IBM
IBM® Netfinity® 4500R
Installation Guide
SC09-N819-30
NOTE
Before using this information and the product it supports, be sure to read the general information in
“Appendix A. Product warranties and notices,” on page 31.
First Edition (March 2000)
© COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 2000. All rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject
to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Chapter 1.Introduction . . . . . . . . . . . . . . . . 1
Specifications and features. . . . . . . . . . . . . . . . . . . . . . . . . 2
Notices used in this book. . . . . . . . . . . . . . . . . . . . . . . . . . 3
Major components of the Netfinity 4500R server. . . . . . 4
Chapter 2.Installing Options. . . . . . . . . . . . 5
Working inside a server with power on. . . . . . . . . . . . . . 5
Installing adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing a drive in a hot-swap bay. . . . . . . . . . . . . . . . . 9
Installing a microprocessor . . . . . . . . . . . . . . . . . . . . . . . 10
Installing a hot-swap power supply . . . . . . . . . . . . . . . 12
Installing memory modules. . . . . . . . . . . . . . . . . . . . . . . 14
Cabling the server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Chapter 3.Starting the server . . . . . . . . . . 17
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operator information panel. . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 4.Configuring your server . . . . . 21
Using the ServerGuide CDs. . . . . . . . . . . . . . . . . . . . . . . 21
After installing the NOS . . . . . . . . . . . . . . . . . . . . . . . 22
Netfinity systems management solutions . . . . . . . . . . . 22
Chapter 5.Solving problems. . . . . . . . . . . 23
POST beep code descriptions . . . . . . . . . . . . . . . . . . . . . 23
POST error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
ServerGuide startup problems . . . . . . . . . . . . . . . . . . . . 26
Troubleshooting chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Appendix A. Product warranties and
notices . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Warranty Statements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
IBM Statement of Limited Warranty for United States,
Puerto Rico, and Canada (Part 1 - General Terms) . 31
IBM Statement of Warranty Worldwide except
Canada, Puerto Rico, Turkey, United States (Part 1 –
General Terms) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Part 2 - Worldwide Country-Unique Terms. . . . . . . 36
Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Edition Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Year 2000 readiness and instructions. . . . . . . . . . . . . 41
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Electronic emission notices . . . . . . . . . . . . . . . . . . . . . . . 42
Federal Communications Commission (FCC)
Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Industry Canada Class A emission compliance
statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Australia and New Zealand Class A statement. . . . 43
United Kingdom telecommunications safety
requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
European Union EMC Directive conformance
statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Taiwan electrical emission statement . . . . . . . . . . . . 44
Japanese Voluntary Control Council for Interference
(VCCI) statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Power cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
IBM® Netfinity® 4500R Installati on Guide
© Copyright IBM Corp. 2000 v
Safety
Safety
Before installing this product, read the Safety Information book.
Antes de instalar este produto, leia o Manual de Informações sobre Segurança.
Læs hæftet med sikkerhedsforskrifter, før du install erer dette produkt.
Lue Safety Information -kirjanen, ennen kuin asennat tämän tuotteen.
Avant de procéder à l'installatio n de ce produit, lisez le manuel Safety Information.
Vor Beginn der Installation die Broschüre mit Sicherheitshinweisen lesen.
Prima di installare questo prodotto, leggere l'opuscolo contenente le informazioni
sulla sicurezza.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Przed zainstalowaniem tego produktu należy przeczytać broszurę Informacje Dotyczące
Bezpieczeństwa.
vi IBM® Netfinity® 4500R Installation Guide
Safety
Lees voordat u dit product installeert eerst het boekje met veiligheidsvoorschriften.
Les heftet om sikkerhetsinformasjon (Safety Information) før du installerer dette
produktet.
Antes de instalar este produto, leia o folheto Informações sobre Segurança.
Antes de instalar este producto, lea la Información de Seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Перед установкой продукта прочтите брошюру по технике безопасности
(Safety Information).
Pred inštaláciou tohto produktu si pre ítajte Informa nú brožúrku o bezpe nosti.
Preden namestite ta izdelek, preberite knjižico Varnostne informacije.
Installálás el tt olvassa el a Biztonsági el írások kézikönyvét !
vii
Safety
Statement 1
Danger
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
• Do not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical storm.
• Connect all power cords to a properly wired and grounded electrical outlet.
• Connect to properly wired outlets any equipment that will be attached to
this product.
• When possible, use one hand only to connect or disconnect signal cables.
• Never turn on any equipment when there is evidence of fire, water, or
structural damage.
• Disconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
• Connect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached devices.
To connect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
To disconnect:
1. Turn everything OFF.
2. First, remove power cords from
outlet.
3. Remove signa l cables from
connectors.
4. Remove all cables from devices.
viii IBM® Netfinity® 4500R Installation Guide
Safety
Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manu facturer. If your system has a
module containing a lithium battery, replace it only with the same module type
made by the same manufacturer . The battery contain s lithium and can explode if
not properly used, handled, or disposed of.
Do not:
• Throw or immerse into water.
• Heat to more than 100 C (212 F)
• Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
• Do not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
• Use of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.
Danger
Some laser products contain an embedded Class 3A or Class 3B laser diode. Note
the following. Laser radiation when open. Do no t star e into the beam, d o not view
directly with optical instruments, and avoid direct exposure to the beam.
ix
Safety
Statement 4
≥
18 kg (37 lbs)
≥
32 kg (70.5 lbs)
≥
55 kg (121.2 lbs)
CAUTION:
Use safe practices when lifting.
Statement 5
CAUTION:
The power control button on the device and the power supply do not turn off
the electrical current supplied to the device. The device also might have more
than one power cord. To remove all electrical current from the device, ensure
that all power cords are disconnected from the power source.
1
2
x IBM® Netfinity® 4500R Installation Guide
Safety
© Copyright IBM Corp. 2000 1
Chapter 1. Introduction
Introduction
Thank you for purchasing an IBM® Netfinity® 4500R server. This Installation Guide
provides the information needed to:
• Set up and cable your server
• Start and configure your serv er
• Install your network operating system (NOS)
Packaged with the Installation Guide are software CDs that help you configure
hardware, install device drivers, and install the network operating system (NOS).
Also included is an IBM Netfinity Documentation CD that provides detailed
information about your server.
Your server comes with a three-year limited warranty and 90-Day IBM Start Up
Support. If you have access to the World Wide Web, you can obtain up-to-date
information about your server model and other IBM server products at the following
World Wide Web address:
http://www.ibm.com/pc/us/netfinity/
Refer to the Rack Installation Instructions for installa t ion and removal instructions.
Record your product information in this table.
Product name _____________________________________________
Machine type _____________________________________________
Model number _____________________________________________
Serial number _______________ ____________________ __________
2 IBM® Netfinity® 4500R Installation Guide
Specifications and features
Specifications and features
Specifications and features
The following table provides a summary of the features and specifications for your
Netfinity 4500R server.
Microprocessor:
• Intel® Pentium® III
• 256 KB Level-2 cache
• Supports up to two
microprocessors
Memory:
• Maximum: 4 GB
• Type: ECC, SDRAM,
Registered DIMMs
• Slots: 4 non-interleaved
Drives standard:
• Diskette: 1.44 MB
• CD-ROM: 40X IDE
Expansion bays:
• Hot-swap: 3 slim high
• Non-hot-swap: Two 5.25inch
PCI expansion slots:
• Three 33 MHz/64-bit
• T wo 33 MHz/32-bit
Hot-swap power supplies:
270 Watt (115-230 Vac)
• Minimum: One
• Maximum: Two, second
power supply provides
redundant power
Redundant cooling:
Three hot-swap fans
Video:
• S3 video controller
• Compatible with SVGA
and VGA
• 8 MB video memory
Size (3U):
• Height: 13.4 mm (5.25 in.)
• Depth: 66.1 mm (26 in.)
• Width: 41.5 mm (16.3 in.)
• W ei ght: 22 .7 to 29. 5 Kg (50
to 65 lbs.) depending
upon configura t ion
Integrated functions:
• Netfinity Advanced
System Management
processor
• Dual channel Ultra3 SCSI
controller
• One 10BASE-T/100BASETX AMD Ethernet
controller
• Two serial ports
• One parallel port
• Two universal serial bus
ports
• Keyboard port
•Mouse port
• Video port
Acoustical noise emissions:
• Declared sound power,
idling (open bay): 6.3 bel
maximum
• Sound power, operating:
6.3 bel maximum
• Sound pressure,
operating: 47.5 dBa
maximum
Environment:
• Air temperature:
— Server on: 10° to 35° C
(50° to 95° F). Altitude: 0
to 914 m (2998 ft.)
— Server on: 10° to 32° C
(50° to 89.6° F). Altitude:
914 m (2998 ft.) to 2133
m (6998 ft.)
— Server off: 10° to 43° C
(50° to 109.4° F).
Maximum altitude: 213 3
m (6998 ft.)
• Humidity:
— Server on: 8% to 80%
— Server off: 8% to 80%
Heat output:
Approximate heat output in
British Thermal Units (BTU) per
hour
• Minimum configuration: 375
BTU (110 watts)
• Maximum configuration:
897.4 BTU (375 watts)
Electrical input:
• Sine-wave input (50-60 Hz)
required
• Input voltage low range:
— Minimum: 100 V ac
— Maximum: 127 V ac
• Input voltage high range:
— Minimum: 200 V ac
— Maximum: 240 V ac
• Input kilovolt-amperes
(kVA) approximately:
— Minimum: 0.08 kVA
(0.076 kW)
— Maximum: 0.28 kVA
(0.266 kW)
Table 1. Features and Specifications
Chapter 1. Introduction 3
Notices used in this book
Notices used in this book
Notices used in this book
This information product contains notices that relate to a specific topic. The Caution
and Danger notices also appear in the multilingual safety booklet that came with your
Netfinity product. Each notice is numbered for easy reference to the corresponding
notices in the safety booklet.
The notice definitions are as follows:
• Notes: These notices provide important tips, guidance, or advice.
• Attention: These notices indicate possible damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in
which damage could occur.
• Caution: These notices indicate situations that can be potentially hazardous to
you. A caution notice is placed just before descriptions of potentially hazardous
procedure steps or situations.
• Danger: These notices indicate situations that can be potentially lethal or
extremely hazardous to you. A danger no tice is placed just before descriptions of
potentially lethal or extremely hazardous procedure steps or situations.
4 IBM® Netfinity® 4500R Installation Guide
Major components
Major components of the Netfinity 4500R server
Major components
The orange color on components and labels in your server identifies hot-swap or hotplug components. This means that you can install or remove the components while
the system is running, provided that your system is configured to support this
function. For information about installing or removing a hot-swap co mponent, see
“Chapter 2. Installing Options,” on page 5.
The blue color on components and labels identifies touch points where a component
can be gripped, a latch moved, and so on.
Note: The illustrations in this document might differ slightly from your hardware.
Attention: When you handle Electrostatic Discharge-Sensitive devices (ESD), take
precautions to avoid damage from static electricity. For details on handling these
devices, refer to the following Web site and use a search term of ESD:
http://www.ibm.com/
Hot-swap fan
Air baffle
Microprocessor
Memory module
Terminator card
System board
Filler panel for
drive bay
Hot-swap hard
disk drive
Filler panel for device bay
Filler panel for
power supply bay
Hot-swap
power supply
© Copyright IBM Corp. 2000 5
Chapter 2. Installing Options
This chapter provides the basic information needed to install hardware options in
your server. This section is for all users, but is written with the experienced user in
mind. If you need more detailed installation information, refer to the User’s Reference
on the IBM Netfinity Documentation CD.
Working inside a server with power on
Your server supports hot-swap drives, fans, and power supplies and is designed to
operate safely while turned on with the cover removed. Follow these guidelines when
you work inside a server that is turned on:
• Avoid loo se-fitting clothing on your forearms. Button long-sleeved shirts before
working inside the server; do not wear cuff links while you are working inside
the server.
• Do not allow your necktie or scarf to hang inside the server.
• Remove jewelry, such as bracelets, rings, necklaces, and loose-fitting wrist
watches.
• Remove items from your shirt pocket (such as pens or pencils) that could fall
into the server as you lean over it.
• Take care to avoid dropping any metallic objects, such as paper clips, hair pins,
or screws, into the server.
Installing adapters
Installing adapters
This section describes how to install PCI adapters. Before you continue with the
adapter-installation procedure, review the following:
• Your server supports 5.0 V and universal PCI adapters; it does not support 3.3 V
adapters.
• The system scans PCI slots 1 through 5 to assign system resources; then, if you
have not changed the boot precedence from the default, the system starts (boots)
the PCI devices in the following order: PCI slots 1 and 2, system board SCSI
devices, and then PCI slots 3 through 5.
Note: You can use the Configuration/Setup Utility program to change the
boot precedence for your server. Select Start Options from the
Configuration/Setup Utility main menu.
• You ca n install a 32-bit adapter in any of th e P C I slots, but you might want to
install it in a 32-bit slot and use the 64-bit slots for 64-bit adapters.
6 IBM® Netfinity® 4500R Installation Guide
Installing adapters
The following illustration shows the location of the PCI expansion slots on the system
board.
Note: The illustrations in this document might differ slightly from your hardware.
PCI slot 5
64-bit
33 MHz (J44)
PCI slot 4
64-bit
33 MHz (J39)
PCI slot 3
64-bit
33 MHz (J34)
PCI slot 2
32-bit
33 MHz (J32)
PCI slot 1
32-bit
33 MHz (J27)
Chapter 2. Installing Options 7
Installing adapters
The following illustration shows the installation of an adapter.
To install an adapter :
Attention: When you handle Electrostatic Discharge-Sensitive devices (ESD), take
precautions to avoid damage from static electricity. For details on handling these
devices, refer to the following Web site and use a search term of ESD:
http://www.ibm.com/
1. Review the safety precautions listed in “Safety” on page v.
2. Tu rn off the server. Disconnect the signal cables; then disconnect the power cords.
3. Remove the cover.
4. Select a slot and remove the expansion-slot cover.
5. Install the adapter in the slot; then, install the retaining screw.
6. Install the cover.
7. Reconnect the cables and power cords; then, turn on the server.
Adapter
Expansion-slot cover
8 IBM® Netfinity® 4500R Installation Guide
Installing adapters
The following illustration shows the rerouting of the SCSI cable if you install an IBM
ServeRAID adapter.
1. Disconnect the cable from SCSI connector B on the system board.
2. Connect the cable to the connector on the ServeRAID adapter.
SCSI connector B (J29)
Loading...
