ThinkPad SL400 an d SL500 Hardw are Maintenance Manual

Note

Before using this information and the product it supports, be sure to read the general information under “Notices” on page

207.

LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.

LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are delivered pursuant a General Services Administration ″GSA″ contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

About this manual . . . . . . . . . .v

Safety information . . . . . . . . . .1

General safety . . . . . . . . . . . . . .2

Electrical safety . . . . . . . . . . . . .3

Safety inspection guide . . . . . . . . . . .5

Handling devices that are sensitive to electrostatic

discharge . . . . . . . . . . . . . . .6

Grounding requirements . . . . . . . . . .6

Safety notices: multilingual translations . . . . .7

Laser compliance statement . . . . . . . . .14

Important service information . . . . .17

Strategy for replacing FRUs . . . . . . . . .17

Strategy for replacing a hard disk drive . . . .18

Important notice for replacing a system board . .18

How to use error message . . . . . . . .18

Strategy for replacing FRUs for CTO, CMV, and

GAV . . . . . . . . . . . . . . . . .19

Product definition . . . . . . . . . . .19

FRU identification for CTO, CMV, and GAV

products . . . . . . . . . . . . . .19

Important information about replacing RoHS

compliant FRUs . . . . . . . . . . . . .21

General checkout . . . . . . . . . .23

What to do first . . . . . . . . . . . . .24

Checkout guide . . . . . . . . . . . . .25

Diagnostics using PC-Doctor for DOS . . . .26

PC-Doctor for Windows . . . . . . . . .28

PC-Doctor for Rescue and Recovery . . . . .28

Power system checkout . . . . . . . . . .29

Checking the AC adapter . . . . . . . . .29

Checking operational charging . . . . . . .30

Checking the battery pack . . . . . . . .30

Checking the backup battery . . . . . . .31

Related service information . . . . . .33

Restoring the factory contents by using Product

Recovery discs . . . . . . . . . . . . .33

Passwords . . . . . . . . . . . . . . .34

Power-on password . . . . . . . . . .34

Hard-disk password . . . . . . . . . .34

Supervisor password . . . . . . . . . .34

How to remove the power-on password . . . .35

How to remove the hard-disk password . . . .35

Power management . . . . . . . . . . .37

Screen blank mode . . . . . . . . . . .37

Standby mode . . . . . . . . . . . .37

Hibernation mode . . . . . . . . . . .38

Symptom-to-FRU index . . . . . . . . . .39

Numeric error codes . . . . . . . . . .39

Error messages . . . . . . . . . . . .44

Beep symptoms . . . . . . . . . . . .45

No-beep symptoms . . . . . . . . . . .45

LCD-related symptoms . . . . . . . . .46

Intermittent problems . . . . . . . . . .47

Undetermined problems . . . . . . . . .47

ThinkPad SL400 and SL500 . . . . . .49

Specifications . . . . . . . . . . . . . .49

Status indicators . . . . . . . . . . . . .52

FRU tests . . . . . . . . . . . . . . .54

Fn key combinations . . . . . . . . . . .56

FRU replacement notices . . . . . . . . . .58

Screw notices . . . . . . . . . . . . .58

Retaining serial numbers . . . . . . . . .59

Removing and replacing a FRU . . . . . . . .62

1010 Battery pack . . . . . . . . . . .63

1020 Optical drive . . . . . . . . . . .64

1030 Hard disk drive (HDD) cover and HDD . .65 1040 DIMM slot cover (for ThinkPad SL400) . .67 1050 DIMM slot cover (for ThinkPad SL500) . .67

1060 DIMM . . . . . . . . . . . . .68

1070 PCI Express Mini Card for wireless

LAN/WiMAX . . . . . . . . . . . .69

1080 PCI Express Mini Card for wireless WAN

(for ThinkPad SL400) . . . . . . . . . .72

1090 Wireless WAN slot cover and PCI Express Mini Card for wireless WAN (for ThinkPad

SL500) . . . . . . . . . . . . . . .74

1100 Thermal door (for ThinkPad SL400) . . .76 1110 Thermal door (for ThinkPad SL500) . . .77

1120 Fan assembly . . . . . . . . . . .78

1130 CPU thermal module . . . . . . . .81

1140 CPU . . . . . . . . . . . . . .83

1150 Palm rest (for ThinkPad SL400) . . . . .84

1160 Palm rest (for ThinkPad SL500) . . . . .86

1170 Bluetooth daughter card (BDC-2.1) . . . .88

1180 Intel Turbo Memory Minicard or Wireless

USB adapter . . . . . . . . . . . . .89

1190 Backup battery (for ThinkPad SL400) . . .91 1200 Backup battery (for ThinkPad SL500) . . .92

1210 Keyboard . . . . . . . . . . . .93

1220 To p case sub assembly (for ThinkPad SL400) 95 1230 To p case sub assembly (for ThinkPad SL500) 97

1240 LCD unit (for ThinkPad SL400) . . . . 100

1250 LCD unit (for ThinkPad SL500) . . . . 105

1260 Frame L (magnesium frame assembly) . . 109 1270 SATA-ODD connector boardThinkPad

SL500) . . . . . . . . . . . . . . . 111

1280 System board . . . . . . . . . . .112

1290 I/O board and I/O board FPC (for

ThinkPad SL400) . . . . . . . . . . .116

1300 Small board (for ThinkPad SL400) . . . .118

1310 Frame R (magnesium frame assembly), DC-in connector, and base cover (for ThinkPad

SL400) . . . . . . . . . . . . . . . 120

1320 Frame R (magnesium frame assembly), I/O board, I/O board FPC, DC-in connector, small board, and base cover (for ThinkPad

SL500) . . . . . . . . . . . . . . . 122

2010 LCD front bezel . . . . . . . . . . 125

2020 Inverter card . . . . . . . . . . . 126

2030 Integrated camera . . . . . . . . . 127

2040 Wireless LAN antenna assembly, wireless WAN antenna assembly, and camera cable (for

ThinkPad SL400) . . . . . . . . . . . 128

2050 Wireless LAN antenna assembly. wireless WAN antenna assembly, and camera cable (for

ThinkPad SL500) . . . . . . . . . . . 130

2060 LCD panel, hinge L, hinge R, LCD cable, and LCD rear cover assembly (for ThinkPad

SL400) . . . . . . . . . . . . . . . 132

2070 LCD panel, hinge L, hinge R, LCD cable, and LCD rear cover assembly (for ThinkPad

SL500) . . . . . . . . . . . . . . . 135

Locations . . . . . . . . . . . . . . . 138

Front view (for ThinkPad SL400) . . . . . . 138

Rear view (for ThinkPad SL400) . . . . . . 140

Bottom view (for ThinkPad SL400) . . . . . 141

Front view (for ThinkPad SL500) . . . . . . 142

Rear view (for ThinkPad SL500) . . . . . . 144

Bottom view (for ThinkPad SL500) . . . . . 144

Parts list . . . . . . . . . . . . . . . 145

Overall . . . . . . . . . . . . . . 146

LCD FRUs . . . . . . . . . . . . . 177

Keyboard . . . . . . . . . . . . . . 192

Miscellaneous parts . . . . . . . . . . 193

AC adapters . . . . . . . . . . . . . 194

Power cords . . . . . . . . . . . . . 195

Recovery discs . . . . . . . . . . . . 196

Common service tools . . . . . . . . . 205

Notices . . . . . . . . . . . . . . 207

Trademarks . . . . . . . . . . . . . . 208

iv ThinkPad SL400 and SL500Hardware Maintenance Manual

About this manual

This manual contains service and reference information for the following ThinkPad® products.

ThinkPad SL400

ThinkPad SL500

Use this manual along with the advanced diagnostic tests to troubleshoot

problems.

The manual is divided into sections as follows:

v The common sections provide general information, guidelines, and safety

information required in servicing computers.

v The product-specific section includes service, reference, and product-specific

parts information.

MT 2743

MT 2746

Important:

This manual is intended only for trained servicers who are familiar with ThinkPad products. Use this manual along with the advanced diagnostic tests to troubleshoot problems effectively.

Before servicing a ThinkPad product, be sure to read all the information under “Safety information” on page 1 and “Important service information” on page 17.

vi ThinkPad SL400 and SL500Hardware Maintenance Manual

Safety information

This chapter presents following safety information that you need to be familiar with before you service a ThinkPad computer.

v “General safety” on page 2 v “Electrical safety” on page 3 v “Safety inspection guide” on page 5 v “Handling devices that are sensitive to electrostatic discharge” on page 6 v “Grounding requirements” on page 6 v “Safety notices: multilingual translations” on page 7 v “Laser compliance statement” on page 14

General safety

Follow these rules to ensure general safety:

v Observe good housekeeping in the area of the machines during and after

maintenance.

v When lifting any heavy object:

1. Make sure that you can stand safely without slipping.

2. Distribute the weight of the object equally between your feet.

3. Use a slow lifting force. Never move suddenly or twist when you attempt to

lift.

4. Lift by standing or by pushing up with your leg muscles; this action removes

the strain from the muscles in your back. Do not attempt to lift any object that

weighs more than 16 kg (35 lb) or that you think is too heavy for you.

v Do not perform any action that causes hazards to the customer, or that makes

the equipment unsafe.

v Before you start the machine, make sure that other service representatives and

the customer’s personnel are not in a hazardous position.

v Place removed covers and other parts in a safe place, away from all personnel,

while you are servicing the machine.

v Keep your toolcase away from walk areas so that other people will not trip over

it.

v Do not wear loose clothing that can be trapped in the moving parts of a

machine. Make sure that your sleeves are fastened or rolled up above your elbows. If your hair is long, fasten it.

v Insert the ends of your necktie or scarf inside clothing or fasten it with a

nonconductive clip, about 8 centimeters (3 inches) from the end.

v Do not wear jewelry, chains, metal-frame eyeglasses, or metal fasteners for your

clothing. Attention: Metal objects are good electrical conductors.

v Wear safety glasses when you are hammering, drilling, soldering, cutting wire,

attaching springs, using solvents, or working in any other conditions that might be hazardous to your eyes.

v After service, reinstall all safety shields, guards, labels, and ground wires.

Replace any safety device that is worn or defective.

v Reinstall all covers correctly before returning the machine to the customer.

v Fan louvers on the machine help to prevent overheating of internal components.

Do not obstruct fan louvers or cover them with labels or stickers.

2 ThinkPad SL400 and SL500Hardware Maintenance Manual

Electrical safety

Observe the following rules when working on electrical equipment.

Important:

Use only approved tools and test equipment. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents.

Many customers have, near their equipment, rubber floor mats that contain small conductive fibers to decrease electrostatic discharges. Do not use this type of mat to protect yourself from electrical shock.

v Find the room emergency power-off (EPO) switch, disconnecting switch, or

electrical outlet. If an electrical accident occurs, you can then operate the switch or unplug the power cord quickly.

v Do not work alone under hazardous conditions or near equipment that has

hazardous voltages.

v Disconnect all power before:

– Performing a mechanical inspection – Working near power supplies – Removing or installing main units

v Before you start to work on the machine, unplug the power cord. If you cannot

unplug it, ask the customer to power-off the wall box that supplies power to the machine, and to lock the wall box in the off position.

v If you need to work on a machine that has exposed electrical circuits, observe the

following precautions: – Ensure that another person, familiar with the power-off controls, is near you.

Attention: Another person must be there to switch off the power, if necessary.

– Use only one hand when working with powered-on electrical equipment;

keep the other hand in your pocket or behind your back. Attention: An electrical shock can occur only when there is a complete

circuit. By observing the above rule, you may prevent a current from passing through your body.

– When using testers, set the controls correctly and use the approved probe

leads and accessories for that tester.

– Stand on suitable rubber mats (obtained locally, if necessary) to insulate you

from grounds such as metal floor strips and machine frames.

Observe

the special safety precautions when you work with very high voltages;

Instructions for these precautions are in the safety sections of maintenance information. Use extreme care when measuring high voltages.

v Regularly inspect and maintain your electrical hand tools for safe operational

condition.

v Do not use worn or broken tools and testers.

v Never assume that power has been disconnected from a circuit. First, check that it

has been powered off.

v Always look carefully for possible hazards in your work area. Examples of these

hazards are moist floors, nongrounded power extension cables, power surges, and missing safety grounds.

Safety information 3

v Do not touch live electrical circuits with the reflective surface of a plastic dental

mirror. The surface is conductive; such touching can cause personal injury and machine damage.

v Do not service the following parts with the power on when they are removed

from their normal operating places in a machine: – Power supply units – Pumps – Blowers and fans – Motor generators

and similar units. (This practice ensures correct grounding of the units.)

v If an electrical accident occurs:

– Use caution; do not become a victim yourself. – Switch off power. – Send another person to get medical aid.

4 ThinkPad SL400 and SL500Hardware Maintenance Manual

Safety inspection guide

The purpose of this inspection guide is to assist you in identifying potentially unsafe conditions. As each machine was designed and built, required safety items were installed to protect users and service personnel from injury. This guide addresses only those items. Yo u should use good judgment to identify potential safety hazards due to attachment of non-ThinkPad features or options not covered by this inspection guide.

If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem.

Consider these conditions and the safety hazards they present:

v Electrical hazards, especially primary power (primary voltage on the frame can

cause serious or fatal electrical shock)

v Explosive hazards, such as a damaged CRT face or a bulging capacitor

v Mechanical hazards, such as loose or missing hardware

determine whether there are any potentially unsafe conditions, use the

To following checklist at the beginning of every service task. Begin the checks with the power off, and the power cord disconnected.

Checklist:

1. Check exterior covers for damage (loose, broken, or sharp edges).

2. Power off the computer. Disconnect the power cord.

3. Check the power cord for:

a. A third-wire ground connector in good condition. Use a meter to measure

third-wire ground continuity for 0.1 ohm or less between the external ground pin and the frame ground.

b. The power cord should be the type specified in the parts list.

c. Insulation must not be frayed or worn.

4. Check for cracked or bulging batteries.

5. Remove the cover.

6. Check for any obvious non-ThinkPad alterations. Use good judgment as to the

safety of any non-ThinkPad alterations.

7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

8. Check for worn, frayed, or pinched cables.

9. Check that the power-supply cover fasteners (screws or rivets) have not been

removed or tampered with.

Safety information 5

Handling devices that are sensitive to electrostatic discharge

Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to electrostatic discharge (ESD.) ESD damage can occur when there is a difference in charge between objects. Protect against ESD damage by equalizing the charge so that the machine, the part, the work mat, and the person handling the part are all at the same charge.

Notes:

1. Use product-specific ESD procedures when they exceed the requirements noted here.

2. Make sure that the ESD protective devices you use have been certified (ISO

9000) as fully effective.

When handling ESD-sensitive parts:

v Keep the parts in protective packages until they are inserted into the product.

v Avoid contact with other people.

v Wear a grounded wrist strap against your skin to eliminate static on your body.

v Prevent the part from touching your clothing. Most clothing is insulative and

retains a charge even when you are wearing a wrist strap.

v Use the black side of a grounded work mat to provide a static-free work surface.

The mat is especially useful when handling ESD-sensitive devices.

v Select a grounding system, such as those listed below, to provide protection that

meets the specific service requirement.

Note:

use of a grounding system to guard against ESD damage is desirable but not

The necessary.

– Attach the ESD ground clip to any frame ground, ground braid, or green-wire

ground.

– When working on a double-insulated or battery-operated system, use an ESD

common ground or reference point. Yo u can use coax or connector-outside shells on these systems.

– Use the round ground prong of the ac plug on ac-operated computers.

Grounding requirements

Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician.

6 ThinkPad SL400 and SL500Hardware Maintenance Manual

Safety notices: multilingual translations

The safety notices in this section are provided in English, French, German, Hebrew, Italian, Japanese, and Spanish.

Safety notice 1

Before the computer is powered on after FRU replacement, make sure all screws, springs, and other small parts are in place and are not left loose inside the computer. Verify this by shaking the computer and listening for rattling sounds. Metallic parts or metal flakes can cause electrical shorts.

Avant de remettre l’ordinateur sous tension après remplacement d’une unité en clientèle, vérifiez que tous les ressorts, vis et autres pièces sont bien en place et bien fixées. Pour ce faire, secouez l’unité et assurez-vous qu’aucun bruit suspect ne se produit. Des pièces métalliques ou des copeaux de métal pourraient causer un court-circuit.

Bevor nach einem FRU-Austausch der Computer wieder angeschlossen wird, muß sichergestellt werden, daß keine Schrauben, Federn oder andere Kleinteile fehlen oder im Gehäuse vergessen wurden. Der Computer muß geschüttelt und auf Klappergeräusche geprüft werden. Metallteile oder-splitter können Kurzschlüsse erzeugen.

Prima di accendere l’elaboratore dopo che é stata effettuata la sostituzione di una FRU, accertarsi che tutte le viti, le molle e tutte le altri parti di piccole dimensioni siano nella corretta posizione e non siano sparse all’interno dell’elaboratore. Verificare ciò scuotendo l’elaboratore e prestando attenzione ad eventuali rumori; eventuali parti o pezzetti metallici possono provocare cortocircuiti pericolosi.

Antes de encender el sistema despues de sustituir una FRU, compruebe que todos los tornillos, muelles y demás piezas pequeñas se encuentran en su sitio y no se encuentran sueltas dentro del sistema. Compruébelo agitando el sistema y escuchando los posibles ruidos que provocarían. Las piezas metálicas pueden causar cortocircuitos eléctricos.

Safety information 7

Safety notice 2

DANGER

Some standby batteries contain a small amount of nickel and cadmium. Do not disassemble a standby battery, recharge it, throw it into fire or water, or short-circuit it. Dispose of the battery as required by local ordinances or regulations. Use only the battery in the appropriate parts listing. Use of an incorrect battery can result in ignition or explosion of the battery.

Certaines batteries de secours contiennent du nickel et du cadmium. Ne les démontez pas, ne les rechargez pas, ne les exposez ni au feu ni à l’eau. Ne les mettez pas en court-circuit. Pour les mettre au rebut, conformez-vous à la réglementation en vigueur. Lorsque vous remplacez la pile de sauvegarde ou celle de l’horloge temps réel, veillez à n’utiliser que les modèles cités dans la liste de pièces détachées adéquate. Une batterie ou une pile inappropriée risque de prendre feu ou d’exploser.

Die Bereitschaftsbatterie, die sich unter dem Diskettenlaufwerk befindet, kann geringe Mengen Nickel und Cadmium enthalten. Sie darf nur durch die Verkaufsstelle oder den IBM Kundendienst ausgetauscht werden. Sie darf nicht zerlegt, wiederaufgeladen, kurzgeschlossen, oder Feuer oder Wasser ausgesetzt werden. Die Batterie kann schwere Verbrennungen oder Verätzungen verursachen. Bei der Entsorgung die örtlichen Bestimmungen für Sondermüll beachten. Beim Ersetzen der Bereitschafts-oder Systembatterie nur Batterien des Typs verwenden, der in der Ersatzteilliste aufgeführt ist. Der Einsatz falscher Batterien kann zu Entzündung oder Explosion führen.

Alcune batterie di riserva contengono una piccola quantità di nichel e cadmio. Non smontarle, ricaricarle, gettarle nel fuoco o nell’acqua né cortocircuitarle. Smaltirle secondo la normativa in vigore (DPR 915/82, successive disposizioni e disposizioni locali). Quando si sostituisce la batteria dell’RTC (real time clock) o la batteria di supporto, utilizzare soltanto i tipi inseriti nell’appropriato Catalogo parti. L’impiego di una batteria non adatta potrebbe determinare l’incendio o l’esplosione della batteria stessa.

Algunas baterías de reserva contienen una pequeña cantidad de níquel y cadmio. No las desmonte, ni recargue, ni las eche al fuego o al agua ni las cortocircuite. Deséchelas tal como dispone la normativa local. Utilice sólo baterías que se encuentren en la lista de piezas. La utilización de una batería no apropiada puede provocar la ignición o explosión de la misma.

8 ThinkPad SL400 and SL500Hardware Maintenance Manual

Safety notice 3

DANGER

The battery pack contains small amounts of nickel. Do not disassemble it, throw it into fire or water, or short-circuit it. Dispose of the battery pack as required by local ordinances or regulations. Use only the battery in the appropriate parts listing when replacing the battery pack. Use of an incorrect battery can result in ignition or explosion of the battery.

La batterie contient du nickel. Ne la démontez pas, ne l’exposez ni au feu ni à l’eau. Ne la mettez pas en court-circuit. Pour la mettre au rebut, conformez-vous à la réglementation en vigueur. Lorsque vous remplacez la batterie, veillez à n’utiliser que les modèles cités dans la liste de pièces détachées adéquate. En effet, une batterie inappropriée risque de prendre feu ou d’exploser.

Akkus enthalten geringe Mengen von Nickel. Sie dürfen nicht zerlegt, wiederaufgeladen, kurzgeschlossen, oder Feuer oder Wasser ausgesetzt werden. Bei der Entsorgung die örtlichen Bestimmungen für Sondermüll beachten. Beim Ersetzen der Batterie nur Batterien des Typs verwenden, der in der Ersatzteilliste aufgeführt ist. Der Einsatz falscher Batterien kann zu Entzündung oder Explosion führen.

La batteria contiene piccole quantità di nichel. Non smontarla, gettarla nel fuoco o nell’acqua né cortocircuitarla. Smaltirla secondo la normativa in vigore (DPR 915/82, successive disposizioni e disposizioni locali). Quando si sostituisce la batteria, utilizzare soltanto i tipi inseriti nell’appropriato Catalogo parti. L’impiego di una batteria non adatta potrebbe determinare l’incendio o l’esplosione della batteria stessa.

Las baterías contienen pequeñas cantidades de níquel. No las desmonte, ni recargue, ni las eche al fuego o al agua ni las cortocircuite. Deséchelas tal como dispone la normativa local. Utilice sólo baterías que se encuentren en la lista de piezas al sustituir la batería. La utilización de una batería no apropiada puede provocar la ignición o explosión de la misma.

Safety information 9

Safety notice 4

DANGER

The lithium battery can cause a fire, an explosion, or a severe burn. Do not recharge it, remove its polarized connector, disassemble it, heat it above 100°C (212°F), incinerate it, or expose its cell contents to water. Dispose of the battery as required by local ordinances or regulations. Use only the battery in the appropriate parts listing. Use of an incorrect battery can result in ignition or explosion of the battery.

La pile de sauvegarde contient du lithium. Elle présente des risques d’incendie, d’explosion ou de brûlures graves. Ne la rechargez pas, ne retirez pas son connecteur polarisé et ne la démontez pas. Ne l’exposez pas à une temperature supérieure à 100°C, ne la faites pas brûler et n’en exposez pas le contenu à l’eau. Mettez la pile au rebut conformément à la réglementation en vigueur. Une pile inappropriée risque de prendre feu ou d’exploser.

Die Systembatterie ist eine Lithiumbatterie. Sie kann sich entzünden, explodieren oder schwere Verbrennungen hervorrufen. Batterien dieses Typs dürfen nicht aufgeladen, zerlegt, über 100 C erhitzt oder verbrannt werden. Auch darf ihr Inhalt nicht mit Wasser in Verbindung gebracht oder der zur richtigen Polung angebrachte Verbindungsstecker entfernt werden. Bei der Entsorgung die örtlichen Bestimmungen für Sondermüll beachten. Beim Ersetzen der Batterie nur Batterien des Typs verwenden, der in der Ersatzteilliste aufgeführt ist. Der Einsatz falscher Batterien kann zu Entzündung oder Explosion führen.

La batteria di supporto e una batteria al litio e puo incendiarsi, esplodere o procurare gravi ustioni. Evitare di ricaricarla, smontarne il connettore polarizzato, smontarla, riscaldarla ad una temperatura superiore ai 100 gradi centigradi, incendiarla o gettarla in acqua. Smaltirla secondo la normativa in vigore (DPR 915/82, successive disposizioni e disposizioni locali). L’impiego di una batteria non adatta potrebbe determinare l’incendio o l’esplosione della batteria stessa.

La batería de repuesto es una batería de litio y puede provocar incendios, explosiones o quemaduras graves. No la recargue, ni quite el conector polarizado, ni la desmonte, ni caliente por encima de los 100°C (212°F), ni la incinere ni exponga el contenido de sus celdas al agua. Deséchela tal como dispone la normativa local.

10 ThinkPad SL400 and SL500Hardware Maintenance Manual

Safety notice 5

If the LCD breaks and the fluid from inside the LCD gets into your eyes or on your hands, immediately wash the affected areas with water for at least 15 minutes. Seek medical care if any symptoms from the fluid are present after washing.

Si le panneau d’affichage à cristaux liquides se brise et que vous recevez dans les yeux ou sur les mains une partie du fluide, rincez-les abondamment pendant au moins quinze minutes. Consultez un médecin si des symptômes persistent après le lavage.

Die Leuchtstoffröhre im LCD-Bildschirm enthält Quecksilber. Bei der Entsorgung die örtlichen Bestimmungen für Sondermüll beachten. Der LCD-Bildschirm besteht aus Glas und kann zerbrechen, wenn er unsachgemäß behandelt wird oder der Computer auf den Boden fällt. Wenn der Bildschirm beschädigt ist und die darin befindliche Flüssigkeit in Kontakt mit Haut und Augen gerät, sollten die betroffenen Stellen mindestens 15 Minuten mit Wasser abgespült und bei Beschwerden anschließend ein Arzt aufgesucht werden.

Nel caso che caso l’LCD si dovesse rompere ed il liquido in esso contenuto entrasse in contatto con gli occhi o le mani, lavare immediatamente le parti interessate con acqua corrente per almeno 15 minuti; poi consultare un medico se i sintomi dovessero permanere.

Si la LCD se rompe y el fluido de su interior entra en contacto con sus ojos o sus manos, lave inmediatamente las áreas afectadas con agua durante 15 minutos como mínimo. Obtenga atención medica si se presenta algún síntoma del fluido despues de lavarse.

Safety information 11

Safety notice 6

DANGER

To avoid shock, do not remove the plastic cover that protects the lower part of the inverter card.

Afin d’éviter tout risque de choc électrique, ne retirez pas le cache en plastique protégeant la partie inférieure de la carte d’alimentation.

Aus Sicherheitsgründen die Kunststoffabdeckung, die den unteren Teil der Spannungswandlerplatine umgibt, nicht entfernen.

Per evitare scosse elettriche, non rimuovere la copertura in plastica che avvolge la parte inferiore della scheda invertitore.

Para evitar descargas, no quite la cubierta de plástico que rodea la parte baja de la tarjeta invertida.

Safety notice 7

DANGER

Though the main batteries have low voltage, a shorted or grounded battery can produce enough current to burn personnel or combustible materials.

Bien que le voltage des batteries principales soit peu élevé, le court-circuit ou la mise à la masse d’une batterie peut produire suffisamment de courant pour brûler des matériaux combustibles ou causer des brûlures corporelles graves.

Obwohl Hauptbatterien eine niedrige Spannung haben, können sie doch bei Kurzschluß oder Erdung genug Strom abgeben, um brennbare Materialien zu entzünden oder Verletzungen bei Personen hervorzurufen.

Sebbene le batterie di alimentazione siano a basso voltaggio, una batteria in corto circuito o a massa può fornire corrente sufficiente da bruciare materiali combustibili o provocare ustioni ai tecnici di manutenzione.

Aunque las baterías principales tienen un voltaje bajo, una batería cortocircuitada o con contacto a tierra puede producir la corriente suficiente como para quemar material combustible o provocar quemaduras en el personal.

12 ThinkPad SL400 and SL500Hardware Maintenance Manual

Safety notice 8

DANGER

Before removing any FRU, power off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables.

Avant de retirer une unité remplaçable en clientèle, mettez le système hors tension, débranchez tous les cordons d’alimentation des socles de prise de courant, retirez la batterie et déconnectez tous les cordons d’interface.

Die Stromzufuhr muß abgeschaltet, alle Stromkabel aus der Steckdose gezogen, der Akku entfernt und alle Verbindungskabel abgenommen sein, bevor eine FRU entfernt wird.

Prima di rimuovere qualsiasi FRU, spegnere il sistema, scollegare dalle prese elettriche tutti i cavi di alimentazione, rimuovere la batteria e poi scollegare i cavi di interconnessione.

Antes de quitar una FRU, apague el sistema, desenchufe todos los cables de las tomas de corriente eléctrica, quite la batería y, a continuación, desconecte cualquier cable de conexión entre dispositivos.

Safety information 13

Laser compliance statement

Some models of ThinkPad computer are equipped from the factory with an optical storage device such as a CD-ROM drive or a DVD-ROM drive. Such devices are also sold separately as options. If one of these drives is installed, it is certified in the U.S. to conform to the requirements of the Department of Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN 60 825 for Class 1 laser products.

If a CD-ROM drive, a DVD-ROM drive, or another laser device is installed, note the following:

CAUTION:

Use of controls or adjustments or performance of procedures other than those specified herein might result in hazardous radiation exposure.

O uso de controles, ajustes ou desempenho de procedimentos diferentes daqueles aqui especificados pode resultar em perigosa exposição à radiação.

Pour éviter tout risque d’exposition au rayon laser, respectez les consignes de réglage et d’utilisation des commandes, ainsi que les procédures décrites.

Werden Steuer- und Einstellelemente anders als hier festgesetzt verwendet, kann gefährliche Laserstrahlung auftreten.

L’utilizzo di controlli, regolazioni o l’esecuzione di procedure diverse da quelle specificate possono provocare l’esposizione a.

El uso de controles o ajustes o la ejecución de procedimientos distintos de los aquí especificados puede provocar la exposición a radiaciones peligrosas.

Opening the CD-ROM drive, the DVD-ROM drive, or any other optical storage device could result in exposure to hazardous laser radiation. There are no serviceable parts inside those drives. Do not open.

14 ThinkPad SL400 and SL500Hardware Maintenance Manual

A CD-ROM drive, a DVD-ROM drive, or any other storage device installed may contain an embedded Class 3A or Class 3B laser diode. Note the following:

DANGER

Emits visible and invisible laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam.

Radiação por raio laser ao abrir. Não olhe fixo no feixe de luz, não olhe diretamente por meio de instrumentos óticos e evite exposição direta com o feixe de luz.

Rayonnement laser si carter ouvert. Évitez de fixer le faisceau, de le regarder directement avec des instruments optiques, ou de vous exposer au rayon.

Laserstrahlung bei geöffnetem Gerät. Nicht direkt oder über optische Instrumente in den Laserstrahl sehen und den Strahlungsbereich meiden.

Kinyitáskor lézersugár ! Ne nézzen bele se szabad szemmel, se optikai eszközökkel. Kerülje a sugárnyalábbal való érintkezést !.

Aprendo l’unità vengono emesse radiazioni laser. Non fissare il fascio, non guardarlo direttamente con strumenti ottici e evitare l’esposizione diretta al fascio.

Radiación láser al abrir. No mire fijamente ni examine con instrumental óptico el haz de luz. Evite la exposición directa al haz.

Safety information 15

16 ThinkPad SL400 and SL500Hardware Maintenance Manual

Important service information

This chapter presents following important service information: v “Strategy for replacing FRUs”

– “Strategy for replacing a hard disk drive” on page 18 – “Important notice for replacing a system board” on page 18 – “How to use error message” on page 18

v “Strategy for replacing FRUs for CTO, CMV, and GAV” on page 19

– “Product definition” on page 19 – “FRU identification for CTO, CMV, and GAV products” on page 19

v “Important information about replacing RoHS compliant FRUs” on page 21

Important:

BIOS and device driver fixes are customer-installable. The BIOS and device drivers are posted on the customer support site http://www.lenovo.com/support

System Disassembly/Reassembly videos that show the FRU removals or replacements for the Lenovo® authorized service technicians are available in the following support site: http://www.lenovoservicetraining.com/ion/

Advise customers to contact the Customer Support Center at 800-426-7378 if they need assistance in obtaining or installing any software fixes, drivers, and BIOS downloads.

Customers in Canada should call the Customer Support Center at 800-565-3344 for assistance or download information.

Strategy for replacing FRUs

Before replacing parts:

sure that all software fixes, drivers, and BIOS downloads are installed

Make before replacing any FRUs listed in this manual.

After a system board is replaced, ensure that the latest BIOS is loaded to the system board before completing the service action.

To download software fixes, drivers, and BIOS, do as follows:

1. Go to http://www.lenovo.com/support

2. Enter the product number of the computer or press Auto-detect button on the

screen.

3. Select Downloads and drivers.

4. Follow the directions on the screen and install the necessary software.

Use the following strategy to prevent unnecessary expense for replacing and servicing FRUs:

v If you are instructed to replace a FRU but the replacement does not correct the

problem, reinstall the original FRU before you continue.

v Some computers have both a processor board and a system board. If you are

instructed to replace either the processor board or the system board, and replacing one of them does not correct the problem, reinstall that board, and then replace the other one.

v If an adapter or a device consists of more than one FRU, any of the FRUs may

be the cause of the error. Before replacing the adapter or device, remove the FRUs, one by one, to see if the symptoms change. Replace only the FRU that changed the symptoms.

Attention: The setup configuration on the computer you are servicing may have been customized. Running Automatic Configuration may alter the settings. Note the current configuration settings (using the View Configuration option); then, when service has been completed, verify that those settings remain in effect.

Strategy for replacing a hard disk drive

Always try to run a low-level format before replacing a hard disk drive. This will cause all customer data on the hard disk to be lost. Be sure that the customer has a current backup of the data before doing this task.

Attention: The drive startup sequence in the computer you are servicing may have been changed. Be extremely careful during write operations such as copying, saving, or formatting. If you select an incorrect drive, data or programs can be overwritten.

Important notice for replacing a system board

Some components mounted on a system board are very sensitive. Improper handling of a system board can cause damage to those components, and may cause a system malfunction.

Attention: When handling a system board:

v Do not drop a system board or apply any excessive force to it.

v Avoid rough handling of any kind.

v Avoid bending a system board and hard pushing to prevent cracking at each

BGA (Ball Grid Array) chipset.

How to use error message

Use the error codes displayed on the screen to diagnose failures. If more than one error code is displayed, begin the diagnosis with the first error code. Whatever causes the first error code may also cause false error codes. If no error code is displayed, see whether the error symptom is listed in the Symptom-to-FRU Index for the computer you are servicing.

18 ThinkPad SL400 and SL500Hardware Maintenance Manual

Strategy for replacing FRUs for CTO, CMV, and GAV

Product definition

Dynamic Configure To Order (CTO)

This provides the ability for a customer to configure an IBM® or a Lenovo solution from an eSite, and have this configuration sent to fulfillment, where it is built and shipped directly to the customer. The machine label, Product Entitlement Warehouse (PEW), eSupport, and the HMM will load these products as the 4-digit MT and 3-digit model, where model = “CTO” (Example: 1829-CTO).

Custom Model Variant (CMV)

This is a unique configuration that has been negotiated between IBM or Lenovo and the customer. A unique 4-digit MT and 3-digit model is provided to the customer to place orders (Example: 1829-W15). A CMV is a special bid offering. Therefore, it is NOT generally announced.

v The MTM portion of the machine label is the 4-digit MT and 3-digit model,

where model = “CTO” (Example: 1829-CTO). The PRODUCT ID portion of the machine label is the 4-digit MT and 3-digit CMV model (Example: 1829-W15).

v The PEW record is the 4-digit MT and 3-digit model, where model = “CTO”

(Example: 1829-CTO).

v eSupport will show both the CTO and CMV machine type models (Example:

1829-CTO and 1829-W15 will be found on the eSupport site.)

v The HMM will have the 4-digit MT and 3-digit CTO model only (Example:

1829-CTO). Again, CMVs are custom models and are not found in the HMM.

General Announce Variant (GAV)

This is a standard model (fixed configuration). GAVs are announced and offered to all customers. The MTM portion of the machine label is a 4-digit MT and 3-digit model, where model = a “fixed part number”, not “CTO” (Example: 1829-F1U). Also, PEW, eSupport, and the HMM will list these products under the same fixed model number.

FRU identification for CTO, CMV, and GAV products

There are three information resources to identify which FRUs are used to support CTO, CMV, and GAV products. These sources are PEW, eSupport, and the HMM.

Using PEW

v PEW is the primary source for identifying FRU part numbers and FRU

descriptions for the key commodities for CTO, CMV and GAV products at a MT

- serial number level. An example of key commodities are hard disk drives, system boards, microprocessors, Liquid Crystal Displays (LCDs), and memory.

v Remember, all CTO and CMV products are loaded in PEW under the 4-digit MT

and 3-digit model, where model = “CTO” (Example: 1829-CTO). GAVs are loaded in PEW under the 4-digit MT and 3-digit model, where model = a “fixed part number”, not “CTO” (Example: 1829-F1U).

v PEW can be accessed at the following Web site: http://w3-01.ibm.com/pc/

entitle/pg2/Service.wss/display/Home

Customers can also access PEW via

http://www-307.ibm.com/pc/support/site.wss/product.do?template=/warranty/

Important service information 19

warranty.vm&sitestyle=lenovo

Select Warranty lookup. Input the MT and the Serial number and the list of key commodities will be returned in the PEW record under COMPONENT INFORMATION.

v Business Partners using Eclaim will access PEW when performing Entitlement

Lookup. Business Partners will enter Loc ID, MT and Serial, and the key commodities will be returned in the Eclaim record under SYSTEM DETAILS.

v Authorized IBM Business Partners can access Eclaim at the following We b site:

https://wca.eclaim.com

Using eSupport

For Key Commodities (Examples - hard disk drive, system board, microprocessor, LCD, and memory)

v eSupport can be used to view the list of key commodities built in a particular

machine serial (this is the same record found in PEW).

v eSupport can be accessed at the following Web site: http://www.lenovo.com/

support

v To view the key commodities, click on PA RT S INFORMATION, then PARTS

LOOKUP. Type in the model type and serial number. The key commodities will be returned in the eSupport record under PARTS SHIPPED WITH YOUR SYSTEM.

the Remaining FRUs (the complete list of FRUs at the MT Model level)

For

v eSupport can be used to view the complete list of FRUs for a machine type and

model.

v To view the complete list of FRUs, type in the machine type and model

(Example: 1829-CTO) under QUICK PATH. Under “View by Document Type” select PARTS INFORMATION. Under “Filter by Category” select SERVICE PARTS. Under “Parts Information by Date” select SYSTEM SERVICE PARTS. The list of service parts by description, with applicable machine type model and FRU will be displayed.

Using the HMM

For Key Commodities (Examples - hard disk drive, system board, microprocessor, LCD, and memory)

Use the HMM as a back-up to PEW and eSupport to view the complete list of FRUs at the MT Model level.

20 ThinkPad SL400 and SL500Hardware Maintenance Manual

Important information about replacing RoHS compliant FRUs

RoHS, The Restriction of Hazardous Substances in Electrical and Electronic Equipment Directive (2002/95/EC) is a European Union legal requirement affecting the global electronics industry. RoHS requirements must be implemented on Lenovo products placed on the market after June 2006. Products on the market before June 2006 are not required to have RoHS compliant parts. If the original FRU parts are non compliant, replacement parts can also be non compliant. In all cases if the original FRU parts are RoHS compliant, the replacement part must also be RoHS compliant.

Note: RoHS and non-RoHS FRU part numbers with the same fit and function are

identified with unique FRU part numbers.

Lenovo plans to transition to RoHS compliance well before the implementation date and expects its suppliers to be ready to support Lenovo’s requirements and schedule in the EU. Products sold in 2005 and 2006, will contain some RoHS compliant FRUs. The following statement pertains to these products and any product Lenovo produces containing RoHS compliant FRUs.

RoHS compliant FRUs have unique FRU part numbers. Before or after the RoHS implementation date, failed RoHS compliant parts must always be replaced using RoHS compliant FRUs, so only the FRUs identified as compliant in the system HMM or direct substitutions for those FRUs may be used.

Products marketed before June 2006 Products marketed after June 2006 Current or original

part

Replacement FRU Current or original

part

Replacement FRU

Non-RoHS Can be Non-RoHS Must be RoHS Must be RoHS

Non-RoHS Can be RoHS

Non-RoHS Can sub to RoHS

RoHS Must be RoHS

Note: A direct substitution is a part with a different FRU part number that is automatically shipped by the distribution center at the time of the order.

Important service information 21

22 ThinkPad SL400 and SL500Hardware Maintenance Manual

General checkout

This chapter presents following information:

v “What to do first” on page 24 v “Checkout guide” on page 25

– “Diagnostics using PC-Doctor for DOS” on page 26 – “PC-Doctor for Windows” on page 28 – “PC-Doctor for Rescue and Recovery” on page 28

“Power system checkout” on page 29

The descriptions in this chapter apply to any ThinkPad model that supports the PC-Doctor® for DOS diagnostics program. Some descriptions might not apply to your particular computer.

Before you go to the checkout guide, be sure to read the following important notes.

Important notes:

v Only certified trained personnel should service the computer. v Before replacing any FRU, read the entire page on removing and replacing

FRUs.

v When you replace FRUs, use new nylon-coated screws. v Be extremely careful during such write operations as copying, saving, or

formatting. Drives in the computer that you are servicing sequence might have been altered. If you select an incorrect drive, data or programs might be overwritten.

v Replace a FRU only with another FRU of the correct model. When you

replace a FRU, make sure that the model of the machine and the FRU part number are correct by referring to the FRU parts list.

v A FRU should not be replaced because of a single, unreproducible failure.

Single failures can occur for a variety of reasons that have nothing to do with a hardware defect, such as cosmic radiation, electrostatic discharge, or software errors. Consider replacing a FRU only when a problem recurs. If you suspect that a FRU is defective, clear the error log and run the test again. If the error does not recur, do not replace the FRU.

v Be careful not to replace a nondefective FRU.

What to do first

When you do return a FRU, you must include the following information in the parts exchange form or parts return form that you attach to it:

__ 1. Name and phone number of servicer __ 2. Date of service __ 3. Date on which the machine failed __ 4. Date of purchase __ 5. Failure symptoms, error codes appearing on the display, and beep

symptoms

__ 6. Procedure index and page number in which the failing FRU was detected __ 7. Failing FRU name and part number __ 8. Machine type, model number, and serial number __ 9. Customer’s name and address

for warranty: During the warranty period, the customer may be responsible

Note

for repair costs if the computer damage was caused by misuse, accident, modification, unsuitable physical or operating environment, or improper maintenance by the customer.

Following is a list of some common items that are not covered under warranty and some symptoms that might indicate that the system was subjected to stress beyond normal use.

Before checking problems with the computer, determine whether the damage is covered under the warranty by referring to the following list:

The following are not covered under warranty:

v LCD panel cracked from the application of excessive force or from being

dropped

v Scratched (cosmetic) parts v Distortion, deformation, or discoloration of the cosmetic parts v Plastic parts, latches, pins, or connectors that have been cracked or broken by

excessive force

v Damage caused by liquid spilled into the system v Damage caused by the improper insertion of a PC Card or the installation of an

incompatible card

v Improper disc insertion or use of an optical drive v Diskette drive damage caused by pressure on the diskette drive cover, foreign

material in the drive, or the insertion of a diskette with multiple labels

v Damaged or bent diskette eject button v Fuses blown by attachment of a nonsupported device v Forgotten computer password (making the computer unusable) v Sticky keys caused by spilling a liquid onto the keyboard v Use of an incorrect ac adapter on laptop products

following symptoms might indicate damage caused by nonwarranted

The activities:

v Missing parts might be a symptom of unauthorized service or modification. v If the spindle of a hard disk drive becomes noisy, it may have been subjected to

excessive force, or dropped.

24 ThinkPad SL400 and SL500Hardware Maintenance Manual

Checkout guide

Use the following procedures as a guide in identifying and correcting problems with the ThinkPad computer.

Note: The diagnostic tests are intended to test only ThinkPad products. The use of non-ThinkPad products, prototype cards, or modified options can lead to false indications of errors and invalid system responses.

1. Identify the failing symptoms in as much detail as possible.

2. Verify the symptoms. Tr y to re-create the failure by running the diagnostic test

or by repeating the operation.

General checkout 25

Diagnostics using PC-Doctor for DOS

The ThinkPad computer has a test program called PC-Doctor for DOS (hereafter called PC-Doctor.) You can detect errors by running the diagnostics test included in PC-Doctor. This section is an overview of the procedure. For details that depend on model-unique functions, refer to “ThinkPad SL400 and SL500” on page 49.

Note:

PC-Doctor

support

To create the PC-Doctor diagnostic diskette, follow the instruction on the We b site.

For some possible configurations of the computer, PC-Doctor might not run correctly. To avoid this problem, you need to initialize the computer setup by use of the BIOS Setup Utility before you run PC-Doctor.

To enter BIOS Setup Utility, do as follows:

1. Turn on the computer.

2. When the ThinkPad logo comes up, immediately press F1 to enter the BIOS

Setup Utility.

for DOS is available at following We b site: http://www.lenovo.com/

If a supervisor password only has been set by the customer, BIOS Setup

Note:

Utility menu appears after the password is entered. You can start the utility by pressing Enter instead of entering the supervisor password; however, you cannot change the parameters that are protected by the supervisor password.

On the BIOS Setup Utility screen, press F9, Enter, F10, and then Enter.

Note: When you initialize the computer configuration, some devices are disabled, such as the serial port. If you test one of these devices, you will need to enable it by using Configuration utility for DOS. The utility is available on the following Web site: http://www.lenovo.com/support

Testing the computer

To run the test, do as follows:

Note: In the following procedure, you can select an item not only with the arrow keys, but also with the TrackPoint® pointer. Instead of pressing Enter, click the left button.

1. Insert the PC-Doctor disc into the optical drive; then power on the computer.

If the computer cannot be powered on, go to “Power system checkout” on page 29, and check the power sources.

If an error code appears, go to “Symptom-to-FRU index” on page 39.

On the first screen, select the model and press Enter. Follow the instructions on the screen.

2. The main panel of PC-Doctor appears.

3. Select Diagnostics with the arrow keys, and press Enter.

A pull-down menu appears. (Its exact form depends on the model.)

26 ThinkPad SL400 and SL500Hardware Maintenance Manual

Note: PC-Doctor menu does not mean the formal support device list. Some

unsupported device names may appear in the PC-Doctor menu.

Diagnostics

Run Normal Test Run Quick Test CPU/Coprocessor Systemboard Video Adapter Serial Ports Parallel Ports Fixed Disks Diskette Drives Other Devices Communication Wireless LAN PM Memory

Use the cursor keys and ESC to move in menus.Press ENTER to select.

Interactive Tests Hardware Info Utility Quit F1=Help

The options on the test menu are as follows:

Diagnostics Interactive Tests

v Run Normal Test v Run Quick Test v CPU/Coprocessor v Systemboard v Video Adapter v Serial Ports v Parallel Ports v Fixed Disks

v Keyboard v Video v Internal Speaker v Mouse v Diskette v System Load v Optical Drive Test

v Intel 5XXX WLAN Radio Test v Diskette Drives v Other Devices v Communication v Wireless LAN v PM Memory

Notes:

v In the Keyboard test in Interactive Tests, the Fn key should be held down for

at least 2 seconds; otherwise, it cannot be sensed.

v Video Adapter test supports only the LCD display on the ThinkPad computer.

If you have an external monitor attached to your computer, detach it before running PC-Doctor for DOS.

4. Run the applicable function test.

5. Follow the instructions on the screen. If there is a problem, PC-Doctor shows

messages describing it.

6. To exit the test, select Quit — Exit Diags.

To cancel the test, press Esc.

After running PC-Doctor, check the time and date on the system and reset

Note:

them if they are incorrect.

General checkout 27

Detecting system information with PC-Doctor

PC-Doctor can detect the following system information:

Hardware Info

v System Configuration v Memory Contents v Physical Disk Drives v Logical Disk Drives v VGA Information v IDE Drive Info v PCI Information v PNPISA Info v SMBIOS Info v VESA LCD Info v Hardware Events Log

Utility

v Run External Tests v Surface Scan Hard Disk v Benchmark System v DOS Shell v Tech Support Form v Battery Rundown v View Test Log v Print Log v Save Log v Full Erase Hard Drive v Quick Erase Hard Drive

PC-Doctor for Windows

This product is designed to help you troubleshoot and resolve problems related to your computer. Select one of the categories listed below to display symptoms and solutions:

v Check System Health v System and Device Tests v Lenovo Troubleshooting Center v System Reports v Updates and Support

PC-Doctor for Rescue and Recovery

In some models of ThinkPad computer, the Rescue and Recovery® workspace enables you to run the PC-Doctor program to test the hardware features of the computer.

To run the test, click “Run Diagnostics” on the Rescue and Recovery main screen.

28 ThinkPad SL400 and SL500Hardware Maintenance Manual

Power system checkout

To verify a symptom, do the following:

1. Turn off the computer.

2. Remove the battery pack.

3. Connect the ac adapter.

4. Check that power is supplied when you turn on the computer.

5. Turn off the computer.

6. Disconnect the ac adapter and install the charged battery pack.

7. Check that the battery pack supplies power when you turn on the computer.

you suspect a power problem, see the appropriate one of the following power

If supply checkouts:

v “Checking the AC adapter” v “Checking operational charging” on page 30 v “Checking the battery pack” on page 30 v “Checking the backup battery” on page 31

Checking the AC adapter

You are here because the computer fails only when the AC adapter is used.

v If the power problem occurs only when the ThinkPad Essential Port Replicator

is used, replace the port replicator.

v If the power-on indicator does not turn on, check the power cord of the AC

adapter for correct continuity and installation.

v If the computer does not charge during operation, go to “Checking operational

charging” on page 30

check the AC adapter, do the following:

1. Unplug the AC adapter cable from the computer.

2. Measure the output voltage at the plug of the AC adapter cable. See the

following figure:

Pin Voltage (V dc)

1 +20

2 0

3 Ground

(20V)

Note: Output voltage of pin no.2 of the AC adapter may different from the one you are servicing.

3. If the voltage is not correct, replace the AC adapter.

4. If the voltage is acceptable, do the following:

v Replace the system board. v If the problem persists, go to “ThinkPad SL400 and SL500” on page 49.

Noise from the AC adapter does not always indicate a defect.

Note:

General checkout 29

Checking operational charging

To check whether the battery charges properly during operation, use a discharged battery pack or a battery pack that has less than 50% of the total power remaining when installed in the computer.

Perform operational charging. If the battery status indicator or icon does not turn on, remove the battery pack and let it return to room temperature. Reinstall the battery pack. If the charge indicator or icon still does not turn on, replace the battery pack.

If the charge indicator still does not turn on, replace the system board. Then reinstall the battery pack. If it is still not charged, go to the next section.

Checking the battery pack

Battery charging does not start until the Power Meter shows that less than 95% of the total power remains; under this condition the battery pack can charge to 100% of its capacity. This protects the battery pack from being overcharged or from having a shortened life.

To check your battery, move your cursor to the Power Meter icon in the icon tray of the Windows® taskbar and wait for a moment (but do not click), and the percentage of battery power remaining is displayed. To get detailed information about the battery, double-click the Power Meter icon.

Note: If the battery pack becomes hot, it may not be able to charge. Remove it from the computer and leave it at room temperature for a while. After it cools down, reinstall and recharge it.

To check the battery pack, do the following:

1. Power off the computer.

2. Remove the battery pack and measure the voltage between battery terminals 1

(+) and 7 (-). See the following figure:

Terminal Voltage (V dc)

1 + 0 to + 12.6

7(-)

1(+)

2(+)

6(-)

7 Ground (-)

3. If the voltage is less than +11.0 V dc, the battery pack has been discharged.

Note: Recharging will take at least 3 hours, even if the indicator does not turn on.

If the voltage is still less than +11.0 V dc after recharging, replace the battery.

4. If the voltage is more than +11.0 V dc, measure the resistance between battery

terminals 5 and 7. The resistance must be 4 to 30 K .

If the resistance is not correct, replace the battery pack. If the resistance is correct, replace the system board.

30 ThinkPad SL400 and SL500Hardware Maintenance Manual

Checking the backup battery

Do the following:

1. Power off the computer, and unplug the ac adapter from it.

2. Turn the computer upside down.

3. Remove the battery pack (see “1010 Battery pack” on page 63).

4. Remove the backup battery (see “1190 Backup battery (for ThinkPad SL400)” on

page 91).

5. Measure the voltage of the backup battery. See the following figure.

v If the voltage is correct, replace the system board.

v If the voltage is not correct, replace the backup battery.

v If the backup battery discharges quickly after replacement, replace the system

board.

Red (+)

Black (-)

Wire Voltage (V dc)

Red +2.5 to +3.2

Black Ground

General checkout 31

32 ThinkPad SL400 and SL500Hardware Maintenance Manual

Related service information

This chapter presents following information:

v “Restoring the factory contents by using Product Recovery discs” v “Passwords” on page 34 v “Power management” on page 37 v “Symptom-to-FRU index” on page 39

Service Web site:

the latest maintenance diskette and the system program service diskette

When become available, they will be posted on http://www.lenovo.com/spm

Restoring the factory contents by using Product Recovery discs

When the hard disk drive (HDD) or solid state drive (SSD) is replaced because of a failure, no Product Recovery program is on the new drive. In this case, you must use the recovery discs for the computer. Order the recovery discs and the drive at the same time so that you can recover the new drive with the pre-installed software when they arrive. For information on which discs to order, see “Recovery discs” on page 196.

To install the factory contents by using Product Recovery discs, do the following:

Note: Recovery takes several hours. The length of time depends on the method you use. If you use recovery discs, recovery takes at least five hours.

1. Insert the bootable Start Recovery Disc into the DVD drive.

2. Select your language and click Next.

3. Read the license. If you agree with the terms, select I accept these terms and

conditions and then click Next.

4. Insert the Operating System Recovery Disc when prompted and click Yes to

begin the operating system recovery process.

5. Insert the Product Recovery Disc when prompted and click OK.

6. If you have a Supplemental Recovery Disc, insert it when prompted and click

Yes. If you do not have a Supplemental Recovery Disc, click No.

Not all recovery disc sets come with a Supplemental Recovery Disc. If

Note: there is a Supplemental Recovery Disc, it will be clearly marked as such.

7. When all of the data has been copied from the last disc in the set, a message is displayed prompting you to restart the computer. Remove the disc and then click Yes.

The remainder of the recovery process is fully automated and no action

Note:

is required by you. The computer will restart into the Windows desktop several times and you might experience periods when no activity is apparent on the screen for several minutes at a time. This is normal.

Passwords

Power-on password

8. When the recovery process is complete, the Welcome to Microsoft Windows screen is displayed. Follow the instructions on the screen to complete the Windows setup.

As many as three passwords may be needed for any ThinkPad computer: the power-on password (POP), the hard-disk password (HDP), and the supervisor password (SVP).

If any of these passwords has been set, a prompt for it appears on the screen whenever the computer is turned on. The computer does not start until the password is entered.

Exception: If only an SVP is installed, the password prompt does not appear when the operating system is booted.

A power-on password (POP) protects the system from being powered on by an unauthorized person. The password must be entered before an operating system can be booted. For how to remove the POP, see “How to remove the power-on password” on page 35.

Hard-disk password

There are two hard-disk passwords (HDPs):

v User HDP—for the user

v Master HDP—for the system administrator, who can use it to get access to the

hard disk even if the user has changed the user HDP

There are two modes for the HDP: User only and Master + User. The

Note: Master + User mode requires two HDPs; the system administrator enters both in

the same operation. The system administrator then provides the user HDP to the system user.

Attention:

If the user HDP has been forgotten, check whether a master HDP has

been set. If it has, it can be used for access to the hard disk drive. If no master HDP is available, neither Lenovo nor Lenovo authorized servicers provide any services to reset either the user or the master HDP, or to recover data from the hard disk drive. The hard disk drive can be replaced for a scheduled fee.

For how to remove the POP, see “How to remove the hard-disk password” on page 35.

Supervisor password

A supervisor password (SVP) protects the system information stored in the BIOS Setup Utility. The user must enter the SVP in order to get access to the BIOS Setup Utility and change the system configuration.

Attention: If the SVP has been forgotten and cannot be made available to the servicer, there is no service procedure to reset the password. The system board must be replaced for a scheduled fee.

34 ThinkPad SL400 and SL500Hardware Maintenance Manual

How to remove the power-on password

To remove a POP that you have forgotten, do the following:

(A) If no SVP has been set:

1. Turn off the computer.

2. Remove the battery pack.

For how to remove the battery pack, see “1010 Battery pack” on page 63.

3. Remove the backup battery.

For how to remove the backup battery, see “1190 Backup battery (for ThinkPad SL400)” on page 91.

4. Turn on the computer and wait until the POST ends.

After the POST ends, the password prompt does not appear. The POP has been removed.

5. Reinstall the backup battery and the battery pack.

If an SVP has been set and is known by the servicer:

(B)

1. Turn on the computer.

2. When the ThinkPad logo comes up, immediately press F1 to enterBIOS Setup

Utility. Press F1 while the Enter Password is appearing on the screen; then enter the

SVP.

3. Select Security, using the cursor directional keys to move down the menu.

4. Select Password.

5. Select Power-On Password.

6. Type the current POP in the Enter CURRENT Password field. then leave the

Enter New Password field blank, and press Enter.

7. In the Password uninstalled window, press Enter.

8. Press F10; then, in the Setup confirmation window, select OK .

How to remove the hard-disk password

Attention: If User only mode is selected and the user HDP has been forgotten and cannot be made available to the servicer, neither Lenovo nor Lenovo authorized servicers provide any services to reset the user HDPs or to recover data from the hard disk drive. The hard disk drive can be replaced for a scheduled fee.

To remove a user HDP that has been forgotten, when the SVP and the master HDP are known, do the following:

1. Turn on the computer.

2. When the ThinkPad logo comes up, immediately press F1 to enterBIOS Setup

Utility. Press F1 while Hard Disk locked, enter user password is appearing on the

screen; then press ESC to switch to Master Password. While Hard Disk locked, enter master password is appearing on the screen, enter the master HDP.

While Enter Password is appearing on the screen, enter the SVP.

3. Select Security, using the cursor directional keys to move down the menu.

4. Select Password.

Related service information 35

5. Select HardDisk Security Setting and press Enter. Hard Disk x Password, where x is the letter of the hard disk drive.

6. Select Change HDD Master Password by using the cursor directional keys.

7. Type the current master HDP in the Enter CURRENT Password field. then

leave the Enter New Password field blank, and press Enter twice.

8. Press F10.

9. Select OK in the Setup Configuration window.

Both user HDP and master HDP will have been removed.

36 ThinkPad SL400 and SL500Hardware Maintenance Manual

Power management

To reduce power consumption, the computer has three power management modes: screen blank, standby, and hibernation.

Screen blank mode

If the time set on the “Turn off monitor” timer in the operating system expires, the LCD backlight turns off.

To put the computer into screen blank mode, press Fn+F3.

To end screen blank mode and resume normal operation, press any key.

Standby mode

When the computer enters standby mode, the following events occur in addition to what occurs in screen blank mode:

v The LCD is powered off. v The hard disk drive is powered off. v The CPU stops.

enter standby mode, press Fn+F4.

Note: If you are using the ACPI operating system, you can change the action of Fn+F4.

In certain circumstances, the computer goes into standby mode automatically:

v If a “suspend time” has been set on the timer, and the user does not do any

operation with the keyboard, the TrackPoint, the hard disk, the parallel connector, or the diskette drive within that time.

v If the battery indicator blinks orange, indicating that the battery power is low.

(Alternatively, if Hibernate when battery becomes low has been selected in the “Power Management Properties” window, the computer goes into hibernation mode.)

for the APM operating system: Even if you do not set the low-battery alarm,

Note

the charge indicator notifies you when the battery is low, and then the computer enters the power-saving mode automatically. This default low-battery behavior is independent of the operating system; so if you have set the low-battery alarm, the computer may not do what you specified. It chooses either your setting or the default setting, whichever is appropriate.

If you are using the ACPI operating system, only the low-battery alarm is available.

To cause the computer to return from standby mode and resume operation, do one of the following:

v Press the Fn key. v Open the LCD cover. v Turn on the power switch.

in either of the following events, the computer automatically returns from

Also, standby mode and resumes operation:

Related service information 37

v The ring indicator (RI) is signaled by a serial device or a PC Card device.

v The time set on the resume timer elapses.

Note: The computer does not accept any input immediately after it enters standby mode. Wait a few seconds before taking any action to reenter operation mode.

Hibernation mode

In hibernation mode, the following occurs:

v The system status, RAM, VRAM, and setup data are stored on the hard disk.

v The system is powered off.

cause the computer to enter hibernation mode, do any of the following:

v Press the Fn+F12 keys. v If you are using the APM operating system and have set the mode to Power

switch mode [Hibernation], turn off the power switch.

v If you are using the ACPI operating system and have defined one of the

following actions as the event that causes the system to go into hibernation mode, perform that action. – Closing the lid. – Pressing the power button. – Pressing Fn+F4 keys.

Also, the computer goes into hibernation mode automatically in either of the following conditions:

v If a “hibernation time” has been set on the timer, and if the user does not do

any operation with the keyboard, the TrackPoint, the hard disk drive, the parallel connector, or the diskette drive within that time.

v If the timer conditions are satisfied in suspend mode. v If you are using the APM operating system and have set the mode to Hibernate

when battery becomes low, and the battery charge becomes critically low.

the power is turned on, the computer returns from hibernation mode and

When resumes operation. The hibernation file in the boot record on the hard disk drive is read, and system status is restored from the hard disk drive.

38 ThinkPad SL400 and SL500Hardware Maintenance Manual

Symptom-to-FRU index

This section contains following information:

v “Numeric error codes” v “Error messages” on page 44 v “Beep symptoms” on page 45 v “No-beep symptoms” on page 45 v “LCD-related symptoms” on page 46 v “Intermittent problems” on page 47 v “Undetermined problems” on page 47

symptom-to-FRU index in this section lists symptoms and errors and their

The possible causes. The most likely cause is listed first, in boldface type.

Note: Do the FRU replacement or other actions in the sequence shown in the column headed “FRU or action, in sequence.” If replacing a FRU does not solve the problem, put the original part back in the computer. Do not replace a nondefective FRU.

This index can also help you determine, during regular servicing, what FRUs are likely to need to be replaced next.

A numeric error is displayed for each error detected in POST or system operation. In the displays, n can be any number.

If no numeric code is displayed, check the narrative descriptions of symptoms. If the symptom is not described there, go to “Intermittent problems” on page 47.

Note:

a device not supported by diagnostic codes in the ThinkPad computers, see

For the manual for that device.

Numeric error codes

Table 1. Numeric error codes

Symptom or error FRU or action, in sequence 1802

Remove the MiniPCI network card.

Unauthorized network card is plugged in Power off and remove the miniPCI network card.

1804

Remove the wireless WAN card.

Unauthorized WA N card is plugged in Power off and remove the WA N card.

1805

Remove the wireless USB card.

Unauthorized Wireless USB card is plugged in - Power off and remove the Wireless USB card.

1810

Fan.

Fan Error

1811

CPU.

Thermal sensing error

Related service information 39

Table 1. Numeric error codes (continued)

Symptom or error FRU or action, in sequence 7001

Add the DIMMs.

(HDCP) Memory is not enough for HDCP Key Provisioning!

7002

System board.

(HDCP) Failed to check the key set Family-EKS!

7003

System board.

(HDCP) Chip-Unique-EKS re-encryption failed!

7004

(HDCP)

Failed to check the key set

System board.

Chip-Unique-EKS!

7005

(HDCP)

Cipher Initialization with

System board.

Chip-Unique-EKS failed!

8100

Gate20 Error

8101

Multi-Bit ECC Error

8102

Parity Error

8103

RAM R/W test failed

8104

CMOS

Memory Size Wrong

8200

Boot Failure ...

8201

Invalid Boot Diskette

8202

Drive Not Ready

8203

Drive Error

1. System board.

2. DIMM.

1. DIMM.

2. System board.

1. DIMM.

2. System board.

1. DIMM.

2. System board.

1. DIMM.

2. System board.

Reseat the boot device. Confirm that boot image is stored in the failing device.

Confirm that boot image is stored in the failing diskette.

Confirm that the boot media is installed in the driver.

Reseat the diskette drive.

1. Diskette drive.

2. USB cable (if diskette drive has removal

USB cable.)

8204

B: Drive Error

Reseat the diskette drive.

1. Diskette drive.

2. USB cable (if diskette drive has removal

USB cable.)

8205

Insert BOOT diskette in A:

8206

Reboot and Select proper Boot device or Insert Boot Media in selected Boot device

8207

NO ROM BASIC

Reaset the diskette cable. Confirm that boot image is stored in the failing diskette.

Reseat the bootable devices. Confirm that the bootable device or media is in the system.

40 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 1. Numeric error codes (continued)

Symptom or error FRU or action, in sequence 8318

S.M.A.R.T. Capable but Command Failed

1. Hard disk drive.

2. System board.

3. S ATA cable.

8319

S.M.A.R.T. Command Failed

1. Hard disk drive.

2. System board.

3. S ATA cable.

831A

S.M.A.R.T. Status BAD, Backup and Replace

1. Hard disk drive.

2. System board.

3. S ATA cable.

831B

S.M.A.R.T. Capable and Status BAD

1. Hard disk drive.

2. System board.

3. S ATA cable.

8400

BootSector Write !!

8401

VIRUS: Continue (Y/N)?

8500

Disconnect the system from the network. There might be Virus on the system.

System board.

DMA-1 Error

8501

System board.

DMA-2 Error

8502

System board.

DMA Controller Error

8503

System board.

Checking NVRAM..Update Failed

8504

Update the BIOS.

Microcode Error

8505

NVRAM Checksum Bad, NVRAM Cleared

Set data by using the maintenance diskette. If the same error still happens after setting the data, replace the system board.

8506

Resource Conflict

After removing the option devices from the system, if the same error still happens, replace the system board.

8507

Set data by using the maintenance diskette.

NVRAM Ignored

8508

NVRAM Bad

Set data by using the maintenance diskette. If the same error still happens the after setting the data, replace the system board.

8509

Static Resource Conflict

After removing the option devices from the system, if the same error still happens, replace the system board.

850A

PCI I/O conflict

After removing the option devices from the system, if the same error still happens, replace the system board.

850B

PCI ROM conflict

After removing the option devices from the system, if the same error still happens, replace the system board.

850C

PCI IRQ conflict

After removing the option devices from the system, if the same error still happens, replace the system board.

Related service information 41

Table 1. Numeric error codes (continued)

Symptom or error FRU or action, in sequence 850D

Update the BIOS.

PCI IRQ routing table error

850E

System board.

Timer Error

850F

System board.

Refresh timer test failed

8510

System board.

Interrupt Controller-1 error

8511

System board.

Interrupt Controller-2 error

8600

CMOS Date/Time Not Set

Run BIOS Setup Utility and save it. If the same error happens after doing it, replace the system board.

8601

CMOS Battery Low

8602

CMOS Settings Wrong

1. Backup battery.

2. System board.

Run BIOS Setup Utility and save it. If the same error happens after doing it, check these FRUs:

1. Backup battery.

2. System board.

8603

CMOS Checksum Bad

Run BIOS Setup Utility and save it. If the same error happens after doing it, check these FRUs:

1. Backup battery.

2. System board.

8700

KBC

BAT Test failed

8701

Keyboard Error

8702

PS2 Keyboard not found

Run interactive tests of the keyboard and the auxiliary input device.

Confirm that the keyboard cable is connected correctly.

If setting is incorrect, reset the BIOS Setup Utility. If setting is correct, after confirming the PS2 keyboard is correct, replace the system board.

8703

PS2 Mouse not found

If setting is incorrect, reset the BIOS Setup Utility. If setting is correct, after confirming the PS2 mouse is correct, replace the system board.

8704

Keyboard/Interface

8705

Unlock keyboard

8706

Error

System board.

1. System board.

2. Keyboard.

System board.

System Halted

8707

<INS> Pressed

If the error continues, check these FRUs:

1. Backup battery.

2. System board.

8708

Password

check failed

If the error continues, check these FRUs:

1. Backup battery.

2. System board.

42 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 1. Numeric error codes (continued)

Symptom or error FRU or action, in sequence 870A

Update the BIOS.

Unknown BIOS error. Error code = 004Bh

870B

Floppy Controller Failure

8800

1. External floppy disk drive.

2. System board.

Remove unsupported USB devices.

Warning! Unsupported USB device found and disabled!

8801

Warning!

Port 60h/64h emulation is not

If possible, change the setting.

supported by this USB Host Controller!

8802

Update the BIOS.

Warning! EHCI controller disabled. It requires 64bit data support in the BIOS.

8900

Not

enough space in Runtime area!! SMBIOS

System board.

data will not be available.

8A00

Warning! This system board does not

1. CPU.

2. System board.

support the power requirements of the installed processor. The processor will be run at a reduced frequency, which will impact system performance.

8B00

System board.

Insufficient Runtime space for MPS data! System may operate in PIC or Non-MPS mode.

Related service information 43

Error messages

Table 2. Error messages

Symptom or error FRU or action, in sequence Device address conflict. 1. Load “Setup Defaults” in the BIOS

Setup Utility.

2. Backup battery.

3. System board.

Allocation error for device. 1. Load “Setup Defaults” in the BIOS

Setup Utility.

2. Backup battery.

3. System board.

Failing bits: nnnn. 1. DIMM.

2. System board.

Invalid system configuration data. 1. DIMM.

2. System board.

I/O device IRQ conflict. 1. Load “Setup Defaults” in the BIOS

Setup Utility.

2. Backup battery.

3. System board.

Hibernation error. 1. Restore the system configuration to

what it was before the computer entered hibernation mode.

2. If memory size has been changed, re-create the hibernation file.

Fan error. 1. Fan.

2. Thermal grease.

3. System board.

Thermal sensing error. System board. Cannot boot from any device. Check the status of device which you want

to boot from.

44 ThinkPad SL400 and SL500Hardware Maintenance Manual

Device not found.

1. The device you want to boot from.

2. System board.

Device Error.

1. The device you want to boot from.

2. System board.

valid operating system.

1. Check that the operating system has no

failure and is installed correctly.

2. Reinstall the operation system.

Excluded

from boot order.

v Enter the BIOS Setup Utility and add the

device in boot order.

Beep symptoms

Table 3. Beep symptoms

Symptom or error FRU or action, in sequence

One beep and a blank, unreadable, or flashing LCD.

1. Reseat the LCD connector.

2. LCD assembly.

3. External CRT.

4. System board.

One long and two short beeps, and a blank or unreadable LCD.

1. System board.

2. LCD assembly.

3. DIMM.

Two short beeps with error codes. POST error. See “Numeric error codes” on

page 39.

Two short beeps and a blank screen. 1. System board.

2. DIMM.

Three short beeps, pause, three more short beeps, and one short beep.

One short beep, pause, three short beeps,

1. DIMM.

2. System board.

Reinstall the operating system.

pause, three more short beeps, and one short beep. Only the cursor appears.

Five short beeps and a blank screen. System board.

No-beep symptoms

Table 4. No-beep symptoms

Symptom or error FRU or action, in sequence

No beep, power-on indicator on, LCD blank, and no POST.

1. Make sure that every connector is connected tightly and correctly.

2. DIMM.

3. System board.

No beep, power-on indicator on, and LCD blank during POST.

1. Reseat DIMM.

2. System board.

The power-on password prompt appears. A power-on password or a supervisor

password is set. Type the password and press Enter.

The hard-disk password prompt appears. A hard-disk password is set. Type the

password and press Enter.

Related service information 45

LCD-related symptoms

Important: The TFT LCD for the notebook computer contains many thin-film transistors (TFTs). The presence of a small number of dots that are missing, discolored, or always lighted is characteristic of TFT LCD technology, but excessive pixel problems can cause viewing concerns. The LCD should be replaced if the number of missing, discolored, or lighted dots in any background is as follows:

Table 5. Minimum quantity of defective pixels required for LCD replacement on June 2006 or later manufactured ThinkPad

LCD resolution Bright dots Dark dots Bright and dark dots

XGA, WXGA 5 6 6

WXGA+, SXGA+,

5 8 10

WSXGA+

UXGA, WUXGA,

5 13 13

QXGA

Notes:

v Lenovo will not provide replacement if the LCD is within specification as we

cannot guarantee that any replacement LCD will have zero pixel defects.

v A bright dot means a pixel is always on (white or color.)

v A dark dot means a pixel is always off (black color.)

v One pixel consists of R, G, B sub-pixels.

Table 6. LCD-related symptoms

Symptom or error FRU or action, in sequence

No beep, power-on indicator on, and a

System board.

blank LCD during POST.

v LCD backlight not working. v LCD too dark. v LCD brightness cannot be adjusted.

1. Reseat the LCD connectors.

2. LCD assembly.

3. System board.

v LCD contrast cannot be adjusted.

v LCD screen unreadable. v Characters missing pixels. v Screen abnormal. v Wrong color displayed.

1. See important note for “LCD-related symptoms.”

2. Reseat all LCD connectors.

3. LCD assembly.

4. System board.

Horizontal or vertical lines displayed on

LCD assembly.

LCD.

46 ThinkPad SL400 and SL500Hardware Maintenance Manual

Intermittent problems

Intermittent system hang problems can be due to a variety of causes that have nothing to do with a hardware defect, such as cosmic radiation, electrostatic discharge, or software errors. FRU replacement should be considered only when a problem recurs.

When analyzing an intermittent problem, do the following:

1. Run the diagnostic test for the system board in loop mode at least 10 times.

2. If no error is detected, do not replace any FRUs.

3. If any error is detected, replace the FRU shown by the FRU code. Rerun the

test to verify that no more errors exist.

Undetermined problems

If the diagnostic tests did not identify the adapter or device that has failed, if wrong devices are installed, or if the system simply is not operating, follow these procedures to isolate the failing FRU (do not isolate FRUs that have no defects).

Verify that all attached devices are supported by the computer.

Verify that the power supply being used at the time of the failure is operating correctly. (See “Power system checkout” on page 29.)

1. Turn off the computer.

2. Visually check each FRU for damage. Replace any damaged FRU.

3. Remove or disconnect all of the following devices: a. Non-ThinkPad devices b. Devices attached to the docking station or the port replicator c. Printer, mouse, and other external devices d. Battery pack e. Hard disk drive f. External diskette drive or optical drive g. DIMM h. Optical disk or diskette in the internal drive i. PC Cards

4. Turn on the computer.

5. Determine whether the problem has been solved.

6. If the problem does not recur, reconnect the removed devices one at a time

until you find the failing FRU.

7. If the problem remains, replace the following FRUs one at a time (do not replace a nondefective FRU):

a. System board b. LCD assembly

Related service information 47

48 ThinkPad SL400 and SL500Hardware Maintenance Manual

ThinkPad SL400 and SL500

This chapter presents following product-specific service references and product-specific parts information.

v “Specifications” v “Status indicators” on page 52 v “FRU tests” on page 54 v “Fn key combinations” on page 56 v “FRU replacement notices” on page 58 v “Removing and replacing a FRU” on page 62 v “Locations” on page 138 v “Parts list” on page 145

Specifications

The following table lists the specifications of the ThinkPad SL400 and SL500 :

Table 7. Specifications

Feature Description

Processor v Intel® Celeron® processor 575 (2.0 GHz), 3-MB L2 cache

v Intel Celeron processor 585 (2.16 GHz), 3-MB L2 cache v Intel Celeron Dual Core processor T1600 (1.66 GHz), 3-MB

L2 cache

v Intel Celeron Dual Core processor T1700 (1.83 GHz), 3-MB

L2 cache

v Intel® Core™ 2 Duo processor P7370 (2.0 GHz), 3-MB L2

cache

v Intel Core 2 Duo processor P7370 (2.0 GHz), 3-MB L2

cache

v Intel Core 2 Duo processor P8400 (2.26 GHz), 3-MB L2

cache

v Intel Core 2 Duo processor P8600 (2.40 GHz), 3-MB L2

cache

v Intel Core 2 Duo processor P8700 (2.53 GHz), 3-MB L2

cache

v Intel Core 2 Duo processor T5670 (1.8 GHz), 6-MB L2

cache

v Intel Core 2 Duo processor T5870 (2.0 GHz), 6-MB L2

cache

v Intel Core 2 Duo processor T6570 (2.1 GHz), 6-MB L2

cache

v Intel Core 2 Duo processor T9400 (2.53 GHz), 6-MB L2

cache

v Intel Core 2 Duo processor T9550 (2.66 GHz), 6-MB L2

cache

v Intel Core 2 Duo processor T9800 (2.93 GHz), 6-MB L2

cache

Bus architecture v 1066-MHz FSB

v 667-MHz DDR2 SDRAM (PC2-5300) v PCI bus v PCI Express bus v DMI

Table 7. Specifications (continued)

Feature Description

Graphic memory chip v Intel GL40 graphics

v Intel GM45 graphics v nVidia graphics

Display v 14.1-inch, 16M colors, WXGA (1280 × 800 resolution) Anti

Glare TFT color LCD

v 14.1-inch, 16M colors, WXGA (1280 × 800 resolution) Glare

TFT color LCD

v 14.1-inch, 16M colors, WXGA+ (1440 × 900 resolution)

Anti Glare TFT color LCD

v 15.4-inch, 16M colors, WXGA (1280 × 800 resolution) Anti

Glare TFT color LCD

v 15.4-inch, 16M colors, WXGA (1280 × 800 resolution) Glare

TFT color LCD

v 15.4-inch, 16M colors, WSXGA+ (1680 × 1050 resolution)

Anti Glare TFT color LCD

Standard memory v 512-MB DDR2-667 SDRAM SO-DIMM (PC2-5300) card× 1

v 1-GB DDR2-667 SDRAM SO-DIMM (PC2-5300) card × 1 v 1-GB DDR2-667 SDRAM SO-DIMM (PC2-5300) card × 2 v 2-GB DDR2-667 SDRAM SO-DIMM (PC2-5300) card × 1 v 2-GB DDR2-667 SDRAM SO-DIMM (PC2-5300) card × 2

Optional memory v 512-MB DDR2-667 SDRAM SO-DIMM (PC2-5300) card

v 1-GB DDR2-667 SDRAM SO-DIMM (PC2-5300) card v 2-GB DDR2-667 SDRAM SO-DIMM (PC2-5300) card

Extended memory device (some models)

(maximum

v Intel Turbo Memory 2-GB Minicard v Intel Turbo Memory 4-GB Minicard

of 4.0 GB)

CMOS RAM v 242 bytes

Hard disk drive v 80 GB, 5400 rpm, 9.5 mm high, SATA interface

v 160 GB, 5400 rpm, 9.5 mm high, SATA interface v 250 GB, 5400 rpm, 9.5 mm high, SATA interface v 320 GB, 5400 rpm, 9.5 mm high, SATA interface

Optical drive v DVD drive, 12.7 mm high

Fingerprint reader Some models

I/O port v External monitor connector

Internal modem v 56.6 Kbps

Audio v Built-in stereo speakers

50 ThinkPad SL400 and SL500Hardware Maintenance Manual

Supported

hard disk drives depend on the model.

v DVD/CD-RW combo drive, 12.7 mm high v DVD multi drive, 12.7 mm high v Blu-ray drive, 12.7 mm high v Blu-ray combo drive, 12.7 mm high

v Stereo headphone jack v Monaural microphone jack v IEEE 1394 connector v RJ11 connector v RJ45 connector v Universal serial bus (USB) connector × 4 (compatible with

USB 1.1 and 2.0)

v 7-in-1 slot

v Software control volume

Table 7. Specifications (continued)

Feature Description

Ethernet (on the system

v Gigabit Ethernet

board)

PCI Express Mini Card v ThinkPad 11b/g Wireless LAN Mini PCI Express Adapter

III

v Intel WiFi Link 5100 v Intel WiMAX/WiFi Link 5150 v Intel WiMAX/WiFi Link 5350 v Ericsson F3507g USA - Wireless WA N card v Ericsson F3507g Other - Wireless WAN card v Wireless USB PCI Express Half-Mini Card

ExpressCard slot/Smart Card slot

Bluetooth wireless (some

v One ExpressCard slot v One Smart Card slot

v ThinkPad Bluetooth with Enhanced Data Rate (BDC-2.1)

models)

Touch pad v UltraNav

Battery v Li-ion battery (6 cells) 2.4 Ah

v Li-ion battery (6 cells) 2.6 Ah v Li-ion battery (9 cells) 2.6 Ah

AC adapter v 65-watt type

v 90-watt type

Preinstalled operating system

v Windows XP Professional v Windows Vista® Starter Edition (32 bit) v Windows Vista Home Basic (32 bit) v Windows Vista Home Premium (32 bit) v Windows Vista Business (32 bit) v Windows Vista Ultimate (32 bit)

ThinkPad SL400 and SL500 51

Status indicators

The system status indicators show the status of the computer, as follows:

Table 8. Status indicators

Indicator Meaning

1 Power on The computer is on and ready to use. The power switch stays lit

whenever the computer is on and is not lit when the computer is in sleep (standby) mode.

2 Device access A hard disk drive is being used to read or write data. When this

indicator is blinking, do not put the computer into sleep (standby) mode or turn it off. Note: Do not move the system while the green drive-in-use light is on. Sudden physical shock could cause drive errors.

3 Media Card

Reader

A card in the 7-in-1 Media Card Reader is being used to read and write data. When this indicator is blinking, do not put the computer into sleep mode, remove the card from the slot, or turn off the computer.

4 Numeric lock The numeric keypad on the keyboard is enabled. To enable or

disable the keypad, press and hold the Shift key or Fn key, and press the NumLk (Delete) key.

5 CapsLock

CapsLock mode is enabled. Yo u can enter all alphabetic characters (A-Z) in uppercase without pressing the Shift key. To enable or disable CapsLock mode, press and hold the Shift key, and press the CapsLock key.

52 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 8. Status indicators (continued)

Indicator Meaning

6 Sleep (standby

in Windows XP) status

Green: The computer is in sleep (standby) mode. Blinking green:

The computer is entering sleep (standby) mode or hibernation mode, or is resuming normal operation.

7 Battery status Green: The battery has more than 20% charge.

Orange:

The battery has between 5% and 20% charge.

Blinking orange (rapid):

The battery has less than 5% charge.

Note: The battery may be charging.

Blinking orange (slow):

The battery is being charged. When it reaches 20%, the blinking color changes to green.

Blinking green (slow):

The battery has between 20% and 80% charge, and charging is continuing. When the battery reaches 80% charge, blinking stops, but the charging may continue until the battery is 100% charged. Note: If the computer is operating on battery power, the battery status indicator does not work while the computer is turned off or is in sleep (standby) mode or hibernation mode.

8 Bluetooth

wireless status

Green: Bluetooth wireless is on, and the radio link is ready for

use.

Blinking green:

Data is being transmitted.

9 Wireless

WAN/WiMAX status

Green: The wireless WA N or WiMAX feature is on, and the

radio link is ready for use.

Blinking green:

Data is being transmitted.

10 Wireless LAN

status

Green: The wireless LAN feature (the IEEE 802.11 standard) is

on, and the radio link is ready for use.

Blinking green:

Data is being transmitted.

ThinkPad SL400 and SL500 53

FRU tests

The following table shows the test for each FRU.

Table 9. FRU tests

FRU Applicable test System board 1. Diagnostics --> CPU/Coprocessor

2. Diagnostics --> Systemboard

Power Diagnostics --> ThinkPad Devices --> AC Adapter, Battery 1

(Battery2)

LCD unit 1. Diagnostics --> Video Adapter

2. Interactive Tests --> Video

Modem daughter card (MDC-1.5)

1. Make sure the modem is set up correctly.

2. Replace the modem jack and the modem card in turn, and run

the following tests in Diagnostics --> Communication:

a. Conexant Smart Modem Interrupt b. Conexant Smart Modem Dialtone

Audio Enter the BIOS Setup Utility and change Serial ATA (SATA ) setting

to Compatibility, and run Diagnostics --> Other Devices -->

Analog Devices HDA CODEC Test

Speaker Interactive Tests --> Internal Speaker

Note: Once Modem/Audio test is done, the no sound is heard

this test. In this case, turn off and turn on the computer. Then, run this test again.

PC Card slot Diagnostics --> Systemboard --> PCMCIA

ExpressCard slot 1. Insert a PCI-Express/USB Wrap card into the ExpressCard slot.

2. Turn on the computer.

3. Run Diagnostics --> ThinkPad Devices --> ExpressCard slot.

Keyboard 1. Diagnostics --> Systemboard --> Keyboard

2. Interactive Tests --> Keyboard

Hard disk drive Enter the BIOS Setup Utility and change Serial ATA (SATA) setting

to Compatibility, and run Diagnostics --> Fixed Disks

You can also diagnose the hard disk drive without starting up the operating system. To diagnose the hard disk drive from the BIOS Setup Utility, do as follows:

1. Remove any diskette from the diskette drive, and then turn off the computer.

2. Turn on the computer.

3. While the message, “To interrupt normal startup, press the

blue ThinkVangate button,” is displayed at the lower left of the screen, press F1 to enter the BIOS Setup Utility.

4. Using cursor keys, select HDD diagnostic program. Press enter.

5. Using cursor keys, select Main hard disk drive or Ultrabay hard disk drive.

6. Press Enter to start the diagnostic program.

Diskette drive 1. Diagnostics --> Diskette Drives

2. Interactive Tests --> Diskette

DVD drive or DVD/CD-RW combo

1. Diagnostics --> Other Devices--> Optical Drive

2. Interactive Tests --> Optical Drive Test

drive

54 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 9. FRU tests (continued)

FRU Applicable test

Memory 1. If two DIMMs are installed, remove one of them and run

Diagnostics --> Memory Test—Quick.

2. If the problem does not recur, return the DIMM to its place, remove the other one, and run the test again.

3. If the test does not detect the error, run Diagnostics --> Memory Test—Full.

Fan 1. Turn on the computer and check the air turbulence at the

louver near the PC Card slot.

2. Run Diagnostics --> ThinkPad Devices --> Fan.

TrackPoint or pointing device

If the TrackPoint does not work, check the configuration as specified in the BIOS Setup Utility. If the TrackPoint is disabled, select Automatic to enable it.

After you use the TrackPoint, the pointer may drift on the screen for a short time. This drift can occur when a slight, steady pressure is applied to the TrackPoint pointer. This symptom is not a hardware problem. If the pointer stops after a short time, no service action is necessary.

If enabling the TrackPoint does not correct the problem, continue with the following: v Interactive Tests --> Mouse

Touch Pad If the Touch Pad does not work, check the configuration as

specified in the BIOS Setup Utility. If the Touch Pad is disabled, select Automatic to enable it. If enabling the Touch Pad does not correct the problem, continue with the following: v Interactive Tests --> Mouse

ThinkPad SL400 and SL500 55

Fn key combinations

The following table shows the function of each combination of Fn with a function key.

Table 10. Fn key combinations

Key combination Description

Fn+F1 Reserved.

Fn+F2 Lock your computer.

Fn+F3 Select a power scheme that has been created by Power Manager. When

you press this combination, a panel for selecting a power scheme appears.

Notes:

1. To use the Fn+F3 key combination, you must have the ThinkPad PM device driver installed on the computer.

2. If you have logged on with an administrator user ID, and you press Fn+F3, the panel for selecting a power scheme appears. If you have logged on with another user ID, and you press Fn+F3, the panel does not appear.

3. Yo u cannot turn off the computer display by pressing Fn+F3.

Fn+F4 Put the computer in standby mode. To return to normal operation,

press the Fn key only, without pressing a function key.

Notes:

1. To use the Fn+F4 key combination, you must have the ThinkPad PM device driver installed on the computer.

2. This combination of keys also functions as a sleep button. If you want to use the combination to put the computer into hibernation mode or shut the computer down, change the settings in the Power Manager.

Fn+F5 Enable or disable the built-in wireless networking features and the

Bluetooth features. If you press Fn+F5, a list of wireless features is displayed. You can quickly change the power state of each feature in the list. Note: If you want to use Fn+F5 to enable the feature specified in IEEE standard 802.11, the following device drivers must be installed on the computer beforehand:

v ThinkPad Power Management driver v OnScreen Display Utility v Wireless device drivers

Fn+F6 Reserved.

56 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 10. Fn key combinations (continued)

Key combination Description

Fn+F7 Apply a presentation scheme directly, with no need to start

Presentation Director.

To disable this function and use the Fn+F7 key combination for switching a display output location, start Presentation Director, and change the settings.

Switch a display output location

v External monitor (CRT display) v Computer display and external monitor (LCD + CRT display) v Computer display (LCD)

Notes:

1. This function is not supported if different desktop images are displayed on the computer display and the external monitor (the Extend desktop function).

2. This function does not work while a DVD movie or a video clip is playing.

enable this function, start Presentation Director, and change the

Fn+F7 settings. Note: Multiple users can log on to a single operating system by using different user IDs. Each user needs to change the settings.

Fn+F8 Change the settings of the UltraNav pointing device.

Fn+F9 Open the EasyEject Utility screen. Buttons for the following choices are

displayed: v Run EasyEject Actions: Yo u can select, stop, and remove external

devices connected to the ThinkPad computer.

v Confiture EasyEject Actions: Yo u can open the EasyEject Utility

main window.

v Fn+F9 Settings: You can configure the settings for the Fn+F9

function.

Fn+F10 Reserved.

Fn+F11 Reserved.

Fn+F12 Put the computer into hibernation mode. To return to normal operation,

press the power button for less than four seconds. Note: To use Fn+F12 for hibernation, you must have the ThinkPad PM device driver installed on the computer.

Fn+Home The computer display becomes dimmer.

Fn+End The computer display becomes brighter.

Fn+Spacebar Enable the FullScreen Magnifier function.

Fn+PrtSc Has the same function as the SysRq key.

Fn+ScrLk Enable or disable the numeric keypad.

Fn+Pause Has the same function as the Break key.

Fn+cursor keys These key combinations work with Windows Windows Media Player.

Fn+down arrow key works for the Play or Pause button, Fn+up arrow key for the Stop button, Fn+right arrow key for the Next Track button, and Fn+left arrow key for the Previous Track button.

ThinkPad SL400 and SL500 57

FRU replacement notices

This section contains notices related to removing and replacing parts. Read this section carefully before replacing any FRU.

Screw notices

Loose screws can cause a reliability problem. In the ThinkPad computer, this problem is addressed with special nylon-coated screws that have the following characteristics:

v They maintain tight connections. v They do not easily come loose, even with shock or vibration. v They are harder to tighten. v Each one should be used only once.

the following when you service this machine:

Do v Keep the screw kit (for the P/N, see “Miscellaneous parts” on page 193) in your

tool bag.

v Always use new screws. v Use a torque screwdriver if you have one.

Tighten

screws as follows:

v Plastic to plastic

Turn an additional 90 degrees after the screw head touches the surface of the plastic part:

90 degrees more

(Cross-section)

v Logic card to plastic

Turn an additional 180 degrees after the screw head touches the surface of the logic card:

180 degrees more

(Cross-section)

v Torque driver

If you have a torque driver, refer to the “Torque” column for each step.

v Make sure that you use the correct screw. If you have a torque screwdriver,

tighten all screws firmly to the torque shown in the table. Never use a screw

that you removed. Use a new one. Make sure that all of the screws are tightened firmly.

v Ensure torque screw drivers are calibrated correctly following country

specifications.

58 ThinkPad SL400 and SL500Hardware Maintenance Manual

Retaining serial numbers

This section includes the following descriptions:

v “Restoring the serial number of the system unit” v “Retaining the UUID” v “Reading or writing the ECA information” on page 61

Restoring the serial number of the system unit

When the computer was manufactured, the EEPROM on the system board was loaded with the serial numbers of the system and all major components. These numbers need to remain the same throughout the life of the computer.

If you replace the system board, you must restore the serial number of the system unit to its original value.

Before replacing the system board, save the original serial number by doing the following:

1. Install the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later, and restart the computer.

2. From the main menu, select 1. Set System Identification.

3. Select 2. Read S/N data.

4. Select 1. Read system S/N data.

System information in your computer is displayed; the serial number of the system unit is listed as follows: v 07: Serial Number=

Write down that number.

Note: The serial number of the system unit is also written on the label attached to the bottom of the computer.

After you have replaced the system board, restore the serial number by doing the following:

1. Install the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later and restart the computer.

2. From the main menu, select 1. Set System Identification.

3. Select 1. Add S/N data.

4. Select 1. Add system S/N data.

Follow the instructions on the screen.

If the MTM and Product ID numbers differ from each other on the rear label, use what is shown for the Product ID field. See example below:

MTM on rear label:

TTTT-CTO S/N SSSSSSS

Product ID on rear label:

TTTT-MMM (Use this number when setting Serial Number)

In the example, the Serial Number to be input is ’1STTTTMMMSSSSSSS’.

Retaining the UUID

The Universally Unique Identifier (UUID) is a 128-bit number uniquely assigned to your computer at production and stored in the EEPROM of your system board.

ThinkPad SL400 and SL500 59

The algorithm that generates the number is designed to provide unique IDs until the year A.D. 3400. No two computers in the world have the same number.

When you replace the system board, you must set the UUID on the new system board as follows:

1. Install the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later, and restart the computer.

2. From the main menu, select 2. Assign UUID.

A new UUID is created and written. If a valid UUID already exists, it is not overwritten.

60 ThinkPad SL400 and SL500Hardware Maintenance Manual

Reading or writing the ECA information

Information on Engineering Change Announcements (ECA) are stored in the EEPROM of the system board. The electronic storage of this information simplifies the procedure to check if the ECA has been previously applied to a machine. The machine does not need to be disassembled to check for the ECA application.

To check what ECAs have been previously applied to the machine, use the ECA Information Read/Write function on the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later.

1. Insert the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later, and restart the computer.

2. From the main menu, select 3. Set ECA Information.

3. To read ECA information, select 2. Read ECA/rework number and follow the

instruction.

4. To read box build date, select 5. Read box build date, and follow the instruction on the screen.

After an ECA has been applied to the machine, the EEPROM must be updated to reflect the ECA’s application. Use the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later to update the EEPROM.

Note: Only the ECA number is stored in the EEPROM. The machine type of the ECA is assumed be the same as the machine type of the machine that had the ECA applied to it.

1. Insert the LENOVO ThinkPad SL Series Maintenance Diskette Version 1.01 or later, and restart the computer.

2. From the main menu, select 3. Set ECA Information.

3. To write ECA information, select 1. Write ECA/rework number, and follow the

instruction.

4. To write box build date, select 4. Write box build date, and follow the instruction on the screen.

If the system board is being replaced, try to read the ECA information from the old system board and transfer the information to the new system. If the system board is inoperable, this will not be possible.

ThinkPad SL400 and SL500 61

Removing and replacing a FRU

This section presents directions and drawings for use in removing and replacing a FRU. Be sure to observe the following general rules:

1. Do not try to service any computer unless you have been trained and certified. An untrained person runs the risk of damaging parts.

2. Before replacing any FRU, review “FRU replacement notices” on page 58.

3. Begin by removing any FRUs that have to be removed before the failing FRU.

Any such FRUs are listed at the top of the page. Remove them in the order in which they are listed.

4. Follow the correct sequence in the steps for removing the FRU, as given in the drawings by the numbers in square callouts.

5. When turning a screw to replace a FRU, turn it in the direction as given by the arrow in the drawing.

6. When removing the FRU, move it in the direction as given by the arrow in the drawing.

7. To put the new FRU in place, reverse the removal procedure and follow any notes that pertain to replacement. For information about connecting and arranging internal cables, see “Locations” on page 138.

8. When replacing a FRU, use the correct screw as shown in the procedures.

DANGER

Before removing any FRU, turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables.

Attention: After replacing a FRU, do not turn on the computer until you have

made sure that all screws, springs, and other small parts are in place and none are loose inside the computer. Verify this by shaking the computer gently and listening for rattling sounds. Metallic parts or metal flakes can cause electrical short circuits.

Attention: The system board is sensitive to, and can be damaged by, electrostatic

discharge. Before touching it, establish personal grounding by touching a ground point with one hand or by using an electrostatic discharge (ESD) strap (P/N

6405959).

62 ThinkPad SL400 and SL500Hardware Maintenance Manual

1010 Battery pack

DANGER

Use only the battery specified in the parts list for your computer. Any other battery could ignite or explode.

Table 11 . Removal steps of battery pack

Unlock the battery release lever 1. Holding the battery release lever in the unlocked position 2, remove the battery pack in the direction shown by arrow 3.

1 2

When installing: Install the battery pack along the slide rails of the slot. Then make sure that the battery release lever is in the locked position.

ThinkPad SL400 and SL500 63

1020 Optical drive

For access, remove this FRU: v “1010 Battery pack” on page 63

Table 12. Removal steps of optical drive

Step Screw (quantity) Color Torque

1 M2 × 3 mm, wafer-head, nylon-coated (1) Black 0.167 Nm

kgfcm)

(1.7

64 ThinkPad SL400 and SL500Hardware Maintenance Manual

1030 Hard disk drive (HDD) cover and HDD

For access, remove this FRU: v “1010 Battery pack” on page 63

Attention:

v Do not drop the hard disk drive or apply any physical shock to it. The hard

disk drive is sensitive to physical shock. Improper handling can cause damage and permanent loss of data.

v Before removing the drive, have the user make a backup copy of all the

information on it if possible.

v Never remove the drive while the system is operating or is in suspend mode.

Table 13. Removal steps of HDD cover and HDD

Step Screw (quantity) Color Torque

1 Hard disk drive screw, nylon-coated (1) Black 0.167 Nm

kgfcm)

(1.7

ThinkPad SL400 and SL500 65

Table 13. Removal steps of HDD cover and HDD (continued)

When installing: Make sure that the HDD connector is attached firmly.

66 ThinkPad SL400 and SL500Hardware Maintenance Manual

1040 DIMM slot cover (for ThinkPad SL400)

For access, remove this FRU: v “1010 Battery pack” on page 63

Table 14. Removal steps of DIMM slot cover

Note: Loosen the screws 1, but do not remove them.

1050 DIMM slot cover (for ThinkPad SL500)

For access, remove this FRU: v “1010 Battery pack” on page 63

Table 15. Removal steps of DIMM slot cover

Note: Loosen the screws 1, but do not remove them.

ThinkPad SL400 and SL500 67

1060 DIMM

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1040 DIMM slot cover (for ThinkPad SL400)” on page 67 v “1050 DIMM slot cover (for ThinkPad SL500)” on page 67

Table 16. Removal steps of DIMM

1 1

Note: If only one DIMM is used on the computer you are servicing, the card must be installed in SLOT-0 (a: lower slot), but not in SLOT-1 (b: upper slot).

When installing: Insert the notched end of the DIMM into the socket. Press the DIMM firmly, and pivot it until it snaps into the place. Make sure that it is firmly fixed in the slot and does not move easily.

68 ThinkPad SL400 and SL500Hardware Maintenance Manual

1070 PCI Express Mini Card for wireless LAN/WiMAX

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1040 DIMM slot cover (for ThinkPad SL400)” on page 67 v “1050 DIMM slot cover (for ThinkPad SL500)” on page 67

Table 17. Removal steps of PCI Express Mini Card (full size) for wireless LAN/WiMAX

In step 1, unplug the jacks by using the removal tool antenna RF connector (P/N: 08K7159) or pick the connectors with your fingers and gently unplug them in direction of the arrow. Note: Some models might have only two antenna cables or two connector jacks in step 1.

Step Screw (quantity) Color Torque

3 M2 × 3 mm, wafer-head, nylon-coated (2) Black 0.167 Nm

kgfcm)

(1.7

ThinkPad SL400 and SL500 69

Table 17. Removal steps of PCI Express Mini Card (full size) for wireless LAN/WiMAX (continued)

Table 18. Removal steps of PCI Express Mini Card (half size) for wireless LAN

In step 1, unplug the jacks by using the removal tool antenna RF connector (P/N: 08K7159) or pick the connectors with your fingers and gently unplug them in direction of the arrow.

Step Screw (quantity) Color Torque

2 M2 × 3 mm, wafer-head, nylon-coated (2) Black 0.167 Nm

70 ThinkPad SL400 and SL500Hardware Maintenance Manual

(1.7

kgfcm)

Table 18. Removal steps of PCI Express Mini Card (half size) for wireless LAN (continued)

When installing: In models with wireless LAN card that has two antenna connectors, plug the black cable with gray label into the jack labeled MAIN, and the black cable with black label into the jack labeled AUX on the card. If the computer you are servicing has three cables, put the white cable in the cable holder.

In models with wireless LAN card that has three antenna connectors, plug the black cable with gray label (MAIN) into the jack labeled TR1, the black cable with white label (3rd) into jack labeled TR3, and the black cable with black label (AUX) into jack labeled TR2 on the card.

ThinkPad SL400 and SL500 71

1080 PCI Express Mini Card for wireless WAN (for ThinkPad SL400)

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1040 DIMM slot cover (for ThinkPad SL400)” on page 67

Table 19. Removal steps of PCI Express Mini Card for wireless WAN (for ThinkPad SL400)

In step 1, unplug the jacks by using the removal tool antenna RF connector (P/N: 08K7159) or pick the connectors with your fingers and gently unplug them in direction of the arrow.

Step Screw (quantity) Color Torque

1 M2 × 3 mm, wafer-head, nylon-coated (1) Black 0.167 Nm

When installing: Plug the black cable with red label into the jack labeled MAIN, and the black cable with blue label into the jack labeled AUX on the

card.

72 ThinkPad SL400 and SL500Hardware Maintenance Manual

(1.7

kgfcm)

Table 19. Removal steps of PCI Express Mini Card for wireless WAN (for ThinkPad SL400) (continued)

ThinkPad SL400 and SL500 73

1090 Wireless WAN slot cover and PCI Express Mini Card for wireless WAN (for ThinkPad SL500)

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1050 DIMM slot cover (for ThinkPad SL500)” on page 67

Table 20. Removal steps of PCI Express Mini Card for wireless WAN (for ThinkPad SL500)

Note: Loosen the screws 1, but do not remove them.

74 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 20. Removal steps of PCI Express Mini Card for wireless WAN (for ThinkPad SL500) (continued)

In step 3, unplug the jacks by using the removal tool antenna RF connector (P/N: 08K7159) or pick the connectors with your fingers and gently unplug them in direction of the arrow.

Step Screw (quantity) Color Torque

4 M2 × 3 mm, wafer-head, nylon-coated (2) Black 0.167 Nm

kgfcm)

(1.7

When installing: Plug the black cable with red label into the jack labeled MAIN, and the black cable with blue label into the jack labeled AUX on the

card.

ThinkPad SL400 and SL500 75

1100 Thermal door (for ThinkPad SL400)

For access, remove this FRU: v “1010 Battery pack” on page 63

Table 21. Removal steps of thermal door for wireless WAN (for ThinkPad SL400)

Note: Loosen the screws 2, but do not remove them.

76 ThinkPad SL400 and SL500Hardware Maintenance Manual

1110 Thermal door (for ThinkPad SL500)

For access, remove this FRU: v “1010 Battery pack” on page 63

Table 22. Removal steps of thermal door for wireless WAN (for ThinkPad SL500)

Note: Loosen the screws 2, but do not remove them.

ThinkPad SL400 and SL500 77

1120 Fan assembly

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1100 Thermal door (for ThinkPad SL400)” on page 76 v “1110 Thermal door (for ThinkPad SL500)” on page 77

Table 23. Removal steps of fan assembly

Step Screw (quantity) Color Torque

2 M2 × 4 mm, wafer-head, nylon-coated (5) Silver 0.167 Nm

Attention: Do not handle the fan roughly. Improper handling of the fan can cause distortion or deformation and imperfect contact with components.

78 ThinkPad SL400 and SL500Hardware Maintenance Manual

(1.7

kgfcm)

Table 23. Removal steps of fan assembly (continued)

ThinkPad SL400 and SL500 79

Table 24. Installation of the fan assembly

When installing:

v Before you attach the fan assembly to the computer, apply thermal grease, at an

amount of 0.2 grams, on the part marked a as in the following figure. Either too much or too less application of grease can cause a thermal problem due to imperfect contact with a component. In some modes, you need to peel the thin film off from the rubber b.

v Make sure that the fan connector is attached firmly.

v For ThinkPad SL400, route the antenna cables as shown in this figure.

80 ThinkPad SL400 and SL500Hardware Maintenance Manual

1130 CPU thermal module

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1100 Thermal door (for ThinkPad SL400)” on page 76 v “1110 Thermal door (for ThinkPad SL500)” on page 77 v “1120 Fan assembly” on page 78

Table 25. Removal steps of CPU thermal module

Step Screw (quantity) Color Torque

1 to 4

M2 × 4 mm, wafer-head, nylon-coated (4) Silver 0.167 Nm

kgfcm)

(1.7

Attention: Do not handle the CPU thermal module roughly. Improper handling of the module can cause distortion or deformation and imperfect contact with components.

ThinkPad SL400 and SL500 81

Table 25. Removal steps of CPU thermal module (continued)

Table 26. Installation of the CPU thermal module

When installing:

v Before you attach the CPU thermal module to the computer, apply thermal

grease, at an amount of 0.2 grams, on the part marked a as in the following figure. Either too much or too less application of grease can cause a thermal problem due to imperfect contact with a component.

v Make sure that the fan connector is attached firmly.

82 ThinkPad SL400 and SL500Hardware Maintenance Manual

1140 CPU

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1100 Thermal door (for ThinkPad SL400)” on page 76 v “1110 Thermal door (for ThinkPad SL500)” on page 77 v “1120 Fan assembly” on page 78 v “1130 CPU thermal module” on page 81

Attention:

CPU is extremely sensitive. When you service the CPU, avoid any

kind of rough handling.

Table 27. Removal steps of CPU

Rotate the head of the screw in the direction shown by arrow 1 to release the lock; then remove the CPU.

When installing: Place the CPU on the CPU socket a, and then rotate the head of the screw in the direction shown by arrow b to secure the CPU.

ThinkPad SL400 and SL500 83

1150 Palm rest (for ThinkPad SL400)

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1030 Hard disk drive (HDD) cover and HDD” on page 65

Note:

models with the fingerprint reader, the sensor is attached to the palm rest

In FRU. If the fingerprint reader has any defects, you can replace it by the procedures given in this section, which are the same for a palm rest with or without a fingerprint reader.

Table 28. Removal steps of palm rest (for ThinkPad SL400)

Step Icon Screw (quantity) Color Torque

1

2 M2 × 12 mm, wafer-head,

M2 × 7 mm, wafer-head, nylon-coated (2)

Black 0.167 Nm

kgfcm)

(1.7

Black 0.167 Nm

nylon-coated (2)

(1.7

kgfcm)

84 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 28. Removal steps of palm rest (for ThinkPad SL400) (continued)

ThinkPad SL400 and SL500 85

1160 Palm rest (for ThinkPad SL500)

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1030 Hard disk drive (HDD) cover and HDD” on page 65

Note:

models with the fingerprint reader, the sensor is attached to the palm rest

In FRU. If the fingerprint reader has any defects, you can replace it by the procedures given in this section, which are the same for a palm rest with or without a fingerprint reader.

Table 29. Removal steps of palm rest (for ThinkPad SL500)

Step Icon Screw (quantity) Color Torque

1

2 M2 × 12 mm, wafer-head,

M2 × 7 mm, wafer-head, nylon-coated (1)

Black 0.167 Nm

kgfcm)

(1.7

Black 0.167 Nm

nylon-coated (4)

(1.7

kgfcm)

86 ThinkPad SL400 and SL500Hardware Maintenance Manual

Table 29. Removal steps of palm rest (for ThinkPad SL500) (continued)

ThinkPad SL400 and SL500 87

1170 Bluetooth daughter card (BDC-2.1)

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1030 Hard disk drive (HDD) cover and HDD” on page 65 v “1150 Palm rest (for ThinkPad SL400)” on page 84 v “1160 Palm rest (for ThinkPad SL500)” on page 86

Table 30. Removal steps of BDC-2.1

Step Screw (quantity) Color Torque

1 M2 × 3 mm, wafer-head, nylon-coated (1) Black 0.167 Nm

When installing: Make sure that connector is attached firmly.

88 ThinkPad SL400 and SL500Hardware Maintenance Manual

(1.7

kgfcm)

1180 Intel Turbo Memory Minicard or Wireless USB adapter

For access, remove these FRUs in order:

Table 31. Removal steps of Intel Turbo Memory Minicard or Wireless USB adapter

Note: Step 1 is only for the models with Wireless USB adapter. For the models with Intel Turbo Memory Minicard, skip step 1.

Step Screw (quantity) Color Torque

2 For Japan

M2 × 3 mm, tamper proof (2) Black 0.189 Nm

kgfcm)

(1.85

Other than Japan

M2 × 3 mm, wafer-head, nylon-coated (2) Black 0.189 Nm

kgfcm)

(1.85

ThinkPad SL400 and SL500 89

Table 31. Removal steps of Intel Turbo Memory Minicard or Wireless USB adapter (continued)

90 ThinkPad SL400 and SL500Hardware Maintenance Manual

1190 Backup battery (for ThinkPad SL400)

DANGER

Use only the battery specified in the parts list for your computer. Any other battery could ignite or explode.

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1030 Hard disk drive (HDD) cover and HDD” on page 65 v “1150 Palm rest (for ThinkPad SL400)” on page 84

Table 32. Removal steps of backup battery (for ThinkPad SL400)

When installing: Make sure that the battery connector is attached firmly.

ThinkPad SL400 and SL500 91

1200 Backup battery (for ThinkPad SL500)

DANGER

Use only the battery specified in the parts list for your computer. Any other battery could ignite or explode.

For access, remove these FRUs in order:

v “1010 Battery pack” on page 63 v “1030 Hard disk drive (HDD) cover and HDD” on page 65 v “1160 Palm rest (for ThinkPad SL500)” on page 86

Table 33. Removal steps of backup battery (for ThinkPad SL500)

When installing: Make sure that the battery connector is attached firmly.

92 ThinkPad SL400 and SL500Hardware Maintenance Manual

IBM SL500 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

About this manual

Safety information

General safety

Electrical safety

Safety inspection guide

Handling devices that are sensitive to electrostatic discharge

Grounding requirements

Safety notices: multilingual translations

Laser compliance statement

Important service information

Strategy for replacing FRUs

Strategy for replacing a hard disk drive

Important notice for replacing a system board

How to use error message

Strategy for replacing FRUs for CTO, CMV, and GAV

Product definition

FRU identification for CTO, CMV, and GAV products

Important information about replacing RoHS compliant FRUs

General checkout

What to do first

Checkout guide

Diagnostics using PC-Doctor for DOS

Testing the computer

Detecting system information with PC-Doctor

PC-Doctor for Windows

PC-Doctor for Rescue and Recovery

Power system checkout

Checking the AC adapter

Checking operational charging

Checking the battery pack

Checking the backup battery

Related service information

Restoring the factory contents by using Product Recovery discs

Passwords

Power-on password

Hard-disk password

Supervisor password

How to remove the power-on password

How to remove the hard-disk password

Power management

Screen blank mode

Standby mode

Hibernation mode

Symptom-to-FRU index

Numeric error codes

Error messages

Beep symptoms

No-beep symptoms

LCD-related symptoms

Intermittent problems

Undetermined problems

ThinkPad SL400 and SL500

Specifications

Status indicators

FRU tests

Fn key combinations

FRU replacement notices

Screw notices

Retaining serial numbers

Restoring the serial number of the system unit

Retaining the UUID

Reading or writing the ECA information

Removing and replacing a FRU

1010 Battery pack

1020 Optical drive

1030 Hard disk drive (HDD) cover and HDD

1040 DIMM slot cover (for ThinkPad SL400)

1050 DIMM slot cover (for ThinkPad SL500)

1060 DIMM

1070 PCI Express Mini Card for wireless LAN/WiMAX

1080 PCI Express Mini Card for wireless WAN (for ThinkPad SL400)

1090 Wireless WAN slot cover and PCI Express Mini Card for wireless WAN (for ThinkPad SL500)

1100 Thermal door (for ThinkPad SL400)

1110 Thermal door (for ThinkPad SL500)

1120 Fan assembly
