IBM System z10 Business Class (z10 BC) Reference Guide

April 2009

The New Face of Enterprise Computing

Table of Contents

IBM System z10 Business Class (z10 BC) Overview page 3

z/Architecture page 6

z10 BC page 11

z10 BC Design and Technology page 14

z10 BC Model page 15

z10 BC Performance page 17

z10 BC I/O Subsystem page 18

z10 BC Channels and I/O Connectivity page 19

HiperSockets page 34

Security page 36

Cryptography page 36

On Demand Capabilities page 41

Reliability, Availability, and Serviceability (RAS) page 45

Availability Functions page 46

Environmental Enhancements page 48

Parallel Sysplex Cluster Technology page 49

HMC System Support page 57

Implementation Services for Parallel Sysplex page 59

Fiber Quick Connect for FICON LX Environments page 60

z10 BC Physical Characteristics page 61

z10 BC Conﬁ guration Detail page 62

Coupling Facility – CF Level of Support page 64

Statement of Direction page 65

Publications page 66

IBM System z10 Business Class (z10 BC) Overview

In today’s world, IT is woven in to almost everything that

a business does and consequently is pivotal to a busi-

ness. Yet technology leaders are challenged to manage

sprawling, complex distributed infrastructures and the ever

growing ﬂ ow of data while remaining highly responsive to

the demands of the business. And they must continually

evaluate and decide when and how to adopt a multitude

of innovations to keep the company competitive. IBM has

a vision that can help—the Dynamic Infrastructure

—an

evolutionary model that helps reset the economics of IT

and can dramatically improve operational efﬁ ciency. It also

can help reduce and control rising costs and improve pro-

visioning speed and data center security and resiliency—at

any scale. It will allow you to be highly responsive to any

user need. And it aligns technology and business—giving

you the freedom and the tools you need to innovate and be

competitive. IBM System z

is an excellent choice as the

foundation for a highly responsive infrastructure.

New world. New business. A whole new mainframe. Meet

™

the IBM System z10

Business Class™ (z10 BC), the tech-

nology that could change the way you think about Enter-

prise solutions. The technology that delivers the scalability,

ﬂ exibility, virtualization, and breakthrough performance

you need—at the lower capacity entry point you want.

This is the technology that ﬁ ghts old myths and percep-

tions—that’s not just for banks and insurance companies.

This is the technology for any business that wants to ramp

up innovation, boost efﬁ ciencies and lower costs—pretty

much any enterprise, any size, any location. This is a

mainframe technology for a new kind of data center—resil-

™

ient, responsive, energy efﬁ cient—this is z10

BC. And

it’s about to rewrite the rules and deliver new freedoms for

your business. Whether you want to deploy new applica-

tions quickly, grow your business without growing IT costs

or consolidate your infrastructure for reduced complexity,

look no further—

Think Big, Virtually Limitless

The Information Technology industry has recognized the

business value of exploiting virtualization technologies on

any and all server platforms. The leading edge virtualization

capabilities of System z, backed by over 40 years of tech-

nology innovation, are the most advanced in the industry.

With utilization rates of up to 100%, it’s the perfect platform

for workload consolidation, both traditional and new.

• Want to deploy dozens—or hundreds—of applications

on a single server for lower total cost of ownership? Want

a more simpliﬁ ed, responsive infrastructure?

• Want investment protection where new generation tech-

nology typically allows application growth at no extra

cost?

The virtualization technology found in z/VM

with the

System z platform may help clients achieve all of these

operational goals while also helping to maximize the ﬁ nan-

cial return on their System z investments.

™

The z10 BC

can have big advantages over traditional

server farms. The z10 BC is designed to reduce energy

usage and save ﬂ oor space when used to consolidate x86

servers. With increased capacity the z10 BC virtualization

capabilities can help to support hundreds of virtual servers

in a single 1.42 square meters footprint. When consolidat-

ing on System z you can create virtual servers on demand;

™

achieve network savings through HiperSockets

(internal

LAN); improve systems management of virtual servers;

and most importantly, consolidate software from many dis-

tributed servers to a single consolidated server.

So why run hundreds of standalone servers when z10 BC

could do the work more efﬁ ciently, in a smaller space, at a

lower cost, virtually? Less power. Less space. Less impact

on the environment.

z Can Do IT

More Solutions, More Affordable

Today’s businesses with extensive investments in hardware

assets and core applications are demanding more from

IT—more value, more transactions, more for the money.

Above all, they are looking for business solutions that can

help enable business growth while driving costs out of the

business. System z has an ever growing set of solutions

that are being enhanced to help you lower IT costs. From

enterprise wide applications such as SAP or Cognos

to the consolidation of infrastructure workloads, z10 BC

has low cost solutions that also help you save more as

your demand grows. So, consider consolidating your IT

workloads on the z10 BC server if you want the right solu-

tions on a premier platform at a price you can afford.

The convergence of Service-Oriented Architecture (SOA)

and mainframe technologies can also help liberate these

core business assets by making it easier to enrich, mod-

ernize, extend and reuse them well beyond their original

scope of design. The ultimate implementation of ﬂ exibility

for today’s On Demand Business is a Service Oriented

Architecture—an IT architectural style that allows you to

design your applications to solve real business problems.

The z10 BC, along with the inherent strengths and capa-

bilities of multiple operating system choices and innovative

System z software solutions from WebSphere

Rational

and Lotus® strengthen the ﬂ exibility of doing SOA

, CICS®,

and strengthen System z as an enterprise hub.

Special workloads, Specialty engines, affordable technology

The z10 BC continues the long history of providing inte-

grated technologies to optimize a variety of workloads. The

use of specialty engines can help users expand the use

of the mainframe for new workloads, while helping to lower

the cost of ownership. The IBM System z specialty engines

can run independently or complement each other. For

example, the zAAP and zIIP processors enable you to

purchase additional processing capacity exclusively for

speciﬁ c workloads, without affecting the MSU rating of the

IBM System z model designation. This means that adding

a specialty engine will not cause increased charges for

IBM System z software running on general purpose pro-

cessors in the server.

In order of introduction:

The Internal Coupling Facility (ICF) processor was intro-

duced to help cut the cost of Coupling Facility functions

by reducing the need for an external Coupling Facility.

IBM System z Parallel Sysplex

technology allows for

greater scalability and availability by coupling mainframes

together. Using Parallel Sysplex clustering, System z serv-

ers are designed for up to 99.999% availability.

The Integrated Facility for Linux

(IFL) processor offers

support for Linux and brings a wealth of available appli-

cations that can be run in a real or virtual environment

™

on the z10 BC. An example is the z/VSE

strategy which

supports integration between the IFL, z/VSE and Linux on

System z to help customers integrate timely production

of z/VSE data into new Linux applications, such as data

warehouse environments built upon a DB2

data server. To

consolidate distributed servers onto System z, the IFL with

Linux and the System z virtualization technologies fulﬁ ll the

qualiﬁ cations for business-critical workloads as well as for

infrastructure workloads. For customers interested to use a

z10 BC only for Linux workload, the z10 BC can be conﬁ g-

ured as a server with IFLs only.

The System z10 Application Assist Processor (zAAP) is

designed to help enable strategic integration of new appli-

™

cation technologies such as Java

technology-based Web

applications and XML-based data interchange services

with core business database environments. This helps

provide a more cost-effective, specialized z/OS® applica-

tion Java execution environment. Workloads eligible for the

zAAP (with z/OS V1.8) include all Java processed via the

IBM Solution Developers Kit (SDK) and XML processed

locally via z/OS XML System Services.

The System z10 Integrated Information Processor (zIIP) is

designed to support select data and transaction process-

ing and network workloads and thereby make the consoli-

dation of these workloads on to the System z platform

more cost effective. Workloads eligible for the zIIP (with

z/OS V1.7 or later) include remote connectivity to DB2

to help support these workloads: Business Intelligence

(BI), Enterprise Relationship Management (ERP), Customer

Relationship Management (CRM) and Extensible Markup

Language (XML) applications. In addition to supporting

remote connectivity to DB2 (via DRDA

over TCP/IP) the

zIIP also supports DB2 long running parallel queries—a

workload integral to Business Intelligence and Data Ware-

housing solutions. The zIIP (with z/OS V1.8) also supports

IPSec processing, making the zIIP an IPSec encryption

engine helpful in creating highly secure connections

in an enterprise. In addition, zIIP (with z/OS V1.10) sup-

ports select z/OS Global Mirror (formerly called Extended

Remote Copy, XRC) disk copy service functions. z/OS

V1.10 also introduces zIIP Assisted HiperSockets for large

messages (available on System z10 servers only).

The New Face Of System z

IBM’s mainframe capabilities are legendary. Customers

deploy systems that remain available for years because

they are expected to, and continue to, work above expec-

tations. However, these systems have seen signiﬁ cant

innovative improvements for running new applications and

consolidating workloads in the last few years, and custom-

ers can see real gains in price/performance by taking

advantage of this new technology.

IBM provides affordable world-class technology to help

today’s enterprises respond to business conditions quickly

and with ﬂ exibility. From automation to advanced virtualiza-

tion technologies to new applications supported by open

industry standards such as SOA, IBM servers teamed with

IBM’s Storage Systems, Global Technology Services and

IBM Global Financing help deliver competitive advantages

for a Dynamic Infrastructure.

z Can Do IT. The future runs on IBM System z and the

future begins today!

The new capability provided with z/VM-Mode partitions

increases ﬂ exibility and simpliﬁ es systems management by

allowing z/VM 5.4 to manage guests to operate Linux on

System z on IFLs, to operate z/VSE and z/OS on CPs,

to ofﬂ oad z/OS system software overhead, such as DB2

workloads on zIIPs, and to offer an economical Java exe-

cution environment under z/OS on zAAPs, all in the same

z/VM LPAR.

z/Architecture

The z10 BC continues the line of upward compatible main-

frame processors and retains application compatibility

since 1964. The z10 BC supports all z/Architecture

-com-

pliant Operating Systems. The heart of the processor unit

is the IBM z10 Enterprise Quad Core processor chip run-

ning at 3.5 GHz, designed to help improve CPU intensive

workloads.

The z10 BC, like its predecessors, supports 24, 31,

and 64-bit addressing, as well as multiple arithmetic for-

mats. High-performance logical partitioning via Processor

™

Resource/Systems Manager

(PR/SM™) is achieved by

industry-leading virtualization support provided by z/VM.

A change to the z/Architecture on z10 BC is designed

to allow memory to be extended to support large (1 mega-

byte (MB)) pages. Use of large pages can improve CPU

utilization for exploiting applications.

Large page support is primarily of beneﬁ t for long-running

applications that are memory-access-intensive. Large

page is not recommended for general use. Short-lived

processes with small working sets are normally not good

candidates for large pages.

Large page support is exclusive to System z10 running

either z/OS or Linux on System z.

z10 BC Architecture

Rich CISC Instruction Set Architecture (ISA)

• 894 instructions (668 implemented entirely in hardware)

• Multiple address spaces robust inter-process security

• Multiple arithmetic formats

Architectural extensions for z10 BC

• 50+ instructions added to z10 BC to improve compiled

code efﬁ ciency

• Enablement for software/hardware cache optimization

• Support for 1 MB page frames

• Full hardware support for Hardware Decimal Floating-

point Unit (HDFU)

z/Architecture operating system support

Delivering the technologies required to address today’s

IT challenges also takes much more than just a server;

it requires all of the system elements to be working

together. IBM System z10 operating systems and servers

are designed with a collaborative approach to exploit each

other’s strengths.

The z10 BC is also able to exploit numerous operating sys-

tems concurrently on a single server, these include z/OS,

z/VM, z/VSE, z/TPF, TPF and Linux for System z. These

operating systems are designed to support existing appli-

cation investments without anticipated change and help

you realize the beneﬁ ts of the z10 BC. z10 BC—the new

business equation.

z/OS

August 5, 2008, IBM announced z/OS V1.10. This release

of the z/OS operating system builds on leadership capa-

bilities, enhances time-tested technologies, and leverages

deep synergies with the IBM System z10 and IBM System

™

Storage

family of products. z/OS V1.10 supports new

capabilities designed to provide:

• Storage scalability. Extended Address Volumes (EAVs)

enable you to deﬁ ne volumes as large as 223 GB to

relieve storage constraints and help you simplify storage

management by providing the ability to manage fewer,

large volumes as opposed to many small volumes.

• Application and data serving scalability. Up to 64

engines, up to 1.5 TB per server with up to 1.0 TB of

real memory per LPAR, and support for large (1 MB)

pages on the System z10 can help provide scale and

performance for your critical workloads.

• Intelligent and optimized dispatching of workloads.

HiperDispatch can help provide increased scalability

and performance of higher n-way System z10 systems

by improving the way workload is dispatched within the

server.

• Low-cost, high-availability disk solution. The Basic

HyperSwap

™

capability (enabled by TotalStorage®

Productivity Center for Replication Basic Edition

for System z) provides a low-cost, single-site, high-

availability disk solution which allows the conﬁ guration

of disk replication services using an intuitive browser-

based graphical user interface (GUI) served from z/OS.

• Improved total cost of ownership. zIIP-Assisted

HiperSockets for Large Messages, IBM Scalable

Architecture for Financial Reporting

™

enabled for zIIP (a

service offering of IBM Global Business Services), zIIP-

Assisted z/OS Global Mirror (XRC), and additional z/OS

XML System Services exploitation of zIIP and zAAP help

make these workloads more attractive on System z.

Improved management of temporary processor capac-

•

ity. Capacity Provisioning Manager which is available

on z/OS V1.10, and on z/OS V1.9 with PTFs, can monitor

z/OS systems on System z10 servers. Activation and

deactivation of temporary capacity can be suggested or

performed automatically based on user-deﬁ ned sched-

™

ules and workload criteria. RMF

or equivalent function is

required to use the Capacity Provisioning Manager.

• Improved network security. z/OS Communications Server

introduces new defensive ﬁ ltering capability. Defensive

ﬁ lters are evaluated ahead of conﬁ gured IP ﬁ lters, and

can be created dynamically, which can provide added

protection and minimal disruption of services in the

event of an attack.

• z/OS V1.10 also supports RSA key, ISO Format-3 PIN

block, 13-Digit through 19-Digit PAN data, secure key

AES, and SHA algorithms.

• Improved productivity. z/OS V1.10 provides improve-

ments in or new capabilities for: simplifying diagnosis

and problem determination; expanded Health Check

Services; network and security management; automatic

dump and re-IPL capability; as well as overall z/OS, I/O

conﬁ guration, sysplex, and storage operations

With z/OS 1.9, IBM delivers functionality that continues to

solidify System z leadership as the premier data server.

z/OS 1.9 offers enhancements in the areas of security, net-

working, scalability, availability, application development,

integration, and improved economics with more exploita-

tion for specialty engines. A foundational element of the

platform — the z/OS tight interaction with the System z

hardware and its high level of system integrity.

With z/OS 1.9, IBM introduces:

• A revised and expanded Statement of z/OS System

Integrity

• Large Page Support (1 MB)

• Capacity Provisioning

• Support for up to 64 engines in a single image (on

IBM System z10 Enterprise Class (z10 EC

™

) model only)

• Simpliﬁ ed and centralized policy-based networking

• Expanded IBM Health Checker

• Simpliﬁ ed RACF

Administration

• Hardware Decimal Floating Point

• Parallel Sysplex support for Inﬁ niBand

Coupling Links

• NTP Support for STP

• HiperSockets Multiple Write Facility

• OSA-Express3 support

• Advancements in ease of use for both new and existing

IT professionals coming to z/OS

• Support for zIIP-assisted IPSec, System Data Mover

(SDM) ofﬂ oad to zIIP, and support for eligible portions of

DB2 9 XML parsing workloads to be ofﬂ oaded to zAAP

processors

• Expanded options for AT-TLS and System SSL network

security

• Improved creation and management of digital certiﬁ -

cates with RACF, SAF, and z/OS PKI Services

• Additional centralized ICSF encryption key management

functions for applications

• Improved availability with Parallel Sysplex and Coupling

Facility improvement

• Enhanced application development and integration with

new System REXX™ facility, Metal C facility, and z/OS

System Services commands

UNIX

• Enhanced Workload Manager in managing discretionary

work and zIIP and zAAP workloads

Commitment to system integrity

™

First issued in 1973, IBM’s MVS

ment and subsequent statements for OS/390

System Integrity State-

and z/OS

stand as a symbol of IBM’s conﬁ dence and commitment

to the z/OS operating system. Today, IBM reafﬁ rms its com-

mitment to z/OS system integrity.

IBM’s commitment includes designs and development

practices intended to prevent unauthorized application

programs, subsystems, and users from bypassing z/OS

security—that is, to prevent them from gaining access,

circumventing, disabling, altering, or obtaining control of

key z/OS system processes and resources unless allowed

by the installation. Speciﬁ cally, z/OS “System Integrity” is

deﬁ ned as the inability of any program not authorized by

a mechanism under the installation’s control to circumvent

or disable store or fetch protection, access a resource

protected by the z/OS Security Server (RACF), or obtain

control in an authorized state; that is, in supervisor state,

with a protection key less than eight (8), or Authorized

Program Facility (APF) authorized. In the event that an IBM

System Integrity problem is reported, IBM will always take

action to resolve it.

IBM’s long-term commitment to System Integrity is unique

in the industry, and forms the basis of the z/OS industry

leadership in system security. z/OS is designed to help you

protect your system, data, transactions, and applications

from accidental or malicious modiﬁ cation. This is one of

the many reasons System z remains the industry’s premier

data server for mission-critical workloads.

z/VM

z/VM V5.4 is designed to extend its System z virtualization

technology leadership by exploiting more capabilities of

System z servers including:

• Greater ﬂ exibility, with support for the new z/VM-mode

logical partitions, allowing all System z processor-types

(CPs, IFLs, zIIPs, zAAPs, and ICFs) to be deﬁ ned in

the same z/VM LPAR for use by various guest operating

systems

• Capability to install Linux on System z as well as z/VM

from the HMC on a System z10 that eliminates the need

for any external network setup or a physical connection

between an LPAR and the HMC

• Enhanced physical connectivity by exploiting all OSA-

Express3 ports, helping service the network and reduc-

ing the number of required resources

• Dynamic memory upgrade support that allows real

memory to be added to a running z/VM system. With z/VM

V5.4, memory can be added nondisruptively to individual

guests that support the dynamic memory reconﬁ guration

architecture. Systems can now be conﬁ gured to reduce

the need to re-IPL z/VM. Processors, channels, OSA

adapters, and now memory can be dynamically added to

both the z/VM system itself and to individual guests.

The operation and management of virtual machines

has been enhanced with new systems management

APIs, improvements to the algorithm for distributing a

guest’s CPU share among virtual processors, and usability

enhancements for managing a virtual network.

Security capabilities of z/VM V5.4 provide an upgraded

LDAP server at the functional level of the z/OS V1.10 IBM

Directory Server for z/OS and enhancements to the

Tivoli

RACF Security Server to create LDAP change log entries

in response to updates to RACF group and user proﬁ les,

including user passwords and password phrases. The z/VM

SSL server now operates in a CMS environment, instead of

requiring a Linux distribution, thus allowing encryption ser-

vices to be deployed more quickly and helping to simplify

installation, service, and release-to-release migration.

The z/VM hypervisor is designed to help clients extend the

business value of mainframe technology across the enter-

prise by integrating applications and data while providing

exceptional levels of availability, security, and operational

ease. z/VM virtualization technology is designed to provide

the capability for clients to run hundreds to thousands of

Linux servers in a single mainframe, together with other

System z operating systems such as z/OS, or as a large-

scale Linux-only enterprise-server solution. z/VM V5.4 can

also help to improve productivity by hosting non-Linux

workloads such as z/OS, z/VSE, and z/TPF.

August 5, 2008, IBM announced z/VM 5.4. Enhancements

in z/VM 5.4 include:

z/VSE 4.1 is designed to support:

• z/Architecture mode only

• 64-bit real addressing and up to 8 GB of processor

storage

• System z encryption technology including CPACF, con-

ﬁ gurable Crypto Express2, and TS1120 encrypting tape

• Midrange Workload License Charge (MWLC) pricing,

including full-capacity and sub-capacity options

IBM has previewed z/VSE 4.2. When available, z/VSE 4.2

is designed to help address the needs of VSE clients with

growing core VSE workloads. z/VSE V4.2 is designed to

support:

• Increased ﬂ exibility with support for new z/VM-mode

logical partitions

• Dynamic addition of memory to an active z/VM LPAR

by exploiting System z dynamic storage-reconﬁ guration

capabilities

• Enhanced physical connectivity by exploiting all OSA-

Express3 ports

• Capability to install Linux on System z from the HMC

without requiring an external network connection

• Enhancements for scalability and constraint relief

• Operation of the SSL server in a CMS environment

• Systems management enhancements for Linux and

other virtual images

For the most current information on z/VM, refer to the z/VM

Web site at http://www.vm.ibm.com.

z/VSE

z/VSE 4.1, the latest advance in the ongoing evolution of

VSE, is designed to help address needs of VSE clients

with growing core VSE workloads and/or those who wish

to exploit Linux on System z for new, Web-based business

solutions and infrastructure simpliﬁ cation.

• More than 255 VSE tasks to help clients grow their CICS

workloads and to ease migration from CS/VSE to CICS

Transaction Server for VSE/ESA

™

• Up to 32 GB of processor storage

• Sub-Capacity Reporting Tool running “natively”

•

Encryption Facility for z/VSE as an optional priced feature

• IBM System Storage TS3400 Tape Library (via the

TS1120 Controller)

• IBM System Storage TS7740 Virtualization Engine

Release 1.3

z/VSE V4.2 plans to continue the focus on hybrid solutions

exploiting z/VSE and Linux on System z, service-oriented

architecture (SOA), and security. It is the preferred replace-

ment for z/VSE V4.1, z/VSE V3, or VSE/ESA. It is designed

to protect and leverage existing VSE information assets.

z/TPF

z/TPF is a 64-bit operating system that allows you to move

legacy applications into an open development environ-

ment, leveraging large scale memory spaces for increased

diagnostics and functionality. The open develop-

speed,

ment environment allows access to commodity skills and

enhanced access to open code libraries, both of which

can be used to lower development costs. Large memory

spaces can be used to increase both system and appli-

cation efﬁ ciency as I/Os or memory management can be

eliminated.

z/TPF is designed to support:

• 64-bit mode

• Linux development environment (GCC and HLASM for

Linux)

• 32 processors/cluster

• Up to 84* engines/processor

• 40,000 modules

• Workload License Charge

Linux on System z

The System z10 BC supports the following Linux on

System z distributions (most recent service levels):

• Novell SUSE SLES 9

• Novell SUSE SLES 10

• Red Hat RHEL 4

• Red Hat RHEL 5

Operating System ESA/390 z/Architecture (31-bit) (64-bit)

z/OS V1R8, 9 and 10 No Yes

z/OS V1R7

(1)(2)

with BM Lifecycle

Extension for z/OS V1.7 No Yes

Linux on System z

(2)

, Red Hat

RHEL 4, & Novell SUSE SLES 9 Yes Yes

Linux on System z

(2)

, Red Hat

RHEL 5, & Novell SUSE SLES 10 No Yes

(3)

z/VM V5R2

z/VSE V3R1

z/VSE V4R1

(3)

, 3

and 4 No* Yes

(2)(4)

(2)(5)

and 2

(5)

Yes No

No Yes

z/TPF V1R1 No Yes

TPF V4R1 (ESA mode only) Yes No

1. z/OS V1.7 support on the z10 BC requires the Lifecycle Extension for

z/OS V1.7, 5637-A01. The Lifecycle Extension for z/OS R1.7 + zIIP Web Deliverable required for z10 to enable HiperDispatch on z10 (does not require a zIIP). z/OS V1.7 support was withdrawn September 30, 2008. The Lifecycle Extension for z/OS V1.7 (5637-A01) makes fee-based corrective service for z/OS V1.7 available through September 2009. With this Lifecycle Extension, z/OS V1.7 supports the z10 BC server. Certain functions and features of the z10 BC server require later releases of z/OS. For a complete list of software support, see the PSP buckets and the Software Requirements section of the z10 BC announcement letter, dated October 21, 2008.

2. Compatibility Support for listed releases. Compatibility support allows OS to IPL and operate on z10 BC.

3. Requires Compatibility Support which allows z/VM to IPL and operate on the System z10 providing IBM System z9 and Guests. *z/VM supports 31-bit and 64-bit guests.

4. z/VSE V3 31-bit mode only. It does not implement z/Architecture, and speciﬁ cally does not implement 64-bit mode capabilities. z/VSE is designed to exploit select features of System z10, System z9, and IBM

™

eServer

5. z/VSE V4 is designed to exploit 64-bit real memory addressing, but will

Note: Refer to the z/OS, z/VM, z/VSE subsets of the 2098DEVICE Preventive Planning (PSP) bucket prior to installing a z10 BC.

zSeries® hardware.

not support 64-bit virtual memory addressing.

functionality for the base OS

z10 BC

The IBM System z10 Business Class (z10 BC) delivers

innovative technologies for small and medium enter-

prises that give you a whole new world of capabilities

to run modern applications. Ideally suited in a Dynamic

Infratructure, this competitively priced server delivers

unparalleled qualities of service to help manage growth

and reduce cost and risk in your business.

The z10 BC further extends the leadership of System z by

delivering expanded granularity and optimized scalability

for growth, enriched virtualization technology for consoli-

dation of distributed workloads, improved availability and

security to help increase business resiliency, and just-in-

time management of resources. The z10 BC is at the core

of the enhanced System z platform and is the new face

of System z.

The z10 BC has the machine type of 2098, with one model

(E10) offering between one to ten conﬁ gurable Processor

Units (PUs). This model design offers increased ﬂ exibility

over the two model IBM System z9 Business Class (z9® BC)

by delivering seamless growth within a single model, both

temporary and permanent.

The z10 BC delivers improvements in both the granular

increments and total scalability compared to previous

System z midrange servers, achieved by both increasing

the performance of the individual PU as well as increasing

the number of PUs per server. The z10 BC Model E10 is

designed to provide up to 1.5 times the total system capac-

ity for general purpose processing, and over 40% more

conﬁ gurable processors than the z9 BC Model S07.

The z10 BC advances the innovation of the System z10

platform and brings value to a wider audience. It is built

using a redesigned air cooled drawer package which

replaces the prior “book” concept in order to reduce cost

and increase ﬂ exibility. A redesigned I/O drawer offers

higher availability and can be concurrently added or

replaced when at least two drawers are installed. Reduced

capacity and priced I/O features will continue to be offered

on the z10 BC to help lower your total cost of acquisition.

The quad core design z10 processor chip delivers higher

frequency and will be introduced at 3.5 GHz which can

help improve the execution of CPU intensive workloads on

the z10 BC. These design approaches facilitate the high-

availability, dynamic capabilities and lower cost that differ-

entiate this z10 BC from other servers.

The z10 BC supports from 4 GB up to 248 GB of real

customer memory. This is almost four times the maximum

memory available on the z9 BC. The increased available

memory on the server can help to beneﬁ t workloads that

perform better with larger memory conﬁ gurations, such

as DB2, WebSphere and Linux. In addition to the cus-

tomer purchased memory, an additional 8 GB of memory

is included for the Hardware System Area (HSA). The

HSA holds the I/O conﬁ guration data for the server and is

entirely fenced from customer memory.

High speed connectivity and high bandwidth out to the

data and the network are critical in achieving high levels of

transaction throughput and enabling resources inside and

outside the server to maximize application requirements.

The z10 BC has a host bus interface with a link data rate

of 6 GB using the industry standard Inﬁ niBand protocol to

help satisfy requirements for coupling (ICF and server-to-

server connectivity), cryptography (Crypto Express2 with

secure coprocessors and SSL transactions), I/O (ESCON

FICON

or FCP) and LAN (OSA-Express3 Gigabit, 10

Gigabit and 1000BASE-T Ethernet features). High Perfor-

mance FICON for System z (zHPF) also brings new levels

of performance when accessing data on enabled storage

™

devices such as the IBM System Storage DS8000

PUs deﬁ ned as Internal Coupling Facilities (ICFs), Inte-

grated Facility for Linux (IFLs), System z10 Application

Assist Processor (zAAPs) and System z10 Integrated Infor-

mation Processor (zIIPs) are no longer grouped together in

one pool as on the IBM eServer

™

zSeries® 890 (z890), but

are grouped together in their own pool, where they can be

managed separately. The separation signiﬁ cantly simpli-

ﬁ es capacity planning and management for LPAR and can

have an effect on weight management since CP weights

and zAAP and zIIP weights can now be managed sepa-

rately. Capacity BackUp (CBU) features are available for

IFLs, ICFs, zAAPs and zIIPs.

LAN connectivity has been enhanced with the introduction

of the third generation of Open Systems Adapter-Express

(OSA-Express3). This new family of LAN adapters have

been introduced to reduce latency and overhead, deliver

double the port density of OSA-Express2 and provide

increased throughput. The z10 BC continues to support

OSA-Express2 1000BASE-T and GbE Ethernet features,

supports IP version 6 (IPv6) on HiperSockets. While

and

OSA-Express2 OSN (OSA for NCP) is still available on

System z10 BC to support the Channel Data Link Control

(CDLC) protocol, the OSA-Express3 will also provide this

function.

Additional channel and networking improvements include

support for Layer 2 and Layer 3 trafﬁ c, FCP management

facility for z/VM and Linux for System z, FCP security

improvements, and Linux support for HiperSockets IPv6.

STP enhancements include the additional support for NTP

clients and STP over Inﬁ niBand links.

Like the System z9 BC, the z10 BC offers a conﬁ gurable

Crypto Express2 feature, with PCI-X adapters that can

be individually conﬁ gured as a secure coprocessor or

an accelerator for SSL, the TKE workstation with optional

Smart Card Reader, and provides the following CP Assist

for Cryptographic Function (CPACF):

• DES, TDES, AES-128, AES-192, AES-256

• SHA-1, SHA-224, SHA-256, SHA-384, SHA-512

• Pseudo Random Number Generation (PRNG)

z10 BC is designed to deliver the industry leading Reli-

ability, Availability and Serviceability (RAS) customers

expect from System z servers. RAS is designed to

reduce all sources of outages by reducing unscheduled,

scheduled and planned outages. Planned outages are

further designed to be reduced by reducing preplanning

requirements.

z10 BC preplanning improvements are designed to avoid

planned outages and include:

• Reduce pre-planning to avoid POR

– “Fixed” HSA amount

– Dynamic I/O enabled by default

– Add Logical Channel Subsystem (LCSS)

– Change LCSS Subchannel Sets

– Add/Delete logical partitions

• Reduce pre-planning to avoid LPAR deactivate

– Change partition logical processor conﬁ guration

– Change partition crypto coprocessor conﬁ guration

• CoD – Flexible activation/deactivation

• Elimination of unnecessary CBU passwords

• Enhanced Driver Maintenance (EDM) upgrades

– Multiple “from” sync point support

– Improved control of channel LIC levels

• Plan ahead memory

• Concurrent I/O drawer add/repair

Additionally, several service enhancements have also

been designed to avoid unscheduled outages and include

continued focus on ﬁ rmware quality, reduced chip count

on Single Chip Module (SCM) and memory subsystem

improvements. In the area of scheduled outage enhance-

ments include redundant 100Mb Ethernet service network

with VLAN, rebalance of PSIFB and I/O fanouts, and single

processor core sparing and checkstop. Exclusive to the

System z10 is the ability to hot swap ICB-4 and Inﬁ niBand

hub cards.

Enterprises with IBM System z9 BC and IBM z890

may upgrade to any z10 Business Class model. Model

upgrades within the z10 BC are concurrent. If you desire

a consolidation platform for your mainframe and Linux

capable applications, you can add capacity and even

expand your current application workloads in a cost-effec-

tive manner. If your traditional and new applications are

growing, you may ﬁ nd the z10 BC a good ﬁ t with its base

qualities of service and its specialty processors designed

for assisting with new workloads. Value is leveraged with

improved hardware price/performance and System z10 BC

software pricing strategies.

The z10 BC is speciﬁ cally designed and optimized for

full z/Architecture compatibility. New features enhance

enterprise data serving performance, industry leading

virtualization capabilities, energy efﬁ ciency at system

and data center levels. The z10 BC is designed to further

extend and integrate key platform characteristics such as

dynamic ﬂ exible partitioning and resource management in

mixed and unpredictable workload environments, provid-

ing scalability, high availability and Qualities of Service

(QoS) to emerging applications such as WebSphere, Java

and Linux.

With the logical partition (LPAR) group capacity limit on

z10 BC, z10 EC, z9 EC and z9 BC, you can now specify

LPAR group capacity limits allowing you to deﬁ ne each

LPAR with its own capacity and one or more groups of

LPARs on a server. This is designed to allow z/OS to

manage the groups in such a way that the sum of the

LPARs’ CPU utilization within a group will not exceed the

group’s deﬁ ned capacity. Each LPAR in a group can still

optionally continue to deﬁ ne an individual LPAR capacity

limit.

The z10 BC has one model with a total of 130 capacity

settings available as new build systems and as upgrades

from the z9 BC and z890.

The z10 BC model is designed with a Central Processor

Complex (CPC) drawer with Single Chip Modules (SCM)

that provides up to 10 Processor Units (PUs) that can

be characterized as either Central Processors (CPs), IFLs,

ICFs, zAAPs or zIIPs.

Some of the signiﬁ cant enhancements in the z10 BC that

help bring improved performance, availability and function

to the platform have been identiﬁ ed. The following sections

highlight the functions and features of the z10 BC.

z10 BC Design and Technology

The System z10 BC is designed to provide balanced

system performance. From processor storage to the

system’s I/O and network channels, end-to-end bandwidth

is provided and designed to deliver data where and when

it is needed.

The processor subsystem is comprised of one CPC, which

houses the processor units (PUs), Storage Controllers

(SCs), memory, Self-Time-Interconnects (STI)/Inﬁ niBand

(IFB) and Oscillator/External Time Reference (ETR). The

z10 BC design provides growth paths up to a 10 engine

system where each of the 10 PUs has full access to all

system resources, speciﬁ cally memory and I/O.

The z10 BC uses the same processor chip as the z10 EC,

relying only on 3 out of 4 functional cores per chip. Each

chip is individually packaged in an SCM. Four SCMs will

be plugged in the processor board providing the 12 PUs

for the design. Clock frequency will be 3.5 GHz.

There are three active cores per PU, an L1 cache divided

into a 64 KB cache for instructions and a 128 KB cache for

data. Each PU also has an L1.5 cache. This cache is 3 MB

in size. Each L1 cache has a Translation Look-aside Buffer

(TLB) of 512 entries associated with it. The PU, which uses

a high-frequency z/Architecture microprocessor core, is

built on CMOS 11S chip technology and has a cycle time

of approximately 0.286 nanoseconds.

The PU chip includes data compression and crypto-

graphic functions. Hardware data compression can play a

signiﬁ cant role in improving performance and saving costs

over doing compression in software. Standard clear key

cryptographic processors right on the processor translate

to high-speed cryptography for protecting data in storage,

integrated as part of the PU.

Speed and precision in numerical computing are important

for all our customers. The z10 BC offers improvements

for decimal ﬂ oating point instructions, because each z10

processor chip has its own hardware decimal ﬂ oating

point unit, designed to improve performance over that

provided by the System z9. Decimal calculations are often

used in ﬁ nancial applications and those done using other

ﬂ oating point facilities have typically been performed by

software through the use of libraries. With a hardware

decimal ﬂ oating point unit some of these calculations may

be done directly and accelerated.

The design of the z10 BC provides the ﬂ exibility to con-

ﬁ gure the PUs for different uses; There are 12 PUs per

system, two are designated as System Assist Processors

(SAPs) standard per system. The remaining 10 PUs are

available to be characterized as either CPs, ICF proces-

sors for Coupling Facility applications, or IFLs for Linux

applications and z/VM hosting Linux as a guest, System

z10 Application Assist Processors (zAAPs), System z10

Integrated Information Processors (zIIPs) or as optional

SAPs and provide you with tremendous ﬂ exibility in estab-

lishing the best system for running applications.

The z10 BC can support from the 4 GB minimum memory

up to 248 GB of available real memory per server for grow-

ing application needs. A new 8 GB ﬁ xed HSA which is

managed separately from customer memory. This ﬁ xed

HSA is designed to improve availability by avoiding out-

ages that were necessary on prior models to increase its

size. There are up to 12 I/O interconnects per system at 6

GBps each.

The z10 BC supports a combination of Memory Bus

Adapter (MBA) and Host Channel Adapter (HCA) fanout

cards. New MBA fanout cards are used exclusively for

ICB-4. New ICB-4 cables are needed for z10 BC. The

Inﬁ niBand Multiplexer (IFB-MP) card replaces the Self-

z10 BC Model

Timed Interconnect Multiplexer (STI-MP) card. There are

two types of HCA fanout cards: HCA2-C is copper and

is always used to connect to I/O (IFB-MP card) and the

HCA2-O which is optical and used for customer Inﬁ niBand

coupling.

The z10 BC has been designed to offer high performance

and efﬁ cient I/O structure. The z10 BC ships with a single

frame: the A-Frame which supports the installation of up

to four I/O drawers. Each drawer supports up to eight I/O

cards, four in front and four in the rear, providing support

for up to 480 channels (32 I/O features).

To increase the I/O device addressing capability, the I/O

subsystem has been enhanced by introducing support

for multiple subchannels sets (MSS), which are designed

to allow improved device connectivity for Parallel Access

Volumes (PAVs). To support the highly scalable system

design, the z9 BC I/O subsystem uses the Logical Chan-

nel SubSystem (LCSS) which provides the capability to

install up to 512 CHPIDs across the I/O drawers (256 per

operating system image). The Parallel Sysplex Coupling

Link architecture and technology continues to support

high speed links providing efﬁ cient transmission between

the Coupling Facility and z/OS systems. HiperSockets

provides high speed capability to communicate among

virtual servers and logical partitions. HiperSockets is now

improved with the IP version 6 (IPv6) support; this is based

on high speed TCP/IP memory speed transfers and pro-

vides value in allowing applications running in one partition

to communicate with applications running in another with-

out dependency on an external network. Industry standard

and openness are design objectives for I/O in z9 BC.

The z10 BC has one model, the E10, (Machine Type 2098)

offering between 1 to 10 processor units (PUs), which

can be conﬁ gured to provide a highly scalable solution

designed to meet the needs of both high transaction pro-

cessing applications and On Demand business. The PUs

can be characterized as either CPs, IFLs, ICFs, zAAPs,

zIIPs or option SAPs. An easy-to-enable ability to “turn

off” CPs or IFLs is available on z10 BC, allowing you to

purchase capacity for future use with minimal or no impact

on software billing. An MES feature will enable the “turned

off” CPs or IFLs for use where you require the increased

capacity. There are a wide range of upgrade options avail-

able in getting to and within the z10 BC.

The z10 BC hardware model number (E10) on its own does

not indicate the number of PUs which are being used as

CPs. For software billing purposes only, there will be a

Capacity Indicator associated with the number PUs that

are characterized as CPs. This number will be reported

by the Store System Information (STSI) instruction for soft-

ware billing purposes only. There is no afﬁ nity between the

hardware model and the number of CPs.

z10 BC capacity identiﬁ ers

nxx, where n = subcapacity engine size and xx = number

of CPs

• Total 130 Capacity Indicators for “software settings”

• A00 for systems with IFL(s) or ICF(s) only.

Memory DIMM sizes: 2 GB and 4 GB

• Maximum physical memory: 256 GB per system

– Minimum physical installed = 16 GB of which 8 GB is

for Fixed HSA

• For 8 to 32, 4 GB increments, from 32 to 248, 8 GB

increments

z10 BC model upgrades

The z10 BC provides for the dynamic and ﬂ exible capac-

ity growth for mainframe servers. There are full upgrades

within the z10 BC and upgrades from any z9 BC or z890 to

any z10 BC. Temporary capacity upgrades are available

through On/Off Capacity on Demand (CoD).

z9 BC

R07 S07

A04

z890

z10 BC

z10 EC

E12E10

z10 BC Model Capacity IDs:

• A00, A01 to Z01, A01 to Z02, A03 to Z03, A04 to Z04,

and A05 to Z05

• Capacity setting A00 does not have any CP engines

• Nxx, where n = the capacity setting of the engine, and

xx = the number of PU characterized as CPs in the CPC

Z01

Z02

Z03

Z04

Y01

X01

W01

V01 U01

T01

S01

R01

Q01 P01 O01 N01 M01

L01

K01

J01

I01

H01 G01

F01

E01

D01

C01

B01

A01

1-way

Specialty

Engine

Y02

X02

W02

V02 U02

T02

S02

R02

Q02

P02

O02

N02

M02

L02

K02 J02

I02

H02

G02

F02

E02

D02

C02

B02

A02

2-way

Specialty

Engine

Y03

X03

W03

V03 U03

T03

S03

R03

Q03

P03

O03

N03

M03

L03

K03 J03

I03

H03

G03

F03

E03

D03

C03

B03

A03

3-way

Specialty

Engine

Y04

X04

W04

V04 U04

T04

S04

R04

Q04 P04 O04 N04 M04

L04

K04

J04

I04 H04 G04

F04

E04

D04

C04

B04

A04

4-way

Specialty

Engine

Z05

Y05

X05

W05

V05 U05

T05

S05

R05

Q05 P05 O05 N05 M05

L05

K05

J05

I05 H05 G05

F05

E05

D05

C05

B05

A05

5-way

Specialty

Engine

Specialty

Engine

Specialty

Engine

Specialty

Engine

Specialty

Engine

Specialty

Engine

For the z10 BC models, there are twenty-six capacity

settings per engine for central processors (CPs). Sub-

capacity processors have availability of z10 BC features/

functions and any-to-any upgradeability is available within

the sub-capacity matrix. All CPs must be the same capac-

ity setting size within one z10 BC. All specialty engines run

at full speed.

The one for one entitlement to purchase one zAAP and/or

one zIIP for each CP purchased is the same for CPs of

any speed.

z10 BC Performance

The performance design of the z/Architecture can enable

the server to support a new standard of performance for

applications through expanding upon a balanced system

approach. As CMOS technology has been enhanced to

support not only additional processing power, but also

more PUs, the entire server is modiﬁ ed to support the

increase in processing power. The I/O subsystem supports

a greater amount of bandwidth than previous generations

through internal changes, providing for larger and faster

volume of data movement into and out of the server. Sup-

port of larger amounts of data within the server required

improved management of storage conﬁ gurations, made

available through integration of the operating system and

hardware support of 64-bit addressing. The combined bal-

anced system design allows for increases in performance

across a broad spectrum of work.

Large System Performance Reference

IBM’s Large Systems Performance Reference (LSPR)

method is designed to provide comprehensive

z/Architecture processor capacity ratios for different con-

ﬁ gurations of Central Processors (CPs) across a wide

variety of system control programs and workload envi-

ronments. For z10 BC, z/Architecture processor capacity

identiﬁ er is deﬁ ned with a (A0x-Z0x) notation, where x is

the number of installed CPs, from one to ﬁ ve. There are

a total of 26 subcapacity levels, designated by the letters

A through Z.

In addition to the general information provided for z/OS

V1.9, the LSPR also contains performance relationships for

z/VM and Linux operating environments.

• up to 1.4 times that of the z9 BC (2096) Z01.

Moving from a System z9 partition to an equivalently sized

System z10 BC partition, a z/VM workload will experience

an ITR ratio that is somewhat related to the workload’s

instruction mix, MP factor, and level of storage over com-

mitment. Workloads with higher levels of storage over

commitment or higher MP factors are likely to experience

lower than average z10 BC to z9 ITR scaling ratios. The

range of likely ITR ratios is wider than the range has been

for previous processor migrations.

The LSPR contains the Internal Throughput Rate Ratios

(ITRRs) for the z10 BC and the previous-generation

zSeries processor families based upon measurements

and projections using standard IBM benchmarks in a con-

trolled environment. The actual throughput that any user

may experience will vary depending upon considerations

such as the amount of multiprogramming in the user’s job

stream, the I/O conﬁ guration, and the workload processed.

Therefore no assurance can be given that an individual

user will achieve throughput improvements equivalent

to the performance ratios stated. For more detailed per-

formance information, consult the Large Systems Perfor-

mance Reference (LSPR) available at:

http://www.ibm.com/servers/eserver/zseries/lspr/.

CPU Measurement Facility

The CPU Measurement Facility is a hardware facility which

consists of counters and samples. The facility provides a

means to collect run-time data for software performance

tuning. The detailed architecture information for this facility

™

can be found in the System z10 Library in Resource Link

Based on using an LSPR mixed workload, the perfor-

mance of the z10 BC (2098) Z01 is expected to be:

z10 BC I/O Subsystem

A new host bus interface using Inﬁ niBand with a link data

rate of 6 GBps, was introduced on the z10 BC. It provides

enough throughput to support the full capacity and pro-

cessing power of the CPC. The z10 BC contains an I/O

subsystem infrastructure which uses up to four I/O drawers

that provides eight I/O slots in each drawer. There are two

I/O domains per drawer, and four I/O cards per domain.

I/O cards are horizontal and may be added concurrently.

Concurrent replacement and/or repair is available with

systems containing more than one I/O drawer. Drawers

may be added concurrently should the need for more con-

nectivity arise.

ESCON, FICON Express4, FICON Express2, FICON

Express, OSA-Express3, OSA-Express2, and Crypto

Express2 features plug into the z10 BC I/O drawer along

with any ISC-3s and Inﬁ niBand Multiplexer (IFB-MP) cards.

All I/O features and their support cards can be hot-

plugged in the I/O drawer. Each model ships with one

I/O drawer as standard in the A-Frame (the A-Frame also

contains the Central Processor Complex [CPC]), where the

I/O drawers are installed. Each IFB-MP has a bandwidth

up to 6 GigaBytes per second (GB/sec) for I/O domains

and MBA fanout cards provide 2.0 GB/sec for ICB-4s.

The z10 BC continues to support all of the features

announced with the System z9 BC such as:

• Logical Channel Subsystems (LCSSs) and support for

up to 30 logical partitions

• Increased number of Subchannels (63.75k)

• Multiple Subchannel Sets (MSS)

• Redundant I/O Interconnect

• Physical Channel IDs (PCHIDs)

• System Initiated CHPID Reconﬁ guration

• Logical Channel SubSystem (LCSS) Spanning

System I/O Conﬁ guration Analyzer

Today the information needed to manage a system’s I/O

conﬁ guration has to be obtained from many separate

applications. The System’s I/O Conﬁ guration Analyzer

(SIOA) tool is a SE/HMC-based tool that will allow the

system hardware administrator access to the information

from these many sources in one place. This will make it

much easier to manage I/O conﬁ gurations, particularly

across multiple CPCs. The SIOA is a “view-only” tool. It

does not offer any options other than viewing options.

First the SIOA tool analyzes the current active IOCDS on

the SE. It extracts information about the deﬁ ned channel,

partitions, link addresses and control units. Next the SIOA

tool asks the channels for their node ID information. The

FICON channels support remote node ID information, so

that is also collected from them. The data is then formatted

and displayed on ﬁ ve screens:

1)PCHID Control Unit Screen – Shows PCHIDs, CSS.

CHPIDs and their control units

2)PCHID Partition Screen – Shows PCHIDS, CSS. CHPIDs

and what partitions they are in

3)Control Unit Screen – Shows the control units, their

PCHIDs and their link addresses in each of the CSS’s

4)Link Load Screen – Shows the Link address and the

PCHIDs that use it

5)Node ID Screen – Shows the Node ID data under the

PCHIDs

The SIOA tool allows the user to sort on various columns

and export the data to a USB ﬂ ash drive for later viewing.

z10 BC Channels and I/O Connectivity

ESCON Channels

The z10 BC supports up to 480 ESCON channels. The

high density ESCON feature has 16 ports, 15 of which

can be activated for customer use. One port is always

reserved as a spare which is activated in the event of a

failure of one of the other ports. For high availability the

initial order of ESCON features will deliver two 16-port

ESCON features and the active ports will be distributed

across those features.

Fibre Channel Connectivity

The on demand operating environment requires fast data

access, continuous data availability, and improved ﬂ ex-

ibility, all with a lower cost of ownership. The four port

FICON Express4 and FICON Express2 features available

on the z9 BC continue to be supported on the System

z10 BC.

Choose the FICON Express4 features that best meet your

business requirements

To meet the demands of your Storage Area Network (SAN),

provide granularity, facilitate redundant paths, and satisfy

your infrastructure requirements, there are ﬁ ve features

from which to choose.

FICON Express4 Channels

The z10 BC supports up to 128 FICON Express4 chan-

nels, each one operating at 1, 2 or 4 Gb/sec auto-negoti-

ated. The FICON Express4 features are available in long

wavelength (LX) and short wavelength (SX). For customers

exploiting LX, there are two options available for unre-

peated distances of up to 4 kilometers (2.5 miles) or up to

10 kilometers (6.2 miles). Both LX features use 9 micron

single mode ﬁ ber optic cables. The SX feature uses 50

or 62.5 micron multimode ﬁ ber optic cables. Each FICON

Express4 feature has four independent channels (ports)

and can be conﬁ gured to carry native FICON trafﬁ c or

Fibre Channel (SCSI) trafﬁ c. LX and SX cannot be inter-

mixed on a single feature. The receiving devices must cor-

respond to the appropriate LX or SX feature. The maximum

number of FICON Express4 features is 32 using four I/O

drawers.

Exclusive to the z10 BC and z9 BC is the availability of

a, lower cost FICON Express4 2-port feature, the FICON

Express4-2C 4KM LX and FICON Express4-2C SC. These

features support two FICON 4 Gbps LX and SX chan-

nels respectively. The FICON Express4-2-port cards are

designed to operate like the 4 port card but with the ﬂ ex-

ibility of having fewer ports per card.

Feature FC # Infrastructure Ports per Feature

FICON Express4 10KM LX 3321

FICON Express4 4KM LX 3324

FICON Express4-2C 4KM LX 3323

FICON Express4 SX 3322 Multimode ﬁ ber 4

FICON Express4-2C SX 3318 Multimode ﬁ ber 2

Choose the features that best meet your granularity, ﬁ ber

optic cabling, and unrepeated distance requirements.

Single mode ﬁ ber

FICON Express2 Channels

The z10 BC supports carrying forward FICON Express2

channels, each one operating at 1 or 2 Gb/sec auto-

negotiated. The FICON Express2 features are available

in long wavelength (LX) using 9 micron single mode ﬁ ber

optic cables and short wavelength (SX) using 50 and

62.5 micron multimode ﬁ ber optic cables. Each FICON

Express2 feature has four independent channels (ports)

and each can be conﬁ gured to carry native FICON trafﬁ c

or Fibre Channel (SCSI) trafﬁ c. LX and SX cannot be inter-

mixed on a single feature. The maximum number of FICON

Express2 features is 20, using four I/O drawers.

FICON Express Channels

The z10 BC also supports carrying forward FICON

Express LX and SX channels from z9 BC and z990 each

channel operating at 1 or 2 Gb/sec auto-negotiated. Each

FICON Express feature has two independent channels

(ports).

Concurrent Update

The FICON Express4 SX and LX features may be added

to an existing z10 BC concurrently. This concurrent update

capability allows you to continue to run workloads through

other channels while the new FICON Express4 features are

being added. This applies to CHPID types FC and FCP.

The System z10 BC Model E10 is limited to 32 features –

any combination of FICON Express4, FICON Express2 and

FICON Express LX and SX features.

The FICON Express4, FICON Express2 and FICON

Express feature conforms to the Fibre Connection (FICON)

architecture and the Fibre Channel (FC) architecture, pro-

viding connectivity between any combination of servers,

directors, switches, and devices in a Storage Area Network

(SAN). Each of the four independent channels (FICON

Express only supports two channels per feature) is capa-

ble of 1 Gigabit per second (Gb/sec), 2 Gb/sec, or 4

Gb/sec (only FICON Express4 supports 4 Gbps) depend-

ing upon the capability of the attached switch or device.

The link speed is auto-negotiated, point-to-point, and is

transparent to users and applications. Not all switches and

devices support 2 or 4 Gb/sec link data rates.

FICON Express4 and FICON Express2 Performance

Your enterprise may beneﬁ t from FICON Express4 and

FICON Express2 with:

Continued Support of Spanned Channels and Logical Partitions

The FICON Express4 and FICON Express2, FICON and

FCP (CHPID types FC and FCP) channel types, can be

deﬁ ned as a spanned channel and can be shared among

logical partitions within and across LCSSs.

Modes of Operation

There are two modes of operation supported by FICON

Express4 and FICON Express2 SX and LX. These modes

are conﬁ gured on a channel-by-channel basis – each of

the four channels can be conﬁ gured in either of two sup-

ported modes.

• Fibre Channel (CHPID type FC), which is native FICON

or FICON Channel-to-Channel (server-to-server)

• Fibre Channel Protocol (CHPID type FCP), which sup-

ports attachment to SCSI devices via Fibre Channel

switches or directors in z/VM, z/VSE, and Linux on

System z10 environments

• Increased data transfer rates (bandwidth)

• Improved performance

• Increased number of start I/Os

• Reduced backup windows

• Channel aggregation to help reduce infrastructure costs

For more information about FICON, visit the IBM Redbooks®

Web site at: http://www.redbooks.ibm.com/ search for

SG24-5444. There are also various FICON I/O Connectivity

information at: www-03.ibm.com/systems/z/connectivity/.

Native FICON Channels

Native FICON channels and devices can help to reduce

bandwidth constraints and channel contention to enable

easier server consolidation, new application growth,

large business intelligence queries and exploitation of On

Demand Business.

The FICON Express4, FICON Express2 and FICON

Express channels support native FICON and FICON

Channel-to-Channel (CTC) trafﬁ c for attachment to servers,

disks, tapes, and printers that comply with the FICON

architecture. Native FICON is supported by all of the

z10 BC operating systems. Native FICON and FICON

CTC are deﬁ ned as CHPID type FC.

Because the FICON CTC function is included as part of

the native FICON (FC) mode of operation, FICON CTC is

not limited to intersystem connectivity (as is the case with

ESCON), but will support multiple device deﬁ nitions.

FICON Support for Cascaded Directors

Native FICON (FC) channels support cascaded directors.

This support is for a single hop conﬁ guration only. Two-

director cascading requires a single vendor high integrity

fabric. Directors must be from the same vendor since

cascaded architecture implementations can be unique.

This type of cascaded support is important for disaster

recovery and business continuity solutions because it can

help provide high availability, extended distance connec-

tivity, and (particularly with the implementation of 2 Gb/sec

Inter Switch Links) has the potential for ﬁ ber infrastructure

cost savings by reducing the number of channels for inter-

connecting the two sites.

IBM

Two site non-cascaded director

topology. Each CEC connects to

directors in both sites.

With Inter Switch Links (ISLs),

less fiber cabling may be needed

for cross-site connectivity

Two Site cascaded director

topology. Each CEC connects to

IBM

local directors only.

FCP Channels

z10 BC supports FCP channels, switches and FCP/ SCSI

disks with full fabric connectivity under Linux on System

z and z/VM 5.2 (or later) for Linux as a guest under z/VM,

under z/VM 5.2 (or later), and under z/VSE 3.1 for system

usage including install and IPL. Support for FCP devices

means that z10 BC servers are capable of attaching to

select FCP-attached SCSI devices and may access these

devices from Linux on z10 BC and z/VSE. This expanded

attachability means that enterprises have more choices

for new storage solutions, or may have the ability to use

existing storage devices, thus leveraging existing invest-

ments and lowering total cost of ownership for their Linux

implementations.

The same FICON features used for native FICON chan-

nels can be deﬁ ned to be used for Fibre Channel Protocol

(FCP) channels. FCP channels are deﬁ ned as CHPID type

FCP. The 4 Gb/sec capability on the FICON Express4

channel means that 4 Gb/sec link data rates are available

for FCP channels as well.

FCP – increased performance for small block sizes

The Fibre Channel Protocol (FCP) Licensed Internal

Code has been modiﬁ ed to help provide increased I/O

operations per second for small block sizes. With FICON

Express4, there may be up to 57,000 I/O operations

per second (all reads, all writes, or a mix of reads and

writes), an 80% increase compared to System z9. These

results are achieved in a laboratory environment using

one channel conﬁ gured as CHPID type FCP with no other

processing occurring and do not represent actual ﬁ eld

measurements. A signiﬁ cant increase in I/O operations per

second for small block sizes can also be expected with

FICON Express2.

This FCP performance improvement is transparent to oper-

ating systems that support FCP, and applies to all the

FICON Express4 and FICON Express2 features when con-

ﬁ gured as CHPID type FCP, communicating with SCSI

devices.

SCSI IPL now a base function

The SCSI Initial Program Load (IPL) enablement feature,

ﬁ rst introduced on z990 in October of 2003, is no longer

required. The function is now delivered as a part of the

server Licensed Internal Code. SCSI IPL allows an IPL of

an operating system from an FCP-attached SCSI disk.

FCP Full fabric connectivity

FCP full fabric support means that any number of (single

vendor) FCP directors/ switches can be placed between

the server and an FCP/SCSI device, thereby allowing

many “hops” through a Storage Area Network (SAN) for

I/O connectivity. FCP full fabric connectivity enables mul-

tiple FCP switches/directors on a fabric to share links and

therefore provides improved utilization of inter-site con-

nected resources and infrastructure.

FICON and FCP for connectivity to disk, tape, and printers

High Performance FICON – improvement in performance and

RAS

Enhancements have been made to the z/Architecture

and the FICON interface architecture to deliver optimiza-

tions for online transaction processing (OLTP) workloads.

When exploited by the FICON channel, the z/OS operating

system, and the control unit, High Performance FICON for

System z (zHPF) is designed to help reduce overhead and

improve performance.

Additionally, the changes to the architectures offer end-

to-end system enhancements to improve reliability, avail-

ability, and serviceability (RAS).

zHPF channel programs can be exploited by the OLTP

I/O workloads – DB2, VSAM, PDSE, and zFS – which

transfer small blocks of ﬁ xed size data (4K blocks). zHPF

implementation by the DS8000 is exclusively for I/Os that

transfer less than a single track of data.

The maximum number of I/Os is designed to be improved

up to 100% for small data transfers that can exploit zHPF.

Realistic production workloads with a mix of data transfer

sizes can see up to 30 to 70% of FICON I/Os utilizing zHPF

resulting in up to a 10 to 30% savings in channel utilization.

Sequential I/Os transferring less than a single track size

(for example, 12x4k bytes/IO) may also beneﬁ t.

The FICON Express4 and FICON Express2 features will

support both the existing FICON protocol and the zHPF

protocol concurrently in the server Licensed Internal Code.

High performance FICON is supported by z/OS for DB2,

VSAM, PDSE, and zFS applications. zHPF applies to all

FICON Express4 and FICON Express2 features (CHPID

type FC) and is exclusive to System z10. Exploitation is

required by the control unit.

IBM System Storage DS8000 Release 4.1 delivers new

capabilities to support High Performance FICON for

System z, which can improve FICON I/O throughput on a

DS8000 port by up to 100%. The DS8000 series Licensed

Machine Code (LMC) level 5.4.2xx.xx (bundle version

64.2.xx.xx), or later, is required.

Platform and name server registration in FICON channel

The FICON channel now provides the same information

to the fabric as is commonly provided by open systems,

registering with the name server in the attached FICON

directors. With this information, your storage area network

(SAN) can be more easily and efﬁ ciently managed,

enhancing your ability to perform problem determination

and analysis.

Registration allows other nodes and/or SAN managers to

query the name server to determine what is connected

to the fabric, what protocols are supported (FICON, FCP)

and to gain information about the System z10 using the

attributes that are registered. The FICON channel is now

designed to perform registration with the ﬁ bre channel’s

Management Service and Directory Service.

It will register:

• Platform’s:

– Worldwide node name (node name for the platform –

same for all channels)

– Platform type (host computer)

– Platform name (includes vendor ID, product ID, and

vendor speciﬁ c data from the node descriptor)

• Channel’s:

– Worldwide port name (WWPN)

– Node port identiﬁ cation (N_PORT ID)

– FC-4 types supported (always 0x1B and additionally

0x1C if any Channel-to-Channel (CTC) control units are deﬁ ned on that channel)

– Classes of service support by the channel

Platform registration is a service deﬁ ned in the Fibre Chan-

nel – Generic Services 4 (FC-GS-4) standard (INCITS

(ANSI) T11 group).

Platform and name server registration applies to all of the

FICON Express4, FICON Express2, and FICON Express

features (CHPID type FC). This support is exclusive to

System z10 and is transparent to operating systems.

Preplanning and setup of SAN for a System z10 environment

The worldwide port name (WWPN) prediction tool is now

available to assist you with preplanning of your Storage

Area Network (SAN) environment prior to the installation of

your System z10 server.

This standalone tool is designed to allow you to setup

your SAN in advance, so that you can be up and running

much faster once the server is installed. The tool assigns

WWPNs to each virtual Fibre Channel Protocol (FCP)

channel/port using the same WWPN assignment algo-

rithms a system uses when assigning WWPNs for channels

utilizing N_Port Identiﬁ er Virtualization (NPIV).

The tool needs to know the FCP-speciﬁ c I/O device deﬁ ni-

tions in the form of a .csv ﬁ le. This ﬁ le can either be cre-

ated manually, or exported from Hardware Conﬁ guration

Deﬁ nition/Hardware Conﬁ guration Manager (HCD/HCM).

The tool will then create the WWPN assignments, which

are required to set up your SAN. The tool will also create

a binary conﬁ guration ﬁ le that can later on be imported by

your system.

The WWPN prediction tool can be downloaded from

Resource Link and is applicable to all FICON channels

deﬁ ned as CHPID type FCP (for communication with SCSI

devices). Check Preventive Service Planning (PSP) buck-

ets for required maintenance.

http://www.ibm.com/servers/resourcelink/

Extended distance FICON – improved performance at extended

distance

An enhancement to the industry standard FICON architec-

ture (FC-SB-3) helps avoid degradation of performance at

extended distances by implementing a new protocol for

“persistent” Information Unit (IU) pacing. Control units that

exploit the enhancement to the architecture can increase

the pacing count (the number of IUs allowed to be in ﬂ ight

from channel to control unit). Extended distance FICON also

allows the channel to “remember” the last pacing update for

use on subsequent operations to help avoid degradation of

performance at the start of each new operation.

Improved IU pacing can help to optimize the utilization of

the link, for example help keep a 4 Gbps link fully utilized

at 50 km, and allows channel extenders to work at any dis-

tance, with performance results similar to that experienced

when using emulation.

The requirements for channel extension equipment are

simpliﬁ ed with the increased number of commands in

ﬂ ight. This may beneﬁ t z/OS Global Mirror (Extended

Remote Copy – XRC) applications as the channel exten-

sion kit is no longer required to simulate speciﬁ c channel

commands. Simplifying the channel extension require-

ments may help reduce the total cost of ownership of end-

to-end solutions.

Extended distance FICON is transparent to operating sys-

tems and applies to all the FICON Express2 and FICON

Express4 features carrying native FICON trafﬁ c (CHPID

type FC). For exploitation, the control unit must support the

new IU pacing protocol. The channel will default to cur-

rent pacing values when operating with control units that

cannot exploit extended distance FICON.

Exploitation of extended distance FICON is supported by

IBM System Storage DS8000 series Licensed Machine

Code (LMC) level 5.3.1xx.xx (bundle version 63.1.xx.xx),

or later.

To support extended distance without performance degra-

dation, the buffer credits in the FICON director must be

set appropriately. The number of buffer credits required is

dependent upon the link data rate (1 Gbps, 2 Gbps, or 4

Gbps), the maximum number of buffer credits supported

by the FICON director or control unit, as well as application

and workload characteristics. High bandwidth at extended

distances is achievable only if enough buffer credits exist

to support the link data rate.

FICON Express enhancements for Storage Area Networks

N_Port ID Virtualization

N_Port ID Virtualization is designed to allow for sharing of

a single physical FCP channel among multiple operating

system images. Virtualization function is currently available

for ESCON and FICON channels, and is now available for

FCP channels. This function offers improved FCP channel

utilization due to fewer hardware requirements, and can

reduce the complexity of physical FCP I/O connectivity.

Program Directed re-IPL

Program Directed re-IPL is designed to enable an operat-

ing system to determine how and from where it had been

loaded. Further, Program Directed re-IPL may then request

that it be reloaded again from the same load device using

the same load parameters. In this way, Program Directed

re-IPL allows a program running natively in a partition to

trigger a re-IPL. This re-IPL is supported for both SCSI

and ECKD devices. z/VM 5.3 provides support for guest

exploitation.

FICON Link Incident Reporting

FICON Link Incident Reporting is designed to allow an

operating system image (without operating intervention) to

ability to capture data for link error analysis. The informa-

tion can be displayed and is saved in the system log.

Serviceability Enhancements

Requests Node Identiﬁ cation Data (RNID) is designed to

facilitate the resolution of ﬁ ber optic cabling problems.

You can now request RNID data for a device attached to a

native FICON channel.

Local Area Network (LAN) connectivity

OSA-Express3 – the newest family of LAN adapters

The third generation of Open Systems Adapter-Express

(OSA-Express3) features have been introduced to help

reduce latency and overhead, deliver double the port den-

sity of OSA-Express2, and provide increased throughput

OSA-Express3 for reduced latency and improved throughput

To help reduce latency, the OSA-Express3 features now

have an Ethernet hardware data router; what was previ-

ously done in ﬁ rmware (packet construction, inspection,

and routing) is now performed in hardware. With direct

memory access, packets ﬂ ow directly from host memory

to the LAN without ﬁ rmware intervention. OSA-Express3 is

also designed to help reduce the round-trip networking

time between systems. Up to a 45% reduction in latency at

the TCP/IP application layer has been measured.

The OSA-Express3 features are also designed to improve

throughput for standard frames (1492 byte) and jumbo

frames (8992 byte) to help satisfy the bandwidth require-

ments of your applications. Up to a 4x improvement has

been measured (compared to OSA-Express2).

The above statements are based on OSA-Express3 perfor-

mance measurements performed in a laboratory environ-

ment on a System z10 and do not represent actual ﬁ eld

measurements. Results may vary.

Choose the OSA-Express3 features that best meet your

business requirements.

To meet the demands of your applications, provide granu-

larity, facilitate redundant paths, and satisfy your infrastruc-

ture requirements, there are seven features from which to

choose. In the 10 GbE environment, Short Reach (SR) is

being offered for the ﬁ rst time.

Feature Infrastructure Ports per Feature

OSA-Express3 GbE LX

OSA-Express3 10 GbE LR

OSA-Express3 GbE SX Multimode ﬁ ber 4

OSA-Express3 10 GbE SR Multimode ﬁ ber 2

OSA-Express3-2P GbE SX Multimode ﬁ ber 2

OSA-Express3 1000BASE-T Copper 4

OSA-Express3-2P 1000BASE-T Copper 2

Note that software PTFs or a new release may be required

(depending on CHPID type) to support all ports.

Single mode ﬁ ber

Port density or granularity

The OSA-Express3 features have Peripheral Component

Interconnect Express (PCI-E) adapters. The previous table

identiﬁ es whether the feature has 2 or 4 ports for LAN con-

nectivity. Select the density that best meets your business

requirements. Doubling the port density on a single feature

helps to reduce the number of I/O slots required for high-

speed connectivity to the Local Area Network.

The OSA-Express3 10 GbE features support Long Reach

(LR) using 9 micron single mode ﬁ ber optic cabling and

Short Reach (SR) using 50 or 62.5 micron multimode

ﬁ ber optic cabling. The connector is new; it is now the

small form factor, LC Duplex connector. Previously the SC

Duplex connector was supported for LR. The LC Duplex

connector is common with FICON, ISC-3, and OSA-

Express2 Gigabit Ethernet LX and SX.

The OSA-Express3 features are exclusive to System z10.

There are operating system dependencies for exploitation

of two ports in OSD mode per PCI-E adapter. Whether it is

a 2-port or a 4-port feature, only one of the ports will be

visible on a PCI-E adapter if operating system exploitation

updates are not installed.

OSA-Express3 Ethernet features – Summary of beneﬁ ts

OSA-Express3 10 GbE LR (single mode ﬁ ber), 10 GbE SR

(multimode ﬁ ber), GbE LX (single mode ﬁ ber), GbE SX

(multimode ﬁ ber), and 1000BASE-T (copper) are designed

for use in high-speed enterprise backbones, for local area

network connectivity between campuses, to connect server

farms to System z10, and to consolidate ﬁ le servers onto

System z10. With reduced latency, improved throughput,

and up to 96 ports of LAN connectivity, (when all are 4-port

features, 24 features per server), you can “do more with

less.”

The key beneﬁ ts of OSA-Express3 compared to OSA-

Express2 are:

• Reduced latency (up to 45% reduction) and increased

throughput (up to 4x) for applications

• More physical connectivity to service the network and

fewer required resources:

– Fewer CHPIDs to deﬁ ne and manage

– Reduction in the number of required I/O slots

– Possible reduction in the number of I/O drawers

– Double the port density of OSA-Express2

– A solution to the requirement for more than 48 LAN

ports (now up to 96 ports)

The OSA-Express3 features are exclusive to System z10.

OSA-Express2 availability

OSA-Express2 Gigabit Ethernet and 1000BASE-T Ethernet

continue to be available for ordering, for a limited time, if

you are not yet in a position to migrate to the latest release

of the operating system for exploitation of two ports per

PCI-E adapter and if you are not resource-constrained.

Historical summary: Functions that continue to be sup-

ported by OSA-Express3 and OSA-Express2:

• Queued Direct Input/Output (QDIO) – uses memory

queues and a signaling protocol to directly exchange

data between the OSA microprocessor and the network

software for high-speed communication.

– QDIO Layer 2 (Link layer) – for IP (IPv4, IPv6) or non-

IP (AppleTalk, DECnet, IPX, NetBIOS, or SNA) workloads. Using this mode the Open Systems Adapter (OSA) is protocol-independent and Layer-3 independent. Packet forwarding decisions are based upon the Medium Access Control (MAC) address.

– QDIO Layer 3 (Network or IP layer) – for IP workloads.

Packet forwarding decisions are based upon the IP address. All guests share OSA’s MAC address.

Jumbo frames in QDIO mode (8992 byte frame size) when

•

operating at 1 Gbps (ﬁ ber or copper) and 10 Gbps (ﬁ ber).

• 640 TCP/IP stacks per CHPID – for hosting more images

• Large send for IPv4 packets – for TCP/IP trafﬁ c and CPU

efﬁ ciency, ofﬂ oading the TCP segmentation processing

from the host TCP/IP stack to the OSA-Express feature

• Concurrent LIC update – to help minimize the disrup-

tion of network trafﬁ c during an update; when properly

conﬁ gured, designed to avoid a conﬁ guration off or on

(applies to CHPID types OSD and OSN)

• Multiple Image Facility (MIF) and spanned channels – for

sharing OSA among logical channel subsystems

The OSA-Express3 and OSA-Express2 Ethernet features

support the following CHPID types:

CHPID OSA-Express3, Purpose/Trafﬁ c Type OSA-Express2 Features

OSC 1000BASE-T

OSD

GbE TCP/IP trafﬁ c when Layer 3 10 GbE Protocol-independent when Layer 2

1000BASE-T

OSE 1000BASE-T Non-QDIO, SNA/APPN

passthru (LCS)

OSA-Integrated Console Controller (OSA-ICC) TN3270E, non-SNA DFT, IPL to CPC and LPARs Operating system console operations

Queued Direct Input/Output (QDIO)

/HPR and/or TCP/IP

OSN 1000BASE-T OSA for NCP

GbE Supports channel data link control (CDLC)

OSA-Express3 10 GbE

OSA-Express3 10 Gigabit Ethernet LR

The OSA-Express3 10 Gigabit Ethernet (GbE) long reach

(LR) feature has two ports. Each port resides on a PCIe

adapter and has its own channel path identiﬁ er (CHPID).

There are two PCIe adapters per feature. OSA-Express3

10 GbE LR is designed to support attachment to a 10

Gigabits per second (Gbps) Ethernet Local Area Net-

work (LAN) or Ethernet switch capable of 10 Gbps.

OSA-Express3 10 GbE LR supports CHPID type OSD

exclusively. It can be deﬁ ned as a spanned channel and

can be shared among LPARs within and across LCSSs.

OSA-Express3 10 Gigabit Ethernet SR

The OSA-Express3 10 Gigabit Ethernet (GbE) short reach

(LR) feature has two ports. Each port resides on a PCIe

adapter and has its own channel path identiﬁ er (CHPID).

There are two PCIe adapters per feature. OSA-Express3

10 GbE SR is designed to support attachment to a 10

Gigabits per second (Gbps) Ethernet Local Area Net-

work (LAN) or Ethernet switch capable of 10 Gbps.

OSA-Express3 10 GbE SR supports CHPID type OSD

exclusively. It can be deﬁ ned as a spanned channel and

can be shared among LPARs within and across LCSSs.

OSA-Express3 Gigabit Ethernet LX

The OSA-Express3 Gigabit Ethernet (GbE) long wave-

length (LX) feature has four ports. Two ports reside on a

PCIe adapter and share a channel path identiﬁ er (CHPID).

There are two PCIe adapters per feature. Each port sup-

ports attachment to a one Gigabit per second (Gbps) Eth-

ernet Local Area Network (LAN). OSA-Express3 GbE LX

supports CHPID types OSD and OSN. It can be deﬁ ned

as a spanned channel and can be shared among LPARs

within and across LCSSs.

OSA-Express3 Gigabit Ethernet SX

The OSA-Express3 Gigabit Ethernet (GbE) short wave-

length (SX) feature has four ports. Two ports reside on a

PCIe adapter and share a channel path identiﬁ er (CHPID).

There are two PCIe adapters per feature. Each port sup-

ports attachment to a one Gigabit per second (Gbps) Eth-

ernet Local Area Network (LAN). OSA-Express3 GbE SX

supports CHPID types OSD and OSN. It can be deﬁ ned

as a spanned channel and can be shared among LPARs

within and across LCSSs.

OSA-Express3-2P Gigabit Ethernet SX

The OSA-Express3-2P Gigabit Ethernet (GbE) short

wavelength (SX) feature has two ports which reside on a

single PCIe adapter and share one channel path identiﬁ er

(CHPID). Each port supports attachment to a one Gigabit

per second (Gbps) Ethernet Local Area Network (LAN).

OSA-Express3 GbE SX supports CHPID types OSD and

OSN. It can be deﬁ ned as a spanned channel and can be

shared among LPARs within and across LCSSs.

Four-port exploitation on OSA-Express3 GbE SX and LX

For the operating system to recognize all four ports on an

OSA-Express3 Gigabit Ethernet feature, a new release

and/or PTF is required. If software updates are not applied,

only two of the four ports will be “visible” to the operating

system.

Activating all four ports on an OSA-Express3 feature pro-

vides you with more physical connectivity to service the

network and reduces the number of required resources

(I/O slots, I/O cages, fewer CHPIDs to deﬁ ne and manage).

Four-port exploitation is supported by z/OS, z/VM, z/VSE,

z/TPF, and Linux on System z.

OSA-Express3 1000BASE-T Ethernet

The OSA-Express3 1000BASE-T Ethernet feature has

four ports. Two ports reside on a PCIe adapter and share

a channel path identiﬁ er (CHPID). There are two PCIe

adapters per feature. Each port supports attachment to

either a 10BASE-T (10 Mbps), 100BASE-TX (100 Mbps), or

1000BASE-T (1000 Mbps or 1 Gbps) Ethernet Local Area

Network (LAN). The feature supports auto-negotiation and

automatically adjusts to 10, 100, or 1000 Mbps, depending

upon the LAN. When the feature is set to autonegotiate,

the target device must also be set to autonegotiate. The

feature supports the following settings: 10 Mbps half or full

duplex, 100 Mbps half or full duplex, 1000 Mbps (1 Gbps)

full duplex. OSA-Express3 1000BASE-T Ethernet supports

CHPID types OSC, OSD, OSE, and OSN. It can be deﬁ ned

as a spanned channel and can be shared among LPARs

within and across LCSSs.

When conﬁ gured at 1 Gbps, the 1000BASE-T Ethernet

feature operates in full duplex mode only and supports

jumbo frames when in QDIO mode (CHPID type OSD).

OSA-Express3-2P 1000BASE-T Ethernet

The OSA-Express3-2P 1000BASE-T Ethernet feature has

two ports which reside on a single PCIe adapter and share

one channel path identiﬁ er (CHPID). Each port supports

attachment to either a 10BASE-T (10 Mbps), 100BASE-TX

(100 Mbps), or 1000BASE-T (1000 Mbps or 1 Gbps) Ether-

net Local Area Network (LAN). The feature supports auto-

negotiation and automatically adjusts to 10, 100, or 1000

Mbps, depending upon the LAN. When the feature is set to

autonegotiate, the target device must also be set to auto-

negotiate. The feature supports the following settings: 10

Mbps half or full duplex, 100 Mbps half or full duplex, 1000

Mbps (1 Gbps) full duplex. OSA-Express3 1000BASE-T

Ethernet supports CHPID types OSC, OSD, OSE, and

OSN. It can be deﬁ ned as a spanned channel and can be

shared among LPARs within and across LCSSs. Software

updates are required to exploit both ports.

When conﬁ gured at 1 Gbps, the 1000BASE-T Ethernet

feature operates in full duplex mode only and supports

jumbo frames when in QDIO mode (CHPID type OSD).

OSA-Express QDIO data connection isolation for the z/VM

environment

Multi-tier security zones are fast becoming the network

conﬁ guration standard for new workloads. Therefore, it is

essential for workloads (servers and clients) hosted in a

virtualized environment (shared resources) to be protected

from intrusion or exposure of data and processes from

other workloads.

Internal “routing” can be disabled on a per QDIO connec-

tion basis. This support does not affect the ability to share

an OSA-Express port. Sharing occurs as it does today, but

the ability to communicate between sharing QDIO data

connections may be restricted through the use of this sup-

port. You decide whether an operating system’s or z/VM’s

Virtual Switch OSA-Express QDIO connection is to be non-

isolated (default) or isolated.

QDIO data connection isolation applies to the device

statement deﬁ ned at the operating system level. While

an OSA-Express CHPID may be shared by an operating

system, the data device is not shared.

With Queued Direct Input/Output (QDIO) data connection

isolation you:

• Have the ability to adhere to security and HIPAA-security

guidelines and regulations for network isolation between

the operating system instances sharing physical network

connectivity

• Can establish security zone boundaries that have been

deﬁ ned by your network administrators

Have a mechanism to isolate a QDIO data connection (on

•

an OSA port), ensuring all internal OSA routing between

the isolated QDIO data connections and all other shar-

ing QDIO data connections is disabled. In this state, only

external communications to and from the isolated QDIO

data connection are allowed. If you choose to deploy

an external ﬁ rewall to control the access between hosts

on an isolated virtual switch and sharing LPARs then an

external ﬁ rewall needs to be conﬁ gured and each indi-

vidual host and or LPAR must have a route added to their

TCP/IP stack to forward local trafﬁ c to the ﬁ rewall.

QDIO data connection isolation applies to the z/VM 5.3 and

5.4 with PTFs environment and to all of the OSA-Express3

and OSA-Express2 features (CHPID type OSD) on System

z10 and to the OSA-Express2 features on System z9.

Network Trafﬁ c Analyzer

With the large volume and complexity of today’s network

trafﬁ c, the z10 BC offers systems programmers and net-

work administrators the ability to more easily solve net-

work problems. With the introduction of the OSA-Express

Network Trafﬁ c Analyzer and QDIO Diagnostic Synchro-

nization on the System z and available on the z10 BC,

customers will have the ability to capture trace/trap data

and forward it to z/OS 1.8 tools for easier problem determi-

nation and resolution.

This function is designed to allow the operating system

to control the sniffer trace for the LAN and capture the

records into host memory and storage (ﬁ le systems), using

existing host operating system tools to format, edit, and

process the sniffer records.

OSA-Express Network Trafﬁ c Analyzer is exclusive to the

z10 BC, z9 BC, z10 EC, and z9 EC, and is applicable

to the OSA-Express3 and OSA-Express2 features when

conﬁ gured as CHPID type OSD (QDIO), and is supported

by z/OS.

Dynamic LAN idle for z/OS

Dynamic LAN idle is designed to reduce latency and

improve network performance by dynamically adjusting

the inbound blocking algorithm. When enabled, the z/OS

TCP/IP stack is designed to adjust the inbound blocking

algorithm to best match the application requirements.

For latency sensitive applications, the blocking algo-

rithm is modiﬁ ed to be “latency sensitive.” For streaming

(throughput sensitive) applications, the blocking algorithm

is adjusted to maximize throughput. The z/OS TCP/IP stack

can dynamically detect the application requirements,

making the necessary adjustments to the blocking algo-

rithm. The monitoring of the application and the blocking

algorithm adjustments are made in real-time, dynamically

adjusting the application’s LAN performance.

System administrators can authorize the z/OS TCP/IP stack

to enable a dynamic setting, which was previously a static

setting. The z/OS TCP/IP stack is able to help determine

the best setting for the current running application, based

on system conﬁ guration, inbound workload volume, CPU

utilization, and trafﬁ c patterns.

OSA-Express2 (or OSA-Express3) port to the z/VM operat-

ing system when the port is participating in an aggregated

group when conﬁ gured in Layer 2 mode. Link aggregation

(trunking) is designed to allow you to combine multiple

physical OSA-Express3 and OSA-Express2 ports (of the

same type for example 1GbE or 10GbE) into a single logi-

cal link for increased throughput and for nondisruptive

failover in the event that a port becomes unavailable.

• Aggregated link viewed as one logical trunk and con-

taining all of the Virtual LANs (VLANs) required by the

LAN segment

• Load balance communications across several links in a

trunk to prevent a single link from being overrun

• Link aggregation between a VSWITCH and the physical

network switch

• Point-to-point connections

• Up to eight OSA-Express3 or OSA-Express2 ports in one

aggregated link

• Ability to dynamically add/remove OSA ports for “on

demand” bandwidth

• Full-duplex mode (send and receive)

• Target links for aggregation must be of the same type

(for example, Gigabit Ethernet to Gigabit Ethernet)

The Open Systems Adapter/Support Facility (OSA/SF) will

provide status information on an OSA port – its “shared” or

“exclusive use” state. OSA/SF is an integrated component

of z/VM.

Link aggregation for z/VM in Layer 2 mode

z/VM Virtual Switch-controlled (VSWITCH-controlled) link

aggregation (IEEE 802.3ad) allows you to dedicate an

Link aggregation is exclusive to System z10 and System

z9, is applicable to the OSA-Express3 and OSA-Express2

features in Layer 2 mode when conﬁ gured as CHPID type

OSD (QDIO), and is supported by z/VM 5.3 and later.

Layer 2 transport mode: When would it be used?

If you have an environment with an abundance of Linux

images in a guest LAN environment, or you need to deﬁ ne

router guests to provide the connection between these

guest LANs and the OSA-Express3 features, then using the

Layer 2 transport mode may be the solution. If you have

Internetwork Packet Exchange (IPX), NetBIOS, and SNA pro-

tocols, in addition to Internet Protocol Version 4 (IPv4) and

IPv6, use of Layer 2 could provide “protocol independence.”

The OSA-Express3 features have the capability to perform

like Layer 2 type devices, providing the capability of being

protocol- or Layer-3-independent (that is, not IP-only).

the Layer 2 interface, packet forwarding decisions

With

are based

of Network

system attached

upon Link Layer (Layer 2) information, instead

Layer (Layer 3) information. Each operating

to the Layer 2 interface uses its own MAC

address. This means the trafﬁ c can be IPX, NetBIOS, SNA,

IPv4, or IPv6.

An OSA-Express3 feature can ﬁ lter inbound datagrams by

Virtual Local Area Network identiﬁ cation (VLAN ID, IEEE

802.1q), and/or the Ethernet destination MAC address. Fil-

tering can reduce the amount of inbound trafﬁ c being pro-

cessed by the operating system, reducing CPU utilization.

OSA Layer 3 Virtual MAC for z/OS

To simplify the infrastructure and to facilitate load balanc-

ing when an LPAR is sharing the same OSA Media Access

Control (MAC) address with another LPAR, each operating

system instance can now have its own unique “logical” or

“virtual” MAC (VMAC) address. All IP addresses associ-

ated with a TCP/IP stack are accessible using their own

VMAC address, instead of sharing the MAC address of

an OSA port. This applies to Layer 3 mode and to an OSA

port shared among Logical Channel Subsystems.

This support is designed to:

• Improve IP workload balancing

• Dedicate a Layer 3 VMAC to a single TCP/IP stack

• Remove the dependency on Generic Routing Encapsu-

lation (GRE) tunnels

• Improve outbound routing

• Simplify conﬁ guration setup

• Allow WebSphere Application Server content-based

routing to work with z/OS in an IPv6 network

• Allow z/OS to use a “standard” interface ID for IPv6

addresses

• Remove the need for PRIROUTER/SECROUTER function

in z/OS

Layer 2 transport mode is supported by z/VM and Linux on

System z.

OSA Layer 3 VMAC for z/OS is exclusive to System z, and

is applicable to OSA-Express3 and OSA-Express2 features

when conﬁ gured as CHPID type OSD (QDIO).

Direct Memory Access (DMA)

OSA-Express3 and the operating systems share a

common storage area for memory-to-memory communi-

cation, reducing system overhead and improving perfor-

mance. There are no read or write channel programs for

data exchange. For write processing, no I/O interrupts

have to be handled. For read processing, the number of

I/O interrupts is minimized.

Hardware data router

With OSA-Express3, much of what was previously done in

ﬁ rmware (packet construction, inspection, and routing) is

now performed in hardware. This allows packets to ﬂ ow

directly from host memory to the LAN without ﬁ rmware

intervention.

With the hardware data router, the “store and forward”

technique is no longer used, which enables true direct

memory access, a direct host memory-to-LAN ﬂ ow, return-

ing CPU cycles for application use.

This avoids a “hop” and is designed to reduce latency and

to increase throughput for standard frames (1492 byte)

and jumbo frames (8992 byte).

CCL helps preserve mission critical SNA functions, such

as SNI, and z/OS applications workloads which depend

upon these functions, allowing you to collapse SNA inside

a z10 BC while exploiting and leveraging IP.

The OSA-Express3 and OSA-Express2 GbE and

1000BASE-T Ethernet features provide support for CCL.

This support is designed to require no changes to operat-

ing systems (does require a PTF to support CHPID type

OSN) and also allows TPF to exploit CCL. Supported by

z/VM for Linux and z/TPF guest environments.

OSA-Express3 and OSA-Express2 OSN (OSA for NCP)

OSA-Express for Network Control Program (NCP), Channel

path identiﬁ er (CHPID) type OSN, is now available for use

with the OSA-Express3 GbE features as well as the OSA-

Express3 1000BASE-T Ethernet features.

OSA-Express for NCP, supporting the channel data link

control (CDLC) protocol, provides connectivity between

System z operating systems and IBM Communication Con-

troller for Linux (CCL). CCL allows you to keep your busi-

ness data and applications on the mainframe operating

systems while moving NCP functions to Linux on System z.

IBM Communication Controller for Linux (CCL)

CCL is designed to help eliminate hardware dependen-

cies, such as 3745/3746 Communication Controllers,

ESCON channels, and Token Ring LANs, by providing a

software solution that allows the Network Control Program

(NCP) to be run in Linux on System z freeing up valuable

data center ﬂ oor space.

CCL provides a foundation to help enterprises simplify

their network infrastructure while supporting traditional

Systems Network Architecture (SNA) functions such as

SNA Network Interconnect (SNI).

Communication Controller for Linux on System z (Program

Number 5724-J38) is the solution for companies that

want to help improve network availability by replacing

Token-Ring networks and ESCON channels with an Ether-

net network and integrated LAN adapters on System z10,

OSA-Express3 or OSA-Express2 GbE or 1000BASE-T.

OSA-Express for NCP is supported in the z/OS, z/VM,

z/VSE, TPF, z/TPF, and Linux on System z environments.

OSA Integrated Console Controller

The OSA-Express Integrated Console Controller

(OSA-ICC) support is a no-charge function included in

Licensed Internal Code (LIC) on z10 BC, z10 EC, z9 EC,

z9 BC, z990, and z890 servers. It is available via the

OSA-Express2 and OSA-Express 1000BASE-T Ethernet

features, and supports Ethernet-attached TN3270E con-

soles.

The OSA-ICC provides a system console function at IPL

time and operating systems support for multiple logical

partitions. Console support can be used by z/OS, z/OS.e,

z/VM, z/VSE, z/TPF, and TPF. The OSA-ICC also supports

local non-SNA DFT 3270 and 328x printer emulation for

™

TSO/E, CICS, IMS

communicates through VTAM

, or any other 3270 application that

With the OSA-Express3 and OSA-Express2 1000BASE-T

Ethernet features, the OSA-ICC is conﬁ gured on a port by

port basis, using the Channel Path Identiﬁ er (CHPID) type

OSC. Each port can support up to 120 console session

connections, can be shared among logical partitions using

Multiple Image Facility (MIF), and can be spanned across

multiple Channel Subsystems (CSSs).

Remove L2/L3 LPAR-to-LPAR Restriction

OSA port sharing between virtual switches can communi-

cate whether the transport mode is the same (Layer 2 to

Layer 2) or different (Layer 2 to Layer 3). This enhance-

ment is designed to allow seamless mixing of Layer 2 and

Layer 3 trafﬁ c, helping to reduce the total cost of network-

ing. Previously, Layer 2 and Layer 3 TCP/IP connections

through the same OSA port (CHPID) were unable to com-

municate with each other LPAR-to-LPAR using the Multiple

Image Facility (MIF).

This enhancement is designed to facilitate a migration

from Layer 3 to Layer 2 and to continue to allow LAN

administrators to conﬁ gure and manage their mainframe

network topology using the same techniques as their non-

mainframe topology.

OSA/SF Virtual MAC and VLAN id Display Capability

The Open Systems Adapter/Support Facility (OSA/SF) has

the capability to support virtual Medium Access Control

(MAC) and Virtual Local Area Network (VLAN) identiﬁ ca-

tions (IDs) associated with OSA-Express2 feature conﬁ g-

ured as a Layer 2 interface. This information will now be

displayed as a part of an OSA Address Table (OAT) entry.

This information is independent of IPv4 and IPv6 formats.

There can be multiple Layer 2 VLAN Ids associated to a

single unit address. One group MAC can be associated to

multiple unit addresses.

For additional information, view IBM Redbooks, IBM

System z Connectivity Handbook (SG24-5444) at:

www.redbooks.ibm.com/.

HiperSockets

The HiperSockets function, also known as internal Queued

Direct Input/Output (iDQIO) or internal QDIO, is an inte-

grated function of the z10 BC server that provides users

with attachments to up to sixteen high-speed “virtual”

Local Area Networks (LANs) with minimal system and

network overhead. HiperSockets eliminates the need to

utilize I/O subsystem operations and the need to traverse

an external network connection to communicate between

logical partitions in the same z10 BC server.

Now, the HiperSockets internal networks on z10 BC can

support two transport modes: Layer 2 (Link Layer) as well

as the current Layer 3 (Network or IP Layer). Trafﬁ c can

be Internet Protocol (IP) version 4 or version 6 (IPv4, IPv6)

or non-IP (AppleTalk, DECnet, IPX, NetBIOS, or SNA).

HiperSockets devices are now protocol-independent and

Layer 3 independent. Each HiperSockets device has its

own Layer 2 Media Access Control (MAC) address, which

is designed to allow the use of applications that depend

on the existence of Layer 2 addresses such as DHCP

servers and ﬁ rewalls.

A HiperSockets device can ﬁ lter inbound datagrams by

Virtual Local Area Network identiﬁ cation (VLAN ID, IEEE

802.1q), the Ethernet destination MAC address, or both.

Filtering can help reduce the amount of inbound traf-

ﬁ c being processed by the operating system, helping to

reduce CPU utilization.

Analogous to the respective Layer 3 functions, HiperSockets

Layer 2 devices can be conﬁ gured as primary or secondary

connectors or multicast routers. This is designed to enable

the creation of high performance and high availability Link

Layer switches between the internal HiperSockets network

and an external Ethernet or to connect the HiperSockets

Layer 2 networks of different servers. The HiperSockets

Multiple Write Facility for z10 BC is also supported for

Layer 2 HiperSockets devices, thus allowing performance

improvements for large Layer 2 datastreams.

HiperSockets Layer 2 support is exclusive to System z10

and is supported by z/OS, Linux on System z environ-

ments, and z/VM for Linux guest exploitation.

Layer 2 support can help facilitate server consolidation.

Complexity can be reduced, network conﬁ guration is

simpliﬁ ed and intuitive, and LAN administrators can con-

ﬁ gure and maintain the mainframe environment the same

as they do a non-mainframe environment. With support

of the new Layer 2 interface by HiperSockets, packet

forwarding decisions are now based upon Layer 2 infor-

mation, instead of Layer 3 information. The HiperSockets

device performs automatic MAC address generation and

assignment to allow uniqueness within and across logical

partitions (LPs) and servers. MAC addresses can also be

locally administered. The use of Group MAC addresses

for multicast is supported as well as broadcasts to all

other Layer 2 devices on the same HiperSockets network.

Datagrams are only delivered between HiperSockets

devices that are using the same transport mode (Layer 2

with Layer 2 and Layer 3 with Layer 3). A Layer 2 device

cannot communicate directly with a Layer 3 device in

another LPAR.

HiperSockets Multiple Write Facility for increased performance

Though HiperSockets provides high-speed internal TCP/IP

connectivity between logical partitions within a System z

server – the problem is that HiperSockets draws excessive

CPU utilization for large outbound messages. This may

lead to increased software licensing cost – HiperSock-

ets large outbound messages are charged to a general

CPU which can incur high general purpose CPU costs.

This may also lead to some performance issues due to

synchronous application blocking – HiperSockets large

outbound messages will block a sending application while

synchronously moving data.

A solution is HiperSockets Multiple Write Facility.

HiperSockets performance has been enhanced to allow

for the streaming of bulk data over a HiperSockets link

between logical partitions (LPARs). The receiving LPAR

can now process a much larger amount of data per I/O

interrupt. This enhancement is transparent to the operating

system in the receiving LPAR. HiperSockets Multiple Write

Facility, with fewer I/O interrupts, is designed to reduce

CPU utilization of the sending and receiving LPAR.

The HiperSockets Multiple Write solution moves multiple

output data buffers in one write operation.

If the function is disabled then one output data buffer is

moved in one write operation. This is also how HiperSockets

functioned in the past.

If the function is enabled then multiple output data buf-

fers are moved in one write operation. This reduces CPU

utilization related to large outbound messages. When

enabled, HiperSockets Multiple Write will be used anytime

a message spans an IQD frame requiring multiple output

data buffers (SBALs) to transfer the message. Spanning

multiple output data buffers can be affected by a number

of factors including:

• IQD frame size

• Application socket send size

• TCP send size

• MTU size

The HiperSockets Multiple Write Facility is supported in

the z/OS environment. For a complete description of the

System z10 connectivity capabilities refer to IBM System z

Connectivity Handbook, SG24-5444.

HiperSockets Multiple Write Facility and zIIP enablement

is described as “zIIP-Assisted HiperSockets for large mes-

sages.” zIIP-Assisted HiperSockets can help make highly

secure, available, virtual HiperSockets networking a more

attractive option. z/OS application workloads based on

XML, HTTP, SOAP, Java, etc., as well as traditional ﬁ le

transfer, can beneﬁ t from zIIP enablement by helping to

lower general purpose processor utilization for such TCP/

IP trafﬁ c.

Only outbound z/OS TCP/IP large messages which origi-

nate within a z/OS host are eligible for HiperSockets zIIP-

Assisted processing. Other types of network trafﬁ c such

as IP forwarding, Sysplex Distributor, inbound processing,

small messages, or other non TCP/IP network protocols

are not eligible for zIIP-Assisted HiperSockets. When the

workload is eligible, then the TCP/IP HiperSockets device

driver layer (write) processing is redirected to a zIIP,

which will unblock the sending application. zIIP Assisted

HiperSockets for large messages is available with z/OS

V1.10 with PTF and System z10 only. This feature is unsup-

ported if z/OS is running as a guest in a z/VM environment

and is supported for large outbound messages only.

To estimate potential ofﬂ oad, use PROJECTCPU for current

and existing workloads. This is accurate and very simple,

but you have to be on z/OS 1.10 with the enabling PTFs

AND System z10 server AND you need to be performing

HiperSockets Multiple Write workload already on z/OS.

HiperSockets Enhancement for zIIP Exploitation

In z/OS V1.10, speciﬁ cally, the z/OS Communications

Server allows the HiperSockets Multiple Write Facility

processing for outbound large messages originating

from z/OS to be performed on a zIIP. The combination of

Security Cryptography

Today’s world mandates that your systems are secure and

available 24/7. The z10 BC employs some of the most

advanced security technologies in the industry—helping

you to meet rigid regulatory requirements that include

encryption solutions, access control management, and

extensive auditing features. It also provides disaster recov-

ery conﬁ gurations and is designed to deliver 99.999%

application availability to help avoid the downside of

planned downtime, equipment failure, or the complete loss

of a data center.

When you need to be more secure, more resilient —

z Can Do IT. The z10 processor chip has on board cryp-

tographic functions. Standard clear key integrated crypto-

graphic coprocessors provide high speed cryptography

for protecting data in storage. CP Assist for Cryptographic

Function (CPACF) supports DES, TDES, Secure Hash Algo-

rithms (SHA) for up to 512 bits, Advanced Encryption Stan-

dard (AES) for up to 256 bits and Pseudo Random Number

Generation (PRNG). Audit logging has been added to the

new TKE workstation to enable better problem tracking.

System z is investing in accelerators that provide improved

performance for specialized functions. The Crypto

Express2 feature for cryptography is an example. The

Crypto Express2 feature can be conﬁ gured as a secure

key coprocessor or for Secure Sockets Layer (SSL) accel-

eration. The feature includes support for 13, 14, 15, 16, 17,

18 and 19 digit Personal Account Numbers for stronger

protection of data. And the tamper-resistant cryptographic

coprocessor is certiﬁ ed at FIPS 140-2 Level 4. To help cus-

tomers scale their Crypto Express2 investments for their

business needs, Crypto Express2 is also available on z10

BC as a single PCI-X adapter which may be deﬁ ned as

either a coprocessor or an accelerator.

System z security is one of the many reasons why the

world’s top banks and retailers rely on the IBM mainframe

to help secure sensitive business transactions.

z Can Do IT securely.

The z10 BC includes both standard cryptographic hard-

ware and optional cryptographic features for ﬂ exibility and

growth capability. IBM has a long history of providing hard-

ware cryptographic solutions, from the development of

Data Encryption Standard (DES) in the 1970s to delivering

integrated cryptographic hardware in a server to achieve

the US Government’s highest FIPS 140-2 Level 4 rating for

secure cryptographic hardware.

The IBM System z10 BC cryptographic functions include

the full range of cryptographic operations needed for e-

business, e-commerce, and ﬁ nancial institution applica-

tions. In addition, custom cryptographic functions can be

added to the set of functions that the z10 BC offers.

New integrated clear key encryption security features on

z10 BC include support for a higher advanced encryption

standard and more secure hashing algorithms. Performing

these functions in hardware is designed to contribute to

improved performance.

Enhancements to eliminate preplanning in the cryptogra-

phy area include the System z10 function to dynamically

add Crypto to a logical partition. Changes to image pro-

ﬁ les, to support Crypto Express2 features, are available

without an outage to the logical partition. Crypto Express2

features can also be dynamically deleted or moved.

CP Assist for Cryptographic Function (CPACF)

CPACF supports clear-key encryption. All CPACF func-

tions can be invoked by problem state instructions deﬁ ned

by an extension of System z architecture. The function is

activated using a no-charge enablement feature and offers

the following on every CPACF that is shared between two

Processor Units (PUs) and designated as CPs and/or Inte-

grated Facility for Linux (IFL):

• DES, TDES, AES-128, AES-192, AES-256

• SHA-1, SHA-224, SHA-256, SHA-384, SHA-512

• Pseudo Random Number Generation (PRNG)

Enhancements to CP Assist for Cryptographic Function (CPACF):

CPACF has been enhanced to include support of the fol-

lowing on CPs and IFLs:

• Advanced Encryption Standard (AES) for 192-bit keys

and 256-bit keys

• SHA-384 and SHA-512 bit for message digest

SHA-1, SHA-256, and SHA-512 are shipped enabled and

do not require the enablement feature.

Support for CPACF is also available using the Integrated

Cryptographic Service Facility (ICSF). ICSF is a com-

ponent of z/OS, and is designed to transparently use

the available cryptographic functions, whether CPACF

or Crypto Express2, to balance the workload and help

address the bandwidth requirements of your applications.

The enhancements to CPACF are exclusive to the System

z10 and supported by z/OS, z/VM, z/VSE, and Linux on

System z.

Crypto Express2 Accelerator – for Secure Sockets Layer

(SSL) acceleration:

• Is designed to support clear-key RSA operations

• Ofﬂ oads compute-intensive RSA public-key and private-

key cryptographic operations employed in the SSL pro-

tocol Crypto Express2 features can be carried forward

on an upgrade to the System z10 BC, so users may con-

tinue to take advantage of the SSL performance and the

conﬁ guration capability

The conﬁ gurable Crypto Express2 feature is supported by

z/OS, z/VM, z/VSE, and Linux on System z. z/VSE offers

support for clear-key operations only. Current versions of

z/OS, z/VM, and Linux on System z offer support for both

clear-key and secure-key operations.

Crypto Express2-1P

An option of one PCI-X adapter per feature, in addition

to the current two PCI-X adapters per feature, is being

offered for the z10 BC to help satisfy small and midrange

security requirements while maintaining high performance.

Conﬁ gurable Crypto Express2

The Crypto Express2 feature has two PCI-X adapters.

Each of the PCI-X adapters can be deﬁ ned as either a

Coprocessor or an Accelerator.

Crypto Express2 Coprocessor – for secure-key encrypted

transactions (default) is:

• Designed to support security-rich cryptographic func-

tions, use of secure-encrypted-key values, and User

Deﬁ ned Extensions (UDX)

• Designed to support secure and clear-key RSA opera-

tions

• The tamper-responding hardware and lower-level ﬁ rm-

ware layers are validated to U.S. Government FIPS 140-

2 standard: Security Requirements for Cryptographic

Modules at Level 4

The Crypto Express2-1P feature, with one PCI-X adapter,

can continue to be deﬁ ned as either a Coprocessor or an

Accelerator. A minimum of two features must be ordered.

Additional cryptographic functions and features with

Crypto Express2 and Crypto Express2-1P.

Key management – Added key management for remote

loading of ATM and Point of Sale (POS) keys. The elimina-

tion of manual key entry is designed to reduce downtime

due to key entry errors, service calls, and key manage-

ment costs.

Improved key exchange – Added Improved key

exchange with non-CCA cryptographic systems. New fea-

tures added to IBM Common Cryptographic Architecture

(CCA) are designed to enhance the ability to exchange

keys between CCA systems, and systems that do not

use control vectors by allowing the CCA system owner

to deﬁ ne permitted types of key import and export while

preventing uncontrolled key exchange that can open the

system to an increased threat of attack.

These are supported by z/OS and by z/VM for guest

exploitation.

Support for ISO 16609

Support for ISO 16609 CBC Mode T-DES Message

Authentication (MAC) requirements ISO 16609 CBC Mode

T-DES MAC is accessible through ICSF function calls

made in the PCI-X Cryptographic Adapter segment 3

Common Cryptographic Architecture (CCA) code.

This is supported by z/OS and by z/VM for guest exploita-

tion.

Support for RSA keys up to 4096 bits

The RSA services in the CCA API are extended to sup-

port RSA keys with modulus lengths up to 4096 bits. The

services affected include key generation, RSA-based

key management, digital signatures, and other functions

related to these.

Refer to the ICSF Application Programmers Guide, SA22-

7522, for additional details.

Cryptographic enhancements to Crypto Express2 and Crypto Express2-1P

Dynamically add crypto to a logical partition.

Today, users can preplan the addition of Crypto Express2

features to a logical partition (LP) by using the Crypto

page in the image proﬁ le to deﬁ ne the Cryptographic

Candidate List, Cryptographic Online List, and Usage and

Control Domain Indexes in advance of crypto hardware

installation.

With the change to dynamically add crypto to a logical

partition, changes to image proﬁ les, to support Crypto

Express2 features, are available without outage to the

logical partition. Users can also dynamically delete or

move Crypto Express2 features. Preplanning is no longer

required.

This enhancement is supported by z/OS, z/VM for guest

exploitation, z/VSE, and Linux on System z.

Secure Key AES

The Advanced Encryption Standard (AES) is a National

Institute of Standards and Technology speciﬁ cation for the

encryption of electronic data. It is expected to become the

accepted means of encrypting digital information, includ-

ing ﬁ nancial, telecommunications, and government data.

AES is the symmetric algorithm of choice, instead of Data

Encryption Standard (DES) or Triple-DES, for the encryp-

tion and decryption of data. The AES encryption algorithm

will be supported with secure (encrypted) keys of 128,

192, and 256 bits. The secure key approach, similar to

what is supported today for DES and TDES, provides the

ability to keep the encryption keys protected at all times,

including the ability to import and export AES keys, using

RSA public key technology.

Support for AES encryption algorithm includes the master

key management functions required to load or generate

AES master keys, update those keys, and re-encipher key

tokens under a new master key.

Support for 13- thru 19-digit Personal Account Numbers

Credit card companies sometimes perform card security

code computations based on Personal Account Number

(PAN) data. Currently, ICSF callable services CSNBCSV

(VISA CVV Service Verify) and CSNBCSG (VISA CVV

Service Generate) are used to verify and to generate a

VISA Card Veriﬁ cation Value (CVV) or a MasterCard Card

Veriﬁ cation Code (CVC). The ICSF callable services cur-

rently support 13-, 16-, and 19-digit PAN data. To provide

additional ﬂ exibility, new keywords PAN-14, PAN-15, PAN-

17, and PAN-18 are implemented in the rule array for both

CSNBCSG and CSNBCSV to indicate that the PAN data is

comprised of 14, 15, 17, or 18 PAN digits, respectively.

Support for 13- through 19-digit PANs is exclusive to

System z10 and is offered by z/OS and z/VM for guest

exploitation.

Enhancement with TKE 5.3 LIC

The TKE 5.3 level of LIC includes support for the AES

encryption algorithm, adds 256-bit master keys, and

includes the master key management functions required to

load or generate AES master keys to cryptographic copro-

cessors in the host.

Also included is an imbedded screen capture utility to

permit users to create and to transfer TKE master key entry

instructions to diskette or DVD. Under ‘Service Manage-

ment’ a “Manage Print Screen Files” utility will be available

to all users.

The TKE workstation and TKE 5.3 LIC are available on the

z10 EC, z10 BC, z9 EC, and z9 BC.

Smart Card Reader

Support for an optional Smart Card Reader attached to

the TKE 5.3 workstation allows for the use of smart cards

that contain an embedded microprocessor and associated

memory for data storage. Access to and the use of con-

ﬁ dential data on the smart cards is protected by a user-

deﬁ ned Personal Identiﬁ cation Number (PIN).

TKE 5.3 workstation

The Trusted Key Entry (TKE) workstation and the TKE

5.3 level of Licensed Internal Code are optional features

on the System z10 BC. The TKE 5.3 Licensed Internal

Code (LIC) is loaded on the TKE workstation prior to ship-

ment. The TKE workstation offers security-rich local and

remote key management, providing authorized persons a

method of operational and master key entry, identiﬁ cation,

exchange, separation, and update. The TKE workstation

supports connectivity to an Ethernet Local Area Network

(LAN) operating at 10 or 100 Mbps. Up to ten TKE work-

stations can be ordered.

TKE 5.3 LIC has added the capability to store key parts

on DVD-RAMs and continues to support the ability to store

key parts on paper, or optionally on a smart card. TKE 5.3

LIC has limited the use of ﬂ oppy diskettes to read-only.

The TKE 5.3 LIC can remotely control host cryptographic

coprocessors using a password-protected authority signa-

ture key pair either in a binary ﬁ le or on a smart card.

The Smart Card Reader, attached to a TKE workstation

with the 5.3 level of LIC will support System z10 BC,

z10 EC, z9 EC, and z9 BC. However, TKE workstations

with 5.0, 5.1 and 5.2 LIC must be upgraded to TKE 5.3

LIC.

TKE additional smart cards – new feature

You have the capability to order Java-based blank smart

cards which offers a highly efﬁ cient cryptographic and

data management application built-in to read-only memory

for storage of keys, certiﬁ cates, passwords, applications,

and data. The TKE blank smart cards are compliant with

FIPS 140-2 Level 2. When you place an order for a quantity

of one, you are shipped 10 smart cards.

System z10 BC cryptographic migration

Clients using a User Deﬁ ned Extension (UDX) of the

Common Cryptographic Architecture should contact their

UDX provider for an application upgrade before order-

ing a new System z10 BC machine; or before planning to

migrate or activate a UDX application to ﬁ rmware driver

level 73 and higher.

• The Crypto Express2 feature is supported on the z9

BC and can be carried forward on an upgrade to the

System z10 BC

• You may continue to use TKE workstations with 5.3

licensed internal code to control the System z10 BC

• TKE 5.0 and 5.1 workstations (#0839 and #0859) may

be used to control z9 EC, z9 BC, z890, and IBM eServer

zSeries 990 (z990) servers

Remote Key Loading Beneﬁ ts

• Provides a mechanism to load initial ATM keys without

the need to send technical staff to ATMs

• Reduces downtime due to key entry errors

• Reduces service call and key management costs

• Improves the ability to manage ATM conversions and

upgrades

Integrated Cryptographic Service Facility (ICSF), together

with Crypto Express2, support the basic mechanisms in

Remote Key Loading. The implementation offers a secure

bridge between the highly secure Common Cryptographic

Architecture (CCA) environment and the various formats

and encryption schemes offered by the ATM vendors. The

following ICSF services are offered for Remote Key loading:

•

Trusted Block Create (CSNDTBC): This callable service

is used to create a trusted block containing a public

key

and some processing rules

• Remote Key Export (CSNDRKX): This callable service

uses the trusted block to generate or export DES keys

for local use and for distribution to an ATM or other

remote device

Refer to Application Programmers Guide, SA22-7522, for

additional details.

Remote Loading of Initial ATM Keys

Typically, a new ATM has none of the ﬁ nancial institution’s

keys installed. Remote Key Loading refers to the pro-

cess of loading Data Encryption Standard (DES) keys to

Automated Teller Machines (ATMs) from a central admin-

istrative site without the need for personnel to visit each

machine to manually load DES keys. This has been done

by manually loading each of the two clear text key parts

individually and separately into ATMs. Manual entry of

keys is one of the most error-prone and labor-intensive

activities that occur during an installation, making it expen-

sive for the banks and ﬁ nancial institutions.

Improved Key Exchange With Non-CCA Cryptographic Systems

IBM Common Cryptographic Architecture (CCA) employs

Control Vectors to control usage of cryptographic keys.

Non-CCA systems use other mechanisms, or may use

keys that have no associated control information. This

enhancement provides the ability to exchange keys

between CCA systems, and systems that do not use Con-

trol Vectors. Additionally, it allows the CCA system owner

to deﬁ ne permitted types of key import and export which

can help to prevent uncontrolled key exchange that can

open the system to an increased threat of attack.

These enhancements are exclusive to System z10, and

System z9 and are supported by z/OS and z/VM for z/OS

guest exploitation.

On Demand Capabilities

It may sound revolutionary, but it’s really quite simple. In

the highly unpredictable world of On Demand business,

you should get what you need, when you need it. And you

should pay for only what you use. Radical? Not to IBM. It’s

the basic principle underlying IBM capacity on demand for

the IBM System z10.

The z10 BC also introduces a architectural approach for

temporary offerings that can change the thinking about on

demand capacity. One or more ﬂ exible conﬁ guration deﬁ -

nitions can be used to solve multiple temporary situations

and multiple capacity conﬁ gurations can be active at once

(for example, activation of just two CBUs out of a deﬁ nition

that has four CBUs is acceptable). This means that On/Off

CoD can be active and up to seven other offerings can be

active simultaneously. Tokens can be purchased for On/Off

CoD so hardware activations can be prepaid.

All activations can be done without having to interact with

IBM—when it is determined that capacity is required, no

passwords or phone connections are necessary. As long

as the total z10 BC can support the maximums that are

deﬁ ned, then they can be made available. With the z10

BC it is now possible to add permanent capacity while a

temporary capacity is currently activated, without having to

return ﬁ rst to the original conﬁ guration.

Capacity on Demand – Temporary Capacity

The set of contract documents which support the various

Capacity on Demand offerings available for z10 BC has

been completely refreshed. While customers with exist-

ing contracts for Capacity Back Up (CBU) and Customer

Initiated Upgrade (CIU) – On/Off Capacity on Demand

(On/Off CoD) may carry those contracts forward to z10 BC

machines, new CoD capability and offerings for z10 BC is

only supported by this new contract set.

The new contract set is structured in a modular, hierarchi-

cal approach. This new approach will eliminate redundant

terms between contract documents, simplifying the con-

tracts for our customers and IBM.

Just-in-time deployment of System z10 BC Capacity on

Demand (CoD) is a radical departure from previous System

z and zSeries servers. This new architecture allows:

• Up to eight temporary records to be installed on the CPC

and active at any given time

• Up to 200 temporary records to be staged on the SE

• Variability in the amount of resources that can be acti-

vated per record

• The ability to control and update records independent of

each other

• Improved query functions to monitor the state of each

record

• The ability to add capabilities to individual records con-

currently, eliminating the need for constant ordering of

new temporary records for different user scenarios

• Permanent LIC-CC upgrades to be performed while

temporary resources are active

These capabilities allow you to access and manage pro-

cessing capacity on a temporary basis, providing increased

ﬂ exibility for on demand environments. The CoD offerings

are built from a common Licensed Internal Code – Conﬁ gu-

ration Code (LIC-CC) record structure. These

Entitlement Records (TERs) contain the information neces-

sary to control which type of resource can be accessed

and to what extent, how many times and for how long, and

under what condition – test or real workload. Use of this

information gives the different offerings their personality.

Capacity Back Up (CBU): Temporary access to dormant

processing units (PUs), intended to replace capacity lost

within the enterprise due to a disaster. CP capacity or any

and all specialty engine types (zIIP, zAAP, SAP, IFL, ICF)

Temporary

can be added up to what the physical hardware model

can contain for up to 10 days for a test activation or 90

days for a true disaster recovery.

On system z10 the CBU entitlement records contain an

expiration date that is established at the time of order

and is dependent upon the quantity of CBU years. You

will now have the capability to extend your CBU entitle-

ments through the purchase of additional CBU years. The

number of CBU years per instance of CBU entitlement

remains limited to ﬁ ve and fractional years are rounded up

to the near whole integer when calculating this limit. For

instance, if there are two years and eight months to the

expiration date at the time of order, the expiration date can

be extended by no more than two additional years. One

test activation is provided for each additional CBU year

added to the CBU entitlement record.

CBU Tests: The allocation of the default number of test

activations changed. Rather than a ﬁ xed default number

of ﬁ ve test activations for each CBU entitlement record,

the number of test activations per instance of the CBU

entitlement record will coincide with the number of CBU

years, the number of years assigned to the CBU record.

This equates to one test activation per year for each CBU

entitlement purchased.Additional test activations are now

available in quantities of one and the number of test acti-

vations remains limited at 15 per CBU entitlement record.

These changes apply only to System z10 and to CBU

entitlements purchased through the IBM sales channel or

directly from Resource Link.

There are terms governing System z Capacity Back Up

(CBU) now available which allow customers to execute

production workload on a CBU Upgrade during a CBU

Test.

While all new CBU contract documents contain the new

CBU Test terms, existing CBU customers will need to exe-

cute a contract to expand their authorization for CBU Test

upgrades if they want to have the right to execute produc-

tion workload on the CBU Upgrade during a CBU Test.

Amendment for CBU Tests

The modiﬁ cation of CBU Test terms is available for existing

CBU customers via the IBM Customer Agreement Amend-

ment for IBM System z Capacity Backup Upgrade Tests (in

the US this is form number Z125-8145). This amendment

can be executed at any time, and separate from any par-

ticular order.

Capacity for Planned Event (CPE): Temporary access

to dormant PUs, intended to replace capacity lost within

the enterprise due to a planned event such as a facility

upgrade or system relocation. This offering is available

only on the System z10. CPE is similar to CBU in that it is

intended to replace lost capacity; however, it differs in its

scope and intent. Where CBU addresses disaster

recovery

scenarios that can take up to three months to remedy, CPE

is intended for short-duration events lasting up to three

days, maximum. Each CPE record, once activated, gives

you access to all dormant PUs on the machine that can be

conﬁ gured in any combination of CP capacity or specialty

engine types (zIIP, zAAP, SAP, IFL, ICF).

On/Off Capacity on Demand (On/Off CoD): Temporary

access to dormant PUs, intended to augment the existing

capacity of a given system. On/Off CoD helps you contain

workload spikes that may exceed permanent capacity

such that Service Level Agreements cannot be met and

business conditions do not justify a permanent upgrade.

An On/Off CoD record allows you to temporarily add CP

capacity or any and all specialty engine types (zIIP, zAAP,

SAP, IFL, ICF) up to the following limits:

• The quantity of temporary CP capacity ordered is limited

by the quantity of purchased CP capacity (permanently

active plus unassigned)

• The quantity of temporary IFLs ordered is limited by

quantity of purchased IFLs (permanently active plus

unassigned)

• Temporary use of unassigned CP capacity or unas-

signed IFLs will not incur a hardware charge

• The quantity of permanent zIIPs plus temporary zIIPs

can not exceed the quantity of purchased (permanent

plus unassigned) CPs plus temporary CPs and the

quantity of temporary zIIPs can not exceed the quantity

of permanent zIIPs

• The quantity of permanent zAAPs plus temporary zAAPs

can not exceed the quantity of purchased (permanent

plus unassigned) CPs plus temporary CPs and the

quantity of temporary zAAPs can not exceed the quan-

tity of permanent zAAPs

The quantity of temporary ICFs ordered is limited by the

•

quantity of permanent ICFs as long as the sum of perma-

nent and temporary ICFs is less than or equal to 16

•

The quantity of temporary SAPs ordered is limited by the

quantity of permanent SAPs as long as the sum of

per-

manent and temporary SAPs is less than or equal to 32

Although the System z10 BC will allow up to eight tempo-

rary records of any type to be installed, only one tempo-

rary On/Off CoD record may be active at any given time.

An On/Off CoD record may be active while other tempo-

rary records are active.

Management of temporary capacity through On/Off CoD

is further enhanced through the introduction of resource

tokens. For CP capacity, a resource token represents

an amount of processing capacity that will result in one

MSU of SW cost for one day – an MSU-day. For specialty

engines, a resource token represents activation of one

engine of that type for one day – an IFL-day, a zIIP-day or

a zAAP-day. The different resource tokens are contained

in separate pools within the On/Off CoD record. The

customer, via the Resource Link ordering process, deter-

mines how many tokens go into each pool. Once On/Off

CoD resources are activated, tokens will be decremented

from their pools every 24 hours. The amount decremented

is based on the highest activation level for that engine type

during the previous 24 hours.

Resource tokens are intended to help customers bound

the hardware costs associated with using On/Off CoD. The

use of resource tokens is optional and they are available

on either a prepaid or post-paid basis. When prepaid, the

customer is billed for the total amount of resource tokens

contained within the On/Off CoD record. When post-paid,

the total billing against the On/Off Cod record is limited by

the total amount of resource tokens contained within the

record. Resource Link will provide the customer an ordering

wizard to help determine how many tokens they need to

purchase for different activation scenarios. Resource tokens

within an On/Off CoD record may also be replenished.

Resource Link offers an ordering wizard to help determine

how many tokens you need to purchase for different acti-

vation scenarios. Resource tokens within an On/Off CoD

record may also be replenished. For more information

on the use and ordering of resource tokens, refer to the

Capacity on Demand Users Guide, SC28-6871.

Capacity Provisioning

Hardware working with software is critical. The activation

of On/Off CoD on z10 EC can be simpliﬁ ed or automated

by using z/OS Capacity Provisioning (available with z/OS

V1.10 and z/OS V1.9). This capability enables the monitor-

ing of multiple systems based on Capacity Provisioning and

Workload Manager (WLM) deﬁ nitions. When the deﬁ ned

conditions are met, z/OS can suggest capacity changes for

manual activation from a z/OS console or the system can

add or remove temporary capacity automatically and with-

out operator intervention. z10 BC Can Do IT better.

z/OS Capacity provisioning allows you to set up rules

deﬁ ning the circumstances under which additional capac-

ity should be provisioned in order to fulﬁ ll a speciﬁ c busi-

ness need. The rules are based on criteria, such as: a

speciﬁ c application, the maximum additional capacity that

should be activated, time and workload conditions. This

support provides a fast response to capacity changes and

ensures sufﬁ cient processing power will be available with

the least possible delay even if workloads ﬂ uctuate.

An installed On/Off CoD record is a necessary prerequisite

for automated control of temporary capacity through z/OS

Capacity Provisioning.

See z/OS MVS Capacity Provisioning User’s Guide (SA33-

8299) for more information.

On/Off CoD Test: On/Off CoD allows for a no-charge test.

No IBM charges are assessed for the test, including IBM

charges associated with temporary hardware capacity,

IBM software, or IBM maintenance. This test can be used

to validate the processes to download, stage, install, acti-

vate, and deactivate On/Off CoD capacity non-disruptively.

Each On/Off CoD-enabled server is entitled to only one no-

charge test. This test may last up to a maximum duration

of 24 hours commencing upon the activation of any capac-

ity resources contained in the On/Off CoD record. Activa-

tion levels of capacity may change during the 24 hour test

period. The On/Off CoD test automatically terminates at

the end of the 24 hours period. In addition to validating

the On/Off CoD function within your environment, you may

choose to use this test as a training session for your per-

sonnel who are authorized to activate On/Off CoD.

SNMP API (Simple Network Management Protocol Appli-

cation Programming Interface) enhancements have also

been made for the new Capacity On Demand features.

More information can be found in the System z10 Capacity

On Demand User’s Guide, SC28-6871.

Capacity on Demand – Permanent Capacity

Customer Initiated Upgrade (CIU) facility: When your

business needs additional capacity quickly, Customer

Initiated Upgrade (CIU) is designed to deliver it. CIU is

designed to allow you to respond to sudden increased

capacity requirements by requesting a System z10 BC PU

and/or memory upgrade via the Web, using IBM Resource

Link, and downloading and applying it to your System z10

BC server using your system’s Remote Support connec-

tion. Further, with the Express option on CIU, an upgrade

may be made available for installation as fast as within a

few hours after order submission.

Permanent upgrades: Orders (MESs) of all PU types and

memory for System z10 BC servers that can be delivered by

Licensed Internal Code, Control Code (LIC-CC) are eligible

for CIU delivery. CIU upgrades may be performed up to the

maximum available processor and memory resources on

the installed server, as conﬁ gured. While capacity upgrades

to the server itself are concurrent, your software may not be

able to take advantage of the increased capacity without

performing an Initial Programming Load (IPL).

System z9 System z10

Resources

CP, zIIP, zAAP, IFL, ICF CP, zIIP, zAAP, IFL, ICF, SAP

Offerings Requires access to IBM/ No password required or

RETAIN® to activate access to IBM/RETAIN to activate CBU, On/Off CoD CBU, On/Off CoD, CPE One offering at a time Multiple offerings active

Permanent Requires de-provisioning Concurrent with temporary upgrades

Replenishment No

of temporary capacity ﬁ rst

offerings

Yes w/ CBU & On/Off CoD

CBU Tests 5 tests per record Up to 15 per record

CBU Expiration No expiration Speciﬁ c term length

Capacity Provisioning No Yes Manager Support

Reliability, Availability, and Serviceability (RAS)

In today’s on demand environment, downtime is not only

unwelcome—it’s costly. If your applications aren’t consis-

tently available, your business suffers. The damage can

extend well beyond the ﬁ nancial realm into key areas of

customer loyalty, market competitiveness and regulatory

compliance. High on the list of critical business require-

ments today is the need to keep applications up and run-

ning in the event of planned or unplanned disruptions to

your systems.

While some servers are thought of offering weeks or even

months of up time, System z thinks of this in terms of

achieving years. The z10 BC continues our commitment

to deliver improvements in hardware Reliability, Availability

and Serviceability (RAS) with every new System z server.

They include microcode driver enhancements, dynamic

segment sparing for memory and ﬁ xed HSA, as well as a

new I/O drawer design. The z10 BC is a server that can

help keep applications up and running in the event of

planned or unplanned disruptions to the system.

The System z10 BC is designed to deliver industry lead-

ing reliability, availability and security our customers have

come to expect from System z servers. System z10 BC

RAS is designed to reduce all sources of outages by

reducing unscheduled, scheduled and planned outages.

Planned outages are further designed to be reduced

with the introduction of concurrent I/O drawer add and

eliminating pre-planning requirements. These features are

designed to reduce the need for a Power-on-Reset (POR)

and help eliminate the need to deactivate/activate/IPL a

logical partition.

RAS Design Focus

High Availability (HA) – The attribute of a system

designed to provide service during deﬁ ned periods, at

acceptable or agreed upon levels and masks UNPLANNED

OUTAGES from end users. It employs fault tolerance, auto-

mated failure detection, recovery, bypass reconﬁ guration,

testing, problem and change management.

Continuous Operations (CO) – The attribute of a system

designed to continuously operate and mask PLANNED

OUTAGES from end users. It employs non-disruptive hard-

ware and software changes, non-disruptive conﬁ guration

and software coexistence.

Continuous Availability (CA) – The attribute of a system

designed to deliver non-disruptive service to the end user

7 days a week, 24 HOURS A DAY (there are no planned or

unplanned outages). It includes the ability to recover from

a site disaster by switching computing to a second site.

Availability Functions

With the z10 BC, signiﬁ cant steps have been taken in the

area of server availability with a focus on reducing pre-

planning requirements. Pre-planning requirements are

minimized by delivering and reserving 8 GB for HSA so the

maximum conﬁ guration capabilities can be exploited. And

with the introduction of the ability to seamlessly include

such events as creation of LPARs, inclusion of logical

subsystems, changing logical processor deﬁ nitions in an

LPAR, and the introduction of cryptography into an LPAR.

Features that carry forward from previous generation pro-

cessors include the ability to dynamically enable I/O, and

the dynamic swapping of processor types.

Hardware System Area (HSA)

Fixed HSA of 8 GB is provided as standard with the z10

BC. The HSA has been designed to eliminate planning for

HSA and makes all the memory purchased by customers

available for customer use. Preplanning for HSA expansion

for conﬁ gurations will be eliminated as HCD/IOCP will, via

the IOCDS process, always reserve:

• 2 Logical Channel Subsystems (LCSS), pre-deﬁ ned

• 30 Logical Partitions (LPARs), pre-deﬁ ned

• Subchannel set 0 with 63.75k devices

• Subchannel set 1 with 64K-1 devices

•

Dynamic I/O Reconﬁ guration – always enabled by

default

• Concurrent Patch – always enabled by default

• Add/Change the number of logical CP, IFL, ICF, zAAP,

zIIP, processors per partition and add SAPs to the con-

ﬁ guration

• Dynamic LPAR PU assignment optimization CPs, ICFs,

IFLs, zAAPs, zIIPs, SAPs

• Dynamically Add/Remove Crypto (no LPAR deactivation

required)

Redundant I/O Interconnect

In the event of a failure or customer initiated action such

as the replacement of an HCA/STI fanout card, the z10 BC

s designed to provide access to your I/O devices through

another HCA/STI to the affected I/O domains. This is exclu-

sive to System z10 and System z9.

Enhanced Driver Maintenance

One of the greatest contributors to downtime during

planned outages is Licensed Internal Code (LIC) updates.

When properly conﬁ gured, z10 BC is designed to permit

select planned LIC updates.

A new query function has been added to validate LIC EDM

requirements in advance. Enhanced programmatic internal

controls have been added to help eliminate manual analy-

sis by the service team of certain exception conditions.

With the z10 BC, PR/SM code has been enhanced to allow

multiple EDM ‘From’ sync points. Automatic apply of EDM

licensed internal change requirements is now limited to

EDM and the licensed internal code changes update pro-

cess.

There are several reliability, availability, and serviceability

(RAS) enhancements that have been made to the HMC/SE

based on the feedback from the System z9 Enhanced

Driver Maintenance ﬁ eld experience.

• Change to better handle intermittent customer network

issues

• EDM performance improvements

• New EDM user interface features to allow for customer

and service personnel to better plan for the EDM

• A new option to check all licensed internal code which

can be executed in advance of the EDM preload or

activate.

Dynamic Oscillator Switchover

The z10 BC has two oscillator cards, a primary and a

backup. For most cases, should a failure occur on the pri-

mary oscillator card, the backup can detect it, switch over,

and provide the clock signal to the system transparently,

with no system outage. Previously, in the event of a failure

of the active oscillator, a system outage would occur, the

subsequent system Power On Reset (POR) would select

the backup, and the system would resume operation.

Dynamic Oscillator Switchover is exclusive to System z10

and System z9.

Transparent Sparing

The z10 BC offers 12 PUs, two are designated as System

Assist Processors (SAPs). In the event of processor failure,

if there are spare processor units available (undeﬁ ned),

these PUs are used for transparent sparing.

Concurrent Memory Upgrade

Memory can be upgraded concurrently using LIC-CC

if physical memory is available on the machine either

through the Plan Ahead Memory feature or by having more

physical memory installed in the machine that has not

been activated.

Plan Ahead Memory

Future memory upgrades can now be preplanned to be

nondisruptive. The preplanned memory feature will add

the necessary physical memory required to support target

memory sizes. The granularity of physical memory in the

System z10 design is more closely associated with the

granularity of logical, entitled memory, leaving little room

for growth. If you anticipate an increase in memory require-

ments, a “target” logical memory size can now be speci-

ﬁ ed in the conﬁ guration tool along with a “starting” logical

memory size. The conﬁ guration tool will then calculate the

physical memory required to satisfy this target memory.

Should additional physical memory be required, it will be

fulﬁ lled with the preplanned memory features.

The preplanned memory feature is offered in 4 gigabyte

(GB) increments. The quantity assigned by the conﬁ gu-

ration tool is the number of 4 GB blocks necessary to

increase the physical memory from that required for the

“starting” logical memory to the physical memory required

for the “target” logical conﬁ guration. Activation of any

preplanned memory requires the purchase of preplanned

memory activation features. One preplanned memory acti-

vation feature is required for each preplanned memory fea-

ture. You now have the ﬂ exibility to activate memory to any

logical size offered between the starting and target size.

Service Enhancements

z10 BC service enhancements designed to avoid sched-

uled outages include:

• Concurrent ﬁ rmware ﬁ xes

• Concurrent driver upgrades

• Concurrent parts replacement

• Concurrent hardware upgrades

• DIMM FRU indicators

• Single processor core checkstop

• Single processor core sparing

• Rebalance PSIFB and I/O Fanouts

• Redundant 100 Mb Ethernet service network with VLAN

Environmental Enhancements

Power and cooling discussions have entered the budget

planning of every IT environment. As energy prices have

risen and utilities have restricted the amount of power

usage, it is important to review the role of the server in bal-

ancing IT spending.

Power Monitoring

The “mainframe gas gauge” feature introduced on the

System z9 servers, provides power and thermal informa-

tion via the System Activity Display (SAD) on the Hardware

Management Console and will be available on the z10

BC giving a point in time reference of the information. The

current total power consumption in watts and BTU/hour as

well as the air input temperature will be displayed.

Power Estimation Tool

To assist in energy planning, Resource Link provides tools

to estimate server energy requirements before a new

server purchase. A user will input the machine model,

memory, and I/O conﬁ guration and the tool will output

an estimate of the system total heat load and utility input

power. A customized planning aid is also available on

Resource Link which provides physical characteristics

of the machine along with cooling recommendations,

environmental speciﬁ cations, system power rating, power

plugs/receptacles, line cord wire speciﬁ cations and the

machine conﬁ guration.

IBM Systems Director Active Energy Manager

™

IBM Systems Director Active Energy Manager

(AEM) is a

building block which enables customers to manage actual

power consumption and resulting thermal loads IBM serv-

ers place in the data center. The z10 BC provides support

for IBM Systems Director Active Energy Manager (AEM)

for Linux on System z for a single view of actual energy

usage across multiple heterogeneous IBM platforms within

the infrastructure. AEM for Linux on System z will allow

tracking of trends for both the z10 BC as well as multiple

server platforms. With this trend analysis, a data center

administrator will have the data to help properly estimate

power inputs and more accurately plan data center con-

solidation or modiﬁ cation projects.

On System z10, the HMC will now provide support for the

Active Energy Manager (AEM) which will display power

consumption/air input temperature as well as exhaust

temperature. AEM will also provide some limited status/

conﬁ guration information which might assist in explaining

changes to the power consumption. AEM is exclusive to

System z10.

Parallel Sysplex Cluster Technology

IBM System z servers stand alone against competition and

have stood the test of time with our business resiliency

solutions. Our coupling solutions with Parallel Sysplex

technology allow for greater scalability and availability.

Parallel Sysplex clustering is designed to bring the power

of parallel processing to business-critical System z10,

System z9, z990 or z890 applications. A Parallel Sysplex

cluster consists of up to 32 z/OS images coupled to one or

more Coupling Facilities (CFs or ICFs) using high-speed

specialized links for communication. The Coupling Facili-

ties, at the heart of the Parallel Sysplex cluster, enable

high speed, read/write data sharing and resource sharing

among all the z/OS images in a cluster. All images are also

connected to a Sysplex Timer

or by implementing the

Server Time Protocol (STP), so that all events can be prop-

erly sequenced in time.

Although there is signiﬁ cant value in a single footprint and

multi-footprint environment with resource sharing, those

customers looking for high availability must move on to

a database data sharing conﬁ guration. With the Paral-

lel Sysplex environment, combined with the Workload

Manager and CICS TS, DB2 or IMS, incoming work can

be dynamically routed to the z/OS image most capable

of handling the work. This dynamic workload balancing,

along with the capability to have read/write access data

from anywhere in the Parallel Sysplex cluster, provides

scalability and availability. When conﬁ gured properly, a

Parallel Sysplex cluster is designed with no single point of

failure and can provide customers with near continuous

application availability over planned and unplanned outages.

With the introduction of the z10 EC, we have the concept

of n-2 on the hardware as well as the software. The z10 BC

participates in a Sysplex with System z10 EC, System z9,

z990 and z890 only and currently supports z/OS 1.8 and

higher and z/VM 5.2 for a guest virtualization coupling

facility test environment.

Parallel Sysplex Resource Sharing enables multiple

system resources to be managed as a single logical

resource shared among all of the images. Some examples

of resource sharing include JES2 Checkpoint, GRS “star,”

and Enhanced Catalog Sharing; all of which provide sim-

pliﬁ ed systems management, increased performance and/

or scalability.

For detailed information on IBM’s Parallel Sysplex technol-

ogy, visit our Parallel Sysplex home page at http://www-

03.ibm.com/systems/z/pso/.

Coupling Facility Control Code (CFCC) Level 16

CFCC Level 16 is being made available on the IBM

System z10 BC.

Improved service time with Coupling Facility Duplex-

ing enhancements: Prior to Coupling Facility Control

Code (CFCC) Level 16, System-Managed Coupling

Facility (CF) Structure Duplexing required two duplexing

protocol exchanges to occur synchronously during pro-

cessing of each duplexed structure request. CFCC Level

16 allows one of these protocol exchanges to complete

asynchronously. This allows faster duplexed request ser-

vice time, with more beneﬁ ts when the Coupling Facilities

are further apart, such as in a multi-site Parallel Sysplex

environment.

List notiﬁ cation improvements: Prior to CFCC Level 16,

when a shared queue (subsidiary list) changed state from

empty to non-empty, the CF would notify ALL active con-

nectors. The ﬁ rst one to respond would process the new

message, but when the others tried to do the same, they

would ﬁ nd nothing, incurring additional overhead.

CFCC Level 16 can help improve the efﬁ ciency of coupling

communications for IMS Shared Queue and WebSphere

MQ Shared Queue environments. The Coupling Facility

notiﬁ es only one connector in a sequential fashion. If the

shared queue is processed within a ﬁ xed period of time,

the other connectors do not need to be notiﬁ ed, saving the

cost of the false scheduling. If a shared queue is not read

within the time limit, then the other connectors are notiﬁ ed

as they were prior to CFCC Level 16.

When migrating CF levels, lock, list and cache structure

sizes might need to be increased to support new function.

For example, when you upgrade from CFCC Level 15 to

Level 16 the required size of the structure might increase.

This adjustment can have an impact when the system

allocates structures or copies structures from one coupling

facility to another at different CF levels.

The coupling facility structure sizer tool can size struc-

tures for you and takes into account the amount of space

needed for the current CFCC levels.

Access the tool at:

http://www.ibm.com/servers/eserver/zseries/cfsizer/.

CFCC Level 16 is exclusive to System z10 and is sup-

ported by z/OS and z/VM for guest exploitation.

Coupling Facility Conﬁ guration Alternatives

IBM offers multiple options for conﬁ guring a functioning

Coupling Facility:

• Standalone Coupling Facility: The standalone CF

provides the most “robust” CF capability, as the CPC is

wholly dedicated to running the CFCC microcode — all

of the processors, links and memory are for CF use

only. A natural beneﬁ t of this characteristic is that the

standalone CF is always failure-isolated from exploiting

z/OS software and the server that z/OS is running on for

environments without System-Managed CF Structure

Duplexing. The z10 BC with capacity indicator A00 is

used for systems with ICF(s) only. There are no software

charges associated with such a conﬁ guration.

• Internal Coupling Facility (ICF): Customers consider-

ing clustering technology can get started with Parallel

Sysplex technology at a lower cost by using an ICF

instead of purchasing a standalone Coupling Facility.

An ICF feature is a processor that can only run Coupling

Facility Control Code (CFCC) in a partition. Since CF

LPARs on ICFs are restricted to running only CFCC,

there are no IBM software charges associated with

ICFs. ICFs are ideal for Intelligent Resource Director and

resource sharing environments as well as for data shar-

ing environments where System-Managed CF Structure

Duplexing is exploited.

System-Managed CF Structure Duplexing

System-Managed Coupling Facility (CF) Structure Duplex-

ing provides a general purpose, hardware-assisted, easy-

to-exploit mechanism for duplexing CF structure data. This

provides a robust recovery mechanism for failures such

as loss of a single structure or CF or loss of connectivity to

a single CF, through rapid failover to the backup instance

of the duplexed structure pair. CFCC Level 16 provides CF

Duplexing enhancements described previously in the sec-

tion titled “Coupling Facility Control Code (CFCC) Level 16”.

System z10 / z9

zSeries 990 / 890

ICF z/OSz/OS ICF

A robust failure recovery capability

System z10 / z9

zSeries 990 / 890

Introducing long reach Inﬁ niBand coupling links

Now, Inﬁ niBand can be used for Parallel Sysplex coupling

and STP communication at unrepeated distances up to 10

km (6.2 miles) and even greater distances when attached

to a qualiﬁ ed optical networking solution. Inﬁ niBand cou-

pling links supporting extended distance are referred to as

1x (one pair of ﬁ ber) IB-SDR or 1x IB-DDR.

Parallel Sysplex Coupling Connectivity

The Coupling Facilities communicate with z/OS images in

the Parallel Sysplex environment over specialized high-

speed links. As processor performance increases, it is

important to also use faster links so that link performance

does not become constrained. The performance, avail-

ability and distance requirements of a Parallel Sysplex

environment are the key factors that will identify the appro-

priate connectivity option for a given conﬁ guration.

When connecting between System z10, System z9 and

z990/z890 servers the links must be conﬁ gured to operate

in Peer Mode. This allows for higher data transfer rates

to and from the Coupling Facilities. The peer link acts

simultaneously as both a CF Sender and CF Receiver link,

reducing the number of links required. Larger and more

data buffers and improved protocols may also improve

long distance performance.

12x PSIFB

Up to 150 meters

1x PSIFB

z10

...

HCA2-O

HCA2-O LR

MBA

HCA2-C

HCA2-O

New ICB-4 cable

ICB-4 10 meters

IFB-MP

I/O Drawer

Up to 10/100 Km

12x PSIFB

Up to 150 meters

ISC-3 ISC-3

ISC-3

Up to 10/100

ISC-3

z9 EC and z9 BC S07

z10 EC, z10 BC, z9 EC,

z9 BC, z990, z890

ISC-3

z10 EC, z10 BC, z9 EC,

z9 BC, z990, z890

z10 EC, z10 BC

• Long reach 1x Inﬁ niBand coupling links support single

data rate (SDR) at 2.5 gigabits per second (Gbps) when

connected to a DWDM capable of SDR

• Long reach 1x Inﬁ niBand coupling links support double

data rate (DDR) at 5 Gbps when connected to a DWDM

capable of DDR.

Depending on the capability of the attached DWDM, the

link data rate will automatically be set to either SDR or

DDR.

The IBM System z10 introduces Inﬁ niBand coupling link

technology designed to provide a high-speed solution and

increased distance (150 meters) compared to ICB-4 (10

meters).

Inﬁ niBand coupling links also provide the ability to deﬁ ne

up to 16 CHPIDs on a single PSIFB port, allowing physi-

cal coupling links to be shared by multiple sysplexes.

This also provides additional subchannels for Coupling

Facility communication, improving scalability, and reduc-

ing contention in heavily utilized system conﬁ gurations. It

also allows for one CHPID to be directed to one CF, and

another CHPID directed to another CF on the same target

server, using the same port.

Like other coupling links, external Inﬁ niBand coupling

links are also valid to pass time synchronization signals for

Server Time Protocol (STP). Therefore the same coupling

links can be used to exchange timekeeping informa-

tion and Coupling Facility messages in a Parallel Sysplex

environment.

The IBM System z10 BC also takes advantage of

Inﬁ niBand as a higher-bandwidth replacement for the Self-

Timed Interconnect (STI) I/O interface features found in

prior System z servers.

Inﬁ niBand coupling links are CHPID type CIB.

Coupling Connectivity for Parallel Sysplex

Five coupling link options: The z10 BC supports Internal

Coupling channels (ICs), Integrated Cluster Bus-4 (ICB-4),

InterSystem Channel-3 (ISC-3) (peer mode), and 12x and

1x Inﬁ niBand (IFB) links for communication in a Parallel

Sysplex environment.

Internal Coupling Channels (ICs) can be used for inter-

nal communication between Coupling Facilities (CFs)

deﬁ ned in LPARs and z/OS images on the same server.

2) Integrated Cluster Bus-4 (ICB-4) links are for short

distances. ICB-4 links use 10 meter (33 feet) copper

cables, of which 3 meters (10 feet) is used for internal

routing and strain relief. ICB-4 is used to connect z10

BC-to-z10 BC, z10 EC, z9 EC, z9 BC, z990, and z890.

Note: If connecting to a z9 BC or a z10 BC with ICB-4,

those servers cannot be installed with the non-raised

ﬂ oor feature. Also, if the z10 BC is ordered with the non-

raised ﬂ oor feature, ICB-4 cannot be ordered.

3) InterSystem Channel-3 (ISC-3) supports communi-

cation over unrepeated distances of up to 10 km (6.2

miles) using 9 micron single mode ﬁ ber optic cables

and even greater distances with System z qualiﬁ ed opti-

cal networking solutions. ISC-3s are supported exclu-

sively in peer mode (CHPID type CFP).

System z now supports 12x Inﬁ niBand single data rate

(12x IB-SDR) coupling link attachment between System

z10 and System z9 general purpose (no longer limited to

standalone coupling facility)

5) Long Reach 1x Inﬁ niBand coupling links (1x IB-

SDR or 1x IB-DDR) are an alternative to ISC-3 and

offer greater distances with support for point-to-point

unrepeated connections of up to 10 km (6.2 miles)

using 9 micron single mode ﬁ ber optic cables. Greater

distances can be supported with System z qualiﬁ ed

optical networking solutions. Long reach 1x Inﬁ niBand

coupling links support the same sharing capability as

the 12x Inﬁ niBand version allowing one physical link to

be shared across multiple CF images on a system.

Note: The Inﬁ niBand link data rates do not represent the

performance of the link. The actual performance is depen-

dent upon many factors including latency through the

adapters, cable lengths, and the type of workload. Speciﬁ -

cally, with 12x Inﬁ niBand coupling links, while the link data

rate can be higher than that of ICB, the service times of

coupling operations are greater, and the actual throughput

is less.

Refer to the Coupling Facility Conﬁ guration Options white-

paper for a more speciﬁ c explanation of when to continue

using the current ICB or ISC-3 technology versus migrat-

ing to Inﬁ niBand coupling links.

The whitepaper is available at: http://www.ibm.com/

systems/z/advantages/pso/whitepaper.html.

4) 12x Inﬁ niBand coupling links (12x IB-SDR or 12x

IB-DDR) offer an alternative to ISC-3 in the data center

and facilitate coupling link consolidation; physical links

can be shared by multiple systems or CF images on a

single system. The 12x IB links support distances up to

150 meters (492 feet) using industry-standard OM3 50

micron ﬁ ber optic cables.

z10 Coupling Link Options

Type Description Use Link Distance d Max

PSIFB

1x IB-DDR LR (6.2 miles) 100 km repeated

PSIFB 12x IB-DDR z10 to z10 6 GBps 150 meters 12*/32* z10 to z9 3 GBps

IC Internal Coupling Communi- Speeds Channel cation

ICB-4 Copper z10, z9 2 GBps 10 meters*** 12/16 connection z990, z890 (33 ft) between OS and CF

ISC-3 Fiber z10, z9 2 Gbps 10 km 48/48 connection z990, z890 unrepeated between OS (6.2 miles) and CF 100 km repeated

• The maximum number of Coupling Links combined cannot exceed 64

per server (PSIFB, ICB-4, ISC-3). There is a maximum of 64 Coupling CHPIDs (CIB, ICP, CBP, CFP) per server.

• For each MBA fanout installed for ICB-4s, the number of possible cus-

tomer HCA fanouts is reduced by one

* Each link supports deﬁ nition of multiple CIB CHPIDs, up to 16 per fanout

** z10 negotiates to 3 GBps (12x IB-SDR) when connected to a System z9

*** 3 meters (10 feet) reserved for internal routing and strain relief

Note: The Inﬁ niBand link data rates of 6 GBps, 3 GBps, 2.5 Gbps, or 5 Gbps do not represent the performance of the link. The actual performance is dependent upon many factors including latency through the adapters, cable lengths, and the type of workload. With Inﬁ niBand coupling links, while the link data rate may be higher than that of ICB (12x IB-SDR or 12x IB-DDR) or ISC-3 (1x IB-SDR or 1x IB-DDR), the service times of coupling operations are greater, and the actual throughput may be less than with ICB links or ISC-3 links.

z10 to z10

Internal Internal N/A 32/32

ata rate

5 Gbps 10 km unrepeated 12*/32*

(492 ft)***

z10 BC z10

z10 EC Max

64 CHPIDS

The Sysplex Timer Model 2 is the centralized time source

that sets the Time-Of-Day (TOD) clocks in all attached

servers to maintain synchronization. The Sysplex Timer

Model 2 provides the stepping signal that helps ensure

that all TOD clocks in a multi-server environment incre-

ment in unison to permit full read or write data sharing with

integrity. The Sysplex Timer Model 2 is a key component of

an IBM Parallel Sysplex environment and a Geographically

™

Dispersed Parallel Sysplex

(GDPS®) availability solution

for On Demand Business.

The z10 BC server requires the External Time Reference

(ETR) feature to attach to a Sysplex Timer. The ETR fea-

is standard on the z10 BC and supports attachment

ture

at an unrepeated distance of up to three kilometers (1.86

miles) and a link data rate of 8 Megabits per second.

The distance from the Sysplex Timer to the server can be

extended to 100 km using qualiﬁ ed Dense Wavelength

Division Multiplexers (DWDMs). However, the maximum

repeated distance between Sysplex Timers is limited to

40 km.

Server Time Protocol (STP)

STP messages: STP is a message-based protocol in

which timekeeping information is transmitted between

servers over externally deﬁ ned coupling links. ICB-4, ISC-

3, and Inﬁ niBand coupling links can be used to transport

STP messages.

Time synchronization and time accuracy on z10 BC

If you require time synchronization across multiple servers

(for example you have a Parallel Sysplex environment) or

you require time accuracy either for one or more System z

servers or you require the same time across heterogeneous

platforms (System z, UNIX, AIX

, etc.) you can meet these

requirements by either installing a Sysplex Timer Model 2

(9037-002) or by implementing Server Time Protocol (STP).

Server Time Protocol enhancements

STP conﬁ guration and time information restoration

after Power on Resets (POR) or power outage: This

enhancement delivers system management improvements

by restoring the STP conﬁ guration and time information

after Power on Resets (PORs) or power failure that affects

both servers of a two server STP-only Coordinated Timing

Network (CTN). To enable this function the customer has to

select an option that will assure than no other servers can

join the two server CTN. Previously, if both the Preferred

Time Server (PTS) and the Backup Time Server (BTS)

experienced a simultaneous power outage (site failure),

or both experienced a POR, reinitialization of time, and

special roles (PTS, BTS, and CTS) was required. With this

enhancement, you will no longer need to reinitialize the

time or reassign the roles for these events.

Preview - Improved STP System Management with

new z/OS Messaging: This is a new function planned to

generate z/OS messages when various hardware events

that affect the External Time Sources (ETS) conﬁ gured for

an STP-only CTN occur. This may improve problem deter-

mination and correction times. Previously, the messages

were generated only on the Hardware Management Con-

sole (HMC).

The ability to generate z/OS messages will be supported

on IBM System z10 and System z9 servers with z/OS 1.11

(with enabling support rolled back to z/OS 1.9) in the

second half of 2009.

The following Server Time Protocol (STP) enhancements

are available on the z10 EC, z10 BC, z9 EC, and z10 BC.

The prerequisites are that you install STP feature and that

the latest MCLs are installed for the applicable driver.

NTP client support: This enhancement addresses the

requirements of customers who need to provide the same

accurate time across heterogeneous platforms in an enter-

prise.

The STP design has been enhanced to include support

for a Simple Network Time Protocol (SNTP) client on the

Support Element. By conﬁ guring an NTP server as the

STP External Time Source (ETS), the time of an STP-only

Coordinated Timing Network (CTN) can track to the time

provided by the NTP server, and maintain a time accuracy

of 100 milliseconds.

Note: NTP client support has been available since October

2007.

Enhanced accuracy to an External Time Source: The

time accuracy of an STP-only CTN has been improved by

adding the capability to conﬁ gure an NTP server that has

a pulse per second (PPS) output signal as the ETS device.

This type of ETS device is available worldwide from sev-

eral vendors that provide network timing solutions.

STP has been designed to track to the highly stable,

accurate PPS signal from the NTP server, and maintain

an accuracy of 10 microseconds as measured at the PPS

input of the System z server. A number of variables such

as accuracy of the NTP server to its time source (GPS,

radio signals for example), and cable used to connect the

PPS signal will determine the ultimate accuracy of STP to

Coordinated Universal Time (UTC).

In comparison, the IBM Sysplex Timer is designed to

maintain an accuracy of 100 microseconds when attached

to an ETS with a PPS output. If STP is conﬁ gured to use

a dial-out time service or an NTP server without PPS, it is

designed to provide a time accuracy of 100 milliseconds

to the ETS device.

For this enhancement, the NTP output of the NTP server

has to be connected to the Support Element (SE) LAN,

and the PPS output of the same NTP server has to be con-

nected to the PPS input provided on the External Time Ref-

erence (ETR) card of the System z10 or System z9 server.

Continuous Availability of NTP servers used as Exter-

nal Time Source: Improved External Time Source (ETS)

availability can now be provided if you conﬁ gure different

NTP servers for the Preferred Time Server (PTS) and the

Backup Time Server (BTS). Only the PTS or the BTS can

be the Current Time Server (CTS) in an STP-only CTN.

Prior to this enhancement, only the CTS calculated the

time adjustments necessary to maintain time accuracy.

With this enhancement, if the PTS/CTS cannot access the

NTP Server or the pulse per second (PPS) signal from the

NTP server, the BTS, if conﬁ gured to a different NTP server,

may be able to calculate the adjustment required and

propagate it to the PTS/CTS. The PTS/CTS in turn will per-

form the necessary time adjustment steering.

This avoids a manual reconﬁ guration of the BTS to be the

CTS, if the PTS/CTS is not able to access its ETS. In an

ETR network when the primary Sysplex Timer is not able

to access the ETS device, the secondary Sysplex Timer

takes over the role of the primary – a recovery action not

always accepted by some customers. The STP design

provides continuous availability of ETS while maintaining

the special roles of PTS and BTS as – signed by the cus-

tomer.

The availability improvement is available when the ETS is

conﬁ gured as an NTP server or an NTP server using PPS.

NTP Server on Hardware Management Console:

Improved security can be obtained by providing NTP

server support on the HMC. If an NTP server (with or with-

out PPS) is conﬁ gured as the ETS device for STP, it needs

to be attached directly to the Support Element (SE) LAN.

The SE LAN is considered by many users to be a private

dedicated LAN to be kept as isolated as possible from the

intranet or Internet.

attaching NTP servers to the SE LAN. The HMC, via a

separate LAN connection, can access an NTP server avail-

able either on the intranet or Internet for its time source.

Note that when using the HMC as the NTP server, there is

no pulse per second capability available. Therefore, you

should not conﬁ gure the ETS to be an NTP server using

PPS.

Enhanced STP recovery when Internal Battery Feature

is in use: Improved availability can be obtained when

power has failed for a single server (PTS/CTS), or when

there is a site power outage in a multi site conﬁ guration

where the PTS/CTS is installed (the site with the BTS is a

different site not affected by the power outage).

If an Internal Battery Feature (IBF) is installed on your

System z server, STP now has the capability of receiving

notiﬁ cation that customer power has failed and that the

IBF is engaged. When STP receives this notiﬁ cation from a

server that has the role of the PTS/CTS, STP can automati-

cally reassign the role of the CTS to the BTS, thus automat-

ing the recovery action and improving availability.

STP conﬁ guration and time information saved across

Power on Resets (POR) or power outages: This

enhancement delivers system management improvements

by saving the STP conﬁ guration across PORs and power

failures for a single server STP-only CTN. Previously, if

the server was PORed or experienced a power outage,

the time, and assignment of the PTS and CTS roles would

have to be reinitialized. You will no longer need to reinitial-

ize the time or reassign the role of PTS/CTS across POR or

power outage events.

Note that this enhancement is also available on the z990

and z890 servers.

Since the HMC is normally attached to the SE LAN, pro-

viding an NTP server capability on the HMC addresses

the potential security concerns most users may have for

Application Programming Interface (API) to automate

STP CTN reconﬁ guration: The concept of “a pair and

a spare” has been around since the original Sysplex

Couple Data Sets (CDSs). If the primary CDS becomes

unavailable, the backup CDS would take over. Many sites

have had automation routines bring a new backup CDS

online to avoid a single point of failure. This idea is being

extended to STP. With this enhancement, if the PTS fails

and the BTS takes over as CTS, an API is now available

on the HMC so you can automate the reassignment of the

PTS, BTS, and Arbiter roles. This can improve availability

by avoiding a single point of failure after the BTS has taken

over as the CTS.

Prior to this enhancement, the PTS, BTS, and Arbiter roles

had to be reassigned manually using the System (Sysplex)

Time task on the HMC.

For additional details on the API, please refer to System z

Application Programming Interfaces, SB10-7030-11.

Additional information is available on the STP Web page:

http://www.ibm.com/systems/z/pso/stp.html.

The following Redbooks are available on the Redbooks

Web site: http://www.redbooks.ibm.com/.

• Server Time Protocol Planning Guide, SG24-7280

• Server Time Protocol Implementation Guide, SG24-7281

Internal Battery Feature Recommendation

Single data center

• CTN with 2 servers, install IBF on at least the PTS/CTS

– Also recommend IBF on BTS to provide recovery pro-

tection when BTS is the CTS

– CTN with 3 or more servers IBF not required for STP

recovery, if Arbiter conﬁ gured

Two data centers

• CTN with 2 servers (one in each data center) install IBF

on at least the PTS/CTS

– Also recommend IBF on BTS to provide recovery pro-

tection when BTS is the CTS

• CTN with 3 or more servers, install IBF on at least the

PTS/CTS

– Also recommend IBF on BTS to provide recovery pro-

tection when BTS is the CTS

Message Time Ordering (Sysplex Timer Connectivity to Coupling

Facilities)

As processor and Coupling Facility link technologies have

improved, the requirement for time synchronization toler-

ance between systems in a Parallel Sysplex environment

has become ever more rigorous. In order to enable any

exchange of timestamped information between systems

in a sysplex involving the Coupling Facility to observe the

correct time ordering, time stamps are now included in

the message-transfer protocol between the systems and

the Coupling Facility. Therefore, when a Coupling Facility

is conﬁ gured on any System z10 or System z9, the Cou-

pling Facility will require connectivity to the same 9037

Sysplex Timer or Server Time Protocol (STP) conﬁ gured

Coordinated Timing Network (CTN) that the systems in its

Parallel Sysplex cluster are using for time synchroniza-

tion. If the ICF is on the same server as a member of its

Parallel Sysplex environment, no additional connectivity is

required, since the server already has connectivity to the

Sysplex Timer.

However, when an ICF is conﬁ gured on any z10 which

does not host any systems in the same Parallel Sysplex

cluster, it is necessary to attach the server to the 9037

Sysplex Timer or implement STP.

HMC System Support

The new functions available on the Hardware Management

Console (HMC) version 2.10.1 as described apply exclu-

sively to System z10. However, the HMC version 2.10.1 will

continue to support the systems as shown.

The 2.10.1 HMC will continue to support up to two 10/100

Mbps Ethernet LANs. Token Ring LANs are not supported.

The 2.10.1 HMC applications have been updated to sup-

port HMC hardware without a diskette drive. DVD-RAM,

CD-ROM, and/or USB ﬂ ash memory drive media will be

used.

Family Machine Type Firmware Driver SE Version

z10 BC 2098 76 2.10.1

z10 EC 2097 73 2.10.0

z9 BC 2096 67 2.9.2

z9 EC 2094 67 2.9.2

z890 2086 55 1.8.2

z990 2084 55 1.8.2

z800 2066 3G 1.7.3

z900 2064 3G 1.7.3

9672 G6 9672/9674 26 1.6.2

9672 G5 9672/9674 26 1.6.2

Internet Protocol, Version 6 (IPv6)

HMC version 2.10.1 and Support Element (SE) version

2.10.1 can now communicate using IP Version 4 (IPv4),

IP Version 6 (IPv6), or both. It is no longer necessary to

assign a static IP address to an SE if it only needs to com-

municate with HMCs on the same subnet. An HMC and

SE can use IPv6 link-local addresses to communicate with

each other.

HMC/SE support is addressing the following requirements:

• The availability of addresses in the IPv4 address space

is becoming increasingly scarce.

• The demand for IPv6 support is high in Asia/Paciﬁ c

countries since many companies are deploying IPv6.

• The U.S. Department of Defense and other U.S. govern-

ment agencies are requiring IPv6 support for any prod-

ucts purchased after June 2008.

More information on the U.S. government requirements

can be found at: http://www.whitehouse.gov/omb/

memoranda/fy2005/m05-22.pdf and

http://www.whitehouse.gov/omb/egov/documents/IPv6_

FAQs.pdf.

HMC/SE Console Messenger

On systems prior to System z9, the remote browser capa-

bility was limited to Platform Independent Remote Console

(PIRC), with a very small subset of functionality. Full func-

tionality via Desktop On-Call (DTOC) was limited to one

user at a time; it was slow, and was rarely used.

With System z9, full functionality to multiple users was

delivered with a fast Web browser solution. You liked this,

but requested the ability to communicate to other remote

users.

There is now a new Console Manager task that offers

basic messaging capabilities to allow system operators or

administrators to coordinate their activities. The new task

may be invoked directly, or via a new option in Users and

Tasks. This capability is available for HMC and SE local

and remote users permitting interactive plain-text com-

munication between two users and also allowing a user to

broadcast a plain-text message to all users. This feature is

a limited instant messenger application and does not inter-

act with other instant messengers.

HMC z/VM Tower System Management Enhancements

Building upon the previous z/VM Systems Management

support from the Hardware Management Console (HMC),

which offered management support for already deﬁ ned

virtual resources, new HMC capabilities are being made

available allowing selected virtual resources to be deﬁ ned.

In addition, further enhancements have been made for

managing deﬁ ned virtual resources.

Enhancements are designed to deliver out-of-the-box

integrated graphical user interface-based (GUI-based)

management of selected parts of z/VM. This is especially

targeted to deliver ease-of-use for enterprises new to

System z. This helps to avoid the purchase and installa-

tion of additional hardware or software, which may include

complicated setup procedures. You can more seamlessly

perform hardware and selected operating system man-

agement using the HMC Web browser-based user inter-

face.

Enhanced installation support for z/VM using the HMC

HMC version 2.10.1 along with Support Element (SE)

version 2.10.1 on z10 BC and corresponding z/VM 5.4 sup-

port, will now give you the ability to install Linux on System

z in a z/VM virtual machine using the HMC DVD drive. This

new function does not require an external network con-

nection between z/VM and the HMC, but instead, uses the

existing communication path between the HMC and SE.

This support is intended for customers who have no alter-

native, such as a LAN-based server, for serving the DVD

contents for Linux installations. The elapsed time for instal-

lation using the HMC DVD drive can be an order of magni-

tude, or more, longer than the elapsed time for LAN-based

alternatives.

Using the legacy support and the z/VM 5.4 support, z/VM

can be installed in an LPAR and both z/VM and Linux on

System z can be installed in a virtual machine from the

HMC DVD drive without requiring any external network

setup or a connection between an LPAR and the HMC.

This addresses security concerns and additional conﬁ gura-

tion efforts using the only other previous solution of the exter-

nal network connection from the HMC to the z/VM image.

Support for the enhanced installation support for z/VM using

the HMC is exclusive to z/VM 5.4 and the System z10.

Support for HMC z/VM tower systems management

enhancements is exclusive to z/VM 5.4 and the System z10.

Implementation Services for Parallel Sysplex

IBM Implementation Services for Parallel Sysplex CICS and

WAS Enablement

IBM Implementation Services for Parallel Sysplex Middle-

ware – CICS enablement consists of ﬁ ve ﬁ xed-price and

ﬁ xed-scope selectable modules:

1)CICS application review

2) z/OS CICS infrastructure review (module 1 is a prerequi-

site for this module)

3)CICS implementation (module 2 is a prerequisite for this

module)

4)CICS application migration

5)CICS health check

IBM Implementation Services for Parallel Sysplex Mid-

dleware – WebSphere Application Server enablement

consists of three ﬁ xed-price and ﬁ xed-scope selectable

modules:

1)WebSphere Application Server network deployment

planning and design

2)WebSphere Application Server network deployment

implementation (module 1 is a prerequisite for this

module)

3)WebSphere Application Server health check

For a detailed description of this service, refer to Services

Announcement 608-041, (RFA47367) dated June 24, 2008.

This DB2 data sharing service is designed for clients who

want to:

1)Enhance the availability of data

2)Enable applications to take full utilization of all servers’

resources

3)Share application system resources to meet business

goals

4)Manage multiple systems as a single system from a

single point of control

5)Respond to unpredicted growth by quickly adding com-

puting power to match business requirements without

disruption

6)Build on the current investments in hardware, software,

applications, and skills while potentially reducing com-

puting costs

The offering consists of six selectable modules; each is

a stand-alone module that can be individually acquired.

The ﬁ rst module is an infrastructure assessment module,

followed by ﬁ ve modules which address the following DB2

data sharing disciplines:

1)DB2 data sharing planning

2)DB2 data sharing implementation

3)Adding additional data sharing members

4)DB2 data sharing testing

5)DB2 data sharing backup and recovery

Implementation Services for Parallel Sysplex DB2 Data Sharing

To assist with the assessment, planning, implementation,

testing, and backup and recovery of a System z DB2 data

sharing environment, IBM Global Technology Services

announced and made available the IBM Implementation

Services for Parallel Sysplex Middleware – DB2 data shar-

ing on February 26, 2008.

For more information on these services contact your IBM

representative or refer to: www.ibm.com/services/server.

Fiber Quick Connect for FICON LX Environments

GDPS

Geographically Dispersed Parallel Sysplex (GDPS) is

designed to provide a comprehensive end-to-end con-

tinuous availability and/or disaster recovery solution

for System z servers, Geographically Dispersed Open

Clusters (GDOC) is designed to address this need for

open systems. When available, GDPS 3.5 will support

GDOC for coordinated disaster recovery across System

z and non-System z servers if Veritas Cluster Server is

already installed. GDPS and the new Basic HyperSwap

(available with z/OS V1.9) solutions help to ensure system

failures are invisible to employees, partners and customers

with dynamic disk-swapping capabilities that ensure appli-

cations and data are available. z10 BC—big on service,

low on cost.

GDPS is a multi-site or single-site end-to-end application

availability solution that provides the capability to manage

remote copy conﬁ guration and storage subsystems

(including IBM TotalStorage), to automate Parallel Sysplex

operation tasks and perform failure recovery from a single

point of control.

GDPS helps automate recovery procedures for planned

and unplanned outages to provide near-continuous avail-

ability and disaster recovery capability.

For additional information on GDPS, visit: http://www-

03.ibm.com/systems/z/gdps/.

Fiber Quick Connect (FQC), an optional feature on z10

BC, is offered for all FICON LX (single-mode ﬁ ber) chan-

nels, in addition to the current support for ESCON (62.5

micron multimode ﬁ ber) channels. FQC is designed to

signiﬁ cantly reduce the amount of time required for on-site

installation and setup of ﬁ ber optic cabling. FQC facilitates

adds, moves, and changes of ESCON and FICON LX ﬁ ber

optic cables in the data center, and may reduce ﬁ ber con-

nection time by up to 80%.

FQC is for factory installation of Fiber Transport System

(FTS) ﬁ ber harnesses for connection to channels in the I/O

drawer.

direct-attach ﬁ ber trunk cables from IBM Global Technol-

ogy Services.

FQC, coupled with FTS, is a solution designed to help

minimize disruptions and to isolate ﬁ ber cabling activities

away from the active system as much as possible.

IBM provides the direct-attach trunk cables, patch panels,

and Central Patching Location (CPL) hardware, as well

as the planning and installation required to complete the

total structured connectivity solution. An ESCON example:

Four trunks, each with 72 ﬁ ber pairs, can displace up

to 240 ﬁ ber optic jumper cables, the maximum quantity

of ESCON channels in one I/O drawer. This signiﬁ cantly

reduces ﬁ ber optic jumper cable bulk.

At CPL panels you can select the connector to best meet

your data center requirements. Small form factor connec-

tors are available to help reduce the ﬂ oor space required

for patch panels.

FTS ﬁ ber harnesses enable connection to FTS

CPL planning and layout is done prior to arrival of the

server on-site using the default CHannel Path IDdentiﬁ er

(CHPID) placement report, and documentation is provided

showing the CHPID layout and how the direct-attach har-

nesses are plugged.

FQC supports all of the ESCON channels and all of the

FICON LX channels in the I/O drawer of the server. On

an upgrade from a z890 or z9 BC, ESCON channels that

are NOT using FQC cannot be used on the z10 BC FQC

feature.

z10 BC Physical Characteristics

Physical Planning

A System z10 BC feature may be ordered to allow use of

the z10 BC in a non-raised ﬂ oor environment. This capabil-

ity may help ease the cost of entry into the z10 BC; a raised

ﬂ oor may not be necessary for some infrastructures.

The non-raised ﬂ oor z10 BC implementation is designed to

meet all electromagnetic compatibility standards. Feature

#7998 must be ordered if the z10 BC is to be used in a non-

raised ﬂ oor environment. A Bolt-down kit (#7992) is also

available for use with a non-raised ﬂ oor z10 BC, providing

frame stabilization and bolt-down hardware to help secure

a frame to a non-raised ﬂ oor. Bolt-down kit (#7992) may be

ordered for initial box or MES starting January 28, 2009.

The Installation Manual for Physical Planning (GC28-6875)

is available on Resource Link and should always be referred

to for detailed planning information.

Integrated Battery

System power supply

Central Processor Complex (CPC) drawer

Support Elements

I/O drawer 3

I/O drawer 2

I/O drawer 1

I/O drawer 4

BATTERYENBLD

(CBMustbeon)

678910 11

BATTERYENBLD

(CBMustbeon)

MDA

PWR

MDA

PWR

Integrated

Battery

System

power supply

Central

Processor

Complex (CPC)

drawer

I/O drawer 3

I/O drawer 2

I/O drawer 1

I/O drawer 4

z10 BC System Power

1 I/O 2 I/O 3 I/O 4 I/O Drawer Drawers Drawers Drawers

normal room 3.686 kW 4.542 kW 5.308 kW 6.253 kW (<28 degC)

warm room 4.339 kW 5.315 kW 6.291 kW 7.266 kW (>=28 degC)

z10 BC Highlights and Physical Dimensions

z10 BC z9 BC

Number of Frames

Height (with covers) Width (with covers)

1 Frame 1 Frame

201.5 cm/79.3 in (42 EIA) 194.1 cm/76.4 in (40 EIA)

77.0 cm /30.3 in 78.5 cm /30.9 in

Depth (with covers) 180.6 cm /71.1 in 157.7 cm /62.1 in Height Reduction 180.9 cm / 71.2 in (EIA) 178.5 cm / 70.3 in (EIA)

Width Reduction None None Machine Area 1.42 sq. m. /15.22 sq. ft. 1.24 sq. m. /13.31 sq. ft.

Service Clearance 3.50 sq. m. /37.62 sq. ft. 3.03 sq. m. /32.61 sq. ft.

(IBF Contained w/in Frame) (IBF Contained w/in Frame)

Maximum of 480 CHPIDs, four I/O drawers, 32 I/O slots (8 I/O

slots per I/O drawer):

A00H

A Frame Front View A Frame Rear View

A00S

z10 BC Conﬁ guration Detail

Features Min # Max # Max Increments

16-port 0

Features Features Connections per Feature Increments

(1)

480 channels

16 channels 4 channels

Purchase

ESCON 1reserved as as a spare

FICON 0

(1)

32 64/128* 2/4*

2/4*

Express4* channels channels channels

(1)

FICON 0 Express2

FICON 0 Express

ICB-4 0

ISC-3 0

1x PSIFB 0

12x PSIFB 0

(1)

OSA- 0 24 48/96* 2 or 4

80 channels

40 channels

(2) (3)

12 links

(2)

48 links

(2)

12 links

(2) (3)

12 links

channels 4 channels

channels 2 channels

links

1 link

2 links

2 ports/

Express3* ports 4 ports

OSA- 0 24 24/48 1 or 2

2 ports/

Express2** ports 1 port

Crypto 0 8 8/16 PCI-X 1/2* PCI-X Express2* adapters adapters adapters

1) Minimum of one I/O feature (ESCON, FICON) or Coupling Link (PSIFB, ICB-4, ISC-3) required.

2) The maximum number of external Coupling Links combined cannot exceed 56 per server. There is a maximum of 64 coupling link CHPIDs per server (ICs, ICB-4s, active ISC-3 links, and IFBs)

3) ICB-4 and 12x IB-DDR are not included in the maximum feature count for I/O slots but are included in the CHPID count.

4) Initial order of Crypto Express2 is 2/4 PCI-X adapters (two features). Each PCI-X adapter can be conﬁ gured as a coprocessor or an accelerator.

* FICON Express4-2C 4KM LX has two channels per feature, OSA-

Express3 GbE and 1000BASE-T have 2 and 4 port options and Crypto Express2-1P has 1 coprocessor

** Available only when carried forward on an upgrade from z890 or or z9

BC. Limited availability for OSA-Express2 GbE features.

2* PCI-X

(4)

z10 BC Concurrent PU Conversions

• Must order (characterize one PU as) a CP, an ICF or an IFL

• Concurrent model upgrade is supported

• Concurrent processor upgrade is supported if PUs are available – Add CP, IFL, unassigned IFL, ICF, zAAP, zIIP or

optional SAP

• PU Conversions – Standard SAP cannot be converted to other PU types

To CP IFL Unassigned ICF From IFL SAP

CP X Yes

IFL Yes X

Unassigned Yes Yes

Yes Yes

X Yes

IFL

ICF Yes Yes

zAAP Yes Yes

zIIP Yes Yes

Optional Yes Yes

Yes X

Yes Yes

SAP

Exceptions: Disruptive if ALL current PUs are converted to different types may require individual LPAR disruption if dedicated PUs are converted.

zAAP

zIIP Optional

Yes Yes Yes

X Yes Yes

Yes X Yes

Yes Yes X

z10 BC Model Structure

z10 BC System weight and IBF hold-up times

Model PU PUs for Max Avail Standard Standard CP/IFL/ Max Max

E10 4 10

* Max is for ESCON channels. ** For each zAAP and/or zIIP installed there must be a corresponding CP.

Customer Subcapacity SAPs Spares ICF/zAAP/ Customer CPs zIIP** Memory

5 2

The CP may satisfy the requirement for both the zAAP and/or zIIP. The combined number of zAAPs and/or zIIPs can not be more than 2x the number of general purpose processors (CPs).

5/10/10/5/5

248 GB

Chan.

480

z10 BC Minimum Maximum

E10

Memory DIMM sizes: 2 GB and 4 GB. (Fixed HSA not included, up to 248 GB for customer use June 30, 2009)

4 GB

248 GB

System z CF Link Connectivity – Peer Mode only

Connectivity z10 z10 z10 z10 Options ISC-3 ICB-4 1x PSIFB 12x PSIFB

z10/z9/z990/z890

2 Gbps N/A

N/A N/A

ISC-3

z10/z9/z990/z890

N/A 2 GBps

N/A N/A

ICB-4

z9 with PSIFB

N/A N/A

N/A 3 GBps*

z10 1x PSIFB

N/A N/A

5 Gbps* N/A

(>150m)

z10 12x PSIFB

N/A N/A

N/A 6 GBps*

z10 Model E10 – Single Frame

w/o IBF w/ IBF

1890 lbs. 2100 lbs.

z10 BC IBF hold uptime

1 I/O 2 I/O 3 I/O 4 I/O Drawer Drawers Drawers Drawers

1 CPC Drawer 13 min 11 min 9 min 7 min

• N-2 Server generation connections allowed

• Theoretical maximum rates shown

• 1x PSIFBs support single data rate (SDR) at 2.5 Gbps when connected to a DWDM capable of SDR speed and double data rate (DDR) at 5 Gbps when connected to a DWDM capable of DDR speed

• System z9 does NOT support 1x IB-DDR or SDR Inﬁ niBand Coupling Links

*Note: The Inﬁ niBand link data rate of 6 GBps, 3 GBps or 5 Gbps does not represent the performance of the link. The actual performance is dependent upon many factors including latency through the adapters, cable lengths, and the type of workload. With Inﬁ niBand coupling links, while the link data rate may be higher than that of ICB, the service times of coupling operations are greater, and the actual throughput may be less than with ICB links.

Coupling Facility – CF Level of Support

CF Level Function

z10 EC z9 EC z990

z10 BC z9 BC z890

16 CF Duplexing Enhancements X List Notiﬁ cation Improvements Structure Size increment increase from 512 MB –> 1 MB

15 Increasing the allowable tasks in the CF from 48 to 112 X X

14 CFCC Dispatcher Enhancements X X

13 DB2 Castout Performance X X

12 z990 Compatibility 64-bit CFCC X X

Addressability Message Time Ordering X X DB2 Performance SM Duplexing Support for zSeries X X

11 z990 Compatibility SM Duplexing Support for 9672 G5/G6/R06 X X

10 z900 GA2 Level X X

9 Intelligent Resource Director IC3 / ICB3 / ISC3 Peer Mode X X

MQSeries WLM Multi-System Enclaves X X

Note: zSeries 900/800 and prior generation servers are not supported with System z10 for Coupling Facility or Parallel Sysplex levels.

Shared Queues X X

Statement of Direction

IBM intends to support optional water cooling on future

high end System z servers. This cooling technology will

tap into building chilled water that already exists within the

datacenter for computer room air conditioning systems.

External chillers or special water conditioning will not be

required. Water cooling technology for high end System z

servers will be designed to deliver improved energy efﬁ -

ciencies.

IBM intends to support the ability to operate from High

Voltage DC power on future System z servers. This will

be in addition to the wide range of AC power already

supported. A direct HV DC datacenter power design can

improve data center energy efﬁ ciency by removing the

need for an additional DC to AC inversion step.

The System z10 will be the last server to support Dynamic

ICF expansion. This is consistent with the System z9 hard-

ware announcement 107-190 dated April 18, 2007, IBM

System z9 Enterprise Class (z9 EC) and System z9 Busi-

ness Class (z9 BC) – Delivering greater value for every-

one, in which the following Statement of Direction was

made: IBM intends to remove the Dynamic ICF expansion

function from future System z servers.

The System z10 will be the last server to support connec-

tions to the Sysplex Timer (9037). Servers that require time

synchronization, such as to support a base or Parallel Sys-

plex, will require Server Time Protocol (STP). STP has been

available since January 2007 and is offered on the System

z10, System z9, and zSeries 990 and 890 servers.

ESCON channels to be phased out: It is IBM’s intent for

ESCON channels to be phased out. System z10 EC and

System z10 BC will be the last servers to support greater

than 240 ESCON channels.

ICB-4 links to be phased out: Restatement of SOD) from

RFA46507) IBM intends to not offer Integrated Cluster Bus-

4 (ICB-4) links on future servers. IBM intends for System

z10 to be the last server to support ICB-4 links.

Publications

The following Redbook publications are available now:

z10 BC Technical Overview

SG24-7632

z10 BC Technical Guide SG24-7516

System z Connectivity Handbook SG24-5444

Server Time Protocol Planning Guide SG24-7280

Server Time Protocol Implementation Guide

The following publications are shipped with the product and

available in the Library section of Resource Link:

z10 BC Installation Manual GC28-6874

z10 BC Service Guide GC28-6878

z10 BC Safety Inspection Guide GC28-6877

System Safety Notices G229-9054

The following publications are available in the Library section of

Resource Link:

Agreement for Licensed Machine Code SC28-6872

Application Programming Interfaces for Java API-JAVA

Application Programming Interfaces SB10-7030

Capacity on Demand User’s Guide SC28-6871

CHPID Mapping Tool User’s Guide GC28-6825

Common Information Model (CIM) Management Interface SB10-7154

Coupling Links I/O Interface Physical Layer SA23-0395

ESCON and FICON CTC Reference SB10-7034

ESCON I/O Interface Physical Layer SA23-0394

FICON I/O Interface Physical Layer SA24-7172

SG24-7281

Hardware Management Console Operations Guide (V2.10.1) SC28-6873

IOCP User’s Guide SB10-7037

Maintenance Information for Fiber Optic Links SY27-2597

OSA-Express Customer’s Guide SA22-7935

OSA-ICC User’s Guide SA22-7990

Planning for Fiber Optic Links GA23-0367

PR/SM Planning Guide SB10-7153

SCSI IPL - Machine Loader Messages SC28-6839

Service Guide for HMCs and SEs GC28-6861

Service Guide for Trusted Key Entry Workstations GC28-6862

Standalone IOCP User’s Guide SB10-7152

Support Element Operations Guide (Version 2.10.0) SC28-6879

System z Functional Matrix ZSW0-1335

TKE PCIX Workstation User’s Guide SA23-2211

z10 BC Parts Catalog GC28-6876

z10 BC System Overview SA22-1085

z10 BC Installation Manual - Physical Planning (IMPP) GC28-6875

Publications for System z10 Business Class can be

obtained at Resource Link by accessing the following Web

site: www.ibm.com/servers/resourcelink

IBM Systems and Technology Group Route 100 Somers, NY 10589

U.S.A Produced in the United States of America,

04-09

References in this publication to IBM products or services do not imply that IBM intends to make them available in every country in which IBM operates. Consult your local IBM business contact for information on the products, features, and services available in your area.

IBM, IBM eServer, the IBM logo, the e-business logo, AIX, APPN, CICS, Cognos, Cool Blue, DB2, DRDA, DS8000, Dynamic Infrastructure, ECKD, ESCON, FICON, Geographically Dispersed Parallel Sysplex, GDPS, HiperSockets, HyperSwap, IMS, Lotus, MQSeries, MVS, OS/390, Parallel Sysplex, PR/SM, Processor Resource/Systems Manager, RACF, Rational, Redbooks, Resource Link, RETAIN, REXX, RMF, Scalable Architecture for Financial Reporting, Sysplex Timer, Systems Director Active Energy Manager, System Storage, System z, System z9, System z10, Tivoli, TotalStorage, VSE/ESA, VTAM, WebSphere, z9, z10, z10 BC, z10 EC, z/ Architecture, z/OS, z/VM, z/VSE, and zSeries are trademarks or registered trademarks of the International Business Machines Corporation in the Unites States and other countries.

Inﬁ niBand is a trademark and service mark of the Inﬁ niBand Trade Association.

Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States or other countries.

Linux is a registered trademark of Linus Torvalds in the United States, other countries, or both.

UNIX is a registered trademark of The Open Group in the Unites States and other countries.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation In the United States, other countries, or both.

Intel is a trademark of the Intel Corporation in the United States and other countries.

Other trademarks and registered trademarks are the properties of their respective companies.

IBM hardware products are manufactured from new parts, or new and used parts. Regardless, our warranty terms apply.

Performance is in Internal Throughput Rate (ITR) ratio based on measurements and projections using standard IBM benchmarks in a controlled environment. The actual throughput that any user will experience will vary depending upon considerations such as the amount of multiprogramming in the user’s job stream, the I/O conﬁ guration, the storage conﬁ guration, and the workload processed. Therefore, no assurance can be given that an individual user will achieve throughput improvements equivalent to the performance ratios stated here.

All performance information was determined in a controlled environment. Actual results may vary. Performance information is provided “AS IS” and no warranties or guarantees are expressed or implied by IBM.

Photographs shown are of engineering prototypes. Changes may be incorporated in production models.

This equipment is subject to all applicable FCC rules and will comply with them upon delivery.

Information concerning non-IBM products was obtained from the suppliers of those products. Questions concerning those products should be directed to those suppliers.

All customer examples described are presented as illustrations of how those customers have used IBM products and the results they may have achieved. Actual environmental costs and performance characteristics

ZSO03021-USEN-02

IBM Z10 BUISNESS CLASS Z10 BC Reference Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
