IBM Netfinity 1000 - Type 8477 Models 11Y, 21Y, 31Y, 42Y, 51Y, 52Y, 61Y & 62Y

Hardware Maintenance Manual

June 2000

We Want Your Comments! (Please see page 254)

S00N-4129-01

IBM Netfinity Servers

IBM Netfinity 1000 - Type 8477 Models 11Y, 21Y, 31Y, 42Y, 51Y, 52Y, 61Y & 62Y

Hardware Maintenance Manual

June 2000

We Want Your Comments! (Please see page 254)

S00N-4129-01

IBM

Note

Before using this information and the product it supports, be sure to read the general information under “Notices” in your manual.

Second Edition (June 2000) The following paragraph does not apply to the United

Kingdom or any country where such provisions are inconsistent with local law: INTERNATIONAL

BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time.

This publication was developed for products and services offered in the United States of America. IBM may not offer the products, services, or features discussed in this document in other countries, and the information is subject to change without notice. Consult your local IBM representative for information on the products, services, and features available in your area.

Requests for technical information about IBM products should be made to your IBM reseller or IBM marketing representative.

Note to U.S. Government users–Documentation related to Restricted rights–Use, duplication, or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

ii Netfinity Server HMM

About this manual

This manual contains diagnostic information, Symptom-to-FRU Indexes, service information, error codes, error messages, and configuration information for the Netfinity 1000 - Type 8477.

Important

This manual is intended for trained servicers who are familiar with IBM Netfinity products.

Before servicing an IBM product, be sure to review “Safety information” on page 210.

Important Safety Information

Be sure to read all caution and danger statements in this book before performing any of the instructions.

Leia todas as instruções de cuidado e perigo antes de executar qualquer operação.

Prenez connaissance de toutes les consignes de type Attention et Danger avant de procéder aux opérations décrites par les instructions.

iii

Lesen Sie alle Sicherheitshinweise, bevor Sie eine Anweisung ausführen.

Accertarsi di leggere tutti gli avvisi di attenzione e di pericolo prima di effettuare qualsiasi operazione.

Lea atentamente todas las declaraciones de precaución y peligro ante de llevar a cabo cualquier operación.

Online support

Use the World Wide Web (WWW) to download Diagnostic, BIOS Flash, and Device Driver files.

File download address is:

http://www.ibm.com/pc/us/files.html

IBM online addresses:

The HMM manuals online address is:

http://www.ibm.com/pc/us/cdt/hmm.html

The IBM Support Page is:

http://www.ibm.com/pc/support/

The IBM Personal computing solutions page.

http://www.ibm.com/pc/

iv Netfinity Server HMM

Contents

About this manual ................. iii

Important Safety Information .......... iii

Online support . . . . . . . . . . . . . . . . . iv

IBM Netfinity 1000 - Type 8477 .......... 1

General checkout . . . . . . . . . . . . . . . . . 4

Diagnostics . . . . . . . . . . . . . . . . . . . . 6

Features . . . . . . . . . . . . . . . . . . . . . 16

Additional service information ........... 18

Locations . . . . . . . . . . . . . . . . . . . . . 59

Symptom-to-FRU index . . . . . . . . . . . . . 162

Undetermined problems . . . . . . . . . . . . . 201

Parts listing (Netfinity 1000 - Type 8477) ..... 202

Related service information .......... 209

Safety information . . . . . . . . . . . . . . . . 210

Battery notice (lithium) ............. 215

Battery notice (nickel cadmium) ......... 218

Laser compliance statement ........... 252

Send us your comments! ............ 254

Problem determination tips ........... 255

Phone numbers, U.S. and Canada ........ 256

Trademarks . . . . . . . . . . . . . . . . . . 258

 Copyright IBM Corp. 1999, 2000 v

vi Netfinity Server HMM

IBM Netfinity 1000 - Type 8477

General checkout . . . . . . . . . . . . . . . . . 4

Diagnostics . . . . . . . . . . . . . . . . . . . . 6

Diagnostic test programs ............ 7

Power-on self-test (POST) ........... 8

POST beep codes ............... 9

Error messages . . . . . . . . . . . . . . . . 9

POST error messages and beep codes . . . 9

SCSI error messages ............ 9

Diagnostic error messages ......... 9

Software-generated error messages ..... 10

Installing files from option diskettes ....... 10

Running the diagnostic test programs ...... 11

Power-on self-test (POST) messages ...... 11

Viewing the test log .............. 14

SIMM/DIMM memory errors ......... 14

Features . . . . . . . . . . . . . . . . . . . . . 16

Additional service information ........... 18

Configuration overview . . . . . . . . . . . . . 19

Configuration conflicts . . . . . . . . . . . . . 21

Hardware configuration conflicts ....... 21

Software configuration conflicts ....... 22

Configuration/Setup utility program ....... 22

Configuration/Setup utility program menus .... 25

System Summary . . . . . . . . . . . . . . 26

Product Data . . . . . . . . . . . . . . . . 26

Devices and I/O Ports ........... 26

Start Options . . . . . . . . . . . . . . . . 27

Date and Time ............... 27

System Security . . . . . . . . . . . . . . 28

Setting power-on password modes .... 28

Setting and changing a power-on password 30 Using the Administrator Password menu . 32 Using the Enhanced Security features . . 33 Restricting access to IDE devices and

diskette drives . . . . . . . . . . . . . 34

Remote administration . . . . . . . . . . 35

Setting adapter ROM security ...... 36

Advanced Setup . . . . . . . . . . . . . . 36

Cache Control . . . . . . . . . . . . . . 36

ROM Shadowing . . . . . . . . . . . . 36

PCI Control . . . . . . . . . . . . . . . 36

Plug and Play Control .......... 36

Processor Control . . . . . . . . . . . . 37

ISA Legacy Resources ........... 37

Power Management . . . . . . . . . . . . 38

Using the Automatic Configuration and

Power Interface (ACPI) BIOS Mode . . . 38

Configuring the Ethernet controller ....... 39

Troubleshooting the 10/100 Mbps Ethernet

Controller . . . . . . . . . . . . . . . . . 41

Network connection problems ...... 41

 Copyright IBM Corp. 1999, 2000 1

Diagnostic LEDs . . . . . . . . . . . . 42

Erasing lost or forgotten passwords ....... 43

Power supply . . . . . . . . . . . . . . . . . 46

ROM operation mode switch setting (BIOS

recovery) . . . . . . . . . . . . . . . . . . 48

SCSISelect utility program ........... 50

Starting the SCSISelect utility program .... 50

SCSISelect utility program choices ...... 50

Configure/view host adapter settings ..... 50

SCSI disk utilities ............ 51

Performing a low-level disk format .... 52

When to use the format disk program . . . 52

Starting the low-level format ....... 52

Specifications (Ethernet cable) ......... 54

Wake on LAN feature ............ 56

Specifications (System) . . . . . . . . . . . . 57

Locations . . . . . . . . . . . . . . . . . . . . . 59

Accessing the system board .......... 60

Adapters . . . . . . . . . . . . . . . . . . . 61

Adapter considerations . . . . . . . . . . . 61

AGP adapters . . . . . . . . . . . . . . 61

ISA and PCI adapters .......... 62

Installing or removing ISA and PCI adapters . 63

Installing or removing AGP adapters ..... 66

Adding security options ............ 68

Installing a U-bolt and security cable ..... 68

Battery . . . . . . . . . . . . . . . . . . . . 70

Bottom cover . . . . . . . . . . . . . . . . . 72

Cabling . . . . . . . . . . . . . . . . . . . . 74

CD-ROM drive . . . . . . . . . . . . . . . . . 75

Handling a CD ............... 76

Loading and unloading a CD ........ 76

Completing the installation ........... 78

Controls and indicators ............. 82

Server controls . . . . . . . . . . . . . . . 82

Status indicators . . . . . . . . . . . . . . 83

Disconnecting cables and removing the side cover 85

External options . . . . . . . . . . . . . . . . 88

Adding a hot-swap storage expansion enclosure 88

External SCSI devices ............. 89

Serial port connectors ............ 90

Parallel port connector ........... 91

External view . . . . . . . . . . . . . . . . . 92

Front fan . . . . . . . . . . . . . . . . . . . 93

Input/output connectors . . . . . . . . . . . . 95

Internal drives . . . . . . . . . . . . . . . . . 98

Expansion bays . . . . . . . . . . . . . . 98

Drive specifications . . . . . . . . . . . . 100

Types of cables ............. 101

SCSI drives . . . . . . . . . . . . . . . 105

SCSI physical unit numbers ...... 105

SCSI logical unit number ........ 105

Termination requirements . . . . . . . 106

Preinstallation steps (all bays) ....... 106

2 Netfinity Server HMM

Working with drives in bays 1 through 4 . . 108

Installing drives in the front drive bay

assembly . . . . . . . . . . . . . . 109

Removing Drives from the drive bay

assembly . . . . . . . . . . . . . . 113

Installing a drive in the drive bay assembly 115

Working with drives in bays 5 and 6 .... 120

Internal view . . . . . . . . . . . . . . . . . 124

Memory modules . . . . . . . . . . . . . . 125

Memory configuration . . . . . . . . . . . 126

Installing or removing memory modules . . 127

Microprocessors . . . . . . . . . . . . . . . 129

Installing or replacing microprocessors . . . 130 Preliminary option installation information . . . 135

Stabilizing feet . . . . . . . . . . . . . . . . 137

System board . . . . . . . . . . . . . . . . 138

System board illustration ........... 141

System board replacement .......... 143

Switch settings . . . . . . . . . . . . . . . 144

Administrator password switch setting . . . 144

Diskette write-protect switch setting .... 146

Ethernet controller operation mode switch

setting . . . . . . . . . . . . . . . . . 148

Updating the server configuration ....... 149

Video port connector ............. 151

Microprocessor speed switches settings . . 152

Keyboard and mouse connectors ..... 157

SCSI connectors . . . . . . . . . . . . . 158

Internal SCSI connector ........ 158

External SCSI connector ........ 158

Universal serial bus ports ......... 160

Ethernet connector . . . . . . . . . . . . 161

Symptom-to-FRU index . . . . . . . . . . . . . 162

No beep symptoms ............. 162

Beep symptoms . . . . . . . . . . . . . . . 162

POST error codes .............. 165

Diagnostic error codes ............ 169

Ethernet controller messages ......... 191

Miscellaneous symptoms . . . . . . . . . . . 194

SCSI messages . . . . . . . . . . . . . . . 200

Undetermined problems . . . . . . . . . . . . . 201

Parts listing (Netfinity 1000 - Type 8477) ..... 202

System . . . . . . . . . . . . . . . . . . . 203

Keyboards . . . . . . . . . . . . . . . . . 206

Power cords . . . . . . . . . . . . . . . . . 208

IBM Netfinity 1000 - Type 8477 3

General checkout

This general checkout procedure is for Netfinity 1000 Type 8477 servers.

Attention

The drives in the system you are servicing might have been rearranged or the drive startup sequence changed. Be extremely careful during write operations such as copying, saving, or formatting. Data or programs can be overwritten if you select an incorrect drive.

Diagnostic error messages appear when a test program finds a problem with a hardware option. For the test programs to properly determine if a test

Aborted

, the test programs check the error-return code at

test completion. General error messages appear if a problem or conflict is

found by an application program, the operating system, or both. For an explanation of these messages, refer to the information supplied with that software package.

A failed system might be part of a shared DASD cluster (two or more systems sharing the same external storage device(s)). Prior to running diagnostics, verify that the failing system is not part of a shared DASD cluster.

A system might be part of a cluster if:

 The customer identifies the system as part of a

cluster.

 One or more external storage units are attached to

the system and at least one of the attached storage

units is additionally attached to another system or

unidentifiable source.

 One or more systems are located near the failing

system.

If the failing system is suspected to be part of a shared DASD cluster, all diagnostic tests can be run except diagnostic tests which test the storage unit (DASD residing in the storage unit) or the storage adapter attached to the storage unit.

Passed, Failed

, or

4 Netfinity Server HMM

Notes

1. For systems that are part of a shared DASD cluster, run one test at a time in looped mode. Do not run all tests in looped mode, as this could enable the DASD diagnostic tests.

2. Before replacing any FRUs, ensure the latest level of BIOS is installed on the system. A down-level BIOS might cause false errors and unnecessary replacement of the system board.

3. If multiple error codes are displayed, diagnose the first error code displayed.

4. If the server hangs with a POST error, go to “Symptom-to-FRU index” on page 162.

5. If the server hangs and no error is displayed, go to “Undetermined problems” on page 201.

6. If an installed device is not recognized by the diagnostics program, that device might be defective.

7. If blank screen, unreadable screen, or other unusual response occurs, go to “Symptom-to-FRU index” on page 162.

8. For power supply problems, see “Power supply” on page 46.

001

IS THE SYSTEM PART OF A CLUSTER? Yes No

002

Go to Step 004.

003

Schedule maintenance with the customer. Shut down all systems related to the cluster. Run storage test.

004

– Power-off the server and all external devices. – Check all cables and power cords. – Set all display controls to the middle position. – Start the diagnostic programs, if necessary see “Running

the diagnostic test programs” on page 11.

– Check for the following responses:

1. One or two beeps (depending on the diagnostics version level).

2. Readable instructions or the Main Menu.

(Step 004 continues)

IBM Netfinity 1000 - Type 8477

(CONTINUED)

004 (continued)

DID YOU RECEIVE THE CORRECT RESPONSES? Yes No

005

Go to the “Symptom-to-FRU index” on page 162.

006

ARE ALL INSTALLED DEVICES IN THE SERVER HIGHLIGHTED ON THE MODULE TEST MENU OR HARDWARE CONFIGURATION REPORT? Yes No

007

The missing device may be defective.

008

Run the Advanced Diagnostics test. If necessary, refer to “Diagnostics.”

 If you receive an error, go to “Symptom-to-FRU index”

on page 162.

 If the test stops and you cannot continue, replace the

last device tested.

Diagnostics

The following tools are available to help identify and resolve hardware-related problems:

 Diagnostic test programs  Power-on self-test (POST)  POST beep codes

 Error messages  Troubleshooting charts  Option diskettes

6 Netfinity Server HMM

Diagnostic test programs

IBM provides programs that you can run to diagnose hardware and some software problems. Several utility programs that provide helpful information about the server are also included. One of these programs provides the user interface for running these diagnostic and utility programs.

The server diagnostic test programs are stored on the

Enhanced Diagnostics CD

These programs are the primary method of testing the system board, memory, and other standard features of the Netfinity 1000 server. You can also use them to test some external devices.

Also, if you cannot determine whether a problem is caused by the hardware or by the software, you can run the test programs to confirm that the hardware is working properly.

The IBM Enhanced Diagnostics programs will isolate the server hardware from software that you have installed on the hard disk. The programs run independently of the operating system, and

diskette

. This method of testing is generally used when other methods are not accessible or have not been successful in isolating a problem suspected to be hardware related.

The server diagnostic test programs can identify most problems associated with major components of the server: the system board, Ethernet controller, video adapter or controller, random-access memory (RAM), CD-ROM, hard disk drive, diskette drive, serial port, parallel port, keyboard, and mouse.

In addition to the server test programs, the

Diagnostics CD

information about the server hardware, including the hardware configuration. This information might be useful in helping to isolate problems related to the operating system and device drivers.

IBM Enhanced Diagnostics CD

The additional diagnostic programs for non-IBM devices.

See “Running the diagnostic test programs” on page 11 for information on running the diagnostic programs that come with the server.

contains utility programs that provide

that comes with the server.

must be run either from CD or

IBM Enhanced

also contains

IBM

IBM Netfinity 1000 - Type 8477

Power-on self-test (POST)

When you power-on the server, it performs a series of tests to check the operation of server components and some options. This series of tests is called the power-on self-test, or POST.

POST does the following:

 Checks the operation of some basic system-board

operations

 Checks the memory operation  Compares the current server configuration with the

stored server configuration information

 Configures PCI adapters  Starts the video operation  Verifies that the drives (such as the diskette,

CD-ROM, and hard disk drives) are connected properly

If Power-On Self-Test is set to [Enhanced], numbers that show the amount of memory being tested appear in the top-left corner of the screen until the total amount of memory in the system is reached. Options for running a quick POST or accessing the Configuration/Setup Utility program appear in the lower-left corner of the screen. Quick mode is the default mode of operation. To change the mode to [Enhanced], select Start Options from the Configuration/Setup Utility program menu and follow the prompts on the screen.

Note

The amount of available memory shown might be somewhat less than expected because of BIOS shadowing in RAM.

If POST finishes without detecting any problems, the first screen of the operating system or application program appears (if you have not set a power-on password). If you have set a power-on password, a password prompt appears. You must enter the password before the first screen of the operating system or application program will appear. (For further information on using passwords, see “System Security” on page 28.)

If Power-On Status is set to [Enabled] and POST detects a problem, you will hear multiple beeps or no beep. In most cases, an error code appears in the top left corner of the screen, and in some cases, a description of the error is displayed beside the code. (Note that the screen will sometimes display multiple error codes and descriptions.)

8 Netfinity Server HMM

POST beep codes

If Power-On Status is set to [Enabled], POST also generates beep codes to indicate successful completion or the detection of an error.

 The startup of the operating system or application

program indicates successful completion of POST.

 More than one beep indicates that POST detected an

error.

For a list of beep codes, see “Symptom-to-FRU index” on page 162.

Error messages

Error messages indicate that a problem exists; they are not intended to be used to identify a failing part. Troubleshooting and servicing of complex problems indicated by error messages should be performed by a trained service technician.

Hardware error messages that occur can be text, numeric, or both. Messages generated by the software generally are text messages, but they also can be numeric.

POST error messages and beep codes

: POST error messages and beep codes occur during

startup when POST finds a problem with the hardware or detects a change in the hardware configuration. POST error messages are 3-, 4-, 5-, 8-, or 12-character alphanumeric messages and include brief explanations (except I999XXXX errors).

For a list of error codes, see “Symptom-to-FRU index” on page 162.

SCSI error messages

: These messages appear if a problem or conflict is

detected by the SCSI subsystem. Refer to the SCSI documentation in the ServerGuide package that comes with the server for information about these messages.

Diagnostic error messages

: Diagnostic error messages occur when a test finds a

problem with the server hardware. The messages present text information that can be used to identify a failing part. These error messages are alphanumeric. Follow the instructions on the screen.

For a list of diagnostic codes, see “Symptom-to-FRU index” on page 162.

IBM Netfinity 1000 - Type 8477 9

Software-generated error messages

: These messages occur if a problem or conflict is

found by an application program, the operating system, or both. Error messages for operating-system and other software problems are generally text messages, but they also can be numeric messages. For information about these software error messages, refer to the information that comes with the operating system or application program, or both.

Installing files from option diskettes

An optional device or adapter might come with a diskette. Diskettes that are included in option packages usually contain files that the system needs for recognizing and activating the options. Until you install the necessary files, the new device or adapter might cause error messages.

If the optional device or adapter comes with a diskette, you might need to install some configuration (.CFG) files or diagnostic files (.EXE or .COM) from the diskette to the hard disk. Refer to the documentation that comes with the option to see if you need to install files.

10 Netfinity Server HMM

Running the diagnostic test programs

Note

See “Diagnostic test programs” on page 7 for a description of the diagnostic programs that come with the server.

Attention

Do not discard the Enhanced Diagnostics CD. Store it in a safe place for later use.

To start the IBM Enhanced Diagnostics using the CD backup Diagnostic Diskette, do the following:

1. Power-off the server and any attached devices.

2. Insert the IBM Enhanced Diagnostics backup diskette into diskette drive A.

3. Power-on all attached devices; then, power-on the server.

4. Follow the instructions on the screen.

To make a backup copy of the IBM Enhanced Diagnostics information on a diskette, do the following:

1. Insert a blank, 3.5-inch, formatted 2 MB diskette into diskette drive A.

2. Boot the system with the Diagnostics CD in the CD-ROM drive.

3. Follow the instructions on the screen.

Power-on self-test (POST) messages

If you receive an error message during the power-on self-test (POST), completing the steps outlined in this section might enable you to resolve the problem.

Note.

If you have just added, removed, or changed the location of a device and you receive an error message, you must reconfigure the server. Follow the procedure described in “Configuration/Setup utility program menus” on page 25. If the procedure in “Configuration/Setup utility program menus” on page 25 does not eliminate the error message, then proceed with the following instructions.

1. Write down all error code numbers and descriptions that appear on the screen as you start the server. (Note that a single problem can cause several error messages to appear. When you correct the cause of the first error message, the other error messages probably will not appear on the screen the next time that you power-on the server.)

2. If you have set a power-on password and have the password prompt set to On or Dual, a password

IBM Netfinity 1000 - Type 8477

prompt appears. If you have set both power-on and administrator passwords, you can type either of the passwords at the password prompt. However, if you think you might need to change any settings in the Configuration/Setup Utility program, you must type the administrator password at the password prompt. If you type the power-on password, you will be able to view the error codes and error code descriptions that are displayed on the POST Startup Errors screen; you will also be able to view limited information in the Configuration/Setup Utility program. However, you will not be able to change any settings.

3. In the case of most errors, the Configuration/Setup Utility program starts automatically so that you can attempt to identify and correct the problem. When the Configuration/Setup Utility program starts, a screen titled POST Startup Errors appears. (Note that the POST Startup Errors screen does not appear immediately. You must wait approximately one minute.) If the POST Startup Errors screen does not appear, proceed to step 6 on page 13.

4. At the POST Startup Errors screen, select Continue if you want to access the Configuration/Setup Utility program menu. Select Exit Setup if you want to exit from the Configuration/Setup Utility program. (For more information on exiting from the Configuration/Setup Utility program, go to the Attention: section that follows step 5d on page 13.) To select an item, press the Up Arrow (↑) or Down Arrow (↓) key to highlight the item; then, press Enter.

5. If you selected Continue in step 4, the Configuration/Setup Utility program menu appears on the screen. You will see a pointer next to any menu items that indicate components that are malfunctioning or that have been changed since the last time you powered-on the server. If you did not knowingly make a change to a flagged component, that component is probably malfunctioning. If you made a change, continue here. If you did not make a change, go to the Attention: section that follows step 5d on page 13.

To use the Configuration/Setup Utility program, do the following:

a. Select the menu item that is flagged (or that you

want to view) by pressing the Up Arrow (↑) or Down Arrow (↓) key; then, press Enter.

b. A new menu specific to the item that you

selected appears. Press the Left Arrow (←) or Right Arrow (→) key to toggle between choices for a menu item. (Note that each menu item has a Help screen. To view the Help screen, select the menu item; then, press F1.)

12 Netfinity Server HMM

c. When you have finished viewing and changing

settings, press Esc to return to the Configuration/Setup Utility program menu.

d. Before you exit from the program, select Save

Settings. When you exit from the Configuration/Setup Utility program menu (see step 5e), the operating system will start automatically (unless there is an unresolved problem with the startup device).

Attention

If you did

not

change any settings in the Configuration/Setup Utility program, note the following:

 You will get an error message if you

exit from the Configuration/Setup Utility program without selecting Save Settings. The operating system will not start, but the server will automatically restart. When the server restarts, you will get a POST error message, and then the Configuration/Setup Utility program will again start automatically.

 You will

not

get an error message if you select Save Settings and then exit from the Configuration/Setup Utility program. The system will save all settings as they currently appear in the Configuration/Setup Utility program, and the operating system will start (unless there is an unresolved problem with the startup device).

e. To exit from the Configuration/Setup Utility

program, press Esc and follow the instructions on the screen.

6. For more information about error messages see “Symptom-to-FRU index” on page 162.

IBM Netfinity 1000 - Type 8477

Viewing the test log

Errors reported by the diagnostic test will be displayed by the program as a failed test.

To view details of a failure or to view a list of test results, do the following from any test category screen:

 Press F3 to activate the log File  Press Tab for details  Press F3 again to save the file to diskette or F2 to

print the file.

SIMM/DIMM memory errors

: SIMM/DIMM error messages issued by the IBM PC

Enhanced Diagnostics:

Message Failure Found Recommended

2xx-1y A memory error

was detected in SIMM socket Y

2xx-2y A memory error

was detected in DIMM socket Y

Corrupt BIOS Information in

BIOS is not as expected.

Not able to find expected DMI information from BIOS.

Memory controller chipset vendor ID does not match expected value.

Actions

Replace the SIMM in the socket identified by the last digit of the error code.

Re-run the test. If the same error

code occurs again, replace the system board.

Replace the DIMM in the socket identified by the last digit of the error code.

Re-run the test. If the same error

code occurs again, replace the system board or where memory is on the processor card, replace the processor card.

Reflash the BIOS.

Replace the system board.

14 Netfinity Server HMM

Message Failure Found Recommended

Test aborted by user

User stopped test.

Actions

Restart test.

IBM Netfinity 1000 - Type 8477 15

Features

The features in the server vary according to the model. The following is a summary of the features that are available with the Netfinity 1000 - Type 8477

Microprocessor

 Intel Pentium II microprocessor

with MMX technology

 66 MHz or 100 MHz Front Side Bus (FSB)  Level-1 and level-2 cache memory varies by microprocessor.

Memory

 Three 3.3 V, synchronous, 168-pin dual in-line

memory-module (DIMM) sockets

 64 MB, expandable to 768 MB  100 MHz, synchronous dynamic random-access memory

(SDRAM) with error checking and correction (ECC)

 Support for 32 MB, 64 MB, and 128 MB unbuffered DIMMs or

for 256 MB registered DIMMs

 Flash memory for system programs

Diskette Drive

 Supports one diskette drive  Standard: One 3.5-inch, 1.44 MB

Hard Disk Drives

 Number and capacities of hard disk drives vary by model  Server supports up to four internal hard disk drives

CD-ROM Drive

 Standard: IDE

Keyboard and Auxiliary Device

 Keyboard  Mouse

Expansion Slot Connectors

 Three dedicated ISA slot connectors  Three dedicated PCI slot connectors  One dedicated Accelerated Graphics Port (AGP) slot

connector

Expansion Bays

 Standard: One dedicated 5.25-inch drive bay for CD-ROM

drive

 One 3.5-inch or 5.25-inch drive bay  Four 3.5-inch drive bays  Number of bays empty and available for expansion varies by

model

Upgradable POST and BIOS

 POST/BIOS upgrades (when available) to update EEPROM

on the system board

Security Features

 Bolt-down capability  Chassis-intrusion detector

 Power-on and administrator passwords

 Security-error indicator

 Selectable drive-startup sequence  Side cover lock  Unattended start mode

16 Netfinity Server HMM

SCSI Features (if a SCSI adapter comes with your model server)

 16-bit UltraSCSI adapter

– One external connector – One internal connector

 Server supports up to four internal SCSI hard disk drives

Power Supply

 330Watts  Auto-sensing function

 Built-in overload and surge protection

Integrated Functions

 Voltage regulator for microprocessor  Two serial ports  Two universal serial bus (USB) ports  One parallel port

 Mouse port  Keyboard port

 Full-duplex 10/100 Mbps Ethernet controller

– 10BASE-T/100BASE-TX port

– Integrated Direct Memory Access (DMA) Buffer

Management Unit for low microprocessor and bus utilization

 AGP function on system board

– 4 MB synchronous graphics random-access memory

(SGRAM), 100 MHz

 Systems Management Controller (LM80)

IBM Netfinity 1000 - Type 8477 17

Additional service information

The following additional service information supports the Netfinity 1000 - Type 8477 server.

 “Configuration overview” on page 19.  “Configuration conflicts” on page 21.  “Configuration/Setup utility program” on page 22.  “Configuration/Setup utility program menus” on

page 25.

 “Configuring the Ethernet controller” on page 39.  “Erasing lost or forgotten passwords” on page 43.  “Power supply” on page 46.  “ROM operation mode switch setting (BIOS recovery)”

on page 48.

 “SCSISelect utility program” on page 50.  “Specifications (Ethernet cable)” on page 54.  “Specifications (System)” on page 57.

18 Netfinity Server HMM

Configuration overview

You play a key role in how the server allocates resources to organize and interconnect hardware devices and software programs. This allocation process is referred to as

configuration.

server depend on the number and types of devices and programs that you install.

The server has connectors for several types of adapters. Because of this flexibility, you can choose from among thousands of adapters and devices that comply with any of the following standards:

 Peripheral Component Interconnect (PCI)  Industry Standard Architecture (ISA)  Small Computer System Interface (SCSI)  Accelerated Graphics Port (AGP)

You can obtain a listing of products that are compatible with the server, and related configuration information, by accessing the following World Wide Web address:

http://www.ibm.com/pc/us/compat/

Jumpers and switches are used to define certain configuration values on the system board, adapters, and other devices. If you need to set jumpers or switches on adapters, drives, or other devices, refer to the documentation that comes with the devices for specific information about the appropriate jumper and switch settings.

In general, the greater the number and variety of hardware devices and software programs that you install in the server, the more you will have to interact with the server and the devices to correctly configure the system.

The server comes with the following hardware configuration utility programs:

 Configuration/Setup Utility program

With the Configuration/Setup Utility program, you can configure system board functions, such as serial and parallel port assignments; change interrupt request settings; and change the startup sequence for drives that you install. You can also use this utility program to set passwords for starting the server and accessing the Configuration/Setup Utility program.

 SCSISelect Utility

With the built-in SCSISelect Utility program, you can configure the SCSI devices that you install in the server. You can use SCSISelect to change default values, resolve configuration conflicts, and perform a low-level format on a SCSI hard disk drive.

Before installing a new device or program, read the documentation that comes with it. Reading the instructions

The steps required to configure the

IBM Netfinity 1000 - Type 8477

helps you to determine the steps required for installation and configuration. The following actions are typically, but not always, required to configure the server.

1. Run the Configuration/Setup Utility program and record the current configuration settings.

See “Configuration/Setup utility program” on page 22.

2. Power-off and unplug the server.

3. Set jumpers or switches on the server's system board.

4. Set jumpers or switches on the device. See the device installation instructions.

5. Install the device in the server. Reserve ISA legacy resources for ISA adapters. See

“ISA Legacy Resources” on page 37.

6. Resolve configuration conflicts. See “Configuration conflicts” on page 21.

7. Install software programs, including device drivers. Refer to the information that comes with the IBM

ServerGuide package for more information.

20 Netfinity Server HMM

Configuration conflicts

The resources used by your server consist of IRQs, DMA, I/O port addresses, and memory. This information is useful when a resource configuration conflict occurs.

Conflicts in the configuration occur if:

 A device that you installed requires the same

resource as another device. (For example, a conflict occurs when two adapters try to write to the same address space.)

 A device resource is changed (for example, changing

jumper settings).

 A device function is changed (for example, assigning

COM1

to two serial ports).

 A software program is installed that requires the same

resource as a hardware device.

The steps required to resolve a configuration error are determined by the number and variety of hardware devices and software programs that you install. If a hardware configuration error is detected, a message appears after the server completes POST and before the operating system is loaded. You can bypass the error by pressing Esc while the error message is displayed.

The Configuration/Setup Utility program configures only the system hardware and interrupt requests. The program does not consider the requirements of the operating system or the application programs. For these reasons, memory-address configuration conflicts might occur. You can resolve some memory-address conflicts by changing the address of the conflicting hardware option, or by changing or moving the hardware. You might have to resolve other memory-address conflicts by changing some software parameters. See “Hardware configuration conflicts” and “Software configuration conflicts” on page 22, respectively, for additional information.

configuration error

Hardware configuration conflicts

: Use the following information to help resolve hardware

configuration conflicts:

1. Run the Configuration/Setup Utility program to view and change the resources that the system board functions use. Record the current settings before making any changes. (See “Configuration/Setup utility program” on page 22 for instructions.)

2. Determine which adapter or device is causing the conflict.

3. Change adapter jumpers or switches. Some devices use jumpers and switches to define the system resources that they need. If the settings are incorrect or set to use a resource that cannot be shared, a

IBM Netfinity 1000 - Type 8477

conflict occurs, and the device will remain deactivated by the configuration program.

4. Change system board jumpers or switches. Then, refer to the system-board diagram inside your server.

5. Remove the device or adapter. Some configurations are not supported. If you must remove an adapter, see “Installing or removing ISA and PCI adapters” on page 63.

Software configuration conflicts

: The Configuration/Setup utility might change the

memory-address space used by some hardware options. If this happens, the new memory-address space and IRQs used by some hardware options might conflict with addresses defined for use through application programs.

If a conflict exists, one or more of the following conditions might exist:

 The system cannot load the operating system.  The system does not work.  An application program does not operate, or it returns

an error.

 Screen messages indicate that a memory-address

conflict exists.

Note

Start the Configuration/Setup Utility program to view the addresses that are used by your system board functions.

The best way to resolve memory-address conflicts is to change the addresses that are used by the application program or the device driver. You can use the Configuration/Setup Utility program to view and change addresses.

Configuration/Setup utility program

For most configurations, the server will operate using the default system settings. You need to change the settings only to resolve configuration conflicts or to enable or change device functions.

When you want or need to change the default settings, the Configuration/Setup Utility program provides a convenient way to display and change the settings.

After you run and exit the Configuration/Setup Utility program, configuration information is stored in electrically erasable programmable read-only memory (EEPROM). While the server is powered off, the configuration information remains available for the next system startup.

Always run the Configuration/Setup Utility program if you receive an error message instructing you to do so. If you installed or removed SCSI devices, run the SCSISelect

22 Netfinity Server HMM

Utility program (see “SCSISelect utility program” on page 50). Review the information that comes with the option before making changes.

When you restart the server for the first time after working with most options, a message appears, indicating that a configuration change has occurred. You are then prompted to enter the Configuration/Setup Utility program to manually update the configuration settings or to confirm and save the settings that were automatically updated by the system programs.

After you change an option and restart the server, the following screen might appear.

POST Startup Error(s)

The following error(s) were detected when the system was

started:

162 Configuration Change Has Occurred

Select one of the following:

Continue Exit Setup

Note

Depending on the configuration changes that occurred, the error message that you see might be different from the one shown here.

If the preceding screen appears, select Continue until you reach the Configuration/Setup Utility program menu; then, go to “Configuration/Setup utility program menus” on page 25.

If the preceding screen does not appear, use the following procedures to access the Configuration/Setup Utility program menu.

To start the Configuration/Setup Utility program:

1. Power-on the server and watch the screen. If the server is already turned on, power-off the

server, wait a few seconds until all in-use lights go off, and then power the server back on. (Do not use Ctrl+Alt+Del to restart the server.)

2. When the message Press F1 to enter Configuration/Setup appears, press F1. The Configuration/Setup Utility program menu appears. For information about the menus, see “Configuration/Setup utility program menus” on page 25.

IBM Netfinity 1000 - Type 8477

Notes

1. If an administrator password is

not

set, the Configuration/Setup Utility program starts once you complete the startup procedure.

2. If an administrator password is set, but a power-on password is

not

set, you must enter the administrator password to access the Configuration/Setup Utility program.

3. If you have set both an administrator and a power-on password, you can enter either one. However, to change any settings in the Configuration/Setup Utility program, you must enter the administrator password. If you enter the power-on password, you can

view

limited information in the Configuration/Setup Utility program, but you cannot

change

any settings.

4. If a configuration error occurs, a prompt appears before the operating system starts (see “Configuration conflicts” on page 21).

24 Netfinity Server HMM

Configuration/Setup utility program menus

From the Configuration/Setup Utility program Main Menu, you can select the settings that you want to change.

Configuration/Setup Utility

Select Option:

•

System Summary

•

Product Data

•

Devices and I/O Ports

•

Start Options

•

Date and Time

•

System Security

•

Advanced Setup

•

ISALegacy Resources

•

Power Management Save Settings

Restore Settings Load Default Settings

Exit Setup

<F1> Help < > < > Move <Esc> Exit <Enter> Select

↑↓

Note

The menu that you see on the server screen might look slightly different from the menu shown here, but it will operate the same way.

Pressing F1 displays Help information for a selected menu item.

In the Configuration/Setup Utility program menus, you can accept the configuration changes by viewing and saving the changes, or you can make manual changes and then save the settings.

The following is a quick reference for identifying symbols in the Configuration/Setup Utility program.

 A bullet () beside a menu item indicates that an

additional menu is available.

 Information enclosed in brackets ([ ]) can be changed.

You cannot change information that is not surrounded by [ ].

 A right arrowhead (5) beside a menu item indicates

that a configuration change occurred in that category. The 5 might also appear in subsequent menus.

 An asterisk (*) beside a menu item indicates that a

resource conflict exists.

To exit from the Configuration/Setup Utility program:

1. From the Configuration/Setup Utility program, select Exit Setup or press Esc.

2. The Exit Setup menu appears. You can save the changes, exit from the Configuration/Setup Utility program without saving the changes, or return to the

IBM Netfinity 1000 - Type 8477

Configuration/Setup Utility program menu. Use the arrow keys to select the desired option; then, press

Enter. Note

The choices on some menus might differ slightly, depending on the BIOS version that comes with the server.

Use the following commands to navigate through the screens and make selections:

Key Function

↑ ↓ Move between menu items. ← → Toggle between choices for a menu item.

Enter Select an item. Esc Exit from a menu after viewing or making changes. F1 Get help on a selected menu item.

System Summary

: Select this choice to display configuration information,

such as the type and speed of the microprocessor, and the amount of memory.

Changes that you make to configuration settings appear on this summary screen. You cannot edit the fields on this screen. If you need to change the configuration settings, you must make the changes from the applicable menu choices.

Product Data

: Select this choice to view the machine type and

model, the system serial number, the system board identifier, and the revision level, issue date, or BIOS Mode of the flash EEPROM (BIOS).

Devices and I/O Ports

: Software recognizes ports from their port assignments.

Each port must have a unique port assignment. The Configuration/Setup Utility program normally handles this, but you might have special hardware or software that requires you to change these assignments.

Select the Devices and I/O Ports choice to view or change the assignments for devices and input/output ports.

26 Netfinity Server HMM

You can add serial ports by installing a serial adapter in an expansion slot. See the documentation that comes with the serial adapter for information about port assignments.

To display or change the port assignments:

1. From the Configuration/Setup Utility program menu, select Devices and I/O Ports; then, press Enter.

2. The Devices and I/O Ports menu appears.

3. Select a device or port. If necessary, press Enter to display an additional menu.

4. Use the Left Arrow (←) or Right Arrow (→) key to advance through the settings.

Start Options

: Select this choice to view and change settings for

device startup sequence, keyboard speed, virus detection, various power-on options, and other features.

You can control the startup sequence of the devices in the server. Each time that you power-on the server, it checks the devices as it looks for the operating system. The order in which the system checks the devices is the device-startup sequence.

Note

The default startup sequence is:

1. CD-ROM drive

2. Diskette drive

3. Hard disk drive

To set the startup sequence:

1. From the Configuration/Setup Utility program menu, select Start Options; then, press Enter.

2. The Start Options menu appears.

3. Select Startup Sequence; then, press Enter.

4. Select the sequence and devices from the choices provided.

5. If Automatic Power On Startup Sequence is

Enabled

, select the sequence and devices from the

choices provided.

To set the power-on status:

1. From the Configuration/Setup Utility program menu, select Start Options; then, press Enter.

2. The Start Options menu appears.

3. Select Startup Sequence; then, press Enter.

4. Select Power-on Status.

5. Select the power-on status from the choices provided.

Date and Time

: Select this choice to set the system date and time.

The system time is in a 24-hour format: hour/minute/second. The system date is in standard

IBM Netfinity 1000 - Type 8477

format for your country or region. For example, in the United States, the format is MM/DD/YYYY (Month/Day/Year).

To set the date and time:

1. From the Configuration/Setup Utility program menu, select Date and Time; then, press Enter.

2. The Date and Time menu appears.

3. Use the Left Arrow (←) or Right Arrow (→) key to advance through each data field.

4. Type the new information; the system saves the information as you enter it.

System Security

: Several security features are available to help you

secure the server and the information that you store in it. To control access to the server, you can implement the security features, such as adding passwords, and securing IDE devices and diskette drives.

Setting power-on password modes

The power-on password can deter unauthorized access to the system. You do not need to set a power-on password, but doing so allows you to control who can use the server. When a power-on password is set, you must type the password at a prompt that appears as the server starts.

When you set the power-on password, you can choose one of three password prompt modes.

In password prompt On mode, you are prompted for the power-on password when you power-on the server. Until you enter the correct password, the operating system will not start, and the keyboard will remain locked. If you have a mouse connected to the mouse port, the mouse also will remain locked until you enter the power-on password. If you have a mouse connected to a serial port, it will be activated when the server is started, regardless of whether a password is set.

Note

If Remote Administration is enabled, you cannot select On. In this case, select Dual.If the power-on password mode is set to On when Remote Administration is enabled, it resets automatically to Dual.

Off

In password prompt Off mode (sometimes referred to as unattended start mode), you are not prompted to enter the power-on password when you power-on the server. The server will start the operating system.

28 Netfinity Server HMM

However, if you have a mouse connected to the mouse port, refer to the following text box.

Important Information for Mouse Users

This information applies only to those who have a mouse connected to the mouse port; a serial mouse is not affected by the password prompt Off mode.

The password prompt Off mode prevents the server from detecting that a mouse is attached. Because, in this mode, the mouse device driver will not be loaded automatically through the CONFIG.SYS or AUTOEXEC.BAT files, an error message will appear to indicate that the mouse port is disabled, and the server will halt. To enable the operating system to load without displaying the error message, follow the instructions that apply to the operating system.



If you are using OS/2

, do one of the following

before enabling password prompt Off mode:

 Set the CONFIG.SYS file so that the

operating system does not stop on a device-driver error. To do this, put the command PAUSEONERROR=NO near the top of the CONFIG.SYS file.

 Remove the mouse driver statement from

the CONFIG.SYS file.

If you are using Windows NT or Windows 95, do the following:

 When the server is started and the mouse

port disabled error message appears, type either the power-on or administrator password to enable the keyboard. Then use the keyboard to put a check mark in the Do

not display this message in the future

check box.

Once the operating system starts in password prompt Off mode, the keyboard will remain locked. If you have a mouse connected to the mouse port, it also will remain locked.

Although you are not prompted to type a password in this mode, you can type either the power-on or administrator password anytime after POST has completed, even after the operating system has loaded. If you type a password, the keyboard will unlock, but the mouse connected to the mouse port will remain disabled.

Password prompt Off mode is useful for network servers and other servers that operate unattended. If a power failure occurs, the server will automatically

IBM Netfinity 1000 - Type 8477

restart and resume operating in this mode when power is restored, without operator intervention.

If you enter a password, the keyboard will unlock, but the mouse connected to the mouse port will remain disabled.

Password prompt Off mode is useful for network environments that cause the server to operate unattended. If a power failure occurs, when power is restored, the server will automatically restart and resume operating in this mode, without operator intervention.

Dual

In the password prompt Dual mode, the startup behavior of the server depends on whether the server is started from the server power switch or by an unattended method, such as a modem or timer.

If you press the power switch to start the server, the server operates the same as it does in password prompt On mode.

If you start the server by an unattended method, such as remotely over a LAN, the server operates in password prompt Off mode.

If both a power-on and administrator password are set, you can type either password at the password prompt

appears as you start the server

change any settings in the Configuration/Setup Utility program, you must type the administrator password at the password prompt

that appears when you try to access the

Configuration/Setup Utility program

power-on password at this prompt, you will be able to view limited information in the Configuration/Setup Utility program, but you will not be able to change any settings.

The password does not appear on the screen as you type it. If you type the wrong password, you receive a screen message telling you so. If you type the wrong password three times, you must power the server off and start again. When you type the correct password, the keyboard and mouse will unlock, and the server will begin normal operation.

. However, if you want to

. If you type the

that

Setting and changing a power-on password

Use the Configuration/Setup Utility program to set or change a power-on password.

30 Netfinity Server HMM

Attention

Keep a record of the power-on password in a secure

place. When a power-on password has been set, you

cannot activate the keyboard and mouse without first

using the password. If you lose or forget the

password, you cannot change or delete it without

removing the server cover and moving a jumper on

the system board. See “Erasing lost or forgotten

passwords” on page 43 for further information.

To set or change a power-on password:

1. From the Configuration/Setup Utility program menu, select System Security; then, press Enter.

2. The System Security menu appears.

3. Select Power-On Password; then, press Enter.

4. The Power-On Password menu appears.

5. To set a power-on password, enter the password in the appropriate data field and press the Down Arrow (↓) key.

You can use any combination of up to seven characters (A–Z, a–z, and 0–9) for this password. Keep a record of the password in a safe place.

6. Enter the password again in the appropriate data field.

7. In the Password Prompt data field, select Off, On, or Dual. Press the Left Arrow (←) or Right Arrow (→) key to toggle among selections.

Note

If Remote Administration is enabled, you cannot select On. In this case, select Dual.If the power-on password mode is set to On when Remote Administration is enabled, it resets automatically to Dual.

8. To change a power-on password, select Change Power-On Password from the Power-On Password menu, and follow the instructions on the screen.

Notes

1. If a power-on password is set and then forgotten, you must remove the server cover and move the

Clear CMOS Request

jumper on the system board. (See “Erasing lost or forgotten passwords” on page 43 for further information.)

2. If a power-on password is set and the password prompt is set to Off, the pointing device (mouse) is disabled until you enter the power-on password.

To delete a power-on password:

IBM Netfinity 1000 - Type 8477

1. From the Configuration/Setup Utility program menu, select System Security; then, press Enter.

2. The System Security menu appears.

3. Select Power-On Password; then, press Enter.

4. The Power-On Password menu appears.

5. Select Delete Power-On Password and follow the instructions on the screen.

Using the Administrator Password menu

The administrator password (sometimes called a supervisor-level password) controls access to some features of the server, including the Configuration/Setup Utility program.

To set or change an administrator password:

1. From the Configuration/Setup Utility program menu, select System Security; then, press Enter.

2. The System Security menu appears.

3. Select Administrator Password; then, press Enter.

4. The Administrator Password menu appears.

5. To set an administrator password, enter the password in the appropriate data field and press the Down Arrow (↓) key.

You can use any combination of up to seven characters (A–Z, a–z, and 0–9) for this password. Keep a record of the password in a safe place.

6. Enter the password again in the appropriate data field.

7. Define the Power-On Password Changeable by

User field. The choices are: Yes The power-on password can be changed

without entering the administrator password, if the administrator password is set.

No The power-on password cannot be changed

unless the administrator password is entered, if the administrator password is set.

8. To change an administrator password, select Change Administrator Password from the Administrator Password menu, and follow the instructions on the screen.

Attention Administrator Password Users:

If an administrator password is set and then forgotten,

one

you must complete access to the Configuration/Setup Utility program:

 If enhanced security is disabled (default setting),

you must remove the server cover and move the

Clear CMOS Request

board. (See “Erasing lost or forgotten passwords” on page 43 for further information.)

 If enhanced security is enabled, you must replace

the system board.

of the following to regain

jumper on the system

32 Netfinity Server HMM

To delete an administrator password:

1. From the Configuration/Setup Utility program menu, select System Security; then, press Enter.

2. The System Security menu appears.

3. Select Administrator Password; then, press Enter.

4. The Administrator Password menu appears.

5. Select Administrator Password.

6. Select Delete Administrator Password and follow the instructions on the screen.

If both a power-on and administrator password are set, you can enter either password to complete the system startup. However, the administrator password provides access to all menu choices, and provides the ability to change information. If you enter the power-on password, you can view limited information in the Configuration/Setup Utility program, but you cannot change any settings.

Using the Enhanced Security features

With enhanced security, the administrator password and drive-startup sequence are stored in a highly protected, nonvolatile, security EEPROM module. When the administrator password and drive-startup sequence are stored in the security EEPROM, they remain intact even if the battery expires or is removed.

Attention Administrator Password Users:

If enhanced security is enabled, and you forget or lose the administrator password, you must replace the system board in the server to regain access to the Configuration/Setup Utility program.

If enhanced security is enabled and you have set an administrator password, the server will operate as follows:

 The security EEPROM is protected from unauthorized

access once the startup procedures are complete. With enhanced security disabled, the contents of the

EEPROM are write protected, and the server can function in a network environment because the POST/BIOS utility program will allow updates to the system programs.

With enhanced security enabled, the POST/BIOS utility program will not allow updates to the system programs. In a network environment, this might prevent certain functions from being performed remotely.

 If the cover of the server has been removed, a

tamper-detection feature will halt system processing and deny access to the keyboard and mouse until the administrator password is entered. This feature will work if the server is powered on or off.

To enable or disable enhanced security:

IBM Netfinity 1000 - Type 8477

Note

Enhanced security can be enabled or disabled only when you update the system programs in the server.

1. Insert the POST/BIOS update diskette in the server. System programs updates are available on the World Wide Web. To obtain up-to-date information about the server model, access the home page for the server at the following address:

http://www.ibm.com/netfinity/

2. Power-on the server. If it is already powered on, you must power it off and back on again.

3. The update begins, and the system prompts you for the administrator password, if you have set an administrator password.

4. When you enter the administrator password, the update diskette will continue to run, and you are given the option of enabling or disabling enhanced security.

To set, change, or delete an administrator password protected by enhanced security:

1. Power-off all attached devices and the server.

2. Disconnect all cables, and remove the server cover.

3. Locate the switch marked as 7 on the rocker switches section of the system board. See “Administrator password switch setting” on page 144 for the location of the switch. Move the switch to the ON position. (It might be helpful to use the end of a small screwdriver to set the switch.)

Note

You must know the administrator password to change or delete it.

4. Set, change, or delete the password. Follow the instructions on the screen. (See “Using the Administrator Password menu” on page 32.)

5. Move the switch back to the OFF position after you have set, changed, or deleted the password.

6. Replace the cover. Then, power-on the server.

Restricting access to IDE devices and diskette drives

The setting for the Secure IDE and Diskette Drives option controls who has access to the IDE devices and diskette drives (user and administrator, or administrator only). The server comes with this feature set to Enable, so that both the user and administrator have access to the IDE devices and diskette drives.

To disable access to the IDE devices and diskette drives:

34 Netfinity Server HMM

1. From the Configuration/Setup Utility program menu, select System Security; then, press Enter.

2. The System Security menu appears.

3. Select Secure IDE Devices and Diskette Drives; then, press Enter.

4. Select a device; then, press the Left Arrow (←) or Right Arrow (→) key to toggle the entry to Disable.

Note

The server supports IDE CD-ROM drives. IDE hard disk drives are not supported.

Remote administration

Using this option, the BIOS can be updated remotely from a network server. If an administrator password is set, it does

not

have to be entered from the server to access this function. Consult the network administrator for information on setting up the network server to perform POST and BIOS updates.

To access the Remote Administration setting:

1. From the Configuration/Setup Utility program menu, select System Security; then, press Enter.

2. The System Security menu appears.

3. Select Remote Administration; then, press Enter.

4. To enable update POST/BIOS over the network, select Enabled (default setting). To disable, select Disabled.

You might need to perform a POST/BIOS (flash) update under the following circumstances:

 When you receive a system message instructing you

to do so

 When you install a new microprocessor (see

“Microprocessors” on page 129)

 When you receive an error code (see

“Symptom-to-FRU index” on page 162)

 When you change certain configuration switch

settings (see “Microprocessor speed switches settings” on page 152 and “ROM operation mode switch setting (BIOS recovery)” on page 48)

Before you can perform a POST/BIOS (flash) update, you must create a

1. Insert a blank, 3.5-inch, formatted 2 MB diskette into diskette drive A.

2. Go to http://www.ibm.com/pc/support/ on the World Wide Web and download the appropriate flash update program. Review the applicable README files, and use this information to copy the Flash Utility program onto the diskette.

3. If applicable, follow any additional instructions on the screen.

Flash Utility Diskette

, as follows:

IBM Netfinity 1000 - Type 8477

Note

The server is shipped with the Remote Administration feature set to Enabled. To ensure

that the POST/BIOS update (flash) procedure works properly, do not change this default value.

To perform a POST/BIOS (flash) update, insert the

Utility Diskette

Flash Utility program. Follow the instructions in the program.

into the primary diskette drive and run the

Flash

Setting adapter ROM security

Use this setting to lock the keyboard during adapter read-only memory (ROM) initialization; this feature can be used in conjunction with an administrator password to prevent the use of adapter ROM-based utility programs.

Advanced Setup

: Select Advanced Setup to change values for

advanced hardware features, such as cache control, ROM shadowing, PCI control, Plug and Play control, and microprocessor control.

Attention

The system might not operate properly if these options are configured incorrectly. Follow the instructions on the screen carefully.

Use the Left Arrow (←) or Right Arrow (→) key to select a menu choice.

Cache Control

Select this choice to define the microprocessor cache state as enabled or disabled.

ROM Shadowing

Select this choice to enable or disable ROM shadowing in specified areas. When these areas are enabled, the contents can be cached, using the Cache Control option. These areas are hexadecimal address ranges. One of these areas is reserved for the system BIOS address space.

PCI Control

Select this choice to control features associated with PCI devices, such as PCI Adapter Reset, PCI Parity, PCI Bus Master, Multimedia Devices, and various types of adapters.

Plug and Play Control

Select this choice to control features associated with Plug and Play devices, such as Set Device Node,

Address Decode, and Plug and Play Operating System.

36 Netfinity Server HMM

Select Set Device Node to control the device node. When you change this value to Disabled, the system cannot update the configuration during POST.

Processor Control

Select this choice to control features associated with

the microprocessors, such as Processor 0 ID and

Processor Updating.

ISA Legacy Resources

Plug and Play

expanding the server easier. Support for Plug and Play is built into the system board of the server.

If an adapter is Plug and Play, there are no switches or jumpers that must be set on the adapter. A Plug and Play adapter comes with configuration specifications set in memory to provide installation information to the server during startup. When you install or remove Plug and Play adapters, this information is interpreted by the BIOS, which supports Plug and Play technology. If the required resources are available, the BIOS software automatically configures the adapter around the resources already in use by other devices.

Most adapters designed for PCI slots are Plug and Play devices that are auto-configuring. However, many ISA adapters are not Plug and Play devices. These adapters are known as adapter, you must manually configure it by setting switches or jumpers on the adapter, and by allocating or reserving the system resources that the adapter will use.

Note

See “Configuration conflicts” on page 21 for

information about handling resource conflicts.

is a configuration method that makes

legacy

adapters. If you install a legacy

Select ISA Legacy Resources to identify the available system resources:

 Memory  I/O ports  DMA  Interrupt

Note

The menus do not contain resources that are used by

the system or by previously installed Plug and Play

adapters.

To store the legacy resource information for an installed adapter:

IBM Netfinity 1000 - Type 8477

1. Select ISA Legacy Resources; then, use the Up Arrow (↑) or Down Arrow (↓) key to highlight the system resource that you want to change.

2. Select a resource; then, use the Left Arrow (←) or Right Arrow (→) key to select a configuration choice.

If you remove an ISA legacy adapter, you must redefine the system resource as [Available].

Power Management

: With Power Management, the server and monitor can

be set to use a reduced-power state if they are inactive for a specified length of time. You can also specify options to automatically start the server.

Attention

The ACPI BIOS Mode feature is the only available Power Management feature.

The APM BIOS Mode feature is set to Disabled. Do not change this default value.

Using the Automatic Configuration and Power Interface (ACPI) BIOS Mode

When the automatic configuration and power interface (ACPI) BIOS mode is enabled, the operating system controls the power management features of your server and the settings for APM BIOS mode are ignored. Refer to your operating-system documentation to determine if your operating system supports ACPI. If your operating system does not support ACPI, you cannot use the ACPI

BIOS Mode Power Management feature. To set ACPI BIOS mode:

1. Select Power Management from the Configuration/Setup Utility program menu.

2. Set ACPI BIOS Mode to Enabled or Disabled as desired using the Left Arrow (←) or Right Arrow (→) key.

38 Netfinity Server HMM

Configuring the Ethernet controller

The Netfinity 1000 server comes with an Ethernet controller on the system board. The Ethernet controller provides 10BASE-T and 100BASE-TX support through the RJ-45 connector on the back of your server. When you connect your server to the network, the Ethernet controller automatically detects the data-transfer rate (10 Mbps or 100 Mbps) on the network and then sets the controller to operate at the appropriate rate. That is, the Ethernet controller will adjust to the network data rate, whether the data rate is standard Ethernet (10BASE-T), Fast Ethernet (100BASE-TX), half duplex (HDX), or full duplex (FDX). This process is also known as auto-negotiation. This auto-negotiation occurs without requiring software intervention. The controller supports half-duplex (HDX) and full-duplex (FDX) modes at both speeds.

However, auto-negotiation works only if the hub or switch to which your server is connected also supports auto-negotiation. If the hub or switch does not support auto-negotiation, the speed (10 Mbps or 100 Mbps) will still be detected correctly, but half-duplex mode will always be selected. A full-duplex switch that does not support auto-negotiation will not attach to the Netfinity 1000 server in full-duplex mode. In this case, if you want the network to operate in full-duplex mode, you must manually override the settings to obtain a full-duplex connection. To do this, your server must have a device driver that supports manual overrides. Use ServerGuide to install this device driver. Refer to your ServerGuide package for instructions on installing device drivers. ServerGuide includes IBM Update Connector, which keeps your BIOS and device drivers current. Verify that you have installed the appropriate device driver. Also, refer to your Ethernet documentation for additional information on operating modes, manual overrides, and device drivers.

Attention

 The 10BASE-T Ethernet and the 100BASE-TX

Fast Ethernet cabling in the network must be Category 5 to meet various standards, including electromagnetic compatibility.

 You must install a device driver to enable your

operating system to address the Ethernet controller. Use ServerGuide to install this device driver. Refer to the ServerGuide package for instructions on installing device drivers.

Fast Ethernet operates at a data rate of up to 100 Mbps. However, except for the different operating speeds, Fast Ethernet and standard Ethernet are structurally identical. Most applications and protocols that are currently installed on a standard Ethernet system can be seamlessly migrated to a Fast Ethernet system. Because of the

IBM Netfinity 1000 - Type 8477

equivalence of the two types of Ethernet, mixed Ethernet and Fast Ethernet systems also can be designed and implemented.

The bandwidth required at each workstation connected to a server is generally far less than the bandwidth required at the server. This is because the server might have to handle the bandwidth of multiple workstations at the same time. A cost-effective solution to the bandwidth requirements of this type of system is a mixed Ethernet and Fast Ethernet network. This mixed network consists of standard Ethernet connections at the workstations and Fast Ethernet connections at the servers.

The Ethernet controller is a PCI device, and is therefore, a Plug and Play device. You do not have to set any jumpers or configure the controller for your operating system before you use the Ethernet controller.

Notes

1. For information on Ethernet indicators, see “Controls and indicators” on page 82.

2. For information on the Ethernet connector, see “Input/output connectors” on page 95 and “Ethernet connector” on page 161.

3. For troubleshooting information, see “Troubleshooting the 10/100 Mbps Ethernet Controller” on page 41.

4. The Ethernet controller supports the operating systems that your server supports. To find out which operating systems your server supports, go to the following World Wide Web address:

http://www.ibm.com/netfinity/

If you need additional Ethernet connections, you can install an Ethernet adapter, such as an IBM 10/100 Ethernet adapter. Review your network-adapter documentation for any additional configuration requirements.

Note

If you are installing an IBM 10/100 Ethernet adapter, be sure to run the Ethernet controller diagnostics and record the server's Ethernet controller configuration information before you install the adapter.

40 Netfinity Server HMM

Troubleshooting the 10/100 Mbps Ethernet Controller: Use the following information to help

isolate problems that might occur with the 10/100 Mbps Ethernet controller.

Note

For additional information about the Ethernet controller, such as configuration and auto-negotiation, see “Configuring the Ethernet controller” on page 39. For an illustration of the Ethernet activity light location on the server, see “Status indicators” on page 83.

Network connection problems:

controller cannot connect to the network, check the following:

1. Make sure that the cable is installed correctly. The network cable must be securely attached at all

connections. If the cable is attached but the problem persists, try a different cable.

If you use the integrated Ethernet controller, you must use Category 5 cabling. See “Specifications (Ethernet cable)” on page 54 for additional information about Ethernet cable requirements.

If you directly connect two workstations (without a hub), or if you are not using a hub with X ports, use a crossover cable. See “Specifications (Ethernet cable)” on page 54 for an illustration of a crossover cable.

Note

To determine whether a hub has an X port, check the port label. If the label contains an the hub has an X port.

2. Check the Ethernet activity light on the front of the server.

The Ethernet activity light comes on when the Ethernet controller sends or receives data over the Ethernet network.

Note

This light is off when you run the diagnostic programs in the Configuration/Setup Utility program.

If the Ethernet

IBM Netfinity 1000 - Type 8477 41

If the Ethernet activity light is off:

a. Make sure that the hub and network are

operating, and that the correct device drivers are loaded.

b. There might be a defective Ethernet connector or

cable, or a problem with the hub.

3. Make sure that you are using the correct device drivers that come with your server.

4. Check for operating system-specific causes for the problem.

5. Test the Ethernet controller or adapter. How you test the Ethernet controller or adapter

depends on which operating system you are using. Refer to your ServerGuide documentation for details about your operating system.

Diagnostic LEDs:

LEDs (one green, and one amber) on the Ethernet connector that is located at the rear of the server.

 When the green LED is on, it indicates that the

Ethernet controller or adapter is connected to a hub or switch and is receiving link pulses. If this LED is not on, check all connections at the controller or adapter and the hub. Make sure that the hub is transmitting at the correct speed, and that the drivers are loaded.

Also, make sure that you have the correct wiring configuration for the controller or adapter to the hub connection. Some hubs require a crossover cable rather than a straight-through cable.

Notes

1. This LED is also known as the Link OK light.

2. The green LED is on when you run the diagnostics loopback test without a cable attached to the controller or adapter.

 When the amber LED is on, it indicates that the

Ethernet network is operating at 100 Mbps. When this LED is off, it indicates that the Ethernet network is operating at 10 Mbps.

Note

The amber LED might remain lit if the link is broken during activity.

The server contains two diagnostic

42 Netfinity Server HMM

Erasing lost or forgotten passwords

Note

To set, change, or delete a password, see “System Security” on page 28.

The server uses

semiconductor (CMOS)

storing configuration and setup information. CMOS memory maintains information about:

 Date and time  Security features  Power-management devices  Storage devices

 Keyboard and mouse

 ISA legacy configuration information

 Plug and Play configuration information  Port assignments

 I/O addresses and interrupts

 Other selectable features

Within the security features are the settings for the power-on and administrator passwords. If you need to

erase

a lost or forgotten administrator password, you must erase all configuration and setup information by moving the jumper designated for CMOS memory. This jumper is known as the

Attention Administrator Password Users:

1. If enhanced security is enabled, and you forget or lose the administrator password, you must replace the system board in your server to regain access to the Configuration/Setup Utility program. For more information, see “Using the Enhanced Security features” on page 33.

2. Clearing CMOS memory erases the configuration of your server. Therefore, you must reconfigure the server after clearing CMOS memory. If possible, record your server configuration information Request jumper.

complementary metal-oxide

memory on the system board for

Clear CMOS Request

before

moving the Clear CMOS

jumper.

The jumper is located on the system board with the label

Clear CMOS Request

board illustration” on page 141, or refer to the label inside the server.

IBM Netfinity 1000 - Type 8477

. To locate this jumper, see “System

Notes

 Using the Configuration/Setup Utility program,

record all configuration information.

 Read “Safety information” on page 210,  Power-off the server, but do not disconnect the

cables.

 Remove the server cover.  Place the server on its side.

1. Locate the

Clear CMOS Request

jumper (J9) on the system board (see “System board illustration” on page 141).

You might have to remove adapters to gain access to the jumper. See “Installing or removing ISA and PCI adapters” on page 63.

2. Move the jumper from its normal position (pins 1 and

2) to pins 2 and 3. It might be helpful to use needlenose pliers to move the jumper, but be careful not to scrape any system board components or to crush the jumper.

3. Power-on the server back on for approximately 10 seconds.

4. Power-off the server.

5. Power-on the server back on.

6. CMOS memory is now cleared and the passwords have been erased. After the POST completes, configuration error messages are displayed.

Note

You might not be able to power-off the power using the power switch until POST is nearly complete. Unplug the power cord to power-off the server.

7. Follow the instructions on the screen to continue.

8. When the Configuration/Setup Utility program starts, make the necessary changes, save the settings, and exit setup. You must update the server configuration. When you see a message that instructs you to move the jumper to the normal position, power-off the server.

44 Netfinity Server HMM

9. Disconnect the power cord from the rear of the chassis.

10. Remove the server cover, and move the jumper back to its normal position (pins 1 and 2).

11. After clearing CMOS memory, you must reconfigure the server. After reassembling the server (see “Completing the installation” on page 78), use the Configuration/Setup Utility program to reset the date and time, reset any passwords, and reconfigure the server. For more information, see “Configuration/Setup utility program menus” on page 25.

IBM Netfinity 1000 - Type 8477

Power supply

Note

The Front Fan and Disk Fan A are controlled by the System Management Controller (LM80) but the power supply fan is not.

If the power-on indicator is not on, the power-supply fan is not running, or the computer will not power-off, do the following.

Check/Verify FRU/Action

1. Check the following for proper installation.  Power Cord  On/Off Switch

connector

 On/Off Switch

Power Supply connector

 System Board

Power Supply connectors

 microprocessor(s)

connection

2. Check the power cord for proper continuity.

3. Check the power-on switch for continuity.

Reseat

Power Cord

Power-on Switch

If the above are correct, check the following voltages.

Attention

These voltages must be checked with the power supply cables connected to the system board or riser card.

Pin Signal Function

1 3.3 V +3.3 V dc 2 3.3 V +3.3 V dc 3 COM Ground 4 5 V +5 V dc 5 COM Ground 6 5 V +5 V dc 7 COM Ground 8 POK Power Good

46 Netfinity Server HMM

Pin Signal Function

9 5VSB Standby Voltage 10 12 V +12 V dc 11 3.3 V +3.3 V dc 12 -12 V -12 V dc 13 COM Ground 14 PS-ON DC Remote Enable 15 COM Ground 16 COM Ground 17 COM Ground 18 -5 V -5 V dc 19 5 V +5 V dc 20 5 V +5 V dc

IBM Netfinity 1000 - Type 8477 47

ROM operation mode switch setting (BIOS recovery)

If the power to your server is interrupted while POST/BIOS is being updated, your server might not restart correctly. If this happens, perform the following procedure to recover.

Notes

 Read “Safety information” on page 210.  Power-off the server and all other connected

devices.

 Disconnect all external cables attached to the

server; then, remove the server cover.

 Create a

administration” on page 35.

Note

If you have not already done so, go to http://www.ibm.com/pc/support/ on the World Wide Web and download the appropriate flash update program. Review the applicable README files, and use this information to create a Perform the POST/BIOS (flash) update procedure (see “Remote administration” on page 35 for additional information).

Flash Utility Diskette

; see “Remote

1. Locate the configuration switches (also known as rocker switches) on the system board. For more information, refer to the label inside the server, or see “System board illustration” on page 141.

2. To set the ROM operation mode to the appropriate value, set switch 5 as shown in the following illustration. It might be helpful to use the end of a small screwdriver to set the switch.

Attention

The following illustration is for reference only. Before you change the settings for switch 5, be sure that you check the orientation of your server system board to correctly identify the switch number locations. If you change the settings for the wrong switches, you might seriously damage server components or options.

Normal ROM Operation ROM Recovery Mode

12345678 12345678

ON ON

OFF OFF

3. Move switch 5 to the ON position.

4. Insert the

Flash Utility Diskette

(POST/BIOS update)

into drive A.

48 Netfinity Server HMM

5. Power-on the server.

6. After the update session completes, power-off the server and remove the diskette from drive A.

7. Move switch 5 back to the OFF position.

8. Reinstall the cover and reconnect any cables that you disconnected.

9. Power-on the server to restart the operating system.

10. After changing configuration switch settings, you must reconfigure the server. After reassembling the server (see “Completing the installation” on page 78), use the Configuration/Setup Utility program to reconfigure the server. For more information, see “Configuration/Setup utility program menus” on page 25.

IBM Netfinity 1000 - Type 8477 49

SCSISelect utility program

Your server comes with a menu-driven configuration utility program, called SCSISelect, that allows you to view and change SCSI settings.

You can use the SCSISelect Utility program to:

 View and change the default SCSI identification (IDs)  Verify and change configuration conflicts  Perform a low-level format on a SCSI hard disk.

Starting the SCSISelect utility program

: You can access this program when you start the

server. The SCSISelect prompt appears after the IBM Netfinity 1000 server logo appears. Press Ctrl+A immediately after the SCSISelect prompt appears:

<<< Press <CTRL><A> for SCSISelect Utility! >>> Use the Up Arrow (↑) or Down Arrow (↓) key to move the

highlight bar to the various menu choices. Press Esc to return to the previous menu. Also, you can press the F5 key to switch between color and monochrome modes (if your monitor permits). To change the settings of the displayed items, such as Channel A or Channel B, follow the directions on the screen. Then, press Enter.

SCSISelect utility program choices

: The following choices appear on the SCSISelect Utility

program menu:

 Configure/View Host Adapter Settings  SCSI Disk Utilities

Configure/view host adapter settings

: To view or change the SCSI controller settings, select

Configure/View Host Adapter Settings and follow the

directions on the screen.

Note

On this menu, the SCSI controller is referred to as the Host Adapter.

This menu has the following choices:

 Host Adapter SCSI ID

The default SCSI ID of the SCSI controller is not change this value!

 SCSI Parity Checking

The default value is value!

 Host Adapter SCSI Termination

The default value is value!

 Boot Device Options

Enabled.

Automatic.

Do not change this

50 Netfinity Server HMM

Select this choice to configure startable device parameters. Before you can make updates, you must know the ID of the device whose parameters you want to configure.

The default startup (boot) SCSI ID is 0 for an internal SCSI hard disk drive in Channel A.

 SCSI Device Configuration

Select this choice to configure SCSI device parameters. Before you can make updates, you must know the ID of the device whose parameters you want to configure.

Notes

1. For SCSI tape drives, set Send Start Unit Command to Off for that SCSI ID. This

ensures proper server operation.

2. When the Maximum Sync Transfer Rate is set to 40.0, this value represents the transfer rate for UltraSCSI devices. When this value is set to 20.0, it represents the transfer rate for Fast SCSI devices.

 Advanced Configuration Options

Select this choice to view or change the settings for advanced configuration options. These options include enabling support for large hard disk drives and support for drives with UltraSCSI speed.

To reset the SCSI controller defaults, press F6; then, follow the instructions on the screen.

SCSI disk utilities

To see the IDs that are assigned to each SCSI device or to format a SCSI device, select SCSI Disk Utilities from the SCSISelect Utility program menu.

To use the utility program, select a drive from the list. Read the screens carefully before you make a selection.

Note

If the following screen appears, you might have pressed Ctrl+A before the selected drives were ready. Restart the server, and watch the SCSISelect messages as each drive spins up. After the drive that you want to view or format spins up, press Ctrl+A.

IBM Netfinity 1000 - Type 8477 51

à ð

Target SCSI ID: 4

SCSI CDB Sent: ð3 ðð ðð ðð ðE ðð ð7 ðð ð2 ðð

Host Adapter Status: ððh - No host adapter error

Target Status: ð2h - Check condition

Sense Key: ð2h - Not ready

+Sense Code: ð4h

+Sense Code Qualifier: ð2h

Unexpected SCSI Command Failure

Press 'Esc' to continue.

Performing a low-level disk format

You can use the

Format Disk

feature of the SCSISelect Utility program to perform a low-level format on hard disks.

Depending on the hard disk capacity, the low-level format program could take up to two hours.

When to use the format disk program

Use the Format Disk program:

 When you are installing software that requires a

low-level format

 When you get recurring messages from the diagnostic

tests directing you to run the Low-Level Format program on the hard disk

 As a last resort before replacing a failing hard disk

drive

Note

For information about backing up all of your files, see your operating-system documentation.

Starting the low-level format

Attention

all

The low-level format erases

data and programs.

1. If the hard disk drive is working, make a backup copy of all the files and programs on the hard disk.

2. Select Format Disk; then, follow the instructions on the screen.

52 Netfinity Server HMM

Note

Hard disks normally contain more tracks than their stated capacity (to allow for defective tracks). A message appears on the screen if the defect limit is reached. If this happens, replace the hard disk.

3. To install an operating system after the hard disk is formatted, follow the instructions in the ServerGuide package that comes with your server.

IBM Netfinity 1000 - Type 8477

Specifications (Ethernet cable)

This appendix contains the specifications for the unshielded twisted-pair (UTP) cables that can be used to connect the server to an IEEE Standard 802.3 network.

The Ethernet controller on your system board provides 10BASE-T and 100BASE-TX support through the RJ-45 connector on the back of your server. When you connect your server to the network, the Ethernet controller automatically detects the data-transfer rate (10 Mbps or 100 Mbps) on the network and then sets the controller to operate at the appropriate rate.

The following information describes the specifications for the unshielded twisted-pair (UTP) cable that can be used to connect the server to an IEEE Standard 802.3 network.

Attention:

To connect the server's 10BASE-T or 100BASE-TX port to a repeater, use an UTP EIA/TIA-568 Category 5 cable that is terminated with RJ-45 connectors. This is a requirement to meet various governmental standards, including electromagnetic compatibility.

The cables used in 10BASE-T or 100BASE-TX link segments do not require grounding. However, all devices connected to the cables must be grounded.

Connect the appropriate type of UTP cable to the repeater.

 If the port on the repeater is a crossover port (also

called an MDI-X port), use a UTP cable that is wired as a straight-through cable.

 If the port on the repeater is not a crossover port

(also known as an MDI port), use a UTP cable that is wired as a crossover cable.

The server contains three diagnostic light-emitting diodes (LEDs) for the Ethernet connector, one located on the front and two located on the rear of the ssrver.

 When the green LED is on, it indicates that the

Ethernet controller is connected to a hub or switch and is receiving link pulses. This LED is also known as the Link OK light.

 When the amber LED is on, it indicates that the

Ethernet network is operating at 100 Mbps. When this LED is off, it indicates that the Ethernet network is operating at 10 Mbps.

Do not use telephone extension cables to connect the server to a repeater. The wire pairs in those cables are not twisted, and the cables do not meet other requirements for use in a 10BASE-T or 100BASE-TX network. You can identify telephone extension cables by their flat and thin appearance. UTP cables are rounder and thicker than telephone extension cables.

54 Netfinity Server HMM

Table 1 on page 55 describes the specifications for UTP cables used in 10BASE-T and 100BASE-TX link segments. Cables for these link segments must be certified as EIA/TIA-568 Category 5.

Table 1. Cabling Specifications for 10BASE-T and 100BASE-TX Link Segments

Characteristic Specificationñ

Cable type UTP cable with two twisted pairs

of 22, 24, or 26 AWGò wire Nominal impedance 100 Ohms Velocity of propagation 0.585 có Maximum attenuation  For 10BASE-T: 8 to 10 dB

per 100 m at 10 MHz

 For 100BASE-TX: 67 dB

per 305 m at 100 MHz

Notes:

1. Cables that have been certified as EIA/TIA-568 Category 5 meet all 10BASE-T and 100BASE-TX specifications. An EIA/TIA-568 Category 5 cable must be used for 10BASE-T and 100BASE-TX.

2. The cable can contain two to four twisted pairs, but only two of the pairs will be used by the 10BASE-T or 100BASE-TX network.

3. The c represents the velocity of light traveling in a vacuum, which is 300000 km/sec (186400 mi/sec).

Note

AWG = American Wire Gauge EIA = Electronics Industries Association STP = shielded twisted pair TIA = Telecommunications Industries Association

The following figure illustrates the RJ-45 connector.

10BASE-T or 100 BASE-TX UTP cable

Pins

RJ-45 modular plug connector

The following figure illustrates the wiring in straight-through cables.

RJ-45 Modular Connector

Signal

Twisted

Name

Pair

TD+

RD+

3, 4

(Not used)

Relative to the device connected to the adapter

10BASE-T / 100 BASE-TX

1 2 3 6

4, 5, 7, 8

RJ-45 Modular Connector

Signal

Name

TD+

RD+

4, 5, 7, 8

(Not used)

IBM Netfinity 1000 - Type 8477 55

The following figure illustrates the wiring in crossover cables.

RJ-45 Modular Connector

Signal

Twisted

Name

Pair

TD+

RD+

3, 4

(Not used)

Relative to the device connected to the adapter

10BASE-T / 100BASE-TX

1 2 3 6

4, 5, 7, 8

RJ-45 Modular Connector

Signal

Name

TD+

RD+

4, 5, 7, 8

(Not used)

Note

For additional information about Ethernet protocols, refer to your Ethernet documentation.

Wake on LAN feature

: The Wake on LAN feature is built into the Ethernet

controller. To enable this feature, you must install the appropriate software in your server. See your Ethernet documentation for additional information about Wake on LAN operation.

To use the Wake on LAN feature with an Ethernet adapter, you must install Wake on LAN cables. For instructions, refer to the documentation and cables that come with the adapter.

56 Netfinity Server HMM

Specifications (System)

The following table contains the environmental specifications for the Netfinity 1000 server.

Notes

1. The following levels were measured in controlled

acoustical environments according to procedures specified by the American National Standards Institute (ANSI) S12.10 and ISO 7779, and are reported in accordance with ISO 9296.

2. Actual sound-pressure levels in your location

might exceed the average values stated because of room reflections and other nearby noise sources. The declared sound power levels indicate an upper limit, below which a large number of computers will operate.

Size

 Depth: 445 mm (17.5 in.)  Width: 200 mm (7.9 in.)  Height: 492 mm (19.4 in.)

Weight

 Maximum configuration (as shipped): 17.3 kg (38 lb)  Standard configuration (as shipped): 15 kg (33 lb)

Environment

 Air temperature:

– System on: 10° to 35°C (50° to 95°F) at altitude

0–915 m (3000 ft)

10° to 32°C (50° to 90°F) at altitude

915–2134 m (3000–7000 ft)

– System off: 10° to 43°C (50° to 110°F)

 Humidity:

– System on: 8% to 80% – System off: 8% to 80%

Heat Output

 Approximate heat output in British thermal units (Btu)

per hour:

– Maximum configuration (as shipped): 306

Btu/hour (90 watts)

– Maximum configuration (theoretical)

Btu/hour (460 watts)

Electrical Input

 Sine-wave input (50/60 Hz) is required

 Input voltage:

: 1564

Under typical maximum configurations, the heat output will be substantially below the theoretical maximum.

IBM Netfinity 1000 - Type 8477 57

– Low range:

- Minimum: 90 V ac

- Maximum: 137 V ac

– High range:

- Minimum: 180 V ac

- Maximum: 265 V ac

– Input kilovolt-amperes (kVA) (approximately):

- Maximum (configuration as shipped): 0.70 kVA

Power consumption and heat output vary depending on the number and type of optional features installed and the power-management optional features in use.

Acoustical Noise-Emission Values

 Average sound-pressure levels:

– At operator position:

- 35 dBA idle

- 40 dBA operating

– At bystander position –1 meter (3.3 ft):

- 33 dBA idle

- 36 dBA operating

 Declared (upper limit) sound power levels:

– 4.7 bels idle – 5.0 bels operating

58 Netfinity Server HMM

Locations

The following information supports the Netfinity 1000 Type 8477 server.

 “Bottom cover” on page 72.  “Cabling” on page 74.  “CD-ROM drive” on page 75.  “Completing the installation” on page 78.  “Controls and indicators” on page 82.  “Disconnecting cables and removing the side cover”

on page 85.

 “External options” on page 88.  “External SCSI devices” on page 89.  “External view” on page 92.  “Front fan” on page 93.  “Input/output connectors” on page 95.  “Internal drives” on page 98.  “Internal view” on page 124.  “Memory modules” on page 125.  “Microprocessors” on page 129.  “Preliminary option installation information” on

page 135.

 “Stabilizing feet” on page 137.  “System board” on page 138.  “System board illustration” on page 141.  “System board replacement” on page 143.  “Switch settings” on page 144.  “Updating the server configuration” on page 149.  “Video port connector” on page 151.

IBM Netfinity 1000 - Type 8477

Accessing the system board

Before you can install or remove certain options, you might need to access the system board. For example, you might need to remove adapters, drives, and cables that impede your access to components on the system board. You also need to access the system board before you can install or remove such options as adapters, memory modules, and microprocessors, because these devices reside on the system board.

To access the system board more easily:

1. Rotate the stabilizer feet in towards the server, so that they do not detach due to the weight of the server.

2. Place the server on a flat, sturdy surface, such as a table.

3. Turn the server on its side, so that the system board is facing you.

If you access the inside of the server while it is in the upright position, ensure that the stabilizer feet are positioned correctly. For more information, see “Stabilizing feet” on page 137.

Note

To see a list of the system-board components and an illustration that shows their locations, see “System board illustration” on page 141.

60 Netfinity Server HMM

Adapters

Adding an adapter, such as a communication adapter, extends the capabilities and power of the server. For example, if the server supports redundant array of independent disks (RAID) technology, you can add a RAID adapter that can enhance logical-drive capacity and performance.

Note

For a complete list of the adapters that the server supports, go to http://www.ibm.com/pc/us/compat/ on the World Wide Web, or contact an IBM marketing representative.

When you are installing or removing adapters, it is important to resolve any resource conflicts that might arise. For example, if you install an ISA legacy adapter, you might need to manually configure the adapter by setting a variety of switches on the adapter and by using the Configuration/Setup Utility program.

Many adapters now use enables the server to automatically configure the adapter, provided that the required resources are available. Refer to the instructions that come with the adapter to determine if it is Plug and Play. For more information, see “ISA Legacy Resources” on page 37.

Plug and Play

technology, which

Adapter considerations: The server has

connectors for Accelerated Graphics Port (AGP), industry standard architecture (ISA), and peripheral component interconnect (PCI) adapters. The following sections contain additional information about these types of adapters.

AGP adapters:

dedicated AGP slot connector, in an ISA slot connector, or in a PCI slot connector. However, the server system board does not support the AGP video connector and the integrated video subsystem simultaneously.

The server contains one dedicated AGP slot connector on the inside rear of the server wall, adjacent to the dual-inline memory module (DIMM) connectors. To locate the dedicated AGP slot connector, see “System board illustration” on page 141.

If you need to install an AGP adapter in the dedicated AGP slot connector, go to “Installing or removing AGP adapters” on page 66. If you need to install a video adapter in an ISA or PCI slot connector, go to “ISA and PCI adapters” on page 62.

IBM Netfinity 1000 - Type 8477

You may install a video adapter in the

ISA and PCI adapters:

The server uses a riser card for expansion. The riser card contains expansion slot connectors that connect adapters to the industry standard architecture (ISA) and peripheral component interconnect (PCI) buses.

You can install a variety of adapters in the expansion slot connectors on the riser card. For information on locating the riser card, see “System board illustration” on page 141. For an illustration of the expansion slots that are located on the rear of the server, see “Input/output connectors” on page 95.

The riser card in the server has three dedicated ISA slot connectors and three dedicated PCI slot connectors.

The following illustration shows the expansion slot connectors and other connectors on the riser card.

ISA

ISA PCI

PCI

CD Audio Connector

340-Pin Connector

Alert on LAN Connector

Disk Fan A Connector

Disk Fan B Connector

Front Fan Connector SCSI Hard Disk LED

Connector

Wake on LAN Connector Asset ID Antenna

Connector

Chassis-Intrusion Detector Connector

Internal Speaker Connector

Modem Wakeup Connector

Notes

1. Alert on LAN and Asset ID are available on some models only.

2. If you attach a 4-position cable connector to the 2-pin Modem Wakeup connector, ensure that the unused positions are

riser card

, as shown in the illustration. If this

next to the bottom of the

cable is incorrectly attached, the server might automatically restart each time that you power-off the power.

62 Netfinity Server HMM

ISA

ISA PCI

PCI

CD Audio Connector

340-Pin Connector

Alert on LAN Connector

Disk Fan A Connector

Disk Fan B Connector

Front Fan Connector SCSI Hard Disk LED

Connector

Wake on LAN Connector Asset ID Antenna

Connector

Chassis-Intrusion Detector Connector

Internal Speaker Connector

Modem Wakeup Connector

Attention

To avoid possible damage to adapters and server components, be sure that the adapters that you install do not touch each other or the other components (such as the microprocessor) inside the server.

Installing or removing ISA and PCI adapters: This section gives the procedure for

installing an ISA or PCI adapter. If you want to remove an ISA or PCI adapter, reverse the order of the following steps. If you need to install an AGP adapter in the dedicated AGP slot connector, go to “Installing or removing AGP adapters” on page 66.

Notes

1. See “Input/output connectors” on page 95 for an illustration of the expansion slots on the rear of the server.

2. If you install an ISA legacy adapter, set the resources to [ISA Resource]; this reserves the resources for the legacy adapter and prevents the BIOS from using these resources for the system or other adapters. If you remove an adapter, reassign the system resources as [Available] for ISA legacy adapters. See “ISA Legacy Resources” on page 37.

3. To install some adapters, especially full-length adapters, you might need to remove the bottom cover, the system board, and the front fan.

Notes

 Read “Safety information” on page 210.  Read the documentation that comes with the

option.

 Read “Accessing the system board” on page 60.

To install an ISA or PCI adapter:

IBM Netfinity 1000 - Type 8477

1. Review the instructions that come with the adapter to determine if it must be installed in an ISA or PCI expansion slot; otherwise, use any empty, bus-compatible slot.

2. Remove the server side cover (see “Disconnecting cables and removing the side cover” on page 85).

3. If necessary, remove the bottom cover (see “Bottom cover” on page 72).

4. Remove the screw and bracket.

5. Remove the appropriate expansion-slot cover:

a. Remove the expansion-slot screw on the top of

the expansion-slot cover. b. Slide the expansion-slot cover out of the server. c. Store the expansion-slot cover in a safe place for

future use.

6. Touch the static-protective package that contains the adapter to any

unpainted

metal surface on the server;

then, remove the adapter from the package.

7. Install the adapter into the appropriate slot on the riser card.

You might have to remove the system board and the front fan in order to slide the adapter into the slot. See “Front fan” on page 93 and “System board” on page 138.

Note

The components of a PCI adapter face down toward the system board, and the components of an ISA adapter face up. If a component in the server or on the adapter interferes with the installation, use another slot.

64 Netfinity Server HMM

Expansion-Slot Cover

Adapter Card

Riser Card

8. Install the bracket and the screw.

9. If you installed a network adapter that uses Wake on LAN or Alert on LAN, attach the cable from the riser card to the adapter. See “ISA and PCI adapters” on page 62 to locate the Wake on LAN or Alert on LAN connector. If you installed a modem and want to use Modem Wakeup, see “ISA and PCI adapters” on page 62 to locate the Modem Wakeup connector on the riser card.

10. If you removed the bottom cover, the front fan, or the system board, replace them. See “Front fan” on page 93, “System board” on page 138, and “Bottom cover” on page 72.

11. If necessary, connect any internal cables to the adapter. Refer to the documentation that comes with the option.

12. If you installed an ISA legacy adapter, go to “ISA Legacy Resources” on page 37 to assign system resources.

13. If you want to install or remove any other options, do so now. Otherwise, go to “Completing the installation” on page 78.

IBM Netfinity 1000 - Type 8477

Installing or removing AGP adapters: This

section gives the procedure for installing an AGP adapter in the dedicated AGP slot connector. If you want to remove an AGP adapter from this slot connector, reverse the order of the following steps. If you need to install an adapter in an ISA or PCI slot connector, go to “Installing or removing ISA and PCI adapters” on page 63.

Notes

1. You may install a video adapter in the dedicated AGP slot connector, in an ISA slot connector, or in a PCI slot connector. However, the server system board supports either the integrated video subsystem or the AGP video connector, but not both simultaneously.

2. You can install only a special AGP graphics adapter in the dedicated AGP slot connector. For information on the available AGP adapters, go to http://www.ibm.com/pc/us/compat/ on the World Wide Web.

Note

 Read “Safety information” on page 210.  Read the documentation that comes with the

option.

 Read “Accessing the system board” on page 60.

Attention

The presence of 5 V ac standby power might result in damage to the hardware unless you disconnect the power cord from the electrical outlet before you open the server.

To install an AGP adapter:

1. Remove the server side cover (see “Disconnecting cables and removing the side cover” on page 85).

2. Remove the screw; then, remove the cover to access the two slots on the server wall. The slots on the server wall provide access to the connector on the AGP adapter for attaching external devices.

66 Netfinity Server HMM

3. Install the AGP adapter. The following illustration shows the installation of an AGP adapter. Note that the connector for external devices on the AGP adapter is accessible through the slot on the server wall.

Note

Some adapters support the attachment of secondary adapters called

daughterboards

.(A daughterboard is an adapter that can be plugged into another adapter or the system board.) Because a daughterboard might provide another connector for external devices, a second slot is provided in the server wall for access.

4. If necessary, connect any internal cables to the adapter. Refer to the documentation that comes with the option.

5. If you want to install or remove any other options, do so now. Otherwise, go to “Completing the installation” on page 78.

IBM Netfinity 1000 - Type 8477

Adding security options

Security features can help to protect the server data and programs from unauthorized access and use, and help to physically protect the server from theft and tampering. After you determine the system security needs, you can activate or implement the appropriate security features.

To control access to the information in the server databases, you can implement security measures through the system configuration programs. These features include defining two levels of password protection, restricting diskette access, and defining a system owner's name. Implementing these security measures helps you to ensure the integrity of the data and programs that are stored in the server. See “System Security” on page 28 for details.

To prevent writing to a diskette in a diskette drive, set the diskette write-protect switch, as described in “Diskette write-protect switch setting” on page 146.

To erase lost or forgotten passwords, you can move the CMOS clear (password) jumper on the system board.

To control access to other hardware components in the server, you can install several types of optional devices. These options include:

 U-bolt  Security cable  Padlock

The following section discusses these security options.

Installing a U-bolt and security cable: You

can help to deter unauthorized removal of the Netfinity 1000 server by installing a U-bolt and security cable on the rear of the server. After you add the security cable, make sure that it does not interfere with other cables that are connected to the server.

Note

 Obtain the following:

– A 19 mm (3/4 in.) U-bolt or wire rope

(similar to National Manufacturing No. 3230,

Stock No. 176-735) – Threaded nuts that fit the U-bolt – A security cable – A lock, such as a combination lock or

padlock

 Read “Safety information” on page 210.

68 Netfinity Server HMM

1. Remove the server side cover (see “Disconnecting cables and removing the side cover” on page 85).

2. Locate the two holes on the lower right edge of the rear of the server.

3. Insert the U-bolt through the rear panel; then, attach and tighten the nuts with an appropriately sized or adjustable wrench.

4. If you have completed installing the U-bolt and do not want to install any other internal options, replace the server side cover and reconnect all external cables and power cords. (See “Completing the installation” on page 78 if you need additional information.)

5. Thread the cable through the U-bolt and around an object that is not a part of or permanently secured to the building structure or foundation, and from which it cannot be removed; then, fasten the cable ends together with a lock.

The following illustration shows an example of how this might work.

Cable

Padlock

IBM Netfinity 1000 - Type 8477 69

Battery

If the server battery malfunctions, you must replace it as described in this section.

IBM has designed this product with your safety in mind. The lithium battery must be handled correctly to avoid possible danger. If you replace the battery, you must adhere to the following instructions.

Caution

When replacing the battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If the system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.

Do not:

 Throw or immerse into water  Heat to more than 100°C (212°F)  Repair or disassemble

Dispose of the battery as required by local ordinances or regulations.

Note

In the U.S., please call 1-800-IBM-4333 for information about battery disposal.

To order replacement batteries, call 1-800-772-2227 within the United States, and 1-800-465-7999 or 1-800-465-6666 within Canada. Outside the U.S. and Canada, call your IBM reseller or IBM marketing representative.

Notes

 Read “Safety information” on page 210.  Followed any special handling and installation

instructions supplied with the replacement battery.

 Removed the server side cover.

Note

After you replace the battery, you must reconfigure the system and reset the system date and time.

To replace the battery:

1. Locate the battery on the system board (see “System board illustration” on page 141).

70 Netfinity Server HMM

2. Remove the battery: a. Use one finger to lift the battery clip over the

battery.

b. Use one finger to slightly slide the battery toward

the front of the server. The spring mechanism behind the battery will push it out toward you as you slide it forward.

c. Use your thumb and index finger to pull the

battery from under the battery clip.

d. Ensure that the battery clip is touching the base

of the battery socket by pressing gently on the clip.

3. Insert the new battery: a. Tilt the battery so that you can insert it into the

front of the socket, under the battery clip.

b. As you slide it under the battery clip, press the

battery down into the socket.

4. Reinstall the server covers and complete the

installation (see “Completing the installation” on page 78).

Note

When you turn on the server for the first time after you replace the battery, an error message might appear. This is normal after battery replacement.

5. Start the Configuration/Setup Utility program and

reset configuration parameters as needed.

 To reset the system date and time, go to “Date

and Time” on page 27.

 To reset the power-on password, go to “Setting

power-on password modes” on page 28.

 To reconfigure the system, follow the instructions

given in “Configuration/Setup utility program” on page 22 (all models).

IBM Netfinity 1000 - Type 8477

Bottom cover

Attention

The presence of 5 V ac standby power might result in damage to the hardware unless you disconnect the power cord from the wall before you open the server.

Note

 Read “Safety information” on page 210.  Read the documentation that comes with the

option.

To remove the bottom cover:

1. Remove the server side cover (see “Disconnecting cables and removing the side cover” on page 85).

2. Position the server as described in “Accessing the system board” on page 60.

3. Remove the screws from the bottom cover.

4. Pivot the end of the bottom cover away from the server frame.

Note

The server bottom cover might look different from the bottom cover in this illustration.

5. Slide the tabs on the end of the cover out of their openings and remove the cover.

To replace the bottom cover:

1. Hold the bottom cover at an angle and align the tabs on the end with the openings in the frame.

2. Fit the tabs into the openings and pivot the bottom cover until it is closed.

72 Netfinity Server HMM

3. Align the holes and insert the two bottom screws.

4. If you want to install or remove any other options, do so now. Otherwise, go to “Completing the installation” on page 78.

IBM Netfinity 1000 - Type 8477 73

Cabling

Before cabling the server:

 Make sure that you have an adequate number of

properly grounded electrical outlets for the server, monitor, and any other options that you intend to install.

 Place the server in a location that is dry. Rain or

spilled liquids might damage the server.

Note

To allow for air circulation, be sure to maintain the clearances.

To cable the server:

1. Use the following illustration to cable the server. For information about Ethernet cables, see

“Specifications (Ethernet cable)” on page 54.

Power Connector

PCI 1

USB 2

Serial 2

Mouse

Expansion Slots

PCI 2

PCI 3

ISA 1

ISA 2

External SCSI Device

Microphone

Audio

Line In

Audio

Line Out Ethernet

(RJ-45)

Parallel

USB 1

Serial 1

Keyboard

Monitor

2. Connect all power cords to electrical outlets.

ISA 3

74 Netfinity Server HMM

CD-ROM drive

An IDE CD-ROM drive is a standard feature on all Netfinity 1000 servers. CD-ROM drives can play back or read from a CD, but cannot write information to it. CD-ROM drives use industry-standard, 12 cm (4.75-inch) CDs.

Follow these guidelines when using a CD-ROM drive:

 Do not place the server where the following

conditions exist: – High temperature – High humidity – Excessive dust

– Excessive vibration or sudden shock – An inclined surface

– Direct sunlight

 Do not insert any object other than a CD into the

drive.

 Before moving the server, remove any CD from the

drive.

The following is an illustration of the front bezel of the server, with the CD-ROM drive location, controls, and indicators.

Tray Eject/Load Button

Emergency-Eject Hole CD-ROM Drive

In-Use Light

Socket7

IBM Netfinity 1000 - Type 8477 75

The following illustration shows the front of the CD-ROM drive.

CD-ROM Drive In-Use Light

Emergency-Eject Hole

Eject/Load Button

Handling a CD: When handling a CD, follow these

guidelines:

 Hold the CD by its edges. Do not touch the surface.  To remove dust or fingerprints, wipe the CD from the

center to the outside. Wiping the CD in a circular direction might cause loss of data.

 Do not write or stick paper on the CD.  Do not scratch or mark the CD.  Do not place or store the CD in direct sunlight.  Do not use benzene, thinners, or other cleaners to

clean the CD.

 Do not drop or bend the CD.

Loading and unloading a CD

Note

Before you load or unload a CD, be sure that you have turned on the server.

To load and unload a CD in a CD-ROM drive:

1. Press the Eject/Load button. The tray slides out of the drive. (Do not manually force the tray open.)

2. Place the CD in the tray with the label facing up.

3. Close the tray by pressing the Eject/Load button, or by gently pushing the tray forward. When the tray is closed, the CD-ROM drive in-use light on the front of the drive will activate to indicate that the drive is in use.

4. To eject the CD, press the Eject/Load button. When the tray slides out, carefully remove the CD.

5. Close the tray by pressing the Eject/Load button, or by gently pushing the tray forward.

76 Netfinity Server HMM

Notes

1. If the tray does not slide out of the drive when

you press the Eject/Load button, insert one end of a large paper clip into the emergency-eject hole located above and to the left of the CD-ROM drive in-use light.

2. In some models, you might have to remove the

front bezel from the CD-ROM drive to access the emergency-eject hole.

IBM Netfinity 1000 - Type 8477 77

Completing the installation

Notes

 Complete all the installation procedures for the

internal options that you have chosen to install.

 Read “Safety information” on page 210.

1. Ensure that all components have been reassembled correctly and that no tools or loose screws are left inside the server.

2. Clear any cables that might impede the replacement of the cover.

3. Place the server in an upright position, and ensure that the stabilizer feet are positioned correctly. For more information, see “Stabilizing feet” on page 137.

Note

It is easier to install the cover if the server is placed in an upright position.

4. Install the side cover:

a. Make sure that the cover lock (if present) is in

the unlocked position.

Cover Lock

78 Netfinity Server HMM

b. Align the three bottom cover guides with the

corresponding notches on the frame of the server.

Tab Opening

Notches

c. Insert the bottom cover tab into the tab opening.

Tab

Notches

d. With one hand, align the top so that the cover

rests against the server. With the other hand, press the cover at the bottom left corner, above the left rotated foot.

IBM Netfinity 1000 - Type 8477 79

Socket7

e. Keep the hand at the top to hold the cover in

place. Use the thumb from the other hand to slide the cover as shown in the following illustration. Make sure that the cover is latched into position.

Socket7

5. If a cover lock is present, go to the back of the server and lock the cover.

You can use the cover lock and keys to secure the outside cover.

80 Netfinity Server HMM

Attention

In the United Kingdom, by law, the telephone cable must be connected

after

the power cord.

Caution

When the power-cord strain-relief bracket option is installed on the power cord, the server must be plugged to a power source that is easily accessible.

6. Reconnect the cables to the back of the server; then, plug the power cords into properly grounded electrical outlets.

Keyboard Mouse

Parallel Device

Ethernet Device

Serial Device

Audio Devices

Monitor

USB Device

SCSI Device

7. If you have a modem or fax machine attached to the server, and you are not in the United Kingdom, reconnect the telephone line to the wall outlet and the server, and plug the power cords into properly grounded electrical outlets.

If you are in the United Kingdom, plug in the power cords first; then, connect the telephone line to the wall outlet and the server.

8. Power-on the server and all attached devices.

Attention

To allow for air circulation, be sure to maintain the following minimum clearances around the server:

 102 mm (4 in.) in the front  127 mm (5 in.) in the rear  51 mm (2 in.) on the left and right sides

When you have completed installing the covers and cables, go to “Updating the server configuration” on page 149.

IBM Netfinity 1000 - Type 8477 81

Controls and indicators

The most commonly used controls and status indicators are on the front of the server.

Server controls

Power Switch

CD-ROM Eject/Load Button

Diskette Eject Button

Socket7

Power Switch: Press this switch to turn

the server on or off.

Attention

Do not turn off the server if a drive in-use light is on. This might damage the information stored on a hard disk or on a diskette.

When the power is on, there is a period of time during the power-on self-test (POST), a short test that occurs when the server is turned on, when a single touch of the power switch will not turn off the power. If power must be turned off during POST, press and hold the power switch for 5 seconds or disconnect the power cord. After POST, the power switch works normally, unless the server is in a hang condition. If the server is in a hang condition, press and hold the power switch until the power turns off.

CD-ROM Eject/Load Button: Push this

button to release a CD from the CD-ROM drive. See “CD-ROM drive” on page 75 for additional information about the CD-ROM drive controls and indicators.

Diskette Eject Button: Push this button

to release a diskette from the diskette drive.

82 Netfinity Server HMM

Status indicators: The following illustration

identifies the indicators located on the front of the server.

Power-On Light Hard-Disk Drive

In-Use Light Ethernet Activity Light

CD-ROM Drive In-Use Light

Diskette Drive

Socket7

Power-On Light: This light comes on when you turn on the server by pressing the power switch.

Hard Disk Drive In-Use Light: This light comes on when the server is accessing a SCSI hard disk drive. If this light remains illuminated, it might indicate that either the SCSI bus or the system microprocessor has stopped.

Ethernet Activity Light: This light comes on when the Ethernet controller is transmitting data to or receiving data from another system in the network.

Ethernet Diagnostic LED:

The server contains diagnostic light-emitting diodes (LEDs) for the Ethernet connector located on the rear panel of the server.

 When the green LED is on, it

indicates that the Ethernet controller is connected to a hub or switch and is receiving link pulses. This LED is also known as the Link OK light.

 When the amber LED is on, it

indicates that the Ethernet network is operating at 100 Mbps. When this LED is off, it indicates that the Ethernet network is operating at 10 Mbps.

CD-ROM Drive In-Use Light: This light

comes on when the CD-ROM drive is accessed.

In-Use Light

IBM Netfinity 1000 - Type 8477

Diskette Drive In-Use Light: This light

comes on when the diskette drive is accessed.

84 Netfinity Server HMM

Disconnecting cables and removing the side cover

Attention

The presence of 5 V ac standby power might result in damage to the hardware unless you disconnect the power cord from the electrical outlet before you open the server.

1. Remove any media (diskettes or CDs) from the drives; then, power-off all attached devices and the server.

Caution

The Power Control button on the front of the server does not turn off the electrical current supplied to the server. The server also might have more than one power cord. To remove all electrical current from the server, ensure that all power cords are disconnected from the power source.

2. Touch the rear of the bare metal frame to dissipate any static electricity from your body.

3. Before disconnecting cables, be sure to note where they attach, so that you can correctly reattach them later.

Note

If you are in the United Kingdom, you must perform step 5 before step 4.

4. Unplug all power cords (cables) from electrical outlets.

5. If you have a modem or fax machine attached to the server, disconnect the telephone line from the wall outlet and the server.

6. Note the location of the remaining cables and cords.

IBM Netfinity 1000 - Type 8477

Caution.

Electrical current from power, telephone, and communication cables can be hazardous. To avoid personal injury or equipment damage, disconnect the attached power cords, telecommunications systems, networks, and modems before you open the server covers, unless instructed otherwise in the installation and configuration procedures.

7. Disconnect all cables attached to the server; this includes power cords, input/output (I/O) cables, and any other cables that are connected to the server.

Notes

1. For more information about the rear connectors, see “Input/output connectors” on page 95.

2. For more information about ports, including universal serial bus (USB), see “External options” on page 88.

Keyboard Mouse

Parallel Device

Ethernet Device

Serial Device

Audio Devices

Monitor

USB Device

SCSI Device

86 Netfinity Server HMM

8. If necessary, unlock the server side cover. (The cover lock is located at the rear of the server.)

Cover Lock

9. Remove the side cover by pulling out on the cover-release tab at the rear of the side cover. Then, slide the cover toward the front of the server and lift it off.

10. Set the door aside.

CoverRelease Tab

IBM Netfinity 1000 - Type 8477 87

External options

Some examples of the external options that you can connect to the server include SCSI drives and storage enclosures, printers, modems, and other serial and parallel devices.

To attach an external option:

1. Power-off the server and all attached devices.

2. Follow the instructions that come with the option and the information in this section to connect it to the server.

The information in this section supplements the instructions that come with the external option. Use the instructions that come with the option to prepare it for installation.

Adding a hot-swap storage expansion enclosure: You can connect a storage enclosure to

the external SCSI connector on the separately installed SCSI adapter. Contact your IBM reseller or IBM marketing representative for additional information.

Hot-Swap Drive Bays

88 Netfinity Server HMM

External SCSI devices

Note

If an internal device(s) is/are attached to the SCSI controller, only one external device is supported.

The internal SCSI connector provides support for SCSI devices installed inside the server. The external SCSI connector provides support for external SCSI devices. The UltraSCSI adapter can support a maximum of 15 devices.

Notes

 If you plan to install both internal and external

SCSI devices, you must follow the instructions given in “Internal drives” on page 98 in addition to the instructions in this section. Read “Internal drives”; then, return here.

For additional information about SCSI configurations supported, see http://www.ibm.com/netfinity/

 The server comes with a wide (16-bit) SCSI

cable that supports 16-bit devices. If you want to attach narrow (8-bit) devices to the server, you must purchase a SCSI 68-pin to 50-Pin Converter that will enable the connection of the device to the cable that comes with the server.

 It is good practice not to exceed the following

cable-length guidelines:

– If you connect one or more UltraSCSI

devices to the UltraSCSI adapter, do not exceed 1.5 meters (5 feet) total length for all cables (internal and external).

– If you connect only Fast SCSI devices to the

UltraSCSI adapter, do not exceed 3 meters (10 feet) total length for all cables (internal and external).

Attention

In addition to cable length and the number of installed devices, you must consider other factors that limit the performance of the SCSI subsystem. For example, if you install UltraSCSI devices in an external expansion enclosure that is limited to Fast transfer rates, or if you exceed the previously described cable-length guidelines, the transfer rate to all SCSI devices must be limited to Fast or standard transfer rates. You accomplish this by using the SCSISelect Utility program. See “SCSISelect utility program” on page 50 for additional information.

If you plan to attach an external SCSI device, you must order an additional SCSI cable. That is, to use an external

IBM Netfinity 1000 - Type 8477

device with the Netfinity 1000 server, you must connect it to the external SCSI connector, using a SCSI cable. This SCSI cable must have the proper connector for the SCSI external connector on one end, and the proper connector for the external device on the other end. To select and order the correct SCSI cable for use with the external device, contact your IBM reseller or IBM marketing representative.

Serial port connectors: Serial ports are used to

communicate with printers, plotters, external modems, auxiliary terminals, and other computers. The server provides two serial ports (1 and 2). You can add more serial ports by installing a serial adapter in one of the expansion slots.

Serial ports transfer data

asynchronously

transmit any number of bits at any time, with no restriction on the duration of the pauses between characters.

The serial ports transmit and receive data and commands at a rate of 300 bits per second (bps) up to 115200 bps. The bits-per-second measurement is commonly referred to

baud rate.

as the Both of the serial connectors on the server use a 9-pin,

D-shell connector.

; they can

Table 2 shows the pin-number assignments for the serial port connectors. The pin-number assignments conform to the industry standard.

Pin Signal Pin Signal

1 Data carrier detect 6 Data set ready 2 Receive data 7 Request to send 3 Transmit data 8 Clear to send 4 Data terminal ready 9 Ring indicator 5 Signal ground

Table 2. Serial Port Connector Pin-Number Assignments

90 Netfinity Server HMM

Parallel port connector: Parallel ports are used to

communicate with printers and other devices, such as some CD-ROM and tape drives. The server provides one 25-pin, D-shell connector on the back of the server.

This parallel port connector conforms to the Institute of Electrical and Electronics Engineers (IEEE) Standard 1284. There are three standard modes of operation:

 Standard Parallel Port (SSP)  Enhanced Parallel Port (EPP)  Extended Parallel Port (ECP)

Table 3 shows the pin-number assignments for the parallel port connector. The signal names for all three modes are shown. SSP and ECP signal names are the same; EPP signal names that are different are shown in parentheses.

Pin Signal Pin Signal

1 -STROBE (-WRITE) 14 -AUTO FD (-DSTRB) 2 Data 0 15 -ERROR 3 Data 1 16 -INIT 4 Data 2 17 -SLCT IN (-ASTRB) 5 Data 3 18 Ground 6 Data 4 19 Ground 7 Data 5 20 Ground 8 Data 6 21 Ground 9 Data 7 22 Ground 10 -ACK 23 Ground 11 BUSY (-WAIT) 24 Ground 12 PE 25 Ground 13 SLCT

Table 3. Parallel Port Connector Pin-Number Assignments

IBM Netfinity 1000 - Type 8477 91

External view

The following illustration shows the external view of the server.

Note

This illustration is for reference only.

.1/ Power-on button .2/ Power-on light .3/ Hard disk drive light .4/ Ethernet activity light .5/ Bay 1, CD-ROM drive .6/ CD-ROM eject button .7/ CD-ROM emergency eject hole .8/ Bay 2 .9/ Bay 3 .1ð/ Bay 4, 3.5-inch diskette drive

The server comes with a diskette drive installed in bay 4 and a CD-ROM drive installed in bay 1. If the server comes with a hard disk drive, it is installed in bay 6.

Note

In some models, you might have to remove the front bezel from the CD-ROM drive to access the emergency-eject hole.

92 Netfinity Server HMM
