IBM NETCOOL 4.3-X User Manual

Tivoli

Document Revision R2E1

Netcool®/Proviso® 4.3-X

IBM

Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide

Notices

This information was developed for products and
services offered in the U.S.A. IBM
products, services, or features discussed in this
document in other countries. Consult your local IBM
representative for information about the products and
services currently available in your area. Any reference to
an IBM product, program, or service is not intended to
state or imply that only that IBM product, program, or
service may be used. Any functionally equivalent
product, program, or service that does not infringe any
IBM intellectual property right may be used instead.
However, it is the user’s responsibility to evaluate and
verify the operation of any non-IBM product, program,
or service.

IBM may have patents or pending patent applications
covering subject matter described in this document. The
furnishing of this document does not give you any
license to these patents. You can send license inquiries,
in writing, to:

IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785 U.S.A.

For license inquiries regarding double-byte (DBCS)
information, contact the IBM Intellectual Property
Department in your country or send inquiries, in writing,
to:

IBM World Trade Asia Corporation
Licensing
2-31 Roppongi 3-chome, Minato-ku
Tokyo 106, Japan

The following paragraph does not apply to the
United Kingdom or any other country where such
provisions are inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES
CORPORATION PROVIDES THIS PUBLICATION
"AS IS" WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A
PART I C U LAR PURPOSE.

Some states do not allow disclaimer of express or
implied warranties in certain transactions, therefore, this
statement might not apply to you.

This information could include technical inaccuracies or
typographical errors. Changes are periodically made to
the information herein; these changes will be

®

may not offer the

incorporated in new editions of the publication. IBM
may make improvements and/or changes in the
product(s) and/or the program(s) described in this
publication at any time without notice.

Any references in this information to non-IBM Web
sites are provided for convenience only and do not in any
manner serve as an endorsement of those Web sites. The
materials at those Web sites are not part of the materials
for this IBM product and use of those Web sites is at
your own risk.

IBM may use or distribute any of the information you
supply in any way it believes appropriate without
incurring any obligation to you.

Licensees of this program who wish to have information
about it for the purpose of enabling: (i) the exchange of
information between independently created programs
and other programs (including this one) and (ii) the
mutual use of the information which has been
exchanged, should contact:

IBM Corporation
2Z4A/101
11400 Burnet Road
Austin, TX 78758
U. S. A.

Such information may be available, subject to
appropriate terms and conditions, including in some
cases payment of a fee.

The licensed program described in this document and all
licensed material available for it are provided by IBM
under terms of the IBM Customer Agreement, IBM
International Program License Agreement or any
equivalent agreement between us.

Any performance data contained herein was determined
in a controlled environment. Therefore, the results
obtained in other operating environments may vary
significantly. Some measurements may have been made
on development-level systems and there is no guarantee
that these measurements will be the same on generally
available systems. Furthermore, some measurement may
have been estimated through extrapolation. Actual
results may vary. Users of this document should verify
the applicable data for their specific environment.

Information concerning non-IBM products was
obtained from the suppliers of those products, their
published announcements or other publicly available
sources. IBM has not tested those products and cannot
confirm the accuracy of performance, compatibility or
any other claims related to non-IBM products.

Questions on the capabilities of non-IBM products
should be addressed to the suppliers of those products.

All statements regarding IBM’s future direction or intent
are subject to change or withdrawal without notice, and
represent goals and objectives only.

This information is for planning purposes only. The
information herein is subject to change before the
products described become available.

This information contains examples of data and reports
used in daily business operations. To illustrate them as
completely as possible, the examples include the names
of individuals, companies, brands, and products. All of
these names are fictitious and any similarity to the names
and addresses used by an actual business enterprise is
entirely coincidental.

COPYRIGHT LICENSE:

This information contains sample application programs
in source language, which illustrate programming

Trademarks

techniques on various operating systems. You may copy,
modify, and distribute these sample programs in any
form without payment to IBM, for the purposes of
developing, using, marketing or distributing application
programs conforming to the application programming
interface for the operating system for which the sample
programs are written. These examples have not been
thoroughly tested under all conditions. IBM, therefore,
cannot guarantee or imply reliability, serviceability, or
function of these programs. You may copy, modify, and
distribute these sample programs in any form without
payment to IBM for the purposes of developing, using,
marketing, or distributing application programs
conforming to IBM's application programming
interfaces.

If you are viewing this information in softcopy form, the
photographs and color illustrations might not appear.

AIX®, DB2®, developerWorks®, eServer, i5/OS®,

®

IBM

, the IBM logo®, IBMLink, iSeries®, Lotus®,
Netcool
Passport Advantage
OS/390
Enterprise Console

®

, Netcool/Proviso®, OMEGAMON®,

®

, OS/400®, Tivoli®, the Tivoli logo®, Tivoli

®

, pSeries®, Rational®, Redbooks®,

®

, WebSphere®, and zSeries® are
trademarks or registered trademarks of International
Business Machines Corporation in the United States,
other countries, or both.

®

Intel

is a registered trademark of Intel Corporation or
its subsidiaries in the United States, other countries, or
both.

Linux is a trademark of Linus Torvalds in the United
States, other countries, or both.

Microsoft

®

, Windows®, Windows NT®, and the
Windows logo are trademarks of Microsoft Corporation
in the United States, other countries, or both.

Java™ and all Java-based
trademarks and logos are
trademarks or registered
trademarks of Sun Microsystems,
Inc. in the United States, other
countries, or both.

UNIX® is a registered trademark of The Open Group in
the United States and other countries.

Other company, product, and service names may be
trademarks or service marks of others.

© Copyright IBM Corp. 2009.

US Government Users Restricted Rights — Use,
duplication or disclosure restricted by GSA ADP
Schedule Contract with IBM Corp.

Contents

Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

How is the Data Collected? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Inventory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Collection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

How is the Data Processed and Loaded into the Database? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

CME Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

How is the Data Reported? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 2: Supported Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Report Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Reporter Sets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Reporter Set Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Ethernet Port Drops and Discards Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Ethernet Port Drops and Discards Summary Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Ethernet Port Drops and Discards Summary Resource. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Ethernet Port Jitter Probe Egress Negative Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Ethernet Port Jitter Probe Egress Positive Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Ethernet Port Jitter Probe Ingress Negative Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Ethernet Port Jitter Probe Ingress Positive Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Ethernet Port Jitter Probe Summary Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Ethernet Port Jitter Probe Summary Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Ethernet Port Latency Probe Delay Egress Oneway Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Ethernet Port Latency Probe Delay Ingress Oneway Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Ethernet Port Latency Probe Delay Round Trip Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Ethernet Port Latency Probe Delay Summary Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Ethernet Port Latency Probe Delay Summary Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Ethernet Port Latency Probe Error Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X v

Ethernet Port Latency Probe Loss Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Ethernet Port Latency Probe Sequence Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Ethernet Port Latency Probe Summary Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Ethernet Port Latency Probe Summary Resource. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Ethernet Port Optical Environment Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Ethernet Port Optical Environment Summary Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Ethernet Port Optical Environment Summary Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Ethernet Port Throughput Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Ethernet Port Throughput Summary Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Ethernet Port Throughput Summary Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Metro Ethernet Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

WAN Uplink Optical Environment Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

WAN Uplink Optical Environment Summary Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

WAN Uplink Optical Environment Summary Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

WAN Uplink Port Throughput Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

WAN Uplink Port Throughput Summary Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

WAN Uplink Port Throughput Summary Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Chapter 3: Devices and Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Summary of Device Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Supported MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Chapter 4: Element and Sub-Element Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Adva Optical Metro Ethernet Device Element Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Adva Optical Metro Ethernet Device Sub-Element Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Element.NAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Element.STATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

EsaProbeHistoryIndex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

EsaProbeId . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

LanPort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

LanPortHistoryIndex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

LanPortStatsIndex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

MECustomerName. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

MEEsa_DestinationIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

vi Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

MEEsa_ProbePacketInterval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

MEEsa_ProbePackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

MEEsa_ProbePacketSize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

MEEsa_ProbePortId . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

MEEsa_ProbePriority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

MEEsa_ProbeStorageType . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

MEEsa_Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

MEEsa_ServiceType. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

MEEsa_SourceIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

MEEsa_VlanId . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

MEEsa_VlanPriority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

MESiteName. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

MEUNI_CBS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

MEUNI_CIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

MEUNI_EBS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

MEUNI_EgressCBS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

MEUNI_EgressCIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

MEUNI_EgressEBS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

MEUNI_EgressEIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

MEUNI_EIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

MEUNI_InterfaceType . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

MEUNI_PortID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

MEUNI_PortMode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

MEUNI_PortSpeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

MEUNI_Priority. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

MEUNI_PrioVID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

MEUNI_TaggedFrames. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

MEUNI_VlanId . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

MEVendorName. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

MEWAN_InterfaceType . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

MEWAN_PortId . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

STATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

WanPort. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

WanPortHistoryIndex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

WanPortStatsIndex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X vii

Chapter 5: Sub-Element Grouping Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

NOC Reporting Grouping Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Sub-Element Collect Grouping Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Chapter 6: Defined Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Adva Optical Metro Ethernet Technology Pack Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Sub-Element Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Tables of Sub-Element Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Chapter 7: SNMP Collection Formulas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Data Collection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Formulas and Metrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Formula Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Egress Bitrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Egress Broadcast Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Egress Broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Egress Bytes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Egress DE Dropped Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Egress DE Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Egress Delay Variance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Egress Discarded Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Egress Erred Packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Egress Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Egress Loss Percentage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Egress Lost Packets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Egress Multicast Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Egress Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Egress Negative Jitter Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Egress Negative Jitter Minimum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Egress Negative Jitter Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Egress Negative Jitter Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Egress Negative Jitter Variance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Egress Oneway Delay Average. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

viii Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Egress Oneway Delay Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Egress Oneway Delay Minimum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Egress Oneway Delay Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Egress Packets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Egress Positive Jitter Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Egress Positive Jitter Minimum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Egress Positive Jitter Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Egress Positive Jitter Sum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Egress Positive Jitter Variance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Egress Sync Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Egress Tail Drop (Frames). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Egress Throughput (bps) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Egress Unicast Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Egress Unicast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Ingress Bitrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Ingress DE Dropped Frames. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Ingress DE Frames. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Ingress Delay Variance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Ingress Discarded Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Ingress Erred Packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Ingress Loss Percentage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Ingress Lost Packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Ingress Negative Jitter Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Ingress Negative Jitter Minimum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Ingress Negative Jitter Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Ingress Negative Jitter Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Ingress Negative Jitter Variance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

Ingress Oneway Delay Average . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Ingress Oneway Delay Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Ingress Oneway Delay Minimum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

Ingress Oneway Delay Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

Ingress Packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Ingress Positive Jitter Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Ingress Positive Jitter Minimum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164

Ingress Positive Jitter Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Ingress Positive Jitter Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X ix

Ingress Positive Jitter Variance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Ingress Sync Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

Ingress Tail Drop (Frames). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Ingress Throughput (bps). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Laser Bias Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Laser Bias Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Late Packets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Lost Packets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Out of Sequence Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Received Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Received Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Round Trip Delay Average . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Round Trip Delay Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

Round Trip Delay Minimum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

Round Trip Delay Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Round Trip Delay Variance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

Sequence Gaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Transmitted Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Transmitted Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Chapter 8: Discovery Formulas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Netcool/Proviso Discovery Formula Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Discovery Formula Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

The Results Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

ESAProbes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

LanPort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

WanPort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Appendix A: Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Configure the Technology Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Other Tasks and Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Verifying Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

x Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Preface

This manual describes the Netcool/Proviso Adva Optical Metro Ethernet Technology Pack, focusing on the
Adva Optical Metro Ethernet environment. Specifically, the manual describes the reports for displaying
information about the devices and technologies that operate in the Adva Optical Metro Ethernet environment.
The manual also describes the data collection model, properties, resources, collection formulas, and metrics that
the Adva Optical Metro Ethernet Technology Pack provides to create the associated reporter sets.

Audience

The audiences for this manual are the network administration engineers at IBM customer sites who will install,
configure, and use the Adva Optical Metro Ethernet Technology Pack as part of their Netcool/Proviso
installation. IBM Professional Services engineers may also find this manual useful.

To install and use the Adva Optical Metro Ethernet Technology Pack, you should have a working knowledge of
the following subjects:

• Netcool/Proviso DataMart

• TCP/IP networks

• Telecom network management

• Administration of the operating system

The audiences should also be familiar with the specific technology that the Adva Optical Metro Ethernet
Technology Pack deals with, in this case Adva Optical Metro Ethernet.

Organization

This guide is organized as follows:

• Chapter 1, Introduction

Provides a general introduction to technology packs.

• Chapter 2, Supported Reports

Provides information about the reports that the Adva Optical Metro Ethernet Technology Pack provides for
each device operating in the Adva Optical Metro Ethernet environment.

• Chapter 3, Devices and Services

Describes the devices and services that the Adva Optical Metro Ethernet Technology Pack supports.

• Chapter 4, Element and Sub-Element Properties

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X xi

Preface

Describes the properties that the Adva Optical Metro Ethernet Technology Pack discovers during the
inventory process.

• Chapter 5, Sub-Element Grouping Rules

Describes the sub-element collection grouping rules and the NOC reporting grouping rules that the Adva
Optical Metro Ethernet Technology Pack defines.

• Chapter 6, Defined Resources

Provides information about the elements and sub-elements that the Adva Optical Metro Ethernet
Technology Pack defines in the Proviso database.

• Chapter 7, SNMP Collection Formulas

Provides information about the SNMP collection formulas that the Adva Optical Metro Ethernet
Technology Pack provides for devices operating in the Adva Optical Metro Ethernet environment that use
an SNMP Agent.

• Chapter 8, Discovery Formulas

Provides information about the Discovery formulas that the Adva Optical Metro Ethernet Technology Pack
provides for devices operating in the Adva Optical Metro Ethernet environment.

• Appendix A, Configuration

Describes how to configure the Adva Optical Metro Ethernet Technology Pack.

The Netcool/Proviso Product Suite

Netcool/Proviso is made up of the following components:

• Netcool/Proviso DataMart is a set of management, configuration and troubleshooting GUIs that the
Netcool/Proviso System Administrator uses to define policies and configuration, as well as verify and
troubleshoot operations.

• Netcool/Proviso DataLoad provides flexible, distributed data collection and data import of SNMP and
non-SNMP data to a centralized database.

• Netcool/Proviso DataChannel aggregates the data collected through Netcool/Proviso DataLoad for use
by the Netcool/Proviso DataView reporting functions. It also processes on-line calculations and detects real­time threshold violations.

• Netcool/Proviso DataView is a reliable application server for on-demand, web-based network reports.

• Netcool/Proviso Technology Packs extend the Netcool/Proviso system with service-ready reports for
network operations, business development, and customer viewing.

The following figure shows the different Netcool/Proviso modules.

xii Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Figure 1: Netcool/Proviso Modules

DataLoad
collects
network data.

DataChannel
computes
aggregations
and stores data
in DataMart.

Netcool/Proviso Documentation

DataMart
provides data
management
and applications.

Preface

DataView
produces and
manages reports.

Netcool/Proviso documentation consists of the following:

• release notes

• configuration recommendations

•user guides

• technical notes

• online help

The documentation is available for viewing and downloading on the infocenter at:

http://publib.boulder.ibm.com/infocenter/tivihelp/v8r1/index.jsp?topic=/com.ibm.netcool_proviso.doc/welcome.htm

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X xiii

Preface

xiv Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 1: Introduction

This chapter discusses the following topics:

Topic P a g e

Overview 1

How is the Data Collected? 1

How is the Data Processed and Loaded into the Database? 2

How is the Data Reported? 3

Overview

Netcool/Proviso Technology Packs are individually installed modules that contain discovery, grouping,
collection, and reporting instructions created by Technology Pack developers or Professional Services personnel
for a specific network technology or network equipment provider, such as Adva Optical Metro Ethernet.

Once installed, a Technology Pack “programs” Netcool/Proviso to inventory and group specific network
resources, perform mathematical calculations on raw or aggregated data streams collected from these resources,
and produce key performance monitoring metrics that are stored on the Netcool/Proviso database. Reporter sets
designed for each Technology Pack query the database for this information and display the results on a web portal
in the form of specialized report tables, graphs, and charts.

This chapter provides an overview of how Technology Packs work with Netcool/Proviso to collect, process, load,
and report data from a network environment.

How is the Data Collected?

Inventory

After a Netcool/Proviso Technology Pack has been installed, an inventory process must be run so that the
Technology Pack’s target network resources can be identified and modeled within Netcool/Proviso as sub­elements. Sub-elements must be created before data from any network resource can be collected, processed, and
stored in the database.

How sub-elements are discovered depends on whether the target resources are SNMP resources or non-SNMP
resources:

• For SNMP network resources, a Technology Pack provides a discovery formula. Discovery formulas are used
to evaluate network resources, determine which resources become sub-elements, and set values for items
defined as properties in the formula. Once all the sub-elements have been discovered and created in the
database, the inventory process organizes the sub-elements according to the grouping rules provided by a

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 1

Chapter 1: Introduction

Technology Pack. The grouping rules use the properties and values defined within inventory formulas or
adaptor design files to filter the sub-elements into their appropriate collection or reporting groups.

• For non-SNMP network resources, a Technology Pack provides a Bulk Adaptor Design File. Bulk Adaptor

Design Files define how data fields that reside in files generated by network resources are used to create sub­elements and set values for items defined as properties.

During the database synchronization phase of the inventory process, the list of discovered sub-elements is
compared to what exists in the database. Newly discovered sub-elements are assigned a resource identifier (RID)
and timestamp, and the database uses both items to create a new entry for the sub-element to reflect the known
state of the network inventory.

Collection

Following the completion of the inventory process, Netcool/Proviso is ready to collect performance data for a
Technology Pack’s target network resources. A Technology Pack provides Netcool/Proviso with collection
formulas that instruct a DataLoad collector residing in a DataChannel to collect specific types of performance
data against a particular sub-element.

The types of collection formulas applied to the data depend on whether the sub-element is an SNMP resource
or non-SNMP resource:

• For SNMP network resources, a Technology Pack provides SNMP collection formulas. SNMP collection

formulas instruct the SNMP Collector to take the data gathered during a specified collection interval,
perform some mathematical operation on the data, and output the result as a performance metric.

• For non-SNMP network resources, a Technology Pack provides Bulk collection formulas. A Bulk collection

formula, unlike an SNMP collection formula, has no executable instructions. A Bulk collection formula
consists of a metric name that is mapped by the Bulk Adaptor Design File to a statistic that resides in the
input file generated by a network resource.

Either type of collection formula outputs a metric and corresponding unique metric identifier (MID) that are
passed along the DataChannel to the Complex Metric Engine for processing.

How is the Data Processed and Loaded into the Database?

The Complex Metric Engine (CME) is a component in the DataChannel that performs calculations on data
gathered by the SNMP or Bulk collectors deployed in a network. These calculations include the following:

• Pre-defined formulas that are provided by a Technology Pack

• User-defined formulas created using the CME Formula API

• Time aggregations for sub-elements

In addition to performing calculations on the data stream in the DataChannel, the CME also buffers and sorts
metric records according to their RIDs and MIDs to optimize how the data and metrics are stored in the database.

2 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 1: Introduction

CME Operation

The CME is designed to work with data that is gathered over the space of one hour. Within that hour, there are
several distinct phases that characterize the operation of the CME:

• Loading Phase

• Building Phase

• Processing Phase

• Output Phase

Loading Phase

During the beginning of each hour, the CME creates a new network configuration model based on the inventory
structure that exists in the database at that time. This model is used as a snapshot of the network environment
and serves as the basis for all metric processing for the entire duration of the hour. At the end of the hour, the
CME polls the database for any changes that have been made to the inventory and creates a new network
configuration model for the next hour.

As the CME reloads its configuration hourly, any metrics produced by sub-elements following the last polling
period are rejected by the CME until the beginning of the next hour.

Building Phase

Once the current configuration model has been built, the CME creates a table of sub-elements and metrics that
are expected for the current hour. The CME uses the RIDs and MIDs to build the table and determine which
metrics should be arriving from the collectors. The table also specifies how resources are related, and determines
if there are any CME formulas that must be applied to a sub-element’s metrics once the data is gathered.

Processing Phase

Whenever new data arrives at the CME, it is evaluated and stored in the appropriate table location, along with any
Resource Aggregation information. Once the input and processing dependencies for a metric in the table have
been met, the CME processes the metrics and stores the data until the end of the hour.

Output Phase

At the end of the current hour, the CME outputs everything in memory to the Hourly and Daily Loaders. The
data sent to the database loaders includes the sorted data for the current hour, and resource and group
aggregations for each of the processing periods up to the current time. The Hourly Loader computes group and
resource aggregations, while the Daily Loader creates metric statistics and inserts the data into the database.

How is the Data Reported?

The data collected, processed, and stored in the database by Netcool/Proviso is organized and output for
customers using reporter sets that are designed by developers and Professional Services personnel for a specific
Technology Pack.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 3

Chapter 1: Introduction

A Technology Pack reporter set is a related group of reports that provide performance information on a specific
set of devices or resources that exist in a network. Each report consists of a series of queries that retrieve related
sub-elements and their corresponding metrics from the database using the RIDs and MIDs assigned during the
inventory and collection processes. The retrieved results are then organized within the report and are displayed
on a web portal in the form of tables, graphs, and charts.

A Technology Pack provides a variety of reports and charts, including:

• Resource Summary Reports (RSTs) (sometimes referred to as Resource Summary Tables) aggregate data

across time for an individual sub-element and define the statistics that are relevant for a measure of its
network performance.

• Group Summary Reports (GSTs) (sometimes referred to as Group Summary Tables) aggregate data across

both time and sub-elements, and define the statistics that are relevant for a measure of network performance
for a group of resources.

• Detail Charts (DCs) display raw data for a metric that has been aggregated for an individual sub-element over

a particular period of time.

• Dashboards display a series of abbreviated tables and charts that provide an overall summary of the metrics

collected for the target network resource supported by the Technology Pack.

• Timeseries charts present time series information, where the x axis is time and the y axis is the data value.

• TopN reports list the N highest values during a specified time range for a specific metric.

• Resource Distribution charts (often referred to as pie charts) show the distribution of resources across

specific ranges. Typically, a legend for the Resource Distribution chart appears in the report.

• Resource Over Threshold Tables (RTTs) display a list of resources that have violated their threshold for a

specific metric. Typically, users navigate to an RTT from a Group Summary Table (GST), using the threshold
overflow cell navigation link.

• Ratio charts show the relationship of a single metric among different resources or a single resource among

different metrics.

4 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 2: Supported Reports

This chapter discusses the following topics:

Topic P a g e

Overview 5

Report Reference 5

Reporter Sets 6

Overview

The Adva Optical Metro Ethernet Technology Pack supplies a set of reports suitable for displaying information
about the devices and activity associated with the Adva Optical Metro Ethernet environment.

Reports contain metrics that are generated by the formulas that this technology pack provides. Metric names are
the same as the names of the formulas that generate them. For information about a metric that is listed for a
particular report, see the description of the associated formula in the collection formula chapter of this guide.

This chapter includes information to help you navigate to a particular report on the DataView portal. This
navigation path is the same as the path where the report has been deployed through the DataMart Resource
Editor. Note, however, that some reports are not explicitly deployed on the portal navigation path. You can
display such a report by "drilling down" to it from other reports.

For information about understanding report types, creating reports, configuring reports, viewing and working
with reports, and deploying reports, see the Netcool/Proviso DataView User’s Guide. This Technology Pack User’s
Guide assumes an understanding of the report-related topics discussed in the Netcool/Proviso DataView User’s
Guide.

Report Reference

The following pages provide a reference of the reports that this technology pack provides. The reference pages
have the following sections:

• Description. Describes the purpose and content of the report.

• Reporter Set. The reporter set that the report belongs to.

• Tables and Charts. The types of tables and charts in this report. For each listed table or chart type, this
section shows how many of the given type that the technology pack implements out of the total that the
stylesheet provides. For example:

Tables: Resource Summary Table (1 of 2 implemented)

Charts: Resource Distribution Chart (2 of 2 implemented)

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 5

Chapter 2: Supported Reports

In cases where the stylesheet information is not available for a given report, only the number of tables or
charts actually implemented is shown.

• Metrics Used in Reports. The collection formulas that provide metrics for the report.

• Navigation Path. The navigation path to use to select the report on the DataView portal.

Some reports are not accessed directly from a DataView portal navigation path. You can access such reports
by drilling down from another report. If you want to make the report available on the navigation path, you
can use the DataMart Resource Editor to deploy it.

• Drills Down To. One or more reports that can be accessed by drilling down from a table or chart in the

report.

• Drilled Down From. One or more reports from which you can drill down to reach the report.

Reporter Sets

A reporter set contains a group of reporters that together provide information about a specific technology or a
vendor device. Technology pack developers use the Reporter Set Wizard to choose the type of template upon
which to base the reporter set.

Specifically, the Adva Optical Metro Ethernet Technology Pack uses reporter sets as the framework for defining
the reports that display in meaningful ways on a WWW portal the collected information about the devices and
technologies that operate in the Adva Optical Metro Ethernet environment.

See the Netcool/Proviso DataView User’s Guide for more information about reporter sets and the Reporter Set
Wizard.

Reporter Set Tree

This technology pack provides the reporter sets listed below. The list presents the reporter sets as they appear in
the DataView Navigator tree structure:

AP Adva Optical Metro Ethernet
...Port

......UNI

......WAN

...ESA Probe
...Metro Ethernet Dashboard

6 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Reports

This technology pack provides the following reports:

Ethernet Port Drops and Discards Details

Ethernet Port Drops and Discards Summary Group

Ethernet Port Drops and Discards Summary Resource

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Jitter Probe Summary Group

Ethernet Port Jitter Probe Summary Resource

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Chapter 2: Supported Reports

Ethernet Port Latency Probe Delay Summary Group

Ethernet Port Latency Probe Delay Summary Resource

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Ethernet Port Latency Probe Summary Group

Ethernet Port Latency Probe Summary Resource

Ethernet Port Optical Environment Details

Ethernet Port Optical Environment Summary Group

Ethernet Port Optical Environment Summary Resource

Ethernet Port Throughput Details

Ethernet Port Throughput Summary Group

Ethernet Port Throughput Summary Resource

Metro Ethernet Overview

WAN Uplink Optical Environment Details

WAN Uplink Optical Environment Summary Group

WAN Uplink Optical Environment Summary Resource

WAN Uplink Port Throughput Details

WAN Uplink Port Throughput Summary Group

WAN Uplink Port Throughput Summary Resource

The reports in this technology pack are described on the following pages.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 7

Chapter 2: Supported Reports

Ethernet Port Drops and Discards Details

Description

AP Adva Optical Metro Ethernet - Per UNI Port QoS (DE Dropped) - Detail Chart

Reporter Set

UNI

Tables and Charts

Charts: Resource Time Series Chart (8 of 8 implemented) - Real-Time support

Metrics Used in Report

Egress DE Dropped Frames

Egress DE Frames

Egress Discarded Frames

Egress Tail Drop (Frames)

Ingress DE Dropped Frames

Ingress DE Frames

Ingress Discarded Frames

Ingress Tail Drop (Frames)

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Drops and Discards Summary Resource

8 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Drops and Discards Summary Group

Description

AP Adva Optical Metro Ethernet - Per UNI Port QoS Summary - GST

Reporter Set

UNI

Tables and Charts

Tables: Group Summary Table (2 of 2 implemented)

Charts: Resource Distribution Chart (0 of 4 implemented)

Metrics Used in Report

Egress DE Dropped Frames

Chapter 2: Supported Reports

Egress DE Frames

Egress Discarded Frames

Egress Tail Drop (Frames)

Ingress DE Dropped Frames

Ingress DE Frames

Ingress Discarded Frames

Ingress Tail Drop (Frames)

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > Ethernet Port

Drills Down To

Ethernet Port Drops and Discards Summary Resource

Drilled Down From

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 9

Chapter 2: Supported Reports

Ethernet Port Drops and Discards Summary Resource

Description

AP Adva Optical Metro Ethernet - Per UNI Port QoS (DE Frames) Summary - RST1

Reporter Set

UNI

Tables and Charts

Tables: Resource Summary Table (2 of 1 implemented)

Charts: Resource Distribution Chart (0 of 2 implemented)

Metrics Used in Report

Egress DE Dropped Frames

Egress DE Frames

Egress Discarded Frames

Egress Tail Drop (Frames)

Ingress DE Dropped Frames

Ingress DE Frames

Ingress Discarded Frames

Ingress Tail Drop (Frames)

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > Ethernet Port > %(Element.NAME)

Drills Down To

Ethernet Port Drops and Discards Details

Drilled Down From

Ethernet Port Drops and Discards Summary Group

10 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Jitter Probe Egress Negative Details

Description

AP Adva Optical Metro Ethernet - Port Jitter Probe Egress Negative - Detail Chart.

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Egress Negative Jitter Maximum

Chapter 2: Supported Reports

Egress Negative Jitter Minimum

Egress Negative Jitter Number

Egress Negative Jitter Sum

Egress Negative Jitter Variance

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Jitter Probe Summary Resource

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 11

Chapter 2: Supported Reports

Ethernet Port Jitter Probe Egress Positive Details

Description

AP Adva Optical Metro Ethernet - Port Jitter Probe Egress Positive - Detail Chart.

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Egress Positive Jitter Maximum

Egress Positive Jitter Minimum

Egress Positive Jitter Number

Egress Positive Jitter Sum

Egress Positive Jitter Variance

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Jitter Probe Summary Resource

12 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Jitter Probe Ingress Negative Details

Description

AP Adva Optical Metro Ethernet - Port Jitter Probe Ingress Negative - Detail Chart.

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Ingress Negative Jitter Maximum

Chapter 2: Supported Reports

Ingress Negative Jitter Minimum

Ingress Negative Jitter Number

Ingress Negative Jitter Sum

Ingress Negative Jitter Variance

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Jitter Probe Summary Resource

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 13

Chapter 2: Supported Reports

Ethernet Port Jitter Probe Ingress Positive Details

Description

AP Adva Optical Metro Ethernet - Port Jitter Probe Ingress Positive - Detail Chart.

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Ingress Positive Jitter Maximum

Ingress Positive Jitter Minimum

Ingress Positive Jitter Number

Ingress Positive Jitter Sum

Ingress Positive Jitter Variance

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Jitter Probe Summary Resource

14 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Jitter Probe Summary Group

Description

AP Adva Optical Metro Ethernet - Port Jitter Probe Summary - GST.

Reporter Set

ESA Probe

Tables and Charts

Tables: GroupSummary (4 implemented)

Metrics Used in Report

Egress Negative Jitter Maximum

Chapter 2: Supported Reports

Egress Negative Jitter Minimum

Egress Negative Jitter Number

Egress Negative Jitter Sum

Egress Negative Jitter Variance

Egress Positive Jitter Maximum

Egress Positive Jitter Minimum

Egress Positive Jitter Number

Egress Positive Jitter Sum

Egress Positive Jitter Variance

Ingress Negative Jitter Maximum

Ingress Negative Jitter Minimum

Ingress Negative Jitter Number

Ingress Negative Jitter Sum

Ingress Negative Jitter Variance

Ingress Positive Jitter Maximum

Ingress Positive Jitter Minimum

Ingress Positive Jitter Number

Ingress Positive Jitter Sum

Ingress Positive Jitter Variance

Navigation Path

Navigation path on the DataView portal:

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 15

Chapter 2: Supported Reports

NOC Reporting > Adva Optical Metro Ethernet > ESA Probes

Drills Down To

Ethernet Port Jitter Probe Summary Resource

Drilled Down From

None.

16 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Jitter Probe Summary Resource

Description

AP Adva Optical Metro Ethernet - Port Jitter Probe Summary - RST.

Reporter Set

ESA Probe

Tables and Charts

Tables: ResSummary (4 implemented)

Metrics Used in Report

Egress Negative Jitter Maximum

Chapter 2: Supported Reports

Egress Negative Jitter Minimum

Egress Negative Jitter Number

Egress Negative Jitter Sum

Egress Negative Jitter Variance

Egress Positive Jitter Maximum

Egress Positive Jitter Minimum

Egress Positive Jitter Number

Egress Positive Jitter Sum

Egress Positive Jitter Variance

Ingress Negative Jitter Maximum

Ingress Negative Jitter Minimum

Ingress Negative Jitter Number

Ingress Negative Jitter Sum

Ingress Negative Jitter Variance

Ingress Positive Jitter Maximum

Ingress Positive Jitter Minimum

Ingress Positive Jitter Number

Ingress Positive Jitter Sum

Ingress Positive Jitter Variance

Navigation Path

Navigation path on the DataView portal:

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 17

Chapter 2: Supported Reports

NOC Reporting > Adva Optical Metro Ethernet > ESA Probes > %(Element.NAME)

Drills Down To

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Drilled Down From

Ethernet Port Jitter Probe Summary Group

18 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 2: Supported Reports

Ethernet Port Latency Probe Delay Egress Oneway Details

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Egress Oneway Delay - Detail Chart

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Egress Delay Variance

Egress Oneway Delay Average

Egress Oneway Delay Maximum

Egress Oneway Delay Minimum

Egress Oneway Delay Sum

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Latency Probe Delay Summary Resource

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 19

Chapter 2: Supported Reports

Ethernet Port Latency Probe Delay Ingress Oneway Details

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Ingress Oneway Delay - Detail Chart

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Ingress Delay Variance

Ingress Oneway Delay Average

Ingress Oneway Delay Maximum

Ingress Oneway Delay Minimum

Ingress Oneway Delay Sum

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Latency Probe Delay Summary Resource

20 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Latency Probe Delay Round Trip Details

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Round Trip Delay - Detail Chart

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (5 of 9 implemented) - Real-Time support

Metrics Used in Report

Round Trip Delay Average

Chapter 2: Supported Reports

Round Trip Delay Maximum

Round Trip Delay Minimum

Round Trip Delay Sum

Round Trip Delay Variance

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Latency Probe Delay Summary Resource

Metro Ethernet Overview

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 21

Chapter 2: Supported Reports

Ethernet Port Latency Probe Delay Summary Group

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Delay Summary - GST

Reporter Set

ESA Probe

Tables and Charts

Tables: GroupSummary (3 implemented)

Metrics Used in Report

Egress Delay Variance

Egress Oneway Delay Average

Egress Oneway Delay Maximum

Egress Oneway Delay Minimum

Egress Oneway Delay Sum

Ingress Delay Variance

Ingress Oneway Delay Average

Ingress Oneway Delay Maximum

Ingress Oneway Delay Minimum

Ingress Oneway Delay Sum

Round Trip Delay Average

Round Trip Delay Maximum

Round Trip Delay Minimum

Round Trip Delay Sum

Round Trip Delay Variance

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > ESA Probes

Drills Down To

Ethernet Port Latency Probe Delay Summary Resource

22 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Drilled Down From

None.

Chapter 2: Supported Reports

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 23

Chapter 2: Supported Reports

Ethernet Port Latency Probe Delay Summary Resource

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Delay Summary - RST

Reporter Set

ESA Probe

Tables and Charts

Tables: ResSummary (3 implemented)

Metrics Used in Report

Egress Delay Variance

Egress Oneway Delay Average

Egress Oneway Delay Maximum

Egress Oneway Delay Minimum

Egress Oneway Delay Sum

Ingress Delay Variance

Ingress Oneway Delay Average

Ingress Oneway Delay Maximum

Ingress Oneway Delay Minimum

Ingress Oneway Delay Sum

Round Trip Delay Average

Round Trip Delay Maximum

Round Trip Delay Minimum

Round Trip Delay Sum

Round Trip Delay Variance

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > ESA Probes > %(Element.NAME)

Drills Down To

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

24 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Latency Probe Delay Round Trip Details

Drilled Down From

Ethernet Port Latency Probe Delay Summary Group

Chapter 2: Supported Reports

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 25

Chapter 2: Supported Reports

Ethernet Port Latency Probe Error Details

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Error - Detail Chart

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (4 of 8 implemented) - Real-Time support

Metrics Used in Report

Egress Erred Packets

Egress Sync Errors

Ingress Erred Packets

Ingress Sync Errors

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Latency Probe Summary Resource

26 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Latency Probe Loss Details

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Loss - Detail Chart

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (6 of 8 implemented) - Real-Time support

Metrics Used in Report

Egress Loss Percentage

Chapter 2: Supported Reports

Egress Lost Packets

Egress Packets

Ingress Loss Percentage

Ingress Lost Packets

Ingress Packets

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Latency Probe Summary Resource

Metro Ethernet Overview

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 27

Chapter 2: Supported Reports

Ethernet Port Latency Probe Sequence Details

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Sequence - Detail Chart

Reporter Set

ESA Probe

Tables and Charts

Charts: Resource Time Series Chart (4 of 8 implemented) - Real-Time support

Metrics Used in Report

Late Packets

Lost Packets

Out of Sequence Errors

Sequence Gaps

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Latency Probe Summary Resource

28 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Latency Probe Summary Group

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Summary - GST

Reporter Set

ESA Probe

Tables and Charts

Tables: GroupSummary (3 implemented)

Metrics Used in Report

Egress Erred Packets

Chapter 2: Supported Reports

Egress Loss Percentage

Egress Lost Packets

Egress Packets

Egress Sync Errors

Ingress Erred Packets

Ingress Loss Percentage

Ingress Lost Packets

Ingress Packets

Ingress Sync Errors

Late Packets

Lost Packets

Out of Sequence Errors

Sequence Gaps

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > ESA Probes

Drills Down To

Ethernet Port Latency Probe Summary Resource

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 29

Chapter 2: Supported Reports

Drilled Down From

None.

30 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Latency Probe Summary Resource

Description

AP Adva Optical Metro Ethernet - Port Latency Probe Summary - RST

Reporter Set

ESA Probe

Tables and Charts

Tables: ResSummary (3 implemented)

Metrics Used in Report

Egress Erred Packets

Chapter 2: Supported Reports

Egress Loss Percentage

Egress Lost Packets

Egress Packets

Egress Sync Errors

Ingress Erred Packets

Ingress Loss Percentage

Ingress Lost Packets

Ingress Packets

Ingress Sync Errors

Late Packets

Lost Packets

Out of Sequence Errors

Sequence Gaps

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > ESA Probes > %(Element.NAME)

Drills Down To

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 31

Chapter 2: Supported Reports

Drilled Down From

Ethernet Port Latency Probe Summary Group

32 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Optical Environment Details

Description

AP Adva Optical Metro Ethernet - Per UNI Port Optical Environment - Detail Chart

Reporter Set

UNI

Tables and Charts

Charts: Resource Time Series Chart (3 of 9 implemented) - Real-Time support

Metrics Used in Report

Laser Bias Current

Chapter 2: Supported Reports

Received Power

Transmitted Power

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Optical Environment Summary Resource

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 33

Chapter 2: Supported Reports

Ethernet Port Optical Environment Summary Group

Description

AP Adva Optical Metro Ethernet - Per UNI Port Optical Environment - GST

Reporter Set

UNI

Tables and Charts

Tables: Group Summary Table (1 of 2 implemented)

Charts: Resource Distribution Chart (0 of 4 implemented)

Metrics Used in Report

Laser Bias Current

Received Power

Transmitted Power

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > Ethernet Port

Drills Down To

Ethernet Port Optical Environment Summary Resource

Drilled Down From

None.

34 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 2: Supported Reports

Ethernet Port Optical Environment Summary Resource

Description

AP Adva Optical Metro Ethernet - Per UNI Port Optical Environment

Reporter Set

UNI

Tables and Charts

Tables: Resource Summary Table (1 of 1 implemented)

Charts: Resource Distribution Chart (0 of 2 implemented)

Metrics Used in Report

Laser Bias Current

Received Power

Transmitted Power

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > Ethernet Port > %(Element.NAME)

Drills Down To

Ethernet Port Optical Environment Details

Drilled Down From

Ethernet Port Optical Environment Summary Group

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 35

Chapter 2: Supported Reports

Ethernet Port Throughput Details

Description

AP Adva Optical Metro Ethernet - Per UNI Port Throughput - Detail Chart

Reporter Set

UNI

Tables and Charts

Charts: Resource Time Series Chart (6 of 8 implemented) - Real-Time support

Metrics Used in Report

Egress Broadcast Frames

Egress Frames

Egress Multicast Frames

Egress Throughput (bps)

Egress Unicast Frames

Ingress Throughput (bps)

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

Ethernet Port Throughput Summary Resource

Metro Ethernet Overview

36 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Ethernet Port Throughput Summary Group

Description

AP Adva Optical Metro Ethernet - Port Throughput Summary - GST

Reporter Set

UNI

Tables and Charts

Tables: Group Summary Table (1 of 2 implemented)

Charts: Resource Distribution Chart (0 of 4 implemented)

Metrics Used in Report

Egress Broadcast Frames

Chapter 2: Supported Reports

Egress Frames

Egress Multicast Frames

Egress Throughput (bps)

Egress Unicast Frames

Ingress Throughput (bps)

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > Ethernet Port

Drills Down To

Ethernet Port Throughput Summary Resource

Drilled Down From

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 37

Chapter 2: Supported Reports

Ethernet Port Throughput Summary Resource

Description

AP Adva Optical Metro Ethernet - Per UNI Port Throughput Summary

Reporter Set

UNI

Tables and Charts

Tables: Resource Summary Table (1 of 1 implemented)

Charts: Resource Distribution Chart (0 of 2 implemented)

Metrics Used in Report

Egress Broadcast Frames

Egress Frames

Egress Multicast Frames

Egress Throughput (bps)

Egress Unicast Frames

Ingress Throughput (bps)

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > Ethernet Port > %(Element.NAME)

Drills Down To

Ethernet Port Throughput Details

Drilled Down From

Ethernet Port Throughput Summary Group

38 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Metro Ethernet Overview

Description

AP Adva Optical Metro Ethernet - Dashboard

Reporter Set

Metro Ethernet Dashboard

Tables and Charts

Tables: TopN (5 of 9 implemented)

Charts: TopN (5 of 9 implemented)

Metrics Used in Report

Egress Loss Percentage

Chapter 2: Supported Reports

Egress Throughput (bps)

Ingress Loss Percentage

Ingress Throughput (bps)

Round Trip Delay Average

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet

Drills Down To

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Throughput Details

Drilled Down From

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 39

Chapter 2: Supported Reports

WAN Uplink Optical Environment Details

Description

AP Adva Optical Metro Ethernet - Uplink (Gig-E) Optical Environment Stats - Detail Chart

Reporter Set

WAN

Tables and Charts

Charts: Resource Time Series Chart (3 of 9 implemented) - Real-Time support

Metrics Used in Report

Laser Bias Current

Received Power

Transmitted Power

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

WAN Uplink Optical Environment Summary Resource

40 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

WAN Uplink Optical Environment Summary Group

Description

AP Adva Optical Metro Ethernet - Uplink (Gig-E) Optical Environment Stats - GST

Reporter Set

WAN

Tables and Charts

Tables: Group Summary Table (1 of 2 implemented)

Charts: Resource Distribution Chart (0 of 4 implemented)

Metrics Used in Report

Laser Bias Current

Chapter 2: Supported Reports

Received Power

Transmitted Power

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > WAN Port

Drills Down To

WAN Uplink Optical Environment Summary Resource

Drilled Down From

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 41

Chapter 2: Supported Reports

WAN Uplink Optical Environment Summary Resource

Description

AP Adva Optical Metro Ethernet - Uplink (Gig-E) Optical Environment Stats - RST

Reporter Set

WAN

Tables and Charts

Tables: Resource Summary Table (1 of 1 implemented)

Charts: Resource Distribution Chart (0 of 2 implemented)

Metrics Used in Report

Laser Bias Current

Received Power

Transmitted Power

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > WAN Port > %(Element.NAME)

Drills Down To

WAN Uplink Optical Environment Details

Drilled Down From

WAN Uplink Optical Environment Summary Group

42 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

WAN Uplink Port Throughput Details

Description

AP Adva Optical Metro Ethernet - Uplink (Gig-E) Traffic (PB enabled) - Detail Chart

Reporter Set

WAN

Tables and Charts

Charts: Resource Time Series Chart (6 of 8 implemented) - Real-Time support

Metrics Used in Report

Egress Bitrate

Chapter 2: Supported Reports

Egress Broadcast

Egress Bytes

Egress Multicast

Egress Unicast

Ingress Bitrate

Navigation Path

This report is not deployed on the portal navigation path during the initial configuration of the technology pack.
To display this report, drill down to it from another report or deploy it with the DataMart Resource Editor.

Drills Down To

None.

Drilled Down From

WAN Uplink Port Throughput Summary Resource

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 43

Chapter 2: Supported Reports

WAN Uplink Port Throughput Summary Group

Description

AP Adva Optical Metro Ethernet - Uplink (Gig-E) Throughput (PB enabled) - GST

Reporter Set

WAN

Tables and Charts

Tables: Group Summary Table (1 of 2 implemented)

Charts: Resource Distribution Chart (0 of 4 implemented)

Metrics Used in Report

Egress Bitrate

Egress Broadcast

Egress Bytes

Egress Multicast

Egress Unicast

Ingress Bitrate

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > WAN Port

Drills Down To

WAN Uplink Port Throughput Summary Resource

Drilled Down From

None.

44 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

WAN Uplink Port Throughput Summary Resource

Description

AP Adva Optical Metro Ethernet - Uplink (Gig-E) Traffic (PB enabled) Summary

Reporter Set

WAN

Tables and Charts

Tables: Resource Summary Table (1 of 1 implemented)

Charts: Resource Distribution Chart (0 of 2 implemented)

Metrics Used in Report

Egress Bitrate

Chapter 2: Supported Reports

Egress Broadcast

Egress Bytes

Egress Multicast

Egress Unicast

Ingress Bitrate

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > Adva Optical Metro Ethernet > WAN Port > %(Element.NAME)

Drills Down To

WAN Uplink Port Throughput Details

Drilled Down From

WAN Uplink Port Throughput Summary Group

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 45

Chapter 2: Supported Reports

NOTES

46 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 3: Devices and Services

This chapter discusses the following topics:

Topic P a g e

Overview 47

Summary of Device Technology 47

Supported MIBs 48

Overview

This chapter provides a summary of the Adva Optical Metro Ethernet device technology and the associated
Management Information Bases (MIBs), which the Adva Optical Metro Ethernet Technology Pack is designed
to support.

Note: The Adva Optical Metro Ethernet Technology Pack operates with Adva Optical Metro Ethernet devices

running Version 3.4.1 of the operating system.

Summary of Device Technology

Metro Ethernet Services using Ethernet technology deliver cost-effective, high-speed connectivity for
metropolitan-area network (MAN) and wide-area network (WAN) applications. This simple, easy-to-use
technology appeals to customers who are already using Ethernet throughout their local-area networks (LANs).
Metro Ethernet Services provide scalable bandwidth in flexible increments with simplified management and
faster, lower-cost provisioning.

The Adva Optical Metro Ethernet Technology Pack is designed to work with the Adva Optical Metro Ethernet
by reporting on the following categories of metrics:

•LAN Port

•WAN Port

•ESA Probes

Note: It is impractical and beyond the scope of this Technology Pack User’s Guide to provide exhaustive

descriptions and explanations of the Adva Optical Metro Ethernet technology. See the documentation that ships
with the previously listed devices and associated services for detailed information on the devices’ and services’
capabilities and features.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 47

Chapter 3: Devices and Services

Supported MIBs

The Adva Optical Metro Ethernet Technology Pack uses the following MIBs for inventory and data collection:

• ethernetServices.my

• ethernetServicesPB.my

•covEsa.my

48 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

NOTES

Chapter 3: Devices and Services

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 49

Chapter 3: Devices and Services

50 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

This chapter discusses the following topics:

Topic P a g e

Overview 51

Adva Optical Metro Ethernet Device Element Properties 51

Adva Optical Metro Ethernet Device Sub-Element Properties 52

Overview

A Netcool/Proviso property is an attribute or characteristic of an element or sub-element. Typically, a
Netcool/Proviso Technology Pack uses an inventory process to collect information generated by the devices,
interfaces, and services operating in the technology environment it supports.

A technology pack uses Netcool/Proviso properties for some or all of the following purposes:

• To organize information in reports

• To display values in reports

• To construct names such as sub-element names, sub-element instance names, and sub-element labels

The Netcool/Proviso properties associated with sub-elements appear in the Properties list (Sub-Element view)
of the Netcool/Proviso DataMart Resource Editor. See the Netcool/Proviso DataMart Configuration Guide for more
information on the Resource Editor.

Adva Optical Metro Ethernet Device Element Properties

The Adva Optical Metro Ethernet Technology Pack defines the following properties for the elements it creates:

Element Property Description

ipAddress

ipName The IP name of the network device to which the SNMP Agent element maps. The

physAddress The physical address of the network device to which the SNMP Agent element maps.

The IP address of the network device on which the SNMP Agent is running.

ipName property might have the same value as the ipAddress property.

For example,

6.8.0.32.192.84.250.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 51

Chapter 4: Element and Sub-Element Properties

Element Property Description

sysDescr

A string that identifies the manufacturer of or some other information about the
network device to which the SNMP Agent element maps. For example, "Cisco
Systems ws-C5000".

sysName A string that identifies the name of the computer or server to which the SNMP Agent

element maps. For example,

"MIMC_Agent#2 Server MIMIC2".

Adva Optical Metro Ethernet Device Sub-Element Properties

The following pages provide a reference of the properties that this technology pack provides. The reference pages
have the following sections:

• Description. The description of the property.

• Captured in Discovery Formulas. The discovery formulas that capture the property.

• Used in CME Formulas. The Complex Metric Engline formulas that use the property as input.

• Used in Reports. The reports in which this property is used.

• Used in Grouping Rules. Indicates whether the property is used by the NOC Reporting or Sub-Element

Collect grouping rules to organize and filter data.

The following pages describe the sub-element properties used in this technology pack.

52 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Element.NAME

Description

The Name of the Element.

Captured in Discovery Formulas

None.

Used in CME Formulas

None.

Used in Reports

None.

Chapter 4: Element and Sub-Element Properties

Used in Grouping Rules

NOC Reporting

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 53

Chapter 4: Element and Sub-Element Properties

Element.STATE

Description

This property indicates if an element is active or not. The value should be ON for collection and discovery to
occur.

Captured in Discovery Formulas

None.

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

NOC Reporting

Sub-Element Collect

54 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

EsaProbeHistoryIndex

Description

An arbitrary integer index value used to uniquely identify this ESA Probe History entry.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 55

Chapter 4: Element and Sub-Element Properties

EsaProbeId

Description

A unique identifier to distinguish the ESA Probe.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

56 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

LanPort

Description

An integer index value used to uniquely identify this Ethernet Services interface within the
ethernetPBPortSvcTable.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 57

Chapter 4: Element and Sub-Element Properties

LanPortHistoryIndex

Description

An arbitrary integer index value used to uniquely identify the Ethernet Services history statistics entry.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

58 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

LanPortStatsIndex

Description

An arbitrary integer index vlaue used to uniquely identify the Ethernet Services statistics entry.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 59

Chapter 4: Element and Sub-Element Properties

MECustomerName

Description

The name of the customer.

Captured in Discovery Formulas

LanPort

WanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

60 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEEsa_DestinationIP

Description

A variable that specifies the Reflector’s destination IP Address. This IP Address is used in the IP header of the
ESA Probe generated packets as the destination address.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 61

Chapter 4: Element and Sub-Element Properties

MEEsa_ProbePacketInterval

Description

Specifies the interval (in milliseconds) between packet generation. A non-zero value must be specified.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

62 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEEsa_ProbePackets

Description

Specifies the number of packets within a sample run for ESA traffic generation. A non-zero value must be
specified.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 63

Chapter 4: Element and Sub-Element Properties

MEEsa_ProbePacketSize

Description

Specifies the fixed-length frame size (in bytes) for ESA traffic generation. A default value of 64 bytes is used
unless otherwise specified.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

64 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEEsa_ProbePortId

Description

This object has the same value as ifIndex for Ethernet Port, on which the service to be monitored resides.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Used in Grouping Rules

NOC Reporting

Sub-Element Collect

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 65

Chapter 4: Element and Sub-Element Properties

MEEsa_ProbePriority

Description

Specifies the Priority Value for esaProbePrioMapMode as TOS/DSCP.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

66 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

MEEsa_ProbeStorageType

Description

The type of storage configured for this entry.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Chapter 4: Element and Sub-Element Properties

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 67

Chapter 4: Element and Sub-Element Properties

MEEsa_Protocol

Description

Protocol used in ESA Probe messages. Note that an udpEcho protocol can be used for standard ESA - in other
words the reflector can be any node running the UDP Echo service (in this case only round-trip delay time
metrics are available). The icmpTimestamp protocol can be used for enhanced ESA (in this case the reflector
must be a Covaro node). Round-trip delay time as well as one-way-jitter metrics are available with this enhanced
ESA.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Used in Grouping Rules

None.

68 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEEsa_ServiceType

Description

Specifies whether or not to use VLAN tagged or untagged ESA traffic generation on the Probe.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 69

Chapter 4: Element and Sub-Element Properties

MEEsa_SourceIP

Description

Specifies the Probe’s source IP Address. This IP Address is used as the source address in the IP header of the
ESA Probe generated packets.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Used in Grouping Rules

None.

70 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEEsa_VlanId

Description

Specifies the monitored service’s VLAN tag. It is valid if esaProbeSvcType is specified as VLAN tagged.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 71

Chapter 4: Element and Sub-Element Properties

MEEsa_VlanPriority

Description

Specifies the monitored service’s VLAN priority. It is valid if esaProbeSvcType is specified as VLAN tagged.

Captured in Discovery Formulas

ESAProbes

Used in CME Formulas

None.

Used in Reports

Ethernet Port Jitter Probe Egress Negative Details

Ethernet Port Jitter Probe Egress Positive Details

Ethernet Port Jitter Probe Ingress Negative Details

Ethernet Port Jitter Probe Ingress Positive Details

Ethernet Port Latency Probe Delay Egress Oneway Details

Ethernet Port Latency Probe Delay Ingress Oneway Details

Ethernet Port Latency Probe Delay Round Trip Details

Ethernet Port Latency Probe Error Details

Ethernet Port Latency Probe Loss Details

Ethernet Port Latency Probe Sequence Details

Used in Grouping Rules

None.

72 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

MESiteName

Description

The Name of the Site.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Chapter 4: Element and Sub-Element Properties

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 73

Chapter 4: Element and Sub-Element Properties

MEUNI_CBS

Description

This object allows configuration of the Commited Burst Size (CBS) on the Ethernet port. It is only applicable in
connection-oriented TLS mode.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

Ethernet Port Drops and Discards Details

Ethernet Port Throughput Details

Used in Grouping Rules

None.

74 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEUNI_CIR

Description

Enables configuration of the Commited Information Rate(CIR) on the Ethernet port. This object is only
applicable in connection-oriented TLS mode.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

Ethernet Port Drops and Discards Details

Ethernet Port Throughput Details

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 75

Chapter 4: Element and Sub-Element Properties

MEUNI_EBS

Description

This object allows SNMP management entities to set the Excess Burst Size (EBS) of the Ethernet Service Port,
when the port is in connection-oriented TLS mode.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

Ethernet Port Drops and Discards Details

Ethernet Port Throughput Details

Used in Grouping Rules

None.

76 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEUNI_EgressCBS

Description

This object allows configuration of the Egress Commited Burst Size (CBS) on Ethernet port. It is only applicable
in connection-oriented TLS mode and is valid only if ethernetPBPortSvcEgressRateLimitingEnabled is TRUE.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 77

Chapter 4: Element and Sub-Element Properties

MEUNI_EgressCIR

Description

This object is applicable only for connection-oriented TLS mode.It allows for configuration of the Egress
Commited Information Rate (CIR) on Ethernet port. It is valid only if
ethernetPBPortSvcEgressRateLimitingEnabled is TRUE.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

78 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEUNI_EgressEBS

Description

This object allows SNMP management entities to set the Excess Burst Size (EBS) of the Ethernet Service Port,
when the port is in connection-oriented TLS mode. This object is valid only if
ethernetPBPortSvcEgressRateLimitingEnabled is TRUE.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 79

Chapter 4: Element and Sub-Element Properties

MEUNI_EgressEIR

Description

This object is applicable only for connection-oriented TLS mode. It allows for configuration of the Egress Peak
Information Rate(EIR) on Ethernet port. It is valid only if ethernetPBPortSvcEgressRateLimitingEnabled is
TRUE.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

80 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEUNI_EIR

Description

This object allows SNMP management entities to set the Excess Information Rate (EIR) of the Ethernet Service
Port, when the port is in connection-oriented TLS mode.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

Ethernet Port Drops and Discards Details

Ethernet Port Throughput Details

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 81

Chapter 4: Element and Sub-Element Properties

MEUNI_InterfaceType

Description

Specifies a transparent (TLS) service or VLAN/priority classified service (TVLS). This object is only applicable
when ethernetPBPortSvcPortMode is connection-oriented.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

Ethernet Port Drops and Discards Details

Ethernet Port Optical Environment Details

Ethernet Port Throughput Details

Used in Grouping Rules

None.

82 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEUNI_PortID

Description

An integer index value used to uniquely identify the Ethernet Services interface. This object has the same value
as ifIndex for Ethernet Port.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

Ethernet Port Drops and Discards Details

Ethernet Port Optical Environment Details

Ethernet Port Throughput Details

Used in Grouping Rules

NOC Reporting

Sub-Element Collect

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 83

Chapter 4: Element and Sub-Element Properties

MEUNI_PortMode

Description

This object allows SNMP management entities to indicate whether the Ethernet Service Port is connected or not.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

84 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X

Chapter 4: Element and Sub-Element Properties

MEUNI_PortSpeed

Description

This object allows configuration of the port speed. Speed-auto enables auto-negotiation and advertises all speeds
(10M Half Duplex, 10M Full Duplex, 100M Half Duplex, 100M Full Duplex). Speed-auto with specific settings
enables auto-negotiation for that specific speed/duplexicity only (for example, speed-auto-10M-half is auto
negotiation enabled with advertisement for 10M Half Duplex).

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X 85

Chapter 4: Element and Sub-Element Properties

MEUNI_Priority

Description

This object specifies the port Priority on the Ethernet port.

Captured in Discovery Formulas

LanPort

Used in CME Formulas

None.

Used in Reports

None.

Used in Grouping Rules

None.

86 Netcool/Proviso Adva Optical Metro Ethernet 2.1.1.0 Technology Pack User’s Guide, Version 4.3-X
