IBM System x3500 M4

IBM Redbooks Product Guide

The IBM® System x3500 M4 server provides outstanding performance for your business-critical applications. Its energy-efficient design supports more cores, memory, and data capacity in a scalable Tower or 5U Rack package that is easy to service and manage. With more computing power per watt and the latest Intel Xeon processors, you can reduce costs while maintaining speed and availability.

Suggested use: infrastructure applications, collaboration/email, web, and virtualized desktops in a workgroup or distributed environments.

Figure 1 shows the IBM System x3500 M4.

Figure 1. The IBM System x3500 M4

Did you know?

The x3500 M4 offers a flexible, scalable design and simple upgrade path to 32 HDDs, with up to eight PCIe 3.0 slots and up to 768 GB of memory. The Onboard Ethernet solution provides four standard integrated Gigabit Ethernet ports without occupying PCIe slots. Comprehensive systems management tools with the next-generation Integrated Management Module II (IMM2) make it easy to deploy, integrate, service, and manage.

IBM System x3500 M4 1

Key features

A high-performance dual-socket tower server, the IBM System x3500 M4, can deliver the scalability, reliable performance, and optimized efficiency for your business-critical applications. Start with the basics and upgrade as your business changes without jeopardizing existing investments. Virtualizing the PC infrastructure into one server can provide access to a powerful server with abundant storage space, while significantly reducing IT costs.

Scalability and performance

The x3500 M4 offers numerous features to boost performance, improve scalability, and reduce costs:

The Intel Xeon processor E5-2600 product family improves productivity by offering superior system performance with 8-core processors and up to 2.9 GHz core speeds, up to 20 MB of L3 cache, and two QPI interconnect links of up to 8 GT/s.

Up to two processors, 16 cores, and 32 threads maximize the concurrent execution of multi-threaded applications.

Intelligent and adaptive system performance with Intel Turbo Boost Technology 2.0 allows CPU cores to run at maximum speeds during peak workloads by temporary going beyond processor TDP.

Intel Hyper-Threading Technology boosts performance for multi-threaded applications by enabling simultaneous multi-threading within each processor core, up to two threads per core.

Intel Virtualization Technology integrates hardware-level virtualization hooks that allow operating system vendors to better utilize the hardware for virtualization workloads.

Intel Advanced Vector Extensions (AVT) significantly improve floating point performance for compute-intensive technical and scientific applications compared to Intel Xeon 5600 series processors.

Twenty-four Load Reduced DIMMs (LRDIMMs) of 1333 MHz DDR3 ECC memory provide speed, high availability, and a memory capacity of up to 768 GB.

The theoretical maximum memory bandwidth of the Intel Xeon processor E5 family is 51.6 GBps, which is 60% more than in the previous generation of Intel Xeon processors.

Up to 32 drive bays together with internal backup and optical drive at the same time provide a flexible and scalable all-in-one platform to meet increasing demands.

The server has four integrated Gigabit Ethernet ports that double the network throughput compared with the previous generation of IBM System x® servers.

The server offers PCI Express 3.0 I/O expansion capabilities that improve the theoretical maximum bandwidth by 60% (8 GT/s per link) compared with the previous generation of PCI Express 2.0.

With Intel Integrated I/O Technology, the PCI Express 3.0 controller is integrated into the Intel Xeon processor E5 family. This helps to dramatically reduce I/O latency and increase overall system performance.

Availability and serviceability

The x3500 M4 provides many features to simplify serviceability and increase system uptime:

The server offers memory mirroring and memory rank sparing for redundancy in the event of a non-correctable memory failure.

Tool-less cover removal provides easy access to upgrades and serviceable parts, such as CPU, memory, and adapter cards.

IBM System x3500 M4 2

The server offers hot-swap drives supporting RAID redundancy for data protection and greater system uptime.

The server has up to two redundant hot-swap power supplies and up to six simple swap N+N redundant fans to provide availability for business-critical applications.

The power source independent light path diagnostics panel and individual light path LEDs quickly lead the technician to failed (or failing) components. This simplifies servicing, speeds up problem resolution and helps improve system availability.

The Predictive Failure Analysis (PFA) detects when system components (for example, processors, memory, hard disk drives) operate outside of standard thresholds and generates pro-active alerts in advance of possible failure, therefore increasing uptime.

Built-in Integrated Management Module Version II (IMM2) continuously monitors system parameters, triggers alerts, and performs recovering actions in case of failures to minimize downtime.

Built-in diagnostics using Dynamic Systems Analysis (DSA) Preboot speeds up troubleshooting tasks to reduce service time.

Three-year customer replaceable unit and onsite limited warranty, next business day 9x5. Optional service upgrades available.

Manageability and security

Powerful systems management features simplify local and remote management of the x3500 M4:

The server includes an Integrated Management Module II (IMM2) to monitor server availability and perform remote management.

Integrated industry-standard Unified Extensible Firmware Interface (UEFI) enables improved setup, configuration, and updates, and simplifies error handling.

Integrated Trusted Platform Module (TPM) 1.2 support enables advanced cryptographic functionality, such as digital signatures and remote attestation.

Industry-standard AES NI support for faster, stronger encryption.

IBM Systems Director is included for proactive systems management. It offers comprehensive systems management tools that help to increase up-time, reduce costs, and improve productivity through advanced server management capabilities.

Intel Execute Disable Bit functionality can help prevent certain classes of malicious buffer overflow attacks when combined with a supporting operating system.

Intel Trusted Execution Technology provides enhanced security through hardware-based resistance to malicious software attacks, allowing an application to run in its own isolated space protected from all other software running on a system.

Energy efficiency

The x3500 M4 offers the following energy-efficiency features to save energy, reduce operational costs, increase energy availability, and contribute to the green environment:

Energy-efficient planar components help lower operational costs.

High-efficient 750 W and 900 W power supplies with 80 PLUS Platinum certification.

The Intel Xeon processor E5-2600 product family offers significantly better performance over the previous generation while fitting into the same thermal design power (TDP) limits.

Intel Intelligent Power Capability powers individual processor elements on and off as needed, to reduce power draw.

IBM System x3500 M4 3

Low-voltage Intel Xeon processors draw less energy to satisfy demands of power and thermally constrained data centers and telecommunication environments.

Low-voltage 1.35 V DDR3 memory RDIMMs consume 15% less energy than 1.5 V DDR3 RDIMMs.

The server uses hexagonal ventilation holes, a part of IBM Calibrated Vectored Cooling™ technology. Hexagonal holes can be grouped more densely than round holes, providing more efficient airflow through the system.

IBM Systems Director Active Energy Manager™ provides advanced data center power notification and management to help achieve lower heat output and reduced cooling needs.

Locations of key components and connectors

Figure 2 shows the front of the server.

Figure 2. Front view of the IBM System x3500 M4

IBM System x3500 M4 4

Figure 3 shows the rear of the server.

Figure 3. Rear view of the IBM System x3500 M4

Figure 4 shows the locations of key components inside the server.

Figure 4. Inside view of the IBM System x3500 M4

IBM System x3500 M4 5

Standard specifications

The following table lists the standard specifications.

Table 1. Standard specifications (part 1)

Components Specification

Form factor Tower or 5U Rack.

Processor Up to two Intel Xeon processor E5-2600 product family CPUs with eight cores (up to 2.9 GHz) or

six cores (up to 2.9 GHz) or quad-cores (up to 3.3 GHz). Two QPI links up to 8.0 GT/s each. Up to 1600 MHz memory speed. Up to 20 MB L3 cache.

Chipset Intel C602J.

Memory Up to 24 DDR3 DIMM sockets (12 DIMMs per processor). RDIMMs, UDIMMs, and LRDIMMs are

supported, but memory types cannot be intermixed.

Memory maximums

With LRDIMMs: Up to 768 GB with 24x 32 GB LRDIMMs and two processors. With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors. With UDIMMs: Up to 32 GB with 16x 2 GB UDIMMs and two processors.

Memory

ECC, memory mirroring, and memory sparing.

protection

Disk drive bays Up to thirty-two 2.5" hot-swap SAS/SATA HDDs, or up to eight 3.5" hot-swap SAS/SATA HDDs,

or up to eight 3.5" Simple Swap SATA HDDs.

Maximum internal storage

28.8 TB with 900 GB 2.5" SAS HDDs, or 32 TB with 1 TB 2.5" SATA HDDs, or 24 TB with 3 TB

3.5" SATA HDDs. Intermix of SAS/SATA is supported.

RAID support RAID 0, 1, 10 with M1115 or ServeRAID M5110. Optional upgrade to RAID 5, 50 available for

M1115. Optional upgrades to RAID 5, 50 are available for M5110 (zero-cache, 512 MB battery-backed cache, 512 MB or 1 GB flash-backed cache). Optional upgrade to RAID 6, 60 available for M5110.

Optical drive

Two half-height 5.25" bays for optical or tape drives. Supports DVD-ROM or Multiburner.

bays

Tape drive bays Two half-height 5.25" bays for optical or tape drives. Support for one RDX or DDS internal USB

tape drive. Supports up to two LTO internal SAS tape drives.

Network interfaces

PCI Expansion slots

Four integrated Gigabit Ethernet 1000BASE-T ports (RJ-45) based on Intel I350AM4 Quad Port GbE LAN Controller chip.

Up to eight slots with two processors and six slots when one CPU is installed. All slots are PCIe

3.0 slots except Slot 1, which is a Gen 2 slot:

Slot 1: PCIe x8 (x4 wired); full-height, half-length (supports optional PCI-X 64 bit/133 MHz interposer card)

Slot 2: PCIe x8; full-height, half-length

Slot 3: PCIe x8; full-height, full-length

Slot 4: PCIe x8 (x4 wired); full-height, full-length

Slot 5: PCIe x16; full-height, full-length

Slot 6: PCIe x8 (x4 wired); full-height, full-length

Slot 7: PCIe x16; full-height, full-length (requires second processor)

Slot 8: PCIe x16; full-height, full-length (requires second processor)

Ports Two USB 2.0s on front. Four USB 2.0s, one DB-15 video, one DB-9 serial, one RJ-45 systems

management, four RJ-45 GbE network ports on rear. Two internal USB ports (for embedded hypervisor and internal tape drive).

Cooling IBM Calibrated Vectored Cooling with up to six simple swap fans (two fans shipped standard on

single processor models and three fans shipped on dual processor models) with optional N+N redundancy available .

IBM System x3500 M4 6

Table 1. Standard specifications (part 2)

Components Specification

Power supply Up to two redundant hot-swap 750 W ac or 900 W ac power supplies (80 PLUS Platinum

certification).

Hot-swap parts Hard drives, power supplies.

Systems management

Security features

Video Matrox G200eR2 with 16 MB memory integrated into the IMM2. Maximum resolution is

Operating systems supported

Limited warranty 3-year customer-replaceable unit and onsite limited warranty with 9x5/NBD.

Service and support

Dimensions Width: 218 mm (8.6 in), depth: 750 mm (29.5 in), height: 440 mm (17.3 in).

Weight Minimum configuration: 25.0 kg (55.1 lb), maximum: 39.8 kg (87.7lb).

UEFI, IBM Integrated Management Module II (IMM2), Predictive Failure Analysis, Light Path Diagnostics, Automatic Server Restart, IBM Systems Director and IBM Systems Director Active Energy Manager, IBM ServerGuide. Optional IMM Advanced Upgrade via Feature on Demand (FoD) for remote presence (graphics, keyboard and mouse, virtual media).

Power-on password, administrator's password, Trusted Platform Module (TPM).

1600x1200 at 75 Hz with 16 M colors.

Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux 5 and 6, SUSE Linux Enterprise Server 10 and 11, VMware vSphere 5.

Optional service upgrades are available through IBM ServicePacs®: 4-hour or 2-hour response time, 8-hour fix time, 1-year or 2-year warranty extension, remote technical support for IBM hardware and selected IBM and third-party (Microsoft, Linux, VMware) software.

The x3500 M4 servers are shipped with the following items:

Statement of Limited Warranty

Important Notices

Registration flyer

Documentation CD that contains the

IBM Systems Director 6.3 Base for x86 DVD-ROM

One 2.8 m C13 line cord (country-specific)

Installation and User's Guide

IBM System x3500 M4 7

Standard models

The following table lists the standard models.

Table 2. Standard models

Model Intel Xeon processors†

(2 maximum)

Models announced March 2012

7383-A2x 1x E5-2603 4C 1.8GHz

10MB 1066MHz 80W

7383-B2x 1x E5-2609 4C 2.4GHz

10MB 1066MHz 80W

7383-C2x 1x E5-2620 6C 2.0GHz

15MB 1333MHz 95W

7383-C4x 1x E5-2620 6C 2.0GHz

15MB 1333MHz 95W

7383-D2x 1x E5-2630 6C 2.3GHz

15MB 1333MHz 95W

7383-F2x 1x E5-2640 6C 2.5GHz

15MB 1333MHz 95W

7383-G2x 1x E5-2650 8C 2.0GHz

20MB 1600MHz 95W

7383-H2x 1x E5-2670 8C 2.6GHz

20MB 1600MHz 115W

7383-J2x 1x E5-2680 8C 2.7GHz

20MB 1600MHz 130W

Memory RAID Disk

1x 4 GB M1115 8x 2.5" HS / 32 Open 4 DVD-ROM 1x 750W

1x 8 GB M1115 8x 2.5" HS / 32 Open 4 DVD-ROM 1x 750W

1x 8 GB M1115 8x 3.5" HS / 8 Open 4 DVD-ROM 1x 750W

1x 8 GB M1115 8x 2.5" HS / 32 Open 4 DVD-ROM 1x 750W

1x 8 GB M5110

512MB (f)

1x 8 GB M5110

1GB (f)

1x 8 GB M5110

1GB (f)

1x 8 GB M5110

1GB (f)

bays

8x 2.5" HS / 32 Open 4 DVD-ROM 1x 750W

8x 2.5" HS / 32 Open 4 DVD-ROM 1x 900W

Disks GbE DVD Power

† Processor detail: Processor quantity and model, number of cores, core speed, L3 cache, memory speed, power consumption. (f) The ServeRAID M5110 RAID controller in this model includes flash-backed cache. The cache size is 512 MB or 1 GB, as indicated.

Refer to the Specifications section for information about standard features of the server.

IBM System x3500 M4 8

Processor options

The x3500 M4 supports the processor options listed in the following table. The server supports up to two processors. This table shows which server models have each processor standard. If there is no corresponding CTO.

Table 3. Processor options

Part number Description Standard models

Intel Xeon processor E5-2600 product family

90Y5942 Intel Xeon Processor E5-2603 4C 1.8GHz 10MB 80W Upgrade Kit A2x

90Y5944 Intel Xeon Processor E5-2609 4C 2.4GHz 10MB 80W Upgrade Kit B2x

90Y5945 Intel Xeon Processor E5-2620 6C 2.0GHz 15MB 95W Upgrade Kit C2x, C4x

90Y5946 Intel Xeon Processor E5-2630 6C 2.3GHz 15MB 95W Upgrade Kit D2x

90Y5953 Intel Xeon Processor E5-2630L 6C 2.0GHz 15MB 60W Upgrade Kit -

94Y7342 Intel Xeon Processor E5-2637 2C 3.0GHz 5MB 80W Upgrade Kit -

90Y5947 Intel Xeon Processor E5-2640 6C 2.5GHz 15MB 95W Upgrade Kit F2x

94Y7341 Intel Xeon Processor E5-2643 4C 3.3GHz 10MB 130W Upgrade Kit -

where-used

model for a particular processor, then this processor is only available through

where used

90Y5948 Intel Xeon Processor E5-2650 8C 2.0GHz 20MB 95W Upgrade Kit G2x

90Y5954 Intel Xeon Processor E5-2650L 8C 1.8GHz 20MB 70W Upgrade Kit -

90Y5949 Intel Xeon Processor E5-2660 8C 2.2GHz 20MB 95W Upgrade Kit -

94Y7442 Intel Xeon Processor E5-2665 8C 2.4GHz 20MB 115W Upgrade Kit -

90Y5951 Intel Xeon Processor E5-2667 6C 2.9GHz 15MB 130W Upgrade Kit -

90Y5955 Intel Xeon Processor E5-2670 8C 2.6GHz 20MB 115W Upgrade Kit H2x

90Y5950 Intel Xeon Processor E5-2680 8C 2.7GHz 20MB 130W Upgrade Kit J2x

94Y7343 Intel Xeon Processor E5-2690 8C 2.9GHz 20MB 135W Upgrade Kit -

IBM System x3500 M4 9

Memory options

The IBM System x3500 M4 supports DDR3 memory. The server supports up to 12 DIMMs when one processor is installed and up to 24 DIMMs when two processors are installed. Each processor has four memory channels, and there are three DIMMs per channel. The following rules apply when selecting the memory configuration:

The server supports UDIMMs, RDIMMs, and LRDIMMs.

Mixing different types of memory (UDIMMs, RDIMMs, and LRDIMMs) is not supported.

Mixing 1.5 V and 1.35 V DIMMs in the same server is supported. In such a case all DIMMs operate at

1.5 V.

The maximum number of ranks per channel is eight (with the exception of Load Reduced DIMMs, where more than eight ranks are supported because one quad-rank LRDIMM provides the same electrical load on a memory bus as a single-rank RDIMM).

The maximum quantity of DIMMs that can be installed in a server depends on the number of CPUs, DIMM type, rank, and operating voltage, as shown in the "Max. qty supported" row in Table 4.

All DIMMs in the server operate at the same speed, which is determined as the lowest value of:

Memory speed supported by specific CPU

Lowest maximum operating speed for the selected memory configuration that depends on rated speed, operating voltage, and quantity of DIMMs per channel, as shown in the "Max. operating speed" section in Table 4

Table 4. Maximum memory speeds

DIMM type

DIMM specification

Rank Dual rank Single rank Dual rank Quad rank Quad rank

Rated speed 1333 MHz 1333 MHz 1333 MHz 1600 MHz 1066 MHz 1333 MHz

Rated voltage 1.35 V 1.35 V 1.35 V 1.5 V 1.35 V 1.35 V

Operating voltage 1.35 V 1.5 V 1.35 V 1.5 V 1.35 V 1.5 V 1.5 V 1.35 V 1.5 V 1.35 V 1.5 V

Max. qty supported*

Max. DIMM capacity

Max. memory capacity

Max. operating speed

1 DIMM per channel

2 DIMMs per channel

3 DIMMs per channel

UDIMM RDIMM LRDIMM

16 16 16 24 16 24 24 16 16 24 24

2 GB 2 GB 4 GB 4 GB 16 GB 16 GB 4 GB 16 GB 16 GB 32 GB 32 GB

32 GB 32 GB 64 GB 96 GB 256GB 384GB 96GB 256GB 256GB 768GB 768GB

____

1333 MHz

1066 MHz

NS** NS** NS** 1066

____

1333 MHz

____

1333 MHz

____

1333 MHz

MHz

_____

1333 MHz

NS** 1066

_____

1333 MHz

MHz

_____

1600 MHz

1066 MHz

_____

800 MHz

NS** NS** 1066

_____

1066 MHz

800 MHz

_____

1333 MHz

1066 MHz

MHz

_____

1333 MHz

1066 MHz

* The maximum quantity supported is shown for two processors installed. When one processor installed the maximum quantity supported is a half of that shown. ** NS = Not supported.

IBM System x3500 M4 10

The following memory protection technologies are supported:

ECC

Memory mirroring

Memory sparing

If memory mirroring is used, then DIMMs must be installed in pairs (minimum of one pair per CPU), and both DIMMs in a pair must be identical in type and size. If memory sparing is used, then DIMMs must be installed in sets of three, and all DIMMs in the same set must be identical in type and size.

The following table lists memory options available for the x3500 M4 server.

Table 5. Memory options

Part number

UDIMMs

49Y1403 2GB (1x2GB, 1Rx8, 1.35V) PC3L-10600 ECC DDR3

RDIMMs

49Y1405 2GB (1x2GB, 1Rx8, 1.35V) PC3L-10600 CL9 ECC

49Y1406 4GB (1x4GB, 1Rx4, 1.35V) PC3L-10600 CL9 ECC

49Y1407 4GB (1x4GB, 2Rx8, 1.35V) PC3L-10600 CL9 ECC

90Y3178 4GB (1x4GB, 2Rx8, 1.5V) PC3-12800 CL11 ECC DDR3

49Y1397 8GB (1x8GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC 1333

49Y1400 16GB (1x16GB, 4Rx4, 1.35V) PC3L-8500 CL7 ECC

49Y1563 16GB (1x16GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC

Description Maximum quantity

1333MHz LP UDIMM

DDR3 1333 MHz LP RDIMM

1600MHz LP RDIMM

MHz LP RDIMM

DDR3 1066MHz LP RDIMM

DDR3 1333MHz LP RDIMM

Standard models

supported

16 (8 per CPU) -

24 (12 per CPU) -

24 (12 per CPU) A2x, B2x

24 (12 per CPU) -

24 (12 per CPU) C2x, C4x, D2x,

16 (8 per CPU) -

24 (12 per CPU) -

where used

F2x, G2x, H2x, J2x

LRDIMMs

90Y3105 32GB (1x32GB, 4Rx4, 1.35V) PC3L-10600 CL9 ECC

DDR3 1333MHz LP LRDIMM

IBM System x3500 M4 11

24 (12 per CPU) -

Internal disk storage options

The IBM System x3500 M4 server supports the following internal storage configurations:

8x 3.5" Simple Swap SATA hard drive bays (only available in CTO)

8x 3.5" hot-swap SAS/SATA hard drive bays

8x 3.5" hot-swap SAS/SATA drive bays + 8x 2.5" Slim-SFF SAS/SATA hot-swap drive bays (only available in CTO, requires two RAID controllers)

8x 2.5" Slim-SFF SAS/SATA hot-swap hard drive bays

16x 2.5" Slim-SFF SAS/SATA hot-swap hard drive bays

24x 2.5" Slim-SFF SAS/SATA hot-swap hard drive bays

32x 2.5" Slim-SFF SAS/SATA hot-swap hard drive bays

Figure 5 shows these configurations.

Figure 5. Internal drive configurations

Backplanes

Standard models of x3500 M4 ship with eight (all models except C4x) 2.5" Slim-SFF SAS/SATA hot-swap drive bays. Model C4x ships with eight 3.5" SAS/SATA hot-swap hard drive bays. The following table shows internal storage expansion options available for the x3500 M4 server.

Table 6. Internal storage expansion options

Part number

94Y5978 Additional 8 x 2.5” Hot-Swap SAS/SATA Upgrade Kit for 16 or 24 HDDs (shown in Figure 5

81Y7010 Additional 8 x 2.5" Hot-Swap SAS/SATA Upgrade Kit for 32 HDDs (shown in Figure 5 as an

IBM System x3500 M4 12

Name Maximum

quantity supported

as an Upgrade 1 used in configurations 4, 5, and 6)

Upgrade 2 used in configuration 6)

These options have the following descriptions:

94Y5978 upgrades models with eight hot-swap 2.5" drive bays to 16 hot-swap 2.5" drive bays or models with 16 hot-swap 2.5" drive bays to 24 hot-swap 2.5" drive bays. This option includes a SAS expander card that is mounted on an HDD backplane, and does not consume a PCIe slot.

81Y7010 upgrades models with 24 hot-swap 2.5" drive bays to 32 hot-swap 2.5" drive bays. This option does not include an SAS expander.

As shown in Figure 5, each configuration supports an optical drive and a tape drive. All standard configurations ship with DVD-ROM optical drive. For configure-to-order (CTO) configurations, you can add a tape drive instead of an optical drive if so desired.

Configurations 4, 5, and 6 shown in Figure 5 can be implemented with one or two RAID controllers (M1115 or M5110). Configuration 2 requires two RAID controllers.

RAID controllers

The following table lists the RAID controllers and additional options used for internal disk storage of the x3500 M4 server.

Table 7. RAID controllers for internal storage

Part number

81Y4448 ServeRAID M1115 SAS/SATA Controller for System x 2 A2x, B2x, C2x, C4x,

81Y4542 ServeRAID M1100 Series Zero Cache/RAID 5 Upgrade for IBM

81Y4481 ServeRAID M5110 SAS/SATA Controller 2 F2x, G2x, H2x,J2x

81Y4544 ServeRAID M5100 Series Zero Cache/RAID 5 Upgrade for IBM

81Y4484 ServeRAID M5100 Series 512MB Cache/RAID 5 Upgrade for

81Y4487 ServeRAID M5100 Series 512MB Flash/RAID 5 Upgrade for IBM

81Y4559 ServeRAID M5100 Series 1GB Flash/RAID 5 Upgrade for IBM

81Y4508 ServeRAID M5100 Series Battery Kit for IBM System x 2* -

81Y4546 ServeRAID M5100 Series RAID 6 Upgrade for IBM System x 2† -

* The ServeRAID M5100 Series Battery Kit (81Y4508) is only supported with ServeRAID M5100 Series 512MB Cache/RAID 5 Upgrade (81Y4484). † The ServeRAID M5100 Series RAID 6 Upgrade (81Y4546) requires RAID 5 Upgrade.

Description Max

quantity supported

2 -

System x

2 -

System x

2 -

IBM System x

2 F2x

System x

2 G2x, H2x, J2x

System x

Standard models where used

D2x

IBM System x3500 M4 13

The ServeRAID M1115 SAS/SATA Controller has the following specifications:

Eight internal 6 Gbps SAS/SATA ports

Two x4 mini-SAS internal connectors (SFF-8087)

Supports RAID levels 0, 1, and 10

Supports RAID levels 5 and 50 with optional M1100 Series RAID 5 upgrades

6 Gbps throughput per port

PCIe x8 Gen 3 host interface

Based on the LSI SAS2008 6 Gbps ROC controller

The ServeRAID M5110 SAS/SATA Controller has the following specifications:

Eight internal 6 Gbps SAS/SATA ports

Two x4 mini-SAS internal connectors (SFF-8087)

Supports RAID levels 0, 1, and 10

Supports RAID levels 5 and 50 with optional M5100 Series RAID 5 upgrades

Supports RAID 6 and 60 with the optional M5100 Series RAID 6 Upgrade

Supports 512 MB battery-backed cache or 512 MB or 1 TB flash-backed cache

6 Gbps throughput per port

PCIe x8 Gen 3 host interface

Based on the LSI SAS2208 6 Gbps ROC controller

IBM System x3500 M4 14

Internal disk drive options

The following table lists hard drive options for internal disk storage of the x3500 M4 server.

Table 8. Disk drive options for internal disk storage

Part number Description Maximum quantity

supported

2.5" NL SATA Hot-Swap HDDs

81Y9730 IBM 1TB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 32

2.5" NL SAS Hot-Swap HDDs

90Y8953 IBM 500GB 7.2K 6Gbps NL SAS 2.5" SFF G2HS HDD 32

81Y9690 IBM 1TB 7.2K 6Gbps NL SAS 2.5" SFF HS HDD 32

2.5" SAS Hot-Swap HDDs

90Y8926 IBM 146GB 15K 6Gbps SAS 2.5" SFF G2HS HDD 32

90Y8877 IBM 300GB 10K 6Gbps SAS 2.5" SFF G2HS HDD 32

90Y8913 IBM 300GB 10K 6Gbps SAS 2.5" SFF G2HS SED 32

81Y9670 IBM 300GB 15K 6Gbps SAS 2.5" SFF HS HDD 32

90Y8872 IBM 600GB 10K 6Gbps SAS 2.5" SFF G2HS HDD 32

81Y9650 IBM 900GB 10K 6Gbps SAS 2.5" SFF HS HDD 32

3.5" NL SAS Hot-swap HDDs

90Y8567 IBM 1TB 7.2K 6Gbps NL SAS 3.5" G2HS HDD 8

90Y8572 IBM 2TB 7.2K 6Gbps NL SAS 3.5" G2HS HDD 8

90Y8577 IBM 3TB 7.2K 6Gbps NL SAS 3.5" G2HS HDD 8

3.5" NL SATA Hot-swap HDDs

81Y9786 IBM 500GB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 8

81Y9790 IBM 1TB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 8

81Y9794 IBM 2TB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 8

81Y9798 IBM 3TB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 8

3.5" NL SATA Simple-Swap HDDs

81Y9802 IBM 500GB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8

81Y9806 IBM 1TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8

81Y9810 IBM 2TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8

81Y9814 IBM 3TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8

IBM System x3500 M4 15

Internal backup units

The server supports the internal tape drive options listed in the following table.

Table 9. Internal tape drives

Part number

46C5364 IBM RDX Removable Hard Disk System - Internal USB 160 GB Bundle 1

46C5387 IBM RDX Removable Hard Disk System - Internal USB 320 GB Bundle 1

46C5388 IBM RDX Removable Hard Disk System - Internal USB 500 GB Bundle 1

46C5399 IBM DDS Generation 5 USB Tape Drive 1

39M5636 IBM DDS Generation 6 USB Tape Drive 1

43W8478 IBM Half High LTO Gen 3 SAS Tape Drive 2*

44E8895 IBM Half High LTO Gen 4 SAS Tape Drive 2*

49Y9898 IBM Half High LTO Gen 5 Internal SAS Tape Drive 2*

* Note: With standard models, installation of a second tape drive requires removal of DVD-ROM.

Description Maximum quantity

supported

USB tape drives are attached to the internal USB connector. SAS tape drives require SAS HBA (sold separately). See Table 13 for list of available SAS HBAs.

For more information, see the following at-a-glance guides:

IBM RDX Removable Disk Backup Solution

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0726.html?Open

IBM DDS Generation 5 USB Tape Drive

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0755.html?Open

IBM DDS Generation 6 USB Tape Drive

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0725.html?Open

Optical drives

The server supports the optical drive options listed in the following table.

Table 10. Optical drives

Part number Description Maximum

None* Half-High SATA DVD-ROM 2 A2x, B2x, C2x, C4x, D2x, F2x,

81Y6404 Half-High SATA Multiburner 2 -

* This option is only available via CTO or is already installed in standard models.

The two half-high drives in the table can be installed in any open 5.25" drive bay (Figure 5).

IBM System x3500 M4 16

quantity supported

Standard models where used

G2x, H2x, J2x

Half-High SATA DVD-ROM supports the following media and speeds for reading:

CD-ROM 48X

CD-DA (DAE) 40X

CD-R 48X

CD-RW 40X

DVD-ROM (single layer) 16X

DVD-ROM (dual layer) 12X

DVD-R (4.7 GB) 16X

DVD-R DL 12X

DVD+R 16X

DVD+R DL 12X

DVD-RW (4.7 GB) 12X

DVD+RW 12X

DVD-RAM (4.7/9.4 GB) 6X

Half-High SATA multiburner supports the same media and speeds for reading as HH DVD-ROM. In addition, this drive supports the following media and speeds for writing:

CD-R 24X

CD-RW 4X

High Speed CD-RW 10X

Ultra Speed CD-RW 16X

DVD-R 8X

DVD-R DL 8X

DVD+R 8X

DVD+R DL 8X

DVD-RW 6X

DVD+RW 8X

DVD-RAM 3X

I/O expansion options

The server supports up to eight PCIe slots: six slots (1 to 6) when one CPU is installed or eight slots when two CPUs are installed. These are the slot form factors:

Slot 1: PCIe x8 (x4 wired); full-height, half-length (supports optional PCI-X interposer card)

Slot 2: PCIe x8; full-height, half-length

Slot 3: PCIe x8; full-height, full-length

Slot 4: PCIe x8 (x4 wired); full-height, full-length

Slot 5: PCIe x16; full-height, full-length

Slot 6: PCIe x8 (x4 wired); full-height, full-length

Slot 7: PCIe x16; full-height, full-length (requires second processor)

Slot 8: PCIe x16; full-height, full-length (requires second processor)

All PCIe slots are PCI Express 3.0 slots except Slot 1, which is a PCI Express 2.0 slot. Slot 1 can be converted to a PCI-X slot with the PCI-X Conversion Kit, which is described in the following table.

Table 11. PCI riser card options

Part number Description Maximum quantity

supported

81Y7012 PCI-X Interposer Conversion Kit 1

IBM System x3500 M4 17

Network adapters

x3500 M4 supports four integrated Gigabit Ethernet ports.

Integrated NICs have the following features:

Intel I350AM4 chip

Four GbE ports

TCP Offload Engine (TOE) support

Wake on LAN support

802.1Q VLAN tagging support

NIC Teaming (load balancing and failover)

The following table lists additional supported network adapters.

Table 12. Network adapters

Part number Description Maximum quantity

supported†

10 Gb Ethernet

49Y7910 Broadcom NetXtreme II Dual Port 10GBase-T Adapter for IBM System x 8

95Y3762 Emulex Dual Port 10GbE SFP+ VFA III for IBM System x 8

SBB 95Y3768# Emulex Dual Port 10GbE SFP+ Integrated VFA III for IBM System x 1

95Y3760 Emulex VFA III FCoE/iSCSI License for IBM System x 8*

49Y7960 Intel X520-DA2 Dual Port 10GbE SFP+ Adapter for IBM System x 8

Converged Network Adapters (CNA)

42C1800 QLogic 10 Gb Dual Port CNA for IBM System x 8**

42C1820 Brocade 10 Gb Dual-port CNA for IBM System x 8**

Gigabit Ethernet

39Y6066 NetXtreme II 1000 Express Ethernet Adapter 8

42C1780 NetXtreme II 1000 Express Dual Port Ethernet Adapter 8

49Y4220 NetXtreme II 1000 Express Quad Port Ethernet Adapter 8

42C1750 PRO/1000 PF Server Adapter by Intel 8

49Y4230 Intel Ethernet Dual Port Server Adapter I340-T2 for IBM System x 8

49Y4240 Intel Ethernet Quad Port Server Adapter I340-T4 for IBM System x 8

90Y9352 Broadcom NetXtreme I Quad Port GbE Adapter for IBM System x 8

90Y9370 Broadcom NetXtreme I Dual Port GbE Adapter for IBM System x 8

† The maximum quantity is achieved with two processors installed. With one processor, the maximum quantity is

limited to six. # Emulex Dual Port 10GbE SFP+ Integrated VFA III is only available through CTO or Special Bid. * One license per one Emulex Dual Port 10GbE VFA III (95Y3762) or Emulex Dual Port 10GbE Integrated VFA III (SBB 95Y3768). ** Converged Network Adapters require SFP+ optical transceivers or DAC cables that must be purchased separately.

IBM System x3500 M4 18

Storage host bus adapters

The following table lists storage HBAs supported by the x3500 M4 server.

Table 13. Storage adapters

Part number Description Maximum quantity

supported

Fibre Channel

39R6525 QLogic 4 Gb FC Single-Port PCIe HBA for IBM System x 8

39R6527 QLogic 4 Gb FC Dual-Port PCIe HBA for IBM System x 8

42C2069 Emulex 4 Gbps FC Single-Port PCI-e HBA for IBM System x 8

42C2071 Emulex 4 Gbps FC Dual-Port PCI-e HBA for IBM System x 8

42D0485 Emulex 8 Gb FC Single-port HBA for IBM System x 8

42D0494 Emulex 8 Gb FC Dual-port HBA for IBM System x 8

42D0501 QLogic 8 Gb FC Single-port HBA for IBM System x 8

42D0510 QLogic 8 Gb FC Dual-port HBA for IBM System x 8

46M6049 Brocade 8 Gb FC Single-port HBA for IBM System x 8

46M6050 Brocade 8 Gb FC Dual-port HBA for IBM System x 8

59Y1987 Brocade 4 Gb FC Single-port HBA for IBM System x 8

59Y1993 Brocade 4 Gb FC Dual-port HBA for IBM System x 8

SAS

46M0907 IBM 6 Gb SAS HBA Controller 8

PCIe SSD adapters

Currently, the server does not support High IOPS SSD adapters.

IBM System x3500 M4 19

Power supplies and redundant cooling

The server supports up to two redundant power supplies. Standard models come with one or two power supplies (model dependent). The server also comes standard with either two (for models with one processor installed) or three (for models with two processors installed) simple swap cooling fans. Optional upgrade is available to provide N+N cooling redundancy. The following table lists the power supplies and redundant cooling upgrade option.

Table 14. Power supplies

Part number

94Y5973 IBM System x 750W High Efficiency Platinum AC

94Y5974 IBM System x 900W High Efficiency Platinum AC

81Y7007 Redundant Cooling Upgrade Kit 1 -

Description Max quantity

supported

2 A2x, B2x, C2x, C4x, D2x, F2x

Power Supply

2 G2x, H2x, J2x

Power Supply

Standard models where used

An AC power supply ships standard with one 2.8 m line cord (country specific). The redundant cooling kit contains three simple swap fans.

Integrated virtualization

The server supports VMware ESXi installed on a USB memory key. The key is installed in a USB socket inside the server. The following table lists the virtualization options.

Table 15. Virtualization options

Part number Description Maximum quantity

supported

41Y8298 IBM Blank USB Memory Key for VMware ESXi Downloads 1

41Y8300 IBM USB Memory Key for VMware vSphere 5.0 1

Remote management

The server contains IBM Integrated Management Module II (IMM2), which provides advanced service-processor control, monitoring, and an alerting function. If an environmental condition exceeds a threshold or if a system component fails, the IMM2 lights LEDs to help you diagnose the problem, records the error in the event log, and alerts you to the problem. Optionally, the IMM2 also provides a virtual presence capability for remote server management capabilities.

The IMM2 provides remote server management through industry-standard interfaces:

Intelligent Platform Management Interface (IPMI) Version 2.0

Simple Network Management Protocol (SNMP) Version 3

Common Information Model (CIM)

Web browser

IBM System x3500 M4 20

The optional IMM Advanced Upgrade (software feature) is required to enable the remote presence and

blue-screen capture features. The remote presence feature provides the following functions:

Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz with up to 23 bits per pixel color depths, regardless of the system state

Remotely accessing the server using the keyboard and mouse from a remote client

Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote client, and mapping ISO and diskette image files as virtual drives that are available for use by the server

Uploading a diskette image to the IMM memory and mapping it to the server as a virtual drive

The blue-screen capture feature captures the video display contents before the IMM restarts the server

when the IMM detects an operating-system hang condition. A system administrator can use the

blue-screen capture to assist in determining the cause of the hang condition. The following table lists the

remote management option.

Table 16. Remote management option

Part number Description Maximum quantity supported

90Y3901 IBM Integrated Management Module

Advanced Upgrade

Supported operating systems

The server supports the following operating systems:

Microsoft Windows Server 2008 R2

Microsoft Windows Server 2008, Datacenter x64 Edition

Microsoft Windows Server 2008, Datacenter x86 Edition

Microsoft Windows Server 2008, Enterprise x64 Edition

Microsoft Windows Server 2008, Enterprise x86 Edition

Microsoft Windows Server 2008, Standard x64 Edition

Microsoft Windows Server 2008, Standard x86 Edition

Microsoft Windows Server 2008, Web x64 Edition

Microsoft Windows Server 2008, Web x86 Edition

Microsoft Windows Small Business Server 2008 Premium Edition

Microsoft Windows Small Business Server 2008 Standard Edition

Red Hat Enterprise Linux 5 Server with Xen x64 Edition

Red Hat Enterprise Linux 5 Server x64 Edition

Red Hat Enterprise Linux 6 Server Edition

Red Hat Enterprise Linux 6 Server x64 Edition

SUSE LINUX Enterprise Server 10 for AMD64/EM64T

SUSE LINUX Enterprise Server 10 with Xen for AMD64/EM64T

SUSE LINUX Enterprise Server 11 for AMD64/EM64T

SUSE LINUX Enterprise Server 11 with Xen for AMD64/EM64T

VMware vSphere 5

See the IBM ServerProven® website for the latest information about the specific versions and service

levels supported and any other prerequisites:

http://www.ibm.com/systems/info/x86servers/serverproven/compat/us/nos/matrix.shtml

IBM System x3500 M4 21

Physical and electrical specifications

Dimensions and weight (approximate):

Tower:

Width: 218 mm (8.6 in)

Depth: 750 mm (29.5 in)

Height: 440 mm (17.3 in)

Weight:

Minimum configuration: 25.0 kg (55.1 lb)

Maximum configuration: 39.8 kg (87.7 lb)

Rack (using the Tower-to-Rack Conversion Kit, 81Y7006):

Width: 424 mm (16.7 in)

Depth: 702 mm (27.6 in)

Height: 218 mm (8.5 in)

Weight:

24.5 kg (53.9 lb) (minimum configuration)

39.3 kg (86.6 lb) (maximum configuration)

Supported environment:

Air temperature

Server on: 10 - 35 °C (50 to 95 °F); altitude: 0 - 915 m (3,000 ft)

Server on: 10 - 32 °C (50 - 90 °F); altitude: 915 m (3,000 ft) - 2,134 m (7,000 ft)

Server on: 10 - 28 °C (50 - 83 °F); altitude: 2,134 m (7,000 ft) - 3,050 m (10,000 ft)

Server off (with standby power): 5 - 45 °C (41.0 - 113 °F)

Shipping: -40 - 60 °C (-40 - 140 °F)

Humidity

Server on: 20 - 80% , Max. Dew Point 21 °C, Max. rate of change 5 °C/hr

Server off: 8 - 80%, Max. Dew Point 27 °C

Electrical

Models with 900 W power supplies:

100 to 127 (nominal) V ac; 50 Hz or 60 Hz; 11 A

200 to 240 (nominal) V ac; 50 Hz or 60 Hz; 5.5 A

Input kilovolt-amperes (kVA) (approximately):

Minimum configuration: 0.6 kVA

Maximum configuration: 1.1 kVA

Models with 750 W power supplies:

100 to 127 (nominal) V ac; 50 Hz or 60 Hz; 8.9 A

200 to 240 (nominal) V ac; 50 Hz or 60 Hz; 4.5 A

Input kilovolt-amperes (kVA) (approximately):

Minimum configuration: 0.6 kVA

Maximum configuration: 0.9 kVA

BTU output

Minimum configuration: 2013 Btu/hr (590 watts)

Maximum configuration: 3610 Btu/hr (1056 watts)

IBM System x3500 M4 22

Warranty options

The IBM System x3500 M4 has a 3-year onsite warranty with 9x5/next business day terms. IBM offers the warranty service upgrades through IBM ServicePacs, discussed in this section. The IBM ServicePac is a series of prepackaged warranty maintenance upgrades and post-warranty maintenance agreements with a well-defined scope of services, including service hours, response time, term of service, and service agreement terms and conditions.

IBM ServicePac offerings are country-specific. That is, each country might have its own service types, service levels, response times, and terms and conditions. Not all covered types of ServicePacs might be available in a particular country. For more information about IBM ServicePac offerings available in your country visit the IBM ServicePac Product Selector at:

https://www-304.ibm.com/sales/gss/download/spst/servicepac

The following table explains warranty service definitions in more detail.

Table 17. Warranty service definitions

Term Description

IBM onsite repair (IOR)

24x7x2 hour A service technician is scheduled to arrive at your customer’s location within two hours after remote

24x7x4 hour A service technician is scheduled to arrive at your customer’s location within four hours after remote

9x5x4 hour A service technician is scheduled to arrive at your customer’s location within four business hours

9x5 next business day

A service technician will come to the server's location for equipment repair.

problem determination is completed. We provide service around the clock, every day, including IBM holidays.

after remote problem determination is completed. We provide service from 8:00 a.m. to 5:00 p.m. in the customer's local time zone, Monday through Friday, excluding IBM holidays. If after 1:00 p.m. it is determined that onsite service is required, the customer can expect the service technician to arrive the morning of the following business day. For noncritical service requests, a service technician will arrive by the end of the following business day.

A service technician is scheduled to arrive at your customer’s location on the business day after we receive your call, following remote problem determination. We provide service from 8:00 a.m. to 5:00 p.m. in the customer's local time zone, Monday through Friday, excluding IBM holidays.

IBM System x3500 M4 23

In general, the types of IBM ServicePacs are as follows:

Warranty and maintenance service upgrades

One, 2, 3, 4, or 5 years of 9x5 or 24x7 service coverage

Onsite repair from next business day to 4 or 2 hours

One or 2 years of warranty extension

Remote technical support services

One or three years with 24x7 coverage (severity 1) or 9x5/next business day for all severities

Installation and startup support for System x servers

Remote technical support for System x servers

Software support - Support Line

Microsoft or Linux software

VMware

IBM Director

Regulatory compliance

The server conforms to the following standards:

FCC - Verified to comply with Part 15 of the FCC Rules, Class A

Canada ICES-003, issue 4, Class A

UL/IEC 60950-1

CSA C22.2 No. 60950-1-07

NOM-019

Argentina IEC60950-1

Japan VCCI, Class A

Australia/New Zealand AS/NZS CISPR 22:2006, Class A

IEC-60950-1 (CB Certificate and CB Test Report)

Taiwan BSMI CNS13438, Class A; CNS14336-1

China CCC (GB4943-2001), GB9254-2008 class A, GB17625.1-2003

Korea KN22, Class A; KN24

CE Mark (EN55022 Class A, EN60950-1, EN55024, EN61000-3-2, and EN61000-3-3)

CISPR 22, Class A

TUV-GS EN60950-1 /IEC60950-1,EK1-ITB2000)

Russia/GOST ME01, IEC-60950-1, GOST R 51318.22-99, GOST R 51318.24-99, GOST R

51317.3.2-99, GOST R 51317.3.3-99

IEC 60950-1 (CB Certificate and CB Test Report)

External disk storage expansion

Currently, IBM x3500 M4 does not support external storage expansion like the EXP2500 series. It can be attached to the supported external storage system shown in Table 18, using the supported HBAs listed in Table 13.

IBM System x3500 M4 24

External disk storage systems

Table 18 lists the external storage systems that are supported by x3500 M4 and can be ordered through the System x sales channel. The server might support other IBM disk systems that are not listed in this table. Refer to IBM System Storage® Interoperability Center for further information.

Table 18. External disk storage systems

Part number Description

1746A2D IBM System Storage DS3512 Express Dual Controller Storage System

1746A2S IBM System Storage DS3512 Express Single Controller Storage System

1746A4D IBM System Storage DS3524 Express Dual Controller Storage System

1746A4S IBM System Storage DS3524 Express Single Controller Storage System

181494H IBM System Storage DS3950 Model 94

181498H IBM System Storage DS3950 Model 98

181492H IBM System Storage EXP395 Expansion Unit

1746A2E IBM System Storage EXP3512 Express Storage™ Expansion Unit

1746A4E IBM System Storage EXP3524 Express Storage Expansion Unit

IBM System x3500 M4 25

External backup units

The server supports the external backup attachment options listed in Table 19.

Table 19. External backup options (part 1)

Part number Description

External tape expansion enclosures for internal tape drives

87651UX 1U Tape Drive Enclosure

8767HHX Half High Tape Drive Enclosure

87651NX 1U Tape Drive Enclosure (with Nema 5-15P LineCord)

8767HNX Half High Tape Drive Enclosure (with Nema 5-15P LineCord)

Tape enclosure adapters (with cables)

44E8869 USB Enclosure Adapter Kit

40K2599 SAS Enclosure Adapter Kit

Internal backup drives supported by external tape enclosures

46C5364 IBM RDX Removable Hard Disk Storage System - Internal USB 160 GB Bundle

46C5387 IBM RDX Removable Hard Disk Storage System - Internal USB 320 GB Bundle

46C5388 IBM RDX Removable Hard Disk Storage System - Internal USB 500 GB Bundle

46C5399 IBM DDS Generation 5 USB Tape Drive

39M5636 IBM DDS Generation 6 USB Tape Drive

43W8478 IBM Half High LTO Gen 3 SAS Tape Drive

44E8895 IBM Half High LTO Gen 4 SAS Tape Drive

49Y9898 IBM Half High LTO Gen 5 Internal SAS Tape Drive

IBM System x3500 M4 26

Table 19. External backup options (part 2)

Part number Description

External backup units*

362516X IBM RDX Removable Hard Disk Storage System - External USB 160 GB Bundle

362532X IBM RDX Removable Hard Disk Storage System - External USB 320 GB Bundle

362550X IBM RDX Removable Hard Disk Storage System - External USB 500 GB Bundle

3628L3X IBM Half High LTO Gen 3 External SAS Tape Drive (with US line cord)

3628L4X IBM Half High LTO Gen 4 External SAS Tape Drive (with US line cord)

3628L5X IBM Half High LTO Gen 5 External SAS Tape Drive (with US line cord)

3628N3X IBM Half High LTO Gen 3 External SAS Tape Drive (without line cord)

3628N4X IBM Half High LTO Gen 4 External SAS Tape Drive (without line cord)

3628N5X IBM Half High LTO Gen 5 External SAS Tape Drive (without line cord)

3580S3V System Storage TS2230 Tape Drive Express Model H3V

3580S4V System Storage TS2240 Tape Drive Express Model H4V

3580S5E System Storage TS2250 Tape Drive Express Model H5S

3580S5X System Storage TS2350 Tape Drive Express Model S53

3572S4R TS2900 Tape Library with LTO4 HH SAS drive & rack mount kit

3572S5R TS2900 Tape Library with LTO5 HH SAS drive & rack mount kit

35732UL TS3100 Tape Library Model L2U Driveless

35734UL TS3200 Tape Library Model L4U Driveless

46X2682† LTO Ultrium 5 Fibre Channel Drive

46X2683† LTO Ultrium 5 SAS Drive Sled

46X2684† LTO Ultrium 5 Half High Fibre Drive Sled

46X2685† LTO Ultrium 5 Half High SAS Drive Sled

46X6912† LTO Ultrium 4 Half High Fibre Channel Drive Sled

46X7117† LTO Ultrium 4 Half High SAS DriveV2 Sled

46X7122† LTO Ultrium 3 Half High SAS DriveV2 Sled

* Note: The external tape drives listed can be ordered through the System x sales channel. The server might support other IBM tape drives that are not listed in this table. Refer to IBM System Storage Interoperability Center for further information.

† Note: These part numbers are the tape drives options for 35732UL and 35734UL.

External USB tape drives are connected to the external USB ports on the server. External SAS or Fibre Channel tape drives require respective HBA (sold separately, see Table 14).

See the IBM ServerProven website for the latest information about the specific versions and service levels

supported and any other prerequisites:

http://www.ibm.com/systems/info/x86servers/serverproven/compat/us/nos/matrix.shtml

IBM System x3500 M4 27

Top-of-rack Ethernet switches

The server supports the top-of-rack Ethernet switches from IBM System Networking listed in the following

table.

Table 20. IBM System Networking: Top-of-rack switches

Part number Description

IBM System Networking - 1 Gb top-of-rack switches 0446013 IBM System Networking RackSwitch G8000R 7309CFC IBM System Networking RackSwitch G8000F 7309CD8 IBM System Networking RackSwitch G8000DC 7309G52 IBM System Networking RackSwitch G8052R 730952F IBM System Networking RackSwitch G8052F 427348E IBM Ethernet Switch J48E 6630010 Juniper Networks EX2200 24 Port 6630011 Juniper Networks EX2200 24 Port with PoE 6630012 Juniper Networks EX2200 48 Port 6630013 Juniper Networks EX2200 48 Port with PoE IBM System Networking - 10 Gb top-of-rack switches 0446017 IBM System Networking RackSwitch G8124R 7309BF9 IBM System Networking RackSwitch G8124F 7309BD5 IBM System Networking RackSwitch G8124DC 7309BR6 IBM System Networking RackSwitch G8124ER 7309BF7 IBM System Networking RackSwitch G8124EF 7309G64 IBM System Networking RackSwitch G8264R 730964F IBM System Networking RackSwitch G8264F 7309-CR9 IBM System Networking RackSwitch G8264TR 7309-CF9 IBM System Networking RackSwitch G8264TF 0719-410 Juniper Networks EX4500 - Front to Back Airflow 0719-420 Juniper Networks EX4500 - Back to Front Airflow IBM System Networking - 40 Gb top-of-rack switches 8036AR 8036AFX IBM System Networking RackSwitch G8316F

IBM System Networking RackSwitch G8316R

IBM System x3500 M4 28

Uninterruptible power supply units

The server supports attachments to the uninterruptible power supply (UPS) units listed in the following table.

Table 21. Uninterruptible power supply units

Part number Description

Tower UPS

53961AX IBM 1000VA LCD Tower UPS (120V)

53961JX IBM 1000VA LCD Tower UPS (100V)

53961KX IBM 1000VA LCD Tower UPS (230V)

53962AX IBM 1500VA LCD Tower UPS (120V)

53962JX IBM 1500VA LCD Tower UPS (100V)

53962KX IBM 1500VA LCD Tower UPS (230V)

Rack-mounted UPS

21304RX IBM UPS 10000XHV

53951AX IBM 1500VA LCD 2U Rack UPS (100V/120V)

53951KX IBM 1500VA LCD 2U Rack UPS (230V)

53952AX IBM 2200VA LCD 2U Rack UPS (100V/120V)

53952KX IBM 2200VA LCD 2U Rack UPS (230V)

53953AX IBM 3000VA LCD 3U Rack UPS (100V/120V)

53953JX IBM 3000VA LCD 3U Rack UPS (200V/208V)

53956AX IBM 6000VA LCD 4U Rack UPS (200V/208V)

53956KX IBM 6000VA LCD 4U Rack UPS (230V)

53959KX IBM 11000VA LCD 5U Rack UPS (200V/208V/230V)

For more information, see the following at-a-glance guides:

IBM 3000VA LCD 3U Rack Uninterruptible Power Supply for IBM System x

http://www.redbooks.ibm.com/abstracts/tips0782.html?Open

IBM 6000VA LCD 4U Rack UPS

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0793.html?Open

at-a-glance guide

IBM System x3500 M4 29

Power distribution units

The server supports attachments to the power distribution units (PDUs) listed in the following table.

Table 22. Power distribution units (part 1)

Part number Description

Switched and Monitored PDUs

46M4002 IBM 1U 9 C19/3 C13 Active Energy Manager DPI® PDU

46M4003 IBM 1U 9 C19/3 C13 Active Energy Manager 60A 3 Phase PDU

46M4004 IBM 1U 12 C13 Active Energy Manager DPI PDU

46M4005 IBM 1U 12 C13 Active Energy Manager 60A 3 Phase PDU

46M4167 IBM 1U 9 C19/3 C13 Switched and Monitored 30A 3 Phase PDU

46M4116 IBM 0U 24 C13 Switched and Monitored 30A PDU

46M4119 IBM 0U 24 C13 Switched and Monitored 32A PDU

46M4134 IBM 0U 12 C19/12 C13 Switched and Monitored 50A 3 Phase PDU

46M4137 IBM 0U 12 C19/12 C13 Switched and Monitored 32A 3 Phase PDU

Enterprise PDUs

71762MX IBM Ultra Density Enterprise PDU C19 PDU+ (WW)

71762NX IBM Ultra Density Enterprise PDU C19 PDU (WW)

71763MU IBM Ultra Density Enterprise PDU C19 3 Phase 60A PDU+ (NA)

71763NU IBM Ultra Density Enterprise PDU C19 3 Phase 60A PDU (NA)

39M2816 IBM DPI C13 Enterprise PDU without linecord

39Y8923 DPI 60A Three Phase C19 Enterprise PDU with IEC309 3P+G (208 V) fixed line cord

39Y8941 DPI Single Phase C13 Enterprise PDU without line cord

39Y8948 DPI Single Phase C19 Enterprise PDU without line cord

Front-end PDUs

39Y8934 DPI 32 amp/250 V Front-end PDU with IEC 309 2P+Gnd connector

39Y8935 DPI 63amp/250 V Front-end PDU with IEC 309 2P+Gnd connector

39Y8938 30 amp/125 V Front-end PDU with NEMA L5-30P connector

39Y8939 30 amp/250 V Front-end PDU with NEMA L6-30P connector

39Y8940 60 amp/250 V Front-end PDU with IEC 309 60A 2P+N+Gnd connector

IBM System x3500 M4 30

Table 22. Power distribution units (part 2)

Part number Description

Universal PDUs

39Y8951 DPI Universal Rack PDU with US LV and HV line cords

39Y8952 DPI Universal Rack PDU with CEE7-VII Europe LC

39Y8953 DPI Universal Rack PDU with Denmark LC

39Y8954 DPI Universal Rack PDU with Israel LC

39Y8955 DPI Universal Rack PDU with Italy LC

39Y8956 DPI Universal Rack PDU with South Africa LC

39Y8957 DPI Universal Rack PDU with UK LC

39Y8958 DPI Universal Rack PDU with AS/NZ LC

39Y8959 DPI Universal Rack PDU with China LC

39Y8962 DPI Universal Rack PDU (Argentina)

39Y8960 DPI Universal Rack PDU (Brazil)

39Y8961 DPI Universal Rack PDU (India)

0U Basic PDUs

46M4122 IBM 0U 24 C13 16A 3 Phase PDU

46M4125 IBM 0U 24 C13 30A 3 Phase PDU

46M4128 IBM 0U 24 C13 30A PDU

46M4131 IBM 0U 24 C13 32A PDU

46M4140 IBM 0U 12 C19/12 C13 60A 3 Phase PDU

46M4143 IBM 0U 12 C19/12 C13 32A 3 Phase PDU

For more information, see the

IBM 1U Switched and Monitored Power Distribution Units

at: http://www.redbooks.ibm.com/abstracts/tips0775.html?Open

at-a-glance guide

IBM System x3500 M4 31

Rack cabinets

The x3500 M4 server can be installed in the rack with the Tower to Rack Conversion Kit (81Y7006). The server supports the rack cabinets listed in the following table.

Table 23. Rack cabinets and Tower to Rack Conversion Kits

Part number Description

Tower to rack conversion kits

81Y7006 Tower to Rack Conversion Kit

Rack cabinets

201886X IBM 11U Office Enablement Kit

93072PX IBM 25U Static S2 Standard Rack

93072RX IBM 25U Standard Rack

93074RX IBM 42U Standard Rack

93074XX IBM 42U Standard Rack Extension

93084EX IBM 42U Enterprise Expansion Rack

93084PX IBM 42U Enterprise Rack

93604EX IBM 42U 1200 mm Deep Dynamic Expansion Rack

93604PX IBM 42U 1200 mm Deep Dynamic Rack

93614EX IBM 42U 1200 mm Deep Static Expansion Rack

93614PX IBM 42U 1200 mm Deep Static Rack

93624EX IBM 47U 1200 mm Deep Static Expansion Rack

93624PX IBM 47U 1200 mm Deep Static Rack

99564RX IBM S2 42U Dynamic Standard Rack

99564XX IBM S2 42U Dynamic Standard Expansion Rack

IBM System x3500 M4 32

Figure 6 shows the server installed in the Tower to Rack Conversion Kit.

Figure 6. The IBM System x3550 M4 with the Tower to Rack Conversion Kit

Rack options

The server supports the rack console switches and monitor kits listed in the following table.

Table 24. Rack options

Part number Description

Monitor kits and keyboard trays

172317X 1U 17in Flat Panel Console Kit

172319X

Console switches

1754D2X IBM Global 4x2x32 Console Manager (GCM32)

1754D1X IBM Global 2x2x16 Console Manager (GCM16)

1754A2X IBM Local 2x16 Console Manager (LCM16)

1754A1X IBM Local 1x8 Console Manager (LCM8)

Console cables

43V6147 IBM Single Cable USB Conversion Option (UCO)

39M2895 IBM USB Conversion Option (4 Pack UCO)

39M2897 IBM Long KVM Conversion Option (4 Pack Long KCO)

46M5383 IBM Virtual Media Conversion Option Gen2 (VCO2)

1U 19in Flat Panel Console Kit

46M5382 IBM Serial Conversion Option (SCO)

IBM System x3500 M4 33

For more information, see the following IBM Redbooks® at-a-glance guides:

IBM 1754 LCM8 and LCM16 Local Console Managers

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0788.html?Open

IBM GCM16 and GCM32 Global Console Managers

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0772.html?Open

IBM 1U 17-inch and 19-inch Flat Panel Console Kits

at-a-glance guide

http://www.redbooks.ibm.com/abstracts/tips0731.html?Open

IBM System x3500 M4, X3500 M4 Product Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
