Product Specification
LC-SC 10G 50/125µm OM3 MM Duplex Fiber Optic Jumper
Package Includes
A. LC-SC 10G 50/125µm OM3 MM Duplex Fiber
Jumper, 1 pc.
B. Test Results Label, 1 pc.
Features and Benefits
Made from OFNR riser rated cables, exceeding industry requirements
Laser optimized fiber optic cable designed for 10 GHz applications
Made with ClearCurve*, Bend-insensitive multimode fiber (BIMMF)
Used with ICC fiber optic products
Available in 1, 2, 3, 5, 7, and 10 meters
Dust Cap Included
Test results included
*ClearCurve is a registered trademark of Corning*
Part No: ICFOJ2G7XX
Rev: A
Page 2 of 2
I 888-ASK-4ICC icc.com csr@icc.com I
© Copyright 2015, ICC. This document and the designs, specifications and information contained herein are the property of ICC. Reproduction, modification,
alteration or unauthorized use without ICC’s approval is strictly prohibited. ICC and the ICC logo are registered trade name and trademark of ICC. All rights reserved.
Product Specification
L
ITEM NUMBER
L (LENGTH)
ICFOJ2G701
1 METER ± 10 CM
ICFOJ2G702
2 METER ± 10 CM
ICFOJ2G703
3 METER ± 10 CM
ICFOJ2G705
5 METER ± 10 CM
ICFOJ2G707
7 METER ± 10 CM
ICFOJ2G710
10 METER ± 10 CM
NOTE: UNLESS OTHERWISE SPECIFIED
1. Cable:
A. Color: Aqua
B. Fiber Counts: 2 Fiber Zipcord
C. Fiber Type: Laser Optimized MM 50/125µm
D. Attenuation: 2.3/0.6 dB/km @ 850/1300 nm
E. Bandwidth: 2000 MHz.km EMB @ 850 nm
F. Cable Data:
Cable diameter: .079 in (2.0mm)
Weight: 12 lbs./kft
Bend radius: 1.2” MIN
Loading: 135 lbs. MAX
Impact cycle: 1500
2. LC Connector:
A. Ferrule: Zirconia
B. Insertion Loss: 0.2 dB Typical, 0.3 dB MAX
C. Reflection: N/A
3. LC Connector:
A. Ferrule: Zirconia
B. Insertion Loss: 0.2 dB Typical, 0.3 dB MAX
C. Reflection: N/A
4. Compliance:
A. ANSI/TIA-568-C.3
5. Length: XX: 01, 02, 03, 05, 07, & 10
