IBM Netfinity 3500 M20 Installation Manual
IBM
IBM® Netfinity® 3500 M20
Installation Guide
SC19-K077-90
IBM
IBM® Netfinity® 3500 M20
Installation Guide
SC19-K077-90
NOTE
Before using this information and the product it supports, be sure to read the general information in
“Appendix A. Product warranties and notices,” on page 29.
First Edition (April 2000)
© COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 2000. All rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject
to restrictions se t forth in GSA ADP Schedule Contract with IBM Corp.
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Chapter 1.Introduction . . . . . . . . . . . . . . . . 1
Features and specifications . . . . . . . . . . . . . . . . . . . . . . . . 2
Notices used in this book. . . . . . . . . . . . . . . . . . . . . . . . . . 3
Major components of the Netfinity 3500 M20 server. . . 4
Chapter 2.Installing Options. . . . . . . . . . . . 5
Removing the support bracket . . . . . . . . . . . . . . . . . . . . . 5
Working with adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adapter considerations. . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing an adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing memory modules . . . . . . . . . . . . . . . . . . . . . . . 9
Installing an internal drive. . . . . . . . . . . . . . . . . . . . . . . . 10
Installing a drive in bay A, B, C, or D. . . . . . . . . . . . 11
Installing a hard disk drive in bay E, F, or G . . . . . . 12
Installing a microprocessor . . . . . . . . . . . . . . . . . . . . . . . 13
Input/output connectors . . . . . . . . . . . . . . . . . . . . . . . . . 15
Chapter 3.Starting the server . . . . . . . . . . 17
Server controls and indicators. . . . . . . . . . . . . . . . . . . . . 18
Chapter 4. Configur in g y o ur server . . . . . 19
Using the ServerGuide CDs. . . . . . . . . . . . . . . . . . . . . . . 19
After installing the NOS . . . . . . . . . . . . . . . . . . . . . . . 20
Netfinity systems management solutions . . . . . . . . . . . 20
Chapter 5.Solving problems. . . . . . . . . . . 21
Diagnostic tools overview . . . . . . . . . . . . . . . . . . . . . . . . 21
POST beep code descriptions . . . . . . . . . . . . . . . . . . . . . 21
POST error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
ServerGuide startup problems . . . . . . . . . . . . . . . . . . . . 23
Troubleshooting chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Appendix A. Product warranties and
notices . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty Statements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
IBM Statement of Limited Warranty for United States,
Puerto Rico, and Canada (Part 1 - General Terms) . 29
IBM Statement of Warranty Worldwide except
Canada, Puerto Rico, Turkey, United States (Part 1 –
General Terms) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Part 2 - Worldwide Country-Unique Terms. . . . . . . 34
Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Edition Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Year 2000 readiness and instructions. . . . . . . . . . . . . 39
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Electronic emission notices . . . . . . . . . . . . . . . . . . . . . . . 40
Federal Communications Commission (FCC)
Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Industry Canada Class A emission compliance
statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Australia and New Zealand Class A statement. . . . 41
United Kingdom telecommunications safety
requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
European Union EMC Directive conformance
statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Taiwan electrical emission statement . . . . . . . . . . . . 42
Japanese Voluntary Control Council for Interference
(VCCI) statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Power cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
IBM Netfinity 3500 M20 Inst all at ion G uide
© Copyright IBM Corp. 2000 v
Safety
Before installing this product, read the Safety Information book .
Antes de instalar este produto, leia o Manual de Informações sobre Segurança.
Læs hæftet med sikkerhedsforskrifter, før du installerer dette produkt.
Lue Safety Information -kirjanen, ennen kuin asennat tämän tuotteen.
Avant de procéder à l'installation de ce produit, lisez le manuel Safety Information.
Vor Beginn der Installation die Broschüre mit Sicherheitshinweisen lesen.
Prima di installare questo prodotto, leggere l'opuscolo contenente le informazioni
sulla sicurezza.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Przed zainstalowaniem tego produktu należy przeczytać broszurę Informacje Dotyczące
Bezpieczeństwa.
vi IBM® Netfinity® 3500 M20 Installation Guide
Lees voordat u dit product installeert eerst het boekje met veiligheidsvoorschriften.
Les heftet om sikkerhetsinformasjon (Safety Information) før du installerer dette
produktet.
Antes de instalar este produto, leia o folheto Informações sobre Segurança.
Antes de instalar este producto, lea la Información de Seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Перед установкой продукта прочтите брошюру по технике безопасности
(Safety Information).
Pred inštaláciou tohto produktu si pre ítajte Informa nú brožúrku o bezpe nosti.
Preden namestite ta izdelek, preberite knjižico Varnostne informacije.
Installálás el tt olvassa el a Biztonsági el írások kézikönyvét !
vii
Statement 1
Danger
Electrical current from power, telephone, and communication cables is
hazardous.
To avoi d a sh ock hazard:
• Do not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical storm.
• Connect all power cords to a properly wired and grounde d ele ctr ical outlet.
• Connect to properly wired outlets any equipment that will be attached to
this product.
• When possible, use one hand only to connect or disconnect signal cables.
• Never turn on any equipment when there is evidence of fire, water, or
structural damage.
• Disconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
• Connect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached devices.
To connect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn devic e ON.
To disconnect:
1. Turn everything OFF.
2. First, remove power cords from
outlet.
3. Remove signal cables from
connectors.
4. Remove all cables from devices.
viii IBM® Netfinity® 3500 M20 Installation Guide
Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery r ecommended by the manufactur er . If your system has a
module containing a lithium battery, replace it only with the same module type
made by the same manufacturer. The battery contains lithium and can explode
if not properly used, handled, or disposed of.
Do not:
• Throw or immerse into water.
• Heat to more than 100 C (212 F)
• Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
• Do not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
• Use of controls or adjustments or per formance of procedures other than
those specified herein might result in hazardous radiation exposure.
Danger
Some laser products contain an em b edded Class 3A or Class 3B laser diode. Note
the following. Laser radiation when open. Do not stare into the beam, do not view
directly with optical instruments, and avoid direct exposure to the beam.
ix
Statement 4
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs)
CAUTION:
Use safe pr actices when lifting.
Statement 5
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. T o remove all electrical current from
the device, ensure that all power cords are disconnected from the power source.
1
2
x IBM® Netfinity® 3500 M20 Installation Guide
© Copyright IBM Corp. 2000 1
Chapter 1. Introduction
Thank you for purchasing an IBM® Netfinity® 3500 M20 server. This Installation Guide
provides the information that is needed to:
• Set up and cable your server
• Start and configure your server
• Install your network operating system (NOS)
Packaged with the Installation Guide are software CDs that help you to configure
hardware, install device drivers, and install the network operating system.
Also included is an IBM Netfinity Documentation CD, which provides detailed
information about your server.
Your server comes with a three-year limited warranty and IBM Server Start Up
Support. If you have access to the World Wide Web, you can obtain up-to-date
information about your Netfinity 3500 M20 model and other IBM server products at
the following World Wide Web address:
http://www.ibm.com/pc/us/netfinity/
The server serial number is located on labels on the rear of the server and on the front
of the server below the bezel.
Note: Your server keys cannot be duplicated by locksmiths. If you lose them, order
replacement keys from the key manufacturer. The key serial number and
phone number of the manufacturer are on a tag attached to the keys.
Record your product information in this table.
Product name ___________________________________________
Machine type ___________________________________________
Model number ___________________________________________
Serial number ___________________________________________
Key serial number ___________________________________________
Key manufacturer __________________________________ ___ ______
Key phone number ___________________________________________
2 IBM® Netfinity® 3500 M20 Installation Guide
Features and specifications
The following table provides a summary of the features and specifications for your
Netfinity 3500 M20 server.
Microprocessor:
• Intel® Pentium® III
microprocessor with
MMX™ technology and
SIMD extensions
• 256 KB Level-2 cache (min.)
• Supports up to two
microprocessors
Memory:
• Standard: 128 MB
• Maximum: 2 GB
• Type: 133 MHz, ECC,
SDRAM, Registered
DIMMs
• Slots: 4 dual inline
Drives standard:
• Diskette: 1.44 MB
• CD-ROM: 40X IDE
Expansion bays:
• Two 5.25-in. bays (1 CD
ROM drive installed)
• Two 3.5-in. bays (1 diskette
drive installed)
• Three 3.5-in. slim high bays
available
PCI expansion slots:
• Three 33 MHz/64-bit
• Two 33 MHz/32-bit
Power supply:
One 330 watt (115-230 Vac)
Video:
• S3 video controller
(integrated on system
board)
• Compatible with SVGA
and VGA
• 8 MB SDRAM video
memory
Size
• Height: 492 m m (19.4 in.)
• Depth: 460 mm (18.1 in.)
• Width: 200 mm (7.9 in.)
• Weight: approximately
20.9 Kg (46 lb.) when fully
configured or 16.8 Kg (37
lb.) minimum.
Integrated functions:
• Ultra 160 SCSI controller
• One 10BASE-T/100BASE-
TX Intel Ethernet
controller
• Two serial ports
• One parallel port
• Two Universal Serial Bus
(USB) ports
• Keyboard po r t
• Mouse port
• IDE controller port
• Video port
Acoustical noise emissions:
• Sound power, idling: 5.9
bel maximum
• Sound power, operating:
6.1 bel maximum
Environment:
• Air temperature:
— Server on: 10º to 35º C
(50.0º to 95.0º F).
Altitude: 0 to 914 m
(2998.7 ft.)
— Server on: 10º to 32º C
(50.0º to 89.6º F).
Altitude: 914 m (2998.7
ft.) to 2133 m (6998.0 ft.)
— Server off: 10º to 43º C
(50.0º to 109.4º F).
Maximum altitude: 213 3
m (6998.0 ft.)
• Humidity:
— Server on: 8% to 80%
— Server off: 8% to 80%
Heat output:
Approximate heat output in
British Thermal Units (BTU) per
hour
• Minimum configuration:
341 BTU (100 watts)
• Maximum configurati on:
1604 BTU (470 watts)
Electrical input:
• Sine-wave input (50-60 Hz)
required
• Input voltage low range:
— Minimum: 100 V ac
— Maximum: 127 V ac
• Input voltage high range:
— Minimum: 200 V ac
— Maximum: 240 V ac
• Input kilovolt-amperes
(kVA) approximately:
— Minimum: 0.08 kVA
— Maximum: 0.52 kVA
Table 1. Features and Specifications
Chapter 1. Introduct ion 3
Notices used in this book
This information product contains notices that relate to a specific topic. The Caution
and Danger notices also appear in the multilingual safety booklet that came with your
Netfinity product. Each notice is numbered for easy reference to the corresponding
notices in the safety booklet.
The notice definitions are as follows:
• Notes: These notices provide important tips, guidance, or advice.
• Attention: These notices indicate possible damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in
which damage could occur.
• Caution: These notices indicate situations that can be potentially hazardous to
you. A caution notice is placed just before descriptions of potentially hazardous
procedure steps or situations.
• Danger: These notices indicate situations that can be potentia lly lethal or
extremely hazardous to you. A danger notice is placed just before descriptions of
potentially lethal or extremely hazardous procedure steps or situations.
4 IBM® Netfinity® 3500 M20 Installation Guide
Major components of the Netfinity 3500 M20 server
The following illustration shows the locations of majo r components in your server.
Note: The illustrations in this document might differ slightly from your hardware.
Filler panel
Memory module
Drive cage
Adapter support bracket
Support bracket
Microprocessor
Terminator card
Air baffle
Hard disk drive
© Copyright IBM Corp. 2000 5
Chapter 2. Installing Options
This chapter provides the basic information needed to ins tall hardware options in
your server. This section is for all users, but is written with the experienced user in
mind. If you need more detailed installation information, refer to the User’s Reference
on the IBM Netfinity Documentat ion CD.
Removing the support bracket
When working with some options such as hard disk drives , microprocessors, and
memory modules you must first remove the support bracket to access the location for
the option.
To remove the sup port bracket:
1. Remove the screw from the bottom front corner.
2. Pull the front corner of the bracket away from the server, then lift the bracket out
of the server.
3. Store the screw and bracket in a safe place.
Netfinity 3500
M20
Support bracket
6 IBM® Netfinity® 3500 M20 Installation Guide
Working with adapters
Y ou can install up to five peripheral component interconnect (PCI) adapters in the PCI
slots on the system board.
Your server comes with an integrated video controller, which is a component on the
system board. When you install a video adapter, the server BIOS automatically
disables the integrated video controller.
The following illustration shows the location of the 33 M Hz PCI expansion slots on
the system board.
Note: The illustrations in this document might differ slightly from your hardware.
Adapter considerations
Before you install adapters, review the following:
• Locate the documentation that comes with the adapter and follow those
instructions in addition to the instructio ns given in this chapter. If you need to
change the switch or jumper settings on your adapter, follow the instructions
that come with the adapter.
• You can install full-length adapters in all expansion slots.
• You ca n install a 32-bit adapter in an y of the PCI slots, but you might want to
install it in a 32-bit slot and use the 6 4-b it slots for 64-bit adapters.
• Your server supports 5.0V and universal PCI adapters; it does not support 3.3V
adapters.
• Your server uses a rotational interrupt technique to configure PCI adapters.
Because of this technique, you can install a variety of PCI adapters that currently
do not support sharing of PCI interrupts.
PCI slot 1
32-bit
33 MHz (J29)
PCI slot 2
32-bit
33 MHz (J31)
PCI slot 3
64-bit
33 MHz (J35)
PCI slot 4
64-bit
33 MHz (J39)
PCI slot 5
64-bit
33 MHz (J40)
Loading...
