IBM xSeries 305 Type 8673, eserver xSeries 305 Type 8673 User Manual

ERserver



xSeries 305
Type 8673

User’s Guide

ER s e r v e r



xSeries 305
Type 8673

User’s Guide

Note: Before using this information and the product it supports, be sure to read the general information

in Appendix B, “Warranty information” on page 23, and Appendix C, “Notices” on page 35.

First Edition (August 2002)

© Copyright International Business Machines Corporation 2002. All rights reserved.

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents

Safety ............................v

Chapter 1. Introducing the xSeries™305 Type 8673 server ........1

Related publications .......................1

Notices and statements used in this book ...............2

Features and specifications .....................3

What your server offers ......................4

Reliability, availability, and serviceability features .............5

IBM Director ..........................5

Server controls, LEDs, and power ..................7

Front view ..........................7

Rear view ..........................8

Server power features ......................9

Chapter 2. Configuring your server ................11

Using the Configuration/Setup Utility program..............11

Starting the Configuration/Setup Utility program ............11

Configuration/Setup Utility menu choices ..............12

Additional Configuration/Setup Utility menu choices ..........14

Passwords .........................14

Using the ServerGuide Setup and Installation CD ............15

ServerGuide features .....................15

Setup and configuration overview .................16

System Partition .......................17

Typical operating-system installation ................17

Setting up or updating multiple servers ...............18

Installing your operating system without ServerGuide ..........18

Using the SCSISelect Utility program (some models) ...........18

Starting the SCSISelect Utility program ...............18

SCSISelect Utility menu choices .................18

Configuring the Gigabit Ethernet controller ...............20

High-performance Ethernet modes.................20

Appendix A. Getting help and technical assistance ..........21

Before you call .........................21

Using the documentation .....................21

Getting help and information from the World Wide Web ..........21

Software service and support ...................22

Hardware service and support ...................22

Appendix B. Warranty information .................23

Warranty period ........................23

Problem determination .....................23

Warranty service and support ..................24

International Warranty Service ..................24

Purchasing additional services ..................25

IBM Statement of Limited Warranty Z125-4753-06 8/2000 .........26

Part 1 - General Terms .....................26

Part 2 - Country-unique Terms ..................28

Appendix C. Notices ......................35

Edition notice .........................35

Trademarks ..........................36

© Copyright IBM Corp. 2002 iii

Important notes.........................36

Electronic emission notices ....................37

Federal Communications Commission (FCC) statement .........37

Industry Canada Class A emission compliance statement ........38

Australia and New Zealand Class A statement ............38

United Kingdom telecommunications safety requirement.........38

European Union EMC Directive conformance statement .........38

Taiwanese Class A warning statement ...............38

Japanese Voluntary Control Council for Interference (VCCI) statement . . . 39

Power cords ..........................39

Index ............................41

iv xSeries 305 Type 8673: User’s Guide

Safety

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

© Copyright IBM Corp. 2002 v

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

Statement 1:

DANGER

Electrical current from power, telephone, and communication cables is
hazardous.

To avoid a shock hazard:
v Do not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical
storm.

v Connect all power cords to a properly wired and grounded electrical

outlet.

v Connect to properly wired outlets any equipment that will be attached to

this product.

v When possible, use one hand only to connect or disconnect signal

cables.

v Never turn on any equipment when there is evidence of fire, water, or

structural damage.

v Disconnect the attached power cords, telecommunications systems,

networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.

v Connect and disconnect cables as described in the following table when

installing, moving, or opening covers on this product or attached
devices.

To Connect: To Disconnect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

vi xSeries 305 Type 8673: User’s Guide

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

Statement 2:

CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
a module containing a lithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.

Do not:

v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble

Dispose of the battery as required by local ordinances or regulations.

Statement 3:

CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:

v Do not remove the covers. Removing the covers of the laser product could

result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.

v Use of controls or adjustments or performance of procedures other than

those specified herein might result in hazardous radiation exposure.

DANGER

Some laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following.

Laser radiation when open. Do not stare into the beam, do not view directly
with optical instruments, and avoid direct exposure to the beam.

Class 1 Laser Product
Laser Klasse 1
Laser Klass 1
Luokan 1 Laserlaite
Appareil A Laser de Classe 1

`

Safety vii

Statement 4:

≥ 18 kg (39.7 lb) ≥ 32 kg (70.5 lb) ≥ 55 kg (121.2 lb)

CAUTION:
Use safe practices when lifting.

Statement 5:

CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current
from the device, ensure that all power cords are disconnected from the power
source.

2

1

viii xSeries 305 Type 8673: User’s Guide

Statement 8:

CAUTION:
Never remove the cover on a power supply or any part that has the following
label attached.

Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact
a service technician.

Safety ix

x xSeries 305 Type 8673: User’s Guide

Chapter 1. Introducing the xSeries™305 Type 8673 server

The IBM®Eserver xSeries 305 Type 8673 server, which features IBM
X-Architecture
networking environments that require superior microprocessor performance, efficient
memory management, flexibility, and large amounts of reliable data storage.

Performance, reliability, and expansion capabilities were key considerations in the
design of your server. These design features make it possible for you to customize
the system hardware to meet your needs today, while providing flexible expansion
capabilities for the future.

If you have access to the Internet, you can obtain up-to-date information about your
server and other IBM server products at http://www.ibm.com/eserver/xseries/ on the
World Wide Web.

For service or assistance information, see Appendix A, “Getting help and technical
assistance” on page 21.

The latest version of this publication is available from the IBM Web site. Go to
http://www.ibm.com/ and click Support & downloads. In the Technical support
keyword search field, type 8673 and click Go. A list of publications for your server is
displayed.

Related publications

The following documentation comes with your server:

v User’s Guide

This publication is in Portable Document Format (PDF) on the IBM xSeries
Documentation CD. It contains general information about your server.

v Installation Guide

This printed publication contains instructions for setting up your server and basic
instructions for installing some options.

v Option Installation Guide

This publication is in PDF on the IBM xSeries Documentation CD. It contains
detailed instructions for installing, removing, and connecting optional devices that
your server supports.

v Safety Book

This publication is in PDF on the IBM xSeries Documentation CD. It contains
translated caution and danger statements. Each caution and danger statement
that appears in the documentation has a number that you can use to locate the
corresponding statement in your language in the Safety Book.

v Rack Installation Instructions

This printed publication contains instructions for installing your server in a rack.

v Hardware Maintenance Manual and Troubleshooting Guide

This publication is in PDF on the IBM xSeries Documentation CD. It contains
information to help you solve problems yourself, and it contains information for
service technicians.

™

technology, is a high-performance server. It is ideally suited for

Depending on your server model, additional publications might be included on the
IBM xSeries Documentation CD.

© Copyright IBM Corp. 2002 1

Notices and statements used in this book

The caution and danger statements that appear in this book are also in the
multilingual Safety Book, which is on the IBM xSeries Documentation CD. Each
statement is numbered for reference to the corresponding statement in the Safety
Book.

The following notices and statements are used in the documentation:

v Notes: These notices provide important tips, guidance, or advice.
v Important: These notices provide information or advice that might help you avoid

inconvenient or problem situations.

v Attention: These notices indicate potential damage to programs, devices, or

data. An attention notice is placed just before the instruction or situation in which
damage could occur.

v Caution: These statements indicate situations that can be potentially hazardous

to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.

v Danger: These statements indicate situations that can be potentially lethal or

extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.

2 xSeries 305 Type 8673: User’s Guide

Features and specifications

The following table provides a summary of the features and specifications of your
xSeries 305 Type 8673 server. Depending on your server model, some features and
specifications might not apply.

Racks are marked in vertical increments of 1.75 inches. Each increment is referred
to as a unit, or “U.” A 1-U-high device is 1.75 inches tall.

Table 1. Features and specifications

Microprocessor:

®

One Intel
Level-2 cache and MMX

Pentium®4 with 512 KB

™

(MMX2)

technology

Memory:

v Minimum: 256 MB
v Maximum: 4 GB
v Type: PC2100 266 MHz, ECC

SDRAM, registered DIMMs only

v Slots: Four dual inline
v Supports 256 MB, 512 MB, and

1GBDIMMs

Drives:

v Diskette: 1.44 MB
v CD-ROM: IDE
v Supports up to two slim-high hard

disk drives

Expansion bays:

Two 3.5-in. slim-high bays for hard
disk drives

Expansion slots:

Two 66/100/133 MHz/64-bit PCI-X
slots on the system board (one
half-length full-height, one low profile)

Video controller:

v ATI Rage XL video on system

board

v Compatible with SVGA and VGA
v 8 MB SDRAM video memory

Power supply:

203 watt (110 or 220 V ac
auto-sensing)

Size:

v Height: 43 mm (1.75 inches, 1 U)

v Depth: 424 mm (16.54 inches)

v Width: 430 mm (16.69 inches)

v Maximum weight: 12.7 kg (28 lb)

depending on your configuration

Integrated functions:

v Broadcom

10/100/1000 Base-T (dual)
Ethernet controllers on the system
board with Wake on LAN
Alert Standard Format support

v Serial port
v Two USB ports
v Keyboard port
v Mouse port
v Dual-channel bus mastering IDE

controller

Hard disk controller:

v Dual-channel bus mastering IDE

controller

v Ultra160 SCSI adapter is installed

in one of the expansion slots
(SCSI models)

Acoustical noise emissions:

v Sound power, idling: 6.5 bel

maximum

v Sound power, operating: 6.5 bel

maximum

Environment:

v Air temperature:

– Server on: 10° to 35°C (50.0°

– Server off: -40° to 60°C

v Humidity:

– Server on: 8% to 80%
– Server off: 8% to 80%

®

and

to 95.0°F); altitude: 0 to 914 m
(2998.7 ft)

(-104° to 140°F); maximum
altitude: 2133 m (6998.0 ft)

Heat output:

Approximate heat output in British
thermal units (Btu) per hour:
v Minimum configuration: 297 Btu (87

watts)

v Maximum configuration: 512 Btu

(150 watts)

Electrical input:

v Sine-wave input (47-63 Hz) required
v Input voltage low range:

– Minimum: 100 V ac
– Maximum: 127 V ac

v Input voltage high range:

– Minimum: 200 V ac
– Maximum: 240 V ac

v Input kilovolt-amperes (kVA),

approximately:
– Minimum: 0.0870 kVA
– Maximum: 0.150 kVA

Notes:

1. Power consumption and heat
output vary depending on the
number and type of optional
features installed and the
power-management optional
features in use.

2. These levels were measured in
controlled acoustical environments
according to the procedures
specified by the American National
Standards Institute (ANSI) S12.10
and ISO 7779 and are reported in
accordance with ISO 9296. Actual
sound-pressure levels in a given
location might exceed the average
values stated because of room
reflections and other nearby noise
sources. The declared sound-power
levels indicate an upper limit, below
which a large number of computers
will operate.

Chapter 1. Introducing the xSeries™305 Type 8673 server 3

What your server offers

The design of your server takes advantage of advancements in data storage,
disk-array technologies, and memory management. Your server combines:

v Impressive performance using the latest microprocessor technology

Your server comes with one Intel Pentium 4 microprocessor installed.

v Large system-memory capacity

The memory bus in your server supports up to 4 GB of system memory. The
memory controller provides error correcting code (ECC) support for up to four
industry standard PC 2100, 2.5V, 184-pin, 266 megahertz (MHz), registered,
synchronous dynamic random access memory (SDRAM) dual inline memory
modules (DIMMs).

v IBM X-Architecture technology

IBM X-Architecture technology is an IBM design blueprint that takes full
advantage of existing IBM technologies to build powerful, scalable, and reliable
Intel-processor-based servers.

v Integrated network environment support

Your server comes with two Ethernet controllers on the system board. These
Ethernet controllers have an interface for connecting to 10-Mbps, 100-Mbps, or
1000-Mbps networks. The server automatically selects among 10Base-T,
1000BASE-TX, and 1000BASE-T. The controller provides full-duplex (FDX)
capability, which enables simultaneous transmission and reception of data on the
Ethernet local area network (LAN).

v IBM ServerGuide

The ServerGuide Setup and Installation CD that comes with your server provides
programs to help you set up your server and install the operating system. The
ServerGuide program detects installed hardware options and provides the correct
configuration programs and device drivers.

For more information about the ServerGuide Setup and Installation CD, see
“Using the ServerGuide Setup and Installation CD” on page 15.

v Systems-management capabilities

Your server comes with features that a network administrator or file server can
use to remotely manage and control the server. Some of the features include
Wake on LAN
Assistant.

If your server is connected to an Advanced System Management (ASM)
interconnect network that is managed by a Remote Supervisor Adapter, you can
view the system health; turn on, turn off, and restart the server; view the error
log; view the vital product data; and send alerts over the ASM interconnect
network. To order an optional Remote Supervisor Adapter, contact your IBM
reseller or IBM marketing representative.

™

Setup and Installation CD

®

, IBM Director, Remote Administration, and System Migration

4 xSeries 305 Type 8673: User’s Guide

Reliability, availability, and serviceability features

Three important computer design features are reliability, availability, and
serviceability (RAS). The RAS features help to ensure the integrity of the data that
is stored in your server, the availability of the computer when you need it, and the
ease with which you can diagnose and repair problems.

Your server has the following RAS features:

v Adaptec 29160LP built-in self-test (BIST)

v Advanced Configuration and Power Interface (ACPI)

v Advanced Desktop Management Interface (DMI) features

v Automatic error retry or recovery

v Automatic restart after power failure

v Auto-restart initial program load (IPL) power supply

v Boot-block recovery

v Built-in, menu-driven configuration and setup programs

v Cooling fans with speed-sensing capability

v Customer-upgradeable basic input/output system (BIOS) code

v ECC memory

v Error codes and messages

v Failover Ethernet support

v Menu-driven diagnostic programs on CD

v Microprocessor serial number access

v Monitoring support for temperature, voltage, and fan speed

v Parity checking on the SCSI bus and PCI bus

v Power-on self-test (POST)

v Read-only memory (ROM) checksums

v SDRAM with serial presence detect (SPD)

v Server management

v Standby voltage for system management features and monitoring

v System error log (with an optional Remote Supervisor Adapter installed)

v Vital product data (VPD) (This includes information stored in nonvolatile memory

for easier remote viewing.)

v Wake on LAN and Alert Standard Format

IBM Director

With IBM Director, a network administrator can:

v View the hardware configuration of remote systems, in detail

v Monitor the usage and performance of critical components, such as

microprocessors, disks, and memory

v Centrally manage individual or large groups of IBM and non-IBM Intel-based

servers, desktop computers, workstations, and mobile computers on a variety of
platforms

IBM Director provides a comprehensive entry-level workgroup hardware manager.
Key features include:

v Advanced self-management capabilities for maximum system availability

Chapter 1. Introducing the xSeries™305 Type 8673 server 5

v Multiple operating-system platform support, including Microsoft®Windows®98,

Windows NT®, Windows 2000, Windows XP Professional, Novell NetWare, IBM

®

, SCO UnixWare, Linux®, and Caldera OpenUNIX

OS/2

®

v Support for IBM and non-IBM servers, desktop computers, workstations, and

mobile computers

v Support for systems-management industry standards

v Integration into leading workgroup and enterprise systems-management

environments

v Ease of use, training, and setup

IBM Director also provides an extensible platform that supports advanced server
tools that are designed to reduce the total cost of managing and supporting
networked systems. By deploying IBM Director, you can achieve reductions in
ownership costs through:

v Reduced downtime

v Increased productivity of IT personnel and users

v Reduced service and support costs

For more information about IBM Director, see the IBM Director CD that comes with
your server, the IBM Director publications on the CD, and the following Web pages:

Systems Management - Director Package

http://www.ibm.com/pc/qtechinfo/MIGR-40738.html

This Web page includes links to software downloads and publications for
the latest release of IBM Director.

IBM xSeries Systems Management page

http://www.ibm.com/pc/ww/eserver/xseries/systems_management/index.html

This Web page presents an overview of IBM Systems Management and
IBM Director.

IBM Universal Manageability page

http://www.ibm.com/pc/us/pc/um/index.html

This Web page links to an IBM portfolio of advanced management tools
that help reduce costs and increase availability throughout the life cycle of a
product.

6 xSeries 305 Type 8673: User’s Guide

Server controls, LEDs, and power

This section describes the controls and light-emitting diodes (LEDs) and how to turn
the server on and off.

Front view

The following illustration shows the controls and LEDs on the front of the server.

Power-control
button

USB 2 connector

USB 1 connector

Reset
button

Power-on
LED (green)

CD-eject button

CD-ROM drive
activity LED
(green)

Diskette drive
activity LED
(green)

Diskette-eject
button

System-error
LED (amber)

Hard disk drive
activity LED (green)

CD-eject button: Press this button to release a CD from the CD-ROM drive.

CD-ROM drive activity LED: When this LED is lit, it indicates that the CD-ROM

drive is in use.

Diskette drive activity LED: When this LED is lit, it indicates that the diskette drive
is in use.

Diskette-eject button: Press this button to release a diskette from the diskette
drive.

Power-control button: Press this button to turn the server on and off manually.

USB 2 Connector: Connect a USB device to this connector.

USB 1 Connector: Connect a USB device to this connector.

Power-on LED: When this LED is lit, it indicates that the server is turned on.

Reset button: Press this button to reset the server and run the power-on self-test

(POST). You might have to use a pen or the end of a straightened paper clip to
press the button.

Hard disk drive activity LED: When this LED is flashing, it indicates that the
associated hard disk drive is in use.

System-error LED: When this LED is lit, it indicates that a system error has
occurred.

Chapter 1. Introducing the xSeries™305 Type 8673 server 7

Rear view

The following illustration shows the LEDs on the rear of the server.

Ethernet 2 link
LED (green)

Ethernet 2 activity
LED (green)

Ethernet 1 activity
LED (green)

Ethernet 1 link
LED (green)

Ethernet 2 link LED (green): When this green LED is lit, it indicates that the speed
of the Ethernet LAN is 1000BASE-T. When this green LED is off, it indicates that
the speed of the Ethernet LAN is 10/100BASE-T.

Ethernet 2 activity LED (green): When this green LED is flashing, it indicates that
there is an active link connection between Ethernet port 2 and the network.

Ethernet 1 activity LED (green): When this green LED is flashing, it indicates that
there is an active link connection between Ethernet port 1 and the network.

Ethernet 1 link LED (green): When this green LED is lit, it indicates that the speed
of the Ethernet LAN is 1000BASE-T. When this green LED is off, it indicates that
the speed of the Ethernet LAN is 10/100BASE-T.

8 xSeries 305 Type 8673: User’s Guide

Server power features

This section contains information about how to turn your server on and off.

Turning on the server

Statement 13:

DANGER

Overloading a branch circuit is potentially a fire hazard and a shock hazard
under certain conditions. To avoid these hazards, ensure that your system
electrical requirements do not exceed branch circuit protection
requirements. Refer to the information that is provided with your device for
electrical specifications.

After you connect the server to an ac power source, the server can be turned on in
any of the following ways:

v You can press the power-control button on the front.

v If a power failure occurs while the server is turned on, the server can restart

automatically when the power is restored. To enable this feature in the
Configuration/Setup Utility program, select Power Management, Automatic
Power on, and Previous State.

Complete the following steps to manually turn on the server:

1. Review the information in “Safety” on page v.

2. Turn on all external devices, such as the monitor.

3. Plug the server power cord into the power source.

4. Press the power-control button on the front of the server.

Note: While the server is turning on, the power-on LED on the front of the

server is lit.

Turning off the server

Complete the following steps to manually turn off the server:

1. Review the information in “Safety” on page v.

2. See your operating system documentation for the proper procedure to shut
down the operating system.

When you turn off the server, observe the following precaution.

3. Press the power-control button on the front of the server.

Statement 5:

Chapter 1. Introducing the xSeries™305 Type 8673 server 9

CAUTION:
The power control button on the device and the power switch on the
power supply do not turn off the electrical current supplied to the device.
The device also might have more than one power cord. To remove all
electrical current from the device, ensure that all power cords are
disconnected from the power source.

2

1

10 xSeries 305 Type 8673: User’s Guide

Chapter 2. Configuring your server

The following configuration programs and capabilities come with your server:

v Configuration/Setup Utility program

This is part of the basic input/output system (BIOS) code in your server. Use it to
configure serial port assignments, change interrupt request (IRQ) settings,
change the startup-device sequence, set the date and time, and set passwords.

v IBM ServerGuide Setup and Installation CD

This provides software-setup tools and installation tools that are designed for
your server. Use this CD during the installation of your server to configure basic
hardware features and to simplify the installation of your operating system. For
information about using this CD, see “Using the ServerGuide Setup and
Installation CD” on page 15.

v SCSISelect Utility program (some models)

Use this to configure devices that are attached to the SCSI adapter. Use it to
change default settings, resolve configuration conflicts, and perform low-level
formats on SCSI hard disk drives. For information about using this utility
program, see “Using the SCSISelect Utility program (some models)” on page 18.

v Gigabit Ethernet controller configuration

Your server comes with two integrated Gigabit Ethernet controllers. These
controllers provide an interface for connecting to a 10-Mbps, 100-Mbps, or
1000-Mbps network and provides full-duplex (FDX) capability, which enables
simultaneous transmission and reception of data on the Ethernet local area
network (LAN).

v IBM Director

IBM Director is a workgroup-hardware-management tool that you can use to
centrally manage xSeries servers; IBM NetVista
computers; and non-IBM Intel-microprocessor-based systems. IBM Director
automates tasks such as inventory-taking, monitoring of environmental sensors
(such as temperature, voltage and fans), alerting, and system-health information.
For more information about IBM Director, see the IBM Director CD that comes
with your server.

™

, IntelliStation®, and ThinkPad

®

Using the Configuration/Setup Utility program

Use the Configuration/Setup Utility program to:

v View configuration information

v View and change assignments for devices and I/O ports

v Set the date and time

v Set and change passwords and Remote Control Security settings

v Set the startup characteristics of the server and the order of startup devices

v Set and change settings for advanced hardware features

v View and clear error logs

Starting the Configuration/Setup Utility program

Complete the following steps to start the Configuration/Setup Utility program:

1. Turn on the server.

2. When the prompt Press F1 for Configuration/Setup appears, press F1. If you
have set both a power-on password and an administrator password, you must

© Copyright IBM Corp. 2002 11

type the administrator password to access the full Configuration/Setup Utility
menu. If you do not type the administrator password, a limited
Configuration/Setup Utility menu is available.

3. Select settings to view or change.

Configuration/Setup Utility menu choices

The following choices are on the Configuration/Setup Utility main menu. Depending
on the version of the BIOS code in your server, some menu choices might differ
slightly from these descriptions.

v System Summary

Select this choice to view configuration information, including the type, speed,
and cache sizes of the microprocessors and the amount of installed memory.
When you make configuration changes through other options in the
Configuration/Setup Utility program, the changes are reflected in the system
summary; you cannot change settings directly in the system summary.

This choice is on the full and limited Configuration/Setup Utility menu.

v System Information

Select this choice to view information about your server. When you make
changes through other options in the Configuration/Setup Utility program, some
of those changes are reflected in the system information; you cannot change
settings directly in the system information.

v Devices and I/O Ports

Select this choice to view or change assignments for devices and input/output
(I/O) ports.

Select this choice to enable or disable Ethernet controllers and all standard ports
(such as serial and parallel). Enable is the default setting for all controllers. If you
disable a device, it cannot be configured, and the operating system will not be
able to detect it (this is equivalent to disconnecting the device). If you disable the
integrated Ethernet controllers and no Ethernet adapter is installed, the server
will have no Ethernet capability.

This choice is on the full Configuration/Setup Utility menu only.

v Start Options

Select this choice to view or change the start options. Changes in the start
options take effect when you restart the server.

You can set keyboard operating characteristics, such as the keyboard speed, and
you can specify whether the server starts with the keyboard number lock on or
off. You can enable the server to run without a diskette drive, monitor, or
keyboard.

The startup sequence specifies the order in which the server checks devices to
find a boot record. The server starts from the first boot record that it finds. If your
server has Wake on LAN hardware and software and the operating system
supports Wake on LAN functions, you can specify a startup sequence for the
Wake on LAN functions. You can also specify whether the integrated SCSI
controller or a PCI SCSI adapter has boot precedence.

If you enable the boot fail count, the BIOS default settings will be restored after
three consecutive failures to find a boot record.

You can enable a virus-detection test that checks for changes in the boot record
when the server starts.

This choice is on the full Configuration/Setup Utility menu only.

12 xSeries 305 Type 8673: User’s Guide

v Date and Time

Select this choice to set the date and time in the server, in 24-hour format
(hour:minute:second).

This choice is on the full Configuration/Setup Utility menu only.

v System Security

Select this choice to set passwords. See “Passwords” on page 14 for more
information about passwords.

v Advanced Setup

Select this choice to change values for the following advanced hardware
features:

Important: The server might malfunction if these options are incorrectly
configured. Follow the instructions on the screen carefully.

– Memory/Cache Options

Select this choice to enable or disable the microprocessor cache.
Attention: Do not make changes to the cache control unless directed to do

so by an IBM authorized service representative.

– PnP/PCI Options

Select this option to configure Plug-n-Play and PCI devices.

– CPU Frequency

Select this option to enable or disable the microprocessor cache.

v Power Management

Select this choice to enable or disable system power settings.

v Error Logs

Select this choice to display the POST error log and the System error log. The
System Error Log menu is available only when a Remote Supervisor Adapter is
installed.

v Save Settings

Select this choice to save the changes you have made in the settings.

v Restore Settings

Select this choice to cancel the changes you have made in the settings and
restore the previous settings.

v Load Default Settings

Select this choice to cancel the changes you have made in the settings and
restore the factory settings.

Chapter 2. Configuring your server 13

v Exit Setup

Select this choice to exit from the Configuration/Setup Utility program. If you have
not saved the changes you have made in the settings, you are asked whether
you want to save the changes or exit without saving them.

Additional Configuration/Setup Utility menu choices

When you install a Remote Supervisor Adapter in your server, you can view
additional menu choices in the Configuration/Setup Utility program, such as:

v System Card Data

Select this choice to display information about your server.

v Remote Control Security Settings

Select this choice to set a remote-control password. When you set a
remote-control password, you can also set the number of failed attempts to enter
the correct remote-control password, and the duration before another attempt is
allowed.

Passwords

From the System Security choice, you can set, change, and delete a power-on
password. The System Security choice is on the full Configuration/Setup menu
only.

If you set a power-on password, you must type the power-on password to complete
the system startup, and you have access to the full Configuration/Setup Utility
menu.

If you set a power-on password for a user and an administrator password for a
system administrator, you can type either password to complete the system startup.
A system administrator who types the administrator password has access to the full
Configuration/Setup Utility menu; the system administrator can give the user
authority to set, change, and delete the power-on password. A user who types the
power-on password has access to only the limited Configuration/Setup Utility menu;
the user can set, change, and delete the power-on password, if the system
administrator has given the user that authority.

Power-on password

If a power-on password (also known as the user’s password) is set, when you turn
on the server, the system startup will not be completed until you type the power-on
password. You can use any combination of up to seven characters (A–Z, a–z, and
0–9) for the password.

When a power-on password is set, you can enable the Unattended Start mode, in
which the keyboard and mouse remain locked but the operating system can start.
You can unlock the keyboard and mouse by typing the power-on password.

If you forget the power-on password, you can regain access to the server in any of
the following ways:

v If an administrator password is set, type the administrator password at the

password prompt. Start the Configuration/Setup Utility program and reset the
power-on password.

v Remove the server battery and then reinstall it. See the Option Installation Guide

for instructions for removing the battery.

14 xSeries 305 Type 8673: User’s Guide

Administrator password

If an administrator password is set, you must type the administrator password for
access to the full Configuration/Setup Utility menu. You can use any combination of
up to seven characters (A–Z, a–z, and 0–9) for the password.

Attention: If you set an administrator password and then forget it, there is no way
to change, override, or remove it. You must replace the system board.

Using the ServerGuide Setup and Installation CD

The ServerGuide Setup and Installation CD includes an easy-to-use setup and
installation program that is designed for your IBM server. The ServerGuide program
detects the server model and hardware options that are installed and uses that
information during setup to configure the hardware. The ServerGuide program
simplifies operating-system installations by providing updated device drivers and, in
some cases, installing them automatically.

To purchase the latest ServerGuide Setup and Installation CD, see the
“ServerGuide Updates” flyer that comes with your server library, or go to the
ServerGuide fulfillment Web site at http://www.ibm.com/pc/coupon/.

The ServerGuide program has the following features to make setup easier:

v An easy-to-use interface with online help

v Diskette-free setup, and configuration programs that are based on detected

hardware

v ServeRAID Manager program, which configures your ServeRAID adapter or

integrated SCSI controller with RAID capabilities, if installed

v A system BIOS code update program, which updates the BIOS code directly from

the CD

v Device drivers that are provided for your server model and detected hardware

v Operating-system partition size and file-system type that are selectable during

setup

ServerGuide features

Features and functions can vary slightly with different versions of the ServerGuide
program. To learn more about the version that you have, start the ServerGuide
Setup and Installation CD and view the online overview. Not all features are
supported on all server models.

The ServerGuide program requires a supported IBM server with an enabled
startable (bootable) CD-ROM drive. In addition to the ServerGuide Setup and
Installation CD, you must have your operating-system CD to install your operating
system.

The ServerGuide program has the following features:

v Sets system date and time.
v Detects the SCSI RAID adapter, controller, or integrated SCSI controller with

RAID capabilities, if installed and runs the SCSI RAID configuration program.

v Updates the licensed internal code (firmware) level without diskettes.
v Checks the system BIOS code and microcode (firmware) levels of supported

options to determine whether a later level is available from the CD. You can
perform updates without using diskettes.

v Creates a System Partition on the default drive. You can run server-specific utility

programs after setup.

Chapter 2. Configuring your server 15

v Detects installed hardware options and provides updated device drivers for most

adapters and devices.

v Creates a setup-replication diskette for replicating setup selections for other

servers of the same model.

v Provides diskette-free installation for supported operating systems.
v Provides a replicated installation path for multiple installations of supported

operating systems.

v Includes an online README file with links to tips for your hardware and

operating-system installation.

Setup and configuration overview

When you use the ServerGuide Setup and Installation CD, you do not need setup
diskettes. You can use the CD to configure any supported IBM server model. The
ServerGuide program checks your system BIOS, service processors, and other
system hardware to determine if system updates are available. The setup program
provides a list of tasks that are required to set up your server model. On a server
with a ServeRAID adapter or integrated SCSI controller with RAID capabilities, you
can run the SCSI RAID configuration program to create logical drives.

Note: Features and functions can vary slightly with different versions of the

ServerGuide program.

When you start the ServerGuide Setup and Installation CD, the program performs
the following tasks:

v The ServerGuide program prompts you for your language, country, and keyboard

layout. (This information is stored and later passed to the operating-system
installation program.)

v The ServerGuide program displays choices for running the configuration

programs. For example:

– The Express Configuration method runs the required programs for your

server, based on the hardware that is detected.

– The Custom Configuration method displays all programs that are available for

your server, and you decide which programs to run.

– The Replicated Configuration method provides the option of duplicating your

setup selections to other servers that are the same model.

v If you select the Custom Configuration method, the following features are

optional. If you select the Express Configuration method, some or all of these
features are run, depending on the hardware that is detected:

– The Set Date and Time feature is provided so that you do not have to use the

Configuration/Setup Utility program to access these settings.

– The Clear Hard Disks feature is provided so you can delete all partitions on all

hard disk drives.

– The ServerGuide program checks the server BIOS code and microcode

(firmware) levels for supported options and then checks the CD for a newer
level. The CD content might be newer than the BIOS code and firmware level.
The ServerGuide program can perform a flash update of the BIOS code and
supported microcode (firmware) options without using diskettes.

– The SCSI RAID configuration program starts, leading you through the entire

configuration process.

– The ServerGuide program creates a System Partition on the default drive.

16 xSeries 305 Type 8673: User’s Guide

v The ServerGuide program displays a confirmation summary, so that you will

Notes:

1. Plug and Play adapters are configured automatically. Non-Plug and Play

2. Diagnostics for your server come in BIOS code or on a separate diagnostics

System Partition

The ServerGuide program creates a 50 MB System Partition on the default drive.
The System Partition contains server-specific utility programs such as
service-processor disk operating system (DOS) utilities, system diagnostics, flash
BIOS updates, and other programs. Programs in the System Partition vary by
server model, and not all server models run utility programs from the System
Partition. To determine which ones do, start the ServerGuide Setup and Installation
CD and view the online overview.

After setup is complete, you can access programs in the System Partition by
restarting the server and pressing Alt+F1 when the prompt is displayed. The
System Partition menu displays the programs that are available on your server
model.

know when you have completed all the required tasks. Then, you are ready to
install your operating system.

adapters or non-IBM adapters might require switch settings, additional device
drivers, and installation after the operating system is installed. See the
documentation that comes with the adapter.

CD.

Typical operating-system installation

You can use the ServerGuide program to shorten your installation time. The
ServerGuide program provides the device drivers that are required for your
hardware and for the operating system that you are installing. This section
describes a typical ServerGuide operating-system installation.

Note: Features and functions can vary slightly with different versions of the

ServerGuide program.

1. After you have completed the setup process, the operating-system installation
program starts. (You will need your operating-system CD to complete the
installation.)

2. The ServerGuide program stores information about the server model, service
processor, hard disk drive controllers, and network adapters. Then, the program
checks the CD for newer device drivers. This information is stored and then
passed to the operating-system installation program.

3. With some operating-system installations, you can create an operating-system
replication diskette for setting up additional servers. This diskette contains the
Internet protocol (IP) address, server name, and other selections.

4. The ServerGuide program presents operating-system partition options that are
based on your operating-system selection and the installed hard disk drives.

5. If you are installing the operating system from diskettes, the ServerGuide
program lists the diskettes that you must create and the optional device-driver
diskettes (for installed adapters or controllers) that you might want to create.

6. The ServerGuide program prompts you to insert your operating-system CD and
restart the server. At this point, the installation program for the operating system
takes control to complete the installation.

Chapter 2. Configuring your server 17

Setting up or updating multiple servers

You can use the ServerGuide program to create diskettes that help you set up or
update multiple servers. You can modify information on the diskettes as you use
them to set up or update other servers.

Note: Availability and function can vary by server model and by the hardware that

is installed.

You can create a setup-replication diskette, which contains your hardware
configuration selections. Use this diskette to replicate selections to other servers
that are of the same model.

You can create an operating-system replication diskette, which contains information
that you need to complete multiple installations. Not all operating systems support
operating-system replication diskettes.

Installing your operating system without ServerGuide

If you have already configured the server hardware and you decide not to use the
ServerGuide program to install your operating system, complete the following steps
to download the latest operating-system installation instructions from the IBM
Support Web page:

1. Go to http://www.ibm.com/pc/support/.

2. Under Browse, click Servers.

3. From the Family drop-down list, select your server model.

4. If operating-system installation instructions are available for your server model,

OS installation is in the list in the upper-left corner of the Web page. Click OS
installation and select the instructions for your operating system.

Using the SCSISelect Utility program (some models)

Use the SCSISelect Utility program to:

v View the default SCSI IDs

v Locate and correct configuration conflicts

v Perform a low-level format on a SCSI hard disk

Starting the SCSISelect Utility program

Complete the following steps to start the SCSISelect Utility program:

1. Turn on the server.

2. When the prompt <<< Press <CTRL><A> for SCSISelect Utility! >>> appears,

press Ctrl+A. If you have set an administrator password, you are prompted to
type the password.

3. When the prompt Would you like to configure the SCSISelect controller or
run the SCSI Disk Utilities? appears, make your selection and press Enter.

4. Use the arrow keys to select a choice from the menu.

5. Follow the instructions on the screen to change the settings of the selected
items, and press Enter.

SCSISelect Utility menu choices

The following choices are on the Configure/View SCSI Controller Settings and the
SCSI Disk Utilities menu:

v Configure/View SCSI Controller Settings

18 xSeries 305 Type 8673: User’s Guide

– Configuration

Select this choice to view or change SCSI controller settings. To reset the
controller to its default settings, press F6 and follow the instructions on the
screen.

You can view and change the following controller settings:

- SCSI Controller ID

Select this choice to view the SCSI controller ID, which is typically 7.

- SCSI Controller Parity
This choice is set to Enabled and cannot be changed.

- SCSI Controller Termination
This choice is set to Enabled and cannot be changed.

– Additional Options

Select this choice to view or change the setting for advanced configuration
options. These options include support for large hard disk drives and support
for drives with Ultra SCSI speeds.

- Boot Device Configurations

Select this choice to configure startable-device parameters. You must know
the SCSI ID of the device that you want to configure.

- SCSI Device Configuration

Select this choice to configure SCSI-device parameters. You must know the
SCSI ID of the device that you want to configure.

The sync transfer rate is the transfer rate for Ultra SCSI devices. For Ultra3
SCSI LVD devices, the maximum rate is 160 MBps; for Ultra2 SCSI
devices, 80 MBps; for Fast SCSI devices, 20 MBps.

- Advanced Configurations

Select this choice to reset the SCSI Bus and to display a message during
BIOS initialization.

– BIOS Information

- Interrupt (IRQ) Channel

Select this choice to view the Change Interrupt Request settings.

- I/O Port Address

Select this choice to view the Input/Output ports.

v SCSI Disk Utilities

Select this choice to view the SCSI ID that is assigned to a device or to format a
SCSI device. Select a device from the list and read the instructions on the screen
carefully before making a selection.

Chapter 2. Configuring your server 19

Configuring the Gigabit Ethernet controller

The Ethernet controller is integrated on the system board. This controller provides
an interface for connecting to 10-Mbps, 100-Mbps, or 1000-Mbps networks and
provides full duplex (FDX) capability, which enables simultaneous transmission and
reception of data on the Ethernet local area network (LAN). You do not need to set
any jumpers or configure the controller for your operating system before you use
the Ethernet controller. However, you must install a device driver to enable your
operating system to address the Ethernet controller. The device drivers are provided
on the ServerGuide Setup and Installation CD.

When you connect your server to the network, the Ethernet controller automatically
detects the data-transfer rate (10-Mbps, 100-Mbps, or 1000-Mbps) on the network
and then sets the controller to operate at the appropriate rate. In addition, if the
Ethernet ports that your server is connected to support auto-negotiation, the Gigabit
Ethernet controller will set the appropriate duplex state. That is, the Ethernet
controller will adjust to the network data rate, whether the data rate is standard
Ethernet (10BASE-T), Fast Ethernet (100BASE-TX/1000BASE-T), half duplex
(HDX), or full duplex (FDX). The controller supports half-duplex (HDX) and
full-duplex (FDX) modes at both speeds.

For information on configuring your Ethernet controller, see the Broadcom
NetXtreme Gigabit Ethernet Software CD that comes with your server. For updated
information on configuring your Ethernet controller, go to the IBM Support Web site
at http://www.ibm.com/pc/support and navigate to the area for your specific server
type. From this area, you can download documentation, the most current device
drivers for your server, and software that supports advanced networking functions.
After downloading, run the downloaded program launch.exe.

High-performance Ethernet modes

Your Ethernet controller supports optional modes, such as teaming, priority packets,
load balancing, fault tolerance, and virtual LANs, which provide higher performance,
security, and throughput for your server. These modes apply to the integrated
Ethernet controller and to the controllers on supported Ethernet adapters.

20 xSeries 305 Type 8673: User’s Guide

Appendix A. Getting help and technical assistance

If you need help, service, or technical assistance or just want more information
about IBM products, you will find a wide variety of sources available from IBM to
assist you. This appendix contains information about where to go for additional
information about IBM and IBM products, what to do if you experience a problem
with your xSeries or IntelliStation
necessary.

Before you call

Before you call, make sure that you have taken these steps to try to solve the
problem yourself:

v Check all cables to make sure that they are connected.

v Check the power switches to make sure that the system is turned on.

v Use the troubleshooting information in your system documentation, and use the

diagnostic tools that come with your system.

v Go to the IBM Support Web site at http://www.ibm.com/pc/support/ to check for

technical information, hints, tips, and new device drivers.

v Use an IBM discussion forum on the IBM Web site to ask questions.

You can solve many problems without outside assistance by following the
troubleshooting procedures that IBM provides in the online help or in the
publications that are provided with your system and software. The information that
comes with your system also describes the diagnostic tests that you can perform.
Most xSeries and IntelliStation systems, operating systems, and programs come
with information that contains troubleshooting procedures and explanations of error
messages and error codes. If you suspect a software problem, see the information
for the operating system or program.

®

system, and whom to call for service, if it is

Using the documentation

Information about your IBM xSeries or IntelliStation system and preinstalled
software, if any, is available in the documentation that comes with your system.
That documentation includes printed books, online books, README files, and help
files. See the troubleshooting information in your system documentation for
instructions for using the diagnostic programs. The troubleshooting information or
the diagnostic programs might tell you that you need additional or updated device
drivers or other software. IBM maintains pages on the World Wide Web where you
can get the latest technical information and download device drivers and updates.
To access these pages, go to http://www.ibm.com/pc/support/ and follow the
instructions. Also, you can order publications through the IBM Publications Ordering
System at
http://www.elink.ibmlink.ibm.com/public/applications/publications/cgibin/pbi.cgi.

Getting help and information from the World Wide Web

On the World Wide Web, the IBM Web site has up-to-date information about IBM
xSeries and IntelliStation™products, services, and support. The address for IBM
xSeries information is http://www.ibm.com/eserver/xseries/. The address for IBM
IntelliStation information is http://www.ibm.com/pc/intellistation/.

© Copyright IBM Corp. 2002 21

You can find service information for your IBM products, including supported options,
at http://www.ibm.com/pc/support/. If you click Profile from the support page, you
can create a customized support page. The support page has many sources of
information and ways for you to solve problems, including:

v Diagnosing problems, using the IBM Online Assistant

v Downloading the latest device drivers and updates for your products

v Viewing Frequently Asked Questions (FAQ)

v Viewing hints and tips to help you solve problems

v Participating in IBM discussion forums

v Setting up e-mail notification of technical updates about your products

Software service and support

Through IBM Support Line, you can get telephone assistance, for a fee, with usage,
configuration, and software problems with xSeries servers, IntelliStation
workstations, and appliances. For information about which products are supported
by Support Line in your country or region, go to
http://www.ibm.com/services/sl/products/.

For more information about Support Line and other IBM services, go to
http://www.ibm.com/services/, or go to http://www.ibm.com/planetwide/ for support
telephone numbers.

Hardware service and support

You can receive hardware service through IBM Integrated Technology Services or
through your IBM reseller, if your reseller is authorized by IBM to provide warranty
service. Go to http://www.ibm.com/planetwide/ for support telephone numbers.

In the U.S. and Canada, hardware service and support is available 24 hours a day,
7 days a week. In the U.K., these services are available Monday through Friday,
from 9 a.m. to 6 p.m.

22 xSeries 305 Type 8673: User’s Guide

Appendix B. Warranty information

This section contains information about your warranty period and the service and
support that are provided by your warranty.

Warranty period

The warranty period varies by machine type and country or region.

Contact your place of purchase for warranty service information. Some IBM
Machines are eligible for on-site warranty service depending on the country or
region where service is performed.

Prior to on-site warranty service, you are required to go through problem
determination with an IBM service specialist call center technician.

A warranty period of 3 years on parts and 1 year on labor means that IBM will
provide warranty service without charge for:

1. parts and labor during the first year of the warranty period

2. parts only, on an exchange basis, in the second and third years of the warranty
period. IBM will charge you for any labor it provides in performance of the repair
or replacement.

The IBM Machine Warranties Web site at
http://www.ibm.com/servers/support/machine_warranties/ contains a worldwide
overview of the IBM Statement of Limited Warranty for IBM Machines, a glossary of
terms used in the Statement of Limited Warranty, Frequently Asked Questions
(FAQ), and links to Product Support Web pages. The IBM Statement of Limited
Warranty is available from this Web site in 29 languages in Portable Document
Format (PDF).

Machine - IBM xSeries 305 Type 8673

Country or region Warranty period Service delivery method

Worldwide 1 year On-site

Problem determination

Prior to on-site warranty service, you are required to go through problem
determination with an IBM service specialist call center technician. The service
specialist will run diagnostic tests on the hardware and check the software.

Running diagnostics

The IBM service specialist will help you determine whether your equipment is
functioning as specified. It might be necessary to isolate the failing xSeries,
Netfinity
production environment to run diagnostics and perform defect-isolation programs.
You are responsible for making the system, IBM component, or both available for
running diagnostics and defect-isolation programs.

Checking software

The IBM service specialist will help you ensure that the correct BIOS code,
firmware, device drivers, and other supporting IBM software are installed and
correctly configured. It might be necessary to manually gather information about the
relevant software levels or run IBM-approved utility programs to gather this

®

, or IntelliStation system; IBM component; or both from any active

© Copyright IBM Corp. 2002 23

information. It might be necessary to isolate the failing system from any active
production environment to gather this information. You are responsible, with
assistance from the service specialist, for gathering this information. The IBM
Statement of Limited Warranty does not include on-site assistance with this activity.

Warranty service and support

With the original purchase of an IBM xSeries or IntelliStation system, you have
access to extensive service and support. During the IBM Machine warranty period,
you may call IBM or your reseller for problem-determination assistance under the
terms of the IBM Statement of Limited Warranty.

The following services are available during the warranty period:
v Problem determination - Trained personnel are available to assist you with

determining if you have a hardware problem and deciding what action is
necessary to fix the problem.

v IBM hardware repair - If the problem is determined to be caused by IBM

hardware under warranty, trained service personnel are available to provide the
applicable level of service, either on-site or at an IBM service center as
determined by IBM.

v Engineering Change management - Occasionally, there might be changes that

are required after a product has been shipped from IBM. In those instances, IBM
will make Engineering Changes (ECs) available that apply to your hardware.

v Customer replaceable units (CRUs) - Some parts of IBM xSeries and

IntelliStation systems are designated as customer replaceable units. IBM ships
CRUs to you for replacement by you. CRUs include keyboards, monitors,
memory, diskette drives, hard disk drives, and mice (this list is not inclusive of all
CRUs).

The following items are not covered under warranty service:

v Replacement or use of non-IBM parts. All IBM parts contain a 7-character

identification in the format IBM FRU XXXXXXX.

v Identification of software problem sources.

v Installation of customer replaceable units (CRUs).

v Installation and configuration of BIOS code, firmware, or device drivers that are

designated as customer installable.

See the IBM Statement of Limited Warranty for a full explanation of IBM warranty
terms. Be sure to retain your proof of purchase to obtain warranty service.

Please have the following information ready when you call:

v The machine type and model of your IBM hardware product (if available)

v Serial numbers of your IBM hardware products

v A description of the problem

v The exact wording of any error messages

v Hardware and software configuration information

International Warranty Service

If you travel with your xSeries or IntelliStation system or relocate it to a country or
region where your system is sold and serviced by IBM or IBM resellers authorized
to perform warranty service, International Warranty Service (IWS) is available during
the warranty period. Eligible IBM systems are identified by their four-digit machine
types.

24 xSeries 305 Type 8673: User’s Guide

You can obtain IWS through the service delivery method (such as depot, carry-in, or
on-site) provided in the servicing country or region. Service methods and
procedures vary by country or region, and some service or parts might not be
available in all countries and regions. Service centers in certain countries or regions
might not be able to service all models of a particular machine type. In addition,
some countries or regions might have fees and restrictions that apply at the time of
service.

To determine whether your system is eligible for IWS, go to
http://www.ibm.com/pc/support/ and click Warranty lookup.

Purchasing additional services

During and after the warranty period, you can purchase additional services, such as
support for IBM and non-IBM hardware, operating systems, and application
programs; network setup and configuration; upgraded or extended hardware repair
services; and custom installations. Service availability and service name might vary
by country or region.

For more information about these services, contact your IBM marketing
representative.

Appendix B. Warranty information 25

IBM Statement of Limited Warranty Z125-4753-06 8/2000

Part 1 - General Terms

This Statement of Limited Warranty includes Part 1 - General Terms and Part 2 ­Country-unique Terms. The terms of Part 2 replace or modify those of Part 1. The
warranties provided by IBM in this Statement of Limited Warranty apply only to
Machines you purchase for your use, and not for resale, from IBM or your reseller.
The term “Machine” means an IBM machine, its features, conversions, upgrades,
elements, or accessories, or any combination of them. The term “Machine” does not
include any software programs, whether pre-loaded with the Machine, installed
subsequently or otherwise. Unless IBM specifies otherwise, the following warranties
apply only in the country where you acquire the Machine. Nothing in this Statement
of Limited Warranty affects any statutory rights of consumers that cannot be waived
or limited by contract. If you have any questions, contact IBM or your reseller.

The IBM Warranty for Machines: IBM warrants that each Machine 1) is free from
defects in materials and workmanship and 2) conforms to IBM’s Official Published
Specifications (“Specifications”). The warranty period for a Machine is a specified,
fixed period commencing on its Date of Installation. The date on your sales receipt
is the Date of Installation unless IBM or your reseller informs you otherwise.

If a Machine does not function as warranted during the warranty period, and IBM or
your reseller are unable to either 1) make it do so or 2) replace it with one that is at
least functionally equivalent, you may return it to your place of purchase and your
money will be refunded.

Extent of Warranty: The warranty does not cover the repair or exchange of a
Machine resulting from misuse, accident, modification, unsuitable physical or
operating environment, improper maintenance by you, or failure caused by a
product for which IBM is not responsible. The warranty is voided by removal or
alteration of Machine or parts identification labels.

THESE WARRANTIES ARE YOUR EXCLUSIVE WARRANTIES AND REPLACE
ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THESE WARRANTIES GIVE YOU SPECIFIC LEGAL RIGHTS AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM JURISDICTION TO
JURISDICTION. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF EXPRESS OR IMPLIED WARRANTIES, SO THE ABOVE
EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU. IN THAT EVENT, SUCH
WARRANTIES ARE LIMITED IN DURATION TO THE WARRANTY PERIOD. NO
WARRANTIES APPLY AFTER THAT PERIOD.

Items Not Covered by Warranty: IBM does not warrant uninterrupted or error-free

operation of a Machine. Any technical or other support provided for a Machine
under warranty, such as assistance via telephone with “how-to” questions and those
regarding Machine set-up and installation, will be provided WITHOUT

WARRANTIES OF ANY KIND.

Warranty Service: To obtain warranty service for a Machine, contact IBM or your

reseller. If you do not register your Machine with IBM, you may be required to
present proof of purchase.

26 xSeries 305 Type 8673: User’s Guide

During the warranty period, IBM or your reseller, if approved by IBM to provide
warranty service, provides without charge certain types of repair and exchange
service to keep Machines in, or restore them to, conformance with their
Specifications. IBM or your reseller will inform you of the available types of service
for a Machine based on its country of installation. At its discretion, IBM or your
reseller will 1) either repair or exchange the failing Machine and 2) provide the
service either at your location or a service center. IBM or your reseller will also
manage and install selected engineering changes that apply to the Machine.

Some parts of IBM Machines are designated as Customer Replaceable Units
(called “CRUs”), e.g., keyboards, memory, or hard disk drives. IBM ships CRUs to
you for replacement by you. You must return all defective CRUs to IBM within 30
days of your receipt of the replacement CRU. You are responsible for downloading
designated Machine Code and Licensed Internal Code updates from an IBM
Internet Web site or from other electronic media, and following the instructions that
IBM provides.

When warranty service involves the exchange of a Machine or part, the item IBM or
your reseller replaces becomes its property and the replacement becomes yours.
You represent that all removed items are genuine and unaltered. The replacement
may not be new, but will be in good working order and at least functionally
equivalent to the item replaced. The replacement assumes the warranty service
status of the replaced item. Many features, conversions, or upgrades involve the
removal of parts and their return to IBM. A part that replaces a removed part will
assume the warranty service status of the removed part.

Before IBM or your reseller exchanges a Machine or part, you agree to remove all
features, parts, options, alterations, and attachments not under warranty service.

You also agree to

1. ensure that the Machine is free of any legal obligations or restrictions that
prevent its exchange;

2. obtain authorization from the owner to have IBM or your reseller service a
Machine that you do not own; and

3. where applicable, before service is provided:
a. follow the problem determination, problem analysis, and service request

procedures that IBM or your reseller provides;
b. secure all programs, data, and funds contained in a Machine;
c. provide IBM or your reseller with sufficient, free, and safe access to your

facilities to permit them to fulfill their obligations; and
d. inform IBM or your reseller of changes in a Machine’s location.

IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM’s
possession or 2) in transit in those cases where IBM is responsible for the
transportation charges.

Neither IBM nor your reseller is responsible for any of your confidential, proprietary
or personal information contained in a Machine which you return to IBM or your
reseller for any reason. You should remove all such information from the Machine
prior to its return.

Limitation of Liability: Circumstances may arise where, because of a default on
IBM’s part or other liability, you are entitled to recover damages from IBM. In each
such instance, regardless of the basis on which you are entitled to claim damages
from IBM (including fundamental breach, negligence, misrepresentation, or other

Appendix B. Warranty information 27

contract or tort claim), except for any liability that cannot be waived or limited by
applicable laws, IBM is liable for no more than

1. damages for bodily injury (including death) and damage to real property and
tangible personal property; and

2. the amount of any other actual direct damages, up to the charges (if recurring,
12 months’ charges apply) for the Machine that is subject of the claim. For
purposes of this item, the term “Machine” includes Machine Code and Licensed
Internal Code.

This limit also applies to IBM’s suppliers and your reseller. It is the maximum for
which IBM, its suppliers, and your reseller are collectively responsible.

UNDER NO CIRCUMSTANCES IS IBM LIABLE FOR ANY OF THE FOLLOWING:

1) THIRD-PARTY CLAIMS AGAINST YOU FOR DAMAGES (OTHER THAN

THOSE UNDER THE FIRST ITEM LISTED ABOVE); 2) LOSS OF, OR DAMAGE
TO, YOUR RECORDS OR DATA; OR 3) SPECIAL, INCIDENTAL, OR INDIRECT
DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES, LOST
PROFITS OR LOST SAVINGS, EVEN IF IBM, ITS SUPPLIERS OR YOUR
RESELLER IS INFORMED OF THEIR POSSIBILITY. SOME JURISDICTIONS DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION
MAY NOT APPLY TO YOU.

Governing Law: Both you and IBM consent to the application of the laws of the

country in which you acquired the Machine to govern, interpret, and enforce all of
your and IBM’s rights, duties, and obligations arising from, or relating in any manner
to, the subject matter of this Agreement, without regard to conflict of law principles.

Part 2 - Country-unique Terms

AMERICAS

BRAZIL

Governing Law: The following is added after the first sentence:Any litigation arising

from this Agreement will be settled exclusively by the court of Rio de Janeiro.

NORTH AMERICA

Warranty Service: The following is added to this Section: To obtain warranty

service from IBM in Canada or the United States, call 1-800-IBM-SERV (426-7378).

CANADA

Governing Law: The following replaces “laws of the country in which you acquired

the Machine” in the first sentence: laws in the Province of Ontario.

UNITED STATES

Governing Law: The following replaces “laws of the country in which you acquired

the Machine” in the first sentence: laws of the State of New York.

ASIA PACIFIC

AUSTRALIA

28 xSeries 305 Type 8673: User’s Guide

The IBM Warranty for Machines: The following paragraph is added to this Section:

The warranties specified in this Section are in addition to any rights you may have
under the Trade Practices Act 1974 or other similar legislation and are only limited
to the extent permitted by the applicable legislation.

Limitation of Liability: The following is added to this Section: Where IBM is in
breach of a condition or warranty implied by the Trade Practices Act 1974 or other
similar legislation, IBM’s liability is limited to the repair or replacement of the goods
or the supply of equivalent goods. Where that condition or warranty relates to right
to sell, quiet possession or clear title, or the goods are of a kind ordinarily acquired
for personal, domestic or household use or consumption, then none of the
limitations in this paragraph apply.

Governing Law: The following replaces “laws of the country in which you acquired
the Machine” in the first sentence: laws of the State or Territory.

CAMBODIA, LAOS, AND VIETNAM

Governing Law: The following replaces “laws of the country in which you acquired

the Machine” in the first sentence:laws of the State of New York.

The following is added to this Section: Disputes and differences arising out of or in

connection with this Agreement shall be finally settled by arbitration which shall be
held in Singapore in accordance with the rules of the International Chamber of
Commerce (ICC). The arbitrator or arbitrators designated in conformity with those
rules shall have the power to rule on their own competence and on the validity of
the Agreement to submit to arbitration. The arbitration award shall be final and
binding for the parties without appeal and the arbitral award shall be in writing and
set forth the findings of fact and the conclusions of law.

All proceedings shall be conducted, including all documents presented in such
proceedings, in the English language. The number of arbitrators shall be three, with
each side to the dispute being entitled to appoint one arbitrator.

The two arbitrators appointed by the parties shall appoint a third arbitrator before
proceeding upon the reference. The third arbitrator shall act as chairman of the
proceedings. Vacancies in the post of chairman shall be filled by the president of
the ICC. Other vacancies shall be filled by the respective nominating party.
Proceedings shall continue from the stage they were at when the vacancy occurred.

If one of the parties refuses or otherwise fails to appoint an arbitrator within 30 days
of the date the other party appoints its, the first appointed arbitrator shall be the
sole arbitrator, provided that the arbitrator was validly and properly appointed.

The English language version of this Agreement prevails over any other language
version.

HONG KONG AND MACAU

Governing Law: The following replaces “laws of the country in which you acquired

the Machine” in the first sentence: laws of Hong Kong Special Administrative
Region.

INDIA

Limitation of Liability: The following replaces items 1 and 2 of this Section:

Appendix B. Warranty information 29

1. liability for bodily injury (including death) or damage to real property and tangible
personal property will be limited to that caused by IBM’s negligence;

2. as to any other actual damage arising in any situation involving nonperformance
by IBM pursuant to, or in any way related to the subject of this Statement of
Limited Warranty, IBM’s liability will be limited to the charge paid by you for the
individual Machine that is the subject of the claim.

JAPAN

Governing Law: The following sentence is added to this Section:Any doubts

concerning this Agreement will be initially resolved between us in good faith and in
accordance with the principle of mutual trust.

NEW ZEALAND

The IBM Warranty for Machines: The following paragraph is added to this Section:

The warranties specified in this Section are in addition to any rights you may have
under the Consumer Guarantees Act 1993 or other legislation which cannot be
excluded or limited. The Consumer Guarantees Act 1993 will not apply in respect of
any goods which IBM provides, if you require the goods for the purposes of a
business as defined in that Act.

Limitation of Liability: The following is added to this Section: Where Machines are
not acquired for the purposes of a business as defined in the Consumer
Guarantees Act 1993, the limitations in this Section are subject to the limitations in
that Act.

PEOPLE’S REPUBLIC OF CHINA (PRC)

Governing Law: The following replaces this Section: Both you and IBM consent to

the application of the laws of the State of New York (except when local law requires
otherwise) to govern, interpret, and enforce all your and IBM’s rights, duties, and
obligations arising from, or relating in any manner to, the subject matter of this
Agreement, without regard to conflict of law principles.

Any disputes arising from or in connection with this Agreement will first be resolved
by friendly negotiations, failing which either of us has the right to submit the dispute
to the China International Economic and Trade Arbitration Commission in Beijing,
the PRC, for arbitration in accordance with its arbitration rules in force at the time.
The arbitration tribunal will consist of three arbitrators. The language to be used
therein will be English and Chinese. An arbitral award will be final and binding on all
the parties, and will be enforceable under the Convention on the Recognition and
Enforcement of Foreign Arbitral Awards (1958).

The arbitration fee will be borne by the losing party unless otherwise determined by
the arbitral award.

During the course of arbitration, this Agreement will continue to be performed
except for the part which the parties are disputing and which is undergoing
arbitration.

EUROPE, MIDDLE EAST, AFRICA (EMEA)

THE FOLLOWING TERMS APPLY TO ALL EMEA COUNTRIES: The terms of this
Statement of Limited Warranty apply to Machines purchased from IBM or an IBM
reseller.

30 xSeries 305 Type 8673: User’s Guide

Warranty Service: If you purchase an IBM Machine in Austria, Belgium, Denmark,
Estonia, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland or United
Kingdom, you may obtain warranty service for that Machine in any of those
countries from either (1) an IBM reseller approved to perform warranty service or
(2) from IBM. If you purchase an IBM Personal Computer Machine in Albania,
Armenia, Belarus, Bosnia and Herzegovina, Bulgaria, Croatia, Czech Republic,
Georgia, Hungary, Kazakhstan, Kirghizia, Federal Republic of Yugoslavia, Former
Yugoslav Republic of Macedonia (FYROM), Moldova, Poland, Romania, Russia,
Slovak Republic, Slovenia, or Ukraine, you may obtain warranty service for that
Machine in any of those countries from either (1) an IBM reseller approved to
perform warranty service or (2) from IBM.

If you purchase an IBM Machine in a Middle Eastern or African country, you may
obtain warranty service for that Machine from the IBM entity within the country of
purchase, if that IBM entity provides warranty service in that country, or from an
IBM reseller, approved by IBM to perform warranty service on that Machine in that
country. Warranty service in Africa is available within 50 kilometers of an IBM
authorized service provider. You are responsible for transportation costs for
Machines located outside 50 kilometers of an IBM authorized service provider.

Governing Law: The applicable laws that govern, interpret and enforce rights,
duties, and obligations of each of us arising from, or relating in any manner to, the
subject matter of this Statement, without regard to conflict of laws principles, as well
as Country-unique terms and competent court for this Statement are those of the
country in which the warranty service is being provided, except that in 1) Albania,
Bosnia-Herzegovina, Bulgaria, Croatia, Hungary, Former Yugoslav Republic of
Macedonia, Romania, Slovakia, Slovenia, Armenia, Azerbaijan, Belarus, Georgia,
Kazakhstan, Kyrgyzstan, Moldova, Russia, Tajikistan, Turkmenistan, Ukraine, and
Uzbekistan, the laws of Austria apply; 2) Estonia, Latvia, and Lithuania, the laws of
Finland apply; 3) Algeria, Benin, Burkina Faso, Cameroon, Cape Verde, Central
African Republic, Chad, Congo, Djibouti, Democratic Republic of Congo, Equatorial
Guinea, France, Gabon, Gambia, Guinea, Guinea-Bissau, Ivory Coast, Lebanon,
Mali, Mauritania, Morocco, Niger, Senegal, Togo, and Tunisia, this Agreement will
be construed and the legal relations between the parties will be determined in
accordance with the French laws and all disputes arising out of this Agreement or
related to its violation or execution, including summary proceedings, will be settled
exclusively by the Commercial Court of Paris; 4) Angola, Bahrain, Botswana,
Burundi, Egypt, Eritrea, Ethiopia, Ghana, Jordan, Kenya, Kuwait, Liberia, Malawi,
Malta, Mozambique, Nigeria, Oman, Pakistan, Qatar, Rwanda, Sao Tome, Saudi
Arabia, Sierra Leone, Somalia, Tanzania, Uganda, United Arab Emirates, United
Kingdom, West Bank/Gaza, Yemen, Zambia, and Zimbabwe, this Agreement will be
governed by English Law and disputes relating to it will be submitted to the
exclusive jurisdiction of the English courts; and 5) in Greece, Israel, Italy, Portugal,
and Spain any legal claim arising out of this Statement will be brought before, and
finally settled by, the competent court of Athens, Tel Aviv, Milan, Lisbon, and Madrid,
respectively.

THE FOLLOWING TERMS APPLY TO THE COUNTRY SPECIFIED:

AUSTRIA AND GERMANY

The IBM Warranty for Machines: The following replaces the first sentence of the

first paragraph of this Section: The warranty for an IBM Machine covers the
functionality of the Machine for its normal use and the Machine’s conformity to its
Specifications.

Appendix B. Warranty information 31

The following paragraphs are added to this Section:

The minimum warranty period for Machines is six months. In case IBM or your
reseller is unable to repair an IBM Machine, you can alternatively ask for a partial
refund as far as justified by the reduced value of the unrepaired Machine or ask for
a cancellation of the respective agreement for such Machine and get your money
refunded.

Extent of Warranty: The second paragraph does not apply.

Warranty Service: The following is added to this Section: During the warranty

period, transportation for delivery of the failing Machine to IBM will be at IBM’s
expense.

Limitation of Liability: The following paragraph is added to this Section: The
limitations and exclusions specified in the Statement of Limited Warranty will not
apply to damages caused by IBM with fraud or gross negligence and for express
warranty.

The following sentence is added to the end of item 2: IBM’s liability under this item
is limited to the violation of essential contractual terms in cases of ordinary
negligence.

EGYPT

Limitation of Liability: The following replaces item 2 in this Section: as to any

other actual direct damages, IBM’s liability will be limited to the total amount you
paid for the Machine that is the subject of the claim. For purposes of this item, the
term “Machine” includes Machine Code and Licensed Internal Code.

Applicability of suppliers and resellers (unchanged).

FRANCE

Limitation of Liability: The following replaces the second sentence of the first

paragraph of this Section:In such instances, regardless of the basis on which you
are entitled to claim damages from IBM, IBM is liable for no more than: (items 1
and 2 unchanged).

IRELAND

Extent of Warranty: The following is added to this Section: Except as expressly

provided in these terms and conditions, all statutory conditions, including all
warranties implied, but without prejudice to the generality of the foregoing all
warranties implied by the Sale of Goods Act 1893 or the Sale of Goods and Supply
of Services Act 1980 are hereby excluded.

Limitation of Liability: The following replaces items one and two of the first
paragraph of this Section:1. death or personal injury or physical damage to your

real property solely caused by IBM’s negligence; and 2. the amount of any other
actual direct damages, up to 125 percent of the charges (if recurring, the 12
months’ charges apply) for the Machine that is the subject of the claim or which
otherwise gives rise to the claim.

Applicability of suppliers and resellers (unchanged).

32 xSeries 305 Type 8673: User’s Guide

The following paragraph is added at the end of this Section: IBM’s entire liability
and your sole remedy, whether in contract or in tort, in respect of any default shall
be limited to damages.

ITALY

Limitation of Liability: The following replaces the second sentence in the first

paragraph:In each such instance unless otherwise provided by mandatory law, IBM
is liable for no more than: 1. (unchanged) 2. as to any other actual damage arising
in all situations involving nonperformance by IBM pursuant to, or in any way related
to the subject matter of this Statement of Warranty, IBM’s liability, will be limited to
the total amount you paid for the Machine that is the subject of the claim.

Applicability of suppliers and resellers (unchanged).

The following replaces the third paragraph of this Section: Unless otherwise

provided by mandatory law, IBM and your reseller are not liable for any of the
following: (items 1 and 2 unchanged) 3) indirect damages, even if IBM or your
reseller is informed of their possibility.

SOUTH AFRICA, NAMIBIA, BOTSWANA, LESOTHO AND SWAZILAND

Limitation of Liability: The following is added to this Section: IBM’s entire liability

to you for actual damages arising in all situations involving nonperformance by IBM
in respect of the subject matter of this Statement of Warranty will be limited to the
charge paid by you for the individual Machine that is the subject of your claim from
IBM.

UNITED KINGDOM

Limitation of Liability: The following replaces items 1 and 2 of the first paragraph

of this Section:

1. death or personal injury or physical damage to your real property solely caused
by IBM’s negligence;

2. the amount of any other actual direct damages or loss, up to 125 percent of the
charges (if recurring, the 12 months’ charges apply) for the Machine that is the
subject of the claim or which otherwise gives rise to the claim;

The following item is added to this paragraph: 3. breach of IBM’s obligations implied
by Section 12 of the Sale of Goods Act 1979 or Section 2 of the Supply of Goods
and Services Act 1982.

Applicability of suppliers and resellers (unchanged).

The following is added to the end of this Section: IBM’s entire liability and your sole

remedy, whether in contract or in tort, in respect of any default shall be limited to
damages.

Appendix B. Warranty information 33

34 xSeries 305 Type 8673: User’s Guide

Appendix C. Notices

This publication was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in
other countries. Consult your local IBM representative for information on the
products and services currently available in your area. Any reference to an IBM
product, program, or service is not intended to state or imply that only that IBM
product, program, or service may be used. Any functionally equivalent product,
program, or service that does not infringe any IBM intellectual property right may be
used instead. However, it is the user’s responsibility to evaluate and verify the
operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you any
license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or
implied warranties in certain transactions, therefore, this statement may not apply to
you.

Edition notice

This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. IBM may make improvements and/or
changes in the product(s) and/or the program(s) described in this publication at any
time without notice.

Any references in this publication to non-IBM Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those
Web sites. The materials at those Web sites are not part of the materials for this
IBM product, and use of those Web sites is at your own risk.

IBM may use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you.

© COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 2002.
All rights reserved.

Note to U.S. Government Users — Documentation related to restricted rights —
Use, duplication or disclosure is subject to restrictions set forth in GSA ADP
Schedule Contract with IBM Corp.

© Copyright IBM Corp. 2002 35

Trademarks

The following terms are trademarks of International Business Machines Corporation
in the United States, other countries, or both:

Active Memory PS/2
Active PCI ServeRAID
Active PCI-X ServerGuide
Alert on LAN ServerProven
C2T Interconnect TechConnect
Chipkill Tivoli
EtherJet Tivoli Enterprise
e-business logo Update Connector
FlashCopy Wake on LAN
IBM XA-32
IntelliStation XA-64
Light Path Diagnostics X-Architecture
NetBAY XceL4
Netfinity XpandOnDemand
NetView xSeries
OS/2 WARP
Predictive Failure Analysis

Important notes

Lotus, Lotus Notes, SmartSuite, and Domino are trademarks of Lotus Development
Corporation and/or IBM Corporation in the United States, other countries, or both.

Intel, Celeron, LANDesk, MMX, NetBurst, Pentium, Pentium II Xeon, Pentium III
Xeon, and Xeon are trademarks of Intel Corporation in the United States, other
countries, or both.

Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in
the United States, other countries, or both.

UNIX is a registered trademark of The Open Group in the United States and other
countries.

Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States, other countries, or both.

Linux is a registered trademark of Linus Torvalds.

Other company, product, or service names may be trademarks or service marks of
others.

Processor speeds indicate the internal clock speed of the microprocessor; other
factors also affect application performance.

CD-ROM drive speeds list the variable read rate. Actual speeds vary and are often
less than the maximum possible.

36 xSeries 305 Type 8673: User’s Guide

When referring to processor storage, real and virtual storage, or channel volume,
KB stands for approximately 1000 bytes, MB stands for approximately 1 000 000
bytes, and GB stands for approximately 1 000 000 000 bytes.

When referring to hard disk drive capacity or communications volume, MB stands
for 1 000 000 bytes, and GB stands for 1 000 000 000 bytes. Total user-accessible
capacity may vary depending on operating environments.

Maximum internal hard disk drive capacities assume the replacement of any
standard hard disk drives and population of all hard disk drive bays with the largest
currently supported drives available from IBM.

Maximum memory may require replacement of the standard memory with an
optional memory module.

IBM makes no representation or warranties regarding non-IBM products and
services that are ServerProven
of merchantability and fitness for a particular purpose. These products are offered
and warranted solely by third parties.

IBM makes no representations or warranties with respect to non-IBM products.
Support (if any) for the non-IBM products is provided by the third party, not IBM.

Some software may differ from its retail version (if available), and may not include
user manuals or all program functionality.

®

, including but not limited to the implied warranties

Electronic emission notices

Federal Communications Commission (FCC) statement

Note: This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the
interference at his own expense.

Properly shielded and grounded cables and connectors must be used in order to
meet FCC emission limits. Properly shielded and grounded cables and connectors
must be used in order to meet FCC emission limits.IBM is not responsible for any
radio or television interference causedby using other than recommended cables and
connectors or by using other than recommended cables and connectors or by
unauthorized changes or modifications to this equipment. Unauthorized changes or
modifications could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

Appendix C. Notices 37

Industry Canada Class A emission compliance statement

This Class A digital apparatus complies with Canadian ICES-003.

Avis de conformité à la réglementation d’Industrie Canada

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.

Australia and New Zealand Class A statement

Attention: This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take adequate
measures.

United Kingdom telecommunications safety requirement

Notice to Customers

This apparatus is approved under approval number NS/G/1234/J/100003 for indirect
connection to public telecommunication systems in the United Kingdom.

European Union EMC Directive conformance statement

This product is in conformity with the protection requirements of EU Council
Directive 89/336/EEC on the approximation of the laws of the Member States
relating to electromagnetic compatibility. IBM cannot accept responsibility for any
failure to satisfy the protection requirements resulting from a nonrecommended
modification of the product, including the fitting of non-IBM option cards.

This product has been tested and found to comply with the limits for Class A
Information Technology Equipment according to CISPR 22/European Standard EN

55022. The limits for Class A equipment were derived for commercial and industrial
environments to provide reasonable protection against interference with licensed
communication equipment.

Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.

Taiwanese Class A warning statement

38 xSeries 305 Type 8673: User’s Guide

Japanese Voluntary Control Council for Interference (VCCI) statement

Power cords

For your safety, IBM provides a power cord with a grounded attachment plug to use
with this IBM product. To avoid electrical shock, always use the power cord and
plug with a properly grounded outlet.

IBM power cords used in the United States and Canada are listed by Underwriter’s
Laboratories (UL) and certified by the Canadian Standards Association (CSA).

For units intended to be operated at 115 volts: Use a UL-listed and CSA-certified
cord set consisting of a minimum 18 AWG, Type SVT or SJT, three-conductor cord,
a maximum of 15 feet in length and a parallel blade, grounding-type attachment
plug rated 15 amperes, 125 volts.

For units intended to be operated at 230 volts (U.S. use): Use a UL-listed and
CSA-certified cord set consisting of a minimum 18 AWG, Type SVT or SJT,
three-conductor cord, a maximum of 15 feet in length and a tandem blade,
grounding-type attachment plug rated 15 amperes, 250 volts.

For units intended to be operated at 230 volts (outside the U.S.): Use a cord set
with a grounding-type attachment plug. The cord set should have the appropriate
safety approvals for the country in which the equipment will be installed.

IBM power cords for a specific country or region are usually available only in that
country or region.

IBM power cord part
number

13F9940 Argentina, Australia, China (PRC), New Zealand, Papua New

13F9979 Afghanistan, Algeria, Andorra, Angola, Austria, Belgium, Benin,

13F9997 Denmark

14F0015 Bangladesh, Burma, Pakistan, South Africa, Sri Lanka

Used in these countries and regions

Guinea, Paraguay, Uruguay, Western Samoa

Bulgaria, Burkina Faso, Burundi, Cameroon, Central African Rep.,
Chad, China (Macau S.A.R.), Czech Republic, Egypt, Finland,
France, French Guiana, Germany, Greece, Guinea, Hungary,
Iceland, Indonesia, Iran, Ivory Coast, Jordan, Lebanon,
Luxembourg, Malagasy, Mali, Martinique, Mauritania, Mauritius,
Monaco, Morocco, Mozambique, Netherlands, New Caledonia,
Niger, Norway, Poland, Portugal, Romania, Senegal, Slovakia,
Spain, Sudan, Sweden, Syria, Togo, Tunisia, Turkey, former
USSR, Vietnam, former Yugoslavia, Zaire, Zimbabwe

Appendix C. Notices 39

IBM power cord part
number

14F0033 Antigua, Bahrain, Brunei, Channel Islands, China (Hong Kong

14F0051 Liechtenstein, Switzerland

14F0069 Chile, Ethiopia, Italy, Libya, Somalia

14F0087 Israel

1838574 Thailand

6952301 Bahamas, Barbados, Bermuda, Bolivia, Brazil, Canada, Cayman

Used in these countries and regions

S.A.R.), Cyprus, Dubai, Fiji, Ghana, India, Iraq, Ireland, Kenya,
Kuwait, Malawi, Malaysia, Malta, Nepal, Nigeria, Polynesia, Qatar,
Sierra Leone, Singapore, Tanzania, Uganda, United Kingdom,
Yemen, Zambia

Islands, Colombia, Costa Rica, Dominican Republic, Ecuador, El
Salvador, Guatemala, Guyana, Haiti, Honduras, Jamaica, Japan,
Korea (South), Liberia, Mexico, Netherlands Antilles, Nicaragua,
Panama, Peru, Philippines, Saudi Arabia, Suriname, Taiwan,
Trinidad (West Indies), United States of America, Venezuela

40 xSeries 305 Type 8673: User’s Guide

Index

A

advanced setup 13
attention notices 2

B

bays 3

C

cache control 13
caution statements 2
CD-eject button 7
CD-ROM

drive specification 3
CD-ROM drive activity LED 7
chipset feature 13
Class A electronic emission notice 37
configuration

Ethernet 20

with ServerGuide 16
connectors 8
core chipset control 13

D

danger statements 2
data rate, Ethernet 20
DIMMs

supported 3
diskette drive

specifications 3
diskette drive activity LED 7
diskette-eject button 7
drives 3

E

electrical input 3
electronic emission Class A notice 37
environment 3
Ethernet

configuring 20

high performance modes 20

integrated on system board 20

modes 20

teaming 20
Ethernet controller, configuring 20
expansion bays 3
expansion slots 3

F

Fast Ethernet 20
FCC Class A notice 37
features 3, 4

features (continued)

RAS 5
ServerGuide 15

H

hard disk drive

activity LED 7
heat output 3
humidity 3

I

important notices 2
integrated functions 3

L

LEDs 7, 8

M

memory 3
microprocessor 3

cache 13
modes, Ethernet 20

N

noise emissions 3
NOS installation

with ServerGuide 17

without ServerGuide 18
notes 2
notes, important 36
notices

electronic emission 37

FCC, Class A 37
notices and statements 2

P

power cords 39
power requirement 3
power supply 3
power-control button 7
power-on LED 7

R

RAS features 5
related publications 1
reset button 7
ROM shadowing 13

© Copyright IBM Corp. 2002 41

S

ServerGuide

features 15
NOS installation 17
setting up multiple servers 18
using 15

setting up

multiple servers 18

setup

advanced 13

with ServerGuide 16
shutting down the server 9
size 3
slots 3
software coupon

ServerGuide 15
specifications 3
starting the server 9
statements and notices 2
stopping the server 9
system management

capabilities 4

T

temperature 3
trademarks 36
turning off the server 9
turning on the server 9

U

United States electronic emission Class A notice 37
United States FCC Class A notice 37

V

video controller 3

W

Web site

ServerGuide 15
weight 3

42 xSeries 305 Type 8673: User’s Guide



Part Number: 33P2607

Printed in U.S.A.

(1P) P/N: 33P2607
