IBM Sys te m Sto rage



N6200SeriesHardwareandServiceGuide

CoveringtheN6210,N6220,N6240,N6250,andN6270models

GA32-0838-04

Note:

Before using this information and the product it supports, be sure to read the general information in “Notices” on page 109.

The following paragraph does not apply to any country (or region) where such provisions are inconsistent with local law.

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states (or regions) do not allow disclaimer of express or implied warranties in certain transactions; therefore, this statement may not apply to you.

Order publications through your IBM representative or the IBM branch office serving your locality.

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

Safety notices

This section contains information about:

v “Safety notices and labels”

v “Laser safety” on page vii

v “Rack safety” on page viii

v “Fire suppression systems” on page xi

For information about environmental notices, see the IBM and User Guide, Z125-5823.

Safety notices and labels

When using this product, observe the danger, caution, and attention notices contained in this guide. The notices are accompanied by symbols that represent the severity of the safety condition.

The following sections define each type of safety notice and provide examples.

The following notices and statements are used in IBM documents. They are listed below in order of increasing severity of potential hazards. Follow the links for more detailed descriptions and examples of the danger, caution, and attention notices in the sections that follow.

Environmental Notices

“Danger notices”

These statements indicate situations that can be potentially lethal or extremely hazardous to you. Safety labels are also attached directly to products to warn of these situations.

“Caution notices” on page vi

These statements indicate situations that can be potentially hazardous to you.

“Attention notices” on page vi

These notices indicate potential damage to programs, devices, or data.

Notes These notices provide important tips, guidance, or advice.

In addition to these notices, “Labels” on page v may be attached to the product to warn of potential hazards.

Danger notices

A danger notice calls attention to a situation that is potentially lethal or extremely hazardous to people. A lightning bolt symbol accompanies a danger notice to represent a dangerous electrical condition. A sample danger notice follows.

DANGER

An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock. (D004)

A general danger notice provides instructions on how to avoid shock hazards when servicing equipment. Unless instructed otherwise, follow the procedures in the following danger notice.

iv IBM System Storage: N6200 Series Hardware and Service Guide

DANGER

When working on or around the system, observe the following precautions:

Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard:

v Connect power to this unit only with the IBM provided power cord. Do

not use the IBM provided power cord for any other product.

v Do not open or service any power supply assembly.

v Do not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical storm.

v The product might be equipped with multiple power cords. To remove all

hazardous voltages, disconnect all power cords.

v Connect all power cords to a properly wired and grounded electrical

outlet. Ensure outlet supplies proper voltage and phase rotation according to the system rating plate.

v Connect any equipment that will be attached to this product to properly

wired outlets.

v When possible, use one hand only to connect or disconnect signal cables.

v Never turn on any equipment when there is evidence of fire, water, or

structural damage.

v Disconnect the attached power cords, telecommunications systems,

networks, and modems before you open the device covers, unless instructed otherwise in the installation and configuration procedures.

v Connect and disconnect cables as described below when installing,

moving, or opening covers on this product or attached devices.

To Disconnect:

1. Turn off everything (unless instructed otherwise).

2. Remove power cords from the outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

To Connect:

1. Turn off everything (unless instructed otherwise).

2. Attach all cables to devices.

3. Attach signal cables to the connectors.

4. Attach power cords to the outlets.

5. Turn on the devices.

(D005)

Labels

As an added precaution, safety labels are often installed directly on products or product components to warn of potential hazards.

The actual product safety labels may differ from these sample safety labels:

Safety notices v

DANGER

Hazardous voltage, current, or energy levels are present inside any component that has this label attached. Do not open any cover or barrier

(L001)

(L003)

that contains this label.

DANGER

Multiple power cords. The product might be equipped with multiple power cords. To remove all hazardous voltages, disconnect all power cords.

Caution notices

A caution notice calls attention to a situation that is potentially hazardous to people because of some existing condition. A caution notice can be accompanied by different symbols, as in the examples below:

If the symbol is... It means....

A hazardous electrical condition with less severity than electrical danger.

A generally hazardous condition not represented by other safety symbols.

A hazardous condition due to the use of a laser in the product. Laser symbols are always accompanied by the classification of the laser as defined by the U. S. Department of Health and Human Services (for example, Class I, Class II, and so forth).

Attention notices

An attention notice indicates the possibility of damage to a program, device, or system, or to data. An exclamation point symbol may accompany an attention notice, but is not required. A sample attention notice follows:

Attention: Do not bend a fiber cable to a radius less than 5 cm (2 in.); you can damage the cable. Tie wraps are not recommended for optical cables because they can be easily overtightened, causing damage to the cable.

vi IBM System Storage: N6200 Series Hardware and Service Guide

Laser safety

CAUTION: This product contains a Class 1M laser. Do not view directly with optical instruments. (C028)

This equipment contains Class 1 laser products, and complies with FDA radiation Performance Standards, 21 CFR Subchapter J and the international laser safety standard IEC 825-2.

CAUTION: Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. (C027)

Attention: In the United States, use only SFP or GBIC optical transceivers that

comply with the FDA radiation performance standards, 21 CFR Subchapter J. Internationally, use only SFP or GBIC optical transceivers that comply with IEC standard 825–1. Optical products that do not comply with these standards may produce light that is hazardous to the eyes.

Usage restrictions

The optical ports of the modules must be terminated with an optical connector or with a dust plug.

Safety notices vii

Rack safety

Rack installation

DANGER

Observe the following precautions when working on or around your IT rack system:

v Heavy equipment - personal injury or equipment damage might

result if mishandled.

v Always lower the leveling pads on the rack cabinet.

v Always install stabilizer brackets on the rack cabinet.

v To avoid hazardous conditions due to uneven mechanical

loading, always install the heaviest devices in the bottom of the rack cabinet. Always install servers and optional devices starting from the bottom of the rack cabinet.

v Rack-mounted devices are not to be used as shelves or work

spaces. Do not place objects on top of rack-mounted devices.

(R001 part 1 of 2)

v Each rack cabinet might have more than one power cord. Be

sure to disconnect all power cords in the rack cabinet when directed to disconnect power during servicing.

v Connect all devices installed in a rack cabinet to power devices

installed in the same rack cabinet. Do not plug a power cord from a device installed in one rack cabinet into a power device installed in a different rack cabinet.

v An electrical outlet that is not correctly wired could place

hazardous voltage on the metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock.

viii IBM System Storage: N6200 Series Hardware and Service Guide

CAUTION:

v Do not install a unit in a rack where the internal rack ambient temperatures

will exceed the manufacturer's recommended ambient temperature for all your rack-mounted devices.

v Do not install a unit in a rack where the air flow is compromised. Ensure that

air flow is not blocked or reduced on any side, front, or back of a unit used for air flow through the unit.

v Consideration should be given to the connection of the equipment to the

supply circuit so that overloading of the circuits does not compromise the supply wiring or overcurrent protection. To provide the correct power connection to a rack, refer to the rating labels located on the equipment in the rack to determine the total power requirement of the supply circuit.

v (For sliding drawers.) Do not pull out or install any drawer or feature if the rack

stabilizer brackets are not attached to the rack. Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time.

v (For fixed drawers) This drawer is a fixed drawer and should not be moved for

servicing unless specified by manufacturer. Attempting to move the drawer partially or completely out of the rack may cause the rack to become unstable or cause the drawer to fall out of the rack.

(R001 part 2 of 2)

Safety notices ix

Rack relocation (19" rack)

CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building:

v Reduce the weight of the rack cabinet by removing equipment starting at the

top of the rack cabinet. When possible, restore the rack cabinet to the configuration of the rack cabinet as you received it. If this configuration is not known, you must do the following:

– Remove all devices in the 32U position and above.

– Ensure that the heaviest devices are installed in the bottom of the rack

cabinet.

– Ensure that there are no empty U-levels between devices installed in the

rack cabinet below the 32U level.

– If the rack cabinet you are relocating is part of a suite of rack cabinets,

detach the rack cabinet from the suite.

– Inspect the route that you plan to take when moving the rack to eliminate

potential hazards.

– Verify that the route that you choose can support the weight of the loaded

rack cabinet. Refer to the documentation that came with your rack cabinet for the weight of a loaded rack cabinet.

– Verify that all door openings are at least 760 x 2030 mm (30 x 80 in.).

– Ensure that all devices, shelves, drawers, doors, and cables are secure.

– Ensure that the four leveling pads are raised to their highest position.

– Ensure that there is no stabilizer bracket installed on the rack cabinet

during movement.

– Do not use a ramp inclined at more than ten degrees.

– Once the rack cabinet is in the new location, do the following:

- Lower the four leveling pads.

- Install stabilizer brackets on the rack cabinet.

- If you removed any devices from the rack cabinet, repopulate the rack cabinet from the lowest position to the highest position.

– If a long distance relocation is required, restore the rack cabinet to the

configuration of the rack cabinet as you received it. Pack the rack cabinet in the original packaging material, or equivalent. Also, lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the pallet.

(R002)

x IBM System Storage: N6200 Series Hardware and Service Guide

Handling fiber-optic cables

Before you use fiber-optic cables, read the following precautions.

Attention: To avoid damage to the fiber-optic cables, follow these guidelines:

v Do not route the cable along a folding cable-management arm.

v When attaching to a device on slide rails, leave enough slack in the cable so that

it does not bend to a radius of less than 38 mm (1.5 in.) when extended or become pinched when retracted.

v Route the cable away from places where it can be snagged by other devices in

the rack cabinet.

v Do not overtighten the cable straps or bend the cables to a radius of less than 38

mm (1.5 in.).

v Do not put excess weight on the cable at the connection point. Be sure that the

cable is well supported.

Fire suppression systems

A fire suppression system is the responsibility of the customer. The customer's own insurance underwriter, local fire marshal, or a local building inspector, or both, should be consulted in selecting a fire suppression system that provides the correct level of coverage and protection.

IBM designs and manufactures equipment to internal and external standards that require certain environments for reliable operation. Because IBM does not test any equipment for compatibility with fire suppression systems, IBM does not make compatibility claims of any kind nor does IBM provide recommendations on fire suppression systems.

Safety notices xi

xii IBM System Storage: N6200 Series Hardware and Service Guide

Safety notices .................................iii

Safety notices and labels ...............................iii

Laser safety ...................................vii

Rack safety ...................................viii

Handling fiber-optic cables ..............................xi

Fire suppression systems ...............................xi

Figures ...................................xvii

Tables ....................................xix

About this document .............................xxi

Who should read this document ............................xxi

Related documents.................................xxi

Supported features ................................xxii

Websites ....................................xxii

Getting information, help, and service ..........................xxii

Before you call ................................xxiii

Using the documentation .............................xxiii

Hardware service and support ...........................xxiii

Firmware updates ...............................xxiii

Terminology and conventions used in this document .....................xxiv

Active/active and high-availability terms ........................xxiv

Storage terms .................................xxiv

Command conventions ..............................xxv

Formatting conventions ..............................xxv

Keyboard conventions ..............................xxvi

How to send your comments .............................xxvi

Preparing for the installation ...........................1

About the N6200 series system .............................1

Required manuals, tools, and equipment ..........................3

Handling static-sensitive devices.............................4

Planning and organizing the installation ..........................4

Hardware specifications ..............................5

Checking shipment package contents ..........................9

Rules for installing the system in a rack .........................10

Guide to the installation process ...........................11

Connecting an N6200 series system .......................13

Connecting your system to a power source .........................13

Connecting your system to an IP network .........................13

Connecting your system to storage ...........................15

Connecting a filer to storage expansion units .......................15

Connecting to SAS storage expansion units .......................15

Connecting to EXN1000 and EXN4000 storage expansion units ................15

Cabling an N6200 series system to Fibre Channel switches using a Fibre Channel expansion adapter . . . 16

Connecting a gateway to external storage ........................18

Connecting to a third-party device...........................19

Rules for connecting the third-party devices ......................19

Connecting your system to an ASCII terminal console .....................19

Configuring an N6200 series system .......................21

Configuring the N6200 series system ...........................21

Configuring the Fibre Channel port ...........................21

Configuring for initiator mode ............................21

Configuring and using the Service Processor ........................22

Replacing N6200 series system devices .....................23

Replacing a fan module in an N6200 series system ......................26

Removing a fan module ..............................26

Installing a fan module ..............................27

Completing the replacement process ..........................28

Replacing a power supply on an N6200 series system .....................28

Removing a power supply .............................28

Installing a power supply .............................29

Completing the replacement process ..........................30

Replacing an NVMEM battery or NVMEM DIMMs in an N6200 series system .............30

Shutting down the node ..............................30

Shutting down a node in an HA pair .........................30

Shutting down the node in a stand-alone system .....................31

Opening the system ...............................32

Removing an NVMEM battery from an N6200 series system ..................33

Removing the NVMEM DIMM ............................35

Installing the system DIMMs ............................37

Installing an NVMEM battery ............................38

Reinstalling the controller module and booting the system...................38

Checking the status of the NVMEM battery and running diagnostics ...............40

Completing the replacement process ..........................42

Disposing of batteries ..............................42

Replacing a system DIMM in an N6200 series system .....................42

Shutting down the node ..............................43

Shutting down a node in an HA pair .........................43

Shutting down the node in a stand-alone system .....................44

Opening the system ...............................44

Removing the system DIMMs ............................45

Installing the system DIMMs ............................47

Reinstalling the controller module and booting the system...................47

Running diagnostics on the system DIMM ........................48

Completing the replacement process ..........................51

Replacing PCIe cards in an N6200 series system .......................51

Shutting down the node ..............................52

Shutting down a node in an HA pair .........................52

Shutting down the node in a stand-alone system .....................53

Opening the system ...............................54

Removing a PCIe card ...............................54

Installing a PCIe card ...............................55

Reinstalling the controller module and booting the system...................56

Running diagnostics on a PCIe card ..........................57

Completing the replacement process ..........................59

Replacing a boot device in an N6200 series system running Data ONTAP 7.3.5 and later releases in the Data

ONTAP 7.3 release family ..............................59

Shutting down a node ...............................60

Opening the system ...............................60

Removing the boot device from the controller .......................61

Installing the boot device and transferring system files to the boot device .............62

Completing the replacement process ..........................65

Replacing a boot device in an N6200 series system running Data ONTAP 8.x .............65

Replacing a boot device in a system running Data ONTAP 7-Mode ................66

Shutting down a node ..............................66

Opening the system ..............................67

Removing the boot device from the controller ......................67

Installing the boot device in a system running in 7-Mode ..................68

Replacing a boot device in a system running in Clustered Data ONTAP ..............78

Shutting down a node in a high-availability configuration ..................78

xiv IBM System Storage: N6200 Series Hardware and Service Guide

Opening the system ..............................78

Removing the boot device from the controller ......................79

Installing the boot device in a system running Clustered Data ONTAP .............80

Completing the replacement process ..........................87

Replacing the I/O expansion module in an N6200 series system..................87

Shutting down the node ..............................87

Shutting down a node in an HA configuration .....................87

Shutting down the node in a stand-alone system .....................88

Removing the I/O expansion module .........................89

Installing the I/O expansion module ..........................90

Running diagnostics on the I/O expansion module .....................91

Completing the replacement process ..........................93

Disposing of batteries ..............................93

Replacing the Real-Time Clock (RTC) battery in an N6200 series system ...............94

Shutting down the node ..............................94

Shutting down a node in an HA pair .........................94

Shutting down the node in a stand-alone system .....................95

Opening the system ...............................96

Removing an RTC battery .............................96

Installing an RTC battery ..............................97

Reinstalling the controller module and booting the system...................98

Running diagnostics on the RTC battery.........................99

Resetting the date and time on the system........................101

Completing the replacement process..........................102

Disposing of batteries .............................102

Recommended power line sizes ........................103

Recommended AC power line sizes ...........................103

FRU/CRU and power cord list for N series products................105

FRU/CRU list for N series products ...........................105

Power cord list for N series products ..........................105

Notices ...................................109

Trademarks ...................................110

Important notes..................................111

Electronic emission notices ..............................111

Federal Communications Commission Statement .....................111

Industry Canada Compliance Statement ........................112

Australia and New Zealand Class A Statement ......................112

European Union Electromagnetic Compatibility Directive...................112

Germany Electromagnetic Compatibility Directive .....................113

People's Republic of China Class A Statement ......................114

Taiwan Class A Statement .............................114

Taiwan Contact Information ............................114

Japan Voluntary Control Council for Interference Class A Statement ...............114

Japan Electronics and Information Technology Industries Association Statement ...........114

Korean Communications Commission Class A Statement ...................115

Russia Electromagnetic Interference Class A Statement....................115

Power cords ...................................115

Index ....................................117

Contents xv

xvi IBM System Storage: N6200 Series Hardware and Service Guide

Figures

1. N6200 series system - Front view...........................1

2. N6210 2858-C10 and N6220 2858-C15 .........................2

3. N6240 2858-E11, N6270 2858-E12, N6220 2858-E15, and N6250 2858-E16..............2

4. N6210 2858-C20, N6240 2858-C21, N6270 2858-C22, and N6220 2858-C25 .............2

5. N6240 2858-E21, N6270 2858-E22, N6220 2858-E25, and N6250 2858-E26..............3

6. Rear view ..................................13

7. Appliance ports and LEDs ............................14

8. Cabling the N6200 series system to Fibre Channel switches .................17

9. Cabling the N6200 series system expansion adapter to storage expansion units ...........18

10. Cabling the N6200 series system expansion adapter to storage expansion units ...........18

11. N6200 series system components - Front ........................23

12. N6200 series system components - Rear ........................24

13. N6200 series ports and LEDs............................24

14. N6200 series system components - Exploded view ....................25

15. N6200 series system fans .............................27

16. Removing the power supply ............................29

17. NVMEM LED.................................32

18. NVMEM battery location .............................34

19. Removing the NVMEM battery ...........................35

20. DIMM locations ................................36

21. Removing DIMMs ...............................37

22. Installing the NVMEM battery ...........................38

23. NVMEM LED.................................44

24. DIMM locations ................................46

25. Removing DIMMs ...............................47

26. NVMEM LED.................................53

27. Removing the PCI card .............................55

28. Removing the boot device.............................62

29. Removing the boot device.............................68

30. Removing the boot device.............................80

31. NVMEM LED.................................89

32. Remving the IOX module .............................90

33. NVMEM LED.................................96

34. Removing the RTC battery ............................97

xviii IBM System Storage: N6200 Series Hardware and Service Guide

Tables

1. N6200 series physical characteristics..........................5

2. N6200 series clearance dimensions ..........................5

3. N6200 series environmental requirements ........................6

4. N6200 series systems maximum electrical power .....................6

5. N6210 electrical requirements–one controller node, with one 256-GB Flash Cache module ........6

6. N6210 electrical requirements–two controller nodes, with one 256-GB Flash Cache module per node ....7

7. N6220 electrical requirements–one controller node, with one 512-GB Flash Cache or Flash Cache 2 module 7

8. N6220/N6240 electrical requirements–two controller nodes, with one 256-GB Flash Cache module or one

512-GB Flash Cache or Flash Cache 2 module per controller node ................8

9. N6220/N6240 electrical requirements–one controller node, with one 256-GB Flash Cache module or one

512-GB Flash Cache or Flash Cache 2 module, and one I/O expansion module ...........8

10. N6270 electrical requirements–two controller nodes, with one 512-GB or one 1-TB Flash Cache or Flash Cache

2 module per controller node ............................8

11. N6250/N6270 electrical requirements–one controller node, with one 512-GB or one 1-TB Flash Cache or Flash

Cache 2 module, and one I/O expansion module .....................9

12. Filer installation process procedures .........................12

13. Service Processor manuals ............................22

14. 110V, single phase recommended conductor sizes ....................103

15. 220V, single phase recommended conductor sizes ....................103

16. American Wire Gage to Harmonized Cordage equivalents .................103

xx IBM System Storage: N6200 Series Hardware and Service Guide

About this document

This guide describes how to connect and manage the following IBM System Storage®N6200 series systems:

v N6210 (model numbers 2858-C10 and 2858-C20)

v N6220 (model numbers 2858-C15, 2858-C25, 2858-E15, and 2858-E25)

v N6240 (model numbers 2858-C21, 2858-E11, and 2858-E21)

v N6250 (model numbers 2858-E16 and 2858-E26)

v N6270 (model numbers 2858-C22, 2858-E12, and 2858-E22)

Note: Throughout this document, the N6210, N6220, N6240, N6250, and N6270 systems are referred to generically as N6200 series systems, unless information applies only to a specific system, in which case the specific machine name is used.

Compliance ID 2858-CAR covers MT/models 2858-C10, 2858-C20, 2858-C21, 2858-C15, 2858-C25, 2858-E15, 2858-E25, 2858-E11, 2858-E21, 2858-C22, 2858-E12, 2858-E22, 2858-E16 and 2858-E26.

Note: This guide applies to systems, including systems with gateway functionality, running Data ONTAP 7.x and Data ONTAP 8.x 7-Mode and Clustered Data ONTAP. In the Data ONTAP 8.x 7-Mode product name, the term 7-Mode signifies that the 8.x release has the same features and functionality found in the prior Data ONTAP 7.1, 7.2, and 7.3 release families.

For the latest version of this document and all IBM System Storage N series documentation, go to the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Who should read this document

This guide is for customer use. It is intended for qualified system administrators and service personnel who are familiar with IBM storage systems. It addresses setup, operation, and servicing of the N6200 series system models.

Supported features

IBM System Storage N series storage systems are driven by NetApp Data ONTAP software. Some features described in the product software documentation are neither offered nor supported by IBM. Please contact your local IBM representative or reseller for further details.

Information about supported features can also be found on the N series support website, which is accessed and navigated as described in “Websites.”

Websites

IBM maintains pages on the World Wide Web where you can get the latest technical information and download device drivers and updates. The following web pages provide N series information:

v A listing of currently available N series products and features can be found at

the following web page:

www.ibm.com/storage/nas/

v The IBM System Storage N series support website requires users to register in

order to obtain access to N series support content on the web. To understand how the N series support web content is organized and navigated, and to access the N series support website, refer to the following publicly accessible web page:

www.ibm.com/storage/support/nseries/

This web page also provides links to AutoSupport information as well as other important N series product resources.

v IBM System Storage N series products attach to a variety of servers and

operating systems. To determine the latest supported attachments, go to the IBM N series interoperability matrix at the following web page:

www.ibm.com/systems/storage/network/interophome.html

v For the latest N series hardware product documentation, including planning,

installation and setup, and hardware monitoring, service and diagnostics, see the IBM N series Information Center at the following web page:

http://publib.boulder.ibm.com/infocenter/nasinfo/nseries/index.jsp

Getting information, help, and service

If you need help, service, or technical assistance or just want more information about IBM products, you will find a wide variety of sources available from IBM to assist you. This section contains information about where to go for additional information about IBM and IBM products, what to do if you experience a problem with your IBM N series product, and whom to call for service, if it is necessary.

xxii IBM System Storage: N6200 Series Hardware and Service Guide

The following applies in Taiwan:

IBM Taiwan Product Service Contact Info: IBM Taiwan Corporation 3F, No 7, Song Ren Rd., Taipei Taiwan Tel: 0800-016-888

Before you call

Before you call, make sure you have taken these steps to try to solve the problem yourself:

v Check all cables to make sure they are connected.

v Check the power switches to make sure the system is turned on.

v Use the troubleshooting information in your system documentation and use the

diagnostic tools that come with your system.

v Refer to the IBM support website for information on known problems and

limitations.

Using the documentation

The latest versions of N series software documentation, including Data ONTAP and other software products, are available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Current N series hardware product documentation is shipped with your hardware product in printed documents or as PDF files on a documentation CD. For the latest N series hardware product documentation PDFs, go to the IBM N series support website.

Hardware documentation, including planning, installation and setup, and hardware monitoring, service, and diagnostics, is also provided in an IBM N series Information Center at the following web page:

http://publib.boulder.ibm.com/infocenter/nasinfo/nseries/index.jsp

Hardware service and support

You can receive hardware service through IBM Integrated Technology Services. Visit the following web page for support telephone numbers:

www.ibm.com/planetwide/

Firmware updates

IBM N series product firmware is embedded in Data ONTAP. As with all devices, it is recommended that you run the latest level of firmware. Any firmware updates are posted to the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Note: If you do not see new firmware updates on the IBM N series support website, you are running the latest level of firmware.

About this document xxiii

Verify that the latest level of firmware is installed on your machine before contacting IBM for technical support.

Terminology and conventions used in this document

This guide uses the following terminology, command conventions, format conventions and keyboard conventions.

In this document, the term gateway describes IBM N series storage systems that have been ordered with gateway functionality. Gateways support various types of storage, and they are used with third-party disk storage systems. In this case, disk storage for customer data and the RAID controller functionality is provided by the back-end disk storage system. A gateway might also be used with disk storage expansion units specifically designed for the IBM N series models.

The term filer describes IBM N series storage systems that either contain internal disk storage or attach to disk storage expansion units specifically designed for the IBM N series storage systems. Filer storage systems do not support using third-party disk storage systems.

The terms system or storage system refer to either a gateway by itself or a filer, either by itself or with additional disk drives.

Active/active and high-availability terms

active/active configuration

In the Data ONTAP 7.2 and 7.3 release families, refers to a pair of storage systems (sometimes called nodes) configured to serve data for each other if one of the two systems stops functioning. Also sometimes referred to as active/active pairs.

cluster

In the Data ONTAP 7.1 release family, refers to a pair of storage systems (sometimes called nodes) configured to serve data for each other if one of the two systems stops functioning. In Data ONTAP 8.x ,acluster is a group of connected nodes (storage systems) that share a global namespace and that you can manage as a single virtual server or multiple virtual servers, providing performance, reliability, and scalability benefits.

HA (high availability)

In Data ONTAP 8.x, the recovery capability provided by a pair of nodes (storage systems), called an HA pair, that are configured to serve data for each other if one of the two nodes stops functioning.

HA pair

In Data ONTAP 8.x, a pair of nodes (storage systems) configured to serve data for each other if one of the two nodes stops functioning.

Storage terms

ACP Alternate Control Path is a protocol that enables Data ONTAP to manage

and control the storage expansion unit storage subsystem using a separate network from the data path, so management communication is not dependent on the data path being intact and available.

AT-FCX

The controller module of the EXN1000 serial advanced technology attachment (SATA) storage expansion unit.

xxiv IBM System Storage: N6200 Series Hardware and Service Guide

Disk Any hard disk drive

Disk shelf or shelf

Any storage expansion unit containing hard disk drives.

ESH The controller module of Fibre Channel disk storage expansion units.

IOM The Input/Output module of SAS disk storage expansion units.

Loop or Fibre-Channel Arbitrated Loop

One or more daisy-chained Fibre Channel storage expansion units connected to an N series storage system.

Node The system controller module that executes the software on an N series

system. There is one node in single-controller models; there are two nodes in active/active or high availability models.

Stack or SAS stack

A stack of one or more SAS storage expansion units using IOM modules connected to the storage system. The maximum number of storage expansion units in a stack of storage expansion units and the number of storage expansion unit stacks in a configuration are dependent on the type of storage system.

Command conventions

You can enter commands on the system console or from any client that can obtain access to the storage system using a Telnet session. In examples that illustrate commands executed on a UNIX workstation, the command syntax and output might differ, depending on your version of UNIX.

Formatting conventions

The following table lists different character formats used in this guide to set off special information.

Formatting convention Type of information

Italic type

Monospaced font

Bold monospaced font Words or characters you type. What you

v Words or characters that require special

attention.

v Placeholders for information you must

supply. For example, if the guide requires you to enter the fctest adaptername command, you enter the characters fctest followed by the actual name of the adapter.

v Book titles in cross-references.

v Command and daemon names.

v Information displayed on the system

console or other computer monitors.

v The contents of files.

type is always shown in lowercase letters, unless your program is case-sensitive and uppercase letters are necessary for it to work properly.

About this document xxv

Keyboard conventions

This guide uses capitalization and some abbreviations to refer to the keys on the keyboard. The keys on your keyboard might not be labeled exactly as they are in this guide.

What is in this guide... What it means...

hyphen (-) Used to separate individual keys. For

Enter Used to refer to the key that generates a

type Used to mean pressing one or more keys on

enter Used to mean pressing one or more keys

How to send your comments

Your feedback is important in helping us provide the most accurate and high-quality information. If you have comments or suggestions for improving this document, send us your comments by email to starpubs@us.ibm.com.

example, Ctrl-D means holding down the Ctrl key while pressing the D key.

carriage return, although the key is named Return on some keyboards.

the keyboard.

and then pressing the Enter key.

Be sure to include the following information:

v Exact publication title

v Publication form number (for example, GC26-1234-02)

v Page, table, or illustration numbers

v A detailed description of any information that should be changed

xxvi IBM System Storage: N6200 Series Hardware and Service Guide

Preparing for the installation

This chapter provides an overview of the entire IBM System Storage N6200 series system installation process, hardware specifications, and the appropriate documentation references for the procedures.

Refer to the Installation and Setup Instructions that came with your system for further information about installing your equipment.

This chapter discusses the following topics:

v “About the N6200 series system”

v “Required manuals, tools, and equipment” on page 3

v “Handling static-sensitive devices” on page 4

v “Planning and organizing the installation” on page 4

About the N6200 series system

Figure 1 shows the front view of the N6200 series system.

Figure 1. N6200 series system - Front view

1 Fan module

2 System LEDs - power fault, controller A activity, controller B activity

3 Fan CAM handle

4 Fan LED

n62hw02

The following images show the available models of the N6200 series systems.

N6210 2858-C10 and N6220 2858-C15 are single-enclosure, non-HA system with a single controller. They do not contain an Input/Output expansion module.

c0a e0a

c0b

e0b

IOIOI

PSUPSU

0a 0b

Figure 2. N6210 2858-C10 and N6220 2858-C15

The N6240 2858-E11, N6270 2858-E12, N6220 2858-E15, and N6250 2858-E16 are single-enclosure, non-HA systems with a single controller and one Input/Output expansion module (IOXM).

c0a e0a

c0b

e0b

IOXM

IOIOI

PSU

0a 0b

PSU

n62hw08

n62hw05

Figure 3. N6240 2858-E11, N6270 2858-E12, N6220 2858-E15, and N6250 2858-E16

The N6210 2858-C20, N6240 2858-C21, N6270 2858-C22, and N6220 2858-C25 are single-enclosure HA systems with two controllers. They do not contain an Input/Output expansion module.

c0a e0a

0a 0b

c0b

e0b

FC GbE

c0a e0a

c0b

e0b

IOIOI

PSUPSU

Figure 4. N6210 2858-C20, N6240 2858-C21, N6270 2858-C22, and N6220 2858-C25

The N6240 2858-E21, N6270 2858-E22, N6220 2858-E25, and N6250 2858-E26 are dual-enclosure HA systems. Each enclosure contains one controller and one Input/Output expansion module.

n62hw06

2 IBM System Storage: N6200 Series Hardware and Service Guide

c0a e0a

c0b

e0b

0a 0b

PSU

c0a e0a

c0b

e0b

0a 0b

PSU

Figure 5. N6240 2858-E21, N6270 2858-E22, N6220 2858-E25, and N6250 2858-E26

Required manuals, tools, and equipment

IOXM

IOIOI

PSU

IOIOI

PSU

n62hw07

You need the following manuals in addition to this manual. Data ONTAP publications are available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

v Installation and Setup Instructions for your IBM N series system and storage

expansion units

v Data ONTAP Software Setup Guide for your version of Data ONTAP

v Data ONTAP Active/Active Configuration Guide or Data ONTAP High Availability

Configuration Guide for your version of Data ONTAP, if applicable

You need to supply the following tools and equipment:

v Ethernet LAN cables

v Fibre Channel cables

v Console (for example, a PC or notebook) with a serial port

v #2 Phillips screwdriver and slotted screwdriver

v Grounding leash and ESD strap

v 7-mm nut driver (required if removing or installing storage expansion units)

RJ-45 to DB-9 console adapter cables and serial null modem cables are provided by IBM with your shipment package.

Preparing for the installation 3

Handling static-sensitive devices

CAUTION: This system uses electronic components that are sensitive to static electricity. Static discharge from your clothing or other fixtures around you can damage these components. Put on an antistatic ESD strap and grounding leash to free yourself of static electricity before touching any electronic components.

Attention: Static electricity can damage electronic devices and your system. To

avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them.

To reduce the possibility of electrostatic discharge (ESD), observe the following precautions:

v Limit your movement. Movement can cause static electricity to build up around

you.

v Handle the device carefully, holding it by its edges or its frame.

v Do not touch solder joints, pins, or exposed printed circuitry.

v Do not leave the device where others can handle and possibly damage the

device.

v While the device is still in its static-protective package, touch it to an unpainted

metal part of the system unit for at least two seconds. This drains static electricity from the package and from your body.

v Remove the device from its package and install it directly into your system unit

without setting it down. If it is necessary to set the device down, place it in its static-protective package. Do not place the device on your system unit cover or on a metal table. Take additional care when handling devices during cold weather because heating reduces indoor humidity and increases static electricity.

Planning and organizing the installation

This section identifies the shipment contents and the rules and regulations you need to observe for the proper installation of your system. It also provides an overview of the entire system installation process and the appropriate documentation references for the procedures.

For detailed information, see the following topics:

v “Hardware specifications” on page 5

v “Checking shipment package contents” on page 9

v “Rules for installing the system in a rack” on page 10

v “Guide to the installation process” on page 11

Telecommunication regulatory statement

This product may not be certified in your country for connection by any means whatsoever to interfaces of public telecommunications networks. Further certification may be required by law prior to making any such connection. Contact an IBM representative or reseller for any questions.

4 IBM System Storage: N6200 Series Hardware and Service Guide

Hardware specifications

The following tables list the characteristics and requirements for your hardware.

30.9-36.4 kg (68-80 lbs)

n6200021

DANGER

The weight of this part or unit is between 30.9 and 36.4 kg (68 and 80 lb). It takes three persons to safely lift this part or unit.

Note: Operating at the extremes of the environmental requirements might increase

the risk of device failure.

Table 1. N6200 series physical characteristics

Weight

v 2858-C10 and 2858-C15 (single enclosure with one

controller): 30.9 kg (68 lb)

v 2858-C20, 2858-C21, and and 2858-C25 (single

enclosure with two controllers): 36.4 kg (80 lb)

v 2858-C22 (single enclosure with two controllers):

33.7 kg (74.3 lb)

v 2858-E12 (single enclosure with one controller and

one IOXM): 33.7 kg (74.3 lb)

v 2858-E11, 2858-E15, and 2858-E16 (single enclosure

with one controller and one IOXM): 33.6 kg (74 lb)

v 2858-E21, 2858-E25, and 2858-E26 (two enclosures,

each with one controller and one IOXM): 67.2 kg (148 lb)

v 2858-E22 (two enclosures, each with one controller

and one IOXM): 67.4 kg (148.6 lb)

Rack units

Height

Width

Depth

Table 2. N6200 series clearance dimensions

Airflow

Front 25.4 cm (10 in.)

Rear 30.5 cm (12 in.)

v 3U for single enclosure models

v 6U for dual enclosure models

v 13 cm (5.12 in.) for single enclosure models

v 26 cm (10.24 in.) for dual enclosure models

44.7 cm (17.6 in.)

61 cm (24 in.) without bezel65.5 cm (25.8 in.) with bezel

Preparing for the installation 5

Table 2. N6200 series clearance dimensions (continued)

Service

Front 76.2 cm (30 in.)

Rear 76.2 cm (30 in.)

Table 3. N6200 series environmental requirements

Operating temperature maximum range

Operating temperature recommended range

Nonoperating temperature range

Operating relative humidity

Nonoperating relative humidity

Recommended operating temperature relative humidity range

Maximum wet bulb temperature

Maximum altitude

Acoustic level

50° F to 104° F (10° C to 40° C)

68° F to 77° F (20° C to 25° C)

-40° F to 158° F (-40° C to 70° C)

20 to 80% noncondensing

10 to 95% noncondensing (in original container)

40 to 55%

28° C (82° F)

3050 m (10,000 ft.)

55.5 dBA, 7.5 bels at 23° C

The following tables list the maximum electrical power for the N6200 series systems and the electrical requirements for different configurations of the N6200 series systems.

Table 4. N6200 series systems maximum electrical power

System Maximum electrical power

N6200 series systems 100-240 V ac, 12-8 A, 50-60 Hz.

In the following tables, Worst-case indicates a system running with one PSU and high fan speed. Typical Per PSU/System, two PSUs indicates a system running one PSU on one circuit and a system running two PSUs on two circuits.

Note: Electrical requirements for systems containing performance accelerator, Flash Cache, and Flash Cache 2 modules are measured with the maximum number of these modules installed in the system. The maximum power draw is 25W.

Table 5. N6210 electrical requirements–one controller node, with one 256-GB Flash Cache module

100 to 120V 200 to 240V

Input voltage

Input current measured, A

Worstcase, single PSU

4.22 1.52 3.03 2.11 0.83 1.66

Per PSU

Typical

System, two PSUs Per PSU

Worstcase, single PSU

Typical

System, two PSUs

6 IBM System Storage: N6200 Series Hardware and Service Guide

Table 5. N6210 electrical requirements–one controller node, with one 256-GB Flash Cache module (continued)

100 to 120V 200 to 240V

Input voltage

Input power

Worstcase, single PSU

Per PSU

Typical

System, two PSUs Per PSU

421 150 299 411 147 293

Worstcase, single PSU

Typical

System, two PSUs

measured, W

Thermal

1,437 511 1,021 1,403 500 1,000 dissipation, BTU/hr

Input power

50 to 60 frequency, Hz

Table 6. N6210 electrical requirements–two controller nodes, with one 256-GB Flash Cache module per node

100 to 120V 200 to 240V

Input voltage

Input current

Worst-

case,

single

PSU

Per PSU

Typical

System, two PSUs Per PSU

6.27 2.32 4.64 3.11 1.19 2.38

Worstcase, single PSU

Typical

System, two PSUs

measured, A

Input power

626 231 462 612 225 450 measured, W

Thermal

2,137 789 1,577 2089 768 1,536 dissipation, BTU/hr

Input power

50 to 60 frequency, Hz

Table 7. N6220 electrical requirements–one controller node, with one 512-GB Flash Cache or Flash Cache 2 module

100 to 120V 200 to 240V

Input voltage

Input current

Worst-

case,

single

PSU

Per PSU

Typical

System, two PSUs Per PSU

4.31 1.55 3.09 2.41 0.87 1.73

Worstcase, single PSU

Typical

System, two PSUs

measured, A

Input power

431 155 309 421 152 303 measured, W

Thermal

1,437 511 1,021 1,403 500 1,000 dissipation, BTU/hr

Input power

50 to 60 frequency, Hz

Preparing for the installation 7

Table 8. N6220/N6240 electrical requirements–two controller nodes, with one 256-GB Flash Cache module or one 512-GB Flash Cache or Flash Cache 2 module per controller node

100 to 120V 200 to 240V

Input voltage

Input current measured, A

Input power measured, W

Thermal dissipation, BTU/hr

Input power frequency, Hz

Worstcase, single PSU

6.37 2.35 4.70 3.15 1.21 2.41

635 233 466 620 228 456

2,168 796 1,591 2,116 779 1,557

50 to 60

Per PSU

Typical

System, two PSUs Per PSU

Worstcase, single PSU

Typical

System, two PSUs

Note: N6220 does not support the 256-GB Flash Cache module.

Table 9. N6220/N6240 electrical requirements–one controller node, with one 256-GB Flash Cache module or one 512-GB Flash Cache or Flash Cache 2 module, and one I/O expansion module

100 to 120V 200 to 240V

Input voltage

Input current measured, A

Input power measured, W

Thermal dissipation, BTU/hr

Input power frequency, Hz

Worstcase, single PSU

5.01 1.86 3.71 2.50 0.98 1.96

500 184 368 478 180 360

1,707 628 1,256 1,632 615 1,229

50 to 60

Per PSU

Typical

System, two PSUs Per PSU

Worstcase, single PSU

Typical

System, two PSUs

Note: N6220 does not support the 256-GB Flash Cache module.

Table 10. N6270 electrical requirements–two controller nodes, with one 512-GB or one 1-TB Flash Cache or Flash Cache 2 module per controller node

100 to 120V 200 to 240V

Worstcase, single

Input voltage

Input current measured, A

Input power measured, W

PSU

7.28 2.78 5.56 3.58 1.42 2.83

728 278 552 707 271 541

Per PSU

8 IBM System Storage: N6200 Series Hardware and Service Guide

Typical

System, two PSUs Per PSU

Worstcase, single PSU

Typical

System, two PSUs

Table 10. N6270 electrical requirements–two controller nodes, with one 512-GB or one 1-TB Flash Cache or Flash Cache 2 module per controller node (continued)

100 to 120V 200 to 240V

Worst-

case,

single Input voltage

Thermal dissipation, BTU/hr

Input power frequency, Hz

Table 11. N6250/N6270 electrical requirements–one controller node, with one 512-GB or one 1-TB Flash Cache or Flash Cache 2 module, and one I/O expansion module

Input voltage

Input current measured, A

Input power measured, W

Thermal dissipation, BTU/hr

Input power frequency, Hz

PSU

2,485 942 1,884 2,413 924 1,847

50 to 60

100 to 120V 200 to 240V

Worst-

case,

single

PSU

5.47 2.07 4.14 2.73 1.07 2.13

547 204 408 533 199 398

1,867 697 1,393 1,820 680 1,359

50 to 60

Per PSU

Typical

System, two PSUs Per PSU

Typical

System, two PSUs Per PSU

Worstcase, single PSU

Typical

System, two PSUs

Typical

System, two PSUs

Checking shipment package contents

Make sure that your shipment package includes the following items for your N6200 series model.

Each shipment package will also contain envelopes with the software EULA and license keys.

v N6210 2858-C10 and N6220 2858-C15

– 1 single-enclosure, non-HA system with a single controller, containing any

options you ordered

– 1 console adapter cable, RJ-45 to DB-9

– 2 cable management arms (two per controller node)

– 1 ESD wrist strap

– 2 power cords

– 1 serial null modem cable

– 1 IBM rail kit

– 1 set of IBM publications

v N6240 2858-E11, N6220 2858-E15, N6250 2858-E16, and N6270 2858-E12

– 1 single-enclosure, non-HA system with a single controller and one

Input/Output expansion module (IOXM), containing any options you ordered

Preparing for the installation 9

– 1 console adapter cable, RJ-45 to DB-9

– 4 cable management arms (two per controller node, and two per IOXM)

– 1 ESD wrist strap

– 2 power cords

– 1 serial null modem cable

– 1 IBM rail kit

– 1 set of IBM publications

v N6210 2858-C20, N6240 2858-C21, N6220 2858-C25, and N6270 2858-C22

– 1 single-enclosure HA system with two controllers, containing any options

you ordered

– 2 console adapter cables, RJ-45 to DB-9

– 4 cable management arms (two per controller node)

– 1 ESD wrist strap

– 2 power cords

– 2 serial null modem cables

– 1 IBM rail kit

– 1 set of IBM publications

v N6240 2858-E21, N6220 2858-E25, N6250 2858-E26, and N6270 2858-E22:

– 1 dual-enclosure HA system, containing any options you ordered. Each

enclosure ships in a separate container, and each enclosure contains one controller and one Input/Output expansion module.

– 2 console adapter cables, RJ-45 to DB-9 (1 per enclosure)

– 8 cable management arms (two per controller node, and two per IOXM, for a

total of 4 per enclosure)

– 2 ESD wrist straps (1 per enclosure)

– 4 power cords (2 per enclosure)

– 2 serial null modem cables (1 per enclosure)

– 2 cluster connection cables (either SFP+ integrated copper cables or 10GbE

SFP+ transceivers with fiber cables, depending on your order)

– 2 IBM rail kits (1 per enclosure)

– 1 set of IBM publications

Rules for installing the system in a rack

Attention: The rack installation instructions provided in this document and in the

Installation and Setup Instructions for your N series product apply specifically to the installation of the N series product in an IBM 19-inch rack. IBM service personnel cannot install the N series product in a non-IBM rack.

If the N series product is being installed in a non-IBM rack, the rails shipped with the N series product may or may not work with the non-IBM rack. Physical installation of the N series product in a non-IBM rack is the customer's responsibility.

You need to observe the following rules and restrictions when installing an N6200 series system in a standard IBM 19-inch (48.26 cm) equipment rack with mounting rails:

10 IBM System Storage: N6200 Series Hardware and Service Guide

30.9-36.4 kg (68-80 lbs)

n6200021

DANGER

The weight of this part or unit is between 30.9 and 36.4 kg (68 and 80 lb). It takes three persons to safely lift this part or unit.

v Install the system at the bottom of your configuration, so that stacks or loops

extend above your system.

DANGER

To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet. Always install servers and optional devices starting from the bottom of the rack cabinet. (R001 part 1 of 2)

v When installing storage expansion units in a rack, do not exceed the maximum

storage limit for your system.

v Make sure that the ID on the back panel of each storage expansion unit matches

the ID specified on its label.

v Always install the storage expansion units fully loaded. Do not remove disk

drives to reduce the weight.

Guide to the installation process

The following table provides a guide to the filer installation process.

Attention: Before you begin your installation, print and complete a configuration worksheet for your storage system to gather the information that the software setup process requires. The configuration worksheet is provided in the Data ONTAP Software Setup Guide for your version of Data ONTAP. This guide, as well as other Data ONTAP publications, is available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

If you are configuring a storage system as part of a high-availability (or active/active) configuration, some information types must be unique for each storage system mode in the configuration, and some information types must be identical on both storage system nodes. If you have a high-availability (or active/active) configuration, IBM recommends that you print and complete two copies of the configuration worksheet, one for each system node.

Refer to the Installation and Setup Instructions that shipped with your system and storage expansion units for complete installation details.

Note: The initial hardware installation of an N6200 series gateway is performed by IBM. Additional installation services can be performed by IBM through an IBM services offering. Contact your IBM representative for more information.

Preparing for the installation 11

Table 12. Filer installation process procedures

Is the procedure

Stage Procedure

1 Print and complete

a configuration worksheet for each system node of your storage system to gather the information that the software setup process requires.

2 Install the system

in a standard IBM 19-inch rack.

3 Connect the system

to the IP (Internet Protocol) network.

Filer: Connect the storage system to storage expansion units.

4 Gateway: Connect

the system to the back-end storage.

5 Connect the system

to a power source.

6 Configure the

system.

7 Connect the system

to a third-party device.

required?

Yes Customer Customer The configuration worksheet

Yes Customer IBM The Installation and Setup

Yes Customer Customer “Connecting your system to

Yes Customer n/a “Connecting a filer to storage

Yes n/a Customer Refer to the documentation

Yes Customer Customer “Connecting your system to

Yes Customer Customer The Data ONTAP Software

No Customer Customer “Connecting your system to

Procedure is performed by...

For instructions, see...Filer Gateway

is provided in the Data ONTAP Software Setup Guide

for your version of Data ONTAP.

Instructions for your system

an IP network” on page 13, or the Installation and Setup Instructions that came with your system

expansion units” on page 15, or the Installation and Setup Instructions that came with your system

for your external storage for additional information.

a power source” on page 13, or the Installation and Setup Instructions that came with your system

Setup Guide for your version of Data ONTAP, or the

Installation and Setup Instructions that came with

your system

storage” on page 15

12 IBM System Storage: N6200 Series Hardware and Service Guide

Connecting an N6200 series system

This chapter describes how to connect an N6200 series system in the following topics:

v “Connecting your system to a power source”

v “Connecting your system to an IP network”

v “Connecting your system to storage” on page 15

v “Connecting your system to an ASCII terminal console” on page 19

Connecting your system to a power source

The N6200 series systems are shipped with redundant power supplies, referred to as PSU1 and PSU2. Each power supply has its own AC power cord. You should have separate circuit breakers for each power supply to ensure power redundancy.

For information on connecting your N6200 series system to a power source, see the Installation and Setup Instructions that came with your system.

Figure 6. Rear view

1 Controller module

2 I/O expansion module

3 PSUs

Connecting your system to an IP network

Each node of your system connects to an IP network. If you have an active/active or high availability system, both nodes need to connect to the network. For information that describes how to connect your system, refer to the Installation and Setup Instructions that came with your system.

The N6200 series system has two onboard Ethernet ports per controller node, labeled e0a and e0b, as shown in Figure 7 on page 14. For the 2858-C10, 2858-C15, 2858-C20, 2858-C21, 2858-C22, and 2858-C25 up to two Network Interface Cards (NICs) per node can be plugged into the PCI slots to provide additional Ethernet ports. For the 2858-E11, 2858-E12, 2858-E15, 2858-E16, 2858-E21, 2858-E22, 2858-E25,

n62hw01

and 2858-E26, up to six Network Interface Cards (NICs) per node can be plugged into the PCI slots to provide additional Ethernet ports.

The integrated Ethernet RJ-45 twisted-pair connectors are compatible with the IEEE

802.3 Ethernet network 10/100/1000 BASE-TX link. When connecting to the Ethernet port, connect a twisted-pair (CAT-5 or better) cable to the RJ-45 Ethernet port located on the back of the system drawer.

If you are connecting to a copper NIC, use RJ-45 CAT-5 or better copper cables.

If you are connecting to a fiber NIC, use (50- or 62.5-micron) fiber-optic cables with LC connectors.

For information about monitoring the Ethernet port LEDs, see the IBM System Storage N Series Platform Monitoring Guide.

LNK LNK

c0b

c0a

e0a

e0b

6810

Figure 7. Appliance ports and LEDs

1 NVMEM LED

2 Controller fault LED

3 USB (top) and serial console (bottom) ports

4 Private management 10/100 Mb Ethernet port

5 Management Ethernet 10/100 Mb port and LEDs

6 1-GbE ports (e0a and e0b)

7 1-GbE port LEDs

8 Fibre Channel ports (0c and 0d)

9 Fibre Channel port LEDs

10 HA ports (c0a and c0b)

11 HA port LEDs

12 SAS ports

13 SAS port LEDs

579

234

n62hw03

14 IBM System Storage: N6200 Series Hardware and Service Guide

Connecting your system to storage

For SAS connections, the N6200 series system has two onboard SAS ports per node, labeled 0a and 0b, as shown in Figure 7 on page 14. For the 2858-C10, 2858-C15, 2858-C20, 2858-C21, 2858-C22, and 2858-C25,up to two SAS HBAs per node can be plugged into the PCI slots to provide additional SAS ports. For the 2858-E11, 2858-E12, 2858-E15, 2858-E21, 2858-E22, and 2858-E25, up to six SAS HBAs per node can be plugged into the PCI slots to provide additional SAS ports.

For Fibre Channel connections, the N6200 series system has two onboard Fibre Channel ports per node, labeled 0c and 0d, as shown in Figure 7 on page 14. For the 2858-C10, 2858-C15, 2858-C20, 2858-C21, 2858-C22, and 2858-C25, up to two HBAs per node can be plugged into the PCI slots to provide additional Fibre Channel ports. For the 2858-E11, 2858-E12, 2858-E15, 2858-E21, 2858-E22, and 2858-E25, up to six HBAs per node can be plugged into the PCI slots to provide additional Fibre Channel ports. Attach the (50- or 62.5-micron) fiber-optic cables with LC connectors to the Fibre Channel ports.

Note: SFPs must be firmly seated in the Fibre Channel ports before making connections.

Connecting a filer to storage expansion units

You must connect at least one storage expansion unit per controller module to your N6200 series filer. A single-controller filer (C10/C15/E11/E12/E15/E16) must be connected to at least one storage expansion unit. A dual-controller (active/active or high availability) filer (C20/C21/C22/C25/E21/E22/E25//E26) must be connected to at least two storage expansion units.

Connecting to SAS storage expansion units

You must use SAS and ACP cables for the connections from the filer to SAS storage expansion units

For information that describes how to connect your N6200 series filer to SAS storage expansion units using the onboard SAS ports, see the Installation and Setup Instructions that came with your system.

For detailed information about cabling SAS storage expansion units, see the IBM System Storage N series Universal SAS and ACP Cabling Guide.

Connecting to EXN1000 and EXN4000 storage expansion units

For connections to EXN1000s and EXN4000s, you must use fiber-optic cables for the connection from the filer to the first storage expansion unit.

For information that describes how to connect your filer using the onboard Fibre Channel ports to storage expansion units, see the Installation and Setup Instructions that came with your storage expansion units.

Attention: If you are connecting to EXN1000 and EXN4000 storage expansion units, make sure that all storage expansion unit (1Gb/2Gb/4Gb) switches are set to the 2Gb or 4Gb (if supported) position. If necessary, refer to the documents that came with the storage expansion unit for information about checking and changing the switch setting.

Connecting an N6200 series system 15

Attention: If you are using optional Fibre Channel adapter cards instead of the onboard Fibre Channel ports to connect your N6200 series filer to storage expansion units, see the cabling instructions described in “Cabling an N6200 series system to Fibre Channel switches using a Fibre Channel expansion adapter.”

Dual-path Fibre Channel cabling is supported for N6200 series filers. Dual-path Fibre Channel cabling is designed to improve reliability, availability and serviceability of the storage expansion units attached to the storage controller by creating two redundant paths from each storage controller to each loop of the storage expansion units. For more information about using dual-path Fibre Channel cabling, see the Installation and Setup Instructions that came with your system.

Important: If you are not using the onboard Fibre Channel ports for storage, then you must set your onboard ports to Target mode, as described in the IBM System Storage N series Data ONTAP Block Access Management Guide for your version of Data ONTAP. This guide, as well as other Data ONTAP publications, is available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Cabling an N6200 series system to Fibre Channel switches using a Fibre Channel expansion adapter

About this task

This section describes how to cable an N6200 series system to Fibre Channel switches using a dual-port optical Fibre Channel expansion adapter for expansion unit storage. The example shown in this section illustrates the connections for a single-enclosure HA pair, such as the N6210 2858-C20, N6240 2858-C21, N6270 2858-C22, or N6220 2858-C25.

For a list of optional adapter cards supported by your N6200 series system, refer to the appropriate "Optional adapter cards" appendix in the IBM System Storage N series Introduction and Planning Guide. This guide, as well as other N series and Data ONTAP documentation, is available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Important: If you are not using the onboard Fibre Channel ports for storage, then you must set your onboard Fibre Channel ports to Target mode, as described in the IBM System Storage N series Data ONTAP Block Access Management Guide for your version of Data ONTAP.

Note: The illustrations in the following sections show connections to EXN4000 storage expansion units. In EXN1000 storage expansion units, the positions of the In and Out ports are reversed from those of the EXN4000.

Procedure

1. As shown in Figure 8 on page 17, cable onboard ports 0c of both the top and

bottom controller modules (CM-A and CM-B) to two ports on one Fibre Channel switch.

2. As shown in Figure 8 on page 17, cable onboard ports 0d of both the top and

bottom controller modules (CM-A and CM-B) to two ports on a second Fibre Channel switch.

16 IBM System Storage: N6200 Series Hardware and Service Guide

OUT

PSU PSU

IN OUT

OUT

PSU PSU

OUT

PSU

CM-A

0a 0b

CM-B

0a 0b

e0a

c0a

c0b

e0b

e0a

c0a

c0b

e0b

PSU

EXN

N6200

n62hw023

FC Switch 1

FC Switch 2

Figure 8. Cabling the N6200 series system to Fibre Channel switches

3. As shown in Figure 9 on page 18, cable the dual-port expansion adapter Port 1a

on the top controller module (CM-A) to the first storage expansion unit Channel A ESH4 or AT-FCX IN port.

4. As shown in Figure 9 on page 18, cable the dual-port expansion adapter Port 1a

on the bottom controller module (CM-B) to the first storage expansion unit Channel B ESH4 or AT-FCX IN port.

5. As shown in Figure 9 on page 18, cable the first storage expansion unit Channel

A ESH4 or AT-FCX OUT port to the next storage expansion unit Channel A ESH4 or AT-FCX IN port. Label this cable with a solid-colored label.

6. As shown in Figure 9 on page 18, cable the first storage expansion unit Channel

B ESH4 or AT-FCX OUT port to the storage expansion unit Channel B ESH4 or AT-FCX IN port. Label this cable with a solid-colored label.

7. Repeat Steps 5 and 6, connecting OUT port to IN port, for the remaining

storage expansion units in the loop.

Do not plug any cables in the ESH4 or AT-FCX OUT port of the last unit. The storage expansion units are self-terminating.

Note: The ESH4 is self-terminating and does not have a terminate switch. The AT-FCX is self-terminating.

Connecting an N6200 series system 17

OUT

PSU PSU

IN OUT

OUT

PSU PSU

OUT

PSU

CM-A

0a 0b

CM-B

0a 0b

e0a

c0a

c0b

e0b

e0a

c0a

c0b

e0b

PSU

EXN

N6200

n62hw024

FC Switch 1

FC Switch 2

Figure 9. Cabling the N6200 series system expansion adapter to storage expansion units

8. As shown in Figure 10, cable the dual-port expansion adapter Port 1b on the

top controller module (CM-A) to the last storage expansion unit Channel B ESH4 or AT-FCX OUT port.

9. As shown in Figure 10, cable the dual-port expansion adapter Port 1b on the

bottom controller module (CM-B) to the last storage expansion unit Channel A ESH4 or AT-FCX OUT port.

OUT

PSU PSU

IN OUT

OUT

PSU PSU

OUT

PSU

CM-A

0a 0b

CM-B

0a 0b

e0a

c0a

c0b

e0b

e0a

c0a

c0b

e0b

PSU

EXN

N6200

n62hw025

FC Switch 1

Figure 10. Cabling the N6200 series system expansion adapter to storage expansion units

Connecting a gateway to external storage

You must use fiber-optic cables to connect a gateway to external storage on a Fibre Channel SAN.

18 IBM System Storage: N6200 Series Hardware and Service Guide

FC Switch 2

See the Gateway Interoperability Matrix at the following web page for supported third-party storage for your N6200 series system:

www.ibm.com/systems/storage/network/interophome.html

Refer to the documentation for your external storage for additional information.

Connecting to a third-party device

You can connect third-party devices to your system through an optical Fibre Channel interface using any Fibre Channel port on the back of the chassis.

The N6200 series systems only support third-party devices with an optical Fibre Channel interface. For supported devices for your system, see the Interoperability Matrix on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Refer to the documentation that comes with the third-party device for connection information.

Rules for connecting the third-party devices

Observe the following rules for connecting the third-party devices:

v Use a fiber-optic cable that is:

– Appropriate to the Fibre Channel connection on your N6200 series system

– Of an approved length for the third-party device

Note: See the documentation for the third-party device.

v An unsupported tape backup device might cause the system to halt. To verify

support for your third-party device, check the Interoperability Matrix on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

v For additional information about Fibre Channel cables, see the IBM N series

support website.

Connecting your system to an ASCII terminal console

The ASCII terminal console enables you to monitor the boot process, helps you configure your system after it boots, and enables you to perform system administration.

For information about ASCII terminal console wiring, DB-9 to RJ-45 console adapter pin connections, and connecting your system to an ASCII terminal console, see the IBM System Storage N series Introduction and Planning Guide. This guide, as well as other N series documentation, is available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Connecting an N6200 series system 19

20 IBM System Storage: N6200 Series Hardware and Service Guide

Configuring an N6200 series system

v “Configuring the N6200 series system”

v “Configuring the Fibre Channel port”

For information about monitoring the LEDs for your N6200 series system and optional adapter cards, refer to the IBM System Storage N series Platform Monitoring Guide.

For diagnostic information about your N6200 series system, see the IBM System Storage N series System-Level Diagnostics Guide.

Configuring the N6200 series system

Refer to the completed configuration worksheet for your storage system. The configuration worksheet is provided in the Data ONTAP Software Setup Guide for your version of Data ONTAP, available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

For information about how to boot your filer for the first time, refer to the Installation and Setup Instructions that came with your system.

For gateway systems, initial startup and configuration tasks must be performed by IBM. For additional information about gateway systems, refer to the list of gateway documentation provided in the "Bibliography" appendix of the IBM System Storage N series Introduction and Planning Guide. This guide, as well as other N series documentation, is available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Configuring the Fibre Channel port

Each N6200 series system controller module provides two independent Fibre Channel ports, identified as 0c and 0d. SFPs must be firmly seated in all four ports before connecting cables.

The Fibre Channel ports can operate in target or initiator mode. Fibre Channel ports do not support mixed initiator/target mode. The default mode for the ports is initiator mode. You do not need to configure the ports to use them in initiator mode.

The Fibre Channel ports should be used in initiator mode to communicate with tape backup devices, such as in a TapeSAN backup configuration.

Fibre Channel ports on HBAs cannot be configured in target mode. They can only be used in initiator mode.

Configuring for initiator mode

About this task

To configure the system back to initiator mode, complete the following steps.

Procedure

1. Set the specified onboard ports to operate in initiator mode by entering the

following command:

fcadmin config -t initiator adapter

where adapter is the port number. You can specify more than one port.

Example: The following example sets onboard ports 0c and 0d to initiator mode.

fcadmin config -t initiator 0c 0d

2. Reboot the system by entering the following command:

reboot

3. Verify that the Fibre Channel ports are online and configured in the correct

state for your configuration by entering the following command:

fcadmin config

Example: The following output example shows two ports configured as Fibre Channel targets and two ports configured as initiators.

n6000a> fcadmin config

Adapter Type State Status

--------------------------------------------------0a target CONFIGURED online 0b target CONFIGURED online 0c initiator CONFIGURED online 0d initiator CONFIGURED online

Local

Results

For information on converting the onboard ports to target mode and configuring your SAN, see the IBM System Storage N series Data ONTAP Block Access

Management Guide or IBM System Storage N series Data ONTAP SAN Administration Guide for your version of Data ONTAP. This guide, as well as other Data ONTAP

publications, is available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Configuring and using the Service Processor

The Service Processor (SP) enables you to remotely access, monitor, and troubleshoot N6200 series systems.

The following table provides a list of documents for configuring and using the Service Processor. These documents are available on the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

Table 13. Service Processor manuals

Manual Title Information Provided

IBM System Storage N series System-Level Diagnostics Guide

Data ONTAP System Administration Guide for

your version of Data ONTAP

IBM System Storage N series Platform Monitoring Guide

Lists and describes the diagnostic tests for the Service Processor.

Describes Service Processor cabling, configuration and use.

Lists Service Processor error messages and gives corrective actions for the error.

22 IBM System Storage: N6200 Series Hardware and Service Guide

Replacing N6200 series system devices

This chapter describes how to replace parts in your N6200 series system.

This chapter discusses the following topics:

v “Replacing a fan module in an N6200 series system” on page 26

v “Replacing a power supply on an N6200 series system” on page 28

v “Replacing an NVMEM battery or NVMEM DIMMs in an N6200 series system”

on page 30

v “Replacing a system DIMM in an N6200 series system” on page 42

v “Replacing PCIe cards in an N6200 series system” on page 51

v “Replacing a boot device in an N6200 series system running Data ONTAP 7.3.5

and later releases in the Data ONTAP 7.3 release family” on page 59

v “Replacing a boot device in an N6200 series system running Data ONTAP 8.x”

on page 65

v “Replacing the I/O expansion module in an N6200 series system” on page 87

v “Replacing the Real-Time Clock (RTC) battery in an N6200 series system” on

page 94

Figure 11 shows the locations of components at the front of your N6200 series system.

Figure 11. N6200 series system components - Front

Fan module

System LEDs - power fault, controller A activity, controller B activity

Fan CAM handle

Fan LED

n62hw02

Figure 12 shows the locations of components at the rear of your N6200 series system.

Figure 12. N6200 series system components - Rear

n62hw01

Controller module

I/O expansion module

PSUs

Figure 13 shows a view of the ports and LEDs of your N6200 series system.

LNK LNK

Figure 13. N6200 series ports and LEDs

c0b

c0a

579

e0a

e0b

6810

234

n62hw03

NVMEM LED

Controller fault LED

USB (top) and serial console (bottom) ports

Private management 10/100 Mb Ethernet port

Management Ethernet 10/100 Mb port and LEDs

1-GbE ports (e0a and e0b)

24 IBM System Storage: N6200 Series Hardware and Service Guide

1-GbE port LEDs

Fibre Channel ports (0c and 0d)

Fibre Channel port LEDs

HA ports (c0a and c0b)

HA port LEDs

SAS ports

SAS port LEDs

Figure 14 shows an exploded view of the components of your N6200 series system.

1 2 3 4

1 2

Figure 14. N6200 series system components - Exploded view

NVMEM (1, 2) and system DIMMs (1, 2, 3, 4)

DIMM and NVMEM DIMM slots

CPU air ducts

Replacing N6200 series system devices 25

n62hw04

PCIe card(s)

PCIe side panel

Boot device

Boot device enclosure

RTC battery holder and battery

NVMEM battery

NVMEM battery cable

Replacing a fan module in an N6200 series system

To replace a fan module, you must perform a specific sequence of tasks.

About this task

The fan module is hot-swappable and can be replaced without interrupting service.

Removing a fan module

You can remove a fan module without powering down the system.

About this task

Attention: You must replace the fan module within two minutes of removing it from the chassis. System airflow is disrupted and the controller module or modules shut down after two minutes to avoid overheating.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Remove the bezel (if necessary) with two hands, by grasping the openings on

each side of the bezel, and then pulling it toward you until the bezel releases from the four ball studs on the chassis frame.

3. Identify the fan module that you must replace by checking the console error

messages and looking at the Status LED on each fan module cam handle. A failed fan module LED is solid amber, indicating that the fan module failed. No LEDs are lit if the fan module is not receiving power.

4. Press down the release latch on the fan module cam handle and pull the cam

handle downward. The fan module moves a little bit away from the chassis.

26 IBM System Storage: N6200 Series Hardware and Service Guide

Figure 15. N6200 series system fans

Cam handle

Fan module

Cam handle release latch

Fan module status LED

5. Pull the fan module straight out from the chassis, making sure that you

support it with your free hand, so that it does not swing out of the chassis.

Attention: The fan modules are short. Always support the bottom of the module with your free hand so that it does not suddenly drop free from the chassis and injure you.

6. Set the fan module aside.

Installing a fan module

To install a fan module, you must perform a specific sequence of steps.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Remove the bezel, if necessary.

3. Insert the replacement fan module into the chassis by aligning it with the

opening and sliding it into the chassis.

4. Push firmly on the fan module cam handle to ensure that it is seated all the

way into the chassis. The cam handle raises slightly when the fan module is completely seated.

5. Swing the cam handle up to its closed position, making sure that the cam

handle release latch clicks into the locked position.

6. Reinstall the bezel.

7. Run diagnostics on the replacement fan module during the next scheduled

system downtime. See the IBM System Storage N series System-Level Diagnostics Guide for more information.

Replacing N6200 series system devices 27

Completing the replacement process

Return the failed part to IBM. Contact IBM Service and Support at 1-800-IBM-SERV (1-800-426-7378) for more information on the return procedure.

Replacing a power supply on an N6200 series system

To replace a power supply in the system, you must perform a specific sequence of tasks.

About this task

v All other components in the system must be functioning properly; if not, contact

technical support.

v The power supplies are redundant, and are hot-swappable and interchangeable.

v To prevent system downtime, replace only one power supply at a time.

Note: Power supplies are auto-ranging. See the IBM System Storage N series Introduction and Planning Guide for more information.

Removing a power supply

To remove a power supply, you must follow the steps to identify the one you want to remove, disconnect the power cord, and remove the power supply from the chassis.

About this task

Attention: You should replace the power supply within two minutes of removing it from the chassis.

Procedure

1. Identify the power supply you want to replace, based on console error

messages or through the LEDs on the power supplies. See the IBM System Storage N series Platform Monitoring Guide for a description of LED behaviors.

2. If you are not already grounded, properly ground yourself.

3. Turn off the target power supply and remove the power cord by completing

the following substeps, using the illustration for reference:

28 IBM System Storage: N6200 Series Hardware and Service Guide

Figure 16. Removing the power supply

Power supply

Cam handle release latch

Power and Fault LEDs

Cam handle

Power cord locking mechanism

Note: If you are having difficulty unplugging the power supply, remove the cable management arm from the controller module.

a. Pinch the tab on the locking mechanism of the cable retainer clip, and then

open the retainer clip.

b. Slide the retainer clip off the cord.

c. Unplug the power cord from the power source, and then remove the power

cord from the power supply.

4. Press down the release latch on the power supply cam handle, lower the cam

handle to the fully open position, and then slide the power supply out of the chassis. Make sure that you support the power supply with your free hand.

Installing a power supply

To install a power supply, you must place the power supply in the chassis, secure it, and reconnect the power cord to the power source.

Procedure

1. Make sure that the on/off switch of the new power supply is in the Off

position.

2. If you are not already grounded, properly ground yourself.

Replacing N6200 series system devices 29

3. Align the edges of the power supply with the opening in the system chassis

and gently push the power supply into the chassis.

4. Push on the power supply cam handle to seat it all the way into the chassis,

and then push the cam handle to the closed position, making sure that the cam handle release latch clicks into its locked position.

5. Reconnect the power cord and secure it to the power supply using the cable

retaining clip.

6. Reconnect the power supply to the power source, and then turn it on. The

power supply should run with no fault LEDs lit.

Note: Reinstall the cable management arm, if you removed it when unplugging the power supply.

7. Run diagnostics on the power supply at the next reboot. See the IBM System

Storage System-Level Diagnostics Guide for more information.

Completing the replacement process

Return the failed part to IBM. Contact IBM Service and Support at 1-800-IBM-SERV (1-800-426-7378) for more information on the return procedure.

Replacing an NVMEM battery or NVMEM DIMMs in an N6200 series system

To replace an NVMEM battery or NVMEM DIMMs in the system, you must remove the controller module from the system, open it, replace the battery, and close and replace the controller module.

About this task

v This procedure refers to HA pairs, which in releases prior to Data ONTAP 8.0

were called active/active configurations.

v All other components in the system must be functioning properly; if not,

contact technical support.

Shutting down the node

You shut down a node using different procedures, depending on whether it is a stand-alone system or part of an HA pair.

Shutting down a node in an HA pair

To shut down the node, you must determine the status of the node and, if necessary, take over the node so that the partner continues to serve data from the node's storage.

Before you begin

Note: If your system has two controller modules in the same chassis, you must leave the power supplies turned on at the end of this procedure to provide power to the partner node.

Procedure

1. Check the status of the target node (the node you want to perform maintenance

on) by entering the following command at the system console of either node:

30 IBM System Storage: N6200 Series Hardware and Service Guide

For... Issue the command...

7-Mode cf status

Clustered Data ONTAP storage failover show

2. Take one of the following actions, depending on the result of the cf status or

storage failover command:

If... Then...

Neither node is in takeover mode Go to the next step in this procedure.

The partner node took over the target node The target node is in a state where you can

begin removing it from the system chassis.

Continue with the task "Opening the system".

The target node took over the partner node

1. Correct the problem that caused the

takeover.

2. Enter the cf giveback command (7-Mode) or storage failover giveback

-fromnode nodename command (Clustered Data ONTAP) from the target node console.

3. Go back to the beginning of this procedure.

3. Take over the target node by entering one of the following commands from the

partner node’s console:

For... Issue the command...

7-Mode cf takeover

Clustered Data ONTAP storage failover takeover -bynode node

Shutting down the node in a stand-alone system

For a node that is in a stand-alone configuration, you must perform a clean shutdown to ensure that all data has been written to disk and disconnect the power supplies.

Procedure

1. Enter the following commands from the system console:

If your system is configured in... Then issue this command...

7-Mode halt

Clustered Data ONTAP halt local

After you issue the command, wait until the system stops at the LOADER prompt.

Replacing N6200 series system devices 31

Attention: You must perform a clean system shutdown before replacing system components to avoid losing unwritten data in the nonvolatile memory (NVMEM). The NVMEM LED is located on the controller module to the right of the network ports, marked with a battery symbol. If the NVMEM LED is flashing, there is content in the NVMEM that has not been saved to disk. You need to reboot the controller module and proceed from the beginning of this procedure. If repeated attempts to cleanly shut down the controller module fail, be aware that you might lose any data that was not saved to disk.

LNK LNK

Figure 17. NVMEM LED

NVMEM LED

2. If you are not already grounded, properly ground yourself.

3. Turn off the power supplies, unplug the power cords from the power source,

and remove the power cords.

Opening the system

To access components inside the controller module, you must open the system.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Unplug the system cables and SFPs from the controller module, as needed, and

keep track of where the cables were connected. Leave the cables in the cable management arm, so that when you reinstall the cable management arm in the controller module, the cables will be organized.

3. Disconnect the right and left cable management arms from the controller

module. To release the arms, press the silver button on the power supply side of each arm, and then remove the arm from the controller module.

c0a

c0b

e0a

e0b

32 IBM System Storage: N6200 Series Hardware and Service Guide

LNK

4. Loosen the thumbscrew on the cam handle.

5. Pull the cam handle downward and slide the controller module out of the

system.

Removing an NVMEM battery from an N6200 series system

You must complete a specific sequence of steps to remove the NVMEM battery from the controller module.

Procedure

1. Open the CPU air duct.

2. Locate the battery, squeeze the clip on the face of the battery plug to release the

plug from the socket, and then lift the battery cable from the socket.

v If you are only replacing NVMEM DIMMs, and you are not replacing the

NVMEM battery, go to “Removing the NVMEM DIMM” on page 35.

v If you are replacing the NVMEM battery, continue with the next step in this

procedure.

Replacing N6200 series system devices 33

Figure 18. NVMEM battery location

CPU air duct

NVMEM battery

NVMEM battery plug

NVMEM battery locking tab

3. Gently pull the locking tab on the battery housing, near the plug, away from

the controller module side.

4. Place your forefinger at the far end of the battery housing and gently push it

toward the CPU air duct. You should see the tabs on the battery housing aligning with the notches in the controller module sheet metal.

34 IBM System Storage: N6200 Series Hardware and Service Guide

1 2 3

Figure 19. Removing the NVMEM battery

NVMEM battery

NVMEM battery alignment marker

Chassis alignment marker

5. Gently pull the battery housing toward the center of the controller module and

then lift the battery out of the controller module.

6. Continue with one of the following tasks:

Option Description

If you are also replacing the NVMEM DIMMS

If you are replacing only the NVMEM battery, and not replacing the NVMEM DIMMS

Removing the NVMEM DIMM

To remove the N6200 series NVMEM DIMM, you must perform a specific sequence of steps.

Before you begin

Continue with “Removing the NVMEM DIMM”

Continue with “Installing an NVMEM battery” on page 38

You must unplug the NVMEM battery from the controller module before you remove the NVMEM DIMM.

Replacing N6200 series system devices 35

Procedure

1. If you are not already grounded, properly ground yourself.

2. Open the CPU air duct, if necessary, and locate the DIMMs on the controller

module. The NVMEM DIMMs are located in DIMM slots 1 and 2, and have white DIMM locking tabs. There is also a fault LED for these DIMMs.

This illustration shows a system fully populated with DIMMs:

1 2

1 2 3 4

1 2

Figure 20. DIMM locations

NVMEM DIMMs 1 and 2.

System DIMMs 1 through 4.

The number of DIMMs in your system will vary. DIMM sockets 1 and 2 are always populated in all N6200 series models, while DIMM sockets 3 and 4 are only populated in the N6270.

DIMM sockets.

The NVMEM DIMM sockets have white DIMM locking tabs, while the system DIMM sockets have black locking tabs.

3. Note the orientation of the DIMM in the socket so that you can insert the

replacement DIMM in the proper orientation.

36 IBM System Storage: N6200 Series Hardware and Service Guide

4. Slowly press down simultaneously on the two DIMM ejector tabs to eject the

DIMM from its slot, and then lift it out of the slot.

Figure 21. Removing DIMMs

CAUTION: The DIMMs are located very close to the CPU heat sync, which might still be hot. Avoid touching the CPU heat sync when removing the DIMM.

Attention: Carefully hold the DIMM by the edges to avoid pressure on the

components on the DIMM circuit board.

5. Repeat these steps to remove additional DIMMs as needed.

Installing the system DIMMs

To install one or more system DIMMs, you must perform a specific sequence of steps.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Locate the slot where you are installing the new DIMM.

3. Remove the replacement DIMM from the antistatic shipping bag, hold the

DIMM by the corners, and align it over the slot. The notch among the pins on the DIMM should line up with the tab in the socket.

4. Insert the DIMM straight into the slot. The DIMM fits tightly in the slot, but

should go in easily. If not, realign the DIMM with the slot and reinsert it.

Attention: Visually inspect the DIMM to verify that it is evenly aligned and fully inserted into the slot.

5. Push carefully, but firmly, on the top edge of the DIMM until the latches snap

into place over the notches at the ends of the DIMM.

6. Repeat the preceding steps to install additional DIMMs as needed.

v If you are only replacing the DIMM, plug in the battery, close the CPU air

duct, and then go to “Reinstalling the controller module and booting the system” on page 38.

v If you are replacing both the DIMMs and the NVMEM battery, continue with

the next step and the following topics.

7. Close the CPU air duct.

Replacing N6200 series system devices 37

Installing an NVMEM battery

To install an NVMEM battery in the controller module, you must perform a specific sequence of steps.

Procedure

1. Align the tabs on the battery holder with the notches in the controller module

side, and gently push the battery housing so that the notches are under the lip of the controller module side.

1 2 3

Figure 22. Installing the NVMEM battery

NVMEM battery

Battery tabs

Notch on chassis with alignment arrow

2. While gently pushing the battery against the sheet metal on the chassis to hold

it in the battery guide, place the forefinger of your free hand against the battery housing behind the locking tab on the battery, and then gently push the battery housing away from the CPU air duct. If it is properly aligned, the battery snaps into place on the side of the controller module. If it does not, repeat these steps.

3. Seat the battery in the holder and plug it into the controller module.

The plug should lock down onto the socket on the controller module.

4. Close the CPU air duct, if necessary.

Reinstalling the controller module and booting the system

After you replace a component within the controller module, you must reinstall the controller module in the system chassis.

38 IBM System Storage: N6200 Series Hardware and Service Guide

About this task

Note: For HA pairs with two controller modules in the same chassis, the sequence in which you reinstall the controller module is especially important because it attempts to reboot as soon as you completely seat it in the chassis. Read this entire

section before you reinstall the controller module in an HA pair.

Procedure

1. Align the end of the controller module with the opening in the chassis, if

necessary, and then gently push the controller module halfway into the system.

2. Reinstall the cable management arms and recable the controller module, as

needed.

When recabling, remember to reinstall the media converters (SFPs) if you are using fiber cables.

3. Reinstall the controller module:

If your system is in... Then perform these steps...

An HA pair in which both controller modules are in the same chassis

A stand-alone configuration or an HA pair in which both controller modules are in separate chassis

1. Be prepared to interrupt the boot process.

The controller module begins to boot as soon as it is fully seated in the chassis.

2. With the cam handle in the open position, insert the controller module into the chassis, firmly pushing until the controller module meets the midplane, and then close the cam handle so that the latch clicks into the locked position and the controller module is fully seated.

Attention: Do not use excessive force when sliding the controller module into the chassis; you might damage the connectors.

3. As the system begins to boot, press Ctrl-c to interrupt the boot process.

1. With the cam handle in the open position, insert the controller module motherboard tray into the chassis, firmly pushing until the controller module meets the midplane, and then close the cam handle so that the latch clicks into the locked position and the controller module is fully seated.

Attention: Do not use excessive force when sliding the controller module into the chassis; you might damage the connectors.

2. Reconnect the power cables to the power supplies and to the power sources, turn on the power to start the boot process, and then press Ctrl-c.

The boot process is halted at either the Boot menu or the LOADER prompt.

Replacing N6200 series system devices 39

Checking the status of the NVMEM battery and running diagnostics

After installing a new NVMEM battery, you should run diagnostics on the NVMEM and check the status of the battery.

Procedure

1. Complete the applicable step, depending on where the node halted during the

boot process:

v If the node halted at the LOADER prompt, continue with the next step in

this procedure.

v If the node halted at the Boot menu, then perform the following steps to

reach the Loader prompt before continuing with this procedure.

a. Select the Maintenance mode option from the displayed menu. b. Enter the following command at the prompt: halt

After you issue the command, wait until the system stops at the LOADER prompt.

c. Continue with the next step in this procedure.

2. On the target node, enter the following command at the LOADER prompt:

boot_diags

Important: During the boot_diags process, you must enter y to the following question before the system will boot to Maintenance mode: WARNING: System id

mismatch. This usually occurs when replacing CF or NVRAM cards! Override system ID? {y|n} [n] y

Note: You must run this command from the LOADER prompt for system-level diagnostics to function properly. The boot_diags command starts special drivers designed specifically for system-level diagnostics.

The Maintenance mode prompt (*>) appears.

3. Enter the following command at the Maintenance mode prompt:

sldiag For details about the sldiag command, see the sldiag man page.

4. Clear the status logs by entering the following command:

sldiag device clearstatus

5. Verify that the log is cleared by entering the following command:

sldiag device status The following default response is displayed:

SLDIAG: No log messages are present.

6. Enter the following command at the prompt: sldiag device run -dev nvmem

7. View the status of the test by entering the following command:

sldiag device status Your storage system provides the following output while the tests are still running:

There are still test(s) being processed.

After all the tests are complete, the following response appears by default:

*> <SLDIAG:_ALL_TESTS_COMPLETED>

40 IBM System Storage: N6200 Series Hardware and Service Guide

8. Verify that no hardware problems resulted from the addition or replacement of

hardware components on your system by entering the following command:

sldiag device status [-dev devtype] [-name device] -long -state failed

System-level diagnostics returns you to the prompt if there are no test failures, or lists the full status of failures resulting from testing the component.

9. Proceed based on the result of the preceding step.

If the system-level diagnostics tests... Then...

Were completed without any failures

1. Clear the status logs by entering the following command:

sldiag device clearstatus

2. Verify that the log is cleared by entering the following command:

sldiag device status

The following default response is displayed:

SLDIAG: No log messages are present.

3. Exit Maintenance mode by entering the following command:

halt

4. Enter the following command at the firmware prompt to reboot the storage system:

boot

5. If your system is in an HA pair , enter the cf giveback command (7-Mode) or storage failover giveback command (Cluster-Mode) from the partner node console.

You have completed system-level diagnostics.

Replacing N6200 series system devices 41

If the system-level diagnostics tests... Then...

Resulted in some test failures Determine the cause of the problem.

1. Exit Maintenance mode by entering the

following command:

halt

After you issue the command, wait until the system stops at the LOADER prompt.

2. Turn off or leave on the power supplies,

depending on how many controller modules are in the target chassis:

v If you have two controller modules in

the chassis, leave the power supplies turned on to provide power to the partner node.

v If you have one controller module in

the chassis, turn off the power supplies and unplug them from the power sources.

3. Verify that you have observed all the

considerations identified for running system-level diagnostics, that cables are securely connected, and that hardware components are properly installed in the storage system.

4. Boot the target node, interrupting the

boot by pressing Ctrl-c:

v If you have two controller modules in

the chassis, fully seat the controller module in the chassis. The controller module boots up when fully seated.

v If you have one controller module in

the chassis, connect the power supplies and turn them on.

5. Rerun the system-level diagnostics tests.

Completing the replacement process

Return the failed part to IBM. Contact IBM Service and Support at 1-800-IBM-SERV (1-800-426-7378) for more information on the return procedure.

Disposing of batteries

Dispose of batteries according to local regulations regarding battery recycling or disposal.

About this task

For more information, see the IBM Environmental Notices and User Guide.

Replacing a system DIMM in an N6200 series system

You replace a system DIMM in the controller module when your system registers an increasing number of correctable error correction codes (ECC); failure to do so causes a system panic.

42 IBM System Storage: N6200 Series Hardware and Service Guide

About this task

v This procedure refers to HA pairs, which in releases prior to Data ONTAP 8.0

were called active/active configurations.

v All other components in the system must be functioning properly; if not, contact

technical support.

v You can use this procedure with all versions of Data ONTAP supported by your

system. A 7-Mode system refers to a system running Data ONTAP 8.x operating in 7-Mode or releases prior to Data ONTAP 8.0.

Shutting down the node

You shut down a node using different procedures, depending on whether it is a stand-alone system or part of an HA pair.

Shutting down a node in an HA pair

To shut down the node, you must determine the status of the node and, if necessary, take over the node so that the partner continues to serve data from the node's storage.

Before you begin

Note: If your system has two controller modules in the same chassis, you must leave the power supplies turned on at the end of this procedure to provide power to the partner node.

Procedure

1. Check the status of the target node (the node you want to perform maintenance

on) by entering the following command at the system console of either node:

For... Issue the command...

7-Mode cf status

Clustered Data ONTAP storage failover show

2. Take one of the following actions, depending on the result of the cf status or

storage failover command:

If... Then...

Neither node is in takeover mode Go to the next step in this procedure.

The partner node took over the target node The target node is in a state where you can

begin removing it from the system chassis.

Continue with the task "Opening the system".

The target node took over the partner node

1. Correct the problem that caused the takeover.

2. Go back to the beginning of this procedure.

3. Take over the target node by entering one of the following commands from the

partner node’s console:

For... Issue the command...

7-Mode cf takeover

Replacing N6200 series system devices 43

For... Issue the command...

Clustered Data ONTAP storage failover takeover -ofnode

target_node_name

Shutting down the node in a stand-alone system

For a node that is in a stand-alone configuration, you must perform a clean shutdown to ensure that all data has been written to disk and disconnect the power supplies.

Procedure

1. Enter the following commands from the system console:

If your system is configured in... Then issue this command...

7-Mode halt

Clustered Data ONTAP halt local

After you issue the command, wait until the system stops at the LOADER prompt.

LNK LNK

Figure 23. NVMEM LED

NVMEM LED

2. If you are not already grounded, properly ground yourself.

3. Turn off the power supplies, unplug the power cords from the power source,

and remove the power cords.

Opening the system

To access components inside the controller module, you must open the system.

44 IBM System Storage: N6200 Series Hardware and Service Guide

c0b

c0a

e0a

e0b

Procedure

1. If you are not already grounded, properly ground yourself.

2. Unplug the system cables and SFPs from the controller module, as needed, and

3. Disconnect the right and left cable management arms from the controller

module. To release the arms, press the silver button on the power supply side of each arm, and then remove the arm from the controller module.

4. Loosen the thumbscrew on the cam handle.

5. Pull the cam handle downward and slide the controller module out of the

system.

Removing the system DIMMs

To remove a system DIMM, you must perform a specific sequence of steps.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Open the CPU air duct.

3. Locate the DIMMs.

Note: Each system memory DIMM has an LED located on the board next to each DIMM slot. The LED is illuminated if the DIMM needs to be replaced.

This illustration shows a system fully populated with DIMMs:

LNK

Replacing N6200 series system devices 45

1 2

1 2 3 4

1 2

Figure 24. DIMM locations

NVMEM DIMMs 1 and 2.

Note: See “Replacing an NVMEM battery or NVMEM DIMMs in an N6200 series system” on page 30 for information about removing these two DIMMs.

System DIMMs 1 through 4.

The number of DIMMs in your system will vary.

v In N6210 and N6240, only DIMM sockets 1 and 2 are populated.

v In all other N6200 series models, all DIMM sockets are populated.

DIMM sockets.

The NVMEM DIMM sockets have white DIMM locking tabs, while the system DIMM sockets have black locking tabs.

4. Note the orientation of the DIMM in the socket so that you can insert the

replacement DIMM in the proper orientation.

5. Slowly press down simultaneously on the two DIMM ejector tabs to eject the

DIMM from its slot, and then lift it out of the slot.

46 IBM System Storage: N6200 Series Hardware and Service Guide

Figure 25. Removing DIMMs

CAUTION: The DIMMs are located very close to the CPU heat sync, which might still be hot. Avoid touching the CPU heat sync when removing the DIMM.

Attention: Carefully hold the DIMM by the edges to avoid pressure on the

components on the DIMM circuit board.

6. Repeat these steps to remove additional DIMMs as needed.

Installing the system DIMMs

To install one or more system DIMMs, you must perform a specific sequence of steps.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Locate the slot where you are installing the new DIMM.

3. Remove the replacement DIMM from the antistatic shipping bag, hold the

DIMM by the corners, and align it over the slot. The notch among the pins on the DIMM should line up with the tab in the socket.

4. Insert the DIMM straight into the slot. The DIMM fits tightly in the slot, but

should go in easily. If not, realign the DIMM with the slot and reinsert it.

Attention: Visually inspect the DIMM to verify that it is evenly aligned and fully inserted into the slot.

5. Push carefully, but firmly, on the top edge of the DIMM until the latches snap

into place over the notches at the ends of the DIMM.

6. Repeat the preceding steps to install additional DIMMs as needed.

v If you are only replacing the DIMM, plug in the battery, close the CPU air

duct, and then go to “Reinstalling the controller module and booting the system” on page 38.

v If you are replacing both the DIMMs and the NVMEM battery, continue with

the next step and the following topics.

7. Close the CPU air duct.

Reinstalling the controller module and booting the system

After you replace a component within the controller module, you must reinstall the controller module in the system chassis.

Replacing N6200 series system devices 47

About this task

section before you reinstall the controller module in an HA pair.

Procedure

1. Align the end of the controller module with the opening in the chassis, if

necessary, and then gently push the controller module halfway into the system.

2. Reinstall the cable management arms and recable the controller module, as

needed.

When recabling, remember to reinstall the media converters (SFPs) if you are using fiber cables.

3. Reinstall the controller module:

If your system is in... Then perform these steps...

An HA pair in which both controller modules are in the same chassis

A stand-alone configuration or an HA pair in which both controller modules are in separate chassis

1. Be prepared to interrupt the boot

process.

The controller module begins to boot as soon as it is fully seated in the chassis.

2. With the cam handle in the open

position, insert the controller module into the chassis, firmly pushing until the controller module meets the midplane, and then close the cam handle so that the latch clicks into the locked position and the controller module is fully seated.

Attention: Do not use excessive force when sliding the controller module into the chassis; you might damage the connectors.

3. As the system begins to boot, press Ctrl-c

to interrupt the boot process.

1. With the cam handle in the open

position, insert the controller module motherboard tray into the chassis, firmly pushing until the controller module meets the midplane, and then close the cam handle so that the latch clicks into the locked position and the controller module is fully seated.

Attention: Do not use excessive force when sliding the controller module into the chassis; you might damage the connectors.

2. Reconnect the power cables to the power

supplies and to the power sources, turn on the power to start the boot process, and then press Ctrl-c.

The boot process is halted at either the Boot menu or the LOADER prompt.

Running diagnostics on the system DIMM

After installing a new system DIMM, you should run diagnostics.

48 IBM System Storage: N6200 Series Hardware and Service Guide

Procedure

1. Complete the applicable step, depending on where the node halted during the

boot process:

v If the node halted at the Loader prompt, continue with the next step in this

procedure.

v If the node halted at the Boot menu, then perform the following steps to

reach the Loader prompt before continuing with this procedure.

a. Select the Maintenance mode option from the displayed menu. b. Enter the following command at the prompt: halt

After you issue the command, wait until the system stops at the LOADER prompt.

c. Continue with the next step in this procedure.

2. On the target node, enter the following command at the LOADER prompt:

boot_diags

Important: During the boot_diags process, you must enter y to the following question before the system will boot to Maintenance mode: WARNING: System id

mismatch. This usually occurs when replacing CF or NVRAM cards! Override system ID? {y|n} [n] y

The Maintenance mode prompt (*>) appears.

3. Enter the following command at the Maintenance mode prompt:

sldiag For details about the sldiag command, see the sldiag man page.

4. Clear the status logs by entering the following command:

sldiag device clearstatus

5. Verify that the log is cleared by entering the following command:

sldiag device status

The following default response is displayed:

SLDIAG: No log messages are present.

6. Check the status of the system memory by entering the following command at

the prompt, depending on which DIMM was replaced:

If the DIMM that was replaced was the... Then issue this command...

NVMEM DIMM sldiag device run -dev nvmem

System DIMM sldiag device run -dev mem

7. View the status of the test by entering the following command: sldiag device status Your storage system provides the following output while the tests are

still running:

There are still test(s) being processed.

After all the tests are complete, the following response appears by default:

Replacing N6200 series system devices 49

*> <SLDIAG:_ALL_TESTS_COMPLETED>

8. Verify that no hardware problems resulted from the addition or replacement of

hardware components on your system by entering the following command:

sldiag device status [-dev devtype] [-name device] -long -state failed

System-level diagnostics returns you to the prompt if there are no test failures, or lists the full status of failures resulting from testing the component.

9. Proceed based on the result of the preceding step.

If the system-level diagnostics tests... Then...

Were completed without any failures

1. Clear the status logs by entering the

following command:

sldiag device clearstatus

2. Verify that the log is cleared by entering

the following command:

sldiag device status

The following default response is displayed:

SLDIAG: No log messages are present.

3. Exit Maintenance mode by entering the

following command:

halt

4. Enter the following command at the

firmware prompt to reboot the storage system:

boot

5. If your system is in an HA pair, enter the

cf giveback command (7-Mode) or storage failover giveback command

(Clustered Data ONTAP) from the partner node console.

50 IBM System Storage: N6200 Series Hardware and Service Guide

You have completed system-level diagnostics.

If the system-level diagnostics tests... Then...

Resulted in some test failures Determine the cause of the problem.

1. Exit Maintenance mode by entering the

following command:

halt

After you issue the command, wait until the system stops at the LOADER prompt.

2. Turn off or leave on the power supplies,

depending on how many controller modules are in the target chassis:

v If you have two controller modules in

the chassis, leave the power supplies turned on to provide power to the partner node.

v If you have one controller module in

the chassis, turn off the power supplies and unplug them from the power sources.

3. Verify that you have observed all the

considerations identified for running system-level diagnostics, that cables are securely connected, and that hardware components are properly installed in the storage system.

4. Boot the target node, interrupting the

boot by pressing Ctrl-c:

v If you have two controller modules in

the chassis, fully seat the controller module in the chassis. The controller module boots up when fully seated.

v If you have one controller module in

the chassis, connect the power supplies and turn them on.

5. Rerun the system-level diagnostics tests.

What to do next

See the IBM System Storage N series System-Level Diagnostics Guide for more information on running diagnostics.

Completing the replacement process

Return the failed part to IBM. Contact IBM Service and Support at 1-800-IBM-SERV (1-800-426-7378) for more information on the return procedure.

Replacing PCIe cards in an N6200 series system

To replace a PCIe card or riser in the system, you must perform a specific sequence of tasks.

Replacing N6200 series system devices 51

About this task

Note: If you are replacing or installing a Performance Acceleration Module (PAM) or Flash Cache module, refer to the "Installing or replacing a Flash Cache module or PAM" appendix in the IBM System Storage N series Introduction and Planning Guide.

v This procedure refers to HA pairs, which in releases prior to Data ONTAP 8.0

were called active/active configurations.

v All other components in the system must be functioning properly; if not, contact

technical support.

Shutting down the node

You shut down a node using different procedures, depending on whether it is a stand-alone system or part of an HA pair.

Shutting down a node in an HA pair

To shut down the node, you must determine the status of the node and, if necessary, take over the node so that the partner continues to serve data from the node's storage.

Before you begin

Note: If your system has two controller modules in the same chassis, you must leave the power supplies turned on at the end of this procedure to provide power to the partner node.

Procedure

1. Check the status of the target node (the node you want to perform maintenance

on) by entering the following command at the system console of either node:

For... Issue the command...

7-Mode cf status

Clustered Data ONTAP storage failover show

2. Take one of the following actions, depending on the result of the cf status or

storage failover command:

If... Then...

Neither node is in takeover mode Go to the next step in this procedure.

The partner node took over the target node The target node is in a state where you can

begin removing it from the system chassis.

Continue with the task "Opening the system".

The target node took over the partner node

1. Correct the problem that caused the

takeover.

2. Enter the cf giveback command (7-Mode) or storage failover giveback

-fromnode nodename command (Clustered Data ONTAP) from the target node console.

3. Go back to the beginning of this procedure.

52 IBM System Storage: N6200 Series Hardware and Service Guide

3. Take over the target node by entering one of the following commands from the

partner node’s console:

For... Issue the command...

7-Mode cf takeover

Clustered Data ONTAP storage failover takeover -bynode node

Shutting down the node in a stand-alone system

For a node that is in a stand-alone configuration, you must perform a clean shutdown to ensure that all data has been written to disk and disconnect the power supplies.

Procedure

1. Enter the following commands from the system console:

If your system is configured in... Then issue this command...

7-Mode halt

Clustered Data ONTAP halt local

After you issue the command, wait until the system stops at the LOADER prompt.

LNK LNK

c0a

c0b

e0a

e0b

Figure 26. NVMEM LED

NVMEM LED

2. If you are not already grounded, properly ground yourself.

3. Turn off the power supplies, unplug the power cords from the power source,

and remove the power cords.

Replacing N6200 series system devices 53

Opening the system

To access components inside the controller module, you must open the system.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Unplug the system cables and SFPs from the controller module, as needed, and

3. Disconnect the right and left cable management arms from the controller

module. To release the arms, press the silver button on the power supply side of each arm, and then remove the arm from the controller module.

4. Loosen the thumbscrew on the cam handle.

5. Pull the cam handle downward and slide the controller module out of the

system.

Removing a PCIe card

To remove a PCIe card from the system, you must perform a specific sequence of steps.

Procedure

1. Loosen the thumbscrew on the controller module side panel.

2. Swing the side panel open until it comes off the controller module.

LNK

54 IBM System Storage: N6200 Series Hardware and Service Guide

Figure 27. Removing the PCI card

Controller module side panel with thumbscrew

Controller module PCIe card

3. Remove the PCIe card from the controller module and set it aside.

4. Repeat the preceding steps as needed.

Installing a PCIe card

To install a PCIe card in the system, you must perform a specific sequence of steps.

Procedure

1. Open the controller module side panel, if necessary, slide off the PCIe card

filler plate, as needed, and install the PCIe card. Be sure that you properly align the card in the slot and exert even pressure on the card when seating it in the socket. The adapter must be fully and evenly seated in the slot.

Note: If you are installing a card in the bottom slot and cannot see the card socket well, remove the top card so that you can see the card socket, install the card, and the reinstall the card you removed from the top slot.

2. Repeat the preceding step as needed for additional cards.

3. Close the side panel and tighten the thumbscrew.

Replacing N6200 series system devices 55

Reinstalling the controller module and booting the system

After you replace a component within the controller module, you must reinstall the controller module in the system chassis.

About this task

section before you reinstall the controller module in an HA pair.

Procedure

1. Align the end of the controller module with the opening in the chassis, if

necessary, and then gently push the controller module halfway into the system.

2. Reinstall the cable management arms and recable the controller module, as

needed.

When recabling, remember to reinstall the media converters (SFPs) if you are using fiber cables.

3. Reinstall the controller module:

If your system is in... Then perform these steps...

An HA pair in which both controller modules are in the same chassis

A stand-alone configuration or an HA pair in which both controller modules are in separate chassis

1. Be prepared to interrupt the boot process.

The controller module begins to boot as soon as it is fully seated in the chassis.

Attention: Do not use excessive force when sliding the controller module into the chassis; you might damage the connectors.

3. As the system begins to boot, press Ctrl-c to interrupt the boot process.

Attention: Do not use excessive force when sliding the controller module into the chassis; you might damage the connectors.

2. Reconnect the power cables to the power supplies and to the power sources, turn on the power to start the boot process, and then press Ctrl-c.

56 IBM System Storage: N6200 Series Hardware and Service Guide

The boot process is halted at either the Boot menu or the LOADER prompt.

Running diagnostics on a PCIe card

After installing a PCIe card, you should run diagnostics.

About this task

Before running diagnostics tests on your PCIe card you need to have it cabled according to the following guidelines:

v NIC interfaces must be cabled in a pair-wise manner, with adjacent ports

connected together or connected through a switch. Enter sldiag device show and then connect the ports to each other, based on the order in which the port names appear on the console. Do not connect ports e0M and e0P together, because of the internal switch connection.

Note: On N6200 series systems, the e0M port is the management port (labelled with a wrench icon) and the e0P port is the private management port (labelled with a wrench and padlock icon).

v SAS card ports must be connected to storage or connected to the adjacent SAS

ports. If the SAS cards or systems with more than 2 ports are not connected to storage, connect ports A to B, C to D, and so forth.

v The FC card ports must be connected to storage or the ports terminated with

loopback plugs.

Procedure

1. Complete the applicable step, depending on where the node halted during the

boot process:

v If the node halted at the Loader prompt, continue with the next step in this

procedure.

v If the node halted at the Boot menu, then perform the following steps to

reach the Loader prompt before continuing with this procedure.

a. Select the Maintenance mode option from the displayed menu. b. Enter the following command at the prompt: halt

c. Continue with the next step in this procedure.

2. On the target node, enter the following command at the LOADER prompt:

boot_diags

Important: During the boot_diags process, you must enter y to the following question before the system will boot to Maintenance mode: WARNING: System

id mismatch. This usually occurs when replacing CF or NVRAM cards! Override system ID? {y|n} [n] y

The Maintenance mode prompt (*>) appears.

3. Enter the following command at the Maintenance mode prompt:

sldiag For details about the sldiag command, see the sldiag man page.

4. Clear the status logs by entering the following command:

Replacing N6200 series system devices 57

sldiag device clearstatus

5. Verify that the log is cleared by entering the following command:

sldiag device status

The following default response is displayed:

SLDIAG: No log messages are present.

6. View the types of devices available for checking by entering the following

command:

sldiag device show

7. Run the test for the type of PCIe card you installed by entering the following

command at the Maintenance mode prompt:

sldiag device run -dev fcal|sas|ata|nic|toe

Note: See the IBM System Storage N series System-Level Diagnostics Guide for a description of other types of tests you can run.

8. View the status of the test by entering the following command: sldiag device status Your storage system provides the following output while the tests are

still running:

There are still test(s) being processed.

After all the tests are complete, the following response appears by default:

*> <SLDIAG:_ALL_TESTS_COMPLETED>

9. Verify that no hardware problems resulted from the addition or replacement of hardware components on your system by entering the following command:

sldiag device status [-dev devtype] [-name device] -long -state failed

System-level diagnostics returns you to the prompt if there are no test failures, or lists the full status of failures resulting from testing the component.

10. Proceed based on the result of the preceding step.

58 IBM System Storage: N6200 Series Hardware and Service Guide

If the system-level diagnostics tests... Then...

Were completed without any failures

1. Clear the status logs by entering the

following command:

sldiag device clearstatus

2. Verify that the log is cleared by entering

the following command:

sldiag device status

The following default response is displayed:

3. Exit Maintenance mode by entering the

following command:

halt

4. Enter the following command at the

firmware prompt to reboot the storage system:

boot

5. If your system is in an HA pair , run the

cf giveback command (Data ONTAP 7-Mode) or the storage failover giveback command (Clustered Data ONTAP) from the partner node console.

SLDIAG: No log messages are present.

You have completed system-level diagnostics.

Resulted in some test failures Determine the cause of the problem.

1. Exit Maintenance mode by entering the

2. Perform a clean shutdown and

3. Verify that you have observed all the

4. Reconnect the power supplies and power

5. Rerun the system-level diagnostics tests.

Completing the replacement process

Return the failed part to IBM. Contact IBM Service and Support at 1-800-IBM-SERV (1-800-426-7378) for more information on the return procedure.

following command:

halt

disconnect the power supplies.

considerations identified for running system-level diagnostics, that cables are securely connected, and that hardware components are properly installed in the storage system.

on the storage system.

Replacing a boot device in an N6200 series system running Data ONTAP 7.3.5 and later releases in the Data ONTAP 7.3 release family

The boot device stores a primary and secondary set of system files on it (also called the boot image) that the system uses when it boots. To replace the boot device, you must complete a specific sequence of tasks.

Replacing N6200 series system devices 59

About this task

v You can use this procedure only with systems running Data ONTAP 7.3.5 and

later releases in the Data ONTAP 7.3 release family. Do not use it for systems running Data ONTAP 8.0 or later.

v The term boot device refers to the USB boot media.

Shutting down a node

When replacing the boot device in a system running Data ONTAP 7.3.5 or later in the 7.3 release family, you should shut down the system.

About this task

If your system has:

v Two controller modules in the same chassis, you must leave the power supplies

turned on to provide power to the partner node.

v One controller module in the chassis, but is part of an HA pair or in a

stand-alone configuration, you should turn off the power supplies in the target node chassis.

Procedure

1. Shut down the system or node.

If the system is in... Then...

A stand-alone configuration and is running

A stand-alone configuration and is not running

An HA pair

1. Enter the following command at the

console:

halt -t 0

2. Go to the next step.

Go to the next step.

1. Check the status of the target node by

entering the following command at the console:

cf status

2. Take one of the following actions,

depending on the result of cf status command:

v If the target node is not running or has

been taken over by the partner node, go to the next step.

v If the target node has not been taken

over by the partner node and is running, enter the following command, and then go to the next step:

cf takeover

2. If applicable, turn off the power supplies, unplug both power cords from the

power source and then remove the power cords.

Opening the system

To access components inside the controller module, you must open the system.

60 IBM System Storage: N6200 Series Hardware and Service Guide

Procedure

1. If you are not already grounded, properly ground yourself.

2. Unplug the system cables and SFPs from the controller module, as needed, and

3. Disconnect the right and left cable management arms from the controller

module. To release the arms, press the silver button on the power supply side of each arm, and then remove the arm from the controller module.

LNK

4. Loosen the thumbscrew on the cam handle.

5. Pull the cam handle downward and slide the controller module out of the

system.

Removing the boot device from the controller

You must physically remove the old or failed boot device from the target controller in your system prior to installing the new or replacement boot device.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Remove the controller module and turn it so that you can see where the boot

device is located. Use the FRU map on the controller module or the following illustration to help you locate the boot device enclosure.

Replacing N6200 series system devices 61

Figure 28. Removing the boot device

Boot device cover

Boot device

3. Open the boot device cover and gently lift the boot device out of the housing.

4. Set the boot device aside.

Installing the boot device and transferring system files to the boot device

You can transfer the system files and restore configuration information to your system by using netboot to boot the system and performing a software update to copy the system files to the replacement boot device.

Before you begin

For copying system files to the boot device, you must have the following:

v The blank replacement boot device you received from your provider.

v Access to an HTTP server.

v The same version of Data ONTAP on both nodes in active/active

configurations.

62 IBM System Storage: N6200 Series Hardware and Service Guide

v Access to the IBM N series support website, which is accessed and navigated as

described in “Websites” on page xxii.

This enables you to download the necessary system files for your platform and version of Data ONTAP running on it.

v A copy of the Data ONTAP 7.3 Upgrade Guide, available on the IBM N series

support website.

Procedure

1. If your system is in an active/active configuration, check the version of Data

ONTAP you are running by entering the following command on the partner's console: version

2. Copy the boot image ( <release>_netboot.q) and software image ( <release>_setup_q.exe) from the IBM N series support website, which is

accessed and navigated as described in “Websites” on page xxii, to a web-accessible directory. On the IBM N series support website, the Data ONTAP Matrix provides a current list and history of Data ONTAP releases available by release family and supported storage systems.

3. If you are not already grounded, properly ground yourself.

4. Turn the controller module so that you can locate the boot device enclosure.

Use the FRU map on the controller module to help you locate the boot device enclosure.

5. Lift the boot device cover, if applicable.

6. Align the boot device with the boot device socket or connector, and then

firmly push it into the socket or connector.

7. Check the boot device to make sure that it is seated squarely and completely in the socket or connector, and reseat the boot device, if necessary.

8. Close the boot device cover.

9. Align the end of the controller module with the opening in the chassis, and

then gently push the controller module halfway into the system.

10. Reinstall the cable management arms and recable the system, as needed.

When recabling, remember to reinstall the media converters (SFPs) if you are using fiber cables.

11. Push the controller module all the way into the system, firmly push the cam

handle to finish seating it, push the cam handle to the closed position, and then tighten the thumbscrew.

12. Enter one of the following commands at the firmware prompt:

v If you are configuring DHCP, enter the following command: ifconfig e0a

-auto

v If you are configuring manual connections, enter the following command:

ifconfig e0a -addr=filer_addr -mask=netmask -gw=gateway -dns=dns_addr

-domain=dns_domain

filer_addr is the IP address of the storage system.

netmask is the network mask of the storage system.

gateway is the gateway for the storage system.

dns_addr is the IP address of a name server on your network.

dns_domain is the Domain Name System (DNS) domain name. If you use this

optional parameter, you do not need a fully qualified domain name in the netboot server URL; you need only the server's host name.

Replacing N6200 series system devices 63

Note: Other parameters might be necessary for your interface. Enter help ifconfig at the firmware prompt for details.

13. At the firmware prompt, enter the following command:

netboot http://path_to_the_web-accessible_directory/ <release>_netboot.q The system begins to boot, but stops at the Boot menu.

14. Select the Normal Boot option from the displayed menu.

Please choose one of the following:

1) Normal Boot

2) Boot without /etc/rc

3) Change Password

4) Initialize all disks 4a) Same as option 4, but create a flexible root volume

5) Maintenance mode boot

Selection (1-5)? 1

15. The next step depends on your system configuration.

If your system is in... Then...

A stand-alone configuration Go to the next step.

An active/active configuration Give back the node after the boot process is

complete by entering the following command from the partner console:

cf giveback

16. Copy and install the image from your HTTP server by entering the following

command:

software update http://path_to_the_web-accessible_directory/ <release>_setup_q.exe -r

17. Reapply any BIOS or firmware service images that were previously installed

on the node by entering the following commands and noting the displayed information:

version -b sysconfig

18. Verify that the correct BIOS or firmware service images are installed.

If your system is in... Then...

A stand-alone configuration Use the most current versions available for

your system.

An active/active configuration Compare the displayed versions from the

target node with the versions installed on the partner node. If the versions are not the same, update that target node by installing the same version of files on the target node from any applicable service images available from the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii.

19. The next step depends on your system configuration.

64 IBM System Storage: N6200 Series Hardware and Service Guide

If your system is in... Then...

A stand-alone configuration Reboot your system by entering the

following command:

reboot

An active/active configuration Complete the following substeps:

1. If the system is in use, enter the

following command from the partner node; otherwise, go to the next step:

cifs terminate -t nn

Note: CIFS automatically restarts when the node is rebooted during the takeover and giveback process.

2. From the partner node's console, enter

the following command:

cf takeover

3. Give back the target node by entering

the following command:

cf giveback

Note: if the system is in use, wait for at least eight minutes to allow host multipathing software to stabilize before entering the cf giveback command.

Completing the replacement process

Return the failed part to IBM. Contact IBM Service and Support at 1-800-IBM-SERV (1-800-426-7378) for more information on the return procedure.

Replacing a boot device in an N6200 series system running Data ONTAP 8.x

Before you begin

Before extracting the compressed system files during the boot device installation process, make sure that the utility you use is set to suppress any automatic CR/LF conversions in the extracted files.

If you experience any problems during netboot, you can verify the integrity of the files extracted from the package by comparing the md5sum values stored in the MD5SUMS file.

About this task

v You must replace the failed component with a replacement FRU component you

received from your provider.

v The steps for replacing a boot device in a system running 7-Mode are different

than for a system running Clustered Data ONTAP. You must use the correct procedure for your version of Data ONTAP.

v The term boot device refers to the USB boot media.

Replacing N6200 series system devices 65

v This procedure refers to HA pairs, which in releases prior to Data ONTAP 8.0

were called active/active configurations.

v Cluster-Mode refers to a system running Clustered Data ONTAP.

v 7-Mode refers to a system running Data ONTAP in 7-Mode.

Replacing a boot device in a system running Data ONTAP 7-Mode

Replacing a boot device in a 7-Mode system involves shutting down the node, removing the old boot device, and transferring the system files to the new boot device.

Shutting down a node

When replacing the boot device in a system running Data ONTAP 7-Mode, you should shut down the system. Depending on your system's configuration, you might also need to turn off the power supplies.

Procedure

1. Shut down the system or node.

If the system is in... Then...

A stand-alone configuration and is running

A stand-alone configuration and is not running

An HA pair

1. Enter the following command at the

console: halt -t 0

2. Go to the next step.

Go to the next step.

1. Check the status of the target node by

entering the following command at the console: cf status

2. Take one of the following actions,

depending on the result of cf status command:

v If the target node is not running or has

been taken over by the partner node, go to the next step.

v If the target node took over the

partner node, give back the partner node using the cf giveback command from the target node, initiate the takeover from the partner node using the cf takeover command, and then go to the next step.

v If the target node has not been taken

over by the partner node and is running, enter the following command, and then go to the next step: cf takeover

2. If you are replacing a device in a stand-alone system, or if you are replacing a

device in one enclosure of a dual-enclosure HA pair, turn off the power supplies in the enclosure, unplug the power cords from the power source, and then remove the power cords from the power supplies. If you are replacing a device in a single-enclosure HA pair, do not remove power from the enclosure.

66 IBM System Storage: N6200 Series Hardware and Service Guide

Opening the system

To access components inside the controller module, you must open the system.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Unplug the system cables and SFPs from the controller module, as needed, and

3. Disconnect the right and left cable management arms from the controller

module. To release the arms, press the silver button on the power supply side of each arm, and then remove the arm from the controller module.

LNK

4. Loosen the thumbscrew on the cam handle.

5. Pull the cam handle downward and slide the controller module out of the

system.

Removing the boot device from the controller

You must physically remove the old or failed boot device from the target controller in your system prior to installing the new or replacement boot device.

Procedure

1. If you are not already grounded, properly ground yourself.

2. Remove the controller module and turn it so that you can see where the boot

device is located. Use the FRU map on the controller module or the following illustration to help you locate the boot device enclosure.

Replacing N6200 series system devices 67

Figure 29. Removing the boot device

Boot device cover

Boot device

3. Open the boot device cover and gently lift the boot device out of the housing.

4. Set the boot device aside.

Installing the boot device in a system running in 7-Mode

After you remove the old boot device, you must transfer system files and restore configuration information to your replacement boot device using one of several methods.

Before you begin

Note: For systems running in 7-Mode, it is advised to use the nondisruptive procedure for HA configurations running Data ONTAP 8.0.1 and later.

v “Installing the boot device and transferring system files nondisruptively using

netboot in systems running Data ONTAP 8.0.x or 8.1 for 7-Mode” on page 69

v “Installing the boot device and transferring system files nondisruptively using

netboot in systems running Data ONTAP 8.1.1 for 7-Mode” on page 71

v “Installing the boot device and transferring system files disruptively using

netboot in a 7-Mode system” on page 74

68 IBM System Storage: N6200 Series Hardware and Service Guide

Installing the boot device and transferring system files nondisruptively using netboot in systems running Data ONTAP 8.0.x or 8.1 for 7-Mode:

You can nondisruptively transfer the system files and restore configuration information to your HA configuration by using netboot and a the partner node.

Before you begin

Important: This nondisruptive procedure can only be used in an system in an HA

configuration that is running Data ONTAP 8.0.1.

For copying system files to the boot device, you must have the following:

v The blank replacement boot device you received from your provider.

v A network interface to the HA pair partner node.

v A separate IP address to use to netboot the target node.

About this task

The following procedure is written with the assumption that the target node has been take over by the partner node and that the target node has booted to the firmware prompt after the takeover has completed.

Procedure

1. Download and extract the netboot.tgz file from the IBM N series support website, which is accessed and navigated as described in “Websites” on page xxii. This file is used for performing a netboot of your system. Download the file contents to a web-accessible directory. To download the file, complete the following substeps:

a. Download the netboot.tgz file from the IBM N series support website to

the web-accessible directory.

b. Change to the web-accessible directory. c. Extract the contents of the netboot.tgz file to the target directory by

entering the following command: tar -zxvf netboot.tgz

Your directory listing should contain the following directory:

netboot/

2. Download the image.tgz file from the IBM N series support website to the web-accessible directory. Your directory listing should contain the following file and directory:

image.tgz netboot/

3. If you are not already grounded, properly ground yourself.

4. Turn the controller module so that you can locate the boot device enclosure.

Use the FRU map on the controller module to help you locate the boot device enclosure.

5. Open the boot device cover, if applicable.

6. Align the boot device with the boot device socket or connector, and then

firmly push it into the socket or connector.

7. Check the boot device to make sure that it is seated squarely and completely in the socket or connector, and reseat the boot device, if necessary.

Replacing N6200 series system devices 69

8. Close the boot device cover.

9. Align the end of the controller module with the opening in the chassis, and

then gently push the controller module halfway into the system.

10. Reinstall the cable management arms and recable the system, as needed.

When recabling, remember to reinstall the media converters (SFPs) if you are using fiber cables.

11. Push the controller module all the way into the system, firmly pushing the

cam handle to finish seating it, push the cam handle to the closed position and then tighten the thumbscrew. The node reboots and stops at the firmware prompt as soon as you seat the controller module completely into the system.

12. The next step depends on your system configuration:

If your system has... Then...

One controller module in the chassis Reconnect the power cables to the power

supplies and to the power sources, and then turn on the power.

Two controller modules in the chassis The node already began rebooting; go to the

next step.

13. Set up the TFTP server on the partner node by entering the following

commands on the partner node console:

a. partner options tftpd.enable off b. partner options tftpd.rootdir /etc c. partner options tftpd.enable on

14. Enter one of the following commands at the firmware prompt:

v If you are configuring DHCP, enter the following command: ifconfig e0a

-auto

v If you are configuring manual connections, enter the following command:

ifconfig e0a -addr=filer_addr -mask=netmask -gw=gateway -dns=dns_addr

-domain=dns_domain

filer_addr is the IP address of the storage system.

netmask is the network mask of the storage system.

gateway is the gateway for the storage system.

dns_addr is the IP address of a name server on your network.

dns_domain is the Domain Name System (DNS) domain name. If you use this

optional parameter, you do not need a fully qualified domain name in the netboot server URL; you need only the server's host name.

Note: To netboot the node when your system is running in 7-Mode, use an IP address that is not the management IP address for the target.

Note: Other parameters might be necessary for your interface. Enter help ifconfig at the firmware prompt for details.

15. At the firmware prompt, enter the following command: netboot http://path_to_web-accessible_directory/netboot/kernel

16. Select the Install new software first option from the displayed menu. This menu option downloads and installs the new Data ONTAP image to the boot device. If you are prompted to continue the procedure, enter y when prompted.

17. Enter y when you see the following prompt:

70 IBM System Storage: N6200 Series Hardware and Service Guide

This procedure is not supported for Non-Disruptive Upgrade on an HA pair. Do you want to continue? [y|no]y

18. Enter the path to the image.tgz when you see the following prompt:

What is the URL for the package? http://path_to_web-accessible_directory/image.tgz

19. Restore the backup configuration by entering y and then entering the IP

address of the server containing the varfs.tgz file when you see the following screen:

**************************************************************** * Restore Backup Configuration * * This procedure only applies to storage controllers that * * are configures as an HA pair. * ** * Choose Yes to restore the "varfs" backup configuration * * from the TFTP server. Refer to the Boot Device Replacement * * guide for more details. * * Choose No to skip the backup and recovery and return to the * * boot menu. * ****************************************************************

Do you want to restore the backup configuration now? {y|n} y

Enter the IP address of the server: target_node.management_IP.address Checking network link... success. Checking route to host "target_node.management_IP.address"... success. Attempting to reach "target_node.management_IP.address"... success. Checking boot device file system... success. Mounting boot device to /tmp/mnt... success. Checking boot device mount point... success. Restoring backup configuration... Received 82481 bytes in 0.1 seconds

Backup Configuration successfully restored

20. Reboot the target node by entering y when you see the following prompt:

The node must be rebooted to start using the newly installed software. Do you want to reboot now? {y|n} y

21. While the target node is rebooting, restore the tftp settings on the partner

node by entering the following commands from the partner node console:

a. partner options tftpd.enable off b. partner options tftpd.rootdir /etc/tftpboot

22. Reboot the target node by entering the following command on the target node

console: boot_ontap

23. Once the target node has rebooted, complete the procedure by entering the

following command on the partner node's console: cf giveback

Installing the boot device and transferring system files nondisruptively using netboot in systems running Data ONTAP 8.1.1 for 7-Mode:

You can nondisruptively transfer the system files and restore configuration information to your HA configuration by using netboot and a the partner node.

Before you begin

Important: This nondisruptive procedure can only be used in an system in an HA

configuration that is running Data ONTAP 8.0.1.

Replacing N6200 series system devices 71

For copying system files to the boot device, you must have the following:

v You must have the blank replacement boot device you received from your

provider

v You must have a network interface to the HA pair partner node

v You must have a separate IP address to use to netboot the target node

About this task

Procedure

1. Download and extract the netboot.tgz file from the IBM N series support

website, which is accessed and navigated as described in “Websites” on page xxii. This file is used for performing a netboot of your system. Download the file contents to a web-accessible directory. To download the file, complete the following substeps:

a. Download the netboot.tgz file from the IBM N series support site to the

web-accessible directory.

b. Change to the web-accessible directory. c. Extract the contents of the netboot.tgz file to the target directory by

entering the following command:tar -zxvf netboot.tgz

Your directory listing should contain the following directory:

netboot/

2. Download the image.tgz file from the IBM N series support website to the

web-accessible directory. Your directory listing should contain the following file and directory:

image.tgz netboot/

3. If you are not already grounded, properly ground yourself.

4. Turn the controller module so that you can locate the boot device enclosure.

Use the FRU map on the controller module to help you locate the boot device enclosure.

5. Open the boot device cover, if applicable.

6. Align the boot device with the boot device socket or connector, and then

firmly push it into the socket or connector.

7. Check the boot device to make sure that it is seated squarely and completely

in the socket or connector, and reseat the boot device, if necessary.

8. Close the boot device cover.

9. Align the end of the controller module with the opening in the chassis, and

then gently push the controller module halfway into the system.

10. Reinstall the cable management arms and recable the system, as needed.

When recabling, remember to reinstall the media converters (SFPs) if you are using fiber cables.

11. Push the controller module all the way into the system, firmly pushing the

cam handle to finish seating it, push the cam handle to the closed position and then tighten the thumbscrew.

72 IBM System Storage: N6200 Series Hardware and Service Guide

12. The next step depends on your system configuration:

If your system has... Then...

One controller module in the chassis Reconnect the power cables to the power

supplies and to the power sources, and then turn on the power.

Two controller modules in the chassis The node already began rebooting; go to the

next step.

13. Enter one of the following commands at the firmware prompt:

v If you are configuring DHCP, enter the following command: ifconfig e0a

-auto

v If you are configuring manual connections, enter the following command:

ifconfig e0a -addr=filer_addr -mask=netmask -gw=gateway -dns=dns_addr

-domain=dns_domain

filer_addr is the IP address of the storage system.

netmask is the network mask of the storage system.

gateway is the gateway for the storage system.

dns_addr is the IP address of a name server on your network.

dns_domain is the Domain Name System (DNS) domain name. If you use this

optional parameter, you do not need a fully qualified domain name in the netboot server URL; you need only the server's host name.

Note: To netboot the node when your system is running in 7-Mode, use an IP address that is not the management IP address for the target.

Note: Other parameters might be necessary for your interface. Enter help ifconfig at the firmware prompt for details.

14. At the firmware prompt, enter the following command: netboot http://path_to_web-accessible_directory/netboot/kernel

15. Select the Install new software first option from the displayed menu. This menu option downloads and installs the new Data ONTAP image to the boot device. If you are prompted to continue the procedure, enter y when prompted.

16. Enter y when you see the following prompt:

This procedure is not supported for Non-Disruptive Upgrade on an HA pair. Do you want to continue? [y|no]y

17. Enter the path to the image.tgz when you see the following prompt:

What is the URL for the package? http://path_to_web-accessible_directory/image.tgz

18. Restore the backup configuration by entering y and then entering the IP address of the server containing the varfs.tgz file when you see the following screen:

Replacing N6200 series system devices 73

**************************************************************** * Restore Backup Configuration * * This procedure only applies to storage controllers that * * are configures as an HA pair. * ** * Choose Yes to restore the "varfs" backup configuration * * from the SSH server. Refer to the Boot Device Replacement * * guide for more details. * * Choose No to skip the backup and recovery and return to the * * boot menu. * ****************************************************************

Do you want to restore the backup configuration now? {y|n} y

Start the restore_backup procedure on this node’s HA partner. The restore configuration has been copied from the HA partner to this node, would you like to use this restored copy now? {y|n}

19. Copy the varfs.tgz file from the HA partner node to the target node by

entering the following command from the partner node console:

restore_backup target_node.netboot_IP.address

Use the same IP address that was assigned to the target node and used for the netboot command.

20. Finish the restore backup on the target node by entering y when you see the

following screen:

The restore configuration has been copied from the HA partner to this node, would you like to use this restored copy now? {y|n} y CF device: /dev/ad0 found... Checking /dev/ad0s1 file system... success. Mounting /dev/ad0s1 to /cfcard... success. Checking /cfcard/x86/freebsd mount point... success. Restoring backup configuration...

21. Reboot the target node by entering the following command on the target node

console: boot_ontap

22. After the target node has rebooted and is displaying the Waiting for giveback message, complete the procedure by entering the following command on the partner node's console: cf giveback

Installing the boot device and transferring system files disruptively using netboot in a 7-Mode system:

You can transfer the system files and restore configuration information to your system by using netboot to copy the system files to the replacement boot device.

Before you begin

Important: This procedure is disruptive, even when using it with a system in an

HA configuration. You may experience a service outage or possible data loss during the procedure. IBM recommends using the nondisruptive procedure for HA configurations running Data ONTAP 8.0.1 and later in 7-Mode.

For copying system files to the boot device, you must have the following:

v The blank replacement boot device you received from your provider.

v Access to an HTTP server.

74 IBM System Storage: N6200 Series Hardware and Service Guide

IBM N6270, N6240, N6220, N6250, N6210 Hardware And Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety notices

Safety notices and labels

Laser safety

Rack safety

Handling fiber-optic cables

Fire suppression systems

Contents

Figures

Tables

About this document

Who should read this document

Related documents

Supported features

Websites
