXIMUM

Cleaning: 65m / Min Transporting: 72 m / Min

213.25 ft / Min 236.22 ft / Min

MINIMUM AISLE TURN 63 in / 1,600 mm

PAD/BRUSH PRESSURE

39.68 lbs / 18kg

79.37 lbs / 36kg

119.05 lbs / 54kg

SOLUTION FLOW RATE

0 ~ 2.7 L / Min

0 ~ 0.66 Gal / Min

BRUSH MOTOR 0.75 hp / 0.55 KW × 2

VACUUM MOTOR 0.8 hp / 0.6 KW

WATER LIFT - AIR FLOW 65 in / 1,650 mm

BATTERIES 4 - 6V, 260AH @ 20 hr

RUN TIME PER CHARGE 3.5~4 Hours

VOLTAGE DC 24V

DECIBEL RATING AT OPERATOR'S EAR, INDOORS

68 dB(A)

GRADE LEVEL, MAX 5% (3°)

Page 13

ICE i28BT / i32BT

PARTS LIST

RECOVERY TANK GROUP

Page 14

ICE i28BT / i32BT

PARTS LIST

RECOVERY TANK GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8111001 GASKET 1

2 8131003 CAP 1

3 8210102 RECOVERY TANK 1

4 8131010 DRAIN HOSE 1

5 1962050 CLAMP 1

6 8111300 HINGE ASSEMBLY 2

7 1421618 FLAT WASHER M6×18×1.6 10

8 1021616 HEX BOLT M6 X 16 12

9 8210207 CABLE 1

10 1421612 FLAT WASHER M6×12×1.6 5

11 8112005 GASKET, VACUUM MOTOR 1

12 1121605 HEX NUT M6 3

13 8210209 STUD M6×110 3

8210260 AMETEK VACUUM MOTOR 24VDC, KIT 1

8132006 CARBON BRUSH, VACUUM MOTOR 2

15 1123608 LOCK NUT M6 3

16 1914300 TIE, NYLON, 5X300 1

17 8132007 MUFFLER, VACUUM MOTOR 1

18 8210230 LABEL, BATTERY INSTALLATION 1

19 4010316 ICE LOGO 1

20 8111008 BRACKET 1

21 1421816 FLAT WASHER M8×16×1.6 2

22 8111007 RECOVERY TANK SUPPORT 1

23 8115404 SLEEVE, P/M 1

24 1021830 HEX BOLT M8×30 1

25 8111016 PLATE 2

26 1221512 SCREW M5×12 2

27 8111015 FLOAT, SHUT-OFF 1

28 8111014 FLOAT ADAPTER 1

29 8210201 RECOVERY TANK COVER SEAL 1

30 8011005 CAP 1

31 8210103 RECOVERY TANK COVER 1

32 8111022 WARNING LABEL 1

Page 15

ICE i28BT / i32BT

PARTS LIST

SOLUTION TANK GROUP

Page 16

ICE i28BT / i32BT

PARTS LIST

SOLUTION TANK GROUP

DIA

NO.

PART

NUMBER

DESCRIPTION NO REQ'D

1 6210131 NYLON, CLAMP 6

2 1421510 FLAT WASHER M5×10×1 20

3 1221512 SCREW M5×12 9

4 1123507 LOCK NUT M5 6

5 8210111

BRACKET, ON BOARD BATTERY CHARGER MNTG

6 8210117 CAP, CHARGER 1

7 1421612 FLAT WASHER M6×12×1.6 12

8 1021616 HEX BOLT M6 X 16 10

9 1221525 SCREW M5×25 4

10 8210106A 25A ON BOARD BATTERY CHARGER 1

11 8112030 POWER CORD, BATTERY CHARGER, US 1

12 8210180-US 25A ON BOARD BATTERY CHARGER, KIT, US 1

13 1222641 SCREW M6 X 40 2

14 8210112 HOOK, CORD 2

15 8210114 COVER 1

16 1221412 SCREW M4×12 4

17 1321213 SELF-TAPPING SCREW ST4.2X13 2

18 8210113 CAP, SOLUTION FILL 1

19 8210101 SOLUTION TANK 1

20 4010316 ICE Logo 2

21 8210140 CLEAN TUBING 1

22 1962025 CLAMP 16-25mm 1

23 8210151 LABEL, LEFT SIDE 1

24 8210141 BATTERY CONNECT CABLE, BLACK 3

25 8113013 SPACER, BATTERY 2

26 8210105 BATTERY, 260AH @ 20Hr 4

27 8210107 BATTERY TRAY 1

28 8114751 JACKET, BATTERY TERMINAL, BLACK 8

29 8210104 COVER, FRONT 1

30 1321110 SELF-TAPPING SCREW ST3.5 ×10 3

Page 17

ICE i28BT / i32BT

PARTS LIST

SOLUTION TANK GROUP

DIA

NO.

PART

NUMBER

DESCRIPTION

REQ'D

31 1421409 FLAT WASHER M4×9×0.8 5

32 8133610 LED LIGHT, KIT 1

33 8133601 LED LIGHT MNTG BASE 1

34 1221520 SCREW M5X20 3

35 8133602 LED LIGHT COVER 1

36 8210531 KNOB, M6 2

1535630 SET SCREW M6 ×30 2

1421618 PLAIN WASHER 6×18×1.6,SS 6

39 8113112 BUSHING 2

40 8210152 LABEL, RIGHT SIDE 1

41 8113030 SEAL 1

42 8113002 COVER 1

43 8113007 STRAP 1

44 8210421 RELAY 1

45 1422616 LOCK WASHER, M6 6

46 8114705 STAND-OFF, M6, RED 2

8114703 CIRCUIT BREAKER, 35A 1

48 1222520 SCREW M5X20 2

8210422 60A FUSE ASSEMBLY 1

8210423 FUSE, 60A 1

50 8124704 SOLENOID SWITCH 1

51 1123608 LOCK NUT M6 4

52 1123406 LOCK NUT M4 2

53 8210160 BATTERY CONNECT CABLE, ASSEMBLY 1

54 8210161 CONNECTOR, SB175-RED 2

55 1521635 SCREW, HEX SOCKET, M6 X 35 2

56 8210165 BATTERY CONNECT CABLE, ASSEMBLY 1

57 1021610 HEX BOLT M6 × 10 2

58 8210126 BRACKET, SOLENOID SWITCH 1

Page 18

ICE i28BT / i32BT

PARTS LIST

CONTROL CONSOLE GROUP

Page 19

ICE i28BT / i32BT

PARTS LIST

CONTROL CONSOLE GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8134001 CONTROL CONSOLE HOUSING 1

2 1421307 FLAT WASHER M3×7×0.5 5

3 1221306 SCREW M3×6 5

4 8210401 PCB ASSEMBLY 1

5 8134015 GASLET 1

6 1123305 LOCK NUT M3 6

7 8114710 TIMER 1

8114709 KEY SWITCH 1

8114752 KEY 1

9 8124717A POTENTIOMETER, KIT 1

10 8124718 KNOB, POTENTIOMETER 1

11 8210410 CONTROL PANEL 1

8210415 CONTROL PANEL DECAL, i28BT 1

8210412 CONTROL PANEL DECAL, i32BT 1

13 1221512 SCREW M5×12 12

14 1021616 HEX BOLT M6 X 16 5

15 1421618 PLAIN WASHER 6×18×1.6,SS 9

16 8124007 BUTTON,EMERGENCY STOP 1

17 8210414 CAP 2

18 8124008 SPRING 2

19 8144030 BASE, CIRCUIT BREAKERS MNTG 1

20 8114703 CIRCUIT BREAKER, 35A 1

21 8124715A EMERGENCY STOP SWITCH, KIT 1

22 1421409 FLAT WASHER M4×9×0.8 4

23 1221421 SCREW M4×20 2

24 8114005 CONNECTOR 1

25 1421510 FLAT WASHER M5×10×1.0 5

26 1021630 HEX HEAD BOLT M6×30,SS 1

27 8014101 LIFTING ROPE SPACER 1

28 1021512 HEX HEAD BOLT M5×12,SS 2

29 1421515 FLAT WASHER M5×15×1.0 1

30 8210413 CABLE, SQGE LIFT 1

31 1021620 HEX HEAD BOLT, M6 ×20 2

32 8014012 BAFFLE 1

33 1123608 LOCK NUT M6 8

34 8134501 BRACKET 1

Page 20

ICE i28BT / i32BT

PARTS LIST

CONTROL CONSOLE GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

35 8134508 SLEEVE 1

36 1421132 FLAT WASHER 12×32×1.5 2

37 8014010 SQUEEGEE LIFTING HANDLE 1

38 8113104 BALL KNOB M8 1

39 1121605 HEX NUT M6 2

40 1021840 HEX BOLT M8×40 2

41 1422821 LOCK WASHER M8 8

42 1421828 FLAT WASHER M8×28×3 2

43 6210111 CLAMP, DRAIN HOSE 1

44 1221515 PH SCREW M5×15,SS 2

45 8124743 MICRO SWITCH 1

46 8114712 MICRO SWITCH 1

47 1434300 LOCK WASHER, TOOTH, M3 4

48 1021320 SCREW M3×20 4

49 8134022 BRACKET,SWITCH 1

50 8114402 BRACKET, SPRING 1

51 1521616 SCREW M6X16, HEX SCOKET 2

52 8114300 ACTUATOR 1

53 1534608 SET SCREW M6 ×8 4

54 1535630 SET SCREW M6 ×30 1

55 8114306 SPRING 1

56 8114101 SHAFT 1

57 8134300 LEVER, BAIL 1

58 1123507 LOCK NUT M5 3

59 8124501 SPEED CONTROL BOARD 1

60 8134021 REAR PLATE, CONTROL CONSOLE 1

61 1421824 FLAT WASHER M8×24×2 6

62 1021820 HEX BOLT M8×20 6

63 1021535 SCREW, M5 × 35 2

64 8114707 RELAY, 40A 1

Page 21

ICE i28BT / i32BT

PARTS LIST

FRAME & TRANSAXLE GROUP

Page 22

ICE i28BT / i32BT

PARTS LIST

FRAME & TRANSAXLE GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8211507 KNOB M8 ×60 1 2 8211505 SHOULDER SCREW,M12 1 3 1421132 FLAT WASHER 12×32×1.5 2 4 8135001

PLASTIC THRUST WASHER M12×∮ 30×1.5

2 5 8211506 SHAFT 1 6 1123608 LOCK NUT M6 7 7 1421618 FLAT WASHER M6×18×1.6 2 8 8211503 BRACKET, SQUEEGEE 1 9 8114511 BALL JOINT M6 1

10 8211504 SHOULDER SCREW,M8 4 11 8210508 SPIRNG 1 12 8211501 BRACKET, SQGE LIFT 1 13 1121807 NUT, M8 2 14 1421824 FLAT WASHER M8×24×2 12 15 8211502 BRACKET,SQGE SWING 1 16 1123810 LOCK NUT M8 11 17 8211508 BUSHING 1 18 1123115 LOCK NUT M12 1 19 8115203 COVER, WHEEL 2 20 1021816 HEX BOLT M8 × 16 2 21 1422821 LOCK WASHER M8 7 22 1421828 FLAT WASHER M8×28×2 2

8125200 WHEEL, 8 INCH 2

8225200 AIR FILLED WHEEL, 8 INCH, KIT (OPTION)

8225210 FOAM FILLED WHEEL, 8INCH, KIT (OPTION)

24 1021825 HEX BOLT M8 × 25 4 25 8210123 BRACKET, TRANSAXLE MNTG 2 26 1436019 RETAINING RING 19 2 27 8125403 WOODRUFF KEY 2 28 8210120A TRANSAXLE, 24VDC 1 29 1022800 HEX BOLT M8 X 100 1 30 1021030 HEX BOLT M10 X 30 8 31 1421020 FLAT WASHER 10×20×2.0 8 32 8210109 4" CASTER 2 33 1021820 HEX BOLT M8×20 5 34 8210115 ARM, SCRUB HEAD LIFTING 2 35 8210116 BUSHING 2 36 8210130 FRAME 1 37 1021855 HEX BOLT M8 × 55 2 38 1123012 LOCK NUT M10 8 39 8210138 SPACER (OPTION) 2 40 8210137 TOGGLE CLAMP, BRAKE (OPTION) 1 41 1021630 HEX BOLT M6 X 30 4

Page 23

ICE i28BT / i32BT

PARTS LIST

SCRUB HEAD GROUP

Page 24

ICE i28BT / i32BT

PARTS LIST

SCRUB HEAD GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8210807 PIN 2 2 8210309 PIN, COTTER 2 3 1021825 HEX BOLT M8 × 25 11 4 8210830 BRACKET, SCRUB HEAD LIFT, RIGHT 1 5 1421816 FLAT WASHER M8×16×1.6 14 6 8210806 BRACKET, ACTUATOR MNTG 1 7 8210820 BRACKET, SCRUB HEAD LIFT, LEFT 1 8 1123810 LOCK NUT M8 10

8210899 BRUSH MOTOR, 24VDC, 550W, KIT 2

8210850 CARBON BRUSH 2 10 1655025 KEY, 5X5X25 2 11 8210803 SPACER, RUBBER 2 12 8210808 KNOB, M10 2 13 8210809 SPRING 2

8220801 HOUSING, SCRUB HEAD, i28BT 1

8210801 HOUSING, SCRUB HEAD, i32BT 1 15 1022090 HEX BOLT M10 × 90 2 16 1421612 FLAT WASHER M6×12×1.6 8 17 1422616 LOCK WASHER, M6 8 18 1021620 HEX BOLT M6 × 20 8 19 8210804 SPACER 4 20 8210805 HUB, BRUSH DRIVE 2 21 1421828 FLAT WASHER M8×28×3.0 2 22 1422821 LOCK WASHER M8 2

8220810 BUMPER, SCRUB HEAD, i28BT 2

8218050 BUMPER, SCRUB HEAD, i32BT 2 24 1221635 SCREW, M6 × 35 12 25 1221640 SCREW, M6 × 40 4 26 1421618 FLAT WASHER M6×18×1.6 4 27 8210861 RETAINER BAR 4 28 8210862 SPRING, G-400S 4 29 9000004 CLUTCH, G-400S 4

9050014 BRUSH ASSEMBLY, 14 INCH, i28BT, OPTION 2

9050016 BRUSH ASSEMBLY, 16 INCH, i32BT, OPTION 2 31 1321325 SELF-TAPPING SCREW, ST5 X 25 6 32 9000003 CENTER LOCK, #3 2 33 8116040 SPACER, 6.5×14.5×7.0 6

9040014 PAD DRIVER, 14INCH, i28BT 2

9040016 PAD DRIVER, 14INCH, i32BT 2 35 1111215 HEX NUT, M16 1 36 8210811 AJUSTMENT STUD, M16 1 37 8210810 BRACKET, ROLLER MNTG 1 38 1421824 FLAT WASHER M8×24×2 2 39 8115404 SLEEVE, P/M 1 40 8116009 PROTECTIVE WHEEL 1 41 1021830 HEX BOLT M8 × 30 1

Page 25

ICE i28BT / i32BT

PARTS LIST

SCRUB HEAD LIFT GROUP

Page 26

ICE i28BT / i32BT

PARTS LIST

SCRUB HEAD LIFT GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 1123810 LOCK NUT M8 6

2 1421824 FLAT WASHER M8×24×2 10

3 8210306 BRACKET, GUIDE MNTG 1

4 1021825 HEX BOLT M8×25 2

5 1422821 LOCK WASHER M8 4

6 1021820 HEX BOLT M8×20 2

7 8210311 SPRING 2

8 8210312 WASHER, PM 2

9 8210314 shaft 1

10 8210310 GUIDE, ROLLER 1

11 8210313 ROLLER 1

12 1022800 HEX BOLT M8 X 100 1

13 8210316 BRACKET, SCRUB LIFT 1

14 1123008 LOCK NUT 3/8 2

15 1022811 HEX BOLT M8 X 110 1

16 8210319 SPRING 2

17 8210317 BRACKET, SPRING 1

18 1421132 FLAT WASHER 12×32×1.5 4

19 8210322 PIN 1

20 8210309 PIN, COTTER 2

21 8210318 SPRING 2

22 8210320 SLEEVE 2

23 8210321 BOLT, SHOULDER, 3/8 2

24 8210302 ACTUATOR, 24VDC 1

25 8210301 PIN 1

26 8210303 BRACKET, ACTUATOR MNTG 1

27 1421612 FLAT WASHER M6×12×1.6 4

28 1422616 LOCK WASHER M6 4

29 1021616 HEX BOLT M6 X 16 4

Page 27

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 46.5 INCH, OLD STYLE, i32BT OPTION

Page 28

ICE i28BT / i32BT

PARTS LIST

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8210518 STAR KNOB M8 4

2 1021835 HEX BOLT M8×35 2

3 1421824 FLAT WASHER M8×24×2.0 2

4 8116009 PROTECTIVE WHEEL 2

5 8115404 BEARING, JOURNAL 2

6 1421816 FLAT WASHER M8×16×1.6 6

7 1021616 HEX BOLT M6×16 8

8 1421618 FLAT WASHER M6×18×1.6 8

9 8210515 BRACKET, ROLLER MNTG 2

10 8118300 RIGHT BRACKET 1

11 8210511 SQUEEGEE HOUSING 1

12 1123810 LOCK NUT M8 2

13 1121807 HEX NUT M8 4

14 1221575 SCREW M5×75 1

15 8210525 SHORT CLAMP ASSEBLY 1

16 8118624 SHAFT 1

17 8118623 SPACER 1

18 1123507 LOCK NUT M5 1

8210520 CLAMP ASSEMBLY, SQUEEGEE 1

8211520

CLAMP ASSEMBLY, SQUEEGEE(OPTION)

20 1022845 HEX BOLT M8×45 1

21 8210527 WHEEL, 2 INCH 1

22 1021860 HEX BOLT M8×60 4

23 1221516 SCREW M5×16 2

8210514 SQUEEGEE BLADE, REAR, LINATEX 1

8210517

SQUEEGEE BLADE, REAR, PU (OPTION)

25 8210512 RETAINER,SQUEEGEE 1

26 1021625 HEX BOLT M6×25 2

8210513 SQUEEGEE BLADE, FRONT, LINATEX 1

8210516

SQUEEGEE BLADE, FRONT, PU (OPTION)

28 8210519 CLAMP, FRONT BLADE 1

29 8210531 KNOB, M6 2

30 8210530 KNOB, M6 × 12 6

31 8118400 CASTER, 2 INCH 2

32 8118200 LEFT BRACKET 1

33 1121008 HEX NUT M10 2

34 8118109 HOLDER VACUUM HOSE 1

35 8118006 VACUUM HOSE 1

36 1962050 CLAMP 1

37 8210510 SQUEEGEE ASSEMBLY, 46.5 INCH 1

SQUEEGEE GROUP, 46.5 INCH, OLD STYLE, i32BT OPTION

Page 29

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 46.5 INCH, NEW STYLE, i32BT STANDARD

Page 30

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 46.5 INCH, NEW STYLE, i32BT STANDARD

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8210518 STAR KNOB M8 4

2 1021835 HEX BOLT M8×35 2

3 1421824 FLAT WASHER M8×24×2.0 2

4 8116009 PROTECTIVE WHEEL 2

5 8115404 BEARING, JOURNAL 2

6 1421816 FLAT WASHER M8×16×1.6 6

7 1021616 HEX BOLT M6×16 8

8 1421618 FLAT WASHER M6×18×1.6 8

9 8210515 BRACKET, ROLLER MNTG 2

10 8118300 RIGHT BRACKET 1

11 8230501 SQUEEGEE HOUSING 1

12 1123810 LOCK NUT M8 2

13 1221575 SCREW M5×75 1

14 8210525 SHORT CLAMP ASSEBLY 1

15 8118624 SHAFT 1

16 8118623 SPACER 1

17 1123507 LOCK NUT M5 1

18 1022845 HEX BOLT M8×45 1

19 8210527 WHEEL, 2 INCH 1

20 8210520 CLAMP ASSEMBLY, SQUEEGEE 1

8230504 SQUEEGEE BLADE, REAR, LINATEX 1

8230534 SQUEEGEE BLADE, REAR, PU (OPTION) 1

22 8230502 RETAINER,SQUEEGEE 1

8230503 SQUEEGEE BLADE, FRONT, LINATEX 1

8230513 SQUEEGEE BLADE, FRONT, PU (OPTION) 1

24 8118400 CASTER, 2 INCH 2

25 8118200 LEFT BRACKET 1

26 1121008 HEX NUT M10 2

27 8118109 HOLDER VACUUM HOSE 1

28 8118006 VACUUM HOSE 1

29 1962050 CLAMP 1

30 8230500

SQUEEGEE ASSEMBLY FOR i32BT, 46.5 INCH, STANDARD

Page 31

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 44.5 INCH, i32BT OPTION

Page 32

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 44.5 INCH, i32BT OPTION

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 1021835 HEX BOLT M8×35 2

2 1421824 FLAT WASHER M8×24×2.0 2

3 8116009 PROTECTIVE WHEEL 2

4 8115404 BEARING, JOURNAL 2

5 1121008 HEX NUT M10 2

6 8220501 SQUEEGEE HOUSING 1

7 8210518 STAR KNOB M8 2

8 1123810 LOCK NUT M8 2

9 1221575 SCREW M5×75 1

10 8210525 SHORT CLAMP ASSEBLY 1

11 8118624 SHAFT 1

12 8118623 SPACER 1

13 1123507 LOCK NUT M5 1

14 8220521 CLAMP ASSEMBLY, SQUEEGEE 1

8220513 SQUEEGEE BLADE, REAR, LINATEX 1

8220523

SQUEEGEE BLADE, REAR, PU (OPTION)

16 8118400 CASTER, 2 INCH 2

8220514 SQUEEGEE BLADE, FRONT, LINATEX 1

8220524

SQUEEGEE BLADE, FRONT, PU (OPTION)

18 8220518 FRONT CLAMP, LEFT 1

19 1121403 HEX NUT M4 1

20 1123406 LOCK NUT M4 1

21 1421409 FLAT WASHER M4×9×0.5 1

22 1211435 SCREW M4×35 1

23 8220515 FRONT CLAMP, LEFT 1

24 8118109 HOLDER VACUUM HOSE 1

25 8118006 VACUUM HOSE 1

26 1962050 CLAMP 1

27 8220500 SQUEEGEE ASSEMBLY, 44.5 INCH 1

Page 33

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 40.5 INCH, i28BT OPTION

Page 34

ICE i28BT / i32BT

PARTS LIST

SQUEEGEE GROUP, 40.5 INCH, i28BT OPTION

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 1123810 LOCK NUT M8 2

2 1421824 FLAT WASHER M8×∮24×2.0 4

3 8116009 PROTECTIVE WHEEL 2

4 8115404 BEARING, JOURNAL 2

5 1021616 HEX BOLT M6×16 2

6 1421612 FLAT WASHER M6×∮12×1.6 2

7 1121008 HEX NUT M10 2

8 8118300 RIGHT BRACKET 1

9 8310550 CASTER, 2 INCH 2

10 8310514 CLAMP ASSEMBLY 1

8310536 SQUEEGEE BLADE, REAR, LINATEX 1

8310546 SQUEEGEE BLADE, REAR, PU (OPTION) 1

12 8310511 SQUEEGEE HOSING 1

13 1021835 BOLT, HEX HEAD, M8×35 2

14 8310512 RETAINER, SQUEEGEE 1

8310535 SQUEEGEE BLADE, FRONT, LINATEX 1

8310545 SQUEEGEE BLADE, FRONT, PU (OPTION) 1

16 8210518 STAR KNOB M8 2

17 8118200 LEFT BRACKET 1

18 8210525 SHORT CLAMP ASSEBLY 1

19 1221575 SCREW M5×75 1

20 8118624 SHAFT 1

21 8118623 SPACER 1

22 1123507 LOCK NUT M5 1

23 8118109 HOLDER VACUUM HOSE 1

24 8118006 VACUUM HOSE 1

25 1962050 CLAMP 1

26 8310570 SQUEEGEE ASSEMBLY, 40.5 INCH 1

Page 35

ICE i28BT / i32BT

PARTS LIST

SOLUTION GROUP

Page 36

ICE i28BT / i32BT

PARTS LIST

SOLUTION GROUP

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

1 8119005 BALL VALVE, G1/2 1

2 8119007 ELBOW G1/2 1

3 8119006 CLAMP 5

4 8210901 TUBING ID=12MM L=330MM 2

8119100 FILTER ASSEMBLY, 70 MESH 1

8119200 FILTER ASSEMBLY, 40 MESH 1

6 8119101 BASE, FILTER ASSEMBLY 1

8119103 SCREEN, FILTER, 70 MESH 1

8119105

SCREEN, FILTER, 40 MESH (OPTIONAL)

8 1622760 O RING 1

9 8119102 CAP, FILTER ASSEMBLY 1

10 1421510 FLAT WASHER M5×10×1 2

11 1221512 SCREW M5×12 2

12 8210902 TUBING ID=12MM L=480MM 1

13 8119002 ELBOW, TUBING BARB 1

14 8210903 TUBING ID=12MM L=120MM 1

15 1962016 CLAMP, 10-16mm 5

16 1221412 SCREW M4×12 2

17 1422411 LOCK WASHER M4 2

18 1421409 FLAT WASHER M4×9×0.8 2

19 8119003 SOLENOID VALVE,24VDC 1

20 1914300 TIE, NYLON, 5X300 5

21 8210904 TUBING ID=10MM L=180MM 2

22 8119008 FITTING, PLASTIC, TEE 1

Page 37

ICE i28BT / i32BT

WEAR AND TEAR PARTS

DIA NO.

PART

NUMBER

DESCRIPTION

REQ'D

8125200 WHEEL, 8 INCH 2

8225200 AIR FILLED WHEEL, 8 INCH, KIT (OPTION) 2

8225210 FOAM FILLED WHEEL, 8INCH, KIT (OPTION) 2

2 8116009 PROTECTIVE WHEEL 3

8230503 SQUEEGEE BLADE, FRONT, LINATEX 1

8230513 SQUEEGEE BLADE, FRONT, PU (OPTION) 1

8210513 SQUEEGEE BLADE, FRONT, LINATEX (OPTION) 1

8210516 SQUEEGEE BLADE, FRONT, PU (OPTION) 1

8220514 SQUEEGEE BLADE, FRONT, LINATEX (OPTION) 1

8220524 SQUEEGEE BLADE, FRONT, PU (OPTION) 1

8310535 SQUEEGEE BLADE, FRONT, LINATEX 1

8310545 SQUEEGEE BLADE, FRONT, PU (OPTION) 1

8230504 SQUEEGEE BLADE, REAR, LINATEX 1

8230534 SQUEEGEE BLADE, REAR, PU (OPTION) 1

8210514 SQUEEGEE BLADE, REAR, LINATEX (OPTION) 1

8210517 SQUEEGEE BLADE, REAR, PU (OPTION) 1

8220513 SQUEEGEE BLADE, REAR, LINATEX (OPTION) 1

8220523 SQUEEGEE BLADE, REAR, PU (OPTION) 1

8310536 SQUEEGEE BLADE, REAR, LINATEX 1

8310546 SQUEEGEE BLADE, REAR, PU (OPTION) 1

9050014 14" BRUSH , i28BT (OPTION) 2

9050016 16" BRUSH , i32BT (OPTION) 2

9040014 14" PAD HOLDER, i28BT 2

9040016 16" PAD HOLDER, i32BT 2

Page 38

ICE i28BT / i32BT

WIRING DIAGRAM

BD: Driver motor circuit breaker

RV: Speed potentiometer

SW1: Control switch, forward

SW2: Control switch, backward

EB: Speed control board

M1: Traction motor

K: Relay

M3: Scrub head lifting motor

BR: Vacuum motor circuit breaker

M2: Vacuum motor

ML: Brush motor, left

MR: Brush motor, right

BAT: 4-6V Batteries

CHARGER: On board battery charger

BR1: Brake circuit breaker

KEY SW: Main power Key switch

HM: Hour meter

ES1: Brush motor solenoid switch

EW: Solution solenoid valve switch

ES2: Vacuum motor relay

PCB: Function electronic board

STOP SW: Emergency stop switch

MB: Electronmagnetic brake

LED1: Running lights

LED2: Emergency stop lights
