iSeries

TCP/IP Configuration and Reference

Version 5

SC41-5420-04



iSeries

TCP/IP Configuration and Reference

Version 5

SC41-5420-04

Note

Before using this information and the product it supports, be sure to read the information in “Notices” on page 93.

Fifth Edition (May 2001)

This edition replaces SC41-5420-03. This edition applies only to reduced instruction set computer (RISC) systems.

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

About TCP/IP Configuration and

Reference (SC41-5420) ........v

Prerequisite and related information . . vii

OperationsNavigator...........vii

How to send your comments .....ix

Summary of changes .........xi

Chapter 1. Configuring TCP/IP .....1

What you need to know before you can configure

TCP/IP ................1

Planning for TCP/IP Installation and Configuration . 2

Gathering Information About your Network . . . 2

TCP/IP Planning Checklists .........3

Line Description Parameters Checklist .....3

Local TCP/IP Host Information Checklist....4

Installing the TCP/IP Application Programs ....5

Using the TCP/IP Administration Menu .....6

Using the Configure TCP/IP Menu .......7

Configuring TCP/IP using the EZ-Setup Wizard . . 9 Configuring TCP/IP using the Command Line

Interface ................9

Step 1—Configuring a Line Description ....10

Step 2—Configuring a TCP/IP Interface ....10

Step 3—Configuring TCP/IP Routes .....12

Step 4—Configuring TCP/IP attributes ....16

Step 5—Configuring TCP/IP Remote System

Information(X.25)...........16

Step 6—Configuring TCP/IP Host Table Entries 18

Adding an Entry to the Host Table ....18

Work with TCP/IP Host Table Display . . . 19

AnyNet/400: APPC over TCP/IP .....22

Step 7—Configuring the Local Domain and Host

Name...............22

Domain Name System (DNS) Server ....23

Step 8—Starting TCP/IP and TCP/IP Servers . . 24

TCP/IP Jobs ............25

End TCP/IP (ENDTCP) .......26

Step 9—Verifying the TCP/IP Connection . . . 26 Verifying Additional TCP/IP Connections . . . 27

Verifying TCP/IP Connections with Host

Name—Example...........29

Verifying TCP/IP Connections with Internet

Address—Example ..........30

Step 10—Saving Your TCP/IP Configuration . . 30

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics . . 33

NetworkStatus.............33

Work with TCP/IP Network Status Menu . . . 33

Work with TCP/IP Interface Status .....34

Starting TCP/IP Interfaces .......35

Ending TCP/IP Interfaces .......36

Route-to-Interface Binding ......36

Display TCP/IP Route Information .....37

Work with TCP/IP Connection Status ....38

Ending TCP/IP Connections.......40

WorkingwithConfigurationStatus.....41

Displaying TCP/IP Network Status Information 42

Display Multicast Groups........42

Displaying TCP/IP Interfaces ......43

DisplayingAssociatedRoutes......44

Displaying Route Details Option .....45

Displaying TCP/IP Route Information . . . 46

Displaying TCP/IP Connections .....48

Displaying Connection Totals ......49

TCP/IP Host Tables ...........50

Managing TCP/IP Host Tables ........51

HostFileFormats...........51

Host Table Information with *AIX Files . . . 51

Host Table Information with *NIC Files . . . 51

Host Table Information with *AS400 Files . . 52

TipsforMergingHostTables.......52

Merging TCP/IP Host Tables .......52

Example: Successful Host Table Merge . . . 53

Example: Partly Successful Host Table Merge 53 Managing the Host Table from a Central Site . . 53

Step 1—Create the Host Table on Your Central

System ..............53

Step 2—Start FTP to a Remote System . . . 53

Step 3—Tell FTP to Send the Host File to the

Remote System ...........53

Step 4—MergetheFile ........54

IP Routing and Internet Control Message Protocol

(ICMP) Redirecting ............54

Dead Gateway Processing .........55

Negative Advice from TCP or the Data Link

Layer ...............55

How IP Responds to Negative Advice ....56

Multihoming Function...........56

Example: A Single Host on a Network over a

CommunicationsLine..........57

Example: Multiple Hosts on the Same Network

overtheSameCommunicationsLine.....57

Example: Multiple Hosts on the Same Network

over Multiple Communications Lines.....57

Example: Multiple Hosts on Different Networks

overtheSameCommunicationsLine.....58

Example: Multiple Hosts on Different Networks

over Multiple Communications Lines.....58

Example: The Multihoming function ......59

TypeofService(TOS)..........60

TOS Example ............61

Multiple Routes ............61

TCP/IP Port Restriction ..........62

Configuring TCP/IP Port Restrictions ....63

RelatedTablesandtheHostTable.......65

Using X.25 PVC instead of SVC .......67

IP Multicasting .............68

Multicast Application Programming Information 68

Multicast Restrictions ..........68

Chapter 3. TCP/IP Performance ....71

*BASE Pool Size .............71

TCP/IP Jobs ..............71

TCP/IP Protocol Support Provided by IOP ....71

Merge Host Table Performance ........73

Running TCP/IP Only: Performance Considerations 73

Appendix A. Configuring a Physical

Line for TCP/IP Communication ....75

ConfigurationSteps ...........76

Creating the Line Description .......76

Line Description Name ........76

Source Service Access Point .......76

Setting the Maximum Transmission Unit . . . 77 Determining the Maximum Size of Datagrams. . 77

Appendix B. TCP/IP Application Exit

Points and Programs ........79

TCP/IP Exit Points and Exit Programs .....79

OS/400 Registration Facility .........80

TCP/IP Application Exit Points........80

CreatingExitPrograms..........81

Adding Your Exit Program to the Registration

Facility ...............81

Step 1. Select your exit point ......82

Step 2: Select the Add Exit Program option . . 83

Step 3: Add your exit program ......83

RemovingExitPrograms.........84

Exit Point Interfaces for TCP/IP Application Exit

Points................85

TCP/IP Application Request Validation Exit

Point Interface ............85

Required Parameter Group .......85

UsageNotes............87

Remote Execution Server Command Processing

Selection Exit Point ...........89

|| || ||

Required Parameter Group .......89

UsageNotes............90

Notices ..............93

Programming Interface Information ......94

Trademarks..............94

Index ...............97

OS/400 TCP/IP Configuration and Reference V5R1

About TCP/IP Configuration and Reference (SC41-5420)

This book contains information about configuring Transmission Control Protocol/Internet Protocol (TCP/IP) and operating and managing your network. Most topics have been moved to the Information Center.

Note: This book contains links to various topics within the Information Center and

to references outside the Information Center. The URL addresses for these links are current for V5R1.

vi OS/400 TCP/IP Configuration and Reference V5R1

Prerequisite and related information

Use the iSeries Information Center as your starting point for looking up iSeries and AS/400e technical information. You can access the Information Center two ways:

v From the following Web site:

http://www.ibm.com/eserver/iseries/infocenter

v From CD-ROMs that ship with your Operating System/400 order:

iSeries Information Center, SK3T-4091-00. This package also includes the PDF versions of iSeries manuals, iSeries Information Center: Supplemental Manuals, SK3T-4092-00, which replaces the Softcopy Library CD-ROM.

The iSeries Information Center contains advisors and important topics such as CL commands, system application programming interfaces (APIs), logical partitions, clustering, Java links to related IBM the Technical Studio and the IBM home page.

With every new hardware order, you receive the following CD-ROM information:

v iSeries 400 Installation and Service Library, SK3T-4096-00. This CD-ROM contains

PDF manuals needed for installation and system maintenance of an IBM ~ iSeries 400 server.

v iSeries 400 Setup and Operations CD-ROM, SK3T-4098-00. This CD-ROM contains

IBM iSeries Client Access Express for Windows and the EZ-Setup wizard. Client Access connecting PCs to iSeries servers. The EZ-Setup wizard automates many of the iSeries setup tasks.

™

, TCP/IP, Web serving, and secured networks. It also includes

Redbooks and Internet links to other IBM Web sites such as

™

Express offers a powerful set of client and server capabilities for

Operations Navigator

IBM iSeries Operations Navigator is a powerful graphical interface for managing your iSeries and AS/400e servers. Operations Navigator functionality includes system navigation, configuration, planning capabilities, and online help to guide you through your tasks. Operations Navigator makes operation and administration of the server easier and more productive and is the only user interface to the new, advanced features of the OS/400 operating system. It also includes Management Central for managing multiple servers from a central server.

For more information on Operations Navigator, see the iSeries Information Center.

viii OS/400 TCP/IP Configuration and Reference V5R1

How to send your comments

Your feedback is important in helping to provide the most accurate and high-quality information. If you have any comments about this book or any other iSeries documentation, fill out the readers’ comment form at the back of this book.

v If you prefer to send comments by mail, use the readers’ comment form with the

address that is printed on the back. If you are mailing a readers’ comment form from a country other than the United States, you can give the form to the local IBM branch office or IBM representative for postage-paid mailing.

v If you prefer to send comments by FAX, use either of the following numbers:

– United States, Canada, and Puerto Rico: 1-800-937-3430

– Other countries: 1-507-253-5192

v If you prefer to send comments electronically, use one of these e-mail addresses:

– Comments on books:

RCHCLERK@us.ibm.com

– Comments on the iSeries Information Center:

RCHINFOC@us.ibm.com

Be sure to include the following:

v The name of the book or iSeries Information Center topic.

v The publication number of a book.

v The page number or topic of a book to which your comment applies.

x OS/400 TCP/IP Configuration and Reference V5R1

Summary of changes

This is the fifth edition of TCP/IP Configuration and Reference.

Most topics from the fourth edition of TCP/IP Configuration and Reference have been moved to the iSeries Information Center. See the iSeries Information Center for information on the following relocated topics:

v Bootstrap Protocol (BOOTP)

v Domain Name Server (DNS)

v Dynamic Host Configuration Protocol (DHCP)

v File Transfer Protocol (FTP)

v Line Printer Daemon (LPD)

v Line Printer Requester (LPR)

v Point-to-Point Protocol (PPP)

v Post Office Protocol (POP)

v Remote Execution (REXEC)

v Route Daemon (RouteD)

v Telnet

v Trivial File Transfer Protocol (TFTP)

v Troubleshooting

v Workstation Gateway Server (WSG)

This edition of TCP/IP Configuration and Reference retains basic information on configuring Transmission Control Protocol/Internet Protocol (TCP/IP) and operating and managing the network.

New features in this edition include the EZ Setup Wizard as the preferred method for configuring TCP/IP on the iSeries and the addition of links to supplementary information in the iSeries Information Center and on the World Wide Web.

xii OS/400 TCP/IP Configuration and Reference V5R1

Chapter 1. Configuring TCP/IP

This chapter explains how to configure an iSeries 400®server for Transmission Control Protocol/Internet Protocol (TCP/IP). If this is the first time that you have configured TCP/IP on an iSeries, you should read the entire chapter before performing any of the configuration tasks.

If you are unfamiliar with TCP/IP, see TCP/IP (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/ rzahgictcp2.htm) in the Information Center, refer to the Manuals and Redbooks topic, and select IBM redbook TCP/IP Tutorial and Technical Overview as a resource. For a complete formal description of TCP/IP, you can read the Request for Comments (RFC). Or, refer to any of the TCP/IP references that are listed on the RFC Editor Site (http://www.rfc-editor.org/rfc.html).

What you need to know before you can configure TCP/IP

Before you start configuring TCP/IP, you must ensure that the TCP/IP Connectivity Utilities for AS/400

“Installing the TCP/IP Application Programs” on page 5 for more information.

The iSeries has many commands and menus available to help you configure TCP/IP on the server. Before you begin this task, take time to review the TCP/IP Administration (TCPADM) menu, Figure 1 on page 6, and the Configure TCP/IP (CGFTCP) menu, Figure 2 on page 8.

The initial displays and menus that are shown when you configure TCP/IP on your system may not contain any entries. The sample command line interface displays in this chapter may already contain data, which was entered for the purpose of example in previous configuration steps.

Performing configuration tasks on a single network or even a simple multiple network requires that you do some planning before configuring TCP/IP on any system in that network, including an iSeries. To help you get started with setting up TCP/IP, this chapter includes complete planning details and checklists.

Once you have designed a plan, follow the step-by-step process that is outlined for you in this chapter. Each step guides you through TCP/IP installation and configuration on your system, defines various terms, and describes how these terms relate to TCP/IP.

Using the Operations Navigator interface: After initial setup and configuration, you can customize your TCP/IP through Operations Navigator. Information related to Operations Navigator is located in the online help and on the Operations Navigator (http://www.as400.ibm.com/oper_nav/index.htm) Web page. See the online help in Operations Navigator for information about the following TCP/IP functions:

v Configuring TCP/IP, including basic functions such as starting and stopping

TCP/IP

v Creating a new Ethernet line

v Creating a new token-ring line

v Working with TCP/IP interfaces, including configuring a TCP/IP route

licensed program (LP) is installed on your system. See

v Working with TCP/IP host tables, including configuring a TCP/IP host name

and domain name

v Verifying a TCP/IP connection (PING)

Planning for TCP/IP Installation and Configuration

If you are in charge of configuring an iSeries server for TCP/IP communications you will, in most cases, include your server in an existing TCP/IP network. Before you are able to start configuring, you will need to collect all of the required information. Use Table 1 on page 3 and Table 2 on page 4 as checklists to record this information.

Gathering Information About your Network

After collecting the preliminary information about your network, plan the installation and configuration of TCP/IP by using the steps that are listed below:

1. Draw a diagram of your network: A diagram will help you decide how you

want to attach your iSeries server to the other systems in the network. Include data that relates to your network, such as:

v Line description information

v Internet Protocol addresses and domain names

v The number of route entries that are required

Refer to Table 1 on page 3.

2. Identify the names of the systems in your network: For example, do either of

the following:

v Build a local host table.

v Identify a Domain Name System (DNS) server for maintaining host table

entries.

3. Install the appropriate hardware and software: You must install the

appropriate hardware adapters in your server if you are going to connect to the following networks:

v X.25 packet-switching

v Frame relay

v Token-ring

v Ethernet

v Fiber distributed data interface (FDDI)

v Shielded twisted pair distributed data interface (SDDI)

v Wireless local area network (LAN)

v Synchronous or asynchronous communications line

v Twinaxial data link support (TDLC)

You also need to make sure that the appropriate software is installed on all the systems. On the iSeries server, the OS/400 licensed program and the TCP/IP Connectivity Utilities for iSeries licensed program must be installed.

4. Assign names and Internet addresses: If you are attaching to an existing

network, you need to know the Internet addresses and names used by the other systems.

Depending on the size of your network and its complexities, determine whether a host table or a DNS server is the preferred method for maintaining and updating host name and IP address associations. In this chapter, refer to

2 OS/400 TCP/IP Configuration and Reference V5R1

“Step 6—Configuring TCP/IP Host Table Entries” on page 18. For information about configuring and using a DNS server, see DNS(http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzakk/ rzakkkickoff.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

5. Obtain X.25 network addresses: If you plan to use TCP/IP on an X.25 private

or public data network, you need to know whether you will be using a switched virtual circuit (SVC) or permanent virtual circuit (PVC).

v To use an SVC, you need to know the network address of each remote

system in the network with which you want to communicate.

v To use a PVC, you need to know the related logical channel identifier. You

can have a network address or a permanent virtual circuit, but not both, for a remote system information entry.

If a remote system is an iSeries, you can determine its network address by using the Display Line Description (DSPLIND) command on that remote system.

6. Familiarize yourself with the TCP/IP Administration Menu: The TCP/IP

Administration menu (Figure 1 on page 6) provides easy access to common functions associated with administering TCP/IP.

To get to this menu, enter the GO TCPADM command from the iSeries Main Menu.

7. Familiarize yourself with the Configure TCP/IP Menu: The Configure TCP/IP

menu (Figure 2 on page 8) guides you through all the tasks for configuring your server to communicate with other systems in a TCP/IP network.

You can reach this menu in two ways:

v Select option 1 on the TCPADM menu.

v Enter the Configure TCP/IP (CFGTCP) command.

TCP/IP Planning Checklists

The following checklists (Table 1 and Table 2 on page 4) can help you prepare for the installation and configuration of TCP/IP on your network

v Line description parameters

v Local TCP/IP host information

Line Description Parameters Checklist

Table 1. Line Description Parameters

Line Type *ELAN *TRLAN *WLS *DDI *FR *X25 *ASYNC *PPP *TDLC

Resource name R R R R R R R

Local adapter address O O O O

Speed O OOOO O O

SSAP (session services access point)

Maximumframesize O O OOOO O O

Local manager mode O

Attached non-switched NWI name

Data link connection ID R

O O OOO

Chapter 1. Configuring TCP/IP 3

Table 1. Line Description Parameters (continued)

Line Type *ELAN *TRLAN *WLS *DDI *FR *X25 *ASYNC *PPP *TDLC

Network controller R

Connection type R

Logical channel identifier

Logical channel type R

PVC (permanent virtual circuit) controller

Local network address R

Physical interface type O

Packet size O

Window size O

Attached workstation controller

Note:

R means the parameter is required

O means OS/400 suggests a default value

Local TCP/IP Host Information Checklist

Table 2. Local TCP/IP Host Information

Interfaces to Local TCP/IP Networks

Interface #1 Interface #2 Interface #3

Internet address

Line description name

Subnet mask

Interface MTU

Local host name

Local domain name

Domain name server (Internet address)

Default route/next hop (Internet address)

IP datagram forwarding (yes or no)

Explicit Routes to Remote TCP/IP Networks

Route #1 Route #2 Route #3

Internet address

Subnet mask

Next hop (Internet address)

MTU size

Local Host Table Entries: Remote TCP/IP Hosts

Internet address Host Name #1 Host Name #2 Host Name #3

4 OS/400 TCP/IP Configuration and Reference V5R1

Table 2. Local TCP/IP Host Information (continued)

X.25 / Remote System Information

Host #1 Host #2 Host #3

Internet address

X.25 network address

PVC channel ID

Packet or window size

Once you have documented configuration information, you are ready to install the TCP/IP program on your server. The information in the section that follows will help you do that. See “Installing the TCP/IP Application Programs”.

Installing the TCP/IP Application Programs

Important

To determine whether the TCP/IP LP is already installed, enter GO LICPGM (Go Licensed Program) on the command line and then select Option 10 to display the installed licensed programs. If the TCP/IP Connectivity Utilities LP is not installed on your system, continue by following the instructions in this section to perform the installation.

Installing TCP/IP on your iSeries server allows you to connect an iSeries to a network.

Perform the following steps to install TCP/IP on your server:

1. Insert your installation media for TCP/IP into your server. If your installation

media is a CD-ROM, insert it into your optical device. If your installation media is a tape, insert it into your tape drive.

2. Type GO LICPGM at the command prompt and press Enter to access the Work with Licensed Programs display.

3. Select option 11 (Install licensed programs) on the Work with Licensed Programs display to see a list of licensed programs and optional parts of

licensed programs.

4. Type 1 in the option column next to 5769TC1 TCP/IP Connectivity Utilities for AS/400 licensed program. The Confirm Licensed Programs to Install display

shows the licensed program you selected to install. Press Enter to confirm.

5. Fill in the following choices on the Install Options display:

v Installation Device

Type OPT01, if installing from a CD drive.

Type TAP01, if installing from a tape drive.

v Objects to Install

The Objects to Install option allows you to install both programs and language objects, only programs, or only language objects.

Chapter 1. Configuring TCP/IP 5

v Automatic IPL

The Automatic IPL option determines whether the system automatically starts when the installation process has completed successfully.

When TCP/IP successfully installs, either the Work with Licensed Programs menu or the Sign On display appears.

6. Select option 50 (Display log for messages) to verify that you have installed the

licensed program successfully. If an error occurs, you will see the message Work with licensed program function not complete on the bottom of the Work with Licensed Programs display.

To use TCP/IP, you must configure it after you have completed the installation. See “Configuring TCP/IP using the EZ-Setup Wizard” on page 9.

Using the TCP/IP Administration Menu

The TCP/IP Administration menu (Figure 1) is a starting point for the configuration tasks. To display the menu, enter GO TCPADM from the iSeries Main Menu.

TCPADM TCP/IP Administration

Select one of the following:

1. Configure TCP/IP

2. Configure TCP/IP applications

3. Start TCP/IP

4. End TCP/IP

5. Start TCP/IP servers

6. End TCP/IP servers

7. Work with TCP/IP network status

8. Verify TCP/IP connection

9. Start TCP/IP FTP session

10. Start TCP/IP TELNET session

11. Send TCP/IP spooled file

20. Work with TCP/IP jobs in QSYSWRK subsystem

Selection or command ===>

F3=Exit F4=Prompt F9=Retrieve F12=Cancel

Figure 1. TCP/IP Administration Menu

System: RC

Following are descriptions of the menu options.

v Option 1. Configure TCP/IP: Displays the Configure TCP/IP menu. Use the

options on this menu to configure your local server to communicate with other systems in a TCP/IP network.

v Option 2. Configure TCP/IP applications: Displays the Configure TCP/IP

Applications menu. Use the options on this menu to configure the TCP/IP licensed program (5769-TC1) applications installed on your system.

v Option 3. Start TCP/IP: Select this option to issue the Start TCP/IP (STRTCP)

command. This command initializes and activates TCP/IP processing, starts the TCP/IP interfaces, and starts the TCP/IP server jobs.

v Option 4. End TCP/IP: Select this option to issue the End TCP/IP (ENDTCP)

command. This command is used to end all TCP/IP processing on this system.

6 OS/400 TCP/IP Configuration and Reference V5R1

v Option 5. Start TCP/IP servers: Select this option to issue the Start TCP/IP

Server (STRTCPSVR) command. This command is used to start the TCP/IP application servers that are shipped with OS/400

or the TCP/IP licensed program (5769-TC1). This command starts the TCP/IP application server jobs in the QSYSWRK subsystem.

v Option 6. End TCP/IP servers: Select this option to issue the End TCP/IP Server

(ENDTCPSVR) command. This command is used to end the TCP/IP application servers that are shipped with OS/400 or the TCP/IP licensed program (5769-TC1). This command ends the TCP/IP application server jobs in the QSYSWRK subsystem.

v Option 7. Work with TCP/IP network status: Select this option to issue the

Work with TCP/IP Network Status (WRKTCPSTS) command. This command is used to view and manage the status information of your TCP/IP and IP over Systems Network Architecture (SNA) interfaces, routes, and connections. This command is the iSeries version of the TCP/IP NETSTAT (Network Status) command. NETSTAT is also shipped as an iSeries command.

v Option 8. Verify TCP/IP connection: Select this option to issue the Verify

TCP/IP Connection (VFYTCPCNN) command. This command tests the TCP/IP connection between your system and a remote system. The VFYTCPCNN command is the iSeries version of the TCP/IP PING (Packet InterNet Groper) command. PING is also shipped as an iSeries command.

v Option 9. Start TCP/IP FTP session: Select this option to issue the Start TCP/IP

FTP (STRTCPFTP) command. This command is used to start a file transfer using TCP/IP. This command is the iSeries version of the TCP/IP FTP (File Transfer Protocol) command. FTP is also shipped as an iSeries command.

v Option 10. Start TCP/IP TELNET session: Select this option to issue the Start

TCP/IP TELNET (STRTCPTELN) command. This command is used to start a TELNET client session with a remote system. This command is the iSeries version of the TCP/IP TELNET command. TELNET is also shipped as an iSeries command.

v Option 11. Send TCP/IP spooled file: Select this option to issue the Send

TCP/IP Spooled File (SNDTCPSPLF) command. This command sends a spooled file to be printed on a remote system. The remote system must be running TCP/IP. The SNDTCPSPLF command is the iSeries version of the TCP/IP LPR (line printer requester) command. LPR is also shipped as an iSeries command.

v Option 20. Work with TCP/IP jobs in QSYSWRK subsystem: Select this option

to work with the status and performance information for the active TCP/IP jobs in the QSYSWRK subsystem. This option issues the Work with Active Jobs (WRKACTJOB) command with these parameters:

WRKACTJOB SBS(QSYSWRK) JOB(QT*)

Using the Configure TCP/IP Menu

The Configure TCP/IP menu is shown here (Figure 2 on page 8) so that you are familiar with all of the options available during configuration of the TCP/IP network. To get to this menu, select option 1 on the TCPADM menu or enter the Configure TCP/IP (CFGTCP) command.

Chapter 1. Configuring TCP/IP 7

CFGTCP Configure TCP/IP

Select one of the following:

1. Work with TCP/IP interfaces

2. Work with TCP/IP routes

3. Change TCP/IP attributes

4. Work with TCP/IP port restrictions

5. Work with TCP/IP remote system information

10. Work with TCP/IP host table entries

11. Merge TCP/IP host table

12. Change TCP/IP domain information

20. Configure TCP/IP applications

21. Configure related tables

22. Configure point-to-point TCP/IP

Selection or command ===>

F3=Exit F4=Prompt F9=Retrieve F12=Cancel

Figure 2. Configure TCP/IP Menu

System: SYSNAM890

Following are descriptions of the Configure TCP/IP menu options.

v Option 1. Work with TCP/IP interfaces: Select this option to add TCP/IP

interface information to the list of current interfaces or to display, change, print, or remove TCP/IP interface information that you have already added. Select this option to start or end a TCP/IP interface.

v Option 2. Work with TCP/IP routes: Select this option to add route information

or to display, change, print, or remove route information that you have already added.

v Option 3. Change TCP/IP attributes: Select this option to run the Change

TCP/IP Attributes (CHGTCPA) command.

With this option you can change User Datagram Protocol (UDP) checksum processing, IP datagram forwarding, IP time-to-live values, and other attributes that relate to the TCP/IP protocol stack.

v Option 4. Work with TCP/IP port restrictions: Select this option to add port

restrictions or to display, remove, or print port restrictions that you have already added.

v Option 5. Work with TCP/IP remote system information: Select this option to

add or remove X.25 data network addresses or to print the list.

v Option 10. Work with TCP/IP host table entries: Select this option to add host

IP addresses and their associated host names to the host table or to display, change, print, rename, or remove items that you have already added.

v Option 11. Merge TCP/IP host table: Select this option to merge or replace a

local host table by using the Merge TCP/IP Host Table (MRGTCPHT) command.

v Option 12. Change TCP/IP domain information: Select this option to change

TCP/IP domain information.

Note: Prior to Version 4 Release 2, the Configure TCP/IP menu contained both

an option 12 and an option 13. In Version 4 Release 2, the functions of options 12 and 13 were combined, and option 13 (Change Remote name

8 OS/400 TCP/IP Configuration and Reference V5R1

server) was removed from the menu. Option 12, formerly Change local domain and host names, was renamed to Change TCP/IP domain information.

v Option 20. Configure TCP/IP applications: Select this option to configure the

TCP/IP applications that are installed on your system. The list of applications varies depending on whether the TCP/IP licensed program is installed on your system. If the TCP/IP licensed program is not installed on your system, you can configure only the following server applications:

– Simple Network Management Protocol (SNMP)

– Bootstrap Protocol (BOOTP) server

– Trivial File Transfer Protocol (TFTP) server

– Route Daemon (RouteD)

If the TCP/IP licensed program is installed on your system, you can configure the following server applications:

– Simple Mail Transfer Protocol (SMTP)

– File Transfer Protocol (FTP), TELNET

– Post Office Protocol (POP) Version 3 mail server

– Line Printer Daemon (LPD)

– Remote Execution (REXEC) server

– Workstation gateway applications

– Simple Network Management Protocol (SNMP)

v Option 21. Configure related tables: Select this option to configure the tables

related to TCP/IP. These tables are:

– Protocol table

Contains a list of protocols used in the Internet.

– Services table

Contains a list of services and the specific port and protocol a service uses.

– Network table

Contains a list of networks and the corresponding IP addresses for that network.

v Option 22. Configure point-to-point TCP/IP: Select this option to define,

change, or display your TCP/IP point-to-point (SLIP) configuration.

Configuring TCP/IP using the EZ-Setup Wizard

If you are setting up a new iSeries, use the EZ-Setup Wizard to establish a connection and to configure TCP/IP for the first time. The CD-ROM containing the EZ-Setup Wizard is packaged with your new iSeries. The wizard steps you through a process that will get your iSeries up and running.

Note: If you are unable to use the EZ-Setup Wizard, you may use the command

line interface to configure TCP/IP. See the next section for these instructions.

Configuring TCP/IP using the Command Line Interface

The following steps using the command line interface will guide you through configuring TCP/IP on your iSeries server:

1. Configuring line descriptions

2. Configuring TCP/IP interfaces

Chapter 1. Configuring TCP/IP 9

3. Configuring TCP/IP routes

4. Configuring TCP/IP attributes

5. Configuring remote system information (X.25)

6. Configuring host table entries

7. Configuring local domain and host name

8. Starting TCP/IP

9. Verifying TCP/IP connection

10. Saving the TCP/IP configuration

Important Note:

To perform the configuration steps discussed throughout this chapter, you need the special authority of *IOSYSCFG defined in your user profile.

Step 1—Configuring a Line Description

iSeries TCP/IP supports various local area network (LAN) and wide area network (WAN) connection types: Ethernet, token-ring, SDDI and FDDI, wireless LAN, X.25 SVC, and permanent virtual circuit (PVC), Async (for SLIP), Point-to-Point (PPP) and frame relay. Refer to Appendix A. Configuring a Physical Line for TCP/IP Communication for information about how to configure an Ethernet line for TCP/IP communications.

These are the important parameters for configuring a line description:

v Line description name

v Resource name

v Local adapter address

v Ethernet standard

v Source service access point (SSAP) list.

The SSAP X'AA' required for an IEEE 802.3 Ethernet is automatically allocated if you use the *SYSGEN special value.

When TCP/IP starts an interface, the line, controller, and device descriptions are varied on automatically. If the controller and device descriptions for a line do not exist, TCP/IP creates them automatically when it attempts to start an interface using that line. This happens at TCP/IP startup time if the TCP/IP interface that is associated with the newly configured line is set to AUTOSTART *YES.

Step 2—Configuring a TCP/IP Interface

In an iSeries server, each line that connects to a TCP/IP network must be assigned to at least one Internet address. You do this by configuring, or adding a TCP/IP interface. The additional interfaces are logical interfaces, not physical ones. These logical interfaces are associated with a line description.

An interface identifies a direct connection to a network using TCP/IP and a physical medium (communications line). You must consider the following when defining an interface:

Internet address

A 32-bit address assigned to hosts using TCP/IP. It is associated with the line description.

10 OS/400 TCP/IP Configuration and Reference V5R1

Subnet mask

Defines which part of an Internet address forms the subnet (subnetwork) field of an Internet address. An example of a single-network subnet mask is: 255.255.255.128.

Line description

Contains information describing a communications line that is attached to the iSeries server, as defined previously in “Step 1—Configuring a Line Description” on page 10.

To find the names of the currently defined line descriptions, use the Work with Line Descriptions (WRKLIND) command.

Associated local interface

Allows the network to which this interface is attached appear to be part of the same network that the associated local interface is attached to. This is referred to as transparent subnetting.

Transparent subnetting allows TCP/IP traffic to flow between the two physical networks without defining additional routing. This is only valid for broadcast-capable networks. This also requires the Internet address for Add TCP/IP Interface (ADDTCPIFC) to be configured in the same network as the associated local interface. An additional requirement is for the subnet mask that is defined for the associated local interface.

Automatic start

Refers to whether the TCP/IP interface is started automatically whenever TCP/IP is started. The default setting is *YES. If you choose *NO, you must start the interface yourself by using the STRTCPIFC command or by selecting option 9 (Start) on the Work with TCP/IP Interfaces display, as shown in Figure 4 on page 12.

To add a TCP/IP interface, do the following:

1. Enter GO TCPADM to get the TCP/IP Administration menu.

2. Select option 1 to get to the Configure TCP/IP menu.

3. Select option 1 on the Configure TCP/IP menu.

The Work with TCP/IP Interfaces display is shown in Figure 4 on page 12.

4. Type option 1 (Add) at the input-capable top list entry on this display

to go to the Add TCP/IP Interfaces (ADDTCPIFC) display, as shown in Figure 3 on page 12.

(You can go directly to this display by typing ADDTCPIFC command on any command line and pressing F4.)

iSeries TCP/IP supports multihoming, which allows you to specify multiple interfaces for each line description. See “Multihoming Function” on page 56 for further information.

Chapter 1. Configuring TCP/IP 11

Add TCP/IP Interface (ADDTCPIFC)

Type choices, press Enter.

Internet address........

Line description........ Name, *LOOPBACK, *VIRTUALIP

Subnet mask ..........

Associated local interface... *NONE

Type of service ........ *NORMAL *MINDELAY, *MAXTHRPUT...

Maximum transmission unit . . . *LIND 576-16388, *LIND

Autostart ........... *YES *YES, *NO

PVC logical channel identifier 001-FFF

X.25 idle circuit timeout . . . 60 1-600 X.25 maximum virtual circuits . 64 0-64

X.25 DDN interface....... *NO *YES, *NO

TRLAN bit sequencing...... *MSB *MSB, *LSB

+ for more values

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More key

Bottom

Figure 3. Add TCP/IP Interfaces Display

When you are finished adding entries, the Work with TCP/IP Interfaces display looks like Figure 4.

Work with TCP/IP Interfaces

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 9=Start 10=End

Internet Subnet Line Line

Opt Address Mask Description Type

- 9.4.73.129 255.255.255.128 ETHLINE *ELAN

Figure 4. Work with TCP/IP Interfaces Display

System: SYSNAM890

Note: Any change to the TCP/IP interfaces configuration, except for the automatic

start parameter, takes effect immediately.

Step 3—Configuring TCP/IP Routes

Do you need to add routes at all?

If you have several individual networks to which the server is not directly attached, you must add routing entries to allow the server to reach these remote networks.

If your server is attached to a single network and if there are no IP routers in your network, you do not need to add routes.

To reach remote networks, at least one routing entry is required. If no routing entries are manually added, your server cannot reach systems that are not on the

12 OS/400 TCP/IP Configuration and Reference V5R1

same network that the server is attached to. You must also add routing entries to allow TCP/IP clients that are attempting to reach your server from a remote network to function correctly.

For example, suppose that someone using a PC is using the TELNET application to start a remote terminal session on your server. The application on the PC must know the route or path to reach the server. Your server must also be able to determine the route back to the PC. If the PC and your server are not on the same network, a routing entry must exist on the PC and on your server.

Note: You should plan to have the routing table defined so that there is always an

entry for at least one default route (*DFTROUTE). If there is no match on any other entry in the routing table, data is sent to the IP router specified by the first available default route entry. The only exception to this is if you intend to dial out over a SLIP link to an Internet Service Provider or another remote host.

Before adding routing entries, familiarize yourself with the following terms:

Route destination

The network ID portion of an Internet address. The network ID portion is composed of the first byte, the first two bytes, or the first three bytes of the Internet address (depending on the network class). The remaining bytes define the host ID portion of the Internet address.

If subnetting is used, route destination includes the subnet part as well. In other words, the route destination equals the address of a TCP/IP

network to be reached.

Subnet mask

A bit mask that defines which part of an Internet address forms the network and the subnetwork.

The technique known as subnet addressing, subnet routing,orsubnetting allows a single network ID to be used on multiple physical networks. This technique lets you define separate routes to different sets of Internet addresses within a specific network.

Next hop

The Internet address of the first system in the route between your system and the destination network. The next hop value is always an Internet address. Next hops need to be hosts on a directly connected TCP/IP network defined by the TCP/IP interfaces.

Maximum Transmission Unit (MTU) size

The maximum size (in bytes) of IP datagrams sent on a route. If you specify *IFC, the size is calculated for you based on values found in the server line description. The maximum size specified for a particular route must not be larger than the smallest MTU supported by any router or bridge in that route. If you specify a larger size, some datagrams may be lost.

In addition, the MTU specified for a particular route should not be larger than the smallest MTU supported by any system used as an IP router for that route. If you specify a larger size, performance may degrade as systems attempt to divide the IP datagrams into smaller fragments.

For additional information about setting the MTU, see Appendix A. Configuring a Physical Line for TCP/IP Communication.

Chapter 1. Configuring TCP/IP 13

Preferred binding interface

The preferred binding interface allows administrators to choose which of the TCP/IP interfaces that they prefer the route to be bound to or on. This provides the administrator with more flexibility to route traffic over a specific interface. The interface is preferred because the route is bound to the indicated interface if the interface is active. If the indicated interface is not active, then a best-match-first algorithm is used in determining which interface the route is bound.

In Figure 5, a preferred binding interface of *NONE has been defined. By using this definition, the user allows the TCP/IP protocol stack to choose an interface to bind this route to, using a best-match-first algorithm.

Adding TCP/IP routes

You must define routes for any TCP/IP network, including subnetworks, with which you want to communicate. You do not need to define routes for the TCP/IP network that your server is directly attached to when you are using an iSeries adapter.

Manual configuration of the routes that tell TCP/IP how to reach the local networks is not required. iSeries TCP/IP generates these routes automatically from the configuration information for the interfaces every time TCP/IP is started. In other words, the direct route to the network, which has an interface attached, is automatically created when you add the interface.

To display all routing entries, including direct routes, use the Network Status (NETSTAT) command after starting TCP/IP.

To add a route, type option 2 on the Configure TCP/IP menu. The Work with TCP/IP Routes display (Figure 5) is shown.

Work with TCP/IP Routes

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display

Route Subnet Next Preferred

Opt Destination Mask Hop Interface

_ ________________ _______________ _______________ _ *DFTROUTE *NONE 9.4.73.193 *NONE

Figure 5. Work with TCP/IP Routes Display

System: SYSNAM890

Type option 1 (Add) at the input-capable top list entry on that display to go to the Add TCP/IP Route (ADDTCPRTE) display, as shown in Figure 6

on page 15.

(To go directly to this display, type the ADDTCPRTE command on any command line and press F4.)

14 OS/400 TCP/IP Configuration and Reference V5R1

Add TCP/IP Route (ADDTCPRTE)

Type choices, press Enter.

Route destination .......> '9.4.6.128'

Subnet mask ..........> '255.255.255.128'

Type of service ........ *NORMAL *MINDELAY, *MAXTHRPUT...

Next hop............> '9.4.73.193'

Preferred binding interface . . *NONE Maximum transmission unit . . . 576 576-16388, *IFC

Route metric.......... 1 1-16

Route redistribution...... *NO *NO, *YES

Duplicate route priority.... 5 1-10

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More keys

Figure 6. Add TCP/IP Routes Display

Note: Any changes that you make to the routing information take effect

immediately.

Work with TCP/IP Routes

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display

Route Subnet Next Preferred

Opt Destination Mask Hop Interface

_ ________________ _______________ _______________ _ *DFTROUTE *NONE 9.4.73.193 *NONE _ 9.4.6.128 255.255.255.128 9.4.73.193

Figure 7. Work with TCP/IP Routes Display

Multiple Default Routes

Default routes are used to route data that is being addressed to a remote destination and that does not have a specific route defined. Default routes are based on the availability of the next hop router and the type of service (TOS). If no specific TOS is requested, the first available default route with TOS of *NORMAL is used.

Bottom

If a default route is not defined, only the networks explicitly defined by any non-default routes appear as though TCP/IP can reach them, and datagrams bound for any undefined networks are not sent.

Note: A default route cannot have a subnetwork; therefore, you must leave

the subnet mask at the default value of *NONE.

Consult “Multiple Routes” on page 61 for further information about multiple default routes and the type of service (TOS) parameter.

Chapter 1. Configuring TCP/IP 15

Step 4—Configuring TCP/IP attributes

To configure the TCP/IP attributes, type option 3 on the Configure TCP/IP menu. The Change TCP/IP Attributes (CHGTCPA) display is shown (Figure 8).

Change TCP/IP Attributes (CHGTCPA)

Type choices, press Enter.

TCP keep alive......... 120 1-40320, *SAME, *DFT

TCP urgent pointer....... *BSD *SAME, *BSD, *RFC

TCP receive buffer size .... 8192 512-8388608, *SAME, *DFT

TCP send buffer size...... 8192 512-8388608, *SAME, *DFT

UDP checksum.......... *YES *SAME, *YES, *NO

IP datagram forwarding..... *YES *SAME, *YES, *NO

IP source routing ....... *YES *SAME, *YES, *NO

IP reassembly time-out..... 10 5-120, *SAME, *DFT

IP time to live ........ 64 1-255, *SAME, *DFT

ARP cache timeout ....... 5 1-1440, *SAME, *DFT

Log protocol errors ...... *YES *SAME, *YES, *NO

Figure 8. Change TCP/IP Attributes Display

For information about the various parameters for this command, see the online help. In this step only the IP Datagram Forwarding (IPDTGFWD) parameter is discussed.

IP Datagram Forwarding

Specifies whether your system should forward datagrams destined for other networks. The default value is *NO.

Step 5—Configuring TCP/IP Remote System Information (X.25)

Note: If you are not using X.25, then proceed to “Step 6—Configuring TCP/IP

Host Table Entries” on page 18.

If you use an X.25 connection to reach TCP/IP hosts with a public or private packet switched data network (PSDN), you need to add remote system information for each remote TCP/IP host. You must define the X.25 network address of each system if you use a switched virtual circuit (SVC). If a permanent virtual circuit (PVC) is set up by the network connecting your system with your remote TCP/IP partner, you need to know the local logical channel identifier of this PVC.

Adding Remote System Information (X.25)

To add an X.25 remote system address, type option 5 on the Configure TCP/IP menu. The Work with the TCP/IP Remote System Information display appears, as shown in Figure 9 on page 17.

16 OS/400 TCP/IP Configuration and Reference V5R1

Work with TCP/IP Remote System Information

Type options, press Enter.

1=Add 4=Remove 5=Display

System: SYSNAM890

Opt Address Address PVC Charges

Internet Network Reverse

_ _______________

(No remote system information)

Figure 9. Work with Remote System (X.25) Information

Type option 1 (Add) at the input-capable top list entry to go to the Add TCP/IP Remote System (ADDTCPRSI) display, as shown in Figure 10.

Add TCP/IP Remote System (ADDTCPRSI)

Type choices, press Enter.

Internet address........>'9.4.73.66'

Network address ........>40030002

PVC logical channel identifier 001-FFF

X.25 reverse charge ...... *NONE *NONE, *REQUEST, *ACCEPT

Additional Parameters

Default packet size:

Transmit packet size..... *LIND *LIND, 64, 128, 256, 512...

Receive packet size ..... *LIND *LIND, *TRANSMIT, 64, 128...

Default window size:

Transmit window size..... *LIND 1-15, *LIND

Receive window size ..... *LIND 1-15, *LIND, *TRANSMIT

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More keys

Bottom

Figure 10. Add Remote System (X.25) Information

The network controller used by iSeries TCP/IP does not allow you to specify X.25 user facilities. However, some of the values usually configured on a controller, using the ADDTCPRSI command, allow you to configure each X.25 remote system. These values include reverse charging, packet sizes, and window sizes.

Use the following CL command to enter the information as shown in the display above:

ADDTCPRSI INTNETADR('9.4.73.66')

NETADR(40030002)

Notes:

1. Specifying remote system information for an X.25 DDN interface causes that

information to be used instead of the DDN conversion algorithm. The DDN conversion algorithm is used only for a connection with DDN specified as *YES when you try to connect to a host that is not defined in the remote system

Chapter 1. Configuring TCP/IP 17

information. If DDN is specified as *YES on the X.25 connection, you should not specify remote system information for that interface or its associated DDN network systems.

2. A routing error occurs when both of the following are true:

v The remote system information associated with the Internet address is an

extended data terminal equipment (DTE) address.

v The configured X.25 interface’s line does not support X.25 extended

addressing.

Note: Any changes that you make to the remote system information take effect

immediately.

Step 6—Configuring TCP/IP Host Table Entries

Each computer system in your network is called a host. The host table allows you to associate a host name to an Internet address. This step gives instruction for configuring a host table and host table entries. However, you should determine early in the configuration planning if a host table or a Domain Name System (DNS) server is the best option for you in managing host name and IP address translations.

Whenever possible, a DNS server should be used as a replacement for, or in addition to, the local host table. The DNS server is a single source for host names, which is one reason that it is often preferred over host tables, especially for larger networks.

The local host table on your server contains a list of the Internet addresses and related host names for your network. Host tables map Internet addresses to TCP/IP host names. Host tables allow users to use an easily remembered name for a system in a network without having to remember the Internet address.

To configure the mapping of host names to Internet addresses, you can use three different options on the Configure TCP/IP menu. You can use only one or a combination of all three to obtain the host name processing you need for your network. The three options on the Configure TCP/IP menu related to Internet address mappings are:

1. Option 10 (Work with TCP/IP host table entries) to create your own host table.

The Work with Host Table Entries display is shown in Figure 11 on page 19.

2. Option 11 (Merge TCP/IP host table) to merge or convert a host table sent from

another system.

For more information about merging and converting host tables, see “Merging TCP/IP Host Tables” on page 52.

3. Option 12 (Change TCP/IP domain information) to call the following new

command, CHGTCPDMN.

Note: You can start TCP/IP client functions, such as FTP, by specifying the

Internet address directly without using the host table.

For more information about managing host tables, including host file formats, and merging host tables, see “Managing TCP/IP Host Tables” on page 51.

Adding an Entry to the Host Table

The Add TCP/IP Host Table Entry display provides fields for an Internet address, associated host name, and an optional text description.

18 OS/400 TCP/IP Configuration and Reference V5R1

To add an entry to your local host table, type option 10 on the Configure TCP/IP menu. The Work with TCP/IP Host Table Entries display is shown in Figure 11.

Work with TCP/IP Host Table Entries

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 7=Rename

Internet Host

Opt Address Name

_ _______________ _ 127.0.0.1 LOOPBACK

LOCALHOST

System: SYSNAM890

Figure 11. Work with TCP/IP Host Table Entries Display

Note: Just as iSeries TCP/IP automatically creates a LOOPBACK interface, it also

automatically adds an entry to your local host table to associate the IP address 127.0.0.1 with the host names LOOPBACK and LOCALHOST. Type option 1 (Add) at the input-capable top list entry to show the Add TCP/IP Host Table Entry display.

Work with TCP/IP Host Table Display

Figure 12 and Figure 13 on page 20 show how the host table looks after you enter all hosts explicitly known.

Work with TCP/IP Host Table Entries

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 7=Rename

System: SYSNAM890

Internet Host

Opt Address Name

_ _______________ _ 9.4.6.129 ROUTER2 _ 9.4.6.134 HPUX _ 9.4.6.138 SPARKY _ 9.4.6.252 MVAX _ 9.4.73.65 XSYSNAM890 _ 9.4.73.66 XSYSNAM456 _ 9.4.73.129 ESYSNAM890 _ 9.4.73.130 ESYSNAMRS _ 9.4.73.193 ROUTER1 _ 9.4.73.198 SYSNAMRS _ 9.4.73.206 ITALY _ 9.4.73.207 HOLLAND _ 9.4.73.208 ENGLAND

Figure 12. Work with Host Table Entries, Display 1 of 2

More...

Chapter 1. Configuring TCP/IP 19

Work with TCP/IP Host Table Entries

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 7=Rename

Internet Host

Opt Address Name

_ _______________ _ 9.4.73.211 BERN _ 9.4.73.212 SYSNAM890 _ 9.4.73.214 MACIAN _ 9.4.191.76 DNS _ 127.0.0.1 LOOPBACK

LOCALHOST

Figure 13. Work with Host Table Entries, Display 2 of 2

System: SYSNAM890

The iSeries TCP/IP host table is shipped with the LOOPBACK entry. The LOOPBACK entry has an Internet address of 127.0.0.1 and two host names: LOOPBACK and LOCALHOST.

The 127.0.0.1 Internet address can be changed (CHGTCPHTE) and a different one can be added (ADDTCPHTE). The local table command processing programs ensure that any LOOPBACK host name added or changed in the host table is in the range of 127.0.0.1 to 127.255.255.254. Multiple loopback host table entries are allowed in the server host table.

You may alter the LOOPBACK host name or add additional host names using the (CHGTCPHTE) command.

If the LOOPBACK or LOCALHOST name is changed or removed from the host table, the name is not valid, unless the domain name server has a LOOPBACK entry that specifies this value as a host name.

You can define up to four names for each Internet address. If the TCP/IP host is in your local domain, then it is not necessary to qualify the host with the domain name. As long as a TCP/IP host is in your local domain, you need only to enter the host name with the host table entry.

However, if you would like to add TCP/IP hosts that are outside of your local domain, you need to add these TCP/IP hosts as fully qualified. The fully qualified host name of SYSNAMEND.ENDICOTT.IBM.COM shows this as an example in Figure 14

on page 21.

20 OS/400 TCP/IP Configuration and Reference V5R1

Work with TCP/IP Host Table Entries

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 7=Rename

Internet Host

Opt Address Name

_ _______________ _ 9.4.73.211 BERN _ 9.4.73.212 SYSNAM890 _ 9.4.73.214 MACIAN _ 9.4.191.76 DNS _ 9.125.87.127 SYSNAMEND.ENDICOTT.IBM.COM _ 127.0.0.1 LOOPBACK

LOCALHOST

System: SYSNAM890

Figure 14. Example of a Fully Qualified Host Table Entry

Additional host names are useful as alternative nicknames. See the examples in Figure 15.

Host names need not be unique. When searching the host table with a duplicate host name, the result is random. However, IP addresses have to be unique. The uniqueness of the IP address is enforced at the time you try to add a new entry to the host table.

Note: An IP address cannot be used as a host name.

Work with TCP/IP Host Table Entries

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 7=Rename

Internet Host

Opt Address Name

_ _______________ _ 9.4.73.211 BERN _ 9.4.73.212 SYSNAM890

M03 F25

MYSYSTEM _ 9.4.73.214 MACIAN _ 9.4.191.76 DNS _ 9.4.73.198 SYSNAMRS

Figure 15. Multiple Host Names

System: SYSNAM890

To remove one of the additional host names, select option 2 to change the selected host table entry. Type *BLANK over the host name to remove it.

Note: The fully qualified host name is used when sending mail between two

TCP/IP hosts.

Notice in the example that the name of server SYSNAM890 is in the host table too. There are several reasons to put your host name in the host table:

v You may want to use your host name when using FTP, TELNET, or PING to test

your own system’s configuration.

Chapter 1. Configuring TCP/IP 21

v Simple Mail Transfer Protocol (SMTP) requires your host name to be in the host

table or on a domain name server.

v You may want to use your host table on other systems in the network. Your host

name must be in the host table on those systems so they can refer to your system by name.

v Applications written to use host table lookup routines may require this

information.

When you are finished working with the host table, press F3 (Exit) or F12 (Cancel).

AnyNet/400: APPC over TCP/IP

Advanced program-to-program communication (APPC) over TCP/IP support allows Common Programming Interface (CPI) Communications or Intersystem Communications Function (ICF) applications to run over TCP/IP with no changes. To use the APPC over TCP/IP support, the logical unit (LU) name or the remote location that your application uses must be mapped to an Internet address. For APPC over TCP/IP support, the host table is configured to map Internet addresses to LU names. To do this, you can update the TCP/IP host table using the configuration menus. The format for the host name is:

LUNAME.NETID.SNA.IBM.COM

Step 7—Configuring the Local Domain and Host Name

Within TCP/IP, the primary name associated with your system (your system can have more than one name) is called your local domain and host name. The combination of the local domain and host name forms a fully-qualified host name. The fully qualified host name is the name by which your system is known and identified in the TCP/IP domain. The local domain name is also used by sockets to help in host name resolution at the Domain Name System (DNS) server. The Post Office Protocol (POP) and Simple Mail Transfer Protocol (SMTP) mail servers require that the local domain and host name be configured. It is used, but not required, by line printer requester (LPR), File Transfer Protocol (FTP), and Simple Network Management Protocol (SNMP).

A domain name consists of labels that are separated by periods, for example, SYSNAM890.ROCHESTER.IBM.COM. For hosts, the first label in a domain name is the name of a host that belongs in the domain identified by the other labels. In this example, host SYSNAM890 belongs to the domain ROCHESTER.IBM.COM. SYSNAM890.ROCHESTER.IBM.COM is known as the host’s fully qualified domain name.

To define a local domain name and a host name, use option 12 (Change TCP/IP domain information) from the Configure TCP/IP menu (Figure 2 on page 8).

You may need to configure the local domain name if you use a DNS server that requires a fully qualified host name to resolve an Internet address. For more information on how to do that, see DNS (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzakk/ rzakkkickoff.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

The iSeries TCP/IP applications concatenate the local domain name to the host name if a period is not used at the end of the domain name. For an example, see Concatenating the Domain Name to the Host Name

22 OS/400 TCP/IP Configuration and Reference V5R1

(http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzaku/ rzakuconcat.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

To change the local domain name, type option 12 on the Configure TCP/IP menu. The Change TCP/IP domain information display is shown in Figure 16.

Change TCP/IP Domain (CHGTCPDMN)

Type choices, press Enter.

Host name ........... SYSNAM890

Domain name .......... SYSNAM123.IBM.COM

Host name search priority . . . *LOCAL *REMOTE, *LOCAL, *SAME Domain name server:

Internet address....... '9.4.73.129'

Figure 16. Change TCP/IP Domain Information (CHGTCPDMN)

Notes:

1. Changes that you make using the Change TCP/IP domain information

(CHGTCPDMN) command take effect immediately.

2. The local domain name is used by many applications including PING. PING

appends the local domain to a host name if a domain is not specified or if a period (.) does not appear at the end of the specified host name.

Domain Name System (DNS) Server

The conversion from host name to Internet address can be performed by using the host table on the local system or by defining a Domain Name System server, or DNS server.

In large networks with large host tables, it is more convenient to have DNS servers than to have a complete copy of the host table on every host in the network.

A DNS server maintains the host table for an entire TCP/IP domain. This prevents each single host from having to maintain its own local host table.

You can configure your server to use both a DNS server and your local host table, but they are not mutually exclusive. You can also specify whether the domain name server or your local host table is searched first.

For more information about how the Domain Name System works and how to configure a DNS server, see DNS (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzakk/ rzakkkickoff.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Chapter 1. Configuring TCP/IP 23

Step 8—Starting TCP/IP and TCP/IP Servers

Before any TCP/IP services are available on the iSeries system, TCP/IP processing must be initialized and activated. To start TCP/IP, you have two options:

1. Select option 3 from the TCP/IP Administration menu (GO TCPADM),

2. Enter the Start TCP/IP (STRTCP) command.

The STRTCP command initializes and activates TCP/IP processing, starts the TCP/IP interfaces, and starts the TCP/IP server jobs. Only TCP/IP interfaces with AUTOSTART *YES are started at STRTCP time. Allow a few moments for TCP/IP to start, and then check to see if the QTCPIP job has started.

Option 20 of the TCP/IP Administration menu allows you to display the jobs related with TCP/IP. You can also use the following command:

WRKACTJOB SBS(QSYSWRK) JOB(QT*)

The job QTCPIP should be displayed.

Messages indicating that TCP/IP has been started are sent to the QTCP and QSYSOPR message queues. To check for the successful start of TCP/IP, enter either of these commands:

DSPMSG QSYSOPR DSPMSG QTCP

Figure 17 contains a sample of the messages that are issued.

STRTCP issued by job 007138/DJONES/DSP02. QTCPIP job started.

127.0.0.1 interface started. QTCPIP job starting 9.5.5.162 interface.

127.0.0.2 interface started. SNMP Server starting. TELNET Server starting FTP Server starting SMTP Server starting POP Server starting LPD Server starting

9.5.5.162 interface started. STRTCP completed successfully.

Figure 17. Sample Messages from STRTCP with All Applications Autostarted

If the QTCPIP job does not start, look for spooled job logs. Generally, the user for these job logs is QTCP. Use the Work with Spooled Files (WRKSPLF) command and specify QTCP for the user (WRKSPLF QTCP) to find the logs.

Application Servers: The TCP/IP application server jobs run under subsystem QSYSWRK. Several types of TCP/IP server jobs run in the QSYSWRK subsystem. They are the server jobs for TELNET, POP, FTP, SMTP, LPD, BOOTP, TFTP, RouteD, REXEC, and SNMP.

The STRTCP command starts the server jobs for an application if the automatic start attribute for that server is equal to *YES. To change the autostart attribute for an application, do either of the following:

v Select option 2 from the TCP/IP Administration menu

v Option 20 from the TCP/IP Configuration menu

24 OS/400 TCP/IP Configuration and Reference V5R1

Using the Start TCP/IP Server (STRTCPSVR) command starts the servers individually or together. You can monitor the jobs with option 20 (Work with TCP/IP jobs in QSYSWRK subsystem) from the TCP/IP Administration menu.

If you want TCP/IP processing and any related TCP/IP servers to start automatically at the initial program load (IPL), add STRTCP to the QSTRUP CL program.

Note: If they are installed, the Client Access host servers are automatically started

when TCP/IP is started.

| | | | | | |

Changing the IPL Start-Up Program The autostart job in the controlling subsystem transfers control to the program specified in the system value QSTRUPPGM. You can tailor this program. For instructions on how to create your own IPL start-up program, see Work Management (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzaks/rzaks1.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

REMINDER: Host Table Conversion: If you had a pre-V3R1M0 version of TCP/IP installed on your iSeries and you had a local host table with more than 75 entries, use one of the host table configuration commands, such as CHGTCPHTE or MRGTCPHT before you run the STRTCP command. Using the host table configuration commands converts pre-V3R1M0 host tables to the new format without affecting the performance of the STRTCP command processing.

TCP/IP Jobs

Jobs started by the Start TCP/IP (STRTCP) command are listed in Table 3.

Table 3. Jobs Used by TCP/IP

Job Name Description

QAPPCTCP APPC over TCP/IP applications

QTBOOTP BOOTP server

QTCPIP Main TCP/IP job

QTFTPxxxxx FTP server (there may be several)

QTGTELNETS TELNET server (there may be several)

QTRTDxxxxx RouteD server

QTRXCxxxx REXEC server (there may be several)

QTSMTPCLNT SMTP client

QTSMTPSRVR SMTP server

QTSMTPBRCL SMTP bridge client

QTSMTPBRSR SMTP bridge server

QTTFTxxxxx TFTP server (there may be several)

QTMSNMP SNMP server

QTMSNMPRCV SNMP server

QSNMPSA SNMP server

QTLPDxxxxx LPD server (there may be several)

QTPOxxxxxx POP server (there may be several)

QTPPANSxxx Dial-in (*ANS) support (PPP)

QTPPDIALxx Dial-out (*DIAL) support (PPP)

Chapter 1. Configuring TCP/IP 25

Table 3. Jobs Used by TCP/IP (continued)

Job Name Description

ADMIN and DEFAULT ICS (HTTP) server

QTWSGxxxxx Workstation gateway (there may be several)

Note:

1. There may be other jobs running in the QSYSWRK subsystem that have nothing to do

with TCP/IP.

2. The TCP/IP jobs in QSYSWRK run under the QTCP user profile, with two exceptions:

the TFTP server runs under the QTFTP profile, and the workstation gateway server runs under the QTMTWSG profile.

3. To use APPC over TCP/IP applications, you must set the network attribute Allow

AnyNet

(ALWANYNET) to *YES.

End TCP/IP (ENDTCP):

ATTENTION!

No confirmation display appears when you enter ENDTCP is entered. Therefore, you must use the ENDTCP command carefully. The default for the ENDTCP command is to immediately end all TCP/IP processing on the server that you are working on.

Use the End TCP/IP (ENDTCP) command to end all TCP/IP processing.

The command can be issued from the command line or by using option 4 on the TCP/IP Administration menu. To display this menu, enter GO TCPADM on the command line.

Step 9—Verifying the TCP/IP Connection

To verify the TCP/IP connection from your server to the network, use the PING (VFYTCPCNN) function.

1. To test the TCP/IP code without sending anything out of the token-ring

adapter, specify the special host name LOOPBACK as follows:

PING LOOPBACK

2. To test the TCP/IP code, token-ring adapter, and token-ring connection, specify

the Internet address of the local adapter, as defined in the host table, as follows:

PING RMTSYS(*INTNETADR)

INTNETADR('9.4.73.212')

Or you may enter:

PING RMTSYS(SYSNAM890)

This command sends data out onto the token-ring line, which the local adapter receives again as if the data is from the TCP/IP network.

Figure 18 on page 27 shows the results from a successful connection verification.

26 OS/400 TCP/IP Configuration and Reference V5R1

> ping '9.4.73.212'

Verifying connection to host system 9.4.73.212. PING request 1 from 9.4.73.212 took 24 ms. 256 bytes. TTL 64. PING request 2 from 9.4.73.212 took 11 ms. 256 bytes. TTL 64. PING request 3 from 9.4.73.212 took 31 ms. 256 bytes. TTL 64. PING request 4 from 9.4.73.212 took 11 ms. 256 bytes. TTL 64 PING request 5 from 9.4.73.212 took 12 ms. 256 bytes. TTL 64. Round-trip (in milliseconds) min/avg/max = 11/17/31 Connection verification statistics: 5 of 5 successful (100 %).

Figure 18. Successful PING Messages

3. If the PING operation is successful, you should see messages similar to those in

Figure 18.

If the PING operation is unsuccessful, you should see messages similar to those in Figure 19.

If you receive an unsuccessful PING message, check your configuration steps. Also check that the configuration at the remote system is correct and that the remote system is not powered down. For additional information about identifying the cause for an unsuccessful connection verification, see TCP/IP Troubleshooting (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzaku/ rzakuoverview.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

> ping '9.4.73.198'

Verifying connection to host system 9.4.73.198. No response from host within 1 seconds for connection verification 1. No response from host within 1 seconds for connection verification 2. No response from host within 1 seconds for connection verification 3. No response from host within 1 seconds for connection verification 4. No response from host within 1 seconds for connection verification 5. Connection verification statistics: 0 of 5 successful (0 %).

Figure 19. Unsuccessful PING Messages

Bottom

Note: A datagram sent by TCP or UDP to a system with the name LOOPBACK

does not actually leave the system. The IP layer, instead, returns the datagram to the TCP or UDP layer from which it came. The other layers then treat the datagram as a normal incoming datagram. The LOOPBACK host name can be used with any TCP/IP command requiring a system name, such as PING or FTP (or any TCP or UDP application including user-written applications). Using the LOOPBACK default host name provides an ability to test TCP/IP applications without actually connecting to a physical network.

The server defines LOOPBACK as the default host name by automatically creating an entry in the local host table.

Verifying Additional TCP/IP Connections

Once TCP/IP is configured on the iSeries, and the initial connection is verified, you will probably want to add more systems to your network. When you connect

Chapter 1. Configuring TCP/IP 27

additional systems to your network, you also need to verify their TCP/IP connection. The examples in the following paragraphs show you how to verify a remote TCP/IP connection.

Use the system menus or the Verify TCP/IP Connection (VFYTCPCNN or PING) command to verify your system’s ability to communicate with a remote system using TCP/IP.

Note: PING uses the Internet Control Message Protocol (ICMP) to send data to a

host’s Internet address and waits for a response. The user command to perform this verification is called PING (Packet InterNet Groper) on non-iSeries servers. On an iSeries server, use either the PING command or the VFYTCPCNN command.

To verify TCP/IP connections, perform the three steps below in the order in which they are listed:

1. Type VFYTCPCNN and then press F4.

The display for the VFYTCPCNN command appears (Figure 20).

2. Type the name of a remote system as defined in your host table or as defined

by your domain name server.

If you prefer to use an Internet address, type the address enclosed in apostrophes. You can also type *INTNETADR to be prompted for the Internet address.

3. Press F10 to view or change the additional parameters.

As you can see in Figure 21 on page 29, the system defaults are to send five packets of 256 bytes each and to wait 1 second for a response on each packet.

Type choices, press Enter.

Remote system ......... ____________________________________________

_______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________

Figure 20. Verify TCP/IP Connection

Verify TCP/IP Connection (VFYTCPCNN)

28 OS/400 TCP/IP Configuration and Reference V5R1

Verify TCP/IP Connection (PING)

Type choices, press Enter.

Remote system ......... sysnam36.sysnam123.ibm.com__________________

Remote internet address .... _____________________________

Additional Parameters

Message mode:

Response message detail . . . *VERBOSE *VERBOSE, *QUIET

Summary, if response errors . *COMP *COMP, *ESCAPE

Packet length (in bytes).... 256 8-512

Number of packets ....... 5 1-999

Wait time (in seconds)..... 1 1-120

Local internet address..... *ANY________

Type of service ........ *NORMAL *MINDELAY, *MAXTHRPUT...

IP time to live ........ *DFT 1-255, *DFT

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More keys

More...

Figure 21. Verify TCP/IP Connection, Additional Parameters

Verifying TCP/IP Connections with Host Name—Example

In this example, sending five packets of 256 bytes each verifies the connection to the remote system SYSNAM36. The local system waits 1 second for a response to each packet that is sent.

Chapter 1. Configuring TCP/IP 29

Verify TCP/IP Connection (PING)

Type choices, press Enter.

Remote system .........>SYSNAM36.SYSNAM123.IBM.COM_____________

Additional Parameters

Message mode:

Response message detail . . . *VERBOSE *VERBOSE, *QUIET

Summary, if response errors . *COMP *COMP, *ESCAPE

Packet length (in bytes).... 256 8-512

Number of packets ....... 5 1-999

Wait time (in seconds)..... 1 1-120

Local internet address..... *ANY________

Type of service ........ *NORMAL *MINDELAY, *MAXTHRPUT...

IP time to live ........ *DFT 1-255, *DFT

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More keys

More...

Figure 22. Verifying Connection to Remote System SYS1

Verifying TCP/IP Connections with Internet Address—Example

In this example, (Figure 22) the connection to the remote system at Internet address

9.4.191.76 is verified using the system defaults for packet length, number of packets, and wait time.

Verify TCP/IP Connection (PING)

Type choices, press Enter.

Remote system ......... *intnetadr___________________________

Remote internet address ....>'9.4.191.76'

Figure 23. Verifying Connection to Remote System at Internet Address 9.4.191.76

Step 10—Saving Your TCP/IP Configuration

To save your TCP/IP configuration files, use the following command:

SAVOBJ OBJ(QATOC* QATM*) LIB(QUSRSYS)

DEV(TAP01) OBJTYPE(*FILE)

The associated line descriptions are not saved with this command. Configuration objects are saved with the system.

To maintain consistency, save all TCP/IP configuration files together.

30 OS/400 TCP/IP Configuration and Reference V5R1

Note: You do not have to end TCP/IP in order to save the configuration files.

However, you should end TCP/IP before any TCP/IP configuration files are restored.

Chapter 1. Configuring TCP/IP 31

32 OS/400 TCP/IP Configuration and Reference V5R1

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics

This chapter discusses managing your network by using the NETSTAT command, and the maintenance of host tables. In addition, this chapter covers other topics beyond those that are required to configure and use TCP/IP on iSeries 400. This information may help you to understand and maximize your usage of the iSeries TCP/IP support.

TCP/IP on an iSeries server can also be managed by Simple Network Management Protocol (SNMP). For information about SNMP, see resources in the Information Center: Supplemental Manuals.

Network Status

The network status function on the server allows you to get information about the status of TCP/IP network interfaces, routes, and connections on your local system. This function also allows you to end TCP/IP connections and to start or end TCP/IP interfaces.

Note: Network status functions may also be administered by Operations

Navigator. Use the Operations Navigator interface for these functions if it is installed on your system. See the Operations Navigator (http://www.as400.ibm.com/oper_nav/index.htm) Web page for more information.

NETSTAT displays the current TCP/IP protocol stack information. This information does not necessarily match the configuration data you see when using the Configure TCP/IP (CFGTCP) menu. In most cases, the NETSTAT command displays more information than the configuration data. In some cases, the configuration data might even change.

The reason for such a change is that the iSeries TCP/IP dynamically creates some information, such as *DIRECT routes, when TCP/IP starts. A change may also occur if the configuration data that was sent to TCP/IP when it starts is changed dynamically by TCP/IP applications that run after you start TCP/IP. Several types of processing alter the initial TCP/IP configuration:

v Internet Control Message Protocol (ICMP) requests v Sockets ioctl system calls

v Simple Network Management Protocol (SNMP) requests

v iSeries TCP/IP internal processing

Work with TCP/IP Network Status Menu

The Work with TCP/IP Network Status menu allows you to work with the various network status functions.

To display the Work with TCP/IP Network Status menu, take these steps:

1. Type the WRKTCPSTS (Work with TCP/IP Network Status) command or the

NETSTAT (Network Status) command.

2. Press the Enter key. (See Figure 24 on page 34.)

Work with TCP/IP Network Status

Select one of the following:

1. Work with TCP/IP interface status

2. Display TCP/IP route information

3. Work with TCP/IP connection status

Figure 24. Work with TCP/IP Network Status

Work with TCP/IP Interface Status

The Work with TCP/IP Interface Status display, as shown in Figure 25, provides the most current summary of interface activity. This display allows you to view TCP/IP interface information for selected interfaces and to start or end TCP/IP interfaces. To view the Work with TCP/IP Interface Status display, take these steps:

1. Type 1 on the command line of the Work with TCP/IP Network Status menu

or enter the WRKTCPSTS *IFC command.

2. Press the Enter key.

System: SYSNAM04

Work with TCP/IP Interface Status

Type options, press Enter.

5=Display details 8=Display associated routes 9=Start 10=End

12=Work with configuration status

Internet Network Line Interface

Opt Address Address Description Status

9.125.87.10 9.125.87.0 TRNLINE Active

9.125.87.222 9.125.87.0 TESTTRN Active

127.0.0.1 127.0.0.0 *LOOPBACK Active

F3=Exit F4=Prompt F5=Refresh F11=Display line information F12=Cancel F13=Sort by column F24=More keys

System: SYSNAM04

Bottom

Figure 25. Work with TCP/IP Interface Status, Display 1 of 2

Press F11 to change the contents of the display to include the subnet mask, type of service, maximum transmission unit (MTU), and line type, as shown in Figure 26

on page 35.

34 OS/400 TCP/IP Configuration and Reference V5R1

Work with TCP/IP Interface Status

Type options, press Enter.

5=Display details 8=Display associated routes 9=Start 10=End 12=Work with configuration status

Internet Subnet Type of Line

Opt Address Mask Service MTU Type

9.125.87.10 255.255.255.0 *MAXTHRPUT 1989 *TRLAN

9.125.87.222 255.255.255.0 *NORMAL 1989 *TRLAN

127.0.0.1 255.0.0.0 *NORMAL 576 *NONE

Figure 26. Work with TCP/IP Interface Status, Display 2 of 2

System: SYSNAM04

Starting TCP/IP Interfaces

TCP/IP interfaces are started in one of the following ways:

v The Work with TCP/IP Interface Status displays are reached by:

– Option 1 on the Configure TCP/IP (CFGTCP) menu

– Option 1 on the Network Status (NETSTAT or WRKTCPSTS) menu

v The Start TCP/IP Interface (STRTCPIFC) command

v Using the Operations Navigator interface

Note: You can start TCP/IP interfaces through the Operations Navigator

interface wizard. However, this chapter does not document any of the Operations Navigator functions. See the online help in Operations Navigator for this information.

To start a TCP/IP interface from the Work with TCP/IP Interface Status menu, type 9 in the option field for each interface that you want to start and press the Enter key.

To start a TCP/IP interface using the STRTCPIFC command, take these steps:

1. Type STRTCPIFC on the command line and press F4 (Prompt).

2. Type the Internet address of the interface that you want to start and press the

Enter key.

Option 9 on the Work with TCP/IP Interface Status display is used to start both TCP/IP interfaces and Internet Protocol (IP) over Systems Network Architecture (SNA) interfaces. For information about starting IP over SNA interfaces, see the STRIPSIFC (Start IP over SNA Interface) command in Control Languages (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rbam6/ rbam6clmain.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Note: When starting the first TCP/IP interface associated with an Integrated

xSeries Server for iSeries (also known as File Server Input/Output Processor and FSIOP) network server description, a considerable amount of time may pass before the interface becomes active. This is because TCP/IP activation includes starting the network server. The amount of time that is required

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 35

depends mainly on machine use and the size of the processor. To determine whether the interface has started, view the messages in the QTCPIP job log and the QSYSOPR message queue.

Ending TCP/IP Interfaces

The ENDTCPIFC (End TCP/IP Interface) command ends an existing TCP/IP interface immediately. As a result, all TCP/IP connections using this interface also end immediately. However, the operation of any other TCP or IP over SNA interface, using the same line description as the interface that is ending, is not affected.

TCP/IP interfaces can be ended in one of two ways:

v Using the Work with TCP/IP Interface Status display, which is reached by:

– Option 1 on the Configure TCP/IP (CFGTCP) menu

– Option 1 on the Network Status (NETSTAT or WRKTCPSTS) menu

v Using the ENDTCPIFC (End TCP/IP Interface) command

To end a TCP/IP interface from the Work with TCP/IP Interface Status menu:

1. Type 10 in the option field for each interface that you want to end.

2. Press the Enter key.

To end a TCP/IP interface using the ENDTCPIFC command:

1. Type ENDTCPIFC on the command line.

2. Press F4 (Prompt).

3. Type the Internet address of the interface that you want to end.

4. Press the Enter key.

Option 10 on the Work with TCP/IP Interface Status display is used to end both TCP/IP interfaces and IP over SNA interfaces. For information about ending IP over SNA interfaces, see the ENDIPSIFC (End IP over SNA Interface) command in Control Languages (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rbam6/ rbam6clmain.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Route-to-Interface Binding: Interfaces define direct paths to networks or subnetworks to which an iSeries server is directly attached. Routes define indirect paths. A route identifies the first hop on the path to a network or subnetwork to which an iSeries is not directly attached.

Routes are bound to interfaces through the use of a best-match-first algorithm. This algorithm is based on the state of the interface, and on the type of service (TOS) specified for the route and interface. When you end an interface, the routes associated with the interface can move to another existing active interface if the following conditions are satisfied:

v If the TOS for the route is something other than *NORMAL, the algorithm looks

for an interface with the same TOS. If an interface with the specified TOS is not found, an interface with TOS *NORMAL is sought. Again, if one is not found, that route will not be moved.

v The MTU value for the route that is being moved must be less than or equal to

the MTU value for the active interface.

36 OS/400 TCP/IP Configuration and Reference V5R1

v The network ID of the interface must be equal to the logical AND of the next

hop for the route and the subnet mask for the interface.

Notes:

1. If the next hop of a route is identical to an interface’s IP address, that route will

never be bound to another interface.

2. When starting interfaces (if all interfaces are currently inactive) routes are

bound to the interfaces with the same best-match-first algorithm. An exception is if the route is defined with a preferred binding interface. In this case, an attempt is made to bind the route to the interface that is indicated. If the binding attempt fails, then the best-match-first algorithm is used.

Display TCP/IP Route Information

The display TCP/IP route information function allows you to view information about TCP/IP routes.

To display TCP/IP route information:

1. On the Work with TCP/IP Network Status menu, type 2 on the command line

or enter the WRKTCPSTS *RTE command.

2. Press the Enter key.

The first of the two Display TCP/IP Route Information displays appears, as shown in Figure 27.

Display TCP/IP Route Information

Type options, press Enter.

5=Display details

Route Subnet Next Route

Opt Destination Mask Hop Available

9.125.87.0 255.255.255.0 *DIRECT *YES

9.125.109.3 *HOST 9.125.87.17 *YES

127.0.0.0 255.0.0.0 *DIRECT *YES *DFTROUTE *NONE 9.125.87.169 *YES *DFTROUTE *NONE 9.125.87.250 *YES

F3=Exit F5=Refresh F6=Print list F11=Display route type F12=Cancel F13=Sort by column F17=Top F18=Bottom

Figure 27. Display TCP/IP Route Information, Display 1 of 2

System: SYSNAM04

Bottom

To view the second display, press F11 (Display route type). The route information is presented as shown in Figure 28 on page 38. To return to the first display, press F11 (Display next hop).

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 37

Display TCP/IP Route Information

Type options, press Enter.

5=Display details

Route Type of Route Route Route

Opt Destination Service MTU Type Source

9.125.87.0 *MAXTHRPUT 1989 *DIRECT *CFG

9.125.87.0 *NORMAL 1989 *DIRECT *CFG

9.125.109.3 *MINDELAY 576 *HOST *ICMP

127.0.0.0 *NORMAL 576 *DIRECT *CFG *DFTROUTE *MAXTHRPUT 1989 *DFTROUTE *CFG *DFTROUTE *NORMAL 1989 *DFTROUTE *CFG

System: SYSNAM04

F3=Exit F5=Refresh F6=Print list F11=Display next hop F12=Cancel F13=Sort by column F17=Top F18=Bottom

Figure 28. Display TCP/IP Route Information, Display 2 of 2

To view detailed information about a specific route, type 5 in the option field next to the route and press the Enter key.

Routes listed on the Display TCP/IP Route Information display differ from the routes that are displayed on the Work with TCP/IP Routes display. Only routes with a route source of *CFG and a route type that is not *DIRECT can be changed with the Work with TCP/IP Routes display. Similarly, only routes that meet these conditions can be changed or removed with the CHGTCPRTE or RMVTCPRTE commands. *CFG means the route was added using iSeries configuration commands or is a *DIRECT route. *DIRECT means that the route is to a network or subnetwork to which this system has a direct physical connection. This route is not defined with an add route command.

Work with TCP/IP Connection Status

The Work with TCP/IP Connection Status display allows you to display or end a TCP/IP connection between a local system and a remote system.

Bottom

To display the Work with TCP/IP Connection Status display:

1. Type 3 on the command line of the Work with TCP/IP Network Status menu

or enter the WRKTCPSTS *CNN command.

2. Press the Enter key.

The first of the three Work with TCP/IP Connection Status displays, as shown in Figure 29 on page 39.

To display the second and third Work with TCP/IP Connection Status displays, press F11 (see Figure 30 on page 39 and Figure 31 on page 40). To display port numbers instead of port service names, press F14.

In Figure 29 on page 39, the connections indicate that the FTP server, SMTP server, and TELNET server are active and ready to receive connection attempts. Because no connection has been established yet, the Remote Address and Remote Port fields

38 OS/400 TCP/IP Configuration and Reference V5R1

contain an asterisk (*). When an application requests a connection to a listening socket, a new connection is created. The remote Internet address and remote port are shown for the new connection. The listening socket always remains in the list of connections.

Work with TCP/IP Connection Status

System: SYSNAM04

Local internet address ...........: *ALL

Type options, press Enter.

4=End 5=Display details

Remote Remote Local

Opt Address Port Port Idle Time State

* * ftp-con > 000:20:41 Listen * * telnet 001:39:00 Listen * * telnet 000:14:27 Listen * * smtp 000:55:23 Listen * * lpd 002:36:29 Listen * * 1049 001:31:01 *UDP * * 1050 001:28:02 *UDP * * 1051 001:12:05 *UDP * * 1052 001:09:52 *UDP * * 1070 000:35:53 Listen

9.5.1.180 1211 telnet 000:10:17 Established

F5=Refresh F11=Display byte counts F13=Sort by column F14=Display port numbers F22=Display entire field F24=More keys

Figure 29. Work with TCP/IP Connection Status, Display 1 of 3

Work with TCP/IP Connection Status

System: SYSNAM04

Local internet address ...........: *ALL

More...

Type options, press Enter.

4=End 5=Display details

Remote Remote Local

Opt Address Port Port User Bytes Out Bytes In

* * ftp-con > QTCP 0 0 * * telnet QTCP 0 0 * * telnet QTCP 0 0 * * lpd QTCP 0 0 * * 1070 BILANSKY 0 0

9.5.1.131 1954 telnet QTCP 48583 815

9.5.1.180 1211 telnet QTCP 32319 4704

9.5.15.134 1024 telnet QTCP 403415 226141

9.5.15.141 1027 telnet QTCP 3831 236

9.130.38.18 2099 telnet QTCP 509788 15394

9.130.38.74 1125 telnet QTCP 680 34

F5=Refresh F11=Display connection type F13=Sort by column F14=Display port numbers F22=Display entire field F24=More keys

Figure 30. Work with TCP/IP Connection Status, Display 2 of 3

More...

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 39

Work with TCP/IP Connection Status

Local internet address ...........: *ALL

Type options, press Enter.

4=End 5=Display details

Remote Remote Local Local

Opt Address Port Address Port Type

* * * ftp-con > *TCP * * * telnet *TCP * * * telnet *TCP * * * lpd *TCP * * 9.125.87.222 1070 *TCP

9.5.1.131 1954 9.125.87.10 telnet *TCP

9.5.1.180 1211 9.125.87.10 telnet *TCP

9.5.15.134 1024 9.125.87.10 telnet *TCP

9.130.38.18 2099 9.125.87.222 telnet *TCP

9.130.38.74 1125 9.125.87.10 telnet *TCP

9.130.38.74 1126 9.125.87.222 telnet *TCP

F5=Refresh F11=Display connection state F13=Sort by column F14=Display port numbers F22=Display entire field F24=More keys

Figure 31. Work with TCP/IP Connection Status, Display 3 of 3

System: SYSNAM04

More...

Ending TCP/IP Connections

TCP/IP connections and User Datagram Protocol (UDP) sockets can be ended from the Work with TCP/IP Connection Status display. To do so:

1. Type 4 in the option field for the lines containing the connections that you want

to end.

2. Press the Enter key.

The Confirm End of TCP/IP Connections displays is then presented as shown in Figure 32 on page 41.

40 OS/400 TCP/IP Configuration and Reference V5R1

Confirm End of TCP/IP Connections

Local internet address ...........: *ALL

Press Enter to confirm your choices for 4=End. Press F12 to return to change your choices.

Remote Remote Local Local

Opt Address Port Address Port Type

4 9.5.15.134 1024 9.125.87.10 telnet *TCP

System: SYSNAM04

F11=Display connection state F12=Cancel F14=Display port numbers F22=Display entire field

Figure 32. Confirm End of TCP/IP Connections

To end the TCP/IP connections, press the Enter key from the Confirm End of TCP/IP Connections display.

If you decide not to end a TCP/IP connection or if you want to change your choices, press F12 (Cancel).

Working with Configuration Status

To work with the line description used by an interface:

1. On the Work with TCP/IP Interface Status menu, type 12 in the option field for

each interface that you want to work with.

2. Press the Enter key.

This option issues the WRKCFGSTS (Work with Configuration Status) command for the line description associated with the interface. Using the options shown in Figure 33 on page 42 you can vary a line description on or off, display the Work with Job menu, and display the line description or mode status.

Bottom

This option cannot be used for IP over SNA interfaces because IP over SNA does not use specific line descriptions.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 41

Work with Configuration Status SYSNAM04

Position to ..... Starting characters

Type options, press Enter.

1=Vary on 2=Vary off 5=Work with job 8=Work with description

9=Display mode status ...

Opt Description Status -------------Job--------------

TRNLINE ACTIVE

TRNLINET ACTIVE

TRNLITCP ACTIVE QTCPIP QTCP 007936

Figure 33. Work with Configuration Status

04/26/94 15:55:58

Displaying TCP/IP Network Status Information

In addition to working with network status functions, the Work with TCP/IP Network Status menu allows you to display current information about your TCP/IP network, including multicast groups, TCP/IP interfaces, and associated routes, to name a few.

Display Multicast Groups

To display the multicast groups associated with an interface:

1. On the Work with TCP/IP Interface Status display, type 14 in the option field

for each interface for which you want to see the associated multicast groups.

2. Press the Enter key.

Figure 34 on page 43 illustrates the display of the multicast groups for an Ethernet interface.

If you have requested multicast group information for more than one interface, press the Enter key to review the remaining displays.

42 OS/400 TCP/IP Configuration and Reference V5R1

Display Multicast Host Groups

Interface internet address ...........: 10.5.5.55

Host Group Hardware Address Host Group Hardware Address

224.0.0.1 01:00:5E:00:00:01

225.4.5.6 01:00:5E:04:05:06

233.32.40.51 01:00:5E:20:28:33

224.0.0.9 01:00:5E:00:00:09 229:200:100:1 01:00:5E:48:64:01

System: SYSNAM04

F3=Exit F5=Refresh F6=Print F9=Command line F11=Hide hardware address F12=Cancel

Bottom

Figure 34. Display Multicast Host Groups

Displaying TCP/IP Interfaces

To display more detailed information about the TCP/IP interface status for specific interfaces:

1. On the Work with TCP/IP Interface Status display, type 5 in the option field for

each interface about which you want more information.

2. Press the Enter key.

If you requested status for a token-ring interface, the information displays, as shown in Figure 35 on page 44.

If you have requested interface status information for more than one interface, press the Enter key to view the remaining displays.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 43

Display TCP/IP Interface Status

Interface host name.............: sysnam04.endicott.ibm. >

Internet address ..............: 9.125.87.10

Subnet mask................: 255.255.255.0

Network address..............: 9.125.87.0

Host address ...............: 0.0.0.10

Directed broadcast address ........: 9.125.87.255

Interface status ..............: Active

Change date/time ..............: 04/26/94 14:32:32

Line description ..............: TRNLINE

Line type..................: *TRLAN

Type of service...............: *MAXTHRPUT

Maximum transmission unit..........: 1989

Automatic start...............: *YES

TRLAN bit sequencing ............: *MSB

System: SYSNAM04

Figure 35. Display TCP/IP Interface Status for a Token-Ring Interface

Displaying Associated Routes

To display information about the routes associated with a specific interface:

1. On the Work with TCP/IP Interface Status display, type 8 in the option field for

each interface for which you want to see the associated routes information.

2. Press the Enter key.

The first of two displays with associated route information is shown in Figure 36

on page 45.

If you have requested associated route information for more than one interface, press the Enter key to view the remaining displays.

44 OS/400 TCP/IP Configuration and Reference V5R1

Display Associated Routes

Interface internet address .........: 9.125.87.10

Type options, press Enter.

5=Display details

Route Subnet Next Route

Opt Destination Mask Hop Available

9.125.87.0 255.255.255.0 *DIRECT *YES *DFTROUTE *NONE 9.125.87.169 *YES

System: SYSNAM04

F3=Exit F5=Refresh F6=Print list F11=Display route type F12=Cancel F13=Sort by column F17=Top F18=Bottom

Bottom

Figure 36. Associated Route Information, Display 1 of 2

Press F11 to show the display that includes the type of service (TOS), maximum transmission unit (MTU), type, and source.

Displaying Route Details Option

To display detailed information about the route:

1. On the Display Associated Routes display, type 5 in the option field for each

route about which you want more information.

2. Press the Enter key.

Figure 37 on page 46 and Figure 38 on page 46 are examples.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 45

Display TCP/IP Route Details

System: SYSNAM04

Route information:

Route destination.............: 9.125.87.0

Subnet mask................: 255.255.255.0

Next hop host name ............: sysnam04.endicott.ibm. >

Next hop .................: *DIRECT

Type of service..............: *MAXTHRPUT

Route available..............: *YES

Route type ................: *DIRECT

Route source ...............: *CFG

Change date/time .............: 04/26/94 14:32:32

Route maximum transmission unit......: 1989

Reference count..............: 0

Local interface information:

Internet address .............: 9.125.87.10

Subnet mask...............: 255.255.255.0

Network address.............: 9.125.87.0

Press Enter to continue.

F3=Exit F6=Print F12=Cancel F22=Display entire field

Figure 37. Display TCP/IP Route Details, Display 1 of 2

More...

Display TCP/IP Route Details

Interface status .............: Active

Line description .............: TRNLINE

Line type.................: *TRLAN

System: SYSNAM04

Figure 38. Display TCP/IP Route Details, Display 2 of 2

Displaying TCP/IP Route Information

To display TCP/IP route information:

1. On the Work with TCP/IP Network Status menu, type 2 on the command line

or enter the WRKTCPSTS *RTE command.

2. Press the Enter key.

The first of the two Display TCP/IP Route Information displays is presented as shown in Figure 39 on page 47.

46 OS/400 TCP/IP Configuration and Reference V5R1

Display TCP/IP Route Information

Type options, press Enter.

5=Display details

Route Subnet Next Route

Opt Destination Mask Hop Available

9.125.87.0 255.255.255.0 *DIRECT *YES

9.125.109.3 *HOST 9.125.87.17 *YES

127.0.0.0 255.0.0.0 *DIRECT *YES *DFTROUTE *NONE 9.125.87.169 *YES *DFTROUTE *NONE 9.125.87.250 *YES

System: SYSNAM04

F3=Exit F5=Refresh F6=Print list F11=Display route type F12=Cancel F13=Sort by column F17=Top F18=Bottom

Bottom

Figure 39. Display TCP/IP Route Information, Display 1 of 2

To view the second Display TCP/IP Route Information display, press F11 (Display route type). The route information is presented in Figure 40. To return to the first display, press F11 (Display next hop).

Display TCP/IP Route Information

Type options, press Enter.

5=Display details

Route Type of Route Route Route

Opt Destination Service MTU Type Source

9.125.87.0 *MAXTHRPUT 1989 *DIRECT *CFG

9.125.87.0 *NORMAL 1989 *DIRECT *CFG

9.125.109.3 *MINDELAY 576 *HOST *ICMP

127.0.0.0 *NORMAL 576 *DIRECT *CFG *DFTROUTE *MAXTHRPUT 1989 *DFTROUTE *CFG *DFTROUTE *NORMAL 1989 *DFTROUTE *CFG

System: SYSNAM04

F3=Exit F5=Refresh F6=Print list F11=Display next hop F12=Cancel F13=Sort by column F17=Top F18=Bottom

Bottom

Figure 40. Display TCP/IP Route Information, Display 2 of 2

To view detailed information about a specific route, type 5 in the option field next to the route and press the Enter key. See Figure 37 on page 46 and Figure 38 on page 46.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 47

Displaying TCP/IP Connections

You can request more detailed information about TCP/IP connections shown on the Work with TCP/IP Connection Status display. This information includes timing information and transmission statistics for the connection displayed.

To display more information about the listed TCP/IP connections:

1. Type 5 in the option field for each connection about which you want more

information.

2. Press the Enter key.

A series of up to three displays for each connection appears. Press the Page Down key to view the remaining displays.

The contents of the displays vary depending on the type of connection, whether *TCP, *UDP, or *IPS. (Figure 41, Figure 42 on page 49, and Figure 43 on page 49 show displays for a TCP connection.)

Display TCP Connection Status

System: SYSNAM04

Connection identification:

Remote host name ..............: drfun.rchland.ibm.com

Remote internet address..........: 9.5.15.134

Remote port................: 1025

Local host name...............: sysnam04.endicott.ibm. >

Local internet address ..........: 9.125.87.143

Local port ................: telnet

Associated user profile...........: QTCP

TCP programming interface information:

State....................: Established

Connection open type ............: Passive

Timing information:

Idle time..................: 000:00:00.381

Last activity date/time..........: 05/25/94 14:38:11

Round-trip time...............: .133

Round-trip variance.............: .016

Press Enter to continue. F3=Exit F5=Refresh F6=Print F10=Display IP options F12=Cancel F14=Display port numbers F22=Display entire field

Figure 41. Display TCP/IP Connection Status, Display 1 of 3

More...

48 OS/400 TCP/IP Configuration and Reference V5R1

Display TCP Connection Status

Bytes out...................: 57692

Outgoing bytes buffered...........: 0

User send next ...............: 3270868150

Send next..................: 3270868150

Send unacknowledged.............: 3270868150

Outgoing push number ............: 3270868149

Outgoing urgency number...........: 3270868149

Outgoing window number ...........: 3270896558

Bytes in ...................: 1021

Incoming bytes buffered...........: 0

Receive next ................: 1545153023

User receive next..............: 1545153023

Incoming push number ............: 1545153023

Incoming urgency number...........: 1545153022

Incoming window number ...........: 1545160742

System: SYSNAM04

Press Enter to continue. F3=Exit F5=Refresh F6=Print F10=Display IP options F12=Cancel F14=Display port numbers F22=Display entire field

Figure 42. Display TCP/IP Connection Status, Display 2 of 3

Display TCP Connection Status

System: SYSNAM04

Retransmission information:

Total retransmissions............: 8

Current retransmissions...........: 0

Send window information:

Maximum size ................: 28672

Current size ................: 28408

Last update.................: 1545153004

Last update acknowledged ..........: 3270868150

Congestion window..............: 2704

Slow start threshold ............: 1281

Precedence and security:

Precedence .................: 0

Initialization information:

Maximum segment size ............: 536

Initial send sequence number ........: 3270810457

Initial receive sequence number.......: 1545152001

More...

Press Enter to continue. F3=Exit F5=Refresh F6=Print F10=Display IP options F12=Cancel F14=Display port numbers F22=Display entire field

Bottom

Figure 43. Display TCP/IP Connection Status, Display 3 of 3

Displaying Connection Totals

To display a summary of TCP and UDP counts, press F10 on the Work with TCP/IP Connection Status display. The counts provided are a cumulative summary of all TCP and UDP activity since the last time the STRTCP (Start TCP) command was issued.

The information in Figure 44 on page 50 and Figure 45 on page 50 shows TCP and UDP counts that are maintained for Simple Network Management Protocol

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 49

(SNMP). For additional information about SNMP, see resources in the Information Center: Supplemental Manuals.

Display TCP/IP Connection Totals

TCP connection information:

Currently established...........: 1

Active opens ...............: 0

Passive opens...............: 0

Attempted opens that failed........: 0

Established and then reset ........: 0

TCP send information:

Segments sent...............: 108

Retransmitted segments ..........: 10

Reset segments ..............: 0

TCP receive information:

Segments received.............: 117

Segments received in error ........: 0

Press Enter to continue.

F3=Exit F5=Refresh F6=Print F12=Cancel

Figure 44. Display TCP/IP Connection Totals, Display 1 of 2

Display TCP/IP Connection Totals

UDP send information:

Datagrams sent ..............: 0

System: SYSNAM04

More...

System: SYSNAM04

UDP receive information:

Datagrams received ............: 0

Datagrams not delivered..........: 0

Figure 45. Display TCP/IP Connection Totals, Display 2 of 2

TCP/IP Host Tables

Host tables are a method for mapping host names to IP addresses. This is done by using a hosts file for name-to-address resolution. Because the host table lacks the structure to list names in any hierarchical order, names assigned to hosts must be unique. In the topics that follow, you will find discussions about the overall management of TCP/IP host tables. Instructions for merging host tables and managing a host table from a central site are included.

Successful TCP/IP host table maintenance also includes periodically evaluating whether or not to use a DNS server to manage your network. The DNS server is often the preferred alternative to host tables for the purpose of managing IP addresses and host names, particularly in large network environments. However, even some small organizations that access the Internet require a DNS server to meet their name-service needs.

Application port not found .......: 0

Other datagrams in error ........: 0

50 OS/400 TCP/IP Configuration and Reference V5R1

Managing TCP/IP Host Tables

In a large network, it can be more efficient to administer iSeries TCP/IP from a central site. Working with the host table would be time consuming if each system is individually updated with the TCP/IP configuration menu. Updates can be made more quickly on one system and then copied to others.

iSeries TCP/IP is designed to protect configuration files, including the host table. You cannot change the host table file unless you use the Configure TCP/IP menu or the MRGTCPHT, ADDTCPHTE, RNMTCPHTE, CHGTCPHTE, or RMVTCPHTE commands. However, you can still import and use a host table from a central site by using the MRGTCPHT command.

The following host table file types can be imported and merged with the server host table:

v Host table type *AS400, generated by iSeries TCP/IP Version 3 Release 1

Modification 0 (V3R1M0) or later

v Host table type *AIX, generated by iSeries TCP/IP Version 3 Release 0

Modification .5 (V3R0M5), Version 2 Release 3 (V2R3) or earlier, or many other IBM and non-IBM systems

v Host table type *NIC, host table format used by public domain systems

You can merge or replace the local server host table with the imported host table. The name of the database file containing the local host table is QATOCHOST with member HOSTS in library QUSRSYS. This file is used directly by iSeries TCP/IP; no conversion into an internal version takes place.

Host File Formats

If you receive a host file and want to use it on your system, the MRGTCPHT (Merge TCP/IP Host Table) command allows you to specify which format you are using. You can use host information files that are in either the *NIC format, the *AIX format, or the *AS400 format. The record length of the imported host table file is not limited.

Host Table Information with *AIX Files

Table 4 shows the *AIX format supported on the server.

Table 4. *AIX Supported on the AS/400 System

Delimiter Meaning

# (pound sign) Indicates the beginning of a comment. The text

blank, tab Indicates a field delimiter.

Host Table Information with *NIC Files

The *NIC format is often used by hosts in the public domain. A record in a *NIC file has the following format:

HOST : 128.12.19.1 : Host2.lan.ibm.com,Host2 : PC-AT : DOS : TCP/IP

This entry describes one host (at address 128.12.19.1) with two names (Host2.lan.ibm.com) and (Host2). The host is an IBM Personal Computer AT computer running MS-DOS and supporting TCP/IP.

following the pound sign is a comment and is not part of the host table.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 51

A complete description of the *NIC format is found in Request for Comment (RFC) 952, Internet Host Table Specification. See the RFC Editor Site (http://www.rfceditor.org/rfc.html) to retrieve this RFC. The subset supported on the server is shown in Table 5. The *NIC continuation characters are not supported because the record length of the file can be up to 512 bytes.

Table 5. *NIC Subset Supported on the AS400 System

Delimiter Meaning

; (semicolon)

NET

GATEWAY A keyword introducing a gateway entry.

HOST A keyword introducing a host entry.

: (colon) A field delimiter.

:: (two colons) Indicates a null field.

, (comma) A data element delimiter.

Notes:

1. If any line in the *NIC table contains a semicolon as the first column value, then that

line is not merged into the server host table.

2. These entries are not merged into the server host table.

Indicates the beginning of a comment. The text following the semicolon is a comment and is not part of the host table.

A keyword introducing a network entry.

Host Table Information with *AS400 Files

The *AS400 file format is the format of the local server host table file used by iSeries TCP/IP directly. The name of the file is QATOCHOST with member HOSTS in library QUSRSYS. A single record contains an Internet address, up to four host/domain names and a text description field. For more details regarding record and file formats, use the DSPFFD (Display File Field Description) command.

This file can be exchanged between iSeries servers. However, there is no function to convert from *AS400 to *AIX or *NIC format.

Tips for Merging Host Tables

A maximum of four host names per IP address is allowed when host tables are merged. For example, if the local host table already has three host names and the physical file member to be merged has two additional host names, only the first host name in the physical file is merged into the final host table.

Host names that exist for the same Internet address are not duplicated. If the same host name is found for Internet addresses that are different, then that host name is accepted, but a warning message is displayed.

The original copy of the local host table is not saved by the MRGTCPHT (Merge TCP/IP Host Table) command. To save the original host table, create a copy of the file QUSRSYS/QATOCHOST.HOSTS by using the Copy File (CPYF) command. Do this before issuing the MRGTCPHT command.

Merging TCP/IP Host Tables

You can use imported host tables in two ways: v Overwrite the current host table. To do this, specify Replace Host Table (*Yes)

on the Merge Host Table display.

52 OS/400 TCP/IP Configuration and Reference V5R1

v Merge the information of the imported host table with the information that was

entered by using option 10 (Work with TCP/IP host table entries) from the Configure TCP/IP menu. To merge the information, specify Replace Host Table (*No) on the Merge Host Table display.

You can merge an imported host table with the local host table while TCP/IP is running by using the CFGTCP (Configure TCP/IP) command. The changes take affect the next time a TCP/IP application accesses the host table.

Select option 11 to merge an imported host table with the local server host table.

You can also use the Merge TCP/IP Host Table (MRGTCPHT) command from any command line.

Example: Successful Host Table Merge

The following example shows the command to merge an imported host table with the local host table.

MRGTCPHT FROMFILE(QUSRSYS/M02HOSTS) FILEFMT(*AS400) REPLACE(*NO)

File M02HOSTS, member *FIRST, successfully merged with host table.

Example: Partly Successful Host Table Merge

The following example shows the command to merge an imported host table with the local host table.

MRGTCPHT FROMFILE(QUSRSYS/M03HOSTS) FILEFMT(*AS400) REPLACE(*NO)

Duplicate host name SPARKY.SYSNAM123.IBM.COM at address 9.4.6.138

found host table.

Duplicate host name MVAX.SYSNAM123.IBM.COM at address 9.4.6.252

found host table.

File M03HOSTS, member *FIRST, merged with host table: however,

error occurred.

In this example, the host table contains entries with the same host name, which shows in the message as duplicate host names.

Managing the Host Table from a Central Site

If your network has multiple servers, you can define the TCP/IP host table on one system and share that table with the other systems. This saves you the effort of having to define the host table on each system. To do this, follow these steps:

Step 1—Create the Host Table on Your Central System

Use the CFGTCP command to configure your host table. Select option 10 (Work with TCP/IP host table entries). Your system’s host table is stored in member HOSTS of file QATOCHOST in library QUSRSYS.

Step 2—Start FTP to a Remote System

For example, if your host table defines the remote system as SYSNAM02, type the FTP command as follows:

ftp sysnam02

Step 3—Tell FTP to Send the Host File to the Remote System

Type the following FTP subcommand:

put qusrsys/qatochost.hosts qusrsys/m03host.hosts

Note: Do not use FTP to put the host file directly into file QATOCHOST

containing the server host table.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 53

Step 4—Merge the File

Type the following FTP subcommand:

quote rcmd mrgtcpht fromfile(qusrsys/m03host) frommbr(host)

IP Routing and Internet Control Message Protocol (ICMP) Redirecting

Internet routing tables usually remain static for long periods. TCP/IP generates routing tables at activation time from configuration data and adjusts the routing tables based on ICMP redirects, SNMP manager requests, dead gateway processing and socket routing requests.

If network interconnections change, routing tables in a particular host may become incorrect. Because gateways exchange routing information periodically to accommodate network changes and to keep their routes up to date, a gateway usually knows better routes than a host. When a gateway detects that a host is using a route that is not optimum, the gateway sends an ICMP redirect message to that host. It also forwards the original datagram on to its destination. Redirect messages are limited to interactions between a gateway and a host on the same network.

If the host that sends the original datagram is an iSeries, it receives the ICMP redirect message from the gateway and uses this information to update its internal routing table. The next datagram is then sent using the more optimum route received from the gateway. You can see the updated routing table by using NETSTAT, option 2. A route created by the ICMP redirect mechanism is recorded in the IP dynamic routing table and remains there as long as an upper level protocol is using it. When the last upper-level protocol user has completed its unit of work using a route created by the ICMP redirect mechanism, the route is then removed from the routing table. When TCP/IP is restarted, this process is repeated.

In Figure 46 on page 55, host A1 in network 2 is an iSeries server that sends a message to host A2 in network 3. The routing table in host A1 indicates that the first hop to host A2 is through gateway G1, which connects networks 1 and 2. When this gateway receives the datagram, it forwards the datagram to gateway G2, which sends it to the host A2. Gateway G1 then sends an ICMP redirect message to host A1 to inform it that a better route to host A2 is to use gateway G2 as the first hop. This information updates the internal routing table in host A1, and the next datagram to host A2 in network 3 is sent to gateway G2 as the first hop. The gateway then sends the datagram to host A2. When the TCP/IP services are stopped, the collected routing information is deleted and host A1 starts the learning process again.

54 OS/400 TCP/IP Configuration and Reference V5R1

Figure 46. Example of ICMP Redirect

To see routing changes due to ICMP redirect messages, select NETSTAT menu 2 or NETSTAT *RTE and then press PF11. Comparing the next hop in this display with the next hop present in the routing table, you can verify whether a route has been dynamically changed.

Dead Gateway Processing

RFC-1122, Requirements For Internet Hosts - Communication Layers, requires the IP layer to include a dead gateway algorithm to manage suspected gateway failures. This section is intended to give you an overview of dead gateway processing.

Two types of gateway failures can occur:

v Failure of a first-hop gateway. A first-hop gateway is the gateway that is

specified in an IP route. First-hop gateways must be on a directly-connected network. This type of failure can be detected by either TCP or the data link layer.

v Failure of a gateway other than the first-hop gateway. The path between source

and destination TCP/IP hosts can traverse multiple gateways. This type of failure can be detected only by TCP.

Dead gateway processing is initiated when IP receives a negative advice indicator from either TCP or the data link layer. These indicators from TCP and the data link layer are referred to as advice since they may result from transient conditions as well as from a serious gateway failure.

Negative Advice from TCP or the Data Link Layer

Retransmissions on a TCP connection occur as a result of transient or non-transient problems somewhere along the path to a destination host. When TCP notices excessive retransmissions on a TCP connection, a TCP negative advice indicator is sent to IP.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 55

The data link layer passes a negative advice indicator to IP when it is unable to transmit data to a first-hop (directly-connected) gateway. In most cases, negative advice from the data link layer means that the Address Resolution Process (ARP) processing performed by the data link layer was unable to resolve the location of first-hop gateway on the directly connected physical network. (ARP is not performed on all physical network types. Some physical network types, such as X.25, use an alternative scheme for this purpose.)

Negative advice, whether from TCP or the data link layer, is always expressed in terms of the first-hop gateway. Dead gateway processing on a given host only attempts to verify the first-hop gateway. However, gateways also carry out their own dead gateway processing for other adjacent gateways. In this way, all of the gateways along the path to a destination host are taken care of.

How IP Responds to Negative Advice

When receiving negative advice from TCP or the data link layer concerning a next hop gateway, IP marks all routes that use this gateway as suspect. IP attempts to deliver data destined for the suspect gateway via routes that use other gateways (if any are configured). Next, an IP process is started that uses periodic PING requests to attempt to contact the suspect next-hop gateway. If the suspect gateway continues to be unresponsive for an extended period of time, the frequency of the PING requests is reduced.

When any PING response is received from a suspect gateway, the gateway is considered active and the routes are restored.

Notes about IP Responses to Negative Advice:

1. If an ICMP redirect message is received during dead gateway processing,

routes to a suspect gateway may be temporarily restored. However, dead gateway PING processing is not interrupted, and subsequent negative advice forces the IP routing table back to its previously adjusted state.

2. Responses from user-initiated PINGs can also indicate that a suspect gateway is

active.

3. Negative advice is not passed from the UDP or RAW IP protocol machines.

Applications using these protocols must use other mechanisms to detect and respond to apparent network problems. However, data link layer-negative advice is still used to manage problems with the first-hop gateway.

Multihoming Function

A multihomed host has multiple IP addresses, which we may think of as logical interfaces. These logical interfaces may be associated with one or more physical interfaces, and these physical interfaces may be connected to the same or different networks.

The iSeries TCP/IP implementation supports multihoming. This allows you to specify either a single interface or multiple interfaces for a line description. You can have your server appear as any one or combination of the following scenarios:

v A single host on a network over a communications line

v Multiple hosts on the same network over the same communications line

v Multiple hosts on the same network over multiple communications lines

v Multiple hosts on different networks over the same communications line

v Multiple hosts on different networks over multiple communications lines

56 OS/400 TCP/IP Configuration and Reference V5R1

Note: The maximum number of interfaces that can be active on a line description

at any given time is 128. This is true for all line types (for example, token-ring, Ethernet, frame relay, and so forth).

Example: A Single Host on a Network over a Communications Line

Your server uses one adapter for TCP/IP to attach to a LAN or WAN network. You add one TCP/IP interface. This TCP/IP interface includes the Internet address of your server. With this single Internet address, your server is part of a single TCP/IP network (Figure 47).

Figure 47. Multihoming - Single Host, Single Network, Single Line

Example: Multiple Hosts on the Same Network over the Same Communications Line

Your server uses one adapter for TCP/IP to attach to a LAN or WAN network. You add multiple TCP/IP interfaces. Each of these TCP/IP interfaces includes an Internet address of the same TCP/IP network. With these multiple Internet addresses your server appears as multiple hosts in a single TCP/IP network (Figure 48).

This can be a migration scenario.

Figure 48. Multihoming - Multiple Hosts, Single Network, Single Line

Example: Multiple Hosts on the Same Network over Multiple Communications Lines

Your server uses more than one adapter for TCP/IP to attach to the same LAN or WAN network. You add multiple TCP/IP interfaces. At least one interface is assigned to each adapter/line description. Each of these TCP/IP interfaces includes an Internet address of the same TCP/IP networks. With these multiple Internet

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 57

addresses, your server appears as multiple TCP/IP hosts in the same TCP/IP network (Figure 49).

Figure 49. Multihoming - Multiple Hosts, Single Network, Multiple Lines

This scenario can be helpful for backup or to improve performance. However, there is no dynamic backup or performance balance function.

Example: Multiple Hosts on Different Networks over the Same Communications Line

Your server uses one adapter for TCP/IP to attach to a LAN or WAN network. You add multiple TCP/IP interfaces. Each of these TCP/IP interfaces includes an Internet address of different TCP/IP networks. With these multiple Internet addresses, you participate in different TCP/IP networks (Figure 50).

Figure 50. Multihoming - Multiple Hosts, Multiple Networks, Single Line

| | | |

Imagine a public X.25 network. With this physical network, you can run multiple TCP/IP networks, for example the company intranet, and connections with business partners and service providers. For each of these different TCP/IP networks, your server must configure a unique Internet address.

Running multiple TCP/IP networks within a single local area network (LAN) is also supported. In most situations, however, one designs a single TCP/IP network per physical LAN only.

Example: Multiple Hosts on Different Networks over Multiple Communications Lines

Your server uses more than one adapter for TCP/IP to attach to multiple LAN or WAN networks. You add multiple TCP/IP interfaces. At least one interface is assigned to each adapter/line description. Each of these TCP/IP interfaces includes

58 OS/400 TCP/IP Configuration and Reference V5R1

an Internet address of different TCP/IP networks. With these multiple Internet addresses, you take part in different TCP/IP networks (Figure 51).

This example is a combination of all of the previous examples discussed.

Figure 51. Multihoming - Multiple Hosts, Multiple Networks, Multiple Lines

Example: The Multihoming function

Assume servers SYSNAM02 and SYSNAM03 are connected with a public or private X.25 network. The Internet address of this network is 9.4.73.64.

In this example, the server SYSNAM03 connects with a service provider by using TCP/IP and the same X.25 network attachment (Figure 52). The Internet address assigned by the service provider for the server is 223.1.1.17.

Figure 52. Multihoming TCP/IP Network

The multihoming function supports multiple networks with the same adapter. Server SYSNAM03 must handle two different Internet addresses on the same attachment. To do this, an additional TCP/IP interface needed to be specified (Figure 53 on page 60).

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 59

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display 9=Start 10=End

Internet Subnet Line Line Opt Address Mask Description Type __ _______________ __ 9.4.73.65 255.255.255.192 X25LINE *X25 __ 127.0.0.1 255.0.0.0 *LOOPBACK *NONE __ 223.1.1.17 255.255.255.0 X25LINE *X25

F3=Exit F5=Refresh F6=Print list F11=Display interface status F12=Cancel F17=Top F18=Bottom

Figure 53. Work with TCP/IP Interfaces Display, Multihoming

Type of Service (TOS)

Type of Service (TOS) is a parameter defined to indicate a quality of the service desired by an application program. It is specified within a single octet of the IP datagram header, and it is used to select Internet service. It denotes how the Internet hosts and routers should make trade-offs between throughput, delay, reliability, and cost.

Work with TCP/IP Interfaces

System: SYSNAM03

TOS is used to identify and select the actual transmission characteristics for a particular network, the interface, and the route to be used when routing an Internet datagram. The TOS values are mapped into the actual TOS value of the particular network a datagram is going through. All of the values are mutually exclusive.

The TOS values are defined through the Add TCP/IP Interface (ADDTCPIFC) and Add TCP/IP Route (ADDTCPRTE) commands. The possible selections are as follows:

*NORMAL

Normal service is used for delivery of datagrams.

*MINDELAY

Minimize delay means that prompt delivery is important for datagrams with this indication.

*MAXTHRPUT

Maximize throughput means that high data rate is important for datagrams with this indication.

*MAXRLB

Maximize reliability means that a higher level of effort to ensure delivery is important for datagrams with this indication.

*MINCOST

Minimize monetary cost means that lower cost is important for datagrams with this indication.

60 OS/400 TCP/IP Configuration and Reference V5R1

The following table shows which type of services your server uses for some of the TCP/IP applications:

Table 6. AS/400 TCP/IP applications and Type of Services

Protocol or Application Type of Service Used

TELNET Normal

FTP (control connection) Minimize delay

FTP (data connection) Maximize throughput

SMTP (command phase) Minimize delay

SMTP (data phase) Maximize throughput

POP (all phases) Maximize throughput

SNMP Maximize reliability

Thus, TOS is a suggestion, not a demand, to the interface (if more than one is present in the system) and to the routing algorithms. If a TCP/IP subsystem knows more than one interface and more than one possible route to a given destination, it uses the TOS to select one with characteristics closest to that desired.

TOS Example

For example, suppose the system can select between a low-capacity nonswitched line or a high-bandwidth (but high delay) satellite connection:

v Datagrams carrying keystrokes from a user to a remote computer could have the

type of service set to *MINDELAY, requesting that they be delivered as quickly as possible.

v Datagrams carrying a bulk file transfer could have the type of service set to

*MAXTHRPUT, requesting that they travel across the high-capacity satellite path.

It is up to the network administrator to define TOS values when defining interfaces and routes in the TCP/IP configuration. Based on the administrator’s knowledge of the hardware technologies available on systems and networks used, TOS values for the routes must also be defined according to the interface’sTOS value. This means that if a *MINDELAY value is defined in the interface definition, at least one route definition must have the *MINDELAY TOS value defined.

Note: A TCP/IP network does not guarantee the TOS requested. However,

datagram transmission is never denied.

Multiple Routes

You can have multiple routes in your routing table (by using the ADDTCPRTE command). You can have more than one route for the same destination Internet address with the same type of service or a different type of service. If you have multiple routes with the same types of service, they are used in the order specified. If a particular next hop router is not available, the subsequent specified next hop router is used. This continues until an entry that is active is found or the list of next hop values is exhausted. If you have multiple routes with different TOS, the one with the TOS equal to the one requested by applications with TOS octet in IP datagram is used. If no match is found in any specified routes, the route with the closest TOS or *NORMAL TOS is used.

You can have *DFTROUTE, and specific route destination addresses. Default routes are used only when data is sent to a remote destination system that does not have

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 61

a specific route defined. The system allows up to eight default routes, but each route must have a unique next hop value.

An example of a multiple route table can be found in Figure 54.

Type options, press Enter.

1=Add 2=Change 4=Remove 5=Display

Route Subnet Next Preferred

Opt Destination Mask Hop Interface

_ ______________ ______________ ______________ _ *DFTROUTE *NONE 9.4.73.193 *NONE _ *DFTROUTE *NONE 9.4.73.197 *NONE _ *DFTROUTE *NONE 9.4.73.196 *NONE _ 9.4.70.0 255.255.255.0 9.4.73.194 *NONE _ 9.4.70.0 255.255.255.0 9.4.73.195 *NONE _ 9.4.70.0 255.255.255.0 9.4.73.198 *NONE

F3=Exit F5=Refresh F6=Print list F10=Work with IP over SNA routes F11= Display type of service F12=Cancel F17=Top F18=Bottom

Figure 54. Work with TCP/IP Routes Display

TCP/IP Port Restriction

Work with TCP/IP Routes

System: SYSNAM003

Bottom

TCP and UDP protocols use ports to identify a unique origin or destination of communication with an application. Each port is assigned a small integer. You can configure port information if you want to restrict the use of a TCP or UDP port to one or more user IDs.

The range of port numbers is from 1 to 65535. However, ports 0-1023 are reserved as well-known port numbers, which are controlled and assigned by the Internet Assigned Numbers Authority (IANA). Only those applications that have been assigned one of these ports should use a number within this range. Refer to the current Assigned Numbers RFC for a list of the port assignments.

Because this range of port numbers, 0-1023, is reserved for the well-known ports, they should not be used by user application programs because it could affect the operation of TCP/IP. For example, restricting the use of ports 21, 23, or 25, prevents other users from using FTP, TELNET, or SMTP, respectively.

The iSeries Add TCP/IP Port Restriction (ADDTCPPORT) command allows you to restrict usage of a single port or a range of ports to a particular iSeries user profile.

Restricting ports is like allocating ports to a specific user profile. When a socket application issues the bind() system call, or when a TCP/UDP Pascal API application issues a call to the TcpOpen, TcpWaitOpen, or UdpOpen function, the job’s user profile is checked against the list of user profiles that are associated with

62 OS/400 TCP/IP Configuration and Reference V5R1

the specified port. If no match is found, the requesting program is not allowed to use the specified port. If any port in the 1-1023 range is restricted, the following message is posted:

Port restriction added but may affect TCP/IP processing

If no user profiles are associated with a specific port, there are no restrictions.

It is not necessary to configure port restrictions unless you are writing your own TCP/IP applications and you want to reserve the use of the applications to certain user profiles.

Note: For an installation in which user-written programs use ports other than the

well-known ports, you can consider restricting the use of the well-known ports to the user profiles running the server application. As an example, for File Transfer Protocol (FTP), this would be user profile QTCP.

Configuring TCP/IP Port Restrictions

To configure TCP/IP port restrictions, type option 4 on the Configure TCP/IP menu. The Work with TCP/IP Port Restrictions display is shown (Figure 55).

Work with TCP/IP Port Restrictions

Type options, press Enter.

1=Add 4=Remove

--Port Range--- User

Opt Lower Upper Protocol Profile

_ _____ *ONLY ____ __________

1050 1059 *TCP PAOLO

F3=Exit F5=Refresh F6=Print list F12=Cancel F17=Top F18=Bottom

Figure 55. Work with TCP/IP Port Restrictions Display

System: SYSNAM03

Bottom

Type option 1 (Add) at the input-capable top list entry to get to the Add TCP/IP Port Entry (ADDTCPPORT) display shown in Figure 56 on page 64. You can go directly to this display by typing ADDTCPPORT on any command line and pressing F4.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 63

Add TCP/IP Port Restriction (ADDTCPPORT)

Type choices, press Enter.

Range of port values:

Lower value ......... 1060 1-65535

Upper value .........>*ONLY 1-65535, *ONLY

Protocol............ *tcp *UDP, *TCP

User profile.......... gerry Character value

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More keys

Bottom

Figure 56. Add TCP/IP Port Restriction Display

Let us assume we have an application that uses Port 1060 in the TCP layer and we want to restrict its use to user profile GERRY. Type the information as shown in Figure 56.

Figure 57 shows what the display looks like after you enter port information for both user profiles PAOLO and GERRY.

Changes to the port restrictions take effect immediately. However, applications that are already active are not affected until they are restarted.

Work with TCP/IP Port Restrictions

Type options, press Enter.

1=Add 4=Remove

--Port Range--- User

Opt Lower Upper Protocol Profile

_ _____ *ONLY ____ __________

1050 1059 *TCP PAOLO 1060 *ONLY *TCP GERRY

System: SYSNAM03

F3=Exit F5=Refresh F6=Print list F12=Cancel F17=Top F18=Bottom

Figure 57. Work with TCP/IP Port Restrictions Display

64 OS/400 TCP/IP Configuration and Reference V5R1

Bottom

Related Tables and the Host Table

Socket applications require a set of tables from which they can retrieve specific TCP/IP network data when needed. These are as follows:

v Host table

v Service table

v Protocol table

v Network table

The host table contains a list of host names and corresponding Internet addresses. Socket applications requesting host data obtain it either from the server host database file or from the domain name server.

The service table contains a list of services and the specific port and protocol a services uses. The protocol table contains a list of protocols used in the TCP/IP network. The network table contains a list of networks and the corresponding Internet addresses.

UNIX** systems traditionally store this information in the following files:

v /etc/hosts - host table

v /etc/protocols - protocol table

v /etc/services - service table

v /etc/networks - network table

iSeries TCP/IP maintains the service, protocol, and network tables as database files. iSeries TCP/IP refers to these three tables as related tables. To configure or view the protocol, services, or network tables, select option 21 (Configure Related Tables) on the Configure TCP/IP menu. You are shown the display in Figure 58.

Configure Related Tables

Select one of the following:

1. Work with service table entry

2. Work with protocol table entry

3. Work with network table entry

Selection or command ===> ___________________________________________________________________ ________________________________________________________________________ F3=Exit F4=Prompt F9=Retrieve F12=Cancel

System: SYSNAM03

Figure 58. Configure Related Tables Menu

You can change the services, protocols, and network files using the options from this display.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 65

The services table stores the mapping of services to ports or ports to services as shown in Figure 59. The mapping information is usually accessed with the getservbyname() and getservbyport() socket functions.

Work with Service Table Entry

Type options, press Enter.

1=Add 4=Remove 5=Display

Opt Service Port Protocol

echo 7 udp finger 79 tcp finger 79 udp ftp-control 21 tcp ftp-control 21 udp ftp-data 20 tcp ftp-data 20 udp gopher 70 tcp gopher 70 udp graphics 41 tcp graphics 41 udp pop3 110 tcp

Parameters for options 1 and 4 or command ===> F3=Exit F4=Prompt F5=Refresh F6=Print list F9=Retrieve F12=Can F17=Top F18=Bottom

System: SYSNAM03

More...

Figure 59. Work with Service Table Entry Display

The protocol table stores the mapping of protocol names to protocol numbers and protocol numbers to protocol names. Socket applications use getprotobyname() and getprotobynumber() functions to access this table (Figure 60).

Work with Protocol Table Entry

System: SYSNAM03

Type options, press Enter.

1=Add 4=Remove 5=Display

Protocol

Opt Protocol number

_ _____________________________ _ icmp 1 _ip 0 _ tcp 6 _ udp 17

Parameters for options 1 and 4 or command ===> ______________________________________________________________________ F3=Exit F4=Prompt F5=Refresh F6=Print list F9=Retrieve F12=Cancel F17=Top F18=Bottom

Figure 60. Work with Protocol Table Entry Display

Bottom

66 OS/400 TCP/IP Configuration and Reference V5R1

The network table contains the networks and the Internet address associated with the network. Socket applications use the getnetbyname() and getnetbyaddr() functions to access the information in the network table (Figure 61).

Work with Network Table Entry

System: SYSNAM03

Type options, press Enter.

1=Add 4=Remove 5=Display

Internet

Opt Network address

_ _____________________________________ _______________ _ IBM 9.0.0.0

Figure 61. Work with Network Table Entry Display

Bottom

The protocols and services tables that are shipped contain standard information. The network tables do not contain any information. The network IBM information has been added in Figure 61, as an example.

For additional information about sockets, refer to Socket Programming (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzab6/ rzab6soxoverview.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Using X.25 PVC instead of SVC

In “Step 5—Configuring TCP/IP Remote System Information (X.25)” on page 16 you were shown how to define the X.25 network address of each system that uses a switched virtual circuit (SVC).

To replace the X.25 SVC with an X.25 permanent virtual circuit (PVC) connection, the example below is helpful. The following CL commands will look different: CRTLINX25, ADDTCPIFC, and ADDTCPRSI.

Use the same X.25 line description, but replace the first of the four SVCs with a PVC.

CRTLINX25 LIND(X25LINE) RSRCNAME(LIN051)

LGLCHLE((001 *PVC) (002 *SVCBOTH) (003 *SVCBOTH) (004 *SVCBOTH)) NETADR(40030003) CNNINIT(*LOCAL) TEXT('ITSO X.25 Network')

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 67

IP Multicasting

Multicast Application Programming Information

The TCP/IP interface now points to a specific PVC instead of a pool of SVCs.

ADDTCPIFC INTNETADR('9.4.73.65') LIND(X25LINE)

SUBNETMASK('255.255.255.192') PVCLGLCHLI(001) MAXSVC(0)

The TCP/IP remote system information no longer includes the X.25 address to be called. Instead, the entry points to the PVC channel ID.

ADDTCPRSI INTNETADR('9.4.73.66')

PVCLGLCHLI(001)

IP multicasting is the process of transmitting an IP datagram to a host group. The hosts that are in the group may reside on a single subnet or on different subnets that are connected by multicast-capable routers. Hosts may join and leave groups at any time. There are no restrictions on the location or number of members in a host group. For more information about IP multicasting, refer to RFC 1112, Host Extensions for IP Multicasting in the RFC Editor Site (http://www.rfceditor.org/rfc.html).

Note: The server cannot act as a multicast-capable router.

An application program can send or receive multicast datagrams by using the Sockets API and connectionless, SOCK_DGRAM type sockets. Multicasting is a one-to-many transmission method. You cannot use connection-oriented sockets of type SOCK_STREAM for multicasting. When a socket of type SOCK_DGRAM is created, an application can use the setsockopt() function to control the multicast characteristics associated with that socket. The setsockopt() function accepts the following IPPROTO_IP level flags:

v IP_ADD_MEMBERSHIP: Joins the multicast group specified.

v IP_DROP_MEMBERSHIP: Leaves the multicast group specified.

v IP_MULTICAST_IF: Sets the interface over which outgoing multicast datagrams

should be sent.

v IP_MULTICAST_TTL: Sets the time to live (TTL) in the IP header for outgoing

multicast datagrams.

v IP_MULTICAST_LOOP: Specifies whether or not a copy of an outgoing

multicast datagram should be delivered to the sending host as long as it is a member of the multicast group.

For additional information about sockets, including sample programs, see Sockets Programming (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzab6/ rzab6soxoverview.htm) in the Information Center. The System API Reference (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/apis/api.htm) documents the sockets API. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Multicast Restrictions

Multicast does not map well to all types of physical lines. For this reason, it is not supported on all lines. For example, a switched network such as X.25 does not lend itself to multicast applications because no mechanism exists for transmitting a single packet to all systems in the network that have joined a group. IP multicast is supported on broadcast capable networks and on SLIP/PPP interfaces, but it is not

68 OS/400 TCP/IP Configuration and Reference V5R1

supported on multi-access nonbroadcast networks. IP multicast is also not currently supported on Frame Relay, FDDI/SDDI, or ATM networks. To determine whether an interface supports multicast, enter option 14 on the Work with TCP/IP Interface Status display. If the interface supports multicast, there will be at least one Host Group entry for the All Hosts group 224.0.0.1. Otherwise, the interface does not support multicast.

The 2626 token-ring input-output processor (IOP) requires manual configuration to receive multicast datagrams. In particular, you must specify the token-ring address, C00000040000, on the functional address parameter for the token-ring line description. To add this address to a line description that is named TRNLINE, use the following command:

CHGLINTRN LIND(TRNLINE) FCNADR(C00000040000)

The 2617 Ethernet IOP also requires manual configuration in order to receive multicast datagrams. The Ethernet group addresses to be received need to be specified on the group address parameter (GRPADR) for the Ethernet line description. A 4-byte IP multicast address is mapped to a 6-byte Ethernet group address by placing the low-order 23 bits of the IP multicast address into the low-order 23 bits of the Ethernet group address 01005E000000. For example, to receive multicast datagrams with a destination address of 224.255.0.2, the GRPADR parameter for the 2617 Ethernet line description must include 01005E7F0002.

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 69

70 OS/400 TCP/IP Configuration and Reference V5R1

Chapter 3. TCP/IP Performance

The following are performance items that should be considered when using TCP/IP.

*BASE Pool Size

The TCP/IP protocol and application code always runs in the *BASE pool on the iSeries 400 server. If the *BASE pool is not given enough storage, TCP/IP performance, especially SMTP performance, can be adversely affected.

Although it is possible to run in less than 4000 KB of storage to perform well when running both FTP and SMTP sessions, it is suggested that the *BASE pool be configured to use at least 4000 KB of storage. You can use the WRKSYSSTS to view and change pool sizes on the server. Pool 2 is the base pool. Another alternative is to change the pool in which the TCP/IP jobs run.

TCP/IP Jobs

TCP/IP jobs, like other jobs on your system, are created from job descriptions and associated classes. The job descriptions and classes should be adequate in most cases; however, they may be changed to fit your configuration. The TCP/IP job descriptions, classes, and subsystem descriptions can be found in the QTCP or the QSYS library that was loaded in your system when TCP/IP was installed.

Each application has a job description associated with it. This job description has a number of items associated with it that define how the application runs on the server. One of these pieces of information is the routing entry compare value. This value identifies which routing entry in a subsystem description is used when this job is submitted. By changing that routing entry, you can select in which storage pool to run the jobs for a particular application. For information on compare values, see Work Management (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rzaks/ rzaks1.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Other items that can be changed or selected on a job description include the job priority, the logging level for messages, and the initial library list.

If the storage pool that you select to run the TCP/IP application jobs in is not large enough, excessive paging can occur. This directly affects performance on the server and the performance of the applications.

TCP/IP Protocol Support Provided by IOP

iSeries TCP/IP protocol support runs down in the AS/400 System Licensed Internal Code, at the same level as LU 6.2 and APPN*. One of the goals of integrating TCP/IP into the AS/400 System Licensed Internal Code is to provide performance and capacity comparable to APPC.

| | |

Further, moving some functions that are normally done by the TCP/IP software into the IOP reduces interactions between the system and the input/output processor (input-output processor (IOP)). These functions may include:

| |

| | |

v Checksum calculation of outgoing TCP and UPD datagrams (prior to V4R4)

v Checksum verification of incoming TCP and UPD datagrams (prior to V4R4)

v Outbound batching of TCP and UDP datagrams.

v Fragmentation of TCP and UDP datagrams into segments that match the MTU

size.

v Starting with V4R2, iSeries collects all TCP datagrams in one batch and UDP

datagrams in a second batch. Ports and IP addresses are ignored. Releases prior to V4R2 batch together datagrams at the IOP when these conditions are true:

– The protocol (TCP or UDP) matches

– The source and destination ports match

– The source IP address and destination IP address match

– They arrive consecutively into the IOP

| |

| | | | |

| | |

The IOP then passes the datagram batch to IP.

v Handling of IP and ICMP datagrams in error (unless IP NAT, which disables this

function, is active)

v Resolving physical addresses using ARP protocol

These functions are called TCP/IP-assist functions. Whether these functions are done by the IOP or the System Licensed Internal Code (SLIC), depends on the IOP type, the OS/400 release, and the TCP/IP configuration. For details about specific functions, contact your local service representative. TCP/IP-assist functions are available on these IOPs:

v #2617 Ethernet/IEEE 802.3 adapter/HP

v #2619 16/4 Mbps Token-Ring Network adapter/HP

v #2618 Fiber distributed data interface adapter (FDDI)

v #2665 Shielded distributed data interface adapter (SDDI)

v #2666 High-speed communication adapter that is running frame relay only

v #2668 iSeries wireless LAN adapter

Note: You can get the same function without using one of the above IOP adapters

(done instead at a higher level in the system (SLIC)). When you use the X.25 protocol, you do not gain the advantage of the TCP/IP-assist function.

The TCP/IP-assist functions are also available on the following LAN IOAs and ATM IOAs:

v #2723 PCI Ethernet IOA

v #2724 PCI Token-Ring IOA

v #2838 PCI 100/10 Mbps Ethernet IOA

v #6149 16/4 Mbps Token-Ring IOA

v #2811 PCI 25 Mbps UTP ATM IOA

v #2812 PCI 45 Mbps Coax T3/DS3 ATM IOA

v #2813 PCI 155 Mbps MMF ATM IOA

v #2814 PCI 100 Mbps MMF ATM IOA

v #2815 PCI 155 Mbps UTP 0C3 ATM IOA

v #2816 PCI 155 Mbps MMF ATM IOA

v #2818 PCI 155 Mbps SMF 0C3 IOA

v #2819 PCI 34 Mbps Coax E3 ATM IOA

72 OS/400 TCP/IP Configuration and Reference V5R1

| |

Note: If you configure your 100 Mbps ethernet line for TCPONLY, all IOP assist

functions are disabled.

TCP/IP-assist functions that are available on frame relay IOAs are:

v #2699 Two-Line WAN IOA

v #2720 PCI WAN/Twinaxial IOA

v #2721 PCI Two-Line WAN IOA

Communications restrictions apply if any of the following communication functions are required when using the frame relay IOAs, as listed above:

v X.25, Frame Relay, or IPX Protocol

v SDLC protocol, if used to connect to more than 64 remote sites

v Communications line speeds greater than 64 Kbps and up to 2.048 Mbps for the

synchronous data link control (SDLC) or frame relay protocols (bisync is always limited to a maximum of 64 Kbps)

v Communications line speeds greater than 64 Kbps and up to 640Kbps for X.25

Merge Host Table Performance

| | |

You can use the following data to help you plan for and anticipate performance when merging host tables. The data represents averages of measurements that are taken. The actual time required on your server will be different.

Three cases were measured:

v Small merge—merge a 250-record file into the local host table that currently has

50 entries

v Medium merge—merge a 2000-record file into the local host table that currently

has 50 entries

v Large merge—merge a 5000-record file into the local host table that currently has

50 entries.

The results of this test are shown in Table 7.

Table 7. Merge Host Table Performance

Number of records merged Record format

250 *AIX 0:42 43.7 2000 *NIC 5:38 49.4 5000 *NIC 13:54 48.6

Elapsed time (min:sec) CPU percent

This data equates to about 6 records per second and about .07-.08 processing unit seconds per record.

Running TCP/IP Only: Performance Considerations

| | |

| |

Certain configurations of 2838 - 10/100 Mbps Ethernet cards allow you to run the IOP with only TCP/IP instead of all protocols for better performance. You need a 2838 Ethernet card with either:

v 2810 IOP

v 2809 IOP (the 2838 must be the only input/output adapter (IOA)IOA on the

IOP)

Chapter 3. TCP/IP Performance 73

| | |

If you have one of these configurations, you can use the TCPONLY parameter when you create or change your Ethernet line descriptions. Setting TCPONLY to *YES in other hardware configurations has no effect on the line.

74 OS/400 TCP/IP Configuration and Reference V5R1

Appendix A. Configuring a Physical Line for TCP/IP Communication

On the iSeries 400, communication occurs through objects called lines, controllers, and devices. The communications objects for iSeries TCP/IP are the line descriptions, the network controller descriptions, and the network device descriptions.

TCP/IP communicates over a variety of physical line types and network interfaces (NWI). The command that defines the characteristics of the physical line connection or network interface depends on the type of communications adapter, as shown in Table 8.

Table 8. Line Types and Network Interfaces Supported by TCP/IP

Line type Configuration command

Asynchronous Create Line Description (Async) (CRTLINASC) See Link

Configuration (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/ rzaiy/rzaiylinkline.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

DDI Create Line Description (DDI Network) (CRTLINDDI)

Ethernet Create Line Description (Ethernet) (CRTLINETH)

Frame relay Create Line Description (Frame Relay Network) (CRTLINFR)

Frame relay NWI using a frame relay, token ring, Ethernet, or DDI line description

ISDN NWI using an X.25 line description

The frame relay NWI is created using the Create Network Interface Frame Relay Network (CRTNWIFR) command.

The line description is created using the appropriate Create Line Description command and attached to the frame relay NWI by specifying the NWI and NWIDLCI parameters.

The ISDN NWI is created using the Create Network Interface ISDN (CRTNWIISDN) command.

The X.25 line is created using the Create Line X.25 (CRTLINX25) command and attached to the ISDN NWI by specifying the NWI, NWICHLTYPE, NWICHLNBR, and SWTNWILST parameters.

Point-to-Point Create Line Description (PPP) (CRTLINPPP) See Link Configuration

(http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/ rzaiy/rzaiylinkline.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Token-ring Create Line Description (Token-Ring Network) (CRTLINTRN)

Twinax Create Line Description (TDLC) (CRTLINTDLC)

Wireless Create Line Description (Wireless Network) (CRTLINWLS)

X.25 Create Line Description (X.25) (CRTLINX25)

You can describe the characteristics of the communications controllers by using the Create Controller Description (Network) (CRTCTLNET) command or by letting the system create the controller automatically when you activate TCP/IP. You only need one network controller to describe all the systems with which you communicate over any given line description.

You can describe the characteristics of the communications devices using the by Create Device Description (Network) (CRTDEVNET) command or by letting the system create the device automatically when you activate TCP/IP.

If you want to change controller or device descriptions, use the Change Controller Description (Network) (CHGCTLNET) and Change Device Description (Network) (CHGDEVNET) commands. For more information on changing controller or device descriptions, see Control Languages (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rbam6/ rbam6clmain.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Configuration Steps

To connect any of the communications adapters listed in Table 8 on page 75 to the network, perform the following steps:

1. Create a line description (see “Creating the Line Description”).

2. Set the line description maximum frame size or SSAP maximum frame size.

You must consider this value when setting the maximum transmission unit (MTU) of the TCP/IP interface (see “Setting the Maximum Transmission Unit”

on page 77). This is not a required step because there are default MTU values

for all line types.

Creating the Line Description

If you have already configured a physical line, this existing line can be shared between TCP/IP data and data from other protocols like SNA or OSI at the same time. There is no need for a separate physical line to support TCP/IP. If a line description does not exist for a physical IOP, you must create a new one. Use one of the commands mentioned in Table 8 on page 75 to create a line description or network interface appropriate for your communications adapter. For more information on creating line descriptions, see LAN, Frame-Relay and ATM Support, X.25 Network Support, and Communications Configuration. Pay particular attention to the following items when creating or changing a line description for TCP/IP communications:

v Line description name.

v Source Service Access Point (SSAP).

Line Description Name

You need the name of the line description when you configure TCP/IP on your system (see “Step 1—Configuring a Line Description” on page 10). Remember the name you choose when you create the line description, or use the Work with Configuration Status (WRKCFGSTS) command to find the name of an existing line.

Source Service Access Point

If the line type supports source service access points (SSAP), you must specify X'AA' as entries in the SSAP list. SSAP examples include Token-ring, Ethernet IEEE802.3, DDI, and wireless. This occurs by default when you create a new line description and leave the SSAP parameter at its default value of *SYSGEN.Ifyou have an existing line description, use the appropriate change line description command and add X'AA' to the SSAP list.

If the Ethernet standard prompt value is *ALL or IEEE8023, then you must specify X'AA' as entries in the SSAP list. This occurs by default when you create a new line description and leave the SSAP parameter at its default value of *SYSGEN.

76 OS/400 TCP/IP Configuration and Reference V5R1

If the Ethernet standard prompt is *ETHV2, the system sends and receives all TCP/IP data in Ethernet Version 2 frames. You do not need to configure any additional SSAPs for TCP/IP.

Setting the Maximum Transmission Unit

The maximum transmission unit (MTU) parameter that you can enter on the Add TCP/IP Interface (ADDTCPIFC) command, Add TCP/IP Route (ADDTCPRTE) command, Change TCP/IP Interface (CHGTCPIFC) command, or Change TCP/IP Route (CHGTCPRTE) command depends on the type of line that you use. The

following is a list of the maximum MTU values that you can specify, based on the line type:

Asynchronous (SLIP) 1006 DDI 4352 Ethernet 802.3 1492 Ethernet Version 2 1500 Frame relay 8177 Point-to-Point (PPP) 4096 Token ring (4 meg) 4060 Token ring (16 meg) 16388 Wireless 802.3 1492 Wireless Version 2 1500 X.25 4096

Notes:

1. TCP/IP processing uses a small part of each datagram. Therefore, the whole

datagram size is unavailable for user data.

2. The value of the maximum transmission unit used by TCP/IP processing

depends on the value that you specify for the route on the MTU parameter of the route or interface commands mentioned previously. It also depends on the type of physical line that you use, the maximum frame size of the network line, and the SSAP maximum frame size.

Determining the Maximum Size of Datagrams

For a communications line, specify the maximum frame size on the appropriate Create Line Description command. The maximum frame size is compared to the MTU value of the route or interface. TCP/IP uses the lesser of these two values to determine the maximum size of datagrams that it sends by over this line.

For example, if you specify 1024 for the MTU parameter for a route attached to a communications line and the line description contained a value of 512 for a maximum frame size, the maximum datagram size value for the route that TCP/IP uses is 512. If the line is varied off and you change the maximum frame size on the Token-ring line description to 1994, and then the line is varied on, the maximum transmission unit used for the route is reset to 1024 when the next TCP/IP operation occurs that causes a datagram to be sent.

Appendix A. Configuring a Physical Line for TCP/IP Communication 77

78 OS/400 TCP/IP Configuration and Reference V5R1

Appendix B. TCP/IP Application Exit Points and Programs

Certain TCP/IP applications provide exit points that enable them to call customer-written exit programs. This appendix contains the following information:

v Conceptual information on TCP/IP exit points and programs

v General instructions on creating exit programs for TCP/IP applications

v Descriptions of the TCP/IP application exit point interfaces

v Specific instructions on how to prepare exit programs for each TCP/IP

application exit point, with examples.

TCP/IP Exit Points and Exit Programs

An exit point is a specific point in the TCP/IP application program where control may be passed to an exit program. An exit program is a program to which the exit point passes control.

For each exit point, there is an associated programming interface, called an exit point interface. The exit point uses this interface to pass information between the TCP/IP application and the exit program. Each exit point has a unique name. Each exit point interface has an exit point format name that defines how information is passed between the TCP/IP application and the customer-written exit program.

Different exit points may share the same exit point interface. When this is the case, multiple exit points can call a single exit program.

Figure 62 shows how parameters and control are passed from the TCP/IP application program to the customer-written exit program and back again.

Figure 62. TCP/IP Exit Point Processing

OS/400 Registration Facility

Exit points for TCP/IP applications are automatically registered when the parent product or option is installed, using the OS/400 registration facility. The registration facility contains a repository that allows customers to associate their exit programs with specific exit points. TCP/IP applications check the registration facility repository to determine which exit program to call for a particular exit point.

You must add your exit program to an exit point in the registration repository before a TCP/IP application can call it. Adding the exit program to the repository associates the exit program with a specific exit point.

For security exit programs, the TCP/IP application will typically request the exit program to indicate if a specified operation should be allowed. When no exit program has been added to an exit point, the TCP/IP application assumes that no additional security controls are to be applied.

You can use the Work with Registration Information (WRKREGINF) command to display a list of the exit points in the OS/400 registration facility. Use this list to display information about an exit point or to work with exit programs associated with an exit point. The Work with Registration Information display is shown in Figure 63 on page 82.

TCP/IP Application Exit Points

The following table lists the exit points provided for each TCP/IP application.

Note: If using Distributed Data Management (DDM), see the DDMACC parameter

on CHGNETACMD in Control Languages (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/rbam6/ rbam6clmain.htm) for more information. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Table 9. TCP/IP Application Exit Points

TCP/IP Application Exit Point Exit Point Format

FTP Client QIBM_QTMF_CLIENT_REQ VLRQ0100

FTP Server QIBM_QTMF_SERVER_REQ VLRQ0100

|||

FTP Server QIBM_QTMF_SVR_LOGON TCPL0100

REXEC Server QIBM_QTMX_SERVER_REQ VLRQ0100

|||

REXEC Server QIBM_QTMF_SVR_LOGON TCPL0100

REXEC Server QIBM_QTMF_SVR_SELECT RXCS0100 (see page 89

|||

TFTP Server QIBM_QTOD_SERVER_REQ VLRQ0100

Workstation gateway (WSG) server

DHCP Server QIBM_QTOD_DHCP_REQ DHCV0100

DHCP Server QIBM_QTOD_DHCP_ABND DHCA0100

DHCP Server QIBM_QTOD_DHCP_ARLS DHCR0100

TELNET Server QIBM_QTG_DEVINIT INIT0100

TELNET Server QIBM_QTG_DEVTERM TERM0100

QIBM_QTMT_WSG QAPP0100

(see page 85)

or TCP0200

(see page 85)

80 OS/400 TCP/IP Configuration and Reference V5R1

Table 9. TCP/IP Application Exit Points (continued)

TCP/IP Application Exit Point Exit Point Format

Note:

|| | |

The same interface format is used for request validation for the FTP client, FTP server, REXEC server, and TFTP server. This allows the use of one exit program for request validation of any combination of these applications.

The same interface format is used for server log-on processing for the FTP server and REXEC server applications. This allows the use of one exit program to process log-on requests for both of these applications.

For a detailed description of the DHCP exit points and how to use them, see System API Reference (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/apis/api.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

Creating Exit Programs

There are several steps involved in designing and writing exit programs. They include:

1. Review the purpose of the exit point and the format of its interface

2. Define the scope and operation of your exit program

3. Design the exit program

4. Code the exit program

5. Add the exit program to the appropriate exit point in the registration facility.

(See “Adding Your Exit Program to the Registration Facility” for instructions on how to do this.)

Note: Only users with both *SECADM and *ALLOBJ authority are allowed to

add and remove TCP/IP application exit programs.

6. Test your exit program

v Tests for each user ID

v Tests for each operation

The most important step in establishing security exit programs is verifying that the exit program works. You must assure that the security wall works and does not have any weaknesses.

Notes:

1. If the exit program fails or returns an incorrect output parameter, the operation

will not be allowed by the TCP/IP application.

2. To ensure the highest level of security, create the exit program in a library that

has *PUBLIC authority of *EXCLUDE and give the exit program itself a *PUBLIC authority of *EXCLUDE. The TCP/IP application adopts authority when it is necessary to resolve and call the exit program.

Adding Your Exit Program to the Registration Facility

To add your exit program, run the Work with Registration Information (WRKREGINF) command. The following display is shown:

Appendix B. TCP/IP Application Exit Points and Programs 81

Work with Registration Information

Type options, press Enter.

5=Display exit point 8=Work with exit programs

Exit Point

Opt Point Format Registered Text

QIBM_QRQ_SQL RSQL0100 *YES Original Remote SQL Server QIBM_QSY_CHG_PROFILE CHGP0100 *YES Change User Profile Exit Poin QIBM_QSY_CRT_PROFILE CRTP0100 *YES Create User Profile Exit Poin QIBM_QSY_DLT_PROFILE DLTP0100 *YES Delete User Profile Exit Poin QIBM_QSY_DLT_PROFILE DLTP0200 *YES Delete User Profile Exit Poin QIBM_QSY_RST_PROFILE RSTP0100 *YES Restore User Profile Exit Poi QIBM_QTF_TRANSFER TRAN0100 *YES Original File Transfer Functi QIBM_QTMF_CLIENT_REQ VLRQ0100 *YES FTP Client Request Validation QIBM_QTMF_SERVER_REQ VLRQ0100 *YES FTP Server Request Validation QIBM_QTMF_SVR_LOGON TCPL0100 *YES FTP Server Logon QIBM_QTMT_WSG QAPP0100 *YES WSG Server Sign-On Validation

Command ===> F3=Exit F4=Prompt F9=Retrieve F12=Cancel

Exit

More...

Figure 63. Work with Registration Information Display — Display 1

Step 1. Select your exit point

Type 8 next to the exit point to which you want to add an exit program. For example, to associate a program with the WSG server sign-on validation exit point, type an 8 next to this exit point, as shown.

QIBM_QSY_RST_PROFILE RSTP0100 *YES Restore User Profile Exit Poi QIBM_QTF_TRANSFER TRAN0100 *YES Original File Transfer Functi QIBM_QTMF_CLIENT_REQ VLRQ0100 *YES FTP Client Request Validation QIBM_QTMF_SERVER_REQ VLRQ0100 *YES FTP Server Request Validation QIBM_QTMF_SVR_LOGON TCPL0100 *YES FTP Server Logon

8 QIBM_QTMT_WSG QAPP0100 *YES WSG Server Sign-On Validation

Command ===> F3=Exit F4=Prompt F9=Retrieve F12=Cancel

Figure 64. Work with Registration Information Display — Display 2

The Work with Exit Programs display is shown.

More...

82 OS/400 TCP/IP Configuration and Reference V5R1

Work with Exit Programs

Exit point: QIBM_QTMT_WSG Format: QAPP0100

Type options, press Enter.

1=Add 4=Remove 5=Display 10=Replace

Exit

Opt Number Program Library

(No exit programs found.)

Figure 65. Adding an Exit Program — Display 1

Program Exit

Step 2: Select the Add Exit Program option

Select the add option by typing a 1 (Add) in the Opt column as shown in Figure 66.

Work with Exit Programs

Exit point: QIBM_QTMT_WSG Format: QAPP0100

Type options, press Enter.

1=Add 4=Remove 5=Display 10=Replace

Exit

Opt Number Program Library

(No exit programs found.)

Figure 66. Adding an Exit Program — Display 2

Program Exit

Step 3: Add your exit program

Fill in the exit program information as shown in Figure 67 on page 84 and Figure 68 on page 84, then press enter.

Notes:

1. You can bypass Steps 1 and 2 by using the Add Exit Program (ADDEXITPGM)

command.

2. You must set the Program number parameter of the Add Exit Program

(ADDEXITPGM) command to 1 when adding exit programs to FTP exit points.

3. When you add exit programs for FTP clients, these programs take effect as

soon as you start additional sessions. Changes do not affect client sessions that are already running.

4. When you add FTP server exit programs, end and restart the FTP servers to

ensure that all servers are using the exit programs.

Appendix B. TCP/IP Application Exit Points and Programs 83

When you add workstation gateway server exit programs, you do not need to end and restart the workstation gateway server. The WSG server checks for the exit program dynamically.

When you add REXEC server exit programs, you do not need to end and restart the REXEC server. The REXEC server checks for the exit programs dynamically.

Add Exit Program (ADDEXITPGM)

Type choices, press Enter.

Exit point...........>QIBM_QTMT_WSG

Exit point format .......>QAPP0100 Name

Program number.........>1 1-2147483647, *LOW, *HIGH

Program ............>YOURPGM Name

Library ...........> YOURLIB Name, *CURLIB

Text 'description'.......>'Description of your exit program'

Additional Parameters

Replace existing entry.....>*NO *YES, *NO

Create exit point ....... *NO *YES, *NO

F3=Exit F4=Prompt F5=Refresh F12=Cancel F13=How to use this display F24=More keys

Figure 67. Adding an Exit Program — Display 3

Type choices, press Enter.

Exit program data:

Coded character set ID.... *JOB Number, *NONE, *JOB

Length of data........ 0-2048, *CALC

Program data.........

...

Figure 68. Adding an Exit Program — Display 4

Removing Exit Programs

To remove an exit program from an exit point, do one of the following:

v Follow the steps for adding an exit point until the Work with Exit Programs

display is shown. Select option 4 (Remove) to remove the exit program.

v Use the Remove Exit Program (RMVEXITPGM) command.

More...

Add Exit Program (ADDEXITPGM)

When you remove an exit program that performs a security-related operation, this operation is no longer performed. Remove security-related exit programs with caution.

84 OS/400 TCP/IP Configuration and Reference V5R1

Exit Point Interfaces for TCP/IP Application Exit Points

The exit point interfaces for TCP/IP application exit points are:

| |

v TCP/IP application request validation exit point interface

v TCP/IP remote execution server command processing selection exit point

interface

Note: For a detailed description of the DHCP exit points and how to use them, see

System API Reference (http://publib.boulder.ibm.com/pubs/html/as400/v5r1/ic2924/info/apis/ api.htm) in the Information Center. If you are using the Supplemental Manuals CD, then switch to the iSeries Information Center CD to access this information.

TCP/IP Application Request Validation Exit Point Interface

Required Parameter Group:

1 Application identifier Input Binary(4) 2 Operation identifier Input Binary(4) 3 User profile Input Char(10) 4 Remote IP address Input Char(*) 5 Length of remote IP address Input Binary(4) 6 Operation-specific information Input Char(*) 7 Length of operation-specific

information

8 Allow operation Output Binary(4)

Input Binary(4)

Exit Point Name: QIBM_QTMF_CLIENT_REQ Exit Point Name: QIBM_QTMF_SERVER_REQ Exit Point Name: QIBM_QTMX_SERVER_REQ Exit Point Name: QIBM_QTOD_SERVER_REQ Exit Point Format Name: VLRQ0100

The TCP/IP request validation exit point enables additional control for restricting an operation. Any restrictions that are imposed by the exit program are in addition to any validation that is performed by the application program, such as normal server object security. When an exit program is added to the exit point, it is called by the TCP/IP application to validate the requested action specified by the operation identifier and other input parameters in the required parameter group. The exit program sets the output parameter, Allow operation, to indicate if the TCP/IP application is to perform the operation.

Note: All character data passed to the exit program is in the coded character set

ID (CCSID) of the job, or if the job CCSID is 65535, the default CCSID of the job.

Required Parameter Group

Application identifier

INPUT; BINARY(4) Identifies the application program from which the request is being made. The valid values are as follows:

0 FTP client program

1 FTP server program

2 REXEC server program

Appendix B. TCP/IP Application Exit Points and Programs 85

3 TFTP server program

Operation identifier

INPUT; BINARY(4) Indicates the operation that the user is attempting to

perform. When the application identifier indicates the FTP client or FTP server

program, the valid values are as follows:

0 Session initialization

1 Directory/library creation

2 Directory/library deletion

3 Set current directory

4 List files

5 File deletion

6 Sending file

7 Receiving file

8 Renaming file

9 Execute CL command

When the application identifier indicates the REXEC server program, valid

values are as follows:

0 Session initialization

9 Perform CL command

When the application identifier indicated the TFTP server program, the valid

values are as follows:

6 Sending file (RRQ)

7 Receiving file (WRQ)

User profile

INPUT; CHAR(10) The user profile under which the requested operation is run

(if it is allowed).

Remote IP address

INPUT; CHAR(*) The Internet Protocol (IP) address of the remote host system.

This string is in dotted decimal format, left justified. The remote host may be a

client or a server based on the setting of the application identifier parameter.

Length of remote IP address

INPUT; BINARY(4) Indicates the length (in bytes) of the remote IP address.

Operation specific information

INPUT; CHAR(*) Information that describes the operation being attempted.

The contents of this field are dependent on the value of the operation

identifier.

For operation identifier 0 and application identifier 0, there is no

operation-specific information. This field is blank.

For operation identifier 0 and application identifier 1, the operation-specific

information contains the IP address that identifies the TCP/IP interface

through which the connection to the local host (server) system is established.

This string is in dotted decimal format, left justified.

86 OS/400 TCP/IP Configuration and Reference V5R1

IBM SC41-5420-04 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

About TCP/IP Configuration and Reference (SC41-5420)

Prerequisite and related information

Operations Navigator

How to send your comments

Summary of changes

Chapter 1. Configuring TCP/IP

What you need to know before you can configure TCP/IP

Planning for TCP/IP Installation and Configuration

Gathering Information About your Network

TCP/IP Planning Checklists

Line Description Parameters Checklist

Local TCP/IP Host Information Checklist

Installing the TCP/IP Application Programs

Using the TCP/IP Administration Menu

Using the Configure TCP/IP Menu

Configuring TCP/IP using the EZ-Setup Wizard

Configuring TCP/IP using the Command Line Interface

Step 1—Configuring a Line Description

Step 2—Configuring a TCP/IP Interface

Step 3—Configuring TCP/IP Routes

Step 4—Configuring TCP/IP attributes

Step 5—Configuring TCP/IP Remote System Information (X.25)

Step 6—Configuring TCP/IP Host Table Entries

Adding an Entry to the Host Table

Work with TCP/IP Host Table Display

AnyNet/400: APPC over TCP/IP

Step 7—Configuring the Local Domain and Host Name

Domain Name System (DNS) Server

Step 8—Starting TCP/IP and TCP/IP Servers

TCP/IP Jobs

Step 9—Verifying the TCP/IP Connection

Verifying Additional TCP/IP Connections

Verifying TCP/IP Connections with Host Name—Example

Verifying TCP/IP Connections with Internet Address—Example

Step 10—Saving Your TCP/IP Configuration

Chapter 2. TCP/IP: Operation, Management, and Advanced Topics

Network Status

Work with TCP/IP Network Status Menu

Work with TCP/IP Interface Status

Starting TCP/IP Interfaces

Ending TCP/IP Interfaces

Display TCP/IP Route Information

Work with TCP/IP Connection Status

Ending TCP/IP Connections

Working with Configuration Status

Displaying TCP/IP Network Status Information

Display Multicast Groups

Displaying TCP/IP Interfaces

Displaying Associated Routes

Displaying Route Details Option

Displaying TCP/IP Route Information

Displaying TCP/IP Connections

Displaying Connection Totals

TCP/IP Host Tables

Managing TCP/IP Host Tables

Host File Formats

Host Table Information with *AIX Files

Host Table Information with *NIC Files

Host Table Information with *AS400 Files

Tips for Merging Host Tables

Merging TCP/IP Host Tables

Example: Successful Host Table Merge

Example: Partly Successful Host Table Merge

Managing the Host Table from a Central Site

Step 1—Create the Host Table on Your Central System

Step 2—Start FTP to a Remote System

Step 3—Tell FTP to Send the Host File to the Remote System

Step 4—Merge the File

IP Routing and Internet Control Message Protocol (ICMP) Redirecting

Dead Gateway Processing

Negative Advice from TCP or the Data Link Layer

How IP Responds to Negative Advice

Multihoming Function

Example: A Single Host on a Network over a Communications Line

Example: Multiple Hosts on the Same Network over the Same Communications Line
