IBM Netcool/OMNIbus Probe for Nortel CNM, Tivoli Netcool/OMNIbus Probe for Nortel CNM Reference Manual

SC23-6398-02

IBM

Netcool/OMNIbus Probe for Nortel CNM

1.0.3744

frontmatter.fm December 22, 2007

Reference Guide

Publication Date: December 22, 2007

This edition applies to 1.0.3744 of Netcool/OMNIbus Probe for Nortel CNM (SC23-6398-02) and to all subsequent releases
and modifications until otherwise indicated in new editions.

This edition replaces SC23-6398-01.

© Copyright International Business Machines Corporation, 2007. All rights reserved.

US Government Users Restricted Rights - Use, duplication or disclosure restricted by GSA ADP Schedule Contract with
IBM Corp.

Note

Before using this information and the product it supports, read the information in Appendix A. "Notices" on page 25.

iii

Contents

Document control page. . . . . . . . . . . . . . . v

Probe for Nortel CNM

. . . . . . . . . . . . . . . . . 1

Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Supported platforms . . . . . . . . . . . . . . . . . . . . . . . . 3

Basic configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installation requirements . . . . . . . . . . . . . . . . . . 3

Updating the rules file . . . . . . . . . . . . . . . . . . . . 3

Data acquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connecting to the CORBA interface . . . . . . . . .4

Status checking . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Retrieving objects . . . . . . . . . . . . . . . . . . . . . . . . 5

Running multiple probes . . . . . . . . . . . . . . . . . . 5

Shutting down the probe . . . . . . . . . . . . . . . . . .5

Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Filtering notifications and alarms . . . . . . . . . . .6

Command line interface . . . . . . . . . . . . . . . . . . . 7

Peer-to-Peer failover functionality . . . . . . . . . . . . .9

Example property file settings for peer-to-peer
failover9

Internationalization support . . . . . . . . . . . . . . . . .10

Example multi-byte character set configuration
on Solaris10

Properties and command line options . . . . . . . . .11

Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

ProbeWatch messages . . . . . . . . . . . . . . . . . . . . . . 21

Appendix A. Notices . . . . . . . . . . . . . . . . 25

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Netcool/OMNIbus Probe for Nortel CNM Reference Guideiv

v

docscontrol.fm December 22, 2007

Document control page

The Netcool/OMNIbus Probe for Nortel CNM documentation is provided in softcopy
format only. To obtain the most recent version, visit the IBM Tivoli Netcool Information
Center:

http://publib.boulder.ibm.com/infocenter/tivihelp/v8r1/index.jsp

Table 1. Document modification history

Document
version

Publication
date

Comments

01 June 22, 2007 First IBM publication.

02 December 22,

2007

Summary section updated.

Secure FTP connection information added.

Connecting to a remote system section added.

FtpPassword property removed.

Netcool/OMNIbus Probe for Nortel CNM Reference Guidevi

Probe for Nortel CNM 1

Nortel CNM.fm December 22, 2007

Probe for Nortel CNM

Nortel CNM (CDMA Network manager) is a networking and service management system
that provides a real-time view of the service provisioning, order managment, fault and
performance management for an enterprise customer’s network. This system supports
multiple wireless network technologies, and customer management interfaces for the
creation, delivery, and playback of multimedia over GSM and CDMA2000 wireless
networks.

The Probe for Nortel CNM collects alarms from Nortel CNM system using a 3GPP2 CORBA
(Common Object Request Broker Architecture) interface for CDMA2000 networks.

This guide contains the following sections:

• Summary

• Supported platforms

• Basic configuration

• Data acquisition

• Peer-to-Peer failover functionality

• Internationalization support

• Properties and command line options

• Elements

• Error messages

• ProbeWatch messages

Netcool/OMNIbus Probe for Nortel CNM Reference Guide2

Summary

Table 2 provides a summary of the Probe for Nortel CNM.

Table 2. Summary

Probe target Nortel CNM version 7

Probe executable name nco_p_nortel_cnm

Patch number 1.0

Probe supported on HP-UX, Solaris

Properties file $OMNIHOME/probes/arch/nortel_cnm.props

Rules file $OMNIHOME/probes/arch/nortel_cnm.rules

Requirements A currently supported version of Tivoli Netcool/OMNIbus.

JDK 1.5

probe-compatibility-3.x (for Tivoli Netcool/

OMNIbus 3.6)

probe-nonnative-base

probe-nonnative-java

nco_p_commandport-0

probe-visibroker-support

Note: The Visibroker patch is not available on the support

site; to obtain this patch, you must contact IBM
Technical Support.

Connection method CORBA

Remote connectivity Yes

Licensing Electronic licensing is no longer implemented in Tivoli

Netcool/OMNIbus products. All Tivoli products now use
the IBM Tivoli software licensing process.

Internationalization Available

Peer-to-peer failover functionality Available

IP environment IPv4 and IPv6

Note: The probe only supports the IPv6 environment on

Tivoli Netcool/OMNIbus v7.x running on Solaris.

Probe for Nortel CNM 3

Supported platforms

For details of the versions of HP-UX and Solaris on which this probe is supported, see the
following page on the IBM Tivoli Netcool Information Center:

http://publib.boulder.ibm.com/infocenter/tivihelp/v8r1/index.jsp?topic=/com.ibm.net
cool_OMNIbus.doc/Supported_Platforms.htm

Basic configuration

This section describes the basic configuration requirements for the Probe for Nortel CNM.

Installation requirements

Before running the probe, you must install the JDK 1.5 runtime libraries and the following
IBM Tivoli Netcool/OMNIbus patches in the following order:

1. probe-compatibility-3.x

2. probe-nonnative-base

3. probe-nonnative-java

4. nco_p_commandport-0

5. probe-visibroker-support

Note: These patches (except the VisiBroker patch) are available from the IBM Support

Site. To obtain the VisiBroker patch, you must contact IBM Support.

Updating the rules file

The Probe for Nortel CNM is supplied with a lookup table (Corba_3gpp2_
R6C1.lookup). This file is installed in the following location:

$OMNIHOME/probes/includes/

This file is referenced in the rules file by the following command:

include "/opt/netcool/probes/includes/Corba_3gpp2_R6C1.lookup"

If the Tivoli Netcool/OMNIbus installation directory is different from /opt/netcool/,
you must update the rules file include statement accordingly.

Note: $OMNIHOME cannot be used in the paths to the lookup files; you must enter the full

path to the Tivoli Netcool/OMNIbus installation directory.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide4

Data acquisition

The Probe for Nortel CNM gathers events from the Nortel CNM 3GPP servers using a
Common Object Request Broker Architecture (CORBA) interface. CORBA is an Object
Management Group specification that provides a standard interface definition between
objects in a distributed environment; that is, it allows applications to communicate with one
another regardless of where they are located or who has designed them.

Connecting to the CORBA interface

The Probe for Nortel CNM acts as an Integration Reference Point (IRP) Manager. The
AlarmIRPOperation and NotificationIRPOperation points form a part of the IRP agent to
which the probe connects through a CORBA interface.

The probe uses the Using Interoperable Object Reference (IOR) files for this connection:

Using IOR files

To connect to the CORBA interface, the probe uses the SecurityIRPAgent Interoperable
Object Reference (IOR) file. If the IOR file is on a remote machine, specify the FTP command
that the probe must use to access it using the SecurityIrpFtpCommand property. If the
IOR file is on a local machine, specify its location using the NortelSecurityIrpFile
property.

Connecting to a remote system

The probe uses secure mode to connect to the remote machine where the IOR file is
available.

To access the IOR file on the remote machine, perform the following steps:

1. Set up the required OpenSSL environment in both the probe server and target system.

2. Create your own PKI key. Remember the password that you specify while creating the
PKI key.

3. Change the access permissions of the PKI key for the SSH to access.

4. Edit the download_ior.sh script so that the IOR_FILE_NAME script variable points
to the same value as the NortelSecurityIrpFile property.

5. Replace the <remote machine name>:<remote path to nortel ior file>
text in the download_ior.sh script with the location and name of the remote
machine.

6. Replace the <password> text in the add-passwd script with the password you
specified while creating the PKI key.

7. Run the probe.

Probe for Nortel CNM 5

The FTP command is run in the user’s home directory. For FTP users other than root, you
must change the default path specified by the NortelSecurityIrpFile property to
enable the probe to locate the security IRP file; for example, if the FTP user is norteluser,
the home directory for this user will be /home/norteluser. In this case, you must change
the default path specified by the NortelSecurityIrpFile property to:

../../opt/nortel/config/3GPP/NortelSecurityIrpAgent.ior

Status checking

The probe checks the status of the IRP agent every 60 seconds. You can change this
frequency if required using the Agentheartbeat property.

Retrieving objects

If the Resynch property is set to true, the probe initially receives a list of all active alarms
from the AlarmIRP server. The probe then connects to the NotificationIRP server and uses
the CORBA notification push model to receive new alarms from the server as they are
generated. If the Resynch property is set to false, the probe only receives new alarms.

The probe initially receives a list of all active alarms from the AlarmIRP server. The probe
then connects to the NotificationIRP server and uses the CORBA notification push model
to receive new alarms from the server as they are generated.

Running multiple probes

You can run multiple instances of the Probe for Nortel CNM. For each instance running,
you must specify a different port to which the server listens using the ORBLocalport
property.

Shutting down the probe

To stop an instance of the probe, you must issue a stop signal to the process associated with
that probe instance.

Timeout

The Probe for Nortel CNM has a timeout facility that allows it to di sconnect from the s ystem
if there is no activity for a predefined amount of time. You can specify how long the probe
waits before disconnecting using the Timeout property.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide6

Filtering notifications and alarms

The NotificationFilter and AlarmFilter properties allow you to specify what
notifications and alarms the probe expects from the device. When you use these properties,
you must use the actual token names. For example, the token h represents the element
NV_PERCEIVED_SEVERITY; so, to specify that the probe is only sent notifications with a
perceived severity of 3, you must set the NotificationFilter property to $h == 3.

You can specify more complex filters using and and or statements; for example, to specify
that the probe is sent notifications with a perceived severity of 3 or 4, you must set the
NotificationFilter property to $h == 3 or $h == 4.

Note: The filtering of elements sent from the device can only be configured at the Nortel

CNM 3GPP2 (CORBA). For details of the syntax required for filtering the object
classes refer to your CORBA documentation, or contact your system administrator.

Table 3 displays the token mappings for use with the AlarmFilter and
NotificationFilter properties.

Table 3. Token mappings (1 of 2)

Element Token

NV_NOTIFICATION_ID a

NV_EVENT_TIME b

NV_SYSTEM_DN c

NV_MANAGED_OBJECT_CLASS d

NV_MANAGED_OBJECT_INSTANCE e

NV_ALARM_ID f

NV_PROBABLE_CAUSE g

NV_PERCEIVED_SEVERITY h

NV_SPECIFIC_PROBLEM i

NV_ADDITIONAL_TEXT j

NV_ACK_TIME k

NV_ACK_USER_ID l

NV_ACK_SYSTEM_ID m

NV_ACK_STATE n

NV_COMMENTS o

NV_BACKED_UP_STATUS p

NV_BACK_UP_OBJECT q

NV_THRESHOLD_INFO r

NV_TREND_INDICATION s

Probe for Nortel CNM 7

Command line interface

The Probe for Nortel CNM is supplied with a command line interface (CLI). This interface
allows you to perform commands using the probe (for example, to acknowledge alarms or
to request a full resynchronization of the CORBA interface).

To use the CLI, you must use the CommandPort property in the properties file to specify a
port through which commands will be sent. When you want to perform commands, telnet
to this port. Table 4 describes the commands that you can use with the command line
interface.

NV_STATE_CHANGE_DEFINITION t

NV_MONITORED_ATTRIBUTES u

NV_PROPOSED_REPAIR_ACTIONS v

NV_CORRELATED_NOTIFICATIONS w

NV_REASON x

CLEAR_USER_ID y

CLEAR_SYSTEM_ID z

NV_ALARM_LIST_ALIGNMENT_
REQUIREMENT

ff

NV_SERVICE_USER gg

NV_SERVICE_PROVIDER hh

NV_SECURITY_ALARM_DETECTOR ii

NV_VENDOR_SPECIFIC_ALARM_TYPE jj

NV_ALARM_RAISED_TIME kk

NV_ALARM_CLEARED_TIME ll

Table 3. Token mappings (2 of 2)

Element Token

Table 4. CLI commands (1 of 2)

Command Description

acknowledge_alarm Allows you to acknowledge an alarm in the 3GPP2

interface.

Note: This command takes as a parameter the

NV_ALARM_ID of the alarm being
acknowledged. Only one alarm can be
acknowledged at a time.

help Displays online help about the CLI.

resynch_all Allows you to perform a full resynchonization with

the 3GPP2 interface.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide8

Note: Since the CLI is based upon telnet connections, you can connect to the probe from

anywhere. This means that simple scripts can be set up to allow users to
acknowledge selected events from the Tivoli Netcool/OMNIbus event list by
creating desktop tools to telnet to the probe, send a command, and then close the
connection.

resynch_filter Allows you to a perform partial resynchronization

with the 3GPP2 interface.

Note: This command takes as a parameter a filter in

the same format as the AlarmFilter
property. For details, see "Filtering
notifications and alarms" on page 6.

unacknowledge_alarm Allows you to unacknowledge an alarm in the

3GPP2 interface.

userid_clear_alarms Allows you to clear an alarm in the 3GPP2 interface

by specifying the USER_ID. This parameter is
specified by the ClearSystemId property.

user_clear_alarms Allows you to clear the identity of the user who who

invokes the clearAlarms operation.

userid_acknowledge_alarm Allows you to acknowledge an alarm in the 3GPP2

interface by specifying the NV_ALARM_ID and the
NV_ACK_USER_ID. These parameters are specified
by the AckSystemId and AckUserId properties,
respectively.

userid_unacknowledge_alarm Allows you to unacknowledge an alarm in the

3GPP2 interface by specifying the NV_ALARM_ID
and the NV_ACK_USER_ID.

version Displays the version of the probe.

Table 4. CLI commands (2 of 2)

Command Description

Probe for Nortel CNM 9

Peer-to-Peer failover functionality

The Probe for Nortel CNM supports failover configurations where two probes run
simultaneously. One probe acts as the master probe, sending events to the ObjectServer; the
other acts as the slave probe on standby. In the event of the master probe failing, the slave
probe activates.

While the slave probe receives heartbeats from the master probe, it will not forward events
to the ObjectServer. If the master shuts down, the slave probe will stop receiving heartbeats
from the master and any events it receives thereafter will be forwarded to the ObjectServer
on behalf of the master probe. When the master is running again, the slave will continue to
receive events from the trap forwarder, but will no longer send them to the ObjectServer.

Example property file settings for peer-to-peer failover

The following configuration shows the peer-to-peer settings from the properties file of an
example master probe:

Server :"NCOMS"
RulesFile :"master_rules_file"
MessageLog :"master_log_file"
PeerHost :"slave_hostname"
PeerPort : 5555 # [communication port between master and slave probes]
Mode :"master"

The following configuration shows the peer-to-peer settings from the properties file of the
corresponding slave probe:

Server :"NCOMS"
RulesFile :"slave_rules_file"
MessageLog :"slave_log_file"
PeerHost :"master_hostname"
PeerPort : 5555 # [communication port between master and slave probes]
Mode :"slave"

Netcool/OMNIbus Probe for Nortel CNM Reference Guide10

Internationalization support

The Probe for Nortel CNM supports multi-byte character sets. To view the character sets
correctly, you must configure the locale settings on the host machine correctly. Each
multi-byte character set is configured slightly differently on each platform. The following
section describes example locale configurations on a UNIX platform; other character sets on
other platforms will be configured in a similar way.

Example multi-byte character set configuration on Solaris

The following steps describe how to configure Solaris to use the Japanese character set:

1. Install the necessary components for Japanese on to the host machine using the Solaris
CD.

2. Set the LANG and LC_ALL environment variables to ja_JP PCK. This uses SJIS
encoding.

Note: You may have to set LANG in the host machine’s default settings file and reboot

to make the changes take effect.

3. Make sure that the following entry is present in the $OMNIHOME/platform/arch/

locales/locales.dat file:

locale = ja_JP PCK, japanese, sjis

where ja_JP PCK is the vendor locale, japanese is the Sybase language, and sjis
is the Sybase character set.

Probe for Nortel CNM 11

Properties and command line options

Table 5 describes the properties and command line options specific to this probe. For
information about generic probe properties and command line options, see the IBM Tivoli
Netcool/OMNIbus Probe and Gateway Guide, (SC23-6387).

Table 5. Properties and command line options (1 of 4)

Property name Command line option Description

AckSystemId string -acksystemid

string

Processing system on which the IRP
Manager runs. This is used by the
acknowledge_alarm CLI function.

The default is "".

AckUserId string -ackuserid string Name of the user acknowledging the

alarm. This is used by the acknowledge_
alarm CLI function.

The default is "".

Agentheartbeat

integer

-agentheartbeat

integer

Frequency (in seconds) with which the
probe checks the status of the IRP agent.

The default is 60.

AlarmFilter string -alarmfilter

string

Filter the alarm IRP uses to limit the alarms
sent to the probe.

The default is "".

AlarmIrpName

string

-alarmirpname

string

Name of the Alarm IRP Agent.

The default is 32.111-3 V6.5.

ClearSystemId

string

-clearsystemid

string

Name of the IRP Manager that supports the
user who clears the alarms using the CLI.

It can be used to identify the system, such
as system 6, or it can contain no
information such as "".

The default is "".

For more information on CLI, see
"Command line interface" on page 7.

ClearUserId string -clearuserid

string

Name of the user clearing the alarms used
by the CLI function of the probe.

The identity can be a human operator such
as "John Smith", or a group such as
"Team Six", or it can contain no
information such as "".

The default is "".

For more information on CLI, see
"Command line interface" on page 7.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide12

CommandPort

integer

-commandport

integer

Specifies the port to which users can telnet
to communicate with the 3GPP2 interface
using the Command Line Interface (CLI)
supplied with the probe. For more
information on CLI, see "Command line
interface" on page 7.

The default is 6970.

CommandPortLimit

integer

-commandportlimit

integer

Maximum number of telnet connections
that can be made to the probe.

The default is 10.

EntryPointIrpName

string

-entrypointirpname

string

Name used to resolve the EntryPoint IRP.

The default is 32.363 V6.4.

NortelSecurityIrp
File string

-nortelsecurityirp
file string

File that provides an object reference to the
Nortel security object.

The default is

opt/nortel/config/3gpp/
NortelSecurityIrpAgent.ior.

Notification
Categories string

-notification
categories string

Specifies the categories of notifications to
which the probe subscribes.

A semi-colon (;) separates each category:

category1;category2;category3…

The default is "" (subscribes to all
notification categories).

Notification
Filter string

-notification
filter string

Filter the notification IRP uses when
subscribing to online notifications.

The default is "".

NotificationIrp
Name string

-notificationirp
name string

Name of the Notification IRP IOR file.

The default is 32.303 V6.6.

ORBLocalPort

integer

-orblocalport

integer

Local port to which the Object Request
Broker (ORB) listens.

The default is 0 (ORB selects an available
port at random).

Table 5. Properties and command line options (2 of 4)

Property name Command line option Description

Probe for Nortel CNM 13

Password string -password string Password required with the Username

property to log in to the system.

The default is "".

Note: Specify the password encrypted

using the nco_g_crypt utility. For
details about this utility, see IBM

Tivoli Netcool/OMNIbus
Administration Guide, SC23-6371.

Resynch string -resynch string Specifies whether the probe should

resynchronize the events in the Nortel
CNM system:

true - probe resynchronizes events in the
system

false - probe does not resynchronize
events in the system

he default is false.

Retry string -retry string Specifies whether the probe attempts to

reconnect to the system following a
timeout:

false - probe does not attempt to
reconnect to the system

true - probe attempts to reconnect to the
system

The default is false.

SecurityIrpFtp
Command string

-securityirp
ftpcommand string

FTP command to retrieve the Nortel
Security IRP IOR file.

The default is "" (the probe retrieves IOR
file from the default local location).

Timeout integer -timeout integer Time (in seconds) that the probe allows the

port to be silent before disconnecting.

The default is 0 (probe never disconnects).

Table 5. Properties and command line options (3 of 4)

Property name Command line option Description

Netcool/OMNIbus Probe for Nortel CNM Reference Guide14

TimeTick integer -timetick integer Time (in minutes) that the Notificiation IRP

session remains open to connections. This
is used by the 3GPP server.

The default is 15.

Note: A value of -1 keeps the session

forever open.

Username string -username string Username required by the Nortel Security

Building Block to provide the object
reference to the EntryPoint IRP.

The default is "".

Table 5. Properties and command line options (4 of 4)

Property name Command line option Description

Probe for Nortel CNM 15

Elements

Table 6 describes the elements generated by the Probe for Nortel CNM.

Table 6. Elements (1 of 2)

Element name Element description

AttributeValue(element_name) Contains the value of an element being monitored.

This element is generated dynamically and its content
is dependent on the IRP agent.

Note: The element_name part of this element and
the next element can be the name of any of the other
elements in this table.

AttributeValueChange(element_
name)

Indicates how the value of the element being
monitored has changed.

CLEAR_USER_ID Identity of the user who clears the alarms.

CLEAR_SYSTEM_ID Identity of the the IRPManager where the alarms are

cleared.

DOMAIN_NAME Domain name from which the notification originated.

EVENT_NAME Extended event type for this IRP.

EVENT_TYPE Event type of the notification.

NV_ACK_STATE Acknowledgement state of the alarm.

NV_ACK_SYSTEM_ID System ID of the IRP Manager processing the

notification.

NV_ACK_TIME Time at which the user acknowledged the alarm.

NV_ACK_USER_ID Identifies the last user who has changed the

acknowledgement state.

NV_ADDITIONAL_TEXT Information about the network element from which

the alarm originated.

NV_ALARM_TIME Date when the alarm is cleared. Date is in the

mm/dd/yy format.

NV_ALARM_ID Identification information of the alarm as it appears

in the alarm list.

NV_ALARM_LIST_ALIGNMENT_
REQUIREMENT

Indicates whether the alarm list requires alignment.

NV_ALARM_ALARM_RAISED_TIME Date when the the alarm is raised. Date is in the

mm/dd/yy format.

NV_BACK_UP_OBJECT Distinguished Name (DN) of the backup object.

NV_COMMENTS Comments about the alarms.

NV_BACKED_UP_STATUS Identifies whether the object has been backed up.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide16

NV_CORRELATED_NOTIFICATIONS_

notif_ID_Set

Set of notifications to which this notification is
considered to be correlated. This element is generated
dynamically and its content is dependent on the IRP
agent.

NV_CORRELATED_NOTIFICATIONS_
SOURCE

Source of the notification set.

NV_EVENT_TIME Time at which the event occurred.

NV_MANAGED_OBJECT_CLASS Managed object class of the network resource.

NV_MANAGED_OBJECT_INSTANCE Managed object instance of the network resource.

NV_MONITORED_ATTRIBUTE Managed object attribute of the network resource.

NV_NOTIFICATION_ID Identification information of the notification.

NV_PERCEIVED_SEVERITY Relative level of urgency for operator attention.

NV_PROBABLE_CAUSE Provides further information about the probable

cause of the alarm.

NV_PROPOSED_REPAIR_ACTIONS Proposed repair actions associated with the

notification.

NV_REASON Reason that triggered the proposed repair action.

NV_SERVICE_USER Name of the user who uses the service.

NV_SERVICE_PROVIDER Name of the service provider.

NV_SECURITY_ALARM_DETECTOR Security alarm detector for the device.

NV_SPECIFIC_PROBLEM Further information about the problem to which the

notification relates.

NV_STATE_CHANGE_DEFINITION Information about the status change of the alarm.

NV_SYSTEM_DN Distinguished name (DN) used to identify the system.

NV_THRESHOLD_INFO Provides information about a threshold that has been

crossed.

NV_TREND_INDICATION Indicates how an observed condition has changed.

NV_VENDOR_SPECIFIC_ALARM_TYPE Alarm type specific to the vendor.

Table 6. Elements (2 of 2)

Element name Element description

Probe for Nortel CNM 17

Error messages

Table 7 describes the error messages specific to this probe. For information about generic
error messages, see the IBM Tivoli Netcool/OMNIbus Probe and Gateway Guide, (SC23-6387).

Table 7. Error messages (1 of 4)

Error Description Action

Cannot initialize the
Orb:

The probe could not initialize
the ORB.

Ensure your CLASSPATH
contains the path to the
Visibroker jar files.

Command_Port Error
occurred

Command_Port Failed
to get

CommandPortLimit
property - using 10

Command_Port Failed
to get property

CommandPort

Command_Port Failed

to open listening
socket, shutting down
Thread!

Command_Port Failed
to send probewatch
message!

Command_Port host
Failed to close
command socket

Command_Port host
Failed to get socket
IO

Command_Port host
Failed to read
command

Command_Port Thread
shutting down due to
error!

NetcoolIRPManager:
Failed to
acknowledge_alarms()

NetcoolIRPManager:
Failed to
Unacknowledge_
alarms()

There was a problem with
command port functionality.

Check that you have specified the
command port correctly. Check
the connection between the probe
and the command port.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide18

BAD_PARAM Exception
i.e one or more of
the in/out parameter
is null

InvalidParameter
Exception

NetcoolIRPManager:
Exception occurred.
Stack trace to stderr

OperationNotSupported
Exception

Unexpected CORBA
Exception

There is a problem with the
CORBA interface.

Refer to your CORBA
documentation.

COMMUNICATION FAILURE
Exception i.e Server
is dead

GetSubscriptionStatus
Exception

NetcoolIRPManager:Bot
h NameServiceHost and
NSPort property needs
to be set

NetcoolIRPManager:
'Alarmirp' property
needs to be set

NetcoolIRPManager:
'Notificationirp'
property needs to be
set

NetcoolIRPManager:
Failed to perform
resynch

The probe cannot connect to the
server.

Check that the Nortel CNM
server is running correctly.
Check that you have specified the
parameters correctly in the
properties file.

Table 7. Error messages (2 of 4)

Error Description Action

Probe for Nortel CNM 19

Error to parse event
completely

Failed to parse event
completely

Name is null, cannot
create Element

NetcoolIRPManager:
Category Value NOT
supported: Discarding
Alarm

NetcoolIRPManager:
Error when parsing
event

NetcoolIRPManager:
Failed to send event

The probe cannot parse the
alarm; this is probably because
the alarm is not in a format that
the probe can understand.

Check that the Nortel CNM
server is running correctly.

Failed to get timeout
property value,
defaulting to 0

The Timeout property has not
been set.

Check the value for the Timeout
property; change this value if
necessary.

Failed to find the
AlarmIRP object

The probe could not get the
AlarmIRP object using the
EntryPoint IRP.

Check the value for the
AlarmIrpName property;
change this value if necessary.

Failed to find the
NotificationIRP
object

The probe could not get the
NotificationIRP object
using the EntryPoint IRP.

Check the value for the
NotificationIrpName
property; change this value if
necessary.

Failed to perform
resynch

The probe could not
resynchronize the alarms with
device.

Check the value for the Resynch
property; change this value if
necessary.

Failed to narrow
Security IRP
interface

SECURITY: Failed to
get IRP object :

SECURITY: Unknown
exception occured

The probe has failed to get the
EntryPointIRP object.

Check the value for the
SecurityIrpFtpCommand
property; change this value if
necessary.

NetcoolIRPManager:
Stack Trace to stder:

This message is generated by
the Netcool IRP Manager.

This message is intended for use
when debugging.

NetcoolIRPManager:
Failed to retrieve
EntryPointIRP object
from security
interface:

The probe has failed to get the
EntryPointIRP object.

Check the value for the
SecurityIrpFtpCommand
property; change this value if
necessary.

Table 7. Error messages (3 of 4)

Error Description Action

Netcool/OMNIbus Probe for Nortel CNM Reference Guide20

NetcoolIRPManager:
Failed to retrieve
EntryPointIRP object
from security
interface:

The probe has failed to take the
Corba Object of the Security IRP
and narrow it to its specific
type.

Check the value for the
SecurityIrpFtpCommand
property; change this value if
necessary.

Problem while trying
to connect to the IRP
points

The probe found a problem
while connecting to the

AlarmIRP or
NotificationIRP points.

Check the values set for the

AlarmIrpName, and
NotificationIrpName

property; change the values if
necessary.

Failed to ping
notification service

The probe found a problem
while connecting to the
NotificationIRP point.

Check the values set for the
NotificationIrpName
property; change the values if
necessary.

OperationNotSupported
Exception

The Nortel system doesn’t
support the Notification
IrpSystem.idl.

Contact the IBM support.

Communication failure

- lost connection to
NoticiationIRP:

CORBA.TRANSIENT
exception raised.
NotificationIRP is
down!

CORBA.OBJECT_NOT_
EXIST exception
raised.
NotificationIRP is
down!

Failed to Connect

Either, the server is
not running, the IOR
is out of date, or
probe cannot reach
remote Server

Cannot proceed.
Shutting down!

The NotificationIRP point
from the Nortel System is not
responding.

Check that the Nortel CNM
system is still running.

Failed to iterate
through resynch
alarms

There was a problem with the
resynchronization process.

Check that the Nortel CNM
system is running correctly.
Check that you have specified the
Resynch property correctly.

Table 7. Error messages (4 of 4)

Error Description Action

Probe for Nortel CNM 21

ProbeWatch messages

Table 8 describes the raw ProbeWatch error messages that the probe generates. For
information about generic ProbeWatch messages, see the IBM Tivoli Netcool/OMNIbus Probe
and Gateway Guide, (SC23-6387).

Table 8. ProbeWatch messages (1 of 3)

ProbeWatch message Description Triggers/causes

Communication failure

- lost connection to
NoticiationIRP

Failed to get
subscripton status

CORBA TIMEOUT
Exception while
trying to get
subscription status
from NotificationIRP

CORBA.OBJECT_NOT_
EXIST Exception: Lost
connection to
NotificationIRP

CORBA.TRANSIENT
Exception: Lost
connection to
NotificationIRP

The probe has failed to get the
subscription status from the
NotificationIRP point.

The Notification service is not
available.

Connection to
NotificationIRP
server has been
established

The probe has successfully
established a connection to the
NotificationIRP point.

The probe has successfully
subscribed to the Notification
service.

Detaching
subscription

The probe is disconnecting from
the NotificationIRP point.

Either the probe has not received
any events for the specified
timeout period, the probe is
shutting down, or the probe has
received a stop signal.

END SYNCHRONIZATION The probe is closing the

synchronization process.

The probe has finished receiving
alarms from the alarm list.

Failed to find IOR
file ior_file_name

The probe could not find the
specified file.

The IRP Manager has not been
set up correctly using the
properties file.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide22

Failed to log in to
the Nortel Security
IRP - incorrect
username/password

Failed to log in to
interface

PermissionDenied

Failed to get IRP
Outline

The probe could not login to the
SecurityIRP file.

Incorrect username and
password given in the properties
file.

Failed to find IOR
file ior_file_name

The probe could not find the
specified file.

The IRP Manager has not been
set up correctly using the
properties file.

Failed to listen for
commands on port
number listening_port

The probe could not open the
socket specified by the port to
listen for commands.

The specified port is in use for
another process.

Failed to connect to
NotificationIRP:
ae.reason. Shutting
down

The probe could not connect to
the NotificationIRP point.

The specified reason has failed
the connection to the

NotificationIRP point.

Going Down The probe is shutting down. The probe has started shutting

down the connection.

Invalid IRPVersion

Failed to get IRP
reference

The probe could not retrieve the
NotificationIRP point.

Incorrect NotificationIRP
name specified in the properties
file.

Inactivity: No events
received for timeout
seconds

The probe has exceeded the
time out period already set.

The probe did not receive events
for the specified period.

NetcoolIRPManager:
Failed to find IOR
file alarmirp_ior

_file

The probe has failed to get the
IOR file specified.

The AlarmirpFile property in the
properties file is incorrectly set.

NetcoolIRPManager:
Failed to find IOR
file notificationirp_

ior_file

The probe has failed to get the
IOR file.

The NotificationirpFile
property in the properties file is
incorrectly set.

Running The probe is successfully

running.

The probe has started
functioning.

START SYNCHRONIZATION The probe is synchronizing the

events.

The probe has started receiving
alarms from the alarm list.

Table 8.

ProbeWatch messages (2 of 3)

ProbeWatch message Description Triggers/causes

Probe for Nortel CNM 23

SYNCHRONIZATION
FAILED

The probe could not get new
alarms.

The probe failed to get the alarm
list, or failed to perform
resynchronization of alarms.

Unable to get events The probe could not get events

from Nortel CNM 3GPP2.

The probe has failed to get
events.

Unexpected fatal
error, failed to
connect

Unexpected fatal
error when connecting
to interface

Unexpected fatal
error while getting
IRP Outline

Unexpected fatal
error when getting
IRP reference from
Entry Point IRP

The probe encountered an
unexpected fatal error.

Contact the IBM support.

Will listen for
commands on port
number listening_port

The probe is listening for
commands on the specified
port.

The specified port is ready to
receive commands.

Table 8. ProbeWatch messages (3 of 3)

ProbeWatch message Description Triggers/causes

Netcool/OMNIbus Probe for Nortel CNM Reference Guide24

25

appnotices.fm December 22, 2007

Appendix A. Notices

This appendix contains the following:

• "Notices" on page 25

• "Trademarks" on page 27

Notices

This information was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in other
countries. Consult your local IBM representative for information on the products and
services currently available in your area. Any reference to an IBM product, program, or
service is not intended to state or imply that only that IBM product, program, or service
may be used. Any functionally equivalent product, program, or service that does not
infringe any IBM intellectual property right may be used instead. However, it is the user's
responsibility to evaluate and verify the operation of any non-IBM product, program, or
service.

IBM may have patents or pending patent applications covering subject matter described in
this document. The furnishing of this document does not grant you any license to these
patents. You can send license inquiries, in writing, to:

IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.

For license inquiries regarding double-byte (DBCS) information, contact the IBM
Intellectual Property Department in your country or send inquiries, in writing, to:

IBM World Trade Asia Corporation
Licensing
2-31 Roppongi 3-chome, Minato-ku
Tokyo 106-0032, Japan

The following paragraph does not apply to the United Kingdom or any other country
where such provisions are inconsistent with local law: INTERNATIONAL BUSINESS

MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT

Netcool/OMNIbus Probe for Nortel CNM Reference Guide26

LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not
allow disclaimer of express or implied warranties in certain transactions, therefore, this
statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are
periodically made to the information herein; these changes will be incorporated in new
editions of the publication. IBM may make improvements and/or changes in the product(s)
and/or the program(s) described in this publication at any time without notice.

Any references in this information to non-IBM Web sites are provided for convenience only
and do not in any manner serve as an endorsement of those Web sites. The materials at
those Web sites are not part of the materials for this IBM product and use of those Web sites
is at your own risk.

IBM may use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you.

Licensees of this program who wish to have information about it for the purpose of
enabling: (i) the exchange of information between independently created programs and
other programs (including this one) and (ii) the mutual use of the information which has
been exchanged, should contact:

IBM Corporation
958/NH04
IBM Centre, St Leonards
601 Pacific Hwy
St Leonards, NSW, 2069
Australia

IBM Corporation
896471/H128B
76 Upper Ground
London SE1 9PZ
United Kingdom

IBM Corporation
JBFA/SOM1
294 Route 100
Somers, NY, 10589-0100
United States of America

Such information may be available, subject to appropriate terms and conditions, including
in some cases, payment of a fee.

The licensed program described in this document and all licensed material available for it
are provided by IBM under terms of the IBM Customer Agreement, IBM International
Program License Agreement or any equivalent agreement between us.

Appendix A. Notices 27

Any performance data contained herein was determined in a controlled environment.
Therefore, the results obtained in other operating environments may vary significantly.
Some measurements may have been made on development-level systems and there is no
guarantee that these measurements will be the same on generally available systems.
Furthermore, some measurements may have been estimated through extrapolation. Actual
results may vary. Users of this document should verify the applicable data for their specific
environment.

Information concerning non-IBM products was obtained from the suppliers of those
products, their published announcements or other publicly available sources. IBM has not
tested those products and cannot confirm the accuracy of performance, compatibility or any
other claims related to non-IBM products. Questions on the capabilities of non-IBM
products should be addressed to the suppliers of those products.

All statements regarding IBM's future direction or intent are subject to change or
withdrawal without notice, and represent goals and objectives only.

This information contains examples of data and reports used in daily business operations.
To illustrate them as completely as possible, the examples include the names of individuals,
companies, brands, and products. All of these names are fictitious and any similarity to the
names and addresses used by an actual business enterprise is entirely coincidental.

Trademarks

The following terms are trademarks of International Business Machines Corporation in the
United States, other countries, or both:

AIX

AIX 5L

Netcool

Intel, Intel Inside (logos), MMX, and Pentium are trademarks of Intel Corporation in the
United States, other countries, or both.

Microsoft, Windows, Windows NT, and the Windows logo are trademarks of Microsoft
Corporation in the United States, other countries, or both.

Java and all Java-based trademarks are trademarks of Sun Microsystems, Inc. in the United
States, other countries, or both.

Linux is a trademark of Linus Torvalds in the United States, other countries, or both.

UNIX is a registered trademark of The Open Group in the United States and other
countries.

Other company, product, or service names may be trademarks or service marks of others.

Netcool/OMNIbus Probe for Nortel CNM Reference Guide28
