IBM 7947E5U, System x3650 M2 Product Manual

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

Product Guide

December 2009

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options

x3650 M2 Images

x3650 M2 Specifications

The Bottom Line

Server Comparison

For More Information

Legal Information

IBM System x3650 M2

Flagship 2U server packed with innovation

Suggested Uses: All sectors requiring highly available, energy-efficient, rack-optimized solution for physical and virtual intensive commercial environments like eBusiness/eCommerce, collaboration, virtualization, database, and enterprise resource planning applications.

Your challenge is to do more with less—serve more Web pages, handle more secure connections, support more e-mail users. You need to reduce the costs of doing business and

improve the service you deliver to your customers while lowering your overall risk. The dual- socket IBM® System x3650 M2 can reduce your costs with its new energy smart design. It can

improve service with reduced operational complexity and increased management functionality. It

will lower your IT risk with the resiliency that comes from no single point of failure. And like all IBM servers, the x3650 M2 offers you the trust that comes from the IBM global reach, service and

support.

The x3650 M2 is not simply an upgrade to a previous server. It is one of our new generation of XArchitecture servers. It is a game-changing, completely redesigned rack server using significantly

less power with unified systems management tools, leadership reliability, availability,

serviceability features and broad system flexibility, housed in a compact 2U mechanical package.

The x3650 M2 features Intel® Xeon® 5500 Series 4-core and 2-core processors, and either 8MB

or 4MB of shared cache, to help provide you with the computing power you need to match your

business needs and growth. This new line of Intel processors delivers unprecedented intelligent performance with features like adaptive performance for applications and environments, turbo

boost and hyper-threading technology, and integrated power gates and automated power management.

The x3650M2 uses up to 16 DIMMs with 128GB of registered 1333MHz DDR3 memory with

Chipkill™ ECC (Error Checking and Correcting) protection—for high performance and reliability.

For even higher levels of availability, the x3650M2 also offers online memory mirroring. Up to 4 integrated high-speed Gigabit Ethernet controllers with TOE (TCP Offload Engine) and Jumbo Frame support are available, as are four high-performance adapter slots (PCIe x8). The x3650M2 offers an optional embedded hypervisor to manage your virtual workloads.

The System x3650 M2 offers a choice of up to twelve high-performance hot-swap hard disk drives with an internal storage capacity of 6.0TB (twelve 2.5-inch hot-swap Serial-Attached SCSI (SAS) or Serial-Attached ATA (SATA) HDDs). Twelve optional solid-state drives (SSDs) are also available to keep power low, improve resiliency, and offer up to 600GB of storage. Alternatively, up to eight HDDs or SSDs and one internal tape drive can be used. The server supports a choice of four IBM ServeRAID® storage controllers which provide broad levels of hardware-based RAID solutions. The ultra-dense 2U form factor allows businesses to increase their computing power and spread their workload without outgrowing their current data center. Up to 21 of these 2U servers can be installed in a single 42U rack, for a total of up to 42 processors and 168 processor cores, offering tremendous deployment flexibility. Optional Advanced Connectivity Technology (ACT) interconnect cabling reduces cable clutter and cost and minimizes installation time when interconnecting many rack-mounted servers.

Standard in the x3650 M2 is the Integrated Management Module (IMM) that enables the user to manage and control the server easily—both locally and remotely. In conjunction with the IMM, the x3650 M2 comes with a Bosch BMP085 altitude sensor (altimeter) that governs fan rotation based on altitude, to help lower your energy consumption. The IMM offers a high level of manageability that is designed to keep costs down and the system up—even when network usage increases. IBM’s innovative pop-out/drop-down light path diagnostics panel enables quick servicing of the system if a problem develops. These advanced features help maximize network availability by increasing uptime, as do hot-swap solid-state drives; hot-

swap/redundant SAS or SATA HDDs, redundant ultra-efficient power supplies and fan modules; Active Memory™; integrated RAID; temperature-controlled fans with Calibrated

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

Flexibility

expandable, rack-dense, 2U dual-socket server

Vectored Cooling™; IPMI 2.0 support, including highly secure remote power control and Serial over LAN; as well as text-console redirect over LAN.

Another improvement with the new generation of X-Architecture is the replacement of old BIOS with a new generation United Extensible Firmware Interface (UEFI). UEFI provides a more intuitive user interface and understandable event logs and better management.

With the inclusion of unique IBM service and support features such as the IMM, light path diagnostics, IBM Systems Director 6.1, IBM Systems Director Active Energy Manager™, IBM

ServerGuide™ and support for the optional Virtual Media Key for remote presence capability, the

x3650 M2 is designed for superior uptime.

If you need highly manageable, dual-socket/multi-core computing power in a rack-dense package, the x3650 M2 is the ideal system.

Selling Features

Price/Performance

The x3650 M2 offers numerous features to boost performance and reduce costs:

• Up to two 4-core Xeon 5500 Series processors and 8MB or 4MB of cache per processor, offer superior performance capable of tackling the toughest jobs. 64-bit extensions provide the flexibility to run 32-bit and 64-bit applications concurrently. Xeon 5500 series processors offer up to 225% better performance than the previous-generation 5400 series processors and up to 900% better performance than the single-core processors of a few years ago that you may still be using.

• Low-voltage processors draw less energy and produce less waste heat than high-voltage processors, thus helping to reduce data center energy costs. Some 4-core Xeon 5500 Series processors use only 60W. This is less than half the wattage consumed by older 130W processors.

• Sixteen DIMMs of ultra-fast registered 1333MHz (or 1066MHz or 800MHz) DDR3 ECC memory with Chipkill1 protection (optional) provides speed, high availability, and a memory capacity of up 128GB.

• Optional 50GB solid-state drives (SSD) use only 2W of power per drive, vs. 9-10W for 2.5- inch HDDs. This is as much as 80% less power than a 2.5 inch HDD would use (with a corresponding reduction in heat output).

• The x3650 M2 is a leader in server resiliency. With hot-swap power supplies, fan modules, and storage, the x3650 M2 has no single point of failure.

• An altimeter works in conjunction with IMM to govern fan rotation based on the readings which it delivers to save money under normal conditions because the fans do not have to spin at high speed.

• Four high-speed x8 (“by 8”) PCIe Gen 2 adapter slots offer investment protection by supporting high-performance adapters, such as 10Gb Ethernet, Fibre Channel and InfiniBand cards, none of which will run in older 33MHz and 66MHz conventional PCI slots.

• Integrated ServeRAID-M5015 (on selected models) provides RAID-0/1/10/5/50 (optional 6/60 with Self-Encrypting Disk (SED)) without consuming a valuable adapter slot. It also offers higher performance 512MB battery-backed cache.

• Up to twelve 2.5-inch hot-swap SAS hard disk drives offer high-performance with high availability. The SAS controller provides full-duplex (bidirectional 300MBps) data transfers for SAS drives.

• The integrated dual Gigabit Ethernet controllers with IPMI 2.0 provide high-speed network communications. Jumbo Frames offer higher efficiency transfers for large data packets. Two more NICS can be supported on the planar with an additional Dual Port Gb Ethernet daughtercard. The TCP Offload Engine (TOE) feature offers higher performance for TCP/IP traffic, with less overhead on the system processor.

• A high degree of device integration—including hot swap SAS/SATA HDDs or SSD drives, multiple hardware based ServeRAID options, Gigabit Ethernet ports, systems management and video controllers—lowers costs and frees up valuable adapter slots.

The x3650 M2 has the ability to grow with your application requirements, thanks to

• A choice of four-core or two-core processors with 1.86 to 2.93GHz clock rates, up to 6.4

• Up to 128GB of high-speed registered DDR3 system memory.

• Four available high-performance PCIe x8 adapter slots in all models. Optionally, riser cards

All models require Chipkill-enabled DIMMs (provided standard) for Chipkill protection.

Please see the Legal Information section for important notices and information.

gigatransfers per second, and 60W to 95W maximum power draw.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

supporting two PCI-X/133 adapters can be exchanged for the PCIe slots.

• Installing the ServeRAID-M5015 option upgrades the basic ServeRAID controller with 512MB of cache (optional battery) to enable higher-performance hardware RAID support, and allows the x3650 M2 to offer five RAID levels standard: RAID-0/1/10/5/50 (optionally 6/60 with

SED). The optional ServeRAID MR10M controller supports up to four IBM System Storage™ EXP3000 expansion units containing up to 48 SAS HDDs and 14.4TB of external storage.

• The five USB 2.0 ports (two front, two rear, one internal) are up to 40X faster2 than older USB

1.1 ports. This provides speedy access to external HDDs (non-arrayed), optical drives, tape

drives, and other USB devices. Two ports are on the front of the unit and two are on the back. The internal port supports a flash drive with embedded hypervisor or an internal tape or IBM RDX removable disk storage drive.

• A choice of up to twelve 2.5-inch hot-swap SAS/SATA HDDs or solid-state drives, or eight

2.5-inch drives and one internal tape drive, offer a variety of storage options. The SAS and SATA models provide a maximum of 6.0TB of internal hot-swap storage.

• Alternatively, iSCSI or Fibre Channel-attached storage can be attached using IBM System Storage™ servers.

Manageability

Powerful systems management features simplify local and remote management of the x3650 M2:

• The x3650 M2 includes an Integrated Management Module (IMM) to monitor server availability, perform Predictive Failure Analysis, etc., and trigger IBM Systems Director alerts. The IMM performs the functions of both the Baseboard Management Controller (BMC) of earlier systems and the Remote Supervisor Adapter II and is upgradeable to remote presence/cKVM.

• An optional Virtual Media Key provides additional systems management capabilities, including Web-based out-of-band control; virtual floppy and optical drive support; Windows “blue screen” error capture; LDAP and SSL support; and remote redirection of PCI video, text, keyboard and mouse (cKVM). And it does all this without consuming a valuable adapter slot.

• Integrated industry-standard Unified Extensible Firmware Interface (UEFI) next-generation BIOS. New capabilities include:

– Human readable event logs — no more beep codes – Complete out-of-band coverage by the Advance Settings Utility to simplify remote setup – A complete setup solution, allowing adapter configuration functions to be moved into UEFI – Consistent firmware management across an entire product line

• Integrated Trusted Platform Module (TPM) 1.2 support.

• Integrated IPMI 2.0 support alerts IBM Systems Director to anomalous environmental factors,

such as voltage and thermal conditions. It also supports highly secure remote power control using data encryption.

• Text Console Redirection support allows the administrator to remotely view x3650 M2 text messages over Serial or LAN.

• The completely redesigned IBM Systems Director is included for proactive systems management. IBM Systems Director comes with a portfolio of tools, including IBM Systems Director Active Energy Manager, IBM Service and Support Manager, and others. In addition, IBM Systems Director offers extended systems management tools for additional server management and increased availability. When a problem is encountered, IBM Systems Director can issue administrator alerts via e-mail, pager, and other methods.

• IBM Systems Director Active Energy Manager, an IBM-exclusive, is designed to take advantage of new system power management features, by providing actual realtime energy monitoring and reporting features.

Availability and Serviceability

The System x3650 M2 provides many features to simplify serviceability and increase system uptime:

• x3650 M2 servers offer Chipkill ECC memory protection3 (when using x4 DIMMs). Chipkill

• The x3650 M2 offers memory mirroring for redundancy in the event of a non-correctable

Data transfer rates may be less than the maximum possible.

Chipkill protection is supported with x4 DDR-3 DIMMs, but not x8 DIMMs.

Please see the Legal Information section for important notices and information.

memory is up to 16X better than standard ECC memory at correcting memory errors. This can help reduce downtime caused by memory errors.

memory failure

Leadership enterprise server with significantly lower cost of ownership in a highly available and

High

Performance Xeon

5500 Series

Processors

expandable, rack-dense, 2U dual-socket server

Key Features

• Toolless cover removal provides easy access to upgrades and serviceable parts. Similarly, the Virtual Media Key and the ServeRAID controller can be installed and replaced without tools. This means less time (and therefore less money) spent servicing the x3650 M2. Additionally, hot-swap/redundant HDDs, fan modules and power supplies, as well as online mirrored memory, mean greater system uptime while these components are being serviced.

• New toolless slides ship with the server, together with a Cable Management Arm (CMA), that allows the rack server to easily slide into place

• IBM Thermal Diagnostics allows the administrator to evaluate thermal data on the server without taking the hardware offline. This can provide greater server uptime.

• The drop-down light path diagnostics panel and individual light path LEDs quickly lead the technician to failed (or failing) components. This simplifies servicing, speeds up problem resolution and helps improve network availability.

• Integrated 3Gbps or 6 Gbps RAID controller to enhance system availability and data protection without using a PCIe slot.

• IPMI 2.0 supports highly secure remote system power control using data encryption. This allows an administrator to restart a server without having to visit it in person, saving travel time and getting the server back up and running quickly and securely. It also adds new features to those provided by IPMI 1.5, including VLAN support, Serial over LAN, enhanced authentication and encryption algorithms (RMCP+, SHA-1, AES) and a firmware firewall.

• Altitude- and temperature-controlled fans adjust to compensate for changing thermal characteristics. At the lower speeds they draw less power and suffer less wear. Equally important in a crowded data center, temperature-controlled fans produce less ambient noise in the data center than if they were constantly running at full speed.

• The three-year (parts and labor) limited onsite warranty4 helps afford you peace of mind and greater investment protection than a one-year warranty does.

The x3650 M2 supports up to two high-performance Intel Xeon 5500 Series processors, allowing you to upgrade to a second processor as your business needs require. The x3650 M2 offers a choice of processor clock rates, memory access speeds and energy draw, including:

• 95W four-core Xeon models X5550, X5560, or X5570 running at 2.66, 2.8, or 293GHz, respectively, with impressive performance/watt (23.75W per core; 6.4Gtbps QPI speed), 8MB of L3 processor cache, 1333MHz memory access, and Intel Turbo Boost technology

• 60W four-core Xeon low-voltage models or L5530* running at 2.26GHz or 2.4GHz, respectively, with low power draw and impressive performance/watt (only 15W per core;

5.86Gtps QPI speed), and 8MB of shared L3 cache, 1066MHz memory access, and Intel Turbo Boost technology

• 80W four-core Xeon models E5520, E5530, or E5540 running at 2.26, 2.4, or 2.53GHz, respectively, with reduced power draw and impressive performance/watt (only 20W per core;

5.86Gtps QPI speed), 8MB of L3 processor cache, 1066MHz memory access, and Intel Turbo Boost technology

• 60W four-core Xeon low-voltage model L5506 running at 2.13GHz, with low power draw and impressive performance/watt (only 15W per core; 4.8Gtps QPI speed), 4MB of L3 processor cache, and 800MHz memory access

• 80W four-core Xeon models E5504 or E5506 running at 2.0 or 2.13GHz, respectively, with

reduced power draw and impressive performance/watt (only 20W per core; 4.8Gtps QPI speed), 4MB of L3 processor cache, and 800MHz memory access

• 80W two-core Xeon model E5502 running at 1.86GHz, with reduced power draw (40W per core; 4.8Gtps QPI speed), 4MB of L3 processor cache and 800MHz memory access

With the Xeon 5500 Series processors, Intel has diverged from its traditional Symmetric Multiprocessing (SMP) architecture to a Non-Uniform Memory Access (NUMA) architecture. The Xeon 5500 processors are connected through a serial coherency link called QuickPath Interconnect (QPI). QPI is capable of 6.4, 5.6 or 4.8 GT/s (gigatransfers per second), depending on the processor model.

Two-core Xeon processors contain two complete processor cores; four-core processors, similarly, contain four cores. Some processors contain one unified cache shared by all cores,

For terms and conditions or copies of the IBM Statement of Limited Warranty, call 800-772-2227 in the U.S. In Canada call 800-

426-2255. Telephone support may be subject to additional charges. For warranties including onsite labor, a technician is sent after IBM attempts to resolve the problem remotely. International warranty service is available in any country in which this product is sold.

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

DDR

3 Registered Memory with Chipkill ECC

Protection

Ch1 Ch0 Ch2 Ch1 Ch0 Ch2

expandable, rack-dense, 2U dual-socket server

cache is dynamically allocated between the cores as needed. The multiple cores appear to software as multiple physical processors. The two-core processors offer considerably higher performance than a same-speed Xeon processor with a single core. Likewise, four-core processors offer considerably higher performance than a same-speed Xeon processor with dual cores.

Turbo Boost Technology dynamically turns off unused processor cores and increases the clock speed of the cores in use, by up to two model frequencies. For example, with three cores active, a 2.26GHz processor can run the cores at 2.4GHz. With only one or two cores active, the same processor can run those cores at 2.53GHz. Similarly, a 2.93GHz processor can run at 3.06GHz or even 3.33GHz. When the cores are needed again, they are dynamically turned back on and the processor frequency is adjusted accordingly.

Intel Extended Memory 64 Technology (EM64T) 64-bit extensions allow the Xeon processor to use large memory addressing when running with a 64-bit operating system. This in turn lets individual software processes directly access more than 4GB of RAM, which was the limit of 32bit addressing. This can result in much higher performance for certain kinds of programs, such as database management and CAD. Additional registers and instructions (SSE3) can further boost performance for applications written to use them. Contact your software provider to determine their software support for EM64T.

Intelligent Power Capability powers individual processor elements on and off as needed, to reduce power draw.

Execute Disable Bit functionality can help prevent certain classes of malicious buffer overflow attacks when combined with a supporting operating system.

The x3650 M2 ships with registered double data rate III (DDR-3) memory and provides Active Memory features, including advanced Chipkill memory protection (optionally), for up to 16X better error correction than standard ECC memory. In addition to offering better performance than DDR-2 or fully-buffered memory, DDR-3 memory also uses less energy. DDR-2 memory already offered up to 37% lower energy use than fully buffered memory. Now, a generation later, DDR-3 memory is even more efficient, using 22% less energy than DDR-2 memory.

The x3650 M2 supports up to 128GB of memory in sixteen DIMM slots. Redesign in the architecture of the Xeon 5500 series processors bring radical changes in the way memory works in these servers. For example, the Xeon 5500 series processor integrates the memory controller inside the processor, resulting in two memory controllers in a 2-socket system. Each memory controller has three memory channels. Depending on the type of memory, population of memory, and processor model, the memory may be clocked at 1333MHz, 1066MHz or 800MHz.

Xeon 5500

Processor 0

Memory Controller

QPI

Memory Controller

Xeon 5500

Processor 1

D10

D11

D12

D13

D14

D15

D16

1-16: DIMM population sequence; D1-D16: DIMM slot assignments

Note: If only one processor is installed, only the first eight DIMM slots can be used. Adding a second processor not only doubles the amount of memory available for use, but also doubles the number of memory controllers, thus doubling the system memory bandwidth. If you add a second processor, but no additional memory for the second processor, the second processor has to access the memory from the first processor “remotely,” resulting in longer latencies and lower performance. The latency to access remote memory is almost 75% higher than local memory access. So, the goal should be to always populate both processors with memory.

The X55xx models support up to 1333MHz memory clock speed, while the E55xx-and-up and L55xx-and-up models support up to 1066MHz clock speed, and the E550x models support

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

800MHz clock speed.. Using 1333MHz memory (where supported) versus 1066MHz offers up to 9% better performance, while 1066MHz memory produces up to 28% better performance than 800MHz memory.

Xeon 5550 series processors access memory with almost 50% lower latency than the previous generation 5400 series processors. That can result in faster processing of latency-sensitive workloads.

This new processor design comes with some trade-offs in memory capacity, performance, and cost: For example, greater memory capacity comes with lower memory speed. Alternatively, it is possible to achieve the same memory capacity at lower cost but at a lower memory speed.

Regardless of memory speed, the Xeon 5500 platform represents a significant improvement in memory bandwidth over the previous Xeon 5400 platform. At 1333MHz, the improvement is almost 500% over the previous generation. This huge improvement is mainly due to the dual integrated memory controllers and faster DDR-3 1333MHz memory. Throughput at 800MHz is 25 gigabytes per second (GBps); at 1066MHz it’s 32GBps; and at 1333MHz it’s 35GBps. This improvement translates into improved application performance and scalability.

Memory interleaving refers to how physical memory is interleaved across the physical DIMMs. A balanced system provides the best interleaving. A Xeon 5500 processor-based system is balanced when all memory channels on a socket have the same amount of memory.

A memory rank is simply a segment of memory that is addressed by a specific address bit. DIMMs typically have 1, 2 or 4 memory ranks, as indicated by their size designation.

• A typical memory DIMM description is 2GB 4Rx8 DIMM

• The 4R designator is the rank count for this particular DIMM (R for rank = 4)

• The x8 designator is the data width of the rank

It is important to ensure that DIMMs with appropriate number of ranks are populated in each channel for optimal performance. Whenever possible, it is recommended to use dual-rank DIMMs in the system. Dual-rank DIMMs offer better interleaving and hence better performance than single-rank DIMMs. For instance, a system populated with six 2GB dual-rank DIMMs outperforms a system populated with six 2GB single-rank DIMMs by 7% for SPECjbb2005. Dualrank DIMMs are also better than quad-rank DIMMs because quad-rank DIMMs will cause the memory speed to be down-clocked.

Another important guideline is to populate equivalent ranks per channel. For instance, mixing one single-rank DIMM and one dual-rank DIMM in a channel should be avoided.

Note: It is important to ensure that all three memory channels in each processor are populated. The relative memory bandwidth decreases as the number of channels populated decreases. This is because the bandwidth of all the memory channels is utilized to support the capability of the processor. So, as the channels are decreased, the burden to support the requisite bandwidth is increased on the remaining channels, causing them to become a bottleneck.

For increased availability, the x3650 M2 offers an additional (but mutually exclusive) level of IBM Active Memory protection: online memory mirroring..

Memory mirroring works much like disk mirroring. The total memory is divided into two channels. Data is written concurrently to both channels. If a DIMM fails in one of the DIMMs in the primary channel, it is instantly disabled and the mirrored (backup) memory in the other channel becomes active (primary) until the failing DIMM is replaced. One-half of total memory is available for use with mirroring enabled. (Note: Due to the double writes to memory, performance is affected.)

Mirroring is handled at the hardware level; no operating system support is required.

DDR-3 memory is available in 1GB, 2GB, 4GB and 8GB DIMMs. DIMMs are installed individually (not in pairs).

Drive Bays

The x3650 M2 contains twelve drive bays in all. Hot-swap drives may be inserted or removed through the front of the server without powering off the system. Simple-swap solid-state drives can be inserted or removed through the front of the server as well; however, the system power must first be turned off.

For additional storage, a direct-attach, NAS or SAN external expansion option can be added, using an optional controller.

A 24X/24X/24X/8X5 speed (ultraslim, 0.5”) CD-RW/DVD-ROM Combo drive or CD-RW/DVD-RW Multi-burner drive is connected to a dedicated SATA port. No diskette drive is supplied with any model; an external USB floppy drive may be used, if needed.

Variable read rate. Actual playback speed varies and is often less than the maximum possible.

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

Disk Controllers

All x3650 M2 models include a ServeRAID-BR10i, ServeRAID-M5014 or ServerRAID-M5015 SAS/SATA controller (model-dependent) to enhance system availability and data protection without using a PCI slot

The 6Gbps ServeRAID-M5015 SAS/SATA controller offers enhanced performance with 512MB of cache memory (optional battery), supports RAID-0/1/10/5/50. (Optional RAID-6/60 with SED.)

The 6Gbps ServeRAID-M5014 SAS/SATA controller offers enhanced performance with 256MB of cache memory (optional battery), supports RAID-0/1/10/5/50. (Optional RAID-6/60 with SED.)

The ServeRAID-BR10i controller offers hardware RAID-0/1/1E support. The controller provides data transfer speeds of up to 3Gbps6.

For external storage, the ServeRAID-MR10M controller enables connection to up to four IBM System Storage EXP3000 SAS expansion units (48 HDDs total). It provides RAID-0/1/10/5/50 support and 256MB of onboard cache.

Large Storage Capacity

The x3650 M2 offers flexibility with up to twelve 2.5” HDD bays, supporting high-performance drives that provide high density/high reliability and allow you to scale up as your business grows.

2.5-inch Hot-Swap SAS

• 7,200 RPMs — 500GB (3.0TB maximum capacity)

• 10,000 RPMs — 73.4, 146.8, 300, or 500GB (3.0TB maximum)

• 15,000 RPMs — 73.4 or 146.8GB (1.76TB maximum)

2.5-inch Hot-Swap SATA

• 7,200 RPMs — 160 or 500GB (6.0TB maximum)

• 10,000 RPMs — 300GB (3.6TB maximum)

2.5-inch Hot-Swap or Simple-Swap SSDs

• 50GB High IOPS (600GB maximum)

 High I/O Performance

– Offers up to 8X more IOPS than HDDs (67/33% read/write OLTP transaction base mix) – Optimized for heavy mix of read and write operations, such as transaction processing,

media streaming, surveillance, file copy, logging, backup/recovery, and business Intelligence

 Lower-Cost IOPS Performance

– Yields better $/IOPS: lower capacity (GB) required to achieve higher IOPS – Utilizes less energy and heat than conventional disk drive

 Superior Uptime

– 3X the availability of mechanical disk drives – No moving parts to fail – Enterprise wear-leveling to extend life even further

 Flexible Deployment with full OS Support

– Traditional HDD form factor offerings – Supports Linux, Windows and VMware

2-5-inch HDDs not only require less space than 3.5-inch drives, they weigh less, consume half the power, produce less noise, seek faster, and offer increased reliability.

The hot-swap SAS drives use the Converged Tray for interchangeability with other IBM System x® systems. If you need more storage space, terabyte capacities are possible with external IBM System Storage direct-attach, NAS and SAN offerings.

Data transfer rates depend on many factors and are often less than the maximum possible.

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

Ultra

Efficient Cooling

expandable, rack-dense, 2U dual-socket server

High-Performance Adapter Slots

The x3650 M2 provides four x8 (“by 8”) 8GBps PCIe (PCI Express) Gen 2 high performance I/O slots that the double performance vs. the x3650 for added long-term investment protection (2 PCI x16 Gen 2 slots optional via riser cards). Each is capable of supporting x1/x4/x8 adapters at full speed. One slot is full height, half length. The other is low profile.

• Four PCIe Gen 2 slots:

 Two x8-full-height, half-length (convertible to one PCI-X/133 MHz with riser option)  One x8 full height, half length  One x8 low profile (convertible to one PCI-X133 MHz with riser option)

• All new adapter development is on PCI Express

• Example: no 8GB fibre for PCI-X

• Good for digital media, 2D graphics environments

PCI Express is a high-performance, low-latency, next-generation serial I/O bus that is rapidly replacing the older parallel PCI and PCI-X buses. A x16 PCIe adapter offers approximately eight times the maximum throughput of a 133MHz PCI-X adapter7. (A x1 adapter offers throughput similar to a 66MHz PCI-X slot.)

There is a built-in riser card in the x3650 M2 that provides a PCIe connector (physical x8 connector wired with x4 lanes) for an internal ServeRAID card.

Dual-Port Gigabit Ethernet Controller

The x3650 M2 includes one dual-port integrated Broadcom 5709C Gigabit Ethernet controller standard, for up to 10X higher maximum throughput than a 10/100 Ethernet controller, as well as support for Jumbo Frames and TOE (TCP Offload Engine).

Jumbo Frames—those larger than the standard frame (packet) size of 1,500 bytes—can be more efficient, dramatically increasing network performance and reducing server CPU overhead. TOE helps improve overall system performance by offloading TCP/IP protocol processing from the system microprocessor to the onboard Ethernet TOE processor. There is no additional charge for this capability.

It also supports highly secure remote power management using IPMI 2.0, plus Wake on LAN® and PXE (Preboot Execution Environment) flash interface. Optional PCI adapters offering failover and load balancing between adapters are available for added throughput and increased system availability.

Integrated quad Gb Ethernet ports:

• Up to four (4) Gb Ethernet ports, ideal for virtualization and I/O-intensive workloads

• 2 ports standard, plus two additional ports via optional daughtercard

• Improves system performance by offloading protocol processing from CPU to a separate TOE

engine

• Primary performance improvement for data copying (CPU) where CPU utilization is 90-100%

• The embedded NIC/TOE supports software iSCSI using a Microsoft iSCSI initiator

• Using a software initiator enables offloading the processing of TCP frames with the TOE

engine in the adapter card, but the processing of iSCSI packets themselves is not hardwareoffloaded at the Broadcom NIC

• Broadcom hardware-offloaded iSCSI (using TOE engine) of the iSCSI frames

• iSCSI and RDMA are not supported on this server

Two Broadcom 5709 Gigabit Ethernet controllers (one on-board and one on an optional daughter card) provide four Gigabit ports supporting IEEE 802.3 for 1000Base-T, 100Base-TX, and 10Base-T applications (802.3, 802.3u, 802.3ab) through a RJ-45 connector to an Ethernet network over a CAT 5 twisted-pair cable. This controller supports PXE 2.0 remote boot, TOE, and jumbo frames (9KB). A license key is required to enable the iSCSI and RDMA features. TOE support on Windows is available today, but requires the Windows Scalable Network Pack (SNP) installed. Linux has no plan to support TOE at this time. Please refer to TOE_RDMA_iSCSI.doc for technology details. Internet Protocol version 6 (IPv6) is supported.

Strategically located fans, combined with efficient airflow paths, provide highly effective system cooling for the x3650 M2, known as Calibrated Vectored Cooling. The base server with one power supply includes three hot-swap fan modules, for redundant cooling. Each pack includes two back-to-back fans with counter-rotating blades for a total of 3 fan modules. In addition, each

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

power supply also contains a fan.

The system contains three cooling zones. Zone 1 (incorporating one fan pack) cools all 16 DIMM sockets, Zone 2 (one fan pack) cools the primary processor, and Zone 3 (one fan pack) cools the second processor.

The fans automatically adjust speeds in response to changing thermal requirements depending on the zone and internal temperatures. When the temperature inside the server increases, the fans speed up to maintain the proper ambient temperature. When the temperature returns to a normal operating level, the fans return to their default speed. In addition, the Bosch BMP085 altimeter works in conjunction with IMM to govern fan rotation. At high altitudes the air is thinner and doesn’t cool as well as at lower elevations. In most servers, the fans run fast all the time to allow for use at high elevations, wasting power. The altimeter allows the IBM fans to run at lower speeds at lower altitudes.

Why not simply run the fans at 100% capacity all the time? For several good reasons: to reduce the ambient noise, reduce the wear-and-tear on the fans and reduce the server power draw. The reduction in ambient noise and power draw may be relatively minor for a single server, but put dozens or hundreds in a data center and it can make a big difference!

In addition, the server uses hexagonal ventilation holes in the chassis. Hexagonal holes can be grouped more densely than round holes, providing greater airflow through the system cover.

This cooling scheme is important because newer, more powerful processors generate a significant amount of heat, and heat must be controlled for the system to function properly.

There are temperature sensors on the planar placed to sense DIMM exhaust temperature, SAS HDD exhaust temperature, and CPU2 exhaust temperature (through the altimeter).

Light Path Diagnostics

Light path diagnostics enables a technician to quickly identify and locate a failed or failing system component, such as a specific fan or memory DIMM. This enables quick replacement of the component, which helps increase server uptime and lower operating costs.

The front of the server has an LED indicator light to show possible component failures. If the front LED indicates an error condition, by pressing a button on the front of the server an LED panel will pop out and drop down for easy viewing without the need to open the server cover or remove the server from the rack. The light path diagnostics panel tells the servicer which component requires attention. In addition, many components have their own identifying LEDs. For example, each of the memory modules has an LED next to the socket, as do both processors, all adapter slots, all fans, all power supplies, the voltage regulator module and the service processor, allowing the servicer to easily identify exactly which component needs servicing. By following the “light path,” the component can be replaced quickly, and without guesswork. (Note: In the event of a failed DIMM, the system will restart and mark the DIMM as bad while offline, thus allowing the system to continue running, with reduced memory capacity, until serviced.)

Hot-Swap/Redundant Components

System availability is maximized through the extensive use of hot-swap and redundant components, including:

• Redundant memory protection (with Chipkill protection, and memory mirroring enabled)

• Hot-swap, redundant hard disk drives (with RAID protection)

• Hot-swap, redundant power supplies

• Hot-swap, redundant cooling fan modules

Other Features

• Five USB 2.0 ports — Provides flexibility to add high-speed external devices. The USB 2.0 specification supports up to 480Mbps transfer rates. (Note: Not all USB 2.0 devices are capable of achieving this rate.) Two ports are provided on the front of the server, two on the back, plus one USB connector reserved for an internal USB flash memory key containing an embedded hypervisor. For pre-boot and normal drive use, use the external ports.

• Embedded hypervisor (via USB connector on the motherboard) — Activated with an optional 2GB USB key for supporting VMWare ESXi for virtualization.

• Virtual Media Key — This optional full-function systems management adapter adds local and remote management functions without consuming a valuable adapter slot.

• Dual video ports — A Matrox G200eV SVGA video controller provides up to 1024x768 resolution, with a color depth of 32 bits at 85Hz refresh rate. To simplify local systems management, one video port is provided on the front of the unit and one on the back.

• Toolless slides — Allows quick rack installation and quicker upgrade and servicing of the server.

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

Extensive System Support Features

mouse) switch boxes and other components you need, as well as the proper

airflow

clearances,

Directly

expandable, rack-dense, 2U dual-socket server

• Toolless chassis — The cover can be opened without tools, and many components can be removed and replaced without tools, including the CD-RW/DVD combo drive, hot-swap drives, and PCIe adapters, as well as the integrated ServeRAID card, embedded hypervisor key, and Virtual Media Key. This can save a servicer significant time.

Rack Cable Management and KVM Console Switching

IBM Advanced Cabling Technology (ACT) is an optional feature that offers many advantages over standard KVM cabling across the entire System x and xSeries product line. So now you can interconnect all of your servers with one smart cabling architecture. ACT cabling eliminates the need for one-to-one direct connections between each server and a KVM switch by using a daisychain approach.

The snarl of cabling behind most racks is at best inconvenient to work around and at worst an expensive logistical nightmare, requiring the rewiring of servers, PDUs, KVM switches, and other equipment whenever a rack server is added or removed. Even worse, the veil of cables blocks rack airflow and can actually contribute to equipment failure due to overheating. ACT cabling is the solution for reducing behind-the-rack cabling by as much as 87%.

The illustration below shows a sample ACT configuration:

Via Daisy-Chain

• Max.16 servers per port

All CAT5, 5e, 6

cabling

Conventional cabling has bulky KVM cables exiting each server, which then connect to a KVM switch. The cables exiting a series of KVM switches must then be aggregated via additional KVM switches and PDUs, which only increases the number—and cost—of cables, KVM switches and PDUs. Instead, the daisy-chain approach of ACT cabling uses readily available, inexpensive CAT5 and 6 cabling to considerably reduce the number of cables, KVM switches, and PDUs needed, rather than increasing them. If a server is removed or added, no complicated rewiring is needed. One cable connects the first server in the rack to the next, and so on. Up to 16 servers form a chain; up to 8 chains can connect to one Local Console Manager (LCM); 16 LCMs can connect to one Global Console Manager (GCM). In this manner, up to 2,048 servers can be centrally managed. Equally importantly, with ACT—unlike some other offerings—everything is done externally via cabling; no special adapters are required.

The IBM services and technical support portfolio provides world-class, consistent, high-quality service and support. The x3650 M2 server offers a number of tools and services designed to make ownership a positive experience. From the start, IBM programs make it easier for you to plan for, configure and purchase System x or xSeries servers, get them running and keep them running long-term. These features include IBM Express Portfolio, IBM ServerProven®, IBM Standalone Solutions Configuration Tool, IBM System x and BladeCenter Power Configurator, IBM ServerGuide, IBM Systems Director Service and Support Manager, Product Customization Services and extensive technical support offerings.

The IBM ServerProven program provides the confidence that specific options and operating systems have been tested on the server and are officially supported to work together. It is updated frequently to ensure that the latest compatibility information is always at your fingertips.

The IBM Standalone Solutions Configuration Tool (SSCT) is a downloadable tool that simplifies the often complex chore of configuring a full rack of servers (including blade servers) and confirming that you have all the cables, power distribution units, KVM (keyboard, video and

Via Secondary

Switch

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

electrical circuits and other environmental conditions.

IBM System x and BladeCenter Power Configurator helps IT managers plan for data center power needs, by providing the following information for specific configurations of System x and BladeCenter systems: power input (watts), PDU sizing (amps), heat output (BTUs), airflow requirements through chassis (CFM), VA rating, leakage current (mA), and peak inrush current (amps).

IBM ServerGuide (installed from CD) simplifies the process of installing and configuring System x and xSeries servers. ServerGuide goes beyond mere hardware configuration by assisting with the automated installation of the Microsoft® Windows® Server 2000 and 2003 operating systems, device drivers and other system components, with minimal user intervention. (Drivers are also included for support of Novell NetWare, Red Hat Linux and SUSE LINUX.) This focus on deployment helps you reduce both you total cost of ownership and the complexity that administrators and technical personnel face.

IBM Systems Director Service and Support Manager (previously called IBM Electronic Service Agent™) is an innovative “call home” feature that allows System x and BladeCenter servers to automatically report hardware problems to IBM support, which can even dispatch onsite service8 if necessary to those customers entitled to onsite support under the terms of their warranty or an IBM Maintenance Agreement. Service and Support Manager resides on a server and provides electronic support and problem management capabilities through a highly secure electronic dialogue between your systems and IBM. It monitors networked servers for hardware errors and it can perform hardware and software inventories and report inventory changes to IBM. All information sent to IBM is stored in a highly secure database and used for improved problem determination.

Additional services include hardware warranty upgrades and factory-installed Product Customization Services (PCS), such as asset tagging, hardware integration, software imaging and operating systems personalization.

IBM offers extensive technical support by phone and via the Web. Support options include links to forums/newsgroups, problem submission, online shopping support, service offerings, device drivers for all IBM product lines, software downloads and even upcoming technical seminar worldwide schedules and registration. Also available are remote installation, configuration and usage support for System x and xSeries hardware and software, as well as onsite custom services to provide the level of expertise you require.

Advanced Systems Management Capabilities

The x3650 M2 has a high level of systems management capabilities that are well-suited to remote locations as well as to stand-alone environments. Features include UEFI, IMM, Tool Center, IBM Systems Director Active Energy Manager, Automatic Server Restart, Wake on LAN® support, PXE support, text console redirect, Predictive Failure Analysis, IBM Systems Director and support for an optional Remote Supervisor Adapter II SlimLine.

The Integrated Management Module (IMM) provides industry-standard Intelligent Platform Management Interface (IPMI) 2.0-compliant systems management. It provides a number of important system functions, including:

• Monitoring of system and battery voltage, system temperature, fans, power supplies, processor and DIMM status

• Fan speed control

• Product ID and Family ID detection

• Highly secure remote power on/off

• System reset control

• NMI/SMI detection and generation

• System diagnostic LED control (power, HDD, activity, alerts, heartbeat)

• IPMI over LAN

• Serial Over LAN

• Proxy server support

• LAN messaging and alerting

• Text console redirection over LAN

• VLAN support

• Enhanced authentication and encryption algorithms (RMCP+, SHA-1, AES)

• Local update of IMM firmware

• Firmware firewall

• Support for IPMI v2.0 compliant management software (e.g., xCAT)

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

• Other mandatory and optional IPMI IMM functions

The IMM alerts IBM Systems Director to anomalous environmental factors, such as voltage and thermal conditions—even if the server has failed.

The x3650 M2 also supports an optional IBM Virtual Media Key for additional systems management capabilities, including:

• Graphical console redirection over LAN

• Web-based out-of-band control

• Windows “blue screen” capture

• Remote virtual floppy and CD-ROM

• High-speed remote redirection of PCI video, keyboard and mouse

• SSL (Secure Socket Layer) and LDAP (Lightweight Directory Access Protocol) support

IBM developed IBM Systems Director Active Energy Manager to put control of system power- saving features at the fingertips of administrators. Active Energy Manager is designed to take advantage of new features, such as monitoring power usage and balancing the performance of the system according to available power input. It provides the ability to plan and predict power consumption based on your hardware configuration. It also helps enable you to reduce the infrastructure required for redundancy, by using fewer servers on smaller power feeds and potentially lowering your overall data center support costs. It does this by inventorying all components, then adding up the total power draw and tracking the usage. It also includes power management features to help administrators manage or reduce power usage.

Automatic Server Restart (ASR) helps reduce downtime by restarting the server automatically in the event of a system lockup. ASR technology is a combination of hardware circuitry tied into the server’s system reset function and a device driver. As long as the server continues running, the ASR watchdog timer will keep being reset, but if the operating system crashes or the hardware freezes somehow the ASR software will be unable to reset the hardware timer. If the timer is not reset within five minutes, it automatically triggers the ASR hardware, which immediately restarts the server (and logs an ASR event with IBM Systems Director). These features are designed so that no more than five minutes can pass before the server is restarted.

Wake on LAN permits the server to be remotely powered on if it has been shut off. Once powered up, the server can be controlled across the network, using the Preboot Execution Environment (PXE).

Like Wake on LAN, PXE is system firmware. It enables software such as the optional IBM Remote Deployment Manager to take control of a system before the BIOS, operating system or applications are loaded (using Wake on LAN/PXE) and lets an administrator perform many lowlevel tasks remotely that would otherwise require a visit to each system. These tasks may include such things as formatting a hard disk drive, updating system firmware, or deploying a Windows or Linux operating system.

Text Console Redirection support allows the administrator to remotely view x3650 M2 text messages over serial or LAN. An optional upgrade to the Virtual Media Key adds graphical console redirection.

Predictive Failure Analysis (PFA) is designed to allow the system to detect impending failure of supported components (processors, memory, HDDs, voltage regulator modules (VRMs), power supplies, and fans) before actual failure, and alert the administrator through IBM Systems Director. This gives you the ability to replace the failing component before it fails, resulting in increased uptime.

IBM Systems Director software for advanced workgroup management is included with the x3650 M2. IBM Systems Director comes with a portfolio of tools, including IBM Systems

Director Active Energy Manager™, Service and Support Manager, and others. System Availability (a no-charge download) and Capacity Manager (sold separately) are available as add-

ons for additional server management and increased availability. IBM Systems Director provides a single uniform graphical interface for all of these systems management functions.

IBM Systems Director enables you to customize thresholds and monitor system components (for things like temperature, voltage regulation, etc.) to help maximize uptime.

Key Options

IBM options for System x servers help you take your servers to a higher level

You rely on System x options to supply a complete solution for your business needs. Options help you create an optimized server system to meet your data protection, storage and availability needs. Every IBM option is designed and tested for peak performance and flexibility, helping to maximize your return on investment. The combination of System x servers and options lets you keep your fingers on the pulse of your e-business.

Processors — The Intel Xeon processor provides high clock rates, two or four cores, 64-bit

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

extensions, a large cache and advanced features for availability and manageability. Large cache size, combined with fast 1333MHz, 1066MHz or 800MHz memory access and an integrated memory controller reduce memory latency and facilitates the movement of data. (Note: System performance depends not only on the number of processors in the server but also on the power and functionality of each processor.) Adding a second processor may be a cost-effective way to achieve significant performance improvements.

Memory — Memory is a significant factor in systems application performance. Adding more memory to a System x server is one of the most effective ways to increase application performance. For best performance in a server with a 4-core processor, there should be twice as much memory available as for a 2-core processor.

Hard Disk Drives — IBM hard disk drives help you improve the transaction and cost performance of your System x servers. The choice of hard disk drives can be a critical aspect of maximizing the I/O throughput of the system. SAS hard disk drives are available for the x3550 M2 with capacities of 500GB (2.5-inch) at 7,200 RPMs and 146.8GB (2.5-inch) at 15,000 RPMs.

2.5-inch SATA HDDs are available in capacities up to 500GB (2.5-inch) at 7,200 RPMs.

Solid State Drives — IBM solid-state drives offer high performance and the ultimate in reliability, with 3X the MTBF (mean time between failure) rate of enterprise HDDs. IBM SSDs. are available in 50GB capacities. They can be used as a highly available boot drive, for storing disk images, or for other uses that stress read performance.

Power Supply — The optional second power supply for the x3650 M2 enables redundancy for hot-swap power. In addition, its 92%-efficient design helps lower your energy bill for power and cooling.

Virtual Media Key — The x3650 M2 includes a plethora of systems management features builtin; however, sometimes additional management capability is needed. In those situations, the Virtual Media Key not only offers powerful new features, it does so without taking up a valuable PCI-X or PCIe adapter slot, instead using a dedicated connector on the motherboard.

ServeRAID Controllers — System x servers using ServeRAID technology allow companies to build a reliable foundation for business-critical computing. IBM ServeRAID technology allows an array consisting of multiple physical hard disk drives to be treated as one logical drive. ServeRAID technology also allows data to be stored redundantly, across multiple hard disk drives— enhancing both the integrity and the availability of the data. SAS and SATA ServeRAID controllers offer enhanced performance due to onboard processors and cache. Because IBM ServeRAID controllers can help significantly improve data transfer rates, this technology is extremely effective when implementing demanding, transaction-oriented applications. By employing the advanced fault tolerance of IBM ServeRAID technology, companies can effectively implement networked business systems that require large amounts of storage space for data and applications that must be available for their businesses to continue operating.

External Storage — The IBM System Storage DS3000, DS4000, DS6000, and DS8000 series, as well as the N3000, N5000, and N7000 series, comprise a powerful and broad shared storage family with integrated management software designed to meet midrange and enterprise needs. For lower-end needs, IBM offers the System Storage EXP3000 storage enclosure.

External SAN, iSCSI, and direct-attach storage is available using one of several IBM System Storage and TotalStorage host bus adapters. Additionally, external LAN-attached tape storage is available.

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

Hot-Swap Power

USB

Hot-Swap

ServeRAID

Empty Hot

Swap 2.5

”

Bays

Status

Pop-Out Light Path

Hexagonal

Power

USB 2.0

Light Path Diagnostics

Hot-Swap 2.5

”

expandable, rack-dense, 2U dual-socket server

IBM System x3650 M2 Images

Front View

HDDs

Inside View

Hypervisor Key

Optical Drive

Diagnostics Panel

Controller

Video Port

Button

Ports

Panel Eject Button

Ventilation Holes

Lights

Supplies

HDD Bays

Fan Packs

16 DIMM Slots

Processor

Adapter Slots

Gb Ethernet

Adapter Slots

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

5.86Gtps

64x/66x)

6.4Gtps

94x/96x)

expandable, rack-dense, 2U dual-socket server

Rear View

Adapter Slots Adapter Slots

Hot-Swap Power Supplies

Fast Ethernet Port for IMM

Gb Ethernet Ports

Video Port

Serial Port

USB Ports

IBM System x3650 M2 Specifications

Machine type 7947-1XX, 2XX, 3XX, 4XX, 5XX, 6XX, 7XX, 8XX, 9XX

Form factor

Processor type

Maximum processor power draw

QuickPath Interconnect (QPI) speed (gigatransfers per second)

# of processors standard / maximum

Internal L3 cache

4-Core Xeon

2.0GHz E5504 (24x), 2.13GHz E5506 (34x,3Ax),

2.26GHz E5520 (32x, 44x), 2.26GHz L5520 (4Lx),

2.4GHz E5530 (56x), 2.53GHz E5540 (64x, 66x),

2.66GHz X5550 (74x, 76x), 2.8GHz X5560 (84x, 86x),

60W (4Lx) ---

2.4GHz L5530

supported via CTO

(12x, 24x, 3Ax/34x)

4MB (1 x 4MB unified cache)—(12x,

(E55xx/L55xx/X55xx)

2.93GHz X5570 (94x, 96x),

other processors supported via CTO

80W (12x, 24x, 3Ax/34x,

32x, 44x, 56x, 64x/66x)

4.8Gtps

2 / 2 (76x, 86x, 96x) 1 / 2 (all other models)

24x, 34x/3Ax)

(32x/44x, 4Lx, 56x,

8MB (1 x 8MB unified cache)—(32x,

44x/4Lx, 56x, 64x/66x, 74x/76x,

2-Core Xeon

(E55xx)

1.86GHz E5502 (12X)

95W (74x/76x, 84x/86x,

94x/96x)

(74x/76x, 84x/86x,

84x/86x, 94x/96x)

Chipset

Standard memory9 (128GB maximum)

Standard memory type Registered PC3-10600 (DDR III ECC (Chipkill protection when using x4 DIMMs)

Maximum memory access speed 1333MHz (74x/76x, 84x/86x, 94x/96x) 1066MHz (32x/44x, 4Lx, 56x, 64x/66x)

Memory interleaving

DIMM capacities supported

# of DIMM sockets total / available

Online hot-spare memory supported

Memory mirroring supported / # of DIMM sockets reserved for mirroring

Please see the Legal Information section for important notices and information.

Intel 5520

16GB (4 x 4GB) — 76x, 86x, 96x 8GB (2 x 4GB) — 66x

4GB (1 x 4GB)

(64x, 74x,, 84x, 94x)

Yes (four-way using multiples of 4 DIMMs; two-way otherwise)

Yes / 1 channel active, 1 spare, 1 unused

4GB (2 x 2GB)

(24x, 34x, 44x, 4Lx, 56x)

1GB, 2GB, 4GB, 8GB

16 (8 per processor) / 14

2GB (2 x 1GB) (12x, 32x, 3Ax)

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

# of HDD drive bays total / available

# of 5.25" bays total / available

Maximum drive capacity

Drive capacities supported

# of HDDs standard

# of optical drives standard

# of diskette drives standard

Internal tape drives supported

Disk drive technology

Integrated disk controller

# of disk drives supported per port

Integrated RAID controller

(Requires a Hot Swap SAS-SATA 4 Pac kit)

1 / 1 (24x, 44x, 4Lx, 56x, 64x/66x, 74x,

84x, 94x)

2.5-inch SAS/SATA

6.0TB (12 x 500GB) hot-swap

2.5-inch HS SAS

500GB – 7.2K

73.4, 146.8, 300GB –

10K

73.4, 146.8GB —15K

1 CD-RW/DVD-ROM

Combo

(12x, 32x/3Ax)

Hot-swap SAS/SATA/SSD; also simple-swap SSD

ServeRAID-BR10i—

RAID-0/1/1E (12x,

24x, 32x/34x/3Ax,

44x/4Lx, 56x)

12 / 12 (2.5-inch)

2.5-inch HS SATA

160, 500GB – 7.2K

300GB – 10K

None (all models open bay)

1 CD-RW/DVD-RW

Multi-burner —

(34x, 76x, 86x, 96x)

None (optional)

One (DDS Gen 5, DDS Gen 6)

LSI 1068

ServeRAID-M5014

(256MB cache) optional

battery—RAID-0/1/10/5/50;

optional RAID-6/60 with

SED (64x/66x)

1 / 0 (12x, 34x/3Ax, 32x, 76x, 86x, 96x)

2.5-inch SSD

600GB (12 x 50GB) hot-swap

2.5-inch HS or SS SSD

50GB

None (optional for 24x, 44x/4Lx, 56x, 64x/66x,

74x, 84x, 94x)

ServeRAID-M5015

(512MB cache) with

battery—RAID-0/1/10/5/50;

optional RAID-6/60 with SED (74x/76x, 84x/86x,

94x/96x)

Optional internal RAID controllers supported

External disk drives supported

# of adapter slots total / available

# of PCIe x8 Gen 2 slots (8GBps)

# of PCI-X/133 slots (1GBps)

# of 33MHz legacy PCI slots

# of video ports

Video controller

Video memory

Maximum video resolution at 32-bit color

Gigabit Ethernet controller

# of Gigabit Ethernet ports

# of RS485 ports

# of serial ports

# of parallel ports

ServeRAID-M5014

(256MB cache) optional battery RAID-

0/1/10/5/50; optional RAID-6/60 with

SED (12x, 24x, 32x/34x/3Ax, 44x/4Lx,

56x)

Yes, via optional ServeRAID-MR10M controller (256MB cache standard—

SAS/SATA; adds RAID-0/1/10/5/50/6/60)

2 (via optional risers)

None standard (optional in place of 1 PCIe slot)

2 (one front, one rear)

Matrox G200eV (in IMM) standard

(NVIDIA FX580, 1800, or 3800 available for CTO and special-bid models)

16MB DDR-2 SDRAM

1600 x 1200 x 16-bit color at 85Hz

Broadcom BCM5709

2 standard plus 2 optional

None (USB-attached)

ServeRAID-M5015 (512MB cache)

optional battery RAID-0/1/10/5/50;

optional RAID-6/60 with SED (12x, 24x,

32x/34x/3Ax, 44x/4Lx, 56x, 64x/66x)

4 /4

None

1 (rear)

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

# of mouse ports

# of keyboard ports

# of USB 2.0 ports

Integrated systems management controller

Optional systems management adapter

Light path diagnostics support

Predictive Failure Analysis (PFA) support

Power supply size

# of power supplies standard / maximum

Hot-swap/redundant power supported

# of fans/blowers standard / maximum 3 (with one processor installed) 3 (with two processors installed)

Hot-swap/redundant fans supported

Rack mount method

Maximum altitude

Operating temperature range

Dimensions (HWD) / weight

5 (2 front, 2 rear, 1 internal for an optional tape drive, IBM RDX disk storage

device, or USB flash memory key containing an embedded hypervisor) ports

Yes, with external pop-out/drop-down panel

Processors, memory, voltage regulator modules (VRMs), power supplies and fans

675W universal, autoswitching, hot-swap

2 / 2 (76x, 86x, 96x) 1 / 2 (all other models)

Slides and Cable Management Arm (provided standard)

50 – 95º F; 10 – 35º C (up to 3,000 ft /

914.4 m)

3.35” (85mm) H

17.47” (443.6mm) W

28.74” (730.1mm) D

None (USB-attached)

Yes (IMM)

Virtual Media Key (optional)

Yes (with two power supplies installed)

Yes (standard)

7,000 ft; 2,133 m

50 – 90º F; 10 – 32º C (3,000 ft to 7,000

ft / 914.4m to 2,133m)

28 (minimum) – 34.5 lb (maximum)

12.7 – 15.6 kg

Operating systems supported

Length of limited warranty

The Bottom Line

Microsoft Windows Server 2008 / 2008 R2; Microsoft Windows Server 2003 / 2003

R2; RHEL 4 32/64-bit without Xen; RHEL 5 32/64-bit, with and without Xen;

SLES 10/11 32/64-bit with and without Xen; VMware ESX Server 4.0, ESXi Server

4.0; Solaris 10

3 years (parts and labor)10

The IBM System x3650 M2 is an extremely energy efficient, powerful system, incorporating significantly redesigned management tools and abundant IBM-unique innovations:

Price/Performance

• High-throughput processors — Up to two 2.0 to 2.93GHz four-core or 1.86GHz two-core Xeon processors; up to two 4-core or 2-core processors total

• Energy-efficient low-voltage processors — 60W four-core Xeon 5500 Series processors

• Large cache — 8MB or 4MB of L3 processor cache (processor-specific)

• 64-bit extensions (EM64T)

• Fast memory — Registered PC3-10600 DDR III ECC DIMMs standard, operating at

1333MHz, 1066MHz or 800Mhz (depending on processor model and memory configuration)

• Fast disk technology — Supports high-performance drives that provide high density/high reliability and allow you to scale up as your business grows.

• Fast communications — Integrated dual Gigabit Ethernet controllers standard supporting Jumbo Frames and TOE; two additional NICs optional

• Fast I/O — Four PCIe x8 adapter slots (replaceable with two x16)

Flexibility

• Large memory capacity — Up to 128GB of registered DDR2 DIMMs, using 16 DIMM slots

• Up to twelve 2.5-inch hot-swap SAS/SATA HDDs or SSDs or simple-swap SSDs

• Choice of disk storage — Up to 6.0TB of internal SAS/SATA storage, 600GB of internal

solid-state storage

• High-performance external expansion — Five 480Mbps USB 2.0 ports (two front, two rear, one internal for optional USB key with hypervisor)

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

• Slotless hardware-based 3Gbps RAID-0/1/1E or 6Gbps RAID-0/1/10/5/50 (optional RAID6/60 with SED support) standard

• Four available adapter slots:

 Four x811 PCIe Gen 2 slots (8GBps)  An optional riser card containing one 133MHz PCI-X slot can replace each of the two

riser cards

• Integrated CD-RW/DVD-ROM Combo or CD-RW/DVD-RW Multi-burner drive on selected models, optional on others

• Two video ports (one on the front and one on the back)

• Optional iSCSI HBA Adapter for IXA Connectivity (to System i® servers)

Manageability, Serviceability and Availability

• IBM Systems Director systems management software, including:

 IBM Systems Director Active Energy Manager  IBM Service and Support Manager

• Integrated Management Module (IMM):

 IPMI 2.0 compliance, including highly secure remote power control  Text console redirection systems management standard

• Active Memory protection:

 Advanced Chipkill ECC memory protection support  Memory mirroring

• Integrated ServeRAID controller — enhances system availability and serviceability without using a PCI slot

• Hot-swap SAS/SATA HDDs or SSDs, or simple-swap SSDs—no fixed drives

• Optional IBM 50.0GB Solid State Drive as a high-reliability alternative to internal storage

(with up to three times the MTBF of spinning disk drives)

• Ultra-efficient cooling incorporating Calibrated Vectored Cooling features and hot- swap/redundant fan modules

• Standard or optional hot-swap/redundant power supplies (on selected models)

• Light path diagnostics (front LED panel, pop-out/drop-down light path panel)

• Optional Virtual Media Key daughter card (no slot required)

 Supports LDAP and SSL industry standards

• Toolless chassis and toolless slide design; integrated Cable Management Arm

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and







x3250

x3550

x3650

x3850 M2x3950









































expandable, rack-dense, 2U dual-socket server

Server Comparison Chart

Theme Key Workloads

Web 2.0 /

Web 3D

Business

Applications

Infrastructure

Applications

HPC

Cluster / HPC Modeling & Simulation High Performance DB Business Intelligence Search Content Communities Commerce Collaboration ERP/SCM CRM Hosted Client

Point of Sale Branch Office Virtualization Business Continuity Database Email/Collaboration Security Web Serving File & Print

Important Nice to Have Can do without

1 2 3

Floating Point

Performance

Throughput

Scalability

3 1 1 2 2 1 3 3 3 3

2 1 1 1 3 1 3 2 3 3

2 2 1 1 1 3 2 2 3 3

2 1 1 1 2 1 2 2 1 3

3 1 1 1 2 1 3 3 1 2

2 2 2 2 2 1 3 3 2 2

1 2 2 2 1 1 2 3 2 2

2 1 1 1 2 1 1 2 1 2

2 3 2 3 2 1 2 3 2 2

1 2 1 1 1 2 1 1 1 2

2 2 2 2 2 2 2 2 1 3

1 3 2 1 2 2 1 1 2 2

3 3 3 2 1 3 1 1 1 1

2 3 3 3 2 2 1 1 2 1

1 2 2 2 1 2 1 1 2 3

2 3 3 3 1 2 2 1 2 2

2 2 1 2 1 2 1 2 2 3

2 3 2 1 2 2 1 1 2 2

2 2 2 2 2 1 1 1 1 3

3 2 2 2 3 1 2 1 3 3

2 3 2 3 1 2 2 1 3 3

I/O and Storage

Performance

Memory

Integer

High Availability

Management

Systems

Density

Security

Best

Better

Good

Rack-Optimized ServersRequirements

Deployment

Distributed

x3350

x3450

x3455

x3610

x3655

x3755

Please see the Legal Information section for important notices and information.

Leadership enterprise server with significantly lower cost of ownership in a highly available and expandable, rack-dense, 2U dual-socket server

For More Information

IBM System x Servers http://ibm.com/systems/x IBM Systems Director Service and Support Manager http://ibm.com/support/electronic IBM System x and BladeCenter Power Configurator http://ibm.com/systems/bladecenter/powerconfig Standalone Solutions Configuration Tool http://ibm.com/servers/eserver/xseries/library/configtools.html Configuration and Options Guide http://ibm.com/servers/eserver/xseries/cog ServerProven Program http://ibm.com/servers/eserver/serverproven/compat/us Technical Support http://ibm.com/server/support Other Technical Support Resources http://ibm.com/servers/eserver/techsupport.html

Legal Information

IBM Systems and Technology Group Dept. U2SA 3039 Cornwallis Road Research Triangle Park, NC 27709

For a copy of applicable product warranties, write to: Warranty Information, P.O. Box 12195, RTP, NC 27709, Attn: Dept. JDJA/B203. IBM makes no representation or warranty regarding third-party products or services including those designated as ServerProven or ClusterProven. Telephone support may be subject to additional charges. For onsite labor, IBM will attempt to diagnose and resolve the problem remotely before sending a technician.

IBM, the IBM logo, the e-business logo, Active Memory, Predictive Failure Analysis, ServeRAID, System i, System Storage, System x, Xcelerated Memory Technology, and XArchitecture are trademarks of IBM Corporation in the United States and/or other countries, or both. If these and other IBM trademarked terms are marked on their first occurrence in this information with a trademark symbol (® or ™), these symbols indicate U.S. registered or common law trademarks owned by IBM at the time this information was published. Such trademarks may also be registered or common law trademarks in other countries. A current list of IBM trademarks is available on the Web at http://ibm.com/legal/copytrade.shtml.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Linux is a registered trademark of Linus Torvalds.

Microsoft, Windows and the Windows logo are trademarks or registered trademarks of Microsoft Corporation.

Other company, product and service names may be trademarks or service marks of others.

IBM reserves the right to change specifications or other product information without notice. References in this publication to IBM products or services do not imply that IBM intends to make them available in all countries in which IBM

operates. IBM PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions; therefore, this statement may not apply to you.

This publication may contain links to third party sites that are not under the control of or maintained by IBM. Access to any such third party site is at the user's own risk and IBM is not responsible for the accuracy or reliability of any information, data, opinions, advice or statements made on these sites. IBM provides these links merely as a convenience and the inclusion of such links does not imply an endorsement.

Information in this presentation concerning non-IBM products was obtained from the suppliers of these products, published announcement material or other publicly available sources. IBM has not tested these products and cannot confirm the accuracy of performance, compatibility or any other claims related to non-IBM products. Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products.

MB, GB and TB = 1,000,000, 1,000,000,000 and 1,000,000,000,000 bytes, respectively, when referring to storage capacity. Accessible capacity is less; up to 3GB is used in service partition. Actual storage capacity will vary based upon many factors and may be less than stated.

Performance is in Internal Throughput Rate (ITR) ratio based on measurements and projections using standard IBM benchmarks in a controlled environment. The actual throughput that any user will experience will depend on considerations such as the amount of multiprogramming in the user’s job stream, the I/O configuration, the storage configuration and the workload processed. Therefore, no assurance can be given that an individual user will achieve throughput improvements equivalent to the performance ratios stated here.

Maximum internal hard disk and memory capacities may require the replacement of any standard hard drives and/or memory and the population of all hard disk bays and memory slots with the largest currently supported drives available. When referring to variable speed CD-ROMs, CD-Rs, CD-RWs and DVDs, actual playback speed will vary and is often less than the maximum possible.

XSO03060-USEN-03

Please see the Legal Information section for important notices and information.

IBM 7947E5U, System x3650 M2 Product Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
